Dahua 7-inch Touch Screen IP Intercom Kit is the modern doorbell for your home or office. Receive notifications on your Dahua's official DMSS app when visitors press the door station. You can also view on your 7-inch IPC indoor monitor which can be beautifully hanged in your living room. This kits come with rain shade for your outdoor station to protect from different weather for durability. This is the IP video intercoms and cabling can be done by using RJ45 ethernet cables.
1 x 7-inch Monitor DHI-VTH2621GW-P1 x Outdoor Station DHI-VTO2202F-P-S21 x Uniarch 8 Port PoE Switch with Power Supply, SW-2110-P1 x Surface Mount Bracket DH-AC-VTM05R
1 x 7-inch Monitor DHI-VTH2621GW-PDahua IP Indoor Monitor White, 7" TFT capacitive touch screen, 1024 × 600, 6-channel alarm input and 1-channel alarm output, Standard PoE, Outdoor station and IPC monitor, H.265 and H.264 video coding, High performance & cost-effective
7'' TFT capacitive touch screen, 1024 x 600
6-channel alarm input and 1-channel alarm output
Standard PoE
Outdoor station and IPC monitor
H.265 and H.264 video coding
High performance & cost-effective
1 x Outdoor Station DHI-VTO2202F-P-S2Dahua 2-wire IP Villa Door Station comes with both 2-wire and ethernet port
Anodised aluminium front panel
CMOS low illumination 2MP HD colourful 160° fisheye camera
Video intercom function
Access control function that supports two locks
Mobile phone app, talk to the visitor or unlock the door remotely on
Compatible with 2-wire interface & RJ45 interface
IK07 & IP65
Support H.265
Support surface and flush mount
PoE
1 x Uniarch 8 Port PoE Switch with Power Supply, SW-2110-PUniarch switch, 10 x 100Mbps network ports, including 8 PoE/PoE+ ports, 2 x 100Mbps uplink ports, Max capacity for single port 30W, total capacity 120W, up to 250m transmission distance, all-metal housing
Multiple working modes to address your business needs: Normal, Secure and Surveillance
Support port traffic control
Support for secure mode, all downlink ports can communicate only with uplink ports
Up to 250m transmission distance on surveillance mode
Support buffer optimization
All-metal housing, safe and reliable
1 x Surface Mount Bracket DH-AC-VTM05R
Dahua 4MP WizSense Fixed Starlight Turret, 2.8mm, Perimeter, SMD, SD Card, WDR, IR50m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Turret
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HDW3466EMP-S-AUS DatasheetDahua Eyeball Network Camera_Quick Start Guide_V1.0.4Eyeball Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
7 inch Screen, indoor monitor function: Unlock, video call, volume adjustment, and doorway monitoring
Notes: Power Supply doesn't come with this unit. Please shop here.
7" TFT screen
Video intercom function: Unlock, voice call, video call and volume adjustment
Mechanical button
Multiple bell sounds
Specifications
INDOOR MONITORS
SIZE
7 Inch TFT display
COLOUR
White
RESOLUTION
800x480
STORAGE
-
POWER SUPPLY
DC 12V
TECHNOLOGY
Analog
Downloads
Datasheet of DHI-VTH1020J
Dahua 16 Channels AI NVR DHI-NVR5216-16P-AI/ANZ, 1U 16PoE 2HDD WizSense Network Video Recorder
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
32-channel 1080p self-adaptive decoding capability.
Max. 384 Mbps incoming/recording/outgoing bandwidth.
AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus.
AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, and people counting.
Security baseline 2.3.
Specifications
Number of Channels
16 Channel
Number of PoE Ports
16 x PoE Ports
Number of Hard Disk Bay
2 x HDD Bay
Technology
WizSense AI Series
Network Bandwidth
AI disabled: 256 Mbps incoming, 256 Mbps recording and 256 Mbps outgoing AI enabled: 180 Mbps incoming, 180 Mbps recording and 180 Mbps outgoing
Maximum Resolution Support
32MP
Downloads
Datasheet for NVR5216-16P-AI/ANZ
Dahua Security Camera 8MP (4K) WizSense Motorised Starlight Bullet, 2.7-13.5mm, 4K@25/30fps, Perimeter, SMD 4.0, SD Card, WDR, IR60m, Built-in Mic, IP67, POE
8MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 6 MP (3072 x 2048) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 60 m.
ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply, easy for installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HFW3866TP-ZAS-AUS DatasheetBullet Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4=Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua 0.5m CAT6 Ethernet Slim Patch Cord Cable, Blue. Compatible with all CCTV Surveillance Cameras with PoE port
Specifications
CABLES
Colour
Blue
Length
0.5 meter
Type
CAT6
Brand
Dahua
Dahua 22-inch Full-HD LED Monitor DHI-LM22-C200
The 1920*1080 resolution produces clearer and more vivid pictures;
Wide colour gamut, 99% sRGB, 85% NTSC, 85% DCI-P3, 85% Adobe RGB. It meets the designer's demand of image texture;
178°H/178°V extra-wide viewing angle for all-round viewing performance;
Adaptive sync can effectively solve picture lagging and tearing problems;
4ms fast response time with no image blurring or ghosting;
Low blue light technology can support a comfortable viewing experience;
3000:1 high static contrast ratio makes more obvious contrast between bright and dark.
Specifications
Model
Model
DHI-LM22-C200
Display
Screen Size
21.45"
Panel type
VA
Aspect Ratio
16:9
Resolution
1920x1080
Backlight
E-LED
Brightness/Luminance
250nits(typ)
Contrast Ratio
3000:1
Color Support
99% sRGB, 85% NTSC, 85% DCI-P3, 85% Adobe RGB
Viewing Angle(H/V)
178°(H)/178°(V)
Response time
4ms(OD)
Refresh Rate
75Hz
Signals
Interface
VGA×1，HDMI 1.4×1，Audio out×1
General
Power Supply
DC 12V 2A
Power Type
Adapter
Consumption (Standard)
TYP. 19W, MAX. 24 W
Consumption (Standby)
<0.5W
Net Weight
2.5kg
Gross Weight
3.74kg
Tilt Angles
-5°±2°/15°±2°
Swivel(angle)
N/A
Pivot(angle/direction)
N/A
Height Adjustment
N/A
VESA
75x75mm
Dimension(W×H×D)
495.8x286.3x36.7mm(without stand)
Package(W×H×D)
554x120x353mm
Work Environment
Temperature
0°~40°(32°F~104°F)
Humidity
10%~85%
Accessory
Standard
HDMI cable,Adapter,Stand,
Downloads
DHI-LM22-C200_Datasheet
Dahua Security Camera 6MP WizSense Fixed Starlight Dome, 2.8mm, Perimeter, SMD 4.0, SD Card, WDR, IR50m, Built-in Mic, IP67, IK10, POE
6MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 6 MP (3072 x 2048) @25/30 fps.
H.265 codec allows high compression ratio and ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply, easy for installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
6MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WIZSENSE SERIES
POE
POE
Downloads
DH-IPC-HDBW3666EP-AS-AUS Datasheet 20220718Dahua Dome Network Camera_Quick Start Guide_V1.0.1Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua 10-Port Unmanaged Desktop Switch with 8-Port PoE - DH-PFS3010-8ET-96-V
* The parameters and data sheet below can only be applied to V2.0 (version 2.0)
Intelligent PoE
8-pin assignment PoE power supply
Long distance PoE
PoE watchdog
Wide working temperature
Specifications
ETHERNET PORT
10
OPTICAL PORT
Not support
UPLINK PORT
2
POE BUDGET
Idling: 3 W, Full load: 96 W
LAYER
Layer 2
TYPE
Unmanaged
Downloads
PFS3010-8ET-96_datasheet_202107034&8-port Unmanaged Desktop Switch_Quick Start Guide_V1.0.0DH-PFS3010-8ET-96-V2_A&E_20211112091309DH-PFS3010-8ET-96-V2_PORTDH-PFS3010-8ET-96-V2_DIMENSIONS
Dahua 2-wire IP Villa Door Station comes with both 2-wire and ethernet port
Anodised aluminium front panel
CMOS low illumination 2MP HD colourful 160° fisheye camera
Video intercom function
Access control function that supports two locks
Mobile phone app, talk to the visitor or unlock the door remotely on
Compatible with 2-wire interface & RJ45 interface
IK07 & IP65
Support H.265
Support surface and flush mount
PoE
Specifications
System
Main Processor
Embedded processor
Operating System
Embedded Linux Operation System
Button Type
Mechanical
Interoperability
ONVIF; CGI
Network Protocol
SIP; P2P; IPv4; UPnP; SNMP; DNS; DDNS; RTSP; RTP; TCP; UDP
Basic
Camera
1/2.5" 2MP CMOS Low Illumination HD Colourful Fisheye Camera
Field of View
Horizontal: 168.6°; vertical: 87.1; diagonal:176.7°
Focal Length
1.9 mm
WDR
120 dB
Noise Reduction
3D NR
Video Compression
H.265
Video Resolution
50Hz: Main Stream (720P@25 fps), sub stream (1080P@25 fps) 60Hz: Main Stream (720P@30 fps), sub stream (1080P@30 fps)
Video Frame Rate
25 fps
Video Bit Rate
256 Kbps to 4 Mbps
Light Compensation
Auto IR
Day/Night
Auto (ICR)
Audio Compression
G.711u
Audio Input
1 channel
Audio Output
Built-in speaker
Audio Mode
2-way voice communication
Audio Enhancement
Echo suppression/digital noise reduction
Audio Bit Rate
16 KHz, 16 Bit
Status Indicator Light
3
Port
Electric Lock
1
Alarm Output
1
Power Output
1-ch 12 VDC 100mA
Exit Button
1
Door Status Detection
1
Lock Control
1
Network Port
One RJ45 10M/100M network port
General
Appearance colour
Silver
Power Supply
Dahua 2-wire switch (max. power supply distance 50 m)DC 48V 1AStandard PoE
Power Adapter
Optional
Installation
Flush/surface mount
Certifications
CE; FCC; UL
Accessory
Flush/surface mount
Product Dimensions
130 mm × 96 mm × 28.5 mm (5.12" × 3.78" × 1.12")
Protection
IK07; IP65
Operating Temperature
–30°C to +60°C (–22°F to 140°F)
Operating Humidity
10%–90% (RH, non-condensing)
Operating Altitude
0 m–3000 m
Power Consumption
≤ 12W
Net Weight
0.35 kg (0.77 lb)
Gross Weight
0.4 kg (0.88 lb)
Downloads
Datasheet of DHI-VTO2202F-P-S2_20210120Quick Start Guide of DHI-VTO2202F-P-S2Villa Door Station_User's_Manual_V1.0.0-EngDahua Villa Intercom Setup GuideDahua Villa N VTHx NVTO via template
Dahua 2MP IP Villa Outdoor Station, Viewing Wide Angle 100 degree, Adjustable Viewing Angle, ICR 5m Night Vision DHI-VTO2101E-P-S2
HD CMOS camera.
Zinc alloy panel, IP65 and IK10 rated.
ICR night vision and voice prompt.
Video and audio messaging.
TCP/IP, and SIP.
Surface mounted.
Specifications
OUTDOOR STATION
RESOLUTION
2MP
TECHNOLOGY
IP
POWER SUPPLY
DC 12V, PoE
PROTECTION
IP65, IK10
MOUNT
Surface
MATERIAL
Front Panel: Zinc alloy Rear Panel: Aluminum alloy Holder: Aluminum alloy
Downloads
Datasheet of DHI-VTO2101E-P
Quick Start Guide of DHI-VTO2101E-P
Dahua Villa Intercom Setup Guide
Dahua Villa N VTHx NVTO via template
Dahua 2x4MP TiOC Duo Splicing Fixed-focal Eyeball WizSense Network Camera, DH-IPC-PDW3849-A180-AS-PV-ANZ
Outputs 180° wide angle splicing image.
Outputs max. 8 MP (4096 × 1860)@20 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED and warm light, the max. IR illumination distance is 25 m and warm light distance is 20 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in dual Mic; built in speaker, support two-way talk.
12 VDC/PoE power supply, easy for installation.
IP67 protection.
Sound and light alarm (red and blue lights)
EPTZ: Enlarge and track the targets of intelligent alarms.
SMD 4.0.
One-tap arming/disarming through alarm input
Specifications
Dahua Network Security Camera
Megapixels
4MP
Camera Style
Turret
Colour
White
Lens Type
Fixed
Technology
WizSense Series
Connection
PoE
Downloads
IPC-PDW3849-A180-AS-PV DatasheetEyeball Network Camera Installation Guide_V1.0.2Dahua Network Camera Web 3.0_OperationManual_V2.1.5Dahua Network Camera Web 5.0_Operation Manual_V1.0.7Dahua Eyeball Network Camera_Quick Start Guide_V1.0.2IPC-PDW3849-A180-AS-PV INSTALLATION METHOD ENIPC-PDW3849-A180-AS-PV DIMENSIONS5IPC-PDW3849-A180-AS-PV_A&E_20230922151424
Dahua 32 Channels WizSense Series AI NVR, DHI-NVR5432-AI/ANZ comes with no PoE port, 1.5U, 4 x HDD Bay. Work with Dahua DMSS and SmartPSS. Suitable for warehouse or big office surveillance needs.
Feature
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format
32-channel 1080p self-adaptive decoding capability
Max. 384 Mbps incoming/recording/outgoing bandwidth
AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting
Security baseline 2.3
Specification
NVR
Number of Channels
32 Channel
Number of PoE Ports
0 x PoE Ports
Number of Hard Disk Bay
4 x HDD Hard Disk Bay
Technology
WizSense AI Series
Network Bandwidth
AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
Download
NVR5432-AIANZ
This 8MP 4 Channel Kit from Dahua provides superior security surveillance with features such as ultra-high resolution, motion detection, audible warning and full-colour night vision. With AI capabilities and push notifications to your device via the DMSS app, this kit offers the latest in tech security features. Enjoy sharp visuals and 24/7 protection with this top-grade 8MP CCTV kit.
Dahua 8MP 8channel kit includes:
2 x DH-IPC-HDW3866EMP-S-AUS
2 x DH-IPC-HDW3849H-AS-PV-ANZ
1 x DHI-NVR4104HS-8P-AI/ANZ
* NOTE: HDD NOT INCLUDED
In the Kit:2 x 8MP Fixed Turret DH-IPC-HDW3866EMP-S-AUS
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
2 x 8MP TiOC Fixed Turret DH-IPC-HDW3849H-AS-PV-ANZ
8MP 1/2.8'' CMOS image sensor, low luminance, and high definition image.
Outputs max. 8 MP (3840 x 2160)@25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.
ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; buit-in dual MICs; 1-ch speaker; support two-way talk.
12 VDC/PoE power supply.
IP67 protection.
Sound and light alarm (red and blue lights).
SMD 4.0.
One press arming/disarming through alarm input.
1 x 4CH NVR DHI-NVR4104HS-P-AI/ANZ
Dahua Compact NVR, DHI-NVR4104HS-P-AI/ANZ, 4 Channels, 1U, 1 HDD Bay, Record Up to 16MP, 4 PoE, HDMI( 4K), SMD 4.0, P2P, WizSense Network Video Recorder
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 80 Mbps.
Max. decoding capability: 16 x 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
* NOTE: HDD NOT INCLUDED
Dahua Security Camera 8MP (4K) WizSense Motorised Starlight Turret, 2.7-13.5mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR40m, Built-in Mic, IP67, POE, black
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8 MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Turret
COLOUR
Black
LENS TYPE
Motorised
TECHNOLOGY
WizSense Series
Connection
PoE
Downloads
DH-IPC-HDW3866TP-ZS-AUS-BLK DatasheetDahua Eyeball Network Camera Quick Start Guide V1.0.4Eyeball Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua Android 10-inch digital indoor monitor
Android 8.1
More User-Friendly UI
Ethernet and Wi-Fi
10'' TFT Capacitive touch Screen, 1024x600
Micro-SD Card optional, max 256GB
Specifications
System
Main Processor
Embedded processor
Operating System
Android 8.1
Network Protocol
IPv4, TCP, SIP, UDP, RTSP
Basic
Screen Type
Capacitive screen
Display Screen
10 inch TFT LCD
Resolution
1024×600
Video Compression
H.264
Audio Compression
PCM
Audio Input
1 omnidirectional microphone
Audio Output
Built-in 1.5W speaker
Audio Mode
Two-way voice call
Audio Enhancement
Echo suppression/DNR
Audio Bit Rate
16KHz, 16Bit
Function
Information Release
Text announcements released by the management center can be viewed
Communication Mode
Full digital
Elevator Control
You can control the elevator through the indoor monitor
Leave Videos or Text Messages
Yes (SD card is needed)
DND Mode
Do not disturb period can be set.
Extension Number
Villa: 4
Apartment: 9
Wi-Fi
Yes
Wireless Standard
IEEE802.11b/802.11g/802.11n
Wireless Frequency Range
2.4GHz
Wireless Security-Encryption
64/128bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Storage
Micro SD storage, the maximum space is 256GB
Port
RS-485
1
Alarm Input
8
Alarm Output
1
Power Output
1 12V/100mA
Door Bell
Yes, use alarm input port
Network Port
1 10M/100M Ethernet
Alarm
SOS
Yes
Performance
Housing Material
PC+ABS
Regular
Color
Black
Power Supply
12V DC 1AStandard POE
Installation
Surface mount
Certifications
CEFCC
Accessory
Surface mount bracket, alarm ribbon cable, RS-485 cable, and power-supply pins are provided
Product Dimensions
260 mm×170 mm×15 mm (10.24"×6.69"×0.59") (ports are not counted) 260 mm×170 mm×25.4 mm (convex) (10.24"×6.69"×1") (ports are counted)
Operating Temperature
-10°C to +55°C (+14°F to +131°F)
Operating Humidity
10%RH–95%RH (Non-condensing)
Operating Altitude
Less than 3,000 meters (9842.52 ft)
Power Consumption
≤1.5W (standby), ≤7W (working)
Net Weight
770g (1.70lb)
Gross Weight
1.1kg (2.43lb)
Downloads
DHI-VTH5341G-W_datasheet_20200113
IP Indoor Monitor_Quick Start Guide_V1.0.0-Eng
IP Indoor Monitor_User's Manual_V1.0.0-Eng
DHI-VTH5341G-W_INSTALLATION_PROCEDURE
DHI-VTH5341G-W_DIMENSIONS
Dahua 24 Port layer 2 Management Switch, Hi-PoE (60W), PoE+, Total 360W
Intelligent PoE
Red port supports 90W IEEE802.3bt
Web management with friendly interface and easy operation
250 m long distance PoE transmission
PoE watchdog
Plug and play
Specifications
POE SWITCH
Ethernet Port
24
Optical Port
2
Uplink Port
2
PoE Budget
Port 1-2<=90W, Port 3-24<=30W, total<=360W
Layer
Layer 2
Type
Managed
Downloads
DH-PFS4226-24ET-360 DatasheetDH-PFS4226-24ET-360 User Manual
Dahua 1m CAT6 Ethernet Slim Patch Cord Cable, Blue. Compatible with all CCTV Surveillance Cameras with PoE port
Specifications
Network Cables
Colour
Blue
Length
1 meter
Type
CAT6
Brand
Dahua
Dahua 10m CAT6 Ethernet Slim Patch Cord Cable, Blue. Compatible with all CCTV Surveillance Cameras with PoE port
Specifications
CABLES
Colour
Blue
Length
10 meters
Type
CAT6
Brand
Dahua
Dahua 8 Megapixel + 8 Channels Kit: 2 x 8MP TiOC and 2 x 8MP Turret Cameras with 8CH AI NVR, GR-DH-8M8C2T2TIOC
8MP 8channel kit:
2 x DH-IPC-HDW3866EMP-S-AUS
2 x DH-IPC-HDW3849H-AS-PV-ANZ
1 x DHI-NVR4108HS-8P-AI/ANZ
In the Kit:2 x 8MP Fixed Turret DH-IPC-HDW3866EMP-S-AUS
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
2 x 8MP TiOC Fixed Turret DH-IPC-HDW3849H-AS-PV-ANZ
8MP 1/2.8'' CMOS image sensor, low luminance, and high definition image.
Outputs max. 8 MP (3840 x 2160)@25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.
ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; buit-in dual MICs; 1-ch speaker; support two-way talk.
12 VDC/PoE power supply.
IP67 protection.
Sound and light alarm (red and blue lights).
SMD 4.0.
One press arming/disarming through alarm input.
1 x 8CH NVR DHI-NVR4108HS-8P-AI/ANZ
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).
Max. decoding capability: 16 ?? 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
Dahua 4MP 25x Starlight IR WizSense Network PTZ Camera DH-SD4A425DB-HNY
1/2.8" 4Megapixel STARVIS™ CMOS.
25x optical zoom.
Starlight technology.
Max. 25/30fps@4MP.
IR distance up to 100m.
Auto-tracking.
Perimeter protection.
Face detection.
SMD 3.0.
IP66.
Specifications
MEGAPIXELS
4MP
CAMERA STYLE
PTZ
COLOUR
White
LENS TYPE
Motorized
TECHNOLOGY
PTZ SERIES
POE
POE+
Downloads
SD4A425DB-HNY_S0 DatasheetInstallation Guide_V1.0.0_(SD4A)Network Speed Dome & PTZ Camera Installation Manual_V1.0.1Dahua Network Speed Dome and PTZ Camera Web 5.0_User's Manual_V1.0.0SD4A425DB-HNY_DIMENSIONS
Dahua Security Camera 8MP (4K) WizSense Fixed Starlight Bullet, 2.8mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR30m, Built-in Mic, IP67, POE
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8 MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WizSense
POE
POE
Downloads
DH-IPC-HFW3866EP-AS-AUS Datasheet 20220415Dahua HD IR Bullet Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua 4 Channel Penta-brid 4K-N/5MP Compact 1U 1HDD WizSense DVR / XVR Digital Video Recorder, DH-XVR5104HS-4KL-I3
H.265+/H.265 dual-stream video compression
Supports Full-channel AI-Coding
Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Max 8 channels IP camera inputs, each channel up to 8MP; Max 64 Mbps incoming bandwidth
Up to 1 channel video stream (analog channel) Perimeter Protection
Up to 4 channels video stream (analog channel) SMD Plus
Up to 1 channel video stream (analog channel) human face recognition
IoT & POS functionalities
Specifications
NUMBER OF CHANNELS
4CH
NUMBER OF BNC PORTS
4*BNC PORTS
NUMBER OF HARD DISK BAY
1*HDD
TECHNOLOGY
RECORDERS
INCOMING BANDWIDTH
64 Mbps incoming
MAXIMUM RESOLUTION SUPPORT
4K
Downloads
dh-xvr5104hs-4kl-i3 datasheetdigital video recorder mini 1u compact qsgcompact mini hdd installation guidedahua hdcvi ai dvr user s manual
This Dahua 7-inch Touch Screen IP Intercom Kit (black colour monitor) is the modern doorbell for your home or office. Receive notifications on your Dahua's official DMSS app when visitors press the door station. You can also view on your 7-inch IPC black indoor monitor which can be beautifully hanged in your living room. This kits come with rain shade for your outdoor station to protect from different weather for durability. This is the IP video intercoms and cabling can be done by using RJ45 ethernet cables.
Inside the bundle:
1 x 7-inch Monitor VTH2621G-P
1 x Outdoor Station DHI-VTO2202F-P-S2
1 x Door Station Surface Mount Bracket VTM05R
1 x Uniarch 8 Port PoE Switch with Power Supply, SW-2110-P
1 x 7-inch Monitor VTH2621G-PThis Dahua 7-inch IP Indoor Monitor features stylish black colour comes with capacitive touch screen, 1024×600 pixels resolution and Standard PoE. 6 alarms can be connected and security cameras footage can be viewed as well.
7'' TFT capacitive touch screen, 1024 x 600
6-channel alarm input and 1-channel alarm output
Standard PoE
Outdoor station and IPC monitor
H.265 and H.264 video coding
High performance & cost-effective
1 x Outdoor Station DHI-VTO2202F-P-S2Dahua 2-wire IP Villa Door Station comes with both 2-wire and ethernet port
Anodised aluminium front panel
CMOS low illumination 2MP HD colourful 160° fisheye camera
Video intercom function
Access control function that supports two locks
Mobile phone app, talk to the visitor or unlock the door remotely on
Compatible with 2-wire interface & RJ45 interface
IK07 & IP65
Support H.265
Support surface and flush mount
PoE
1 x Uniarch 8 Port PoE Switch with Power Supply, SW-2110-PUniarch switch, 10 x 100Mbps network ports, including 8 PoE/PoE+ ports, 2 x 100Mbps uplink ports, Max capacity for single port 30W, total capacity 120W, up to 250m transmission distance, all-metal housing
Multiple working modes to address your business needs: Normal, Secure and Surveillance
Support port traffic control
Support for secure mode, all downlink ports can communicate only with uplink ports
Up to 250m transmission distance on surveillance mode
Support buffer optimization
All-metal housing, safe and reliable
1 x Door Station Surface Mount Bracket VTM05R
Dahua PoE Extender Passive work with PFT1200, connect up to 3x IPC
Support passive PoE cascade power supply and Ethernet data exchange
Support IEEE 802.3af/at standard power supply IP Camera
Cooperate with High PoE Midspan PFT1200), able to cascade level 2 PoE Extender, connect to 3 IPC (total power consumption <=25W), max transmission distance 300m
1*RJ45 10/100M PoE power supply input; 1*RJ45 10/100M supply power for IP Cam; 1*RJ45 10/100M supply power for the next extender
Installation mode: junction box internal mounting, DIN rail mounting
Downloads
PFT1300_datasheetPoE Extender_User's Manual_V1.0.3
Dahua Wall Mount Bracket
Neat & Integrated design
Wall mount bracket
Material: Aluminum
Safety rope hook attached, secure and reliable
Specifications
CAMERA BRACKETS
TYPE
Wall Mount Bracket
MATERIAL
Aluminum
COLOUR
White
DIMENSION
200mmx160mmx115mm
(7.87''x6.3''x4.53'')
Downloads
DH-PFB305W Datasheet
If you are looking for all black security cameras for your home or office, you are on the right page.
This bundle comes with two TiOC cameras which features two-way audio, full colour night vision and audio alarm to warn off intruders, plus two more standard cameras with IR black and white night vision but full colour when there are lights around with one-way audio from footage. The recorder to store your footage comes with 8 Channel which means you can connect up to 8 cameras which you can add four more cameras at the later stage if you need more. For the storage (Hard Disk), you can add from dropdown menu. 3TB should cover for a week footage for 4 x cameras. But if you want to keep more weeks of footage, you can add up to 8TB.
Dahua 8 MP + 8 Channels Kit: 2 x 8MP TiOC and 2 x 8MP Turret Cameras with 8 Channel AI NVR, Black, GR-DH-8M8C2T2TIOCB
8MP 8channel kit:
2 x DH-IPC-HDW3866EMP-S-AUS-BLK
2 x DH-IPC-HDW3849H-AS-PV-ANZ-BLK
1 x DHI-NVR4108HS-8P-AI/ANZ
In the Kit:2 x 8MP Fixed Turret DH-IPC-HDW3866EMP-S-AUS-BLK
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
2 x 8MP TiOC Fixed Turret DH-IPC-HDW3849H-AS-PV-ANZ-BLK
8MP 1/2.8'' CMOS image sensor, low luminance, and high definition image.
Outputs max. 8 MP (3840 x 2160)@25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.
ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; buit-in dual MICs; 1-ch speaker; support two-way talk.
12 VDC/PoE power supply.
IP67 protection.
Sound and light alarm (red and blue lights).
SMD 4.0.
One press arming/disarming through alarm input.
1 x 8CH NVR DHI-NVR4108HS-8P-AI/ANZ
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).
Max. decoding capability: 16 ?? 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
Dahua 8 MP + 16 Channels Kit: 10 x WizSense Fixed Starlight Turret Cameras, AI NVR, 3X66-K81610T-B-6TB
Dahua 3x66 8MP 16ch Kit includes:
10 x 8MP 2.8mm Fixed Lens DH-IPC-HDW3866EMP-S-AUS-BLK
1 x 16ch DHI-NVR4216-16P-AI/ANZ-6TB
DH-IPC-HDW3866EMP-S-AUS-BLKDahua Security Camera 8MP (4K) WizSense Fixed Starlight Turret, 2.8mm, Perimeter, SMD 4.0, SD Card, WDR, IR50m, Built-in Mic, IP67, POE, Black
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
DHI-NVR4216-16P-AI/ANZDahua 16ch NVR Record Up to 16MP, 16 Port PoE, HDMI(4K), Smart 2.0, P2P, Support 2 HDD, DHI-NVR4216-16P-AI/ANZ
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).
Max. decoding capability: 16 x 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
Dahua Security Camera 8MP (4K) WizSense Fixed Starlight Dome, 2.8mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR30m, Built-in Mic, IP67, IK10, POE
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8 MP (3840 x 2160) @25/30 fps.
H.265 codec allows high compression ratio and ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HDBW3866EP-AS-AUS Datasheet 20220718Dahua Dome Network_ Camera Quick Start Guide_V1.0.1Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua Security Camera 8MP (4K) WizSense Fixed Starlight Bullet, 2.8mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR30m, Built-in Mic, IP67, POE, Black
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8 MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Bullet
COLOUR
Black
LENS TYPE
Fixed
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HFW3866EP-AS-AUS-BLK DatasheetDahua HD IR Bullet Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua Security Camera, DH-IPC-HDBW3466EP-AS-AUS, 4MP WizSense Fixed Starlight Dome, 2.8mm, Perimeter, SMD, SD Card, WDR, IR50m, Built-in Mic, IP67, IK10, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Supports the AFSA (Anti-flicker Self-adaption) function, which
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection
SMD 3.0
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WizSense Series
PoE
PoE
Downloads
DH-IPC-HDBW3466EP-AS-AUS DatasheetDahua Dome Network_ Camera_Quick Start Guide_V1.0.1=Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua 4MP Starlight IP PTZ 4X 2.8mm~12mm VF lens, ICR, WDR, IR 15m, IP66, PoE
1/2.8'' 4Megapixel STARVIS CMOS
Starlight technology
Max. 25/30fps@4MP
4x optical zoom
Face Detection, People Counting, Perimeter Protection
IR distance up to 15m
SMD Plus
PoE
IP66, IK08
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
PTZ
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
PTZ SERIES
POE
POE
Downloads
DH-SD1A404XB-GNR Datasheet 20200605Dahua Network Speed Dome & PTZ Camera Web 3.0 User's Manual_V2.0.2Installation Guide_V1.0.0Network Speed Dome & PTZ Camera Installation Manual_V1.0.0
Dahua Access Control Extension Module DHI-DEE1010B-S2
Used to expand access control functions by working with access control terminal and door station.
Supports RS-485 communication.
Connects to electronic or magnetic locks to bolster security.
Offers 3 indicators to indicate when the device is on or off, functioning, and the status of the door.
Specifications
Port
RS-485
2
Exit Button
1
Door Status Detection
1
Lock Control
1
General
Power Supply
12 VDC, 1 A
Power Consumption
≤ 0.9 W (standby), ≤ 1 W (working)
Product Dimensions
58.2 mm × 49.2 mm × 20.2 mm (2.29" × 1.94" × 0.8") (W × H × D)
Operating Temperature
–10 °C to +60 °C (+14 °F to +140 °F)
Operating Humidity
0%–95% (RH), non-condensing
Net Weight
0.09 kg (0.20 lb)
Gross Weight
0.12 kg (0.26 lb)
Certifications
CE; FCC
Downloads
DEE1010B-S2_datasheet_20220316
Access Control Extension Module_User's Manual_V1.0.0
This Dahua 6 Megapixel 8 Channels Kits GR-DH-6MP8CH-AI make an ideal security system for anyone needing protection indoors and outdoors. Both TiOC and WisSense are waterproof. Plus with two TiOC cameras, you'll have full-colour night vision in your front & backyard with audible warnings & two-way audio.
This kit includes:
DH-IPC-HDW3666EMP-S-AUS x 4
DH-IPC-HDW3649H-AS-PV-ANZ x 2
DHI-NVR4108HS-8P-AI/ANZ x 1
4 x 6MP Fixed Turret DH-IPC-HDW3666EMP-S-AUS
6MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 6 MP (3072 x 2048) @25/30 fps
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply, easy for installation.
IP67 protection.
SMD 4.0, AI SSA.
2 x 6MP TiOC Fixed Turret DH-IPC-HDW3649H-AS-PV-ANZ
6MP 1/2.7'' CMOS image sensor, low luminance, and high definition image.
Outputs max. 6 MP (3200 x 1800) @25/30 fps
H.265 codec, high compression rate, ultra-low bit rate.
Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.
ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; buit-in dual MICs; 1-ch speaker; support two-way talk.
12 VDC/PoE power supply.
IP67 protection.
Sound and light alarm (red and blue lights).
SMD 4.0.
One press arming/disarming through alarm input
1 x 8CH NVR DHI-NVR4108HS-8P-AI/ANZ
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).
Max. decoding capability: 16 x 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
Dahua 8 Megapixel 8 Channel Kit with 6 x Cameras (Black) 3X66-K8086T-B-4TB
Dahua 3x66 8MP 8ch Kit includes:
6 x 8MP 2.8mm Fixed Lens DH-IPC-HDW3866EMP-S-AUS-BLK
1 x 8ch DHI-NVR4108HS-8P-AI/ANZ
DH-IPC-HDW3866EMP-S-AUS-BLKDahua Security Camera 8MP (4K) WizSense Fixed Starlight Turret, 2.8mm, Perimeter, SMD 4.0, SD Card, WDR, IR50m, Built-in Mic, IP67, POE, Black
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
DHI-NVR4108HS-8P-AI/ANZDahua 8ch NVR Record Up to 16MP, 8 Port PoE, HDMI(4K), SMD4.0, Quick Pick, P2P, DHI-NVR4108HS-8P-AI/ANZ
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).
Max. decoding capability: 16 x 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
Dahua 8 MP + 16 Channels Kit: 4 x 8MP TiOC and 6 x 8MP Turret Cameras with 16CH AI NVR, GR-DH-8MP16CH
2023 kit includes:
DH-IPC-HDW3866EMP-S-AUS x 6
DH-IPC-HDW3849H-AS-PV-ANZ x 4
DHI-NVR4216-16P-AI/ANZ x 1
In the Kit:
6 x 8MP Fixed Turret DH-IPC-HDW3866EMP-S-AUS
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
4 x 8MP TiOC Fixed Turret DH-IPC-HDW3849H-AS-PV-ANZ
8MP 1/2.8'' CMOS image sensor, low luminance, and high definition image.
Outputs max. 8 MP (3840 x 2160)@25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.
ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; buit-in dual MICs; 1-ch speaker; support two-way talk.
12 VDC/PoE power supply.
IP67 protection.
Sound and light alarm (red and blue lights).
SMD 4.0.
One press arming/disarming through alarm input.
1 x 16CH NVR DHI-NVR4216-16P-AI/ANZ
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).
Max. decoding capability: 16 x 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
* NOTE: HDD NOT INCLUDED
Recommend for a corporate office, two-storey home and more. This surveillance kit comes with 10 x 4MP cameras (white) and 3TB of storage; you can save and review footage. Safely monitor and secure every second of your place.
Dahua 3x66 4MP 16ch Kit includes:
10 x 4MP 2.8mm Fixed Lens DH-IPC-HDW3466EMP-S-AUS
1 x 16ch DHI-NVR4216-16P-AI/ANZ
DH-IPC-HDW3466EMP-S-AUSDahua 4MP WizSense Fixed Starlight Turret, 2.8mm, Perimeter, SMD, SD Card, WDR, IR50m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
DHI-NVR4216-16P-AI/ANZDahua 16ch NVR Record Up to 16MP, 16 Port PoE, HDMI(4K), Smart 2.0, P2P (without HDD), Support 2 HDD DHI-NVR4216-16P-AI/ANZ
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).
Max. decoding capability: 16 x 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
Dahua 8 Channel NVR Record up to 16MP, 8 Port PoE, HDMI (4K), Smart 2.0, P2P (without HDD), Support 2 x HDD DHI-NVR4208-8P-AI/ANZ
This Dahua advanced AI NVR 2023 comes with two hard disk bays and can connect up to 8 IP cameras which supports OnVif technology. Add storage from 1TB up to 10TB for longer recording of footage. Live monitoring with Dahua's DMSS app for Apple and Android phones or SmartPSS software for laptop or desktop computers.
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).
Max. decoding capability: 16 x 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
Specifications
Number of Channels
8 Channel
Number of PoE Ports
8 x PoE Ports
Number of Hard Disk Bay
2 x Hard Disk Bay
Technology
WizSense AI Series
Network Bandwidth
AI disabled: 256 Mbps incoming, 256 Mbps recording and 256 Mbps outgoing AI enabled: 180 Mbps incoming, 180 Mbps recording and 180 Mbps outgoing
Maximum Resolution Support
16 MP
Downloads
DHI-NVR4208-8P-AIANZ_datasheet_20221209Dahua Network Video Recorder_User's_Manual_V2.3.0-EngNetwork Video Recorder_Quick Start Guide_V1.0.0-EngHDD Installation Guide_V1.0.0
Surface-mounted Rain Cover for VTO2202F and DHI-VTO2202F-P-S2
Specifications
Video Intercom Brackets
TYPE
Rain Cover
MATERIAL
Aluminum
COLOUR
Silver
DIMENSION
141.1 mm x 101.6 mm x 48.5 mm(5.56'' x 4'' x 1.91'')
Downloads
DH-AC-VTM05R Datasheet
Dahua 7-inch 2-wire & Wi-Fi Indoor Monitor
7" TFT capacitive touchscreen, 1024 × 600
6-channel alarm input and 1-channel alarm output
Wi-Fi
Outdoor station and IPC monitor
H.265 and H.264 video decoding
2-wire digital communication
Specifications
System
Main Processor
Embedded processor
Operating System
Embedded Linux operating system
Network Protocol
RTSP; RTP; SIP; DNS; SSH
Basic
Screen Type
Capacitive touchscreen
Display
7" TFT
Screen Resolution
1024 × 600
Audio Compression
G.711a; G.711Mu; G.711u; PCM
Audio Input
1
Audio Output
Built-in speaker
Audio Mode
2-way Audio
Audio Enhancement
Echo suppression
Audio Bit Rate
16 kHz; 16 Bit
Function
Communication Mode
Digital 2-wire
Information Release
Receive and view text information released by the management center
Leave Videos
Yes (insert an SD card into the indoor monitor)
DND Mode
Do not disturb period can be set; Do not disturb mode
Number of Extensions
Villa: 3
Apartment: 2
Wi-Fi
Yes
Wireless Standard
IEEE802.11b/802.11g/802.11n
Wireless Frequency Range
2.4 GHz
Wireless Security Encryption
WPA/WPA2; WPA-PSK/WPA2-PSK
Storage
Micro SD card (up to 64 GB)
Performance
Casing
PC + ABS
Port
RS-485
1
Alarm Input
6
Alarm Output
1
Power Output
1 (12 V/200 mA)
Door Bell
Yes (use any alarm input port)
Network
One two-wire port and one 10 Mbps/100 Mbps Ethernet port (one of them can be selected)
Alarm
SOS
Yes
General
Color
White/Black
Power Supply
48 VDC 1.25 A
Installation
Surface mount
Certifications
CE; FCC
Accessory
Bracket and alarm ribbon cable (included)
Dimensions
189.0 mm × 130.0 mm × 26.9 mm (7.44" × 5.12" × 1.06")
Operating Temperature
–10 °C to +55 °C (+14 °F to 131 °F)
Operating Humidity
10%-95% RH (non-condensing)
Operating Altitude
Beneath 3000 m (9842.52 ft)
Power Consumption
Standby ≤ 2 W; working ≤ 6 W
Net Weight
0.35 kg (0.78 lb)
Gross Weight
0.56 kg (1.23 lb)
Downloads
VTH5422HW(B)-W Datasheet 202111220Digital VTH User's Manual_V1.0.0Digital Indoor Monitor Quick Start Guide (Model H) _V1.0.1
