Hikvision DS-2CD2367G3-LIS2UY/SL — 6MP ColorVu 3.0 Smart Hybrid Light Live-Guard Turret with White Strobe, Dual Mic & Speaker (NEMA 4X)
The Hikvision DS-2CD2367G3-LIS2UY/SL is the new Gen 3 Smart Hybrid Light turret — Hikvision's most-asked-for 6 MP camera for Australian homes, retail, hospitality, schools, body-corporate sites and small business. It pairs a 1/1.8" progressive-scan CMOS sensor with an F1.0 super-aperture lens (2.8 mm or 4 mm), delivering true 24/7 colour at 0.0005 lux via Hikvision's ColorVu 3.0 imaging stack. The Smart Hybrid Light illuminator combines white LEDs and 850 nm IR LEDs into a single 30 m-range array with three modes — IR-only for covert night recording, white-only for 24/7 colour, or auto-blend for the best of both. HikAI-ISP on-chip noise reduction and 130 dB scene-adaptive WDR handle high-contrast Australian scenes — sunset-into-shade driveways, backlit shop entries, sun-on-glass office foyers.
What sets this camera apart from a standard ColorVu turret is the /SL Live-Guard active deterrence package: a built-in white strobe light, a 110 dB built-in speaker capable of triggering audible warnings or playing recorded voice messages, and a built-in arrayed dual microphone for two-way audio. When AcuSense detects a human or vehicle inside your defined zone, the camera flashes the strobe, sounds the warning, and opens two-way audio to your phone via Hik-Connect — intruders leave before they ever reach the door. The -Y suffix denotes Hikvision's NEMA 4X moderate anti-corrosion housing — perfect for the Australian climate, including coastal sites within ~2 km of the shoreline. Australian stock, 3-year Australian warranty, available in 2.8 mm and 4 mm lens options.
Resolution
6 MP · 3200 × 1800 widescreen
Super-Aperture Lens
F1.0 · 2.8 mm or 4 mm
Smart Hybrid Light
White + IR · 3 modes · 30 m
AI Engine
AcuSense · Human + Vehicle
Live-Guard Deterrence
White Strobe · 110 dB Speaker · 2-Way Audio
Protection
IP67 · NEMA 4X · 3-Year AU Warranty
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
See Smart Hybrid Light + ColorVu 3.0 in Action
Hikvision's official Smart Hybrid Light + ColorVu demonstration shows the three illumination modes on the same scene — IR-only at night, white-light-only at night, and the smart auto-blend that gives you the best image quality at the lowest light level. The same imaging chain powers this DS-2CD2367G3-LIS2UY/SL turret.
Why the DS-2CD2367G3-LIS2UY/SL Is Australia's Most-Recommended 6 MP Turret
Three things make this Gen 3 turret the camera we recommend more than any other for Australian homes and small business. One: ColorVu 3.0 + F1.0 lens gives genuine 24/7 colour without flooding the scene in white light. Two: Smart Hybrid Light's three modes let you tune the illumination to the install — covert IR at the back yard, white light at the front door, or smart-blend wherever the scene changes. Three: the /SL Live-Guard package — strobe + 110 dB speaker + two-way audio + AcuSense — turns the camera into an active deterrent, not just a passive recorder. Intruders see, hear and are warned away before they reach the door.
ColorVu 3.0 — True 24/7 Colour
1/1.8" CMOS sensor + F1.0 super-aperture lens + HikAI-ISP noise reduction = 0.0005 lux colour imaging. The camera holds full natural colour in moonlight, ambient streetlight or driveway lighting — no IR cut-over, no black-and-white night mode, no washed-out white-light overexposure.
Smart Hybrid Light — Three Modes, One Camera
Mode 1 — IR only: covert 850 nm IR up to 30 m, black-and-white image, invisible to the eye. Mode 2 — White only: bright white light up to 30 m, full colour 24/7, deterrent value. Mode 3 — Smart blend: IR fills the background, white light triggers on AcuSense events for clear colour evidence frames. Set per site, per zone, per schedule.
AcuSense — Human + Vehicle, Not Cats or Trees
Deep-learning classification on the camera itself filters out the ~90 % of motion alerts caused by foliage, rain, shadows, possums and headlight glare on Australian sites. You only get notified for what matters: a person or a vehicle inside your defined perimeter zone.
Live-Guard /SL — Active Deterrence That Works
The /SL suffix adds three features to the base camera: a white strobe light, a built-in 110 dB speaker, and an arrayed dual microphone for two-way audio. AcuSense fires the strobe and audible warning automatically on a detected event — and you can open a live talk-down to the intruder from your phone via Hik-Connect.
130 dB Scene-Adaptive WDR
Australian sun is brutal — sunset behind a driveway, backlit shop entries, sun-on-glass foyers and bright dock aprons all defeat lesser cameras. 130 dB WDR with scene-adaptive tone-mapping holds detail in the shadows and the highlights at the same time, so you can read a face standing in shadow against a sun-lit doorway.
NEMA 4X Anti-Corrosion (-Y Suffix)
The -Y suffix denotes Hikvision's NEMA 4X-rated moderate anti-corrosion housing — designed for coastal Australian sites within ~2 km of the shoreline, in areas affected by acid rain, and for sustained outdoor exposure. Standard 6 MP turrets without -Y don't have this rating. Important for Sydney, Wollongong, Newcastle, the Gold Coast, Perth and any beachside install.
Smart Hybrid Light — How the 3 Modes Work in Practice
Smart Hybrid Light is the single biggest reason buyers choose the G3 generation over the older G2. The illuminator array combines white LEDs and 850 nm IR LEDs in one housing — both rated to up to 30 m range. The camera lets you choose how the two light sources work together, per camera, per time-of-day schedule, or per AcuSense event.
Smart IR Mode — Covert Night Recording
IR LEDs only, no visible light. Image is black-and-white. Useful for back yards, side gates, and any install where you don't want a bright light visible at night. Range up to 30 m.
Smart White Light Mode — 24/7 Colour
White LEDs only, always on at night. Full natural-colour image around the clock — the way ColorVu was designed to work. Doubles as a passive deterrent: lit-up driveways and entrances are statistically much less likely to be targeted.
Smart Hybrid Mode — Best of Both
IR fills the scene for general motion sensing. The moment AcuSense detects a person or vehicle, the white LEDs flash on to capture a full-colour evidence frame, then return to IR. Lowest visible disturbance to neighbours, best evidence-quality colour shots on actual events.
/SL Live-Guard — Three Active Deterrents in One Camera
The "/SL" suffix in the model name is the difference between a camera that watches a break-in and a camera that stops one. Live-Guard adds three integrated active-deterrent features that fire automatically when AcuSense detects a human or vehicle in your defined zone — no operator required.
White Strobe Light
The bright white strobe flashes on AcuSense triggers — typically enough on its own to make a casual intruder retreat. Visible from a long way off and unmistakable in intent. (Police-style red/blue strobe is available on the alternative /SRB variant — talk to us if needed.)
Built-in 110 dB Speaker
The built-in 2 W speaker delivers up to 110 dB at 10 cm — loud enough to startle, hand-shake or shout at a target across a driveway. Pre-record custom voice warnings ("This area is monitored — please leave") or use Hikvision's built-in alert tones.
Two-Way Audio via Hik-Connect
The arrayed dual microphone picks up clear audio from the scene; the speaker plays it back. Open a live talk-down to the intruder from your phone via Hik-Connect — useful for genuine deterrence ("Mate, I can see you — I've called the police") or for legitimate visitor interaction (couriers, contractors, neighbours).
AcuSense Triggers, Not False Alarms
The active-deterrent features only fire on AcuSense human / vehicle classifications — never on a possum, a tree branch in the wind, or a car driving past the front of your property without entering the zone. The result: deterrents that actually deter, instead of crying wolf and getting ignored.
Smart Linkage to Other Hikvision Devices
Trigger the strobe and audible warning from events on other Hikvision cameras at the same site — for example, a perimeter-sensor camera at the front fence triggers the Live-Guard strobe on the driveway turret. Configured in HikCentral or your NVR's event-linkage console.
Use as a Public-Address Speaker
The built-in speaker doubles as a one-way PA — broadcast voice announcements, music or alerts to the camera's covered area. Useful for retail, hospitality, schools and large hospitality venues where you also want a single device for sound.
2.8 mm vs 4 mm — Which Lens for Your Install?
This camera ships with the buyer's choice of 2.8 mm or 4 mm fixed lens. Both have the same F1.0 super-aperture; they differ only in how wide and how far they see. Choose by the geometry of the space you're covering.
Lens-by-Use-Case Decision Guide
2.8 mm — Field of view
108.8° horizontal · 56.4° vertical · 134.3° diagonal — widest available
2.8 mm — DORI
Detect 89 m · Observe 35 m · Recognise 17 m · Identify 8 m
2.8 mm — Best for
Front door overview, residential carport / driveway, shopfront, reception area, classroom, small office. Captures the whole room or driveway at the same time — first choice for most residential and small-business installs.
4 mm — Field of view
93.3° horizontal · 47.2° vertical · 114.2° diagonal
4 mm — DORI
Detect 109 m · Observe 43 m · Recognise 21 m · Identify 10 m
4 mm — Best for
Long driveways, corridors, side alleys, gateway / approach views, longer-distance retail aisles. Reaches further with more pixels on the target — first choice when you need to identify a face or read a number at the far end of a longer scene.
Not sure which lens? For most Australian homes and small shops, 2.8 mm is the right starting point. Choose 4 mm only if you have a corridor, long driveway or approach view longer than ~15 m where face identification matters at the far end. Talk to our Australian team if you want a second opinion on a specific install.
Technical Specifications
DS-2CD2367G3-LIS2UY/SL · Full Specifications
SKU
DS-2CD2367G3-LIS2UY/SL (AU-stocked default — NEMA 4X anti-corrosion, white strobe Live-Guard)
Camera Type
Hikvision Pro Series G3 · 6 MP ColorVu 3.0 Smart Hybrid Light AcuSense Live-Guard Fixed Turret
Image Sensor
1/1.8" Progressive Scan CMOS · ColorVu 3.0 · HikAI-ISP noise reduction
Max Resolution
3200 × 1800 (6 MP 16:9 widescreen)
Min. Illumination
Colour 0.0005 lux @ F1.0 (AGC ON) · 0 lux with white light
Shutter Speed
1 s to 1/100,000 s
Lens Options
2.8 mm fixed · F1.0 (108.8° H FOV) OR 4 mm fixed · F1.0 (93.3° H FOV) · M16 mount · fixed iris
Depth of Field
2.8 mm: 3.3 m to ∞ · 4 mm: 3.8 m to ∞
Day & Night
ICR (IR cut filter, mechanical)
Wide Dynamic Range
130 dB scene-adaptive
Image Enhancement
BLC · HLC · 3D DNR · distortion correction · digital defog · EIS
SNR
≥ 52 dB
Supplement Light
Smart Hybrid Light — white + 850 nm IR · up to 30 m · 3 modes (IR / White / Smart Blend)
Angle Adjustment
Pan 0°-360° · Tilt 0°-75° · Rotation 0°-360° (3-axis turret)
Frame Rate (Main)
50 Hz: 25 fps @ 6 MP · 60 Hz: 30 fps @ 6 MP
Streams
3 simultaneous (main / sub / third)
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG (sub-stream)
Video Bit Rate
32 Kbps – 16 Mbps · CBR / VBR · SVC (H.264 + H.265) · 1 ROI region
AI — AcuSense
Human + vehicle classification · perimeter protection (line crossing / intrusion / region entry / region exit) · scene change detection · face capture
Basic Events
Motion (human + vehicle trigger filter) · video tampering · exception
Linkage
FTP / NAS / microSD upload · centre notify · email · trigger recording · capture · strobe flash · audible warning
Audio
Built-in arrayed dual microphone · 1 line-in (3.3 Vpp, 4.7 KΩ) · 1 line-out (3.3 Vpp, 100 Ω) · built-in 2 W speaker, max 110 dB @ 10 cm · G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
Alarm I/O
1 input · 1 output (max 24 VDC/VAC, 1 A)
Ethernet
1 × RJ-45 10/100 Mbps self-adaptive
On-Board Storage
microSD / SDHC / SDXC up to 512 GB · NAS (NFS / SMB-CIFS) · ANR auto network replenishment
API & Protocols
ONVIF (Profile S / G / T) · ISAPI · SDK · ISUP · 6 concurrent live-view sessions · 32 users (3 levels)
Cyber Security
TLS 1.1 / 1.2 / 1.3 · HTTPS · 802.1X (EAP-TLS / EAP-LEAP / EAP-MD5) · IP filter · watermark · MAC host authentication · audit log · password protection
Client Software
iVMS-4200 · Hik-Connect · HikCentral Pro
Power Source
12 VDC ±25% (1.29 A, max 15.5 W) OR PoE 802.3at Class 4 (max 17 W) — runs on any modern Hikvision NVR PoE port
Material
Metal cover · metal main body
Dimensions / Weight
Ø 138.3 mm × 115.4 mm · ≈ 820 g
Operating Temperature
−30 °C to +60 °C · ≤95 % humidity (non-condensing)
Weatherproof Rating
IP67 (IEC 60529-2013)
Anti-Corrosion
NEMA 4X (NEMA 250-2018) — Y variant · moderate Hikvision protection tier
Approvals
CE-EMC · CE-LVD · UL 62368-1 · RCM (AS/NZS CISPR 32:2015) · IC ICES-003 · KC · CB · RoHS
Available Variants
/SL (white strobe) · /SRB (red+blue police strobe) · 2.8 mm or 4 mm lens · Black housing option
Warranty
3-Year Australian Warranty (back-to-base)
DS-2CD2367G3-LIS2UY/SL (6 MP) vs DS-2CD2387G3-LIS2UY/SL (8 MP) — Which Resolution for Your Site?
The 6 MP and 8 MP G3 turrets share physically identical hardware — same 1/1.8" CMOS sensor, same F1.0 lens options, same chassis, same Smart Hybrid Light array, same AcuSense AI, same Live-Guard active-deterrent package and same NEMA 4X housing. Published minimum illumination is identical (0.0005 lux) — the 6 MP doesn't gain any low-light advantage over the 8 MP. The decision is about resolution vs storage cost. For most Australian residential, retail, hospitality and small-business sites, 6 MP is the sweet spot — lower storage / bandwidth cost, 16:9 widescreen framing covers the whole scene. Choose 8 MP / 4K UHD if you'll routinely digitally zoom into recordings.
DS-2CD2367G3-LIS2UY/SL (6 MP) vs DS-2CD2387G3-LIS2UY/SL (8 MP)
Feature
DS-2CD2367G3-LIS2UY/SL (this — 6 MP)
DS-2CD2387G3-LIS2UY/SL (8 MP sibling)
Max Resolution
6 MP · 3200 × 1800 (16:9 widescreen)
8 MP · 3840 × 2160 (4K UHD)
Frame Rate (Full Res)
25/30 fps @ 6 MP
25/30 fps @ 8 MP
Image Sensor
1/1.8" CMOS · ColorVu 3.0
1/1.8" CMOS · ColorVu 3.0
Min. Illumination
0.0005 lux @ F1.0 (identical sensor — same low-light)
0.0005 lux @ F1.0
Lens Options
2.8 mm or 4 mm · F1.0
2.8 mm or 4 mm · F1.0
Smart Hybrid Light
White + IR · 30 m · 3 modes
White + IR · 30 m · 3 modes
WDR
130 dB scene-adaptive
130 dB scene-adaptive
AI Engine
AcuSense human + vehicle · perimeter
AcuSense human + vehicle · perimeter
Live-Guard
White strobe + 110 dB speaker + dual mic + 2-way audio
White strobe + 110 dB speaker + dual mic + 2-way audio
Storage / Bandwidth
Lower — fewer pixels = smaller file size
Higher — ~33 % more raw pixel data to record and back-up
Protection
IP67 · NEMA 4X
IP67 · NEMA 4X
Power
PoE 802.3at Class 4 · 12 VDC
PoE 802.3at Class 4 · 12 VDC
Warranty
3-Year Australian Warranty
3-Year Australian Warranty
Best For
Most Australian residential and small-business sites: front door / driveway / shopfront / reception / classroom / side gate / back yard. Widescreen 16:9 framing, lower storage cost.
Sites where you'll routinely digitally zoom into the recording to identify faces / plates after the fact — larger retail floors, multi-bay carparks, gated estates, transit waiting areas.
For the 8 MP sibling: DS-2CD2387G3-LIS2UY/SL (8 MP / 4K UHD G3 Smart Hybrid Light Live-Guard Turret) →
Recording NVRs — Pair with an Affordable M-Series PoE NVR
The DS-2CD2367G3-LIS2UY/SL runs on standard PoE 802.3at and plugs directly into the built-in PoE ports of any Hikvision NVR — no separate injector or switch required. For most Australian residential and small-business installs, the Hikvision M-Series NVRs are the right pairing: 4K HDMI output, H.265+ compression, PoE built-in, plug-and-play setup. AcuSense human / vehicle detection, Live-Guard strobe and audible warnings all work natively with M-Series NVRs. Step up to AcuSeek / DeepinMind only when you specifically need natural-language AI search across the recording fleet.
DS-7604NI-M1/4P — 4CH · 4 PoE · Budget Pick
Four-channel M-Series NVR with 4 built-in PoE ports, 4K HDMI output and a single HDD bay (up to 10 TB). The most cost-effective Hikvision NVR for a typical 4-camera residential install with this G3 turret as the centrepiece. View DS-7604NI-M1/4P →
DS-7608NI-M2/8P — 8CH · 8 PoE · 2 HDD Bay
Eight-channel M-Series NVR with 8 built-in PoE ports, 4K HDMI output and two HDD bays (up to 20 TB total). The sweet spot for small business, retail shopfronts and larger homes with up to 8 G3 turrets. View DS-7608NI-M2/8P →
DS-7616NI-M2/16P — 16CH · 16 PoE · 2 HDD Bay
Sixteen channels at full PoE, 160 Mbps M-Series engine for stutter-free 4K playback. Standard pairing for larger homes, body-corporate sites, schools and multi-shop strata running 10-16 G3 turrets. View DS-7616NI-M2/16P →
Need AI Search? AcuSeek / DeepinMind NVRs
For sites that need natural-language search across the recording fleet ("show me people in red jackets near the front gate yesterday"), step up to a Hikvision AcuSeek (VPro) or DeepinMind AI NVR. Overkill for most homes and small businesses. Browse AcuSeek & DeepinMind NVRs →
Browse the full Hikvision NVR range: Hikvision Network Video Recorders →. Not sure how many channels or which tier is right? Request a free system quote.
Compatible Mounts & Accessories
DS-1273ZJ-140 — Wall Mount
Standard wall-mount bracket sized for this turret. House wall, shopfront column, fence post, garage facade.
DS-1271ZJ-140 — Pendant / Ceiling Mount
Pendant-style mount for hanging from an eave, ceiling, carport gantry or soffit. Common residential front-of-house geometry.
DS-1275ZJ-SUS / DS-1276ZJ-SUS — Pole & Corner
Stainless-steel-banded pole mount and corner-of-building bracket for fence posts, light poles, gate columns and building corners overlooking two perimeter zones.
microSD Card for Local Storage
Supports microSD / SDHC / SDXC up to 512 GB with ANR (Auto Network Replenishment). Camera keeps recording locally during NVR outages, back-fills automatically when network returns.
Frequently Asked Questions
What does "Live-Guard /SL" actually do?The /SL suffix is Hikvision's "Live-Guard" active-deterrence package. When AcuSense detects a human or vehicle in your defined zone, the camera flashes the white strobe, plays a 110 dB audible warning through the built-in speaker, and (optionally) opens two-way audio via Hik-Connect to talk to the intruder live. It's the difference between a camera that watches a break-in and one that stops it.
What's the difference between /SL and /SRB?/SL uses a white strobe light — our Australian default. /SRB uses a red-and-blue police-style strobe — more aggressive in appearance, with regulatory limitations in some Australian states around impersonating emergency services. The /SL is the safe, broadly-deployable choice.
Should I get 2.8 mm or 4 mm?For most Australian residential and small-business sites, 2.8 mm is the right choice — covers the widest area, standard front-door / driveway / shopfront lens. Choose 4 mm only if you have a longer corridor, driveway or approach view (over ~15 m) where you need face identification at the far end.
What does the "-Y" suffix mean?The -Y suffix denotes Hikvision's NEMA 4X-rated moderate anti-corrosion housing — designed for coastal Australian sites within ~2 km of the shoreline and areas affected by acid rain. Right for Sydney, Perth, Brisbane, the Gold Coast and Wollongong.
What's new in G3 vs the older G2 version?The G3 adds Smart Hybrid Light (G2 had ColorVu white-only OR IR-only, not both), upgrades the AI engine to current-generation AcuSense, adds the arrayed dual microphone for clearer two-way audio, adds the built-in 110 dB speaker, and bumps the WDR to 130 dB scene-adaptive.
Does it run on a standard Hikvision NVR's PoE port?Yes — PoE 802.3at Class 4 (max 17 W), the same standard PoE+ rating delivered by every Hikvision PoE NVR. No separate PoE injector required. Plug-and-play.
How much storage will I need?At 6 MP @ 30 fps with H.265+ compression, plan for roughly 1.5-2 TB per camera per month at 24/7 recording, or about 500 GB per camera per month if you record on motion only. A typical 4-camera install with motion-only recording sits comfortably on a single 4 TB HDD with several months of retention.
How does AcuSense filter out false alarms?AcuSense runs deep-learning classification on the camera itself, identifying whether motion is a human, a vehicle, or "other" (animals, foliage, rain, shadows, headlight glare). Only human / vehicle detections trigger alerts and Live-Guard deterrents. ~90 % fewer false alerts than motion-only cameras.
Is this NDAA Section 889 compliant?No. Hikvision is not NDAA Section 889 compliant. For NDAA-required projects (typically US federally-funded), contact our team for alternatives. For Australian residential, commercial, council, body-corporate, school, retail, hospitality, hotel and most state-government projects without an NDAA contractual requirement, this camera is freely usable.
Downloads & Resources
DS-2CD2367G3-LIS2UY/SL Datasheet
Hikvision Turret Quick Start Guide
Hikvision Turret User Manual
Order the Hikvision DS-2CD2367G3-LIS2UY/SL from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision ColorVu Live-Guard turrets — and the DS-2CD2367G3-LIS2UY/SL is the camera we recommend more often than any other for Australian homes, retail shops, hospitality venues, small offices, schools and body-corporate sites. Order the 6 MP G3 Smart Hybrid Light + Live-Guard turret in either 2.8 mm or 4 mm lens for fast Australia-wide dispatch, expert pre-sales advice, multi-camera project pricing and full local warranty support. Building a complete system? Request a free quote or contact our Australian team for tailored camera-and-NVR sizing.
