Ubiquiti AmpliFi MeshPoint HD - WiFi Extender
The AmpliFi MeshPoint HD features an adjustable super antenna. It can be used to expand the coverage of an AmpliFi Mesh System or turn an existing router or Wi-Fi cablebox into a powerful mesh network.
The AmpliFi MeshPoint features an adjustable Super Antenna and fits discreetly in any household, wherever dead spots need coverage. Add MeshPoints as needed to an AmpliFi network or turn an ordinary router into a powerful mesh network. Signal strength LEDs are integrated into the design to ensure the system is positioned for optimal performance.
MeshPoint Specifications
Dimensions243.83 x 54 x 57.75
Weight224 g
Max. TX Power26 dBm
Radios2
MIMO Chains6
Speed1750 Mbps
ESD/EMP Protection ±24kV Air/Contact
ButtonsReset
Antennas1x Dual-Band Antenna, Tri-Polarity
Wi-Fi Standards802.11ac
Power SaveSupported
Wireless SecurityWPA2-PSK AES/TKIP
Operating Temperature14 to 131° F (-10 to 55° C)
Operating Humidity5 to 95% Noncondensing
CertificationsFCC / CE / IC
Supported Data Rates802.11ac13 Mbps to 1300 Mbps (MCS0 - MCS9, VHT 20/40/80)
802.11n6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40)
802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b1, 2, 5.5, 11 Mbps
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps
The Access Point WiFi 6 Pro (U6 Pro) is a high-performance, dual-band WiFi 6 access point ideal for home and office use. The U6 Pro is capable of reaching an aggregate throughput rate up to 5.3 Gbps with its 5 GHz (4x4 MIMO) and 2.4 GHz (2x2 MIMO) bands, which allows it to support over 300 concurrently connected clients while maintaining an even, reliable wireless experience across your entire network. It can also isolate your guest traffic to ensure optimal security and speed. The U6 Pro also operates at full 4x4 MIMO with 160 MHz channels to create high-capacity wireless uplinks and facilitate faster data transfer. It can be set up in minutes and fully managed with the UniFi Network application*.
High-performance, ceiling-mounted WiFi 6 access point designed for large offices.
Features:
WiFi 6 support (2.4/5 GHz bands)
5.3 Gbps aggregate throughput rate
(1) GbE RJ45 port (PoE In)
Downloads
Datasheet Installation Guide
Dual-band WiFi 5 access point designed to support high-density networks and critical system applications.
Features:
2.4/5 GHz WiFi 5 bands (3x3 MIMO)
1.3 Gbps aggregate throughput rate
Balanced antenna pattern for enhanced mounting versatility
(1) GbE RJ45 port (PoE In)*
(1) GbE RJ45 port for extended devices
Managed with the UniFi Network application
Downloads
Datasheet
Quick Start Guide
Ubiquiti High Efficiency Dual Band Directional Mesh AntennaThe UniFi Antenna, model UMA-D, is an optional mesh antenna designed to work with the UniFi® AC Mesh AP, model UAP-AC-M. With dual-band support, the UMA-D expands range coverage and provides customized pattern shaping. It is available in single- and five-packs.
Antenna Features Optimized for 802.11ac, the UMA-D offers a high efficiency directional radiation pattern with dual polarity. Weather-Resistant Enclosure Encased in UV-stabilized plastic, the UMA-D can be used indoors or outdoors.
Versatile Mounting The UMA-D has a ball joint mount designed for precise aiming and can be mounted on a pole or wall.
Compatibility The UMA-D is a connectorized antenna that is compatible with the UAP-AC-M.
The Ubiquiti UniFi® Building-to-Building Bridge is a 1+ Gbps Plug and Play 60 GHz Bridge with 5 GHz Radio Redundancy, UniFi Controller Management, and range of up to 500 m. The UniFi® Building-to-Building Bridge is the ideal solution for short-range, high-throughput connectivity. Integration with the UniFi Controller makes bridging two networks seamless. As a pack of two radios, UniFi Building-to-Building Bridge contains everything you need to get up and running within minutes. Enjoy simple, easy-to-use gigabit connectivity anywhere.Package Contents:
UniFi Building-to-Building Bridge (x2)
Ball joint mount (x2)
Lock ring (x2)
Metal strap (x2)
Gigabit PoE (48V, 0.32A) with mounting bracket (x2)
Power cord (x2)
Ubiquiti UniFi AP AC Outdoor Mesh 1167Mbps, dual-omni antennas - PoE injector includedScalable Enterprise Wi-Fi ManagementUniFi is the revolutionary Wi-Fi system that combines enterprise performance, unlimited scalability, and a central management controller. The UniFi AC Mesh APs have a refined industrial design and can be easily installed using the included mounting hardware.
FeaturesSave money and save time - UniFi comes bundled with a non-dedicated software controller that can be deployed on an on-site PC, Mac, or Linux machine; in a private cloud; or using a public cloud service. You also have the option of using the UniFi Cloud Key with built-in software.Powerful Hardware - The UniFi AC Mesh APs feature Wi-Fi 802.11AC with Plug & Play Mesh technology. Intuitive UniFi Controller Software Configure and manage your APs with the easy-to-learn user interface.Expandable Unlimited scalability - build wireless networks as big or small as needed. Start with one and expand to thousands while maintaining a single unified management system.Antenna Flexibility - The UAP-AC-M can use any other 2.4GHz / 5GHz / Dual Band Ubiquiti airMAX antenna, be it Omni or Sector, to enhance coverage.
Toolless Quick-Mounts for Ubiquiti CPE Products.Designed for additional mounting flexibility and device alignment options, the Quick-Mount accessory kit features an easy-to-use, toolless design.
With the latest 802.11ax WiFi 6 technology, AmpliFi Alien delivers 4x the overall network capacity and 2x the coverage while reaching true gigabit speeds.It features a dual-band radio with 2.4 GHz and 5 GHz 802.11ax radios optimized for WiFi 6 performance and backward compatibility with previous WiFi standards.This combination pack comprises one AmpliFi Alien Router and one Amplifi Alien MeshPoint. The MeshPoint expands wireless range coverage and includes a Gigabit Ethernet port to extend wired connectivity.Features:
WiFi 6 performance
5 GHz 8x8 WiFi 6 radio (Max. aggregate speed: 4804 Mbps)
2.4 GHz 4x4 Wi-Fi 6 radio (Max. aggregate speed: 1148 Mbps)
160 MHz bandwidth and DFS channel support
Router with 4-Port Gigabit Ethernet switch
MeshPoint with (1) Gigabit Ethernet port
Touchscreen display on Router
Includes AmpliFi Teleport configuration-free VPN solution
A compact and powerful UniFi gateway with a full suite of advanced routing and security features.
Up to 10x routing performance increase over USG (tested with IPS/IDS, QoS, and Smart Queues) Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server (1) GbE WAN port (1) GbE LAN port Compact footprint USB-C powered (adapter included) Managed with UniFi Network 8.0.7 and later
Downloads
Installation Guide
Technical Specifications
Mechanical
Dimensions
98 x 98 x 30 mm (3.9 x 3.9 x 1.2")
Weight
320 g (11.3 oz)
Enclosure material
Polycarbonate
Hardware
Processor
Dual-core ARM® Cortex®-A53 at 1 GHz
Memory information
1 GB DDR3L
Management interface
EthernetBluetooth 5.1
Networking interface
LAN:(1) GbE RJ45 portWAN:(1) GbE RJ45 port
Power method
USB type C (5V/3A)
Supported voltage range
100–240V
Max. power consumption
3.83W
Ambient operating temperature
-10 to 40° C (14 to 104° F)
Ambient operating humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
Gateway Features
Performance
WiFi QoS with UniFi APsApplication, domain, and country-based QoSApplication and device type identificationInternet quality and outage reporting
Next-generation security
Application-aware firewall rulesSignature-based IPS/IDS threat detectionContent, country, domain, and ad filteringVLAN/subnet-based traffic segmentationFull stateful firewall
Advanced networking
License-free SD-WAN*WireGuard, L2TP and OpenVPN serverOpenVPN clientOpenVPN and IPsec site-to-site VPNOne-click Teleport* and Identity Enterprise VPN**Policy-based WAN and VPN routingDHCP relayCustomizable DHCP serverIPv6 ISP support*When paired with a Cloud Key or Official UniFi Hosting.**When paired with a Cloud Key.
Application Requirements
UniFi Network
Version 8.0.7 and later
Ubiquiti Wave AP Micro. Wide-coverage 60 GHz PtMP access point powered by Wave Technology
The Wave AP Micro delivers 5 Gbps total throughput (2.5 Gbps duplex) and can connect up to 15 stations. It is equipped with a high-performance 5 GHz backup radio to ensure uninterrupted connectivity and a Bluetooth radio to simplify setup via the UISP® Mobile app.
Wall mount for an UniFi6 Pro or AC Pro.The Access Point Pro Arm Mount (UACC Pro AP AM) allows you to mount an UniFi6 Pro (U6 Pro), or AC Pro (UAP AC Pro) to the wall instead of the ceiling.
Features:
Compatible with a U6 Pro or UAP AC Pro
Compact 802.11ac Wave2 MU-MIMO Enterprise Access Point. PoE Not Included
4x4 MU-MIMO on 5GHz (1733Mbps max PHY rate), 2x2 MIMO on 2.4GHz (300Mbps max PHY rate)
Dimensions - ∅ 160 x 32.65 mm
Environment - Indoor
2.4 GHz Speed - 300 Mbps
5 GHz Speed - 1733 Mbps
PoE Mode - 802.3af PoE
Ports - (1) 10/100/1000 Ethernet
Wi-Fi Users - 200+ Users
MIMO Chains - 4x4
MU-MIMO - Yes
Downloads
Datasheet Installation Guide
No Software Fees
The UniFi® Controller software is bundled with the UniFi AP hardware at no extra charge — no separate software, licensing or support fee.
Dual-band, 802.11ac Wave 2 access point with a 2+ Gbps aggregate throughput rate that can be plugged into any non-AC wall outlet.
The Access Point In-Wall HD (UAP IW HD) is a dual-band, 802.11ac WiFi access point that can be plugged into any non-AC wall outlet. The UAP IW HD can reach a 2+ Gbps aggregate throughput rate with its 5 GHz (4x4 MU-MIMO) and 2.4 GHz (2x2 MIMO) bands, which allows it to support over 200 concurrently connected clients. This access point is powered by PoE* and is equipped with (5) GbE RJ45 ports, including one for configurable 48V PoE passthrough. The UAP IW HD is the perfect plug-and-play access point for those looking for an easy-to-use, inconspicuous way to broaden their wireless coverage. It can be set up in minutes and fully managed with the UniFi Network web application or mobile app.
Features:
5 GHz (4x4 MU-MIMO) band with a 1.733 Gbps throughput rate
2.4 GHz (2x2 MIMO) band with a 300 Mbps throughput rate
200+ concurrent client capacity
Powered by PoE*
(5) GbE RJ45 ports, including (1) for configurable PoE passthrough (Port 1)
Managed with the UniFi Network application
Downloads
Datasheet
Installation Guide
