This high performance & cost-effective Dahua IP Indoor Monitor features white colour frame, 7 inch touch screen, 1024×600 pixels resolution with standard PoE. 6 alarms can be connected and security cameras footage can be viewed as well.
7'' TFT capacitive touch screen, 1024 x 600
6-channel alarm input and 1-channel alarm output
Standard PoE
Door station and IPC monitor
H.265 and H.264 video coding
High performance & cost-effective
Specifications
INDOOR MONITORS
Size
7 Inch TFT display
Colour
White
Resolution
1024 x 600
Storage
Not Support
Power Supply
DC 12V, PoE
Tehnology
IP
Downloads
DHI-VTH2621GW-P DatasheetDHI-VTH2621GW-P Privacy_PolicyDHI-VTH2621GW-P User's ManualOPEN SOURCE SOFTWARE NOTICESOFTWARE LICENSE AGREEMENT
This Dahua 7-inch IP Indoor Monitor features stylish black colour comes with capacitive touch screen, 1024×600 pixels resolution and Standard PoE. 6 alarms can be connected and security cameras footage can be viewed as well.
7'' TFT capacitive touch screen, 1024 x 600
6-channel alarm input and 1-channel alarm output
Standard PoE
Outdoor station and IPC monitor
H.265 and H.264 video coding
High performance & cost-effective
Specifications
SIZE
7-inch TFT display
COLOUR
Black
RESOLUTION
1024x600 pixels
STORAGE
Not Support
POWER SUPPLY
DC 12V, PoE
TECHNOLOGY
IP
Downloads
DHI-VTH2621G-P DatasheetPrivacy_PolicyUser's ManualOPEN SOURCE SOFTWARE NOTICESOFTWARE LICENSE AGREEMENT
7 inch Screen, indoor monitor function: Unlock, video call, volume adjustment, and doorway monitoring
Notes: Power Supply doesn't come with this unit. Please shop here.
7" TFT screen
Video intercom function: Unlock, voice call, video call and volume adjustment
Mechanical button
Multiple bell sounds
Specifications
INDOOR MONITORS
SIZE
7 Inch TFT display
COLOUR
White
RESOLUTION
800x480
STORAGE
-
POWER SUPPLY
DC 12V
TECHNOLOGY
Analog
Downloads
Datasheet of DHI-VTH1020J
Dahua Android 10-inch digital indoor monitor
Android 8.1
More User-Friendly UI
Ethernet and Wi-Fi
10'' TFT Capacitive touch Screen, 1024x600
Micro-SD Card optional, max 256GB
Specifications
System
Main Processor
Embedded processor
Operating System
Android 8.1
Network Protocol
IPv4, TCP, SIP, UDP, RTSP
Basic
Screen Type
Capacitive screen
Display Screen
10 inch TFT LCD
Resolution
1024×600
Video Compression
H.264
Audio Compression
PCM
Audio Input
1 omnidirectional microphone
Audio Output
Built-in 1.5W speaker
Audio Mode
Two-way voice call
Audio Enhancement
Echo suppression/DNR
Audio Bit Rate
16KHz, 16Bit
Function
Information Release
Text announcements released by the management center can be viewed
Communication Mode
Full digital
Elevator Control
You can control the elevator through the indoor monitor
Leave Videos or Text Messages
Yes (SD card is needed)
DND Mode
Do not disturb period can be set.
Extension Number
Villa: 4
Apartment: 9
Wi-Fi
Yes
Wireless Standard
IEEE802.11b/802.11g/802.11n
Wireless Frequency Range
2.4GHz
Wireless Security-Encryption
64/128bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Storage
Micro SD storage, the maximum space is 256GB
Port
RS-485
1
Alarm Input
8
Alarm Output
1
Power Output
1 12V/100mA
Door Bell
Yes, use alarm input port
Network Port
1 10M/100M Ethernet
Alarm
SOS
Yes
Performance
Housing Material
PC+ABS
Regular
Color
Black
Power Supply
12V DC 1AStandard POE
Installation
Surface mount
Certifications
CEFCC
Accessory
Surface mount bracket, alarm ribbon cable, RS-485 cable, and power-supply pins are provided
Product Dimensions
260 mm×170 mm×15 mm (10.24"×6.69"×0.59") (ports are not counted) 260 mm×170 mm×25.4 mm (convex) (10.24"×6.69"×1") (ports are counted)
Operating Temperature
-10°C to +55°C (+14°F to +131°F)
Operating Humidity
10%RH–95%RH (Non-condensing)
Operating Altitude
Less than 3,000 meters (9842.52 ft)
Power Consumption
≤1.5W (standby), ≤7W (working)
Net Weight
770g (1.70lb)
Gross Weight
1.1kg (2.43lb)
Downloads
DHI-VTH5341G-W_datasheet_20200113
IP Indoor Monitor_Quick Start Guide_V1.0.0-Eng
IP Indoor Monitor_User's Manual_V1.0.0-Eng
DHI-VTH5341G-W_INSTALLATION_PROCEDURE
DHI-VTH5341G-W_DIMENSIONS
Dahua 7-inch 2-wire & Wi-Fi Indoor Monitor
7" TFT capacitive touchscreen, 1024 × 600
6-channel alarm input and 1-channel alarm output
Wi-Fi
Outdoor station and IPC monitor
H.265 and H.264 video decoding
2-wire digital communication
Specifications
System
Main Processor
Embedded processor
Operating System
Embedded Linux operating system
Network Protocol
RTSP; RTP; SIP; DNS; SSH
Basic
Screen Type
Capacitive touchscreen
Display
7" TFT
Screen Resolution
1024 × 600
Audio Compression
G.711a; G.711Mu; G.711u; PCM
Audio Input
1
Audio Output
Built-in speaker
Audio Mode
2-way Audio
Audio Enhancement
Echo suppression
Audio Bit Rate
16 kHz; 16 Bit
Function
Communication Mode
Digital 2-wire
Information Release
Receive and view text information released by the management center
Leave Videos
Yes (insert an SD card into the indoor monitor)
DND Mode
Do not disturb period can be set; Do not disturb mode
Number of Extensions
Villa: 3
Apartment: 2
Wi-Fi
Yes
Wireless Standard
IEEE802.11b/802.11g/802.11n
Wireless Frequency Range
2.4 GHz
Wireless Security Encryption
WPA/WPA2; WPA-PSK/WPA2-PSK
Storage
Micro SD card (up to 64 GB)
Performance
Casing
PC + ABS
Port
RS-485
1
Alarm Input
6
Alarm Output
1
Power Output
1 (12 V/200 mA)
Door Bell
Yes (use any alarm input port)
Network
One two-wire port and one 10 Mbps/100 Mbps Ethernet port (one of them can be selected)
Alarm
SOS
Yes
General
Color
White/Black
Power Supply
48 VDC 1.25 A
Installation
Surface mount
Certifications
CE; FCC
Accessory
Bracket and alarm ribbon cable (included)
Dimensions
189.0 mm × 130.0 mm × 26.9 mm (7.44" × 5.12" × 1.06")
Operating Temperature
–10 °C to +55 °C (+14 °F to 131 °F)
Operating Humidity
10%-95% RH (non-condensing)
Operating Altitude
Beneath 3000 m (9842.52 ft)
Power Consumption
Standby ≤ 2 W; working ≤ 6 W
Net Weight
0.35 kg (0.78 lb)
Gross Weight
0.56 kg (1.23 lb)
Downloads
VTH5422HW(B)-W Datasheet 202111220Digital VTH User's Manual_V1.0.0Digital Indoor Monitor Quick Start Guide (Model H) _V1.0.1
Hikvision IP Intercom, GEN 2, 7" Colour Monitor, WiFi, PoE, White KH6 Series IP-Based Indoor Station(6320)
7-inch TFT touch screen with 1024 × 600 resolution
Convenient Hik-Connect APP Mobile Control
Receive calls, open the door and live view remotely
Easy to use without PC
Easy wizard for quick set up
Configure the whole system on one touch screen
Live view of the door station and cameras in public areas
Support voice messages when no response from the indoor station
Receive alarms by linkage with a alarm system and notify the center to handle in time
Elevator access control
Downloads
Datasheet Quick Start Guide User Manual Configuration Manual
Dahua Lite Series VTH2621GIP & Wi-Fi Indoor Monitor Black, 7-inch Touch, PoE, Surface, 3 Year Warranty, DHI-VTH2621G-WP
7" TFT capacitive touch screen, 1024 × 600
6-channel alarm input and 1-channel alarm output
Wi-Fi
Standard PoE
Door station and IPC monitor
H.265 and H.264 video decoding
High performance & cost-effective
Specifications
Technical Specification
System
Main Processor
Embedded processor
Operating System
Embedded Linux operating system
Interoperability
ONVIF; SDK
Network Protocol
RTSP; RTP; SIP; DNS; SSH
ROM
128 MB
RAM
128 MB
CPU
Dual core 1.2 GHz
Basic
Screen Type
Capacitive Touchscreen
Display
7" TFT
Screen Resolution
1024 × 600
Audio Compression
G.711a; G.711u; PCM
Audio Input
1
Audio Output
Built-in speaker
Audio Mode
2-way Audio
Audio Enhancement
Echo suppression
Audio Bit Rate
116 bit
Function
Communication Mode
Full digital
Information Release
Receive and view text information released by the management center
DND Mode
Do not disturb period can be set; Do not disturb mode
Number of Extensions
Villa: 9
Apartment: 4
Wi-Fi intercom: 1 main monitor, 2 extension monitors
Wi-Fi
Yes
Wireless Standard
IEEE802.11b/802.11g/802.11n
Wireless Frequency Range
2,412–2,472 MHz
Wireless Security Encryption
WPA/WPA2; WPA-PSK/WPA2-PSK
Performance
Casing
PC + ABS
Port
Alarm Input
6
Alarm Output
1
Door Bell
Yes (use any alarm input port)
Network
One 10 /100 Mbps Ethernet
Storage
Micro SD Card, Max 64 GB (reserved for software)
General
Appearance Color
Black/White
Power Supply
12 VDC 1A; Standard PoE (36–57 V, 0.35 A)
Installation
Surface Mount
Certifications
CE; FCC
Dimensions
189.6 mm × 134.6 mm × 26.0 mm (7.50" × 5.30" × 1.00")
Operating Temperature
–10 °C to +55 °C (+14 °F to 131 °F)
Operating Humidity
10%–95% RH (non-condensing)
Operating Altitude
Beneath 3,000 m (9,842.52 ft)
Power Consumption
Standby ≤ 2W; working ≤ 6W
Net Weight
0.34 kg (0.74 lb)
Gross Weight
0.58 kg (1.27 lb)
Downloads
DatasheetPrivacy_PolicyUser's ManualOPEN SOURCE SOFTWARE NOTICESOFTWARE LICENSE AGREEMENT
Hikvision IP Intercom, Gen 2, 10" Android Control Centre to Suit Intercom, AX Pro & CCTV, Wifi, POE, White (9510), All-in-one Indoor Station, HIK-DS-KH9510-WTE1-WHITE(B)
10.1-inch colorful touch screen with 1024 × 600 resolution
Built-in Android System
Supports Android APP installation
Support for three-party software integration
Built-in Hik-Connect APP
For all-in-one management of Hikvision’s devices on tablet
DownloadDatasheet
Hikvision IP Intercom, Gen 2, 10" Colour Monitor, Wifi, POE, Black (8520), KH8 Series Indoor Station, HIK-DS-KH8520-WTE1
10.1-inch TFT touch screen with 1024 × 600 resolution
Convenient Hik-Connect APP Mobile Control
Receive calls, open the door and live view remotely
Easy to use without PC
Easy wizard for quick set up
Configure the whole system on one touch screen
Rich functions and extensions
Live-view of the door station and cameras in public areas
Support voice messages when no response from the indoor station
Receive alarms by linkage with a alarm system and notify the center to handle in time
Elevator access control
DownloadDatasheet
Hikvision IP Intercom, Gen 2, 7" Colour Monitor, Wifi, POE, Reddot (8350), KH8 Series Indoor Station, HIK-DS-KH8350-WTE1
7-inch IPS touch screen with 1024 × 600 resolution
Reddot award winner
Convenient Hik-Connect APP Mobile Control
Receive calls, open the door and live view remotely
Easy to use without PC
Easy wizard for quick set up
Configure the whole system on one touch screen
Rich functions and extensions
Live-view of the door station and cameras in public areas
Support voice messages when no response from the indoor station
Receive alarms by internal alarm terminals
Elevator access control
DownloadDS-KH8350-WTE1 Datasheet
Ubiquiti Intercom Viewer, Display Pair With Access Intercom For Visitor Screening & Remote Access Control, Allow Multiple Location, PoE
Display that pairs with the Access Intercom for visitor screening and remote access control, to mount in multiple locations throughout your building.
Features
Two-way audio Instant live view 5" touch display Connect and power using a PoE switch
Technical Specifications
Mechanical
Dimensions
135 x 72 x 31.8 mm (5.3 x 2.8 x 1.3")
Weight
168 g (5.9 oz)
Enclosure materials
Glass, polycarbonate
Mount material
Aluminum alloy
Mounting
Wall (Included)Gang box mount (Gang box not included)
Hardware
Networking interface
(1) 10/100 Mbps RJ45 port
Management interface
Ethernet
Power method
PoE
Supported voltage range
48V DC
Max. power consumption
5W
Display
127 mm (5") diagonal
Resolution
720 x 1280 (9:16)
Display luminance
300 nits (typical)
Touch screen technology
Capacitive multi-touch
Screen orientation
Portrait
Microphone
Yes
Speaker
Yes
Button
Factory reset
Ambient operating temperature
-10 to 40° C (14 to 104° F)
Ambient operating humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
Software
Management application
UniFi Access: Version 1.22.17 and later
Downloads
Installation Guide
Hikvision Master Station, 10.1-inch, 128 Network Cameras, up to 10000 Video Intercom Devices Can Be Added, 10 Inch Touch Android IP Main Station, HIK-DS-KM9503
10.1-inch IPS touch screen with 1280 × 800 resolution
Built-in SIP private server, up to 10,000 video intercom devices accessesUp to 128 network cameras can be added to the device
Supports more than 2 speakers and microphones: Connects to external earphone (3.5 mm), external goose neck microphone
Displays operation pages via HDMI
Supports standard PoE & 12 VDC power supply
Video intercom and access control functions: Call waiting, call priority configuration, call across buildings
DownloadDatasheet
Hikvision Intercom, GEN 2, Two-wire 7-inch Indoor Station, Colour Monitor, WiFi, White, DS-KH6320Y-WTE2
7-inch IPS touch screen 2-Wire IP indoor station with 1024 × 600 resolution
Convenient Hik-Connect APP Mobile Control
Receive calls, open the door and live view remotely
Easy to use without PC
Easy wizard for quick set up
Configure the whole system on one touch screen
Live view of the door station and cameras in public areas
Support voice messages when no response from the indoor station
Receive alarms by linkage with a alarm system and notify the center to handle in time
Elevator access control
Downloads
DS-KH6320Y-WTE2 DatasheetDS-KH6320Y-WTE2 Operation ManualDS-KH6320Y-WTE2 Configuration Manual
Hikvision IP Intercom, Gen 2, 7" Android Control Centre to Suit Intercom, AX Pro & CCTV, Wifi, POE, White (9310), All-in-one Indoor Station, HIK-DS-KH9310-WTE1-WHITE(B)
7-inch colorful touch screen with 1024 × 600 resolution
Built-in Android System
Supports Android APP installation
Support for three-party software integration
Built-in Hik-Connect APP
For all-in-one management of Hikvision’s devices on tablet
DownloadDatasheet
Hikvision Keyboard Joystick, 7" Touch Screen, IP, Controls PTZ, DVRS, NVRS (1100KI), Network Keyboard, HIK-DS-1100KI
Divide video wall into regions to manage video wall by region
open/close window, move window, resize window, divide window, and enlarge/narrow sub-window.
Group and macro
Preview camera live image on network keyboard touchscreen
Quickly switch to the previous/next camera
Control speed dome movement via joystick
Play the decoder videos on video wall
Play the video recorder videos on network keyboard touchscreen. Supports clipping and capturing during playback
Add devices via SDK or ONVIF protocol
HikCentral and KPS platforms access
Support up to 32 users (1 administrator and 31 operators) and 4,000 devices
Add/modify/delete cameras in batch
Import/export configuration file
DownloadDatasheet
Hikvision IP Intercom, Gen 2, 7" Colour Monitor, No SD Card, No App Connection, PoE, White (6320), 7 Inch Touch IP Indoor Station, HIK-DS-KH6320-LE1-WHITE
User friendly design
7-inch colourful touch screen with resolution 1024 × 600 pixels
Standard PoE
Views live video of door stations and linked cameras
No Hik-Connect app support
DownloadDS-KH6320-LE1/White Datasheet
Hikvision IP Intercom, Gen 2, 7" Colour Monitor, No SD Card, No App Connection, Black (6320), 7 Inch Touch IP Indoor Station, HIK-DS-KH6320-LE1-BLACK
7-inch TFT touch screen with 1024 × 600 resolution
Plug & Play
Standard PoE power supply
Live view of the door station and cameras in public areas
Support multiple languages
DownloadDatasheet
Hikvision Intercom, Gen 2, Two-wire 7" Colour Monitor, Wifi, White (6320), Two Wire Indoor Stations, HIK-DS-KH6320-WTE2-white
2-wire IP indoor station
7“ capacitive touch-screen, Wi-Fi
TF card support, max t o 32G
8-ch alarm input, 2 × alarm output, 1 × RS485
Remote unlocking via the client or APP
Views live videos of door stations and linked cameras
DownloadDatasheet
Dahua Master Station DHI-VTS5A40B
Features
Highly convenient, it has a 10-inch glass touch screen with a 1024 (H) x 600 (V) resolution and supports speaker phone and handsets
Supports desk mount installation, and the bracket can be adjusted from 0-45
Offers HDMI output with a resolution up to 1024 (H) x 600 (V)
The intercom can be set for residential areas a
Specifications
MASTER STATION
SIZE
10inch
COLOUR
Titanium Grey
RESOLUTION
1024 x 600
STORAGE
Micro SD, Max 512 GB
POWER SUPPLY
12V DC, 4A
TECHNOLOGY
Android 11
Downloads
VTS5A40B_datasheetDigital VTS_User's Manual_V1.0.0Digital VTS_Quick Start Guide_V1.0.0VTS5A40B_DIMENSIONS
Duhua 2-Wire Wi-Fi Hybrid Indoor Monitor DHI-VTH5123H-W
Features
7'' TFT capacitive touch screen
Offers video intercom that communicates with VTOs through half-duplex, and the app through full-duplex
Supports recording videos and capturing snapshots (SD card is required)
6-channel alarm input and 1-channel alarm output
The app can be used to receive calls and alarm notifications
Supports surface mount
Connects to HDCVI camera
Specifications
INDOOR MONITORS
SIZE
7 Inch
COLOUR
WHITE
RESOLUTION
1024x600
STORAGE
Micro SD, Max 64GB
POWER SUPPLY
2-wire Controller
TECHNOLOGY
2-wire
Downloads
VTH5123H-W_datasheet_20221118Dahua 2-wire Hybrid Indoor Monitor_Privacy PolicyDahua 2-wire Hybrid Indoor Monitor_OPEN SOURCE SOFTWARE NOTICEDahua 2-wire Hybrid Indoor Monitor_SOFTWARE LICENSE AGREEMENT2-Wire Hybrid Indoor Monitor (7-inch)_User's Manual_V1.0.4
