Hikvision 4K NVR DS-7604NI-I1/4P, 4 Channel, 4 PoE, 1 x HDD Bay (7604)
H.265+/H.265/H.264+/H.264 video formats
Up to 4-ch IP camera inputs
2-ch@12 MP (20fps)/4-ch@8 MP (25fps)
4-ch synchronous playback at up to 8MP resolution
Downloads
User ManualQuick Start GuideDatasheet
Hikvision AcuSense 4CH DVR, 5MP@12fps, HDTVI/AHD/CVI/CVBS/IP, 2 HDD Bays, 3TB HDD (7204)
4 channels and 2 HDDs 1U AcuSense DVR
False alarm reduction by human and vehicle target classification based on deep learning
Efficient H.265 pro+ compression technology
Encoding abilty up to 8 MP lite @ 15 fps, 5 MP @ 12 fps
5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
Up to 8 network cameras can be connected
Downloads
Datasheet Quick Start Guide User Manual Communication Matrix
Hikvision DeepinMind, 7716NXI-M4-16P-X 16CH NVR, 320MBPS, 8K, 16 x PoE, 4 HDD Bay, 1.5U
Up to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP decoding capacity
H.265+/H.265/H.264+/H.264 video formats
Up to 16-ch IP cameras can be connected, plug & play with 16 power-over-Ethernet (PoE) interfaces
Intelligent analytics based on deep learning algorithm
Up to 16-ch perimeter protection
Up to 16-ch facial recognition for video stream, or up to 16-ch facial recognition for face picture
Up to 12-ch video structuralization
Downloads
iDS-7716NXI-M4/16P/X DatasheetiDS-7716NXI-M4/16P/X Quick Start GuideiDS-7716NXI-M4/16P/X User ManualiDS-7716NXI-M4/16P/X Communication Matrix
Hikvision 32-ch 1.5U 16 PoE 8K DeepinMind NVR, IDS-7732NXI-M4-16P-X
Up to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP/32-ch@1080p decoding capacity
H.265+/H.265/H.264+/H.264 video formats
Up to 32-ch IP cameras can be connected, plug & play with 16 power-over-Ethernet (PoE) interfaces
Intelligent analytics based on deep learning algorithm
Up to 24-ch perimeter protection
Up to 16-ch facial recognition for video stream, or up to 32-ch facial recognition for face picture
Up to 12-ch video structuralization
Downloads
iDS-7732NXI-M4/16P/X DatasheetiDS-7732NXI-M4/16P/X Quick Start GuideiDS-7732NXI-M4/16P/X User ManualiDS-7732NXI-M4/16P/X Communnication Matrix
Hikvision 64 Channel 4K NVR Recorder, 2U with 400 Mbps, RAID, 2 x HDMI & 2 x VGA, DS-9664NI-M8
Up to 64-ch IP camera inputs
Up to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP/32-ch@1080p decoding capacity
Up to 400 Mbps incoming bandwidth and 400 Mbps outgoing bandwidth
2 HDMI (different source) and 2 VGA (different source) interfaces, 8K or dual 4K video outputs
Supports special cameras, including people counting camera, ANPR (automatic number plate recognition) camera, and fisheye camera
Advanced streaming technology enables smooth live view in poor network conditions
Supports RAID 0, 1, 5, 6, 10 and N+M hot spare for even more reliable data storage, effectively avoids data loss risks
Downloads
DS-9664NI-M8 DatasheetDS-9664NI-M8 Quick Start GuideDS-9664NI-M8 User ManualDS-9664NI-M8 Communication Matix
Hikvision 64 Channel 4K NVR with 3U, 400 Mbps, RAID, 2 x HDMI & 2 x VGA, DS-9664NI-M16
Up to 64-ch IP camera inputs
Up to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP/32-ch@1080p decoding capacity
Up to 400 Mbps incoming bandwidth and 400 Mbps outgoing bandwidth
2 HDMI (different source) and 2 VGA (different source) interfaces, 8K or dual 4K video outputs
Supports special cameras, including people counting camera, ANPR (automatic number plate recognition) camera, and fisheye camera
Advanced streaming technology enables smooth live view in poor network conditions
Supports RAID 0, 1, 5, 6, 10 and N+M hot spare for even more reliable data storage, effectively avoids data loss risks
Downloads
DS-9664NI-M16 Datasheet
DS-9664NI-M16 Quick Start Guide
DS-9664NI-M16 User Manual
DS-9664NI-M16 Communication Matrix
Hikvision 32 Channel 4K NVR with 3U, 320 Mbps, RAID, 2 x HDMI & 2 x VGA, DS-9632NI-M16
Up to 32-ch IP camera inputs
Up to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP/32-ch@1080p decoding capacity
Up to 320 Mbps incoming bandwidth and 400 Mbps outgoing bandwidth
2 HDMI (different source) and 2 VGA (different source) interfaces, 8K or dual 4K video outputs
Supports special cameras, including people counting camera, ANPR (automatic number plate recognition) camera, and fisheye camera
Advanced streaming technology enables smooth live view in poor network conditions
Supports RAID 0, 1, 5, 6, 10 and N+M hot spare for even more reliable data storage, effectively avoids data loss risks
Downloads
DS-9632NI-M16 DatasheetDS-9632NI-M16 Quick Start Guide
DS-9632NI-M16 User Manual
DS-9632NI-M16 Communication Matrix
Hikvision 128 Channel 4K Super NVR with 3U 576 Mbps, 16 x HDD Bay, DS-96128NI-I16
Up to 128 channel IP cameras can be connected
Up to 576 Mbps high incoming bandwidth ensures IP cameras can be connected
2 HDMI (different source) and 1 VGA interfaces16 HDD can be used for continuous video recording
16 HDD can be used for continuous video recording
Supports some specialist cameras, including people counting camera/ANPR (automatic number plate recognition) camera/fisheye camera
Advanced streaming technology enables smooth live view in poor network conditions
Supports RAID 0, 1, 5, 6, 10 and N+1 hot spare for even more reliable data storage, effectively avoids data loss risks
Downloads
DS-96128NI-I16 Datasheet
DS-96128NI-I16 Quick Start Guide
DS-96128NI-I16 User Manual
DS-96128NI-I16 Communication Matrix
Hikvision M Series 8K NVR DS-7732NI-M4-24P-3TB, 32 Channel, 1.5U, 24 PoE (7732)
H.265+/H.265/H.264+/H.264 video formats
Up to 32-ch IP camera inputs
Up to 32-ch@1080p decoding capacity
Up to 320 Mbps incoming bandwidth
Downloads
Datasheet Quick Start Guide User Manual Communication Matrix
Hikvision 8K NVR, 32 Channel 320Mbps, RAID, 2U, NO HDD (9632)
Up to 32-ch IP camera inputs
Up to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP/32-ch@1080p decoding capacity
Up to 320 Mbps incoming bandwidth and 400 Mbps outgoing bandwidth
2 HDMI (different source) and 2 VGA (different source) interfaces, 8K or dual 4K video outputs
Supports special cameras, including people counting camera, ANPR (automatic number plate recognition) camera, and fisheye camera
Advanced streaming technology enables smooth live view in poor network conditions
Supports RAID 0, 1, 5, 6, 10 and N+M hot spare for even more reliable data storage, effectively avoids data loss risks
Downloads
Datasheet Quick Start Guide User Manual Communication Matrix
Hikvision M Series 8K NVR DS-7732NI-M4-16P-3TB, 32 Channel, 1.5U, 16 PoE (7732), DS-7732NI-M4/6P
H.265+/H.265/H.264+/H.264 video formats
Up to 32-ch IP camera inputs
Up to 32-ch@1080p decoding capacity
Up to 320 Mbps incoming bandwidth
Downloads
DS-7732NI-M4/16P DatasheetDS-7732NI-M4/16P Quick Start GuideDS-7732NI-M4/16P User ManualDS-7732NI-M4/16P Communication Matrix
Hikvision 4K NVR DS-7604NI-K1/4P, 4 Channel, 1U, 4 PoE. Options to add 1TB HDD and 3TB HDD.
Up to 4-ch IP camera inputs
H.265+/H.265/H.264+/H.264 video formats
Up to 1-ch@8 MP/3-ch@4 MP/6-ch@1080p decoding capacity
Up to 40 Mbps incoming bandwidth
Downloads
Datasheet Quick Start Guide User Manual Communication Matrix
Hikvision 4K NVR DS-7732NI-I4/16P(B), 32 Channel, 16 PoE (7732)
Up to 32 channel IP cameras can be connected
Up to 2-ch @ 12 MP/16-ch @ 1080p decoding capacity
Only (B) version support 2 HDMI and 1 VGA interfaces, and HDMI interfaces support independent video output
4 HDDs for continuous video recording
Plug & Play with 16 Power-over-Ethernet (PoE) interfaces
Supports various special function cameras, including thermal camera/fisheye/people counting/heatmap/ANPR (automatic number plate recognition)
Advanced streaming technology enables smooth live view and data self-correction in poor network conditions
Supports dual-stream recording to save time and bandwidth.
Downloads
Datasheet Quick Start Guide User Manual Communication Matrix
Hikvision NVR DS-9664NI-I16-3TB, 64 Channel, 3U, 4K, 320Mbps, Raid, 3TB HDD (9664)
Up to 64 channel IP cameras can be connected
Up to 320 Mbps (or 200 Mbps when RAID is enabled) high incoming bandwidth ensures IP cameras can be connected
2 HDMI (different source) and 2 VGA (different source) interfaces
16 HDD can be used for continuous video recording
Supports some specialist cameras, including people counting camera/ANPR (automatic number plate recognition) camera/fisheye camera
Advanced streaming technology enables smooth live view in poor network conditions
Supports RAID 0, 1, 5, 6, 10 and N+1 hot spare for even more reliable data storage, effectively avoids data loss risks
Datasheet Quick Start Guide User Manual Communication Matrix
Hikvision NVR, DeepinMind, 32 Channel, 3U, 4K, 8 Face Detection Channels, No HDD (9632) - iDS-9632NXI-I8/X
H.265+/H.265/H.264+/H.264 video formats
Intelligent analytics based on deep learning algorithm
Up to 16-ch perimeter protection
Up to 8-ch facial recognition for video stream, or up to 16-ch facial recognition for face picture
Up to 8-ch video structuralization
Up to 32-ch IP cameras can be connected
Up to 16-ch 1080p decoding capability
Downloads
Datasheet
Quick Start Guide
User Manual
Communication Matrix
Hikvision NVR iDS-7732NXI-I4/16P/X, DeepinMind, 32 Channel, 16 PoE, 8 Face Detection Channels, No HDD (7732)
H.265+/H.265/H.264+/H.264 video formats
Intelligent analytics based on deep learning algorithm
Up to 16-ch perimeter protection
Up to 8-ch facial recognition for video stream, or up to 16-ch facial recognition for face picture
Up to 8-ch video structuralization
Up to 32-ch IP cameras can be connected
Up to 16-ch 1080p decoding capability
Downloads
Datasheet Quick Start Guide User Manual Communication Matrix
Hikvision NVR iDS-9664NXI-I8/X, DeepinMind, 64 Channel, 8 Face Detection Channels, No HDD (9664)
H.265+/H.265/H.264+/H.264 video formats
Intelligent analytics based on deep learning algorithm
Up to 16-ch perimeter protection
Up to 8-ch facial recognition for video stream, or up to 16-ch facial recognition for face picture
Up to 8-ch video structuralization
Up to 64-ch IP cameras can be connected
Up to 16-ch 1080p decoding capability
Downloads
Datasheet
Quick Start Guide
User Manual
Communication Matrix
Hikvision NVR IDS-9632NXI-I16/X, Deep in Mind, 32 Channel, 16bays, 8 Face Detection Channels, No Hdd (9632)
H.265+/H.265/H.264+/H.264 video formats
Up to 32 channel IP cameras can be connected
16 HDD can be used for continuous video recording
Intelligent analytics based on deep learning algorithm
Up to 16-ch perimeter protection
Up to 8-ch facial recognition for video stream, or up to 16-ch facial recognition for face picture
Up to 4-ch video structuralization
Up to 16-ch 1080p decoding capability
Downloads
Datasheet Quick Start Guide
This Hikvision Ultra Series NVR DS-7616NI-M2-16P-3TB, 16 Channel, 1U, 16 PoE, 8K (7616) comes with 3TB Hard Disk.
H.265+/H.265/H.264+/H.264 video formats
Up to 16-ch IP camera inputs
Up to 16-ch@4MP decoding capacity
Up to 256 Mbps incoming bandwidth
Specifications
Video And Audio
IP Video Input
16-ch
Up to 32 MP resolution
*: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
Incoming Bandwidth
256 Mbps
Outgoing Bandwidth
256 Mbps
HDMI Output
8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output
1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Video Output Mode
HDMI/VGA independent output
CVBS Output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Decoding
Decoding Format
H.265+/H.265/H.264+/H.264
Recording Resolution
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF
*: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
Synchronous Playback
16-ch
Decoding Capability
2-ch@32 MP (30 fps)+2-ch@8MP（30fps）/10-ch@8 MP (30 fps)/20-ch@4 MP (30 fps)/40-ch@1080p (30 fps)
Dual-Stream Recording
Support
Stream Type
Video, Video & Audio
Audio Compression
G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2
Network
Remote Connection
128
Network Protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
Interface
16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power
≤ 200 W
Standard
IEEE 802.3 af/at
Auxiliary Interface
SATA
2 SATA interfaces
Capacity
Up to 16 TB capacity for each HDD
Alarm In/Out
4/1
USB Interface
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
General
Power Supply
100 to 240 VAC, 50 to 60 Hz
Consumption
≤ 15 W (without HDD and PoE off)
Working Temperature
-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity
10% to 90%
Dimension (W × D × H)
385 × 315× 52 mm (15.2" × 12.4" × 2.0")
Weight
≤ 3 kg (without HDD, 2.2 lb.)
Certification
FCC
Part 15 Subpart B, ANSI C63.4-2014
CE
EN 55032:2015+A1:2020, ENIEC61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:201
9, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
Downloads
Datasheet Quick Start Guide Manual Communication Matrix
Hikvision Pro Series 4K NVR DS-7616NI-I2/16P with 3TB , 6TB and 8TB storage to choose from. This NVR comes with 16 Channel with 16 PoE port and can handle 4K resolution.
Up to 16 channel IP cameras can be connected
Up to 2-ch@12 MP/16-ch@1080p decoding capacity
1 HDMI and 1 VGA interfaces: both interfaces support independent video output
2 HDDs for continuous video recording
Plug & Play with 16 Power-over-Ethernet (PoE) interfaces
Supports various special function cameras, including thermal camera/fisheye/people counting/heatmap/ANPR (automatic number plate recognition)
Advanced streaming technology enables smooth live view and data self-correction in poor network conditions
Supports dual-stream recording to save time and bandwidth
Video And Audio
IP Video Input
16-ch
Up to 12 MP resolution
Incoming Bandwidth
160 Mbps
Outgoing Bandwidth
256 Mbps
HDMI Output
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Video Output Mode
HDMI/VGA independent output
Audio Input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Decoding
Decoding Format
H.265+/H.265/H.264+/H.264/MPEG4
Recording Resolution
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF
Synchronous Playback
16-ch
Decoding Capability
2-ch@12 MP (20 fps)/4-ch@8 MP (25 fps)/8-ch@4 MP (30 fps)/16-ch@1080p (30 fps)
Dual-Stream Recording
Support
Stream Type
Video, Video & Audio
Audio Compression
G.711ulaw/G.711alaw/G.722/G.726
Network
Network Protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Remote Connection
128
Network Interface
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
Interface
16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power
≤ 200W
Standard
IEEE 802.3 af/at
Auxiliary Interface
SATA
2 SATA interfaces
Capacity
Up to 10 TB capacity for each HDD
USB Interface
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm In/Out
4/1
General
Power Supply
100 to 240 VAC, 50 to 60 Hz
Consumption
≤15 W (without enabling PoE)
Working Temperature
-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity
10 to 90 %
Dimension (W × D × H)
385 × 315× 52 mm (15.2" × 12.4" × 2.0")
Weight
≤ 3 kg (6.6 lb)
Certification
CE
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
Obtained Certification
CE, CB, UKCA, IC
Downloads
Datasheet Quick Start Guide Manual
Hikvision Decoder DS-6908UDI, 8 x HDMI / 4 x BNC, 4k (6908)
Provides HDMI (adaptable to DVI-D) and BNC output interfaces.
Up to 4K (3840 × 2160@30Hz) via HDMI output interfaces (only for odd interface).
H.265+/H.265, H.264+/H.264, Hik264, MPEG4 and MJPEG video compression.
PS, RTP, TS, ES, HIK encapsulation formats.
Three encoding levels: baseline, main, and high-profile.
G.722, G711A, G726, G711U, MPEG2-L2, and AAC audio compression.
Two decoding modes: active decoding and passive decoding.
Remote video files' decoding output.
Supports two-way audio via client software.
Provides VGA and DVI input interfaces.
Supports window opening, window roaming and window split.
Supports multi-screen control with PC installed with RSC server.
Gets stream and decodes via URL and RTSP from encoding devices.
Displays the decoded video stream on the video wall by directly linking cameras or by stream media forwarding.
You can configure what the video wall shows when decoding ends and streaming fails via the Web browser and client software.
Configurable LED width and height parameters when the LED is connected.
Regular and irregular virtual screen configurable to display multiple signal sources and get rid of the restriction of physical screen.
Accessible by 2.4 MP DeepinView camera.
Accessible by thermal network camera and you can view the temperature measurement, dynamic fire source detection, ship detection and VCA information in live view and playback.
You can enable or disable the smart information for the thermal network camera.
Two-way audio.
Port aggregation technology (Ethernet Channel).
Downloads
DatasheetManual
Hikvision Decoder DS-6904UDI, 6 x HDMI / 2 x BNC, 4K (9604)
Provides HDMI (adaptable to DVI-D) and BNC output interfaces.
Up to 4K (3840 × 2160@30Hz) via HDMI output interfaces (only for odd interface).
H.265+/H.265, H.264+/H.264, Hik264, MPEG4 and MJPEG video compression.
PS, RTP, TS, ES, HIK encapsulation formats.
Three encoding levels: baseline, main, and high-profile.
G.722, G711A, G726, G711U, MPEG2-L2, and AAC audio compression.
Two decoding modes: active decoding and passive decoding.
Remote video files' decoding output.
Provides DVI input interface.
Supports window opening, window roaming and window split.
Supports multi-screen control with PC installed with RSC server.
Gets stream and decodes via URL and RTSP from encoding devices.
Displays the decoded video stream on the video wall by directly linking cameras or by stream media forwarding.
You can configure what the video wall shows when decoding ends and streaming fails via the Web browser and client software.
Configurable LED width and height parameters when the LED is connected.
Regular and irregular virtual screen configurable to display multiple signal sources and get rid of the restriction of physical screen.
Accessible by 2.4 MP DeepinView camera.
Accessible by thermal network camera and you can view the temperature measurement, dynamic fire source detection, ship detection and VCA information in live view and playback.
You can enable or disable the smart information for the thermal network camera.
Port aggregation technology (Ethernet Channel).
Downloads
DatasheetManual
