Hikvision Onboard Security · 4 PoE · GPS / GLONASS · Dual 2.5-inch Bays
Hikvision AE-MN5043(RJ45) 4-Channel Mobile NVR for Vehicle CCTV
The Hikvision AE-MN5043(RJ45) is a rugged mobile network video recorder built for buses, trucks, taxis, fleet vehicles, rail and other onboard-security applications. Four IP cameras connect directly through the recorder’s PoE interfaces, with provision for another four IP cameras through a suitable external PoE switch.
Unlike a standard building NVR, the AE-MN5043 is designed around vehicle power, vibration and movement. It combines a wide 9–36 VDC input, fanless die-cast aluminium chassis, shock-managed removable storage, delayed shutdown, power-loss protection, a built-in super-capacitor, GPS/GLONASS positioning and a built-in G-sensor.
Direct Camera Inputs
4 × PoE IP cameras
Expandable
Up to 4 more via PoE switch
Recording
Up to 5MP · H.265 / H.264
Storage
2 × removable 2.5-inch bays
Vehicle Positioning
Built-in GPS / GLONASS
Warranty
3-year Australian warranty
Australian Stock
Vehicle-Ready Power Protection
Local Technical Support
Designed for Real Vehicle Conditions
Stable Recording While Moving
The removable 2.5-inch drive bays use vibration management to help protect recordings on rough roads. Redundant recording across two drives is supported where configured.
Vehicle Power Protection
A 9–36 VDC input supports common 12 V and 24 V vehicle systems. Delayed shutdown, scheduled startup/shutdown, a super-capacitor and power-off protection help preserve important data when ignition power changes unexpectedly.
Location Recorded with Video
The built-in GPS/GLONASS module records positioning information alongside video, supporting route review, incident investigation and fleet oversight.
Driving-Event Inputs
Sensor and alarm interfaces can collect vehicle information such as braking, reversing and left/right turns when correctly connected and configured by a vehicle-security installer.
Optional Wireless Connectivity
Pluggable 4G and Wi-Fi modules are available for compatible configurations. They are not included with this base recorder unless specifically stated in the selected offer.
Fanless, Rugged Chassis
The die-cast aluminium enclosure has no cooling fan, reducing moving parts while supporting operation from −25 °C to +70 °C.
Who Is This Recorder For?
This mobile NVR is intended for professionally designed onboard CCTV systems in public transport, school buses, taxis, learner vehicles, trucks, service fleets and specialised mobile equipment. It is not a plug-in replacement for a conventional home or business NVR: vehicle power wiring, ignition sensing, cameras, storage, antennas, optional communications modules and peripheral harnesses must be selected for the complete installation.
Storage, 4G and Wi-Fi — Important Ordering Notes
Base Recorder Configuration
| Storage included |
No HDD or SSD included. Two removable 2.5-inch bays are provided. |
| Published storage support |
Hikvision’s current datasheet lists SSD up to 4TB and HDD up to 2TB. Confirm approved drive models and capacity per bay before ordering. |
| 4G module |
Optional pluggable module; not included with the base recorder. |
| Wi-Fi module |
Optional pluggable module; not included with the base recorder. |
| SIM service |
Not included. Hikvision recommends an industrial SIM for 4G-equipped deployments. |
| Installation |
Professional vehicle-CCTV installation and configuration are recommended. |
Technical Specifications
AE-MN5043(RJ45)
| Model / SKU |
AE-MN5043(RJ45) |
| Recorder type |
Mobile network video recorder for onboard vehicle CCTV |
| IP camera inputs |
4 directly through PoE interfaces; 4 additional cameras extendable through an external PoE switch |
| Maximum camera resolution |
Up to 5MP from firmware V5.6.4 |
| Video compression |
H.265 / H.264 · dual stream |
| Frame rate |
PAL 1–25 fps · NTSC 1–30 fps |
| Video outputs |
1 main output through EXT.DEV interface · 1 VGA |
| Two-way audio |
1 channel through EXT.DEV interface |
| Storage bays |
2 × removable 2.5-inch HDD/SSD bays |
| Network interfaces |
Front: 1 × 10/100Mbps RJ45 · Rear: 1 × 10/100Mbps 6-pin aviation connector |
| Positioning |
GPS and GLONASS · 1 × FAKRA antenna interface |
| Vehicle sensor |
Built-in G-sensor |
| Alarm and sensor inputs |
4 high/low alarm inputs, 1 pulse input, 1 button input · 4 high/low sensor inputs |
| Alarm outputs |
2 relay outputs |
| Serial interfaces |
1 × RS-232 (optional harness) · 1 × RS-422 through EXT.DEV |
| USB |
Front USB 2.0 · rear USB 2.0 through 5-pin aviation connector |
| Power input |
9–36 VDC |
| Power consumption |
Standby ≤0.5 W · full load ≤55 W · recorder without peripherals/storage ≤20 W |
| Operating conditions |
−25 °C to +70 °C · 10–95% RH, non-condensing |
| Dimensions |
206 × 225.4 × 60.1 mm |
| Weight |
Approximately 1.66 kg without storage media |
| Certifications |
CE · FCC · E-Mark · EN50155 · EN45545 · CB · RoHS · ISO 7637-2 |
| Warranty |
36-month Australian back-to-base warranty |
Complete Your Mobile CCTV System
The recorder is supplied without storage, cameras or installation cabling. Choose accessories to suit the vehicle, recording period and installation environment.
2.5-inch Vehicle-Rated Storage
The AE-MN5043 uses two removable 2.5-inch HDD/SSD bays. Do not order a standard 3.5-inch surveillance drive for this recorder. Ask us to confirm a compatible vehicle-rated drive and capacity before purchase.
View storage options
CAT6 Network Cabling
Use quality full-copper CAT6 patch leads between the recorder, compatible RJ45 cameras and any external network equipment. Cable length and routing must suit the vehicle installation.
View 1m CAT6 patch cable · Browse Ethernet cables
External PoE Switch
A suitable external PoE switch can be used when expanding beyond the four direct PoE camera connections. Confirm the switch power source, camera PoE budget and vehicle-mounting requirements with your installer.
View 5-port PoE+ switch
UPS and Power Protection
A mains UPS can protect workshop, depot or shore-powered network equipment. It is not a direct substitute for correctly engineered 9–36V vehicle power, ignition sensing, fusing and isolation for this mobile NVR.
View Hikvision UPS options · Browse all UPS models
Found It Cheaper?
We’ll beat an eligible Australian competitor’s advertised price by 5%.
Send us the current in-stock Australian listing for the same genuine model and configuration. Price Beat is subject to verification and our standard terms.
Chat with us for a Price Beat
Frequently Asked Questions
Does the AE-MN5043(RJ45) include a hard drive or SSD?No. This draft is for the base recorder without storage. Select compatible 2.5-inch vehicle-rated storage separately.
Are 4G and Wi-Fi built in?The recorder supports pluggable 4G and Wi-Fi modules, but those modules are optional and are not included with this base configuration.
How many cameras can it record?Four IP cameras connect directly through PoE. Hikvision also specifies support for four additional IP cameras through a suitable external PoE switch.
Will it work in 12 V and 24 V vehicles?Yes. The 9–36 VDC input covers common 12 V and 24 V vehicle systems when correctly wired by a qualified installer.
Does it record the vehicle’s location?Yes. Built-in GPS/GLONASS positioning can record location information with the video when the antenna and system are correctly configured.
Can I install it like a normal desktop NVR?No. It is intended for professional onboard installations and requires correct vehicle power, ignition, camera, antenna, storage and peripheral planning.
