TP-Link Omada ES210X-M2 10-Port 2.5G Smart Managed Switch with 10G SFP+
Multi-Gigabit Switching for Modern Networks — Managed, Scalable, Omada-Ready
The TP-Link Omada ES210X-M2 is a 10-port 2.5G smart managed switch designed for businesses, prosumers, and IT professionals who need multi-gigabit wired performance without the cost of a full 10G infrastructure. With eight 2.5G RJ45 ports, two 10G SFP+ uplink slots, and full Omada SDN integration, the ES210X-M2 delivers the switching capacity to support Wi-Fi 6/6E/7 access points, NAS devices, high-performance workstations, and IP cameras — all managed from a single centralised controller or the Omada cloud.
Key Features
8× 2.5G RJ45 Ports — Multi-gigabit copper ports support 100 Mbps, 1 Gbps, and 2.5 Gbps speeds, making them ideal for Wi-Fi 6/6E/7 APs, NAS devices, and high-performance workstations over standard Cat5e or Cat6 cabling.
2× 10G SFP+ Uplink Slots — High-speed fibre or DAC uplinks for connection to core switches, routers, or NAS devices at full 10G wire speed.
Omada SDN Integration — Fully managed via the Omada Software Defined Networking platform — configure, monitor, and manage remotely through the Omada hardware controller, software controller, or Omada Cloud.
Advanced Layer 2+ Management — Supports 802.1Q VLAN, RSTP/MSTP, LACP (802.3ad), QoS (802.1p/DSCP), IGMP Snooping, and port mirroring for enterprise-grade network control.
Access Control Lists (ACL) — Granular traffic filtering and security policies at the port and VLAN level.
LLDP & LLDP-MED — Automatic device discovery and topology mapping for simplified network management.
Fanless Silent Operation — Passive cooling design for quiet deployment in offices, meeting rooms, and home lab environments.
Rack-Mountable — Standard 1U rack-mount form factor with included mounting hardware for data centre and server room installation.
IPv6 Support — Future-ready networking with full IPv6 management and data plane support.
Use Cases
Wi-Fi 6/6E/7 Access Point Aggregation — Provide 2.5G uplinks to Wi-Fi 6E and Wi-Fi 7 access points that exceed Gigabit throughput, eliminating the wired bottleneck that limits wireless performance.
NAS & Storage Networks — Connect NAS devices and workstations at 2.5G for significantly faster file transfers, backups, and media streaming compared to standard Gigabit.
SMB & Enterprise Edge Switching — Deploy as an edge or distribution switch in small-to-medium business networks with full VLAN segmentation, QoS, and centralised Omada SDN management.
IP Surveillance Networks — Aggregate multiple IP cameras and NVRs with VLAN isolation and IGMP Snooping for efficient multicast video traffic management.
Home Lab & Prosumer Networks — Build a high-performance home lab or prosumer network with multi-gigabit switching, 10G uplinks, and enterprise management features at an accessible price point.
Technical Specifications
Specification
Detail
Model
ES210X-M2
RJ45 Ports
8× 2.5G (100M/1G/2.5G auto-negotiation)
SFP+ Uplink Slots
2× 10G SFP+
Switching Capacity
40 Gbps
Forwarding Rate
29.76 Mpps
MAC Address Table
16K
Jumbo Frame
9216 bytes
VLAN
802.1Q VLAN, up to 4094 VLAN IDs
Spanning Tree
STP, RSTP, MSTP
Link Aggregation
802.3ad LACP, up to 8 groups, 8 ports per group
QoS
802.1p, DSCP, 8 queues per port
IGMP Snooping
v1/v2/v3
Management
Omada SDN (cloud/hardware/software controller), Web GUI, CLI (SSH/Telnet), SNMP v1/v2c/v3
Omada App
iOS & Android
Cooling
Fanless (passive cooling)
Form Factor
1U rack-mountable (rack ears included)
Power Supply
Internal, 100–240 V AC
Power Consumption
Max 18.6 W
Operating Temperature
0 °C to 45 °C
Certifications
RCM (AU/NZ), CE, FCC, RoHS
Recommended Accessories
TP-Link Omada OC300 Hardware Controller — Dedicated Omada SDN hardware controller for centralised management of the ES210X-M2 alongside Omada APs and routers without a cloud subscription.
TP-Link Omada EAP773 Wi-Fi 7 Access Point — Wi-Fi 7 AP with 2.5G uplink — pairs perfectly with the ES210X-M2’s 2.5G ports to eliminate the wired bottleneck on high-speed wireless deployments.
TP-Link TXS431-XS 10G SFP+ DAC Cable — Direct Attach Copper cable for short-distance 10G connections between the ES210X-M2 and a core switch or NAS.
TP-Link Omada ER8411 VPN Router — Multi-WAN enterprise VPN router for use as the gateway in an Omada SDN deployment with the ES210X-M2.
Downloads
ES210X-M2 User Guide (PDF) — Omada Networks AU
ES210X-M2 Datasheet (PDF) — Omada Networks AU
Frequently Asked Questions
What is the difference between a 2.5G switch and a standard Gigabit switch?
A standard Gigabit switch maxes out at 1 Gbps per port. A 2.5G switch supports up to 2.5 Gbps per port — 2.5 times faster — over the same Cat5e or Cat6 cabling already installed in most buildings. This makes the ES210X-M2 ideal for connecting Wi-Fi 6E/7 access points and NAS devices that can exceed 1 Gbps throughput.
Does the ES210X-M2 require the Omada controller to function?
No. The ES210X-M2 can be managed standalone via its web GUI or CLI (SSH/Telnet) without any controller. The Omada SDN controller (hardware, software, or cloud) is optional but recommended for centralised management of multiple Omada devices.
What SFP+ modules are compatible with the ES210X-M2?
The ES210X-M2 supports standard 10G SFP+ modules including TP-Link’s own SFP+ transceivers (single-mode, multi-mode fibre) and DAC (Direct Attach Copper) cables. Third-party SFP+ modules may also be compatible — refer to the TP-Link Omada compatibility list for confirmed modules.
Does the ES210X-M2 support PoE?
No. The ES210X-M2 does not include PoE on its RJ45 ports. If you require PoE switching alongside 2.5G ports, consider the TP-Link Omada TL-SX3008F or a dedicated PoE switch in your network design.
Can I manage the ES210X-M2 from the Omada app on my phone?
Yes. When managed through an Omada controller (hardware, software, or cloud), the ES210X-M2 can be monitored and configured via the Omada app on iOS and Android.
Does CCTV Guru ship the ES210X-M2 Australia-wide?
Yes. We ship to all states and territories across Australia, including metro and regional areas, with fast dispatch from our Australian warehouse.
