Dahua 4-Channel Compact WizSense 4K NVR – Smart & Efficient Surveillance The Dahua DHI-NVR4104HS-P-AI-ANZ is a compact yet powerful 4-channel network video recorder designed for residential and small business security systems. Featuring WizSense AI, this NVR supports Smart Motion Detection 4.0 (SMD 4.0) with accurate human and vehicle filtering, along with 4 PoE ports for easy plug-and-play IP camera connectivity. Supporting up to 16MP resolution, 4K HDMI output, and H.265+ compression, this NVR is capable of delivering high-quality video recording and efficient storage performance. It’s housed in a fanless 1U chassis for silent operation and has 1 × SATA slot for up to 10TB HDD (not included). Perfect for: Home surveillance, small offices, retail shops and low-profile, high-quality security setups. Features 4-channel AI-enabled NVR with 4 PoE ports Supports up to 16MP IP cameras SMD 4.0 for accurate human/vehicle motion detection 1 × SATA HDD bay (up to 10TB, not included) H.265+/H.264 compression for efficient storage HDMI output supports 4K (3840×2160) Compact 1U design with fanless operation ONVIF compliant for 3rd-party IP cameras Remote viewing via DMSS app (iOS/Android) Ideal for small-scale residential and business CCTV Specifications Specification Details Model DHI-NVR4104HS-P-AI-ANZ Channels 4 IP Channels PoE Ports 4 × PoE (IEEE802.3af/at) Max Recording Resolution Up to 16MP AI Features WizSense SMD 4.0, IVS Analytics Video Output 1 × HDMI (4K), 1 × VGA Storage 1 × SATA, up to 10TB (HDD not included) Compression H.265+, H.265, H.264 USB Ports 2 × USB 2.0 Remote Access DMSS App, SmartPSS, Web Interface Form Factor Compact 1U, fanless design Dimensions 260 × 232.5 × 47.6 mm Operating Temp -10°C to +55°C Downloads DHI-NVR4104HS-P-AIANZ Datasheet Dahua Network Video Recorder User ManualDahua NVR Quick Start GuideDahua HDD Installation Guide

Read more less

Dahua 4 Channel Penta-brid 4K-N/5MP Compact 1U 1HDD WizSense DVR / XVR Digital Video Recorder, DH-XVR5104HS-4KL-I3 Featiures H.265+/H.265 dual-stream video compression Supports Full-channel AI-Coding Supports HDCVI/AHD/TVI/CVBS/IP video inputs Max 8 channels IP camera inputs, each channel up to 8MP; Max 64 Mbps incoming bandwidth Up to 1 channel video stream (analog channel) Perimeter Protection Up to 4 channels video stream (analog channel) SMD Plus Up to 1 channel video stream (analog channel) human face recognition IoT & POS functionalities Specifications NUMBER OF CHANNELS 4CH NUMBER OF BNC PORTS 4*BNC PORTS NUMBER OF HARD DISK BAY 1*HDD TECHNOLOGY RECORDERS INCOMING BANDWIDTH 64 Mbps incoming MAXIMUM RESOLUTION SUPPORT 4K Downloads dh-xvr5104hs-4kl-i3 datasheetdigital video recorder mini 1u compact qsgcompact mini hdd installation guidedahua hdcvi ai dvr user s manual

Read more less

HiLook NVR‑104MH‑C/4P 4‑Channel PoE Network Video Recorder The HiLook NVR‑104MH‑C/4P is a professional-grade 4-channel NVR with built-in PoE ports, capable of delivering high-performance recording and advanced smart analytics in a compact unit—perfect for small to medium surveillance setups. Key Features Up to 4 IP camera inputs with built-in PoE (IEEE 802.3af/at) Supports efficient H.265+/H.265/H.264+/H.264 video compression Simultaneous HDMI (up to 4K resolution) and VGA outputs Smart VCA analytics: motion detection, line crossing, intrusion, heat map, ANPR, people counting Supports up to 1‑ch @ 8 MP or 5‑ch @ 1080p decoding Smart search and smart playback for quick video access Expandable storage via one SATA bay—up to 8 TB HDD Technical Specifications Specification Details IP Camera Inputs 4‑channel PoE (RJ‑45, IEEE 802.3af/at) Max Incoming Bandwidth 40 Mbps Video Decoding 1‑ch @ 8 MP (30 fps) or 5‑ch @ 1080p (30 fps) Video Compression H.265+/H.265/H.264+/H.264 Smart VCA Functions Motion, line crossing, intrusion, heat map, ANPR, people counting Video Output HDMI: up to 4K (4096×2160 @30 Hz); VGA: up to 1080p @60 Hz Audio 1‑ch input (RCA), 1‑ch output (RCA); supports G.711ulaw/alaw, G.722, G.726 Storage 1 SATA (up to 8 TB HDD) USB 2× USB 2.0 (rear panel) Network 1× RJ‑45 10/100 Mbps + 4× PoE ports Power Supply 48 VDC, 1.35 A Power Consumption ≤ 10 W (without HDD, PoE off) Operating Temp / Humidity –10 °C to 55 °C, 10 % to 90 % RH Dimensions (W×D×H) 265 × 225 × 48 mm Weight (without HDD) ≤ 1 kg Why Choose This NVR? Trusted HiLook NVR with comprehensive VCA analytics Built‑in PoE simplifies camera setup Future‑proof 4K HDMI output Easy to navigate smart playback Australian stock and support available More Informations HiLook NVR-104MH-C/4P DatasheetHiLook NVR 7 Steps Setup

Read more less

Hikvision 4-channel Pro Series Network Video Recorder with PoE The Hikvision DS-7604NI-M1/4P is a compact yet reliable 4-channel NVR from the Pro Series, designed for small to medium surveillance systems. With 4 PoE ports, it supports plug-and-play IP camera integration and simplifies installation without the need for external power sources. Capable of recording up to 8MP resolution and outputting video via HDMI and VGA, this NVR offers clear image quality and efficient video management. H.265+ compression reduces bandwidth and storage usage while maintaining excellent performance. It’s compatible with Hikvision’s smart IP cameras, allowing support for advanced analytics such as line crossing, intrusion detection, and motion detection (via connected cameras). Ideal for homes, retail stores, and small businesses. Features Video Input: 4 IP Channels PoE Ports: 4 built-in PoE ports (IEEE 802.3af/at) Video Output: HDMI up to 4K (3840 × 2160) and VGA Recording Resolution: Up to 8MP Decoding: 1-ch@8MP or 2-ch@4MP Storage Capacity: 1 SATA port (up to 10TB) Smart Features: Motion detection, line crossing, intrusion (with compatible cameras) Remote Access: Hik-Connect mobile app & browser access Compression Technology: H.265+, H.264+ for efficient storage Form Factor: Compact 1U design Power Supply: 48V DC via external power adapter Specifications Technical Specifications – DS-7604NI-M1/4P 4 IP Channels Supports up to 4 network cameras 4 x PoE IEEE 802.3af/at compliant, plug-and-play HDMI & VGA HDMI up to 4K (3840 × 2160) Up to 8MP Supports HD cameras 1-ch@8MP / 2-ch@4MP Multiple stream decoding H.265+/H.265/H.264+/H.264 Efficient storage and streaming 1 SATA Interface Up to 10TB HDD capacity Motion & Intrusion Detection With compatible cameras Hik-Connect, Web Browser Remote viewing and playback 48V DC External adapter included 1U Desktop Compact and space-saving Downloads DS-7604NI-M1/4P Datasheet

Read more less

Uniarch 4-ch 1-SATA Ultra 265/H.265/H.264 NVR, 4 PoE ports, up to 2*4K@30 recording, 1 SATA HDD up to 6TB, bandwidth I/O: 80/64Mbps, support 1-ch HDMI, 1-ch VGA, support cloud upgrade This Uniarch (Uniview) Pro 4K NVR can connect up to 4 x IP cameras and upgrade up to 6TB of storage for longer footage recording. Support Ultra 265/H.265/H.264 video formats 4-channel input Supports mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T ) and RTSP protocols Support 1-ch HDMI, 1-ch VGA HDMI and VGA simultaneous output Up to 4K resolution recording 1 SATA HDD up to 6 TB Support cloud upgrade Specifications NVR Number of Channels 4 Channel Number of PoE Ports 4 x PoE Ports Number of Hard Disk Bay 1 x HDD Bay Technology Uniarch Pro Series Network Bandwidth 80Mbps Incoming, 64Mbps Outgoing Maximum Resolution Support 8MP Downloads NVR-104X-P4 V1.00Uniarch-NVR-Network Video Recorders Quick Guide-V1.00Uniarch-NVR-PoE Security System Quick Guide-V1.00Uniarch Network Video Recorders User Manual-V1.00

Read more less

Uniview UNV NVR501-04B-P4 4-Channel PoE NVR The NVR501-04B-P4 is a compact 4-channel PoE NVR that delivers plug-and-play setup, efficient Ultra 265/H.265/H.264 recording, and simultaneous HDMI (up to 4K) + VGA output. It supports up to 16 MP recording, includes ANR to protect video during network drops, and offers cloud upgrade for easy maintenance. Key Features 4-channel IP input; 4× PoE ports (plug & play) Ultra 265 / H.265 / H.264 video formats HDMI up to 4K + VGA, simultaneous output Up to 16 MP recording ANR (Automatic Network Replenishment) for storage reliability Supports mainstream ONVIF/RTSP cameras (Profile S/G/T) Cloud upgrade supported Technical Specifications Brand / Model (SKU) Uniview UNV / NVR501-04B-P4 IP Inputs 4 channels PoE Interfaces 4 × RJ45 10/100M (independent PoE) Video Formats Ultra265 / H.265 / H.264 Max Recording Up to 16 MP Local Outputs 1 × HDMI (up to 3840×2160), 1 × VGA; simultaneous Storage 1 × SATA (up to 8 TB per HDD) USB Rear: 1 × USB2.0 & 1 × USB3.0 Network Port 1 × RJ45 10/100M (LAN) Alarm / RS-485 / RS-232 N/A / N/A / N/A Power Supply DC 48 V / 1.35 A (model spec) Environment Intended for continuous operation; ANR for network outages Certifications CE, FCC, UL, RoHS, WEEE What’s Included Uniview UNV NVR501-04B-P4 Power adaptor, mouse, quick guide Customer Requirements RJ45 Cat6 cables to cameras; PoE budget planning Surveillance-grade HDD (up to 16 TB) for recording HDMI/VGA cable for local display (optional) More Information Uniview UNV NVR501-04B-P4 Datasheet Uniview UNV NVR501-04B-P4 Product Page Uniview UNV Quick Start Guide

Read more less

The Uniview NVR501-04B-P4-IQ is a professional-grade 4-channel Network Video Recorder from the Prime Series, engineered for high-performance security. Equipped with 4 independent PoE interfaces and support for up to 4K (8MP) resolution, this NVR is designed for users who need a compact yet powerful recording solution. Its integrated IQ (Intelligent Analysis) features allow for advanced search and smart event filtering, making it easier than ever to manage your security footage. Key Performance Features 4K Ultra-HD Output: Supports recording and playback of up to 4K (3840 x 2160) resolution for maximum detail. Plug & Play PoE: 4 independent PoE network interfaces allow for easy installation—simply plug in your UNV cameras and the NVR does the rest. Ultra 265 Compression: Save up to 75% on storage space and bandwidth without losing image quality compared to standard H.264. Intelligent AI Analysis: Supports advanced features such as human and vehicle detection, intrusion zones, and smart search, allowing you to find critical events in seconds. ANR Technology: Automatic Network Replenishment ensures video is stored on the camera's SD card if the connection to the NVR is lost, then synced back once restored. Cloud Upgrade: Stay up-to-date with one-click cloud firmware updates via the EZView mobile app. Technical Specifications IP Video Input 4 Channels PoE Interfaces 4 Ports (IEEE 802.3at/af) Incoming Bandwidth 40Mbps Outgoing Bandwidth 64Mbps SATA Interface 1 SATA up to 8TB HDMI Output 4K (3840 x 2160) @30Hz Compression Ultra 265 / H.265 / H.264 More Information Download Official Data Sheet Uniview UNV NVR Quick Start Guide Uniview UNV NVR501-04B-P4-IQ Dimension Guru Tip: The "IQ" in the model name means this NVR is optimized for AI. To get the best results, pair this with UNV Prime series cameras. It will allow you to filter recordings by human or vehicle, saving you from scrolling through hours of "empty" motion footage.

Read more less

HiLook DVR-204U-M1 4 Channel Recorder, 1 x HDD Bay, 5 MP Resolution, 1U, H.265 DVR The HiLook DVR-204U-M1 offers 4-channel recording with 1x HDD bay and 5 MP resolution. Utilizing deep learning technology, it provides Motion Detection 2.0 for accurate human and vehicle target classification. With H.265 Pro+ and H.265 video compression, this DVR supports multiple video inputs and up to 8 MP encoding. Features Deep learning based human and vehicle targets classification of Motion Detection 2.0 H.265 Pro+/H.265 Pro/H.265 video compression HDTVI/AHD/CVI/CVBS/IP video inputs Audio via coaxial cable Up to 6-ch IP camera inputs (up to 8 MP) Up to 8 MP@8 fps encoding capability Motion Detection 2.0 Human/Vehicle Analysis: Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported; Recording Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 Encoding Resolution: 8 MP/5 MP/3K/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF Frame Rate: Main stream: 8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) Sub-stream: WD1/4CIF/CIF@25 fps (P)/30 fps (N) Video Bitrate: 32 Kbps to 10 Mbps Dual-Stream: Support Stream Type: Video, Video & Audio Audio Compression: G.711u Audio Bitrate: 64 Kbps Video And Audio IP Video Input: 2-ch (up to 6-ch) Enhanced IP mode on: 4-ch (up to 8-ch), each up to 4 Mbps Up to 8 MP resolution: Support H.265+/H.265/H.264+/H.264 IP cameras Analog Video Input: 4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection Network Total Bandwidth: 96 Mbps Remote Connection: 32 Network Protocol: TCP/IP, PPPoE, DHCP, HiLookVision, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF Network Interface: 1, RJ45 10M/100M self-adaptive Ethernet interfac Wi-Fi: Connectable to Wi-Fi network by Wi-Fi dongle through USB interface Auxiliary Interface SATA: 1 SATA interface Capacity: Up to 10 TB capacity for each disk Alarm In/Out: N/A USB Interface: 2 × USB 2.0 General Power Supply: 12 VDC, 1.5 A Consumption: ≤ 15 W (without HDD) Working Temperature: -10 °C to +55 °C (+14 °F to +131 °F) Working Humidity: 10% to 90% Dimension (W × D × H): 265 × 225 × 48 mm (10.4 × 8.9 × 1.9 inch) Weight: ≤ 1.16 kg (without HDD, 2.6 lb.) Downloads Data SheetQuick Start GuideUser Manual

Read more less

HiLook NVR-104MH-K/4P 4 Channel, 4 x PoE, 1U, 1 x HDD Bay, K Series, AI 4K NVR Recorder The HiLook NVR-104MH-K/4P is a 4-channel NVR recorder with 1 x HDD bay and 4 power-over-Ethernet interfaces. With up to 40 Mbps incoming bandwidth, it supports high-quality video formats such as H.265+/H.265/H.264+/H.264. Using HiLook AI technology, it offers intelligent analytics for facial recognition, perimeter protection, and motion detection, reducing manual effort and security costs. Features Up to 4-ch IP camera inputs, plug & play with 4 power-over-Ethernet (PoE) interfaces H.265+/H.265/H.264+/H.264 video formats Up to 1-ch@12 MP or 2-ch@8 MP or 4-ch@4 MP or 8-ch@1080p decoding capacity Up to 40 Mbps incoming bandwidth Adopt HiLook AI technology to minimize manual effort and security costs Intelligent Analytics AI By Device: Facial recognition, perimeter protection, motion detection 2.0 AI By Camera: Facial recognition, perimeter protection, throwing objects from building, motion detection2.0, ANPR, VCA Facial Recognition Face Attributes: N/A Facial Detection And Analytics: Face picture comparison, human face capture, face picture search Face Picture Comparison (Captured From Camera): 2-ch Motion Detection 2.0 By Device: All channels, 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm By Camera: All channels Perimeter Protection By Device: 1-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm By Camera: All channels Video And Audio IP Video Input: 4-ch Incoming Bandwidth: 40 Mbps Outgoing Bandwidth: 80 Mbps HDMI Output: 1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz VGA Output: 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz Video Output Mode: HDMI1/VGA simultaneous output CVBS Output: N/A Audio Output: 1-ch, RCA (Linear, 1 KΩ) Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) Decoding Decoding Format: H.265/H.265+/H.264+/H.264 Recording Resolution: 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Synchronous Playback: 4-ch Decoding Capability: AI on: 1-ch@12 MP (30 fps)/1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps), AI off: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps) Stream Type: Video, Video & Audio Audio Compression: G.711ulaw/G.711alaw/G.722/G.726/AAC Network Remote Connection: 128 API: ONVIF (profile S/G); SDK; ISAPI Compatible Browser: IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version Network Protocol: TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS Network Interface: 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface PoE Interface: 4, RJ-45 10/100 Mbps self-adaptive Ethernet interface Power: ≤ 50 W Standard: IEEE 802.3af/at Auxiliary Interface SATA: 1 SATA interface Capacity: Up to 10 TB capacity for each HDD USB Interface: Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 Downloads NVR-104MH-K/4P DatasheetHilook NVR 7 Steps Setup

Read more less

TP-Link VIGI 4 Channel PoE+ Network Video Recorder - VIGI NVR1104H-4P 4K HDMI Video Output & 16MP Decoding Capacity: Sharp image definition up to 8MP and a 4-channel display ensures you capture every detail, from every angle‡. Simplified Deployment with PoE+: Easily connect and power your PoE camera with one RJ45 cable transmitting both data and power. No power adapter is needed. Simple HDD Installation†: Install and remove the HDD manually with easy side access. 4-Channel Simultaneous Playback△ : Replay the feed from up to 4 cameras at the same time, increase replay speed, and find events in the video schedule to easily review footage. H.265+: Without using any extra bandwidth, your camera transmits compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality. ONVIF Ensures Compatibility*: Easily add IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility. Plug & Play: Allows new and unused VIGI IP Cameras to be added automatically to the new NVR and activated instantly, making installation faster than ever before. 24/7 Continuous Recording: Stores up to 10 TB of footage from connected cameras to secure your data for quick, convenient access. Remote Monitoring: The dedicated VIGI app, web UI, and VIGI Security Manager enable remote monitoring, providing ease and convenience. Built-In Speaker: Enjoy real-time audio output without needing peripherals for greater convenience. Flexible Installation: Choose the suitable installation method by simply mounting your NVR on the wall, or placing it on or under a desk. Every angle all on one screen.4K HDMI Video Output & 16MP Decoding CapacitySharp image definition up to 8MP and a 4-channel display ensure you capture every detail, from every angleDedicated 4 PoE+ ports (53 W budget) for simplified IP camera deploymentFeatures 4× 10/100Mbps PoE+ ports, the NVR supports up to 30 W on each PoE+ port. Designed to use a single Ethernet cable for both data and power transmission, it offers flexible installation to fit in various surveillance scenarios for small businesses, such as groceries, warehouses, restaurants, and financial institutions.Reviewing footage is faster than ever.4-Channel Simultaneous PlaybackReplay the feed from up to 4 cameras at the same time, increase replay speed, and find events in the video schedule to easily review footage.More Compression. More Savings. More Quality.Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.No need to check long compatibility lists.ONVIF Ensures CompatibilityEasily add IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility Plug & Play.Allows new and unused VIGI IP Cameras to be added automatically to the new NVR and activated instantly, making installation faster than ever before.Security for every hour and every day.24/7 Continuous RecordingStores up to 10 TB of footage from managed cameras to secure your data for quick, convenient access.Keep an eye on things even when you are on the move.Remote MonitoringThe dedicated VIGI app, web UI, and VIGI Security Manager enable remote monitoring, providing ease and convenience.Greet your visitors before they enter.Two-Way AudioWith voice intercom support, carry two-way conversations while watching your feed from anywhere. Suitable for management.One system. Full security.Run your business with peace of mind.The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound. DownloadDatasheet

Read more less

Hikvision AcuSense 4CH DVR, 5MP@12fps, HDTVI/AHD/CVI/CVBS/IP, 2 HDD Bays, 4TB HDD (7204) The Hikvision AcuSense 4CH DVR is an expertly-designed device with advanced features. With 4 channels and 2 HDD bays, it allows for efficient H.265 pro+ compression and can encode up to 8 MP lite @ 15 fps or 5 MP @ 12 fps. Its deep learning-based human and vehicle target classification helps to reduce false alarms, making it a reliable and accurate security solution. It can also adaptively receive signals from HDTVI/AHD/CVI/CVBS/IP sources and connect up to 8 network cameras. Features 4 channels and 2 HDDs 1U AcuSense DVR False alarm reduction by human and vehicle target classification based on deep learning Efficient H.265 pro+ compression technology Encoding abilty up to 8 MP lite @ 15 fps, 5 MP @ 12 fps 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP) Up to 8 network cameras can be connected

Read more less

Dahua 4 Channel DVR,  Penta-brid Record Up to 4K, IVS, Face Detection, Smart Search, Smart Fan, P2P This conventional Digital Video Recorder, DVR can connect up to 6 x HDCVI or IP  cameras with coaxial cables. Work with DMSS app and SmartPSS.  H.265+/H.265 dual-stream video compression Supports HDCVI/AHD/TVI/CVBS/IP video inputs Max 6 channels IP camera inputs, each channel up to 8MP; Max 24Mbps Incoming Bandwidth Smart Search and Intelligent Video System Specifications HD-RECORDER Number of Channesl 4 Channel Number of BNC Ports 4 x BNC Ports Nubmber of Hard Disk Bay 1 x HDD Bay Technology HD Recorder, DVR, XVR Incoming Bandwidth 24 Mbps Incoming Maximum Resolution Support 4K Downloads Datasheet of XVR5104HUser Manual of XVR5104H

Read more less

Uniarch 4 CH 1-SATA Ultra 265/H.265/H.264 NVR, 4 PoE ports, up to 1*4K @ 30 recording, 1 SATA HDD up to 6TB, bandwidth I/O: 40/40Mbps, support 1-ch HDMI, 1-ch VGA, support cloud upgrade.  This Uniarch (Uniview) Lite 4K NVR can connect up to 4 x IP cameras and upgrade up to 6TB of storage for longer footage recording. Support Ultra 265/H.265/H.264 video formats 4/8-channel input Plug & Play with 4/8 independent PoE network interfaces Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T Support 1-ch HDMI, 1-ch VGA HDMI and VGA simultaneous output Up to 8MP resolution recording 1 SATA HDD up to 6TB Support cloud upgrade Specifications Number of Channels 4 Channel Number of PoE Ports 4 x PoE Ports Number of Hard Disk Bay 1 x HDD Bay Technology Uniarch Lite Series Network Bandwidth 40Mbps Incoming, 40Mbps Outgoing Maximum Resolution Support 8MP Downloads NVR-E2-P Series V1.00Uniarch-NVR-Network Video Recorders Quick Guide-V1.00Uniarch-NVR-PoE Security System Quick Guide-V1.00Uniarch Network Video Recorders User Manual-V1.00

Read more less

TP-Link VIGI 4 Channel PoE+ Network Video Recorder - VIGI NVR1004H-4P 4K HDMI Video Output & 16MP Decoding Capacity: Sharp image definition up to 8MP and a 4-channel display ensures you capture every detail, from every angle. Simplified Deployment with PoE: Easily connect and power your PoE camera with one RJ45 cable transmitting both data and power. No power adapter is needed. 4-Channel Simultaneous Playback: Replay the feed from up to 4 cameras at the same time, increase replay speed, and find events in the video schedule to easily review footage. H.265: Without using any extra bandwidth, your camera transmits compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality. ONVIF Ensures Compatibility: Easily add IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility. Plug & Play: Allows new and unused VIGI IP Cameras to be added automatically to the new NVR and activated instantly, making installation faster than ever before. 24/7 Continuous Recording: Stores up to 10 TB of footage from connected cameras to secure your data for quick, convenient access. Remote Monitoring: The dedicated VIGI app and VIGI Security Manager enable remote monitoring, providing ease and convenience. Two-Way Audio: With voice intercom support, carry two-way conversations while watching your feed from anywhere. Suitable for management. 80 Mbps Video Access Bandwidth: High video access bandwidth ensures your NVR manages more cameras with high resolution. Based on laboratory testing using VIGI cameras, VIGI NVR can manage up to four 4MP cameras. Every angle all on one screen.4K HDMI Video Output & 16MP Decoding CapacitySharp image definition up to 8MP and a 4-channel display ensures you capture every detail, from every angle† .Dedicated 4 PoE+ ports (53 W budget) for simplified IP camera deployment .Features 4× 10/100Mbps PoE+ ports, the NVR supports up to 30 W on each PoE+ port. Designed to use a single Ethernet cable for both data and power transmission, it offers flexible installation to fit in various surveillance scenarios for small businesses, such as groceries, warehouses, restaurants, and financial institutions.Reviewing footage is faster than ever. 4-Channel Simultaneous PlaybackReplay the feed from up to 4 cameras at the same time, increase replay speed, and find events in the video schedule to easily review footage.More compression. More savings. Same quality.Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.No need to check long compatibility lists.ONVIF Ensures CompatibilityEasily add IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility.Plug & Play.Allows new and unused VIGI IP Cameras to be added automatically to the new NVR and activated instantly, making installation faster than ever before.Security for every hour and every day.24/7 Continuous RecordingStores up to 10 TB of footage from managed cameras to secure your data for quick, convenient access.Keep an eye on things even when you are on the move.Remote MonitoringThe dedicated VIGI app, web UI, and VIGI Security Manager enable remote monitoring, providing ease and convenience.Greet your visitors before they enter.Two-Way AudioWith voice intercom support, carry two-way conversations while watching your feed from anywhere. Suitable for management.Higher bandwidth for high-definition cameras.80 Mbps Video Access BandwidthHigh video access bandwidth ensures your NVR manages cameras with high resolutions. Based on laboratory testing using VIGI cameras, VIGI NVR can manage up to four HD cameras.One system. Full security.Run your business with peace of mind.The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
