UniFi Gateways Consoles

Ubiquiti Dream Machine Special Edition, All-In-One Unifi Solution, 8x Gbe PoE RJ45 Ports, 3.5' HDD Bay. You can use this UDM-SE as all-in-one router and security gateway with an integrated PoE switch and NVR network video recorder. The UniFi Dream Machine - Special Edition is the first UniFi Console that offers a full UniFi application suite right out of the box. Instantly run a complete UniFi deployment without the need for an additional PoE Switch, NVR, or Hard Disk Drive for storage. The UDM SE is an all-in-one router/security gateway that can power your UniFi devices directly from the integrated 8 port gigabit PoE switch and store your UniFi Protect recordings on the integrated 128GB internal hard drive. UDM SE is completely scalable and customizable, so you can easily expand your deployment. Enterprise-grade, rack-mount UniFi Cloud Gateway with full UniFi application support, 10 Gbps Cloud Gateway with 100+ UniFi device / 1,000+ client support, 3.5 Gbps IPS routing, and built-in PoE switching. Includes full UniFi application suite for device management 3.5+ Gbps routing with IDS/IPS (1) 10G SFP+*, (8) GbE RJ45 LAN ports including (2) PoE+, and (6) PoE (1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports (1) 3.5" NVR HDD bay Built-in 128 GB SSD for NVR detection recordings 1.3" touchscreen Technical Specifications Mechanical Dimensions 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") Weight 5 kg (10.9 lb) Enclosure material Aluminium CNC, SGCC steel Mount material SGCC steel Hardware Processor Quad-core ARM® Cortex®-A57 at 1.7 GHz System memory 4 GB DDR4 On-board storage 16 GB eMMCIntegrated 128 GB SSD Management interface EthernetBluetooth Networking interface LAN:(8) GbE RJ45 ports(1) 10G SFP+ portWAN:(1) 2.5 GbE RJ45 port(1) 10G SFP+ port PoE interface (6) PoE (Pair A 1, 2+; 3, 6-)(2) PoE+ (Pair A 1, 2+; 3, 6-) IDS/IPS throughput 3.5 Gbps**Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation. Power method (1) Universal AC input, 100—240V AC, 4.4A Max., 50/60 Hz(1) USP-RPS DC input, 52V DC, 3.94A Power supply AC/DC, internal, 240W Supported voltage range 100—240V AC Max. power consumption 50W (Excluding PoE output) PoE budget 180W Max. PoE wattage per port by PSE PoE: 15.4WPoE+: 30W Voltage range PoE mode PoE: 44—57VPoE+: 50—57V ESD/EMP protection Air: ± 15kV, contact: ± 8kV LCM display (1) 1.3" touchscreen Button Factory reset Ambient operating temperature -10 to 40° C (14 to 104° F) Ambient operating humidity 5 to 95% noncondensing Certifications CE, FCC, IC Gateway Features Performance Redundant WAN with failover and load balancingWiFi QoS with UniFi APsApplication, domain, and country-based QoSApplication and device type identificationAdditional internet failover with LTE BackupInternet quality and outage reporting Next-generation security Application-aware firewall rulesSignature-based IPS/IDS threat detectionContent, country, domain, and ad filteringVLAN/subnet-based traffic segmentationFull stateful firewall Advanced networking License-free SD-WANWireGuard, L2TP and OpenVPN serverOpenVPN clientOpenVPN and IPsec site-to-site VPNOne-click Teleport and Identity VPNPolicy-based WAN and VPN routingDHCP relayCustomizable DHCP serverIGMP proxyIPv6 ISP support LEDs Ethernet White: link/activity SFP+ White: link/activity HDD White: disk activityAmber: disk error RPS Blue: ready Downloads Installation Guide

Read more less

All-in-one, enterprise-grade UniFi OS Console and security gateway designed to host the full UniFi application suite.Connect the Dream Machine Pro with a USP RPS to create an uninterruptible network.Features: Pre-installed UniFi Network application LAN ports: (8) GbE RJ45, (1) 10G SFP+ WAN ports: (1) GbE RJ45, (1) 10G SFP+ Threat management and traffic/client identification (1) 3.5" HDD bay for storing UniFi Protect recordings Downloads Datasheet Installation Guide

Read more less

UDR - UniFi Dream Router The Dream Router (UDR) is a next-generation WiFi 6 router that delivers unbeatable performance at an unmatched price. Featuring advanced 4x4 MU-MIMO and OFDMA technology, the UDR has an aggregate wireless throughput rate of up to 3 Gbps over its 2.4 and 5 GHz bands, ensuring quality connectivity for all of your devices. The UDR also has (5) GbE RJ45 ports, including two that supply PoE to compatible devices, and all of its connections can be conveniently monitored from the router's LCM color screen. Designed to be a comprehensive, easy-to-use network hub, the UDR can be set up and configured in minutes via the UniFi Network web application or mobile app. Features: Four-stream WiFi 6 technology 5 GHz band (4x4 MU-MIMO/OFDMA) with a 2.4 Gbps throughput rate 2.4 GHz band (4x4 MIMO) with a 600 Mbps throughput rate 128 GB of internal storage (1) GbE RJ45 WAN port (4) LAN ports, including (2) 802.3af PoE outputs 0.96" LCM color screen for network and connection monitoring Micro SD memory card expansion slot* *Requires a memory card with at least 128 GB of storage. Downloads Datasheet Installation Guide

Read more less

  Impressively compact UniFi Cloud Gateway and WiFi 6 access point that runs UniFi Network. Powers an entire network or simply meshes as an access point.  Built-in WiFi 6 AP 140 m² (1,500 ft²) single-unit coverage 60+ connected WiFi devices (1) GbE RJ45 WAN port (1) GbE RJ45 LAN port to extend network 0.96" LCM status display Manages up to four additional UniFi Network devices when operated as a gateway Managed with UniFi Network 8.0.7 and later Technical Specifications Mechanical Dimensions 98 x 98 x 30 mm (3.6 x 3.6 x 1.2") Weight 302 g (10.7 oz) Enclosure material Polycarbonate Hardware Management interface EthernetBluetooth Networking interface LAN:(1) GbE RJ45 portWAN:(1) GbE RJ45 port Power method USB type C (5V DC/3A) Max. power consumption 10W Max. TX power2.4 GHz5 GHz 22 dBm25 dBm MIMO2.4 GHz5 GHz 2 x 2 (DL/UL MU-MIMO)2 x 2 (DL/UL MU-MIMO) Throughput rate2.4 GHz5 GHz 573.5 Mbps2.4 Gbps Antenna gain2.4 GHz5 GHz 4 dBi5.15 dBi Antennas (2) Internal 2.4G/5G WiFi dual-band antenna(1) Internal 2.4G single-band BT antenna LCM display 0.96" status display Button Factory reset Operating temperature -10 to 45° C (14 to 113° F) Operating humidity 5 to 95% noncondensing Certifications CE, FCC, IC Software WiFi standards 802.11a/b/g/n/ac/ax Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) BSSID Console mode: 3 per bandStandard AP: 8 per band VLAN 802.1Q Advanced QoS Per-user rate limiting Guest traffic isolation Supported Concurrent clients 60+ Zero wait DFS Yes Supported Data Rates 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n (WiFi 4) 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) Application Requirements UniFi Network Version 8.0.7 and later Downloads UX Installation Guide

Read more less

Ubiquiti Gateway Max, Multi-WAN UniFi Gateway, 4x 2.5G LAN, 1x 2.5G WAN, 1.5 Gbps Routing with IDS/IPS, Requires Cloud Key/Network Server Compact, multi-WAN independent gateway with full 2.5G support for high-performance networking at small-to-medium sites. Features Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server Up to 1.5 Gbps routing with IDS/IPS (1) 2.5 GbE WAN port (4) 2.5 GbE LAN ports, including (1) remappable to WAN USB-C powered (adapter included) Managed with UniFi Network 8.1.113 and later Downloads Installation Guide Technical Specifications Mechanical Dimensions 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2") Weight 520 g (1.1 lb) Enclosure material Polycarbonate Resistance IK04 Hardware Processor Quad-core ARM® Cortex®-A53 at 1.5 GHz Memory information 2 GB DDR4 Management interface EthernetBluetooth Networking interface LAN:(4) 2.5 GbE RJ45 portsWAN:(1) 2.5 GbE RJ45 port IDS/IPS throughput 1.5 Gbps**Measured with iPerf3 on DHCP WAN. Performance may be reduced with PPPoE depending on ISP implementation. Power method USB type C (5V/3A) Supported voltage range 100–240V Max. power consumption 9.6W LED EthernetWhite: link/activity Button (1) Factory reset Ambient operating temperature -10 to 40° C (14 to 104° F) Ambient operating humidity 5 to 95% noncondensing Certifications CE, FCC, IC Gateway Features Performance WiFi QoS with UniFi APsApplication, domain, and country-based QoSApplication and device type identificationInternet quality and outage reporting Next-generation security Application-aware firewall rulesSignature-based IPS/IDS threat detectionContent, country, domain, and ad filteringVLAN/subnet-based traffic segmentationFull stateful firewall Advanced networking License-free SD-WAN*WireGuard, L2TP and OpenVPN serverOpenVPN clientOpenVPN and IPsec site-to-site VPNOne-click Teleport* and Identity Enterprise VPN**Policy-based WAN and VPN routingDHCP relayCustomizable DHCP serverIPv6 ISP support*When paired with a CloudKey or Official UniFi Hosting.**When paired with a CloudKey. Application Requirements UniFi Network Version 8.1.113 and later

Read more less

Ubiquiti Cloud Key+, UniFi OS Console Connects To Site Manager, Pre-installed 1TB SSD, Connect & Power via PoE, Optional USB-C Power Compact UniFi Console that connects directly to the Site Manager at https://unifi.ui.com/ for powerful, multi-application site management. Features Includes full UniFi application suite for device management Pre-installed 1TB SSD Connect and power using PoE Optional USB-C power with Quick Charge 2.0/3.0 compliant adapter only Bluetooth for instant setup Downloads Installation Guide Technical Specifications Mechanical Dimensions 131.2 x 27.1 x 134.2 mm (5.2 x 1.1 x 5.3") Weight 560 g (1.2 lb) Enclosure material Anodized aluminum Hardware Processor Octa-core Arm® Cortex®-A53 based chip Management interface EthernetBluetooth Networking interface (1) GbE RJ45 port Memory 32 GB eMMC3 GB RAM SSD capacity 1 TB 2.5" SATA SSD (user-upgradeable*)*CloudKey+ only supports drives that can operate on 5V power. Drives that require additional power are not supported. Power method PoEQuick charge 2.0/3.0 power adapter, 9V DC, 2A Max. power consumption 9.6W Display 1.42" gray-scale OLED LEDs (1) Power: white/blue Buttons (1) Power(1) Factory reset Ambient operating temperature 0 to 35° C (32 to 104° F) Ambient operating humidity 20 to 80% noncondensing Certifications FCC, CE, IC Capacity HD cameras2K cameras4K cameras 24148Assumes the UCK-G2-SSD is dedicated to UniFi Protect only. If it’s also running UniFi Network, your maximum camera limit will be lower.

Read more less

Ubiquiti Dream Machine Pro Max, 10 Gbps Cloud Gateway with 200+ UniFi device / 2,000+ client support, 5 Gbps IPS routing, and redundant NVR storage Enhanced computing power and memory for 2x the UniFi device and client capacity of Dream Machine Pro/SE Includes full UniFi application suite for device management 5 Gbps routing with IDS/IPS (1) 10G SFP+*, (8) GbE RJ45 LAN ports (1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports (2) 3.5" NVR HDD bays with RAID data protection Built-in 128 GB SSD for NVR detection recordings 1.3" touchscreen Technical Specifications Mechanical Dimensions 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") Weight 4.7 kg (10.4 lb) Enclosure material Aluminium CNC, SGCC steel Mount material SGCC steel Hardware Processor Quad-core ARM® Cortex®-A57 at 2.0 GHz System memory 8 GB DDR4 On-board storage 32 GB eMMCIntegrated 128 GB SSD Management interface Ethernet Bluetooth Networking interface LAN:(8) GbE RJ45 ports(1) 10G SFP+ portWAN:(1) 2.5 GbE RJ45 port(1) 10G SFP+ port IDS/IPS throughput 5 Gbps**Measured with iPerf3. Power method (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz(1) USP-RPS DC input,12V DC, 4.6A Power supply AC/DC, internal, 100W Supported voltage range 100—240V AC Max. power consumption 60W ESD/EMP protection Air: ± 15kV, contact: ± 8kV LCM display (1) 1.3" touchscreen Button Factory reset Ambient operating temperature -10° to 40° C (14° to 104° F) Ambient operating humidity 5 to 95% noncondensing Certifications CE, FCC, IC Gateway Features Performance Redundant WAN with failover and load balancingWiFi QoS with UniFi APsApplication, domain, and country-based QoSApplication and device type identificationAdditional internet failover with LTE BackupInternet quality and outage reporting Next-generation security Application-aware firewall rulesSignature-based IPS/IDS threat detectionContent, country, domain, and ad filteringVLAN/subnet-based traffic segmentationFull stateful firewall Advanced networking License-free SD-WANWireGuard, L2TP and OpenVPN serverOpenVPN clientOpenVPN and IPsec site-to-site VPNOne-click Teleport and Identity VPNPolicy-based WAN and VPN routingDHCP relayCustomizable DHCP serverIGMP proxyIPv6 ISP support LEDs Ethernet Green: link/activity SFP+ Green: link/activity HDD White: disk activityAmber: disk error RPS Blue: ready Downloads Installation Guide

Read more less

All-in-one internet gateway, WiFi access point, and UniFi Console with an abundance of PoE ports. Integrated Enterprise WiFi6 (4x4 MIMO)] Full UniFi OS and UniFi application support 3.5+ Gbps routing (1) 10G SFP+, (17) GbE RJ45 LAN ports including (4) PoE++, (4) PoE+, and (4) PoE ports (1) 10G SFP+, (1) 2.5GbE RJ45 WAN ports 4.7" touchscreen for management Integrated 128 GB SSD & pre-installed 512 GB microSD card Downloads Installation Guide Technical Specifications Mechanical Dimensions 549 x 342 x 62 mm (21.6 x 13.5 x 2.4") Weight 8.6 kg (19 lb) Enclosure materials Polycarbonate, galvanized steel, aluminum alloy Mount material Stainless steel Hardware Processor Quad-core ARM® Cortex®-A57 at 1.7 GHz System memory 4 GB DDR4 On-board storage 16 GB eMMCIntegrated 128 GB SSDPre-installed 512 GB microSD card Expansion slot Micro SD memory card* *Requires a memory card with at least 128 GB of storage. Management interface Ethernet Bluetooth WiFi Networking interface (17) LAN: GbE RJ45 ports(1) WAN: 2.5 GbE RJ45 port SFP+ interface (1) LAN: 10G SFP+ port(1) WAN: 10G SFP+ port PoE interface (4) PoE (Pair A 1, 2+; 3, 6-)(4) PoE+ (Pair A 1, 2+; 3, 6-)(4) PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-) Power method Universal AC input 100—240V AC, 7A Max., 50/60Hz Power supply (2) Hot-Swappable AC/DC 550W PSU**Comes with (1) pre-installed PSU. Max. power consumption 532W Max. PoE wattage per port by PSE PoE: 15.4WPoE+: 30WPoE++: 60W Voltage range PoE mode PoE: 44—57VPoE+/PoE++: 50—57V Max. TX power2.4 GHz5 GHz 23 dBm26 dBm MIMO2.4 GHz5 GHz 2 x 24 x 4 Throughput rate2.4 GHz5 GHz 300 Mbps2.4 Gbps Antenna gain2.4 GHz5 GHz 5.9 dBi6 dBi ESD/EMP protection Air: ± 8kV, contact: ± 4kV LCM display (1) 4.7" touchscreen Button Factory reset Mounting Wall mount (included) Operating temperature -10 to 40° C (14 to 104° F) Operating humidity 5 to 95% noncondensing Certifications CE, FCC, IC Software WiFi standards 802.11a/b/gWiFi 4/WiFi 5/WiFi 6 Wireless security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) BSSID 8 per radio VLAN 802.1Q Advanced QoS Per-user rate limiting Guest traffic isolation Supported Concurrent clients 300+ LEDs Ethernet White: link/activity SFP+ White: link/activity PSU Blue: ready Amber: failure Supported Data Rates 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n (WiFi 4) 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) 802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
