Ubiquiti Cloud Gateway Max · NDAA & TAA COMPLIANT
Ubiquiti UCG-Max: High-Performance 2.5G Multi-WAN Cloud Gateway with Built-In NVR Storage
Engineered for high-density small-to-medium deployment environments, the Ubiquiti UCG-Max delivers enterprise-grade multi-WAN routing, advanced security inspection, and selectable NVR storage capabilities inside a remarkably compact footprint. Designed to streamline unified network management, it supports the full UniFi application ecosystem to provide seamless control over network infrastructure, security gateways, and high-definition surveillance feeds.
Routing Throughput
2.3 Gbps IDS/IPS
Interface Speed
5x 2.5 GbE RJ45
NVR Storage
512 GB NVMe SSD
Device Capacity
30+ UniFi / 300+ Clients
Advanced Threat Management and Scalable Architecture
The Ubiquiti UCG-Max integrates deep packet inspection, signature-based IDS/IPS threat detection, and application-aware firewall policies to secure complex commercial perimeters. License-free SD-WAN capabilities, multi-WAN load balancing, and WireGuard/OpenVPN server support ensure optimized site-to-site connectivity without recurring subscription overheads. Review full deployment parameters on our Ubiquiti UCG-Max product page.
Multi-Gigabit 2.5G Performance
Equipped with five 2.5 GbE ports, the gateway removes internal bottlenecks, allowing businesses to leverage multi-gigabit internet connections and high-speed local network transfers seamlessly across switches and access points.
Integrated UniFi Protect NVR
Featuring built-in NVMe SSD storage, the unit transforms into a fully functional network video recorder capable of managing multiple high-definition security streams without requiring a separate dedicated appliance.
Technical Specification Matrix
| Model |
UCG-Max |
| Processor |
Quad-core ARM Cortex-A53 at 1.5 GHz |
| System Memory |
3 GB DDR4 |
| On-Board Storage |
512 GB NVMe SSD |
| Networking Interface |
(5) 1/2.5 GbE RJ45 ports (1 WAN, 4 LAN) |
| IDS/IPS Throughput |
2.3 Gbps |
| Power Method |
USB Type-C (5V DC/5A) |
| Enclosure Material |
Polycarbonate |
Does the UCG-Max support multiple WAN connections for failover?
Yes, the gateway supports multi-WAN load balancing and automated failover configurations to maintain uninterrupted business connectivity.
How many security cameras can the built-in NVR handle?
Depending on resolution settings, the unit can comfortably manage up to 15 HD cameras, 8 2K cameras, or 5 4K UniFi security cameras utilizing its integrated NVMe storage.
Is a software subscription required for advanced routing features?
No, all core networking, firewall, deep packet inspection, and license-free SD-WAN features are included natively through the UniFi Network application suite.
Is this hardware compliant with government procurement regulations?
Yes, the Ubiquiti UCG-Max is fully NDAA compliant, satisfying strict federal and corporate supply chain security standards.
