4MP Security IP Cameras with world-class surveillance features. Shop the best CCTV brands available in Australia: Axis, Dahua, Hikvision, Ubiquiti UniFi, HiLook, Uniarch, D-Link, TP-Link and more...
Ubiquiti UniFi Protect G4 Instant Wireless Camera - Compact, wide-angle, two-way audio - NO PSU (Requires USB-C AC Adaptor or Hub)
Compact, wide-angle, WiFi-connected camera with two-way audio.
Features:
2K HD, 30 FPS camera
Built-in IR LEDs with an automatic IR cut filter for optimal nighttime surveillance
Built-in microphone and speakers
IPX5-rated, weatherproof casing
Wall-mountable
Managed with the UniFi Protect application: Version 1.20.0-beta.5 and later (web) / 1.5.6 and later (iOS) / 1.4.7 and later (Android)
Downloads
Datasheet
Installation Guide
Ubiquiti UniFi Protect Camera G5-Bullet, Next-gen indoor/outdoor 2K HD PoE Camera
Features:
2K (4MP) video resolution Flexible 3-axis adjust mount 9 m (30 ft) IR night vision AI event detections Record audio with an integrated microphone Connect and power using PoE Weatherproof (outdoor exposed)
Technical Specifications
Mechanical
Dimensions
Without mount: Ø75.5 x 74.4 mm (Ø3 x 2.9")With mount: Ø75.5 x 150 mm (Ø3 x 5.9")
Weight
Without mount: 225 g (8 oz)With mount: 315 g (11.1 oz)
Enclosure material
Polycarbonate, aluminum alloy
Mount material
Wall mount: aluminum alloy, polycarbonatePole mount: aluminum alloy
Weatherproofing
IPX4
Resistance
IK04
Optics
Sensor
5MP CMOS
Lens
Fixed focal length
View angle
H: 84.4°, V: 45.4°, D: 99.8°
Night mode
Built-in IR LED illumination and IR cut filter
Video
Resolution
4MP 2688 x 1512 (16:9)
Max. frame rate
30 FPS
Image settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
System
Processor
Dual-core Arm® Cortex®-A7 based chip
Networking interface
10/100 MbE RJ45 port
Max. power consumption
4W
Power method
PoE
Supported voltage range
37—57V DC
Button
Factory reset
Mounting
Wall, pole mount
Ambient operating temperature
-20 to 40º C (-4 to 104º F)
Ambient operating humidity
0 to 90% noncondensing
Certifications
FCC, IC, CE
Audio
Microphone
Yes (Can be disabled)
Software
Web application
UniFi Protect: Version 2.2.7 or 2.7.28 and later
Mobile app
UniFi Protect iOS™ and Android™: Version 1.10.0 and later
Downloads
Installation Guide
Image Performance
Dahua 4MP WizSense Fixed Starlight Turret, 2.8mm, Perimeter, SMD, SD Card, WDR, IR50m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Turret
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HDW3466EMP-S-AUS DatasheetDahua Eyeball Network Camera_Quick Start Guide_V1.0.4Eyeball Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Ubiquiti UniFi G5 Turret Ultra, Ultra-compact, Tamper-resistant IK04, IP66 Weatherproof 2K HD PoE Camera, Long-range Night Vision
Ultra-compact, tamper-resistant, and weatherproof 2K HD PoE camera with long-range night vision.
Features
2K (4MP) video resolution Ultra-wide viewing angle (102.4°) 30 m (98 ft) IR night vision AI event detections Record audio with an integrated microphone Connect and power using PoE Weatherproof (outdoor exposed)
Technical Specifications
Mechanical
Dimensions
Ø90 x 71.2 mm (Ø3.5 x 2.8")
Weight
330 g (11.6 oz)
Enclosure material
Aluminum alloy, UV-stabilized polycarbonate
Weatherproofing
IP66
Resistance
IK04
Cable jacket enclosure dimensions
Ø20 x 70.6 mm (0.8 x 2.8")
Cable jacket enclosure materials
Thermoplastic elastomer, polycarbonate, silicone rubber
Cable length
30 cm (1 ft)
Cable diameter
5 mm (0.2")
Cable jacket material
Polycarbonate
Cable connector type
RJ45
Optics
Sensor
1/2.4" CMOS
Lens
Fixed focal length
View angle
H: 102.4°, V: 54.9°, D: 120.6°
Night mode
Built-in IR LED illumination and IR cut filter
Video
Resolution
4MP 2688 x 1512 (16:9)
Max. frame rate
30 FPS
Image settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
System
Processor
Dual-core Arm® Cortex®-A7 based chip
Networking interface
10/100 MbE RJ45 port
Max. power consumption
4W
Power method
PoE
Supported voltage range
37–57V DC
LED
R/G/B/W
Button
Factory reset
Mounting
Surface mount
Ambient operating temperature
-30 to 50º C (-22 to 122º F)
Ambient operating humidity
0 to 90% noncondensing
Certifications
FCC, IC, CE
Audio
Microphone
Yes (Can be disabled)
Downloads
UniFi G5 Turret Ultra Installation Guide
Ubiquiti Versatile 4 MP (1440p) indoor/outdoor bullet camera with 24 FPS video for day or night surveillance with infrared LEDs.The UniFi Camera G4 Bullet delivers clear 4MP, 24 fps video over Gigabit Ethernet. The ball joint mount design allows indoor or outdoor installation and offers flexible 3-axis adjustment. The camera has infrared LEDs with an automatic IR cut filter for day and night surveillance. It features a built-in microphone and supports PoE for power.Features:
4MP, 24 FPS video
Day or night with infrared LEDs
Weatherproof enclosure
Built-in microphone
Powered by PoE
Downloads
Datasheet Installation Guide
Ubiquiti UniFi Protect Cam Dome Camera G5 2K HD PoE ceiling camera NHU-UVC-G5-DOME
Next-gen 2K HD PoE ceiling camera with enhanced dynamic range and low-light performance.
2K (4MP) video resolution Ultra-wide viewing angle (102.4°) 9 m (30 ft) IR night vision AI event detections Integrated 2-way audio Connect and power using PoE Weather-resistant (outdoor covered) Vandal resistant
Technical Specifications
Mechanical
Dimensions
Ø109.2 x 64.5 mm (Ø4.3 x 2.5")
Weight
Without mount: 370 g (13.1 oz)With mount: 390 g (13.8 oz)
Enclosure material
Aluminum alloy, polycarbonate, hard-coated dome
Mount material
Polycarbonate, stainless steel
Weatherproofing
IPX4
Resistance
IK08
Optics
Sensor
5MP CMOS
Lens
Fixed focal length
View angle
H: 102.4°, V: 54.9°, D: 120.6°
Night mode
Built-in IR LED illumination and IR cut filter
Video
Resolution
4MP 2688 x 1512 (16:9)
Max. frame rate
30 FPS
Image settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
System
Processor
Dual-core Arm® Cortex®-A7 based chip
Networking interface
10/100 MbE RJ45 port
Max. power consumption
5W
Power method
PoE
Supported voltage range
37–57V DC
LED
R/G/B/W
Button
Factory reset
Mounting
Wall, ceiling mount
Ambient operating temperature
-20 to 40º C (-4 to 104º F)
Ambient operating humidity
0 to 90% noncondensing
Certifications
FCC, IC, CE
Audio
Microphone
Yes (Can be disabled)
Speaker
Yes
Software
Web application
UniFi Protect: Version 2.2.7 or 2.7.28 and later
Mobile app
UniFi Protect iOS™ and Android™: Version 1.10.0 and later
Downloads
DatasheetInstallation Guide
Dahua 4MP 5x TiOC WizSense Network PTZ Camera, DH-SD3E405DB-GNY-A-PV1
1/2.8" 4Megapixel CMOS.
5x optical zoom.
Max. 25/30fps@4M.
IR distance up to 50 m.
Warm light illumination distance up to 30 m.
SMD 3.0.
Perimeter protection.
Face detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out.
Built-in Mic and Speaker for Two-way Talk.
12 VDC/PoE power supply.
IP66.
Sound and light alarm (red and blue lights).
Downloads
DH-SD3E405DB-GNY-A-PV1 Datasheet Installation Guide (SD3E)_V1.0.1 Network Speed Dome & PTZ Camera Installation Manual_V1.0.1 Dahua Network Speed Dome and PTZ Camera Web 5.0_User's Manual_V1.0.1 SD3E405DB-GNY-A-PV1_INSTALLATION_METHOD_EN SD3E405DB-GNY-A-PV1_DIMENSIONS SD3E405DB-GNY-A-PV1_A&E_20230403163820
Dahua 4MP 25x Starlight IR WizSense Network PTZ Camera DH-SD4A425DB-HNY
1/2.8" 4Megapixel STARVIS™ CMOS.
25x optical zoom.
Starlight technology.
Max. 25/30fps@4MP.
IR distance up to 100m.
Auto-tracking.
Perimeter protection.
Face detection.
SMD 3.0.
IP66.
Specifications
MEGAPIXELS
4MP
CAMERA STYLE
PTZ
COLOUR
White
LENS TYPE
Motorized
TECHNOLOGY
PTZ SERIES
POE
POE+
Downloads
SD4A425DB-HNY_S0 DatasheetInstallation Guide_V1.0.0_(SD4A)Network Speed Dome & PTZ Camera Installation Manual_V1.0.1Dahua Network Speed Dome and PTZ Camera Web 5.0_User's Manual_V1.0.0SD4A425DB-HNY_DIMENSIONS
Hikvision ColorVu Turret DS-2CD2347G2-LU-4, 4MP, White Light, AcuSense, Mic, 4mm (2347)
High quality imaging with 4 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Built-in microphone for real-time audio security(-U)
Focus on human and vehicle targets classification based on deep learning
24/7 colorful imaging
Water and dust resistant (IP67)
Camera
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
2688 × 1520
Min. Illumination
Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time
1/3 s to 1/100,000 s
Angle Adjustment
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens, 2.8, 4, and 6 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 112°, vertical FOV 61°, diagonal FOV 134°
4 mm, horizontal FOV 95°, vertical FOV 51°, diagonal FOV 115°
6 mm, horizontal FOV 58°, vertical FOV 31°, diagonal FOV 69°
Lens Mount
M16
Iris Type
Fixed
Aperture
F1.0
Depth Of Field
2.8 mm, 2.5 m to ∞
4 mm, 3.5 m to ∞
6 mm, 7.5 m to ∞
DORI
DORI
2.8 mm, D: 58 m, O: 23 m, R: 11 m, I: 2 m
4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m
6 mm, D: 115 m, O: 45 m, R: 23 m, I: 11 m
Illuminator
Supplement Light Type
White Light
Supplement Light Range
30 m
Smart Supplement Light
Yes
Video
Main Stream
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
Video Compression
Main stream: H.265/H.264/H.265+/H.264+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
*Third stream is supported under certain settings.
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile/Main Profile/High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR/VBR
Scalable Video Coding (SVC)
H.264 and H.265 encoding
Region Of Interest (ROI)
1 fixed region for main stream and sub-stream
Audio
Audio Compression
-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate
-U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate
-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering
-U: Yes
Network
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
Simultaneous Live View
Up to 6 channels
API
Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
User/Host
Up to 32 users. 3 user levels: administrator, operator and user
Security
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage
MicroSD/microSDHC/microSDXC card (512 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported
Client
iVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE 10, IE 11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Parameters Switch
Yes
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch
Auto, Schedule
Wide Dynamic Range (WDR)
130 dB
SNR
≥ 52 dB
Image Enhancement
BLC, HLC, 3D DNR
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-In Microphone
-U: Yes
Reset Key
Yes
Event
Basic Event
Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event
Line crossing detection, intrusion detection, region entrance detection, region exiting detection
Scene change detection
Linkage
Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email
Deep Learning Function
Face Capture
Yes
General
Power
12 VDC ± 25%, 0.55 A, max. 6.6 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: 802.3af, Class 3, 36 V to 57 V, 0.22 A to 0.13 A, max. 7.6 W
Dimension
Ø138.3 mm × 125.2 mm (Ø5.4" × 4.9")
Package Dimension
170 mm × 170 mm × 150 mm (7" × 7" × 5.9")
Weight
Approx. 750 g (1.7 lb.)
With Package Weight
Approx. 1055 g (2.3 lb.)
Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function
Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
Approval
EMC
FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC VoC (ICES-003: Issue 6, 2016);
KC (KN 32: 2015, KN 35: 2015)
Safety
UL (UL 60950-1);
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
LOA (IEC/EN 60950-1)
Environment
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection
IP67 (IEC 60529-2013)
Download
DS-2CD2347G2-LU Datasheet
DS-2CD2347G2-LU Quick Start GuideDS-2CD2347G2-LU User Manual
Dahua Security Camera, DH-IPC-HDBW3466EP-AS-AUS, 4MP WizSense Fixed Starlight Dome, 2.8mm, Perimeter, SMD, SD Card, WDR, IR50m, Built-in Mic, IP67, IK10, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Supports the AFSA (Anti-flicker Self-adaption) function, which
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection
SMD 3.0
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WizSense Series
PoE
PoE
Downloads
DH-IPC-HDBW3466EP-AS-AUS DatasheetDahua Dome Network_ Camera_Quick Start Guide_V1.0.1=Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua 4MP Starlight IP PTZ 4X 2.8mm~12mm VF lens, ICR, WDR, IR 15m, IP66, PoE
1/2.8'' 4Megapixel STARVIS CMOS
Starlight technology
Max. 25/30fps@4MP
4x optical zoom
Face Detection, People Counting, Perimeter Protection
IR distance up to 15m
SMD Plus
PoE
IP66, IK08
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
PTZ
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
PTZ SERIES
POE
POE
Downloads
DH-SD1A404XB-GNR Datasheet 20200605Dahua Network Speed Dome & PTZ Camera Web 3.0 User's Manual_V2.0.2Installation Guide_V1.0.0Network Speed Dome & PTZ Camera Installation Manual_V1.0.0
Dahua 4MP Fixed-focal Wi-Fi Floodlight Network Camera, DH-IPC-WL46A
4-MP 1/3" CMOS image sensor, low luminance, and high definition image.
Outputs max. 4 MP (2560 × 1440)@25 fps/30 fps
H.265 codec, high compression rate, ultra-low bit rate.
SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
Built-in microphone and speaker for real-time communication.
Active alarm with built-in 110 dB Siren.
The built-in dual floodlights can switch between warm and cool color temperature and have 4 floodlights modes.
Detects humans, vehicles and animals to reduce the occurrence of false alarms.
SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
Dual-band 2.4 GHz and 5 GHz WiFi options, IEEE802.11a/b/g/n/ac.
Supports max. 256 G Micro SD card and NVR storage.
100–240 VAC power supply, easy for installation.
IP65 Protection.
Specifications
MEGAPIXELS
4MP
CAMERA STYLE
Floodlight
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
Floodlight
POE
100-240V AC
Downloads
DH-IPC-WL46A DatasheetDH-IPC-WL46A Operational ManualDH-IPC-WL46A Quick Start GuideDH-IPC-WL46A Installation Method
TP-Link VIGI 4MP Outdoor ColourPro Night Vision Pan Tilt Network Camera - VIGI C540S(4mm)
Ultra-Low Light Colour Night Vision: Capture 24-hour 4MP high-quality and colourful video even in ultra low-light conditions without any supplemental lights.
360° Monitoring: Cover every corner and eliminate blind spots.
Face Recognition*: Efficiently enhances access management and attendance control while better protecting privacy.*
People & Vehicle Analytics*: Quickly find people and vehicles of interest using a series of attributes, allowing you to improve search efficiency.*
Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
Smart Detection: Actively detects abnormal events like area intrusion and line-crossing, sending notifications to you instantly.
True WDR Technology§: Enable crystal-clear images in high contrast scenes.
Active Defense: Warn potential intruders instantly with sound and light when abnormal events.
Two-Way Audio: With voice intercom support, carry two-way conversations while watching your feed from anywhere.
H.265+: Compresses the video size without sacrificing video quality, easing the network load and saving disk space.
IP66 Waterproof: Reliable IP66 for stable outdoor performance.
VIGI ColourPro Night VisionVIGI’s industry-leading ColourPro Night Vision technology enables its cameras to pierce the night and see everything in fine detail.By adopting this best-in-class technology, VIGI C540S can provide 4MP high resolution and capture more vivid full-colour imagesin extreme low-light conditions.Better than the Naked EyeFeaturing high low-light sensitivity, VIGI’s ColourPro Night Vision produces unparalleled colours along with amazingly crisp images inultra-low light conditions, which can’t be achieved with natural eyesight.Beyond IR, Beyond Full-ColourImages captured by IR cameras or traditional full-colour cameras will suffer from digital noise and the loss of detail. VIGI’s ColourPro NightVision cameras reveal excellent image details even in extreme darkness.Less Light PollutionBright illumination is required by conventional full-colour cameras to capture images at pitch-dark hours. But VIGI's ColourPro Night Vision camerasdelivers true colour and bright imaging even in extremely low light with no spotlights needed, greatly reducing environmental light pollution.Core TechnologyVIGI’s powerful ColourPro Night Vision ability to capture vivid images in extreme low-light conditions emerges from four breakthroughPowerful Pan TiltCover every corner flexibly with VIGI’s Pan Tilt camera. Customized patrol routes provide more intelligent and quick options to monitor key areas (up to 8 points for each route), reducing manual costs for adjusting pan & tilt angles repeatedly.Human & Vehicle ClassificationIntegrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.Automatic TrackingAutomatically tracks persons or vehicles of interest and provides seamless and longer video. This way, you will better understand what's happening and take action without wasting time on irrelevant footage.Comprehensive AI Detection with Pre-Set Rules SupportedBy setting the detection rules in advance, VIGI AI-powered cameras can accurately capture various abnormal events. This will greatly reduce false alarms and cover your specified monitoring needs in different scenarios.Face RecognitionVIGI’s advanced built-in face recognition algorithm enables cameras to intelligently capture faces, extract facial features, and form unique facial data. By comparing the facial data with a face library, quickly match a human face, efficiently reducing the risk of unauthorized access.People AnalyticsFilter people of interest by various attributes, such as hair length, and clothing, allowing you to improve search efficiency.Vehicle AnalyticsIdentify and search for vehicles of interest based on vehicle colour and type for targeting meaningful events in a short time.Active DefenseWarn potential intruders off instantly with sound and light to pro-actively protect your property, even while away from the scene.Two-Way AudioWith voice intercom support, carry two-way conversations while watching your feed from anywhere.Smart Video Coding by H.265+Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.PoE Connection, IP66 WeatherproofPoE technology makes your wiring remarkably easy. Reliable IP66 enables stable outdoor performance.Flexible StorageLocal storage is available for each method, as well as onboard storage with an SD card slot (up to 256 GB).One system. Full security. Run your business with peace of mind.The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
DownloadDatasheet
Hikvision 180 Degree Wide Angle Indoor Turret Camera DS-2CD2345G0P-I, 4MP, IR, 1.68MM, (2345)
High quality imaging with 4 MP resolution
180°super wide field of view
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Distortion correction
Robust structure design with full metal materials
Camera
Image Sensor
1/2.7" Progressive Scan CMOS
Min. Illumination
Color: 0.028 Lux @ (F2.0, AGC ON)
B&W: 0.0028 Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Wide Dynamic Range
120 dB
Day & Night
IR Cut Filter
Angle Adjustment
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
Lens Type
Fixed lens, 1.68 mm
FOV
1.68 mm, horizontal FOV: 180° , vertical FOV: 101° , diagonal FOV: 180°
Aperture
F2.0
Lens Mount
M12
Illuminator
IR Range
Up to 10 m
Wavelength
850 nm
Video
Max. Resolution
2688 × 1520
Main Stream
50Hz: 25fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 24fps (2688 × 1520), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Video Compression
Main stream: H.265+/H.264+/H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Video Bit Rate
32 Kbps to 16 Mbps
H.264 Type
Baseline Profile/Main Profile/High Profile
H.265 Type
Main Profile
Scalable Video Coding (SVC)
H.264 and H.265 encoding support
Region Of Interest (ROI)
1 fixed region for main stream, sub-stream and third stream
Network
Simultaneous Live View
Up to 6 channels
API
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Protocols
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
User/Host
Up to 32 users, 3 levels: administrator, operator and user
Security
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Network Storage
microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR
Client
iVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local Service: Chrome 41.0+, Firefox 30.0+
Day/Night Switch
Day/Night/Auto/Schedule
Image Enhancement
BLC, HLC, 3D DNR
Image Settings
Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser
Interface
On-Board Storage
Built-in micro SD slot, up to 256 GB
Hardware Reset
Reset via reset button on camera body, web browser and client software
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
Event
Basic Event
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event
Line crossing detection, intrusion detection, unattended baggage, object removal, face detection, scene change detection
General
Linkage Method
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output , Email
Web Client Language
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
General Function
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
Storage Conditions
-10 °C to 40 °C (14 °F to 104 °F), humidity 95% or less (non-condensing)
Startup And Operating Conditions
-10 °C to 40 °C (14 °F to 104 °F), humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, Φ 5.5 mm coaxial power plug; reverse polarity protection; PoE (802.3af, type 1, class 3)
Power Consumption And Current
12 VDC, 0.48 A, max. 5.8 W; PoE (802.3af, 36 V to 57 V), 0.19 A to 0.12 A, max. 6.8W
Camera Dimension
Camera: Φ 127.3 × 104.1 mm (Φ 5" × 4.1\")
With package: 150 × 150 × 141 mm (5.9 × 5.9\" × 5.6\")
Camera Weight
Camera: Approx. 520 g (1.1 lb.)
With package: Approx. 700 g (1.5 lb.)
Approval
EMC
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
Environment
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Download
DS-2CD2345G0P-I Data SheetQuick Start GuideUser Manual
Dahua 4MP AI Starlight + IP Bullet Fixed 2.8mm, Mic, ICR+White Light, WDR (120dB), Micro SD, IP67, POE, SMD Plus
4MP, 1/2.7'' CMOS image sensor, low illuminance, high image definition
Outputs max. 4MP (2688x1520) @ 30 fps
H.265 codec, high compression rate, low bit rate
Built-in Warm LED, max. LED distance: 30 m
ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)
Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic
12V DC/PoE power support
IP67 protection
SMD Plus
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WIZSENSE SERIES
POE
POE
Downloads
DH-IPC-HFW3449EP-AS-LED-0360B DatasheetQuick Start Guide of DH-IPC-HFW3449EP-AS-LED-0360BInstallation Guide of DH-IPC-HFW3449EP-AS-LED-0360BInstallation Example of DH-IPC-HFW3449EP-AS-LED-0360BLeaflet_Dahua-Full-Color-Camera_V1.0_EN_202002-(6P)
Axis M4216-V Dome Camera, M4216-V 4 MP Compact Dome With a 3-6mm Varifocal Lens and Remote Zoom and Focus. The Axis M4216-V Also Features Deep Learning With Dust- and IP42 Water and Dust-resistant, IK08 Impact-resistant, 02112-001
Varifocal 4 MP dome with deep learning
Great image quality in 4 MP
Varifocal lens with remote zoom and focus
WDR and Lightfinder
Support for analytics with deep learning
HDMI output for public viewing monitors
AXIS M4216-V is a compact and discreet dome that delivers great images even in challenging light conditions. With a deep learning processing unit (DLPU), you can benefit from intelligent applications based on deep learning on the edge.
Great images, every timeIdeal for any indoor surveillance application, AXIS M4216-V delivers 4 MP for wide 4:3 view and 3 MP for 16:9 aspect ratio. Thanks to its varifocal lens it offers a flexible field of view with a viewing angle of up to 100°. Wide Dynamic Range (WDR) ensures clarity even when there’s both dark and light areas in the scene. And, thanks to Lightfinder, you also get sharp, color images in low light. Additionally, with remote zoom and auto focus capabilities, there’s no need for hands-on fine tuning saving you time and effort.
Extended possibilitiesAXIS M4216-V offers great possibilities to add value to your camera and extend the functionality of your surveillance system. With a DLPU, it enables unique opportunities to take advantage of intelligent analytics based on deep learning on the edge. And it comes with AXIS Object Analytics enabling object classification for reliable detection with fewer false alarms. This compact dome offers the flexibility to add audio or I/O connectivity using accessories. And the HDMI port lets you display live video on a public viewing monitor. Furthermore, Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network.
Small and discreetCompact and flexible in design, this varifocal dome offers a wide range of accessories so it can be installed almost anywhere. For instance, it’s easy to conceal in recessed ceilings. This makes the camera perfect for any location where discreet monitoring is needed to protect your assets. AXIS M4216-V can be easily repainted to blend in seamlessly with any environment. Additionally, clear and smoked dome covers are available as accessories. Furthermore, thanks to its vandal-, impact-, and dust-resistant casing you can be confident it’s always safe and secure.
DownloadDatasheet
Dahua Security Camera 4MP WizSense Motorised Starlight Dome, 2.7–13.5 mm, Perimeter, SMD, SD Card, WDR, IR40m, Built-in Mic, IP67, IK10, POEPOE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports); max. 256 G Micro SD card; built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HDBW3466RP-ZAS-AUS DatasheetDahua Dome Network_ Camera_Quick Start Guide_V1.0.1Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua Security Camera 4MP WizSense Fixed Starlight Dome, 2.8mm, Perimeter, SMD, SD Card, WDR, IR30m, Built-in Mic, IP67, IK10, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent detection: Intrusion, tripwire (support the classification and vaccurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HDBW3466FP-AS-AUS Datasheet_20220426Dahua Dome Network_ Camera Quick Start Guide_V1.0.1Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Ubiquiti high-resolution PoE camera designed for overhead and wide-area surveillance.
Compact 4MP vandal-resistant (IK08) and weatherproof (IPx4) dome camera with integrated IR LEDs for crystal clear day and night vision.Features:
4MP, 24 FPS Video
Day or Night with Infrared LEDs
IPx4 weatherproof Enclosure
Built-in Microphone & Speaker
Powered by Power over Ethernet (PoE)
Managed by UniFi Protect Software
IK08 vandal resistant
Note: UniFi Protect is required to run this product with full functionality, we recommend using it with UniFi Dream Machine Pro or UniFi Protect Network Video Recorder
Downloads
Datasheet Installation Guide
TP-Link VIGI 4MP C440I(4mm) IR Turret Network Camera, 4mm Lens, Corridor Mode, Smart Detection, 2YW (LD)
VIGI 4MP IR Turret Network Camera
4MP Super-High Definition: The VIGI C440I camera comes with 4MP — more than enough pixels to pick up some of the more discrete details.
Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
Smart Detection: Receive notifications and check feeds when someone crosses a boundary, enters an area you've set, obstructs the camera, or removes/abandons objects.
H.265+: Without extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
Smart Video Enhancement: VIGI's professional technologies process videos to greatly improve the quality that is vital to your monitoring, including Smart IR, WDR, 3D DNR, and Night Vision.
Corridor Mode: Allows you to change the image aspect ratio from 16:9 to 9:16, and helps to monitor long and narrow areas.
12V DC/PoE: Two types of power supply give you more convenience and make your wiring remarkably easy.
4 mm Lens: Whether you need a wide-angle lens to cover enclosed spaces or a higher millimetre lens for longer distances in open spaces, C440I comes with two different lens types to better suit your security needs.
Flexible Management: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager.
TP-Link VIGI 4MP C540-W(4mm) Outdoor Full-Colour Wi-Fi Pan Tilt Network Camera, 4mm Lens, Smart Detection,2YW (LD)
VIGI 4MP Outdoor Full-Colour Wi-Fi Pan Tilt Network Camera
4MP High Definition: The camera comes with 4MP–more than enough pixels to pick up some of the more discrete details.
24h Full-Colour: Obtain 24-hour colour details, even in pitch-black conditions, via a high-sensitivity sensor and included spotlight LEDs.
Powerful Pan Tilt: Customised patrol routes and auto-tracking provide more intelligent options to monitor key areas and improve security within your property.
Wireless Outdoor Connection: Simple and quick deployment with Wi-Fi signals.
Waterproof: Reliable IP66 for stable outdoor performance.
Smart Detection (motion detection, area intrusion, line-crossing, video tampering): Receive notifications and check feeds when someone crosses a boundary, enters an area you've set, or obstructs the camera.
H.265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
VIGI App: Manage your security from the palm of your hand with the VIGI app.
TP-Link VIGI 4MP C340I(4mm) Outdoor IR Bullet Network Camera, 4mm Lens, Smart Detection, 2YW (LD)
VIGI 4MP Outdoor IR Bullet Network Camera
4MP Super-High Definition: The VIGI C340I camera comes with 4MP — more than enough pixels to pick up some of the more discrete details.
Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
Smart Detection: Receive notifications and check feeds when someone crosses a boundary, enters an area you've set, obstructs the camera, or removes/abandons objects.
Smart Video Enhancement: VIGI's s professional technologies process videos to greatly improve their quality which is vital to your monitoring, including Smart IR, WDR, 3D DNR, and Night Vision.
H.265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
Waterproof: Reliable IP67 for stable outdoor performance.
PoE/12V DC: Two types of power supply not only give you more convenience but also make your wiring remarkably easy.
2.8/4/6 mm Lens: Whether you need a wide-angle lens to cover enclosed spaces or a higher millimetre lens for longer distances in open spaces, C340I comes with three different lens types to better suit your security needs.
Flexible Management: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager.
Hikvision PTZ DS-2DE4425IW-DE(T5), 4MP, 25x (4.8-120mm) Powered by DarkFighter IR Network Speed Dome, 100m, AcuSense (4425)
The Hikvision PTZ DS-2DE4425IW-DE(T5) is a powerful and advanced network speed dome camera, featuring a 4MP resolution and up to 25x optical zoom. With powered-by-DarkFighter technology, it offers excellent low-light performance and up to 100m of IR distance for expansive night views. The camera also supports the latest video compression technology for efficient storage and features a deep learning algorithm for accurate classification of human and vehicle targets, including the ability to capture up to 5 faces at once.
Features
Focuses on human and vehicle targets classification based on deep learning
Support face capture. Up to 5 faces captured at the same time
1/2.8" progressive scan CMOS
High quality imaging with 4 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
25× optical zoom and 16× digital zoom provide close up views over expansive areas
Expansive night view with up to 100m IR distance
Support H.265+/H.265 video compression
Downloads
DS-2DE4425IW-DE(T5) DatasheetDS-2DE4425IW-DE(T5) Quick Start GuideDS-2DE4425IW-DE(T5) User ManualDS-2DE4425IW-DE(T5) FAQ
Dahua Security Camera 4MP WizSense Motorised Starlight Turret, 2.7–13.5 mm, Perimeter, SMD, SD Card, WDR, IR40m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion , tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Turret
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HDW3466TP-ZS-AUS DatasheetDahua Eyeball Network Camera_Quick Start Guide_V1.0.4Eyeball Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Hikvision 4-inch 4 MP 25X Powered by DarkFighter IR Network Speed Dome
Hikvision DS-2DE4A425IWG-E 4 MP Network IR PTZ Camera adopts 1/2.8" progressive scan CMOS chip. With the 25 × optical zoom lens, the camera offers more details overexpansive areas. This series of cameras can be widely used for wide ranges of high-definition, such as the rivers, forests, roads, railways, airports, ports, squares, parks, scenic spots, stations and large venues, etc.
Features
High quality imaging with 4 MP resolution, up to 30 fps
Excellent low-light performance via powered-by-DarkFighter technology
Clear imaging against strong back lighting due to 120 dB WDR technology
Pan and tilt ability enables camera to monitor zones of interest
25 × optical zoom allows for closer viewing of subjects in expansive areas
Up to 50 m IR range ensures safety at night
Water and dust resistant (IP66)
Focuses on human and vehicle targets classification based on deep learning
Downloads
DS-2DE4A425IWG-E DatasheetUserGuideQuick Installation Guide
TP-Link VIGI 4MP C540-4G(4mm) Outdoor Full-Color 4G Pan Tilt Network Camera, 4mm Lens, 4G Mobile Networking, Automatic Tracking, 360° Monitoring
Features
4MP Super-High Definition: The camera comes with 4MP–more than enough pixels to pick up some of the more discrete details.
24h Full-Colour: Experience clear, vibrant 24-hour monitoring, even in total darkness.
4G Mobile Networking: Enjoy hassle-free installation and simple monitoring in places where the internet is not available.
360° Monitoring: Cover every corner and eliminate blind spots.
Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
Smart Detection: Actively detects abnormal events like area intrusion and line-crossing, sending notifications to you instantly.
Automatic Tracking: Automatically tracks persons or vehicles of interest and provides seamless and longer video.
Active Defense: Warn potential intruders instantly with sound and light when abnormal events.
Two-Way Audio: With voice intercom support, carry two-way conversations while watching your feed from anywhere.
H.265+: Compresses the video size without sacrificing video quality, easing the network load and saving disk space.
IP66 Waterproof: Reliable IP66 for stable outdoor performance.
Remote Management: Take full control over your security anytime and anywhere on the VIGI app or PC client.
Onboard Storage: Support on-board storage up to 256 GB (SD card slot).*
Clarity and Colours, All in One
Experience clear, vibrant 24-hour monitoring, even in total darkness, with the VIGI Full-Colour camera. Its 4MP resolution, large-aperturelens, high-sensitivity sensor, and supplemental lights deliver comprehensive, colourful surveillance.
Network Anywhere You Need It
No need to connect network cables. Just insert a Nano-SIM card, then your camera is ready to connect to a 4G LTE network. Enjoy hassle-free installation and simple monitoring in places where the internet is not available, such as farms, forests, and construction sites.
Powerful Pan Tilt
Cover every corner flexibly with VIGI’s Pan Tilt camera. Customized patrol routes provide more intelligent and quick options to monitor key areas (up to 8 points for each route), reducing manual costs for adjusting pan & tilt angles repeatedly.
Human & Vehicle Classification
Integrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.
Automatic Tracking
Automatically tracks persons or vehicles of interest and provides seamless and longer video. This way, you will better understand what's happening and take action without wasting time on irrelevant footage.
Smart Detection for Efficient Monitoring
By setting the detection rules in advance, VIGI AI-powered cameras can accurately capture various abnormal events. This will greatly reduce false alarms and cover your specified monitoring needs in different scenarios.
Active Defense
Warn potential intruders off instantly with sound and light to pro-actively protect your property, even while away from the scene.
Two-Way Audio
With voice intercom support, carry two-way conversations while watching your feed from anywhere.
Smart Video Coding by H.265+
Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
Remote Management
Take full control over your security anytime and anywhere on the VIGI app or client.
Live Views and Real-Time Alerts
Easily check your business security via 24/7 live views. Get notifications as soon as the cameras detect something abnormal.
Easy & Smart Playback
Quickly review and locate certain video clips by event, vehicle, person, time, and more. This will greatly improve event backtracking efficiency and reduce labor costs.
Customized Monitoring Patterns
Based on your monitoring needs, you can freely preset motion zones, adjust the rotation angle, set zoom in & out, customize patrol routes, control patrol routes, and more.
Four-Way Management
Easily control your cameras via the web UI, NVR UI, VIGI app, and VIGI Security Manager. The VIGI app and VIGI Security Manager also allow for remote management.
One system. Full security. Run your business with peace of mind.
The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
Dahua AI access ANPR 4 Megapixel Full HD WDR ANPR Camera, IR, max 120km/hr, 8 mm-32 mm Motorised Lens
Experience advanced security with the Dahua AI access ANPR camera. With its high-performance CMOS image sensor and intelligent deep learning algorithms, it can recognize unlicensed vehicles and their type, brand, and color. Plus, with its built-in ports and LED, controlling external devices and installation is made simple. Its all-in-one structure and IP67 and IK10 ratings make it durable and low power consumption ensures continuous operation. Protect your property with intrusion and loitering detection and light and voice alarms.
Features
High-performance CMOS image sensor and processor that supports continuously extracting metadata 24/7.
Adopts intelligent deep learning algorithms and supports recognition of unlicensed vehicles and the type, brand and color of vehicles.
Built-in signal port, data port, communication port and remote controllers assist in controlling external devices such as entry and exit barriers.
Built-in LED for simplified installation and commissioning.
All-in-one structure with junction box and bracket, and it is also low power consumption.
IP67 and IK10 rated.
Supports intrusion and loitering detection and triggers light and voice alarms when perimeter events occur to actively deter targets. Custom audios can also be imported and edited.
Easily adapts to scenarios through its motorized vari-focal lens.
Downloads
DHI-ITC413-PW4D-IZ3 DatasheetDHI-ITC413-PW4D-IZ3 Operational ManualDHI-ITC413-PW4D-IZ3 Installation GuideDHI-ITC413-PW4D-IZ3 User Manual
TP-Link VIGI 4MP C440I(2.8mm) IR Turret Network Camera, 2.8mm Lens, Corridor Mode, Smart Detection, 2YW (LD)
VIGI 4MP IR Turret Network Camera
4MP Super-High Definition: The VIGI C440I camera comes with 4MP — more than enough pixels to pick up some of the more discrete details.
Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
Smart Detection: Receive notifications and check feeds when someone crosses a boundary, enters an area you've set, obstructs the camera, or removes/abandons objects.
H.265+: Without extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
Smart Video Enhancement: VIGI's professional technologies process videos to greatly improve the quality that is vital to your monitoring, including Smart IR, WDR, 3D DNR, and Night Vision.
Corridor Mode: Allows you to change the image aspect ratio from 16:9 to 9:16, and helps to monitor long and narrow areas.
12V DC/PoE: Two types of power supply give you more convenience and make your wiring remarkably easy.
2.8mm Lens: Whether you need a wide-angle lens to cover enclosed spaces or a higher millimetre lens for longer distances in open spaces, C440I comes with two different lens types to better suit your security needs.
Flexible Management: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager.
HiLook PTZ-N2404I-DE3 2-inch 4 MP 4X Powered by DarkFighter IR Network Speed Dome
Two-inch 4 MP camera with pan, tilt and zoom (4x) ability
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
Great night-time performance with up to 20 m enhanced IR
Water and dust resistant (IP66), and vandal proof (IK10)
Lens
FOV: Horizontal field of view: 100° to 33° (Wide-Tele),Vertical field of view: 53° to 18° (Wide-Tele),Diagonal field of view: 119° to 37.5° (Wide-Tele)
Focal Length: 2.8 mm to 12 mm, 4× optical zoom
Zoom Speed: Approx. 2 s (optical lens, wide-tele)
Working Distance: 10 mm to 1500 mm (wide-tele)
Aperture Range: F1.6 to F2.7
Network
Security Measures: User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
Network Storage: Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR
Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
API: Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform, support Hik-Connect
Simultaneous Live View: Up to 20 channels
User/Host: Up to 32 users,3 levels: Administrator, Operator and User
Client: iVMS-4200, HikCentral, HiLookVision
Web Browser: IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51
Interface
Audio Input: 1-ch audio input (line in)
Audio Output: 1-ch audio output (line out)
Network Interface: 1 RJ45 10 M/100 M Ethernet, PoE
Built-In Microphone: 1 built-in microphone, picking up sounds in the radius up to 5 meters
Camera Module
Image Sensor: 1/3" progressive scan CMOS
Min. Illumination: Color: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001 Lux @(F1.6, AGC ON),0 Lux with IR
White Balance: Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
Gain: Auto/Manual
Shutter Time: 50Hz: 1/1 s to 1/30,000 s,60Hz: 1/1 s to 1/30,000 s
Day & Night: IR Cut Filter
Digital Zoom: 16×
Privacy Mask: 24 programmable privacy masks
Focus Mode: Auto/Semi-automatic/Manual
WDR: 120 dB WDR
General
Material: Aluminum alloy, PC, PC+ABS
Dimensions: Φ 130.7 mm × 101.7 mm (Φ 5.15" × 4.00")
Weight: Approx. 0.53 kg (1.17 lb)
Protection Level: IP66 Standard, IK10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
Power: 12 VDC, 1.5 A (Max. 9.9 W, including max. 4.2 W for IR)
PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 11.2 W, including max. 4.2 W for IR)
Working Temperature: -20°C to 60°C (-4°F to 140°F)
Working Humidity: ≤ 90%
Supplement Light
IR Distance: 20 m
Smart IR: Support
PTZ
Movement Range (Pan): 0° to 330°
Pan Speed: Configurable, from 0.1°/s to 100°/s, Preset speed: 100°/s
Movement Range (Tilt): From 0° to 90°
Tilt Speed: Configurable, from 0.1°/s to 100°/s, Preset Speed: 100°/s
Proportional Zoom: Support
Presets: 300
Power-Off Memory: Support
Downloads
Data SheetQuick Start GuideUser Manual
Axis M3116LVE Network Camera, M3116-LVE is a Compact 4MP Mini Dome in a Flat-faced, Outdoor-ready, IK08 Impact-resistant Design With Built-in IR Illumination, 01605-001
Affordable flat-faced 4 MP dome with IR
4 MP video quality
Forensic WDR, Lightfinder and IR illumination
Zipstream supporting H.264 and H.265
Signed firmware and secure boot
Flat-faced design suppressing light reflections
AXIS M3116-LVE is an affordable, flat-faced dome that offers 4 MP video and an excellent wide-angle view. This compact and discreet camera includes IR illumination for sharp video even in challenging light or complete darkness. It’s ideal for surveillance in a wide range of locations, including hotels, restaurants, retail stores, and offices.
Smooth, sharp videoAXIS M3116-LVE offers excellent 4 MP resolution at up to 30 fps to deliver clear, sharp video of moving objects. It features Axis Forensic WDR which preserves forensic detail when there are both light and dark areas in a scene. And Axis Lightfinder technology for increased light sensitivity and clear colors in low light. It’s perfect for monitoring inside and outside of various premises where there’s often poor light conditions.
Light up the nightThis flat-faced dome is designed to suppress light reflections and deliver excellent image quality and usability. It offers a wide-angle view of 130°, and with built-in IR illumination you’ll enjoy clear, reflection-free footage in low light or complete darkness and vibrant colors during the day. So, there’s no need for extra lighting- you get unobtrusive surveillance both day and night.
Fits in anywhereAXIS M3116-LVE offers flexible and reliable installation. It’s suitable for both indoor and outdoor surveillance and can be mounted on walls or ceilings. Kits are also available for mounting on pendants or on junction boxes. And, with a 3-axis camera angle adjustment, this compact and discreet flat-faced dome can be easily leveled and directed. Furthermore, the impact-resistant, IK08-rated casing can be re-painted in any color to blend in with specific surroundings.It offers enhanced security features to prevent unauthorized access and safeguard your system. And, Axis Zipstream technology with support for both H.264 and H.265 video compression significantly reduces bandwidth and storage requirements. Furthermore, thanks to edge storage you can record directly to an onboard memory card, helping reduce installation and maintenance costs.
DownloadDatasheet
Dahua 4 MP 25x Starlight IR WizSense Network PTZ Camera, 1/2.8" 4Megapixel STARVIS™ CMOS, Powerful 25x optical zoom, Starlight technology, IR distance up to 150 m, Perimeter protection · Face detection, Metadata · Full-colour illuminator; red and blue warning light, IP66, Smart dual illuminators (Recommended to use within 50 m)
Capture clear, high-definition footage with the Dahua 4MP 25x Starlight TiOC Network PTZ Camera. With starlight technology and a powerful 25x optical zoom, this camera produces detailed images even in low-light conditions. Plus, with features like perimeter protection and face detection, you can ensure your property is always secure.
Features
1/2.8" 4Megapixel STARVIS™ CMOS.
25× optical zoom.
Starlight technology.
Max. 25/30 fps@4MP.
IR distance up to 150 m.
Perimeter protection.
Face detection.
Full-color illuminator; red and blue warning light.
Auto tracking 3.0
Quick Pick.
Specifications
Megapixels
4MP
Camera Style
PTZ
Colour
White
Lens Type
Motorised
Technology
PTZ Series
PoE
PoE+
Downloads
SD6C3425GB-HNR-A-PV1_S0 Datasheet 20230614Dahua Network Speed Dome and PTZ Camera Web 5.0_User's Manual_V1.0.1Installation Guide_V1.0.0Network Speed Dome & PTZ Camera Installation Manual_V1.0.1SD6C3425GB-HNR-A-PV1 A&E 20230927134454
Hikvision PTZ DS-2DE4A425IW-DE, 4MP, 5 -120mm, 25x Optical, 16x Digital, 50m Powered by DarkFighter IR Network Speed Dome (4A425)
The Hikvision PTZ DS-2DE4A425IW-DE offers high quality 4 MP resolution imaging, powered-by-DarkFighter technology for excellent low-light performance, and 120 dB WDR technology for clear imaging against strong back lighting. With pan, tilt, and 25x optical zoom capabilities, this camera can monitor zones of interest with ease. Its 50 m IR range and IP66 water and dust resistance provide safety at night.
Features
High quality imaging with 4 MP resolution
Excellent low-light performance via powered-by-DarkFighter technology
Clear imaging against strong back lighting due to 120 dB WDR technology
Pan and tilt ability enables camera to monitor zones of interest
25× optical zoom allows for closer viewing of subjects in expansive areas
Up to 50 m IR range ensures safety at night
Water and dust resistant (IP66)
Downloads
DS-2DE4A425IW-DE DatasheetDS-2DE4A425IW-DE Quick Start GuideDS-2DE4A425IW-DE User Manual
Hikvision ColorVu Turret DS-2CD2347G2-LSU/SL, 4MP, White Light, AcuSense, Built-in Mic, Speaker, Strobe Light, 2.8mm (2347)
The Hikvision ColorVu Turret DS-2CD2347G2-LSU/SL offers high-quality 4 megapixel resolution imaging with efficient H.265+ compression technology. With 130 dB WDR technology, it can take clear images even in strong backlight. It features deep learning based classification for human and vehicle targets and provides 24/7 colorful imaging. The built-in two-way audio, strobe light, and audio alarm help enhance security measures. This IP67 water and dust resistant camera is perfect for both indoor and outdoor use.
Features
High quality imaging with 4 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Focus on human and vehicle targets classification based on deep learning
24/7 colorful imaging
Active strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
Audio and alarm interface available
Water and dust resistant (IP67)
Downloads
DS-2CD2347G2-LSU/SL DatasheetDS-2CD2347G2-LSU/SL Quick Start GuideDS-2CD2347G2-LSU/SL User ManualDS-2CD2347G2-LSU/SL FAQ
Hikvision Bullet iDS-2CD7A46G0-IZHSY( 2.8-12mm), 4MP, Deep in View, 50m IR, Heater, 2.8-12mm (7A46)
High quality imaging with 4 MP resolution
Excellent low-light performance via DarkFighter technology
Clear imaging against strong back light due to 140 dB WDR technology
Efficient H.265+ compression technology to save bandwidth and storage
5 streams to meet a wide variety of applications
Water and dust resistant (IP67) and vandal proof (IK10)
Downloads
iDS-2CD7A46G0-IZHSY( 2.8-12mm) DatasheetiDS-2CD7A46G0-IZHSY( 2.8-12mm) User Manual
VIGI 4MP Outdoor Full-Colour Bullet Network Camera
4MP High Definition: The camera comes with 4MP–more than enough pixels to pick up some of the more discrete details.
24h Full-Colour: Obtain 24-hour colour details, even in pitch-black conditions, via a high-sensitivity sensor and included spotlight LEDs.
Waterproof: Reliable IP66 for stable outdoor performance.
Smart Detection (human detection, motion detection, area intrusion, line-crossing, video tampering): Receive notifications and check feeds when someone crosses a boundary, enter an area you've set, or obstructs the camera.
H.265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
PoE/12V DC: Two power supply ways not only give you more convenience but also make your wiring remarkably easy.
VIGI App: Manage your security from the palm of your hand with the VIGI app.
Dahua Security Camera 4MP WizSense Fixed Starlight Bullet, 2.8mm, Perimeter, SMD4.0, SD Card, WDR, IR50m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HFW3466EP-AS-AUS DatasheetBullet Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua 4MP AI Starlight + IP Bullet Fixed 3.6mm, Mic, ICR+White Light, WDR (120dB), Micro SD, IP67, POE, SMD Plus
4MP, 1/2.7'' CMOS image sensor, low illuminance, high image definition
Outputs max. 4MP (2688x1520) @ 30 fps
H.265 codec, high compression rate, low bit rate
Built-in Warm LED, max. LED distance: 30 m
ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)
Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic
12V DC/PoE power support
IP67 protection
SMD Plus
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WIZSENSE SERIES
POE
POE
Downloads
DH-IPC-HFW3449EP-AS-LED-0360B DatasjeetQuick Start Guide of DH-IPC-HFW3449EP-AS-LED-0360BInstallation Guide of DH-IPC-HFW3449EP-AS-LED-0360BInstallation Example of DH-IPC-HFW3449EP-AS-LED-0360BLeaflet_Dahua-Full-Color-Camera_V1.0_EN_202002-(6P)
Hikvision DS-2CD2H46G2T-IZS, DS-2CD2H46G2-IZS 4MP Acusense Motorised Varifocal Turret Network Camera
Empowered by deep learning algorithms, Hikvision AcuSense technology brings human and vehicle targets classification alarms to front- and back-end devices. The system focuses on human and vehicle targets, vastly improving alarm efficiency and effectiveness.
Features
High quality imaging with 4MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Motorized Varifocal lens for easy installation and monitoring
Clear imaging against strong backlight due to 120 dB WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle targets classification based on deep learning
Audio and alarm interface available
Water and dust resistant (IP66) and vandal proof (IK10)
Downloads
DS-2CD2H46G2-IZS Datasheet
Hikvision Anti-Corrosion Network Dome Camera DS-2XC6142FWD-IS-2.8, WF-2, NEMA4X, C5-M, 4MP, 2.8mm, 120dB Wide Dynamic Range, 3 Video Streams, 10M IR, IP67
The Hikvision Anti-Corrosion Network Dome Camera protects against corrosion in harsh environments, with a durable 316L stainless steel enclosure. Its IP67 rating ensures resistance to water and dust, while efficient compression technology saves storage space and reduces bandwidth requirements. The adjustable lens angle allows for easy installation and manual focus in different directions.
Features
DS-2XC6142FWD-IS(2.8mm)
316L stainless steel enclosure, protecting cameras to be used in corrosive environments, providing reliability and longevity compared to standard cameras
Water and dust resistant (IP67), preventing water ingress for outdoor use
H.265+/H.265/H.264+/H.264 encoding: efficient compression technology saves storage space and reduces bandwidth requirements
Lens angle adjustment allows the camera lens to be adjusted to manually focus in different directions (pan/tilt/rotate), for easy installation
Downloads
DS-2XC6142FWD-IS-2.8 DatasheetDS-2XC6142FWD-IS-2.8 User Manual
Ubiquiti UniFi G5 Dome Ultra, Ultra-compact & IK06 Tamper-resistant 2K HD PoE Camera, Night Vision For Low-profile Indoor Security
Ultra-compact and tamper-resistant 2K HD PoE camera with night vision designed for low-profile indoor security.
Features
2K (4MP) video resolution Ultra-wide viewing angle (102.4°) 20 m (65 ft) IR night vision AI event detections Connect and power using PoE Optional Flush Mount for in-ceiling installation
Technical Specifications
Mechanical
Dimensions
Ø63.6 x 68.2 mm (Ø2.5 x 2.7")
Weight
175 g (6.2 oz)
Enclosure material
Aluminum alloy, polycarbonate
Mount material
Stainless steel
Resistance
IK06
Optics
Sensor
1/2.4" CMOS
Lens
Fixed focal length
View angle
H: 102.4°, V: 54.9°, D: 120.6°
Night mode
Built-in IR LED illumination and IR cut filter
IR distance
20 m (65 ft)
Video
Resolution
4MP 2688 x 1512 (16:9)
Max. frame rate
30 FPS
Image settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
System
Processor
Dual-core Arm® Cortex®-A7 based chip
Networking interface
10/100 MbE RJ45 port
Max. power consumption
4.2W
Power method
PoE
Supported voltage range
37–57V DC
Button
Factory reset
Mounting
Surface mount
Ambient operating temperature
-20 to 40º C (-4 to 104º F)
Ambient operating humidity
10 to 90% noncondensing
Certifications
FCC, IC, CE
Software
Web application
UniFi Protect
Mobile app
UniFi Protect iOS™ and Android™
Downloads
UniFi G5 Dome Ultra Installation Guide
Hikvision ColorVu Acusense 4MP 2.8mm DS-2CD2047G2-LU/SL Live-Guard Gen 2 Outdoor Mini Bullet Camera with Mic 30m White LED
As an industry leader, the Hikvision ColorVu Acusense 4MP 2.8mm DS-2CD2047G2-LU/SL Live-Guard Gen 2 Outdoor Mini Bullet Camera with Mic 30m White LED offers high quality imaging with 4 MP resolution. Its advanced features include efficient H.265+ compression technology, 130 dB WDR technology for clear imaging, and deep learning classification for human and vehicle targets. With 24/7 colorful imaging, active strobe light and audio alarm, and built-in two-way audio, this camera provides real-time security. Plus, its IP67 rating makes it water and dust resistant for outdoor use.
Features
High quality imaging with 4 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Focus on human and vehicle targets classification based on deep learning
24/7 colorful imaging
Active strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
Water and dust resistant (IP67)
Downloads
DS-2CD2047G2-LU/SL Datasheet
DS-2CD2047G2-LU/SL Quick Start Guide
DS-2CD2047G2-LU/SL User Manual
Hikvision DeepinView 2CD7146G0 4MP Indoor Motorised Varifocal Dome Camera, 2.8-12MM, IR 40m
Enhance your security with the Hikvision DeepinView 2CD7146G0 4MP Indoor Motorised Varifocal Dome Camera. With 4 MP resolution and DarkFighter technology, you can capture high quality images even in low-light conditions. The camera also features 140 dB WDR technology for clear imaging against strong back light. Plus, its efficient H.265+ compression technology saves bandwidth and storage. With 5 streams and vandal-proof design, this camera is a reliable choice for a wide range of applications.
Features
High quality imaging with 4 MP resolution
Excellent low-light performance via DarkFighter technology
Clear imaging against strong back light due to 140 dB WDR technology
Efficient H.265+ compression technology to save bandwidth and storage
5 streams to meet a wide variety of applications
Vandal proof (IK10)
Downloads
DatasheetUser Manual
Hikvision DS-2DE3A404IWG-E/W 4MP, IR Wi-Fi Mini PT Dome Camera, Vari-focal 2.8-12mm, 4 x Zoom IR 50m
The Hikvision DS-2DE3A404IWG-E/W 4MP IR Wi-Fi Mini PT Dome Camera delivers top-of-the-line imaging with 4 MP resolution, Deep Learning-based classification, DarkFighter technology for low-light conditions, and 120 dB WDR technology for clear imaging in strong backlight.
This Hikvision PTZ Camera is highly versatile and suitable for use in various indoor and outdoor settings, including corridors, homes, offices, convenience stores, and restaurants. With its vari-focal 2.8-12mm lens and 4x zoom capability, it offers a range of features and functions for professional surveillance and monitoring.
Features
High quality imaging with 4 MP resolution
Focuses on human and vehicle targets classification based on deep learning
Excellent low-light performance via powered-by-DarkFighter technology
Clear imaging against strong back lighting due to 120 dB WDR technology
Pan and tilt ability enables camera to monitor zones of interest
4 × optical zoom allows for closer viewing of subjects in expansive areas
Up to 50 m IR range ensures safety at night
Wi-Fi connection and easy installation
Support audio visual alarm
Downloads
DS-2DE3A404IWG-E/W Datasheet
Hikvision DS-2CD2546G2-IS 4MP Acusense Built-in Mic Fixed Mini Dome Network Camera
High quality imaging with 4 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Focusing on human and vehicle classification based on deep learning
Clear imaging against strong back light due to 120 dB WDR technology
Efficient H.265+ compression technology
-S: audio and alarm interface available
Water and dust resistant IP67 and vandal proof IK08
Downloads
DS-2CD2546G2-IWS DatasheetDS-2CD2546G2-IWS Quick Start GuideDS-2CD2546G2-IWS User Manual
AXIS Q3626-VE 4MP Advanced Fixed Dome, DLPU, Remote Adjustment PTRZ, VF 4-9mm
Advanced 4 MP dome with remote adjustment
Outstanding image quality in 4 MP
Remote adjustment of the camera angle
Analytics with deep learning
Electronic image stabilization
Axis Edge Vault
Specifications
Image sensor
CMOS
Image sensor size
1/1.8
Lightfinder
Lightfinder 2.0
Wide dynamic range
Forensic WDR
Min illumination/ light sensitivity (Color)
0.06 lux
Min illumination/ light sensitivity (B/W)
0.0136 lux
Max video resolution
2688x1512
Max frames per second
50/60
Day and Night functionality
Yes
Electronic image stabilization
Yes
Focal length
4.3 - 8.6 mm
Horizontal field of view
103 - 52 °
Vertical field of view
56.2 - 29.6 °
Remote PTRZ
Yes
Compression
Compression
Zipstream
Yes
H 264
Baseline, High, Main
H 265
Yes
Motion JPEG
Yes
Remote focus
Yes
Remote zoom
Yes
Built-in IR
–
Local storage (memory card slot)
Yes
Operating temperature
-50 to 55 °C
Outdoor Ready
Yes
Vandal rating
IK10
IP rating
IP66, IP6K9K
Designed for repaint
Yes
Sustainability
BFR/CFR free, PVC free
Download
Datasheet
TP-Link VIGI 4MP IR Dome Network Camera - VIGI C240I(2.8mm)
4MP Super-High Definition: The VIGI C240I camera comes with 4MP — more than enough pixels to pick up some of the more discrete details.
Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
Smart Detection: Receive notifications and check feeds when someone crosses a boundary, enters an area you've set, obstructs the camera, or removes/abandons objects.
IK10 Vandal-Proof & IP67 Waterproof: With vandal-resistant, rugged housing and waterproof design, this VIGI dome camera is built tough to withstand vandalism and harsh environments with rain and dust for constant security anywhere and anytime.
H.265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
Smart Video Enhancement: VIGI's professional technologies process videos to greatly improve the quality that is vital to your monitoring, including Smart IR, WDR, 3D DNR, and Night Vision.
PoE/12V DC: Two types of power supply not only give you more convenience but also make your wiring remarkably easy.
4mm Lens: Whether you need a wide-angle lens to cover enclosed spaces or a higher millimetre lens for longer distances in open spaces, C240I comes with two different lens types to better suit your security needs.
Flexible Management: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager.
Looking for a higher resolution? It's right here. 4MP Super-High DefinitionThe VIGI C240I camera comes with 4MP—more than enough pixels to pick up some of the more discrete details.Human & Vehicle ClassificationIntegrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.We keep an eye on your business. Smart DetectionBacked by AI algorithms, the VIGI camera offers more smart detection. You will receive notifications when someone crosses a boundary, enters an area you've set, obstructs the camera, or removes/abandons objects.IK10 Vandal-Proof & IP67 WaterproofWith vandal-resistant, rugged housing and waterproof design, this VIGI dome camera is built tough to withstand vandalism and harsh environments with rain and dust for constant security anywhere and anytime.More compression. More savings. Same quality.Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.Never miss a detail.SmartVid-Smart Video EnhancementVIGI’s professional technologies process videos to greatly improve their quwhichy that is vital to your monitoring, including Smart IR, WDR, 3D DNR, and Night Vision.Discover the best way to power your camera.PoE/12V DCTwo power supply ways not only give you more convenience but also make your wiring remarkably easy.Choose the right lens for your security.2.8/4 mm LensWhether you need a wide-angle lens to cover enclosed spaces like elevators or a higher millimetre lens for longer distances in open spaces like parking lots, C240I comes with two different lens versions to better suit your security needs.Flexible ManagementTake full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager.One system. Full security.Run your business with peace of mind.The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
DownloadDatasheet
Axis M3216-LVE Dome Camera, Fixed Dome Camera With Deep Learning Processing Unit (DLPU), 02372-001
Affordable surveillance in 4 MP with deep learning
Excellent image quality in 4 MP
Lightfinder, Forensic WDR, OptimizedIR
Support for advanced edge analytics
Audio and I/O connectivity
Built-in cybersecurity functionality
DownloadM3216-LVE Datasheet
