| Brand / Series |
Uniview UNV / LightHunter PTZ Dome |
| Model (SKU) |
IPC6424SR-X25-VF-B |
| Sensor / Resolution |
1/2.8″ CMOS / 4 MP (2688×1520 @ 30 fps) |
| Lens / Zoom |
4.8–120 mm motorized AF / 25× optical; 16× digital |
| FOV (H/V/D) |
≈52.2°–2.74° / 30.81°–1.54° / 64.2°–3.23° |
| Low-light / WDR |
LightHunter; 120 dB WDR; 2D/3D DNR; ICR |
| IR Illumination |
Up to 100 m (850 nm); auto/manual |
| Streams / Codec |
Triple streams; Ultra 265 / H.265 / H.264 / MJPEG; ROI; U-code |
| Pan / Tilt |
Pan 360° endless, 0.1–200°/s (preset 240°/s); Tilt −15°~90°, 0.1–120°/s (preset 200°/s) |
| Presets / Patrol |
1024 presets; 16 patrols (≤64 presets each); route/recorded patrol supported |
| Audio / Alarm I/O |
Audio 1 in / 1 out (two-way); Alarm 2 in / 1 out; RS-485 |
| Storage |
microSD up to 256 GB; ANR; NAS (NFS) |
| Network / Security |
IPv4/HTTPS/TLS; ONVIF S/G/T; up to 32 users; RTSP auth |
| Power |
DC12 V (±25%) or PoE+ (IEEE 802.3at); Max ≈21 W |
| Protection / Env. |
IP67; IK10; −40 °C ~ 70 °C; ≤95% RH; 6 kV surge |
| Dimensions / Weight |
Ø166 × 295 mm; ≈3.05 kg |
| DORI (approx.) |
At 4.8 mm: Detect 119 m / Identify 11.9 m; at 120 mm: Detect 2475 m / Identify 247.5 m |
