See our customers' favourite Dahua and Uniarch Network Video Recorders NVRs. All XVR, DVR and NVR come with 128 channels for your favourite security cameras.
Hikvision 128 Channel 4K Super NVR with 3U 576 Mbps, 16 x HDD Bay, DS-96128NI-I16
Up to 128 channel IP cameras can be connected
Up to 576 Mbps high incoming bandwidth ensures IP cameras can be connected
2 HDMI (different source) and 1 VGA interfaces16 HDD can be used for continuous video recording
16 HDD can be used for continuous video recording
Supports some specialist cameras, including people counting camera/ANPR (automatic number plate recognition) camera/fisheye camera
Advanced streaming technology enables smooth live view in poor network conditions
Supports RAID 0, 1, 5, 6, 10 and N+1 hot spare for even more reliable data storage, effectively avoids data loss risks
Downloads
DS-96128NI-I16 Datasheet
DS-96128NI-I16 Quick Start Guide
DS-96128NI-I16 User Manual
DS-96128NI-I16 Communication Matrix
Dahua DHI-NVR616-128-4KS2 128 Channel Ultra Series NVR can record up to 12MP and features RAID, 2 x HDMI (4K), 2 x Ethernet Ports, Face Detection, POS, ANPR, Redundant Power.
New 4.0 user interface
16-channel decoding@1080p (30 fps); self-adaptive decoding capability
Access, storage or forwarding at 384 Mbps
Simultaneous video output for VGA and HDMI1; 4K heterogeneous output for the 2 HDMI ports
Supports RAID 0/1/5/10Multiple data mode such as Raid0, Raid1, Raid5, Raid6, and Raid10
Remote configuration and management of IPCs, such as setting parameters, acquiring information and upgrading IPCs of the same model in batches
AI-by-camera functions such as perimeter protection, face detection and recognition, SMD Plus, video metadata, ANPR and 3D behaviour analysis
N+M cluster. When the host fails, the stand by device will continue to record; once the host recovers, video recorded on the standby device will be transmitted back
Specifications
Number of Channels
128 Channel
Number of PoE Ports
0 x PoE Ports
Number of Hard Disk Bay
16 x HDD Bay
Technology
Ultra Series
Network Bandwidth
384 Mbps Access, Storage or Forwarding
Maximum Resolution Support
12MP
System
Main Processor
Industrial embedded micro-processor
Operating System
Embedded LINUX
Operating Interface
Web mode, local GUI
Perimeter Protection by Camera
Performance
24 channels
AI Search
Search pictures by channel, time, event type
Face Recognition by Camera
Performance
24 channels
Face Attributes
6 attributes: Gender, age, glasses, expression, mouth mask, and beard
AI Search
Search pictures by channel, time and face attributes
SMD Plus By Camera
Performance
32 channels
AI Search
Search by target classification (Human, Vehicle)
Video Metadata By Camera
Performance
12 channels
Human Body
Top, top color, bottom, bottom color, hat, bag, gender, age, umbrella
Vehicle
Plate No., type, color, vehicle type, logo, plate color, ornament, calling, seatbelt, region
Non-motor Vehicle
Type, color, number of passengers, helmet
AI Search
Support search target video by metadata
ANPR by Camera
Performance
8 channels
Stereo Analysis by Camera
Performance
32 channels
AI Search
Search by target classification (Fall Detection, People Approach Detection, People No. Exception Detection, People Staying Detection, Violence Detection)
Video
Access Channel
64/128
Network Bandwidth
384 Mbps for access, 384 Mbps for storage and 384 Mbps for forwarding
Resolution
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/960p/720p/D1/CIF/QCIF
Decoding Capability
16-ch@1080p (30 fps)
Video Output
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720HDMI1/HDMI2: 3840 × 2160@30 fps, 3840 × 2160 @25 fps, 1920 × 1080, 1280 × 1024, 1280 × 7201 channel VGA output, 2 channels HDMI output, VGA and HDMI 1 homologous output, double HDMI heterogeneous output. Support 4K display for both HDMI1 and HDMI2
Multi-screen Display
1st Screen: 1/4/8/9/16/25/36/64
2nd Screen: 1/4/8/9/16
Third Party Camera Access
Panasonic, Sony, Samsung, Axis, Pelco, Arecont, Onvif, Canon and more
Compression
Video
Smart H.265+/H.265/Smart H.264+/H.264/MPEG4/MJPEG
Audio
MP2/G726/G729/G722/G723/G711A/G711U/PCM
Network
Network Protocol
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.), P2P, iSCSI
Mobile Phone Access
iOS, Android
Interoperability
ONVIF (profile T/S/G), CGI, SDK
Browser
Chrome, IE9 or later, Firefox
Record Playback
Multi-channel Playback
1/4/9/16
Record Mode
Manual, Schedule (General, MD (Motion Detection), Alarm, MD & Alarm, Intelligent, POS)
Storage Method
Local HDD and network
Backup
Hard drive, USB device, eSATA device
Playback Function
1. Play, pause, stop, fast forward, fast backward, rewind, play by frame2. Full screen, backup (cut/file), partially enlarge, audio on/off
Storage
Disk Group
Support
Raid Support
RAID 0/1/5/6/10
Alarm
General Alarm
Motion detection, privacy masking, video loss, local alarm, PIR alarm, IPC alarm
Anomaly Alarm
Camera offline, storage error, full storage, IP conflict, MAC conflict, login lock, network security anomaly
Intelligent Alarm
Perimeter protection, face detection, face recognition, SMD, video metadata (human, motor-vehicle, non-motor vehicle), ANPR, people counting, stereo analysis, crowd distribution, heatmap
Alarm Linkage
Record, snapshot, IPC external alarm output, buzzer, log, preset, email
External Port
Audio Input
1 channel, RCA connector
Audio Output
1 channel, RCA connector
HDD
16 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature. Supports Hot-swap.
Alarm Input
16 channels
Alarm Output
8 channels
eSATA
1 eSATA
SAS
1 Mini SAS Port, for Storage Expansion
RS-232
1 channel, used to debug and pass through serial data
RS-485
1 channel, used to control PTZ, and it supports multiple protocols
USB
2 front USB 2.0 ports, 2 rear USB 3.0 ports
HDMI
2
VGA
1
Network
6 in total, 4 × RJ45 10/100/1000 Mbps self-adaptive Ethernet ports and 2 × 1000 Mbps optical port
General Parameter
Power Supply
Single, AC100V–240V, 50–60 Hz
Power Consumption
< 51 W (Without HDD)
Net Weight
17.6 kg (38.8 lb) (Without HDD)
Gross Weight
27 kg (59.5 lb) (Without HDD)
Product Dimensions
485 mm × 516.5 mm × 133.2 mm (W × L × H)19.09 inch × 20.34 inch × 5.24 inch (W × L × H)
Package Dimensions
648 mm × 723 mm × 445 mm (W × L × H)25.51 inch × 28.46 inch × 17.52 inch (W × L × H)
Operating Conditions
–10°C to +55°C (+14°F to +131°F), +35°C (+95°F) when raid enabled
Storage Conditions
0°C to +40°C (+32°F to +104°F)
Operating Humidity
10%–93% (RH)
Storage Humidity
30%–85% (RH)
Operating Altitude
3000 m (9843 ft)
Certifications
CE: EN55022, EN55024, EN50130-4, EN60950-1FCC: Part 15 Subpart B, ANSI C63.4-2014UL: UL 60950-1 and CAN/CSA C22.2 No.60950-1
Downloads
DHI-NVR616-64-4KS2_datasheet_20210113HDD INSTALLATION GUIDE_V1.0.0Dahua Network Video Recorder_User's Manual_V1.2.0
