Uniview UNV NVR516-128E-R 128 Channel Enterprise NVR — 32MP, 16-Bay RAID, Optional Redundant PSU, N+1

Description

Uniview UNV · Network Video Recorder

Uniview UNV NVR516-128E-R 128 Channel Enterprise NVR — 32MP, 16-Bay RAID, Optional Redundant PSU, N+1

The Uniview NVR516-128E-R is a 128-channel network video recorder with 16 SATA drive bays and recording support up to 32MP. It connects to cameras over the network and requires an external PoE switch for PoE cameras. The redundant power supply is optional. Incoming bandwidth is 640 Mbps; storage and analytics should be sized for the intended camera configuration.

Specifications
Model NVR516-128E-R
IP Camera Inputs 128 channels
Maximum Recording Resolution 32MP
Compression Ultra 265, H.265, H.264
Incoming Bandwidth 640 Mbps
Outgoing Bandwidth 640 Mbps
Built-in PoE None; use an external PoE switch or separately powered cameras
Network 2 × RJ45 10/100/1000 Mbps
SATA Bays 16
HDD Capacity Up to 24 TB per drive; 384 TB raw total. Maximum capacity requires ambient temperature no higher than 40°C; supported HDD size and usable capacity depend on configuration.
RAID RAID 0, 1, 5, 6, 10, 50, 60
Power AC 100–240 V; optional redundant power supply
Power Consumption ≤ 50 W without HDDs
Reliability ANR (automatic network replenishment); disk group and redundant storage
Video Outputs 2 × HDMI + 2 × VGA; HDMI1 up to 8K/30 Hz, HDMI2 up to 4K/60 Hz
Hot Swap Supported
N+1 Hot Spare Supported
Smart Functions Receives camera-side analytics including SIP, UMD, face/vehicle detection and video metadata
Dimensions 482 × 533 × 131 mm; 3U
Weight ≤ 6.5 kg without HDDs
Warranty (Australia) 3 years · CCTV Guru Australia

Downloads

Manufacturer datasheet

Frequently Asked Questions

How many cameras and what resolution are supported?

Up to 128 IP cameras, recording at up to 32MP. Total incoming bitrate must stay within 640 Mbps.

Does it power cameras directly?

No. This model has no built-in PoE ports. Use an external PoE switch or a suitable separate camera power supply.

How much storage can it support?

Up to 24 TB per drive; 384 TB raw total. Maximum capacity requires ambient temperature no higher than 40°C; supported HDD size and usable capacity depend on configuration.

Does it support RAID?

RAID 0, 1, 5, 6, 10, 50, 60. RAID usable capacity depends on drive count and the selected RAID level.

What video outputs does it have?

2 × HDMI + 2 × VGA; HDMI1 up to 8K/30 Hz, HDMI2 up to 4K/60 Hz.

What does ANR do?

With compatible cameras and configured camera-side storage, ANR can replenish recorder footage after a network interruption.

What power supply does it require?

AC 100–240 V; optional redundant power supply. Consumption is ≤ 50 W without HDDs.

3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
