Hikvision AcuSense · 16 × 8MP 4K · 32CH NVR · Expandable to 32 Cameras
16 × 8MP · 32CH Enterprise Kit
Hikvision 16 × 8MP 4K AcuSense Enterprise CCTV Kit with 32-Channel NVR
The Hikvision 16-Camera 8MP Enterprise Kit is a large-site surveillance system built for multi-building Australian projects — warehouses, factories, distribution centres, campuses, council facilities and industrial estates. It pairs sixteen DS-2CD2386G2-IU 8MP 4K AcuSense turret cameras with a DS-7732NI-M4/16P 32-channel 8K NVR. Sixteen built-in PoE ports power the supplied cameras directly, while a further 16 channels stay free — so you can double the camera count to 32 as the site grows. AcuSense deep-learning AI classifies people and vehicles to cut false alarms across every channel.
Cameras
16 × 8MP 4K
Recorder
32CH 8K NVR · 16 PoE
Smart AI
AcuSense Human/Vehicle
Night Vision
Smart IR up to 30 m
Audio
Built-in Mic
Storage
4 × SATA · Up to 64 TB
True 4K (8MP) Detail
A 1/1.8" sensor captures 3840 × 2160 detail with the headroom to digitally zoom into recorded footage and still identify a face or number plate.
AcuSense AI — Fewer False Alarms
Deep-learning classification separates people and vehicles from animals, foliage and shadows across all 32 channels, so only real events trigger alerts and recording.
32 Channels — Room to Double Up
Ships with 16 cameras on the NVR's built-in PoE ports, and 16 channels stay free — add ANPR, ColorVu, fisheye or third-party ONVIF cameras to scale to 32 without changing the recorder.
Quad-SATA, Up to 64 TB
Four internal SATA bays accept surveillance HDDs up to 16 TB each, delivering month-long retention even with all channels running at full 4K. RAID 0/1/5/6/10 supported.
What's Included
16 × Cameras
DS-2CD2386G2-IU — 8MP 4K AcuSense turret, 2.8 mm (~111° FOV), Smart IR 30 m, 120 dB WDR, built-in mic, IP67. Each ships with mounting bracket, drill template, screws & quick start guide.
1 × Recorder
DS-7732NI-M4/16P — 32-channel 8K M-Series NVR with 16 built-in PoE ports, 4 × SATA bays (up to 64 TB), up to 32 MP per channel, 8K HDMI output, RAID support and Hik-Connect remote access. Expandable to 32 IP cameras.
Storage
No HDD included — the NVR ships as a chassis with 4 free SATA bays. Add surveillance-grade drives (Seagate SkyHawk or WD Purple) up to 16 TB each, for a maximum of 64 TB total.
Power
The NVR has 16 × built-in PoE ports (IEEE 802.3 af/at, 200 W budget) — one Cat6 cable per camera carries power and data to the supplied 16 cameras, no separate power supplies. To run more than 16 cameras (up to the 32-channel limit), add an external PoE switch for the extra cameras. Network cabling is run on site and is not included; pre-made Cat6 patch leads are available separately.
Mounting
Brackets and templates included for eave/soffit installs. For brick or flush-wall mounting, add a Hikvision wall-mount bracket per camera; a junction box is also available for tidy cable management.
Warranty
3-Year Australian warranty · local CCTV Guru tech support. Genuine Hikvision Australian stock.
Best For
Large warehouses
Loading docks, racking aisles, perimeters and offices with 4K plate and face detail.
Factories & production
Production lines, plant rooms, dispatch and yards with IP67 weatherproof cameras.
Campuses & schools
Entries, hallways, ovals and car parks across multiple blocks on one recorder.
Multi-building sites
Separate structures, gates, driveways and yards consolidated to a single 32CH NVR.
Councils & facilities
Depots, community centres, car parks and public buildings with privacy masking.
Industrial estates
Wide perimeter coverage with headroom to add ANPR and panoramic cameras later.
Camera Specifications — DS-2CD2386G2-IU
Camera Type
8MP 4K AcuSense Fixed Turret
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
8MP · 3840 × 2160
Min. Illumination
Colour 0.003 lux @ F1.6 · 0 lux with IR
Lens
Fixed 2.8 mm · ~111° horizontal FOV
Night Vision
Smart IR up to 30 m
WDR
120 dB True WDR
AI Functions
AcuSense · human & vehicle classification · perimeter protection
Audio
Built-in microphone
On-Board Storage
microSD / SDHC / SDXC up to 256 GB
Compression
H.265+ / H.265 / H.264+ / H.264
Power
12 VDC / PoE (IEEE 802.3af) · max 8 W
Ingress Protection
IP67
Warranty (Australia)
3 years · CCTV Guru Australia
Recorder Specifications — DS-7732NI-M4/16P
Channels
32 IP channels · up to 32 MP input
Incoming Bandwidth
320 Mbps
PoE
16 × PoE ports (IEEE 802.3 af/at) · 200 W budget · add a PoE switch for cameras 17–32
Storage
4 × SATA (up to 16 TB per bay, 64 TB total) · RAID 0/1/5/6/10 · no HDD included
Video Output
1 × HDMI (up to 8K) + 1 × VGA · simultaneous
AI Functions
AcuSense human/vehicle · perimeter · facial (with compatible cameras)
Compression
H.265+ / H.265 / H.264+ / H.264
Form Factor
1.5U desktop / rack-mount compatible
Remote / App
Hik-Connect (iOS & Android) · P2P · ONVIF
Installation Notes
›Cabling: run solid-copper Cat6 from each camera back to the NVR for stable power and video over long distances — typical across multi-building sites.
›PoE switch for expansion: the NVR powers 16 cameras on its built-in PoE ports. To use channels 17–32, connect the extra cameras through an external PoE switch on the same network — no NVR upgrade needed.
›Storage sizing: 16–32 channels of 4K use significant bandwidth — for 30+ days of continuous retention, fit multiple drives across the 4 SATA bays for up to 64 TB total.
Setup & Demo Videos — Hikvision
AcuSense — human & vehicle detection
AcuSense NVR — smart false-alarm filtering
Official NVR & Camera Setup Videos
Use these official Hikvision tutorials to complete the recorder startup wizard and connect the supplied PoE cameras. Menu names may vary slightly with firmware version.
NVR 5.0 Startup Wizard — Official Hikvision Tutorial
Add a PoE Camera to NVR 5.0 — Official Hikvision Tutorial
Downloads & Resources
DS-2CD2386G2-IU Datasheet
DS-7732NI-M4/16P Datasheet
Hikvision Camera Quick Start Guide
Can I expand this kit to 32 cameras?Yes — the DS-7732NI-M4/16P is a 32-channel NVR. It powers the 16 supplied cameras on its built-in PoE ports, and you can add up to 16 more IP cameras (AcuSense, ColorVu, ANPR, fisheye or ONVIF) through an external PoE switch — no recorder upgrade required.
Does the NVR include hard drives?No — it ships as a chassis with 4 free SATA bays. Add surveillance-grade drives up to 16 TB each, for up to 64 TB total, sized to your retention and channel count.
How does AcuSense reduce false alarms?Deep-learning AI classifies motion as human, vehicle or other across all 32 channels, so leaves, animals and shadows don't trigger alerts — only real events reach your phone.
How are the cameras powered?The 16 supplied cameras each run on a single Cat6 cable to one of the NVR's 16 built-in PoE ports — no separate power supplies. For cameras 17–32, use an external PoE switch. Cat6 cabling is run on site and not included.
Can I mix in other Hikvision cameras?Yes — the NVR works with AcuSense, ColorVu, ANPR, PanoVu and other Hikvision IP cameras, plus third-party ONVIF cameras. Talk to us to build a custom variant.
