Complete Dahua IP Video Intercom Kit · Card Unlock · Black or White Monitor
Card Unlock Kit
A complete smart-entry kit for Australian homes, villas, offices and small business. It pairs the VTO2111D-P-S3 IP villa door station — with built-in card reader, IR night vision and a wide 107° view — with a 7-inch touchscreen monitor in your choice of black or white and a 4-port PoE switch. See and speak to visitors, unlock by card, monitor or DMSS app, and run the whole system over one network cable. Genuine Dahua, Australian stock and local support.
In The Kit
Door Station + Monitor + PoE Switch
Access Control
Card · App · Monitor Unlock
Colour Options
Black or White Monitor
Night Vision
Auto IR + WDR
Why Choose This Dahua KTP03-S2 Intercom Kit
One Complete Kit
Door station, monitor and PoE switch are matched and bundled — no compatibility guesswork, just connect and configure.
Black or White Monitor
Pick the black VTH2621G-P for modern or commercial interiors, or white VTH2621GW-P to blend into bright walls.
Card Reader Built In
The VTO2111D-P-S3 stores up to 10,000 cards for fast, keyless entry — ideal for family, staff and regular visitors.
Three Ways To Unlock
Open the door by IC card at the panel, from the indoor monitor, or remotely through the DMSS app — and it controls two locks.
Clear Day & Night
A 2MP HD camera with WDR and auto IR delivers a wide 107° view and dependable low-light visitor identification.
Clean PoE Install
The included 4-port PoE switch powers and connects the system over network cable — cleaner wiring, fewer plugs.
What's In The Box
1 × IP Villa Door Station — VTO2111D-P-S3
2MP HD camera with WDR and auto IR, 107° wide view, two-way audio, card / app / monitor unlock (10,000 cards), controls two locks, tamper alarm, PoE, surface mount, IP65 (sealed) / IK04.
1 × 7″ Indoor Monitor — Black or White
VTH2621G-P (black) or VTH2621GW-P (white). 7-inch capacitive touchscreen (1024×600), two-way voice, door-station and IP camera monitoring, 6 alarm inputs / 1 output, H.265, standard PoE.
1 × 4-Port PoE Switch — DH-PFS3006-4ET-36
Compact Dahua PoE switch with 4 PoE ports and 2 uplink ports to power and connect the intercom cleanly over network cabling.
Ready To Install
A clean, professional intercom backbone in one purchase. Door lock, exit button and cabling are selected separately to suit your door.
Choose Your Monitor Colour
Black — VTH2621G-P
Best for modern interiors, dark switch plates and commercial reception areas where premium black hardware suits the space.
White — VTH2621GW-P
Best for bright homes, apartments and clinics where a white monitor blends cleanly into the wall.
Technical Specifications
Door Station — VTO2111D-P-S3
Camera
1/2.8″ 2MP CMOS, low illumination, DWDR
Field of View
H 107° · V 60° · D 122°
Night Vision
Auto IR, day/night
Audio
Two-way with echo & noise reduction
Unlock
Card, app and indoor monitor
Card Capacity
10,000 cards
Lock Control
Controls two locks · 1 port (NC default)
Video Coding
H.264 / H.265
Power
12 VDC 1A or standard PoE
Protection
IP65 (sealed) & IK04 · tamper alarm
Mounting
Surface mount
Indoor Monitor — VTH2621G-P / VTH2621GW-P
Screen
7-inch TFT capacitive touchscreen
Resolution
1024 × 600
Audio
Two-way voice with built-in speaker
Monitoring
Door station & Dahua IP cameras
Alarm I/O
6 inputs / 1 output
Video Decoding
H.265 & H.264
Storage
microSD up to 64GB (reserved for software)
Power
12 VDC 1A or standard PoE
Colour
Black (VTH2621G-P) or White (VTH2621GW-P)
PoE Switch — DH-PFS3006-4ET-36
PoE Ports
4 × 10/100 Mbps PoE
Uplink Ports
2 × 10/100 Mbps
Certifications
CE, FCC
Housing
Compact desktop, black
Datasheets & Guides
DHI-KTP03-S2 Kit Datasheet
DHI-VTO2111D-P-S3 Door Station Datasheet
DHI-VTH2621G(W)-P Monitor Datasheet
Dahua Indoor Monitor User Manual
Frequently Asked Questions
What's included in this kit?The VTO2111D-P-S3 door station, a 7-inch monitor (black VTH2621G-P or white VTH2621GW-P) and a 4-port Dahua PoE switch.
Can I choose black or white?Yes. Select the black or white monitor above — both share identical specs and use the same door station.
Does it support card unlock?Yes. The door station has a built-in card reader storing up to 10,000 cards, plus app and indoor-monitor unlock.
Can I answer the door from my phone?Yes. The Dahua DMSS app lets you talk to visitors and unlock the door remotely.
Can it unlock two doors?Yes. The door station can control two locks — for example a gate and a front door.
Does it see clearly at night?Yes. A 2MP camera with WDR and auto IR gives a wide 107° view and dependable low-light identification.
Is the door station weatherproof?Yes. It's IP65 rated when sealed correctly and IK04 impact-rated, with a built-in tamper alarm.
Is a door lock included?No. Electric strikes, magnetic locks and exit buttons are chosen separately to suit your door type.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · DHI-VTH2621GW-P · 7" IP PoE Indoor Monitor · WhiteIP PoE MonitorDahua DHI-VTH2621GW-P 7" IP PoE Indoor Monitor (White)
The Dahua DHI-VTH2621GW-P is a high-performance, cost-effective 7-inch IP indoor monitor in a clean white finish. Its 1024×600 capacitive touchscreen, standard PoE for single-cable installation, and H.265/H.264 decoding make it an easy fit for any Dahua IP intercom system. View door stations and IP cameras, wire in up to six alarm zones, and enjoy a tidy, modern panel for residential or commercial spaces.
Screen
7" Touch
Resolution
1024×600
Wiring
IP / PoE
Power
Standard PoE
Codec
H.265
Alarm In
6 Channel
Single-cable PoE install
Standard PoE powers and networks the monitor over one Ethernet run, cutting wiring time and removing the need for a separate plug-pack.
View doors and cameras
Display Dahua IP door stations and IP cameras on the crisp touchscreen with efficient H.265/H.264 decoding.
Alarm-ready
Six alarm inputs and one output let you connect door, window and motion sensors directly to the monitor for layered protection.
Clean white design
A high-performance, cost-effective panel in white that blends neatly into modern residential and commercial interiors.
Specifications — DHI-VTH2621GW-P
Screen
7" TFT capacitive touchscreen
Resolution
1024 × 600
Colour
White
Technology
IP
Video Decoding
H.265 / H.264
Alarm I/O
6-channel input / 1-channel output
Storage
Not supported
Power Supply
DC 12V or standard PoE
Compatibility
Dahua IP door stations and IP cameras
Warranty
3 years · CCTV Guru Australia
Downloads
DHI-VTH2621GW-P DatasheetDahua Digital VTH User Manual
Is this a PoE monitor?Yes. The VTH2621GW-P supports standard PoE so it can be powered and networked over a single Ethernet cable, or run from DC 12V.
Does it have Wi-Fi?No. This is a wired IP/PoE monitor. For Wi-Fi, look at the VTH5422HW or VTH5123H-W models.
Can it record to SD card?No. The VTH2621GW-P does not support local storage; recording is handled by your NVR or intercom server.
What is the difference from the black version?The VTH2621GW-P is white; the VTH2621G-P is the black version. Specs are otherwise the same.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · DHI-VTH2621G-P · 7" IP PoE Indoor Monitor · BlackIP PoE MonitorDahua DHI-VTH2621G-P 7" IP PoE Indoor Monitor (Black)
The Dahua DHI-VTH2621G-P is a sleek black 7-inch IP indoor monitor for integrated intercom systems. A responsive 1024×600 capacitive touchscreen, standard PoE for single-cable installation, and H.265/H.264 decoding make it a high-performance yet cost-effective panel. View door stations and IP cameras, manage six alarm zones, and drop it neatly into any Dahua IP intercom deployment, residential or commercial.
Screen
7" Touch
Resolution
1024×600
Wiring
IP / PoE
Power
Standard PoE
Codec
H.265
Alarm In
6 Channel
Single-cable PoE install
Standard PoE powers and networks the monitor over one Ethernet run, cutting wiring time and removing the need for a separate plug-pack.
View doors and cameras
Display Dahua IP door stations and IP cameras on the crisp touchscreen with efficient H.265/H.264 decoding.
Alarm-ready
Six alarm inputs and one output let you connect door, window and motion sensors directly to the monitor for layered protection.
Sleek black design
A high-performance, cost-effective panel in black that integrates cleanly into modern residential and commercial interiors.
Specifications — DHI-VTH2621G-P
Screen
7" TFT capacitive touchscreen
Resolution
1024 × 600
Colour
Black
Technology
IP
Video Decoding
H.265 / H.264
Alarm I/O
6-channel input / 1-channel output
Storage
Not supported
Power Supply
DC 12V or standard PoE
Compatibility
Dahua IP door stations and IP cameras
Warranty
3 years · CCTV Guru Australia
Downloads
DHI-VTH2621G-P DatasheetDahua Digital VTH User Manual
Is this a PoE monitor?Yes. The VTH2621G-P supports standard PoE so it can be powered and networked over a single Ethernet cable, or run from DC 12V.
Does it have Wi-Fi?No. This is a wired IP/PoE monitor. For Wi-Fi, look at the VTH5422HW or VTH5123H-W models.
Can it record to SD card?No. The VTH2621G-P does not support local storage; recording is handled by your NVR or intercom server.
What is the difference from the white version?The VTH2621G-P is black; the VTH2621GW-P is the white version. Specs are otherwise the same.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua IP Video Intercom Kit · 7" Monitor · DMSS App Access
Dahua DHI-KTP01L-S IP Video Intercom Kit with 7" Monitor & PoE Switch
The Dahua DHI-KTP01L-S is a complete IP video intercom kit for Australian homes, villas, townhouses, offices and small businesses that want a smarter way to manage front-door access. It includes a 7-inch indoor touch screen monitor, a 2MP IP villa door station and a PoE network switch for a clean, modern installation.
Visitors can call from the outdoor station, while users can answer from the indoor monitor or use the DMSS mobile app to talk to visitors and remotely unlock a compatible door or gate. It is a strong upgrade from basic analogue intercoms and consumer doorbells.
Indoor Monitor
7" Touch Screen
Door Station
2MP Wide Angle
Mobile App
DMSS Remote Access
PoE
4 PoE + 2 Uplink
Unlock
App · Monitor
Outdoor Rating
IP65 · IK07
Authorised Dahua Reseller
Fast Australia-Wide Shipping
Expert Intercom Advice
What’s in the Box
1 × IP Villa Door Station
2MP IP villa door station with anodised aluminium front panel, 168.6° wide-angle camera, auto IR, two-way audio, tamper alarm, IP65 / IK07 protection and remote unlock support.
1 × 7" IP Indoor Monitor
7-inch TFT capacitive touch screen monitor with 1024 × 600 resolution, two-way audio, door station monitoring, IPC monitoring, 6 alarm inputs and 1 alarm output.
1 × PoE Network Switch
Compact PoE switch with 4 × PoE ports and 2 × uplink ports, designed to power and connect the intercom system cleanly over network cabling.
Mounting Accessories Included
Includes surface-mount hardware for the outdoor station and indoor monitor, helping create a cleaner installation for homes, villas and business entrances.
Why Choose the Dahua KTP01L-S?
Answer from the Monitor or Phone
Use the indoor monitor when you are inside, or use the DMSS mobile app to talk to visitors and unlock compatible access points remotely.
Ultra-Wide Visitor View
The 2MP door station provides a wide 168.6° horizontal view, helping capture more of the entry area than narrow-view door stations.
Cleaner IP-Based Installation
Standard PoE support helps reduce wiring complexity by carrying power and data through network cabling.
Expandable Smart Entry System
Supports additional compatible indoor monitors and can integrate with compatible door locks, exit buttons and door status detection.
Recommended For
Homes & Villas
See who is at the front door, speak to visitors and unlock a compatible gate or door from the screen or your phone.
Townhouses & Duplexes
A clean single-entry intercom solution with a proper monitor, outdoor station and app-based remote answering.
Small Offices & Reception Areas
Let staff screen visitors before granting access to reception, side doors or controlled business entries.
Clinics & Professional Suites
Ideal for customer-facing offices where visitor screening and controlled access matter.
Technical Specifications
Door Station — IP Villa Station
Camera
1/2.9" 2MP CMOS
Field of View
H: 168.6° · V: 87.1° · D: 176.7°
WDR
120 dB
Noise Reduction
3D NR
Video Compression
H.265 / H.264
Audio
Two-way audio with echo suppression and digital noise reduction
Unlock Mode
Remote unlock
Storage
MicroSD card support up to 256GB
Network Port
1 × RJ-45 10/100 Mbps
Power
12 VDC 2A or PoE 802.3af/at
Protection
IP65 · IK07
Installation
Surface mount, surface mount box included
Dimensions
130 mm × 96 mm × 28.5 mm
Operating Temperature
-30°C to +60°C
Indoor Monitor — 7" IP Monitor
Display
7" TFT capacitive touch screen
Resolution
1024 × 600
Audio
Two-way audio, built-in speaker
Video Decoding
H.265 / H.264
Door Station Monitor
Supported
IPC Monitor
Supported
Alarm Input
6 channels
Alarm Output
1 channel
Door Bell
Supported, reusing alarm input port
Network Port
1 × RJ-45 10/100 Mbps Ethernet
Power
12 VDC 1A or Standard PoE
Installation
Surface mount
Colour
White
Dimensions
189.6 mm × 134.6 mm × 26.0 mm
Operating Temperature
-10°C to +55°C
Networking Device — PoE Switch
PoE Ports
4 × 10/100 Mbps PoE ports
Uplink Ports
2 × 10/100 Mbps uplink ports
Power Supply
Built-in 100–240 VAC power supply
Power Consumption
0.5 W idle, 36 W full load
Operating Temperature
-10°C to +55°C
Colour
Black
Dimensions
194.0 mm × 108.1 mm × 35.0 mm
FAQs
Does the Dahua DHI-KTP01L-S work with the DMSS app?
Yes. The system supports mobile app access, allowing you to talk to visitors and unlock a compatible door remotely from your phone.
Does the kit include a PoE switch?
Yes. The kit includes a PoE networking device with 4 PoE ports and 2 uplink ports.
Can it unlock a door or gate?
Yes. The door station supports remote unlock when connected to a compatible electric strike, lock or gate release.
Is the outdoor station weather rated?
Yes. The door station is rated IP65 and IK07 when installed correctly with appropriate sealing.
Can I connect cameras to the monitor?
Yes. The indoor monitor supports door station and IPC monitoring, depending on the final system configuration.
Is this better than an analogue intercom?
Yes, for most modern installations. This is an IP-based system with app access, PoE support and better expansion options than basic analogue intercom kits.
More Information
Datasheet
Order Your Dahua DHI-KTP01L-S from CCTV Guru Australia
CCTV Guru supplies genuine Dahua video intercom products for Australian homes, offices, clinics and small businesses. Order the Dahua DHI-KTP01L-S IP Video Intercom Kit today for fast Australia-wide shipping, expert pre-sales advice and local support when choosing extra monitors, locks, access control accessories and PoE networking equipment.
4-Wire Hybrid Kit · Wi-Fi Monitor · DMSS App Control
Dahua DHI-KTH01M 4-Wire Hybrid Video Intercom Kit with Wi-Fi Indoor Monitor
The Dahua DHI-KTH01M is a smart hybrid video intercom kit designed for Australian homes, villas, apartments, offices and small commercial buildings. It combines a modern 7-inch touchscreen indoor monitor with a durable outdoor door station, delivering visitor video, two-way audio, remote door release and mobile app control in one complete package.
Unlike traditional analogue intercom systems, the KTH01M bridges both 4-wire analogue installations and modern IP-based functionality. The system supports Wi-Fi connectivity, DMSS mobile app integration, PoE networking, alarm integration and IP camera monitoring, making it an excellent upgrade path for older intercom systems without requiring a complete site rewire.
Model
DHI-KTH01M
Monitor
7" Touchscreen
Connectivity
Wi-Fi · PoE
App
DMSS Mobile
Outdoor Station
IP66 Rated
System
Hybrid 4-Wire
Genuine Dahua
Australian Stock
Local Tech Support
What’s Included in the Kit
1 × DHI-VTH2624GW-WP Indoor Monitor7-inch TFT capacitive touchscreen indoor monitor with Wi-Fi, PoE support, alarm integration, SD card support and DMSS app connectivity.
1 × DHI-VTO1000JM Outdoor StationDurable outdoor video door station with mechanical call button, visitor calling, two-way audio and remote door release support.
Mounting AccessoriesIncludes Dahua-supplied mounting accessories for a clean residential or small commercial installation.
DMSS App SupportAnswer calls, view visitors and unlock the door remotely from your smartphone using the Dahua DMSS app.
Why Choose the Dahua DHI-KTH01M?
Upgrade Older 4-Wire IntercomsIdeal for replacing older analogue intercom systems while adding modern app control, video calling and IP functionality.
7-Inch Touchscreen MonitorThe indoor monitor provides a clear touchscreen interface for answering calls, viewing visitors and unlocking the door.
Remote Unlock with DMSSReceive visitor calls and unlock the door from your phone when configured with the DMSS app and compatible network setup.
Wi-Fi and PoE FlexibilityThe indoor monitor supports Wi-Fi and PoE, giving installers more flexibility across retrofit and new-build applications.
IP Camera MonitoringMonitor compatible Dahua IP cameras from the indoor station for a more complete front-door security experience.
Weather-Resistant Outdoor StationThe outdoor station is designed for Australian entry points with IP66 protection for outdoor use.
Recommended For
Homes & VillasAnswer the front door from the indoor monitor or smartphone, with remote unlock support for visitors and deliveries.
Apartment UpgradesA strong option for selected apartment or unit applications where existing 4-wire cabling can be reused.
Small OfficesControl visitor access at the front entrance and allow staff to answer calls from the monitor or mobile app.
Clinics & Reception AreasManage visitor entry without leaving reception, consultation rooms or staff areas.
Retail & Back EntrancesSecure rear doors, staff entries and delivery points with video calling and controlled release.
Retrofit Intercom ProjectsPerfect when customers want a smarter system without starting again with a full IP intercom rewire.
Watch the Dahua Hybrid Intercom in Action
Dahua hybrid 4-wire video intercom demonstration showing the indoor monitor, outdoor station and smart intercom functionality.
Technical Specifications
Indoor Monitor — DHI-VTH2624GW-WP
Display
7-inch TFT capacitive touchscreen
Resolution
1024 × 600
Network
1 × RJ-45 10/100 Mbps
Wi-Fi
Supported
PoE
Standard PoE supported
Alarm Input
6 channels
Alarm Output
1 channel
SD Card
Up to 64 GB
Mobile App
DMSS
IP Camera Monitoring
Supported
Outdoor Station — DHI-VTO1000JM
Product Type
4-wire outdoor video door station
Call Button
Mechanical button
Video Compression
H.264
Door Release
Supported with compatible lock hardware
Weather Protection
IP66
Application
Villa, home, office and small commercial entry points
Installation Notes
Check Existing 4-Wire CablingFor retrofit jobs, confirm cable condition, cable path and compatibility before replacing an older intercom system.
Plan Door Lock HardwareElectric strikes, magnetic locks, exit buttons and power supplies are normally selected separately based on the door type.
Network Setup Required for App UseDMSS mobile app features require correct network configuration and internet access.
Professional Installation RecommendedFor best results, use a qualified security or intercom installer, especially when door release hardware is required.
Downloads & Resources
Download the Dahua datasheet or contact CCTV Guru for help selecting compatible locks, exit buttons, power supplies and installation accessories.
Download Datasheet
Dahua Intercom Quick Start Guide
Dahua Intercom User Manual
Frequently Asked Questions
Can the Dahua DHI-KTH01M replace an old 4-wire intercom?Yes, it is designed as a hybrid 4-wire kit and is a strong option for upgrading many older intercom systems, subject to cabling and site compatibility.
Does it work with the DMSS app?Yes. The system supports Dahua DMSS app connectivity for mobile viewing, call answering and remote unlock where configured correctly.
Can I unlock the door remotely?Yes, remote unlock is supported when connected to compatible electric strike or magnetic lock hardware and configured correctly.
Does the indoor monitor connect by Wi-Fi?Yes. The DHI-VTH2624GW-WP indoor monitor supports Wi-Fi connectivity.
Is the outdoor station weatherproof?Yes. The outdoor station is IP66 rated for outdoor use.
Can I view Dahua IP cameras on the monitor?Yes. The system supports compatible IP camera monitoring through the indoor monitor.
Does the kit include a door lock?No. Electric strikes, magnetic locks, exit buttons and power supplies are selected separately based on your door and installation requirements.
Does it support PoE?Yes. The indoor monitor supports standard PoE for cleaner installation options.
Is this suitable for apartments?Yes, it can suit selected apartment, villa and unit applications, depending on the existing wiring and installation design.
Do you ship Australia-wide?Yes. CCTV Guru ships genuine Dahua intercom products Australia-wide with local support.
Order the Dahua DHI-KTH01M from CCTV Guru
Order the Dahua DHI-KTH01M 4-Wire Hybrid Video Intercom Kit from CCTV Guru for genuine Dahua hardware, fast Australia-wide dispatch and local advice on compatible electric strikes, magnetic locks, exit buttons, power supplies and installation accessories.
Dahua · DHI-VTO2311R-WP · IP & Wi-Fi Villa Door Station · Slim Card-Unlock Design
Wi-Fi Villa Station
Dahua DHI-VTO2311R-WP IP & Wi-Fi Villa Door Station — Slim 2MP HD Camera with Card & App Unlock
The Dahua DHI-VTO2311R-WP is an ultra-slim villa door station with a 1/2.8" 2MP HD CMOS camera and built-in Wi-Fi. Built from tough PC and ABS for indoor or outdoor mounting, it offers two-way video calling, IR night vision with auto WDR, and IC card or app unlock. Power it over PoE or 12V DC and pair it with a Dahua indoor monitor for a complete home intercom.
Camera
2MP HD
Wiring
IP / Wi-Fi / PoE
Audio
Two-Way Video
Unlock
Card / App
App
DMSS
Weatherproof
IP65
Ultra-Slim, Discreet Design
The low-profile PC/ABS housing sits flush and clean against any entrance, indoors or out. It is a tidy modern look that suits apartments, units and villa front doors alike.
Built-In Wi-Fi
On-board Wi-Fi means you can place the station where wired networking is awkward. It still supports a wired connection and PoE when you want the most reliable link.
Clear Day & Night Video
The 2MP HD CMOS sensor with IR illumination and auto WDR keeps faces visible in glare or darkness, while H.264/H.265 compression keeps recordings efficient.
Video Calls & App Unlock
Answer two-way video calls on your Dahua indoor monitor or the DMSS app, review voice and video messages from visitors, and unlock the door from your phone or with an IC card.
Specifications — DHI-VTO2311R-WP
Type
Villa / home outdoor door station
Camera
1/2.8" 2MP HD CMOS
Wiring
IP / Wi-Fi
Night Vision
IR illumination, auto WDR
Unlock Methods
IC card, remote app, indoor monitor
Audio / Video
Two-way video call; visitor voice & video messages
Compression
H.264 / H.265
App
DMSS
Power
PoE or DC 12V
Ingress
IP65
Material / Mount
PC + ABS · surface mount
Pairs With
Dahua IP indoor monitors (VTH series)
Warranty
3 years · CCTV Guru Australia
Downloads & Resources
DHI-VTO2311R-WP Datasheet
Dahua Villa Door Station User Manual
Can it run on Wi-Fi?Yes. The VTO2311R-WP has built-in Wi-Fi, and it also supports a wired IP connection with PoE for the most reliable link.
How do visitors unlock the door?You unlock remotely from the DMSS app or a paired Dahua indoor monitor, and residents can also use an IC card at the station.
Can I see and talk to visitors on my phone?Yes. It supports two-way video calling through the DMSS app, plus visitor voice and video messages you can review on the indoor monitor.
Which indoor monitor does it pair with?It pairs with Dahua IP indoor monitors (VTH series). Contact our team for a matching monitor to complete the kit.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · DHI-VTO2202F-P-S3 · 2-Wire IP Villa Door Station · 160° Fisheye + PoE
2-Wire Villa Station
Dahua DHI-VTO2202F-P-S3 2-Wire IP Villa Door Station — 2MP Fisheye Camera with 2-Wire & RJ45
The Dahua DHI-VTO2202F-P-S3 is a flexible villa door station that accepts both 2-wire and RJ45 (Ethernet) connections. Its 2MP low-illumination colour fisheye camera delivers a wide ~168° horizontal view with 120 dB WDR, while an anodised aluminium panel rated IP65/IK07 keeps it tough outdoors. Two-way talk, H.265 compression, dual-lock control and PoE power make it a versatile entrance solution.
Camera
2MP Fisheye
Wiring
2-Wire / RJ45
Audio
Two-Way Talk
WDR
120 dB
Lock Control
Dual Lock
Weatherproof
IP65 / IK07
2-Wire or Ethernet
Connect via Dahua's 2-wire system or a standard RJ45 network port — whichever suits your cabling. This flexibility makes retrofits and new installs equally straightforward.
Wide Fisheye Coverage
The 2MP low-illumination colour fisheye lens delivers roughly a 168° horizontal field of view, so callers and the area around the door are captured in a single frame.
Clear in Tricky Light
120 dB WDR, 3D noise reduction and auto IR keep video clear against backlight and after dark, while efficient H.265 compression saves storage and bandwidth.
Dual-Lock & PoE
Control an electric lock with exit button and door-status detection, and power everything over standard PoE or a Dahua 2-wire switch for a clean install.
Specifications — DHI-VTO2202F-P-S3
Type
Villa / home door station (2-wire & IP)
Camera
1/2.5" 2MP CMOS low-illumination colour fisheye
Field of View
~168.6° horizontal
WDR / NR
120 dB WDR · 3D NR
Wiring
2-Wire or RJ45 (10/100M)
Button
Mechanical
Compression
H.265
Audio
Two-way voice; echo & noise reduction
Lock Control
Electric lock, exit button, door-status detection
Power
Dahua 2-wire switch / DC 48V / standard PoE (≤ 12W)
Ingress / Impact
IP65 · IK07
Material / Mount
Anodised aluminium · surface & flush mount
Warranty
3 years · CCTV Guru Australia
Downloads & Resources
DHI-VTO2202F-P-S3 Datasheet
Dahua Villa Door Station Quick Start Guide
Dahua Villa Door Station User Manual
Can it use a normal network cable?Yes. The VTO2202F-P-S3 supports both Dahua 2-wire and a standard RJ45 Ethernet connection, so you can wire it whichever way suits your install.
How wide is the camera view?It uses a 2MP fisheye lens with roughly a 168° horizontal field of view, capturing callers and the surrounding area in one frame.
How is it powered?Via a Dahua 2-wire switch, DC 48V, or standard PoE. Power consumption is around 12W.
Which indoor monitor does it pair with?It pairs with Dahua indoor monitors (VTH series). Contact our team for a matching monitor to complete your intercom.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · DHI-VTH1020J · 7" Analog Indoor Monitor · Multiple Bell SoundsAnalog Indoor MonitorDahua DHI-VTH1020J 7" 4-Wire Analog Indoor Monitor
The Dahua DHI-VTH1020J is a straightforward 7-inch analog indoor monitor for 4-wire video intercom systems. Its 800×480 TFT display and simple mechanical buttons make answering the door, holding a video call, adjusting volume and remotely unlocking the gate effortless. With multiple selectable bell sounds, it is an affordable, reliable choice for analog villa intercom setups. Note: the power supply is sold separately.
Screen
7" TFT
Resolution
800×480
Wiring
4-Wire
Control
Buttons
Audio
Two-Way
Bells
Multiple
Simple, reliable intercom
Mechanical buttons make answering the door, holding a video call and adjusting the volume intuitive for every member of the household.
Unlock from the screen
Trigger your gate or door release straight from the monitor without leaving the comfort of your living room.
Choose your chime
Multiple selectable bell sounds let you personalise the door tone so you always know when someone is calling.
Affordable analog choice
A cost-effective 4-wire monitor that slots neatly into Dahua analog villa intercom systems for clear doorway monitoring.
Specifications — DHI-VTH1020J
Screen
7" TFT display
Resolution
800 × 480
Colour
White
Technology
Analog (4-wire)
Audio
Two-way voice and video intercom
Controls
Mechanical buttons
Bell Sounds
Multiple selectable
Functions
Unlock, voice/video call, volume, doorway monitoring
Power Supply
DC 12V (sold separately)
Warranty
3 years · CCTV Guru Australia
Downloads
DHI-VTH1020J Datasheet
Does the power supply come included?No. The DHI-VTH1020J needs a DC 12V power supply, which is sold separately. Add a Dahua 12V plug-pack to your order if you do not already have one.
Is this monitor IP or analog?It is a 4-wire analog monitor designed for Dahua analog villa intercom systems, not IP or 2-wire digital setups.
Can it record video?No. The VTH1020J is a live-view intercom monitor without onboard recording. For recording, choose an IP or 2-wire model with micro SD support.
Can I change the door chime?Yes. It offers multiple selectable bell sounds so you can pick the tone that suits you best.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · VTM08R · Surface rain cover for VTO6221E-P / VTO3221E-P
Rain cover
Dahua DH-AC-VTM08R Surface-Mount Rain Cover
The DH-AC-VTM08R is a surface-mounted rain cover that shields the Dahua VTO6221E-P and VTO3221E-P door stations from rain, dust and direct sun. Machined from aluminium with a silver finish, it fits neatly over a surface-mounted intercom to keep it reliable outdoors while maintaining a clean, professional look.
Specifications — VTM08R
Type
Surface-mount rain cover
Compatible With
Dahua VTO6221E-P, VTO3221E-P
Material
Aluminium
Finish / Colour
Silver
Dimensions
205.1 x 108.9 x 39.8 mm
Warranty (Australia)
3 years · CCTV Guru Australia
VTM08R Datasheet
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · VTM114 · Flush box for VTO2202F-P Flush box
Dahua DH-AC-VTM114 Flush Mount Box
The DH-AC-VTM114 is a flush-mount box for the Dahua VTO2202F-P villa door station. It recesses into the wall so the intercom sits flush against the surface for a clean, tamper-resistant finish. Cast from ADC12 aluminium alloy with a silver finish for durable outdoor use.
Specifications — VTM114
Type
Flush mount box
Compatible With
Dahua VTO2202F-P
Material
ADC12 aluminium alloy
Finish / Colour
Silver
Dimensions (front)
128.9 x 162.9 x 34.5 mm
Warranty (Australia)
3 years · CCTV Guru Australia
VTM114 Datasheet
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision Video Intercom Accessory
Hikvision DS-KABV6114-RS Rain Shield for Villa Door Stations
The Hikvision DS-KABV6114-RS is a genuine protective rain shield designed for compatible
Hikvision villa door stations. It helps protect the outdoor intercom from direct rain exposure while giving
the installation a cleaner, more professional surface-mounted finish.
This accessory is ideal when installing a Hikvision door station on an exposed wall, front gate pillar,
entryway or outdoor-facing surface where extra protection and a neater finish are required.
Protection
Rain Shield Cover
Compatibility
KV6114 / KV6124 Series
Mounting
Surface Mount
Material
PC Protective Body
Why Use the DS-KABV6114-RS?
Helps Protect Outdoor Door Stations
Adds a protective cover around the compatible Hikvision villa door station to help reduce direct exposure
to rain and outdoor conditions.
Cleaner Surface-Mounted Finish
Gives the installation a more finished look, especially on rendered walls, brickwork, gate pillars and
exposed entrance areas.
Made for Compatible Hikvision Models
Designed for Hikvision KV6114 and KV6124 series villa door stations, including popular 4MP Hikvision
villa intercom door stations.
Ideal for Homes and Small Businesses
A simple but useful add-on for front doors, gates, offices, townhouses, duplexes and small commercial
entry points.
Key Specifications
Model
DS-KABV6114-RS
Product Type
Rain shield / protective shield for Hikvision villa door stations
Installation
Surface mounting
Compatible Series
Hikvision DS-KV6114 / DS-KV6124 series villa door stations
Material
PC
Dimensions
194.49 mm × 84.62 mm × 47 mm
Working Temperature
-40°C to 60°C
Working Humidity
10% to 95%, non-condensing
Compatible Hikvision Door Stations
The DS-KABV6114-RS is commonly used with Hikvision villa door stations from the KV6114 and KV6124 series.
It is especially useful when the door station is installed outdoors or in an area with partial weather exposure.
DS-KV6114 Series
Suitable for compatible Hikvision DS-KV6114 villa door stations where a surface-mounted rain shield is required.
DS-KV6124 Series
Suitable for compatible Hikvision DS-KV6124 keypad villa door stations where extra outdoor protection is preferred.
Recommended Add-ons
Hikvision Villa Door Station
Pair this rain shield with a compatible Hikvision DS-KV6114 or DS-KV6124 villa door station.
Hikvision Indoor Monitor
Complete the intercom setup with a compatible Hikvision indoor station for video calling and door release control.
Electric Strike or Gate Relay
Add door or gate release hardware so visitors can be granted access from the indoor monitor or app.
PoE Switch or Power Supply
Depending on your intercom design, a PoE switch, power supply or compatible network hardware may be required.
FAQs
What is the DS-KABV6114-RS used for?
It is a rain shield / protective shield for compatible Hikvision villa door stations.
Is this a Hikvision genuine accessory?
Yes. The DS-KABV6114-RS is a Hikvision video intercom accessory.
Does it suit the DS-KV6114 series?
Yes. It is designed for compatible Hikvision KV6114 series villa door stations.
Does it suit the DS-KV6124 series?
Yes. It is also commonly listed for compatible KV6124 series villa door stations.
Is this for surface mounting?
Yes. The DS-KABV6114-RS is designed for surface-mounted installations.
Is it suitable for outdoor intercom installs?
Yes. It is designed to help protect compatible outdoor villa door stations from direct weather exposure.
Genuine Hikvision
Australia-Wide Shipping
Fast Dispatch
Dahua · DHI-VTO2101E-P-S2 · IP Villa Door Station · IK10 Vandal-Resistant
IK10 Villa Station
Dahua DHI-VTO2101E-P-S2 IP Villa Door Station — 2MP HD, Adjustable 100° Angle & IK10 Build
The Dahua DHI-VTO2101E-P-S2 is a tough IP villa door station with a 2MP HD CMOS camera, a 100° wide and adjustable viewing angle, and ICR night vision to around 5m. Its zinc-alloy panel carries a vandal-resistant IK10 rating alongside IP65 weatherproofing. With TCP/IP and SIP support, video & audio messaging and PoE power, it is a durable single-button entrance unit.
Camera
2MP HD
Wiring
IP PoE
View
100° Adjustable
Night Vision
ICR ~5m
Protocols
TCP/IP & SIP
Weatherproof
IP65 / IK10
Vandal-Resistant IK10
A solid zinc-alloy panel rated IK10 — the highest impact class — plus IP65 weatherproofing makes this station ideal for exposed or high-traffic entrances.
Adjustable Wide View
The 2MP camera offers a 100° wide angle that can be physically adjusted, letting you aim the lens to capture callers clearly at your specific door.
Clear Night Vision
ICR-based night vision lights visitors out to around 5 metres, and voice prompts confirm calls and actions for an easy experience after dark.
IP & SIP Ready
TCP/IP and SIP support let it integrate into Dahua IP intercom systems, with video and audio messaging to capture visitors when you are away.
Specifications — DHI-VTO2101E-P-S2
Type
Villa / home IP door station
Camera
2MP HD CMOS, 100° adjustable angle
Wiring
IP / PoE
Night Vision
ICR, ~5m
Protocols
TCP/IP, SIP
Messaging
Video & audio messaging
Power
DC 12V / PoE
Ingress / Impact
IP65 · IK10
Material / Mount
Zinc alloy front · surface mount
Pairs With
Dahua IP indoor monitors (VTH series)
Warranty
3 years · CCTV Guru Australia
Downloads & Resources
DHI-VTO2101E-P Datasheet
Dahua Villa Door Station Quick Start Guide
How tough is this door station?The zinc-alloy panel is rated IK10 — the highest impact class — and IP65 weatherproof, making it well suited to exposed entrances.
Can I adjust the camera angle?Yes. The 2MP camera has a 100° wide angle and a physically adjustable viewing angle so you can aim it at your door.
How is it powered?It runs on PoE or DC 12V, so a single network cable can carry both power and data.
Which indoor monitor does it pair with?It pairs with Dahua IP indoor monitors (VTH series). Ask our team for a matching monitor to complete your intercom.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua Video Intercom Series · Android 10" Indoor Monitor · Australian Stock
Android 10" Monitor
Dahua DHI-VTH5341G-W — 10" Android Digital Indoor Monitor
The Dahua DHI-VTH5341G-W is a premium 10-inch Android-powered indoor monitor designed for residential and light commercial video intercom systems. Featuring a large 10" TFT capacitive touchscreen at 1024×600 resolution and running Android 8.1, it delivers a smooth, intuitive user experience for answering door calls, monitoring cameras, controlling access and managing building communications. With both Ethernet and Wi-Fi connectivity, flexible installation is straightforward across Australian homes, apartments and villa complexes.
The VTH5341G-W supports 8 alarm inputs, SOS, two-way voice calls with echo suppression, elevator control, and leave-video/message functionality (with microSD card). A 12V DC or standard PoE power supply keeps installation simple, while the surface-mount design and included accessories make it a complete out-of-box solution for Dahua intercom deployments.
Display
10" TFT · 1024×600 Touch
OS
Android 8.1
Connectivity
Ethernet · Wi-Fi 2.4GHz
Audio
Two-Way · Echo Suppression
Alarm Inputs
8 Inputs · 1 Output · SOS
Power
12V DC · Standard PoE
Dahua Video Intercom
Australian Stock & Support
Dahua Warranty
Why Choose the Dahua DHI-VTH5341G-W in Australia
The DHI-VTH5341G-W is the ideal indoor monitor for Australian residential estates, apartment complexes and villa installations where a large, responsive touchscreen and flexible connectivity are priorities. Its Android platform delivers a familiar, app-like interface for residents, while the dual Ethernet/Wi-Fi connectivity gives installers flexibility in cable-constrained environments. With 8 alarm inputs, elevator control and leave-message capability, it's a fully featured intercom hub — not just a doorbell screen.
10" Capacitive Touchscreen
The large 1024×600 TFT LCD display provides a clear, responsive interface for answering calls, viewing door cameras and navigating menus — easy for all household members to use.
Android 8.1 Platform
Running Android 8.1, the VTH5341G-W offers a modern, user-friendly UI with smooth navigation and compatibility with Dahua's intercom ecosystem and management software.
Ethernet & Wi-Fi Connectivity
Dual connectivity options — wired 10/100M Ethernet or 2.4GHz Wi-Fi (802.11b/g/n) — give installers flexibility and residents a reliable connection in any Australian home layout.
Two-Way Voice with Echo Suppression
Crystal-clear two-way audio with built-in echo suppression and digital noise reduction (DNR) ensures natural, interference-free conversations between residents and visitors.
8 Alarm Inputs + SOS
Eight alarm input ports and one alarm output support integration with door sensors, PIR detectors and other security devices, while the SOS button provides instant emergency alerting.
Leave Video & Text Messages
Visitors can leave video or text messages when residents are unavailable (microSD card required, up to 256 GB) — ensuring no visitor interaction is missed.
Technical Specifications
Model
DHI-VTH5341G-W
Operating System
Android 8.1
Display
10" TFT LCD Capacitive Touchscreen
Resolution
1024 × 600
Video Compression
H.264
Audio Compression
PCM
Audio Input
1 × Omnidirectional Microphone
Audio Output
Built-in 1.5W Speaker
Audio Mode
Two-Way Voice Call
Audio Enhancement
Echo Suppression / DNR
Audio Bit Rate
16 kHz, 16-bit
Network Protocol
IPv4, TCP, SIP, UDP, RTSP
Wi-Fi Standard
IEEE 802.11b/g/n
Wi-Fi Frequency
2.4 GHz
Wi-Fi Security
64/128-bit WEP · WPA/WPA2 · WPA-PSK/WPA2-PSK · WPS
Network Port
1 × 10M/100M Ethernet (RJ45)
RS-485
1
Alarm Input
8
Alarm Output
1
Power Output
1 × 12V / 100mA
Door Bell
Yes (via alarm input port)
SOS
Yes
Elevator Control
Yes (via indoor monitor)
Leave Video/Message
Yes (microSD card required)
DND Mode
Yes (configurable do-not-disturb period)
Information Release
Yes (management centre text announcements)
Extension Numbers
Villa: 4 · Apartment: 9
Edge Storage
microSD up to 256 GB
Communication Mode
Full Digital
Power Supply
12V DC 1A · Standard PoE
Power Consumption
≤1.5W (standby) · ≤7W (working)
Installation
Surface Mount
Housing Material
PC + ABS
Colour
Black
Dimensions
260 × 170 × 15 mm (without ports) · 260 × 170 × 25.4 mm (with ports)
Net Weight
770 g (1.70 lb)
Gross Weight
1.1 kg (2.43 lb)
Operating Temperature
-10°C to +55°C
Operating Humidity
10%–95% RH (Non-condensing)
Operating Altitude
< 3,000 m
Certifications
CE · FCC
Accessories Included
Surface mount bracket · Alarm ribbon cable · RS-485 cable · Power-supply pins
Warranty
Dahua Warranty (Australia)
Downloads & Resources
DHI-VTH5341G-W Datasheet
Quick Start Guide (PDF)
User Manual (PDF)
Installation Procedure (PDF)
Dimensions Drawing (PDF)
Order the Dahua DHI-VTH5341G-W from CCTV Guru
CCTV Guru is an authorised Australian distributor of Dahua video intercom products. Order the DHI-VTH5341G-W today for fast Australia-wide dispatch, expert pre-sales advice and full local warranty support. Contact our team for project pricing on multi-unit apartment or villa intercom installations.
Hikvision Intercom Kit · Keypad Access · PoE Powered
Hikvision Keypad Video Intercom Kit with 4MP Door Station, 10.1" Monitor & PoE Switch
The Hikvision Keypad Video Intercom Kit is a complete PoE-powered access control solution for Australian homes, offices, rental properties, gated entries and small commercial sites. It combines the DS-KV6124-WBE1 4MP villa door station, DS-KH9570-WTE1/S 10.1" indoor station and DS-3E1105P-EI PoE switch into one ready-to-install bundle.
Unlike a basic video doorbell, this kit gives you multiple unlock options including PIN code, RFID card, Bluetooth, indoor monitor unlock and Hik-Connect app control. The wired PoE design provides a cleaner, more reliable installation than Wi-Fi-only intercoms, while the large 10.1" indoor touchscreen gives users a premium control point inside the property.
Door Station
4MP Keypad
Access
PIN · Card · App
Monitor
10.1" Touchscreen
Power
PoE Switch Included
Locks
2 Lock Control
Remote Access
Hik-Connect App
Complete PoE Kit
PIN & Card Access
Australian Support
What’s Included
1 × Hikvision DS-KV6124-WBE14MP villa door station with keypad, 150° viewing angle, card access, PIN code unlock, Bluetooth unlock, Hik-Connect unlock, indoor station unlock and 2-lock control.
1 × Hikvision DS-KH9570-WTE1/SPremium 10.1" IPS indoor station with 1920 × 1200 resolution, Android 14 platform, dual microphones and speakers, noise suppression and echo cancellation.
1 × Hikvision DS-3E1105P-EI4-port Fast Ethernet smart PoE switch with 4 × 10/100 Mbps PoE ports, 1 × 10/100 Mbps uplink port, 60W PoE budget and 6kV surge protection on PoE ports.
Installer-Ready PoE SetupDesigned for a clean wired installation. The PoE switch powers the door station and indoor monitor over network cabling, reducing messy power adapters and Wi-Fi reliability issues.
Why Choose This Keypad Intercom Kit?
PIN Access Without KeysGive family, staff, tenants or trusted visitors a PIN code instead of handing out physical keys.
Multiple Unlock MethodsUnlock using PIN code, RFID card, Bluetooth, the indoor monitor or Hik-Connect mobile app.
Premium Indoor ControlThe 10.1" indoor screen provides a modern control point for answering calls, viewing the door station and unlocking the entry.
Wired PoE ReliabilityPoE is more stable than Wi-Fi-only doorbells and is better suited to permanent homes, offices, gates and rental properties.
Great for Multi-User SitesIdeal where different users need different access methods — homeowners, staff, cleaners, trades or short-stay guests.
Remote App ControlUse Hik-Connect to view the door station, talk to visitors and unlock remotely where configured correctly.
Recommended For
Family HomesFront door, side gate or pedestrian gate access with indoor screen and mobile app control.
Offices & StudiosAllow staff entry by PIN or card while keeping visitor calls visible from the monitor.
Airbnb & RentalsUseful for properties where codes are easier than physical keys or remote handovers.
Gated EntriesUse the 2-lock control capability for pedestrian gates, electric strikes or compatible access hardware.
Technical Specifications
Door Station — Hikvision DS-KV6124-WBE1
Camera
4MP door station camera
Viewing Angle
150° viewing angle
Unlock Methods
Card, PIN code, Bluetooth, Hik-Connect and indoor station unlock
Lock Control
2 locks control
Remote Features
Video recording and playback via Hik-Connect or PC web
Power
IEEE 802.3at PoE
Application
Villa / residential / small commercial door station
Indoor Station — Hikvision DS-KH9570-WTE1/S
Display
10.1" IPS touch display
Resolution
1920 × 1200
Operating Platform
Android 14
Performance
4-core processor · Up to 4GB RAM + 8GB ROM
Audio
Dual microphones and speakers
Audio Processing
Noise suppression and echo cancellation
Use Case
Indoor call answering, monitoring and access control
PoE Switch — Hikvision DS-3E1105P-EI
PoE Ports
4 × 10/100 Mbps PoE RJ45 ports
Uplink Port
1 × 10/100 Mbps RJ45 port
PoE Standard
IEEE 802.3af / IEEE 802.3at
PoE Budget
60W total
Max Port Power
30W per PoE port
Surge Protection
6kV surge protection for PoE ports
Housing
Metal shell, fan-free design
Downloads & Resources
DS-KV6114-WBE1 Datasheet
DS-KH9570-WTE1 Datasheet
DS-KV6114-WBE1 Quick Start Guide
DS-KH9570-WTE1 Quick Start Guide
User Manual
P2P Setup Guide
Frequently Asked Questions
Does this kit support PIN code access?Yes. The DS-KV6124-WBE1 door station includes keypad access for PIN code unlocking.
Can I unlock from my phone?Yes, remote unlock is supported through Hik-Connect when the system is configured correctly.
Does it include the PoE switch?Yes. This bundle includes the DS-3E1105P-EI PoE switch for wired power and data connection.
Is this better than a Wi-Fi doorbell?For permanent installs, yes. A wired PoE intercom is generally more stable and installer-friendly than Wi-Fi-only doorbells.
Can it control an electric strike?Yes, the door station supports 2-lock control. Final lock compatibility depends on your strike, gate controller and wiring design.
Is installation included?No. This is a hardware kit. CCTV Guru can help with product selection and recommend suitable setup guidance for your installer.
Order Your Hikvision Keypad Video Intercom Kit from CCTV Guru
Order the Hikvision Keypad Video Intercom Kit with PoE from CCTV Guru for a complete access control intercom solution with keypad entry, mobile app unlock, 10.1" indoor monitor and PoE switch. Ideal for homes, offices, rental properties and gated entries needing a more secure, flexible upgrade from a standard doorbell.
Clearance. Limited supplier stock, available while stocks last.
Dahua · VTM116-01 · Flush box for VTO6221E-P / VTO3221E-P
Flush box
Dahua DH-AC-VTM116-01 Flush Mount Box
The DH-AC-VTM116-01 is a flush-mount box for the Dahua VTO6221E-P and VTO3221E-P door stations. It recesses into the wall so the intercom sits flush against the surface for a clean, tamper-resistant finish. Cast from ADC12 aluminium alloy with a silver finish.
Specifications — VTM116-01
Type
Flush mount box
Compatible With
Dahua VTO6221E-P, VTO3221E-P
Material
ADC12 aluminium alloy
Finish / Colour
Silver
Dimensions (front)
138 x 240 x 35 mm
Warranty (Australia)
3 years · CCTV Guru Australia
VTM116-01 Datasheet
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision · 2MP · WiFi + Mifare
One-Box Villa Intercom with WiFi and Card Access
The Hikvision DS-KV6113-WPE1 is an all-in-one villa door station that combines a 2MP camera, a single one-touch call button and a built-in Mifare card reader in a single weatherproof unit. It is the practical front-door choice for homes and small premises that want video calling plus card-based entry without a separate access controller.
Built-in WiFi and standard PoE give you flexible installation options, and Hik-Connect support means residents can answer the door and unlock from their phone anywhere. The plastic housing keeps the unit light and easy to mount, while the IP65 rating handles Australian weather at the entry.
Camera
2MP + IR
Wireless
Built-in WiFi
Access
Mifare Reader
Power
Standard PoE
Rating
IP65 Weatherproof
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
What's Included
DS-KV6113-WPE1 Door StationAll-in-one villa door station with camera, call button and card reader.
Mounting HardwareStandard fixings for surface installation at the front entry.
Quick Start GuideSetup and wiring documentation for fast commissioning.
Why Choose DS-KV6113-WPE1
WiFi FlexibilityBuilt-in WiFi means installation isn't tied to a network cable run.
Card Access Built InIntegrated Mifare reader lets residents unlock with a card — no extra controller.
Answer From AnywhereHik-Connect lets you see and speak to visitors and unlock from your phone.
Simple PowerStandard PoE delivers data and power over one cable when wired.
Recommended For
Villas & HomesOne-touch calling and card entry for a single front door.
Card-Access SitesPremises that want Mifare card entry without a separate reader.
App-First HouseholdsResidents who want to answer the door from a smartphone.
Technical Specifications
Model
DS-KV6113-WPE1
Type
Villa door station
Camera
2MP with IR supplement
Call Button
One-touch call button
Card Reader
Built-in Mifare
Wireless
Built-in WiFi
Power
Standard PoE
App
Hik-Connect mobile control
Housing
Plastic
Protection
IP65
Downloads & Resources
DS-KV6113-WPE1 DatasheetPDF
Hikvision Video Intercom Quick Start GuidePDF
Does it have WiFi?Yes — the DS-KV6113-WPE1 has built-in WiFi as well as standard PoE for wired installs.
Can visitors be answered on a phone?Yes — with Hik-Connect you can see, talk to and unlock for visitors from your smartphone.
What cards does it read?It has a built-in Mifare card reader for card-based entry.
How is it powered?Standard PoE delivers power and data over a single network cable.
Is the housing metal?No — this model uses a durable plastic housing.
Is it weatherproof?Yes — it is rated IP65 for outdoor entry use.
How many call buttons?One one-touch call button for a single household or entry.
Does it include a warranty?Yes — genuine Australian stock backed by our 3-Year AU Warranty.
Order the DS-KV6113-WPE1 today from CCTV Guru — genuine Australian stock, backed by our 3-Year AU Warranty, fast AU-wide shipping and local tech support.
Hikvision Intercom · 7" IP · Wi-Fi + PoE
The Hikvision DS-KH6320-WTE1 is a sleek 7-inch IP indoor station for video intercom systems in modern homes, apartments, and multi-tenant buildings. With a 1024 × 600 capacitive touch screen and both Wi-Fi and PoE connectivity, it lets you answer calls, unlock doors, and view live feeds from door stations and linked cameras from one intuitive interface.
It integrates with the Hik-Connect app for remote answer and unlock, and adds smart features like voice-message playback, alarm linkage, and elevator control. An embedded Linux platform with a TF card slot makes it a reliable, quick-to-install indoor monitor for a Hikvision IP intercom setup.
Display
7" Touch
Resolution
1024 × 600
Connectivity
Wi-Fi + PoE
App
Hik-Connect
Storage
TF up to 32 GB
✔ Remote answer & unlock ✔ Live view of cameras ✔ Alarm & elevator control
What's Included
📺 7" Indoor MonitorDS-KH6320-WTE1 IP indoor station with capacitive touch screen.
🔩 Mounting HardwareSurface mount bracket and fixings for quick wall installation.
📄 Quick Start GuideHikvision setup documentation for fast commissioning.
Why Choose This Monitor
📱 Remote AccessAnswer calls and unlock doors from anywhere with the Hik-Connect app.
📹 Camera Live ViewView door stations and up to 16 linked network cameras on screen.
🔔 Alarm & ElevatorSupports alarm linkage and elevator control for larger buildings.
⚡ Flexible PowerWi-Fi and standard PoE for clean, simple installation.
Recommended For
🏠 Homes & ApartmentsEveryday video entry with a clear, responsive touch screen.
🏢 Small CommercialReception and office entry management with camera integration.
🏬 Multi-Tenant BuildingsScales with door stations, extensions, and elevator control.
Technical Specifications
Model
DS-KH6320-WTE1
Type
IP indoor station (network)
Display
7" capacitive TFT touch screen
Resolution
1024 × 600
Connectivity
Wi-Fi 802.11 b/g/n + 10/100 Mbps Ethernet
App Support
Hik-Connect
Audio
Built-in mic & speaker, echo & noise suppression
Storage
TF card up to 32 GB
Linked Devices
16 indoor extensions, 17 door stations, 16 cameras
System
Embedded Linux, 32 MB ROM, 128 MB RAM
Protocols
TCP/IP, SIP, RTSP
Power
PoE or 12 VDC, ≤ 6 W
Dimensions
200 × 140 × 15.1 mm, 355 g
Operating Temp
-10 °C to +55 °C
Downloads & Resources
Download official Hikvision documents for setup, specifications, and product details.
DS-KH6320-WTE1 DatasheetPDF
Indoor Station User ManualPDF
Configuration GuidePDF
Frequently Asked Questions
What is the DS-KH6320-WTE1 used for?It is a 7-inch IP indoor station used to answer intercom calls, unlock doors, and view linked cameras in a Hikvision video intercom system.
Does it support a mobile app?Yes. It works with Hik-Connect for remote call answer, live view, and door unlock from your phone.
Does it support Wi-Fi and PoE?Yes. It connects via Wi-Fi 802.11 b/g/n or wired Ethernet with standard PoE.
Can it view cameras?Yes. It can live view door stations and up to 16 linked network cameras.
Does it have storage?Yes. It accepts a TF card up to 32 GB for messages and snapshots.
Is it suitable for apartments?Yes. It supports door stations, indoor extensions, alarm linkage, and elevator control for multi-tenant buildings.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Professional Video Intercom · Hikvision Pro Series · Keypad + Card + App · PoE + WiFi 6
Hikvision DS-KV6124-WBE1 — 4MP Keypad Video Intercom Door Station
The Hikvision DS-KV6124-WBE1 is the complete access control door station for Australian homes, offices, Airbnb properties, and commercial sites that need more than a basic video doorbell. It combines a 4MP wide-angle camera, keypad PIN entry, RFID card reader, Bluetooth, and Hik-Connect app unlock into one sleek, weatherproof unit — powered by PoE or 12V DC, with WiFi 6 for flexible installation.
Unlike standard intercom door stations, the DS-KV6124-WBE1 supports dual lock output — control two separate doors, gates, or access points from a single device. Assign individual PIN codes per user, issue RFID cards, or let guests unlock remotely via the Hik-Connect app. No keys, no locksmith, no hassle.
Camera
4MP · 150° Wide Angle
Access
PIN / Card / App / BT
Power
PoE + WiFi 6
Lock Control
Dual Output
Night Vision
IR Supplement
Protocol
TCP/IP · ONVIF · RTSP
2-Year Australian Warranty
Australian Stock · Fast Dispatch
Expert Australian Tech Support
Key Features
4MP Wide-Angle Camera
150° horizontal field of view captures the full entry area — faces, hands, and surroundings — in sharp 4MP detail. Built-in IR supplement ensures clear footage at night without external lighting.
Keypad PIN Access
Assign individual PIN codes to residents, staff, or guests. Ideal for Airbnb, rental properties, and offices where physical key management is impractical. Change or revoke codes instantly via the Hik-Connect app.
RFID Card Reader (13.56 MHz M1)
Issue M1 RFID cards or fobs to authorised users. Fast tap-to-unlock — no PIN required for regular users. Cards can be added or removed remotely without replacing hardware.
Bluetooth + Hik-Connect App Unlock
Unlock the door from your smartphone via Bluetooth proximity or remotely via the Hik-Connect app over the internet. Answer video calls, view live footage, and grant access from anywhere in the world.
Dual Lock Output
Control two independent locks, gates, or access points from a single door station. Perfect for properties with a front gate and front door, or a reception door and server room.
PoE + WiFi 6 Connectivity
Power and network via a single Cat6 cable (PoE IEEE 802.3at), or connect wirelessly via WiFi 6 (2.4GHz). Flexible installation for new builds and retrofits alike.
DS-KV6124-WBE1 vs DS-KV6114-WBE1 — Which Should You Choose?
Both models share the same 4MP camera and PoE + WiFi 6 platform. The key difference is the keypad — here's how to decide:
Choose DS-KV6114-WBE1 if…
You need a clean, minimal video intercom for a single-family home where all users have the Hik-Connect app or RFID cards. No PIN entry required. Simpler setup, lower cost.
Choose DS-KV6124-WBE1 if…
You need keypad PIN access for multiple users — Airbnb guests, office staff, delivery drivers, or tradespeople. The keypad makes it a true access control system, not just a video doorbell.
Offices & Commercial Sites
The DS-KV6124 is the right choice for any site where staff need PIN-based entry without issuing physical keys or RFID cards to every person.
Rental & Airbnb Properties
Assign a unique PIN per booking period. Guests check in without a key handover. Change the code between guests in seconds via the app. No locksmith, no key safe, no hassle.
Recommended For
Airbnb & Short-Stay Rentals
Issue a unique PIN per booking. Guests self-check-in without a key handover. Change codes between stays in seconds via the Hik-Connect app.
Offices & Staff Entry
Assign PIN codes and RFID cards to staff. Revoke access instantly when someone leaves. No rekeying, no lost key headaches.
Medical & Dental Clinics
Control reception and treatment-area access. Dual lock output manages the front door and a secure internal door from one unit.
Residential Homes
Replace a traditional doorbell with a full video intercom and keypad. Family members each get their own PIN — no more hiding a key under the mat.
Warehouses & Industrial Sites
Manage after-hours contractor access with time-limited PINs. Dual lock output controls the roller door and the office entry independently.
Schools & Childcare Centres
Secure entry with PIN + video verification. Staff unlock remotely via app; authorised visitors use a PIN. NDAA-compliant Hikvision hardware for government procurement.
Technical Specifications
Camera & Video
4MP resolution · 150° wide-angle lens · IR night vision supplement · H.264 video compression · RTSP stream support
Access Methods
PIN code (keypad) · RFID card (M1, 13.56 MHz) · Bluetooth · Hik-Connect app (remote) · Indoor monitor unlock
Lock & Relay Output
2 × lock relay outputs (dual lock control) · Supports electric strike, magnetic lock, and electric bolt
Power & Network
PoE (IEEE 802.3at) · 12V DC input · WiFi 6 (2.4GHz) · TCP/IP · ONVIF · RTSP
Build & Environment
IP65 weatherproof · IK07 vandal-resistant · Flush or surface mount · Operating temp: -40°C to +60°C
Compatibility
Hik-Connect platform · Compatible with Hikvision indoor monitors (DS-KH series) · ONVIF for third-party integration
More Information
Datasheet
P2P Setup Guide
Quick Start Guide
Frequently Asked Questions
What is the difference between DS-KV6124 and DS-KV6114?The DS-KV6124 includes a keypad for PIN code access, making it a full access control system. The DS-KV6114 has no keypad and suits simpler app or card-based entry.
Can I unlock the door using my phone?Yes — the Hik-Connect app lets you answer video calls and unlock doors remotely from anywhere with an internet connection.
What unlock methods are supported?PIN code, RFID card (M1 13.56 MHz), Bluetooth, Hik-Connect app, and indoor monitor unlock.
Do I need a PoE switch?A PoE switch is recommended for stable power and network. You can also use the 12V DC input or WiFi 6 for wireless-only installations.
Can this control a gate and a door at the same time?Yes — the dual lock relay output lets you independently control two access points (e.g. front gate + front door) from one unit.
Is this suitable for Airbnb or rental properties?Yes — assign a unique PIN per guest booking and change it between stays via the app. No key handover, no locksmith.
Can I add indoor monitors?Yes — pair with Hikvision DS-KH series indoor monitors for a full intercom system across multiple rooms or floors.
Is it weatherproof?Yes — IP65 rated and IK07 vandal-resistant, suitable for outdoor installation in all Australian weather conditions.
Does it work over WiFi only?Yes — WiFi 6 (2.4GHz) is supported for wireless-only installs, though wired PoE is recommended for maximum reliability.
What's the warranty?2-year Australian warranty, supported locally by CCTV Guru's Australian technical team.
Do you ship Australia-wide?Yes — fast dispatch to every state and territory from Australian stock.
Order the Hikvision DS-KV6124-WBE1 from CCTV Guru
CCTV Guru is an authorised Australian distributor of Hikvision access control and intercom products. Order the Hikvision DS-KV6124-WBE1 4MP Keypad Video Intercom Door Station today for fast Australia-wide dispatch, expert pre-sales advice on lock wiring and indoor monitor pairing, and full local warranty support. Contact our Australian team to build a complete intercom system with indoor monitors, PoE switches, and electric locks.
Looking for a simpler option without a keypad? View the DS-KV6114-WBE1 →
Hikvision 9 Series · 10.1" Android · Wi-Fi + PoE
The Hikvision DS-KH9510-WTE1 is a 10.1-inch Android all-in-one indoor station that doubles as a control centre for your whole Hikvision system. Built on a 1024 × 600 colour touch screen with a built-in Android OS, it lets you answer the intercom and manage devices from one tablet-style interface.
Beyond video intercom, this station provides all-in-one management of Hikvision devices — including AX Pro alarm and CCTV cameras — with the built-in Hik-Connect app. It also supports Android app installation and third-party software integration, with both Wi-Fi and PoE for flexible installation. White finish.
Display
10.1" Touch
Platform
Android
Controls
AX Pro + CCTV
Connectivity
Wi-Fi + PoE
App
Hik-Connect
✔ Android all-in-one control ✔ Manage AX Pro & CCTV ✔ Install Android apps
What's Included
📺 10.1" Android StationDS-KH9510-WTE1 all-in-one indoor station with Android OS.
🔩 Mounting HardwareWall bracket and fixings for installation.
📄 Quick Start GuideHikvision setup documentation for commissioning.
Why Choose This Station
🎛️ All-in-One ControlManage intercom, AX Pro alarm, and CCTV from one screen.
🤖 Android PlatformInstall Android apps and integrate third-party software.
📱 Built-in Hik-ConnectStay connected and in control of your Hikvision devices.
⚡ Flexible PowerWi-Fi and PoE for clean, simple installation.
Recommended For
🏠 Smart HomesA single tablet-style hub for intercom, alarm, and cameras.
🏢 Integrated ProjectsSites combining Hikvision intercom, AX Pro, and CCTV.
📲 Modern SystemsInstalls that want Android performance and app flexibility.
Technical Specifications
Model
DS-KH9510-WTE1
Type
Android all-in-one indoor station
Display
10.1" colour touch screen
Resolution
1024 × 600
Operating System
Android (supports app installation)
Device Control
Intercom, AX Pro alarm, CCTV cameras
App Support
Built-in Hik-Connect, third-party software
Connectivity
Wi-Fi + PoE
Finish
White
Downloads & Resources
Download official Hikvision documents for setup, specifications, and product details.
DS-KH9510-WTE1 DatasheetPDF
Indoor Station Quick Start GuidePDF
Indoor Station User ManualPDF
Frequently Asked Questions
What is the DS-KH9510-WTE1?It is a 10.1-inch Android all-in-one indoor station that handles video intercom and acts as a control centre for Hikvision devices.
What can it control?It provides all-in-one management of Hikvision devices including AX Pro alarm systems and CCTV cameras.
Does it run Android apps?Yes. It has a built-in Android system and supports Android app installation and third-party software.
Does it include Hik-Connect?Yes. Hik-Connect is built in for connected control of your system.
Does it support Wi-Fi and PoE?Yes. It supports both Wi-Fi and PoE for flexible installation.
Who is it best for?It suits smart homes and integrated projects that want one hub for intercom, alarm, and cameras.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision Gen2 Intercom Accessory
DS-KABD8003-RS2 — Gen2 Rain Shield for 2-Module Surface Mount
The Hikvision DS-KABD8003-RS2 is a protective rain shield (rain hood) for two-module surface-mounted Gen2 modular door stations. It deflects rain and direct sun away from the panel for reliable outdoor operation.
It suits 2-module surface installations of the DS-KD8003-IME1 and DS-KD8003-IME2 door stations.
Weather protectionShields the door station from rain and direct sunlight.
2-module fitSized for two-module surface-mount door stations.
SECC constructionDurable SECC galvanised steel for outdoor durability.
CompatibleSuits DS-KD8003-IME1 and DS-KD8003-IME2 surface installs.
Specifications
Model
DS-KABD8003-RS2
Type
Rain shield, 2 module (surface)
Material
SECC
Compatibility
DS-KD8003-IME1 / DS-KD8003-IME2
Downloads & Resources
DS-KABD8003-RS2 Datasheet (PDF)
What does it fit?2-module surface-mounted Gen2 door stations (KD8003-IME1/IME2).
What is it made from?SECC galvanised steel for outdoor durability.
Is it for surface mounting?Yes, it suits surface-mount installations.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Fit the DS-KABD8003-RS2 to keep your two-module door station protected from the elements, backed by local Australian support.
Hikvision Intercom Kit · 2MP Door Station · PoE Powered
Hikvision DS-KIS602 IP Video Intercom Kit with 2MP Door Station, 7" Indoor Monitor & PoE Switch
The Hikvision DS-KIS602 is a complete Gen 2 IP video intercom kit for Australian villas, houses, offices and small commercial sites. It pairs the DS-KD8003-IME1 modular door station, DS-KH6320-WTE1 7" indoor monitor and a 4-port PoE switch into one wired, ready-to-install bundle with a single call button for simple, reliable door entry.
The PoE design powers and connects each device over one network cable, giving a cleaner and more dependable installation than Wi-Fi-only doorbells. Answer visitors from the 7" touchscreen or the Hik-Connect app, view the entrance live, and release a compatible electric strike or gate using the door station's two lock relays.
Door Station
2MP Fisheye
Monitor
7" Touchscreen
Power
PoE Switch Included
Remote Access
Hik-Connect App
Locks
2 Lock Relays
Protection
IP65 Door Station
3-Year AU Warranty
PoE Switch Included
AU Tech Support
What's Included
1 × Hikvision DS-KD8003-IME1 Door StationModular main unit with a 2MP HD fisheye colour camera, IR supplement light, one physical call button, two lock relay outputs and 4-channel alarm input. IP65 rated, powered by 12 VDC or standard PoE. Requires a surface or flush mount bracket.
1 × Hikvision DS-KH6320-WTE1 Indoor Monitor7" TFT touchscreen (1024 × 600) with Wi-Fi and PoE, Hik-Connect app control, one-touch setup wizard, live view of the door station and public-area cameras, plus voice-message and alarm linkage support.
1 × 4-Port PoE SwitchPowers and connects the door station and indoor monitor over network cabling for a clean, single-cable-per-device installation.
16GB microSD Card + AU Power AdaptorIncludes a 16GB TF card for local snapshots and an Australian power adaptor, so the kit is ready to commission out of the box.
Why Choose the DS-KIS602?
Wired PoE ReliabilityOne network cable carries power and data to each device, avoiding the dropouts common with Wi-Fi-only video doorbells.
See & Speak ClearlyThe 2MP fisheye camera with IR supplement gives a wide, clear view of callers day or night.
Answer From AnywhereTake calls, view the entrance and unlock remotely through the Hik-Connect app when configured.
Two-Lock ControlTwo relay outputs let the door station release a compatible electric strike, mag lock or gate.
Simple One-Button CallingA single call button keeps operation easy for families, visitors and staff.
Matched, Ready-to-Install KitPre-paired Hikvision parts remove compatibility guesswork for your installer.
Recommended For
Villas & Family HomesFront door or gate entry with an indoor monitor and mobile app control.
Small OfficesLet reception or staff see and speak with visitors before opening the door.
Clinics & StudiosManage appointment and after-hours entry from a single touchscreen.
Gated EntriesPair with a compatible strike or gate controller for controlled access.
Technical Specifications
Door Station — Hikvision DS-KD8003-IME1
Camera
2MP HD fisheye colour camera with IR supplement
Call Button
1 physical call button
Lock Control
2 lock relay outputs
Alarm
4-channel alarm input
Protection
IP65 rated
Power
12 VDC or standard PoE
Mounting
Modular — requires surface/flush bracket
Indoor Monitor — Hikvision DS-KH6320-WTE1
Display
7" TFT capacitive touchscreen
Resolution
1024 × 600
Network
Wi-Fi and PoE
App
Hik-Connect remote call, view & unlock
Features
Live view, voice message, alarm linkage, setup wizard
Included Accessories
Network Switch
4-port standard PoE switch
Storage
16GB microSD (TF) card
Power
Australian power adaptor included
System
Gen 2 IP, 1-to-1 surface mount
Downloads & Resources
DS-KIS602 Datasheet
Hikvision Video Intercom Quick Start Guide
Hikvision Video Intercom User Manual
Frequently Asked Questions
Does the DS-KIS602 include a PoE switch?Yes. The kit includes a 4-port PoE switch to power and connect the door station and indoor monitor over network cabling.
Can I answer the door from my phone?Yes. With Hik-Connect you can view callers, talk and unlock remotely when the system is configured correctly.
Can it unlock an electric strike or gate?Yes. The door station has two lock relay outputs. Final compatibility depends on your strike, mag lock or gate controller and wiring.
Does the door station need a separate bracket?The DS-KD8003-IME1 is modular and uses a surface or flush mount bracket. This kit is configured for surface mounting.
Is it weatherproof?The door station is IP65 rated for outdoor entry use. A weather shield is still recommended in fully exposed positions.
Is installation included?No. This is a hardware kit. We recommend installation by a licensed security or data cabling technician.
Order Your Hikvision DS-KIS602 Intercom Kit from CCTV Guru
Order the Hikvision DS-KIS602 IP Video Intercom Kit from CCTV Guru for a complete wired PoE entry solution with a 2MP door station, 7" indoor monitor, PoE switch and app control. Ideal for Australian villas, homes, offices and gated entries wanting a reliable upgrade from a basic doorbell. Australian stock, backed by a 3-year warranty and local support.
Hikvision Intercom Kit · 4MP Door Station · PoE Powered
Hikvision Premium Video Intercom Kit with 4MP Door Station, 10.1" Monitor & PoE Switch
The Hikvision Premium Video Intercom Kit is a complete wired PoE intercom solution for Australian homes, offices, shops, clinics, studios, rental properties and gated entries. It combines the DS-KV6114-WBE1 4MP video door station, DS-KH9570-WTE1/S 10.1" indoor monitor and DS-3E1105P-EI PoE switch into one clean, ready-to-install package.
Designed for reliable everyday entry control, this kit lets users see visitors clearly, speak through the indoor monitor or Hik-Connect app, and unlock compatible electric strikes or gates when configured by your installer. The PoE design keeps power and data on one network cable per device, giving you a more stable and professional setup than basic Wi-Fi-only video doorbells.
Door Station
4MP Wide Angle
Monitor
10.1" Touchscreen
Power
PoE Switch Included
Remote Access
Hik-Connect App
Unlock
App · Card · Monitor
Install
Wired PoE Setup
Complete Intercom Kit
PoE Switch Included
Australian Support
What’s Included
1 × Hikvision DS-KV6114-WBE14MP video door station with wide-angle viewing, Wi-Fi and PoE support, dual lock control and access options including card, Bluetooth, app and indoor monitor unlock.
1 × Hikvision DS-KH9570-WTE1/SPremium 10.1" indoor station with a modern touchscreen interface for answering calls, viewing the door station and controlling access from inside the property.
1 × Hikvision DS-3E1105P-EICompact PoE switch to power and connect the door station and indoor monitor using network cabling for a cleaner, more stable installation.
Ready-to-Install BundlePre-matched Hikvision components reduce compatibility guesswork and give your installer the core hardware needed for a professional wired intercom setup.
Why Choose This Hikvision Intercom Kit?
Cleaner Than a Basic DoorbellUpgrade from a simple doorbell to a proper video intercom with indoor screen, mobile app access and lock control capability.
Reliable Wired CommunicationPoE provides power and data over network cable, reducing reliance on weak Wi-Fi signals at the front door or gate.
Remote Visitor HandlingUse Hik-Connect to view, talk and unlock remotely when the system is configured correctly by your installer.
Modern Indoor MonitorThe 10.1" indoor station gives homes and businesses a premium control point for answering calls and monitoring the entrance.
Access Control ReadySuitable for compatible electric strikes, magnetic locks and gate controllers where lock wiring and power are correctly designed.
Expandable SetupAdd extra indoor monitors, access cards or lock hardware to suit larger homes, offices or multi-room layouts.
Recommended For
Residential HomesFront door, side gate or pedestrian gate control with indoor monitor and mobile app convenience.
Small OfficesLet reception, staff or managers see and speak with visitors before opening the door.
Clinics & StudiosControl entry for appointments, staff access and after-hours visitor management.
Rental & Airbnb PropertiesUseful where remote visitor handling and app-based access control are preferred over standard doorbells.
Gates & Entry PointsSuitable for controlled entry points when paired with the correct strike, relay or gate controller.
Small Commercial SitesA practical upgrade for warehouses, showrooms, workshops and business entrances.
Optional Add-Ons
Electric Strike LockAdd a compatible electric strike such as FSH FES10 or LOX ES10 for remote door release from the monitor or app.
Extra Indoor MonitorAdd another indoor station for larger homes, upstairs areas, reception counters or back offices.
RFID CardsAdd access cards or fobs for staff, family members or regular users where card access is required.
Cat6 CablingUse quality Cat6 cabling for reliable PoE power and data between the door station, indoor monitor and switch.
Technical Specifications
Door Station — Hikvision DS-KV6114-WBE1
Camera
4MP video door station
Viewing Angle
150° wide-angle view
Unlock Methods
App, card, Bluetooth and indoor monitor unlock
Lock Control
Dual lock control
Network
Wi-Fi and PoE support
Use Case
Villa, residential and small commercial video intercom
Indoor Station — Hikvision DS-KH9570-WTE1/S
Display
10.1" touchscreen indoor monitor
Function
Answer calls, view door station and unlock compatible doors or gates
App Support
Hik-Connect remote viewing and call handling when configured
Use Case
Main indoor control point for homes and small businesses
PoE Switch — Hikvision DS-3E1105P-EI
PoE Ports
4 × PoE ports
Uplink
1 × uplink port
PoE Budget
60W total PoE budget
Purpose
Powers and connects the intercom devices for wired communication
Downloads & Resources
DS-KV6114-WBE1 Datasheet
DS-KH9570-WTE1 Datasheet
DS-KV6114-WBE1 Quick Start Guide
DS-KH9570-WTE1 Quick Start Guide
User Manual
P2P Setup Guide
Frequently Asked Questions
What is included in this kit?This kit includes the Hikvision DS-KV6114-WBE1 4MP door station, DS-KH9570-WTE1/S 10.1" indoor monitor and DS-3E1105P-EI PoE switch.
Can I answer from my phone?Yes. Hik-Connect can be used to view visitors, talk and unlock remotely when the system is configured correctly.
Does it need Wi-Fi?No. The kit is designed around wired PoE communication. Wi-Fi can still be useful depending on how your installer configures remote access.
Can it unlock a door or gate?Yes. The door station supports lock control, but the final setup depends on your electric strike, magnetic lock, gate motor and power design.
Can I add another indoor monitor?Yes, additional compatible indoor stations can be added for multi-room or multi-floor setups.
Is this suitable for business use?Yes. It is suitable for homes, small offices, studios, clinics, warehouses and controlled entry points.
Is installation included?No. This is a hardware kit. We recommend installation by a licensed security or data cabling technician.
Why buy the kit instead of separate parts?The kit gives you matched Hikvision components in one package, reducing compatibility issues and making setup easier for your installer.
Order Your Hikvision Video Intercom Kit from CCTV Guru
Order the Hikvision Premium Video Intercom Kit with 4MP Door Station, 10.1" Indoor Monitor and PoE Switch from CCTV Guru for a complete wired intercom solution with video calling, app access and lock-control capability. Ideal for Australian homes, offices, shops and gated entries needing a more secure upgrade from a basic doorbell.
IP Intercom Kit · 2MP Door Station · 7" Touch · Wi-Fi & PoE · Hik-Connect
2MP IP Intercom Kit
HiLook HA-KIT-IP1 2MP IP Video Intercom Kit — Australian Stock & 2-Year Warranty
The HiLook HA-KIT-IP1 is a complete IP video intercom bundle that lets you see, hear and let in visitors from a 7-inch touch-screen indoor monitor or your smartphone. It pairs a weatherproof 2 MP IP door station with the HA-IN-IP71 indoor station. The indoor monitor supports 2.4 GHz Wi-Fi, standard PoE or 12 VDC; the door station uses standard PoE or 12 VDC. The Australian kit also includes two Australian-standard power adaptors, giving installers a practical choice between PoE and local power.
Beyond door entry, the indoor monitor doubles as a security hub — it can live-view up to 16 IP cameras, so you can check the whole property from one screen. Receive video calls and unlock the door from anywhere through the free Hik-Connect app, with two-way audio to talk to whoever is at the gate. The door station is IP65 rated with infrared night vision and a Mifare card reader for keyless entry. Backed by genuine Australian stock and a 2-year warranty.
Choose your kit: select Intercom Kit Only for the standard package, or choose Intercom Kit + RG-ES106F-P PoE Switch to add a compact 6-port Fast Ethernet switch with four PoE+ camera/device ports and a 54 W PoE budget.
Connectivity
Wi-Fi & PoE
Camera View
Up to 16 IP Cameras
Door Entry and Security in One Kit
7-Inch Touch Indoor Station
The HA-IN-IP71 features a 7-inch capacitive touch screen (1024 × 600) with a friendly, plug-and-play interface for answering calls and releasing the door with a tap.
2 MP IP Door Station
A 2 MP HD camera with a wide field of view, infrared night vision and IP65 weatherproofing gives a clear colour view of every caller, plus a Mifare card reader for keyless entry.
Live-View 16 Cameras
The indoor monitor isn't just for the door — it can display live video from up to 16 HiLook or Hikvision IP cameras, turning it into a compact home security viewer.
Unlock From Anywhere
With Wi-Fi and the free Hik-Connect app, receive video calls, hold a two-way conversation and unlock the door from your phone, whether you're home or away.
What's in the Box
Kit Contents
HA-IN-IP71 — 7-inch Touch IP Indoor Station
1 ×
HA-DS-IP1 — 2 MP IP Door Station (PoE / 12 VDC)
1 ×
Wall-mount bracket
1 ×
Australian-standard power adaptors
2 ×
Mounting hardware & fittings
1 set
RG-ES106F-P — 6-port unmanaged PoE+ switch (4 PoE+, 54 W)
1 × with PoE-switch variant only
Technical Specifications
Door Station — HA-DS-IP1
Camera
2 MP HD camera
Resolution
Main 1920 × 1080p / 720p; Sub 704 × 576
Night Vision
Low-illumination IR supplement, 3 m
Field of View
Horizontal 131° / Vertical 78°
WDR / DNR
True WDR, digital noise reduction
Video Compression
H.264
Audio
Two-way audio (built-in mic + speaker)
Access Control
Mifare card reader, 13.56 MHz; 1 relay lock control
Operation
Single physical call button
Protection Level
IP65
Power
IEEE 802.3af PoE or 12 VDC; < 10 W
Dimensions
138 × 65 × 27 mm
Indoor Station — HA-IN-IP71
Display
7-inch colour TFT LCD
Resolution
1024 × 600
Operation
Capacitive touch
Camera Live-View
Up to 16 IP cameras
Wired Network
RJ-45, 10/100 Mbps self-adaptive
Wi-Fi
802.11 b/g/n (2.4 GHz)
App / Mobile
Hik-Connect — remote call, talk & unlock
Storage
microSD (TF) up to 128 GB
Power
PoE / 12 VDC; ≤ 6 W
Installation
Surface mounting
Dimensions
200 × 140 × 15.1 mm
Warranty
2-Year Australian Warranty
Downloads & Documentation
HA-KIT-IP1 Datasheet
Official HiLook intercom guide
Frequently Asked Questions
How is the kit wired?It's an IP system that supports both PoE and Wi-Fi. A single network cable can carry power and data, or you can connect the indoor monitor over Wi-Fi for a tidier install.
Can I unlock the door from my phone?Yes. Through the free Hik-Connect app you can receive video calls, talk to visitors with two-way audio and release the door from anywhere.
Does it need an internet connection?The door-to-monitor intercom works on your local network without internet. Internet is only required for remote answering and unlocking on your phone.
Can it view my other cameras?Yes. The indoor monitor can live-view up to 16 HiLook or Hikvision IP cameras, so it doubles as a home security screen.
Is the door station weatherproof?Yes. The HA-DS-IP1 door station is IP65 rated for outdoor use and includes infrared night vision for clear views after dark.
Does it support local storage?The indoor monitor accepts a microSD (TF) card up to 128 GB for supported event and visitor storage. The official kit datasheet does not list a card slot for the outdoor door station.
What app does it use?It uses Hik-Connect, Hikvision's free app for iOS and Android, for live video, two-way talk and remote door release.
Does the door station support card access?Yes. It includes a 13.56 MHz Mifare card reader and a relay output for keyless door release.
2-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua Wi-Fi 7″ IP Indoor Monitor · Black or White
Wi-Fi 7″ Monitor
Add or expand a Dahua video intercom with the VTH2621G-WP Wi-Fi indoor monitor — a 7-inch capacitive touchscreen that answers your door station, views compatible Dahua IP cameras and connects over Wi-Fi or PoE. Choose black (VTH2621G-WP) or white (VTH2621GW-WP) to match your interior. Genuine Dahua, 3-year Australian warranty and local support.
Display
7″ Touch · 1024×600
Connectivity
Wi-Fi + Standard PoE
Colour Options
Black or White
Compatibility
ONVIF & Dahua VTO
Why Choose the Dahua VTH2621G-WP
Wi-Fi or PoE Flexibility
Connect over 2.4GHz Wi-Fi where cabling is hard, or run standard PoE for a single-cable wired install.
Black or White
Pick the black VTH2621G-WP for modern or commercial interiors, or white VTH2621GW-WP to blend into bright walls.
Answer & Monitor
Take two-way audio calls from your Dahua door station and view compatible Dahua IP cameras on the same screen.
Expandable Intercom
Supports up to 9 extensions in villa mode (1 main + 2 extensions over Wi-Fi), so you can cover more rooms.
Alarm Ready
Six alarm inputs and one output let the monitor double as a simple alarm panel, with any input usable as a doorbell.
Open Standards
ONVIF and SDK support with RTSP, RTP and SIP makes integration with Dahua and third-party systems straightforward.
Choose Your Colour
Black — VTH2621G-WP
Best for modern interiors, dark switch plates and commercial reception areas where premium black hardware suits the space.
White — VTH2621GW-WP
Best for bright homes, apartments and clinics where a white monitor blends cleanly into the wall.
Technical Specifications
Dahua VTH2621G-WP / VTH2621GW-WP
Screen
7-inch TFT capacitive touchscreen
Resolution
1024 × 600
Processor
Dual-core 1.2 GHz, embedded Linux
Memory
128 MB ROM / 128 MB RAM
Audio
2-way audio with echo suppression
Wi-Fi
IEEE 802.11 b/g/n, 2.4 GHz, WPA/WPA2
Network
1 × 10/100 Mbps Ethernet, standard PoE
Interoperability
ONVIF, SDK · RTSP / RTP / SIP / DNS / SSH
Video Decoding
H.265 & H.264
Alarm I/O
6 inputs / 1 output (any input usable as doorbell)
Extensions
Villa 9 · Apartment 4 · Wi-Fi 1 main + 2 ext
Storage
microSD up to 64GB (reserved for software)
Casing
PC + ABS, surface mount
Colour
Black (VTH2621G-WP) or White (VTH2621GW-WP)
Datasheets & Guides
VTH2621G(W)-WP Datasheet
Quick Start Guidel
Dahua Indoor Monitor User Manual
Frequently Asked Questions
What colours are available?Black (VTH2621G-WP) and white (VTH2621GW-WP) — choose your colour above; both share identical specifications.
Does it use Wi-Fi or PoE?Both. Connect over 2.4GHz Wi-Fi or run standard PoE over a single network cable.
Which door stations does it work with?It pairs with Dahua VTO IP/2-wire villa door stations and supports ONVIF for broader compatibility.
Can it view security cameras?Yes. It monitors compatible Dahua IP cameras alongside the door station.
Can I add more monitors?Yes. It supports up to 9 extensions in villa mode, or 1 main plus 2 extensions over Wi-Fi.
Is there a warranty?Yes — a 3-year Australian warranty with local CCTV Guru support.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Complete Dahua IP Intercom Kit · Black or White Monitor
IP Intercom Kit
A complete IP video intercom for Australian homes and small business — a 7-inch Dahua touchscreen monitor (your choice of black or white), the VTO2311R-WP Wi-Fi villa door station, and an IP-COM F1106P-4-63W 4-port PoE switch to power and connect it all over one network cable. See and talk to visitors, unlock the door from the screen or the DMSS app, and add IC-card access — all genuine Dahua, backed by Australian stock and local support.
In The Kit
Monitor + Door Station + PoE Switch
App Control
DMSS Remote View & Unlock
Colour Options
Black or White Monitor
Built For Outdoors
IP65 Weatherproof Door Station
Why Choose This Dahua IP Intercom Kit
One Complete Kit
Monitor, door station and PoE switch are matched and bundled — no compatibility guesswork, just connect and configure.
Black or White Monitor
Pick the VTH2621G-P black monitor for modern or commercial interiors, or the VTH2621GW-P white for bright homes and clinics.
True PoE Install
The IP-COM F1106P-4-63W carries power and data over a single cable to the monitor and door station — cleaner wiring, fewer plugs.
Visitor Video & Two-Way Audio
The 2MP VTO2311R-WP door station with IR and auto WDR lets you see and speak to callers day or night.
DMSS App + IC Card Access
Answer and unlock from your phone anywhere, and tap an IC card at the door for quick family or staff entry.
Grows With You
The monitor also views compatible Dahua IP cameras, so the kit becomes the hub of a larger security system later.
What's In The Box
1 × Dahua 7″ IP Indoor Monitor
VTH2621G-P (black) or VTH2621GW-P (white). 7-inch TFT capacitive touchscreen, 1024×600, standard PoE, 6 alarm inputs / 1 output, door-station and IP camera monitoring.
1 × Dahua Wi-Fi Villa Door Station
VTO2311R-WP. Slim 2MP IP door station with two-way video, DMSS app unlock, IR night view, auto WDR, Wi-Fi, IC-card unlock and IP65 weather rating.
1 × IP-COM 4-Port PoE Switch
F1106P-4-63W. 6 ports total (4× PoE + 2× uplink), 802.3af/at, up to 30W per port, extend mode to 250m, plug-and-play, desk or wall mount.
Ready To Install
A clean, professional intercom backbone in one purchase. Door lock, exit button and cabling are selected separately to suit your door.
Choose Your Monitor Colour
Black — VTH2621G-P
Best for modern interiors, dark switch plates and commercial reception areas where premium black hardware suits the space.
White — VTH2621GW-P
Best for bright homes, apartments and clinics where a white monitor blends cleanly into the wall.
Technical Specifications
Indoor Monitor — VTH2621G-P / VTH2621GW-P
Screen
7-inch TFT capacitive touchscreen
Resolution
1024 × 600
Power
DC 12V or standard PoE
Alarm I/O
6 inputs / 1 output
Video Coding
H.265 / H.264
Functions
Door-station call & IP camera monitoring
Colour
Black (VTH2621G-P) or White (VTH2621GW-P)
Door Station — VTO2311R-WP
Camera
1/2.8″ 2MP HD CMOS
Video Call
Two-way video with indoor monitor
Mobile App
DMSS call & unlock
Wi-Fi
Supported
Night View
IR illumination + auto WDR
Unlock
IC card & remote unlock
Power
DC 12V or PoE
Weather Rating
IP65
Video Coding
H.264 / H.265
PoE Switch — IP-COM F1106P-4-63W
Ports
4 × 10/100 PoE + 2 × 10/100 uplink (6 total)
PoE Standard
IEEE 802.3af / 802.3at
Per-Port PoE
Up to 30W
Total PoE Power
Up to 63W
Backplane
1.2 Gbps
Extend Mode
Up to 250m transmission
Mounting
Desktop or wall-mount, plug & play
Datasheets & Guides
VTO2311R-WP Door Station Datasheet
Dahua Villa Door Station User Manual
VTH2621G-P Monitor Datasheet
Dahua Indoor Monitor User Manual
F1106P-4-63W Switch Datasheet
IP-COM PoE Switch Quick Start Guide
Frequently Asked Questions
What's included in this kit?A Dahua 7-inch indoor monitor (black or white), the VTO2311R-WP Wi-Fi door station, and an IP-COM F1106P-4-63W 4-port PoE switch.
Can I choose black or white?Yes. Select the black VTH2621G-P or the white VTH2621GW-P monitor — both use the same VTO2311R-WP door station.
Does it work with the DMSS app?Yes. Once configured, DMSS lets you take visitor calls and unlock the door from your phone.
Can I unlock the door remotely?Yes, with a compatible electric strike or magnetic lock. The door release hardware is selected separately.
Does the door station support Wi-Fi?Yes. The VTO2311R-WP runs on PoE or Wi-Fi.
How many devices does the PoE switch power?The F1106P-4-63W has 4 PoE ports — ample for the monitor, door station and an extra camera, up to 30W each.
Can the monitor view security cameras?Yes. The 7-inch monitor displays compatible Dahua IP cameras alongside the door station.
Is the door station weatherproof?Yes. The VTO2311R-WP is IP65 rated for outdoor use.
Is a door lock included?No. Electric strikes, magnetic locks and exit buttons are chosen separately to suit your door type.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Complete Dahua 2-Wire Video Intercom Kit · DHI-KTD01L(S)-S2
2-Wire Kit
A smart front-door upgrade that installs over simple 2-wire cabling — no network knowledge or new structured wiring needed. The kit pairs the VTO2202F-P-S2 door station (2MP colour, 160° fisheye view) with a 7-inch VTH5422HW touchscreen monitor, a 2-wire switch and a surface bracket. See and speak to visitors, unlock up to two doors, and answer from the DMSS app — all genuine Dahua, backed by Australian stock and local support.
In The Kit
Door Station + Monitor + 2-Wire Switch
Simple Wiring
2-Wire — No New Cabling
Wide View
160° Fisheye 2MP Colour
App Control
DMSS Talk & Unlock
Why Choose This Dahua 2-Wire Intercom Kit
Easy 2-Wire Install
Runs power, video and audio over simple 2-wire cabling — ideal for retrofits and homes without network cabling to the gate.
One Complete Kit
Door station, monitor, 2-wire switch and bracket are matched and bundled — connect, configure and go.
160° Fisheye Coverage
The 2MP colour camera captures a wide 160° view, so you see visitors head-to-toe and parcels left at the door.
Unlock Up To Two Doors
Built-in access control drives two locks — handy for a gate plus a front door, or door plus garage.
DMSS App Talk & Unlock
Answer visitors and release the door from your phone when you're away — great for deliveries and daily access.
Expandable Daisy-Chain
The VTH5422HW monitor supports daisy-chain topology, so you can add monitors as the home or office grows.
What's In The Box
1 × 2-Wire IP Door Station — VTO2202F-P-S2
Anodised aluminium panel, 2MP colour 160° fisheye low-illumination camera, two-way video, access control for two locks, 2-wire & RJ45, H.265, IK07 / IP65, surface or flush mount.
1 × 7″ IP Indoor Monitor — VTH5422HW
2.5D glass, 7-inch TFT capacitive touchscreen, 6 alarm inputs / 1 output, H.265, 2-wire digital comms, daisy-chain topology, PoE or power over 2-wire switch.
1 × 2-Wire Switch — VTNS1001B-2
Connects the door station and monitor over 2-wire, with an RJ45 port and DIN guide-rail mounting for a tidy install.
1 × Surface Mount Bracket — VTM115
Surface-mount bracket for the door station, for a clean and secure fit at the entry.
Technical Specifications
Door Station — VTO2202F-P-S2
Camera
2MP HD colour, low illumination
View Angle
160° fisheye
Panel
Anodised aluminium
Access Control
Supports two locks
App
DMSS talk & remote unlock
Wiring
2-wire & RJ45 compatible
Video Coding
H.265
Protection
IP65 & IK07
Mounting
Surface or flush
Indoor Monitor — VTH5422HW
Screen
7-inch TFT capacitive touchscreen, 2.5D glass
Alarm I/O
6 inputs / 1 output
Power
Standard PoE or power over 2-wire switch
Video Coding
H.265 (H.264 by default)
Communication
2-wire digital
Topology
Supports daisy chain
2-Wire Switch — VTNS1001B-2
Connection
2-wire with RJ45 port
Mounting
DIN guide-rail
Role
Links door station & indoor monitor
Datasheets & Guides
DHI-KTD01L(S)-S2 Datasheet
Dahua Villa Door Station Quick Start Guide
Dahua Villa Door Station User Manual
Dahua 2-Wire Switch Installation Guide
Dahua 2-Wire Switch User Manual
Frequently Asked Questions
What's included in this kit?The VTO2202F-P-S2 door station, a 7-inch VTH5422HW indoor monitor, a 2-wire switch (VTNS1001B-2) and a VTM115 surface-mount bracket.
What is a 2-wire intercom?It sends power, video and audio over a simple 2-core cable, so you can install or retrofit without running network cabling to the door.
Can I answer the door from my phone?Yes. The Dahua DMSS app lets you talk to visitors and unlock the door remotely.
Can it unlock more than one door?Yes. The door station's access control supports two locks — for example a gate and a front door.
How wide is the camera view?The 2MP colour fisheye camera captures a wide 160° view to see visitors and parcels close to the door.
Can I add more indoor monitors?Yes. The VTH5422HW supports daisy-chain topology so you can expand to multiple rooms.
Is the door station weatherproof?Yes. The VTO2202F-P-S2 is IP65 weather-rated and IK07 impact-rated for outdoor use.
Is a door lock included?No. Electric strikes, magnetic locks and exit buttons are chosen separately to suit your door type.
2-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · DHI-VTH5422HW · 7" Wi-Fi IP Indoor Monitor · H.265 Two-WayWi-Fi Indoor MonitorDahua DHI-VTH5422HW 7" 2-Wire Wi-Fi IP Indoor Monitor
The Dahua DHI-VTH5422HW is a 7-inch capacitive touchscreen indoor monitor that runs digital 2-wire communication and adds built-in Wi-Fi for app connectivity. With a crisp 1024×600 display, H.265/H.264 decoding, two-way audio with echo suppression, and the ability to view door stations and IP cameras, it is a flexible centrepiece for villa and apartment intercom systems. Six alarm inputs, SOS, DND scheduling and micro SD video messaging round out a genuinely capable monitor.
Screen
7" Touch
Resolution
1024×600
Wiring
2-Wire
Wi-Fi
Yes
Audio
Two-Way
Codec
H.265
Wi-Fi plus 2-wire
Digital 2-wire communication for the door system combined with onboard 2.4 GHz Wi-Fi gives you flexible installation and app connectivity in one panel.
See doors and cameras
View your door stations and IP cameras directly on screen with efficient H.265/H.264 decoding for smooth, low-bandwidth live feeds.
Smart everyday living
SOS alarm, do-not-disturb scheduling, message info release and video messaging via micro SD make daily use comfortable and secure.
Layered alarm input
Six alarm inputs and one output let you wire sensors directly into the monitor, with a 12V/200mA power output for accessories.
Specifications — DHI-VTH5422HW
Screen
7" TFT capacitive touchscreen
Resolution
1024 × 600
Colour
White (also available in black)
Operating System
Embedded Linux
Communication
Digital 2-wire
Video Decoding
H.265 / H.264
Wi-Fi
Yes, 2.4 GHz, IEEE 802.11b/g/n
Audio
Two-way with echo suppression
Alarm I/O
6-channel input / 1-channel output
Power Output
1 (12V / 200mA)
Storage
Micro SD, up to 64 GB
Network
10/100 Mbps Ethernet or 2-wire port
Extensions
Villa: 3 / Apartment: 2
Power Supply
48 VDC, 1.25 A
Mounting
Surface mount
Dimensions
189 × 130 × 26.9 mm
Warranty
3 years · CCTV Guru Australia
Downloads
DHI-VTH5422HW DatasheetDahua Digital Indoor Monitor Quick Start GuideDahua Digital VTH User Manual
Is it 2-wire or IP?It uses digital 2-wire communication and also offers a 10/100 Ethernet port, so it suits 2-wire systems while still supporting IP networking and Wi-Fi.
Can I view IP cameras on it?Yes. The VTH5422HW can display Dahua door stations and IP cameras on screen with H.265/H.264 decoding.
Does it record?With a micro SD card (up to 64 GB) it supports video messaging and event capture.
What colours are available?This listing is the white model. A black variant of the VTH5422HW is also produced.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Complete Dahua Video Intercom Kit · Black or White Monitor
Video Intercom Kit
A modern front-door upgrade for homes, offices and small business — a 7-inch Dahua touchscreen monitor (your choice of black or white), the rugged VTO2101E-P-S2 villa door station, and an IP-COM F1106P-4-63W 4-port PoE switch to power and connect it all over one network cable. See and speak to visitors on the screen or answer from the DMSS app — all genuine Dahua, backed by Australian stock and local support.
In The Kit
Monitor + Door Station + PoE Switch
App Control
DMSS Remote Answering
Colour Options
Black or White Monitor
Built Tough
IP65 & IK10 Vandal-Proof Station
Why Choose This Dahua Video Intercom Kit
One Complete Kit
Monitor, door station and PoE switch are matched and bundled — no compatibility guesswork, just connect and configure.
Black or White Monitor
Pick the VTH2621G-P black monitor for modern or commercial interiors, or the VTH2621GW-P white for bright homes and clinics.
True PoE Install
The IP-COM F1106P-4-63W carries power and data over a single cable to the monitor and door station — cleaner wiring, fewer plugs.
Wide-Angle Night View
The 2MP station sees a 100° wide angle with ICR night vision up to 5m, so you catch visitors clearly day or night.
Vandal & Weather Resistant
A zinc-alloy panel rated IP65 and IK10 stands up to weather and knocks at exposed front doors and gates.
DMSS App Answering
Get visitor alerts and answer the door from your phone when you're away — ideal for deliveries and daily access.
What's In The Box
1 × Dahua 7″ IP Indoor Monitor
VTH2621G-P (black) or VTH2621GW-P (white). 7-inch TFT capacitive touchscreen, 1024×600, standard PoE, door-station and IP camera monitoring.
1 × Dahua Villa Door Station
VTO2101E-P-S2. 2MP HD CMOS, 100° wide angle, adjustable surface mount, ICR night vision to 5m, zinc-alloy IP65 / IK10, TCP/IP & SIP, voice prompt.
1 × IP-COM 4-Port PoE Switch
F1106P-4-63W. 6 ports total (4× PoE + 2× uplink), 802.3af/at, up to 30W per port, extend mode to 250m, plug-and-play, desk or wall mount.
Ready To Install
A clean, professional intercom backbone in one purchase. Door lock, exit button and cabling are selected separately to suit your door.
Choose Your Monitor Colour
Black — VTH2621G-P
Best for modern interiors, dark switch plates and commercial reception areas where premium black hardware suits the space.
White — VTH2621GW-P
Best for bright homes, apartments and clinics where a white monitor blends cleanly into the wall.
Technical Specifications
Indoor Monitor — VTH2621G-P / VTH2621GW-P
Screen
7-inch TFT capacitive touchscreen
Resolution
1024 × 600
Power
DC 12V or standard PoE
Alarm I/O
6 inputs / 1 output
Video Coding
H.265 / H.264
Functions
Door-station call & IP camera monitoring
Colour
Black (VTH2621G-P) or White (VTH2621GW-P)
Door Station — VTO2101E-P-S2
Camera
2MP HD CMOS
Viewing Angle
100° wide angle, adjustable mount
Night Vision
ICR, up to 5m
Audio
Two-way talk + voice prompt
Protocols
TCP/IP & SIP, DMSS app
Material
Zinc-alloy front panel
Protection
IP65 & IK10 vandal-resistant
Mounting
Surface mount
Power
DC 12V or PoE
PoE Switch — IP-COM F1106P-4-63W
Ports
4 × 10/100 PoE + 2 × 10/100 uplink (6 total)
PoE Standard
IEEE 802.3af / 802.3at
Per-Port PoE
Up to 30W
Total PoE Power
Up to 63W
Backplane
1.2 Gbps
Extend Mode
Up to 250m transmission
Mounting
Desktop or wall-mount, plug & play
Datasheets & Guides
VTO2101E-P-S2 Door Station Datasheet
Dahua Door Station Quick Start Guide
VTH2621G-P Monitor Datasheet
Dahua Indoor Monitor User Manual
F1106P-4-63W Switch Datasheet
IP-COM PoE Switch Quick Start Guide
Frequently Asked Questions
What's included in this kit?A Dahua 7-inch indoor monitor (black or white), the VTO2101E-P-S2 villa door station, and an IP-COM F1106P-4-63W 4-port PoE switch.
Can I choose black or white?Yes. Select the black VTH2621G-P or the white VTH2621GW-P monitor — both pair with the same VTO2101E-P-S2 door station.
Can I answer the door from my phone?Yes. With the Dahua DMSS app you receive visitor alerts and can talk to callers when you're away from the monitor.
Is the door station weatherproof?Yes. The VTO2101E-P-S2 is IP65 weather-rated and IK10 vandal-resistant with a zinc-alloy panel.
Does it see clearly at night?Yes. A 100° wide angle and ICR night vision up to 5m help you identify visitors in low light.
How many devices does the PoE switch power?The F1106P-4-63W has 4 PoE ports — ample for the monitor, door station and an extra camera, up to 30W each.
Can the monitor view security cameras?Yes. The 7-inch monitor displays compatible Dahua IP cameras alongside the door station.
Is a door lock included?No. Electric strikes, magnetic locks and exit buttons are chosen separately to suit your door type.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
IP Indoor Monitor · 7" Touch · Wi-Fi 802.11b/g/n · PoE / 12VDC · Hik-Connect
7" IP Indoor Monitor
HiLook HA-IN-IP2 7" IP Intercom Indoor Monitor — Australian Stock & 3-Year Warranty
The HiLook HA-IN-IP2 is a 7-inch IP video intercom indoor monitor that puts answering the door at your fingertips. Its bright capacitive touch screen (1024 × 600) shows live video from your door station so you can see, speak to and let in visitors with a single tap. It's the perfect indoor station to pair with a HiLook IP door station, or to add as an extension in another room.
Connectivity is flexible: power it over standard PoE on a single network cable, or use 12 VDC, and connect over wired Ethernet or built-in Wi-Fi (802.11 b/g/n). With the free Hik-Connect app you can receive video calls and unlock the door from your phone, anywhere. A microSD (TF) card slot supports up to 128 GB for recording visitor events. Backed by genuine Australian stock and a 3-year warranty.
Display
7" Touch 1024 × 600
Connectivity
Wi-Fi & PoE
Answer the Door From Any Room
7-Inch Capacitive Touch
A bright 7-inch colour TFT touch screen (1024 × 600) with a clean, plug-and-play interface makes viewing the door and releasing the lock effortless.
PoE or 12 VDC
Power over a single network cable with standard 802.3af PoE, or use a 12 VDC supply — whichever suits your install. Low ≤ 5 W draw.
Wi-Fi & Wired
Connect over wired 10/100 Mbps Ethernet or built-in 2.4 GHz Wi-Fi (802.11 b/g/n) for flexible placement anywhere in the home.
Unlock From Your Phone
The free Hik-Connect app lets you take video calls, talk to visitors with two-way audio and unlock the door remotely, wherever you are.
Technical Specifications
Display & Operation
Model / SKU
HA-IN-IP2
Display
7-inch colour TFT touch screen
Resolution
1024 × 600
Operation Method
Capacitive touch screen
Operating System
Embedded Linux
Memory / Flash
128 MB / 32 MB
Network, Audio & App
Wired Network
1 × RJ-45, 10/100 Mbps self-adaptive
Wi-Fi
2.4 GHz, IEEE 802.11 b/g/n
Protocols
TCP/IP, SIP, RTSP
Audio
Built-in mic + speaker; two-way audio, noise/echo cancellation
App / Mobile
Hik-Connect — remote video call, talk & door unlock
Interfaces
1 × RS-485; 8-ch alarm inputs; 2 relay outputs
Storage, Power & Build
Storage
TF (microSD) card, up to 128 GB
Power Supply
IEEE 802.3af PoE or 12 VDC
Power Consumption
≤ 5 W
Operating Temp.
−10 °C to 50 °C
Working Humidity
10% to 90%
Colour
White
Dimensions
175 × 113.5 × 21 mm
Warranty
3-Year Australian Warranty
Downloads & Documentation
HA-IN-IP2 Datasheet
HiLook Intercom User Manual
Frequently Asked Questions
What door stations does it work with?The HA-IN-IP2 is an IP indoor monitor designed to pair with HiLook IP video door stations, and can also serve as an extension monitor in another room.
Can I unlock the door from my phone?Yes. With the free Hik-Connect app you can receive video calls, talk to visitors with two-way audio and release the door from anywhere.
Does it need an internet connection?The monitor works on your local network without internet. Internet (Wi-Fi or wired) is only needed for remote answering and unlocking on your phone.
How is it powered?It runs on standard 802.3af PoE over a single network cable, or on a 12 VDC supply, drawing a low ≤ 5 W.
Does it have Wi-Fi?Yes. It supports 2.4 GHz Wi-Fi (802.11 b/g/n) as well as wired 10/100 Mbps Ethernet for flexible placement.
Does it record visitors?Yes. It accepts a microSD (TF) card up to 128 GB for storing footage and visitor events.
What app does it use?It uses Hik-Connect, Hikvision's free app for iOS and Android, for live video, two-way talk and remote door release.
What size is the screen?It has a 7-inch colour TFT capacitive touch screen at 1024 × 600 resolution in a slim white housing.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · A-Mifare ID1356 · Mifare Card · 13.56MHzMifare CardDahua A-Mifare ID1356 13.56MHz Mifare Access Card
The Dahua A-Mifare ID1356 is a contactless 13.56MHz IC (Mifare) card for access control and video intercom entry. Issue one to each staff member or resident for quick, secure card-unlock access with compatible Dahua readers and intercoms. It is also well suited to applications like access management, car parking, toll collection, public transport and loyalty programs.
Specifications — A-Mifare ID1356
Model
A-Mifare ID1356
Type
IC access card
Technology
Mifare (IC card)
Working Frequency
13.56 MHz
Typical Uses
Access management, intercom entry, parking, toll, transport, loyalty
Warranty (Australia)
12 months · CCTV Guru Australia
12-Month AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · DHI-VTNS1001B-2 · 2-Wire Switch · RJ45 + DIN-Rail2-Wire SwitchDahua DHI-VTNS1001B-2 2-Wire Switch
The Dahua DHI-VTNS1001B-2 is a compact 2-wire switch that links your network to a 2-wire intercom device. With an RJ45 port for LAN connection and a single 2-wire port carrying power and signal, it is a simple, dependable building block for Dahua 2-wire intercom systems. Its guide-rail (DIN-rail) mounting and slim PC+ABS housing make for a clean install in any comms cabinet.
2-Wire Port
1×
Network
RJ45
Indicators
2 LEDs
Mounting
Guide Rail
Power
DC 48V
System
2-Wire
Network to 2-wire link
Bridges your LAN to a 2-wire intercom device, carrying both power and signal over a single 2-wire run.
Status at a glance
Two indicator lights show connection and power status so you can confirm the switch is healthy during commissioning.
Tidy DIN-rail install
Guide-rail mounting clicks neatly into a comms cabinet for a professional, serviceable installation.
Compact and dependable
A slim PC+ABS unit certified to CE, FCC and UL standards — a reliable building block for 2-wire intercom systems.
Specifications — DHI-VTNS1001B-2
Type
2-wire switch
Communication
2-wire
2-Wire Port
1 × 2-wire port
Network Port
1 × RJ45
Status LEDs
2
Power Supply
DC 48V, 1A–3A
Power Consumption
≤ 15W (kit)
Mounting
Guide-rail (DIN-rail) mount
Casing
PC + ABS, white
Dimensions
131 × 103 × 40 mm
Certifications
CE; FCC; UL
Warranty
3 years · CCTV Guru Australia
Downloads
DHI-VTNS1001B-2 DatasheetDahua 2-Wire Switch Installation GuideDahua 2-Wire Switch User Manual
What does the VTNS1001B-2 do?It is a 2-wire switch that connects your network (via RJ45) to a 2-wire intercom device, carrying both power and signal over the 2-wire port.
How is it powered?It runs on DC 48V (1A–3A) with power consumption of 15W or less as part of a kit.
How is it mounted?It uses guide-rail (DIN-rail) mounting for a clean install in a comms cabinet.
Is it certified?Yes. It carries CE, FCC and UL certifications.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision Intercom · 4MP · WiFi + PoE
The Hikvision DS-KV6114-WBE1 is a smart 4MP IP video intercom designed for modern homes and small businesses that want secure, flexible access control with mobile connectivity. With a wide 150° viewing angle and multiple unlocking methods, it delivers both convenience and security at your front door.
This compact villa door station supports WiFi 6 and PoE, allowing flexible installation without complex wiring. Users can unlock doors via Hik-Connect app, Bluetooth, card, or indoor monitor, making it ideal for homes, offices, and rental properties.
If you want a reliable smart intercom with remote access, video recording, and dual lock control, the DS-KV6114-WBE1 is one of Hikvision’s best entry-level IP intercom solutions.
Camera
4MP HD
Viewing Angle
150° Wide
Unlock Methods
App / Card / Bluetooth
Connectivity
WiFi 6 + PoE
Locks
Dual Lock Control
✔ Remote unlock via app ✔ Smart access control ✔ Ideal for homes & small business
Best For
🏠 Homes & ApartmentsControl access remotely and see visitors in real time from your phone.
🏢 Small BusinessesManage entry points with app control and card access.
🚪 Gate & Door ControlSupports dual lock control for doors and gates.
📱 Remote MonitoringReceive calls and unlock doors from anywhere using Hik-Connect.
Technical Specifications
Model
DS-KV6114-WBE1
Camera
4MP (2688 × 1520)
Viewing Angle
150° horizontal
WDR
120dB
Night Vision
IR up to 3m
Audio
Built-in mic & speaker
Unlock Methods
Card / Bluetooth / App / Indoor station
Card Capacity
Up to 10,000 cards
Network
WiFi 6 + Ethernet
Power
PoE (802.3at) or 12V DC
Protection
IP65 weatherproof
Frequently Asked Questions
What is the Hikvision DS-KV6114-WBE1 used for?
It is a smart video intercom door station that allows you to see, talk to, and unlock doors or gates for visitors using your phone, card, Bluetooth, or indoor monitor.
Does this intercom support mobile app access?
Yes. It works with Hik-Connect, allowing you to receive calls, view video, and unlock doors remotely from your smartphone.
What unlock methods does it support?
The DS-KV6114-WBE1 supports multiple access methods including card, Bluetooth, mobile app (Hik-Connect), and indoor station control.
Can this intercom control more than one door or gate?
Yes. It supports dual lock control, allowing you to operate two doors or gates from a single device.
Does it require an indoor monitor to work?
No. It can operate as a standalone unit using the Hik-Connect app, but it can also be paired with indoor monitors for a full intercom system.
Is this a WiFi or wired intercom?
It supports both. You can connect via WiFi 6 or use Ethernet with PoE for a more stable wired installation.
What camera quality does it have?
It features a 4MP camera with a wide 150° viewing angle, providing clear video and wide coverage at your entrance.
Can it record video or playback footage?
Yes. It supports video recording and playback via the Hik-Connect app or web interface when properly configured.
Is it suitable for outdoor installation?
Yes. It has an IP65 weatherproof rating, making it suitable for outdoor use in various conditions.
How is the device powered?
It can be powered via PoE (Power over Ethernet) or 12V DC, giving flexibility for different installations.
⚡ Explore More Hikvision Security Solutions
Upgrade your system with video intercom systems, CCTV cameras, or build a complete solution using our CCTV System Builder.
Build Your Security System →
More information
Download official Hikvision documents for setup, specifications, intercom details.
Datasheet
PDF
Quick Start Guide
PDF
User Manual
PDF
2 Year Australian Warranty
Fast Australia-wide Delivery
Genuine Australian Stock
Hikvision G2 Intercom · 7" IP · Wi-Fi
The Hikvision DS-KH6350-WTE1 is a 7-inch Gen 2 IP indoor station that brings clear video intercom and easy entry control to homes, apartments, and small businesses. Its 1024 × 600 capacitive touch screen and simple setup wizard let you answer calls, open doors, and live view door stations and public-area cameras from one screen.
With Hik-Connect app support you can receive calls, view video, and unlock remotely from your phone. The station deploys independently to reduce wiring and install time, and links with alarm systems and elevator control for larger sites. Choose a black or white front panel to suit your interior.
Display
7" Touch
Resolution
1024 × 600
Connectivity
Wi-Fi + IP
App
Hik-Connect
Finish
Black or White
✔ Remote answer & unlock ✔ Live view of cameras ✔ Alarm & elevator control
What's Included
📺 7" Indoor MonitorDS-KH6350-WTE1 G2 IP indoor station with capacitive touch screen.
🔩 Mounting HardwareWall bracket and fixings for fast installation.
📄 Quick Start GuideHikvision setup documentation for quick commissioning.
Why Choose This Monitor
📱 Remote AccessAnswer calls and unlock doors anywhere with Hik-Connect.
🛠️ Easy SetupQuick wizard and on-screen configuration — no PC required.
🔔 Alarm & ElevatorLinks with alarm systems and supports elevator access control.
🎨 Black or WhiteChoose the panel colour that matches your interior.
Recommended For
🏠 Homes & ApartmentsClear video entry with a responsive touch screen.
🏢 Small BusinessManage reception and office entry with camera live view.
🏬 Multi-Tenant SitesIndependent deployment with alarm and elevator integration.
Technical Specifications
Model
DS-KH6350-WTE1 (G2)
Type
IP indoor station (network)
Display
7" TFT capacitive touch screen
Resolution
1024 × 600
Connectivity
Wi-Fi + Ethernet (IP)
App Support
Hik-Connect
Panel Colour
Black or White (selectable)
Functions
Remote answer/unlock, camera live view, voice messages
Alarm & Control
Alarm linkage, elevator access control
Setup
On-screen wizard, no PC required
Downloads & Resources
Download official Hikvision documents for setup, specifications, and product details.
DS-KH6350-WTE1 DatasheetPDF
Indoor Station Quick Start GuidePDF
Frequently Asked Questions
What is the DS-KH6350-WTE1 used for?It is a 7-inch G2 IP indoor station for answering intercom calls, unlocking doors, and viewing linked cameras.
Does it support a mobile app?Yes. It works with Hik-Connect for remote call answer, live view, and door unlock.
Does it support Wi-Fi?Yes. It connects over Wi-Fi as well as wired IP Ethernet.
What colours are available?You can select a black or white front panel from the dropdown.
Do I need a PC to set it up?No. An on-screen wizard lets you configure the whole system from the monitor.
Does it support alarms and elevators?Yes. It links with alarm systems and supports elevator access control.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision · 2MP Fisheye · Stainless
Premium Stainless-Steel Modular Door Station
The Hikvision DS-KD8003-IME1/S is the main unit of Hikvision's Gen 2 modular door station system, finished in robust stainless steel for entries that demand a premium, hard-wearing look. As the heart of a modular setup it pairs with additional modules to build the exact intercom you need.
A 2MP HD fisheye camera with IR supplement delivers a wide, low-light view, while a single call button, two lock relays and a 4-channel alarm input cover access control and security at the door. It mounts with a bracket sold separately and runs on 12VDC or standard PoE, talking to your indoor and master stations over IP.
Camera
2MP Fisheye + IR
Finish
Stainless Steel
Lock Relays
2 Relays
Power
12VDC or PoE
Rating
IP65 Weatherproof
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
What's Included
DS-KD8003-IME1/S Main UnitStainless-steel modular door station main unit with camera and call button.
DocumentationQuick start guide for wiring and commissioning.
Mounting Bracket RequiredA compatible mounting bracket is sold separately to complete the install.
Why Choose DS-KD8003-IME1/S
Premium Stainless FinishStainless-steel construction resists weather, wear and vandalism at the door.
Modular by DesignActs as the main unit for a modular system you can expand with extra modules.
Two Lock RelaysDrive two locks plus a 4-channel alarm input for full door security.
Flexible PowerRun on 12VDC or standard PoE to suit your existing infrastructure.
Recommended For
Premium EntrancesHomes and businesses that want a high-end stainless door panel.
Expandable SystemsSites planning a modular intercom with future module additions.
Two-Lock DoorsEntries needing control of two locks plus alarm inputs.
Technical Specifications
Model
DS-KD8003-IME1/S
Type
Modular door station main unit
Camera
2MP HD fisheye with IR supplement
Call Button
One call button
Lock Relays
2 lock relays
Alarm Input
4-channel
Power
12VDC or standard PoE
Mounting
Bracket required (sold separately)
Housing
Stainless steel
Protection
IP65
Downloads & Resources
DS-KD8003-IME1/S DatasheetPDF
Is this a complete intercom?No — it is the modular door station main unit. Add modules, an indoor or master station and a lock to complete the system.
Does it include a mounting bracket?No — a compatible mounting bracket is required and sold separately.
What finish is it?It has a premium stainless-steel housing for durability and looks.
How many locks can it control?It has two lock relays plus a 4-channel alarm input.
How is it powered?Either 12VDC or standard PoE.
What camera does it use?A 2MP HD fisheye camera with IR supplement for a wide low-light view.
Is it weatherproof?Yes — it carries an IP65 rating.
Does it include a warranty?Yes — genuine Australian stock backed by our 3-Year AU Warranty.
Order the DS-KD8003-IME1/S today from CCTV Guru — genuine Australian stock, backed by our 3-Year AU Warranty, fast AU-wide shipping and local tech support.
Hikvision Intercom Accessory
DS-KABV6113-RS — Surface Rain Shield for KV6103/6113 Villa Door Station
The Hikvision DS-KABV6113-RS is a protective rain shield for surface-mounted KV6103 and KV6113 series villa door stations. It deflects rain and direct sun away from the panel for reliable outdoor operation.
Designed for surface installations, it helps protect the door station and keep communication clear in exposed locations.
Weather protectionShields the villa door station from rain and direct sunlight.
Villa station fitDesigned for KV6103 and KV6113 series villa door stations.
Surface mountingSuits surface-mount door-station installations.
Durable plasticWeather-resistant plastic construction.
Specifications
Model
DS-KABV6113-RS
Type
Rain shield (surface)
Material
Plastic
Compatibility
KV6103 / KV6113 villa door stations
Downloads & Resources
DS-KABV6113-RS Datasheet (PDF)
What does it fit?Surface-mounted KV6103 and KV6113 series villa door stations.
What is it made from?Durable weather-resistant plastic.
Is it for surface mounting?Yes, it suits surface-mount installations.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Fit the DS-KABV6113-RS to keep your villa door station protected from the elements, backed by local Australian support.
Hikvision Gen2 Intercom Accessory
DS-KABD8003-RS1 — Gen2 Rain Shield for 1-Module Surface Mount
The Hikvision DS-KABD8003-RS1 is a protective rain shield (rain hood) for single-module surface-mounted Gen2 modular door stations. It deflects rain and direct sun away from the panel for reliable outdoor operation.
It suits 1-module surface installations of the DS-KD8003-IME1 and DS-KD8003-IME2 door stations.
Weather protectionShields the door station from rain and direct sunlight.
1-module fitSized for single-module surface-mount door stations.
SECC constructionDurable SECC galvanised steel for outdoor durability.
CompatibleSuits DS-KD8003-IME1 and DS-KD8003-IME2 surface installs.
Specifications
Model
DS-KABD8003-RS1
Type
Rain shield, 1 module (surface)
Material
SECC
Compatibility
DS-KD8003-IME1 / DS-KD8003-IME2
Downloads & Resources
DS-KABD8003-RS1 Datasheet (PDF)
What does it fit?1-module surface-mounted Gen2 door stations (KD8003-IME1/IME2).
What is it made from?SECC galvanised steel for outdoor durability.
Is it for surface mounting?Yes, it suits surface-mount installations.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Fit the DS-KABD8003-RS1 to keep your single-module door station protected from the elements, backed by local Australian support.
Dahua · DHI-VTO6221E-P · IP Apartment Door Station · 2.3" OLED + Card Access
OLED Apartment Station
Dahua DHI-VTO6221E-P Small-Size Apartment Door Station — 2.3" OLED, 2MP & Card Access
The Dahua DHI-VTO6221E-P is a compact IP apartment door station with a clear 2.3-inch OLED screen and a 2MP CMOS camera backed by supplemental white light. Its aluminium alloy plate is rated IP65/IK08, and a mechanical button with Braille improves accessibility. Door release is by password or Mifare card, with PoE or DC 12V power for an easy install.
Camera
2MP
Wiring
IP PoE
Display
2.3" OLED
Unlock
Password / Card
Lighting
White Light
Weatherproof
IP65 / IK08
Compact OLED Design
A small-size form factor with a crisp 2.3-inch OLED screen suits tight apartment entrances and tidy facades, guiding visitors clearly during calls.
Accessible Braille Button
The mechanical call button includes Braille for easier, more inclusive access, and supplemental white lighting helps the camera capture faces in low light.
Password & Card Access
Residents enter via PIN password or Mifare card at the station, giving flexible day-to-day access control without extra hardware.
Tough & Easy to Power
An aluminium alloy plate rated IP65/IK08 handles weather and knocks, while PoE or DC 12V power keeps installation simple and clean.
Specifications — DHI-VTO6221E-P
Type
Small-size apartment IP door station
Display
2.3" OLED
Camera
2MP CMOS with supplemental white light
Wiring
IP / PoE
Button
Mechanical with Braille
Unlock Methods
Password, Mifare card
Power
DC 12V / PoE
Ingress / Impact
IP65 · IK08
Material / Mount
Aluminium alloy · surface & flush mount
Pairs With
Dahua IP indoor monitors (VTH series)
Warranty
3 years · CCTV Guru Australia
Downloads & Resources
DHI-VTO6221E-P Datasheet
Dahua Door Station Quick Start Guide
Dahua Door Station User Manual
How do residents unlock the door?By PIN password or Mifare card at the station. Remote unlock is also possible from a paired Dahua indoor monitor.
Does it have a screen?Yes — a 2.3-inch OLED display guides visitors during calls, and a Braille mechanical button improves accessibility.
How is it powered?Via PoE or DC 12V, so you can run a single network cable or a local power supply depending on your setup.
Which indoor monitor does it pair with?It pairs with Dahua IP indoor monitors (VTH series). Ask our team for a matching monitor to complete your kit.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision Gen2 Intercom Accessory
DS-KD-ACF1/S — Gen2 Stainless Steel 1-Module Flush Mount Box
The Hikvision DS-KD-ACF1/S is a stainless steel flush-mount gang box for single-module Gen2 modular door stations. Recessed into the wall, it gives a streamlined, low-profile entry-panel finish with added corrosion resistance.
The package includes the gang box, cover screws and cabling accessories needed to complete a recessed installation.
Stainless steelHigh-grade stainless body for superior corrosion resistance.
1-module capacityHouses a single Hikvision Gen2 modular door-station module.
Flush mountingRecesses into the wall for a flat, low-profile finish.
Complete kitGang box, cover screws and cabling accessories included.
Specifications
Model
DS-KD-ACF1/S
Type
Flush mount gang box, 1 module
Material
Stainless steel
Includes
Gang box, cover screws, cabling accessories
Compatibility
Hikvision Gen2 modular door stations
Downloads & Resources
DS-KD-ACF1/S Datasheet (PDF)
How many modules does it fit?One Hikvision Gen2 modular door-station module.
Surface or flush?Flush mounting, recessed into the wall. For surface installs use the ACW1 box.
Why stainless steel?For extra corrosion resistance in exposed or coastal environments.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Pair the DS-KD-ACF1/S with your single-module Gen2 door station for a premium, recessed entry-panel install backed by local Australian support.
Hikvision Gen2 · Stainless Steel · Two-Module Surface Mount
Premium Stainless-Steel Housing for a Two-Module Hikvision Door Station
The Hikvision DS-KD-ACW2/S is a stainless-steel two-module surface-mount enclosure for compatible Hikvision Gen2 modular video intercom door stations. It creates a clean, durable installation where a recessed wall cavity is unavailable or where a premium stainless finish is preferred.
The kit includes the two-module installation frame, stainless-steel front cover, button cover and required mounting accessories. Pair it with a compatible main door-station module and one function module to build a tailored entry panel for residential, commercial or multi-tenant sites.
Finish
Stainless steel
Capacity
Two modules
Installation
Surface mount
System
Gen2 modular
Why Choose the DS-KD-ACW2/S?
Premium Stainless FinishThe stainless-steel cover gives compatible Gen2 modules a professional, coordinated appearance and improved resistance to exposed conditions.
Flexible Two-Module DesignCombine a compatible main video door station with a keypad, card reader, display or nametag module to suit the entrance.
No Deep Wall RecessSurface mounting suits solid walls, retrofit projects and locations where cutting a flush-mount cavity is impractical.
Complete Mounting PackageSupplied with the two-module frame, stainless front panel, button cover and mounting accessories needed for enclosure assembly.
Product Specifications
Official model
DS-KD-ACW2/S
Product type
Two-module surface mounting box
Cover material
Stainless steel
Installation frame
Aviation aluminium
Mounting method
Surface mount
Module capacity
2 × compatible Hikvision Gen2 modular door-station modules
Package contents
Two-module frame, front panel, button cover and mounting accessories
Modules included
No — door-station and function modules are sold separately
Build a Stainless Two-Module Entry Panel
For the most consistent finish, start with the DS-KD8003-IME1/S stainless main door station. The DS-KD8003-IME1/NS no-button stainless station is useful when the second module will provide the visitor calling or access function.
DS-KD-KP/S KeypadAdd stainless-finish PIN access and keypad calling functions.
DS-KD-KK/S Nametag ModuleAdd six stainless-finish labelled call buttons for small multi-tenant entrances.
DS-KD-M Card ReaderAdd MIFARE card access for authorised users.
DS-KD-DIS DisplayAdd a 3.5-inch directory display for visitor guidance and contact selection.
Choose the Right Two-Module Housing
Model
Installation
Best For
DS-KD-ACW2/S
Stainless-steel surface mount
Premium exposed, retrofit and coastal-style installations
DS-KD-ACW2
Standard surface mount
Cost-effective general installations
DS-KD-ACF2/S
Stainless-steel flush mount
Recessed installations with a low-profile finish
Installation Planning
Confirm that both selected modules belong to the compatible Hikvision Gen2 modular system.
Plan network, two-wire, PoE and lock-control cabling before fixing the enclosure.
Add the DS-KABD8003-RS2 rain shield where additional overhead weather coverage is required.
Use suitable wall fixings and seal cable entries for the installation environment.
Professional installation and system commissioning are recommended.
Frequently Asked Questions
How many modules does it hold?The DS-KD-ACW2/S provides two positions for compatible Hikvision Gen2 modular door-station modules.
Are the intercom modules included?No. This is the mounting enclosure only. The main video door station and chosen function module are sold separately.
Which main station best matches the finish?The DS-KD8003-IME1/S stainless main station provides the closest coordinated appearance.
Can it be flush mounted?No. Choose the DS-KD-ACF2/S for a recessed stainless-steel two-module installation.
Is this the same as the DS-KD-ACW2?No. Both hold two modules and surface mount, but the DS-KD-ACW2/S uses a stainless-steel cover for a premium finish.
Is a rain shield available?Yes. The active DS-KABD8003-RS2 provides additional coverage for a two-module surface-mount assembly.
Downloads & Resources
Official DS-KD-ACW2/S Datasheet
3-Year Australian Warranty
Australia-Wide Delivery
Local Technical Support
Genuine Hikvision · KD8 Series Pro · Stainless Steel
Add PIN Access to a Hikvision Modular Door Station
The Hikvision DS-KD-KP/S is the stainless steel keypad module for a compatible KD8 Series Pro modular door station. It lets visitors enter a PIN to unlock a configured door or call an indoor station, while backlit buttons keep the keypad easy to use after dark.
Module Type
Keypad
Finish
Stainless steel
Protection
IP65 · IK07
Series
KD8 Series Pro
Why Choose This Module?
PIN Door EntryAdd keypad-based access for authorised users without requiring a card or fob for every entry.
Visitor CallingThe keypad can also be used to call an indoor station when the modular door station is correctly configured.
Clear After-Dark UseBacklit buttons make the numbers easier to identify at entrances with limited lighting.
Durable Entrance FinishThe stainless steel face provides a professional appearance, with IP65 ingress protection and IK07 impact resistance.
Key Specifications
Official model
DS-KD-KP/S
Product type
Keypad module for modular door station
Functions
PIN entry for door release; call indoor station
Material
Stainless steel
Button lighting
Backlit keypad
Ingress protection
IP65 when installed as part of a suitable completed assembly
Impact protection
IK07
Compatibility
Hikvision KD8 Series Pro modular door station system
Important Before You Buy
This is an add-on module, not a complete standalone door station. A compatible KD8 Series Pro main unit, mounting frame or housing, power/network arrangement and system configuration are required.
Frequently Asked Questions
Is the DS-KD-KP/S a complete door station?No. It is a keypad module that must be installed with compatible Hikvision KD8 Series Pro door-station components.
What can users do from the keypad?Depending on the system configuration, users can enter a PIN to unlock the door or use the keypad to call an indoor station.
What is the difference between DS-KD-KP and DS-KD-KP/S?The /S version uses a stainless steel face. Choose the module that matches the finish and mounting components planned for your KD8 installation.
Can it be installed outdoors?The module is rated IP65 and IK07. Outdoor performance depends on correct installation in compatible housings with appropriate cable sealing and weather protection.
Downloads & Resources
Official Datasheet
3-Year Australian Warranty
Australia-Wide Delivery
Local Technical Support
Hikvision Intercom · 10.1" IP · Wi-Fi + PoE
The Hikvision DS-KH8520-WTE1 is a large 10.1-inch IP indoor station that gives you a generous, easy-to-read touch interface for your video intercom. Its 1024 × 600 TFT touch screen delivers clear visuals for answering calls, controlling doors, and live viewing door stations and public-area cameras.
With both Wi-Fi and PoE for flexible installation and Hik-Connect for remote call reception, door control, and live view, it is a comprehensive indoor monitor for homes, apartments, and small commercial sites. A setup wizard and on-screen configuration make commissioning simple, and it supports voice messaging, alarm linkage, and elevator access control. Black finish.
Display
10.1" Touch
Resolution
1024 × 600
Connectivity
Wi-Fi + PoE
App
Hik-Connect
Control
Alarm + Elevator
✔ Large 10.1" screen ✔ Remote answer & unlock ✔ Camera live view
What's Included
📺 10.1" Indoor MonitorDS-KH8520-WTE1 black IP indoor station with TFT touch screen.
🔩 Mounting HardwareWall bracket and fixings for installation.
📄 Quick Start GuideHikvision setup documentation for commissioning.
Why Choose This Monitor
🖥️ Large DisplayGenerous 10.1-inch touch screen for clear, comfortable use.
📱 Remote AccessAnswer calls and unlock doors anywhere with Hik-Connect.
⚡ Flexible PowerWi-Fi and PoE for clean, simple installation.
🔔 Alarm & ElevatorVoice messaging, alarm linkage, and elevator access control.
Recommended For
🏠 Premium HomesA larger, clearer indoor station for the main entry point.
🏢 Small CommercialReception and office entry with camera integration.
🏬 Multi-Tenant SitesAlarm and elevator integration for larger buildings.
Technical Specifications
Model
DS-KH8520-WTE1
Type
IP indoor station (network)
Display
10.1" TFT touch screen
Resolution
1024 × 600
Connectivity
Wi-Fi + PoE
App Support
Hik-Connect
Functions
Remote answer/unlock, camera live view, voice messages
Alarm & Control
Alarm linkage, elevator access control
Setup
On-screen wizard, no PC required
Finish
Black
Downloads & Resources
Download official Hikvision documents for setup, specifications, and product details.
DS-KH8520-WTE1 DatasheetPDF
Frequently Asked Questions
What is the DS-KH8520-WTE1 used for?It is a 10.1-inch IP indoor station for answering intercom calls, unlocking doors, and viewing linked cameras.
Does it support a mobile app?Yes. It works with Hik-Connect for remote call answer, live view, and door unlock.
Does it support Wi-Fi and PoE?Yes. It connects via Wi-Fi or wired Ethernet with PoE.
What size is the screen?It has a large 10.1-inch TFT touch screen at 1024 × 600.
Do I need a PC to set it up?No. An on-screen wizard lets you configure the whole system from the monitor.
Does it support alarms and elevators?Yes. It supports alarm linkage and elevator access control.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision · 2MP Colour · Modular
Flexible Modular IP Door Station for Any Entry
The Hikvision DS-KD8003-IME1 is the main unit of Hikvision's Gen 2 modular door station system. As an IP-based door station it integrates cleanly into a networked intercom, talking to indoor and master stations over a single network, and forms the foundation of a setup you can expand with additional modules.
A 2MP HD colour fisheye camera with IR supplement gives a wide, clear view day and night. A single call button, two lock relays and a 4-channel alarm input handle access and security at the door, while 12VDC or standard PoE power keeps wiring simple. A compatible mounting bracket is sold separately.
Camera
2MP Colour Fisheye
Type
Modular IP
Lock Relays
2 Relays
Power
12VDC or PoE
Rating
IP65 Weatherproof
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
What's Included
DS-KD8003-IME1 Main UnitModular IP video door station main unit with colour camera and call button.
DocumentationQuick start guide for wiring and commissioning.
Mounting Bracket RequiredA compatible mounting bracket is sold separately to complete the install.
Why Choose DS-KD8003-IME1
True IP IntegrationNetworked door station that connects to indoor and master stations over IP.
Colour Fisheye View2MP colour fisheye with IR supplement for a wide, clear picture in any light.
Two Lock RelaysControl two locks plus a 4-channel alarm input from one door unit.
Modular & ExpandableActs as the main unit so you can add modules as your needs grow.
Recommended For
Networked SitesPremises running an IP intercom with indoor and master stations.
Expandable SystemsInstalls that may add modules over time.
Two-Lock DoorsEntries that need control of two locks plus alarm inputs.
Technical Specifications
Model
DS-KD8003-IME1
Type
Modular IP door station main unit
Camera
2MP HD colour fisheye with IR supplement
Call Button
One call button
Lock Relays
2 lock relays
Alarm Input
4-channel
Power
12VDC or standard PoE
Mounting
Bracket required (sold separately)
Protection
IP65
Downloads & Resources
DS-KD8003-IME1 DatasheetPDF
Is this a complete intercom?No — it is the modular door station main unit. Add modules, an indoor or master station and a lock to complete the system.
Does it include a mounting bracket?No — a compatible mounting bracket is required and sold separately.
Is the camera colour?Yes — a 2MP HD colour fisheye camera with IR supplement.
How many locks can it control?It has two lock relays plus a 4-channel alarm input.
How is it powered?Either 12VDC or standard PoE.
Does it work over IP?Yes — it connects to indoor and master stations over the network.
Is it weatherproof?Yes — it carries an IP65 rating for outdoor entry use.
Does it include a warranty?Yes — genuine Australian stock backed by our 3-Year AU Warranty.
Order the DS-KD8003-IME1 today from CCTV Guru — genuine Australian stock, backed by our 3-Year AU Warranty, fast AU-wide shipping and local tech support.
Hikvision · Face Recognition · IP65
Hikvision DS-KD9203-E6 — Face Recognition Video Door Station
The DS-KD9203-E6 brings touchless face recognition to a compact door station, supporting up to 5,000 users and faces. A 4.3" colour LCD (800×480) and dual 2MP wide-angle HD cameras deliver clear, wide-coverage visitor video at the door.
Beyond face, residents can unlock via M1 (Mifare) card or PIN code, with the built-in card reading module on board. RJ45, RS-485, alarm input, relay and Wiegand interfaces plus web remote configuration make it flexible to install, and an IP65 rating keeps it dependable outdoors.
Display
4.3" Colour LCD
Cameras
Dual 2MP Wide
Recognition
5,000 Faces
Access
Face · Card · PIN
Rating
IP65
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
What's Included
DS-KD9203-E6 Door StationFace recognition outdoor station with 4.3" LCD and dual 2MP cameras.
Mounting HardwareFixings for secure installation at the door or gate.
Wiring AccessoriesConnector kit for RJ45, RS-485, alarm and Wiegand wiring.
Quick Start GuideSetup guide plus the downloadable datasheet below.
Why Choose DS-KD9203-E6
Touchless EntryFace recognition for up to 5,000 users — hands-free, secure access.
Multi-Mode UnlockFace, M1 (Mifare) card and PIN code in a single station.
Wide Dual CamerasTwo 2MP wide-angle cameras for broad doorway coverage.
Weatherproof BuildIP65 rating for dependable outdoor performance.
Recommended For
ApartmentsFace-based access for up to 5,000 residents and staff.
OfficesTouchless entry control for commercial entrances.
Residential HomesModern face recognition door station for private dwellings.
Managed SitesWeb configuration streamlines setup and credential management.
Technical Specifications
Model
DS-KD9203-E6
Display
4.3" colour LCD, 800×480
Cameras
Dual 2MP wide-angle HD
Face Recognition
Up to 5,000 users / faces
Card Reader
Built-in M1 (Mifare)
Unlock Methods
Face, card, PIN code
Interfaces
RJ45, RS-485, alarm input, relay, Wiegand
Configuration
Web-based remote configuration
Protection
IP65
Downloads & Resources
DS-KD9203-E6 DatasheetPDF
How many faces can the DS-KD9203-E6 store?Up to 5,000 users and faces.
What screen does it have?A 4.3" colour LCD at 800×480 resolution.
How can residents unlock?By face, M1 (Mifare) card or PIN code.
What cameras does it use?Dual 2MP wide-angle HD cameras for broad coverage.
Is it weatherproof?Yes — it carries an IP65 rating.
What interfaces are available?RJ45, RS-485, alarm input, relay and Wiegand.
Can it be configured remotely?Yes — it supports web-based remote configuration.
Does it have a built-in card reader?Yes — an M1 (Mifare) card reading module is built in.
Where is it best used?Apartments, offices and residential homes needing touchless entry.
Order the DS-KD9203-E6 today from CCTV Guru — genuine Australian stock, backed by our 3-Year AU Warranty, fast AU-wide shipping and local tech support.
Dahua · DH-48V(1.25A) · DC Power Supply · 48V 1.25A
48V DC PSU
Dahua DH-48V(1.25A) 48V DC Power Supply
The Dahua DH-48V(1.25A) is a 48V DC 1.25A power adapter designed as the original replacement supply for the Dahua DHI-AC-VTNS1001B-2 PoE switch used in IP intercom systems. It delivers clean, regulated power to keep your access and intercom hardware running reliably.
Supplied as a genuine Dahua spare, it is a direct fit for the VTNS1001B-2. Always confirm the 48V DC input requirement on your device before purchase.
Specifications — DH-48V(1.25A)
Brand / Model
Dahua DH-48V(1.25A)
Device Type
DC Power Supply Adapter
Output Voltage
48V DC
Output Current
1.25A
Designed For
Dahua DHI-AC-VTNS1001B-2 PoE switch
Colour
Black
Warranty (Australia)
3 years · CCTV Guru Australia
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision Intercom Kit · 2-Wire · 2MP Door Station
Hikvision DS-KIS703Y-P Gen 2 Two-Wire Video Intercom Kit with 2MP Door Station & 7" Monitor
The Hikvision DS-KIS703Y-P is a Gen 2 two-wire digital IP video intercom kit built for simple retrofits and new installs in Australian villas, houses and apartments. Its Y-Series two-wire design carries both power and data over a single non-polar pair, making it ideal for upgrading older buildings without running new structured cabling.
The kit pairs the DS-KV8103Y-IMPE2 2MP door station with the DS-KH6320Y-WTPE2 7" indoor monitor and a DS-KABV8103-RS surface mount. Answer calls from the touchscreen or Hik-Connect app, view the entrance live, and release a lock directly from the door station's built-in 12 V power output — no separate lock power supply required.
Door Station
2MP Stainless
Monitor
7" Touchscreen
Wiring
2-Wire Non-Polar
Remote Access
Hik-Connect App
Locks
2 Lock Control
Protection
IP65 Door Station
3-Year AU Warranty
Simple 2-Wire Install
AU Tech Support
What's Included
1 × Hikvision DS-KV8103Y-IMPE2 Door StationTwo-wire 2MP door station with a single call button, two-lock control, IP65 weather protection and a high-quality stainless steel panel. Provides a built-in 12 V / 500 mA output to drive one electric lock without an additional power supply.
1 × Hikvision DS-KH6320Y-WTPE2 Indoor Monitor7" two-wire IP touchscreen (1024 × 600) with Hik-Connect app control, live view of the door station, voice-message support and a quick setup wizard for fast commissioning.
1 × Hikvision DS-KABV8103-RS MountMatched surface mount bracket for the door station for a clean, secure installation.
Two-Wire Power SupplyIncluded PSU powers the two-wire bus, so the system is ready to commission without specifying separate device power.
Why Choose the DS-KIS703Y-P?
Ideal for RetrofitsTwo non-polar wires carry power and data, perfect for upgrading older homes and apartments without new network cabling.
Built-In Lock PowerThe door station supplies 12 V / 500 mA for one electric lock, removing the need for a separate lock power supply.
App ControlView, talk and unlock remotely through Hik-Connect when configured correctly.
Durable Door StationStainless steel panel and IP65 rating suit exposed front-door and gate positions.
Simple One-Button CallingA single call button keeps day-to-day use easy for the whole household.
Matched Hikvision BundlePre-paired Y-Series components reduce compatibility guesswork for your installer.
Recommended For
Retrofit UpgradesReplace an ageing audio or video intercom using existing two-wire runs.
Villas & HousesFront door or gate entry with indoor monitor and app convenience.
ApartmentsSingle-dwelling door entry where running data cable is impractical.
Gated EntriesPair with a compatible electric strike for controlled access.
Technical Specifications
Door Station — Hikvision DS-KV8103Y-IMPE2
Camera
2MP resolution
Call Button
1 physical call button
Lock Control
Two-lock control
Lock Power
12 V / 500 mA output for one electric lock
Panel
Stainless steel
Protection
IP65 rated
Wiring
Two-wire (non-polar)
Indoor Monitor — Hikvision DS-KH6320Y-WTPE2
Display
7" touchscreen
Resolution
1024 × 600
Wiring
Two-wire IP
App
Hik-Connect remote call, view & unlock
Features
Live view, voice message, setup wizard
System & Mount
Mount
DS-KABV8103-RS surface mount
Power
Two-wire PSU included
System
Gen 2, 1-to-1 modular, surface mount
Downloads & Resources
DS-KIS703Y-P Datasheet
Hikvision Video Intercom Quick Start Guide
Hikvision Video Intercom User Manual
Frequently Asked Questions
What does "two-wire" mean?The door station and monitor connect over a single non-polar pair that carries both power and data, so you can often reuse existing cabling when upgrading an old intercom.
Do I need a separate lock power supply?Not for a single lock. The door station provides a 12 V / 500 mA output to drive one electric lock directly.
Can I answer the door from my phone?Yes. With Hik-Connect you can view callers, talk and unlock remotely when configured correctly.
Is the door station weatherproof?Yes, it is IP65 rated with a stainless steel panel suited to outdoor entry positions.
Is this a PoE kit?No. The DS-KIS703Y-P is a two-wire system. For a PoE kit, see the Hikvision DS-KIS602 or DS-KIS603-P.
Is installation included?No. This is a hardware kit. We recommend installation by a licensed security technician.
Order Your Hikvision DS-KIS703Y-P Intercom Kit from CCTV Guru
Order the Hikvision DS-KIS703Y-P Two-Wire Video Intercom Kit from CCTV Guru for a simple, retrofit-friendly entry solution with a 2MP stainless door station, 7" indoor monitor and Hik-Connect app control. Ideal for Australian villas, houses and apartments upgrading from an older intercom. Australian stock, backed by a 3-year warranty and local support.
Dahua · ASC2204C-H · 4-Door Controller · 200,000 Cards4-Door ControllerDahua DHI-ASC2204C-H Four-Door Master Access Controller
The Dahua DHI-ASC2204C-H is a four-door master access controller for commercial and multi-door access control systems. It supports up to 200,000 valid cards and 150,000 records, connects over TCP/IP, and drives readers via Wiegand or RS-485. A CAN bus lets it cascade up to 16 sub-controller modules, while advanced features like global anti-passback, multi-door interlock and multiple alarm types make it suitable for demanding security deployments.
Doors
4 Doors
Card Capacity
200,000 Cards
Records
150,000
Network
TCP/IP
Reader I/O
Wiegand / RS-485
Cascade
16 Sub via CAN
Four Doors, One Master Controller
Manage up to four doors from a single controller, with support for 200,000 valid cards and 150,000 stored event records. A CAN bus cascades up to 16 sub-controller modules to scale across larger sites.
Flexible Credentials
Authenticate users by card, password, fingerprint or a combination, and support multiple cards per door. Readers connect via Wiegand or RS-485, with a TCP/IP interface back to your management platform.
Advanced Access Logic
Global anti-passback, multi-door interlock, multi-person open and remote verification unlock give you fine-grained control. 128 time and holiday schedules, a built-in RTC with DST and a watchdog keep operation reliable.
Comprehensive Alarms & Integration
Door-timeout, intrusion, duress and tamper alarms protect each entry. ONVIF Profile C, CGI and SDK support let the controller integrate with third-party platforms, and a built-in web service configures sub-controllers.
Specifications — ASC2204C-H
Model
DHI-ASC2204C-H
Type
Four-door master access controller
Card Capacity
200,000 valid cards
Record Capacity
150,000 records
Network Interface
TCP/IP
Reader Interface
Wiegand or RS-485
Cascade
CAN bus, up to 16 sub-controller modules
Credentials
Card, password, fingerprint and combinations; multiple cards
Access Logic
Global anti-passback, multi-door interlock, multi-person open, remote verification unlock
Alarms
Door-timeout, intrusion, duress, tamper
Schedules
128 time & holiday schedules; built-in RTC with DST
Integration
ONVIF Profile C, CGI, SDK; web service configuration
Installation
Surface mounted; accumulator battery extension supported
Warranty (Australia)
3 years · CCTV Guru Australia
Downloads & Resources
ASC2204C-H Datasheet
How many doors does the ASC2204C-H control?It manages four doors from a single master controller, and can cascade up to 16 sub-controller modules over CAN bus for larger sites.
How do readers connect?Readers connect via Wiegand or RS-485, while the controller links to your management platform over a TCP/IP network interface.
What capacity does it support?Up to 200,000 valid cards and 150,000 event records, with 128 time and holiday schedules.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
UniFi Protect Accessory
Ubiquiti UniFi Protect G4 Doorbell Black Cover (UVC-G4-DB-Cover-Black)
The UniFi Protect G4 Doorbell Black Cover is a genuine Ubiquiti snap-on skin that lets your UniFi Protect G4 Doorbell (UVC-G4-DoorBell) blend cleanly into dark door frames, walls, and trims. The black finish gives a discreet, low-profile look while leaving the camera, ring button, and microphone fully unobstructed. A simple cosmetic upgrade with genuine Ubiquiti stock and fast Australia-wide shipping — backed by expert AU support.
Model
UVC-G4-DB-Cover-Black
Type
Cosmetic skin / cover
Colour
Black
Compatibility
UniFi Protect G4 Doorbell (UVC-G4-DoorBell)
Installation
Snap-on, no tools required
Brand
Ubiquiti — UniFi Protect
Compliance
NDAA compliant
Discreet Black Finish
Helps the G4 Doorbell blend into dark door frames, walls, and trims for a clean, low-profile install.
Genuine Ubiquiti Accessory
A perfect-fit cover designed specifically for the UniFi Protect G4 Doorbell — precise cutouts keep the camera, ring button, and mic clear.
Tool-Free Fit
Slips over your existing G4 Doorbell in seconds — no rewiring, no tools, no remounting required.
NDAA Compliant
Part of the Ubiquiti UniFi Protect ecosystem, suitable for government and security-sensitive sites.
Fast AU Shipping
Genuine Ubiquiti Stock
Expert AU Support
Hikvision 9 Series · 10.1-inch IPS · Android 14 · Wi-Fi 6 + PoE
Premium 10.1-inch Indoor Station for Hikvision Video Intercom
The Hikvision DS-KH9570-WTE1/S is a flagship indoor video intercom monitor for premium homes, apartments and commercial entry systems. Its large 1920 × 1200 IPS touchscreen provides a clear control point for answering visitor calls, viewing compatible door stations and cameras, and releasing a configured door.
Built on Android 14 with dual-band Wi-Fi 6, BLE 5.0 and IEEE 802.3at PoE, the monitor combines modern connectivity with flexible installation. Dual microphones, dual loudspeakers, noise suppression and echo cancellation support clearer two-way communication.
Display
10.1-inch IPS touch
Platform
Android 14
Wireless
Dual-band Wi-Fi 6
Power
PoE or 12 VDC
Audio
Dual mic + speakers
Local Storage
TF card up to 256GB
Why Choose the DS-KH9570-WTE1/S?
Large, Detailed TouchscreenThe 10.1-inch 1920 × 1200 IPS display gives visitor video, live camera views and system controls more room than a standard seven-inch indoor station.
Clear Two-Way CommunicationTwo omnidirectional microphones, two loudspeakers, noise suppression and echo cancellation support natural conversations at the entrance.
Flexible Wired or Wireless SetupConnect through dual-band Wi-Fi 6 or 10/100 Mbps Ethernet, with power supplied by IEEE 802.3at PoE or a suitable 12 VDC supply.
Broader Hikvision IntegrationUse one indoor screen for compatible doorphones, indoor extensions and linked network cameras within a correctly designed Hikvision system.
Recommended Applications
Premium Homes
A larger, high-resolution indoor control point for a modern front door or pedestrian gate.
Offices & Reception
Answer entry calls, view visitors and release a configured door from a central desk or wall position.
Integrated Security Systems
Suitable where compatible Hikvision intercom devices and network cameras need to be viewed from one station.
Technical Specifications
Official model
DS-KH9570-WTE1/S
Series
Hikvision 9 Series indoor station
Display
10.1-inch colour IPS capacitive touchscreen
Resolution
1920 × 1200
Operating system
Android 14
Memory
4GB RAM · 8GB ROM
Wi-Fi
Wi-Fi 6 · 2.4GHz and 5GHz
Bluetooth
BLE 5.0
Network interface
1 × RJ45 10/100 Mbps
Audio hardware
2 × omnidirectional microphones · 2 × loudspeakers
Audio processing
Noise suppression and echo cancellation
Local storage
TF card slot · up to 256GB
Linked doorphones
Up to 17
Indoor extensions
Up to 15
Linked network cameras
Up to 16
Power
12 VDC, 2.5A or IEEE 802.3at PoE
Installation
Surface mount
Compatibility & Planning
This is an indoor station only; a compatible Hikvision door station, network and door-release hardware are sold separately.
Confirm model compatibility, PoE budget, cabling and lock-control requirements before installation.
Linked-device capacity depends on the final system design and configuration.
Professional installation and commissioning are recommended.
Planning a complete system? Explore video intercom products or use the Hikvision Intercom System Builder.
See Hikvision Intercom Technology
Hikvision video intercom technology overview
Frequently Asked Questions
What is the DS-KH9570-WTE1/S used for?It is an indoor video intercom monitor for answering visitor calls, viewing compatible devices and releasing a configured door.
Does it support Wi-Fi?Yes. It supports dual-band Wi-Fi 6 on 2.4GHz and 5GHz networks.
Can it be powered by PoE?Yes. It supports IEEE 802.3at PoE or a suitable 12 VDC, 2.5A power supply.
Can it display Hikvision cameras?Yes. Hikvision specifies support for up to 16 linked network cameras when the system is correctly configured.
Can I add local storage?Yes. The TF card slot supports a card up to 256GB.
Is a door station included?No. This listing is for the indoor monitor. Compatible door stations, PoE equipment and door-release hardware are available separately.
Downloads & Resources
Official Datasheet
Quick Start Guide
User Manual
2-Year Australian Warranty
Australia-Wide Delivery
Genuine Australian Stock
