Hikvision 9 Series · 10.1-inch IPS · Android 14 · Wi-Fi 6 + PoE
Premium 10.1-inch Indoor Station for Hikvision Video Intercom
The Hikvision DS-KH9570-WTE1/S is a flagship indoor video intercom monitor for premium homes, apartments and commercial entry systems. Its large 1920 × 1200 IPS touchscreen provides a clear control point for answering visitor calls, viewing compatible door stations and cameras, and releasing a configured door.
Built on Android 14 with dual-band Wi-Fi 6, BLE 5.0 and IEEE 802.3at PoE, the monitor combines modern connectivity with flexible installation. Dual microphones, dual loudspeakers, noise suppression and echo cancellation support clearer two-way communication.
Display
10.1-inch IPS touch
Wireless
Dual-band Wi-Fi 6
Audio
Dual mic + speakers
Local Storage
TF card up to 256GB
Why Choose the DS-KH9570-WTE1/S?
Large, Detailed TouchscreenThe 10.1-inch 1920 × 1200 IPS display gives visitor video, live camera views and system controls more room than a standard seven-inch indoor station.
Clear Two-Way CommunicationTwo omnidirectional microphones, two loudspeakers, noise suppression and echo cancellation support natural conversations at the entrance.
Flexible Wired or Wireless SetupConnect through dual-band Wi-Fi 6 or 10/100 Mbps Ethernet, with power supplied by IEEE 802.3at PoE or a suitable 12 VDC supply.
Broader Hikvision IntegrationUse one indoor screen for compatible doorphones, indoor extensions and linked network cameras within a correctly designed Hikvision system.
Recommended Applications
Premium Homes
A larger, high-resolution indoor control point for a modern front door or pedestrian gate.
Offices & Reception
Answer entry calls, view visitors and release a configured door from a central desk or wall position.
Integrated Security Systems
Suitable where compatible Hikvision intercom devices and network cameras need to be viewed from one station.
Technical Specifications
| Official model |
DS-KH9570-WTE1/S |
| Series |
Hikvision 9 Series indoor station |
| Display |
10.1-inch colour IPS capacitive touchscreen |
| Resolution |
1920 × 1200 |
| Operating system |
Android 14 |
| Memory |
4GB RAM · 8GB ROM |
| Wi-Fi |
Wi-Fi 6 · 2.4GHz and 5GHz |
| Bluetooth |
BLE 5.0 |
| Network interface |
1 × RJ45 10/100 Mbps |
| Audio hardware |
2 × omnidirectional microphones · 2 × loudspeakers |
| Audio processing |
Noise suppression and echo cancellation |
| Local storage |
TF card slot · up to 256GB |
| Linked doorphones |
Up to 17 |
| Indoor extensions |
Up to 15 |
| Linked network cameras |
Up to 16 |
| Power |
12 VDC, 2.5A or IEEE 802.3at PoE |
| Installation |
Surface mount |
Compatibility & Planning
- This is an indoor station only; a compatible Hikvision door station, network and door-release hardware are sold separately.
- Confirm model compatibility, PoE budget, cabling and lock-control requirements before installation.
- Linked-device capacity depends on the final system design and configuration.
- Professional installation and commissioning are recommended.
Planning a complete system? Explore video intercom products or use the Hikvision Intercom System Builder.
See Hikvision Intercom Technology
Hikvision video intercom technology overview
Frequently Asked Questions
What is the DS-KH9570-WTE1/S used for?It is an indoor video intercom monitor for answering visitor calls, viewing compatible devices and releasing a configured door.
Does it support Wi-Fi?Yes. It supports dual-band Wi-Fi 6 on 2.4GHz and 5GHz networks.
Can it be powered by PoE?Yes. It supports IEEE 802.3at PoE or a suitable 12 VDC, 2.5A power supply.
Can it display Hikvision cameras?Yes. Hikvision specifies support for up to 16 linked network cameras when the system is correctly configured.
Can I add local storage?Yes. The TF card slot supports a card up to 256GB.
Is a door station included?No. This listing is for the indoor monitor. Compatible door stations, PoE equipment and door-release hardware are available separately.
Downloads & Resources
2-Year Australian Warranty
