Technical Specification
|
|
System
|
|
Main Processor
|
Embedded processor
|
|
Operating System
|
Embedded Linux operating system
|
|
Interoperability
|
ONVIF; SDK
|
|
Network Protocol
|
RTSP; RTP; SIP; DNS; SSH
|
|
ROM
|
128 MB
|
|
RAM
|
128 MB
|
|
CPU
|
Dual core 1.2 GHz
|
|
Basic
|
|
Screen Type
|
Capacitive Touchscreen
|
|
Display
|
7" TFT
|
|
Screen Resolution
|
1024 × 600
|
|
Audio Compression
|
G.711a; G.711u; PCM
|
|
Audio Input
|
1
|
|
Audio Output
|
Built-in speaker
|
|
Audio Mode
|
2-way Audio
|
|
Audio Enhancement
|
Echo suppression
|
|
Audio Bit Rate
|
116 bit
|
|
Function
|
|
Communication Mode
|
Full digital
|
|
Information Release
|
Receive and view text information released by the management center
|
|
DND Mode
|
Do not disturb period can be set; Do not disturb mode
|
|
Number of Extensions
|
Villa: 9
Apartment: 4
Wi-Fi intercom: 1 main monitor, 2 extension monitors
|
|
Wi-Fi
|
Yes
|
|
Wireless Standard
|
IEEE802.11b/802.11g/802.11n
|
|
Wireless Frequency Range
|
2,412–2,472 MHz
|
|
Wireless Security Encryption
|
WPA/WPA2; WPA-PSK/WPA2-PSK
|
|
Performance
|
|
Casing
|
PC + ABS
|
|
Port
|
|
Alarm Input
|
6
|
|
Alarm Output
|
1
|
|
Door Bell
|
Yes (use any alarm input port)
|
|
Network
|
One 10 /100 Mbps Ethernet
|
|
Storage
|
Micro SD Card, Max 64 GB (reserved for software)
|
|
General
|
|
Appearance Color
|
Black/White
|
|
Power Supply
|
12 VDC 1A;
Standard PoE (36–57 V, 0.35 A)
|
|
Installation
|
Surface Mount
|
|
Certifications
|
CE; FCC
|
|
Dimensions
|
189.6 mm × 134.6 mm × 26.0 mm (7.50" × 5.30" × 1.00")
|
|
Operating Temperature
|
–10 °C to +55 °C (+14 °F to 131 °F)
|
|
Operating Humidity
|
10%–95% RH (non-condensing)
|
|
Operating Altitude
|
Beneath 3,000 m (9,842.52 ft)
|
|
Power Consumption
|
Standby ≤ 2W; working ≤ 6W
|
|
Net Weight
|
0.34 kg (0.74 lb)
|
|
Gross Weight
|
0.58 kg (1.27 lb)
|
