Dahua DH-SD4A425DB-HNY — 4 MP 25× Optical Zoom Compact Pro AI Network PTZ Camera WizSense (4-Series Starlight)

Description

WizSense PTZ · 4 MP · 25× Optical Zoom · Compact PTZDahua WizSense PTZ · 4 MP 25× Compact

Dahua DH-SD4A425DB-HNY — 4 MP 25× Optical Zoom Compact Pro AI Network PTZ Camera WizSense (4-Series Starlight)

The Dahua DH-SD4A425DB-HNY is the 4-Series compact WizSense PTZ — a project-grade 4 MP Starlight PTZ in a smaller, lighter form factor than the 5-Series flagship. Built around a 1/2.8" CMOS Starlight sensor capturing 2688 × 1520 at 25/30 fps. The 25× optical zoom lens with auto-focus delivers a wide 59° field down to a tight 3° pull at full zoom — identification-grade reach at 80–100 m. Built-in IR reaches up to 100 m; WDR is 120 dB; the metal housing is IP66 sealed. WizSense deep-learning Pro AI runs perimeter protection, Auto Tracking 3.0 and SMD 4.0. The smaller chassis suits installs where the flagship 5-Series is too heavy or where mounting clearance is limited — awnings, smaller poles, mid-rise commercial corners and project carparks. Backed by a 3-year Australian warranty through CCTV Guru. SKU SD4A425 series.

3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support

Why Choose the Dahua SD4A425DB-HNY Compact Pro AI PTZ

25× Optical Zoom in a Compact Body

True 25× optical zoom in a chassis that's smaller, lighter and cheaper than the 5-Series flagship. Ideal where the larger SD5A won't physically fit or the bracket budget is tight.

100 m Long-Range IR

Built-in IR array reaches up to 100 m at full zoom.

Auto Tracking 3.0

WizSense automatic person and vehicle tracking with pan/tilt/zoom follow.

Perimeter Protection (IVS)

Tripwire, intrusion, fast-moving, loitering, parking and people gathering with human/vehicle classification.

1/2.8" Starlight Sensor

Starlight sensor maintains usable colour at low ambient before IR engages.

Built-in Mic + Audio I/O

Built-in microphone, 1/1 audio I/O for two-way talk integration.

Important Install Note

Compact PTZs trade pure reach for mounting flexibility. For maximum 32× zoom and 150 m IR, use the 5-Series SD5A432GB-HNR. This 4-Series compact is the right choice for sites where the 5-Series is too big or budget too tight. Powered by High-PoE (802.3bt) or 24 VAC.

AI & Smart Detection

Auto Tracking 3.0

Automatic pan/tilt/zoom follow for people and vehicles.

Perimeter Protection (IVS)

Tripwire, intrusion, loitering, parking, people gathering.

SMD 4.0

Motion classification — humans and vehicles only.

Quick Pick & Smart Search

Event-type smart search via compatible Dahua NVRs.

255 Presets, 8 Patrols

Full preset/patrol/tour scheduling.

Two-Way Audio

Built-in mic + audio I/O.

Technical Specifications

Camera, Sensor & Optical Zoom
Model DH-SD4A425DB-HNY
Form Factor Compact network PTZ
Image Sensor 1/2.8" CMOS Starlight
Maximum Resolution 2688 × 1520 (4 MP)
Frame Rate 4 MP @ 25/30 fps
WDR 120 dB
Day / Night Auto (ICR) / Colour / B&W
Optical Zoom 25×
Focal Length 4.8–120 mm motorised vari-focal
Field of View H: 59°–3°
IR Illumination Up to 100 m
PTZ Performance
Pan Range 0°–360° continuous
Tilt Range −15° to +90° (auto-flip)
Presets 255
Patrols 8
Tours 5
Pro AI, Audio & Network
AI Engine WizSense PTZ Series
Auto Tracking Auto Tracking 3.0
IVS Tripwire · intrusion · loitering · parking (human/vehicle)
SMD SMD 4.0
Built-in Mic Yes
Audio I/O 1 in / 1 out
Alarm I/O 2 in / 1 out
Network Port RJ-45 (10/100)
Interoperability ONVIF (Profile S, G, T) · CGI
Storage Micro SD up to 256 GB
Mobile Client DMSS
Power, Environment & Build
Power Supply High-PoE (802.3bt) / 24 VAC
Operating Temperature −40 °C to +65 °C
Protection IP66
Casing Metal
Australian Warranty 3 Years (via CCTV Guru)

Recommended NVR Pairings

Dahua DHI-NVR5216-16P-AI/ANZ

View NVR5216-16P-AI →

Dahua DHI-NVR5432-AI/ANZ

View NVR5432-AI →

Dahua DHI-NVR5208-8P-AI/ANZ

View NVR5208-8P-AI →

Dahua DHI-NVR4216-16P-AI/ANZ

View NVR4216-16P-AI →

Frequently Asked Questions

NDAA compliant?

No.

Standard PoE?

No — High-PoE (802.3bt) or 24 VAC required.

Difference vs 5-Series SD5A432GB-HNR?

The 5-Series has 32× zoom (vs 25×), 150 m IR (vs 100 m) and a larger, IK10 vandal housing.

Auto Tracking?

Auto Tracking 3.0 follows people and vehicles.

IR range?

Up to 100 m at full zoom.

Audio?

Built-in mic + audio I/O.

Third-party VMS?

Yes — ONVIF Profile S, G, T.

Temperature?

−40 °C to +65 °C.

Mount height?

4–8 m for typical commercial installs.

Mobile viewing?

Yes — DMSS app with PTZ control.

Downloads

DH-SD4A425DB-HNY DatasheetDahua PTZ Camera Quick Start GuideDahua PTZ Camera Installation Manual

Order Your Dahua SD4A425DB-HNY from CCTV Guru

Compact PTZ — contact our team for site design. 3-year Australian warranty. cctvguru.com.au/pages/contact.
