| Mechanical |
| Dimensions |
442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
| Weight |
4.7 kg (10.4 lb) |
| Enclosure material |
Aluminium CNC, SGCC steel |
| Mount material |
SGCC steel |
| Hardware |
| Processor |
Quad-core ARM® Cortex®-A57 at 2.0 GHz |
| System memory |
8 GB DDR4 |
| On-board storage |
32 GB eMMC
Integrated 128 GB SSD |
| Management interface |
Ethernet
Bluetooth |
| Networking interface |
LAN:
(8) GbE RJ45 ports
(1) 10G SFP+ port
WAN:
(1) 2.5 GbE RJ45 port
(1) 10G SFP+ port |
| IDS/IPS throughput |
5 Gbps*
*Measured with iPerf3.
|
| Power method |
(1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz
(1) USP-RPS DC input,12V DC, 4.6A |
| Power supply |
AC/DC, internal, 100W |
| Supported voltage range |
100—240V AC |
| Max. power consumption |
60W |
| ESD/EMP protection |
Air: ± 15kV, contact: ± 8kV |
| LCM display |
(1) 1.3" touchscreen |
| Button |
Factory reset |
| Ambient operating temperature |
-10° to 40° C (14° to 104° F) |
| Ambient operating humidity |
5 to 95% noncondensing |
| Certifications |
CE, FCC, IC |
| Gateway Features |
| Performance |
Redundant WAN with failover and load balancing
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reporting |
| Next-generation security |
Application-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall |
| Advanced networking |
License-free SD-WAN
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and Identity VPN
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP support |
| LEDs |
| Ethernet |
Green: link/activity |
| SFP+ |
Green: link/activity |
| HDD |
White: disk activity
Amber: disk error |
| RPS |
Blue: ready |
