TP-Link VIGI NVR1004H-4P 4 Channel PoE+ Network Video Recorder

Description

TP-LINK VIGI · Network video recorder

TP-Link VIGI NVR1004H-4P 4 Channel PoE+ Network Video Recorder

Bring compatible IP camera feeds together in one 4-channel recorder for live monitoring, local recording and footage review.

Camera inputs
4 channels

4 channels is the listed capacity or connection for this model. Plan the connected cameras and network equipment around this specification.

Recording storage
1 SATA bay

The listed storage configuration is 1 SATA bay. Required retention depends on camera count, bitrate and recording schedule; check drive compatibility before purchase.

Connectivity
4 PoE+ ports

4 PoE+ ports is the listed capacity or connection for this model. Plan the connected cameras and network equipment around this specification.

Input bandwidth
80 Mbps

80 Mbps is the listed capacity or connection for this model. Plan the connected cameras and network equipment around this specification.

Designed for your installation

One place to review footage

Manage connected cameras and review recorded events through the VIGI recording system.

Give each camera a clear location name and check that the recorder time is correct. After commissioning, record a short test event and practise locating and exporting it so the system is ready when footage is needed.

Plan the camera network

Built-in PoE+ ports carry camera power and data. Keep the combined camera load within the 53W total budget.

Map the camera connections back to the recorder and router before running cables. Check the combined camera bitrate against the listed incoming bandwidth, leaving capacity for the stream settings you intend to use.

Storage you can size

Use compatible surveillance hard drives and size retention around camera count, bitrate and recording schedule. Recording duration is not a fixed number of days.

Higher bitrates, more cameras and longer recording schedules use more disk space. Decide how long footage needs to be retained, select a compatible surveillance drive and verify the recording schedule after setup.

Technical specifications

Model

VIGI NVR1004H-4P

IP camera channels

4

Incoming bandwidth

80 Mbps

Internal storage

1 SATA bay

Video outputs

HDMI and VGA

Video compression

H.265+ / H.265 / H.264+ / H.264

Integrated camera PoE

4 ports; 53W total

Remote management

VIGI app / compatible VIGI management software

Before you install

  • Hard drive not included with this standalone recorder; add a compatible surveillance HDD.
  • Check camera codec, resolution, decoding load and ONVIF feature support before mixing devices.
  • HDD capacity support varies by hardware version and firmware; check the current compatibility list before buying a drive.
  • PoE budget: 53W total. The per-port limit and combined limit both apply.

Questions answered

Does it include a hard drive?

Hard drive not included with this standalone recorder; add a compatible surveillance HDD.

Will it power my cameras?

Built-in PoE+ ports carry camera power and data. Keep the combined camera load within the 53W total budget.

How long will it record?

Retention depends on drive capacity, camera count, bitrate, frame rate and recording mode. Size the drive for your required retention.

Specifications checked against TP-Link NVR1004H-4P. Features and storage compatibility can vary by hardware revision and firmware; check the supplied unit when planning a system.

Official videos & downloads

Use the official resources below to plan installation and configure your system. Select the hardware version printed on the device before downloading firmware or applying version-specific instructions.

How to Upgrade NVR Firmware

Open this official video on YouTube
VIGI NVR1004H-4P V1 DatasheetVIGI NVR1004H-4P(UN) V1 Installation GuideVIGI App User GuideNVR1004H-4P manuals, firmware & all downloads
