TP-Link VIGI NVR1104H-4P 4-Channel PoE+ Network Video Recorder
The TP-Link VIGI NVR1104H-4P is a compact, easy-to-deploy 4-channel PoE+ network video recorder designed for small businesses and residential installations across Australia. With 4K HDMI output, plug-and-play VIGI camera support, and up to 10TB of local storage, it delivers professional-grade surveillance without the complexity.
Key Features
-
4K HDMI Output & 16MP Decoding — Displays sharp footage up to 8MP resolution across a 4-channel layout, ensuring no detail is missed.
-
4 × PoE+ Ports (53W Budget) — Powers and connects up to four IP cameras over a single Ethernet cable per camera — no separate power adapters required.
-
Plug & Play Camera Setup — New VIGI IP cameras are detected and activated automatically, making installation fast and straightforward.
-
4-Channel Simultaneous Playback — Review footage from all four cameras at once, with variable playback speed and event-based timeline navigation.
-
24/7 Continuous Recording — Supports up to 10TB HDD storage for uninterrupted, long-term footage retention.
-
H.265+ Compression — Reduces storage and bandwidth consumption without sacrificing image quality.
-
ONVIF Compatible — Integrates with VIGI and third-party ONVIF-compliant IP cameras for flexible system design.
-
Two-Way Audio — Built-in speaker and voice intercom support enable real-time communication through compatible cameras.
-
Remote Monitoring — Manage live feeds, playback, and alerts via the VIGI app, web UI, or VIGI Security Manager from anywhere.
-
Flexible Mounting — Install wall-mounted, flat on a desk, or under a desk to suit your site layout.
Use Cases
- Small retail stores, cafés, and restaurants needing a simple, reliable recorder
- Warehouses and storage facilities requiring 24/7 continuous recording
- Small offices and financial institutions with up to four camera positions
- Residential properties upgrading from analogue DVR to IP-based surveillance
- Installers building cost-effective VIGI end-to-end systems for clients
Technical Specifications
| Specification |
Detail |
| Model |
VIGI NVR1104H-4P |
| Video Channels |
4 |
| Max Recording Resolution |
Up to 8MP |
| Decoding Capacity |
16MP (e.g. 4 × 4MP) |
| Video Output |
1 × HDMI (4K), 1 × VGA |
| PoE Ports |
4 × 10/100Mbps PoE+ (IEEE 802.3at) |
| PoE Budget |
53W total / 30W per port |
| Network Port |
1 × RJ45 10/100Mbps (uplink) |
| HDD Bays |
1 × SATA (up to 10TB, HDD not included) |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 |
| Simultaneous Playback |
4 channels |
| Audio |
Built-in speaker; two-way audio via compatible cameras |
| USB Ports |
2 × USB 2.0 |
| ONVIF |
Profile S |
| Remote Access |
VIGI App, Web UI, VIGI Security Manager |
| Operating Temperature |
0°C to 40°C |
| Power Input |
100–240V AC, 50/60Hz |
| Dimensions |
200 × 200 × 45 mm |
| Weight |
Approx. 1.38 kg |
| Warranty |
2 Years |
Recommended Accessories
-
TP-Link VIGI C540 4MP Pan Tilt Camera — Full-colour outdoor PTZ camera, plug-and-play compatible with this NVR.
-
TP-Link VIGI C300 Series Cameras — Cost-effective indoor/outdoor fixed cameras for completing a 4-channel system.
-
3.5" SATA Hard Drive (up to 10TB) — Required for local recording; choose a surveillance-rated HDD (e.g. Seagate SkyHawk or WD Purple).
-
Cat6 Ethernet Cable — For reliable PoE data and power delivery to each connected camera.
-
HDMI Monitor or TV — For local live view and playback via the 4K HDMI output.
Downloads
Frequently Asked Questions
Does the NVR1104H-4P come with a hard drive?
No. The NVR supports one 3.5" SATA HDD up to 10TB, which must be purchased separately. A surveillance-rated drive such as the Seagate SkyHawk or WD Purple is recommended for 24/7 operation.
Can I use non-TP-Link cameras with this NVR?
Yes. The NVR1104H-4P supports ONVIF Profile S, allowing basic integration with compatible third-party IP cameras. For full smart detection, plug-and-play setup, and two-way audio, TP-Link VIGI cameras are recommended.
How many cameras can I connect?
Up to four IP cameras can be connected — one per PoE+ port. All four can record simultaneously and be viewed in a split-screen layout.
Can I access footage remotely?
Yes. Remote access is available via the free VIGI mobile app (iOS and Android), a web browser UI, or the VIGI Security Manager desktop software.
What is the maximum PoE power per port?
Each PoE+ port supports up to 30W, with a total system budget of 53W across all four ports. This is sufficient for most VIGI cameras including pan tilt models.
Is this NVR suitable for outdoor installation?
The NVR itself is designed for indoor use. It should be installed in a sheltered, ventilated location. The connected cameras handle outdoor exposure.
