Hikvision M Series · 8K · 64 Channel · 2U Enterprise
The Hikvision DS-9664NI-M8 is Hikvision's flagship 64-channel M Series 8K Network Video Recorder — built for serious Australian enterprise sites where one recorder needs to manage every camera in a building, campus, depot or multi-site backbone. 64 IP camera inputs, 400 Mbps incoming bandwidth, 8 SATA bays for up to 128 TB, RAID-grade redundancy and 4 simultaneous display outputs (2 × HDMI + 2 × VGA) make this the recorder you specify when downtime, footage loss or "we ran out of channels" are not on the table.
This is a non-PoE enterprise chassis — designed for sites that already run a managed PoE switch backbone (or non-PoE camera infrastructure like fibre or wireless backhaul). Pair it with any of Hikvision's enterprise managed switches or third-party PoE infrastructure, then let the M8 handle recording, AI processing, multi-monitor display, RAID redundancy and centralised management for all 64 channels.
Channels
64 CH · Up to 32 MP
Bandwidth
400 Mbps Incoming
Display
2 × HDMI · 2 × VGA
Storage
8 × SATA · Up to 128 TB
Why 64 channels in one chassis matters
Most large Australian sites running 50–60 cameras end up with two 32-channel NVRs — which means two devices to commission, two firmware update cycles, two user databases, two playback interfaces, and two separate footage archives that have to be cross-referenced when an incident spans multiple cameras. The DS-9664NI-M8 collapses all of that into a single 2U chassis: one recorder, one login, one timeline, one search. It's the difference between managing a security system and fighting one.
64-Channel 32 MP Input
Every channel supports cameras up to 32 MP — mix PanoVu, fisheye, ColorVu and 4K+ AcuSense cameras across a single NVR without throttling resolution or frame rate.
400 Mbps Incoming Bandwidth
Comfortably runs a full deployment of 4K H.265+ cameras across all 64 channels simultaneously — no bottlenecks, no compromise on framerate or bitrate.
Octa-SATA, 128 TB Capacity
Eight internal SATA bays accept enterprise-grade surveillance HDDs up to 16 TB each, delivering month-long retention even with all 64 cameras at full 4K bitrates.
Dual HDMI + Dual VGA
Four independent display outputs — HDMI 1 drives a true 8K monitor, HDMI 2 a 4K monitor, plus two independent VGA workstations. Perfect for multi-operator control rooms.
RAID 0 / 1 / 5 / 6 / 10
Configure RAID across the 8 SATA bays to balance capacity, redundancy and performance. RAID 5 or 6 protects footage from single or dual drive failure without operator intervention.
AcuSense Smart Detection
When paired with AcuSense cameras, the NVR runs deep-learning human and vehicle classification across all 64 channels — filtering false alarms and making playback searches fast.
Watch the M Series 8K NVR in action
AcuSense NVR + Standard Camera — Smart False-Alarm Filtering
Hikvision AcuSense — Installation & Operation Guide
Engineered for Australian enterprise & multi-site projects
Every M Series NVR sold by CCTV Guru ships from our Australian warehouse with local stock, local firmware, and full Australian Hikvision warranty. The DS-9664NI-M8 operates reliably from −10 °C to 55 °C, accepts standard 100–240 V AC mains, ships with rack-mount ears for a standard 19" rack, and is purpose-built to handle the heat, humidity and dust typical of Australian commercial, industrial and outdoor-adjacent sites.
Hik-Connect & Hik-Central
Free remote viewing on Hik-Connect, or integrate into a Hik-Central Pro VMS for centralised management across multiple sites and multiple NVRs.
ONVIF Compatible
Pairs with third-party ONVIF cameras as well as the full Hikvision IP range, giving you flexibility for hybrid and multi-vendor enterprise sites.
Dual Gigabit Ethernet
Two independent self-adaptive Ethernet ports for network redundancy, load balancing or dual-network segregation (camera VLAN vs viewing VLAN).
Smart Playback & Search
Search recordings across all 64 channels by face, human, vehicle, line-crossing or intrusion event — days of footage reviewed in seconds.
Full technical specifications
Hikvision M Series NVR — DS-9664NI-M8
| Model |
DS-9664NI-M8 |
| Series |
Hikvision M Series 8K NVR (Ultra Series) |
| Form Factor |
2U Rack-Mount (19" rack-mount ears included) |
| Video Inputs |
64-channel IP, up to 32 MP per channel |
| Incoming Bandwidth |
400 Mbps |
| Outgoing Bandwidth |
400 Mbps |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 |
| Decoding Capability |
2-ch @ 32 MP (30 fps) + 2-ch @ 8 MP (30 fps) · 10-ch @ 8 MP · 20-ch @ 4 MP · 40-ch @ 1080p |
| Recording Resolution |
32 MP / 24 MP / 12 MP / 8 MP / 7 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA |
| Synchronous Playback |
Up to 16 channels @ 1080p |
| HDMI 1 Output |
8K (7680 × 4320) @ 30 Hz · 4K @ 60 Hz · 2K · 1920 × 1080 @ 60 Hz |
| HDMI 2 Output |
4K (3840 × 2160) @ 60 Hz · 2K · 1920 × 1080 @ 60 Hz · independent source from HDMI 1 |
| VGA Outputs |
2 × 1920 × 1080 @ 60 Hz (independent sources) |
| Audio In / Out |
1-ch RCA in · 2-ch RCA out |
| Smart Function |
AcuSense — Human/Vehicle classification, perimeter protection, facial detection (with compatible cameras) |
| Network Interface |
2 × RJ45 10/100/1000 Mbps Self-Adaptive Ethernet |
| PoE Interfaces |
None (non-PoE chassis — use external managed PoE switch) |
| Network Protocols |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS, ONVIF, OTAP |
| HDD Bays |
8 × SATA, up to 16 TB per drive (128 TB total capacity) |
| eSATA |
1 × eSATA for additional storage expansion |
| RAID |
RAID 0, 1, 5, 6, 10 supported |
| USB Interfaces |
2 × USB 3.0 (front and rear) |
| Alarm In / Out |
16 in / 4 out |
| Power Supply |
100–240 V AC, 50/60 Hz |
| Power Consumption |
≤ 35 W (without HDD) |
| Working Temperature |
−10 °C to 55 °C |
| Working Humidity |
10% – 90% |
| Dimensions (W × D × H) |
445 × 470 × 90 mm |
| Weight (without HDD) |
≤ 8 kg |
| Mobile Apps |
Hik-Connect, Hik-Central, iVMS-4200 |
| Australian Warranty |
3 Years — CCTV Guru / Hikvision Australia |
Downloads & resources
Download official Hikvision documents for setup, specifications, and recorder details.
Frequently asked questions
Does the DS-9664NI-M8 have built-in PoE?
No — this is a non-PoE enterprise chassis. It's designed for sites that already run a managed PoE switch backbone. If you need built-in PoE for some channels, look at the DS-7732NI-M4/24P (32-channel, 24 PoE) as a sibling option.
Does it come with hard drives?
The recorder ships as a chassis only. CCTV Guru offers pre-fitted Seagate SkyHawk, WD Purple or enterprise-grade Exos drives from 8 TB up to 16 TB per bay — choose your RAID-ready configuration at checkout.
What RAID levels are supported?
RAID 0, 1, 5, 6 and 10 are all supported across the 8 SATA bays. For most enterprise deployments we recommend RAID 5 (single drive redundancy) or RAID 6 (dual drive redundancy) — both protect footage if a drive fails.
Can it really output 8K and 4K at the same time?
Yes — HDMI 1 outputs true 8K (7680×4320) @ 30 Hz, and HDMI 2 outputs 4K @ 60 Hz, from independent sources. With the addition of two independent VGA outputs, you can run up to four monitors at once from a single NVR.
Is it rack-mountable?
Yes — the 2U chassis is designed for 19" racks and ships with rack-mount ears. Fits standard server, comms or AV racks at 90 mm height.
