Description
The Ubiquiti U7 Pro Wall is a high-performance wall-mounted WiFi 7 access point, ideal for modern homes and high-density networks. Featuring 6 spatial streams, support for the 6 GHz band, a 2.5 GbE uplink and the capacity to manage 300+ devices, it brings future-ready wireless connectivity into a sleek wall-mount form factor.
Key Features
- WiFi 7 (802.11be) with support for the 6 GHz band — modern, high-speed wireless
- 6 spatial streams for enhanced throughput and capacity
- Wall-mounted design ideal for homes or offices, covering ~140 m² with support for 300+ devices
- 2.5 GbE uplink for high-performance wired backhaul
- PoE+ powered — simple installation and clean setup
- Sleek form-factor, integrates with the UniFi ecosystem for advanced management
Technical Specifications
| Dimensions |
150 × 103 × 36 mm (5.9 × 4.1 × 1.4") |
| Weight |
580 g (1.3 lb) |
| WiFi Standard |
802.11be (WiFi 7) with 6 spatial streams |
| Coverage Area |
Approx. 140 m² (1,500 ft²) |
| Max Client Count |
300+ devices |
| Uplink Interface |
1 × 1/2.5 GbE RJ-45 port |
| Power Method |
PoE+ (44‒57 V DC) |
| Max Power Consumption |
22 W |
| Operating Temperature |
-30 °C to 60 °C |
| Certifications |
CE, FCC, IC – NDAA compliant |
More Information
U7-Pro-Wall Installation Guide
