Ubiquiti UniFi · NDAA COMPLIANT
Next-Gen Outdoor Connectivity with Enterprise WiFi 7 Performance
Engineered for expansive outdoor campus environments, sprawling industrial yards, and high-density public venues, the Ubiquiti U7 Pro Outdoor delivers uncompromising wireless speeds and bulletproof reliability. Harnessing cutting-edge WiFi 7 technology alongside flexible configuration options, this all-weather access point shatters traditional throughput barriers to ensure seamless client roaming across demanding open-air enterprise deployments.
WiFi Standard
WiFi 7 Tri-Band
Spatial Streams
6 Streams Total
Wired Uplink
2.5 GbE RJ45 Port
Weather Rating
IP67 All-Weather
Advanced Architecture & Software-Switchable Antennas
Equipped with a highly versatile design, the U7 Pro Outdoor incorporates a software-switchable antenna system allowing network administrators to toggle effortlessly between an integrated directional super antenna and an omnidirectional pattern. Managed centrally through the robust UniFi Network application platform, this unit features advanced security layers including guest network isolation, RadSec protocol support, and dynamic VLAN assignments to protect institutional workflows.
Software-Configurable Coverage
Adapt instantly to changing site layouts by switching between targeted long-range directional focus and wide-area omnidirectional distribution directly from the controller software.
Extreme Climate Durability
Housed inside a UV-stabilized polycarbonate enclosure carrying an IP67 rating, it functions seamlessly across extreme ambient temperatures ranging from -30°C to 60°C.
Technical Specification Matrix
| Model |
U7-Pro-Outdoor |
| WiFi Standard |
802.11be (WiFi 7) |
| Spatial Streams |
6 Streams Total (2.4 GHz: 2x2, 5 GHz: 4x4) |
| Networking Interface |
(1) 1/2.5 GbE RJ45 Port |
| Power Method |
PoE+ (42.5–57V DC) |
| Max. Power Consumption |
21W |
| Enclosure Rating |
IP67 Weatherproof |
| Compliance |
NDAA Compliant, FCC, IC |
What power injector or switch is required to run the U7 Pro Outdoor?
The unit is powered via standard PoE+ (42.5–57V DC) requiring a maximum power budget of 21W, making it compatible with any standard UniFi PoE+ switch or certified power injector.
Is this hardware model NDAA compliant for government deployments?
Yes, the U7 Pro Outdoor is fully NDAA compliant, rendering it fully eligible for federal, state, educational, and corporate enterprise installations requiring strict regulatory compliance.
How do I switch between directional and omnidirectional modes?
Antenna configurations can be managed and switched dynamically straight from the UniFi Network software management interface without requiring physical alterations to the hardware unit.
What software version is required for initial device adoption?
The access point requires UniFi Network application version 9.0.114 or later for seamless setup, telemetry tracking, and advanced policy configuration.
