Ubiquiti UniFi Network · NDAA COMPLIANT
High-Capacity Outdoor WiFi 6 Access Point with Super-Gain Antenna
Engineered for expansive outdoor environments, sports stadiums, open-air venues, and enterprise campuses, the Ubiquiti U6-Mesh-Pro is a high-performance, outdoor-rated WiFi 6 mesh access point. Built with an integrated high-gain antenna system, it delivers extended wireless coverage range and high multi-user client density, providing robust dual-band WiFi 6 performance managed centrally via UniFi Network.
Wireless Tech
Dual-Band WiFi 6
Antenna System
Super-Gain Long Range
Weather Rating
IPX5 Weatherproof
Compliance
NDAA Compliant
Seamless Wireless Meshing & All-Weather Reliability
The U6-Mesh-Pro is specifically constructed to withstand challenging outdoor elements, featuring an IPX5-rated weather-resistant enclosure. Equipped with dual Gigabit Ethernet ports with PoE input and passthrough, it allows flexible wall, pole, or mast mounting, seamlessly meshing with adjacent access points to extend wireless signals without running dedicated cable lines to every node.
High-Capacity WiFi 6 Throughput
Supports OFDMA and 4x4 MU-MIMO technology to maintain optimal wireless performance across hundreds of connected client devices simultaneously.
License-Free UniFi Controller Integration
Configure SSID isolation, guest portals, captive networks, and RF channel maps effortlessly with no subscription fees using UniFi Network.
Technical Specification Matrix
| Model |
U6-Mesh-Pro |
| Wi-Fi Standards |
WiFi 6 (802.11ax) / WiFi 5 (802.11ac) |
| Operating Bands |
2.4 GHz & 5 GHz Dual-Band High-Gain Arrays |
| Network Interfaces |
(2) Gigabit Ethernet Ports (PoE Input & Passthrough) |
| Power Method |
Power over Ethernet (802.3at PoE+ Required) |
| Enclosure Protection |
IPX5 Weatherproof Rated Enclosure |
| Mounting Hardware |
Wall and Pole Mount Kit Included |
| Management Platform |
UniFi Network Application Suite |
| Compliance |
NDAA Compliant |
Is the U6-Mesh-Pro suitable for outdoor rain and weather exposure?
Yes, the U6-Mesh-Pro features an IPX5-rated weatherproof casing designed specifically for full outdoor installation.
Does the U6-Mesh-Pro require an Ethernet cable for uplink?
While a wired connection delivers maximum speed, it can also connect wirelessly via UniFi Mesh backhaul to nearby UniFi access points.
Is the Ubiquiti U6-Mesh-Pro NDAA compliant?
Yes, the U6-Mesh-Pro is fully NDAA compliant and ready for government, corporate, and commercial deployments.
What mounting hardware is included with the U6-Mesh-Pro?
The package includes heavy-duty mounting hardware for both flat wall and round pole/mast installations.
