DAHUA · IP SECURITY CAMERASDahua DH-IPC-HFW5842E-ZE-S3 8MP 4K WizMind Motorised Bullet Camera
Capture detailed 4K surveillance with a lens that can be matched to the scene. The Dahua DH-IPC-HFW5842E-ZE-S3 pairs an 8MP sensor with a 2.7–12 mm motorised lens, DeepLight imaging and up to 60 m IR for professional IP CCTV installations.
Resolution
8MP, 3840 × 2160
Lens
2.7–12 mm motorised varifocal
Image technology
WizMind S, DeepLight
Night vision
IR up to 60 m
Designed for your installation
WizMind analytics and AcuPick support suit customers who need to locate relevant events efficiently on a compatible recorder. The IP67 and IK10 enclosure provides weather and impact protection when the camera and cable junctions are installed correctly.
Search
AcuPick with compatible Dahua system
Intelligent perimeter analysis
Built-in microphone, 1 audio input and 1 output
Technical Specifications
| Model |
DH-IPC-HFW5842E-ZE-S3 |
| Resolution |
8MP, 3840 × 2160 |
| Lens |
2.7–12 mm motorised varifocal |
| Image technology |
WizMind S, DeepLight |
| Night vision |
IR up to 60 m |
| Dynamic range |
120 dB WDR |
| Search |
AcuPick with compatible Dahua system |
| Analytics |
Intelligent perimeter analysis |
| Audio |
Built-in microphone, 1 audio input and 1 output |
| Alarm interface |
2 inputs, 1 output |
| Storage |
microSD up to 1 TB, sold separately |
| Power |
12 VDC or compatible PoE, ePoE support |
| Protection |
IP67 and IK10 |
Setup and compatibility
This is an IR model: do not expect a permanently illuminated full-colour view in darkness. Select a suitable lens setting and recording bitrate during commissioning. Smart-search functions depend on camera, recorder and firmware compatibility.
Downloads
DH-IPC-HFW5842E-ZE-S3 Datasheet (PDF)
Frequently asked questions
Can DH-IPC-HFW5842E-ZE-S3 record to a microSD card?
Yes. microSD up to 1 TB, sold separately. The card is separate; configure recording and retention for the installation.
What should I check before installation?
This is an IR model: do not expect a permanently illuminated full-colour view in darkness. Select a suitable lens setting and recording bitrate during commissioning. Smart-search functions depend on camera, recorder and firmware compatibility.
Where can I download the DH-IPC-HFW5842E-ZE-S3 datasheet?
The manufacturer PDF is hosted on CCTV Guru’s Shopify file library and linked in Downloads on this product page.
