WizSense PTZ · 4 MP · 32× Optical Zoom · 150 m IRDahua WizSense PTZ · 4 MP 32× ZoomDahua DH-SD5A432GB-HNR — 4 MP 32× Optical Zoom Pro AI Network PTZ Camera WizSense (5-Series, 150 m IR) The Dahua DH-SD5A432GB-HNR is a project-grade 4 MP WizSense PTZ camera — built around a 1/2.8" STARVIS CMOS sensor capturing 2688 × 1520 at 25/30 fps. The 32× optical zoom lens with auto-focus delivers a wide 62° field at the wide end down to a tight 2° pull at full zoom — sufficient to read a number plate at well over 150 m. Built-in IR reaches up to 150 m at full zoom for long-range night surveillance; WDR is 120 dB; the metal housing is IP67 sealed and IK10 vandal-rated. WizSense deep-learning Pro AI runs perimeter protection, Auto Tracking 3.0, SMD 4.0 and event-based pre-record. Built-in 7/2 alarm I/O, 1/1 audio I/O. Pan-tilt-zoom controlled via DMSS, Dahua DSS or any third-party ONVIF VMS. Built for project-grade Australian deployments — carparks, council reserves, sports fields, mine sites, freight yards, school grounds and any large open space where one PTZ replaces many fixed cameras. Backed by a 3-year Australian warranty through CCTV Guru. SKU SD5A432 series. 3-Year AU Warranty Fast AU-Wide Shipping AU Tech Support Why Choose the Dahua SD5A432GB-HNR Pro AI PTZ 32× Optical Zoom — ANPR-Grade Reach Optical zoom at 32× resolves licence plates at over 150 m. Wide-to-tight surveillance from a single PTZ install — no need for paired wide-angle plus telephoto cameras. 150 m IR Long-Range Night Built-in IR array reaches up to 150 m at full zoom — among the longest IR ranges of any PTZ in its class. Auto Tracking 3.0 WizSense Auto Tracking 3.0 detects and follows people and vehicles automatically — the PTZ stays locked on the target across pan/tilt/zoom moves until the target leaves the protected zone. Perimeter Protection (IVS) Tripwire, intrusion, fast-moving, loitering, abandoned/missing object, parking detection and people gathering — all with human/vehicle classification on the WizSense chip. SMD 4.0 Smart Motion Motion alerts triggered only by humans and vehicles — critical for outdoor PTZ deployments where pan tours generate constant motion. Built-in Mic + Audio + 7/2 Alarm I/O Built-in microphone, 1/1 audio I/O and 7/2 alarm I/O for full integration with third-party intercom, public address, perimeter alarms and gate-control systems. Important Install Note This is a true PTZ — pan-tilt-zoom controlled via DMSS, Dahua DSS or any third-party ONVIF VMS. Pair with a Dahua AcuPick AI NVR for end-to-end smart search of recorded video. The 32× optical zoom is best mounted high (pole or building-corner, 6–10 m above ground level) for unobstructed sight lines. Powered by High-PoE (802.3bt) or 24 VAC — NOT standard 802.3af PoE. AI & Smart Detection Auto Tracking 3.0 WizSense-powered automatic person and vehicle tracking with pan/tilt/zoom follow. Perimeter Protection (IVS) Full IVS library — tripwire, intrusion, fast-moving, loitering, abandoned/missing object, parking detection, people gathering. Quick Pick & SMD 4.0 Quick smart search via compatible Dahua NVRs; SMD 4.0 motion classification for humans and vehicles. Heat Map & People Counting Compatible with Dahua heat map and people counting analytics. Preset Tour + Privacy Masking 300 presets, 8 patrols, 5 tours with privacy masking for sensitive zones. Two-Way Audio Built-in mic + 1/1 RCA audio I/O. Technical Specifications Camera, Sensor & Optical Zoom Model DH-SD5A432GB-HNR Form Factor Network PTZ (SD chassis) Image Sensor 1/2.8" CMOS STARVIS Maximum Resolution 2688 × 1520 (4 MP) Frame Rate 4 MP @ 25/30 fps WDR 120 dB Day / Night Auto (ICR) / Colour / B&W Optical Zoom 32× Focal Length 5.5–176 mm motorised vari-focal Field of View H: ~62° — 2° IR Illumination Up to 150 m PTZ Performance Pan Range 0°–360° continuous Tilt Range −15° to +90° (auto-flip) Pan Speed Up to 280°/s Presets 300 Patrols 8 Tours 5 Pro AI, Audio & Network AI Engine WizSense PTZ Series Auto Tracking Auto Tracking 3.0 IVS Tripwire · intrusion · loitering · parking · people gathering (human/vehicle) SMD SMD 4.0 Built-in Mic Yes Audio I/O 1 in / 1 out (RCA) Alarm I/O 7 in / 2 out Network Port RJ-45 (10/100) Interoperability ONVIF (Profile S, G, T) · CGI Storage Micro SD up to 512 GB Mobile Client DMSS Power, Environment & Build Power Supply High-PoE (802.3bt) / 24 VAC Operating Temperature −40 °C to +60 °C Protection IP67 · IK10 vandal Casing Metal Australian Warranty 3 Years (via CCTV Guru) Typical Applications Carparks & Sports Fields 32× zoom covers a full carpark or sporting field from a single mount. Council Reserves & Town Centres Wide-area situational awareness with PTZ tracking for incident response. Freight Yards & Mine Sites Long-range perimeter monitoring with 150 m IR for night operations. School Grounds & Government Sites One PTZ replaces 4–6 fixed cameras for full coverage with detail-on-demand. Recommended NVR Pairings Dahua DHI-NVR5216-16P-AI/ANZ View NVR5216-16P-AI → Dahua DHI-NVR5432-AI/ANZ View NVR5432-AI → Dahua DHI-NVR5208-8P-AI/ANZ View NVR5208-8P-AI → Dahua DHI-NVR4216-16P-AI/ANZ View NVR4216-16P-AI → Frequently Asked Questions NDAA compliant? No. Will standard PoE run it? No — requires High-PoE (802.3bt) or 24 VAC. Plan a PoE++ injector or compatible NVR/switch. Auto Tracking 3.0? WizSense automatic pan-tilt-zoom follow for people and vehicles — locks on and tracks the target. Number plate reading? At 32× optical zoom, licence plates are readable at well over 150 m under daylight; ANPR-grade detail requires proper alignment and lighting. IR range? Up to 150 m at full zoom. Audio? Built-in mic + RCA audio I/O. Third-party VMS? Yes — ONVIF Profile S, G, T. Mount height? 6–10 m for unobstructed sight lines. Temperature? −40 °C to +60 °C alpine-rated. Mobile viewing? Yes — DMSS app with PTZ control. Downloads DH-SD5A432GB-HNR DatasheetDahua PTZ Camera Quick Start GuideDahua PTZ Camera Installation Manual Order Your Dahua SD5A432GB-HNR from CCTV Guru PTZ deployments need design input — please contact our project team to discuss site, mounting, networking and NVR sizing. 3-year Australian warranty. cctvguru.com.au/pages/contact.

Read more less

WizSense + AcuPick · 5-Series · 32-Channel · 16-PoE · 4-HDD32CH PoE NVR The Dahua DHI-NVR5432-16P-AI/ANZ is a 32-channel 5-Series WizSense AI NVR with 16 built-in PoE+ ports (ports 1–8 ePoE-capable up to 800 m), four SATA bays, dual Gigabit NICs, dual HDMI + dual VGA outputs, and a 1.5U rack chassis built for enterprise installs. AcuPick runs across all 32 channels, recording up to 32 MP per camera, scaling storage to 80 TB on-board (plus eSATA and iSCSI expansion), and driving a control-room wall up to 36 channels on the main monitor. This is the official Australia / NZ-market SKU (the AI/ANZ suffix). It's the all-in-one option in our 5-Series 32-channel range — sixteen cameras plug straight into the back of the recorder, the remaining sixteen come in via an external PoE switch on the network. Internal 100–240 VAC universal PSU, AS/NZS-compliant kettle cord, and a local 3-year warranty backed by CCTV Guru in Sydney. 16 PoE+ ports — 8 with ePoE up to 800 m PoE Ports 16 × 10/100 · IEEE 802.3af/at · 1–8 ePoE PoE Budget 150 W total · up to 25.5 W per port 16 cameras plug straight in Each Cat6 run carries power and video back to the NVR — no power adaptors at every camera, no PoE switch in the rack for the first 16 channels. Sixteen more cameras come in via your existing network for the full 32-channel licence. ePoE on ports 1–8 (up to 800 m) Extended PoE on the first 8 ports — 100 Mbps up to 300 m, or 10 Mbps up to 800 m on Cat6. Eliminates intermediate switches and fibre runs on long perimeter, carpark or warehouse runs. Powers PoE+ cameras 25.5 W per port (PoE+ / 802.3at) handles IR-heavy bullets, mini PTZs, multi-sensor cameras and active-deterrence units. 150 W total — plan for ~9 W average per camera across all 16 ports. Scales beyond 16 via network The licence supports up to 32 IP cameras — sixteen on the built-in PoE, sixteen via an external PoE switch or network. Mix Dahua WizSense IPCs and any ONVIF camera you already own. AcuPick on all 32 channels — enterprise-scale search AcuPick Channels Up to 32 ch · 1 event / channel / sec Search Method Image + attribute · front + back AI Search by reference image Click any person or vehicle in recorded video, hit AcuPick, and the NVR scans all 32 channels for matches across hours or days — clothing colour, body shape, vehicle make / model / colour / direction included. Front- + back-end intelligence Camera-side AI extracts target attributes during recording; NVR-side AI runs the comparison. Higher accuracy than recorder-only search and orders of magnitude faster than human review. Investigations finish in minutes Find a suspect across 32 cameras and three weeks of footage in a single search. Especially valuable for police investigations, insurance disputes, and post-incident review. Beyond Quick Pick AcuPick is the next generation of Dahua's Quick Pick — more attributes, more accuracy, and supports both people and vehicles natively. Exclusive to the 5-Series NVR family. 5-Series WizSense AI — depth at scale Industrial AI Chip Full 5-Series feature set at 32-ch Face Database 20 databases · 20,000 images Face Recognition (16-ch image stream) 16 channels of camera-side face detection feeding NVR-side recognition at 16 face snapshots/sec — ideal for entry / exit and high-footfall installs. Twenty face databases, 20,000 images, full attribute filtering. Perimeter Protection (4 ch by NVR) 4 NVR-side channels of tripwire and intrusion analytics (10 IVS rules each), plus all-channel perimeter via camera-side processing — every camera benefits from human/vehicle classification. SMD Plus (8 ch by NVR) 8 NVR-side SMD Plus channels plus all-channel camera-side SMD — deep-learning second-pass classification on every camera, cutting false alarms across the entire site. ANPR by camera (all channels) Pair with Dahua ANPR cameras for full 32-channel licence-plate recognition feeding a 20,000-plate database with blocklist / allowlist control. Carpark, fleet yard, gate management, even multi-site ANPR. Video Metadata search 8 channels of camera-side metadata extraction — top colour, bottom colour, hat, bag, umbrella, gender, age, vehicle make / model / colour / plate, helmet wear and more. N+M cluster failover Pair multiple 5-Series NVRs in an N+M cluster — backup recorders automatically take over if a primary fails, ensuring zero footage loss for sites where downtime isn't an option. See AcuPick in action Dahua AcuPick — Video search technology demonstration AcuPick — how to configure and search on a Dahua NVR 32 MP recording · dual HDMI · 80 TB on-board storage Up to 32 MP per channel True 8K-class input — supports Dahua's highest-resolution cameras, plus 24 MP, 16 MP, 12 MP, 8 MP (4K), 6 MP, 5 MP and 4 MP IP cameras from any ONVIF brand. 2× HDMI + 2× VGA outputs Two independent HDMI heads (each up to 4K) with two mirrored VGAs — drive a multi-monitor control room with independent layouts on each screen. Heterogeneous video routing on HDMI1/HDMI2. 36-channel split on main screen Main monitor supports 1 / 4 / 8 / 9 / 16 / 25 / 36-split layouts (sub monitor up to 16). Drive a wall of thumbnails or zoom on critical channels. 4 SATA bays · up to 80 TB Four surveillance-grade HDDs (WD Purple, Seagate SkyHawk) up to 20 TB each — months of 32-channel recording without touching network storage. eSATA + iSCSI expansion External SATA archive port plus iSCSI network-storage support — scale beyond 80 TB without rebuilding the recorder. RAID-style protection via disk groups. 32-channel 1080p decoding Decode 32 1080p tiles simultaneously for the live wall, or mix and match — 8 × 8 MP, 4 × 16 MP, 2 × 32 MP, or 24 × 1080p with AI on. Enterprise I/O — dual NIC, 16 alarm-in, 12V output Dual Gigabit NICs Two independent RJ-45 Gigabit ports with multi-address, load-balance and fault-tolerance bonding modes — segregate camera VLAN from management VLAN, or run an active-passive failover link. 16 alarm-in / 6 alarm-out Physical terminal block for 16 alarm inputs and 6 alarm outputs — one of the outputs is a 12 V 1 A direct power feed for sirens, strobes or gate solenoids. RS-232 + RS-485 Both serial standards present — integrate with POS systems, gate controllers, access control panels, PTZ joysticks or third-party VMS that need legacy serial. RS-485 is half-duplex. 3 × USB (1 × 2.0 + 2 × 3.0) One front USB 2.0 plus two rear USB 3.0 ports — plug in backup drives, USB mice, keyboards or service tools without juggling cables behind the rack. ONVIF 23.12 (T / S / G) Latest ONVIF profile support — drops into any current VMS, plus native integration for Panasonic, Sony, Axis, Pelco, Arecont, Canon and Hanwha as well as Dahua. DMSS + DSS Pro VMS Free DMSS mobile app for live view, playback and push notifications. For multi-site enterprise deployments, integrate with Dahua DSS Pro for centralised control of multiple 5432 NVRs. NVR5432-16P vs the family — how it compares The 5432-16P (this model) is the all-in-one enterprise NVR — 16 PoE+ ports plus 16 network-fed channels, 80 TB storage, dual NIC, 1.5U rack chassis. Choose this if you want to power your first 16 cameras directly from the recorder. The 5432-AI/ANZ drops the PoE for sites that already have a managed network switch. The 5216-16P is the 16-channel 1U sibling for smaller installs. 5-Series Top-Tier Comparison Specification NVR5432-16P-AI/ANZ (this model) NVR5432-AI/ANZ NVR5216-16P-AI/ANZ IP channels 32 32 16 AcuPick channels Up to 32 Up to 32 Up to 16 Built-in PoE 16 × ports · 150 W · 1-8 ePoE None (external switch) 16 × ports · 130 W · 1-8 ePoE HDD bays 4 SATA · up to 80 TB 4 SATA · up to 80 TB 2 SATA · up to 32 TB eSATA · iSCSI Yes / Yes Yes / Yes No / Yes Network ports 2 × Gigabit (bondable) 2 × Gigabit (bondable) 1 × Gigabit Video outputs 2 × HDMI + 2 × VGA 2 × HDMI + 2 × VGA 1 × HDMI + 1 × VGA Main-screen split Up to 36 Up to 36 Up to 16 Alarm I/O 16 in / 6 out (incl. 12 V) 16 in / 6 out (incl. 12 V) 4 in / 2 out USB ports 1 × 2.0 + 2 × 3.0 1 × 2.0 + 2 × 3.0 1 × 2.0 + 1 × 3.0 Form factor 1.5U 1.5U 1U ONVIF 23.12 (T / S / G) 23.12 (T / S / G) 22.06 (T / S / G) Max camera resolution · Bandwidth 32 MP · 384 / 200 Mbps 32 MP · 384 / 200 Mbps 32 MP · 384 / 200 Mbps N+M cluster · Warranty Yes / 3 years Yes / 3 years Yes / 3 years Full Specifications Model DHI-NVR5432-16P-AI/ANZ Series WizSense · NVR5000-AI/ANZ (Australia / NZ market) Form factor 1.5U · 4-HDD · rack or desktop · 16 built-in PoE+ ports IP channels 32 · up to 32 MP per channel Supported resolutions 32 MP · 24 MP · 16 MP · 12 MP · 8 MP · 6 MP · 5 MP · 4 MP · 3 MP · 1080p · 720p · 960p · D1 · CIF · QCIF Bandwidth (AI off) 384 Mbps incoming / 384 Mbps record / 384 Mbps outgoing Bandwidth (AI on) 200 Mbps incoming / 200 Mbps record / 200 Mbps outgoing Decoding (AI off) 2 × 32 MP @ 25 fps · 4 × 16 MP @ 30 fps · 8 × 8 MP @ 30 fps · 16 × 4 MP @ 30 fps · 32 × 1080p @ 30 fps Decoding (AI on) 1 × 32 MP @ 25 fps · 2 × 16 MP @ 30 fps · 4 × 12 MP @ 30 fps · 6 × 8 MP @ 30 fps · 24 × 1080p @ 30 fps Video compression Smart H.265+ · H.265 · Smart H.264+ · H.264 · MJPEG Audio compression G.711a · G.711u · PCM · G.726 AI engine WizSense (industrial AI chip, deep-learning) · AcuPick supported AcuPick Up to 32 channels · 1 combined event per channel/sec Face Detection (NVR) 2 channels · up to 12 face snapshots/sec each Face Recognition (NVR) 16 ch (FD by camera + FR by recorder, 16 fps) · or 2 ch (FD+FR by recorder, 12 fps) Face Database 20 databases · 20,000 images · 2.5 GB · gender / age / glasses / expression / mask / beard attributes Perimeter Protection 4 channels by NVR · all channels by camera (16 targets/sec) · 10 IVS rules per channel SMD Plus 8 channels by NVR · all channels by camera (32 targets/sec) Video Metadata 8 channels (camera-side) · human / motor / non-motor vehicle attributes ANPR (by camera) All channels · 20,000-plate database · blocklist / allowlist AI by Camera (passthrough) Face detection · Face recognition · Video metadata · Perimeter protection · SMD Plus · Stereo analysis · Crowd distribution · People counting · ANPR · Vehicle density · Heat map N+M cluster · iSCSI · eSATA Yes / Yes / Yes HDD bays 4 × SATA · up to 20 TB per drive (~80 TB max) Video output 2 × HDMI (4K · 3840×2160) + 2 × VGA (1080p) · heterogeneous HDMI1/HDMI2 · simultaneous VGA1+HDMI1 / VGA2+HDMI2 Multi-screen display Main screen: 1 / 4 / 8 / 9 / 16 / 25 / 36 · Sub screen: 1 / 4 / 8 / 9 / 16 Audio I/O 1 × RCA in · 2 × RCA out Alarm I/O 16 × alarm in · 6 × alarm out (1 × 12 V 1 A power output) USB 3 ports: 1 × front USB 2.0 + 2 × rear USB 3.0 Network ports 2 × RJ-45 Gigabit Ethernet (10 / 100 / 1000 Mbps) · multi-address / load-balance / fault-tolerance bonding PoE 16 × ports · 10/100 Mbps · IEEE 802.3af/at · 150 W total · 25.5 W per port (max) · ports 1-8 support ePoE (800 m / 100 Mbps to 300 m, 10 Mbps to 800 m) RS-232 / RS-485 1 / 1 (RS-485 half-duplex) eSATA 1 port (external archive) Network protocols HTTP / HTTPS · TCP/IP · IPv4 · UDP · NTP · DHCP · DNS · SMTP · UPnP · DDNS · Alarm Server · Multicast · P2P · Auto Registration · iSCSI ONVIF 23.12 (Profile T / S / G) · CGI · SDK Third-party camera support ONVIF · Panasonic · Sony · Axis · Arecont · Pelco · Canon · Hanwha Mobile app DMSS (iOS / Android) Record modes General · motion detection · intelligent · alarm · POS Backup USB device · network Power supply 100 – 240 VAC · 50 – 60 Hz (internal universal-voltage PSU) Power consumption ≤ 13 W NVR-side (without HDD, PoE load excluded) Operating temperature −10 °C to +55 °C Operating humidity 10% – 93% RH (non-condensing) Dimensions 440 × 415.1 × 70 mm (1.5U) Installation Rack or desktop Recommended firmware DH_NVR5XXX-EI_MultiLang V5.001.0000000.0.R.251220 (or later) — required for AcuPick, N+M cluster, iSCSI and ONVIF 23.12 Certifications FCC Part 15 Subpart B Class A · CE-EMC · CE-LVD · Security Baseline 2.3 Warranty 3 years (CCTV Guru Australia) Downloads & documentation Download official Dahua documents for setup, specifications, and recorder details. DHI-NVR5432-16P-AI/ANZ Datasheet Dahua NVR Quick Start Guide Dahua NVR User Manual Dahua NVR HDD Installation Guide Frequently asked questions How does this differ from the no-PoE NVR5432-AI/ANZ? The 5432-16P (this model) has 16 built-in PoE+ ports — your first 16 cameras plug straight into the back of the recorder, no PoE switch required. The plain 5432-AI/ANZ has no built-in PoE and is for sites that already run a managed PoE switch. Same chassis, same AI, same 4 HDD bays — just the PoE difference. What does ePoE on ports 1–8 give me? Extended PoE — long-distance Cat6 runs at reduced speed. Ports 1–8 support 100 Mbps up to 300 m or 10 Mbps up to 800 m (most IP cameras work fine at 10 Mbps for sub-stream + main-stream H.265+). Eliminates intermediate switches on long perimeter or carpark runs. Ports 9–16 run standard PoE+ at up to 100 m. How do I connect cameras 17–32? Via your existing managed switch or VLAN. The licence supports up to 32 IP cameras on the NVR; you decide which 16 plug into the built-in PoE and which come in over the network. The Gigabit uplink and second NIC give you plenty of headroom to bring in another 16 channels of camera traffic. What is AcuPick and what do I need for it? AcuPick is Dahua's next-generation attribute-and-image search — it extracts rich target attributes at the camera AND the NVR, then lets you search across all 32 channels by reference image or combined attributes. You need Dahua's AcuPick-ready cameras (typically TiOC PV and 5-Series WizSense Plus IPC families). Standard WizSense cameras still record and recognise faces but the full AcuPick depth requires paired AcuPick IPCs. How much storage do I need for 32 cameras? For 32 × 4 MP cameras at H.265+ on motion-record, allow ~25–35 TB for 30 days of retention. Four 8 TB or 10 TB surveillance-grade drives (WD Purple, Seagate SkyHawk) covers most use cases with disk-group protection. If on-board capacity isn't enough, iSCSI lets you expand onto network-attached storage or eSATA onto external archive arrays. Is the DHI-NVR5432-16P-AI/ANZ NDAA Section 889 compliant? No. Dahua products are not currently NDAA Section 889 compliant. If NDAA compliance is required (federal, government or defence installs), choose a Uniview, Hanwha, Axis, Bosch or IDIS NVR instead — CCTV Guru can recommend an equivalent. Can it be rack-mounted? Yes — 1.5U / 440 mm wide fits a standard 19-inch rack with ears (rack ears sold separately). It can also sit on a desk or shelf if you've allocated cabinet space. Plan for about 7–8 kg fully loaded with four drives. What's the 12 V alarm output for? One of the 6 alarm outputs is a direct 12 V 1 A power feed — drive a siren, strobe light or electric strike directly without needing an external relay or power supply. The other 5 outputs are dry-contact relays you can wire to anything that takes a NO/NC trigger. 3-Year Warranty Australia-Wide Shipping Australian Tech Support

Read more less

WizSense 3 · 4 MP · Wide-Angle 2.8 mm · IR 20 m WizSense 3 Bullet Dahua DH-IPC-HFW3466T-AS-P — 4 MP Wide-Angle Fixed-Focal IR Bullet WizSense 3 Network Camera (3466 Series, 2.8 mm) The Dahua DH-IPC-HFW3466T-AS-P is a 4 MP WizSense 3 fixed-focal bullet built around a 1/3" progressive-scan CMOS sensor, delivering crisp 2688 × 1520 video at 25/30 fps — with an optional 5 MP (2880 × 1620) overclock mode at 20 fps when you need extra pixels on number plates or shopfront tills. The fixed 2.8 mm wide-angle lens captures roughly 113° horizontally, so a single camera blankets a driveway, carport, body-corporate entry or small shopfront edge-to-edge without dead zones. Smart IR 20 m, 120 dB true WDR and IP67 keep the image clean from full Aussie sun through to pitch-black laneways. AcuPick fast image search, SMD 4.0 human & vehicle filtering and full IVS (tripwire, intrusion, perimeter) cut false alerts on possums, trees and washing on the line. A built-in mic, 256 GB microSD slot and 802.3af PoE single-cable install make it ideal for small business shopfronts, body-corp entries, garages and carports, regional homes, school perimeters and back fences, and council depots across Australia. Backed by a 3-Year AU Warranty from CCTV Guru. 3-Year AU Warranty Fast AU-Wide Shipping AU Tech Support Why Choose the Dahua HFW3466T-AS-P Bullet Wide 2.8 mm Coverage (~113°) A single camera covers a whole driveway, shopfront or carport horizon-to-horizon — fewer cameras, fewer cable runs, fewer blind spots. AcuPick Rapid Search Paired with a WizSense AI NVR, AcuPick finds a person or vehicle across hours of footage in seconds using attributes like clothing colour or vehicle type. SMD 4.0 Human & Vehicle Filter Smart Motion Detection 4.0 only triggers on people and vehicles — ignoring possums, branches, rain and shadows for cleaner alerts. Built-in Mic for Audio Evidence Onboard microphone records audio alongside video — perfect for shopfront counters and reception areas (signage required, see notes). 5 MP Overclock Mode Switch to 2880 × 1620 @ 20 fps when you need extra detail on plates, faces or fine signage — configurable in the web UI. IP67 + 802.3af PoE Sealed metal housing rated IP67 against Aussie dust storms and downpours, powered & networked over a single Cat6 PoE run. Important Install Note The 2.8 mm fixed wide lens cannot be zoomed — choose mounting height carefully (3–4 m is typical) so subjects fill the frame rather than getting lost in the wide field. AcuPick attribute search delivers its full benefit only when paired with a matching Dahua WizSense AI NVR; standalone playback works fine but loses the attribute-filter shortcuts. Under Australian state surveillance laws, recording audio with the built-in mic generally requires clear signage informing visitors — check your state legislation before enabling. For long external cable runs or rooftop installs, add network surge protection at the head-end to protect both the camera and your switch. AI & Smart Detection AcuPick Fast Image Search Search recorded footage by person or vehicle attributes — colour, type, direction — in seconds, not hours. SMD 4.0 (Human/Vehicle Classification) On-camera AI classifies motion as human, vehicle or noise — cutting false alerts dramatically vs. plain pixel-motion. IVS (Tripwire/Intrusion) Draw virtual tripwires across gates or driveways and intrusion zones around stock yards for precise event-based alerts. Perimeter Protection Human/vehicle-targeted perimeter rules ignore animals and weather, so you only get pushed when it matters. Privacy Masking Block out neighbour windows or restricted areas with on-camera privacy zones — required for many body-corp installs. ONVIF Integration ONVIF Profile S/G/T means the camera plays nicely with Blue Iris, Milestone, Hanwha NVRs and other third-party platforms. Technical Specifications Camera, Lens & Illumination Model DH-IPC-HFW3466T-AS-P Form Factor Bullet Image Sensor 1/3" Progressive Scan CMOS Max Resolution 4 MP (2688 × 1520) · Overclock 5 MP (2880 × 1620) Frame Rate 25/30 fps @ 4 MP · 20 fps @ 5 MP WDR 120 dB True WDR Day/Night ICR Auto Switch Lens Type Fixed Focal Focal Length 2.8 mm Field of View H: ~113° (Wide Angle) IR Distance Smart IR up to 20 m Intelligence, Audio & Network AI Engine WizSense 3 AcuPick Yes (fast image search) IVS Tripwire, Intrusion (perimeter) SMD SMD 4.0 (Human & Vehicle) Mic Built-in Audio I/O 1/1 Alarm I/O 1/1 Network RJ-45 100 Mbps ONVIF Profile S/G/T Storage microSD up to 256 GB App DMSS (iOS & Android) Power, Environment & Build Power PoE (802.3af) / 12 V DC, ~7 W Operating Temp −30°C to +60°C Protection IP67 Casing Metal Bullet Housing Warranty 3-Year AU Warranty (CCTV Guru) Recommended NVR Pairings Dahua DHI-NVR5208-8P-AI/ANZ 8-channel WizSense AI NVR with 8 built-in PoE ports — ideal for small shopfronts or homes running up to 8 cameras with full AcuPick support. Dahua DHI-NVR5216-16P-AI/ANZ 16-channel, 16-PoE WizSense AI NVR with dual HDD bays — the sweet spot for body-corp lobbies and mid-size businesses. Dahua DHI-NVR4216-16P-AI/ANZ 16-channel 4K Smart AI NVR with 16 PoE — cost-effective WizSense recorder for schools and council depots. Dahua DHI-NVR5432-AI/ANZ 32-channel WizSense AI NVR (no built-in PoE — use a PoE switch) for larger sites, campuses and multi-building rollouts. Frequently Asked Questions Is this camera NDAA compliant? No. Dahua is not on the NDAA-approved manufacturer list. If your site has NDAA §889 procurement requirements, please consider an alternative brand. What is AcuPick and why does it matter? AcuPick is Dahua's fast image-search engine. Instead of scrubbing hours of footage, you filter by attributes (e.g. "red car", "person in blue") and jump to matches in seconds. Does AcuPick work with any NVR? The camera's metadata is recorded on any ONVIF NVR, but AcuPick's attribute-search shortcuts require a matching Dahua WizSense AI NVR (e.g. NVR5208-8P-AI/ANZ). How wide is the 2.8 mm lens in practice? Roughly 113° horizontal — enough to cover an entire single garage, shopfront facade, or two-car driveway from a single mounting point at 3–4 m height. Can I really get 5 MP from a 4 MP camera? Yes — the sensor supports an overclock mode of 2880 × 1620 @ 20 fps. Frame rate drops to 20 fps and you trade a little low-light performance for extra pixels. Is the built-in mic legal in Australia? State surveillance laws vary, but most require clear signage when audio is recorded. Check your state legislation and post visible notices at entry points before enabling audio. Can it be installed indoors or outdoors? Both. The IP67-rated metal housing and −30°C to +60°C operating range handle Aussie summers, coastal humidity and alpine cold. What PoE budget do I need? Around 7 W via 802.3af PoE — well within any standard PoE switch or Dahua AI NVR's per-port budget. SD card or NVR for storage? The microSD slot (up to 256 GB) is great for redundancy or single-camera installs. For multi-camera sites with AcuPick search, pair with a Dahua WizSense AI NVR. What warranty applies? CCTV Guru provides a full 3-Year Australian warranty on this WizSense 3 camera, with local tech support based in Australia. Downloads Datasheet (PDF) Quick Start Guide Installation Guide Order Your Dahua HFW3466T-AS-P from CCTV Guru Need help sizing a kit, choosing between 2.8 mm wide and 3.6 mm narrow, or matching this camera to your existing Dahua NVR? Our AU team can spec your install and ship Australia-wide with full 3-Year AU Warranty backing. Contact CCTV Guru for a tailored quote.

Read more less

WizSense 3 · 4 MP · Motorised 2.7–13.5 mm · IK10 Vandal DomeDahua WizSense 3 · 4 MP Motorised Vandal DomeDahua DH-IPC-HDBW3466RP-ZAS-AUS — 4 MP Motorised Vari-Focal Vandal Dome WizSense 3 Network Camera (3466 Series) The Dahua DH-IPC-HDBW3466RP-ZAS-AUS is the 3466 series 4 MP WizSense 3 motorised vandal dome — built around a 1/3" CMOS sensor capturing 2688 × 1520 at 25/30 fps with Smart H.265+ encoding. The motorised 2.7–13.5 mm vari-focal lens delivers a wide 102° field at 2.7 mm down to a tight 27° pull at 13.5 mm — re-frameable remotely via the DMSS app, no ladder visits required. Built-in IR reaches up to 50 m; WDR is 120 dB; the IK10 vandal-rated metal dome housing is IP67 sealed. WizSense 3 deep-learning edge AI runs perimeter protection (tripwire, intrusion) with human and vehicle classification, plus SMD 4.0 and AcuPick attribute search when paired with a Dahua AcuPick NVR. Built-in microphone, RCA audio I/O and 1/1 alarm wet-contact pair round out the spec. Built for Australian retail floors, transport platforms, school grounds and high-vandalism positions where a vandal dome is preferred and re-frameable optics matter. Backed by a 3-year Australian warranty through CCTV Guru. SKU 3466 series. 3-Year AU Warranty Fast AU-Wide Shipping AU Tech Support Why Choose the Dahua HDBW3466RP-ZAS-AUS WizSense 3 Motorised Vandal Dome IK10 Vandal Dome — Metal Housing Full metal housing with IK10 impact rating — built for transport platforms, schools, retail interiors and shopping centres where vandalism risk is real. The dome chassis discourages tampering. Motorised 5× Vari-Focal Lens 2.7–13.5 mm motorised vari-focal — install wide for general coverage, then pull tight to 13.5 mm on the area of interest remotely from DMSS. No ladder visits for re-framing. True 4 MP Detail at 25/30 fps Native 2688 × 1520 at full 25/30 fps. Double the pixel density of 1080p with smooth full-motion video for retail and transport sites. WizSense 3 + AcuPick AI Perimeter protection, SMD 4.0 and AcuPick attribute search on the WizSense 3 deep-learning chip. AcuPick lets you search recorded video by clothing colour, vehicle type and direction with a Dahua AcuPick NVR. 50 m Long-Range IR Built-in IR array reaches up to 50 m — long-range night surveillance for large retail floors, transport platforms and undercover carparks. 120 dB WDR + Standard PoE Strong wide dynamic range holds detail in backlit Australian doorways. Runs on standard 802.3af PoE — any quality PoE switch will do. Important Install Note The motorised vari-focal lens is remote-controllable via DMSS — re-frame at any time without a site visit. The dome gimbal allows three-axis adjustment for flexible install alignment. Audio recording is subject to local privacy law — check NDIS, retail and public-space rules before enabling. AI & Smart Detection Capabilities AcuPick Attribute Search Search recorded video by colour, top/bottom clothing, vehicle type and direction — with a Dahua AcuPick NVR. SMD 4.0 Smart Motion Motion alerts triggered only by humans and vehicles. Filters out branches, animals and shadows. Perimeter Protection (IVS) Tripwire and intrusion zones with human/vehicle classification. AI SSA Scene Self-Adaptation Automatic image-parameter adjustment for rain, fog, backlight and flicker. Abnormality Detection SD card, network, IP conflict, tampering, audio, voltage events — pushed to DMSS. Two-Way Audio & Alarm I/O Built-in mic + RCA audio I/O; alarm I/O for third-party alarm system integration. ONVIF Profile S, G, T. Technical Specifications Camera, Lens & Illumination Model DH-IPC-HDBW3466RP-ZAS-AUS Form Factor Vandal dome (HDBW chassis) Image Sensor 1/3" CMOS Maximum Resolution 2688 × 1520 (4 MP) Frame Rate 4 MP @ 25/30 fps WDR 120 dB Day / Night Auto (ICR) / Colour / B&W Lens Type Motorised vari-focal Focal Length 2.7 mm – 13.5 mm Field of View H: 102° – 27° IR Illumination Up to 50 m Intelligence, Audio & Network AI Engine WizSense 3 Series IVS Tripwire · intrusion (with human/vehicle classification) SMD SMD 4.0 AcuPick Yes (with Dahua AcuPick NVR) AI SSA Yes Built-in Microphone Yes Audio I/O 1 in / 1 out (RCA) Alarm I/O 1 in / 1 out Network Port RJ-45 (10/100 Base-T) Interoperability ONVIF (Profile S, G, T) · CGI Storage Micro SD up to 512 GB Mobile Client DMSS (iOS / Android) Power, Environment & Build Power Supply 12 VDC / PoE (802.3af) Operating Temperature −30 °C to +60 °C Protection IP67 · IK10 vandal Casing Metal Certifications CE-LVD (EN62368-1) · CE-EMC (2014/30/EU) · RCM (AU) Australian Warranty 3 Years (via CCTV Guru) How It Compares — HDBW3466RP-ZAS (Motorised) vs HDBW3466FP-AS (Fixed) The natural sibling is the Dahua DH-IPC-HDBW3466FP-AS-AUS — the fixed 2.8 mm version of this same 4 MP WizSense 3 vandal dome. Choose this motorised version for re-frameable optics and longer zoom reach; choose the fixed for predictable framing and lower cost. Feature HDBW3466RP-ZAS-AUS (this — motorised) HDBW3466FP-AS-AUS (sibling — fixed) Resolution 4 MP (2688 × 1520) 4 MP (2688 × 1520) Lens Motorised 2.7–13.5 mm Fixed 2.8 mm AI Engine WizSense 3 + AcuPick WizSense 3 + AcuPick IR Distance Up to 50 m Up to 50 m Remote Re-Framing Yes No IK10 Vandal Yes Yes Best For Variable framing & long zoom reach Predictable framing at lower cost Recommended NVR Pairings Dahua DHI-NVR5208-8P-AI/ANZ 5-Series AcuPick NVR · 8 channels. View Dahua NVR5208-8P-AI → Dahua DHI-NVR5216-16P-AI/ANZ 5-Series AcuPick NVR · 16 channels · 16 PoE+. View Dahua NVR5216-16P-AI → Dahua DHI-NVR4216-16P-AI/ANZ 4-Series WizSense AI NVR · 16 channels. View Dahua NVR4216-16P-AI → Dahua DHI-NVR5432-AI/ANZ 5-Series AcuPick NVR · 32 channels. View Dahua NVR5432-AI → Frequently Asked Questions Is the Dahua HDBW3466RP-ZAS-AUS NDAA compliant? No. Dahua is not certified under NDAA Section 889. What does "IK10" mean? IK10 is the highest impact rating in the IK protection standard — the dome can withstand an impact equivalent to 5 kg dropped from 40 cm. Designed for high-vandalism positions. Can I re-frame the lens after install? Yes — motorised vari-focal lens fully controllable via DMSS app. Zoom and focus adjustments are remote-controlled. Does it include AcuPick? Yes. Pair with a Dahua 5-Series AcuPick NVR for attribute-based recorded-video search. Can I run it on standard PoE? Yes — 802.3af-compliant. How far can it see at night? Up to 50 m built-in IR. Does it have audio? Yes — built-in mic + RCA audio I/O. Does it work with third-party NVRs? Yes — ONVIF Profile S, G, T. AcuPick attribute search only on Dahua AI NVRs. What temperature range? −30 °C to +60 °C. Suitable for most Australian sites. Can I view it on my phone? Yes — Dahua's free DMSS app on iOS and Android. Downloads DH-IPC-HDBW3466RP-ZAS-AUS DatasheetDahua IP Dome Camera Quick Start GuideDahua IP Dome Camera Installation GuideDahua IP Dome Camera Operational Manual Order Your Dahua HDBW3466RP-ZAS-AUS from CCTV Guru "Add to cart" to order online, or contact our Australian team for project pricing and NVR sizing. We back every 3466 series camera with a 3-year Australian warranty. Phone, email or live chat us through cctvguru.com.au/pages/contact.

Read more less

WizSense 3 · 8 MP 4K · Motorised 2.7–13.5 mm · 50 m IRDahua WizSense 3 · 8 MP 4K Motorised TurretDahua DH-IPC-HDW3866TP-ZS-AUS — 8 MP 4K Motorised Vari-Focal Starlight IR Eyeball Turret WizSense 3 Network Camera (3866 Series, 2.7–13.5 mm) The Dahua DH-IPC-HDW3866TP-ZS-AUS is the 3866 series 8 MP 4K WizSense 3 motorised eyeball turret in white housing — built around a 1/2.7" CMOS Starlight sensor capturing 3840 × 2160 (true 4K) at 15 fps and 4 MP at full 25/30 fps. The motorised 2.7–13.5 mm vari-focal lens delivers a wide 102° field at 2.7 mm down to a tight 27° pull at 13.5 mm — re-frameable from DMSS. Built-in IR reaches up to 50 m; WDR is 120 dB; the compact metal turret housing is IP67 sealed. WizSense 3 deep-learning Pro AI runs perimeter protection (tripwire, intrusion, fast-moving, loitering) with human and vehicle classification, plus SMD 4.0 and AcuPick attribute search. Built-in microphone, 1/1 RCA audio I/O. The classic white housing blends into white eaves, soffits and awnings — the standard finish for most Australian residential and commercial installs. Backed by a 3-year Australian warranty through CCTV Guru. SKU 3866 series. 3-Year AU Warranty Fast AU-Wide Shipping AU Tech Support Why Choose the Dahua HDW3866TP-ZS-AUS WizSense 3 4K Motorised Turret True 4K Detail (8 MP) Native 3840 × 2160 at 15 fps, or 4 MP at full 25/30 fps. 4× the pixel density of 1080p — identification-grade detail at distance. Motorised 5× Vari-Focal 2.7–13.5 mm motorised vari-focal — install wide, then pull tight on the area of interest via DMSS. Classic White Eyeball Form Standard white metal eyeball turret — blends into white eaves, soffits and awnings. WizSense 3 + AcuPick Perimeter protection, SMD 4.0 and AcuPick attribute search on the WizSense 3 chip. 50 m IR + Starlight 1/2.7" Starlight sensor with usable colour in moonlight; 50 m IR for fully-dark coverage. Built-in Mic + Audio I/O Built-in microphone plus RCA audio I/O for two-way talk integration. Important Install Note The motorised vari-focal lens is remote-controllable via DMSS. The eyeball gimbal allows ±75° pan, ±75° tilt and 0–360° rotation. At full 4K, frame rate caps at 15 fps — drop to 4 MP for full 25/30 fps motion. For a black housing variant, see HDW3866TP-ZS-AUS-BLK. AI & Smart Detection AcuPick Attribute Search Search recorded video by colour, clothing, vehicle type — with a Dahua AcuPick NVR. SMD 4.0 Smart Motion Motion alerts triggered only by humans and vehicles. Perimeter Protection Tripwire, intrusion, fast-moving and loitering with human/vehicle classification. AI SSA Scene self-adaptation for rain, fog, backlight. Abnormality Detection SD card, network, IP conflict, tampering events. Two-Way Audio Built-in mic + RCA audio I/O. Technical Specifications Camera, Lens & Illumination Model DH-IPC-HDW3866TP-ZS-AUS Form Factor Eyeball turret (HDW chassis) — White Image Sensor 1/2.7" CMOS Starlight Maximum Resolution 3840 × 2160 (8 MP / 4K) Frame Rate 4K @ 15 fps · 4 MP @ 25/30 fps WDR 120 dB Day / Night Auto (ICR) / Colour / B&W Lens Type Motorised vari-focal Focal Length 2.7–13.5 mm Field of View H: 102°–27° IR Illumination Up to 50 m Intelligence, Audio & Network AI Engine WizSense 3 Series IVS Tripwire · intrusion · fast-moving · loitering (human/vehicle) SMD SMD 4.0 AcuPick Yes (with Dahua AcuPick NVR) Built-in Mic Yes Audio I/O 1 in / 1 out (RCA) Network Port RJ-45 (10/100) Interoperability ONVIF (Profile S, G, T) · CGI Storage Micro SD up to 512 GB Mobile Client DMSS Power, Environment & Build Power Supply 12 VDC / PoE (802.3af) Operating Temperature −40 °C to +60 °C Protection IP67 Casing Metal — White Australian Warranty 3 Years (via CCTV Guru) Recommended NVR Pairings Dahua DHI-NVR5208-8P-AI/ANZ View NVR5208-8P-AI → Dahua DHI-NVR5216-16P-AI/ANZ View NVR5216-16P-AI → Dahua DHI-NVR4216-16P-AI/ANZ View NVR4216-16P-AI → Dahua DHI-NVR5432-AI/ANZ View NVR5432-AI → Frequently Asked Questions NDAA compliant? No. True 4K? Yes — native 3840 × 2160 at 15 fps. Re-frame after install? Yes — motorised vari-focal via DMSS. AcuPick? Yes — pair with a Dahua AcuPick NVR. Standard PoE? Yes — 802.3af. Available in black? Yes — DH-IPC-HDW3866TP-ZS-AUS-BLK. Night vision? Up to 50 m IR. Audio? Built-in mic + RCA audio I/O. Third-party NVRs? Yes — ONVIF Profile S, G, T. Mobile viewing? Yes — DMSS app. Downloads DH-IPC-HDW3866TP-ZS-AUS DatasheetDahua IP Turret Camera Quick Start GuideDahua IP Turret Camera Installation Guide Order Your Dahua HDW3866TP-ZS-AUS from CCTV Guru "Add to cart" to order, or contact our Australian team for project pricing. 3-year Australian warranty. cctvguru.com.au/pages/contact.

Read more less

WizSense 3 · 8 MP 4K · Fixed 2.8 mm · IK10 Vandal DomeDahua WizSense 3 · 8 MP 4K Vandal DomeDahua DH-IPC-HDBW3866EP-AS-AUS — 8 MP 4K Fixed-Focal IR Vandal Dome WizSense 3 Network Camera (3866 Series, 2.8 mm) The Dahua DH-IPC-HDBW3866EP-AS-AUS is the 3866 series 8 MP 4K WizSense 3 fixed-focal vandal dome — the vandal-dome sibling to the HDW3866TP-ZS-AUS turret. Built around a 1/2.7" CMOS Starlight sensor capturing 3840 × 2160 (true 4K) at 15 fps and 4 MP at full 25/30 fps. The 2.8 mm fixed F1.6 lens delivers a wide 102° field of view; built-in IR reaches up to 40 m; WDR is 120 dB; the IK10 vandal-rated metal dome housing is IP67 sealed across −40 °C to +60 °C. WizSense 3 deep-learning Pro AI runs perimeter protection (tripwire, intrusion, fast-moving, loitering) with human and vehicle classification, plus SMD 4.0 and AcuPick attribute search. Built-in microphone, 1/1 RCA audio I/O. Built for Australian retail interiors, transport platforms, schools, council reserves and high-vandalism positions where 4K detail and vandal-resistant housing matter. Backed by a 3-year Australian warranty through CCTV Guru. SKU 3866 series. 3-Year AU Warranty Fast AU-Wide Shipping AU Tech Support Why Choose the Dahua HDBW3866EP-AS-AUS WizSense 3 4K Vandal Dome True 4K Detail (8 MP) Native 3840 × 2160 at 15 fps, or 4 MP at full 25/30 fps. Identification-grade detail at distance. IK10 Vandal Dome Full metal IK10-rated dome chassis — built for shopping centres, transport platforms, schools and vandal-prone interiors. WizSense 3 + AcuPick Perimeter protection, SMD 4.0 and AcuPick attribute search on the WizSense 3 deep-learning chip. 1/2.7" Starlight + 40 m IR 1/2.7" Starlight sensor with usable colour in moonlight; 40 m IR for fully-dark coverage. Wide 102° FOV 2.8 mm fixed lens covers a wide 102° field of view — large open spaces from a single camera. Built-in Mic + Audio I/O Built-in microphone plus RCA audio I/O for two-way talk integration. Important Install Note Fixed-focal (2.8 mm) — frame at install time. The dome gimbal allows three-axis adjustment. At full 4K resolution, frame rate caps at 15 fps — drop to 4 MP for full 25/30 fps motion. AI & Smart Detection AcuPick Attribute Search Search recorded video by colour, clothing, vehicle type — with a Dahua AcuPick NVR. SMD 4.0 Motion alerts triggered only by humans and vehicles. Perimeter Protection Tripwire, intrusion, fast-moving, loitering with human/vehicle classification. AI SSA Scene self-adaptation. Abnormality Detection SD card, network, IP conflict, tampering events. Two-Way Audio Built-in mic + RCA audio I/O. Technical Specifications Camera, Lens & Illumination Model DH-IPC-HDBW3866EP-AS-AUS Form Factor Vandal dome (HDBW chassis) Image Sensor 1/2.7" CMOS Starlight Maximum Resolution 3840 × 2160 (8 MP / 4K) Frame Rate 4K @ 15 fps · 4 MP @ 25/30 fps WDR 120 dB Lens Type Fixed-focal 2.8 mm F1.6 Field of View H: ~102° IR Illumination Up to 40 m Intelligence, Audio & Network AI Engine WizSense 3 Series IVS Tripwire · intrusion · fast-moving · loitering (human/vehicle) SMD SMD 4.0 AcuPick Yes (with Dahua AcuPick NVR) Built-in Mic Yes Audio I/O 1 in / 1 out (RCA) Network Port RJ-45 (10/100) Interoperability ONVIF (Profile S, G, T) · CGI Storage Micro SD up to 512 GB Mobile Client DMSS Power, Environment & Build Power Supply 12 VDC / PoE (802.3af) Operating Temperature −40 °C to +60 °C Protection IP67 · IK10 vandal Casing Metal Australian Warranty 3 Years (via CCTV Guru) Recommended NVR Pairings Dahua DHI-NVR5208-8P-AI/ANZ View NVR5208-8P-AI → Dahua DHI-NVR5216-16P-AI/ANZ View NVR5216-16P-AI → Dahua DHI-NVR4216-16P-AI/ANZ View NVR4216-16P-AI → Dahua DHI-NVR5432-AI/ANZ View NVR5432-AI → Frequently Asked Questions NDAA compliant? No. True 4K? Yes — native 3840 × 2160 at 15 fps. IK10 vandal? Yes — highest impact rating. AcuPick? Yes — pair with a Dahua AcuPick NVR. Standard PoE? Yes — 802.3af. Night vision? Up to 40 m IR. Audio? Built-in mic + RCA audio I/O. Third-party NVRs? Yes — ONVIF Profile S, G, T. Temperature? −40 °C to +60 °C alpine-rated. Mobile viewing? Yes — DMSS app. Downloads DH-IPC-HDBW3866EP-AS-AUS DatasheetDahua IP Dome Camera Quick Start GuideDahua IP Dome Camera Installation Guide Order Your Dahua HDBW3866EP-AS-AUS from CCTV Guru "Add to cart" to order, or contact our Australian team for project pricing. 3-year Australian warranty. cctvguru.com.au/pages/contact.

Read more less

WizSense 3 · 8 MP 4K · Fixed 2.8 mm · 30 m IR WizSense 3 4K Bullet Dahua DH-IPC-HFW3866EP-AS-AUS — 8 MP 4K Fixed-Focal Starlight IR Bullet WizSense 3 Network Camera (3866 Series, 2.8 mm) The Dahua DH-IPC-HFW3866EP-AS-AUS is a true 8 MP 4K WizSense 3 bullet that combines a 1/2.7″ Starlight CMOS sensor with a wide 2.8 mm fixed lens (102° FoV) to deliver 3840 × 2160 footage at 25/30 fps — sharp enough to capture faces, plates and product detail across driveways, shop fronts, side paths and warehouse perimeters. Smart IR reaches 30 m, while AI SSA (Smart Scene Adaptation) optimises exposure for backlight, low-light and fast-changing scenes without manual tuning. WizSense 3 deep learning runs human and vehicle classification, SMD 4.0 false-alarm filtering and AcuPick metadata search, letting you scrub hours of footage by clothing colour, vehicle colour or direction in seconds. The sealed IP67 metal bullet supports microSD up to 256 GB, audio I/O, alarm I/O and 802.3af PoE, so a single Cat6 run handles power, video and edge recording. Backed by a 3-year Australian warranty through CCTV Guru, an authorised Dahua reseller. 3-Year AU Warranty Fast AU-Wide Shipping AU Tech Support Why Choose the Dahua DH-IPC-HFW3866EP-AS-AUS 4K Bullet True 8 MP 4K Resolution 3840 × 2160 footage at 25/30 fps captures faces, plates and signage with the detail required for AU prosecutions and insurance claims. Wide 2.8 mm Lens 102° horizontal field of view covers a wide front yard, driveway entry or shop floor with a single bullet — no lens swap required. 30 m Smart IR Adaptive Smart IR keeps near-field subjects from blowing out while reaching 30 m down driveways, side paths and back gardens. WizSense 3 + AcuPick On-board human/vehicle classification plus AcuPick metadata search makes evidence retrieval fast on supported Dahua AI/ANZ NVRs. AI SSA Auto-Tuning AI Scene Self-Adaptation automatically adjusts shutter, gain and noise reduction for backlight, low-light and fast-moving scenes. Starlight Sensor 1/2.7″ Starlight CMOS delivers vivid colour down to 0.003 lx — capture detail in twilight, low ambient or off-axis lighting. Important Install Note Mount the HFW3866EP-AS-AUS at 2.5–4 m on a wall or eave for residential driveways and shop fronts; the 2.8 mm wide lens provides ≈ 6 m optimal facial-ID range, with extended general coverage to 15 m. Use Cat6 from a single 802.3af PoE switch to handle power, video and edge recording on the microSD card. Pair with a Dahua AI/ANZ NVR running V5 firmware to unlock AcuPick metadata search and SMD 4.0 false-alarm filtering directly from the NVR or DMSS app. AI & Smart Detection Human / Vehicle Filter WizSense 3 deep learning classifies humans and vehicles to suppress wildlife, weather and shadow false alarms in residential use. SMD 4.0 Smart Motion Detection 4.0 filters non-relevant motion and pushes only humans / vehicles to the NVR or DMSS app. AcuPick Metadata Search Search hours of recorded footage by clothing colour, vehicle colour, body type and direction on supported Dahua NVRs — find a suspect in seconds. Tripwire & Intrusion Define tripwires and intrusion zones with directional rules — alerts fire only on classified human or vehicle targets. AI SSA AI Scene Self-Adaptation tunes exposure and noise reduction for backlit shop fronts, twilight driveways and reflective surfaces. Smart Event Push Push notifications to DMSS, alarm output and FTP/email upload on AI events — integrate with Dahua DSS or third-party VMS via ONVIF. Technical Specifications Camera, Lens & Illumination Image Sensor 1/2.7″ 8 MP Starlight progressive-scan CMOS Effective Pixels 3840 (H) × 2160 (V) Max Resolution 3840 × 2160 @ 25/30 fps Lens 2.8 mm fixed (4 mm and 6 mm variants available) Field of View H: 102° · V: 53° · D: 124° IR Distance Smart IR up to 30 m Min. Illumination 0.003 lx (colour) · 0 lx with IR WDR / SNR 120 dB true WDR · SNR > 56 dB Day/Night ICR auto switching · AI SSA Intelligence, Audio & Network AI Series WizSense 3 with AcuPick · SMD 4.0 · AI SSA Smart Analytics Human/vehicle classification · tripwire · intrusion · SMD 4.0 · AcuPick metadata search Video Compression H.265 / H.264 / MJPEG (sub stream) · smart codec Audio 1 audio in · 1 audio out · G.711a/u, AAC, G.726 Alarm I/O 1 in · 1 out Storage microSD up to 256 GB · NAS · FTP Network RJ45 10/100 · ONVIF (Profile S/G/T) · CGI, RTSP, SDK Compatibility Dahua DMSS · DSS · SmartPSS · ONVIF VMS Power, Environment & Build Power Supply 12 V DC · PoE (802.3af) Power Consumption < 8 W Operating Temp. −40 °C to +60 °C · < 95% RH Ingress Protection IP67 Material Metal housing Dimensions 241.7 mm × 80 mm × 80 mm Weight ≈ 720 g Certifications CE · FCC · RCM Recommended NVR Pairings DHI-NVR5208-8P-AI/ANZ 8-channel WizMind AI NVR with AcuPick search and full 4K decoding — ideal for residential or small business sites. View → DHI-NVR5216-16P-AI/ANZ 16-channel WizMind AI NVR with AcuPick metadata search and 16 PoE ports — perfect for multi-bullet sites. View → DHI-NVR4216-16P-AI/ANZ 16-channel 4K Smart AI NVR — budget-friendly recorder with full WizSense 3 support. View → DHI-NVR5432-AI/ANZ 32-channel WizSense AI NVR for large commercial sites running multiple 4K bullets across long perimeters. View → Frequently Asked Questions Is the HFW3866EP-AS-AUS NDAA compliant?No. Dahua cameras are not NDAA Section 889 compliant and should not be specified for US federal projects. What does AcuPick do?AcuPick lets you search hours of footage by clothing colour, vehicle colour, body type and direction — cutting evidence retrieval from hours to seconds on supported Dahua NVRs. How wide is the 2.8 mm lens?102° horizontal — wide enough for a typical driveway, front yard or shop floor without losing facial detail in the 0–6 m sweet spot. How far does the IR reach?Smart IR up to 30 m — covers long driveways, side paths and warehouse perimeters with adaptive intensity to avoid overexposure. Does it support PoE?Yes — 802.3af PoE handles power, video and edge recording over a single Cat6 run from your switch or NVR. Can I record to an SD card?Yes — microSD up to 256 GB is supported for failover recording when the network or NVR is offline. Does it work with my third-party VMS?Yes. ONVIF Profile S/G/T is supported — works with Milestone, Genetec, Exacq and Network Optix. What is AI SSA?AI Scene Self-Adaptation automatically adjusts shutter, gain and noise reduction for backlit, low-light or fast-changing scenes — no manual tuning required. What warranty applies in Australia?CCTV Guru provides a 3-year Australian warranty on WizSense 3 cameras including the HFW3866EP-AS-AUS, with local technical support. Does CCTV Guru offer installation?Yes — we have a network of certified installers across Australia. Contact our team for a project quote. Downloads Datasheet (PDF) Quick Start Guide Installation Guide Order Your Dahua DH-IPC-HFW3866EP-AS-AUS from CCTV Guru Buy the Dahua DH-IPC-HFW3866EP-AS-AUS 4K WizSense 3 bullet direct from CCTV Guru, an authorised Australian Dahua reseller. Fast AU-wide shipping, 3-year warranty and local technical support. Need help speccing a multi-camera 4K system or integrating with your existing Dahua NVR? Contact our team →

Read more less

WizSense 3 · 8 MP 4K · Motorised 2.7–13.5 mm · BlackDahua WizSense 3 · 8 MP 4K Motorised TurretDahua DH-IPC-HDW3866TP-ZS-AUS-BLK — 8 MP 4K Motorised Vari-Focal Starlight IR Eyeball Turret WizSense 3 Network Camera Black (3866 Series) The Dahua DH-IPC-HDW3866TP-ZS-AUS-BLK is the 3866 series 8 MP 4K WizSense 3 motorised eyeball turret in black housing — built around a 1/2.7" CMOS Starlight sensor capturing 3840 × 2160 (true 4K) at 15 fps and 4 MP at full 25/30 fps. The motorised 2.7–13.5 mm vari-focal lens delivers a wide 102° field at 2.7 mm down to a tight 27° pull at 13.5 mm — re-frameable from DMSS. Built-in IR reaches up to 40 m; WDR is 120 dB; the compact metal turret housing is IP67 sealed. WizSense 3 deep-learning Pro AI runs perimeter protection (tripwire, intrusion, fast-moving, loitering) with human and vehicle classification, plus SMD 4.0 and AcuPick attribute search. Built-in microphone, 1/1 RCA audio I/O. The black housing blends into dark eaves, soffits, awnings and architectural feature surfaces — a popular choice for modern residential, retail and architectural commercial installs. Backed by a 3-year Australian warranty through CCTV Guru. SKU 3866 series. 3-Year AU Warranty Fast AU-Wide Shipping AU Tech Support Why Choose the Dahua HDW3866TP-ZS-AUS-BLK WizSense 3 4K Motorised Turret True 4K Detail (8 MP) Native 3840 × 2160 at 15 fps, or 4 MP at full 25/30 fps. 4× the pixel density of 1080p — identification-grade detail at distance. Motorised 5× Vari-Focal 2.7–13.5 mm motorised vari-focal — install wide, then pull tight on the area of interest via DMSS. Discreet Black Eyeball Form Black metal turret blends into dark eaves, soffits, awnings and architectural feature surfaces. The discreet matte black aesthetic suits modern architecture. WizSense 3 + AcuPick Perimeter protection, SMD 4.0 and AcuPick attribute search on the WizSense 3 chip. 40 m IR + Starlight 1/2.7" Starlight sensor with usable colour in moonlight; 40 m IR for fully-dark coverage. Built-in Mic + Audio I/O Built-in microphone plus RCA audio I/O for two-way talk integration. Important Install Note The motorised vari-focal lens is remote-controllable via DMSS. The eyeball gimbal allows ±75° pan, ±75° tilt and 0–360° rotation for flexible install alignment. At full 4K resolution, frame rate caps at 15 fps — drop to 4 MP for full 25/30 fps motion. Available also in white as DH-IPC-HDW3866TP-ZS-AUS. AI & Smart Detection AcuPick Attribute Search Search recorded video by colour, clothing, vehicle type — with a Dahua AcuPick NVR. SMD 4.0 Smart Motion Motion alerts triggered only by humans and vehicles. Perimeter Protection Tripwire, intrusion, fast-moving and loitering with human/vehicle classification. AI SSA Scene self-adaptation for rain, fog, backlight. Abnormality Detection SD card, network, IP conflict, tampering events. Two-Way Audio Built-in mic + RCA audio I/O. Technical Specifications Camera, Lens & Illumination Model DH-IPC-HDW3866TP-ZS-AUS-BLK Form Factor Eyeball turret (HDW chassis) — Black Image Sensor 1/2.7" CMOS Starlight Maximum Resolution 3840 × 2160 (8 MP / 4K) Frame Rate 4K @ 15 fps · 4 MP @ 25/30 fps WDR 120 dB Day / Night Auto (ICR) / Colour / B&W Lens Type Motorised vari-focal Focal Length 2.7–13.5 mm Field of View H: 102°–27° IR Illumination Up to 40 m Intelligence, Audio & Network AI Engine WizSense 3 Series IVS Tripwire · intrusion · fast-moving · loitering (human/vehicle) SMD SMD 4.0 AcuPick Yes (with Dahua AcuPick NVR) Built-in Mic Yes Audio I/O 1 in / 1 out (RCA) Network Port RJ-45 (10/100) Interoperability ONVIF (Profile S, G, T) · CGI Storage Micro SD up to 512 GB Mobile Client DMSS Power, Environment & Build Power Supply 12 VDC / PoE (802.3af) Operating Temperature −40 °C to +60 °C Protection IP67 Casing Metal — Black Australian Warranty 3 Years (via CCTV Guru) Recommended NVR Pairings Dahua DHI-NVR5208-8P-AI/ANZ View NVR5208-8P-AI → Dahua DHI-NVR5216-16P-AI/ANZ View NVR5216-16P-AI → Dahua DHI-NVR4216-16P-AI/ANZ View NVR4216-16P-AI → Dahua DHI-NVR5432-AI/ANZ View NVR5432-AI → Frequently Asked Questions NDAA compliant? No. True 4K? Yes — native 3840 × 2160 at 15 fps. Drop to 4 MP for 25/30 fps motion. Re-frame after install? Yes — motorised vari-focal via DMSS. AcuPick? Yes — pair with a Dahua AcuPick NVR. Standard PoE? Yes — 802.3af. Available in white? Yes — DH-IPC-HDW3866TP-ZS-AUS. Night vision? Up to 40 m IR. Audio? Built-in mic + RCA audio I/O. Third-party NVRs? Yes — ONVIF Profile S, G, T. Mobile viewing? Yes — DMSS app. Downloads DH-IPC-HDW3866TP-ZS-AUS-BLK DatasheetDahua IP Turret Camera Quick Start GuideDahua IP Turret Camera Installation Guide Order Your Dahua HDW3866TP-ZS-AUS-BLK from CCTV Guru "Add to cart" to order, or contact our Australian team for project pricing. 3-year Australian warranty. cctvguru.com.au/pages/contact.

Read more less

Dahua WizSense 3 · 8MP 4K Vandal Dome · Motorised Vari-Focal8MP 4K Vandal Dome Dahua DH-IPC-HDBW3866RP-ZAS-AUS — 8MP 4K IR Motorised Vari-Focal Vandal Dome The Dahua DH-IPC-HDBW3866RP-ZAS-AUS is an 8MP IR vari-focal vandal dome in Dahua's WizSense 3 Series — a compact 4K surveillance camera built around a 1/2.8" CMOS sensor, a 2.7–13.5 mm motorised zoom lens with F1.5 aperture, and three IR LEDs delivering up to 40 m of night vision. The dome form factor wall-flushes neatly into ceilings, soffits and undercover walkways, and the housing is rated IK10 vandal-resistant as standard — built to take a hammer strike without breaking the lens cover. This is a focused IR surveillance camera. There are no strobe lights, no siren, no warm-light LED and no active deterrence chain. It's purpose-built for sites that need silent, vandal-tolerant 4K monitoring in a discreet dome — schools, healthcare, aged-care, carparks, loading docks, retail interiors and corridors. Powered by Dahua's WizSense AI with SMD 4.0 human/vehicle classification, IVS perimeter protection, AI Coding, EIS image stabilisation, and 120 dB true WDR. Australian stock, 3-year Australian warranty. Resolution 8MP · 4K · 3840 × 2160 Motorised Zoom 2.7–13.5 mm · F1.5 Night Vision 40 m IR (3 LEDs) AI Engine WizSense · SMD 4.0 · IVS Protection IP67 · IK10 Vandal-Rated Power PoE 802.3af · Max 10.5 W 3-Year Australian Warranty Fast Australia-Wide Shipping Australian Tech Support Why Choose the 8MP Vandal Dome The vandal-dome form factor solves a specific Australian install problem: how to put a 4K motorised camera in a public space — a school corridor, a hospital ward, an undercover carpark, a retail back-of-house — without it being torn off the ceiling or smashed at first opportunity. The IK10-rated housing takes a hammer strike without breaking. The compact dome shape sits flush against the ceiling or soffit. And because there's no strobe, no siren and no warm-light LED, the camera watches quietly without alerting anyone to its presence. IK10 Vandal Resistance — Built In The dome housing is rated IK10: it withstands more than 5 strikes from a 5 kg hammer falling 40 cm (20 J impact energy). The lens cover stays intact and the camera keeps recording — critical for public spaces, schools and corridors where bullets and turrets get torn down. Compact Discreet Dome Form Factor At just 94 mm tall × Φ 122 mm and 713 g, the dome sits flush against ceilings, soffits and undercover surfaces. Less visible than a bullet, harder to grab, and aesthetically suited to architectural interiors. 2.7–13.5 mm Motorised Vari-Focal Five-times optical zoom with remote focus and zoom via DMSS or a Dahua NVR. Set the field of view once at install, then re-tune from your phone whenever the scene changes — no ladder, no re-aiming. WizSense AI — SMD 4.0 + IVS On-camera Smart Motion Detection 4.0 classifies humans and vehicles while filtering out animals, foliage and weather. IVS tripwire and intrusion detection trigger smart alerts — no nuisance alarms. 4K Detail With 109° Wide-Angle Coverage At the 2.7 mm wide end, the dome covers a 109° horizontal field of view at full 4K — a whole carpark, corridor or open-plan space from a single mounting point. At telephoto, the same camera identifies a face at 29 m. 120 dB WDR + AI SSA 120 dB true WDR balances harsh contrast — undercover carparks at noon, glass-walled receptions at sunset, mixed indoor/outdoor lighting. AI Scene Self-Adaptation tunes exposure for rain, fog, backlight, low light and flicker automatically. Smart Features for Real-World Australian Sites Remote Zoom & Auto-Focus Adjust the 2.7–13.5 mm zoom from the DMSS app or a Dahua NVR. The motor handles focus automatically as the lens zooms — no manual focus turret to fiddle with at the camera. IVS Tripwire & Intrusion Zones Define a virtual line across a corridor or a no-go zone around a service door — get a notification only when a human or vehicle actually crosses it. No false alarms from cleaners or moving shadows. EIS Image Stabilisation Electronic Image Stabilisation corrects subtle vibration on long-zoom shots from a ceiling, gantry or pole-mounted dome — keeping the image steady at 13.5 mm telephoto. AI Coding — Lower Bandwidth & Storage Dahua's AI Coding (AI H.265 / AI H.264) analyses the scene and dedicates bitrate only to objects of interest, reducing storage and transmission cost over standard Smart H.265+. External Audio & Alarm I/O The ZAS variant supports 1 audio in / 1 audio out (RCA) plus 1 alarm in / 1 alarm out — connect an external speaker, PIR or door contact. Built-in microphone included on-camera. Edge Recording — MicroSD up to 256 GB On-camera MicroSD records 4K footage independently of the NVR — a redundancy layer if the network drops or the recorder is offline. Pair with a Dahua WizSense AI NVR The 3866RP-ZAS-AUS is a WizSense 3 Series camera. SMD 4.0, IVS rules and human/vehicle classification all run on-camera and work with any Dahua AI NVR — including the value 4-Series WizSense NVRs. With a compatible AI NVR you also unlock Quick Pick — fast human/vehicle target extraction from SMD events. (Note: this camera does not support AcuPick attribute search; if that workflow matters to your site, look at the Smart Dual Light + AcuPick HDBW3867 or HFW3867T line instead.) DHI-NVR4108HS-8P-AI/ANZ — 8 Channel · 8 PoE Value 4-Series WizSense AI NVR — 8 channels, 8 built-in PoE ports, perfect partner for a small-to-mid 3866 dome deployment. View NVR4108HS-8P → DHI-NVR4216-16P-AI/ANZ — 16 Channel · 16 PoE 16-channel 4-Series WizSense AI NVR — room to grow into 16 cameras at full PoE, with AI smart search and human/vehicle filtering on every channel. View NVR4216-16P → DHI-NVR5216-16P-AI/ANZ — 16 Channel · Premium Performance Step up to the 5-Series for higher bandwidth, faster playback search and more advanced AI features — ideal if you're building a larger or higher-spec system around the 3866. Fully backward-compatible with this camera. View NVR5216-16P → DHI-NVR5432-16P-AI/ANZ — 32 Channel · 4 HDD Bays 32-channel 1.5U NVR with 16 PoE and 4 HDD bays — for larger commercial sites, retail chains and multi-building campuses needing more channels and longer retention. View NVR5432-16P → Need help sizing? Browse the complete Dahua NVR range → or contact our Australian team for a tailored recommendation based on your camera count and retention requirements. Technical Specifications DH-IPC-HDBW3866RP-ZAS-AUS · Full Specifications SKU DH-IPC-HDBW3866RP-ZAS-AUS Camera Type 8MP IR Vari-focal Vandal Dome · WizSense 3 Series Image Sensor 1/2.8" Progressive Scan CMOS Max Resolution 3840 × 2160 (8MP / 4K) @ 25/30 fps Lens Type Motorised vari-focal · 2.7–13.5 mm · φ14 mount Maximum Aperture F1.5 Field of View H: 109°–30° · V: 56°–17° · D: 131°–35° Close Focus Distance 0.8 m DORI — Wide (2.7 mm) Detect 88.3 m · Observe 35.3 m · Recognise 17.7 m · Identify 8.8 m DORI — Tele (13.5 mm) Detect 289.7 m · Observe 115.7 m · Recognise 57.9 m · Identify 29.0 m Min. Illumination Colour: 0.007 lux @ F1.5 · B/W: 0.0007 lux · 0 lux (Illuminator on) S/N Ratio > 56 dB Dynamic Range 120 dB True WDR Day & Night Auto (ICR) / Colour / B&W Illuminators 3 × IR LED · Up to 40 m (no warm light · no active deterrence) Image Enhancement WDR · 3D NR · HLC · BLC · Defog · AFSA · AI SSA · Smart Illumination · EIS · Image Rotation · Privacy masking (4 areas) · Digital watermarking Intelligent Video WizSense AI · SMD 4.0 · IVS (Tripwire, Intrusion · human/vehicle classification) · Quick Pick (with AI NVR) · Smart Search · AI SSA Active Deterrence Not included — silent IR surveillance camera Video Compression H.265 · H.264 · H.264H · H.264B · MJPEG (sub-stream) · Smart H.265+ / H.264+ · AI H.265 / AI H.264 Streaming 3 streams — Main 3840×2160 · Sub 1 704×576 · Sub 2 1920×1080 (Full HD) Video Bitrate H.264 / H.265: 3 kbps – 8,192 kbps Audio Built-in microphone · G.711a / G.711Mu / G.726 / G.723 / PCM compression Audio I/O (ZAS only) 1 audio in (RCA) · 1 audio out (RCA) Alarm I/O (ZAS only) 1 alarm in (5 mA, 3–5 V DC) · 1 alarm out (300 mA, 12 V DC) IP Camera Protocol ONVIF Profile S/G/T · CGI · P2P · Milestone · Genetec Network Protocols IPv4/v6 · HTTP/HTTPS · TCP/UDP · RTP/RTSP/RTCP/RTMP · SMTP · FTP/SFTP · DHCP · DDNS · UPnP · NTP · ICMP · IGMP · NFS · SAMBA · PPPoE · SNMP Cyber Security Trusted boot · Trusted execution · Trusted upgrade · HTTPS · 802.1x · IP/MAC filtering · X.509 import · syslog · video/firmware/config encryption · account lockout Ethernet RJ-45 (10/100BASE-T) Edge Storage MicroSD up to 256 GB · NAS · FTP / SFTP Weatherproof Rating IP67 Vandal Resistance IK10 (20 J impact energy) Operating Temperature −30 °C to +60 °C · < 95% RH Storage Temperature −40 °C to +60 °C Power Source 12 V DC / PoE (IEEE 802.3af) · ±30% wide voltage Power Consumption Basic 4 W (12 V DC) / 4.9 W (PoE) · Max 9.2 W (12 V DC) / 10.5 W (PoE) Memory ROM 128 MB · RAM 1 GB Pan / Tilt / Rotation Pan 0°–355° · Tilt 0°–80° · Rotation 0°–355° (manual aim at install) Mobile App DMSS · Smart PSS · DSS (iOS & Android) Approvals CE-LVD (EN 62368-1) · CE-EMC 2014/30/EU · FCC Part 15 Subpart B · UL/CUL 62368-1 Housing Metal · White Dimensions 94 mm × Φ 122 mm Weight 713 g (net) · 986 g (gross) Warranty 3-Year Australian Warranty (back-to-base) HDBW3866RP-ZAS-AUS (Dome) vs HFW3866TP-ZAS-AUS (Bullet) — Which Form Factor? Both cameras share the same 1/2.8" sensor, same 8MP 4K resolution, same 2.7–13.5 mm motorised lens, same F1.5 aperture, same WizSense 3 AI engine and the same DORI distances. The deciding question is install footprint and IR reach: do you want a compact vandal-rated dome with 40 m IR, or a long-range bullet with a 60 m IR and integrated sun shield? HDBW3866RP-ZAS-AUS (Vandal Dome) vs HFW3866TP-ZAS-AUS (Bullet) Feature DH-IPC-HDBW3866RP-ZAS-AUS (this vandal dome) DH-IPC-HFW3866TP-ZAS-AUS (bullet sibling) Form Factor Compact vandal dome Long bullet with sun shield Vandal Resistance IK10 built-in (20 J impact) IK10 optional configuration IR Distance 40 m (3 LEDs) 60 m (4 LEDs) Sun Shield No (dome housing) Integrated Image Sensor 1/2.8" CMOS 1/2.8" CMOS Max Resolution 8MP · 3840 × 2160 (4K) 8MP · 3840 × 2160 (4K) Lens 2.7–13.5 mm motorised · F1.5 2.7–13.5 mm motorised · F1.5 FOV (wide) 109° H 109° H DORI Identify (tele) 29.0 m 29.0 m Smart Dual Light No (IR only) No (IR only) AcuPick AI Search No No SMD Version SMD 4.0 SMD 4.0 Quick Pick (with AI NVR) Yes Yes AI Coding Yes (AI H.265 / H.264) Yes (AI H.265 / H.264) EIS Stabilisation Yes Yes WDR 120 dB True WDR 120 dB True WDR Max Video Bitrate 8,192 kbps 8,192 kbps MicroSD Up to 256 GB Up to 256 GB Ingress Protection IP67 IP67 Operating Temperature −30 °C to +60 °C −40 °C to +60 °C Pan / Tilt 0°–355° / 0°–80° 0°–360° / 0°–90° Power (Max PoE) 10.5 W 10.5 W Dimensions 94 × Φ 122 mm (compact dome) 244 × 79 × 76 mm (long bullet) Net Weight 713 g 820 g Colour White White Australian Warranty 3 years back-to-base 3 years back-to-base Best For Indoor / undercover installs, public corridors, schools, hospitals, retail interiors, anywhere a discreet flush-mounted IK10 dome matters more than long-range IR. Exposed pole and gable mounts, sites where 60 m IR reach and sun-shield protection matter more than discreet form factor. Compatible Mounts & Accessories Dahua PFA137 Junction Box Bracket Recessed IP66 junction box for clean cable concealment on exposed brick, render or weatherboard. Mounts the dome cleanly without surface cable runs. View product → Dahua PFA109 Mount Adapter Required adapter to fit the 3866RP dome onto Dahua wall and pole brackets. View product → Dahua PFB220C Ceiling Mount Bracket Drop-down ceiling bracket for retail awnings, undercover car parks and warehouse interiors. View product → Dahua PFB203W Wall Mount Wall-mount bracket specifically for vandal dome cameras — projects the dome out from the wall to widen field of view past the building line. View Dahua accessories → Dahua PFA152-E Pole Mount Heavy-duty pole bracket for fence posts, light poles and gate columns. Pairs with the PFA109 adapter for dome mounting. View product → WD Purple 256 GB Surveillance MicroSD Card Western Digital Purple — purpose-built for 24/7 surveillance read/write cycles, far longer endurance than consumer microSD cards. Maxes out the 3866RP's 256 GB MicroSD ceiling. View WD Purple 256 GB → Frequently Asked Questions What does IK10 vandal resistance mean in practice? IK10 is the highest IK rating in the IEC 62262 impact-resistance standard. The dome housing can withstand more than 5 strikes from a 5 kg hammer falling 40 cm — 20 J of impact energy — without cracking or losing function. Translation: a teenager swinging a brick won't take the camera offline. Does this camera have active deterrence (strobe / siren)? No. The HDBW3866RP-ZAS-AUS is a silent 4K IR surveillance camera — no red/blue strobe, no built-in siren, no voice broadcast, no warm-light LED. If you need active deterrence, look at the Dahua TiOC line (HDW3849H-AS-PV-ANZ-S2 turret is the closest in form factor). Does it support AcuPick AI search? No. AcuPick is reserved for the Smart Dual Light AcuPick line-up (e.g. HFW3867T-ZAS-IL-ANZ bullet). This dome supports SMD 4.0 human/vehicle classification, IVS tripwire/intrusion, and Quick Pick (with an AI NVR) — sufficient for most surveillance workflows without the AcuPick attribute search overhead. Why pick the dome over the bullet form factor? Two reasons. First, vandal resistance — the IK10 dome housing is built to take physical abuse, where a bullet can be grabbed and ripped off. Second, discreet flush mounting — the compact 94 mm dome sits neatly into a ceiling, soffit or undercover surface, while a 244 mm bullet sticks out visibly. Trade-off: shorter 40 m IR range vs the bullet's 60 m, and no integrated sun shield. Can the camera pan and tilt remotely? No. The HDBW3866RP-ZAS is a motorised vari-focal vandal dome, not a PTZ. The lens supports remote zoom and auto-focus, but the camera's three-axis gimbal is for manual aim at install time only (Pan 0–355°, Tilt 0–80°, Rotation 0–355°). For a fully remote PTZ, look at a Dahua PTZ dome. How does the 5× motorised zoom work? At wide-angle (2.7 mm) the camera covers a 109° horizontal field of view — enough for a full corridor or open-plan space from a single mounting point. At telephoto (13.5 mm) you can pull tight on a specific zone — an entry door, a service counter, a checkout aisle. Remote zoom from the DMSS app means you can re-tune the field of view as the site changes. Does it have a built-in microphone? Yes — the camera has a built-in microphone for capturing scene audio. The ZAS variant also adds external audio in / out (RCA) for connecting an external mic or speaker, plus alarm in / out for PIRs or door contacts. Will it keep recording if the NVR or internet goes down? Yes. The on-board MicroSD slot accepts cards up to 256 GB and records 4K footage independently of the NVR. Is the camera suitable for Australian outdoor conditions? Yes. It is rated IP67, IK10 vandal-resistant and −30 °C to +60 °C. The all-metal housing and ±30% wide-voltage tolerance handle coastal salt, undercover carpark grime and unstable rural mains. Note: for the widest operating temperature range (−40 °C to +60 °C), the HFW3866TP-ZAS-AUS bullet has a wider rated spec. Does it work with Hikvision NVRs or third-party VMS? Yes — recording, streaming, motion and the WizSense AI metadata work over ONVIF Profile S/G/T on most third-party NVRs and VMS platforms (Milestone, Genetec, Hanwha WAVE, ExacqVision, Blue Iris, Synology). For the smartest integration (Quick Pick, push notifications, remote zoom from the app), pair it with a Dahua AI NVR. What is the warranty and where is it serviced? This camera ships with a 3-year Australian Dahua warranty, serviced back-to-base by Dahua Australia. CCTV Guru handles the entire RA process and provides Australian-based technical support for the life of the product. Do you ship Australia-wide and is stock genuine? Yes — Australian stock from authorised Dahua Australia channels (not parallel imports). We ship Australia-wide every business day with same-day dispatch on orders placed before 2 pm AEST to Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra, Darwin and regional addresses. Downloads & Resources DH-IPC-HDBW3866RP-ZAS-AUS Datasheet Dahua Dome Quick Start Guide Order the Dahua DH-IPC-HDBW3866RP-ZAS-AUS from CCTV Guru CCTV Guru is an authorised Australian reseller of Dahua WizSense network cameras. Order the 8MP 4K IR motorised vari-focal vandal dome today for fast Australia-wide dispatch, expert pre-sales advice, project pricing for larger rollouts and full local warranty support. For multi-camera projects, contact our Australian team for a tailored quote, NVR sizing and installation guidance — request a free quote or contact the team.

Read more less

WizSense 3 · 4 MP · IR 50 m · IK10 Vandal Dome4 MP Vandal DomeDahua DH-IPC-HDBW3466FP-AS-AUS — 4 MP IR Fixed-Focal Vandal Dome WizSense 3 Network Camera (3466 Series) The Dahua DH-IPC-HDBW3466FP-AS-AUS is the 3466 series 4 MP WizSense 3 vandal dome — built around a 1/3" CMOS sensor capturing 2688 × 1520 at 25/30 fps with Smart H.265+ encoding. A 2.8 mm F1.6 fixed lens provides a wide 105° field of view; built-in IR reaches up to 50 m for long-range night surveillance; WDR is 120 dB; the IK10 vandal-rated metal dome housing is IP67 sealed. WizSense 3 deep-learning edge AI runs perimeter protection (tripwire, intrusion) with human and vehicle classification, plus SMD 4.0 and AcuPick for attribute-based recorded-video search when paired with a Dahua AcuPick NVR. Built-in microphone, RCA audio I/O and 1/1 alarm wet-contact pair round out the spec. Built for Australian retail interiors, transport platforms, school grounds, council reserves and high-vandalism positions where a vandal dome is preferred over a bullet. Backed by a 3-year Australian warranty through CCTV Guru. SKU 3466 series. 3-Year AU Warranty Fast AU-Wide Shipping AU Tech Support Why Choose the Dahua HDBW3466FP-AS-AUS WizSense 3 Vandal Dome IK10 Vandal Dome — Metal Housing Metal housing with IK10 impact rating — built for transport platforms, schools, retail interiors and shopping centres where vandalism risk is real. The dome chassis discourages tampering. True 4 MP Detail at 25/30 fps Native 2688 × 1520 at full 25/30 fps. More than double the pixel density of 1080p, with smooth full-motion video for retail and transport sites. WizSense 3 Edge AI + AcuPick Perimeter protection, SMD 4.0 and AcuPick attribute search run on the WizSense 3 deep-learning chip. AcuPick lets you search recorded video by clothing colour, vehicle type and direction when paired with a Dahua AcuPick NVR. 50 m Long-Range IR Built-in IR array reaches up to 50 m — long-range night surveillance for large retail floors, transport platforms and undercover carparks. 120 dB WDR for AU Sun Strong wide dynamic range holds detail in both the bright sky and the dark interior in a single frame — important for awning-shaded entries and glass shopfronts. Standard PoE & Audio I/O 802.3af PoE-compatible with a modest power budget. Built-in mic plus RCA audio I/O for two-way talk or external mic/speaker integration. Important Install Note This camera is fixed-focal (2.8 mm) — frame at install time. The dome gimbal allows three-axis adjustment for flexible install alignment. Audio recording is subject to local privacy law — check NDIS, retail and public-space rules before enabling. AI & Smart Detection Capabilities AcuPick Attribute Search Search recorded video by colour, top/bottom clothing, vehicle type and direction — with a compatible Dahua AcuPick NVR. SMD 4.0 Smart Motion Motion alerts triggered only by humans and vehicles. Filters out branches, animals, shadows. Perimeter Protection (IVS) Tripwire and intrusion zones with human/vehicle classification. AI SSA Scene Self-Adaptation Automatic image-parameter adjustment for rain, fog, backlight, low light and flicker. Abnormality Detection SD card, network, IP conflict, tampering, audio, voltage events — pushed to DMSS. Two-Way Audio & Alarm I/O Built-in mic + RCA audio I/O; alarm I/O for third-party alarm system integration. Technical Specifications Camera & Image Sensor Model DH-IPC-HDBW3466FP-AS-AUS Form Factor Vandal dome (HDBW chassis) Image Sensor 1/3" CMOS Maximum Resolution 2688 × 1520 (4 MP) Frame Rate 4 MP @ 25/30 fps WDR 120 dB Day / Night Auto (ICR) / Colour / B&W IR Illumination Up to 50 m Lens, Intelligence & Network Lens Type Fixed-focal 2.8 mm F1.6 Field of View H: ~105° AI Engine WizSense 3 Series IVS Tripwire · intrusion (with human/vehicle classification) SMD SMD 4.0 AcuPick Yes (with Dahua AcuPick NVR) Audio Built-in mic · 1/1 RCA audio I/O Alarm I/O 1 in / 1 out Network Port RJ-45 (10/100 Base-T) Interoperability ONVIF (Profile S, G, T) · CGI Storage Micro SD up to 512 GB Mobile Client DMSS (iOS / Android) Power, Environment & Build Power Supply 12 VDC / PoE (802.3af) Operating Temperature −30 °C to +60 °C Protection IP67 · IK10 vandal Casing Metal Certifications CE-LVD (EN62368-1) · CE-EMC (2014/30/EU) · RCM (AU) Australian Warranty 3 Years (via CCTV Guru) How It Compares — HDBW3466FP (Fixed) vs HDBW3466RP-ZAS (Motorised) The natural sibling is the Dahua DH-IPC-HDBW3466RP-ZAS-AUS — the motorised vari-focal 2.7–13.5 mm version of this same 4 MP WizSense 3 vandal dome. Choose this fixed version for predictable framing and lower cost; choose the motorised version for app-controlled re-framing and longer zoom reach. Feature HDBW3466FP-AS-AUS (this — fixed) HDBW3466RP-ZAS-AUS (sibling — motorised) Resolution 4 MP (2688 × 1520) 4 MP (2688 × 1520) Lens Fixed 2.8 mm F1.6 Motorised 2.7–13.5 mm vari-focal AI Engine WizSense 3 + AcuPick WizSense 3 + AcuPick IR Distance Up to 50 m Up to 50 m Remote Re-Framing No — fixed install framing Yes — via DMSS app IK10 Vandal Yes Yes Best For Predictable install framing at lower cost Variable framing requirements with longer zoom reach Recommended NVR Pairings Dahua DHI-NVR5208-8P-AI/ANZ 5-Series AcuPick NVR · 8 channels · 8 PoE ports. View Dahua NVR5208-8P-AI → Dahua DHI-NVR5216-16P-AI/ANZ 5-Series AcuPick NVR · 16 channels · 16 PoE+ ports. View Dahua NVR5216-16P-AI → Dahua DHI-NVR4216-16P-AI/ANZ 4-Series WizSense AI NVR · 16 channels · 16 PoE ports. View Dahua NVR4216-16P-AI → Dahua DHI-NVR5432-AI/ANZ 5-Series AcuPick NVR · 32 channels · 4 HDD bays. View Dahua NVR5432-AI → Frequently Asked Questions Is the Dahua HDBW3466FP-AS-AUS NDAA compliant? No. Dahua is not certified under NDAA Section 889. What does "IK10" mean? IK10 is the highest impact rating in the IK protection standard — the dome can withstand an impact equivalent to 5 kg dropped from 40 cm. Designed for high-vandalism positions. Does the camera include AcuPick? Yes. To use attribute-based recorded-video search, pair with a compatible Dahua 5-Series AcuPick NVR. Can I run this camera on standard PoE? Yes — 802.3af-compliant. Any quality PoE switch will run it comfortably. How far can it see at night? Up to 50 m built-in IR — long-range night surveillance with even illumination. Does it have audio? Yes — built-in microphone plus RCA audio I/O for external mic or speaker. Does it work with third-party NVRs? Yes — ONVIF Profile S, G, T. AcuPick and SMD 4.0 alarm push only work end-to-end on a Dahua AI NVR. What temperature range is it rated for? −30 °C to +60 °C. Suitable for most Australian sites. What's the difference between this and the motorised HDBW3466RP-ZAS? Same WizSense 3 platform and AcuPick. This fixed version uses a 2.8 mm fixed lens (lower cost, simpler); the motorised version has a 2.7–13.5 mm motorised vari-focal for app-controlled re-framing. Can I view it on my phone? Yes — Dahua's free DMSS app on iOS and Android. Downloads DH-IPC-HDBW3466FP-AS-AUS DatasheetDahua IP Dome Camera Quick Start GuideDahua IP Dome Camera Installation GuideDahua IP Dome Camera Operational Manual Order Your Dahua HDBW3466FP-AS-AUS from CCTV Guru "Add to cart" to order online, or contact our Australian team for project pricing, multi-camera fleet deployments and NVR sizing advice. We are authorised Australian Dahua resellers, hold stock locally, and back every 3466 series camera with a 3-year Australian warranty. Phone, email or live chat us through cctvguru.com.au/pages/contact — most enquiries answered the same business day.

Read more less

Dahua WizSense 3 · 8MP 4K Bullet · Motorised Vari-Focal · 60 m IR8MP 4K Bullet Dahua DH-IPC-HFW3866TP-ZAS-AUS — 8MP 4K IR Motorised Vari-Focal Bullet The Dahua DH-IPC-HFW3866TP-ZAS-AUS is an 8MP IR vari-focal bullet in Dahua's WizSense 3 Series — a long-range surveillance camera built around a 1/2.8" CMOS sensor, a 2.7–13.5 mm motorised vari-focal lens, four IR LEDs delivering 60 m of night vision, and on-camera SMD 4.0 AI to filter false alarms. This is a focused IR surveillance camera — there are no strobe lights, no siren, no warm-light LED and no active deterrence chain. It's purpose-built for sites that need silent, long-range 4K monitoring rather than visible deterrence. Powered by Dahua's WizSense AI, the camera supports perimeter protection (tripwire + intrusion with human/vehicle classification), AI SSA scene adaptation, EIS image stabilisation, 120 dB true WDR and AI Coding for reduced bandwidth and storage. Paired with a Dahua AI NVR, Quick Pick surfaces human and vehicle targets straight from SMD events for faster review. The compact metal bullet body is IP67 sealed, with IK10 vandal resistance available as an optional configuration. White only. Australian stock, 3-year Australian warranty. Resolution 8MP · 4K · 3840 × 2160 Motorised Zoom 2.7–13.5 mm · F1.5 Night Vision 60 m IR (4 LEDs) AI Engine WizSense · SMD 4.0 · IVS Protection IP67 · IK10 (optional) Power PoE 802.3af · Max 10.5 W 3-Year Australian Warranty Fast Australia-Wide Shipping Australian Tech Support Why Choose the 8MP IR Motorised Bullet Not every site wants — or is allowed to have — a camera that flashes red and blue strobes and sounds a siren at every fox or possum. For Australian schools, aged-care facilities, healthcare campuses, residential frontages near neighbours, retail interiors and corporate sites, the right camera is one that watches quietly at 4K, illuminates the scene with invisible IR out to 60 m, and lets the rest of the security stack (NVR alerts, monitored response, mobile push) decide what happens next. The 3866TP-ZAS-AUS is built for exactly that role. 4K Surveillance Without Light Pollution Invisible IR illumination from four LEDs reaches out to 60 m. No flashing strobes, no warm-light spill into neighbouring properties, no audible alarms — eyes on the scene without announcing it. 60 m IR Range Four IR LEDs combined with the 5× zoom lens deliver clear night-time monitoring deep into large yards, long driveways and commercial perimeters where shorter-range cameras simply run out of light. 2.7–13.5 mm Motorised Vari-Focal Five-times optical zoom with remote focus and zoom control via DMSS or a Dahua NVR. Set the field of view once at install, then re-tune from your phone whenever the scene changes — no ladder, no re-aiming. SMD 4.0 — Near-Zero False Alarms Dahua's Smart Motion Detection 4.0 runs on-camera, classifying humans and vehicles while filtering out animals, foliage and weather. Sleep through the night, not through the alarm. 120 dB WDR + AI SSA 120 dB true WDR balances harsh contrast (sunset doorways, undercover carparks, mixed lighting). AI Scene Self-Adaptation tunes exposure for rain, fog, backlight, low light and flicker automatically. IP67 Metal Body + IK10 Option Fully sealed against dust and water in a compact all-metal bullet chassis. IK10 vandal-resistance is available as an optional configuration — engineered for carparks, loading docks, school perimeters and high-traffic environments. Smart Features for Real-World Australian Sites Remote Zoom & Auto-Focus Adjust the 2.7–13.5 mm zoom from the DMSS app or a Dahua NVR. The motor handles focus automatically as the lens zooms — no manual focus turret to fiddle with at the camera. IVS Tripwire & Intrusion Zones Define a virtual line across the driveway or a no-go zone around the shed — get a notification only when a human or vehicle actually crosses it. No false alarms from leaves blowing in the wind. EIS Image Stabilisation Electronic Image Stabilisation corrects subtle vibration on long-zoom shots from a pole, gable or fence — keeping the image steady at 13.5 mm telephoto where small movements are most visible. AI Coding — Lower Bandwidth & Storage Dahua's AI Coding (AI H.265 / H.264) analyses the scene and dedicates bitrate only to objects of interest, reducing storage and transmission cost over standard Smart H.265+. External Audio & Alarm I/O The ZAS variant supports 1 audio in / 1 audio out (RCA) plus 1 alarm in / 1 alarm out — connect an external speaker, PIR or door contact to extend the camera's capability. Built-in microphone included on-camera. Edge Recording — MicroSD up to 256 GB On-camera MicroSD records 4K footage independently of the NVR — a redundancy layer if the network drops or the recorder is offline. Pair with a Dahua WizSense AI NVR The 3866TP-ZAS-AUS is a WizSense 3 Series camera. SMD 4.0, IVS rules and human/vehicle classification all run on-camera and work with any Dahua AI NVR — including the value 4-Series WizSense NVRs. With a compatible AI NVR you also unlock Quick Pick — fast human/vehicle target extraction from SMD events. (Note: this camera does not support AcuPick attribute search; if that workflow matters to your site, look at the TiOC AcuPick line instead.) DHI-NVR4108HS-8P-AI/ANZ — 8 Channel · 8 PoE Value 4-Series WizSense AI NVR — 8 channels, 8 built-in PoE ports, perfect partner for a small-to-mid 3866 deployment. View NVR4108HS-8P → DHI-NVR4216-16P-AI/ANZ — 16 Channel · 16 PoE 16-channel 4-Series WizSense AI NVR — room to grow into 16 cameras at full PoE, with AI smart search and human/vehicle filtering on every channel. View NVR4216-16P → DHI-NVR5216-16P-AI/ANZ — 16 Channel · Premium Performance Step up to the 5-Series for higher bandwidth, faster playback search and more advanced AI features — ideal if you're building a larger or higher-spec system around the 3866. Fully backward-compatible with this camera. View NVR5216-16P → DHI-NVR5432-16P-AI/ANZ — 32 Channel · 4 HDD Bays 32-channel 1.5U NVR with 16 PoE and 4 HDD bays — for larger commercial sites, retail chains and multi-building campuses needing more channels and longer retention. View NVR5432-16P → Need help sizing? Browse the complete Dahua NVR range → or contact our Australian team for a tailored recommendation based on your camera count and retention requirements. Technical Specifications DH-IPC-HFW3866TP-ZAS-AUS · Full Specifications SKU DH-IPC-HFW3866TP-ZAS-AUS (White only) Camera Type 8MP IR Vari-focal Bullet · WizSense 3 Series Image Sensor 1/2.8" Progressive Scan CMOS Max Resolution 3840 × 2160 (8MP / 4K) @ 25/30 fps Lens Type Motorised vari-focal · 2.7–13.5 mm · φ14 mount Maximum Aperture F1.5 Field of View H: 109°–30° · V: 56°–17° · D: 131°–35° Close Focus Distance 0.8 m DORI — Wide (2.7 mm) Detect 88.3 m · Observe 35.3 m · Recognise 17.7 m · Identify 8.8 m DORI — Tele (13.5 mm) Detect 289.7 m · Observe 115.7 m · Recognise 57.9 m · Identify 29.0 m Min. Illumination Colour: 0.007 lux @ F1.5 · B/W: 0.0007 lux · 0 lux (Illuminator on) S/N Ratio > 56 dB Dynamic Range 120 dB True WDR Day & Night Auto (ICR) / Colour / B&W Illuminators 4 × IR LED · Up to 60 m (no warm light · no active deterrence) Image Enhancement WDR · 3D NR · HLC · BLC · Defog · AFSA · AI SSA · Smart Illumination · EIS · Image Rotation · Digital watermarking Intelligent Video WizSense AI · SMD 4.0 · IVS (Tripwire, Intrusion · human/vehicle classification) · Quick Pick (with AI NVR) · Smart Search · AI SSA Active Deterrence Not included — silent IR surveillance camera Video Compression H.265 · H.264 · H.264H · H.264B · MJPEG (sub-stream) · Smart H.265+ / H.264+ · AI H.265 / AI H.264 Streaming 3 streams — Main 3840×2160 · Sub 1 704×576 · Sub 2 1920×1080 (Full HD) Video Bitrate H.264 / H.265: 3 kbps – 8,192 kbps Audio Built-in microphone · G.711a / G.711Mu / G.726 / G.723 / PCM compression Audio I/O (ZAS only) 1 audio in (RCA) · 1 audio out (RCA) Alarm I/O (ZAS only) 1 alarm in (5 mA, 3–5 V DC) · 1 alarm out (300 mA, 12 V DC) IP Camera Protocol ONVIF Profile S/G/T · CGI · P2P · Milestone · Genetec Network Protocols IPv4/v6 · HTTP/HTTPS · TCP/UDP · RTP/RTSP/RTCP/RTMP · SMTP · FTP/SFTP · DHCP · DDNS · UPnP · NTP · ICMP · IGMP · NFS · SAMBA · PPPoE · SNMP · 802.1x Cyber Security Trusted boot · Trusted execution · Trusted upgrade · HTTPS · 802.1x · IP/MAC filtering · X.509 import · syslog · video/firmware/config encryption · account lockout Ethernet RJ-45 (10/100BASE-T) Edge Storage MicroSD up to 256 GB · NAS · FTP / SFTP Weatherproof Rating IP67 Vandal Resistance IK10 (optional configuration) Operating Temperature −30 °C to +60 °C · < 95% RH Storage Temperature −40 °C to +60 °C Power Source 12 V DC / PoE (IEEE 802.3af) · ±30% wide voltage Power Consumption Basic 4 W (12 V DC) / 4.9 W (PoE) · Max 9.2 W (12 V DC) / 10.5 W (PoE) Memory ROM 128 MB · RAM 1 GB Pan / Tilt / Rotation Pan 0°–360° · Tilt 0°–90° · Rotation 0°–360° Mobile App DMSS · Smart PSS · DSS (iOS & Android) Approvals CE-LVD (EN 62368-1) · CE-EMC 2014/30/EU · FCC Part 15 Subpart B · UL/CUL 62368-1 Housing Metal · White only Dimensions 244.1 × 79.0 × 75.9 mm (L × W × H) Weight 820 g (net) · 1090 g (gross) Warranty 3-Year Australian Warranty (back-to-base) 3866TP-ZAS-AUS vs 3849T1-ZAS-PV-ANZ-S2 — Silent or Active Deterrence? Both cameras are 4K motorised vari-focal bullets sharing the same WizSense AI engine, SMD 4.0, IVS perimeter protection and IP67 rating. The deciding question is the deterrence chain: do you want the camera to actively scare off intruders, or quietly record them? The 3866TP-ZAS-AUS is the silent surveillance camera — longer 60 m IR reach, no strobe, no siren, no warm light. The 3849T1-ZAS-PV-ANZ-S2 is the active deterrence camera — adds red/blue strobe, siren, voice broadcast, warm-light LED, on-board speaker, dual MIC and AcuPick AI compatibility, at the cost of slightly shorter 50 m IR. 3866TP-ZAS-AUS (Silent IR) vs 3849T1-ZAS-PV-ANZ-S2 (TiOC Active Deterrence) Feature DH-IPC-HFW3866TP-ZAS-AUS (this silent bullet) DH-IPC-HFW3849T1-ZAS-PV-ANZ-S2 (TiOC bullet) Series Position WizSense 3 — Silent IR Surveillance TiOC 3.0 — Active Deterrence Max Resolution 8MP · 3840 × 2160 (4K) 8MP · 3840 × 2160 (4K) Image Sensor 1/2.8" CMOS 1/2.8" CMOS Lens Motorised vari-focal · 2.7–13.5 mm Motorised vari-focal · 2.7–13.5 mm Max Aperture F1.5 F1.2 FOV — Wide 109° H 108° H IR Distance 60 m (4 LEDs) 50 m Warm Light No Yes — 40 m Red/Blue Strobe No Yes Built-in Siren No Yes Voice Broadcast No Yes — custom audio Built-in Speaker No — external audio out only Yes — 1-channel Microphone Built-in (single) Built-in (dual) Two-Way Audio External speaker via audio out Yes — talk-down via DMSS / NVR WDR 120 dB True WDR 120 dB True WDR WizSense AI (SMD 4.0 / IVS) Yes Yes Quick Pick (with AI NVR) Yes Yes AcuPick AI Search No Yes — with 5-Series NVR AI Coding Yes (AI H.265 / H.264) Yes (AI H.265 / H.264) EIS Stabilisation Yes Yes Max Video Bitrate 8,192 kbps 8,192 kbps MicroSD Up to 256 GB Up to 256 GB Vandal Resistance IK10 (optional) — Ingress Protection IP67 IP67 Operating Temperature −30 °C to +60 °C −30 °C to +60 °C Power (Max PoE) 10.5 W 9.8 W Housing Metal · 244 × 79 × 76 mm · 820 g Metal + Plastic · 288 × 94 × 85 mm · 1.05 kg Colour Options White only White & Black Australian Warranty 3 years back-to-base 3 years back-to-base Best For Schools, healthcare, aged-care, residential properties near neighbours, retail interiors, sites where silent surveillance and longer 60 m IR matter more than active deterrence. Driveways, perimeters, tradie yards, shop fronts — anywhere you want the camera to actively scare off intruders, not just record them. Compatible Mounts & Accessories Dahua PFA135 Junction Box Bullet-specific junction box for clean cable concealment behind the camera mount. Indoor / sheltered installs. View Dahua accessories → Dahua PFA130-E Waterproof Junction Box Waterproof junction box for exposed outdoor bullet mounting on render, brick or weatherboard. View Dahua accessories → Dahua PFA152-E Pole Mount Heavy-duty pole bracket — the typical install partner for long-range bullet cameras on fence posts, light poles and gate columns. View product → Dahua PFM900-E Integrated Mount Tester On-site display + power-test tool for commissioning bullet cameras from the ladder. Especially useful when setting the zoom and focus on the vari-focal lens. View Dahua accessories → Dahua PFM321D 12 V DC Power Adapter 1A power adapter for sites not running PoE — bench testing, retrofit installs into existing 12 V power runs. View Dahua accessories → WD Purple 256 GB Surveillance MicroSD Card Western Digital Purple — purpose-built for 24/7 surveillance read/write cycles, far longer endurance than consumer microSD cards. Maxes out the 3866TP's 256 GB MicroSD ceiling. View WD Purple 256 GB → Frequently Asked Questions Does this camera have active deterrence (strobe / siren)? No. The 3866TP-ZAS-AUS is a silent 4K IR surveillance camera — it does not include red/blue strobe lights, built-in siren or voice broadcast, and it does not include a warm-light LED. If you need active deterrence, look at the Dahua TiOC line-up (HFW3849T1-ZAS-PV-ANZ-S2 is the closest equivalent in the same form factor). Does it support AcuPick AI search? No. AcuPick is reserved for Dahua's TiOC AcuPick line-up. This camera is part of the WizSense 3 Series and supports SMD 4.0 human/vehicle classification, IVS tripwire/intrusion, and Quick Pick (with an AI NVR) — all of which work on-camera or with any Dahua AI NVR. What is Quick Pick and how is it different from AcuPick? Quick Pick lets you pull human and vehicle targets straight from SMD events when the camera is paired with an AI NVR. AcuPick goes further — it indexes attribute metadata (clothing colour, vehicle type) so you can search live and recorded video by attribute. Quick Pick is "show me the people from this clip"; AcuPick is "show me everyone wearing red across the entire week". Can the camera pan and tilt remotely? No. The 3866TP-ZAS is a motorised vari-focal bullet, not a PTZ. The lens supports remote zoom and auto-focus, but the camera body itself does not pan or tilt remotely — the housing is aimed manually at install time. For full remote pan/tilt/zoom, look at a Dahua PTZ. How much does the 5× motorised zoom cover at full telephoto? At 13.5 mm telephoto, the camera will detect motion at 289.7 m, recognise a person at 57.9 m, and identify a face at 29.0 m. At the 2.7 mm wide end, it covers a 109° horizontal field of view — a full driveway or carpark from a single mounting point. What does the camera see at night? Four IR LEDs deliver 60 m of infrared illumination, producing clear monochrome 4K footage in complete darkness. In low-light colour conditions (e.g. ambient streetlight) the 1/2.8" sensor produces usable colour image at 0.007 lux before the IR cuts in. Does it have a built-in microphone? Yes — the camera has a built-in microphone for capturing scene audio. The ZAS variant also adds external audio in / out (RCA) for connecting an external mic or speaker, plus alarm in / out for PIRs or door contacts. Will it keep recording if the NVR or internet goes down? Yes. The on-board MicroSD slot accepts cards up to 256 GB and records 4K footage independently of the NVR. Is the camera suitable for Australian outdoor conditions? Yes. It is rated IP67 and −30 °C to +60 °C — covering every Australian climate from a Hobart winter to a Karratha summer. IK10 vandal resistance is available as an optional configuration. The all-metal housing and ±30% wide-voltage tolerance also handle dirty mains power common on rural sites. Does it work with Hikvision NVRs or third-party VMS? Yes — recording, streaming, motion and the WizSense AI metadata work over ONVIF Profile S/G/T on most third-party NVRs and VMS platforms (Milestone, Genetec, Hanwha WAVE, ExacqVision, Blue Iris, Synology). For the smartest integration (Quick Pick, push notifications, remote zoom from the app), pair it with a Dahua AI NVR. What is the warranty and where is it serviced? This camera ships with a 3-year Australian Dahua warranty, serviced back-to-base by Dahua Australia. CCTV Guru handles the entire RA process and provides Australian-based technical support for the life of the product. Do you ship Australia-wide and is stock genuine? Yes — Australian stock from authorised Dahua Australia channels (not parallel imports). We ship Australia-wide every business day with same-day dispatch on orders placed before 2 pm AEST to Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra, Darwin and regional addresses. Downloads & Resources DH-IPC-HFW3866TP-ZAS-AUS Datasheet Dahua Bullet Quick Start Guide Order the Dahua DH-IPC-HFW3866TP-ZAS-AUS from CCTV Guru CCTV Guru is an authorised Australian reseller of Dahua WizSense network cameras. Order the 8MP 4K IR motorised vari-focal bullet today in White for fast Australia-wide dispatch, expert pre-sales advice, project pricing for larger rollouts and full local warranty support. For multi-camera projects, contact our Australian team for a tailored quote, NVR sizing and installation guidance — request a free quote or contact the team.

Read more less

WizSense 3 · 6 MP · Motorised 2.7–13.5 mm · IR 60 mDahua DH-IPC-HFW3666TP-ZAS-AUS — 6 MP Motorised Vari-Focal Starlight IR Bullet WizSense 3 Network Camera (3666 Series) The Dahua DH-IPC-HFW3666TP-ZAS-AUS is the 3666 series 6 MP WizSense 3 motorised bullet — built around a 1/2.7" CMOS Starlight sensor capturing 3072 × 2048 at 25/30 fps. The motorised 2.7–13.5 mm vari-focal lens delivers a wide 102° field at 2.7 mm down to a tight 27° pull at 13.5 mm — re-frameable remotely via the DMSS app. Built-in IR reaches up to 60 m for long-range night surveillance; WDR is 120 dB; the metal bullet housing is IP67 sealed across −40 °C to +60 °C. WizSense 3 deep-learning edge AI runs perimeter protection, SMD 4.0 and AcuPick attribute search; built-in microphone, RCA audio I/O and 1/1 alarm wet-contact pair round out the spec. Built for Australian project-grade outdoor installs — long driveways, depot perimeters, school grounds, council reserves, freight yards and commercial frontages where re-frameable optics and 60 m IR are needed. Backed by a 3-year Australian warranty through CCTV Guru. SKU 3666 series. 3-Year AU Warranty Fast AU-Wide Shipping AU Tech Support Why Choose the Dahua HFW3666TP-ZAS-AUS WizSense 3 Motorised Bullet True 6 MP Detail at 25/30 fps Native 3072 × 2048 at full 25/30 fps. Three times the pixel density of 1080p with smooth motion for fast-moving sites — carparks, freight yards and council reserves. Motorised 5× Vari-Focal Lens 2.7–13.5 mm motorised vari-focal — install wide for general coverage, then pull tight to 13.5 mm on the area of interest remotely from DMSS. No ladder visits for re-framing. WizSense 3 + AcuPick AI Perimeter protection, SMD 4.0 and AcuPick attribute search on the WizSense 3 deep-learning chip. Pair with a Dahua AcuPick NVR to search recorded video by clothing colour and vehicle attributes. 60 m Long-Range IR Built-in IR array reaches up to 60 m — long-range night surveillance for driveways, perimeters and depot yards. 1/2.7" Starlight Sensor & 120 dB WDR Starlight low-light sensor with usable colour in moonlight conditions; 120 dB WDR for high-contrast Australian outdoor scenes. Alpine-Rated & Standard PoE −40 °C to +60 °C operating range. Runs on standard 802.3af PoE — works on any quality PoE switch without requiring PoE+. Important Install Note The motorised vari-focal lens is remote-controllable via DMSS for one-time install framing or ongoing re-alignment. For coastal or humid Australian installs, pair with a Dahua water-proof junction box to protect the RJ-45 termination. AI & Smart Detection Capabilities AcuPick Attribute Search Search recorded video by colour, clothing top/bottom, vehicle type and direction — with a Dahua AcuPick NVR. SMD 4.0 Smart Motion Motion alerts triggered only by humans and vehicles. Filters out branches, animals and shadows at the edge. Perimeter Protection (IVS) Tripwire, intrusion zones with human and vehicle classification. AI SSA Scene Self-Adaptation Automatic image-parameter adjustment for rain, fog, backlight and flicker. Quick Pick & Smart Search Event-type smart search via compatible Dahua NVRs — jump straight to the alarm clips without scrubbing. Two-Way Audio & Alarm I/O Built-in mic + RCA audio I/O; alarm I/O for third-party integration. ONVIF Profile S, G, T. Technical Specifications Camera, Lens & Illumination Model DH-IPC-HFW3666TP-ZAS-AUS Form Factor Bullet (HFW chassis) Image Sensor 1/2.7" CMOS Starlight Maximum Resolution 3072 × 2048 (6 MP) Frame Rate 6 MP @ 25/30 fps WDR 120 dB Day / Night Auto (ICR) / Colour / B&W Lens Type Motorised vari-focal Focal Length 2.7 mm – 13.5 mm Maximum Aperture F1.5 — F2.7 Field of View H: 102° – 27° IR Illumination Up to 60 m Intelligence, Audio & Network AI Engine WizSense 3 Series IVS Tripwire · intrusion (with human/vehicle classification) SMD SMD 4.0 AcuPick Yes (with Dahua AcuPick NVR) AI SSA Yes Built-in Microphone Yes Audio I/O 1 in / 1 out (RCA) Alarm I/O 1 in / 1 out Network Port RJ-45 (10/100 Base-T) Interoperability ONVIF (Profile S, G, T) · CGI Storage Micro SD up to 512 GB Mobile Client DMSS (iOS / Android) Power, Environment & Build Power Supply 12 VDC / PoE (802.3af) Operating Temperature −40 °C to +60 °C Protection IP67 Casing Metal Certifications CE-LVD (EN62368-1) · CE-EMC (2014/30/EU) · RCM (AU) Australian Warranty 3 Years (via CCTV Guru) How It Compares — HFW3666TP-ZAS (Motorised) vs HFW3666EP-AS (Fixed) The natural sibling is the Dahua DH-IPC-HFW3666EP-AS-AUS — the fixed 2.8 mm version of this same 6 MP WizSense 3 bullet. Choose this motorised version for re-frameable optics and longer zoom reach; choose the fixed for predictable framing and lower cost. Feature HFW3666TP-ZAS-AUS (this — motorised) HFW3666EP-AS-AUS (sibling — fixed) Resolution 6 MP (3072 × 2048) 6 MP (3072 × 2048) Lens Motorised 2.7–13.5 mm Fixed 2.8 mm AI Engine WizSense 3 + AcuPick WizSense 3 + AcuPick IR Distance Up to 60 m Up to 40 m Remote Re-Framing Yes No Best For Variable framing & long-range IR — carparks, perimeters Predictable framing at lower cost — shopfronts, residential Recommended NVR Pairings Dahua DHI-NVR5208-8P-AI/ANZ 5-Series AcuPick NVR · 8 channels. View Dahua NVR5208-8P-AI → Dahua DHI-NVR5216-16P-AI/ANZ 5-Series AcuPick NVR · 16 channels · 16 PoE+. View Dahua NVR5216-16P-AI → Dahua DHI-NVR4216-16P-AI/ANZ 4-Series WizSense AI NVR · 16 channels. View Dahua NVR4216-16P-AI → Dahua DHI-NVR5432-AI/ANZ 5-Series AcuPick NVR · 32 channels. View Dahua NVR5432-AI → Frequently Asked Questions Is the Dahua HFW3666TP-ZAS-AUS NDAA compliant? No. Dahua is not certified under NDAA Section 889. What does "TP-ZAS" mean in the SKU? TP = bullet with motorised vari-focal; Z = motorised zoom; AS = audio. Together: motorised vari-focal bullet with audio I/O. Can I re-frame the lens after install? Yes — motorised vari-focal lens fully controllable via DMSS app. Zoom and focus adjustments are remote-controlled. Does the camera include AcuPick? Yes. Pair with a Dahua 5-Series AcuPick NVR for attribute-based recorded-video search. Can I run it on standard PoE? Yes — 802.3af-compliant. How far can it see at night? Up to 60 m built-in IR — long-range night surveillance. Does it have audio? Yes — built-in mic + RCA audio I/O. Does it work with third-party NVRs? Yes — ONVIF Profile S, G, T. AcuPick attribute search only on Dahua AI NVRs. What temperature range? −40 °C to +60 °C. Alpine-rated. Can I view it on my phone? Yes — Dahua's free DMSS app. Downloads DH-IPC-HFW3666TP-ZAS-AUS DatasheetDahua IP Bullet Camera Quick Start GuideDahua IP Bullet Camera Installation GuideDahua IP Bullet Camera Operational Manual Order Your Dahua HFW3666TP-ZAS-AUS from CCTV Guru "Add to cart" to order online, or contact our Australian team for project pricing and NVR sizing. We back every 3666 series camera with a 3-year Australian warranty. Phone, email or live chat us through cctvguru.com.au/pages/contact.

Read more less

WizSense 3 · 6 MP · Fixed 2.8 mm · 40 m IRDahua WizSense 3 · 6 MP Fixed BulletDahua DH-IPC-HFW3666EP-AS-AUS — 6 MP Fixed-Focal Starlight IR Bullet WizSense 3 Network Camera (3666 Series, 2.8 mm) The Dahua DH-IPC-HFW3666EP-AS-AUS is the 3666 series 6 MP WizSense 3 fixed-focal bullet — the fixed sibling to the motorised HFW3666TP-ZAS-AUS. Built around a 1/2.7" CMOS Starlight sensor capturing 3072 × 2048 at 25/30 fps. The 2.8 mm fixed F1.6 lens delivers a wide 102° field of view; built-in IR reaches up to 40 m; WDR is 120 dB; the metal bullet housing is IP67 sealed across −40 °C to +60 °C. WizSense 3 deep-learning Pro AI runs perimeter protection (tripwire, intrusion) with human and vehicle classification, plus SMD 4.0 and AcuPick. Built-in microphone, 1/1 RCA audio I/O. Built for Australian commercial frontages, residential, NDIS, SMB and project-grade installs where predictable framing at lower cost is preferred over the motorised sibling. Backed by a 3-year Australian warranty through CCTV Guru. SKU 3666 series. 3-Year AU Warranty Fast AU-Wide Shipping AU Tech Support Why Choose the Dahua HFW3666EP-AS-AUS WizSense 3 Fixed Bullet True 6 MP Detail at 25/30 fps Native 3072 × 2048 at full 25/30 fps. Three times the pixel density of 1080p. 1/2.7" Starlight Sensor Starlight low-light sensor with usable colour in moonlight conditions. WizSense 3 + AcuPick Perimeter protection, SMD 4.0 and AcuPick attribute search on the WizSense 3 chip. 40 m IR Range Built-in IR array reaches up to 40 m for residential and commercial night surveillance. Predictable Fixed Framing 2.8 mm fixed lens (102° field of view) — lower cost than the motorised HFW3666TP-ZAS sibling, simpler install. Alpine Build Metal IP67 housing rated −40 °C to +60 °C. AI & Smart Detection AcuPick Attribute Search Search recorded video by colour, clothing, vehicle type — with a Dahua AcuPick NVR. SMD 4.0 Smart Motion Motion alerts triggered only by humans and vehicles. Perimeter Protection Tripwire and intrusion zones with human/vehicle classification. AI SSA Scene self-adaptation for rain, fog, backlight. Quick Pick & Smart Search Event-type smart search via compatible Dahua NVRs. Two-Way Audio Built-in mic + RCA audio I/O. Technical Specifications Camera, Lens & Illumination Model DH-IPC-HFW3666EP-AS-AUS Form Factor Bullet (HFW chassis) Image Sensor 1/2.7" CMOS Starlight Maximum Resolution 3072 × 2048 (6 MP) Frame Rate 6 MP @ 25/30 fps WDR 120 dB Lens Type Fixed-focal 2.8 mm F1.6 Field of View H: ~102° IR Illumination Up to 40 m Intelligence, Audio & Network AI Engine WizSense 3 Series IVS Tripwire · intrusion (human/vehicle) SMD SMD 4.0 AcuPick Yes (with Dahua AcuPick NVR) Built-in Mic Yes Audio I/O 1 in / 1 out (RCA) Network Port RJ-45 (10/100) Interoperability ONVIF (Profile S, G, T) · CGI Storage Micro SD up to 512 GB Mobile Client DMSS Power, Environment & Build Power Supply 12 VDC / PoE (802.3af) Operating Temperature −40 °C to +60 °C Protection IP67 Casing Metal Australian Warranty 3 Years (via CCTV Guru) How It Compares — HFW3666EP-AS (Fixed) vs HFW3666TP-ZAS (Motorised) The motorised sibling is the Dahua DH-IPC-HFW3666TP-ZAS-AUS — same 6 MP WizSense 3 platform with motorised 2.7–13.5 mm vari-focal and 60 m IR. Choose this fixed version for predictable framing at lower cost; choose the motorised for remote re-framing and longer IR throw. Recommended NVR Pairings Dahua DHI-NVR5208-8P-AI/ANZ View NVR5208-8P-AI → Dahua DHI-NVR5216-16P-AI/ANZ View NVR5216-16P-AI → Dahua DHI-NVR4216-16P-AI/ANZ View NVR4216-16P-AI → Dahua DHI-NVR5432-AI/ANZ View NVR5432-AI → Frequently Asked Questions NDAA compliant? No. AcuPick? Yes — pair with a Dahua AcuPick NVR. Standard PoE? Yes — 802.3af. Difference vs HFW3666TP-ZAS motorised? Same WizSense 3 platform. This fixed version uses a 2.8 mm fixed lens (lower cost, simpler); the motorised has 2.7–13.5 mm vari-focal and 60 m IR. Night vision? Up to 40 m IR. Audio? Built-in mic + RCA audio I/O. Field of view? Wide 102°. Third-party NVRs? Yes — ONVIF Profile S, G, T. Temperature? −40 °C to +60 °C alpine-rated. Mobile viewing? Yes — DMSS app. Downloads DH-IPC-HFW3666EP-AS-AUS DatasheetDahua IP Bullet Camera Quick Start GuideDahua IP Bullet Camera Installation Guide Order Your Dahua HFW3666EP-AS-AUS from CCTV Guru "Add to cart" to order, or contact our Australian team for project pricing. 3-year Australian warranty. cctvguru.com.au/pages/contact.

Read more less

WizSense 3 · 6 MP · Motorised 2.7–13.5 mm · IK10 Vandal DomeDahua WizSense 3 · 6 MP Motorised Vandal DomeDahua DH-IPC-HDBW3666RP-ZAS-AUS — 6 MP Motorised Vari-Focal Starlight Vandal Dome WizSense 3 Network Camera (3666 Series, 2.7–13.5 mm) The Dahua DH-IPC-HDBW3666RP-ZAS-AUS is the 3666 series 6 MP WizSense 3 motorised vandal dome — the dome sibling to the HFW3666TP-ZAS-AUS bullet. Built around a 1/2.7" CMOS Starlight sensor capturing 3072 × 2048 at 25/30 fps. The motorised 2.7–13.5 mm vari-focal lens delivers a wide 102° field at 2.7 mm down to a tight 27° pull at 13.5 mm — re-frameable from DMSS. Built-in IR reaches up to 40 m; WDR is 120 dB; the IK10 vandal-rated metal dome housing is IP67 sealed across −40 °C to +60 °C. WizSense 3 deep-learning Pro AI runs perimeter protection, SMD 4.0 and AcuPick attribute search. Built-in microphone, 1/1 RCA audio I/O. Built for Australian retail interiors, transport platforms, schools, council reserves and vandal-prone positions where re-frameable optics and 6 MP detail matter. Backed by a 3-year Australian warranty through CCTV Guru. SKU 3666 series. 3-Year AU Warranty Fast AU-Wide Shipping AU Tech Support Why Choose the Dahua HDBW3666RP-ZAS WizSense 3 Motorised Vandal Dome IK10 Vandal Dome with Motorised Optics Full metal IK10-rated dome chassis — built for transport, retail interiors and shopping centres. Motorised 5× vari-focal for remote re-framing without site visits. True 6 MP Detail at 25/30 fps Native 3072 × 2048 at full 25/30 fps. Three times the pixel density of 1080p with smooth motion. Motorised 5× Vari-Focal 2.7–13.5 mm motorised vari-focal — install wide, then pull tight on the area of interest via DMSS. WizSense 3 + AcuPick Perimeter protection, SMD 4.0 and AcuPick attribute search on the WizSense 3 deep-learning chip. 40 m IR + Starlight Sensor 1/2.7" Starlight sensor with usable colour in moonlight; 40 m IR for fully-dark coverage. Alpine-Rated Build −40 °C to +60 °C metal IP67 housing — tropical or alpine Australia. Important Install Note Motorised vari-focal lens is remote-controllable via DMSS. The dome gimbal allows three-axis adjustment. Audio recording is subject to local privacy law. AI & Smart Detection AcuPick Attribute Search Search recorded video by colour, clothing, vehicle type — with a Dahua AcuPick NVR. SMD 4.0 Smart Motion Motion alerts triggered only by humans and vehicles. Perimeter Protection Tripwire and intrusion zones with human/vehicle classification. AI SSA Scene self-adaptation for rain, fog, backlight. Quick Pick & Smart Search Event-type smart search via compatible Dahua NVRs. Two-Way Audio Built-in mic + RCA audio I/O. Technical Specifications Camera, Lens & Illumination Model DH-IPC-HDBW3666RP-ZAS-AUS Form Factor Vandal dome (HDBW chassis) Image Sensor 1/2.7" CMOS Starlight Maximum Resolution 3072 × 2048 (6 MP) Frame Rate 6 MP @ 25/30 fps WDR 120 dB Day / Night Auto (ICR) / Colour / B&W Lens Type Motorised vari-focal Focal Length 2.7–13.5 mm Field of View H: 102°–27° IR Illumination Up to 40 m Intelligence, Audio & Network AI Engine WizSense 3 Series IVS Tripwire · intrusion (human/vehicle) SMD SMD 4.0 AcuPick Yes (with Dahua AcuPick NVR) Built-in Mic Yes Audio I/O 1 in / 1 out (RCA) Network Port RJ-45 (10/100) Interoperability ONVIF (Profile S, G, T) · CGI Storage Micro SD up to 512 GB Mobile Client DMSS Power, Environment & Build Power Supply 12 VDC / PoE (802.3af) Operating Temperature −40 °C to +60 °C Protection IP67 · IK10 vandal Australian Warranty 3 Years (via CCTV Guru) How It Compares — HDBW3666RP-ZAS (Dome) vs HFW3666TP-ZAS (Bullet) The natural sibling is the Dahua DH-IPC-HFW3666TP-ZAS-AUS — the bullet version of this same 6 MP WizSense 3 motorised platform. Choose the dome for IK10 vandal-prone interiors; choose the bullet for outdoor wall mount with longer 60 m IR throw. Recommended NVR Pairings Dahua DHI-NVR5208-8P-AI/ANZ View NVR5208-8P-AI → Dahua DHI-NVR5216-16P-AI/ANZ View NVR5216-16P-AI → Dahua DHI-NVR4216-16P-AI/ANZ View NVR4216-16P-AI → Dahua DHI-NVR5432-AI/ANZ View NVR5432-AI → Frequently Asked Questions NDAA compliant? No. IK10 vandal? Yes — highest impact rating. Re-frame after install? Yes — motorised vari-focal via DMSS. AcuPick? Yes — pair with Dahua AcuPick NVR. Standard PoE? Yes — 802.3af. Night vision? Up to 40 m IR. Audio? Built-in mic + RCA audio I/O. Third-party NVRs? Yes — ONVIF Profile S, G, T. Temperature? −40 °C to +60 °C alpine-rated. Mobile viewing? Yes — DMSS app. Downloads DH-IPC-HDBW3666RP-ZAS-AUS DatasheetDahua IP Dome Camera Quick Start GuideDahua IP Dome Camera Installation Guide Order Your Dahua HDBW3666RP-ZAS from CCTV Guru "Add to cart" to order, or contact our Australian team for project pricing. 3-year Australian warranty. cctvguru.com.au/pages/contact.

Read more less

WizSense 3 · 6 MP · Fixed 2.8 mm · IK10 Vandal Dome WizSense 3 · 6 MP Dome Dahua DH-IPC-HDBW3666EP-AS-AUS — 6 MP Fixed Vandal Dome WizSense 3 (2.8 mm) The Dahua IPC-HDBW3666EP-AS-AUS is a 6 MP WizSense 3 fixed-focal vandal-resistant dome built around a 1/2.7" Starlight CMOS sensor and a 2.8 mm wide-angle lens covering a 102° horizontal field of view. It streams 3072 × 2048 video at 25/30 fps with H.265+ smart codec, throws 50 m of Smart IR for long-range night detail and rides on Dahua's latest WizSense 3 AI stack — SMD 4.0, AcuPick re-search and AI Scene Self-Adaptation (AI SSA). The IP67 / IK10 polycarbonate housing shrugs off vandalism, dust and driving rain, while the built-in microphone, dedicated alarm I/O and 802.3af PoE make it a clean, single-cable install on any modern Dahua or third-party ONVIF NVR. Backed by CCTV Guru's 3-year Australian warranty and local tech support. 3-Year AU Warranty Fast AU-Wide Shipping AU Tech Support Why Choose the Dahua IPC-HDBW3666EP-AS-AUS 6 MP Starlight Imaging 1/2.7" Starlight CMOS captures detailed 3072 × 2048 video with low-noise colour performance well below 1 lux. Fixed 2.8 mm Wide Lens 102° horizontal field of view covers wide entries, hallways, garages and shopfronts — no zoom calibration needed. 50 m Smart IR Long-range IR with anti-overexposure compensation keeps near and far subjects evenly lit at night. WizSense 3 AI Stack Latest AI generation with SMD 4.0 false-alarm filtering, AcuPick subject search and AI Scene Self-Adaptation. IK10 Vandal Build Polycarbonate dome and reinforced base resist impact, sabotage and rough handling in public-facing installs. Single-Cable PoE 802.3af Power-over-Ethernet plus built-in mic and alarm I/O — one Cat6 run carries power, video and audio. Important Install Note The 2.8 mm fixed lens is set wide and is best mounted 2.5–3.5 m above ground level for face-height capture at entries. The dome ships with a 3-axis gimbal that swings the lens away from the rim — rotate the gimbal away from any close vertical wall to prevent the dome glass picking up IR reflection and washing out the bottom of the image. AI & Smart Detection SMD 4.0 Person/Vehicle Filters wildlife, leaves, headlights and shadows — only real people and vehicles trigger alerts and recordings. AcuPick Subject Search When paired with an AcuPick NVR, search recorded footage by attributes like clothing colour or vehicle type in seconds. AI SSA Auto-Tuning AI Scene Self-Adaptation continuously tunes exposure, WDR and noise reduction per scene — install and forget. Tripwire & Intrusion Draw virtual lines and zones across driveways, gates or aisles; AI confirms direction of travel before alarming. Face & Crowd Face detection and crowd-occupancy events for shops, foyers and queue-management dashboards. Perimeter Protection Dedicated WizSense perimeter rules combine SMD with directional logic for low-false-alarm fence and pool-zone alerts. Technical Specifications Camera, Lens & Illumination Image Sensor 1/2.7" 6 MP Starlight CMOS Max Resolution 3072 × 2048 @ 25/30 fps Lens Fixed 2.8 mm Field of View 102° horizontal IR Range Up to 50 m Smart IR Day/Night ICR mechanical filter WDR 120 dB True WDR Min Illumination 0.005 lux colour / 0 lux IR on Intelligence, Audio & Network AI Platform WizSense 3 with AcuPick & AI SSA Smart Events SMD 4.0, Tripwire, Intrusion, Face, Crowd Audio Built-in microphone Alarm I/O 1 in / 1 out Storage microSD up to 512 GB Protocols ONVIF, RTSP, CGI, P2P Cybersecurity HTTPS, 802.1x, IEEE TLS Mobile App Dahua DMSS (iOS & Android) Power, Environment & Build Power PoE 802.3af / 12 V DC Power Consumption < 8.5 W max with IR Operating Temp −30 °C to +60 °C Ingress Rating IP67 Impact Rating IK10 vandal resistant Housing Polycarbonate dome & base Colour White Warranty 3-Year Australian Warranty Recommended NVR Pairings Dahua DHI-NVR5208-8P-AI/ANZ 8-ch WizSense AI NVR with 8 PoE — ideal headend for up to 8 of these 6 MP domes with AcuPick search enabled. View → Dahua DHI-NVR5216-16P-AI/ANZ 16-ch WizSense AI NVR with 16 PoE — recommended for mid-size shops, schools and commercial sites. View → Dahua DHI-NVR4216-16P-AI/ANZ 16-ch 4K Smart AI NVR — budget option that still handles WizSense human/vehicle perimeter events. View → Dahua DHI-NVR5432-AI/ANZ 32-ch WizSense AI NVR (no built-in PoE) for larger sites using an external PoE switch infrastructure. View → Frequently Asked Questions Is the IPC-HDBW3666EP-AS-AUS NDAA compliant?No. Dahua products are not NDAA Section 889 listed and should not be specified for U.S. federally-funded projects. What is the field of view?The 2.8 mm fixed lens gives a 102° horizontal field of view — wide enough for entryways, garages and small shops. How far does the IR reach?Up to 50 m of Smart IR with anti-overexposure — long for a 2.8 mm dome and useful in driveways and large foyers. Does it support AcuPick?Yes — pair it with a WizSense 3 AcuPick NVR to attribute-search recorded video by clothing colour or vehicle type. Does it have audio?Yes, an omnidirectional microphone is built into the housing. There is no built-in speaker on this model. What storage does it support?microSD card slot accepts up to 512 GB for on-camera ANR / event recording. What PoE class does it need?802.3af (PoE) is sufficient — works on any modern PoE switch or Dahua NVR PoE port. Will it work with third-party NVRs?Yes — ONVIF Profile S/T/G compatibility lets it work with Hikvision, Uniview, Milestone, Synology and most NVRs. Is it vandal rated?Yes — IK10 impact rating plus IP67 ingress protection make it suitable for low-mount public installs. What is the warranty?Backed by a full 3-year Australian warranty via CCTV Guru with local RMA and tech support. Downloads Datasheet Quick Start Guide Installation Guide Order Your Dahua IPC-HDBW3666EP-AS-AUS from CCTV Guru CCTV Guru is an authorised Australian Dahua reseller. The IPC-HDBW3666EP-AS-AUS ships from Australian stock with a 3-year Australian warranty and local tech support. Need help speccing camera counts, NVR storage or PoE switches for your site? Reach out at cctvguru.com.au/pages/contact.

Read more less

Dahua TiOC 2.0 · Full-Colour · 5MP Active Deterrence BulletTiOC Deterrence Bullet Dahua DH-IPC-HFW3549T1P-AS-PV-S3 — 5MP TiOC 2.0 Full-Colour Active Deterrence Bullet The Dahua DH-IPC-HFW3549T1P-AS-PV-S3 is a 5MP full-colour active deterrence bullet from Dahua's WizSense 3 Series TiOC 2.0 line-up. Built around a 1/2.7" CMOS sensor and an F1.0 large-aperture lens, it produces colour image at very low light (down to 0.003 lux), with two on-board warm-light LEDs reaching 40 m for clear full-colour video around the clock — no monochrome IR fallback. Paired with the active deterrence chain — red/blue strobe lights, on-board siren, 11 built-in voice alarms plus custom voice import — it's a complete watch-and-warn camera in one weatherproof unit. Powered by Dahua's WizSense AI with SMD Plus human/vehicle classification and IVS perimeter protection (tripwire + intrusion), the 3549T1P fires its deterrence chain only when a genuine human or vehicle is detected — no false alarms from animals or weather. Two-way audio via the built-in mic and speaker, MicroSD edge recording, IP67 weatherproofing and a wide −40 °C to +60 °C operating range round it out. Available in White (DH-IPC-HFW3549T1P-AS-PV-S3) and Black. Australian stock, 3-year Australian warranty. Resolution 5MP · 2592 × 1944 Aperture & FOV F1.0 · 98° H · 2.8 mm Night Vision 40 m Warm Light · Full-Colour Active Deterrence Strobe · Siren · Voice Protection IP67 · −40 °C to +60 °C Power PoE 802.3af · Max 8.8 W 3-Year Australian Warranty Fast Australia-Wide Shipping Australian Tech Support Why Choose the 5MP Full-Colour Active Deterrence Bullet This is the camera Australian installers reach for when the customer wants colour evidence around the clock — not monochrome IR — combined with the visible deterrence of red/blue strobe and audible warnings. The F1.0 large-aperture lens and 40 m warm-light LED illuminator together deliver true full-colour image even at very low ambient light, while the TiOC 2.0 active deterrence chain proactively warns intruders the moment AI confirms a person or vehicle inside the rule zone. Full-Colour 24/7 — No Monochrome IR Fallback Two warm-light LEDs reaching 40 m combine with a 1/2.7" Starlight CMOS sensor and an F1.0 large aperture to deliver clear colour image even at 0.003 lux. You see clothing colour, vehicle paint and hair colour at night — not just a grey IR silhouette. F1.0 Large Aperture The F1.0 aperture gathers significantly more light than a typical F1.6 lens — the single biggest factor behind the camera's true full-colour low-light performance. Active Deterrence — Strobe + Siren + Voice When SMD Plus confirms a human or vehicle, the camera flashes its red/blue strobe lights and sounds an alarm from the built-in speaker — choose from 11 pre-loaded voice alarms or upload custom audio for a site-specific message. SMD Plus + IVS Perimeter Protection WizSense AI classifies humans and vehicles on-camera and filters out animals, foliage and weather. IVS adds virtual tripwires and intrusion zones — only genuine threats trigger the deterrence chain. 120 dB True WDR Real Wide Dynamic Range balances harsh contrast — sunset doorways, undercover carparks, mixed indoor/outdoor lighting. Highlights stay readable, shadows stay detailed. Built Tough for Australia IP67 ingress protection, metal-and-reinforced-plastic chassis, ±30% wide-voltage tolerance and a −40 °C to +60 °C operating range shrug off coastal salt, outback heat, Tasmanian frost and unstable rural mains. Smart Features for Real-World Australian Sites Two-Way Audio & Custom Voice Built-in microphone and speaker support live two-way audio via DMSS or a Dahua NVR. The 11 pre-loaded voice messages plus uploadable custom audio let you record a site-specific warning in your own voice. IVS Tripwire & Intrusion Zones Define a virtual line across the driveway or a no-go zone around the shed — get a notification (and trigger the deterrence chain) only when a human or vehicle actually crosses it. One-Tap Disarming A single tap in the DMSS app disarms the deterrence chain — useful for parties, deliveries and after-hours visitors. Rearm with one button. Smart H.265+ Compression Dahua's Smart H.265+ scene-adaptive encoding reduces bandwidth and storage demand significantly versus standard H.264 — longer retention on the same NVR drive. Triple Streaming · Full HD Sub-Stream Three streams simultaneously — Main 5MP @ 20 fps (or 4MP @ 25/30 fps), Sub 704 × 576 and a Full HD 1920 × 1080 third stream — give flexibility for live view, mobile streaming and NVR recording. External Audio & Alarm I/O 1 audio in / 1 audio out (RCA) plus 1 alarm in / 1 alarm out for connecting external mic, speaker, PIR or door contacts — extend the camera's role beyond stand-alone. Pair with a Dahua WizSense AI NVR The 3549T1P-AS-PV is a WizSense 3 Series TiOC 2.0 camera. SMD Plus, IVS rules, the active deterrence chain and human/vehicle classification all run on-camera and work with any Dahua AI NVR. This camera does not support AcuPick attribute search — that's reserved for the newer TiOC 3.0 line — but pairing with a Dahua AI NVR still unlocks smart event search and human/vehicle filtering across recorded footage. DHI-NVR4108HS-8P-AI/ANZ — 8 Channel · 8 PoE Value 4-Series WizSense AI NVR — 8 channels, 8 built-in PoE ports, perfect partner for a small-to-mid 3549 deployment. View NVR4108HS-8P → DHI-NVR4216-16P-AI/ANZ — 16 Channel · 16 PoE 16-channel 4-Series WizSense AI NVR — room to grow into 16 cameras at full PoE, with AI smart search and human/vehicle filtering on every channel. View NVR4216-16P → DHI-NVR5216-16P-AI/ANZ — 16 Channel · Premium Step up to the 5-Series for higher bandwidth, faster playback and the ability to add TiOC 3.0 AcuPick cameras to the system later. Fully backward-compatible with the 3549. View NVR5216-16P → DHI-NVR5432-16P-AI/ANZ — 32 Channel · 4 HDD Bays 32-channel 1.5U NVR with 16 PoE and 4 HDD bays — for larger commercial sites, retail chains and multi-building campuses needing longer retention. View NVR5432-16P → Need help sizing? Browse the complete Dahua NVR range → or contact our Australian team for a tailored recommendation. Technical Specifications DH-IPC-HFW3549T1P-AS-PV-S3 · Full Specifications SKU DH-IPC-HFW3549T1P-AS-PV-S3 (White) · DH-IPC-HFW3549T1P-AS-PV-S3 (Black variant available) Camera Type 5MP Full-Colour Active Deterrence Fixed-Focal Bullet · WizSense 3 Series · TiOC 2.0 Image Sensor 1/2.7" Progressive Scan 5MP CMOS Max Resolution 2592 × 1944 (5MP) @ 20 fps · 2688 × 1520 (4MP) @ 25/30 fps Lens Type Fixed-focal, 2.8 mm · M12 mount (3.6 mm and 6 mm options also available) Maximum Aperture F1.0 Field of View (2.8 mm) H: 98° · V: 71° · D: 129° DORI (2.8 mm) Detect 67.4 m · Observe 27 m · Recognise 13.5 m · Identify 6.7 m Min. Illumination 0.003 lux @ F1.0 · 0 lux (Illuminator on) S/N Ratio > 56 dB Dynamic Range 120 dB True WDR Day & Night Colour / B&W Illumination 2 × Warm-Light LED · Up to 40 m (no IR LED — full-colour camera) Image Enhancement WDR · 3D NR · HLC · BLC · Scene Self-Adaptation · Smart Illumination · Image Rotation · Digital watermarking Active Deterrence Red/blue strobe lights · Built-in siren · 11 pre-loaded voice alarms + custom voice import Intelligent Video SMD Plus · IVS (Tripwire, Intrusion · human/vehicle classification) · Intelligent Search Video Compression H.265 · H.264 · H.264H · H.264B · MJPEG (sub-stream) · Smart H.265+ / Smart H.264+ Streaming 3 streams — Main 2592×1944 @ 20 fps · Sub 704×576 · Third 1920×1080 Video Bitrate H.264: 32 kbps – 8,192 kbps · H.265: 12 kbps – 8,192 kbps Audio Built-in microphone + speaker · PCM / G.711a / G.711Mu / G.726 / AAC / G.723 compression Audio I/O 1 audio in (RCA) · 1 audio out (RCA) Alarm I/O 1 alarm in (5 mA, 3–5 V DC) · 1 alarm out (300 mA, 12 V DC) IP Camera Protocol ONVIF Profile S/G/T · CGI · Milestone · Genetec · P2P Network Protocols IPv4/v6 · HTTP/HTTPS · TCP/UDP · RTP/RTSP/RTCP/RTMP · SMTP · FTP/SFTP · DHCP · DDNS · UPnP · NTP · ICMP · IGMP · NFS · SAMBA · PPPoE · SNMP · 802.1x Ethernet RJ-45 (10/100BASE-T) Edge Storage MicroSD up to 256 GB · NAS · FTP / SFTP · Dahua Cloud Weatherproof Rating IP67 Operating Temperature −40 °C to +60 °C · < 95% RH Power Source 12 V DC / PoE (IEEE 802.3af) · ±30% wide voltage Power Consumption Basic 2 W (12 V DC) / 2.6 W (PoE) · Max 7.5 W (12 V DC) / 8.8 W (PoE) Memory ROM 128 MB · RAM 512 MB Pan / Tilt / Rotation Pan 0°–360° · Tilt 0°–90° · Rotation 0°–360° Mobile App DMSS · Smart PSS · DSS (iOS & Android) Approvals CE-LVD (EN 62368-1) · CE-EMC 2014/30/EU · FCC Part 15 Subpart B Housing Metal + Plastic · White or Black Dimensions 288.4 × 94.4 × 84.7 mm (L × W × H) Weight 1.0 kg (net) · 1.23 kg (gross) Warranty 3-Year Australian Warranty (back-to-base) 3549T1P (TiOC 2.0) vs 3849T1 (TiOC 3.0) — Which TiOC Bullet Should You Choose? Both cameras are full-active-deterrence bullets in the same chassis with the same red/blue strobe, siren and voice-alarm chain. The deciding question is generation: do you need the latest AI engine and 4K resolution, or are 5MP, SMD Plus and full-colour night vision enough? The 3549T1P (TiOC 2.0) is the more affordable choice with full-colour warm-light illumination and proven WizSense AI. The 3849T1 (TiOC 3.0) adds 4K resolution, SMD 4.0, AcuPick AI compatibility, AI Coding, Smart Dual-Light (IR + warm) and a longer Identify range — at a higher price. Dahua 3549T1P TiOC 2.0 (5MP) vs 3849T1 TiOC 3.0 (8MP) — Both Bullets Feature DH-IPC-HFW3549T1P-AS-PV-S3 (this 5MP TiOC 2.0) DH-IPC-HFW3849T1-AS-PV-ANZ-S2 (8MP TiOC 3.0) Series Position TiOC 2.0 · WizSense 3 · Full-Colour TiOC 3.0 · WizSense 3 Max Resolution 5MP · 2592 × 1944 @ 20 fps (4MP @ 25/30 fps) 8MP · 3840 × 2160 (4K) @ 25/30 fps Image Sensor 1/2.7" CMOS 1/2.8" CMOS Lens (fixed) 2.8 mm · M12 2.8 mm · M12 Maximum Aperture F1.0 F1.0 FOV (2.8 mm) 98° H 106° H DORI Identify 6.7 m 9.1 m Night Vision Warm light only · 40 m (full-colour, no IR) IR 30 m + Warm light 30 m (Smart Dual-Light) Active Deterrence Yes — strobe + siren + 11 voice alarms + custom voice Yes — strobe + siren + custom voice broadcast Two-Way Audio Yes — built-in MIC + speaker Yes — dual MIC + speaker SMD Version SMD Plus SMD 4.0 (improved accuracy, longer range) AcuPick AI Search No Yes — with 5-Series NVR AI Coding (AI H.265/H.264) No — Smart H.265+ only Yes — ≥25% extra efficiency WDR 120 dB True WDR 120 dB True WDR MicroSD Up to 256 GB Up to 256 GB Power (Max PoE) 8.8 W 9.1 W Ingress Protection IP67 IP67 Operating Temperature −40 °C to +60 °C −40 °C to +60 °C Dimensions 288.4 × 94.4 × 84.7 mm 288.4 × 94.4 × 84.7 mm Net Weight 1.0 kg 1.0 kg Colour Options White & Black White & Black Australian Warranty 3 years back-to-base 3 years back-to-base Best For Value-focused TiOC installs where colour 24/7 matters more than 4K detail — residential frontages, shop entrances, tradie yards on a tighter budget. Premium deterrence with 4K detail, longer DORI Identify range, AcuPick AI search and the latest WizSense AI features. Compatible Mounts & Accessories Dahua PFA130-E Waterproof Junction Box Waterproof junction box for exposed outdoor bullet mounting on render, brick or weatherboard. View Dahua accessories → Dahua PFA152-E Pole Mount Heavy-duty pole bracket — the typical install partner for bullet cameras on fence posts, light poles and gate columns. View product → Dahua PFM900-E Integrated Mount Tester On-site display + power-test tool for commissioning bullet cameras from the ladder. Saves the trip down to the laptop. View Dahua accessories → Dahua PFM321D 12 V DC Power Adapter 1A power adapter for sites not running PoE — bench testing, retrofit installs into existing 12 V power runs. View Dahua accessories → LR1002-1ET/1EC Ethernet-over-Coax Extender Single-port long-reach EoC extender — repurpose existing coaxial cable runs to deliver Ethernet and PoE to this bullet camera. Useful in retrofit installs replacing analogue cameras. View Dahua accessories → WD Purple 256 GB Surveillance MicroSD Card Western Digital Purple — purpose-built for 24/7 surveillance read/write cycles, far longer endurance than consumer microSD cards. Maxes out the 3549T1P's 256 GB MicroSD ceiling. View WD Purple 256 GB → Frequently Asked Questions What does "TiOC 2.0" mean and how is it different from TiOC 3.0? TiOC = Three-in-One Camera: AI detection + visual deterrence (red/blue strobe) + audible deterrence (siren and voice) in a single unit. TiOC 2.0 uses SMD Plus AI and full-colour warm-light illumination. TiOC 3.0 (newer) upgrades to SMD 4.0, adds Smart Dual-Light (IR + warm), AI Coding and AcuPick compatibility. The 3549T1P is TiOC 2.0 — proven, full-colour, more affordable. Why pick the 5MP full-colour camera over an IR camera? Full-colour matters when you need to identify colour attributes at night — clothing, vehicle paint, hair colour, signage. IR cameras give you monochrome silhouettes; this full-colour camera gives you usable colour evidence around the clock. For situations where colour identification is critical (retail, forensic evidence, identifying intruders by their clothing), full-colour wins. Does the camera have IR LEDs as backup? No. The 3549T1P-AS-PV is a full-colour camera — its two on-board LEDs are warm-light only. At very low light, the camera relies on the F1.0 large aperture and Starlight sensor; when illumination is needed, the warm-light LED switches on. There's no IR fallback. Will the warm-light LED disturb neighbours? The warm-light LED switches on only when SMD Plus detects a real human or vehicle — not on every fox or possum. For residential sites near neighbours, this means the light only fires on genuine events. If you need pure silent IR monitoring, look at the 3866TP-ZAS-AUS IR bullet instead. Does it support AcuPick AI search? No. AcuPick is reserved for Dahua's newer TiOC 3.0 / AcuPick line-up. The 3549T1P uses SMD Plus and IVS, which work with any Dahua AI NVR for human/vehicle filtering and smart search. Will the camera deter intruders automatically? Yes. The TiOC active deterrence chain fires the instant SMD Plus confirms a human or vehicle inside the rule zone — strobe lights, siren and voice alarm all run on-camera, 24/7, without any operator, NVR command or mobile-app interaction. What is the difference between the White and Black versions? Specifications are identical. White and Black variants are available — choose Black for dark eaves, charcoal fascia and modern industrial aesthetics; White for traditional cream/render walls. Why does it record at 20 fps and not 25/30 fps at full 5MP? At full 5MP resolution (2592 × 1944), the camera records at 20 fps. If you need 25 or 30 fps, drop the resolution to 4MP (2688 × 1520) and the camera will deliver full motion. For surveillance applications, 20 fps at 5MP is more than sufficient — it's the typical trade-off across Dahua's 5MP line. Can I speak through the camera? Yes. The built-in microphone and speaker support two-way audio via the DMSS app or a compatible Dahua NVR — ideal for warning intruders, instructing couriers or speaking to family at the door. Will it keep recording if the NVR or internet goes down? Yes. The on-board MicroSD slot accepts cards up to 256 GB and records footage independently of the NVR. Is the camera suitable for Australian outdoor conditions? Yes. It is rated IP67 and −40 °C to +60 °C — covering every Australian climate from a Hobart winter to a Karratha summer. The metal-and-reinforced-plastic housing and ±30% wide-voltage tolerance also handle dirty mains power common on rural sites. Does it work with Hikvision NVRs or third-party VMS? Basic recording, streaming and motion work over ONVIF Profile S/G/T on most third-party NVRs and VMS platforms (Milestone, Genetec, Hanwha WAVE, ExacqVision, Blue Iris, Synology). However, TiOC deterrence, SMD Plus AI and two-way audio require a Dahua NVR or DMSS to be configured and triggered correctly. Downloads & Resources DH-IPC-HFW3549T1P-AS-PV-S3 Datasheet Dahua Bullet Quick Start Guide Order the Dahua DH-IPC-HFW3549T1P-AS-PV-S3 from CCTV Guru CCTV Guru is an authorised Australian reseller of Dahua TiOC network cameras. Order the 5MP TiOC 2.0 full-colour active deterrence bullet today in White or Black for fast Australia-wide dispatch, expert pre-sales advice, project pricing for larger rollouts and full local warranty support. For multi-camera projects, contact our Australian team for a tailored quote, NVR sizing and installation guidance — request a free quote or contact the team.

Read more less
