WizSense 3 · 8 MP 4K · Motorised 2.7–13.5 mm · 50 m IRDahua WizSense 3 · 8 MP 4K Motorised TurretDahua DH-IPC-HDW3866TP-ZS-AUS — 8 MP 4K Motorised Vari-Focal Starlight IR Eyeball Turret WizSense 3 Network Camera (3866 Series, 2.7–13.5 mm)
The Dahua DH-IPC-HDW3866TP-ZS-AUS is the 3866 series 8 MP 4K WizSense 3 motorised eyeball turret in white housing — built around a 1/2.7" CMOS Starlight sensor capturing 3840 × 2160 (true 4K) at 15 fps and 4 MP at full 25/30 fps. The motorised 2.7–13.5 mm vari-focal lens delivers a wide 102° field at 2.7 mm down to a tight 27° pull at 13.5 mm — re-frameable from DMSS. Built-in IR reaches up to 50 m; WDR is 120 dB; the compact metal turret housing is IP67 sealed. WizSense 3 deep-learning Pro AI runs perimeter protection (tripwire, intrusion, fast-moving, loitering) with human and vehicle classification, plus SMD 4.0 and AcuPick attribute search. Built-in microphone, 1/1 RCA audio I/O. The classic white housing blends into white eaves, soffits and awnings — the standard finish for most Australian residential and commercial installs. Backed by a 3-year Australian warranty through CCTV Guru. SKU 3866 series.
Why Choose the Dahua HDW3866TP-ZS-AUS WizSense 3 4K Motorised Turret
True 4K Detail (8 MP)
Native 3840 × 2160 at 15 fps, or 4 MP at full 25/30 fps. 4× the pixel density of 1080p — identification-grade detail at distance.
Motorised 5× Vari-Focal
2.7–13.5 mm motorised vari-focal — install wide, then pull tight on the area of interest via DMSS.
Classic White Eyeball Form
Standard white metal eyeball turret — blends into white eaves, soffits and awnings.
WizSense 3 + AcuPick
Perimeter protection, SMD 4.0 and AcuPick attribute search on the WizSense 3 chip.
50 m IR + Starlight
1/2.7" Starlight sensor with usable colour in moonlight; 50 m IR for fully-dark coverage.
Built-in Mic + Audio I/O
Built-in microphone plus RCA audio I/O for two-way talk integration.
Important Install Note
The motorised vari-focal lens is remote-controllable via DMSS. The eyeball gimbal allows ±75° pan, ±75° tilt and 0–360° rotation. At full 4K, frame rate caps at 15 fps — drop to 4 MP for full 25/30 fps motion. For a black housing variant, see HDW3866TP-ZS-AUS-BLK.
AI & Smart Detection
AcuPick Attribute Search
Search recorded video by colour, clothing, vehicle type — with a Dahua AcuPick NVR.
SMD 4.0 Smart Motion
Motion alerts triggered only by humans and vehicles.
Perimeter Protection
Tripwire, intrusion, fast-moving and loitering with human/vehicle classification.
AI SSA
Scene self-adaptation for rain, fog, backlight.
Abnormality Detection
SD card, network, IP conflict, tampering events.
Two-Way Audio
Built-in mic + RCA audio I/O.
Technical Specifications
Camera, Lens & Illumination
| Model |
DH-IPC-HDW3866TP-ZS-AUS |
| Form Factor |
Eyeball turret (HDW chassis) — White |
| Image Sensor |
1/2.7" CMOS Starlight |
| Maximum Resolution |
3840 × 2160 (8 MP / 4K) |
| Frame Rate |
4K @ 15 fps · 4 MP @ 25/30 fps |
| WDR |
120 dB |
| Day / Night |
Auto (ICR) / Colour / B&W |
| Lens Type |
Motorised vari-focal |
| Focal Length |
2.7–13.5 mm |
| Field of View |
H: 102°–27° |
| IR Illumination |
Up to 50 m |
Intelligence, Audio & Network
| AI Engine |
WizSense 3 Series |
| IVS |
Tripwire · intrusion · fast-moving · loitering (human/vehicle) |
| SMD |
SMD 4.0 |
| AcuPick |
Yes (with Dahua AcuPick NVR) |
| Built-in Mic |
Yes |
| Audio I/O |
1 in / 1 out (RCA) |
| Network Port |
RJ-45 (10/100) |
| Interoperability |
ONVIF (Profile S, G, T) · CGI |
| Storage |
Micro SD up to 512 GB |
| Mobile Client |
DMSS |
Power, Environment & Build
| Power Supply |
12 VDC / PoE (802.3af) |
| Operating Temperature |
−40 °C to +60 °C |
| Protection |
IP67 |
| Casing |
Metal — White |
| Australian Warranty |
3 Years (via CCTV Guru) |
Recommended NVR Pairings
Frequently Asked Questions
True 4K?
Yes — native 3840 × 2160 at 15 fps.
Re-frame after install?
Yes — motorised vari-focal via DMSS.
AcuPick?
Yes — pair with a Dahua AcuPick NVR.
Standard PoE?
Yes — 802.3af.
Available in black?
Yes — DH-IPC-HDW3866TP-ZS-AUS-BLK.
Night vision?
Up to 50 m IR.
Audio?
Built-in mic + RCA audio I/O.
Third-party NVRs?
Yes — ONVIF Profile S, G, T.
Mobile viewing?
Yes — DMSS app.
