Dahua's late 2022 & 2023 Security Cameras & NVRs. Choose the latest models at best price in Australia. Full 3 year warranty. Australian Stocks only. Brand new and deliver nationwide.
8-Channel NVR · Dahua WizSense AI · 8× PoE · 4K HDMI · SMD+
Dahua DHI-NVR4108HS-8P-AI/ANZ — 8-Channel 4K WizSense AI NVR with 8 Built-In PoE Ports
The Dahua DHI-NVR4108HS-8P-AI/ANZ is the go-to 8-channel NVR for Australian homes and small businesses that want genuine AI-powered surveillance without the complexity of enterprise systems. Eight built-in PoE ports power and connect your cameras over a single Cat6 cable each — no separate switches, no power injectors, no cable clutter. The WizSense AI engine delivers Smart Motion Detection Plus (SMD+), face detection and recognition, and perimeter protection, so you only get alerted when a real person or vehicle is detected — not every time a leaf blows past.
Recording at up to 4K (16MP) with Smart H.265+ compression, this compact 1U NVR suits any environment — living room, comms cabinet, or retail back-office. Remote access via the free DMSS app (iOS/Android) requires no port forwarding or static IP. Supports up to 16TB HDD (not included). ANZ-certified firmware, Australian stock, local technical support.
Channels
8CH · Up to 16MP
PoE
8× Built-In · 72W
AI
SMD+ · Face Recognition
Output
4K HDMI + VGA
Remote
DMSS App · P2P
Storage
1× SATA · Up to 16TB
ANZ-Certified Firmware
Australian Stock · Fast Dispatch
Expert Australian Tech Support
Key Features
8 Built-In PoE Ports — One Cable Per CameraEach of the 8 PoE ports (IEEE 802.3af/at) delivers both power and video over a single Cat6 cable — no separate PoE switch, no power boards. Total PoE budget is 72W with up to 25.5W per port, supporting high-power cameras including PTZ and multi-sensor models.
WizSense SMD+ — Eliminates False AlertsDahua’s Smart Motion Detection Plus uses deep learning to classify motion as human or vehicle only — ignoring animals, foliage, rain, and passing headlights. 4-channel SMD+ by recorder, 8-channel by camera. You only get alerted when a real person or vehicle is detected.
Face Detection & Recognition — Know Who’s There1-channel face detection and recognition by recorder (video stream, 12 face images/s). Supports up to 10 face databases with 200,000 face images. Attributes include gender, age group, glasses, expressions, face mask, and beard. Search footage by face similarity instantly.
Perimeter Protection — Tripwire & Intrusion Zones2-channel perimeter protection by recorder (10 IVS rules per channel), 8-channel by camera. Draw virtual lines or zones on any camera view — alerts only trigger when a classified human or vehicle crosses the boundary. Filters out animals, lights, and weather.
4K Recording — Up to 16MP Camera SupportRecords at up to 4K UHD (16MP). With AI disabled: 4-channel 8MP@30fps, 8-channel 4MP@30fps. With AI enabled: 3-channel 8MP@30fps, 8-channel 1080p@30fps. 4K HDMI output for crystal-clear local monitoring.
Smart H.265+ — Store More, Spend LessSmart H.265+ compression reduces storage consumption by up to 75% versus standard H.264. Supports up to 16TB HDD (1× SATA bay, not included). 256 Mbps bandwidth with AI off, 180 Mbps with AI on.
Quick Pick & AI Search — Find Anyone in SecondsQuick Pick lets you pick human/vehicle targets from SMD events and find every matching clip instantly. AI Search supports metadata search and face picture upload for similarity comparison across all channels and long durations.
ANPR by Camera — Licence Plate RecognitionSupports ANPR (Automatic Number Plate Recognition) via compatible Dahua cameras on up to 4 channels. Create blocklists and allowlists of up to 20,000 plate numbers. Search recorded footage by plate number instantly.
DMSS Remote Access — No Port Forwarding RequiredThe free DMSS app (iOS/Android) connects via Dahua’s P2P cloud — no static IP, no DDNS, no port forwarding. Live view, playback, and push notifications from anywhere. Also supports web viewer, SmartPSS, and CGI/SDK integration.
ONVIF & Third-Party Camera SupportONVIF 21.12 (Profile T, S, G) compliance plus native support for Panasonic, Sony, Samsung, Axis, Pelco, Arecont, and Canon cameras. Ideal for mixed-brand upgrades or adding AI capability to an existing camera installation.
Recommended For
Residential Homes8 channels covers the typical home — front door, driveway, side gates, backyard, and garage. SMD+ means you only get alerted when a person or vehicle is detected, not every time a possum walks past.
Small Retail & Convenience StoresFace recognition logs every person who enters. ANPR tracks vehicle plates. Quick Pick finds any incident in seconds. Perimeter protection secures after-hours entry points.
Small Offices & Commercial PremisesCompact 1U desktop form factor suits office environments. DMSS remote access lets owners monitor from anywhere. 72W PoE budget handles all 8 cameras without a separate switch.
Warehouses & Workshops8 PoE ports handle large coverage areas with a single NVR. Supports up to 16MP cameras for wide-area coverage with enough detail to identify faces and licence plates.
Upgrading an Existing SystemONVIF support means you can reuse existing third-party cameras while upgrading to a modern AI NVR. Add Dahua WizSense cameras progressively as budget allows.
Childcare Centres & SchoolsFace detection and AI search speed up incident review for duty-of-care compliance. SMD+ reduces nuisance alerts in busy environments with constant movement.
What HDD Do I Need?
HDD Not Included — Choose Your CapacityThe NVR has 1 × SATA HDD bay supporting drives up to 16TB. We recommend a WD Purple or Seagate SkyHawk surveillance-grade drive — purpose-built for 24/7 NVR workloads with vibration compensation and extended write cycles.
Estimated Retention (8 × 4MP @ 15fps, H.265+, Motion-Only)1TB ≈ 7–10 days · 2TB ≈ 14–20 days · 4TB ≈ 30–40 days · 8TB ≈ 60–80 days. Continuous 24/7 recording will reduce these estimates. Contact our team for a precise calculation.
Technical Specifications
DHI-NVR4108HS-8P-AI/ANZ — Full Specifications
Model
DHI-NVR4108HS-8P-AI/ANZ
Channels
8 IP channels
Max Camera Resolution
16MP · 12MP · 8MP · 5MP · 4MP · 3MP · 1080p · 720p
Decoding (AI off)
2× 16MP@30fps · 4× 8MP@30fps · 8× 4MP@30fps
Decoding (AI on)
1× 16MP@30fps · 3× 8MP@30fps · 8× 1080p@30fps
Network Bandwidth
256 Mbps in/record/out (AI off) · 180 Mbps (AI on)
Video Output
1× HDMI (4K UHD) · 1× VGA · Simultaneous heterogeneous
Multi-screen Display
1/4/8/9 split (both screens)
Compression
Smart H.265+ · H.265 · Smart H.264+ · H.264 · MJPEG
Audio Compression
G.711a · G.711u · PCM · G.726
SMD Plus
4-channel by recorder · 8-channel by camera
Face Detection
1-channel by recorder · 8-channel by camera · 12 images/s
Face Recognition
Up to 10 databases · 200,000 face images · 2.5GB capacity
Face Attributes
Gender · Age group · Glasses · Expressions · Face mask · Beard
Perimeter Protection
2-channel by recorder (10 IVS rules/ch) · 8-channel by camera
ANPR by Camera
4 channels · Up to 20,000 plates · Blocklist/allowlist
Built-in PoE
8× PoE · IEEE 802.3af/at · 72W total · 25.5W max per port
HDD Bays
1× SATA (up to 16TB)
USB Ports
1× front USB 2.0 · 1× rear USB 2.0
Network Port
1× RJ45 10/100/1000 Mbps Gigabit
Audio
1× RCA audio in · 1× RCA audio out
Remote Access
DMSS app (iOS/Android) · Web viewer · SmartPSS · P2P
Third-Party Support
ONVIF 21.12 (Profile T/S/G) · Panasonic · Sony · Axis · Pelco · Canon
Browser Support
Chrome · Firefox · IE9+
Form Factor
Compact 1U · Rack or desktop
Dimensions
260 × 232.7 × 47.6 mm
Net Weight
0.92 kg (without HDD)
Power Supply
53V DC · 1.812A · <10W NVR · 72W PoE
Operating Temp
−10°C to +55°C
Storage Temp
−20°C to +60°C
Operating Humidity
10%–93% RH
Certifications
FCC Part 15 Class A · CE-EMC · CE-LVD · ANZ firmware
Downloads
Product Documents
Datasheet — DHI-NVR4108HS-8P-AI/ANZ
User Manual — Dahua NVR V2.3.0
Quick Start Guide
HDD Installation Guide
Frequently Asked Questions
Does this NVR include a hard drive?No — the NVR has 1× SATA bay supporting up to 16TB. We recommend WD Purple or Seagate SkyHawk surveillance-grade drives. Add one at checkout or contact our team for a sizing recommendation.
What cameras work with this NVR?All Dahua IP cameras work natively. ONVIF Profile T/S/G cameras (Hikvision, Uniview, Axis, Pelco, Sony, Canon, etc.) also work. For full AI features (SMD+, face recognition, perimeter protection), use Dahua WizSense cameras.
Do I need a separate PoE switch?No — the NVR has 8 built-in PoE ports with a 72W total budget and 25.5W max per port. Each camera connects directly to the NVR with a single Cat6 cable. No separate switch or power injectors needed.
How do I access it remotely?Download the free DMSS app on iOS or Android. The NVR connects via Dahua’s P2P cloud — no port forwarding, no static IP, no DDNS required. Also accessible via web browser (Chrome, Firefox) and SmartPSS desktop software.
What is SMD+ and why does it matter?Smart Motion Detection Plus uses AI to classify motion as human or vehicle only. You only get alerted when a real person or vehicle is detected — not animals, foliage, or weather. 4-channel SMD+ by recorder, 8-channel when using WizSense cameras.
How many faces can the face database store?Up to 10 face databases with a total of 200,000 face images (2.5GB capacity). Each face record can include name, gender, birthday, address, credential type, and more.
Does it support licence plate recognition?Yes — ANPR is supported via compatible Dahua cameras on up to 4 channels. Create blocklists and allowlists of up to 20,000 plate numbers and search recorded footage by plate instantly.
Can I use this NVR with my existing cameras?Yes — ONVIF 21.12 support means it works with most third-party IP cameras. Note that AI features like SMD+ and face recognition require Dahua WizSense cameras to function at full capability.
What’s the warranty?Dahua manufacturer warranty, supported locally by CCTV Guru’s Australian technical team. ANZ-certified firmware ensures full local compliance and support.
Do you ship Australia-wide?Yes — fast dispatch to every state and territory from Australian stock. Same-day dispatch on orders placed before 2pm AEST (business days).
Order the Dahua DHI-NVR4108HS-8P-AI/ANZ from CCTV Guru
CCTV Guru is an authorised Australian distributor of Dahua surveillance products. Order the Dahua 8-Channel 4K WizSense AI NVR today for fast Australia-wide dispatch, expert pre-sales advice on camera compatibility and HDD sizing, and full local warranty support. Contact our Australian team to build a complete camera kit around this NVR.
The Dahua DH-IPC-HDW3666EMP-S-AUS is a high-performance 6MP WizSense network turret camera designed to deliver elite-level security with simplified management. Powered by advanced AI algorithms, this camera excels at distinguishing between humans and vehicles, virtually eliminating false alarms from wind, rain, or animals. Now available in both Classic White and a sleek Midnight Black finish to suit any architectural style.
Advanced AI & Imaging Features
6MP Ultra-HD Resolution: Provides superior image clarity (3072 x 2048) for capturing critical details like faces and clothing textures.
SMD 4.0 (Smart Motion Detection): Intelligent AI filtering that focuses on human and vehicle targets, ensuring you only get alerted when it matters.
Perimeter Protection: Draw digital tripwires and intrusion zones to monitor specific areas with high-precision AI accuracy.
Starlight Technology: Produces clear, usable video in low-light conditions before switching to IR mode.
Built-in Microphone: High-fidelity audio recording adds an extra layer of evidence to your video footage.
Weatherproof Reliability: IP67 rated to withstand the harsh Australian sun and heavy rain.
Technical Specifications
Resolution
6MP (3072 × 2048)
Image Sensor
1/2.7" CMOS
Night Vision
Smart IR (Up to 30 meters)
Lens / FOV
2.8mm Fixed (97° Horizontal)
WDR
120dB True WDR
Audio
Built-in Mic (G.711 / G.726)
Storage
Micro SD Card Slot (Up to 256GB)
Color Options
White (S-AUS) / Black (S-AUS-B)
More Information
Download Data Sheet
Download Installation Guide
Download Quick Start Guide
Professional Tip: For the best AI performance, mount the camera between 2.5m and 3.5m high. This ensures the SMD 4.0 algorithm has the best angle for human and vehicle classification.
Dahua 8MP 4K AI Turret Camera – Intelligent Monitoring with Superior Clarity
The Dahua DH-IPC-HDW3866EMP-S-AUS is a robust 8MP (4K) turret network camera designed for advanced surveillance with AI functionality. Equipped with Smart Motion Detection Plus (SMD+), it accurately detects humans and vehicles while reducing false alarms from environmental noise.
Featuring a 2.8mm wide-angle lens, built-in microphone, WDR, and powerful infrared night vision up to 40 metres, this camera ensures crisp detail in both bright and low-light environments. With H.265+ compression and an IP67-rated enclosure, it’s an excellent choice for outdoor and indoor use in homes, offices, and commercial setups.
Why Choose This Camera:
8MP ultra-HD clarity for precise image capture
AI SMD+ technology: smart human & vehicle detection
Built-in mic for real-time audio monitoring
40m IR night vision and 120dB WDR
IP67 weatherproof & dustproof housing
ONVIF compatible and easy PoE setup
Key Specifications
Model
DH-IPC-HDW3866EMP-S-AUS
Image Sensor
1/2.7” 8MP Progressive CMOS
Max Resolution
3840 × 2160 @ 20fps
Lens
2.8mm fixed lens (horizontal FOV ~111°)
Night Vision
IR LEDs, up to 40m
AI Function
Smart Motion Detection Plus (SMD+)
Audio
Built-in microphone
WDR
120 dB Wide Dynamic Range
Video Compression
Smart H.265+, H.265, H.264
Power
PoE (802.3af) / 12V DC
Weatherproof Rating
IP67
Operating Temperature
-30°C to +60°C
Dimensions
Φ109.9 × 100.9 mm
Installation Accessories
Dahua Waterproof Junction Box White DH-PFA139
Dahua Waterproof Wall Mount Bracket DH-PFB204W
Dahua Pole Mount Bracket DH-PFA152-E
Dahua Ceiling Mount Adapter DH-PFA106
Dahua Ceiling Mount Bracket DH-PFB220C
Dahua Cat6 Ethernet Cables
Downloads
DH-IPC-HDW3866EMP-S-AUS Datasheet 20220718Dahua Eyeball Network Camera Quick Start Guide_V1.0.4Eyeball Network Camera nstallation Guide_V1.0.0Dahua Network Camera Web 5.0 Operation Manual_V1.0.4Dahua Network Camera Web 3.0 Operation Manual_V2.1.4
Dahua WizSense · AcuPick AI · Australian Stock
Dahua DH-IPC-HDW3867EM-S-IL-ANZ — 8MP 4K Smart Dual-Light Turret Camera with AcuPick AI
The Dahua DH-IPC-HDW3867EM-S-IL-ANZ is a premium 8MP 4K turret camera that combines intelligent AcuPick AI target search with Smart Dual-Light technology — delivering forensic-quality colour footage day and night, with the ability to rapidly locate specific people or vehicles from hours of recorded footage in seconds. Built around a 1/2.8" 8MP Progressive CMOS sensor and a 2.8 mm fixed lens (105° horizontal FOV), it outputs crisp 3840×2160 resolution and intelligently switches between IR and warm white LED illumination based on real-time scene activity — providing full-colour images only when needed, eliminating unnecessary light pollution.
Designed for Australian residential and commercial CCTV deployments, the DH-IPC-HDW3867EM-S-IL-ANZ features a built-in microphone for one-way audio recording, IP67 weatherproof metal housing rated for -30°C to +60°C, and standard PoE (802.3af) power. It integrates natively with Dahua 5-Series AcuPick NVRs for deep-learning-powered target matching, and supports ONVIF for compatibility with third-party VMS platforms already deployed across Australian sites.
Resolution
8MP · 3840 × 2160 (4K)
Lens
Fixed 2.8 mm · 105° FOV
Night Vision
Smart Dual-Light · 30 m
AI
AcuPick · SMD · IVS
Protection
IP67 · -30°C to +60°C
Power
PoE 802.3af · 12V DC
Dahua AcuPick AI
Australian Stock & Support
3-Year Dahua Warranty
Why Choose the Dahua DH-IPC-HDW3867EM-S-IL-ANZ in Australia
Australian integrators and property owners choose the DH-IPC-HDW3867EM-S-IL-ANZ because it solves two of the biggest pain points in modern CCTV: finding a specific person or vehicle quickly in hours of footage, and getting usable colour images at night without blinding light pollution. AcuPick AI cuts incident review time from hours to seconds, while Smart Dual-Light delivers full-colour footage only when a human or vehicle is present — preserving night ambience and battery life on hybrid systems. Available in both White and Black to suit any installation aesthetic.
AcuPick AI — Find Anyone in Seconds
AcuPick uses deep learning to accurately match human and vehicle targets across live and recorded video streams. What used to take hours of manual scrubbing now takes seconds — critical for post-incident investigation on Australian retail, residential and commercial sites. Requires a Dahua 5-Series AcuPick NVR.
Smart Dual-Light Night Vision
Intelligently switches between IR (black-and-white) and warm white LED (full colour) illumination based on real-time scene activity. Full-colour images are captured only when a human or vehicle is detected — no unnecessary light pollution, no washed-out footage.
8MP 4K Resolution
3840×2160 at 20 fps delivers forensic-quality detail — faces, licence plates and fine features captured with clarity well above standard HD cameras, meeting evidential requirements for Australian insurance and law enforcement.
SMD + IVS Analytics
Smart Motion Detection filters out irrelevant motion (animals, foliage, shadows) while IVS rules — tripwire, intrusion, abandoned object — trigger precise alerts for real events on Australian sites.
Built-In Microphone
Integrated microphone captures one-way audio alongside video — useful for reception areas, retail floors and entry points where ambient audio context adds evidential value.
IP67 · -30°C to +60°C — Built for Australia
Full IP67 dust and water ingress protection combined with an extreme operating temperature range makes this camera suitable for coastal, outback, alpine and CBD Australian environments alike.
AcuPick — How It Works
AcuPick is Dahua's deep-learning-powered target search system. When integrated with a Dahua 5-Series AcuPick NVR, the camera feeds AI-analysed metadata to the NVR, which can then search across all connected cameras simultaneously for a specific person (by clothing colour, body type) or vehicle (by colour, type). This dramatically reduces investigation time for security managers, loss prevention teams and property managers across Australia.
Note: AcuPick target search functionality requires a compatible Dahua 5-Series NVR. The camera operates as a standard 8MP IP camera with all other NVRs and ONVIF-compatible systems.
Technical Specifications
SKU / Model
DH-IPC-HDW3867EM-S-IL-ANZ
Camera Type
8MP 4K Smart Dual-Light Turret Camera
Image Sensor
1/2.8" 8MP Progressive CMOS
Max Resolution
3840 × 2160 (8MP / 4K) @ 20 fps
Lens Type
Fixed, 2.8 mm (105° Horizontal FOV)
Night Vision
Smart Dual-Light · IR up to 30 m · Warm White LED up to 30 m
AI Features
AcuPick · SMD (Smart Motion Detection) · IVS (Tripwire, Intrusion, Abandoned Object)
Audio
Built-in Microphone (One-Way)
Video Compression
H.265+ / H.265 / H.264+ / H.264
Weatherproof Rating
IP67
Operating Temperature
-30°C to +60°C
Power Source
12V DC · PoE (IEEE 802.3af)
Dimensions
Φ109.9 × 100.9 mm
Camera Style
Turret (Eyeball)
Colours Available
White · Black
Compatibility
Dahua 5-Series AcuPick NVRs · ONVIF-compliant systems
Warranty
3-Year Dahua Warranty (Australia)
Downloads & Resources
DH-IPC-HDW3867EM-S-IL-ANZ Datasheet
Quick Start Guide (PDF)
Web Operation Manual (PDF)
Order the Dahua DH-IPC-HDW3867EM-S-IL-ANZ from CCTV Guru
CCTV Guru is an authorised Australian retailer of Dahua security cameras. Order the DH-IPC-HDW3867EM-S-IL-ANZ today for fast Australia-wide dispatch, expert pre-sales advice, project pricing for multi-camera rollouts, and full local warranty support. Available in White and Black. Contact our Australian team for tailored quotes on larger installations or AcuPick NVR bundles.
Dahua 16 Channels AI NVR DHI-NVR5216-16P-AI/ANZ, 1U 16PoE 2HDD WizSense Network Video Recorder
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
32-channel 1080p self-adaptive decoding capability.
Max. 384 Mbps incoming/recording/outgoing bandwidth.
AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus.
AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, and people counting.
Security baseline 2.3.
Specifications
Number of Channels
16 Channel
Number of PoE Ports
16 x PoE Ports
Number of Hard Disk Bay
2 x HDD Bay
Technology
WizSense AI Series
Network Bandwidth
AI disabled: 256 Mbps incoming, 256 Mbps recording and 256 Mbps outgoing AI enabled: 180 Mbps incoming, 180 Mbps recording and 180 Mbps outgoing
Maximum Resolution Support
32MP
Downloads
Datasheet for NVR5216-16P-AI/ANZ
Dahua WizSense — ANZ Model
Dahua DH-IPC-HDW2541EMP-AS-ANZ — 5MP WizSense Turret Camera
The Dahua DH-IPC-HDW2541EMP-AS-ANZ is a professional-grade 5 megapixel WizSense IP turret camera engineered for Australian residential and commercial surveillance. With AI-powered Smart Motion Detection Plus (SMD+), 30 m IR night vision, a built-in microphone, and an IP67-rated weatherproof housing, it delivers reliable 24/7 security in any environment — indoors or out.
Resolution
5MP / 2K
Night Vision
IR 30 m
Weather Rating
IP67
Power
PoE / 12V DC
Why Choose the Dahua DH-IPC-HDW2541EMP-AS-ANZ?
SMD+ AI Human & Vehicle Detection
WizSense Smart Motion Detection Plus filters out false alarms caused by animals, leaves, and lighting changes — only alerting you when a real human or vehicle is detected.
5MP 2K Clarity
A 1/2.7" CMOS sensor delivers crisp 2960 × 1668 @ 20 fps or 2688 × 1520 @ 25/30 fps footage — enough detail to identify faces, plates, and incidents clearly.
30 m IR Night Vision
Built-in IR LEDs illuminate up to 30 metres in complete darkness, ensuring clear footage around the clock without any additional lighting.
Perimeter Protection
Tripwire and intrusion detection let you define virtual boundaries. Get instant alerts the moment someone crosses a line or enters a restricted zone.
Built-in Microphone
Capture audio alongside video for richer evidence. The integrated mic eliminates the need for external audio hardware in most installations.
IP67 Weatherproof + PoE
Fully sealed against dust and rain for reliable outdoor use. Single-cable PoE (802.3af) simplifies installation — no separate power run needed.
Smart H.265+ Compression
Intelligent coding reduces bandwidth and storage consumption by up to 70% vs standard H.264, without sacrificing image quality.
256 GB MicroSD Edge Storage
Local microSD storage keeps footage safe even if your NVR or network goes down — up to 256 GB of on-camera backup recording.
Technical Specifications
Model
DH-IPC-HDW2541EMP-AS-ANZ
Image Sensor
1/2.7" 5MP CMOS
Max Resolution
2960 × 1668 @ 20 fps
Standard Resolution
2688 × 1520 @ 25/30 fps
Night Vision
Built-in IR LEDs, up to 30 m
AI Analytics
SMD+ (human/vehicle), Perimeter Protection (Tripwire, Intrusion)
Image Enhancements
WDR, 3D-NR, BLC, HLC, ROI, Rotation, Digital Watermarking
Abnormality Alerts
Video/audio tampering, SD card status, network errors
Audio
Built-in microphone
Video Compression
Smart H.265+, H.265, H.264+, H.264
Local Storage
MicroSD up to 256 GB
Power Supply
12V DC / PoE (802.3af)
Weatherproof Rating
IP67
SKU
DH-IPC-HDW2541EMP-AS-ANZ
Frequently Asked Questions
What is WizSense SMD+?
SMD+ (Smart Motion Detection Plus) uses AI to distinguish humans and vehicles from other motion triggers like animals or swaying trees, dramatically reducing false alarms.
Does this camera work with Dahua NVRs?
Yes. It's fully compatible with Dahua NVRs and the DSS/DMSS platform. It also supports ONVIF for third-party NVR integration.
Can it be used outdoors in Australian conditions?
Absolutely. The IP67 rating means it's fully sealed against dust and water ingress, making it suitable for Australian outdoor environments including coastal and high-humidity areas.
Does it need a separate power supply?
No — it supports PoE (802.3af), so a single Ethernet cable from a PoE switch or NVR provides both data and power. A 12V DC adaptor can also be used.
What lens size does it come with?
The ANZ model ships with a fixed 2.8 mm lens, providing a wide field of view ideal for entry points, hallways, and open areas.
Is local storage supported without an NVR?
Yes. Insert a microSD card (up to 256 GB) and the camera records locally — useful as a standalone solution or as a backup when the NVR is offline.
Downloads
Download Datasheet
Quick Start Guide
Fast AU Shipping
Genuine Dahua Stock
Expert AU Support
Dahua DHI-NVR5208-8P-AI/ANZ 8 Channel AcuPick AI NVR, 8 PoE, 2 x HDD Bay, 1U, NVR Recorder
Experience the advanced WizSense series by Dahua Technology, designed to provide high accuracy recognition of humans and vehicles. With independent AI chips and deep learning algorithms, this NVR offers intelligent and simple solutions for your IP video surveillance needs. Benefit from high-grade recording technology to effectively monitor and react to defined targets.
What is AcuPick?
Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets.
Notes: This AcuPick feature only works with Dahua 5-Series NVRs. Click here to shop.
Features
Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.
Max. decoding capability: 32 × 1080p@30 fps or 8 × 8MP@30 fps.
Max. 384/384/384 Mbps incoming/recording/outgoing bandwidth.
Supports IP cameras with a resolution up to 32 MP.
Supports AcuPick with up to 8 channels.
Supports N+M cluster, iSCSI.
AI by Recorder supports 2-channel face detection and recognition, up to 20 face databases and 20,000 face images; 4-channel perimeter protection; 8-channel SMD Plus.
AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.
Supports EPTZ, and one-click arming and disarming.
More Information
DHI-NVR5208-8P-AI/ANZ DatasheetDHI-NVR5208-8P-AI/ANZ Quick Start GuideDahua User ManualDHI-NVR5208-8P-AI/ANZ DimensionDahua NVR HDD Installation Guide
The Dahua IPC-HDW3849H-AS-PV-PRO-ANZ is the ultimate 8MP 4K TiOC (Three-in-One Camera). As part of the WizSense Pro Series, it delivers crystal-clear 4K resolution combined with Active Deterrence and the groundbreaking AcuPick AI. This is the professional choice for high-end residential and commercial security in Australia.
Pro Series vs. Standard S2: Why 8MP Pro Matters
Choosing the PRO-ANZ model ensures you are getting Dahua's highest-tier hardware:
Professional 1/1.8" Sensor: Most 8MP cameras use a small sensor that struggles at night. The Pro uses a massive 1/1.8" sensor, providing vastly superior low-light clarity and 4K detail.
F1.0 Super Aperture: The Pro lens pulls in maximum light, maintaining Full-Colour imaging in environments where other 4K cameras switch to grainy black-and-white.
AcuPick Enabled: Fully compatible with AcuPick technology, allowing you to locate specific people or vehicles across your system in seconds.
TiOC 3.0 Tech: Improved dual-mic "VoiceCatcher" technology for better audio and fewer false alarms via SMD 4.0.
Key Features
8MP 4K Ultra-HD: Stunning 3840 × 2160 resolution for forensic-level detail.
Active Deterrence: Built-in Red & Blue flashing lights and a powerful 110dB siren to stop intruders instantly.
24/7 Full-Colour: High-performance warm LED illuminators provide vivid colour video in total darkness.
Two-Way Audio: High-sensitivity dual mics and a built-in speaker for clear communication via the DMSS app.
IP67 Weatherproof: Full metal housing designed to withstand the harsh Australian climate.
Full Technical Specifications
Feature
IPC-HDW3849H-AS-PV-PRO-ANZ
Image Sensor
1/1.8" Progressive Scan CMOS (Pro Grade)
Max. Resolution
8MP 4K (3840 × 2160) @ 25/30 fps
Min. Illumination
0.0005 Lux @ F1.0 (Color, 30 IRE)
Lens / FOV
2.8mm Fixed Focal (106° Horizontal)
Illumination Range
IR (30m) + Warm Light (30m) - Smart Dual Light
AI Intelligence
AcuPick, SMD 4.0, IVS (Tripwire & Intrusion), AI SSA
Audio
Built-in Dual Mic + Built-in Speaker
Storage
MicroSD Card Slot (Up to 512GB)
More Information
Download Datasheet
Quick Start Guide
Installation Guide
Frequently Asked Questions
What is AcuPick?AcuPick is an industry-leading AI search technology that allows you to select a target from a video clip and instantly find all occurrences across your entire camera system, reducing search time by 90%.
This AcuPick feature only works with Dahua 5-Series NVRs. Click here to shop.
Is this an ANZ model?Yes, this is the official Australian/New Zealand (-ANZ) model with local firmware and Australian warranty support.
Downloads
Dahua IPC-HDW3849H-AS-PV-PRO_S0 Datasheet 20240517 Dahua Network Camera Web 5.0_Operation Manual_V1.2.2Dahua Eyeball Network Camera_Quick Start Guide_V1.0.5 Eyeball Network Camera Installation Guide_V1.0.3 Dahua Network Camera Web 3.0_Operation Manual_V2.1.8
Dahua Security Camera 8MP (4K) WizSense Motorised Starlight Turret, 2.7-13.5mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR40m, Built-in Mic, IP67, PoE
Features
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8 MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Turret
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
WizSense Series
CONNECTION
PoE
Downloads
DH-IPC-HDW3866TP-ZS-AUS Datasheet 20220718Dahua Eyeball Network Camera Quick Start Guide V1.0.4Eyeball Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua 32 Channels WizSense Series AI NVR, DHI-NVR5432-AI/ANZ comes with no PoE port, 1.5U, 4 x HDD Bay. Work with Dahua DMSS and SmartPSS. Suitable for warehouse or big office surveillance needs.
Feature
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format
32-channel 1080p self-adaptive decoding capability
Max. 384 Mbps incoming/recording/outgoing bandwidth
AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting
Security baseline 2.3
Specification
NVR
Number of Channels
32 Channel
Number of PoE Ports
0 x PoE Ports
Number of Hard Disk Bay
4 x HDD Hard Disk Bay
Technology
WizSense AI Series
Network Bandwidth
AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
Download
NVR5432-AIANZ
Dahua IPC-HDW3649H-AS-PV-ANZ-S2 6MP TiOC WizSense Camera (White / Black)
The Dahua IPC-HDW3649H-AS-PV-ANZ-S2 is a powerful 6MP WizSense TiOC network camera designed for intelligent perimeter protection and active deterrence. Available in white and black, this model combines high-resolution imaging, Smart Dual Light, AI analytics and built-in warning systems for superior day and night surveillance.
With Smart Dual Light (IR + warm white LED), the camera automatically switches lighting modes to provide full-colour video when a target is detected. Its TiOC (Three-in-One Camera) design integrates video monitoring, red/blue flashing warning lights and a built-in siren to actively deter intruders.
Key Features
6MP high-resolution imaging
Smart Dual Light (IR + warm LED)
TiOC active deterrence: red/blue lights + siren
WizSense AI with human & vehicle classification (SMD 4.0)
Intrusion & tripwire perimeter protection
Built-in microphone & speaker (two-way audio)
MicroSD support (up to 512GB)
Smart H.265+ compression
PoE & 12V DC power options
IP67 weatherproof housing
What is TiOC?
TiOC (Three-in-One Camera) combines:
AI detection (human & vehicle classification)
Active visual deterrence (red/blue flashing lights)
Audible deterrence (built-in siren & voice broadcast)
This allows the camera not only to detect events — but to actively warn intruders in real time.
What is AcuPick?
AcuPick is Dahua’s advanced AI search technology. When paired with a compatible Dahua 5-Series NVR, AcuPick allows you to:
Quickly search recorded footage for specific people or vehicles
Filter by attributes
Reduce playback time dramatically
Compatible Dahua Recorders
DHI-NVR4216-16P-AI/ANZ – 16CH WizSense PoE NVR
DHI-NVR5216-16P-AI/ANZ – 16CH AI NVR (Supports AcuPick)
DHI-NVR5432-16P-AI/ANZ – 32CH AI NVR
DHI-NVR5464-AI/ANZ – 64CH enterprise AI NVR
For full AcuPick functionality, pair this camera with a Dahua 5-Series NVR.
Technical Specifications
Specification
Details
Model
IPC-HDW3649H-AS-PV-ANZ-S2
Resolution
6MP
Camera Type
TiOC WizSense Network Turret
Lens
2.8mm fixed (wide angle)
Dual Light
IR + Warm LED (auto switching)
AI Features
Human/Vehicle Classification (SMD 4.0), Intrusion, Tripwire
Active Deterrence
Red/Blue Warning Lights + Siren
Audio
Built-in Mic & Speaker
Storage
MicroSD up to 512GB
Video Compression
Smart H.265+ / H.264+
Power
PoE / 12V DC
Weather Rating
IP67
Colour Options
White / Black
More Information
Dahua IPC-HDW3649H-AS-PV-ANZ-S2 Datasheet Dahua Network Camera Web 3.0_Operation Manual_V2.1.8 Eyeball Network Camera Installation Guide_V1.0.3 Dahua Eyeball Network Camera_Quick Start Guide_V1.0.5 Dahua Network Camera Web 5.0_Operation Manual_V1.2.1
Dahua 32-Channel WizSense AI NVR – DHI-NVR5432-16P-AI-ANZ | Intelligent, Scalable CCTV Recording
Upgrade to powerful and intelligent CCTV recording with the Dahua DHI-NVR5432-16P-AI-ANZ, a high-performance 32-channel WizSense AI Network Video Recorder built for professional surveillance systems. Designed for medium to large-scale commercial and enterprise security, this NVR supports advanced AI analytics, 4K resolution, and 16 built-in PoE ports for direct IP camera connectivity.
This NVR features WizSense AI technology including Smart Motion Detection Plus (SMD+), face recognition, perimeter protection, and people counting. With support for H.265+ compression, multiple HDD bays (up to 20TB each), and remote access via DMSS, it’s a reliable and scalable solution for growing surveillance needs.
Key Benefits
Supports up to 32 IP cameras
16 PoE ports for plug-and-play setup
AI features: SMD+, Face Detection, IVS, Heat Mapping
4K HDMI/VGA video output
H.265+ video compression for storage efficiency
4 × SATA interfaces (up to 20TB each, HDD not included)
Remote access via DMSS App (iOS/Android)
ONVIF-compliant, compatible with third-party IP cameras
Ideal for schools, shopping centres, warehouses, and multi-site businesses needing intelligent video surveillance.
Specification
Model
DHI-NVR5432-16P-AI-ANZ
Channels
32 IP Channels
PoE Ports
16 × PoE (IEEE802.3af/at)
AI Functions
SMD+, Face Detection, IVS, People Counting
Video Output
1 × HDMI (4K), 1 × VGA
Compression
H.265+, H.265, H.264
HDD Bays
4 × SATA (up to 20TB each, HDD not included)
Network
2 × RJ-45 10/100/1000 Mbps ports
USB
2 × USB 2.0, 1 × USB 3.0
Remote Access
DMSS App, Web Interface
Dimensions
375 × 327 × 53 mm
Download
DHI-NVR5432-16P-AI/ANZ Datasheet
Dahua Security Camera 8MP (4K) WizSense Motorised Starlight Bullet, 2.7-13.5mm, 4K@25/30fps, Perimeter, SMD 4.0, SD Card, WDR, IR60m, Built-in Mic, IP67, POE
8MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 6 MP (3072 x 2048) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 60 m.
ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply, easy for installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HFW3866TP-ZAS-AUS DatasheetBullet Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4=Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua Security Camera 6MP WizSense Fixed Starlight Dome, 2.8mm, Perimeter, SMD 4.0, SD Card, WDR, IR50m, Built-in Mic, IP67, IK10, POE
The Dahua 6MP WizSense Fixed Starlight Dome Camera delivers exceptional image clarity with its 1/2.7" CMOS sensor and 6MP resolution at 30fps. Equipped with advanced AI features, it accurately detects intrusion and tripwire events, distinguishing between humans and vehicles. Its built-in IR LEDs provide up to 50 meters of night vision, while WDR and 3D noise reduction ensure clear images in challenging lighting. The camera supports flexible H.265 compression for efficient storage and bandwidth use. Ruggedly designed with IP67 and IK10 ratings, plus PoE and an integrated microphone, it’s ideal for reliable perimeter security in diverse environments.
Features
6MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 6 MP (3072 x 2048) @25/30 fps.
H.265 codec allows high compression ratio and ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply, easy for installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
6MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WIZSENSE SERIES
POE
POE
Downloads
DH-IPC-HDBW3666EP-AS-AUS Datasheet 20220718Dahua Dome Network Camera_Quick Start Guide_V1.0.1Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua Security Camera 8MP (4K) WizSense Fixed Starlight Dome, 2.8mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR30m, Built-in Mic, IP67, IK10, POE
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8 MP (3840 x 2160) @25/30 fps.
H.265 codec allows high compression ratio and ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HDBW3866EP-AS-AUS Datasheet 20220718Dahua Dome Network_ Camera Quick Start Guide_V1.0.1Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua Security Camera 8MP (4K) WizSense Motorised Starlight Bullet, 2.7-13.5mm, 4K@25/30fps, Perimeter, SMD 4.0, SD Card, WDR, IR60m, Built-in Mic, IP67, POE, black
The Dahua 8MP 4K WizSense Motorised Starlight Bullet Camera delivers exceptional image clarity with its 1/2.7” CMOS sensor and maximum 6MP output at 30fps. Featuring a vari-focal 2.7-13.5mm lens and built-in IR LEDs with 60m range, it ensures reliable surveillance day and night. Advanced H.265 compression optimizes bandwidth and storage, while intelligent perimeter protection detects intrusion and tripwire events, distinguishing between humans and vehicles. Additional features include WDR, 3D NR, digital watermarking, built-in microphone, IP67 weatherproofing, and Power over Ethernet for easy installation—ideal for high-security monitoring environments.
Features
8MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 6 MP (3072 x 2048) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 60 m.
ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply, easy for installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Bullet
COLOUR
Black
LENS TYPE
Motorised
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HFW3866TP-ZAS-AUS-BLK DatasheetBullet Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua Security Camera 8MP (4K) WizSense Motorised Starlight Turret, 2.7-13.5mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR40m, Built-in Mic, IP67, PoE, Black
Professional-grade 8MP 4K security camera engineered for demanding surveillance applications. Features a 1/2.8" CMOS sensor with exceptional low-light performance and motorised 2.7-13.5mm vari-focal lens for flexible coverage. Delivers 4K resolution at 25/30fps with H.265 codec compression for efficient storage and bandwidth management. Advanced WizSense AI detection identifies intrusions and tripwire events with human/vehicle classification. Built-in 40m IR illumination, IP67 weatherproofing, and POE power simplify installation. Includes SD card backup, digital watermarking, and intelligent image processing (WDR, 3D NR, HLC, BLC) for reliable performance across varied lighting conditions. Ideal for perimeter protection and critical security deployments.
Features
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8 MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Turret
COLOUR
Black
LENS TYPE
Motorised
TECHNOLOGY
WizSense Series
Connection
PoE
Downloads
DH-IPC-HDW3866TP-ZS-AUS-BLK DatasheetDahua Eyeball Network Camera Quick Start Guide V1.0.4Eyeball Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua Security Camera 8MP (4K) WizSense Fixed Starlight Bullet, 2.8mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR30m, Built-in Mic, IP67, POE, Black
The Dahua Security Camera 8MP (4K) IR Fixed-focal Bullet WizSense Network Camera offers excellent low luminance performance and high definition images with its 8MP 1/2.8'' CMOS sensor. With its built-in IR LED, it can capture images up to 30m even in low light conditions. Its advanced features, such as intelligent detection and flexible coding, make it versatile for various monitoring scenarios. Experience reliable and high-quality surveillance with Dahua.
Features
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8 MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Bullet
COLOUR
Black
LENS TYPE
Fixed
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HFW3866EP-AS-AUS-BLK DatasheetDahua HD IR Bullet Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua Security Camera 8MP (4K) WizSense Fixed Starlight Bullet, 2.8mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR30m, Built-in Mic, IP67, PoE
The Dahua 8MP WizSense Fixed Starlight Bullet delivers professional-grade 4K surveillance with exceptional low-light performance. Featuring a 1/2.8" CMOS sensor, this camera captures crisp 3840 x 2160 resolution at 25/30fps, ideal for perimeter monitoring and detailed identification. The 2.8mm lens provides wide coverage, while 30m IR illumination ensures round-the-clock visibility. H.265 codec compression minimizes bandwidth and storage demands without compromising image quality. Advanced features include intelligent perimeter detection (intrusion and tripwire with vehicle/human classification), WDR for challenging lighting, 3D noise reduction, and built-in microphone for audio monitoring. IP67-rated weatherproof housing and PoE power delivery simplify installation. SD card support enables local backup, making this camera a reliable choice for demanding security applications.
Features
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8 MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WizSense
POE
POE
Downloads
DH-IPC-HFW3866EP-AS-AUS Datasheet 20220415Dahua HD IR Bullet Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua Security Camera 8MP (4K) WizSense Motorised Starlight Dome, 2.7-13.5mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR40m, Built-in Mic, IP67, IK10, POE, black
The Dahua 8MP 4K WizSense Motorised Dome Camera delivers crystal-clear surveillance with a 1/2.8" CMOS sensor and 3840 x 2160 resolution at 25/30 fps. Its vari-focal lens (2.7-13.5mm) allows precise zooming, while built-in IR LEDs provide up to 40 meters of night vision. Advanced features include perimeter protection with human and vehicle classification, SMD 4.0, WDR, 3D noise reduction, and digital watermarking. The camera supports H.265 compression for efficient storage and bandwidth use, is IP67 and IK10 rated for durability, and includes PoE and a built-in microphone for comprehensive monitoring.
Features
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports); max. 256 G Micro SD card; built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Dome
COLOUR
Black
LENS TYPE
Motorised
TECHNOLOGY
WizSense Series
PoE
PoE
Downloads
DH-IPC-HDBW3866RP-ZAS-AUS-BLK DatasheetDahua Dome Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
The DH-IPC-HFW3666EP-AS-AUS is a professional-grade 6-Megapixel WizSense network camera featuring an advanced 1/2.7" CMOS sensor. Designed for high-clarity surveillance, it utilizes Dahua's WizSense technology to focus specifically on human and vehicle targets, significantly reducing false alarms and improving security efficiency.
Key Features
6MP Ultra-High Definition: Captures crystal-clear imagery at 3072 × 2048 resolution, providing 50% more detail than standard 4MP cameras.
WizSense AI (SMD 4.0): Advanced Smart Motion Detection that accurately distinguishes humans and vehicles from animals, rustling leaves, and light interference.
Perimeter Protection: Supports Tripwire and Intrusion functions with high-accuracy classification to secure property boundaries.
Starlight Technology: Provides clear, detailed color video in extremely low-light conditions where standard cameras would switch to black and white.
Built-in Microphone: High-fidelity integrated mic for synchronized audio recording, adding an extra layer of evidence to your footage.
Rugged External Design: Rated IP67 for superior protection against dust and water, making it ideal for harsh Australian outdoor conditions.
Smart H.265+ Compression: Reduces bandwidth and storage costs by up to 70% while maintaining high video quality.
Technical Specifications
Image Sensor
1/2.7" 6-Megapixel Progressive CMOS
Max. Resolution
3072 (H) × 2048 (V)
IR Distance
Up to 50 Meters (164 ft)
WDR
120 dB True WDR
Audio Interface
Built-in MIC; 1-ch Audio In/Out
Storage
Micro SD Slot (up to 256GB)
Ingress Protection
IP67 Weatherproof
More Information
For full technical details, installation requirements, and setup procedures, please refer to the official documentation below:
DH-IPC-HFW3666EP-AS-AUS Datasheet 20220718Dahua HD IR Bullet Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua Security Camera 8MP (4K) WizSense Fixed Starlight Dome, 2.8mm, 4K@25/30fps, Perimeter, SMD 4.0, SD Card, WDR, IR30m, Built-in Mic, IP67, IK10, POE, black
The Dahua 8MP WizSense Fixed Starlight Dome Camera delivers ultra-clear 4K resolution at 25/30fps, powered by a 1/2.8" CMOS sensor optimized for low light conditions. Featuring advanced AI perimeter protection with intrusion and tripwire detection, it distinguishes humans and vehicles accurately. The camera supports flexible video encoding with H.265 for efficient bandwidth and storage use. Its robust design includes built-in IR LEDs with a 30m range, IP67 weather resistance, IK10 vandal protection, and Power over Ethernet for simplified installation. Additional enhancements like WDR, 3D noise reduction, and a built-in microphone ensure reliable, high-quality surveillance in diverse environments.
Features
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8 MP (3840 x 2160) @25/30 fps.
H.265 codec allows high compression ratio and ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Dome
COLOUR
Black
LENS TYPE
Fixed
TECHNOLOGY
WizSense Series
CONNECTION
PoE
Downloads
DH-IPC-HDBW3866EP-AS-AUS-BLK DatasheetDahua Dome Network_ Camera_Quick Start Guide_V1.0.1Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua Security Camera 4MP WizSense Fixed Starlight Dome, 2.8mm, Perimeter, SMD, SD Card, WDR, IR30m, Built-in Mic, IP67, IK10, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent detection: Intrusion, tripwire (support the classification and vaccurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HDBW3466FP-AS-AUS Datasheet_20220426Dahua Dome Network_ Camera Quick Start Guide_V1.0.1Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
The existing description is comprehensive and well-structured. Since no excerpt was selected and no specific edit instruction was provided, there is no new content to add. The current description effectively covers the camera's key features, technical specifications, and includes downloadable documentation. If you'd like me to modify, expand, or refine any section of this description, please let me know which part to edit or what changes you'd like made.
Dahua Security Camera 6MP WizSense Motorised Starlight Bullet, 2.7–13.5 mm, Perimeter, SMD4.0, SD Card, WDR, IR60m, Built-in Mic, IP67, POE
6MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 6 MP (3072 x 2048) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 60 m.
ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply, easy for installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
6MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
WIZSENSE SERIES
POE
POE
Downloads
DH-IPC-HFW3666TP-ZAS-AUS Datasheet 20220718Bullet Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua TiOC V2 · Active Deterrence · Australian Stock
Dahua DH-IPC-HFW3849T1-AS-PV-ANZ — 8MP TiOC Active Deterrence Bullet Camera
The Dahua DH-IPC-HFW3849T1-AS-PV-ANZ is a next-generation 8MP TiOC V2 bullet camera engineered to deter intruders before they act — not just record them after the fact. Combining a 1/2.8" CMOS sensor delivering 3840×2160 (4K) resolution with Dahua's TiOC (Three-in-One Camera) technology, it integrates full-colour night vision, AI-powered SMD 4.0 detection and an active deterrence system (red/blue strobe lights + built-in siren) into a single weatherproof bullet housing. A fixed 2.8 mm wide-angle lens, two-way audio via dual microphones and a built-in speaker, and PoE power make it a complete, cable-efficient solution for Australian homes, driveways, retail forecourts and commercial perimeters.
As part of the WizSense Series, the DH-IPC-HFW3849T1-AS-PV-ANZ uses SMD 4.0 to accurately classify humans and vehicles — triggering active deterrence only for genuine threats. One-click arming/disarming via alarm input, onboard microSD storage (up to 256 GB) and H.265+ compression round out a camera that delivers professional-grade deterrence at a practical price point for Australian installers and end users.
Resolution
8MP · 3840 × 2160 (4K)
Lens
Fixed 2.8 mm
Night Vision
Full Colour · 30 m IR + Warm
AI Detection
SMD 4.0 · Human & Vehicle
Active Deterrence
Red/Blue Strobe · Siren · Two-Way Audio
Power
PoE 802.3af · 12V DC
Dahua TiOC V2 AI
Australian Stock & Support
3-Year Dahua Warranty
Why Choose the Dahua DH-IPC-HFW3849T1-AS-PV-ANZ in Australia
Australian installers and security-conscious property owners choose the DH-IPC-HFW3849T1-AS-PV-ANZ because it does what most cameras can't: it actively stops incidents rather than just documenting them. The combination of 4K resolution for forensic-quality evidence, full-colour night vision for 24/7 colour footage, and AI-triggered red/blue strobe lights with a siren makes it a genuine deterrent for driveways, front doors, retail entries, car parks and side paths across Australia.
8MP 4K Resolution
3840×2160 at 25/30 fps delivers forensic-quality footage — faces, licence plates and fine detail captured with clarity well above standard HD cameras, meeting evidential requirements for Australian insurance and law enforcement.
TiOC Full Colour Night Vision
Dual built-in warm light LEDs (30 m range) produce vivid, full-colour footage in complete darkness — no black-and-white IR footage. Colour detail at night dramatically improves identification of clothing, vehicles and individuals.
Active Deterrence — Red/Blue Strobe + Siren
When SMD 4.0 detects a human or vehicle crossing a defined zone, the camera triggers red and blue flashing lights and an audible siren to warn off intruders in real time — before any damage is done.
SMD 4.0 AI Detection
Smart Motion Detection 4.0 accurately classifies humans and vehicles, eliminating false alarms from animals, foliage and passing headlights — so deterrence triggers only when it matters.
Two-Way Audio
Dual built-in microphones and a 1-channel speaker enable live two-way communication — warn visitors, speak to delivery drivers or issue verbal warnings to intruders directly from your phone or NVR.
IP67 + PoE — Built for Australia
IP67 weatherproofing handles Australian rain, dust and UV exposure across coastal, outback and CBD installs. Standard PoE means a single Cat6 cable carries both power and data — clean, cost-effective installation.
Technical Specifications
SKU / Model
DH-IPC-HFW3849T1-AS-PV-ANZ
Camera Type
8MP TiOC V2 Active Deterrence Bullet Camera
Image Sensor
1/2.8" CMOS
Max Resolution
3840 × 2160 (8MP / 4K) @ 25/30 fps
Lens Type
Fixed, 2.8 mm
Night Vision
Full Colour · IR LED 30 m · Warm Light LED 30 m
Dynamic Range
WDR
Video Compression
H.265+ / H.265 / H.264+ / H.264 / MJPEG
AI Features
SMD 4.0 · Perimeter Protection (Intrusion, Tripwire) · Human & Vehicle Classification
Active Deterrence
Red/Blue Strobe Lights · Built-in Siren · One-Click Arm/Disarm via Alarm Input
Audio
2 × Built-in Microphones · 1 × Built-in Speaker · Two-Way Talk · 1 Audio In / 1 Audio Out
Alarm I/O
1 Alarm Input · 1 Alarm Output
Edge Storage
microSD / microSDHC / microSDXC (up to 256 GB)
Weatherproof Rating
IP67
Power Source
12V DC · PoE (IEEE 802.3af)
Camera Style
Bullet
Colour
White
Technology
WizSense / TiOC V2 Series
Warranty
3-Year Dahua Warranty (Australia)
Downloads & Resources
IPC-HFW3849T1-AS-PV Datasheet
Installation Guide (PDF)
Quick Start Guide (PDF)
Web 5.0 Operation Manual (PDF)
Web 3.0 Operation Manual (PDF)
Order the Dahua DH-IPC-HFW3849T1-AS-PV-ANZ from CCTV Guru
CCTV Guru is an authorised Australian distributor of Dahua security cameras. Order the DH-IPC-HFW3849T1-AS-PV-ANZ today for fast Australia-wide dispatch, expert pre-sales advice, project pricing for multi-camera installations, and full local warranty support. Contact our Australian team for tailored quotes on larger deployments.
Dahua WizSense Series 8MP TiOC 3.0 Active Deterrence Bullet Network Camera with 2.8mm Fixed Lens, Built-in Mic & Speaker, WDR, Micro SD, IP67, PoE, Support AcuPick
White SKU: DH-IPC-HFW3849T1-AS-PV-ANZ-S2Black SKU: DH-IPC-HFW3849T1-AS-PV-ANZ-S2-BLK
Dahua WizSense 3 Series Network Camera greatly saves on bandwidth and storage space through its AI Coding technology. Driven by its advanced deep learning algorithms, the camera supports intelligent functions such as perimeter protection, smart motion detection (SMD), AcuPick, and AI SSA (AI Scene Self-adaptation), making it easy and convenient to use. Starlight technology and its large aperture lens alsoallow the camera to produce clear, vivid images even in poor lighting conditions.
What is AcuPick?
Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets.
Notes: This AcuPick feature only works with Dahua 5-Series NVRs. Click here to shop.
Features
8MP 1/2.7'' CMOS image sensor, low luminance, and high definition image
Outputs max. 8 MP (3840 x 2160)@25/30 fps
H.265 codec, high compression rate, ultra-low bit rate
Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m
ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human)
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk
12 VDC/PoE power supply
IP67 protection
Sound and light alarm (red and blue lights)
SMD 4.0
Supports AI SSA and one-tap arming and disarming
SMD area can be set in warm light areas that support triggering alarms.
Specifications
Dahua AcuPick Network Camera
Megapixels
8MP
Camera Style
Bullet
Colour
White
Lens Type
Fixed
Technology
WizSense Series
Connection
PoE
Downloads
Dahua IPC-HFW3849T1-AS-PV-ANZ-S2 Datasheet Dahua Bullet Network Camera_Quick Start Guide_V1.0.2 Dahua Network Camera Web 3.0_Operation Manual_V2.1.8 Bullet Network Camera Installation Guide_V1.0.0 Dahua Network Camera Web 5.0_Operation Manual_V1.2.1
The Dahua IPC-HDW3649H-AS-PV-PRO-ANZ is the flagship 6MP turret in the TiOC (Three-in-One Camera) lineup. While standard models offer great security, the Pro Series is engineered for high-performance low-light environments and advanced forensic searching via AcuPick AI.
Pro vs. Standard: What is the difference?
Many retailers sell the S2 (Standard) version, but here is why the PRO-ANZ model is the superior choice:
Larger Sensor: The Pro features a 1/1.8" CMOS sensor, which is physically larger than the 1/2.7" sensor in the S2. This means significantly cleaner images and less "motion blur" at night.
Superior Lens: Equipped with an F1.0 Super Aperture lens, the Pro pulls in nearly double the light of the S2 (F1.4), maintaining vivid colour in near-pitch-black conditions.
Advanced AI (AcuPick): Only the Pro series fully leverages AcuPick technology for high-speed target searching across your entire NVR system.
Processing Power: The Pro model has higher RAM (2GB) and ROM (256MB) for faster AI analytics and smoother high-bitrate streaming.
Core TiOC 3.0 Features
Active Deterrence: Built-in Red & Blue flashing "Police-style" lights and a 110dB siren proactively stop intruders before they reach your door.
Smart Dual Light: Intelligently switches from discreet IR to Warm LED "Full-Colour" mode only when a human or vehicle is detected.
Two-Way Talk: Enhanced "VoiceCatcher" dual-mic array and high-power speaker for crystal-clear remote communication via the DMSS app.
SMD 4.0: Smart Motion Detection 4.0 reduces false alarms from pets, rain, and trees by 99%, focusing only on real threats.
Full Technical Specifications
Feature
IPC-HDW3649H-AS-PV-PRO-ANZ
Image Sensor
1/1.8" Progressive Scan CMOS (Pro Grade)
Max. Resolution
6MP (3288 × 1850) @ 25/30 fps
Min. Illumination
0.0005 Lux @ F1.0 (Color, 30 IRE)
Lens / Aperture
2.8mm Fixed Focal / F1.0 Super Aperture
Field of View
Horizontal: 109°; Vertical: 58°; Diagonal: 131°
Illumination
IR (30m) + Warm Light (30m) - Smart Dual Light
AI Intelligence
AcuPick, SMD 4.0, IVS (Tripwire & Intrusion), AI SSA
Audio Interface
Built-in Dual Mic + Built-in Speaker
Alarm I/O
1 Channel In / 1 Channel Out
Storage
MicroSD Card Slot (Up to 512GB), FTP, SFTP, NAS
Casing / Protection
Full Metal Body / IP67 Weatherproof
Frequently Asked Questions
Is this an official Australian (ANZ) model?Yes. This is the genuine -ANZ model. It includes local firmware that is compatible with Australian NVRs and provides full local warranty support.
What is AcuPick?AcuPick is a smart search technology that allows you to click on a person or vehicle in your footage and instantly find every other time they appeared on any of your cameras. It is 90% faster than manual searching.
This AcuPick feature only works with Dahua 5-Series NVRs. Click here to shop.
Can I use this without an NVR?Yes. You can use this camera as a standalone device by inserting a MicroSD card and using the Dahua DMSS mobile app for live viewing and notifications.
More Information
Download Datasheet
Quick Installation Guide
Dahua 8MP (4K) WizSense Fixed Starlight Bullet, 3.6mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR30m, Built-in Mic, IP67, PoE DH-IPC-HFW3866EP-AS-AUS-36
Features
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8 MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
MEGAPIXELS
8MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WizSense Series
POE
PoE
Downloads
DH-IPC-HFW3866EP-AS-AUS Datasheet 0220415Dahua HD IR Bullet Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua Security Camera 4MP WizSense Motorised Starlight Dome, 2.7–13.5 mm, Perimeter, SMD, SD Card, WDR, IR40m, Built-in Mic, IP67, IK10, POEPOE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports); max. 256 G Micro SD card; built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HDBW3466RP-ZAS-AUS DatasheetDahua Dome Network_ Camera_Quick Start Guide_V1.0.1Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua WizSense Series 8MP TiOC 3.0 Active Deterrence Bullet Network Camera with 2.7-13.5mm Varifocal Lens, Built-in Mic & Speaker, WDR, Micro SD, IP67, PoE and Support AcuPick
Upgrade your security system with the Dahua DH-IPC-HFW3849T1-ZAS-PV-ANZ-S2 8MP TiOC 3.0 AcuPick Bullet Security Camera. Its advanced deep learning algorithms provide intelligent functionality, such as perimeter protection and smart motion detection. With Starlight technology and a large aperture lens, this camera produces clear images in low light conditions. Plus, it's equipped with a built-in mic, speaker, and siren for added security.
What is AcuPick?
Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets.
Notes: This AcuPick feature only works with Dahua 5-Series NVRs. Click here to shop.
Features
8MP 1/2.8'' CMOS image sensor, low luminance, and high definition image
Outputs max. 8 MP (3840 x 2160 )@25/30 fps
H.265 codec, high compression rate, ultra-low bit rate
Built-in warm light and IR LED; the max. IR illumination distance is 50 m and warm light distance is 40 m
ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human)
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; built-in dual Mic; 1-ch speaker; support two-way talk
12 VDC/PoE power supply
IP67 protection
Sound and light alarm (red and blue lights)
SMD 4.0
Supports AI SSA and one-tap arming and disarming
SMD area can be set in warm light areas that support triggering alarms
Specifications
Dahua TiOC AcuPick Security Camera
Megapixels
8MP
Camera Style
Bullet
Colour
White
Lens Type
Motorised
Technology
WizSense Series
Connection
PoE
Downloads
Dahua IPC-HFW3849T1-ZAS-PV-ANZ-S2 Datasheet Dahua Bullet Network Camera_Quick Start Guide_V1.0.2 Dahua Network Camera Web 3.0_Operation Manual_V2.1.8 Bullet Network Camera Installation Guide_V1.0.0 Dahua Network Camera Web 5.0_Operation Manual_V1.2.1
This Dahua 128 Channel Ultra AI NVR, HDD DHI-NVR608H-128-AI/ANZ comes with 8 Hard Disk Bays, No PoE Ports, Network Video Recorder
Features
32-channel 1080p self-adaptive decoding capability
Max. 1024/1024/800Mbps incoming/recording/outgoing bandwidth
Supports N+M cluster
Support Raid 0/1/5/6/10
Drawer-like chassis design allows for HDD hot swapping
AI by recorder: 4-channel face detection and recognition; 8-channel metadata; 24-channel perimeter protection; 32-channel SMD Plus
AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, and people counting
Specifications
NVR
Number of Channels
128 Channel
Number of PoE Ports
0 x PoE Ports
Number of Hard Disk Bays
8 x HDD Hard Disk Bay
Technology
Ultra Series
Network Bandwidth
AI disabled: 1024 Mbps incoming, 1024 Mbps recording and 800 Mbps outgoing AI enabled: 512 Mbps incoming, 512 Mbps recording and 400 Mbps outgoing
Maximum Resolution
32MP
Downloads
NVR608H-128-AI/ANZQuick Start Guide of DHI-NVR608RUser Manual of DHI-NVR608R
Dahua Security Camera 8MP (4K) WizSense Motorised Starlight Dome, 2.7-13.5mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR40m, Built-in Mic, IP67, IK10, PoE
The Dahua 8MP WizSense Motorised Starlight Dome Camera delivers ultra-clear 4K video at up to 30fps with exceptional low-light performance via its 1/2.8” CMOS sensor and built-in IR LEDs with a 40m range. Featuring a 2.7-13.5mm motorised varifocal lens, it offers flexible viewing angles. Advanced AI-powered perimeter protection detects and classifies human and vehicle intrusion with high accuracy. The camera supports H.265 compression for efficient storage, wide dynamic range (WDR), and robust weather and vandal resistance (IP67, IK10). It includes intelligent video analytics, built-in microphone, and POE for simplified installation in demanding security environments.
Features
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports); max. 256 G Micro SD card; built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
WizSense Series
CONNECTION
PoE
Downloads
DH-IPC-HDBW3866RP-ZAS-AUS Datasheet 20220718Dahua Dome Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua Security Camera 4MP WizSense Fixed Starlight Bullet, 2.8mm, Perimeter, SMD4.0, SD Card, WDR, IR50m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HFW3466EP-AS-AUS DatasheetBullet Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
The IPC-HFW3867T-ZAS-IL-ANZ is a high-performance 8-Megapixel (4K) WizSense network camera designed for professional-grade security. Featuring Dahua's innovative Smart Dual Light technology, this camera intelligently switches between IR and warm light illumination to capture full-color details when a target is detected, providing superior evidence while minimizing light pollution.
Key Features
8MP 4K Ultra HD Resolution: Delivers exceptional image detail and clarity, ideal for large areas requiring high-forensic value.
Smart Dual Light Technology: Intelligently manages illumination by using IR for discreet monitoring and switching to warm light for full-color capture only when a human or vehicle is detected.
Motorized Vari-focal Lens: Equipped with a 2.7mm–13.5mm lens, allowing for remote zoom and focus adjustment to achieve the perfect field of view.
WizSense AI Analytics: Powered by deep learning algorithms to provide accurate Perimeter Protection and SMD 4.0 (Smart Motion Detection) for reduced false alarms.
Built-in Microphone: Supports high-quality audio recording for comprehensive environmental awareness.
Starlight Technology: Ensures high-quality color video in low-light environments, maintaining visibility where standard cameras fail.
IP67 & IK10 Protection: Weatherproof and vandal-resistant design ensures reliable operation in harsh outdoor conditions.
Technical Specifications
Image Sensor
1/2.7" 8-Megapixel Progressive CMOS
Max. Resolution
3840 (H) × 2160 (V)
Lens Type
Motorized Vari-focal (2.7 mm–13.5 mm)
Illumination Distance
IR up to 60m; Warm Light up to 50m
WDR
120 dB True WDR
Audio/Alarm
Built-in Mic; 1-ch Audio In/Out; 1-ch Alarm In/Out
Ingress Protection
IP67; IK10
More Information
For full technical data and setup instructions, please refer to the official Dahua resources:
View DH-IPC-HFW3867T-ZAS-IL-ANZ Technical Data SheetDownload Quick Start Guide
Download Installation Guide
Dahua NVR5464‑AI/ANZ – 64‑Channel WizSense AI NVR (4 HDD Bays)
The Dahua NVR5464‑AI/ANZ is a high‑performance, enterprise‑grade Network Video Recorder designed for large-scale IP CCTV systems. Capable of handling up to 64 camera streams and supporting 4 internal HDDs, this WizSense NVR brings deep-learning intelligence — including face recognition, ANPR (license‑plate recognition), perimeter protection, people counting and heat‑map analytics — directly to your security setup. It's ideal for office buildings, retail complexes, warehouses, campuses and multi‑site deployments.
Key Features
Supports up to 64 IP camera channels
4 × SATA HDD bays (expandable storage, up to your chosen HDD capacity)
AI analytics: Face detection & recognition, ANPR (license‑plate recognition), people counting, heat‑map, stereo analysis, metadata, and more
Perimeter protection & Smart Motion Detection (SMD Plus) — reduces false alarms from non‑relevant motion
Video compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG — efficient storage and bandwidth usage
High bandwidth capacity: up to 384 Mbps incoming/recording/outgoing when AI is off; up to 200 Mbps when AI enabled
Dual HDMI + VGA outputs — supports 4K display and multi‑screen monitoring
Supports high resolution inputs: up to 32 MP; efficient decoding of multiple high‑resolution streams
Wide compatibility: HTTP, HTTPS, ONVIF, RTSP, CGI, ISAPI — works with most IP cameras and VMS solutions [oai_citation:6‡Dahua Technology]
Technical Specifications
Specification
Details
Model / SKU
DHI‑NVR5464‑AI/ANZ
Max Channels
64 IP Cameras
HDD Bays
4 × SATA (user-installed)
Max Bandwidth
384 Mbps (AI off) / 200 Mbps (AI on)
Video Compression
Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
Supported Resolutions
Up to 32 MP; supports 4 K, 8 MP, 5 MP, 1080p etc.
Decoding Capability
Up to 32‑channel 1080p (self‑adaptive) / multiple high‑res streams.
AI by Recorder
Face detection/recognition (2‑ch), 4‑ch perimeter protection, 8‑ch SMD Plus
AI by Camera (when paired)
Face detection/recognition, ANPR, stereo analysis, people counting, heat‑map, metadata, SMD Plus, perimeter protection
Video Outputs
2 × HDMI, 2 × VGA; 4K display supported
Network Protocols
HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, ONVIF, SNMP, FTP, DDNS, etc.
AI Storage Options
HDD (user install), supports large storage capacity via 4 HDD slots
Use Cases
Enterprise, campuses, retail, warehouses, large‑scale CCTV systems
Dahua DH-IPC-HFW3649T1-AS-PV-ANZ-S2 6MP TiOC 3.0 Active Deterrence Bullet Network Camera with 2.8mm Fixed Lens, Built-in Mic & Speaker, Siren Alarm, WDR, Micro SD, IP67, PoE and Support AcuPick
White SKU: DH-IPC-HFW3649T1-AS-PV-ANZ-S2Black SKU: DH-IPC-HFW3649T1-AS-PV-ANZ-S2-BLK
Dahua WizSense 3 Series Network Camera greatly saves on bandwidth and storage space through its AI Coding technology. Driven by its advanced deep learning algorithms, the camera supports intelligent functions such as perimeter protection, smart motion detection (SMD), AcuPick, and AI SSA (AI Scene Self-adaptation), making it easy and convenient to use. Starlight technology and its large aperture lens alsoallow the camera to produce clear, vivid images even in poor lighting conditions.
What is AcuPick?
Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets.
Notes: This AcuPick feature only works with Dahua 5-Series NVRs. Click here to shop.
Features
6MP 1/2.7'' CMOS image sensor, low luminance, and high definition image
Outputs max. 6 MP (3072 x 2048) @25/30 fps
H.265 codec, high compression rate, ultra-low bit rate
Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m
ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human)
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual Mic; 1-ch speaker; support two-way talk
12 VDC/PoE power supply
IP67 protection
Sound and light alarm (red and blue lights)
SMD 4.0
Supports AI SSA and one-tap arming and disarming
SMD area can be set in warm light areas that support triggering alarms
Specifications
Dahua AcuPick Network Camera
Megapixels
6MP
Camera Style
Bullet
Colour
White
Lens Type
Fixed
Technology
WizSense Series
Connection
PoE
Downloads
Dahua IPC-HFW3649T1-AS-PV-ANZ-S2 Datasheet Dahua Bullet Network Camera_Quick Start Guide_V1.0.2 Dahua Network Camera Web 3.0_Operation Manual_V2.1.8 Bullet Network Camera Installation Guide_V1.0.0 Dahua Network Camera Web 5.0_Operation Manual_V1.2.1
Dahua TiOC 8MP Smart Dual Illumination Active Deterrence Fixed-focal Bullet WizSense Network Camera, Black, DH-IPC-HFW3849T1-AS-PV-ANZ-BLK
Get advanced security with Dahua TiOC 8MP Smart Dual Illumination Network Camera. Its 8-MP CMOS image sensor provides high-definition images with low luminance. With features like H.265 codec, smart coding, and intelligent monitoring, feel secure in any environment. The built-in warm light and IR LED provide a maximum distance of 30m.
Features
* The parameters and datasheets below can only be applied to 3849-PV-ANZ series.
8-MP 1/2.8" CMOS image sensor, low luminance, and high definition image.
Outputs max. 8 MP (3840 × 2160)@25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.
ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; buit-in dual MICs; 1-ch speaker; support two-way talk.
12 VDC/PoE power supply.
IP67 protection.
Sound and light alarm (red and blue lights).
SMD 4.0.
One-click arming/disarming through alarm input.
Specifications
NETWORK CAMERA
Megapixels
8MP
Camera Style
Bullet
Colour
Black
Lens Type
Fixed
Technology
WizSense Series
PoE
PoE
Downloads
IPC-HFW3849T1-AS-PV-ANZ DatasheetBullet Network Camera Installation Guide_V1.0.0Dahua Bullet Network Camera_Quick Start Guide_V1.0.2Dahua Network Camera Web 5.0_Operation Manual_V1.0.5Dahua Network Camera Web 3.0_OperationManual_V2.1.5DH-IPC-HFW3849T1P-AS-PV-ANZ DIMENSIONSDH-IPC-HFW3849T1P-AS-PV-ANZ INSTALLATION METHOD ENDH-IPC-HFW3849T1P-AS-PV-ANZ A&E 20221205123053
Dahua Security Camera 6MP WizSense Motorised Starlight Dome, 2.7–13.5 mm, Perimeter, SMD4.0, SD Card, WDR, IR40m, Built-in Mic, IP67, IK10, POE
6MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 6 MP (3072 x 2048) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human); face detection.
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
6MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
WIZSENSE SERIES
POE
POE
Downloads
DH-IPC-HDBW3666RP-ZAS-AUS Datasheet 20220718Dahua Dome Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua WizSense Series · SMD 4.0 AI · Australian Stock
Dahua DH-IPC-HDW3666TP-ZS-AUS — 6MP Motorised Varifocal Turret Camera
The Dahua DH-IPC-HDW3666TP-ZS-AUS is a high-performance 6MP WizSense AI turret camera purpose-built for Australian commercial, retail, education and government installations where detail, flexibility and intelligent detection are non-negotiable. Powered by a 1/2.7" CMOS sensor and a 2.7–13.5 mm motorised varifocal lens, it delivers crisp 3072 × 2048 resolution across a wide zoom range — all without climbing a ladder to adjust the lens. Dahua's Starlight low-light technology and 40 m Smart IR ensure clear, usable footage around the clock, while the IP67 weatherproof housing handles Australia's harshest outdoor conditions.
As part of the WizSense Series, the DH-IPC-HDW3666TP-ZS-AUS features SMD 4.0 (Smart Motion Detection) and Perimeter Protection — accurately classifying humans and vehicles to slash false alarms from animals, foliage and lighting changes. A built-in microphone, onboard microSD card slot (up to 256 GB) and standard PoE power make it a complete, cost-effective solution for any Australian site.
Resolution
6MP · 3072 × 2048
Lens
2.7–13.5 mm Motorised
Night Vision
40 m Smart IR · Starlight
AI Detection
SMD 4.0 · Perimeter
Protection
IP67 · WDR
Power
PoE 802.3af · 12V DC
Dahua WizSense AI
Australian Stock & Support
3-Year Dahua Warranty
Why Choose the Dahua DH-IPC-HDW3666TP-ZS-AUS in Australia
Australian integrators and security professionals choose the DH-IPC-HDW3666TP-ZS-AUS because it combines the flexibility of a motorised zoom lens with the intelligence of Dahua's WizSense AI platform — all in a robust, weatherproof turret housing. Whether you're covering a large retail car park, a school perimeter, a warehouse loading dock or a residential estate, the 5× optical zoom range means one camera model covers multiple scene types without compromise.
6MP Motorised Varifocal Flexibility
The 2.7–13.5 mm motorised lens lets installers dial in the exact field of view remotely — no physical lens adjustment required. One SKU covers wide-angle entry shots and long-range licence plate capture alike.
SMD 4.0 — Smarter Motion Detection
Smart Motion Detection 4.0 accurately distinguishes humans and vehicles from irrelevant motion (animals, trees, headlights), dramatically reducing false alarms and operator fatigue on Australian sites.
Perimeter Protection AI
Tripwire and intrusion detection with human/vehicle classification deliver actionable alerts — not noise. Ideal for after-hours perimeter monitoring at schools, warehouses and retail centres.
Starlight Low-Light Performance
Dahua's Starlight technology produces vivid colour images in near-darkness — critical for Australian dawn/dusk patrol shifts and poorly lit car parks where colour detail aids identification.
40 m Smart IR Night Vision
Adaptive IR intensity prevents overexposure at close range while maintaining reach to 40 m — delivering clean, usable night footage across driveways, yards and open perimeters.
Built-In Mic + Edge Storage
The integrated microphone captures audio evidence without extra cabling, while the microSD slot (up to 256 GB) provides failover edge recording if the network or NVR goes offline.
Technical Specifications
SKU / Model
DH-IPC-HDW3666TP-ZS-AUS
Camera Type
6MP WizSense Motorised Varifocal Turret Camera
Image Sensor
1/2.7" CMOS
Max Resolution
3072 × 2048 @ 25/30 fps
Lens Type
Motorised Varifocal, 2.7–13.5 mm
IR Distance
40 m Smart IR
Dynamic Range
WDR
Video Compression
H.265 / H.265+ / H.264 / H.264+ / MJPEG
AI Features
SMD 4.0 · Perimeter Protection (Tripwire, Intrusion) · Human & Vehicle Classification
Abnormality Detection
Motion Detection · Privacy Masking · Scene Change · Audio Detection · SD Card Alerts · Network Disconnection · IP Conflict · Illegal Access · Voltage Detection
Audio
Built-in Microphone
Edge Storage
microSD / microSDHC / microSDXC (up to 256 GB)
Weatherproof Rating
IP67
Power Source
12V DC · PoE (IEEE 802.3af)
Colour
White
Warranty
3-Year Dahua Warranty (Australia)
Downloads & Resources
DH-IPC-HDW3666TP-ZS-AUS Datasheet
Quick Start Guide (PDF)
Installation Guide (PDF)
Web 5.0 Operation Manual (PDF)
Order the Dahua DH-IPC-HDW3666TP-ZS-AUS from CCTV Guru
CCTV Guru is an authorised Australian distributor of Dahua security cameras. Order the DH-IPC-HDW3666TP-ZS-AUS today for fast Australia-wide dispatch, expert pre-sales advice, project pricing for multi-camera rollouts, and full local warranty support. Contact our Australian team for tailored quotes on larger installations.
DAHUA WIZSENSE 3 SERIES
Description
The Dahua DH-IPC-HDBW3867E-AS-IL-ANZ is a premium 8MP Smart Dual Light fixed-focal dome camera built for customers who want sharper 4K video, more accurate human and vehicle detection, and tougher protection for real-world installations.
It combines 3840 × 2160 resolution, Smart Dual Light, SMD 4.0, perimeter protection, AI Scene Self-adaptation, built-in microphone, and alarm/audio input and output in a compact vandal-resistant dome design. For CCTV Guru customers, this is a strong option for homes, retail shops, offices, warehouses, apartment entries and other sites where reliable day and night evidence matters.
Resolution
8MP 4K
Night vision
IR + Warm Light 30m
AI analytics
SMD 4.0 + IVS
Protection
IP67 + IK10
Why this Dahua dome camera stands out
Sharper 8MP video with better low-light performance
This camera uses an 8MP 1/2.7" CMOS sensor and supports up to 3840 × 2160 at 25/30 fps, helping deliver clearer facial detail, vehicle detail and scene coverage for higher-quality evidence.
Smart Dual Light for cleaner night recording
Dahua Smart Dual Light uses IR as standard at night, then switches on warm light when a target appears in the monitored area. This helps capture important events in full colour while reducing unnecessary light pollution.
Smarter human and vehicle detection
With SMD 4.0 and perimeter protection, this camera helps reduce false alarms and improves event accuracy by focusing on people and vehicles instead of irrelevant movement.
Built for tougher professional installations
With IP67 weather resistance, IK10 vandal resistance, built-in microphone, alarm input/output, audio input/output and MicroSD support up to 512GB, it is well suited to more demanding CCTV projects.
Recommended Dahua NVR pairing
Best for most homes and small business systems
Pair this camera with the
Dahua 8-channel WizSense NVR
when you are running up to 8 cameras. This setup gives you smooth playback,
reliable smart event recording and full access to AI features like motion filtering,
human and vehicle detection.
Best for premium systems and future upgrades
For larger systems or when you want faster search and stronger AI performance,
step up to the
Dahua 16-channel WizSense NVR.
This gives you more processing power, supports more cameras and makes reviewing footage
much faster with intelligent search and event filtering.
Official Dahua videos
WizMind S3 Features
WizMind S Series Overview
Technical specifications
Model
DH-IPC-HDBW3867E-AS-IL-ANZ
Camera type
8MP Smart Dual Light fixed-focal dome WizSense network camera
Image sensor
1/2.7" CMOS
Maximum resolution
3840 × 2160
Frame rate
Main stream up to 3840 × 2160 @ 25/30 fps
Lens options
2.8 mm or 3.6 mm fixed focal
Aperture
F1.4
Min illumination
0.007 lux colour, 0.0007 lux B/W, 0 lux with illuminator on
Night illumination
IR up to 30 m, warm light up to 30 m
WDR
120 dB
Compression
H.265, H.264, Smart H.265+, Smart H.264+, AI H.265, AI H.264
AI functions
Perimeter protection, SMD 4.0, AI SSA, AcuPick, Smart Search
Audio
Built-in mic, 1 audio in, 1 audio out
Alarm
1 alarm in, 1 alarm out
Edge storage
MicroSD up to 512GB
Network
RJ-45 10/100 Base-T
Power
12V DC / PoE (802.3af)
Protection rating
IP67, IK10
Operating temperature
-40 °C to +60 °C
Dimensions
89.1 mm × Φ111.7 mm
Weight
528 g net, 690 g gross
FAQs
Is this a full-colour camera at night?
It supports Dahua Smart Dual Light, which can use warm light when a target is detected to help capture full-colour event footage at night.
Does this camera support human and vehicle detection?
Yes. It supports perimeter protection and SMD 4.0 with classification and accurate detection of human and vehicle targets.
Can it record to an SD card without an NVR?
Yes. It supports MicroSD edge recording up to 512GB, which is useful for standalone or backup recording.
Is this suitable for outdoor use?
Yes. It is rated IP67 for weather resistance and IK10 for vandal resistance, making it suitable for exposed professional installations.
More information
Official Dahua resources and installation accessories help customers choose the right mounting and storage options for this dome camera.
Datasheet DH-IPC-HDBW3867E-AS-IL-ANZ PDF
Authorised Australian reseller
Fast AU shipping
Sydney-based expert support
The Dahua DH-IPC-HDW3867T-ZS-IL-ANZ is a high-performance 8MP (4K) WizSense network turret camera featuring intelligent dual lighting and a smooth varifocal lens for flexible coverage. Designed for both residential and commercial environments, this camera delivers clear, detailed surveillance footage day and night with advanced AI monitoring and robust weatherproof protection.
With Smart Dual Light technology, the camera switches between infrared and warm LED lighting to capture full-colour footage of important events in low light — reducing false triggers and improving identification. Smart Motion Detection (SMD 4.0) and AI Scene Self-Adaption (AI SSA) adapt performance to conditions and help filter out irrelevant alerts.
Key Features
8MP (3840 × 2160) resolution for ultra-clear video footage
Vari-focal lens (motorised zoom) for flexible field of view from wide to narrow angles
Smart Dual Light: IR + warm lighting with automatic switching
AI analytics including Smart Motion Detection (SMD 4.0) and AI Scene Self-Adaption
Supports local storage via MicroSD (up to 512 GB)
Built-in microphone for audio capture
PoE power simplifies installation
IP67 rated for reliable outdoor performance
Ideal for driveways, entrances, retail stores, schools, offices, and warehouses where adjustable coverage and AI-assisted monitoring are critical for security and operational insights.
Technical Specifications
Specification
Details
Model / SKU
DH-IPC-HDW3867T-ZS-IL-ANZ
Image Sensor
1/2.7″ 8MP CMOS
Max Resolution
3840 × 2160 (8MP) @ 25/30 fps
Lens
Motorised vari-focal (2.7 mm – 13.5 mm)
Field of View
H: ~114° – 32°; V: ~58° – 17°; D: ~138° – 36°
Dual Light
Smart Dual Light (IR + Warm LED)
IR/Warm Light Range
IR: ~50 m; Warm Light: ~40 m
AI Features
Smart Motion Detection (SMD 4.0), AI SSA, intrusion & tripwire support
Video Compression
SMART H.265+/H.265, SMART H.264+/H.264
Audio
Built-in microphone
Storage
MicroSD up to 512 GB
Power Options
12 VDC / PoE supported
Ingress Protection
IP67 weatherproof
Mount Type
Wall or ceiling mount (bracket required)
More Information
DH-IPC-HDW3867T-ZS-IL-ANZ Datasheet
Dahua Eyeball Camera Quick Start Guide
Dahua Turret Camera Installation Guide
Powerful AI-powered 32-channel network video recorder from Dahua’s WizSense series. Features 16 PoE ports, 8 HDD bays (up to 16TB each), face recognition, perimeter protection, SMD Plus filtering, and 384Mbps recording bandwidth. Supports advanced analytics for demanding surveillance applications.
Key Features
32-channel IP camera support with 384Mbps bandwidth
16 × PoE ports with IEEE 802.3af/at support (1–8 ePoE)
8 × SATA HDD bays (up to 128TB total)
Smart H.265+/H.264+/MJPEG compression
AI analytics: Face Recognition, SMD Plus, Perimeter Protection
ANPR, Heat Mapping, People Counting (via camera)
Dual HDMI & VGA output (4K support)
RAID 0/1/5/6/10 for data protection
Mobile remote view with DMSS app (iOS/Android)
ONVIF, third-party camera compatible
Technical Specifications
Technical Specifications – DHI-NVR5832-16P-AI/ANZ
Channels
32 IP Channels
PoE Ports
16 × 10/100 Mbps (Ports 1–8 support ePoE)
Max Resolution
Up to 32MP
AI Features
Face Detection/Recognition, SMD Plus, Perimeter Protection
Face Database
20,000 images, 2.5GB total
HDD Support
8 × SATA ports, up to 16TB per bay
RAID
RAID 0/1/5/6/10 support
Bandwidth
384 Mbps (AI Off), 200 Mbps (AI On)
Video Output
2 × HDMI, 2 × VGA, 4K Display Supported
Decoding
Up to 32CH 1080p@30fps
Audio I/O
1 IN / 2 OUT RCA
Alarm I/O
16 IN / 8 OUT
USB
2 × USB 2.0, 2 × USB 3.0
Operating Temp
-10°C to +55°C
Power
100–240V AC, ≤13W (no HDD), PoE 130W total
Certifications
FCC, CE-EMC, CE-LVD
Dimensions
440.1 × 457.9 × 89.1 mm
Installation
Rack or Desktop Mount
More Information
DHI-NVR5832-16P-AI/ANZ Datasheet
The DHI‑NVR608H‑32‑AI/ANZ is a high-capacity, enterprise-grade **WizMind AI network video recorder** supporting up to 32 IP camera channels and 8 internal HDD bays. Built for demanding CCTV deployments, it features hot-swappable design, advanced RAID support, and deep learning AI capabilities.
Key Features
32-channel IP input with 1080p self-adaptive decoding (32ch)
AI by Recorder: 4-channel face detection & recognition, 8-channel metadata, 24-channel perimeter protection
AI by Camera: Face, SMD+, ANPR, people counting, stereo analysis, heat map
8 SATA HDD bays, supports RAID 0/1/5/6/10, hot-swap drawer design
High bandwidth performance: up to 1024 Mbps incoming/recording, 800 Mbps outgoing
Multi-output: 4× HDMI + 2× VGA outputs, with mixed-resolution and heterogeneous mode support
Redundancy & networking: Support N+M clustering, dual network ports, hot-standby failover
Compatibility: ONVIF, RTSP, CGI, third-party camera support
Technical Specifications
Specification
Details
Model / SKU
DHI‑NVR608H‑32‑AI/ANZ
Channels (IP)
32 channels @1080p adaptive decoding
Input / Recording / Output Bandwidth
1024 / 1024 / 800 Mbps
HDD Bays
8 × SATA (supports RAID 0/1/5/6/10)
Video Output
4 × HDMI + 2 × VGA, mixed and heterogeneous modes
AI by Recorder
4-channel face detection, 8-channel metadata, 24-channel perimeter protection, SMD+ 32ch
AI by Camera
Face recognition, ANPR, people counting, stereo analysis, heatmap, metadata, SMD+
Redundancy & Cluster
N+M cluster, hot standby, dual network ports
Power Supply
100 – 240 VAC, 50/60 Hz
Power Consumption (No HDD)
<18 W (typical)
Dimensions
444.0 × 456.6 × 95.0 mm (W × D × H)
Net Weight
6.4 kg (without HDDs)
Operating Temperature / Humidity
–10 °C to +55 °C, 10%–93% RH
Certifications & Standards
CE, FCC, LVD, EMC standards
More Information
DHI-NVR608H-32-AI/ANZ Datasheet
Dahua 4 Megapixel Wide Angle Fixed Dome DH-IPC-HDBW3466R-AS-P
Features
4MP 1/2.7'' CMOS starlight-grade image sensor, low luminance, and high definition image.
Outputs 4 MP (2688 x 1520) @25/30 fps, and supports max. 5 MP (2880 x 1620) @20 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, and the max. illumination distance is 15 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in MIC.
12 VDC/PoE power supply.
IP67, IK10 protection.
EPTZ: Enlarge and track the targets of intelligent alarms.
SMD 3.0.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WizSense Series
POE
POE
Downloads
DH-IPC-HDBW3466R-AS-P Datasheet_20220428Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Dome Network Camera_Quick Start Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua Security Camera 4MP Wide Angle Fixed Bullet WizSense Network Camera DH-IPC-HFW3466T-AS-P
Features
4MP 1/2.7'' CMOS starlight-grade image sensor, low luminance, and high definition image.
Outputs 4 MP (2688 x 1520) @25/30 fps , and supports max. 5 MP (2880 x 1620) @20 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, and the max. illumination distance is 20 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in MIC.
12 VDC/PoE power supply.
IP67 protection.
EPTZ: Enlarge and track the targets of intelligent alarms.
SMD 3.0.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WIZSENSE SERIES
POE
POE
Downloads
DH-IPC-HFW3466T-AS-P DatasheetBullet Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua Security Camera 4MP WizSense Motorised Starlight Bullet, 2.7–13.5 mm, Perimeter, SMD, SD Card, WDR, IR60m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 60 m.
ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - ZAS supports ); audio: 1 in, 1 out (Only - ZAS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 (optional) protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HFW3466TP-ZAS-AUS DatasheetBullet Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
