Dahua DHI-NVR5432-AI/ANZ-S2 32-Channel 32MP WizSense AcuPick NVR with 4 HDD Bays (No PoE)

Description

WizSense S2 · 32-Channel · 4-HDD · Dual 8K HDMI32CH WizSense S2

The Dahua DHI-NVR5432-AI/ANZ-S2 is a 32-channel, 32 MP WizSense network video recorder for enterprise and multi-site surveillance. The S2 platform raises incoming, recording and outgoing bandwidth to 448 Mbps, adds dual HDMI output up to 8K, doubles several recorder-side AI capacities, and supports four surveillance HDDs up to 20 TB each.

This Australia/New Zealand model has no built-in PoE; connect cameras through an external PoE switch. AcuPick is available on 4 channels when processed by the recorder, or on all 32 channels when compatible AcuPick cameras perform the AI analysis.

AcuPick
4-ch by NVR · 32-ch by AI camera
Bandwidth
448 Mbps with AI disabled
Display
2 × HDMI up to 8K
Storage
4 × 20 TB · eSATA · iSCSI

Faster S2 recorder platform

448 Mbps recording bandwidth

Accept, record and serve up to 448 Mbps when recorder AI is disabled, compared with 384 Mbps on the previous model. With recorder AI enabled, bandwidth is 200 Mbps.

32 MP input and stronger decoding

Supports cameras up to 32 MP and decodes up to 10 × 8 MP, 16 × 5 MP, 20 × 4 MP or 32 × 1080p streams at 30 fps with AI disabled.

Dual independent 8K HDMI

Two HDMI and two VGA outputs support independent or paired display layouts. HDMI reaches 7680 × 4320, while VGA supports up to 1080p.

Four high-capacity HDD bays

Four SATA bays accept drives up to 20 TB each for approximately 80 TB onboard, with eSATA and iSCSI available for expansion.

WizSense AI and AcuPick

AcuPick: recorder-side or camera-side

The NVR itself can run AcuPick on 4 channels. When compatible AcuPick cameras perform front-end analysis, all 32 channels can participate, with up to 32 combined targets per second.

Perimeter protection

Run human and vehicle classified tripwire and intrusion analytics on 8 channels by recorder, or all channels with compatible camera-side AI.

SMD Plus

Recorder-side SMD Plus expands to 16 channels for faster human and vehicle event filtering and fewer nuisance motion alerts.

Face detection and recognition

Four recorder-side face-detection channels plus a face library capacity of 20 databases, 30,000 images and 3.75 GB.

Video metadata

Four channels by recorder with up to 22 human and vehicle attributes, with all-channel metadata available through compatible cameras.

ANPR integration

Use compatible Dahua ANPR cameras across all channels with a 20,000-plate blocklist and allowlist database.

Official Dahua AcuPick video

Dahua AcuPick technology demonstration

S2 compared with DHI-NVR5432-AI/ANZ

Generation comparison
Specification DHI-NVR5432-AI/ANZ-S2 DHI-NVR5432-AI/ANZ
IP channels / PoE 32 / none 32 / none
Bandwidth, AI disabled 448 / 448 / 448 Mbps 384 / 384 / 384 Mbps
Bandwidth, AI enabled 200 / 200 / 200 Mbps 200 / 200 / 200 Mbps
Maximum display output 8K via HDMI 4K via HDMI
8 MP decoding, AI disabled 10 channels at 30 fps 8 channels at 30 fps
AcuPick by recorder 4 channels Not listed as recorder-side capability
AcuPick by compatible camera All 32 channels Camera-dependent support
Face detection by recorder 4 channels 2 channels
Perimeter protection by recorder 8 channels 4 channels
SMD Plus by recorder 16 channels 8 channels
Video metadata by recorder 4 channels Not listed
Face library 30,000 images / 3.75 GB 20,000 images / 2.5 GB
Maximum HDD capacity 4 × 20 TB 4 × 16 TB in official datasheet
ONVIF 25.06 · T/S/G/M 21.12 · T/S/G
Net weight 4.27 kg 4.74 kg
Full specifications
Model DHI-NVR5432-AI/ANZ-S2
Channels 32 IP channels · no built-in PoE
Maximum camera resolution 32 MP
Bandwidth 448 Mbps incoming / recording / outgoing with AI disabled; 200 Mbps with AI enabled
Decoding, AI disabled 2 × 32 MP@25 · 2 × 24 MP@25 · 5 × 16 MP@30 · 6 × 12 MP@30 · 10 × 8 MP@30 · 13 × 6 MP@30 · 16 × 5 MP@30 · 20 × 4 MP@30 · 32 × 1080p@30
Decoding, AI enabled 1 × 32 MP@25 · 2 × 24 MP@25 · 4 × 16 MP@30 · 5 × 12 MP@30 · 8 × 8 MP@30 · 10 × 6 MP@30 · 12 × 5 MP@30 · 16 × 4 MP@30 · 32 × 1080p@30
Compression Smart H.265+ · H.265 · Smart H.264+ · H.264 · MJPEG
Recorder AI Face detection/recognition · metadata · perimeter protection · SMD Plus · AcuPick
AcuPick 4 channels by recorder; all 32 channels by compatible cameras
Face databases 20 databases · 30,000 images · 3.75 GB
Video outputs 2 × HDMI up to 8K · 2 × VGA up to 1080p
Storage 4 × SATA, up to 20 TB each · eSATA · iSCSI
Network 2 × Gigabit RJ-45
Alarm I/O 16 in · 6 out including 12 V / 1 A output
Audio I/O 1 × RCA input · 2 × RCA output
Other interfaces 1 × RS-232 · 1 × RS-485 · 3 × USB
ONVIF 25.06 · Profiles T / S / G / M
Power 100–240 VAC · recorder consumption ≤13 W without HDD
Dimensions / weight 440 × 415.6 × 76 mm · 4.27 kg net
Operating environment −10°C to +55°C · 10–93% RH

Downloads

Official Dahua documents hosted on CCTV Guru for reliable access.

Datasheet User Manual HDD Installation Guide Models & Installation Manual Dimensions Port Drawing
3-Year Warranty
Australia-Wide Shipping
Australian Tech Support

Dahua DHI-NVR5432-AI/ANZ-S2 32-Channel 32MP WizSense AcuPick NVR with 4 HDD Bays (No PoE)

Product form

SKU: DHI-NVR5432-AI/ANZ-S2

$819.00 Incl. GST

    • PayPal
    • Apple Pay
    • Visa
    • Mastercard
    • American Express
    • Zip
    • Afterpay

    • Warranty: 36 months
    • 30 day Money Back Guarantee
    • Australian Stocks & Express Delivery
    • Back-to-base Warranty & Tech Support
    • FREE Shipping over $180
