Ubiquiti Dream Machine Special Edition, All-In-One Unifi Solution, 8x Gbe PoE RJ45 Ports, 3.5' HDD Bay. You can use this UDM-SE as all-in-one router and security gateway with an integrated PoE switch and NVR network video recorder.
The UniFi Dream Machine - Special Edition is the first UniFi Console that offers a full UniFi application suite right out of the box. Instantly run a complete UniFi deployment without the need for an additional PoE Switch, NVR, or Hard Disk Drive for storage. The UDM SE is an all-in-one router/security gateway that can power your UniFi devices directly from the integrated 8 port gigabit PoE switch and store your UniFi Protect recordings on the integrated 128GB internal hard drive. UDM SE is completely scalable and customizable, so you can easily expand your deployment.
Enterprise-grade, rack-mount UniFi Cloud Gateway with full UniFi application support, 10 Gbps Cloud Gateway with 100+ UniFi device / 1,000+ client support, 3.5 Gbps IPS routing, and built-in PoE switching.
Includes full UniFi application suite for device management 3.5+ Gbps routing with IDS/IPS (1) 10G SFP+*, (8) GbE RJ45 LAN ports including (2) PoE+, and (6) PoE (1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports (1) 3.5" NVR HDD bay Built-in 128 GB SSD for NVR detection recordings 1.3" touchscreen
Technical Specifications
Mechanical
Dimensions
442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")
Weight
5 kg (10.9 lb)
Enclosure material
Aluminium CNC, SGCC steel
Mount material
SGCC steel
Hardware
Processor
Quad-core ARM® Cortex®-A57 at 1.7 GHz
System memory
4 GB DDR4
On-board storage
16 GB eMMCIntegrated 128 GB SSD
Management interface
EthernetBluetooth
Networking interface
LAN:(8) GbE RJ45 ports(1) 10G SFP+ portWAN:(1) 2.5 GbE RJ45 port(1) 10G SFP+ port
PoE interface
(6) PoE (Pair A 1, 2+; 3, 6-)(2) PoE+ (Pair A 1, 2+; 3, 6-)
IDS/IPS throughput
3.5 Gbps**Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation.
Power method
(1) Universal AC input, 100—240V AC, 4.4A Max., 50/60 Hz(1) USP-RPS DC input, 52V DC, 3.94A
Power supply
AC/DC, internal, 240W
Supported voltage range
100—240V AC
Max. power consumption
50W (Excluding PoE output)
PoE budget
180W
Max. PoE wattage per port by PSE
PoE: 15.4WPoE+: 30W
Voltage range PoE mode
PoE: 44—57VPoE+: 50—57V
ESD/EMP protection
Air: ± 15kV, contact: ± 8kV
LCM display
(1) 1.3" touchscreen
Button
Factory reset
Ambient operating temperature
-10 to 40° C (14 to 104° F)
Ambient operating humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
Gateway Features
Performance
Redundant WAN with failover and load balancingWiFi QoS with UniFi APsApplication, domain, and country-based QoSApplication and device type identificationAdditional internet failover with LTE BackupInternet quality and outage reporting
Next-generation security
Application-aware firewall rulesSignature-based IPS/IDS threat detectionContent, country, domain, and ad filteringVLAN/subnet-based traffic segmentationFull stateful firewall
Advanced networking
License-free SD-WANWireGuard, L2TP and OpenVPN serverOpenVPN clientOpenVPN and IPsec site-to-site VPNOne-click Teleport and Identity VPNPolicy-based WAN and VPN routingDHCP relayCustomizable DHCP serverIGMP proxyIPv6 ISP support
LEDs
Ethernet
White: link/activity
SFP+
White: link/activity
HDD
White: disk activityAmber: disk error
RPS
Blue: ready
Downloads
Installation Guide
Read more less
