TP-Link TL-SM331T 1000BASE-T RJ45 SFP Module The TP-Link TL-SM331T is a 1000BASE-T copper SFP module that adds a standard RJ45 Gigabit Ethernet port to any SFP-equipped switch, router, or NVR. Supporting up to 100 metres over Cat5e or better cabling, it’s the practical solution for installers and network engineers who need to extend a copper Gigabit connection from an SFP slot — without optical fibre or media converters. Key Features 1000BASE-T Copper SFP — Converts an SFP slot into a standard RJ45 Gigabit Ethernet port, compatible with existing Cat5e or Cat6 cabling infrastructure. 100m Reach over Cat5e — Supports the full standard Ethernet distance of 100 metres over UTP Cat5e or above cable. Hot-Swappable — Insert or remove the module without powering down the host device, minimising network downtime during maintenance or upgrades. IEEE 802.3-2002 Compliant — Fully standards-compliant for broad compatibility with SFP-capable switches, NVRs, and routers from TP-Link and other vendors. TX Disable Support — Allows the transmitter to be disabled via software for diagnostics and power management. Low Power Consumption — Typical draw of just 0.5W (max 0.8W), minimising heat and energy use in dense switch deployments. Fully Metallic Enclosure — Robust all-metal housing provides low EMI emissions and durability in rack and cabinet environments. 3.3V Power Supply — Standard SFP power rail, compatible with all compliant SFP host systems. Use Cases Adding a copper Gigabit uplink port to a fibre-only or SFP-only managed switch Connecting a VIGI NVR or IP camera recorder to a switch via an SFP slot using existing Cat6 cabling Extending a Gigabit copper connection from a core switch to an edge device without a media converter Replacing a failed or end-of-life SFP copper module in an existing network installation Providing a flexible, hot-swappable copper port in a rack-mounted switch for temporary or permanent connections Technical Specifications Specification Detail Model TL-SM331T Module Type 1000BASE-T Copper RJ45 SFP Port 1 × 1000Mbps RJ45 Data Rate 1.25 Gbps Max Cable Length 100m (UTP Cat5e or above) Standard IEEE 802.3-2002 (1000BASE-T) Hot-Swappable Yes TX Disable Yes Power Supply 3.3V (from host SFP slot) Power Consumption 0.5W typical / 0.8W max Enclosure Fully metallic (low EMI) Operating Temperature 0°C to 70°C Storage Temperature -40°C to 85°C Certifications FCC, CE Weight Approx. 60g In the Box TL-SM331T module, Installation Guide Warranty 2 Years Recommended Accessories TP-Link TL-SG3210 JetStream Managed Switch — An SFP-equipped managed switch that accepts the TL-SM331T for flexible copper or fibre uplink configurations. TP-Link VIGI NVR with SFP Port — Use the TL-SM331T to connect a VIGI NVR to your network via its SFP slot using standard Cat6 cabling. Cat6 Ethernet Cable — Recommended for reliable Gigabit performance at the full 100m distance. TP-Link TL-SM311LM SFP Module (Multimode Fibre) — If fibre uplinks are needed alongside copper, this companion SFP module covers multimode fibre runs. Frequently Asked Questions What is a copper RJ45 SFP module and why would I need one? An SFP slot on a switch or NVR is typically used for fibre optic connections, but a copper RJ45 SFP module like the TL-SM331T converts that slot into a standard Ethernet port. This is useful when you need an additional copper Gigabit port, want to avoid a media converter, or need to connect to existing Cat5e/Cat6 cabling from an SFP-only uplink slot. Is the TL-SM331T compatible with non-TP-Link switches? The TL-SM331T is IEEE 802.3-2002 compliant and uses the standard SFP form factor, making it broadly compatible with most SFP-capable switches and routers from other vendors. However, some managed switches enforce vendor-specific SFP locking — check your switch’s documentation before purchasing. What cable category is required? Cat5e or above (Cat6, Cat6A) is required for 1000BASE-T operation at up to 100 metres. Cat5 (not Cat5e) is not recommended for Gigabit speeds at full distance. Can I insert or remove this module while the switch is running? Yes. The TL-SM331T is hot-swappable, meaning it can be inserted or removed without powering down the host switch or causing a full system restart. The affected port will go offline briefly during the swap. Does this module work with TP-Link VIGI NVRs that have an SFP port? Yes. VIGI NVRs with an SFP uplink slot accept the TL-SM331T, allowing you to connect the NVR to your network switch using standard Cat5e or Cat6 cabling rather than fibre — a practical option when the NVR is within 100 metres of the switch.

Read more less

Power and Connect Remote IP Cameras Over a Single Fibre Strand up to 20km The TP-Link TL-FC111PB-20 is a WDM (Wavelength Division Multiplexing) BiDi media converter that bridges 10/100Mbps copper Ethernet and single-mode fibre over a single fibre strand — up to 20km. With a built-in 802.3af PoE output port, it can power an IP camera or other PoE device directly at the remote end of the fibre link, eliminating the need for a separate power source at the camera location. Ideal for long-distance CCTV deployments, inter-building links, and remote surveillance installations across Australia. Important: The TL-FC111PB-20 (TX 1310nm / RX 1550nm) must be paired with a complementary TL-FC111PA-20 (TX 1550nm / RX 1310nm) at the opposite end of the fibre link. Two units of the same type will not establish a connection. Key Features 802.3af PoE Output (RJ45 Port): Powers an IP camera, wireless access point, or other 802.3af-compliant device directly at the remote end — no separate power outlet or PoE injector required at the camera location. WDM BiDi Single-Fibre Operation: Transmits and receives over a single strand of single-mode fibre using TX 1310nm and RX 1550nm wavelengths — halving fibre infrastructure costs compared to dual-fibre media converters. 20km Maximum Fibre Range: Extends your network over single-mode fibre up to 20km — ideal for inter-building links, remote camera locations, and campus-wide surveillance networks. SC Simplex Fibre Connector: Standard SC simplex interface compatible with widely available single-mode fibre patch leads and infrastructure. 10/100Mbps Auto-Negotiation RJ45 Port: Connects to any standard Fast Ethernet switch, NVR, or network device via Cat5 or above copper Ethernet cable up to 100m. Half/Full-Duplex Auto-Negotiation: Automatically negotiates the optimal duplex mode with connected devices for reliable, error-free data transfer. Wide Operating Temperature (0–50°C): Suitable for comms cabinets and equipment rooms without dedicated air conditioning. LED Status Indicators: PWR, Link/Act, and PoE LEDs for quick visual status monitoring during installation and troubleshooting. Common Use Cases Powering and connecting a remote IP camera over a single fibre strand up to 20km — no power outlet needed at the camera end Inter-building CCTV links where copper Ethernet distance limits (100m) are exceeded Remote surveillance installations on large properties, farms, and industrial sites Extending a network to a remote building or outbuilding using existing single-mode fibre infrastructure Replacing dual-fibre media converters to halve fibre usage in conduit-constrained environments Technical Specifications Model TL-FC111PB-20 RJ45 Port 1× 10/100Mbps (802.3af PoE output) Fibre Port 1× 100Mbps SC Simplex Fibre Type 9/125μm Single-Mode (SMF) Max Fibre Distance 20km TX Wavelength 1310nm RX Wavelength 1550nm WDM / BiDi Yes (single-strand operation) PoE Standard IEEE 802.3af (output on RJ45 port) Required Pair Unit TL-FC111PA-20 (TX 1550nm / RX 1310nm) Copper Cable Cat5 or above, up to 100m Standards IEEE 802.3, 802.3i, 802.3u Power Supply 48V DC / 0.5A (external adapter) LED Indicators PWR, Link/Act, PoE Dimensions (W × D × H) 94.5 × 73.0 × 27.0mm Operating Temperature 0°C to 50°C Storage Temperature -40°C to 70°C Operating Humidity 10–90% RH (non-condensing) Frequently Asked Questions What unit do I need at the other end of the fibre link? The TL-FC111PB-20 (TX 1310nm / RX 1550nm) must be paired with a TL-FC111PA-20 (TX 1550nm / RX 1310nm) at the opposite end. Using two TL-FC111PB-20 units on the same link will not work — the wavelengths must be complementary. Does the PoE output power the remote camera or the local switch? The 802.3af PoE output is on the RJ45 port of the TL-FC111PB-20. This means the unit at the remote end (near the camera) provides PoE power to the connected IP camera or device. The unit at the local end (near the switch) connects to a standard non-PoE switch port via copper Ethernet. What fibre cable is required? The TL-FC111PB-20 requires 9/125μm single-mode fibre with an SC simplex connector. It is not compatible with multi-mode fibre (OM1, OM2, OM3, OM4) or SC duplex patch leads. Ensure your fibre infrastructure is single-mode before purchasing. Can I use this to connect a camera more than 100m away without running power? Yes — this is the primary use case. Place the TL-FC111PA-20 at the switch end (connected to your NVR or switch via copper Ethernet), run a single-mode fibre strand to the camera location, and connect the TL-FC111PB-20 at the camera end. The TL-FC111PB-20 will power the camera via its PoE RJ45 port — no power outlet needed at the camera location. What is the maximum PoE power output? The TL-FC111PB-20 provides 802.3af PoE output, which delivers up to 15.4W to the connected device. This is sufficient for most standard IP cameras and compact wireless access points. For devices requiring more than 15.4W (802.3at PoE+), a different solution is required. Is this suitable for outdoor camera installations? The media converter itself is rated for indoor use (0–50°C) and should be installed in a weatherproof enclosure or indoor location. The connected IP camera can be outdoor-rated. For the fibre run, use outdoor-rated single-mode fibre cable appropriate for your installation environment.

Read more less

Low-Cost 10Gbps Switch-to-Switch Connectivity Without SFP Modules The TP-Link TL-SM5220-1M is a 1-metre 10G SFP+ Direct Attach Copper (DAC) cable that provides a simple, cost-effective alternative to separate SFP+ transceivers and fibre patch leads for short-distance 10 Gigabit connections. With SFP+ connectors on both ends, it plugs directly into any compatible 10G SFP+ port — delivering full 10Gbps throughput with lower latency and lower cost than optical solutions. Ideal for top-of-rack switch stacking, server-to-switch connections, and NVR uplinks in data centres and comms cabinets across Australia. Key Features 10Gbps Data Rate: Full 10 Gigabit Ethernet throughput for high-bandwidth switch-to-switch and server-to-switch connections. SFP+ Connectors on Both Ends: Plugs directly into any 10G SFP+ port — no separate transceiver modules or fibre patch leads required. 1 Metre Cable Length: Ideal for short in-rack or adjacent-rack connections where devices are in close proximity. Direct Attach Copper (DAC): Passive copper cable design delivers lower latency and lower power consumption compared to active optical solutions. Cost-Effective Alternative to Fibre: Eliminates the need to purchase two SFP+ transceivers plus a fibre patch lead for short-distance 10G links. Replaces TXC432-CU1M: Direct replacement for the legacy TP-Link TXC432-CU1M DAC cable. Wide Temperature Range: Rated for operating temperatures from 0°C to 70°C — suitable for comms cabinets and server rooms. Common Use Cases Stacking or uplink connections between adjacent 10G switches in a comms rack Server-to-switch 10G connections in small data centres and server rooms NVR-to-switch 10G uplinks in high-camera-count CCTV installations Cost-effective alternative to SFP+ transceivers + fibre for in-rack connections Connecting TP-Link JetStream 10G switches (e.g. TL-SG3428X, TL-SG3452X) within the same rack Technical Specifications Model TL-SM5220-1M Cable Type Direct Attach Copper (DAC), Passive Connector Type SFP+ on both ends Data Rate 10 Gbps Cable Length 1 metre Operating Temperature 0°C to 70°C Storage Temperature -40°C to 80°C Operating Humidity 10–90% RH (non-condensing) Storage Humidity 5–90% RH (non-condensing) Replaces TXC432-CU1M Frequently Asked Questions What is a Direct Attach Cable (DAC) and how is it different from a fibre SFP+ connection? A Direct Attach Cable (DAC) is a fixed copper cable with SFP+ connectors permanently attached to both ends. Unlike a fibre SFP+ connection — which requires two separate transceiver modules plus a fibre patch lead — a DAC cable is a single, self-contained unit. DAC cables are cheaper, consume less power, and have lower latency than optical solutions, but are limited to short distances (typically 1–7 metres for passive DAC). Will this cable work with non-TP-Link switches? The TL-SM5220-1M uses standard SFP+ connectors and is designed to work with any switch that has a 10G SFP+ port. However, some switch vendors (notably Cisco and certain enterprise brands) may restrict compatibility to vendor-coded cables. Always verify compatibility with your specific switch model before purchasing. What is the maximum cable length for this DAC? This cable is 1 metre in length. TP-Link also offers longer DAC cables in the TL-SM5220 range (3m and 5m variants) for connections between adjacent racks or slightly further distances. For distances beyond 7 metres, an active optical SFP+ solution such as the TL-SM5110-LR is recommended. Does it require any configuration or drivers? No. DAC cables are passive devices — simply plug both ends into compatible SFP+ ports and the 10G link will establish automatically. No drivers, software, or configuration are required. Is this cable suitable for CCTV installations? Yes. For high-camera-count CCTV installations where an NVR needs a 10G uplink to a core switch within the same rack or cabinet, the TL-SM5220-1M provides a clean, low-cost 10G connection without the need for separate transceivers or fibre infrastructure. What TP-Link switches is this compatible with? The TL-SM5220-1M is compatible with TP-Link JetStream switches featuring 10G SFP+ ports, including the TL-SG3428X, TL-SG3428XMP, TL-SG3452X, and TL-SG3428XF. It is also compatible with most third-party switches with standard 10G SFP+ ports.

Read more less

10Gbps Single-Mode Fibre Transceiver for Long-Distance Network Uplinks The TP-Link TL-SM5110-LR is a 10GBase-LR SFP+ transceiver module designed for 10Gbps data transmission over single-mode fibre at distances up to 10km. Hot-pluggable and SFP+ MSA compatible, it slots directly into any 10G SFP+ port on compatible TP-Link JetStream switches and most third-party switches — making it a reliable, cost-effective solution for long-distance fibre uplinks in commercial networks, data centres, and multi-building installations across Australia. Key Features 10GBase-LR, 10km Reach: Transmits 10Gbps data over 9/125μm single-mode fibre at distances up to 10km — ideal for inter-building and campus network links. LC Duplex Connector: Standard LC duplex interface compatible with widely available single-mode fibre patch leads and infrastructure. Hot-Pluggable: Insert or remove the transceiver without powering down the switch — minimising downtime during installation or replacement. Digital Diagnostic Monitoring (DDM): Real-time monitoring of transceiver parameters including temperature, voltage, TX power, and RX power — enabling proactive fault detection and network health monitoring. SFP+ MSA Compatible: Compliant with the 10G Small Form-factor Pluggable Multi-Source Agreement, ensuring broad compatibility with TP-Link JetStream switches and most third-party 10G SFP+ ports. 1310nm Wavelength: Standard LR wavelength for single-mode fibre, compatible with existing SMF infrastructure. 3.3V Low Power Operation: Energy-efficient design suitable for high-density switch deployments. Common Use Cases 10Gbps fibre uplinks between access switches and core switches in commercial buildings Inter-building fibre connections on campuses, industrial sites, and business parks Data centre top-of-rack to aggregation switch connections Upgrading existing single-mode fibre infrastructure to 10Gbps speeds Long-distance NVR-to-switch uplinks in large CCTV installations Compatible TP-Link Switches The TL-SM5110-LR is compatible with TP-Link JetStream switches featuring 10G SFP+ ports, including: TL-SG3428X TL-SG3428XMP TL-SG3452X TL-SG3428XF Other TP-Link switches with 10G SFP+ slots Also compatible with most third-party switches that accept SFP+ MSA-compliant modules. Always verify compatibility with your specific switch model before purchasing. Technical Specifications Model TL-SM5110-LR Standard 10GBase-LR (IEEE 802.3ae) Data Rate 10 Gbps Connector Type LC Duplex Fibre Type 9/125μm Single-Mode (SMF) Wavelength 1310nm Max Cable Length 10km DDM Support Yes SFP+ MSA Compatible Yes Hot-Pluggable Yes Power Supply 3.3V DC Operating Temperature 0°C to 70°C Storage Temperature -40°C to 85°C Operating Humidity 10–90% RH (non-condensing) Dimensions (W × D × H) 122.5 × 81.5 × 38.5mm Weight 60g Certifications FCC, CE Frequently Asked Questions What is the difference between 10GBase-LR and 10GBase-SR? 10GBase-LR (Long Range) uses 1310nm wavelength over single-mode fibre and supports distances up to 10km. 10GBase-SR (Short Range) uses 850nm wavelength over multi-mode fibre and is limited to distances of 26–300m depending on the fibre grade. Use LR for inter-building or campus links; use SR for short in-rack or in-building connections. Will this transceiver work in non-TP-Link switches? The TL-SM5110-LR is SFP+ MSA compliant, which means it is designed to work in any switch with a standard 10G SFP+ port. However, some switch vendors (notably Cisco and certain enterprise brands) lock their switches to accept only vendor-coded modules. Always verify compatibility with your specific switch model before purchasing. What fibre cable do I need? You need 9/125μm single-mode fibre (SMF) patch leads with LC duplex connectors on both ends. Ensure your fibre infrastructure is single-mode — this transceiver is not compatible with multi-mode fibre (OM1, OM2, OM3, OM4). What does Digital Diagnostic Monitoring (DDM) do? DDM allows the switch to read real-time performance data from the transceiver — including optical transmit and receive power levels, temperature, supply voltage, and laser bias current. This helps network administrators detect degraded transceivers or fibre links before they cause outages. DDM data is typically viewable via the switch's management interface. Can I hot-swap this transceiver without rebooting the switch? Yes. The TL-SM5110-LR is hot-pluggable, meaning you can insert or remove it while the switch is powered on and running. This minimises disruption during installation, replacement, or maintenance. Is this transceiver suitable for CCTV installations? Yes. For large CCTV installations where the NVR or core switch is more than 100m from an access switch, a fibre uplink using the TL-SM5110-LR is the recommended solution. It provides a 10Gbps, interference-free link over distances up to 10km — well beyond the 100m limit of copper Ethernet.

Read more less

TP-Link TL-FC311B-20 Gigabit WDM Media Converter• 1× 10/100/1000Mbps Auto-Negotiation RJ45 port supports Auto-MDI/MDIX• Auto-negotiation of Half-Duplex/Full-Duplex transfer mode• Adopts WDM technology, transmitting and receiving data on one single fibre• Extends fibre distance up to 20 km (for TL-FC311A-20 & TL-FC311B-20)NETWORKStandards and Protocols IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3zENVIRONMENTOperating Temperature 0˚C to 50˚C (32˚F to 122˚F)Storage Temperature -40˚C to 70˚C (-40˚F to 158˚F)Operating Humidity 10% to 90% RH non-condensingStorage Humidity 5% to 90% RH non-condensingHARDWARE FEATURESInterface • 1× Gigabit SC Fiber Port• 1× 10/100/1000 Mbps RJ45 Port (Auto MDI/MDIX)Network Media • Single-mode Fiber• UTP category 5, 5e cable (maximum 100m)Power Supply External Power Adapter: 5 V/0.6 ALED PWR, Link/ActDimensions ( W x D x H ) 3.7×2.9×1.1 in (94.5×73.0×27.0 mm)Wave Length • 1310 nm TX• 1550 nm RXMEDIA CONVERTER & MODULEFiber Type 9/125 μm single-mode fiber

Read more less

TP-Link TL-FC311A-2 / TL-FC311B-2 Gigabit WDM Media Converter• 1× 10/100/1000Mbps Auto-Negotiation RJ45 port supports Auto-MDI/MDIX• Auto-negotiation of Half-Duplex/Full-Duplex transfer mode• Adopts WDM technology, transmitting and receiving data on one single fibre• Extends fibre distance up to 2 km (for TL-FC311A-2 & TL-FC311B-2)TP-Link Gigabit WDM Media Converter is able to convert between electrical and optical signals, providing a gigabit RJ-45 port and a gigabit SC fiber port. WDM (wavelength division multiplexing) technology enables the media converter to send and receive data simultaneously using only one single mode fiber through two channels of different wavelengths, with strong anti‑interference ability. The maximum transmission distance can reach up to 2 km or 20 km, varying among different models.The media converter of model A can work in pair with model B, with one device transmitting signals of 1550nm wavelength and receiving signals of 1310nm wavelength, and the other vice versa. In other scenarios, a single media converter can connect to an SFP module and an RJ-45 port of another device, flexibly fit into diversenetwork topology.Besides, this media converter can work as a standalone device (no rack required) or with TP-Link's TL‑FC1420 rack for central management and power supply.

Read more less

TP-Link TL-FC311A-2 / TL-FC311B-2 Gigabit WDM Media Converter• 1× 10/100/1000Mbps Auto-Negotiation RJ45 port supports Auto-MDI/MDIX• Auto-negotiation of Half-Duplex/Full-Duplex transfer mode• Adopts WDM technology, transmitting and receiving data on one single fibre• Extends fibre distance up to 2 km (for TL-FC311A-2 & TL-FC311B-2)TP-Link Gigabit WDM Media Converter is able to convert between electrical and optical signals, providing a gigabit RJ-45 port and a gigabit SC fiber port. WDM (wavelength division multiplexing) technology enables the media converter to send and receive data simultaneously using only one single mode fiber through two channelsof different wavelengths, with strong anti‑interference ability. The maximum transmission distance can reach up to 2 km or 20 km, varying among different models.The media converter of model A can work in pair with model B, with one device transmitting signals of 1550nm wavelength and receiving signals of 1310nm wavelength, and the other vice versa. In other scenarios, a single media converter can connect to an SFP module and an RJ-45 port of another device, flexibly fit into diversenetwork topology.Besides, this media converter can work as a standalone device (no rack required) or with TP-Link's TL‑FC1420 rack for central management and power supply.

Read more less

Add PoE+ Power to Any Gigabit Network Port — No PoE Switch RequiredThe TP-Link TL-POE160S is a single-port Gigabit PoE+ injector that adds Power over Ethernet capability to any standard network switch or router port. Simply connect it between your existing switch and a PoE-powered device — such as an IP camera, wireless access point, or VoIP phone — and it delivers up to 30W of power alongside data over a single Ethernet cable. No configuration required.Key Features IEEE 802.3af/at Compliant — compatible with all standard PoE and PoE+ powered devices 2× Gigabit Ports — 1× data-in (from switch/router) and 1× data+power-out (to PoE device), both at 10/100/1000Mbps Up to 30W Output — auto-senses and supplies only the power the connected device requires Integrated Power Supply — built-in AC socket (100–240V), no external power brick needed Plug and Play — zero configuration; connect and go Wall-Mountable or Desktop — flexible installation for any environment LED Power Indicator — confirms active PoE power delivery at a glance Typical Use Cases Adding PoE power to a single IP camera without replacing an existing non-PoE switch Powering a wireless access point in a location without a nearby power outlet Supplying power to a VoIP phone or intercom from a standard Ethernet port Temporary or single-device PoE deployments where a full PoE switch is not required Retrofitting PoE capability to legacy network infrastructure Technical Specifications Specification Detail Model TL-POE160S PoE Standard IEEE 802.3af / 802.3at (PoE+) Ports 1× Gigabit RJ45 Data-In, 1× Gigabit RJ45 Data+Power-Out Port Speed 10/100/1000 Mbps (auto-negotiation) Max PoE Output 30W (auto-sensing) Power Input 100–240V AC, 50/60Hz (integrated) Network Standards IEEE 802.3i, 802.3u, 802.3ab, 802.3af, 802.3at Max Cable Length Up to 100m (Cat5e/Cat6) Installation Wall-mount or desktop Dimensions (W×D×H) 125 × 59.4 × 36.8 mm Operating Temperature 0–40°C Certifications FCC, CE, RoHS Warranty 3 Years What's in the Box TL-POE160S PoE+ Injector Installation Guide Frequently Asked Questions What is a PoE injector and how does it work? A PoE injector sits between your existing network switch and a PoE-powered device. It takes standard Ethernet data from your switch and adds DC power to the cable, so the connected device receives both data and power through a single RJ45 cable — no separate power adapter needed at the device end. Do I need to replace my switch to use this injector? No. The TL-POE160S works with any standard Ethernet switch or router, regardless of whether it supports PoE. It adds PoE capability to a single port without any changes to your existing infrastructure. What devices can I power with the TL-POE160S? Any IEEE 802.3af or 802.3at compliant device drawing up to 30W — including IP cameras, wireless access points, VoIP phones, intercoms, and access control readers. Does it work with non-PoE devices? The TL-POE160S will only supply power to devices that actively request it via the 802.3af/at handshake. Non-PoE devices connected to the output port will receive data only and will not be damaged. Can I use this outdoors? The injector itself is rated for indoor use (0–40°C). However, it can power outdoor PoE devices such as weatherproof IP cameras via a cable run from an indoor installation point.

Read more less

TP-Link TL-FC111B-20 10/100 Mbps WDM Media Converter• Complies with 802.3u 10/100Base-TX, 100Base-FX standards• Auto-negotiation of Half-Duplex/Full-Duplex transfer mode• Adopts WDM technology, transmitting and receiving data on one single fibre• Extends fibre distance up to 20kmWhat This Product DoesTL-FC111A-20 is a 100M media converter, providing a 100M RJ-45 port and a 100M SC fiber port, which can convert between electrical and optical signals. And long-distance data transmission through optical fiber can be applied to commercial scenarios such as park security monitoring and wireless networking.How This Product WorksTL-FC111A-20 adopts WDM (wavelength division multiplexing) technology, helping send and receive data at a distance of up to 20 km with only a single mode fiber, which saves half of the cable deployment cost for customers. TL-FC111B-20 transmits data at 1310nm wavelength and receives data at 1550nm wavelength on optical fiber. Therefore, the terminal device used in conjunction with the TL-FC111B-20 should send data at a wavelength of 1550nm and receive data at a wavelength of 1310nm. TP-Link another media converter TL-FC111A-20 is one of the products that can cooperate with TL-FC111B-20.Other FeaturesBesides, this media converter can be used as a standalone device (no rack required) or used with TP-Link’s TL-FC1420 rack for auto MDI/MDI-X in TX port in which duplex mode is automatically negotiated.

Read more less

TP-Link TL-FC111A-20 10/100 Mbps WDM Media Converter• Complies with 802.3u 10/100Base-TX, 100Base-FX standards• Auto-negotiation of Half-Duplex/Full-Duplex transfer mode• Adopts WDM technology, transmitting and receiving data on one single fibre• Extends fibre distance up to 20kmWhat This Product DoesTL-FC111A-20 is a 100M media converter, providing a 100M RJ-45 port and a 100M SC fiber port, which can convert between electrical and optical signals. And long-distance data transmission through optical fiber can be applied to commercial scenarios such as park security monitoring and wireless networking.How This Product WorksTL-FC111A-20 adopts WDM (wavelength division multiplexing) technology, helping send and receive data at a distance of up to 20 km with only a single mode fiber, which saves half of the cable deployment cost for customers. TL-FC111A-20 transmits data at 1550nm wavelength and receives data at 1310nm wavelength on optical fiber. Therefore, the terminal device used in conjunction with the TL-FC111A-20 should send data at a wavelength of 1310nm and receive data at a wavelength of 1550nm. TP-Link another media converter TL-FC111B-20 is one of the products that can cooperate with TL-FC111A-20.Other FeaturesBesides, this media converter can be used as a standalone device (no rack required) or used with TP-Link’s TL-FC1420 rack for auto MDI/MDI-X in TX port in which duplex mode is automatically negotiated.

Read more less

Single-Fibre Gigabit Connectivity — Cut Your Fibre Infrastructure in Half The TP-Link TL-SM321B-2 is a 1000Base-BX WDM BiDi (Bi-Directional) SFP module that transmits and receives over a single strand of single-mode fibre using an LC simplex connector. By using separate wavelengths for TX (1310nm) and RX (1550nm), it eliminates the need for a second fibre strand per link — halving cabling costs and conduit usage compared to standard dual-fibre SFP modules. Ideal for inter-building links, IP surveillance backbones, and any installation where fibre runs are limited or expensive. Important: The TL-SM321B-2 (TX 1310nm / RX 1550nm) must be paired with a TL-SM321A-2 module (TX 1550nm / RX 1310nm) at the opposite end of the fibre link. Two TL-SM321B-2 modules on the same link will not establish a connection. Key Features Single-Strand BiDi Operation: Transmits and receives over one fibre strand using WDM technology — TX at 1310nm, RX at 1550nm — reducing fibre infrastructure by 50% per link. LC Simplex Connector: Standard LC simplex interface compatible with widely available single-mode fibre patch leads and infrastructure. 1.25Gbps Gigabit Data Rate: Full 1000Base-BX Gigabit throughput for switch-to-switch and switch-to-media-converter fibre uplinks. 10km Maximum Range: Supports single-mode fibre runs up to 10km — suitable for inter-building and campus network links. Digital Diagnostic Monitoring (DDM): Real-time monitoring of temperature, voltage, TX power, and RX power via the host switch management interface for proactive fault detection. Hot-Swappable: Insert or remove the module without powering down the host switch — minimising downtime during installation or replacement. SFP-MSA Compliant: Broad compatibility with TP-Link managed switches and media converters that accept standard SFP modules. Low Power: 3.3V powered directly from the host device — no external power required. Common Use Cases Inter-building Gigabit fibre links using a single fibre strand per connection IP surveillance switch-to-switch fibre uplinks in large CCTV installations Conduit-constrained environments where maximising links per fibre count is critical Campus and multi-building networks requiring cost-effective single-mode fibre connectivity Adding Gigabit fibre uplinks to existing TP-Link managed switches without running additional fibre Technical Specifications Model TL-SM321B-2 Module Type 1000Base-BX WDM BiDi SFP Connector LC Simplex TX Wavelength 1310nm RX Wavelength 1550nm Data Rate 1.25Gbps (1000Base-BX) Fibre Type 9/125μm Single-Mode (SMF) Max Cable Length 10km DDM Support Yes Hot-Swappable Yes SFP-MSA Compliant Yes Required Pair Module TL-SM321A-2 (TX 1550nm / RX 1310nm) Power Supply 3.3V (from host device) Standard IEEE 802.3z, TCP/IP Operating Temperature 0°C to 70°C Storage Temperature -40°C to 85°C Operating Humidity 10–90% RH (non-condensing) Weight 60g Certifications FCC, CE Frequently Asked Questions What module do I need at the other end of the fibre link? The TL-SM321B-2 (TX 1310nm / RX 1550nm) must be paired with a TL-SM321A-2 module (TX 1550nm / RX 1310nm) at the opposite end. Using two TL-SM321B-2 modules on the same link will not establish a connection — the wavelengths must be complementary. Why use a BiDi SFP instead of a standard dual-fibre SFP? Standard SFP modules use two fibre strands per link (one for TX, one for RX). A BiDi module uses a single strand by splitting TX and RX onto different wavelengths. This halves the fibre count required per link, reducing cabling costs and conduit usage — particularly valuable in installations where fibre runs are expensive or conduit space is limited. What fibre cable is required? The TL-SM321B-2 requires 9/125μm single-mode fibre with an LC simplex connector on each end. It is not compatible with multi-mode fibre (OM1, OM2, OM3, OM4) or LC duplex patch leads. What does Digital Diagnostic Monitoring (DDM) do? DDM allows the host switch to read real-time performance data from the SFP module — including optical TX and RX power levels, temperature, and supply voltage. This helps network administrators detect degraded modules or fibre links before they cause outages. DDM data is viewable via the switch's management interface. Is it compatible with third-party switches? The TL-SM321B-2 is SFP-MSA compliant, providing broad compatibility. TP-Link validates it specifically for use with TP-Link managed switches and media converters. Compatibility with third-party equipment is not guaranteed — some vendors restrict modules to vendor-coded units only. Can I hot-swap it without rebooting the switch? Yes. The TL-SM321B-2 is hot-swappable and can be inserted or removed while the host switch is powered on and running, minimising disruption during installation or replacement.

Read more less

TP-Link TL-SM321A-2 Gigabit WDM Bi-Directional SFP Module The TP-Link TL-SM321A-2 is a 1000Base-BX WDM (Wavelength Division Multiplexing) bi-directional SFP module that transmits and receives over a single strand of single-mode fibre. With a TX wavelength of 1550nm and RX of 1310nm, it pairs with the complementary TL-SM321B-2 (TX 1310nm / RX 1550nm) to deliver full-duplex Gigabit connectivity over just one fibre run — halving your cabling costs on point-to-point links up to 2km. Key Features 1000Base-BX WDM BiDi — full-duplex Gigabit over a single fibre strand TX: 1550nm / RX: 1310nm — pairs with TL-SM321B-2 at the remote end Up to 2km transmission distance over 9/125μm single-mode fibre (SMF) LC Simplex connector — standard, widely available termination Digital Diagnostic Monitoring (DDM) — real-time optical performance visibility Hot-swappable — insert or remove without powering down the host device SFP-MSA compliant — compatible with most SFP-capable switches and media converters 1.25Gbps data rate, 3.3V power supply Use Cases Point-to-point fibre links — connect two switches or media converters over a single SMF strand, saving one fibre run per link Security and surveillance networks — extend Gigabit connectivity between buildings or floors where copper cabling is impractical Campus and enterprise networks — cost-effective fibre uplinks where existing single-strand fibre infrastructure is already in place ISP and telco last-mile — BiDi SFPs are commonly used in FTTN and point-to-point fibre distribution applications Specifications Specification Detail Model TL-SM321A-2 Standard 1000Base-BX (IEEE 802.3z), TCP/IP TX Wavelength 1550nm RX Wavelength 1310nm Data Rate 1.25Gbps Max. Cable Length 2km Fibre Type 9/125μm Single-Mode Fibre (SMF) Connector LC Simplex DDM Supported Hot Swappable Yes SFP-MSA Compliant Yes Power Supply 3.3V Operating Temperature 0–70°C Storage Temperature -40–85°C Operating Humidity 10–90% RH, Non-Condensing Certifications FCC, CE SKU / Barcode TL-SM321A-2 / 6935364072933 Weight 0.06kg Pairing Note The TL-SM321A-2 (TX 1550nm / RX 1310nm) must be paired with the TL-SM321B-2 (TX 1310nm / RX 1550nm) at the opposite end of the fibre link. Using two modules of the same type will not establish a connection. Frequently Asked Questions What is a BiDi SFP module? A BiDi (bi-directional) SFP uses WDM technology to transmit and receive on different wavelengths over a single fibre strand. This allows a full-duplex Gigabit link using only one fibre run instead of two, reducing cabling costs and simplifying infrastructure. What module do I need at the other end? You must use the complementary TL-SM321B-2 (TX 1310nm / RX 1550nm) at the remote end. The wavelengths must be opposite — one end transmits at 1550nm while the other receives at 1550nm, and vice versa. Is the TL-SM321A-2 compatible with third-party switches? Yes. The TL-SM321A-2 is SFP-MSA compliant, meaning it is designed to work with any switch or media converter that accepts standard SFP modules. Compatibility with specific third-party devices should be verified with the switch manufacturer. What does DDM (Digital Diagnostic Monitoring) do? DDM allows you to monitor real-time optical parameters — such as TX power, RX power, temperature, and voltage — directly from a compatible switch’s management interface. This is useful for diagnosing fibre link issues without physical inspection. Can I hot-swap this module? Yes. The TL-SM321A-2 is hot-swappable, so you can insert or remove it from a compatible SFP port without powering down the host switch or device. Does it ship Australia-wide? Yes. CCTV Guru ships the TL-SM321A-2 Australia-wide from local stock.

Read more less

TP-Link TL-POE150S — Gigabit PoE Injector (802.3af) The TP-Link TL-POE150S is a compact, plug-and-play PoE injector that adds Power over Ethernet capability to any standard non-PoE switch or router. It delivers both data and power to IEEE 802.3af-compliant devices over a single Cat5e/6 cable at distances up to 100 metres — no electrician, no extra power points, no fuss. Key Features IEEE 802.3af compliant — works with IP cameras, access points, VoIP phones, and more 2 × Gigabit RJ45 ports for full-speed 1000Mbps data throughput Delivers power and data over a single cable up to 100m Auto-detects device power requirements — no manual configuration Plug-and-play — no software or drivers needed External power adapter included Typical Use Cases IP Camera Installations: Add PoE to an existing non-PoE switch to power a single IP camera without running a separate power cable Wireless Access Points: Power a ceiling-mounted Wi-Fi access point from a nearby data cabinet VoIP Phones: Supply power and network connectivity to a desk phone over one cable run Access Control Devices: Power card readers or intercoms in locations without a nearby power outlet Retrofit Installations: Upgrade an existing non-PoE network without replacing the switch Technical Specifications Specification Detail Model TL-POE150S PoE Standard IEEE 802.3af Ports 2 × 10/100/1000Mbps RJ45 (Data In + PoE Out) Max Cable Distance 100m (Cat5e or better) PoE Output Power Up to 15.4W (802.3af) Power Detection Auto (no manual configuration required) Power Supply External power adapter Vendor TP-Link SKU TL-POE150S Configuration Plug-and-play, no software required Frequently Asked Questions What is a PoE injector and do I need one? A PoE injector adds Power over Ethernet to a single port on a non-PoE switch or router. If your switch doesn't support PoE and you need to power a device like an IP camera or access point without a nearby power outlet, a PoE injector is the most cost-effective solution. Will the TL-POE150S work with my existing non-PoE switch? Yes. The TL-POE150S sits between your existing switch and the PoE device. Your switch handles data as normal; the injector adds power to the cable before it reaches the end device. Is this compatible with 802.3at (PoE+) devices? The TL-POE150S supports IEEE 802.3af only, which provides up to 15.4W per port. Devices that require 802.3at (PoE+, up to 30W) — such as some PTZ cameras or dual-band access points — are not supported. Check your device's power requirements before purchasing. What cable type do I need? Cat5e or better is recommended for Gigabit speeds and reliable PoE delivery. Maximum cable run is 100 metres. Does this ship Australia-wide? Yes. CCTV Guru ships the TL-POE150S from local Australian stock to all states and territories.

Read more less

TP-Link TL-POE10R Gigabit PoE Splitter Power your network devices without running a separate power cable. The TP-Link TL-POE10R is an IEEE 802.3af-compliant PoE splitter that separates power and data from a single Ethernet cable, delivering clean DC power (12V, 9V, or 5V) to devices that don't have built-in PoE support — all at Gigabit speeds over distances up to 100 metres. Key Features IEEE 802.3af compliant — works with any 802.3af-standard PoE switch or injector Gigabit support — 2 x 10/100/1000Mbps RJ45 ports with Auto-Negotiation and Auto MDI/MDIX Selectable DC output — choose 12V, 9V, or 5V to match your device's power requirement Delivers power and data over a single Cat5/5e/6 cable up to 100 metres Plug-and-play — no configuration or software required PWR LED indicator for quick status confirmation Compact form factor: 80.8 × 54 × 24 mm Use Cases Powering IP cameras, access points, or VoIP phones that lack built-in PoE CCTV and security installations where running separate power cabling is impractical Retail, hospitality, and office deployments requiring tidy, single-cable runs Pairing with a PoE switch to power Raspberry Pi or IoT devices via Ethernet Specifications Specification Detail Model TL-POE10R PoE Standard IEEE 802.3af Data Ports 2 × 10/100/1000Mbps RJ45 Auto-Negotiation / MDI/MDIX Yes Power Output Port 1 × DC output DC Output Options 12V 1A / 9V 1A / 5V 2A (selectable) Max Cable Distance 100 metres Supported Cable Cat3/4/5 (10M), Cat5/5e (100M), Cat5/5e/6 (1000M) LED Indicator PWR Dimensions (W × D × H) 80.8 × 54 × 24 mm Weight 200 g SKU TL-POE10R Vendor TP-Link Recommended Accessories TP-Link TL-POE150S PoE Injector — add PoE to any standard Ethernet port TP-Link TL-SG1005P 5-Port Gigabit PoE Switch — power multiple devices from one switch Cat6 Ethernet patch cables for optimal Gigabit performance Frequently Asked Questions What is a PoE splitter and how does it work? A PoE splitter receives a combined power and data signal from a PoE-enabled switch or injector over a single Ethernet cable. It then splits that signal, passing data through to your device's Ethernet port and converting the power to a standard DC output (12V, 9V, or 5V) for the device's power input. Do I need a PoE switch to use the TL-POE10R? Yes. The TL-POE10R is a passive splitter — it requires a PoE power source such as an IEEE 802.3af-compliant PoE switch or a PoE injector (such as the TP-Link TL-POE150S) to function. Which voltage output should I select? Match the output voltage to your device's power requirement. Common selections are 12V for IP cameras and access points, 9V for some routers, and 5V for USB-powered devices and Raspberry Pi. Always check your device's power label before selecting. Is the TL-POE10R compatible with 802.3at (PoE+) switches? The TL-POE10R is rated for IEEE 802.3af. It will work with 802.3at (PoE+) switches in backward-compatible mode, but will only draw up to 802.3af power levels (max 15.4W at the source). Does CCTV Guru ship Australia-wide? Yes. We ship to all states and territories across Australia. Orders are dispatched promptly from our local warehouse.
