Hikvision 8MP 4K · ColorVu · Live-Guard · 60m Hybrid Light
Hikvision DS-2CD2T87G3-LIS2UY/SL 8MP 4K ColorVu Live-Guard Bullet — Strobe + Siren, 60m Smart Hybrid Light, AcuSense
The Hikvision DS-2CD2T87G3-LIS2UY/SL is the flagship long-range bullet of the G3 series, delivering crystal-clear 8 MP / 4K UHD resolution for large perimeters and open spaces. An F1.0 super-aperture lens drives true 24/7 ColorVu full-colour night vision down to 0.0005 lux, while Smart Hybrid Light reaches an exceptional 60 m with IR and white light. AcuSense AI classifies human and vehicle targets — the camera stays in stealthy IR until detection, then switches to full-colour ColorVu and fires the Live-Guard strobe and siren to stop intruders before they reach the door. A built-in array dual microphone and speaker add two-way audio, and an all-metal IP67 housing withstands harsh Australian weather. Available in 2.8 mm and 4 mm lens. Australian stock, 3-Year Australian warranty.
Resolution
8 MP · 3840 × 2160 (4K)
Lens
F1.0 · 2.8 mm or 4 mm
Smart Hybrid Light
IR + White · up to 60 m
AI Engine
AcuSense · Human + Vehicle
Deterrence
Strobe + Siren · 2-Way Audio
Protection
IP67 · 3-Year AU
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Key Features
4K UHD Resolution
8 MP / 4K provides about 33% more detail than 6 MP — digitally zoom into a recording and still identify a face or read a number plate after the fact.
24/7 ColorVu Full-Colour Night
An F1.0 super-aperture delivers vivid colour in near-total darkness — down to 0.0005 lux — capturing clothing and vehicle colour at night.
60 m Smart Hybrid Light
Stays in discreet IR by default and switches to white-light ColorVu on AcuSense detection, with an exceptional 60 m reach for large yards and long perimeters.
Live-Guard Active Deterrence
A built-in strobe light and adjustable siren trigger automatically on detection to stop intruders at the perimeter.
Why Choose the DS-2CD2T87G3-LIS2UY/SL
AcuSense AI
Deep-learning classification focuses strictly on human and vehicle targets, ignoring pets and leaves to cut false alarms.
Two-Way Audio Talk-Down
A built-in array dual microphone and speaker let you talk through the camera live via Hik-Connect.
Efficient H.265+ Storage
Advanced compression cuts storage use substantially without sacrificing 4K image quality.
Built Tough
All-metal IP67 construction withstands harsh Australian sun, dust and heavy rain.
Recommended For
Large Perimeters & Yards
60 m night reach and 4K detail across big open sites.
Commercial & Industrial
Visible bullet body plus strobe and siren deter intruders at the boundary.
Car Parks & Driveways
Wide 2.8 mm coverage with active deterrence for exposed areas.
Post-Incident Review
4K headroom to digitally zoom into recordings for faces and plates.
Technical Specifications
DS-2CD2T87G3-LIS2UY/SL · Full Specifications
SKU
DS-2CD2T87G3-LIS2UY/SL
Camera Type
Hikvision G3 8 MP / 4K ColorVu Smart Hybrid Light AcuSense Live-Guard Bullet
Max Resolution
3840 × 2160 (8 MP / 4K UHD)
Lens
2.8 mm (108.8° HFOV) or 4 mm (93.3° HFOV) · F1.0
Min. Illumination
0.0005 lux @ F1.0 (AGC ON) · 0 lux with white light
Supplement Light
Smart Hybrid Light — IR + white light · up to 60 m
AI Engine
AcuSense — human + vehicle classification · perimeter protection
Deterrence
Active strobe light + siren
Audio
Built-in array dual microphone & speaker · two-way audio
Video Compression
H.265+ / H.265 / H.264+ / H.264
On-Board Storage
microSD card slot
Power
PoE · 12 VDC
Housing
Metal · integrated sunshield
Weatherproof Rating
IP67
Warranty
3-Year Australian Warranty
Frequently Asked Questions
Why choose 8 MP / 4K over 6 MP?8 MP / 4K provides about 33% more resolution than 6 MP, allowing much clearer digital zoom when you need to identify plates or faces in a recording.
Does this require a subscription?No. It records directly to your NVR — you own your footage with no ongoing monthly cloud fees.
How loud is the siren?The siren is fully adjustable and can be scheduled to trigger only during specific nighttime hours via the Hik-Connect app.
Can I talk through the camera?Yes — the built-in array dual microphone and speaker support real-time two-way audio via Hik-Connect.
Downloads & Resources
DS-2CD2T87G3-LIS2UY/SL Datasheet
Hikvision Network Camera Quick Start Guide
CCTV Guru is an authorised Australian reseller of Hikvision ColorVu Live-Guard cameras. Order the DS-2CD2T87G3-LIS2UY/SL 8 MP / 4K long-range deterrence bullet in 2.8 mm or 4 mm for fast Australia-wide dispatch, expert pre-sales advice and full local warranty support. Request a free quote or contact our Australian team.
Hikvision 6MP · ColorVu · Live-Guard · 60m Hybrid Light
Hikvision DS-2CD2T67G3-LIS2UY/SL 6MP ColorVu Live-Guard Bullet — Strobe + Siren, 60m Smart Hybrid Light, AcuSense
The Hikvision DS-2CD2T67G3-LIS2UY/SL is the long-range deterrence bullet of the G3 series — built for large open spaces. It pairs 6 MP / 3K imaging with an F1.0 super-aperture lens for true 24/7 ColorVu full-colour night vision, and reaches an exceptional 60 m with Smart Hybrid Light (IR + white light). The integrated Live-Guard active-deterrence system fires a high-intensity strobe and siren automatically when AcuSense AI classifies a human or vehicle — ignoring pets, foliage and rain. A built-in microphone and speaker add two-way audio for live talk-down, and an all-metal IP67 housing withstands harsh Australian weather. Available in 2.8 mm and 4 mm lens. Australian stock, 3-Year Australian warranty.
Resolution
6 MP · 3200 × 1800 (3K)
Lens
F1.0 · 2.8 mm or 4 mm
Smart Hybrid Light
IR + White · up to 60 m
AI Engine
AcuSense · Human + Vehicle
Deterrence
Strobe + Siren · 2-Way Audio
Protection
IP67 · 3-Year AU
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Key Features
24/7 ColorVu Full-Colour Night
A high-performance sensor and F1.0 super-aperture deliver vivid colour in near-total darkness — down to 0.0005 lux — so you see clothing, vehicle and skin colour at night, not just grey shapes.
60 m Smart Hybrid Light
The camera stays in discreet IR at night and switches to white-light ColorVu the moment AcuSense detects a human or vehicle — with an exceptional 60 m reach for large yards and long driveways.
Live-Guard Active Deterrence
A built-in strobe light and adjustable siren trigger automatically on detection to stop intruders before they reach the property.
AcuSense AI
Deep-learning classification focuses strictly on human and vehicle targets, ignoring pets, leaves and rain to cut false alarms.
Why Choose the DS-2CD2T67G3-LIS2UY/SL
Two-Way Audio Talk-Down
A built-in microphone and speaker let you talk through the camera live via Hik-Connect — warn off an intruder or direct a delivery driver.
Long-Range Bullet Form
The bullet body with integrated sunshield and 60 m reach suits long driveways, large yards and high-perimeter deterrence where a turret's 30 m falls short.
Efficient H.265+ Storage
Advanced H.265+ compression cuts storage use substantially without sacrificing 3K image quality.
Built Tough
All-metal IP67 construction is built to withstand harsh Australian sun, dust and rain.
Recommended For
Long Driveways & Large Yards
60 m night reach covers ground a standard 30 m camera can't.
Commercial Perimeters
Visible bullet body plus strobe and siren deter intruders at the boundary.
Car Parks & Open Spaces
Wide 2.8 mm coverage with active deterrence for exposed areas.
Rural & Acreage
Long-range detection and deterrence for properties with large setbacks.
Technical Specifications
DS-2CD2T67G3-LIS2UY/SL · Full Specifications
SKU
DS-2CD2T67G3-LIS2UY/SL
Camera Type
Hikvision G3 6 MP ColorVu Smart Hybrid Light AcuSense Live-Guard Bullet
Max Resolution
3200 × 1800 (6 MP / 3K)
Lens
2.8 mm (108.8° HFOV) or 4 mm (93.3° HFOV) · F1.0
Min. Illumination
0.0005 lux @ F1.0 (AGC ON) · 0 lux with white light
Supplement Light
Smart Hybrid Light — IR + white light · up to 60 m
AI Engine
AcuSense — human + vehicle classification · perimeter protection
Deterrence
Active strobe light + siren
Audio
Built-in microphone & speaker · two-way audio
Video Compression
H.265+ / H.265 / H.264+ / H.264
On-Board Storage
microSD card slot
Power
PoE · 12 VDC
Housing
Metal · integrated sunshield
Weatherproof Rating
IP67
Warranty
3-Year Australian Warranty
Frequently Asked Questions
Does this require a subscription?No. It records directly to your NVR or an internal microSD card — you own your footage with no ongoing monthly cloud fees.
Is the 60 m light too bright up close?No — Smart Supplement Light automatically adjusts intensity based on the subject's distance to prevent overexposure of nearby objects.
Can I schedule the siren and strobe?Yes — via Hik-Connect you can set the siren and strobe to activate only during chosen hours, e.g. 10 PM to 6 AM.
Can I talk through the camera?Yes — the built-in microphone and speaker support real-time two-way audio through the Hik-Connect app.
Bullet or turret — which Live-Guard should I choose?This bullet reaches 60 m and suits long driveways and large perimeters; the turret sibling reaches 30 m in a lower-profile body better suited to eaves and entryways.
Downloads & Resources
DS-2CD2T67G3-LIS2UY/SL Datasheet
Hikvision Network Camera Quick Start Guide
CCTV Guru is an authorised Australian reseller of Hikvision ColorVu Live-Guard cameras. Order the DS-2CD2T67G3-LIS2UY/SL long-range deterrence bullet in 2.8 mm or 4 mm for fast Australia-wide dispatch, expert pre-sales advice and full local warranty support. Request a free quote or contact our Australian team.
Dahua · DH-HAC-HDW2802T-A · 8MP 4K HDCVI Turret · Starlight · 2.8mm / IR 50m
8MP 4K Turret
Dahua DH-HAC-HDW2802T-A 8MP 4K HDCVI Starlight Turret Camera
The Dahua DH-HAC-HDW2802T-A is an 8MP 4K (3840×2160) HDCVI Starlight turret that upgrades your existing coax cabling to cinematic Ultra HD without rewiring. A 1/2" CMOS sensor with F1.6 aperture and Starlight technology delivers clean, full-colour images in extreme low light, while a 2.8mm fixed lens gives a 110° ultra-wide view and Smart IR reaches up to 50m in the dark. As an HDCVI camera it connects over coax (BNC) to a Dahua XVR (Penta-brid DVR) — not an IP NVR.
Resolution
8MP 4K (3840×2160)
Lens
2.8mm Fixed
Night Vision
Smart IR 50m
Technology
HDCVI Starlight
Audio
Built-in Mic
Weatherproof
IP67 Metal
True 4K Over Coax
Four times the detail of 1080p, transmitted over your existing RG59/RG6 cable up to 700m — no network rewiring needed.
Starlight Low-Light
A large 1/2" sensor and F1.6 aperture keep footage in full colour down to 0.005 Lux, where ordinary cameras go grainy or mono.
120dB True WDR
Balances bright and dark areas so faces aren't silhouetted against doorways, windows or headlights.
Audio & Multi-Format
Built-in microphone records audio over the same coax, and the output switches between HDCVI/AHD/TVI/CVBS for legacy DVRs.
Specifications — DH-HAC-HDW2802T-A
Model
DH-HAC-HDW2802T-A (2.8mm)
Resolution
8MP / 4K (3840×2160)
Image Sensor
1/2" CMOS
Lens
2.8mm fixed, ~110° horizontal FOV
Night Vision
Smart IR up to 50m
Low-Light
Starlight, F1.6 aperture, 0.005 Lux colour
WDR
120dB true WDR, 3D NR
Audio
Built-in mic (audio-over-coax)
Form Factor
Turret (eyeball), full metal IP67
Power
12V DC
Signal Type
HDCVI (also AHD/TVI/CVBS) — connect to a Dahua XVR
Warranty (Australia)
3 years · CCTV Guru Australia
Downloads & Resources
DH-HAC-HDW2802T-A DatasheetDahua HDCVI Camera Quick Start GuideDahua HDCVI Camera User Manual
What recorder do I need for this camera?A Dahua HDCVI XVR (Penta-brid DVR) that supports 4K/8MP input, such as the XVR5000-4KL or 7000 series. It connects over coax, not a network NVR.
Can I run it on my existing coax cabling?Yes. HDCVI sends 4K video over standard RG59/RG6 coax up to 700m, so you can upgrade older analogue runs without re-cabling.
Does it record audio?Yes, it has a built-in microphone and sends audio over the same coax cable to a compatible XVR.
How is the night vision?Starlight sensor plus Smart IR to 50m gives full-colour low-light performance down to 0.005 Lux and clear mono footage in total darkness.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · ARC3800H · Premium Wireless Alarm Kit · WiFi + 4G LTEPremium Alarm KitDahua ARC3800H Premium Wireless Alarm Kit
The Dahua ARC3800H Premium Wireless Alarm Kit is a step up from a basic starter bundle. It combines the ARC3800H hub with two PIR sensors, a PIR camera, two door/window contacts, two keyfobs and both indoor and outdoor sirens — a complete package for larger homes, retail stores, offices, warehouses and commercial sites. Communication runs over Ethernet, WiFi and 4G LTE, all managed in the DMSS app.
Connectivity
WiFi · LAN · 4G
Verification
PIR Camera
Sirens
Indoor + Outdoor
Encryption
AES128
Entry Sensors
2× Contacts
Expandable
150 Devices
Multi-Network Backup
WiFi, Ethernet and 4G LTE keep the alarm connected even if one connection path drops out.
PIR Camera Verification
The included PIR camera adds visual verification so you get more context when motion triggers an alarm.
Full Coverage Bundle
Two PIRs, two door/window contacts and dual sirens protect entry points, internal areas and the perimeter.
Expandable Platform
The ARC3800H hub supports up to 150 wireless peripherals so you can grow the system over time.
What’s Included
1× Alarm Hub
Dahua ARC3800H
2× Wireless PIR Sensor
ARD1233-W2
1× PIR Camera Sensor
ARD1731-W2
2× Door / Window Contact
ARD324-W2
2× Remote Keyfob
DHI-ARA24-W2
1× Indoor Siren
ARA12-W2
1× Outdoor Siren
ARA13-W2
Specifications — ARC3800H Premium Kit
Main Hub
Dahua ARC3800H
System Type
Premium Wireless Alarm Kit
Network
Ethernet, WiFi and 4G LTE cellular backup
Wireless Communication
Two-way RF with frequency hopping
Encryption
AES128
Motion Detection
2× PIR sensors + 1× PIR camera
Entry Detection
2× door / window contacts
Control
2× wireless keyfobs + DMSS app
Sirens
1× indoor + 1× outdoor wireless siren
Expandable
Supports additional Dahua wireless accessories
Recommended Use
Larger homes, offices, retail, warehouses, commercial sites
Warranty (Australia)
3 years · CCTV Guru Australia
How is this different from a basic kit?It adds more sensors, a PIR camera for visual verification, two keyfobs and both indoor and outdoor sirens.
Does it support 4G LTE backup?Yes. The ARC3800H platform supports Ethernet, WiFi and cellular communication.
Can I add more accessories later?Yes — expand with compatible Dahua PIRs, door contacts, sirens, keypads, keyfobs and repeaters.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision 8MP 4K · AcuSense · DarkFighter · 60m IR
Hikvision DS-2CD2T86G2H-2I — 8MP 4K AcuSense Bullet Camera with DarkFighter Low-Light & 60m IR
The Hikvision DS-2CD2T86G2H-2I is a flagship 8 MP / 4K Ultra-HD bullet camera in the Hikvision Pro-Series, built for high-end Australian residential and commercial perimeters. A large 1/1.8" progressive-scan CMOS sensor with DarkFighter ultra-low-light technology delivers clean colour imaging down to 0.0008 lux, holding a higher shutter speed at night so you capture clear, identifiable faces instead of blurred silhouettes. Smart IR reaches up to 60 m for long-distance night coverage, AcuSense deep-learning classifies humans and vehicles to cut false alarms, and 120 dB true WDR handles high-contrast scenes. The rugged IP67 housing is available with a choice of 2.8 mm or 4 mm lens. Australian stock, 3-year Australian warranty.
Resolution
8 MP · 3840 × 2160 · 4K
Lens
2.8 mm or 4 mm Fixed
Low Light
DarkFighter · 0.0008 lux
IR Range
Smart IR up to 60 m
AI Engine
AcuSense · Human + Vehicle
Protection
IP67 · 120 dB WDR · 3-Year AU
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Pro-Grade 4K Perimeter Surveillance
DarkFighter Low-Light Imaging
DarkFighter ultra-low-light technology delivers clean colour down to 0.0008 lux and holds a higher shutter speed at night — so a moving subject is captured as a clear, identifiable face rather than a blurred silhouette.
60 m Smart IR Night Vision
Smart IR up to 60 m delivers long-distance night coverage, with intensity that adjusts automatically to avoid over-exposing close targets — ideal for driveways, perimeters and large yards.
AcuSense Human & Vehicle AI
AcuSense deep-learning classifies motion as a human or vehicle, dramatically reducing false alarms from animals, foliage and weather for smarter, more reliable alerts.
8 MP 4K Detail, IP67 Build
Crisp 8 MP / 4K imaging with 120 dB true WDR for high-contrast scenes, in a rugged IP67 housing built for exposed Australian outdoor sites. Choose 2.8 mm or 4 mm lens to match your scene.
Technical Specifications
DS-2CD2T86G2H-2I · Specifications
SKU
DS-2CD2T86G2H-2I (2.8 mm or 4 mm)
Camera Type
Hikvision Pro-Series AcuSense · 8 MP / 4K Fixed Bullet
Image Sensor
1/1.8" Progressive Scan CMOS · DarkFighter
Max Resolution
8 MP · 3840 × 2160
Min. Illumination
Colour 0.0008 lux @ F1.0 (AGC ON) · 0 lux with IR
Lens
2.8 mm (105° FOV) or 4 mm (90° FOV) fixed
IR Distance
Smart IR up to 60 m
Wide Dynamic Range
120 dB true WDR
AI / Smart Functions
AcuSense human + vehicle classification
Video Compression
H.265+ · H.265 · H.264+ · H.264
On-Board Storage
microSD / SDHC / SDXC up to 512 GB
Power Source
12 VDC · PoE
Weatherproof Rating
IP67
Warranty
3-Year Australian Warranty
Frequently Asked Questions
Does this camera record audio?No — the -2I model is a visual specialist with high-power 60 m IR and no built-in microphone. If you need audio, choose a Hikvision -IU variant instead.
What is the difference between 2.8 mm and 4 mm?The 2.8 mm lens gives a wider 105° field of view (best for yards and broad areas). The 4 mm lens is more zoomed in at 90° (best for gates and facial identification at a distance).
How do I power this camera?This is a PoE (Power over Ethernet) camera. Power it from a PoE NVR, a PoE switch, or a standard 12 VDC supply.
Is this a genuine Hikvision Australian model?Yes — all our Hikvision stock is genuine Australian stock, allowing official firmware updates and a full 3-year local warranty.
Downloads & Resources
DS-2CD2T86G2H-2I Datasheet
Hikvision Network Camera Quick Start Guide
Hikvision Network Camera User Manual
Order the Hikvision DS-2CD2T86G2H-2I from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision Pro-Series cameras. The DS-2CD2T86G2H-2I is a flagship 4K bullet for high-end residential and commercial perimeters where low-light face capture and long-range night vision matter. Order in 2.8 mm or 4 mm lens for fast Australia-wide dispatch, expert pre-sales advice and full local warranty support. Request a free quote or contact our Australian team.
Hikvision 8MP 4K · AcuSense · Smart Hybrid Light · Built-in Mic
Hikvision DS-2CD2086G2H-IU 8MP 4K AcuSense Mini Bullet Camera — Built-in Mic, Smart Hybrid Light, 30m IR
The Hikvision DS-2CD2086G2H-IU is a professional-grade 8 MP / 4K AcuSense mini bullet for both residential and commercial surveillance. Ultra-high-resolution 4K imaging combines with AcuSense deep-learning AI to dramatically reduce false alarms by focusing on humans and vehicles. The H series adds Smart Hybrid Light, blending IR and white light for clearer night images, and an F1.0 lens delivers strong low-light performance. A built-in microphone captures audio alongside video for added situational awareness, while the IP67 housing and up to 30 m IR suit exposed outdoor installs. Efficient H.265+ compression and simple PoE wiring round it out. Available in 2.8 mm and 4 mm lens. Australian stock, 3-Year Australian warranty.
Resolution
8 MP · 3840 × 2160 (4K)
AI Engine
AcuSense · Human + Vehicle
Supplement Light
Smart Hybrid Light · 30 m IR
Audio
Built-in Microphone
Compression
H.265+ · H.264+
Protection
IP67 · PoE · 3-Year AU
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Key Features
8 MP 4K Ultra HD
3840 × 2160 resolution captures fine detail — faces, plates and activity — with far more clarity than 1080p or 4 MP cameras.
AcuSense Human / Vehicle AI
Deep-learning classification focuses on people and vehicles, filtering out leaves, animals and rain to slash false alarms.
Smart Hybrid Light
Blends infrared and white light for clearer night images, with up to 30 m of IR reach for full darkness.
Built-in Microphone
Captures audio alongside video for added situational awareness at entrances and key areas.
Why Choose the DS-2CD2086G2H-IU
Smart Event Alerts
Line crossing, intrusion and region entrance/exit detection can trigger alarms on human or vehicle targets specifically.
Efficient H.265+ Storage
Advanced compression dramatically reduces storage and bandwidth without losing 4K image quality.
Compact & Weatherproof
The small IP67 mini-bullet body is discreet yet rugged — ideal for eaves, walls and tight outdoor mounting points.
Simple PoE Install
Single-cable PoE power and data, plus 12 V DC support, for flexible setup.
Recommended For
Homes & Driveways
Detailed 4K coverage with AcuSense filtering for residential perimeters.
Entrances
Built-in audio and 4K detail at doorways and gates.
Warehouses & Retail
High-resolution monitoring for commercial sites.
Small Business
Affordable 4K AI camera for offices and workshops.
Technical Specifications
DS-2CD2086G2H-IU · Full Specifications
SKU
DS-2CD2086G2H-IU
Camera Type
Hikvision 8 MP AcuSense Smart Hybrid Light Fixed Mini Bullet Network Camera
Max Resolution
3840 × 2160 (8 MP / 4K)
Lens Options
2.8 mm · 4 mm fixed
Min. Illumination
Colour 0.0008 lux @ F1.0 (AGC ON) · 0 lux with IR
Supplement Light
Smart Hybrid Light — IR + white light · up to 30 m IR
AI Engine
AcuSense — human + vehicle classification
Smart Events
Line crossing · intrusion · region entrance / exit
Audio
Built-in microphone
Video Compression
H.265+ / H.265 / H.264+ / H.264
On-Board Storage
microSD card slot
Power
PoE 802.3af (Class 3) · 12 VDC
Weatherproof Rating
IP67
Warranty
3-Year Australian Warranty
Frequently Asked Questions
Is this camera suitable for outdoor use?Yes — it carries an IP67 weatherproof rating for exposed outdoor installation.
Does it record audio?Yes — it includes a built-in microphone that captures audio alongside video.
What lens options are available?The DS-2CD2086G2H-IU comes in 2.8 mm and 4 mm fixed-lens versions for different fields of view.
Does it work with Hik-Connect?Yes — you can view and manage it via the Hik-Connect app and pair it with Hikvision PoE NVRs.
Downloads & Resources
DS-2CD2086G2H-IU Datasheet
Hikvision Network Camera Quick Start Guide
Hikvision Network Camera User Manual
CCTV Guru is an authorised Australian reseller of Hikvision AcuSense cameras. Order the DS-2CD2086G2H-IU 8 MP / 4K mini bullet in 2.8 mm or 4 mm for fast Australia-wide dispatch, expert pre-sales advice and full local warranty support. Request a free quote or contact our Australian team.
4-Wire Hybrid Kit · Wi-Fi Monitor · DMSS App Control
Dahua DHI-KTH01M 4-Wire Hybrid Video Intercom Kit with Wi-Fi Indoor Monitor
The Dahua DHI-KTH01M is a smart hybrid video intercom kit designed for Australian homes, villas, apartments, offices and small commercial buildings. It combines a modern 7-inch touchscreen indoor monitor with a durable outdoor door station, delivering visitor video, two-way audio, remote door release and mobile app control in one complete package.
Unlike traditional analogue intercom systems, the KTH01M bridges both 4-wire analogue installations and modern IP-based functionality. The system supports Wi-Fi connectivity, DMSS mobile app integration, PoE networking, alarm integration and IP camera monitoring, making it an excellent upgrade path for older intercom systems without requiring a complete site rewire.
Model
DHI-KTH01M
Monitor
7" Touchscreen
Connectivity
Wi-Fi · PoE
App
DMSS Mobile
Outdoor Station
IP66 Rated
System
Hybrid 4-Wire
Genuine Dahua
Australian Stock
Local Tech Support
What’s Included in the Kit
1 × DHI-VTH2624GW-WP Indoor Monitor7-inch TFT capacitive touchscreen indoor monitor with Wi-Fi, PoE support, alarm integration, SD card support and DMSS app connectivity.
1 × DHI-VTO1000JM Outdoor StationDurable outdoor video door station with mechanical call button, visitor calling, two-way audio and remote door release support.
Mounting AccessoriesIncludes Dahua-supplied mounting accessories for a clean residential or small commercial installation.
DMSS App SupportAnswer calls, view visitors and unlock the door remotely from your smartphone using the Dahua DMSS app.
Why Choose the Dahua DHI-KTH01M?
Upgrade Older 4-Wire IntercomsIdeal for replacing older analogue intercom systems while adding modern app control, video calling and IP functionality.
7-Inch Touchscreen MonitorThe indoor monitor provides a clear touchscreen interface for answering calls, viewing visitors and unlocking the door.
Remote Unlock with DMSSReceive visitor calls and unlock the door from your phone when configured with the DMSS app and compatible network setup.
Wi-Fi and PoE FlexibilityThe indoor monitor supports Wi-Fi and PoE, giving installers more flexibility across retrofit and new-build applications.
IP Camera MonitoringMonitor compatible Dahua IP cameras from the indoor station for a more complete front-door security experience.
Weather-Resistant Outdoor StationThe outdoor station is designed for Australian entry points with IP66 protection for outdoor use.
Recommended For
Homes & VillasAnswer the front door from the indoor monitor or smartphone, with remote unlock support for visitors and deliveries.
Apartment UpgradesA strong option for selected apartment or unit applications where existing 4-wire cabling can be reused.
Small OfficesControl visitor access at the front entrance and allow staff to answer calls from the monitor or mobile app.
Clinics & Reception AreasManage visitor entry without leaving reception, consultation rooms or staff areas.
Retail & Back EntrancesSecure rear doors, staff entries and delivery points with video calling and controlled release.
Retrofit Intercom ProjectsPerfect when customers want a smarter system without starting again with a full IP intercom rewire.
Watch the Dahua Hybrid Intercom in Action
Dahua hybrid 4-wire video intercom demonstration showing the indoor monitor, outdoor station and smart intercom functionality.
Technical Specifications
Indoor Monitor — DHI-VTH2624GW-WP
Display
7-inch TFT capacitive touchscreen
Resolution
1024 × 600
Network
1 × RJ-45 10/100 Mbps
Wi-Fi
Supported
PoE
Standard PoE supported
Alarm Input
6 channels
Alarm Output
1 channel
SD Card
Up to 64 GB
Mobile App
DMSS
IP Camera Monitoring
Supported
Outdoor Station — DHI-VTO1000JM
Product Type
4-wire outdoor video door station
Call Button
Mechanical button
Video Compression
H.264
Door Release
Supported with compatible lock hardware
Weather Protection
IP66
Application
Villa, home, office and small commercial entry points
Installation Notes
Check Existing 4-Wire CablingFor retrofit jobs, confirm cable condition, cable path and compatibility before replacing an older intercom system.
Plan Door Lock HardwareElectric strikes, magnetic locks, exit buttons and power supplies are normally selected separately based on the door type.
Network Setup Required for App UseDMSS mobile app features require correct network configuration and internet access.
Professional Installation RecommendedFor best results, use a qualified security or intercom installer, especially when door release hardware is required.
Downloads & Resources
Download the Dahua datasheet or contact CCTV Guru for help selecting compatible locks, exit buttons, power supplies and installation accessories.
Download Datasheet
Dahua Intercom Quick Start Guide
Dahua Intercom User Manual
Frequently Asked Questions
Can the Dahua DHI-KTH01M replace an old 4-wire intercom?Yes, it is designed as a hybrid 4-wire kit and is a strong option for upgrading many older intercom systems, subject to cabling and site compatibility.
Does it work with the DMSS app?Yes. The system supports Dahua DMSS app connectivity for mobile viewing, call answering and remote unlock where configured correctly.
Can I unlock the door remotely?Yes, remote unlock is supported when connected to compatible electric strike or magnetic lock hardware and configured correctly.
Does the indoor monitor connect by Wi-Fi?Yes. The DHI-VTH2624GW-WP indoor monitor supports Wi-Fi connectivity.
Is the outdoor station weatherproof?Yes. The outdoor station is IP66 rated for outdoor use.
Can I view Dahua IP cameras on the monitor?Yes. The system supports compatible IP camera monitoring through the indoor monitor.
Does the kit include a door lock?No. Electric strikes, magnetic locks, exit buttons and power supplies are selected separately based on your door and installation requirements.
Does it support PoE?Yes. The indoor monitor supports standard PoE for cleaner installation options.
Is this suitable for apartments?Yes, it can suit selected apartment, villa and unit applications, depending on the existing wiring and installation design.
Do you ship Australia-wide?Yes. CCTV Guru ships genuine Dahua intercom products Australia-wide with local support.
Order the Dahua DHI-KTH01M from CCTV Guru
Order the Dahua DHI-KTH01M 4-Wire Hybrid Video Intercom Kit from CCTV Guru for genuine Dahua hardware, fast Australia-wide dispatch and local advice on compatible electric strikes, magnetic locks, exit buttons, power supplies and installation accessories.
Hikvision · 2 Live-Guard + 2 Audio Turrets + 2 Mini-Domes · 16CH 8K NVR
6 × 8MP Business Kit
Hikvision 8MP AcuSense Business Kit — 2 Live-Guard + 2 Audio Turrets + 2 IK08 Mini-Domes with 16-Channel 8K NVR
The Hikvision 8MP AcuSense Business Kit is a ready-to-grow bundle built for Australian offices, retail, warehouses and multi-tenant sites. It pairs two DS-2CD2386G2H-IS2U/SL AcuSense Live-Guard turrets for active deterrence on your perimeter, two DS-2CD2386G2H-IU AcuSense DarkFighter audio turrets for detailed coverage, and two DS-2CD2586G2-IS IK08 vandal-resistant mini-domes for discreet indoor and entry monitoring — all running on a DS-7616NI-M2/16P 16-channel 8K M-Series NVR. The 16-port recorder powers all six cameras over a single Cat6 cable each and leaves ten spare channels to expand as the business grows.
Cameras
6 × 8MP 4K
Active Deterrence
2 × Live-Guard Strobe+Siren
Recorder
16CH 8K NVR · 16 PoE
Low-Light
DarkFighter · 0.0008 lux
Smart AI
AcuSense Human/Vehicle
Room to Grow
10 Spare Channels
Three-Tier Coverage
Live-Guard turrets actively deter intruders on the perimeter, DarkFighter audio turrets capture detailed 4K with sound, and discreet IK08 mini-domes cover entries and interiors — deterrence, evidence and discretion in one kit.
Active Deterrence Built In
The two Live-Guard turrets flash a white strobe, sound a siren and let you talk down via Hik-Connect the moment AcuSense detects a person or vehicle — turning intruders away instead of just recording them.
16 PoE Ports — Plug & Play
One Cat6 cable per camera carries power and video to the NVR's 16 built-in PoE ports — no separate power supplies, with ten spare channels to grow.
Built to Expand
Starting on a 16-channel 8K NVR means you never replace the recorder later — add up to ten more Hikvision cameras as the business grows, with up to 32 TB of storage across dual SATA bays.
What's Included
2 × Deterrence Turrets
DS-2CD2386G2H-IS2U/SL — 8MP 4K AcuSense Live-Guard turret with white strobe, siren and two-way audio, Smart Hybrid Light, DarkFighter low-light colour, IP67.
2 × Audio Turrets
DS-2CD2386G2H-IU — 8MP 4K AcuSense powered-by-DarkFighter turret, 120 dB WDR, built-in microphone, 1/1.8" sensor, IP67.
2 × Mini-Domes
DS-2CD2586G2-IS — 8MP 4K AcuSense DarkFighter mini-dome, 120 dB WDR, built-in mic, IR up to 30 m, IP67 + IK08 vandal-resistant, low-profile for offices and retail.
1 × Recorder
DS-7616NI-M2/16P — 16-channel 8K M-Series NVR with 16 built-in PoE ports, up to 32 MP per channel, dual SATA bays, 8K HDMI output and Hik-Connect remote access.
Storage
Add a surveillance-grade HDD to suit your retention needs — dual SATA bays accept up to 16 TB per drive (32 TB total). Choose a surveillance HDD (Seagate SkyHawk or WD Purple) to record from day one.
Power
16 × PoE ports built into the NVR — one Cat6 network cable per camera carries power and data, so there are no separate power supplies. Network cabling is run on site and is not included; pre-made Cat6 patch leads are available separately.
Mounting
Brackets and templates included for turret eave/soffit installs and dome ceiling/wall mounting. For brick or flush-wall mounting, add a Hikvision wall-mount bracket per camera; junction boxes are available for tidy cable management.
Warranty
3-Year Australian warranty · local CCTV Guru tech support. Genuine Hikvision Australian stock.
Best For
Offices & reception
Discreet mini-domes over reception, corridors and meeting rooms, with deterrence turrets on external entries.
Retail & convenience
Mini-domes at the POS and aisles, audio turrets in 4K, with Live-Guard guarding the rear door after hours.
Warehouses & logistics
Loading docks, yard and aisles in 4K, with strobe-and-siren deterrence on roller doors and perimeters.
Multi-tenant & strata
Common areas, lifts and car-park entries, with ten spare channels to add cameras as the site grows.
Cafés & hospitality
Dining floor, register and kitchen pass with audio, plus deterrence on the rear lane and bins.
Medical & professional
Low-profile domes over waiting rooms and corridors with toggleable audio, deterrence turrets on entries.
Deterrence Turret — DS-2CD2386G2H-IS2U/SL
Camera Type
8MP 4K AcuSense Live-Guard Smart Hybrid Light Turret
Image Sensor
1/1.8" Progressive Scan CMOS · DarkFighter low-light
Max. Resolution
8MP · 3840 × 2160 @ 25 fps
Lens
Fixed 2.8 mm · 105° FOV (4 mm 90° available)
Active Deterrence
White-light strobe · audible siren · two-way audio (built-in mic & speaker)
Supplement Light
Smart Hybrid Light · IR + white light up to 30 m
AI
AcuSense human & vehicle classification · perimeter protection
Audio / Storage
Built-in mic & speaker · microSD up to 512 GB
Power / Protection
12 VDC / PoE (IEEE 802.3af) · IP67
Audio Turret — DS-2CD2386G2H-IU
Camera Type
8MP 4K AcuSense Powered-by-DarkFighter Turret
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
8MP · 3840 × 2160
Min. Illumination
Colour 0.0008 lux @ F1.0
Lens
Fixed 2.8 mm · 108° FOV (4 mm 88° available)
WDR / AI
120 dB · AcuSense human & vehicle classification
Audio / Storage
Built-in mic · microSD up to 512 GB
Power / Protection
12 VDC / PoE (IEEE 802.3af) · IP67
Mini-Dome — DS-2CD2586G2-IS
Camera Type
8MP 4K AcuSense Powered-by-DarkFighter Mini-Dome
Max. Resolution
8MP · 3840 × 2160
Lens
Fixed 2.8 mm
Night Vision
IR up to 30 m
WDR / AI
120 dB · AcuSense human & vehicle classification
Audio
Built-in microphone (toggleable) · audio & alarm interface
Compression
H.265+ / H.265 / H.264+ / H.264
Protection
IP67 weatherproof · IK08 vandal-resistant
Dimensions
Ø 113.6 mm × 72.6 mm · approx. 400 g
Recorder Specifications — DS-7616NI-M2/16P
Channels
16 IP channels · up to 32 MP input
Incoming Bandwidth
256 Mbps
PoE
16 × PoE ports (IEEE 802.3 af/at) · 200 W budget · up to 30 W/port
Storage
2 × SATA (up to 16 TB per bay, 32 TB total) · HDD not included
Video Output
1 × HDMI (up to 8K @ 30 Hz) + 1 × VGA · simultaneous
AI Functions
AcuSense human/vehicle · perimeter · facial (with compatible cameras)
Compression
H.265+ / H.265 / H.264+ / H.264
Remote / App
Hik-Connect (iOS & Android) · P2P · ONVIF
Installation Notes
›Camera placement: put the two Live-Guard turrets on the highest-risk approaches (entries, roller doors, rear lanes), the audio turrets on general 4K coverage, and the mini-domes indoors over reception, aisles and corridors.
›Cabling: run solid-copper Cat6 from each camera back to the NVR's PoE ports for stable power and video up to 100 m.
›Audio privacy: the audio turrets and mini-domes have built-in microphones — recording can be disabled per camera in the NVR menu (Video/Audio > Video Only) where audio capture is not permitted.
Setup & Demo Videos — Hikvision
AcuSense — human & vehicle detection
AcuSense NVR — smart false-alarm filtering
Downloads & Resources
DS-2CD2386G2H-IS2U/SL Datasheet
DS-2CD2386G2H-IU Datasheet
DS-2CD2586G2-IS Datasheet
DS-7616NI-M2/16P Datasheet
Hikvision Camera Quick Start Guide
Why a 16-channel NVR for six cameras?Starting on a 16-channel recorder means you never have to replace it later. Ten spare channels and PoE ports let you add cameras as the business grows, and the M-Series engine gives plenty of bandwidth for all six 4K cameras now.
What's the difference between the three camera types?The Live-Guard turrets add strobe, siren and two-way audio for active deterrence; the audio turrets are detail-focused DarkFighter cameras with a mic; the mini-domes are low-profile, IK08 vandal-resistant cameras ideal for indoor and entry coverage.
Are the mini-domes vandal-resistant?Yes — the DS-2CD2586G2-IS is rated IK08 against impact and tampering, plus IP67 for dust and water resistance, so it suits exposed entries and public-facing areas.
Can I turn off the strobe and siren?Yes. The Live-Guard deterrence can be scheduled to activate only after hours or disabled entirely from the Hik-Connect app or NVR menu.
Is a hard drive included?No — the NVR ships as a chassis with two empty SATA bays (up to 32 TB total). Add a surveillance-grade Seagate SkyHawk or WD Purple drive to record from day one.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision · 8MP 180° Panoramic + 8MP ColorVu 3.0 Live-Guard · 8CH or 16CH 8K NVR
8MP Zero Blind Spot Kit
Hikvision 8MP "Zero Blind Spot" Starter Kit — 180° Panoramic ColorVu + ColorVu 3.0 Live-Guard Turret with 8-Channel or 16-Channel 8K NVR
The Hikvision Zero Blind Spot Starter Kit pairs two of Hikvision's most capable visual technologies for Australian homes, retail, offices and warehouses. It combines one DS-2CD2387G2P-LSU/SL 8MP panoramic ColorVu turret — a dual-lens camera that stitches a seamless 180° wide-area view and replaces two standard cameras — with one DS-2CD2387G3-LIS2UY/SL 8MP 4K ColorVu 3.0 Smart Hybrid Light Live-Guard turret for pinpoint detail and active deterrence. Both cameras run on a single Cat6 cable to the recorder's built-in PoE ports. Choose the 8-channel DS-7608NI-M2/8P or 16-channel DS-7616NI-M2/16P 8K M-Series NVR depending on how far you plan to expand — both leave plenty of free channels and PoE ports to grow.
Panoramic
180° Seamless View
Cameras
2 × 8MP 4K
Active Deterrence
Strobe + Siren
Colour Night
ColorVu · 0.0005 lux
Smart AI
Human/Vehicle
Recorder
8CH or 16CH 8K NVR
Zero Blind Spots
The 180° panoramic turret stitches a flat, wall-to-wall widescreen image — no fish-eye distortion — so a wide driveway or frontage is covered by one camera instead of two, while the ColorVu 3.0 turret locks in detail on a side gate or approach.
True 24/7 Colour
Both cameras are ColorVu — the panoramic sees full colour down to 0.0005 lux at F1.0, and the G3 turret adds Smart Hybrid Light (IR or white) with the same 0.0005 lux colour sensitivity. Clothing and plate colour at night, not grey IR.
Active Deterrence Built In
Both cameras carry a white strobe and built-in speaker. The G3 Live-Guard turret adds two-way audio so you can talk an intruder down from your phone via Hik-Connect — prevention, not just evidence.
Plug & Play PoE — Room to Grow
One Cat6 cable per camera carries power and video to the NVR's built-in PoE ports. The 8CH NVR leaves six free channels; the 16CH leaves fourteen — add Hikvision cameras later with no extra hardware.
What's Included
1 × Panoramic Camera
DS-2CD2387G2P-LSU/SL — 8MP dual-lens panoramic ColorVu turret, seamless 180° ±10° horizontal view, 24/7 full colour, 130 dB WDR, human & vehicle detection, active strobe + audio alarm, IP67.
1 × Detail Camera
DS-2CD2387G3-LIS2UY/SL — 8MP 4K ColorVu 3.0 Smart Hybrid Light Live-Guard turret, white strobe + 110 dB speaker + two-way audio, F1.0 24/7 colour, AcuSense, IP67 + NEMA 4X.
1 × Recorder (variant-dependent)
The recorder depends on the variant you choose: the 8-Channel kit ships with the DS-7608NI-M2/8P (8 built-in PoE ports), and the 16-Channel kit ships with the DS-7616NI-M2/16P (16 built-in PoE ports). Both are 8K M-Series NVRs with dual SATA bays, up to 32 MP per channel, 8K HDMI output and Hik-Connect remote access.
Storage
HDD is not included by default so you can size retention to your needs — add a surveillance-grade drive (2 TB–14 TB). For 4K recording we recommend 4 TB or larger; the dual SATA bays accept up to 16 TB per bay (32 TB total).
Power
PoE ports built into the NVR — one Cat6 network cable per camera carries power and data, so there are no separate power supplies. Network cabling is run on site and is not included; pre-made Cat6 patch leads are available separately.
Mounting
Brackets and templates included for eave/soffit installs. For brick or flush-wall mounting, add a Hikvision wall-mount bracket per camera; a junction box is also available for tidy cable management.
Warranty
3-Year Australian warranty · local CCTV Guru tech support. Genuine Hikvision Australian stock.
Best For
Wide driveways & frontages
One 180° panoramic camera covers wall-to-wall with no blind spots — perfect for a wide front-of-house.
Family homes & estates
Panoramic on the driveway, ColorVu 3.0 Live-Guard on the side gate with talk-down deterrence.
Retail & shopfronts
Wide shopfront overview plus a detail camera at the entrance or POS, with deterrence after hours.
Warehouses & loading docks
Panoramic across the yard or loading bay, detail camera on the roller door or pedestrian gate.
Cafés & restaurants
Wide dining-floor coverage plus a register or rear-lane detail camera with two-way audio.
Expandable systems
Start with two cameras, then scale to 8 or 16 channels as your coverage needs grow.
Panoramic Camera — DS-2CD2387G2P-LSU/SL
Camera Type
8MP Dual-Lens Panoramic ColorVu AcuSense Turret · Active Deterrence
Image Sensor
2 × 1/1.8" Progressive Scan CMOS · ColorVu
Max. Resolution
8MP combined · 5120 × 1440 stitched panoramic
Field of View
Horizontal 180° ±10° · Vertical 44° (seamless stitch, no fish-eye)
Min. Illumination
Colour 0.0005 lux @ F1.0 · 0 lux with white light
Lens
Fixed dual lens · 4 mm · up to 30 m white light
Active Deterrence
White-light strobe · built-in speaker · audio alarm
WDR / AI
130 dB · human & vehicle detection · perimeter (line crossing/intrusion)
Audio / Storage
Built-in mic & speaker · microSD up to 512 GB
Power / Protection
12 VDC / PoE (802.3af) · IP67
Detail Camera — DS-2CD2387G3-LIS2UY/SL
Camera Type
8MP 4K ColorVu 3.0 Smart Hybrid Light AcuSense Live-Guard Turret
Image Sensor
1/1.8" Progressive Scan CMOS · ColorVu 3.0 · HikAI-ISP
Max. Resolution
8MP · 3840 × 2160 (4K UHD)
Min. Illumination
Colour 0.0005 lux @ F1.0 · 0 lux with white light
Lens
Fixed 2.8 mm (108.8° FOV) or 4 mm (93.3° FOV) · F1.0
Supplement Light
Smart Hybrid Light (white + IR) · up to 30 m · 3 modes
Active Deterrence
White strobe · 110 dB speaker · two-way audio (talk-down via Hik-Connect)
WDR / AI
130 dB · AcuSense human & vehicle · perimeter
Power / Protection
12 VDC / PoE (802.3at) · IP67 · NEMA 4X
Recorder Specifications — DS-7608NI-M2/8P (8CH) & DS-7616NI-M2/16P (16CH)
Channels
8CH variant: 8 IP channels · 16CH variant: 16 IP channels · up to 32 MP input per channel
Incoming Bandwidth
8CH: 80 Mbps · 16CH: 160 Mbps
PoE
8CH: 8 × PoE ports · 16CH: 16 × PoE ports (IEEE 802.3 af/at)
Storage
2 × SATA (up to 16 TB per bay, 32 TB total) · HDD sold separately
Video Output
1 × HDMI (up to 8K) + 1 × VGA · simultaneous
AI Functions
AcuSense human/vehicle · perimeter · facial (with compatible cameras)
Compression
H.265+ / H.265 / H.264+ / H.264
Remote / App
Hik-Connect (iOS & Android) · P2P · ONVIF
Installation Notes
›Camera placement: mount the 180° panoramic turret on a wide driveway, frontage or yard where one camera replaces two, and the ColorVu 3.0 Live-Guard turret on a side gate, porch or approach where deterrence and face/plate detail matter.
›Cabling: run solid-copper Cat6 from each camera back to the NVR's PoE ports for stable power and video over long distances.
›Add a hard drive: the NVR ships without an HDD — fit a surveillance-grade drive in either SATA bay before first use so the system can record from day one.
Setup & Demo Videos — Hikvision
Smart Hybrid Light + ColorVu — 24/7 colour imaging
AcuSense — human & vehicle detection
Downloads & Resources
DS-2CD2387G2P-LSU/SL Datasheet
DS-2CD2387G3-LIS2UY/SL Datasheet
DS-7608NI-M2/8P Datasheet
DS-7616NI-M2/16P Datasheet
Hikvision Camera Quick Start Guide
Does the 180° image look like a fish-eye?No. The panoramic camera uses two lenses and internal stitching to create a flat, widescreen 180° image without the distortion of a single fish-eye lens.
What's the difference between the two cameras?The DS-2CD2387G2P-LSU/SL is a 180° panoramic camera for wide-area, no-blind-spot coverage; the DS-2CD2387G3-LIS2UY/SL is a 4K ColorVu 3.0 Live-Guard turret for pinpoint detail and two-way-audio deterrence on a focused approach.
Do I need to buy a hard drive?Yes. The NVR ships without an HDD so you can size storage to your retention needs. Add a surveillance-grade drive (2 TB–14 TB); for 4K we recommend 4 TB or larger.
What's the difference between the 8CH and 16CH variants?The 8-Channel kit uses the DS-7608NI-M2/8P (8 PoE ports, 80 Mbps); the 16-Channel kit uses the DS-7616NI-M2/16P (16 PoE ports, 160 Mbps). Choose 16CH if you plan to add many more cameras later.
How are the cameras powered?Each camera runs on a single Cat6 cable to one of the NVR's built-in PoE ports — no separate power supplies. Cat6 cabling is run on site and not included.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision AX PRO
AX PRO 96-Zone Wireless Alarm Kit — Hub, Keypad, 2 PIRs, Reed & Sirens
This premium custom Hikvision AX PRO wireless alarm kit is built for homes, offices and retail spaces that want more than a basic hub-only bundle. It pairs the powerful 96-zone DS-PWA96-M-WB hub with a keypad, two PIR detectors, a magnetic reed switch and both indoor and outdoor sirens for a complete, expandable wireless intrusion solution.
Running on 433MHz AX PRO wireless with AES-128 encryption, the system is fully managed through the Hik-Connect app and ready to grow with extra sensors, sirens or tags whenever you need them.
96 ZonesExpandable hub for homes and businesses
Keypad ControlWall-mounted arm/disarm at the entry
Indoor + Outdoor SirensStrong audible deterrence inside and out
App ManagedHik-Connect with AES-128 encryption
What's Included
1 × DS-PWA96-M-WB
AX PRO wireless control panel (up to 96 zones)
1 × DS-PK1-E-WB
Wireless LED keypad
2 × DS-PDP15P-EG2-WB
Wireless PIR detectors with pet immunity
1 × DS-PDMC-EG2-WB
Wireless magnetic reed switch
1 × DS-PS1-I-WB
Wireless internal siren
1 × DS-PS1-E-WB
Wireless outdoor siren
Platform Specifications
Hub Model
DS-PWA96-M-WB
Wireless Zones / Outputs
Up to 96
Keyfobs
Up to 48
Repeaters
Up to 4
Sounders
Up to 6
Keypads / Tag Readers
Up to 8
Connectivity
TCP/IP, Wi-Fi, optional 3/4G
Management
Hik-Connect, Hik-ProConnect, Web Client
What makes this kit different?It goes beyond a hub-only bundle by adding a keypad, two PIRs, a reed switch and both indoor and outdoor sirens for a ready-to-run system.
Is it expandable?Yes. The 96-zone AX PRO hub accepts extra PIRs, contacts, sirens, keyfobs, tags and more as your needs grow.
How is it controlled?Via the included wireless keypad and the Hik-Connect app for remote arm/disarm and notifications.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
This custom Hikvision AX PRO wireless alarm kit gives you a complete, expandable security system out of the box, backed by a 3-Year Australian warranty and local support.
2.4GHz Outdoor PTP Wireless Bridge KitDS-3WF1000-EI-2N — 2.4GHz Plug-and-Play Wireless Bridge Pair
The Hikvision DS-3WF1000-EI-2N is a 2.4GHz outdoor wireless bridge kit supplied as a pre-paired pair of two units for instant point-to-point (PTP) CCTV links. With 300 Mbps wireless speed and a transmission distance of up to 1km over clear line-of-sight, it connects cameras and recorders across sites without running cable.
A built-in 7dBi 2×2 MIMO antenna delivers reliable performance for IP camera, NVR, and network-extension links, while the plug-and-play, pre-paired design means there is no console setup — simply mount, power, and align.
Band
2.4GHz
Speed
300 Mbps
Range
Up to 1km LoS
Antenna
7dBi 2×2 MIMO
Setup
Pre-Paired Plug & Play
Use
Outdoor PTP
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Key Features
Pre-Paired Plug & Play
Both units ship pre-paired — mount, power, and align for an instant point-to-point link with no console configuration.
300 Mbps over 1km
Reliable 2.4GHz throughput carries IP camera footage across sites up to 1km apart on clear line-of-sight.
7dBi 2×2 MIMO Antenna
Built-in directional MIMO antenna delivers stable signal and consistent throughput across the link.
Outdoor PTP Design
Purpose-built for outdoor point-to-point use, extending CCTV and network connectivity between buildings.
Best Uses
Building to Building
Link a second building, shed, or gate back to the main NVR without trenching cable across the gap.
Farm & Rural
Extend camera coverage to outbuildings and entry points where running copper is impractical.
Warehouse & Yard
Connect cameras across a yard or compound to the recorder with a single wireless hop.
Network Extension
Bridge a network connection to a remote location for IP cameras, NVRs, or general connectivity.
What's in the Box
2× Bridge Units
A pre-paired pair of DS-3WF1000-EI-2N bridges, ready to deploy as the two ends of your link.
Mounting Accessories
Included mounting hardware for installing and aligning each unit on-site.
Documentation
Quick reference documentation to guide installation and alignment.
Pre-Paired Link
Units arrive paired from the factory, so the link is established as soon as both ends are powered.
Technical Specifications
DS-3WF1000-EI-2N · Full Specifications
Product Type
2.4GHz outdoor wireless bridge kit (pre-paired pair of 2)
Wireless Frequency
2.4GHz
Wireless Speed
300 Mbps
Transmission Distance
Up to 1km (clear line-of-sight)
Antenna
Built-in 7dBi 2×2 MIMO
Application
Point-to-point CCTV / IP camera / NVR / network extension
Installation
Plug-and-play, pre-paired
Environment
Outdoor use
In Box
2× bridge units, mounting accessories, documentation
Warranty
3-Year AU Warranty
Downloads & Resources
Datasheet
Frequently Asked Questions
Does it come as a pair?Yes. The DS-3WF1000-EI-2N ships as a pre-paired pair of two units — one for each end of the link — ready to deploy out of the box.
How far will it transmit?Up to 1km over clear line-of-sight. Obstructions such as trees, buildings, or hills will reduce effective range.
What can I connect to it?It creates a point-to-point link for IP cameras, NVRs, and general network extension between two locations.
Do I need to configure it?No. The pair is pre-paired and plug-and-play — mount, power, and align both ends and the link comes up automatically.
Can it be used outdoors?Yes. The kit is designed for outdoor point-to-point installation between buildings and sites.
What warranty applies?This kit is covered by a 3-Year AU Warranty with local tech support from CCTV Guru.
Order the DS-3WF1000-EI-2N from CCTV Guru
Extend your network without trenching cable. Order the Hikvision DS-3WF1000-EI-2N 2.4GHz Wireless Bridge Kit today and enjoy fast AU-wide shipping, a 3-Year AU Warranty, and expert local support from the CCTV Guru team.
Hikvision CAT6 · 305m Cable + 100 RJ45 Plugs
CG-DS-CCB — Hikvision CAT6 305m Cable (Blue) + 100-Pack 30µ Gold RJ45 Plugs Bundle
A matched, single-brand infrastructure kit that pairs Hikvision's 305 m CAT6 UTP cable (DS-1LN6UZC0, Blue) with a 100-pack of 30µ gold-plated RJ45 plugs (DS-1M6UA-30U-100). Sticking to one Hikvision path guarantees correct physical sizing and certified channel performance for high-bitrate IP CCTV networks.
The solid bare copper cable is channel-tested to 100 m under 57 V / 1 A PoE load, while the thick 30-micron gold contacts resist corrosion and insertion wear for stable field connections.
Matched Single-Brand PathHikvision cable + plugs for guaranteed fit and certified performance.
PoE-Optimised CableDS-1LN6UZC0 solid bare copper, channel-tested under PoE load.
30µ Gold Plugs100 connectors with heavy gold plating for durable, low-loss terminations.
Standards CompliantANSI/TIA-568.2-D and ISO/IEC11801; UL94V-2 plug housing.
What's Included
Cable
1 × Hikvision DS-1LN6UZC0 305 m CAT6 UTP (Blue), solid bare copper 0.5 mm
Connectors
1 × Hikvision DS-1M6UA-30U-100, 100-pack unshielded RJ45 (30µ gold)
Transmission
Gigabit Ethernet ready (1000Base-T)
Standards
ANSI/TIA-568.2-D, ISO/IEC11801, RoHS 2.0
Cable Datasheet (PDF)
Is the cable real copper or CCA?It is 100% solid bare copper — safe and certified for PoE and PoE+ runs, unlike cheaper copper-clad aluminium.
Are the plugs pass-through?No. The DS-1M6UA-30U-100 plugs are standard non-pass-through, unshielded 8P8C connectors sized for the cable's 0.5 mm cores.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
A complete single-brand Hikvision cabling kit — 305 m of PoE-ready CAT6 plus 100 gold RJ45 plugs to terminate the whole run.
Hikvision CAT6 RJ45 · 30µ Gold · 100-Pack
DS-1M6UA-30U-100 — Hikvision CAT6 Unshielded RJ45 Plugs, 30µ Gold (100-Pack)
The Hikvision DS-1M6UA-30U-100 is a trade pack of unshielded CAT6 RJ45 (8P8C) male connectors for commercial networking and IP CCTV cabling. Premium 30-micron (30µ) gold-plated contacts deliver low contact resistance, resist corrosion and stand up to repeated insertions — ideal for heavy-duty professional terminations.
Sold exclusively as a 100-piece trade pack for consistent performance across large structured-cabling jobs.
30µ Gold PlatingThick 30-micron gold resists oxidation for ultra-low contact resistance.
Gigabit & PoE Ready8P8C across all conductors — rated for 1000Base-T, PoE and PoE+.
UL94V-2 HousingTransparent flame-retardant polycarbonate for durability and fire safety.
100-Pack Trade ValueBulk box for installers running large-scale deployments.
Technical Specifications
Model
DS-1M6UA-30U-100
Connector Type
CAT6 Unshielded RJ45 (8P8C)
Contact Plating
30 micro-inch (30µ) gold plated
Pack Quantity
100 plugs
Max Voltage
≤ 150 VAC
Max Current
1.5 A @ 25 °C
Housing
Polycarbonate, transparent, UL94V-2
Compliance
RoHS 2.0
Are these sold individually?No — this model ships only as a 100-piece trade pack for the best value on professional installs.
Do they suit shielded (STP) cable?No. These are unshielded (UTP) connectors. For shielded copper with a drain wire, choose a dedicated shielded RJ45 connector.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
A premium 100-pack of genuine Hikvision 30µ gold CAT6 RJ45 plugs — the reliable termination choice for Gigabit and PoE installs.
5GHz Outdoor PTP Wireless Bridge KitDS-3WF02-5AC/D — 5GHz Long-Range Wireless Bridge Pair
The Hikvision DS-3WF02-5AC/D is a 5GHz outdoor wireless bridge supplied as a pre-paired pair of two units for instant point-to-point (PTP) links. With up to 867 Mbps throughput and a transmission range of up to 5km over clear line-of-sight, it carries IP camera footage across sites without trenching cable.
Built on IEEE 802.11 a/n/ac across the 5.15–5.85 GHz band with 12 dBi internal directional antennas, the kit ships in an IP65 weatherproof housing with 6kV surge protection and runs comfortably in a -30°C to +70°C operating range.
Band
5GHz 802.11ac
Throughput
867 Mbps
Range
Up to 5km LoS
Protection
IP65 + 6kV Surge
Ports
2× Gigabit RJ45
Setup
One-Key Pairing
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Key Features
Pre-Paired PTP Pair
Both units ship paired out of the box — mount, power, and align for an instant point-to-point link with no console configuration.
867 Mbps over 5km
Carries multiple high-bitrate 4K camera streams across long clear-line-of-sight links on the uncongested 5GHz band.
Rugged Outdoor Build
IP65 weatherproof enclosure with 6kV surge protection and a wide -30°C to +70°C operating range for harsh AU sites.
Visual Signal Alignment
Built-in LED signal indicators and one-key pairing make antenna aiming and commissioning fast for a single installer.
Best Uses
Site-to-Site CCTV
Link a remote shed, gate, or second building back to the main NVR without trenching fibre or copper.
Rural & Farm
Span paddocks, driveways, and outbuildings where running cable is impractical or costly.
Construction & Temporary
Rapidly deploy a network link across a job site and relocate it as the project moves.
Multi-4K Camera Backhaul
Backhaul roughly 10–15 high-bitrate 4K cameras over a single wireless hop.
What's in the Box
2× Bridge Units
A pre-paired pair of DS-3WF02-5AC/D bridges ready to deploy as the two ends of your link.
Mounting Hardware
Pole and wall mounting accessories for aligning each unit on-site.
Gigabit Connectivity
Each unit provides 2× 10/100/1000M RJ45 gigabit ports for camera, NVR, or switch connection.
Passive PoE Power
Powered by 12V/1A passive PoE for simple single-cable installation.
Technical Specifications
DS-3WF02-5AC/D · Full Specifications
Product Type
5GHz outdoor wireless bridge, PTP kit (pre-paired pair of 2)
Standard
IEEE 802.11 a/n/ac
Operating Frequency
5.15–5.85 GHz
Antenna Gain
12 dBi internal directional
Max Throughput
867 Mbps
Transmission Range
Up to 5km (clear line-of-sight)
Network Ports
2× 10/100/1000M RJ45 gigabit
Protection
IP65 weatherproof, 6kV surge protection
Power
12V/1A passive PoE
Operating Temperature
-30°C to +70°C
Alignment
One-key pairing, visual LED signal indicators
Warranty
3-Year AU Warranty
Downloads & Resources
DatasheetQuick Start GuideUser Manual
Frequently Asked Questions
Does it come as a pair?Yes. The DS-3WF02-5AC/D ships as a pre-paired pair of two units — one for each end of the link — ready to deploy out of the box.
How far will it transmit?Up to 5km over clear line-of-sight. Obstructions such as trees, buildings, or hills will reduce effective range.
How many cameras can it carry?At 867 Mbps it comfortably backhauls roughly 10–15 high-bitrate 4K cameras over a single link.
How is it powered?Each unit uses 12V/1A passive PoE, allowing power and data over a single cable run to each end.
Is it weatherproof?Yes. The housing is rated IP65 with 6kV surge protection and operates from -30°C to +70°C for outdoor AU installations.
How hard is it to set up?One-key pairing and visual LED signal indicators make alignment and commissioning straightforward for a single installer.
What warranty applies?This kit is covered by a 3-Year AU Warranty with local tech support from CCTV Guru.
Order the DS-3WF02-5AC/D from CCTV Guru
Bridge your sites without trenching cable. Order the Hikvision DS-3WF02-5AC/D 5GHz Wireless Bridge Kit today and enjoy fast AU-wide shipping, a 3-Year AU Warranty, and expert local support from the CCTV Guru team.
Hikvision CAT6 · 305m Cable · Pass-Through Termination Kit
GR-DS-CCPB — Hikvision CAT6 305m Cable + Pass-Through Plugs & Crimp Tool Bundle
An installer-ready termination kit built around a full box of genuine Hikvision CAT6. It pairs 305 m of solid bare copper cable (DS-1LN6-UE-W, Blue) with a 100-pack of pass-through RJ45 plugs and a Neptune ratchet crimp tool — everything needed to terminate a full job in one purchase.
Pass-through plugs let you feed the conductors all the way through the connector so you can verify the colour code before crimping. The Neptune tool crimps and trims the excess in a single squeeze, cutting errors and material waste on every run.
Genuine Hikvision Cable305 m DS-1LN6-UE-W solid bare copper, Fluke-tested for PoE.
100 Pass-Through PlugsGold-plated pass-through RJ45 connectors for fast, accurate terminations.
Neptune Crimp ToolHeavy-duty ratchet tool crimps and trims excess wire in one action.
Verify Before You CrimpPass-through design lets you check the colour code before committing.
What's Included
Cable
1 × Hikvision DS-1LN6-UE-W 305 m CAT6 UTP (Blue), solid bare copper, Fluke-tested
Connectors
1 × 100-pack pass-through RJ45 plugs, gold-plated contacts
Tool
1 × Neptune RJ45 ratchet through-crimp tool (crimp + trim)
Why pass-through plugs?You feed each wire fully through the plug to confirm the colour order before crimping, then the tool trims the overhang — far fewer failed terminations.
Is the cable solid copper?Yes — the included Hikvision DS-1LN6-UE-W is solid bare copper, Fluke-tested and safe for PoE runs.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
A complete, time-saving CAT6 termination kit for IP CCTV and data installers — genuine Hikvision cable plus the plugs and tool to finish the job right.
Dahua · CAT6 Bundle · 305m Cable + 100 Plugs + Crimp Tool
CAT6 Bundle
Dahua Professional CAT6 Termination Bundle
Everything you need to wire a full CCTV or network job in one box. This Dahua-specific bundle pairs a 305m run of high-performance CAT6 cable with a pass-through RJ45 system for fast, error-free terminations and reliable Power over Ethernet.
The pass-through plugs let each wire feed completely through the connector so you can verify wire order before crimping, and the ratchet crimp tool trims the excess flush in one clean motion — for consistent terminations across every drop.
305m CAT6 Cable
DH-PFM920I-6UN-C blue, 99.97% oxygen-free copper, PoE-ready, 10-year cable warranty.
100 Pass-Through Plugs
DH-PFM976-631-PT, 15U" gold-plated trident brass, rated for 750 mating cycles.
Ratchet Crimp Tool
Heavy-duty through-type tool crimps and auto-trims excess wire in a single action.
Fewer Failed Drops
Pass-through design lets you confirm wire order before crimping for higher first-time success.
What's Included & Specifications
Cable
1x Dahua DH-PFM920I-6UN-C CAT6 UTP, 305m (Blue)
Conductor
99.97% Oxygen-Free Copper, PoE-ready
Connectors
100x Dahua DH-PFM976-631-PT pass-through RJ45
Plug Plating
15U" gold, trident brass, 750 mating cycles
Tool
1x RJ45 through-type ratchet crimp tool (crimp & trim)
Termination Standard
T568B pass-through
Warranty (Australia)
Cable 10 years; connectors & tool 12 months · CCTV Guru Australia
AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua TiOC PRO · WizColor · AcuPick · 1/1.8″ SensorTiOC PRO Camera
Dahua DH-IPC-HDW3649H-AS-PV-PRO-ANZ — 6MP TiOC PRO WizColor AcuPick Active Deterrence Turret
The Dahua DH-IPC-HDW3649H-AS-PV-PRO-ANZ is the PRO step-up of Dahua's 6MP TiOC line — same red/blue strobe, siren and voice deterrence chain as the standard 3649, but built around a much larger 1/1.8" CMOS sensor and an extraordinary F1.0 aperture. Translation: the PRO gathers more than 2.5× as much light as the standard 3649 and resolves usable colour down to 0.0005 lux — a 6× improvement that produces clean, low-noise colour footage on moonless suburban streets, in undercover carparks and across long dark driveways where the standard model would need to fall back to IR.
Combined with WizColor full-colour night vision, AcuPick attribute target search, SMD 4.0 false-alarm filtering, and Dahua's latest AI Coding (≥25% additional compression efficiency), the PRO is the camera to specify for premium residential frontages, commercial perimeters and any site where image quality at night is the deciding factor — without paying the 4K-storage premium of the 8MP PRO. Available in White (DH-IPC-HDW3649H-AS-PV-PRO-ANZ) and Black (DH-IPC-HDW3649H-AS-PV-PRO-ANZ-BLK). Australian stock with 3-year warranty.
Resolution & Sensor
6MP · 1/1.8″ CMOS
Aperture & FOV
F1.0 · 109° H · 2.8 mm
Low-Light
0.0005 Lux · WizColor
Active Deterrence
Strobe · Siren · Voice
Protection
IP67 · −40 °C to +60 °C
Power
PoE 802.3af · Max 10 W
3-Year Australian Warranty
Fast Australia-Wide Shipping
Australian Tech Support
Why Choose the Dahua DH-IPC-HDW3649H-AS-PV-PRO-ANZ in Australia
The PRO is for installers and customers who refuse to compromise on night-time image quality but don't need the 4K resolution of the 8MP PRO. A larger 1/1.8" sensor, an F1.0 aperture and Dahua's newest WizColor illumination together deliver clean colour at light levels where most cameras have long fallen back to grainy black-and-white. Combined with the full TiOC PRO active-deterrence chain and AcuPick AI, this is the camera Australian integrators reach for on premium homes, perimeters, commercial frontages and high-value loading docks — at a more accessible price point than the 8MP PRO sibling.
1/1.8″ Sensor — A Genuine Image-Quality Upgrade
The PRO swaps the standard 3649's 1/2.7" sensor for a much larger 1/1.8" CMOS. Bigger pixels mean more light per pixel, lower noise, higher dynamic range and noticeably better colour fidelity — especially in dawn, dusk and mixed-light conditions.
F1.0 Aperture — 2.5× More Light Than F1.6
Dahua's largest aperture in the WizSense 3-Series. F1.0 lets in more than 2.5× the light of the standard 3649's F1.6 lens — the single biggest factor in why this camera produces clean colour where others can't.
0.0005 Lux Colour · WizColor Full Colour
Minimum colour illumination drops to 0.0005 Lux (vs 0.003 Lux on the standard 3649) — a 6× improvement that produces usable full-colour footage on a moonless suburban street with nothing but distant streetlight. Even better low-light than the 8MP PRO thanks to larger per-pixel area.
TiOC PRO Active Deterrence — Strobe + Siren + Voice
Same proven TiOC 3.0 deterrence chain: red/blue strobe, on-board siren and custom voice broadcast fire the instant SMD 4.0 confirms a human or vehicle — no operator, no extra hardware required.
AcuPick AI Target Search
AcuPick attribute search runs with a 5-Series NVR — clothing colour, vehicle type, direction — locate any face or plate across a week of footage in seconds rather than hours.
AI Coding — 25%+ Less Storage
Dahua's AI Coding analyses the scene and dedicates bitrate only to objects of interest (people, vehicles) — delivering ≥25% additional compression efficiency over standard Smart H.265+. Longer retention on the same NVR drive.
Smart Features for Real-World Australian Sites
Dahua TiOC PRO Highlight — WizColor · AcuPick · SMD 4.0 (English)
IVS Tripwire & Intrusion Zones
Define a virtual line across the driveway or a no-go zone around the shed — get a notification (and trigger the deterrence chain) only when a human or vehicle actually crosses it.
Two-Way Audio & Custom Voice
Dual built-in microphones and an on-board speaker support live two-way talk via DMSS or a Dahua NVR. Pre-loaded plus uploadable voice files let you record a site-specific warning in your own voice.
Edge Recording — MicroSD up to 512 GB
On-camera MicroSD records days of 6MP footage independently of the NVR — a critical redundancy layer if the network drops, the recorder is stolen or power is cut.
Lens Distortion Correction (LDC)
The PRO adds on-camera LDC — automatic correction of the slight barrel distortion natural to wide-angle 2.8 mm lenses. Straight walls stay straight on playback, especially important for evidential footage.
Cyber-Hardened by Design
Trusted boot, HTTPS, 802.1x, IP/MAC filtering, X.509 certificate import and syslog — the same enterprise hardening Dahua deploys on government and critical-infrastructure cameras.
Plug & Play + Third-Party VMS
Drops into any Dahua NVR via plug-and-play, and works over ONVIF Profile S/G/T with Milestone, Genetec, Hanwha WAVE, ExacqVision, Blue Iris and Synology Surveillance Station.
Pair with a Dahua 5-Series NVR for the Full AcuPick Experience
SMD 4.0, IVS rules, two-way audio and the full TiOC PRO deterrence chain all run on-camera — they work with any Dahua AI NVR, or even an ONVIF third-party recorder. But to unlock AcuPick — attribute-based human and vehicle target search, similar-image cross-camera tracking and AI-accelerated playback — you need a compatible Dahua 5-Series AcuPick NVR. For any new installation we strongly recommend pairing the 3649H-AS-PV-PRO-ANZ with one of the recorders below.
DHI-NVR5208-8P-AI/ANZ — 8 Channel · 8 PoE
Compact 1U 5-Series AcuPick NVR with 8 built-in PoE ports — ideal for a single-home or small-business install with 4–8 TiOC PRO cameras. Full AcuPick target search and AI playback. View NVR5208-8P →
DHI-NVR5216-16P-AI/ANZ — 16 Channel · 16 PoE
16-channel 5-Series AcuPick NVR with 16 PoE ports and dual-HDD bays — the sweet-spot recorder for most residential and SMB Dahua TiOC fleets. Plug-and-play with the 3649H PRO. View NVR5216-16P →
DHI-NVR5432-16P-AI/ANZ — 32 Channel · 16 PoE
32-channel 1.5U AcuPick NVR with 16 PoE and 4 HDD bays — the standard choice for medium commercial sites, retail chains and multi-building campuses. View NVR5432-16P →
DHI-NVR5432-AI/ANZ — 32 Channel · No PoE
32-channel AcuPick NVR without built-in PoE — for sites running a separate managed PoE switch (preferred in larger commercial deployments). Same AcuPick capability, more flexible network design. View NVR5432-AI →
Need help sizing? Browse the complete Dahua AcuPick NVR range → or contact our Australian team for a tailored recommendation based on your camera count, recording retention and AcuPick search workload.
Technical Specifications
DH-IPC-HDW3649H-AS-PV-PRO-ANZ · Full Specifications
SKU
DH-IPC-HDW3649H-AS-PV-PRO-ANZ (White) · DH-IPC-HDW3649H-AS-PV-PRO-ANZ-BLK (Black)
Camera Type
6MP TiOC PRO WizColor WizSense IP Network Turret · Active Deterrence
Image Sensor
1/1.8" Progressive Scan CMOS
Max Resolution
3288 × 1850 (6MP) @ 25/30 fps
Lens Type
Fixed-focal, 2.8 mm · M16 mount (3.6 mm option available)
Maximum Aperture
F1.0 (2.5× the light gathering of F1.6)
Angular Field of View
H: 109° · V: 59° · D: 131° (2.8 mm)
DORI Distance (2.8 mm)
Detect 70.2 m · Observe 28.1 m · Recognise 14.0 m · Identify 7.0 m
Min. Illumination
Colour: 0.0005 Lux @ F1.0 · B/W: 0.0004 Lux · 0 Lux (Illuminator on)
S/N Ratio
> 56 dB
Dynamic Range
120 dB True WDR
Day & Night
Auto (ICR) / Colour / B&W
Illuminators
2 × Multi-core (IR + warm) light · 30 m IR · 30 m warm light · WizColor Smart Dual-Light auto switching
Image Enhancement
3D NR · HLC · BLC · Defog · AI SSA · Smart Illumination · LDC · Image Rotation
Active Deterrence
Red/blue flashing warning lights · Built-in siren · Voice broadcast (custom audio supported)
Intelligent Video
AcuPick · SMD 4.0 · IVS (Tripwire, Intrusion · human/vehicle classification) · AI SSA · Smart Search
Video Compression
AI H.265 · AI H.264 · Smart H.265+ · Smart H.264+ · H.265 · H.264 · MJPEG (sub-stream)
AI Coding
≥25% additional compression efficiency
Streaming
3 streams — Main 3288×1850 · Sub 1920×1080 · Third 1920×1080
Video Bitrate
H.264 / H.265: 3 kbps – 16,384 kbps
Audio Compression
G.711a · G.711Mu · G.726 · G.723 · PCM (Two-Way Audio)
IP Camera Protocol
ONVIF Profile S/G/T · CGI · P2P · RTMP
Network Protocols
IPv4/v6 · HTTP/HTTPS · TCP/UDP · RTP/RTSP/RTCP/RTMP · SMTP · FTP/SFTP · DHCP · DDNS · UPnP · NTP · ICMP · IGMP · NFS · PPPoE · SNMP · 802.1x
Cyber Security
Trusted boot · Trusted execution · Trusted upgrade · HTTPS · 802.1x · IP/MAC filtering · X.509 import · syslog · video/firmware/config encryption · account lockout
Ethernet
RJ-45 (10/100BASE-T)
Alarm I/O
1 alarm in (wet contact) · 1 alarm out (wet contact)
Audio I/O
Dual built-in MIC · 1-channel built-in speaker · 1 × RCA in / 1 × RCA out
Edge Storage
MicroSD up to 512 GB · NAS · FTP / SFTP
Weatherproof Rating
IP67
Operating Temperature
−40 °C to +60 °C · ≤ 95% RH
Power Source
12 V DC · PoE (IEEE 802.3af) · ±30% wide voltage · Dual-power backup
Power Consumption
Basic 4.1 W (12 V DC) / 6 W (PoE) · Max 10 W (PoE) / 8.2 W (12 V DC)
Memory
ROM 256 MB · RAM 2 GB
Mobile App
DMSS · Smart PSS Lite · DSS · DoLynk Care (iOS & Android)
Approvals
CE-LVD (EN 62368-1) · CE-EMC 2014/30/EU
Housing
Metal · White or Black
Dimensions
Φ 122.0 mm × 116.1 mm
Weight
0.8 kg (net) · 1.0 kg (gross)
Warranty
3-Year Australian Warranty (back-to-base)
3649 PRO vs 3649 Standard — Is the PRO Worth the Upgrade?
Both cameras share the same chassis, the same TiOC 3.0 deterrence chain, the same AcuPick AI and the same Smart Dual-Light system. The PRO's upgrades are concentrated in the parts that matter at night and at long range — the sensor, the lens, the AI engine and the image processing. If the camera's main job is to capture clean colour evidence in low light, the PRO is the right call. If the site has plenty of ambient light or the budget is tight, the standard 3649 still does the job.
Dahua 3649H-AS-PV-PRO-ANZ vs 3649H-AS-PV-ANZ-S2
Feature
DH-IPC-HDW3649H-AS-PV-PRO-ANZ (this PRO model)
DH-IPC-HDW3649H-AS-PV-ANZ-S2 (standard)
Image Sensor
1/1.8" CMOS
1/2.7" CMOS
Max Aperture
F1.0
F1.6
Light Gathering vs Standard
~2.5× more light
Baseline
Min Illumination (Colour)
0.0005 Lux @ F1.0
0.003 Lux @ F1.6
Max Resolution
6MP · 3288 × 1850
6MP · 3200 × 1800
Horizontal FOV (2.8 mm)
109°
97°
DORI Detect (2.8 mm)
70.2 m
66 m
DORI Identify (2.8 mm)
7.0 m
6.6 m
WizColor Branding
Yes — TiOC PRO + WizColor
TiOC 3.0
Smart Dual-Light
Yes — multi-core IR + warm
Yes — IR + warm
Red/Blue Strobe · Siren · Voice
Yes
Yes
Two-Way Audio
Yes — dual MIC + speaker
Yes — dual MIC + speaker
AcuPick AI Search
Yes — with 5-Series NVR
Yes — with 5-Series NVR
AI Coding
Yes — ≥25% extra efficiency
Smart H.265+ only
Lens Distortion Correction (LDC)
Yes
No
Memory (RAM)
2 GB
512 MB
Max Video Bitrate
16,384 kbps (16 Mbps)
8,192 kbps (8 Mbps)
Sub-Stream Resolution
1920 × 1080 (Full HD)
704 × 576 (D1)
WDR
120 dB True WDR
120 dB True WDR
MicroSD
Up to 512 GB
Up to 512 GB
Power (Max PoE)
10 W
8.8 W
Ingress Protection
IP67
IP67
Operating Temperature
−40 °C to +60 °C
−40 °C to +60 °C
Colour Options
White & Black
White & Black
Australian Warranty
3 years back-to-base
3 years back-to-base
Best For
Premium homes, commercial frontages, undercover carparks, long dark driveways — any site where night-time colour image quality is the deciding factor.
Solid all-round 6MP TiOC choice for sites with reasonable ambient lighting where the budget is tighter.
Compatible Mounts & Accessories
Dahua PFA137 Waterproof Junction Box
Recessed IP66 junction box for clean cable concealment on exposed brick, render or weatherboard. Available in white and black to match the camera. View product →
Dahua PFB205W-E Wall Mount Bracket
Purpose-built wall arm for soffit, eave and external wall mounting. Available in white and black. View product →
Dahua PFA109 Mount Adapter
Required adapter to fit the 3649H PRO turret onto Dahua wall and pole brackets. View product →
Dahua PFB220C Ceiling Mount
Drop-down ceiling bracket for retail awnings, undercover car parks and warehouse interiors. View product →
Dahua PFA152-E Pole Mount
Heavy-duty pole bracket for fence posts, light poles and gate columns. Pairs with PFB205W-E and PFA137. View product →
WD Purple 256 GB Surveillance MicroSD Card
Western Digital Purple — purpose-built for 24/7 surveillance read/write cycles, far longer endurance than consumer microSD cards. The recommended edge-recording card for Dahua TiOC PRO turrets. View WD Purple 256 GB →
Frequently Asked Questions
What does "PRO" mean on the 3649H-AS-PV-PRO-ANZ?
PRO designates the higher-tier hardware variant in the 3649 line. Compared to the standard 3649, the PRO uses a larger 1/1.8" sensor, an F1.0 aperture (vs F1.6), 2 GB RAM (vs 512 MB), adds AI Coding and Lens Distortion Correction, and produces clean colour image at 0.0005 Lux (vs 0.003 Lux — a 6× improvement).
Is the PRO worth the extra cost over the standard 3649?
For sites where night-time image quality is critical — dark driveways, undercover carparks, commercial perimeters at the edge of street lighting — yes, the F1.0 aperture and 1/1.8" sensor make a visible difference. For well-lit sites, the standard 3649 delivers most of the same TiOC 3.0 capability at a lower price.
Why pick the 6MP PRO over the 8MP PRO?
Two reasons. First, better low-light — 0.0005 Lux on the 6MP PRO vs 0.0008 Lux on the 8MP PRO, because larger pixels gather more light. Second, cheaper storage — 6MP files are about 30% smaller than 4K files, so the same NVR drive holds 30% more days of footage. If you don't need 4K-level zoom-in capability, the 6MP PRO often makes more sense.
What is WizColor?
WizColor is Dahua's branding for full-colour night vision powered by a high-CRI warm-light LED combined with a large-aperture lens and high-sensitivity sensor. The 3649H-AS-PV-PRO is one of the WizSense 3-Series cameras that carries the WizColor designation.
Do I need a special NVR for AcuPick?
Yes — AcuPick target search requires a compatible Dahua 5-Series AcuPick NVR. The TiOC PRO deterrence chain, SMD 4.0, IVS and two-way audio all work on any Dahua AI NVR. Shop AcuPick NVRs here →
Will the camera deter intruders automatically?
Yes. The TiOC PRO deterrence chain fires the instant SMD 4.0 confirms a human or vehicle inside the rule zone — strobe lights, siren and voice broadcast all run on-camera, 24/7, without any operator, NVR command or mobile-app interaction.
What is the difference between the White and Black versions?
Specifications are identical. DH-IPC-HDW3649H-AS-PV-PRO-ANZ is white; DH-IPC-HDW3649H-AS-PV-PRO-ANZ-BLK is black. Choose black for dark eaves and charcoal fascia; white for traditional cream/render walls.
Will it keep recording if the NVR or internet goes down?
Yes. The on-board MicroSD slot accepts cards up to 512 GB and records 6MP footage independently of the NVR. The PRO also supports dual-power backup (PoE + 12 V DC) so the camera keeps running if one power source fails.
Is the camera suitable for Australian outdoor conditions?
Yes. It is rated IP67 and −40 °C to +60 °C — comfortably covering every Australian climate from a Hobart winter to a Karratha summer. The metal housing and ±30% wide-voltage tolerance also handle dirty mains power common on rural sites.
Does it work with Hikvision NVRs or third-party VMS?
Basic recording, streaming and motion work over ONVIF Profile S/G/T on most third-party NVRs and VMS platforms (Milestone, Genetec, Hanwha WAVE, ExacqVision, Blue Iris, Synology). However, TiOC deterrence, AcuPick, SMD 4.0 and two-way audio require a Dahua NVR or DMSS to be triggered correctly.
What is the warranty and where is it serviced?
This camera ships with a 3-year Australian Dahua warranty, serviced back-to-base by Dahua Australia. CCTV Guru handles the entire RA process and provides Australian-based technical support for the life of the product.
Do you ship Australia-wide and is stock genuine?
Yes — Australian stock from authorised Dahua Australia channels (not parallel imports). We ship Australia-wide every business day with same-day dispatch on orders placed before 2 pm AEST to Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra, Darwin and regional addresses.
Downloads & Resources
DH-IPC-HDW3649H-AS-PV-PRO-ANZ Datasheet
Dahua Turret Quick Start Guide
Order the Dahua DH-IPC-HDW3649H-AS-PV-PRO-ANZ from CCTV Guru
CCTV Guru is an authorised Australian reseller of Dahua TiOC PRO cameras. Order the 6MP TiOC PRO WizColor AcuPick turret today in White or Black for fast Australia-wide dispatch, expert pre-sales advice, project pricing for larger rollouts and full local warranty support. For multi-camera projects, contact our Australian team for a tailored quote, NVR sizing and installation guidance — request a free quote or contact the team.
Genuine Dahua · Wall Mount · IP66 AluminiumDahua PFB2203W
Dahua DH-PFB2203W Wall Mount Bracket
DH-PFB2203W IP66 Wall Mount with Junction Box — Australian Stock & 3-Year Warranty
The Dahua DH-PFB2203W is a professional-grade wall mount bracket built from durable aluminium alloy for secure, good-looking installs of Dahua dome and turret cameras. With an IP66 rating and a hollow centre for hidden cabling, it protects connectors from dust, water and tampering. Pre-drilled holes and a G1/2" pipe thread make installation quick and clean.
Specifications
Model / SKU
DH-PFB2203W
Category
Wall mount bracket
Material
Aluminium alloy
Colour
White
IP Rating
IP66
Load Capacity
1.0 kg
Dimensions
160.0 × 122.0 × 76.0 mm
Net Weight
0.49 kg
Operating Temperature
–40 °C to +60 °C
Mounting
Wall mount, G1/2" pipe thread, integrated junction box
Warranty (Australia)
3 years · CCTV Guru Australia
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision 8MP 4K · AcuSense · Live Guard · Smart Hybrid Light
Hikvision DS-2CD2386G2H-IS2U/SL — 8MP 4K AcuSense Live-Guard Turret with Smart Hybrid Light, Strobe & Two-Way Audio
The Hikvision DS-2CD2386G2H-IS2U/SL is an elite 8 MP / 4K network turret camera built for proactive security. Part of the EasyIP 4.0 range, it features Live Guard active deterrence — a built-in white strobe light and audio siren that trigger the moment a threat is detected, warning intruders away before they reach the door. Powered by AcuSense deep learning, it focuses specifically on human and vehicle targets for accurate, actionable alerts. Smart Hybrid Light combines IR and white light up to 30 m for covert or full-colour night imaging, while two-way audio via a built-in mic and speaker enables live talk-back and custom voice warnings. The IP67-rated housing is available in Classic White or Midnight Black with a choice of 2.8 mm or 4 mm lens. Australian stock, 3-year Australian warranty.
Resolution
8 MP · 3840 × 2160 · 4K
Lens
2.8 mm or 4 mm Fixed
Live Guard
White Strobe + Siren
AI Engine
AcuSense · Human + Vehicle
Night Vision
Smart Hybrid · 30 m
Protection
IP67 · 3-Year AU
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
4K Clarity with Active Deterrence
Live Guard Strobe + Siren
Live Guard turns this 4K camera into an active deterrent. When AcuSense detects a person or vehicle, the built-in white strobe light and audio siren trigger automatically — warning intruders away before they reach the door.
AcuSense Human & Vehicle AI
AcuSense deep-learning algorithms classify targets as humans or vehicles, dramatically reducing false alarms from animals, moving foliage and rain so deterrents and alerts fire only on real threats.
Smart Hybrid Light + Two-Way Audio
Smart Hybrid Light blends IR and white light up to 30 m for covert or full-colour night imaging, while built-in mic and speaker enable two-way audio talk-back and custom voice warnings via Hik-Connect.
4K Evidence Detail, White or Black
Crisp 8 MP / 4K imaging at 25 fps gives superb evidence capture and digital-zoom headroom. The IP67 turret is available in Classic White or Midnight Black with 2.8 mm or 4 mm lens to suit your scene.
Technical Specifications
DS-2CD2386G2H-IS2U/SL · Specifications
SKU
DS-2CD2386G2H-IS2U/SL (2.8 mm or 4 mm · white or black)
Camera Type
Hikvision AcuSense EasyIP 4.0 · 8 MP / 4K Live-Guard Fixed Turret
Max Resolution
8 MP · 3840 × 2160 @ 25 fps
Lens (Field of View)
2.8 mm (105° HFOV) or 4 mm (90° HFOV)
Night Vision
Smart Hybrid Light — IR + white light up to 30 m
AI / Smart Functions
AcuSense human + vehicle classification
Deterrence
Live Guard — white strobe light + audio siren
Audio
Built-in mic + speaker · two-way audio
On-Board Storage
microSD up to 512 GB
Weatherproof Rating
IP67
Colour Options
Classic White or Midnight Black
Warranty
3-Year Australian Warranty
Frequently Asked Questions
What does Live Guard do?When AcuSense detects a human or vehicle, Live Guard automatically triggers a white strobe light and an audio siren to actively warn off intruders — turning a passive recorder into a real-time deterrent.
Which lens should I choose?Choose 2.8 mm (105°) for ultra-wide coverage in smaller spaces and close-range perimeters, or 4 mm (90°) to focus on a specific path or driveway with slightly more detail at distance.
Does it do colour at night?Yes. Smart Hybrid Light offers IR mode for covert recording or white-light mode for full-colour night imaging, both up to 30 m, so you can tune the lighting to each install.
Can I talk through the camera?Yes — built-in mic and speaker support two-way audio via Hik-Connect for live talk-back, plus you can play custom recorded voice warnings.
Downloads & Resources
DS-2CD2386G2H-IS2U/SL Datasheet
Order the Hikvision DS-2CD2386G2H-IS2U/SL from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision active-deterrence cameras. The DS-2CD2386G2H-IS2U/SL combines 4K clarity with AI-driven Live Guard deterrence — ideal for homes and businesses that want to stop intruders, not just record them. Order in white or black with 2.8 mm or 4 mm lens for fast Australia-wide dispatch, expert pre-sales advice and full local warranty support. Request a free quote or contact our Australian team.
Dahua WizSense 3 · 8MP 4K Bullet · Smart Dual Light · AcuPickAcuPick Bullet
Dahua DH-IPC-HFW3867T-ZAS-IL-ANZ — 8MP 4K Smart Dual Light Motorised Vari-Focal AcuPick Bullet
The Dahua DH-IPC-HFW3867T-ZAS-IL-ANZ is an 8MP 4K motorised vari-focal bullet in the WizSense 3 Series · Smart Dual Light line — built around a 1/2.7" CMOS sensor, a 2.7–13.5 mm motorised zoom lens with F1.4 aperture, and four multi-core LEDs delivering both 60 m IR and 60 m warm-light illumination. The Smart Dual Light system runs invisible IR by default and switches to warm-light LED for full-colour image the moment a person or vehicle is detected — giving you clean colour evidence at the event, without the constant light spill of a full-time warm-light camera.
Unlike the TiOC bullets, the 3867T-ZAS-IL has no red/blue strobe, no on-board siren and no voice broadcast — it's a focused silent surveillance camera. What it does add over the IR-only 3866TP is the warm-light LED for full-colour night image, AcuPick AI attribute search, 16 Mbps bitrate ceiling, 512 GB MicroSD support, ONVIF Profile M and dual-power backup. Combined with SMD 4.0, EIS image stabilisation, AI Coding and AI SSA, it's the mid-tier sweet spot of Dahua's 8MP bullet line. Available in White and Black. Australian stock, 3-year Australian warranty.
Resolution
8MP · 4K · 3840 × 2160
Motorised Zoom
2.7–13.5 mm · F1.4
Smart Dual Light
60 m IR · 60 m Warm
AI Engine
WizSense · AcuPick · SMD 4.0
Protection
IP67 · All-Metal Body
Power
PoE 802.3af · Max 12.5 W
3-Year Australian Warranty
Fast Australia-Wide Shipping
Australian Tech Support
Why Choose the Smart Dual Light AcuPick Bullet
The 3867T-ZAS-IL is the mid-tier 8MP bullet — between the silent IR-only 3866TP and the TiOC-deterrence 3849T1-ZAS-PV. It's the camera Australian installers reach for when they want colour evidence at night without the visible deterrent of red/blue strobe lights, plus the AcuPick AI workflow for fast post-incident search. Long perimeters, rural driveways, schools, healthcare, retail interiors and any site where colour identification matters more than active deterrence — this is the right tool.
Smart Dual Light — Colour Evidence on Detection
By default the camera uses invisible IR illumination out to 60 m for silent monitoring. The instant SMD 4.0 detects a human or vehicle, it switches to 60 m warm-light LED and records full-colour video — capturing clothing colour, vehicle paint and facial detail that IR alone cannot deliver.
2.7–13.5 mm Motorised Vari-Focal
Five-times optical zoom with remote focus and zoom via DMSS or a Dahua NVR. Set the field of view once at install, then re-tune from your phone — no ladder, no re-aiming. Close focus down to 0.1 m for tight near-field shots.
AcuPick AI Target Search
Paired with a Dahua 5-Series AcuPick NVR, AcuPick indexes every human and vehicle event by attribute — clothing colour, vehicle type, direction — so you find any face or plate across a week of footage in seconds rather than scrubbing timelines.
F1.4 Large Aperture + 1/2.7" Sensor
An F1.4 maximum aperture across the entire zoom range pulls in significantly more light than a typical F1.6 lens, producing clean colour image at low light and reducing how often the warm-light LED needs to fire.
Massive DORI Reach at Tele
At maximum zoom the 3867T will detect motion at 280 m, recognise a person at 56 m, and identify a face at 28 m. One camera secures a typical Australian residential block end-to-end.
Built Tough for Australia
All-metal IP67 chassis with EIS stabilisation, ±30% wide-voltage tolerance, dual-power backup (PoE + 12 V DC simultaneously) and a −30 °C to +60 °C operating range — engineered for coastal salt, outback heat and unstable rural mains.
Smart Features for Real-World Australian Sites
Dahua Smart Dual Illuminators — Official English Overview
Remote Zoom & Auto-Focus
Adjust the 2.7–13.5 mm zoom from the DMSS app or a Dahua NVR. The motor handles focus automatically as the lens zooms — no manual focus turret to fiddle with at the camera.
SMD 4.0 + IVS Perimeter Protection
On-camera Smart Motion Detection 4.0 classifies humans and vehicles while filtering out animals, foliage and weather. IVS tripwire and intrusion detection trigger smart alerts — no false alarms from leaves in the wind.
EIS Image Stabilisation
Electronic Image Stabilisation corrects subtle vibration on long-zoom shots from a pole, gable or fence — keeping the image steady at 13.5 mm telephoto where small movements are most visible.
AI Coding — Lower Bandwidth & Storage
Dahua's AI Coding (AI H.265 / AI H.264) analyses the scene and dedicates bitrate only to objects of interest, reducing storage and transmission cost over standard Smart H.265+.
Dual Sub-Streams at Full HD
Three streams simultaneously — Main 4K, plus a 1920 × 1080 sub-stream and a 1920 × 1080 third stream — gives flexibility for live view, mobile streaming and NVR recording at sharper resolution than typical D1 sub-streams.
Dual-Power Backup
Connect both 12 V DC and PoE simultaneously — if one source fails, the camera keeps running on the other. Useful for critical-uptime sites and rural installs with unreliable mains.
Pair with a Dahua 5-Series NVR for the Full AcuPick Experience
SMD 4.0, IVS rules and Smart Dual Light auto-switching all run on-camera and work with any Dahua AI NVR. But to unlock AcuPick — attribute-based human and vehicle target search, similar-image cross-camera tracking and AI-accelerated playback — you need a compatible Dahua 5-Series AcuPick NVR. For any new installation we strongly recommend pairing the 3867T-ZAS-IL with one of the recorders below.
DHI-NVR5208-8P-AI/ANZ — 8 Channel · 8 PoE
Compact 1U 5-Series AcuPick NVR with 8 built-in PoE ports — ideal for a single-home or small-business install with 4–8 WizSense cameras. Full AcuPick target search and AI playback. View NVR5208-8P →
DHI-NVR5216-16P-AI/ANZ — 16 Channel · 16 PoE
16-channel 5-Series AcuPick NVR with 16 PoE ports and dual-HDD bays — the sweet-spot recorder for most residential and SMB Dahua fleets. Plug-and-play with the 3867T. View NVR5216-16P →
DHI-NVR5432-16P-AI/ANZ — 32 Channel · 16 PoE
32-channel 1.5U AcuPick NVR with 16 PoE and 4 HDD bays — the standard choice for medium commercial sites, retail chains and multi-building campuses. View NVR5432-16P →
DHI-NVR5432-AI/ANZ — 32 Channel · No PoE
32-channel AcuPick NVR without built-in PoE — for sites running a separate managed PoE switch (preferred in larger commercial deployments). Same AcuPick capability, more flexible network design. View NVR5432-AI →
Need help sizing? Browse the complete Dahua AcuPick NVR range → or contact our Australian team for a tailored recommendation based on your camera count, retention and AcuPick search workload.
Technical Specifications
DH-IPC-HFW3867T-ZAS-IL-ANZ · Full Specifications
SKU
DH-IPC-HFW3867T-ZAS-IL-ANZ (available in White and Black)
Camera Type
8MP 4K Smart Dual Light Motorised Vari-Focal Bullet · WizSense 3 Series · AcuPick
Image Sensor
1/2.7" Progressive Scan CMOS
Max Resolution
3840 × 2160 (8MP / 4K) @ 25/30 fps
Lens Type
Motorised vari-focal · 2.7–13.5 mm · φ14 mount
Maximum Aperture
F1.4
Field of View
H: 114°–32° · V: 58°–17° · D: 138°–36°
Close Focus Distance
0.1 m
DORI — Wide (2.7 mm)
Detect 85.3 m · Observe 34.0 m · Recognise 17.1 m · Identify 8.5 m
DORI — Tele (13.5 mm)
Detect 280 m · Observe 112 m · Recognise 56 m · Identify 28 m
Min. Illumination
Colour: 0.007 lux @ F1.4 · B/W: 0.0007 lux · 0 lux (Illuminator on)
S/N Ratio
> 56 dB
Dynamic Range
120 dB True WDR
Day & Night
Auto (ICR) / Colour / B&W
Illuminators
4 × Multi-core (IR + warm) LED · IR up to 60 m · Warm light up to 60 m · Smart Dual Light auto switching
Image Enhancement
WDR · 3D NR · HLC · BLC · Defog · AFSA · AI SSA · Smart Illumination · Smart Dual Light · EIS · Image Rotation · Privacy masking (8 areas) · Digital watermarking
Active Deterrence
Not included — silent Smart Dual Light surveillance camera
Intelligent Video
WizSense AI · AcuPick · SMD 4.0 · IVS (Tripwire, Intrusion · human/vehicle classification) · Quick Pick (with AI NVR) · Smart Search · AI SSA
Video Compression
H.265 · H.264 · H.264H · H.264B · MJPEG (sub-stream) · Smart H.265+ / H.264+ · AI H.265 / AI H.264
Streaming
3 streams — Main 3840×2160 · Sub 1920×1080 · Third 1920×1080 (both sub-streams Full HD)
Video Bitrate
H.264 / H.265: 3 kbps – 16,384 kbps
Audio
Built-in microphone · G.711a / G.711Mu / G.726 / G.723 / PCM compression
Audio I/O
1 audio in (RCA) · 1 audio out (RCA)
Alarm I/O
1 alarm in (wet contact, 5 mA, 3–5 V DC) · 1 alarm out (wet contact, 300 mA, 12 V DC)
IP Camera Protocol
ONVIF Profile S / G / T / M · CGI · P2P
Network Protocols
IPv4/v6 · HTTP/HTTPS · TCP/UDP · RTP/RTSP/RTCP/RTMP · SMTP · FTP/SFTP · DHCP · DDNS · UPnP · NTP · ICMP · IGMP · NFS · SAMBA · PPPoE · SNMP
Cyber Security
Trusted boot · Trusted execution · Trusted upgrade · HTTPS · 802.1x · IP/MAC filtering · X.509 import · syslog · video/firmware/config encryption · account lockout
Ethernet
RJ-45 (10/100BASE-T)
Edge Storage
MicroSD up to 512 GB · NAS · FTP / SFTP
Weatherproof Rating
IP67
Operating Temperature
−30 °C to +60 °C · ≤ 95% RH (non-condensing)
Storage Temperature
−40 °C to +60 °C
Power Source
12 V DC / PoE (IEEE 802.3af) · ±30% wide voltage · Dual Power Backup
Power Consumption
Basic 3.8 W (12 V DC) / 5.3 W (PoE) · Max 9.9 W (12 V DC) / 12.5 W (PoE)
Memory
ROM 256 MB · RAM 1 GB
Pan / Tilt / Rotation
Pan 0°–360° · Tilt 0°–90° · Rotation 0°–360°
Mobile App
DMSS · Smart PSS Lite · DSS (iOS & Android)
Approvals
CE-LVD (EN 62368-1) · CE-EMC 2014/30/EU
Housing
Metal · White or Black
Dimensions
238.5 × 90.7 × 90.7 mm (L × W × H)
Weight
835 g (net) · 1090 g (gross)
Warranty
3-Year Australian Warranty (back-to-base)
3867T-ZAS-IL vs 3866TP-ZAS-AUS — Smart Dual Light or IR-Only?
Both cameras are 8MP 4K motorised vari-focal bullets sharing the same WizSense 3 architecture, SMD 4.0, IVS perimeter protection, EIS stabilisation and AI Coding. Neither has TiOC active deterrence. The deciding question is the illuminator and AI tier: do you want Smart Dual Light with full-colour evidence on detection and AcuPick AI search, or pure IR-only silent monitoring? The 3867T-ZAS-IL adds a 60 m warm-light LED for colour image, AcuPick attribute search, double the bitrate ceiling and double the MicroSD capacity. The 3866TP-ZAS-AUS is the simpler, cheaper IR-only option.
3867T-ZAS-IL (Smart Dual Light + AcuPick) vs 3866TP-ZAS-AUS (IR-Only)
Feature
DH-IPC-HFW3867T-ZAS-IL-ANZ (this Smart Dual Light bullet)
DH-IPC-HFW3866TP-ZAS-AUS (IR-only bullet)
Series Line
Smart Dual Light · WizSense 3
IR Vari-focal · WizSense 3
Max Resolution
8MP · 3840 × 2160 (4K)
8MP · 3840 × 2160 (4K)
Image Sensor
1/2.7" CMOS
1/2.8" CMOS
Lens
Motorised vari-focal · 2.7–13.5 mm
Motorised vari-focal · 2.7–13.5 mm
Max Aperture
F1.4
F1.5
FOV (wide)
114° H
109° H
IR Distance
60 m
60 m
Warm-Light LED
Yes · 60 m
No
Full-Colour Night Image
Yes — Smart Dual Light auto-switch
No — IR monochrome
AcuPick AI Search
Yes — with 5-Series NVR
No
SMD Version
SMD 4.0
SMD 4.0
Quick Pick (with AI NVR)
Yes
Yes
WDR
120 dB True WDR
120 dB True WDR
AI Coding
Yes (AI H.265 / H.264)
Yes (AI H.265 / H.264)
EIS Stabilisation
Yes
Yes
Max Video Bitrate
16,384 kbps
8,192 kbps
MicroSD
Up to 512 GB
Up to 256 GB
Sub-Streams
Both at 1920 × 1080
704 × 576 + 1920 × 1080
Privacy Masking
8 areas
—
ONVIF Profiles
S / G / T / M
S / G / T
Dual Power Backup
Yes
—
Ingress Protection
IP67
IP67
Vandal Resistance
—
IK10 (optional configuration)
Operating Temperature
−30 °C to +60 °C
−30 °C to +60 °C
Power (Max PoE)
12.5 W
10.5 W
Housing
All-metal · 238.5 × 90.7 × 90.7 mm · 835 g
Metal · 244 × 79 × 76 mm · 820 g
Colour Options
White & Black
White only
Australian Warranty
3 years back-to-base
3 years back-to-base
Best For
Sites where colour evidence on detection matters, AcuPick search workflow, longer retention via 512 GB MicroSD, and the latest AI features.
Pure silent IR monitoring where colour at night isn't required and the budget is tighter.
Compatible Mounts & Accessories
Dahua PFA135 Junction Box
Bullet-specific junction box for clean cable concealment behind the camera mount. Indoor / sheltered installs. View Dahua accessories →
Dahua PFA130-E Waterproof Junction Box
Waterproof junction box for exposed outdoor bullet mounting on render, brick or weatherboard. View Dahua accessories →
Dahua PFA152-E Pole Mount
Heavy-duty pole bracket — the typical install partner for long-range bullet cameras on fence posts, light poles and gate columns. View product →
Dahua PFA151 Corner Mount Bracket
Purpose-built corner bracket for mounting the bullet at building corners — typical install pattern on commercial perimeters and warehouse exteriors. View Dahua accessories →
Dahua PFM900-E Integrated Mount Tester
On-site display + power-test tool for commissioning bullet cameras from the ladder. Especially useful when setting the zoom and focus on the vari-focal lens. View Dahua accessories →
WD Purple 256 GB Surveillance MicroSD Card
Western Digital Purple — purpose-built for 24/7 surveillance read/write cycles, far longer endurance than consumer microSD cards. The 3867T accepts cards up to 512 GB. View WD Purple 256 GB →
Frequently Asked Questions
Does this camera have active deterrence (strobe / siren)?
No. The 3867T-ZAS-IL is a silent Smart Dual Light surveillance camera — no red/blue strobe, no built-in siren, no voice broadcast. If you need active deterrence, look at the Dahua TiOC line-up (HFW3849T1-ZAS-PV-ANZ-S2 is the closest equivalent in the same form factor).
How is Smart Dual Light different from full-colour cameras?
Full-colour cameras run the warm-light LED constantly at night — clearly visible from outside, with light spill that can disturb neighbours. Smart Dual Light defaults to invisible IR for normal monitoring; the warm-light LED only fires when SMD 4.0 detects a real human or vehicle, then auto-switches back to IR. Less light pollution, less wear on the LED, full-colour evidence only when it matters.
Does it support AcuPick AI search?
Yes — AcuPick is supported on this camera when paired with a compatible Dahua 5-Series AcuPick NVR. AcuPick indexes attribute metadata (clothing colour, vehicle type, direction) so you can search hours of footage in seconds. Shop AcuPick NVRs here →
How does this compare to the IR-only 3866TP bullet?
Same 8MP / 4K sensor, same 2.7–13.5 mm motorised lens, same WizSense AI core. The 3867T-ZAS-IL adds a 60 m warm-light LED for colour image, AcuPick AI search, 16 Mbps bitrate (vs 8 Mbps), 512 GB MicroSD support (vs 256 GB), dual-power backup, and Full HD on both sub-streams. The 3866TP is the cheaper IR-only option for sites where colour at night isn't required.
Can the camera pan and tilt remotely?
No. The 3867T-ZAS-IL is a motorised vari-focal bullet, not a PTZ. The lens supports remote zoom and auto-focus, but the camera body itself does not pan or tilt remotely — the housing is aimed manually at install time. For a fully remote pan/tilt/zoom camera, look at a Dahua PTZ.
What does the camera see at night?
By default it uses 60 m IR illumination for invisible monitoring. When SMD 4.0 detects a person or vehicle, the warm-light LED switches on (also 60 m) and the camera captures full-colour 4K — clothing colour, vehicle paint, facial detail. Once the target leaves, it switches back to IR.
Does it have a built-in microphone?
Yes — the camera has a built-in microphone for capturing scene audio. There is also 1 audio in / 1 audio out (RCA) for connecting an external mic or speaker, plus 1 alarm in / 1 alarm out for PIRs or door contacts. (No built-in speaker.)
Will it keep recording if the NVR or internet goes down?
Yes. The on-board MicroSD slot accepts cards up to 512 GB and records 4K footage independently of the NVR. Combined with dual-power backup (PoE + 12 V DC simultaneously), the camera has multiple layers of redundancy.
Is the camera suitable for Australian outdoor conditions?
Yes. It is rated IP67 and −30 °C to +60 °C — covering every Australian climate from a Hobart winter to a Karratha summer. The all-metal housing and ±30% wide-voltage tolerance also handle dirty mains power common on rural sites.
Does it work with Hikvision NVRs or third-party VMS?
Yes — recording, streaming, motion and the WizSense AI metadata work over ONVIF Profile S/G/T/M on most third-party NVRs and VMS platforms (Milestone, Genetec, Hanwha WAVE, ExacqVision, Blue Iris, Synology). However, AcuPick attribute search requires a Dahua 5-Series AcuPick NVR.
What is the warranty and where is it serviced?
This camera ships with a 3-year Australian Dahua warranty, serviced back-to-base by Dahua Australia. CCTV Guru handles the entire RA process and provides Australian-based technical support for the life of the product.
Do you ship Australia-wide and is stock genuine?
Yes — Australian stock from authorised Dahua Australia channels (not parallel imports). We ship Australia-wide every business day with same-day dispatch on orders placed before 2 pm AEST to Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra, Darwin and regional addresses.
Downloads & Resources
DH-IPC-HFW3867T-ZAS-IL-ANZ Datasheet Dahua Bullet Quick Start Guide
Order the Dahua DH-IPC-HFW3867T-ZAS-IL-ANZ from CCTV Guru
CCTV Guru is an authorised Australian reseller of Dahua WizSense network cameras. Order the 8MP 4K Smart Dual Light motorised vari-focal AcuPick bullet today in White or Black for fast Australia-wide dispatch, expert pre-sales advice, project pricing for larger rollouts and full local warranty support. For multi-camera projects, contact our Australian team for a tailored quote, NVR sizing and installation guidance — request a free quote or contact the team.
Genuine Dahua · Pole Mount · Heavy-Duty SteelDahua PFA156Heavy-Duty Pole Mount Built for the Outdoors
The Dahua DH-PFA156 is a professional-grade, heavy-duty pole mount bracket for the secure installation of security cameras and outdoor intercom stations. Constructed from high-quality SECC steel with adjustable stainless steel hoops, it delivers a stable platform that lasts in tough outdoor conditions. With a 10 kg load capacity, it comfortably handles larger cameras and stations.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why You'll Love It
SECC steel construction — electro-galvanized cold-rolled steel for superior strength and corrosion resistance.
10 kg load capacity — supports larger cameras and heavy outdoor intercom stations with ease.
Versatile pole fit — adjustable stainless steel hoops suit pole diameters from 80 mm to 150 mm.
All-weather reliability — operates from -40 °C to +60 °C with up to 90% relative humidity.
Specifications
Model
DH-PFA156
Category
Pole Mount
Material
SECC Steel
Colour
Dahua White
Load Capacity
10.0 kg (22.05 lb)
Dimensions
130.4 mm × 170.0 mm × 45.0 mm
Operating Temperature
-40 °C to +60 °C
Mounting
Pole mount (Φ80 mm to Φ150 mm)
Warranty
3 Years (AU)
Frequently Asked Questions
What devices can the PFA156 mount?It is designed for Dahua security cameras and outdoor intercom stations. Check your device's mounting spec to confirm it lists the PFA156, especially for heavier PTZ or station hardware.
What pole sizes does it fit?Its adjustable stainless steel hoops fit pole diameters from 80 mm to 150 mm (3.15" to 5.91").
Is this a genuine Dahua accessory?Yes — the PFA156 is an official Dahua pole mount bracket finished in matching Dahua White.
Is it suitable for outdoor use?Absolutely. The SECC steel build and -40 °C to +60 °C operating range are made for long-term outdoor installation.
Hikvision Wired Alarm
DS-PS103 Wired Internal Sounder Siren
The Hikvision DS-PS103 is a high-output wired internal sounder for intrusion alarm systems. It delivers a sound pressure level of up to 110dB, providing a clear and powerful audible deterrent the moment a security breach is detected.
Built with a high-strength polycarbonate housing and running on standard 12VDC, it is compatible with a wide range of security control panels and mounts discreetly to a wall or ceiling.
110dB OutputLoud, clear alert across large indoor spaces
12VDC PowerCompatible with most security control panels
Durable PC HousingHigh-strength polycarbonate construction
Compact MountDiscreet wall or ceiling installation
Specifications
Model
DS-PS103
Sound Pressure
≥ 110 dB
Rated Voltage
12 VDC
Current Consumption
Max. 250 mA
Frequency Range
2000 Hz to 4000 Hz
Material
PC (polycarbonate)
Operating Temperature
-10°C to +55°C
Dimensions
122 × 72 × 35 mm
Downloads & Resources
DS-PS103 Datasheet (PDF)
How loud is it?It delivers a sound pressure level of up to 110dB, audible throughout large indoor spaces.
What power does it need?Standard 12VDC, making it compatible with a wide range of security control panels.
Where can I mount it?Its compact, surface-mount design suits discreet wall or ceiling installation indoors.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
The DS-PS103 provides a loud, reliable indoor sounder for your wired Hikvision alarm system, backed by a 3-Year Australian warranty and local support.
WizMind 5 · 6 MP · 360° Fisheye · Pro AI
WizMind 5 Fisheye
Dahua DH-IPC-EBW5641-AS — 6 MP Pro AI 360° Fisheye Panoramic Network Camera WizMind 5 (EBW Series)
The Dahua DH-IPC-EBW5641-AS is a 6 MP WizMind 5 Pro AI fisheye dome that delivers a true 360° ceiling-mount panoramic view from a single 1.4 mm super-wide lens, ideal for replacing two or three conventional cameras across retail floors, warehouse aisles, hotel lobbies and education spaces. A 1/1.8″ progressive-scan CMOS captures crisp 3072 × 2048 footage with native WDR, 3D NR and Smart IR illumination to 10 m, while multiple dewarp modes (panorama, double panorama, quad PTZ, original fisheye) let installers pick the perspective that suits each room. WizMind 5 deep learning unlocks face recognition, people counting (with queue, regional and stereo analysis), heat-map traffic flow and ANPR-style metadata, all processed on-device. The IP67/IK10 sealed enclosure, −30 °C to 60 °C operating range and built-in mic, audio in/out, alarm in/out and 256 GB microSD slot make this a complete edge-recording solution. Backed by a 5-year Australian warranty through CCTV Guru, an authorised Dahua reseller.
5-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why Choose the Dahua DH-IPC-EBW5641-AS Fisheye
True 360° Coverage
A single ceiling-mount fisheye replaces 2–3 traditional cameras, removing blind spots in retail, office and warehouse environments.
6 MP WizMind 5 Pro AI
1/1.8″ CMOS sensor delivers 3072 × 2048 panoramic footage at 25/30 fps for sharp identification across the entire scene.
Multi-View Dewarping
Choose panorama, double panorama, quad PTZ or original fisheye streams — pick the perspective that suits each room without losing detail.
Smart IR to 10 m
Adaptive Smart IR prevents overexposure on nearby subjects while extending night-time visibility across the full 360° field.
IP67/IK10 Build
Sealed against dust, water and vandalism with −30 °C to 60 °C operating range — suitable for cold storage, loading docks and outdoor canopies.
Edge Storage to 256 GB
Built-in microSD slot supports up to 256 GB for failover recording — combined with mic, alarm I/O and audio I/O for full on-device intelligence.
Important Install Note
For best results, ceiling mount the EBW5641-AS at 2.5–4 m for full 360° coverage of a typical retail floor or hotel lobby; wall mounting is supported but reduces the analytic footprint. Use Cat6 to keep PoE headroom for the heater and IR array, and enable the dewarp mode that matches your VMS — Dahua DSS, SmartPSS, DMSS, and Dahua AI/ANZ NVRs all support native fisheye streams without quality loss.
AI & Smart Detection
Face Recognition
WizMind 5 deep-learning face capture and recognition with face attribute analysis (age, gender, expression, mask).
People Counting
In/out, regional and queue-management people counting with stereo analysis — ideal for retail footfall, exhibitions and venue capacity tracking.
Heat Map
Visualise dwell time and traffic flow across the panoramic scene — tune store layouts, product placement and staff coverage with data.
Stereo Analysis
Detects fall, climb, fight, run and intrusion behaviours with low false-alarm rates — suited to aged care, schools and detention environments.
Perimeter Protection
Tripwire and intrusion detection with human/vehicle classification reduces nuisance alarms from wildlife or weather effects.
Smart Event Triggers
Push notifications, audio alarm, alarm output and FTP upload on AI events — integrate directly with Dahua DSS or third-party VMS via ONVIF.
Technical Specifications
Camera, Lens & Illumination
Image Sensor
1/1.8″ 6 MP progressive-scan CMOS
Effective Pixels
3072 (H) × 2048 (V)
Max Resolution
3072 × 2048 @ 25/30 fps
Lens
1.4 mm fixed fisheye
Field of View
360° horizontal · 180° vertical
IR Distance
Smart IR up to 10 m
Min. Illumination
0.005 lx (colour) · 0.0005 lx (B/W) · 0 lx with IR
WDR / SNR
120 dB true WDR · SNR > 56 dB
Day/Night
ICR auto switching
Intelligence, Audio & Network
AI Series
WizMind 5 (Pro AI)
Smart Analytics
Face recognition · people counting · heat map · stereo analysis · perimeter protection
Dewarp Modes
Original fisheye · panorama · double panorama · quad PTZ · client- or device-side
Video Compression
H.265 / H.264 / MJPEG (sub stream) · smart codec
Audio
Built-in mic · 1 audio in · 1 audio out · G.711a/u, AAC, G.726
Alarm I/O
2 in · 2 out
Storage
microSD up to 256 GB · NAS · FTP
Network
RJ45 10/100 · ONVIF (Profile S/G/T) · CGI, RTSP, SDK
Power, Environment & Build
Power Supply
12 V DC · PoE (802.3af)
Power Consumption
< 9 W
Operating Temp.
−30 °C to +60 °C · < 95% RH
Ingress Protection
IP67 · IK10
Material
Metal housing · polycarbonate cover
Dimensions
Ø150.5 mm × 56.5 mm
Weight
≈ 750 g
Certifications
CE · FCC · RCM
Recommended NVR Pairings
DHI-NVR5208-8P-AI/ANZ
8-channel WizMind AI NVR with 8 PoE ports — ideal for single-fisheye sites needing native dewarp support. View →
DHI-NVR5216-16P-AI/ANZ
16-channel WizMind AI NVR with face recognition, people counting and 16 PoE ports for multi-camera fisheye sites. View →
DHI-NVR4216-16P-AI/ANZ
16-channel 4K Smart AI NVR — budget-friendly recorder with full fisheye dewarp support. View →
DHI-NVR5432-AI/ANZ
32-channel WizSense AI NVR for large enterprise rollouts mixing fisheye and conventional cameras. View →
Frequently Asked Questions
How much area does a single fisheye cover?At a typical 3 m ceiling height the camera covers approximately 75–100 m² with usable detail — enough to replace 2–3 conventional cameras in most retail or office layouts.
Does it record in true 360° or dewarped only?Both. The camera records the original fisheye stream and simultaneously outputs dewarped panorama, double panorama or quad PTZ views from the same sensor.
Will my Dahua NVR dewarp the stream?Yes — current Dahua AI/ANZ NVRs (4-Series, 5-Series WizSense and WizMind) include native fisheye dewarp during live view and playback.
Does it work with third-party VMS?Yes. ONVIF Profile S/G/T is supported; Milestone, Genetec, Exacq and Network Optix can ingest the fisheye stream and dewarp client-side.
How does people counting compare to a dedicated counter?Stereo analysis on the EBW5641-AS rivals dedicated counters for retail entrances — in/out, regional and queue-management counting are all available.
What ceiling height is recommended?2.5–4 m for general surveillance; up to 6 m is workable but reduces analytic accuracy at the perimeter.
Is audio included?Yes — a built-in microphone plus dedicated audio in and audio out connectors for two-way intercom integration.
What warranty applies in Australia?CCTV Guru provides a 5-year Australian warranty on WizMind 5 cameras including the EBW5641-AS, with local technical support.
Does CCTV Guru offer installation?Yes — we have a network of certified installers across Australia. Contact our team for a project quote.
Downloads
Datasheet (PDF)
Quick Start Guide
Installation Guide
User Manual
Order Your Dahua DH-IPC-EBW5641-AS from CCTV Guru
Buy the Dahua DH-IPC-EBW5641-AS 6 MP Pro AI fisheye direct from CCTV Guru, an authorised Australian Dahua reseller. Fast AU-wide shipping, 5-year warranty and local technical support. Need help speccing a multi-fisheye rollout or integrating with your existing Dahua NVR? Contact our team →
Dahua · DH-IPC-HDW8341XP-BV-3D · 3MP WizMind Dual-Lens Eyeball · Stereo People Counting · PoE
3MP Stereo AI
Dahua DH-IPC-HDW8341XP-BV-3D 3MP WizMind Dual-Lens Stereo Analysis Camera
The Dahua DH-IPC-HDW8341XP-BV-3D is a 3MP WizMind dual-lens network camera built for accurate stereo people counting and queue analytics. Its two 1/2.8" sensors create a 3D depth map so foot-traffic counts stay accurate even in crowds, while a fixed 2.8mm wide lens and IR night vision cover the scene around the clock. Powered over a single PoE cable, it speaks ONVIF and pairs with a Dahua NVR for recording and reporting.
Resolution
3MP (2048×1536)
Lens
Dual 2.8mm fixed
Night Vision
IR up to 20m
AI Engine
WizMind Stereo
Analytics
People counting
Weatherproof
IP67
3D Stereo People Counting
Twin sensors build a depth map of the scene, so the camera counts people by height and volume rather than 2D motion — delivering accurate entry/exit and occupancy figures even when crowds overlap.
WizMind AI Accuracy
Dahua's WizMind engine filters out shopping trolleys, shadows and non-human objects, keeping counting and queue data clean for retail, transport and building-occupancy reporting.
Built for Indoor Ceilings
The compact eyeball form factor mounts overhead at entrances and aisles, with IK10 vandal resistance and IP67 sealing for reliable, tamper-resistant operation.
Single-Cable PoE
One Cat6 run carries power and data. ONVIF compatibility lets it record to a Dahua NVR while feeding counting metadata to your analytics dashboard.
Specifications — DH-IPC-HDW8341XP-BV-3D
Resolution
3MP · 2048×1536
Sensor
Dual 1/2.8" progressive-scan CMOS
Lens
Dual-lens, 2.8mm fixed
Night Vision
Smart IR up to 20m
AI / Analytics
WizMind · 3D stereo people counting, queue & occupancy
Audio
Built-in mic; audio in/out
Protection
IP67 · IK10
Power
PoE 802.3af / 12V DC
Interoperability
ONVIF · pairs with a Dahua NVR
Warranty (Australia)
3 years · CCTV Guru Australia
Downloads & Resources
DH-IPC-HDW8341XP-BV-3D DatasheetDahua Stereo Vision Network Camera Quick Start Guide
What is dual-lens stereo people counting?Two sensors capture the scene from slightly different angles to build a 3D depth map. The camera counts people by their height and volume, which is far more accurate than 2D motion counting in busy entrances.
Does it need a special NVR?It records to any compatible Dahua NVR over PoE and ONVIF. For full counting and occupancy reports, use a Dahua AI/WizMind NVR or Dahua's analytics platform.
Is it suitable for outdoor use?It is IP67 and IK10 rated, but it is designed primarily for indoor overhead mounting at entrances and aisles for counting accuracy.
How is it powered?A single Cat6 cable provides PoE (802.3af) power and data, or you can use a 12V DC supply.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · ADS-110DL-48N-1 · DC Power Supply · 53V 1.812A
53V DC PSU
Dahua ADS-110DL-48N-1 53V DC Power Supply
The Dahua ADS-110DL-48N-1 is a regulated 53V DC power adapter that delivers stable power to Dahua PoE NVRs, PoE switches and network devices requiring a 53V input. With a wide 100-240V AC input range and a 1.812A output, it suits both residential and commercial CCTV installs as an original replacement or spare.
It uses a standard IEC mains input and a 4.0mm DC output jack for quick, secure connection. Note: this adapter is not suitable for NVRs requiring 12V DC input - always confirm the input voltage on your model's datasheet before purchase.
Specifications — ADS-110DL-48N-1
Brand / Model
Dahua ADS-110DL-48N-1
Device Type
DC Power Supply Adapter
Input Voltage
100-240V AC
Input Current
1.5A
Input Connector
IEC Mains Plug
Output Voltage
53V DC
Output Current
1.812A
Output Connector
4.0mm DC Jack
Number of Outputs
1
Powers
Dahua PoE NVRs, PoE switches & 53V network devices
Colour
Black
Warranty (Australia)
3 years · CCTV Guru Australia
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
AX PRO Panic Button
Hikvision DS-PDEBP2-EG2-WB — Wireless Portable Emergency Button
The Hikvision DS-PDEBP2-EG2-WB is a rugged wireless portable emergency button for the AX PRO alarm system. With dual panic buttons and two-way RF wireless communication, it lets users trigger panic, medical or emergency alarms quickly from anywhere on site.
AES-128 encryption and frequency hopping resist interference and jamming, while an IP66 weather-proof, wearable design suits both indoor and outdoor use with optional lanyard or wrist strap.
Dual Panic Buttons
Two emergency buttons for fast, deliberate alarm activation.
Two-Way RF
Tri-X two-way RF with AES-128 encryption and frequency hopping for reliable, secure signalling.
IP66 & Wearable
Weather-proof, portable design usable with a lanyard or wrist strap.
Long Battery Life
Up to ~3 years standby on a single CR2035 battery, with easy enrolment.
Specifications
Model
DS-PDEBP2-EG2-WB
Type
Portable emergency / panic button
Buttons
2 emergency buttons
Wireless Protocol
Tri-X two-way RF
Frequency
433MHz
Security
AES-128 encryption
Range
Up to ~800 m (open space)
Battery
1 × CR2035 (3V), ~3 yr standby
Protection
IP66 weather-proof
Operating Temp
-10°C to +55°C
Dimensions
φ38 × 12 mm
What system does it work with?It is designed for the Hikvision AX PRO alarm system and integrates with the Hik-Connect app.
Why does it have two buttons?The dual-button design helps prevent accidental triggering of emergency alarms.
Can it be used outdoors?Yes. The IP66 weather-proof rating suits indoor and outdoor use.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Add fast, reliable panic alerting to your AX PRO system with the Hikvision DS-PDEBP2-EG2-WB emergency button, backed by a 3-year Australian warranty and local tech support.
Hikvision IP Audio · 7W PoE Network Horn Speaker · IP67
Hikvision DS-QAZ1307G1T-E — 7W PoE Network Horn Speaker (121 dB, Two-Way SIP Audio, IP67 Outdoor Public Address)
The Hikvision DS-QAZ1307G1T-E is a 7 W PoE network horn speaker built for demanding outdoor environments. It delivers up to 121 dBSPL of acoustic pressure for long-range coverage, supports two-way SIP audio for live talk-down and announcements, and plays scheduled or triggered messages via text-to-speech and MP3/WAV files from on-board storage. A single PoE (802.3at) connection carries both power and data — no separate wiring — and the IP67 metal housing withstands rain, dust and temperature extremes. Integrates with Hikvision CCTV for coordinated emergency alerts and public announcements. Australian stock, 3-year Australian warranty.
Output
7 W · 121 dBSPL Max
Two-Way Audio
SIP · Live Talk-Down
Broadcasting
TTS · MP3 / WAV · Scheduled
Single-Cable Power
PoE 802.3at
Protection
IP67 Metal · −30 to +60 °C
Integration
ONVIF · SIP · Alarm Input
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Built for Outdoor Public Address & Active Deterrence
One PoE cable turns this horn into a networked loudspeaker that does far more than play a tone — live talk-down to a site, scheduled announcements, and automatic alerts triggered by your CCTV or alarm system. The IP67 metal body is made to live outdoors year-round.
121 dB Long-Range Output
A 7 W driver delivers up to 121 dBSPL with 110 dB sensitivity at 1 m — loud enough to carry across car parks, yards, building sites and perimeters.
Two-Way SIP Talk-Down
Dual electret microphones plus SIP support enable live two-way audio — speak directly to people on site from a console or app and hear the response.
TTS & Stored Messages
On-board 4 GB eMMC (1 GB for audio) stores MP3/WAV files and text-to-speech messages for regular, scheduled and emergency broadcasts.
CCTV & Alarm Linkage
An alarm input with audio linkage plus ONVIF/SIP integration lets the speaker fire automatic warnings when a camera or sensor triggers — coordinated active deterrence.
Technical Specifications
DS-QAZ1307G1T-E · Specifications
Model
DS-QAZ1307G1T-E
Speaker Rated Power
7 W
Impedance
8 Ω
Max Acoustic Pressure
121 dBSPL
Speaker Sensitivity
110 dB @ 1 m, 1 W
Frequency Response
300 Hz – 13 kHz
Microphones
2 × electret (100 Hz – 20 kHz)
Audio Formats
MP3, WAV
Audio Algorithms
AEC, AGC, ANS, DRC
Storage
4 GB eMMC (1 GB for audio files)
Broadcast Modes
Regular, live, scheduled, emergency alert
Network Protocols
IPv4, HTTP, HTTPS, SIP, ONVIF
Management
Hik-Connect, iVMS-4200, HikCentral
Alarm I/O
Alarm input with audio linkage
Power
PoE (802.3at)
Protection Rating
IP67 weatherproof metal housing
Operating Temperature
−30 °C to +60 °C
Dimensions
~272 × 237 × 175 mm
Weight
~2.1 kg
Warranty
3-Year Australian Warranty
Frequently Asked Questions
How is it powered and connected?A single PoE 802.3at Ethernet cable carries both power and network data — no separate power supply or audio cabling needed. It manages over IP via Hik-Connect, iVMS-4200 or HikCentral.
Can it talk back to people on site?Yes — it has two dual microphones and SIP two-way audio, so an operator can hold a live talk-down conversation, not just play one-way announcements.
Downloads & Resources
DS-QAZ1307G1T-E Datasheet
Order the Hikvision DS-QAZ1307G1T-E from CCTV Guru
CCTV Guru is an authorised Australian Hikvision reseller. Order the DS-QAZ1307G1T-E PoE network horn speaker for fast Australia-wide dispatch, expert pre-sales advice and full local warranty support. Designing a site-wide IP audio or talk-down system? Contact our Australian team and we'll help you spec the right number of speakers and the controller to match.
Hikvision 2MP · Dual-Lens · People Counting · IP67
Hikvision DS-2CD6825G0/C-IVS — 2MP Dual-Lens People-Counting Camera with Built-in Mic, WDR & IR
The Hikvision DS-2CD6825G0/C-IVS is a specialised 2 MP dual-lens network camera engineered for high-accuracy people counting. Its dual-lens configuration enables precise bi-directional counting — tracking people entering and exiting simultaneously — making it ideal for retail stores, shopping centres, office buildings, airports and entry/exit monitoring. Built-in intelligence provides real-time statistics, trend analysis and line-crossing detection, delivering actionable footfall data for marketing, staffing and security decisions. A 1/2.7" CMOS sensor delivers 2560 × 1440 imaging, 120 dB true WDR and 3D DNR keep the image clear in difficult light, and IR up to 6 m handles low-light entrances. A built-in microphone adds audio capture, onboard eMMC storage retains people-count data, and the IP67-rated housing suits indoor and sheltered outdoor entrances. Australian stock, 3-year Australian warranty.
Resolution
2 MP · 2560 × 1440
Lens
Dual-Lens · 2 mm · 104.5°
Analytics
Bi-Directional Counting
WDR / IR
120 dB WDR · 6 m IR
Audio
Built-in Microphone
Protection
IP67 · 3-Year AU
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Accurate Footfall Analytics for Business Intelligence
Dual-Lens Bi-Directional Counting
The dual-lens configuration counts people entering and exiting simultaneously and with high precision — giving you reliable in/out footfall data at a single entrance, not just a one-directional estimate.
Real-Time Stats & Trend Analysis
Built-in intelligence delivers real-time statistics, trend analysis and line-crossing detection — actionable data for marketing, staffing and security decisions, retained in onboard eMMC storage.
Clear Imaging in Difficult Light
120 dB true WDR and 3D DNR keep entrance scenes clear against bright glass-door backlight, while IR up to 6 m maintains accurate counting in low-light conditions.
Built-in Mic & IP67 Build
A built-in microphone adds audio capture for situational awareness, and the IP67-rated housing makes the camera reliable across indoor and sheltered outdoor entrances. Powered by PoE or 12 VDC.
Technical Specifications
DS-2CD6825G0/C-IVS · Specifications
SKU
DS-2CD6825G0/C-IVS
Camera Type
Hikvision · 2 MP Dual-Lens People-Counting Network Camera
Image Sensor
1/2.7" Progressive Scan CMOS
Max Resolution
2 MP · 2560 × 1440
Lens
2 mm fixed · 104.5° HFOV (dual-lens)
People Counting
Bi-directional · real-time · statistical reporting · line-crossing
IR Distance
Up to 6 m
Wide Dynamic Range
120 dB true WDR · 3D DNR
Audio
Built-in microphone
Video Compression
H.265+ · H.265 · H.264+ · H.264
On-Board Storage
Up to 8 GB built-in eMMC (people-count data)
Network
RJ-45 · ONVIF (Profile S / G) · HTTPS · FTP · SNMP
Power Source
12 VDC ±20% · PoE (802.3af) · max 8.5 W
Weatherproof Rating
IP67
Dimensions / Weight
168 × 61 × 41 mm · 435 g
Warranty
3-Year Australian Warranty
Frequently Asked Questions
Why does it have dual lenses?The dual-lens design enables accurate bi-directional people counting — measuring people entering and exiting at the same time — for reliable in/out footfall data at an entrance.
What can I do with the people-count data?The camera provides real-time statistics and trend analysis for footfall — valuable for retail marketing, staff rostering, occupancy management and security planning.
Where is it best installed?It is designed for overhead mounting at entrances and exits — retail stores, shopping centres, office buildings and airports — where accurate footfall counting is required.
How is it powered?It supports PoE (802.3af) over a single Cat 6 cable, or 12 VDC for standalone installs, drawing a maximum of 8.5 W.
Downloads & Resources
DS-2CD6825G0/C-IVS Datasheet
Hikvision Network Camera User Manual
Order the Hikvision DS-2CD6825G0/C-IVS from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision people-counting cameras. The DS-2CD6825G0/C-IVS is the right choice for accurate footfall analytics at retail, office, shopping-centre and transit entrances. Order with fast Australia-wide dispatch, expert pre-sales advice and full local warranty support. Request a free quote or contact our Australian team.
Professional Video Intercom · Hikvision Pro Series · Keypad + Card + App · PoE + WiFi 6
Hikvision DS-KV6124-WBE1 — 4MP Keypad Video Intercom Door Station
The Hikvision DS-KV6124-WBE1 is the complete access control door station for Australian homes, offices, Airbnb properties, and commercial sites that need more than a basic video doorbell. It combines a 4MP wide-angle camera, keypad PIN entry, RFID card reader, Bluetooth, and Hik-Connect app unlock into one sleek, weatherproof unit — powered by PoE or 12V DC, with WiFi 6 for flexible installation.
Unlike standard intercom door stations, the DS-KV6124-WBE1 supports dual lock output — control two separate doors, gates, or access points from a single device. Assign individual PIN codes per user, issue RFID cards, or let guests unlock remotely via the Hik-Connect app. No keys, no locksmith, no hassle.
Camera
4MP · 150° Wide Angle
Access
PIN / Card / App / BT
Power
PoE + WiFi 6
Lock Control
Dual Output
Night Vision
IR Supplement
Protocol
TCP/IP · ONVIF · RTSP
2-Year Australian Warranty
Australian Stock · Fast Dispatch
Expert Australian Tech Support
Key Features
4MP Wide-Angle Camera
150° horizontal field of view captures the full entry area — faces, hands, and surroundings — in sharp 4MP detail. Built-in IR supplement ensures clear footage at night without external lighting.
Keypad PIN Access
Assign individual PIN codes to residents, staff, or guests. Ideal for Airbnb, rental properties, and offices where physical key management is impractical. Change or revoke codes instantly via the Hik-Connect app.
RFID Card Reader (13.56 MHz M1)
Issue M1 RFID cards or fobs to authorised users. Fast tap-to-unlock — no PIN required for regular users. Cards can be added or removed remotely without replacing hardware.
Bluetooth + Hik-Connect App Unlock
Unlock the door from your smartphone via Bluetooth proximity or remotely via the Hik-Connect app over the internet. Answer video calls, view live footage, and grant access from anywhere in the world.
Dual Lock Output
Control two independent locks, gates, or access points from a single door station. Perfect for properties with a front gate and front door, or a reception door and server room.
PoE + WiFi 6 Connectivity
Power and network via a single Cat6 cable (PoE IEEE 802.3at), or connect wirelessly via WiFi 6 (2.4GHz). Flexible installation for new builds and retrofits alike.
DS-KV6124-WBE1 vs DS-KV6114-WBE1 — Which Should You Choose?
Both models share the same 4MP camera and PoE + WiFi 6 platform. The key difference is the keypad — here's how to decide:
Choose DS-KV6114-WBE1 if…
You need a clean, minimal video intercom for a single-family home where all users have the Hik-Connect app or RFID cards. No PIN entry required. Simpler setup, lower cost.
Choose DS-KV6124-WBE1 if…
You need keypad PIN access for multiple users — Airbnb guests, office staff, delivery drivers, or tradespeople. The keypad makes it a true access control system, not just a video doorbell.
Offices & Commercial Sites
The DS-KV6124 is the right choice for any site where staff need PIN-based entry without issuing physical keys or RFID cards to every person.
Rental & Airbnb Properties
Assign a unique PIN per booking period. Guests check in without a key handover. Change the code between guests in seconds via the app. No locksmith, no key safe, no hassle.
Recommended For
Airbnb & Short-Stay Rentals
Issue a unique PIN per booking. Guests self-check-in without a key handover. Change codes between stays in seconds via the Hik-Connect app.
Offices & Staff Entry
Assign PIN codes and RFID cards to staff. Revoke access instantly when someone leaves. No rekeying, no lost key headaches.
Medical & Dental Clinics
Control reception and treatment-area access. Dual lock output manages the front door and a secure internal door from one unit.
Residential Homes
Replace a traditional doorbell with a full video intercom and keypad. Family members each get their own PIN — no more hiding a key under the mat.
Warehouses & Industrial Sites
Manage after-hours contractor access with time-limited PINs. Dual lock output controls the roller door and the office entry independently.
Schools & Childcare Centres
Secure entry with PIN + video verification. Staff unlock remotely via app; authorised visitors use a PIN. NDAA-compliant Hikvision hardware for government procurement.
Technical Specifications
Camera & Video
4MP resolution · 150° wide-angle lens · IR night vision supplement · H.264 video compression · RTSP stream support
Access Methods
PIN code (keypad) · RFID card (M1, 13.56 MHz) · Bluetooth · Hik-Connect app (remote) · Indoor monitor unlock
Lock & Relay Output
2 × lock relay outputs (dual lock control) · Supports electric strike, magnetic lock, and electric bolt
Power & Network
PoE (IEEE 802.3at) · 12V DC input · WiFi 6 (2.4GHz) · TCP/IP · ONVIF · RTSP
Build & Environment
IP65 weatherproof · IK07 vandal-resistant · Flush or surface mount · Operating temp: -40°C to +60°C
Compatibility
Hik-Connect platform · Compatible with Hikvision indoor monitors (DS-KH series) · ONVIF for third-party integration
More Information
Datasheet
P2P Setup Guide
Quick Start Guide
Frequently Asked Questions
What is the difference between DS-KV6124 and DS-KV6114?The DS-KV6124 includes a keypad for PIN code access, making it a full access control system. The DS-KV6114 has no keypad and suits simpler app or card-based entry.
Can I unlock the door using my phone?Yes — the Hik-Connect app lets you answer video calls and unlock doors remotely from anywhere with an internet connection.
What unlock methods are supported?PIN code, RFID card (M1 13.56 MHz), Bluetooth, Hik-Connect app, and indoor monitor unlock.
Do I need a PoE switch?A PoE switch is recommended for stable power and network. You can also use the 12V DC input or WiFi 6 for wireless-only installations.
Can this control a gate and a door at the same time?Yes — the dual lock relay output lets you independently control two access points (e.g. front gate + front door) from one unit.
Is this suitable for Airbnb or rental properties?Yes — assign a unique PIN per guest booking and change it between stays via the app. No key handover, no locksmith.
Can I add indoor monitors?Yes — pair with Hikvision DS-KH series indoor monitors for a full intercom system across multiple rooms or floors.
Is it weatherproof?Yes — IP65 rated and IK07 vandal-resistant, suitable for outdoor installation in all Australian weather conditions.
Does it work over WiFi only?Yes — WiFi 6 (2.4GHz) is supported for wireless-only installs, though wired PoE is recommended for maximum reliability.
What's the warranty?2-year Australian warranty, supported locally by CCTV Guru's Australian technical team.
Do you ship Australia-wide?Yes — fast dispatch to every state and territory from Australian stock.
Order the Hikvision DS-KV6124-WBE1 from CCTV Guru
CCTV Guru is an authorised Australian distributor of Hikvision access control and intercom products. Order the Hikvision DS-KV6124-WBE1 4MP Keypad Video Intercom Door Station today for fast Australia-wide dispatch, expert pre-sales advice on lock wiring and indoor monitor pairing, and full local warranty support. Contact our Australian team to build a complete intercom system with indoor monitors, PoE switches, and electric locks.
Looking for a simpler option without a keypad? View the DS-KV6114-WBE1 →
Dahua · DH-PFT1500 · 5-Port Hi-PoE Extender · 90W · 250m
Hi-PoE Extender
Dahua DH-PFT1500 5-Port Long-Distance PoE Extender
The Dahua DH-PFT1500 takes a single PoE feed and re-powers up to 4 PoE cameras far from your switch, extending PoE transmission to 250 metres with a 90W Hi-PoE budget. It accepts a Gigabit PoE input and powers Dahua and standard IP PoE cameras — including PTZ, AI and multi-sensor models — in a fanless, full-metal industrial body.
Ports
5 (1 in + 4 out)
PoE Output Ports
4 × PoE
PoE Budget
90W total
Max Reach
250m (10Mbps)
PoE Standards
af/at/bt · Hi-PoE
Mounting
Desktop / DIN-rail
Reach Cameras 250m Out
Re-powers the PoE feed so cameras at the far edge of a site — car parks, perimeters, long driveways — stay online well beyond the usual 100m Ethernet limit.
90W Hi-PoE Headroom
Port 1 delivers up to 90W and ports 2–4 up to 30W each, enough for PTZ, AI and multi-sensor cameras that standard PoE+ can't drive.
Built for the Outdoors
Fanless full-metal enclosure, −30°C to +65°C operation and 4kV/2kV surge protection for harsh industrial and roadside installs.
PoE Watchdog
Detects frozen cameras and automatically power-cycles the port to restore the stream — no truck roll for a stuck IPC.
Specifications — DH-PFT1500
Model / SKU
DH-PFT1500
Ports
1 × RJ45 10/100/1000 PoE input, 4 × RJ45 10/100 PoE output
PoE Standards
IEEE 802.3af / 802.3at / 802.3bt / Hi-PoE
PoE Output
Port 1 ≤ 90W, Ports 2–4 ≤ 30W, Total ≤ 90W
Long-Distance PoE
Up to 250m (bandwidth reduced to 10Mbps)
Switching Capacity
2.8 Gbps
Forwarding Rate
2.08 Mpps
MAC Address Table
4K
Operating Temperature
−30°C to +65°C
Protection
ESD 8kV air / 6kV contact; Lightning 4kV common / 2kV differential
Mounting
Desktop or DIN-rail
Dimensions
150 × 100 × 30 mm
Warranty (Australia)
3 years · CCTV Guru Australia
Downloads & Resources
DH-PFT1500 Datasheet
How does the DH-PFT1500 extend PoE distance?It takes a single PoE input from your switch or injector and re-powers up to four downstream PoE cameras, pushing total reach to 250m. In long-distance mode the link runs at 10Mbps, which is ample for a single camera stream.
Will it power a PTZ camera?Yes. Port 1 supplies up to 90W Hi-PoE, comfortably driving PTZ, AI and multi-sensor cameras that need more than standard PoE+.
Can I mount it outdoors?The fanless metal body is rated −30°C to +65°C with 4kV/2kV surge protection. House it in a weatherproof enclosure for exposed locations.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision TandemVu · 6MP Panoramic + 4MP 42× PTZ · 300 m IR · NEMA 4X
Hikvision TandemVu PTZ · 6MP + 4MP
Hikvision DS-2SF8C442MXG1-ELWY/26 — TandemVu 6MP Panoramic + 4MP 42× DarkFighter 2.0 PTZ Speed Dome with 300 m IR (NEMA 4X Anti-Corrosion)
The Hikvision DS-2SF8C442MXG1-ELWY/26 is Hikvision's flagship TandemVu dual-sensor speed dome — a single chassis that combines a 6 MP ultra-wide panoramic bullet (190° HFOV, F1.0) with a 4 MP 42× motorised PTZ (6–252 mm, F1.3), both running on one IP address and one VMS licence. The panoramic channel holds the full situational view at all times while the PTZ channel zooms, pans and tilts to follow incidents — handing off automatically via Auto-Tracking 3.0 with linked tracking capture. DarkFighter 2.0 on the PTZ delivers 0.0003 lux colour; the panoramic delivers 0.0005 lux colour at F1.0. Long-range night surveillance is covered by a built-in 300 m IR illuminator on the PTZ plus 30 m white-light supplement on the panoramic. The -Y suffix on this Australian-stocked SKU denotes Hikvision's moderate anti-corrosion housing — NEMA 4X-rated for coastal Australian sites within roughly 2 km of the shoreline and for areas exposed to acid rain.
This is the camera Hikvision builds for the situations where a conventional PTZ "loses the room" the moment it zooms in — large transport hubs, mining haul roads, port aprons, council CBDs, perimeter walls, scenic-spot overwatch, large industrial campuses, public squares and stadium concourses. With the panoramic channel constantly recording the full 190° scene, an operator (or the AI engine) can investigate any detected event close-up via the PTZ without ever losing the wide view. The bullet channel keeps situational context — who else is in frame, where the target came from, where they're heading — while the 42× PTZ captures the face, the plate, the badge or the action close-up. Cyber-hardened with TPM 2.0 (FIPS 140-2 Level 2), IP67/IK10 rated and powered via PoE 802.3bt Type 4 (90 W) or 36 VDC. Australian stock, 3-year Australian warranty.
TandemVu Channels
6MP Panoramic + 4MP PTZ
PTZ Zoom
42× optical · 6–252 mm · F1.3
Night Imaging
300 m IR · 30 m white · DarkFighter 2.0
AI Engine
Auto-Tracking 3.0 · Face · ANPR
Protection
IP67 · IK10 · NEMA 4X (-Y)
Power
PoE 802.3bt Type 4 · 36 VDC · 90 W
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
See TandemVu in Action — Two Channels, One Camera
Hikvision's official TandemVu demonstration shows the panoramic-plus-PTZ workflow on-screen: the wide channel holds the full scene while the PTZ tracks and zooms in on detected targets simultaneously. The two views are streamed from a single IP address and recorded against a single VMS licence.
Why Choose a TandemVu PTZ over a Single-Sensor PTZ
A conventional PTZ has one fundamental compromise: the moment you zoom in, you lose the wide situational view. If something is happening at the other end of your site, no one is watching. TandemVu fixes this by adding a full-time 6 MP 190° panoramic channel next to the 42× PTZ — the bullet keeps recording the entire scene while the PTZ goes hunting. For high-value, high-coverage sites, this is the difference between an investigation that succeeds and one that comes up short.
6 MP Panoramic — Never Loses the Room
1/2.5" CMOS · 3680 × 1656 (6 MP) · 2.8 mm · F1.0 · 190° horizontal FOV · tilt-adjustable 12°-24°. The bullet records the full scene continuously — even while the PTZ is zoomed in on a specific target at 42×.
4 MP 42× PTZ — Long-Range Detail
1/1.8" CMOS · 2688 × 1520 (4 MP) · 6–252 mm motorised · 42× optical + 16× digital · F1.3 · DarkFighter 2.0. PTZ DORI Identify 296.6 m at full telephoto. Reads faces and plates at distances a single-sensor camera cannot reach.
Auto-Tracking 3.0 + Linked Tracking Capture
The bullet detects a human, vehicle or armed face anywhere in the 190° scene. The PTZ automatically slews to the target, locks on, and follows it across the site — capturing close-up evidence frames the whole time, while the bullet continues recording the wide view.
One IP, One Licence, One Cable
The two channels stream from a single IP address over a single Cat 6 cable. One VMS / NVR licence covers both — half the licence cost of running a separate bullet plus a separate PTZ at the same site.
300 m IR + 30 m White Light
Built-in IR illuminator on the PTZ reaches up to 300 m at full telephoto. The panoramic channel has its own 30 m white-light array for the close-up wide scene — also usable as audio-visual deterrent (flashing light + audible warning).
120 / 150 dB AWDR — Both Channels
Bullet at 120 dB, PTZ at 150 dB AWDR. Both channels handle backlit gateways, low-sun port aprons, mine-pit edges, mixed sodium / LED city lighting and stadium floodlights without burning out faces or losing detail in shadows.
Important Install Note — PoE 802.3bt Type 4 (90 W) or 36 VDC
The DS-2SF8C442MXG1-ELWY/26 is a high-power dual-sensor PTZ. It runs on either PoE 802.3bt Type 4 (42.5-57 V, 1.76 A — full ~90 W from the switch / injector) or a dedicated 36 VDC supply at 2.5 A. Standard 802.3at PoE+ (25.5 W) and Hi-PoE 60 W will not reliably power this camera, especially with the heater, IR ring, white-light array and PTZ motors all under load.
PoE 802.3bt Type 4 injector or switch on the camera's network run — single Cat 6 cable carries data and 90 W of power. Simplest install for most sites.
36 VDC dedicated supply at the camera — used where you're running fibre to the camera or where you prefer to separate power and data drops.
The chassis weighs ≈ 10.5 kg — heavier than a single-sensor PTZ. Use a Hikvision pendant / wall / pole mount rated for the load, and check that the substrate and bracket together can support the camera plus wind loading over a 10-year service life. Contact our Australian team for the right 90 W PoE++ injector, 36 VDC supply or heavy-duty mount for your site.
Deep-Learning AI — Both Channels Working Together
The TandemVu architecture lets the two channels collaborate. The bullet sees the wide scene and detects events; the PTZ closes in on the target and captures evidence frames. The on-camera deep-learning engine handles classification, tracking and metadata generation locally — no central AI server required for the camera-level work.
Auto-Tracking 3.0 — Bullet Sees, PTZ Follows
The panoramic detects motion and classifies the target (human, vehicle, face). The PTZ automatically slews to the target's GPS-mapped location in the wide frame, locks on, and tracks the target through the scene at zoom. Linked tracking capture uploads best-frame close-ups during the entire follow.
Perimeter Protection — On Both Channels
Line crossing, intrusion, region entrance and region exiting detection — filtered by human / vehicle classification — run on the panoramic AND the PTZ independently. Catch perimeter breaches in the wide view and validate them with the PTZ close-up.
Multi-Target-Type Detection
Simultaneous detection of face (7 features), human body (14 features) and vehicle (8 features) — rich metadata indexed against your VMS for fast post-incident search.
Face Capture — 30 Simultaneous
The PTZ captures up to 30 faces simultaneously, grades face quality, and uploads the best frame plus background context. Useful at port gates, mining-camp entries, transit stations and large-venue access points.
Face Comparison — 150,000 Total
10 face libraries × 30,000 faces = 150,000 total with encrypted on-camera storage. Enterprise-scale watchlist comparison runs at the camera — even if the VMS is offline.
Object Arming — Person + Vehicle
Arm specific faces, human IDs or vehicles. When the camera detects an armed target in the scene, it triggers an alarm and switches to tracking-and-capture mode, uploading target location and context continuously.
About On-Camera ANPR (Checkpoint Scenario Only)
The DS-2SF8C442MXG1-ELWY/26 supports on-camera number-plate recognition via its deep-learning Road Traffic and Vehicle Detection engine — ≥98% LPR accuracy, 4 LPR region presets (including Asia-Pacific), a 10,000-record blocklist / allowlist, vehicle attribute capture (type, colour, brand, direction) and vehicle counting. Important caveat: Hikvision specifies LPR support only in a checkpoint scenario — meaning the camera is fixed on a defined approach lane where vehicles drive toward (or past at limited angle) the lens, at known speeds. Up to 120 km/h front-on capture, 80 km/h side capture. This is not the right tool for free-flow surveillance ANPR where the PTZ is also being used for general monitoring — for that workload, choose a dedicated DeepinView ANPR bullet (iDS-2CD7A46G2/P-IZHSY or iDS-2CD7A45G2/P-IZHSY). TandemVu's strength is simultaneous wide-scene + PTZ overwatch with auto-tracking — ANPR is a bonus, not the headline.
PTZ Kinematics — 360° Endless Pan, 300 Presets, 3D Positioning
360° Endless Pan · 240°/s Preset
360° continuous pan with preset speed up to 240°/s and configurable speed from 0.1°/s to 160°/s. Suited for site-wide patrols and rapid handoff between defined incident-response presets.
Tilt −20° to +90° · 200°/s Preset
PTZ tilt from −20° (below horizon, for tall-pole sites with ground beneath) to +90° (straight up) with preset speed to 200°/s. Panoramic channel has its own independent tilt adjustment (12°-24°) to set the wide-scene framing at install.
300 Presets · 8 Patrols · 4 Patterns
300 PTZ presets, 8 patrol routes (32 presets each) and 4 pattern scans with 10+ minutes of recorded movement each. Schedule the PTZ to walk an automated patrol while the bullet keeps recording the full scene.
3D Positioning · Click-to-Frame
Click anywhere on the panoramic live view to centre-frame and zoom the PTZ on that point in one action. The fastest way for an operator to investigate a wide-scene event at zoom.
Technical Specifications
DS-2SF8C442MXG1-ELWY/26 · Full Specifications
SKU
DS-2SF8C442MXG1-ELWY/26 (AU-stocked default — NEMA 4X anti-corrosion, wiper, IR)
Camera Type
Hikvision TandemVu SF8C Series · 6 MP Panoramic + 4 MP 42× DarkFighter 2.0 PTZ Speed Dome
Image Sensor (Panoramic)
1/2.5" Progressive Scan CMOS
Image Sensor (PTZ)
1/1.8" Progressive Scan CMOS · DarkFighter 2.0
Max Resolution (Panoramic)
3680 × 1656 (6 MP)
Max Resolution (PTZ)
2688 × 1520 (4 MP)
Min. Illumination (Panoramic)
Colour 0.0005 lux @ F1.0 · B/W 0.0001 lux @ F1.0 · 0 lux with white light
Min. Illumination (PTZ)
Colour 0.0003 lux @ F1.2 · B/W 0.0001 lux @ F1.2 · 0 lux with IR
Shutter Speed
1 s to 1/30,000 s · Slow Shutter
Lens (Panoramic)
Fixed · 2.8 mm · F1.0 · 190° HFOV / 80° VFOV
Lens (PTZ)
Motorised · 6–252 mm · 42× optical · F1.3 · 16× digital · auto / semi-auto / manual focus
PTZ Field of View
Horizontal 59° → 2° · Vertical 34.2° → 1.1° · Diagonal 67.1° → 2.3°
Zoom Speed (PTZ)
Approx. 5.6 s (wide ↔ tele)
Supplement Light (Panoramic)
White light up to 30 m · audio-visual alarm capable
Supplement Light (PTZ)
Smart IR up to 300 m
Day & Night
Both channels: Day / Night / Schedule / Auto
Wide Dynamic Range
Bullet 120 dB · PTZ 150 dB AWDR · HLC · 3D DNR · optical defog
Image Stabilisation
Built-in gyroscope EIS
Pan Range / Speed
360° endless · 0.1°-160°/s configurable · preset 240°/s · proportional pan
Tilt Range / Speed (PTZ)
−20° to +90° · 0.1°-120°/s · preset 200°/s
Tilt Range (Panoramic)
12° to 24° adjustable
Presets / Patrols / Patterns
300 presets · 8 patrols (32 presets each) · 4 pattern scans
3D Positioning
Yes — click on panoramic to centre PTZ
Frame Rate (Panoramic)
50 Hz: 25 fps @ 6 MP · 60 Hz: 30 fps @ 6 MP
Frame Rate (PTZ)
50 Hz: 50 fps @ 4 MP / 100 fps @ 1080p · 60 Hz: 60 fps @ 4 MP / 120 fps @ 1080p (monitoring mode)
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG
Streams
3 simultaneous per channel
Video Bit Rate
32 Kbps – 16 Mbps · CBR / VBR · SVC · ROI (8 fixed regions per stream)
Deep-Learning AI
Perimeter Protection (line crossing / intrusion / region entry & exit · human + vehicle classification) — on both channels
Face Capture
Up to 30 simultaneous faces · grade / select / upload best frame + context
Face Comparison
10 libraries × 30,000 faces = 150,000 total · encrypted face library
ANPR / LPR
≥98 % LPR · 10,000 blocklist · 4 region presets · vehicle attributes / counting · checkpoint scenario only, ≤120 km/h front, ≤80 km/h side
Smart Tracking
Auto-Tracking 3.0 · manual + automatic · linked tracking capture · person + vehicle arming
Audio
1 line-in · 1 line-out · 1 built-in speaker · G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC / MP3
Alarm I/O
7 inputs · 2 outputs
RS-485
1 × RS-485 — HIKVISION / Pelco-P / Pelco-D self-adaptive
Ethernet
1 × RJ-45 100 Mbps self-adaptive
On-Board Storage
microSD / SDHC / SDXC up to 1 TB · NAS (NFS / SMB-CIFS) · ANR
API & Protocols
ONVIF (Profile S / G / T / M) · ISAPI · SDK · ISUP · OTAP
Cyber Security
TPM 2.0 (FIPS 140-2 Level 2) · HTTPS · 802.1X · IP filter · watermark · MAC host authentication
Power Source
36 VDC @ 2.5 A · PoE 802.3bt Type 4 (42.5–57 V, 1.76 A) · max ~90 W
Heater + Demist + Wiper
YES + YES + YES
Operating Temperature
−40 °C to +70 °C · speaker −30 °C to +55 °C
Material / Dimensions
ADC12 aluminium die-cast · Ø 290 mm × 453.2 mm · ≈ 10.5 kg
Weatherproof Rating
IP67
Vandal Resistance
IK10 (excluding glass window)
Anti-Corrosion
NEMA 4X — Y variant · moderate Hikvision protection tier
DORI (PTZ Tele)
Detect 2,965.5 m · Observe 1,176.8 m · Recognise 593.1 m · Identify 296.6 m
Approvals
CE-EMC · CE-LVD · RCM (AS/NZS CISPR 32:2015) · IC ICES-003 · CB · RoHS · WEEE · REACH
Warranty
3-Year Australian Warranty (back-to-base)
DS-2SF8C442MXG1-ELWY/26 (TandemVu) vs DS-2DF7A436IXG-EL(Y) (Single-Sensor PTZ)
The closest single-sensor sibling is Hikvision's DS-2DF7A436IXG-EL(Y) — a 4 MP 36× DarkFighter 2.0 IR PTZ that shares much of the same imaging chain at the PTZ end. The TandemVu adds a full-time 6 MP panoramic channel next to the PTZ for situational awareness that a single-sensor camera structurally cannot provide.
DS-2SF8C442MXG1-ELWY/26 (TandemVu) vs DS-2DF7A436IXG-EL(Y) (single-sensor PTZ)
Feature
DS-2SF8C442MXG1-ELWY/26 (this — TandemVu)
DS-2DF7A436IXG-EL(Y) (single-sensor 7A IR PTZ)
Sensor Architecture
Dual — 6 MP panoramic + 4 MP PTZ
Single — 4 MP PTZ only
Wide Scene Recording
Yes — 6 MP 190° HFOV at all times
No — only what the PTZ is currently aimed at
PTZ Optical Zoom
42× · 6–252 mm · F1.3
36× · 6–216 mm · F1.2
WDR
Bullet 120 dB · PTZ 150 dB
150 dB AWDR (PTZ only)
IR Illuminator
PTZ up to 300 m
Up to 300 m
White Light
Bullet 30 m (AV alarm capable)
—
Deep-Learning AI
Perimeter · face capture (30) · face comp (150k) · ANPR (checkpoint) · auto-tracking 3.0 + linked tracking capture — on both channels
Perimeter · face capture (30) · face comp (150k) · auto-tracking 3.0 — PTZ only
Auto-Tracking
Bullet detects → PTZ slews automatically
PTZ tracks within its own field of view only
ANPR / LPR
Yes (checkpoint, ≥98 %)
—
Cyber Security
TPM 2.0 · FIPS 140-2 L2
TPM 2.0 · FIPS 140-2 L2
Power
PoE 802.3bt Type 4 · 36 VDC · ~90 W
PoE 802.3bt Class 8 · 36 VDC · ~90 W
Heater / Demist / Wiper
Yes / Yes / Yes
Yes / Yes / No
Weight / Dimensions
≈ 10.5 kg · Ø 290 × 453.2 mm
≈ 5 kg · Ø 215 × 297 mm
Best For
Large high-coverage sites where situational awareness can't be lost when the PTZ zooms in — ports, mining haul roads, council CBDs, transit hubs, stadiums, scenic-spot overwatch, perimeter walls, public squares. Single IP, single VMS licence for two channels.
Long-range surveillance where one PTZ view is enough and a wide channel isn't required — perimeter overwatch on small-to-medium sites, rural property boundaries, single-approach mining roads.
For the single-sensor sibling: DS-2DF7A436IXG-EL(Y) (Ultra 7A · single-sensor IR PTZ) →
Recording NVRs — Plan for Two Channels per Camera
Because TandemVu cameras stream as two IP channels from one camera, plan your NVR channel count and storage to recognise that each TandemVu unit consumes two NVR licences and two streams' worth of bandwidth and disk. Any modern Hikvision NVR supporting ONVIF Profile S/G/T/M or Hikvision ISAPI is compatible. For multi-site rollouts with rich AI metadata, VPro AcuSeek and DeepinMind NVRs unlock natural-language search across the recording.
DS-7616NXI-I2/16P/VPro — 16CH · AcuSeek AI
Sixteen channels supports up to 8 TandemVu cameras (two channels each) — well-sized for a single high-coverage site with a couple of dual-sensor PTZs plus perimeter coverage. View DS-7616NXI-I2/16P/VPro →
DS-7732NXI-I4/16P/VPro — 32CH · AcuSeek AI
Thirty-two channels with 16 PoE ports and 4 HDD bays — the standard mid-tier VPro AcuSeek platform for council, port, mining and multi-building campus rollouts with several TandemVu units. View DS-7732NXI-I4/16P/VPro →
iDS-7716NXI-M4/16P/X — 16CH · DeepinMind
DeepinMind X-Series — Hikvision's most capable 16-channel AI NVR for face-recognition workloads and AcuSearch natural-language search across the fleet. View iDS-7716NXI-M4/16P/X →
DS-7608NXI-I2/8P/VPro — 8CH · AcuSeek AI
Eight-channel VPro AcuSeek AI NVR with 8 built-in PoE ports — sized for a single TandemVu unit plus a handful of perimeter cameras. View DS-7608NXI-I2/8P/VPro →
Important: the TandemVu PTZ does not draw power from these NVRs' built-in PoE ports — it needs a separate PoE 802.3bt Type 4 (90 W) injector or a 36 VDC supply. Browse the full Hikvision NVR range: Hikvision Network Video Recorders →.
Compatible Mounts & Accessories
DS-2115ZJ-PSAC — Pendant Mount
Hikvision's pendant mount kit sized for the SF8C TandemVu chassis. Used where the camera hangs from a horizontal beam, eave or carport gantry — the most common heavy-PTZ install style.
DS-4614ZJ-PAAC — Wall Mount
Heavy-duty wall mount rated for the TandemVu's mass and wind loading. Pairs with the DS-1684ZJ-P-Y junction box for clean cable termination behind the bracket.
DS-1684ZJ-P-Y — Junction Box
Anti-corrosion junction box matched to the -Y variant chassis. Provides a sealed cable termination cavity behind the mount, keeping conduit fittings out of weather.
PoE 802.3bt Type 4 (90 W) Injector / Switch
Required if you're not powering the camera from a separate 36 VDC supply. Make sure the injector or switch is genuinely Type 4 (90 W) — standard PoE+ and Hi-PoE 60 W will not reliably power this camera under full load.
Frequently Asked Questions
What is TandemVu and why is it different from a normal PTZ?TandemVu is Hikvision's dual-sensor PTZ architecture: one chassis houses both a fixed wide-angle bullet (190° HFOV here) and a traditional zoom PTZ. The two sensors run as two independent IP channels from a single network drop. Result: the bullet keeps recording the wide scene at all times, even while the PTZ zooms in and tracks a target. A conventional PTZ loses the wide view the moment it zooms — TandemVu doesn't.
How many channels does this consume on my NVR?Two channels per camera. Each TandemVu unit shows up as two streams (panoramic + PTZ) and consumes two NVR licences. Account for this when sizing the NVR — eight TandemVu cameras = 16 channels.
Does it really support ANPR / number-plate recognition?Yes — but only in a checkpoint scenario. The camera must be fixed on a defined approach lane with vehicles facing the lens (or at limited side angle), at known speeds up to 120 km/h front or 80 km/h side. Accuracy is ≥98 %. This is not a free-flow ANPR camera. For free-flow ANPR on a busy road, choose a dedicated DeepinView ANPR bullet such as the iDS-2CD7A46G2/P-IZHSY.
What does the "-Y" suffix mean and which variant do you stock?The -Y suffix indicates Hikvision's moderate anti-corrosion housing — NEMA 4X-rated, designed for coastal Australian sites within ~2 km of the shoreline and areas affected by acid rain. We stock the DS-2SF8C442MXG1-ELWY/26 (with -Y) as our Australian default.
What does the "/26" suffix in the model number mean?The "/26" denotes the specific variant of this TandemVu SF8C series — Hikvision uses the suffix to distinguish the panoramic-lens and PTZ-zoom-range combination for this SKU.
Why doesn't it run on standard PoE+ or Hi-PoE?Two sensors, two image processors, a 90 W heater / IR / white-light / wiper load and PTZ motors push total demand to around 90 W. Standard PoE+ (IEEE 802.3at, 25.5 W) and Hi-PoE 60 W are not enough headroom. The camera requires PoE 802.3bt Type 4 (90 W) or a dedicated 36 VDC supply at 2.5 A.
How does Auto-Tracking 3.0 work across the two channels?The panoramic detects a target and classifies it (human / vehicle / armed face). The PTZ automatically slews to the target's mapped location in the 190° frame, zooms in, and tracks the target as it moves through the scene. The bullet keeps recording the wide context for the entire follow — so you get both the situational view and the close-up evidence frames simultaneously.
How far away can the PTZ identify a target?Per EN 62676-4 criteria at full telephoto: PTZ Detect 2,965.5 m · Observe 1,176.8 m · Recognise 593.1 m · Identify 296.6 m.
Downloads & Resources
DS-2SF8C442MXG1-ELWY/26 Datasheet
Hikvision TandemVu PTZ Quick Start Guide
Hikvision TandemVu PTZ User Manual
Order the Hikvision DS-2SF8C442MXG1-ELWY/26 from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision TandemVu PTZ cameras. Order the DS-2SF8C442MXG1-ELWY/26 6 MP Panoramic + 4 MP 42× DarkFighter 2.0 PTZ with 300 m IR, 30 m white light, Auto-Tracking 3.0 and NEMA 4X anti-corrosion housing for fast Australia-wide dispatch, expert pre-sales advice, project pricing for multi-camera and multi-PTZ rollouts, and full local warranty support. Designing a TandemVu deployment for a port, mining haul road, council CBD, public square, transit hub, scenic-spot overwatch or large industrial campus? Request a free quote or contact our Australian team for tailored camera-and-NVR sizing — we'll spec the right 90 W PoE++ injector or 36 VDC supply and the right heavy-duty mount at the same time.
Hikvision Ultra Series · 4MP · 42× Zoom · DarkFighter 2.0 · 400 m IR
Hikvision DS-2DF8442IXG1-ELWY — 4MP 42× Zoom DarkFighter 2.0 Ultra Series PTZ (6-250 mm, 400 m IR, IP67/IK10)
The Hikvision DS-2DF8442IXG1-ELWY is a flagship Ultra Series PTZ speed dome built for long-range, wide-area surveillance. A 42× optical zoom (6-250 mm) plus 16× digital reaches right across ports, yards, perimeters and large public spaces, while DarkFighter 2.0 delivers clean colour down to 0.0003 lux @ F1.2 and IR up to 400 m in full darkness. 150 dB adaptive WDR handles extreme contrast, on-board smart analytics drive face capture and vehicle detection, and the camera offers 360° continuous pan with −20° to +90° tilt and auto-flip. A built-in wiper and rugged IP67 / IK10 housing keep it working in harsh Australian outdoor sites. Australian stock, 3-year Australian warranty.
Resolution
4 MP · 2688 × 1520
Optical Zoom
42× · 6-250 mm
Night Vision
DarkFighter 2.0 · 400 m IR
Smart AI
Face Capture · Vehicle Detect
Pan / Tilt
360° · −20° to +90°
Protection
IP67 · IK10 · 150 dB WDR
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why Choose the DS-2DF8442IXG1-ELWY
42× Long-Range Zoom
A 6-250 mm motorised lens with 42× optical (plus 16× digital) reads faces and number plates right across ports, yards and perimeters far beyond any fixed camera.
DarkFighter 2.0 · 400 m IR
Holds colour to 0.0003 lux and switches to 400 m IR in full darkness — clear long-range footage day and night across huge sites.
Smart Analytics
On-board face capture and vehicle detection with traffic analytics surface the events that matter from wide, busy scenes.
Built-in Wiper · IP67 / IK10
An integrated wiper clears rain and dust from the dome, while IP67 weatherproofing and IK10 vandal resistance suit exposed, high-risk locations.
Technical Specifications
DS-2DF8442IXG1-ELWY · Full Specifications
SKU
DS-2DF8442IXG1-ELWY
Camera Type
Hikvision Ultra Series 4 MP DarkFighter 2.0 Network PTZ Speed Dome
Image Sensor
1/1.8" Progressive Scan CMOS
Max Resolution
2688 × 1520 (4 MP)
Optical Zoom
42× · 6-250 mm motorised lens
Digital Zoom
16×
Min. Illumination
Colour 0.0003 lux @ F1.2 · B/W 0.0001 lux · 0 lux with IR
Low-Light Tech
DarkFighter 2.0
IR Range
Up to 400 m (smart IR)
Wide Dynamic Range
150 dB adaptive WDR
Pan / Tilt
Pan 360° continuous · Tilt −20° to +90° · auto-flip
Smart Analytics
Face capture · vehicle detection · traffic analytics
Video Compression
H.265+ · H.265 · H.264+ · H.264
Extras
Built-in wiper · "Y" anti-corrosion variant available
Network & Protocols
RJ-45 · ONVIF · Hik-Connect
Protection
IP67 · IK10
Warranty
3-Year Australian Warranty
Frequently Asked Questions
How far can it see and identify detail?The 42× optical zoom (6-250 mm) plus DarkFighter 2.0 and 400 m IR pick up faces and number plates well across large car parks, ports, yards and perimeters — far beyond any fixed camera.
How is it powered?A PTZ of this class requires Hi-PoE or a 24 VAC supply — confirm the exact power input on the datasheet and budget for it; a standard 802.3af port is not sufficient.
Will it work with my NVR?Yes — it's ONVIF compatible and integrates fully with Hikvision NVRs and Hik-Connect for live view, PTZ control, recording and playback.
Downloads & Resources
DS-2DF8442IXG1-ELWY Datasheet
Hikvision Speed Dome Quick Start Guide
Hikvision Speed Dome User Manual
Order the Hikvision DS-2DF8442IXG1-ELWY from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision Ultra Series PTZ cameras. The DS-2DF8442IXG1-ELWY pairs 4 MP imaging, a 42× long-range zoom, DarkFighter 2.0 low-light and 400 m IR for serious perimeter, port and large-area surveillance. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch. Request a free quote or contact our Australian team.
Hikvision Ultra Series · 7A PTZ · 4MP · 36× Optical · DarkFighter 2.0 · 300 m IR · 150 dB AWDR · NEMA 4X
Hikvision DS-2DF7A436IXG-EL(Y) — 4MP 36× DarkFighter 2.0 PTZ Network Speed Dome with 300 m IR (NEMA 4X Anti-Corrosion)
The Hikvision DS-2DF7A436IXG-EL(Y) is the IR-equipped flagship of Hikvision's 7A Ultra-Series PTZ line — a 4MP outdoor pan/tilt/zoom speed dome that pairs a 1/1.8" progressive-scan CMOS sensor and a 36× motorised optical zoom (6.0–216 mm · F1.2) with a built-in IR illuminator out to 300 m. DarkFighter 2.0 sensor technology, 150 dB AWDR, Smart Pan-Tilt Correction and a built-in gyroscope EIS round out the imaging chain. The -Y suffix on this Australian-stocked SKU denotes Hikvision's moderate anti-corrosion housing — NEMA 4X-rated for coastal Australian sites within roughly 2 km of the shoreline and for areas exposed to acid rain. The base DS-2DF7A436IXG-EL (no -Y) ships with no specific corrosion protection; we stock the -Y variant by default.
This is the camera Hikvision builds for completely dark long-range surveillance — rural property boundaries with no street lighting, dark mining haul roads, unlit perimeter walls, river and forest monitoring at scenic spots, unlit rail-yard aprons, scenic-spot and large-venue overwatch. The IR LED array adds 300 m of reliable illumination at full telephoto zoom, while the DarkFighter 2.0 sensor takes over at any time the scene has even modest ambient light. PTZ kinematics are tuned for incident response: 360° continuous pan at up to 550°/s (700°/s max), tilt −20° to +90° auto-flip, 300 presets, 8 patrol routes and 3D click-to-frame positioning. Powered by PoE 802.3bt Type 4 Class 8 (90 W class) or 36 VDC, with built-in heater and demist. Cyber-hardened with TPM 2.0 (FIPS 140-2 Level 2). Australian stock, 3-year Australian warranty.
Optical Zoom
36× · 6–216 mm · F1.2
Long-Range IR
Up to 300 m · 850 nm
Resolution
4MP · 2688 × 1520 · up to 120 fps
AI Engine
Auto-Tracking 3.0 · Face Capture
Protection
IP67 · IK10 · NEMA 4X (-Y)
Power
PoE 802.3bt Class 8 · 36 VDC · 90 W
3-Year Australian Warranty
Fast Australia-Wide Shipping
Australian Tech Support
Why Choose the 7A IR PTZ over the 6A
Both the 6A and 7A Ultra-Series PTZs share the same 1/1.8" DarkFighter 2.0 sensor, the same 36× optical zoom, the same 150 dB AWDR and the same on-camera deep-learning AI stack. The deciding question is how dark the scene actually gets at the far end of the zoom range. The 7A's built-in 300 m IR illuminator is the difference-maker: it lights an entire perimeter wall, dark haul road or rural property boundary at full telephoto, in zero ambient light. If the scene has streetlights, dock lighting or moonlight, the 6A's DarkFighter 2.0 alone is enough. If the scene is genuinely dark, the 7A is what gets the shot.
300 m IR — Zero-Light Identification
Smart IR illumination out to 300 m at 850 nm wavelength. The IR LED array is matched to the 36× zoom optics — at telephoto, the beam tightens with the zoom to keep target illumination consistent across the working range.
36× Optical Zoom · F1.2 · 6–216 mm
The same long-zoom lens as the 6A — but here paired with the IR ring for completely dark scenes. Identify at 297.9 m tele (EN 62676-4), recognise at 595.9 m, detect to 2,979 m.
DarkFighter 2.0 + 150 dB AWDR
Same sensor and same wide-dynamic-range as the 6A — 0.0003 lux colour, 0.0001 lux monochrome, 150 dB AWDR. At dawn / dusk / mixed lighting the camera produces colour and switches to IR-aided monochrome only when needed.
550°/s Pan · 300°/s Tilt
Pan preset speed up to 550°/s (max 700°/s), tilt to 300°/s. Faster than the 6A's 300°/s — important for incident response on big sites where the camera has to swing from one preset to a diagonally-opposite one in well under a second.
Smart Pan-Tilt Correction + Gyroscope EIS
Smart Pan-Tilt Correction automatically compensates for mechanical drift over time, keeping presets accurate to the original setpoint. Combined with the built-in gyroscope EIS, the image stays steady on tall pole mounts in coastal wind.
Lighter, Smaller, IR-Equipped
At 5 kg and ⌀ 215 × 297 mm, the 7A is actually smaller and lighter than the 6A (6 kg / ⌀ 231 × 356 mm) despite adding the IR LED ring — Hikvision re-engineered the optical assembly to gain the IR without growing the camera body.
Important Install Note — PoE 802.3bt Class 8 (90 W) or 36 VDC
The 7A IR PTZ does not run on standard PoE+ (802.3at, 25.5 W) or even Hi-PoE 60 W. Total camera power draw with the IR LED ring and heater active is up to 90 W on either 36 VDC or PoE 802.3bt Type 4 Class 8 — the camera reserves 6.4 W for IR, 8 W for the heater and 52 W for the camera body. Standardise on one of the following:
PoE 802.3bt Type 4 Class 8 injector or switch on the camera's network run — provides the full 90 W via single Cat 6 cable, the simplest install.
36 VDC dedicated supply at the camera — used where you're running fibre to the camera or where you prefer to feed power separately from the data drop.
Standard PoE+ switches (15 W or 25.5 W class) will not reliably power this camera, especially when the IR ring and heater are both active in cold weather. Contact our Australian team for the right 90 W PoE++ injector or 36 VDC supply for your install.
On-Camera Deep-Learning AI
The 7A PTZ runs Hikvision's deep-learning engine on the camera itself, classifying objects and triggering only on the targets that matter. The full AI stack is identical to the 6A sibling — the 7A's value-add is purely the IR illuminator for dark scenes.
Perimeter Protection
Line crossing, region entrance, intrusion and region exiting detection — each filtered by target type (human / vehicle) to suppress nuisance alarms from rain, foliage, animals and headlight glare.
Multi-Target-Type Detection
Simultaneous detection across three target classes with rich feature extraction: face (7 features), human (14 features) and vehicle (8 features). Feeds searchable metadata into your NVR for fast post-incident review.
Face Capture — 30 Simultaneous
Detects up to 30 faces in frame, grades face quality, and uploads the best frame plus context. Useful at port gates, mining-camp entry points and large-venue access control.
Face Comparison — 150,000 Total
10 face libraries × 30,000 faces = 150,000 total with encrypted on-camera storage — enterprise-scale watchlist comparison without a separate face server.
Smart Tracking 3.0 — Auto-Follow
Locks onto detected human or vehicle targets and pans / tilts / zooms automatically to keep them framed. Person arming mode flags specific faces or human IDs that trigger alarms plus tracking when detected.
Audio & Behaviour Events
Audio exception detection, video tampering, vandal-proof alarm, scene change, unattended baggage and object removal detection — useful for unmanned dock aprons, rail-yard sidings and large-venue overwatch.
Pan / Tilt / Zoom — Faster Kinematics for Incident Response
360° Continuous Pan · 550°/s Preset
360° continuous pan with preset speed up to 550°/s (max 700°/s) — the camera moves from a preset on one side of the site to the opposite-side preset in well under a second.
Tilt −20° to +90° · Auto-Flip
Tilt range from −20° (below horizon, useful for tall-pole overviews of the ground below) to +90° with auto-flip support for tracking a target straight under the dome.
300 Presets · 8 Patrols
300 presets per camera, 8 patrol routes with up to 32 presets each. Schedule the camera to walk a perimeter route automatically every shift change.
3D Positioning · Power-Off Memory
Click any target on the live image to centre-frame and zoom in one motion. Power-off memory returns the camera to its previous orientation after a brown-out.
Smart Pan-Tilt Correction
The PTZ self-corrects mechanical drift over time, keeping presets accurate to their original setpoint without manual re-calibration.
Built-in Gyroscope EIS
The gyroscope drives electronic image stabilisation — critical for tall pole installs in coastal wind, where mount vibration would otherwise blur the image and confuse the AI engine.
Technical Specifications
DS-2DF7A436IXG-EL(Y) · Full Specifications
SKU
DS-2DF7A436IXG-ELY (AU-stocked default — NEMA 4X anti-corrosion)
Camera Type
Hikvision Ultra Series 7A · 4MP 36× DarkFighter 2.0 IR Network Speed Dome PTZ
Image Sensor
1/1.8" Progressive Scan CMOS · DarkFighter 2.0
Max Resolution
2688 × 1520 (4MP)
Min. Illumination
Colour 0.0003 lux @ F1.2 (AGC ON) · B/W 0.0001 lux @ F1.2 · 0 lux with IR
Shutter Speed
1/30 s to 1/30,000 s · Slow Shutter
Lens
Motorised · 6.0–216 mm · 36× optical · F1.2 max aperture · auto / semi-auto / manual / rapid focus
Digital Zoom
16×
Field of View
Horizontal 59.1° → 2.0° · Vertical 34.1° → 1.1° · Diagonal 67.1° → 2.3°
Zoom Speed
Approx. 4.5 s (wide ↔ tele)
IR Illumination
Smart IR · up to 300 m · 850 nm wavelength
Day & Night
ICR (IR cut filter, mechanical)
Wide Dynamic Range
150 dB AWDR · BLC · HLC · 3D DNR · optical defog
Image Stabilisation
Built-in gyroscope · electronic image stabilisation · Smart Pan-Tilt Correction
Pan Range / Speed
360° continuous · 0.1°–550°/s preset · MAX 700°/s · proportional pan
Tilt Range / Speed
−20° to +90° (auto-flip) · 0.1°–300°/s · preset 300°/s
Presets / Patrols
300 presets · 8 patrols (32 presets each)
Park Action
Preset · patrol scan
3D Positioning
Yes — click-to-frame on live view
Preset Freezing
Yes
Power-Off Memory
Yes — returns to last orientation after power restore
Scheduled Task
Preset · patrol scan · dome reboot · dome adjust · aux output
Frame Rate (Main)
50 Hz: 50 fps @ 4MP / 100 fps @ 1080p · 60 Hz: 60 fps @ 4MP / 120 fps @ 1080p
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG (sub-stream)
Streams
3 simultaneous (main / sub / third)
Video Bit Rate
32 Kbps – 16,384 Kbps · CBR / VBR · SVC · ROI (fixed region)
Deep-Learning AI
Perimeter Protection (line crossing / intrusion / region entry & exit · human + vehicle classification)
Multi-Target Detection
Simultaneous face (7 features) / human (14 features) / vehicle (8 features)
Face Capture
Up to 30 simultaneous faces · grade / select / upload best frame + context
Face Comparison
10 libraries × 30,000 faces = 150,000 total · encrypted face library storage
Smart Tracking
Auto-Tracking 3.0 · manual + automatic · person arming
Basic Events
Motion · video tampering · vandal-proof alarm · audio exception · unattended baggage · object removal · exceptions
Linkage
FTP / NAS / microSD upload · centre notify · email · trigger recording · PTZ actions (preset / patrol)
Audio
1 line-in (max 2–2.4 Vpp, 1 KΩ ±10%) · 1 line-out (600 Ω) · G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC
Alarm I/O
7 inputs · 2 outputs
RS-485
1 × RS-485 — HIKVISION / Pelco-P / Pelco-D self-adaptive
Ethernet
1 × RJ-45 10/100 Mbps self-adaptive
On-Board Storage
microSD / SDHC / SDXC up to 1 TB · NAS (NFS / SMB)
Video Output
CVBS · 1.0 V[p-p] / 75 Ω · PAL / NTSC · BNC (debug)
API & Protocols
ISAPI · SDK · ISUP · ONVIF (Profile S / G / T / M) · 20 concurrent live-view sessions
Cyber Security
TPM 2.0 (FIPS 140-2 Level 2) · TLS 1.3 · 802.1X (EAP-TLS / EAP-LEAP / EAP-MD5) · HTTPS · IP filter · watermark · audit log · host authentication (MAC)
Client Software
iVMS-4200 · Hik-Connect · HikCentral Pro
Power Source
36 VDC ±25% (max 90 W) · PoE 802.3bt Type 4 Class 8 (max 90 W) · 52 W camera + 6.4 W IR + 8 W heater
Heater + Demist
YES + YES
Operating Temperature
−40 °C to +70 °C · ≤95% humidity
Material / Dimensions
Outdoor speed dome · ⌀ 214.95 mm × 297.1 mm · ~5 kg
Weatherproof Rating
IP67 (IEC 60529-2013)
Vandal Resistance
IK10 (IEC 62262:2002)
Anti-Corrosion
NEMA 4X (NEMA 250-2018) — Y variant · moderate Hikvision protection tier
Lightning Protection
±6 kV line-to-ground · ±3 kV line-to-line (IEC 61000-4-5) · surge + voltage transient
DORI (Tele)
Detect 2,979.3 m · Observe 1,182.3 m · Recognise 595.9 m · Identify 297.9 m
Approvals
CE-EMC · CE-LVD · RCM (AS/NZS CISPR 32:2015) · IC ICES-003 · KC · CB · LOA · RoHS · WEEE · REACH
Warranty
3-Year Australian Warranty (back-to-base)
DS-2DF7A436IXG-EL(Y) vs DS-2DF6A436XG1-EL(Y) — Built-in IR or Ambient-Light Only?
The 6A and 7A Ultra-Series PTZs are essentially the same camera with one decisive difference: the 7A has a built-in 300 m IR illuminator; the 6A does not. Everything else — sensor, zoom, WDR, low-light spec, deep-learning AI, face capture, face comparison, auto-tracking, IP/IK protection, cyber-security baseline — is essentially identical. The 7A is also faster (550°/s pan vs 300°/s on the 6A) and surprisingly lighter (5 kg vs 6 kg). The cost of the IR ring is more power — the 7A needs PoE 802.3bt Class 8 (90 W) vs the 6A's Hi-PoE (60 W class).
DS-2DF7A436IXG-EL(Y) (7A · with 300 m IR) vs DS-2DF6A436XG1-EL(Y) (6A · DarkFighter 2.0 only)
Feature
DS-2DF7A436IXG-EL(Y) (this 7A IR PTZ)
DS-2DF6A436XG1-EL(Y) (6A no-IR PTZ)
Series Position
Hikvision Ultra Series 7A (higher tier)
Hikvision Ultra Series 6A
IR Illuminator
Built-in · Smart IR up to 300 m · 850 nm
None — DarkFighter 2.0 sensor only
Image Sensor
1/1.8" CMOS · DarkFighter 2.0
1/1.8" CMOS · DarkFighter 2.0
Max Resolution
4MP · 2688 × 1520
4MP · 2688 × 1520
Optical Zoom
36× · 6–216 mm · F1.2
36× · 6–216 mm · F1.2
Min. Illumination
0.0003 lux colour · 0 lux with IR
0.0003 lux colour (no IR option)
Wide Dynamic Range
150 dB AWDR
150 dB AWDR
Shutter Speed
1/30 s to 1/30,000 s
1/1 s to 1/30,000 s (longer slow shutter)
Frame Rate
4MP @ 50/60 fps · 1080p @ 100/120 fps
4MP @ 50/60 fps · 1080p @ 100/120 fps
Pan / Tilt Range
360° · −20° to +90°
360° · −20° to +90°
Pan Preset Speed
550°/s (max 700°/s)
300°/s
Smart Pan-Tilt Correction
Yes
—
Pattern Scans
— (not listed in datasheet)
4 pattern scans
Park Action Options
Preset · patrol scan only
Preset · patrol · auto / tilt / random / frame / panorama scan
Deep Learning
Perimeter · multi-target · face capture (30) · face comparison (150k) · auto-tracking 3.0
Same AI stack + vehicle arming mode
Object Arming
Person arming
Person + vehicle arming
Cyber Security
TPM 2.0 · FIPS 140-2 L2 · TLS 1.3
TPM 2.0 · FIPS 140-2 L2 · TLS 1.3
Protection
IP67 · IK10 · NEMA 4X (-Y)
IP67 · IK10 · NEMA 4X (-Y)
Power Source
PoE 802.3bt Class 8 (90 W) · 36 VDC · max 90 W
Hi-PoE (60 W class) · 36 VDC · max 45 W
Heater / Demist / Wiper
Heater + Demist · No Wiper
Heater + Demist · No Wiper
Weight / Dimensions
5 kg · Ø 215 × 297 mm
6 kg · Ø 231 × 356 mm
Best For
Completely dark long-range sites: rural property boundaries, dark mining haul roads, unlit power-station and substation yards, river / forest / scenic-spot overwatch, unlit perimeter walls. The 300 m IR array unlocks identification at full telephoto in zero ambient light.
Ambient-lit Australian sites: lit carparks, port aprons under dock lighting, council CBDs, school perimeters with security lighting, marinas with mast lighting. Lighter on power, still uses DarkFighter 2.0 for very low light.
For the 6A sibling referenced in the comparison, see: DS-2DF6A436XG1-EL(Y) (Ultra 6A · no IR) →
Recording NVRs — Any Modern Hikvision NVR Works
The 7A PTZ streams to any modern Hikvision NVR over ONVIF Profile S/G/T/M and Hikvision ISAPI. For multi-site rollouts with rich AI metadata, the VPro AcuSeek and DeepinMind NVRs unlock natural-language search across the recording.
DS-7608NXI-I2/8P/VPro — 8CH · AcuSeek AI
Eight-channel VPro AcuSeek AI NVR with 8 built-in PoE ports — a clean partner for a single-site PTZ deployment with mixed perimeter cameras. View DS-7608NXI-I2/8P/VPro →
DS-7616NXI-I2/16P/VPro — 16CH · AcuSeek AI
Sixteen channels at full PoE — room for the PTZ plus a fleet of perimeter and overview cameras across the whole site. View DS-7616NXI-I2/16P/VPro →
DS-7732NXI-I4/16P/VPro — 32CH · AcuSeek AI
Thirty-two channels with 16 PoE and 4 HDD bays — typical VPro AcuSeek platform for council, port, mining and multi-building campus rollouts. View DS-7732NXI-I4/16P/VPro →
iDS-7716NXI-M4/16P/X — 16CH · DeepinMind
DeepinMind X-Series — Hikvision's most capable 16-channel AI NVR for face-recognition workloads and AcuSearch natural-language search across the fleet. View iDS-7716NXI-M4/16P/X →
Important: the PTZ does not draw power from these NVRs' built-in PoE ports — it needs a separate PoE 802.3bt Class 8 (90 W) injector or a 36 VDC supply. Data goes over the Ethernet; power comes from the injector or supply. Browse the full Hikvision NVR range: Hikvision Network Video Recorders →.
Compatible Mounts & Accessories
Hikvision DS-4612ZJ-PA — Pendant Mount
Hikvision's pendant mount kit for the 7A speed dome — sized for the ⌀ 215 mm / 5 kg body. Used where the camera hangs from a horizontal beam, eave or carport gantry.
Hikvision DS-4603ZJ-PA — Wall Mount
Heavy-duty wall mount for the 7A — compatible with rendered, masonry and treated-timber substrates. The most common install partner for building-eave and façade mounts.
Hikvision DS-1674ZJ-P — Junction Box
Junction box for clean cable termination behind the wall or pendant mount. Pairs with the DS-4603ZJ-PA wall bracket.
Hikvision DS-1684ZJ-P / DS-1673ZJ-P — Pole Mounts
Vertical pole mount (DS-1684ZJ-P) and horizontal pole mount (DS-1673ZJ-P) — for installing the PTZ on light poles, fence posts, gate columns and tower mounts. Pairs with the DS-4603ZJ-PA wall bracket.
Hikvision DS-1276ZJ-P / DS-4660ZJ-PC — Corner Mounts
Corner-mount kits for situating the PTZ at the corner of a building overlooking a carpark, dock apron, perimeter line or large-venue ground level.
PoE 802.3bt Class 8 (90 W) Injector / Switch
Required if you're not powering the camera from a separate 36 VDC supply. Make sure the injector or switch is genuinely Type 4 Class 8 (90 W) — standard PoE+ (25.5 W) and Hi-PoE (60 W) will not reliably power this camera with IR active. Contact our Australian team for the right injector.
Frequently Asked Questions
What does the "-Y" suffix mean and which variant do you stock?
The -Y suffix indicates Hikvision's moderate anti-corrosion housing — NEMA 4X-rated, designed for coastal Australian sites within ~2 km of the shoreline and areas affected by acid rain. We stock the DS-2DF7A436IXG-ELY (with -Y) as our Australian default. The base DS-2DF7A436IXG-EL (no -Y) has "no specific anti-corrosion protection" per the datasheet — we don't stock it.
How does the 300 m IR work — does it light the full 300 m at wide-angle?
The IR illumination range scales with the zoom. At full telephoto, the IR beam tightens and reaches up to 300 m with the smart-IR supplement adjusting intensity to avoid over-exposing close-range targets. At wide-angle, the beam spreads to cover the wider field of view at a shorter effective distance. The combination keeps target illumination consistent across the zoom range.
Why doesn't it run on standard PoE+ or Hi-PoE?
Total camera power draw with the IR LED ring and heater active is up to 90 W. Standard PoE+ (IEEE 802.3at) tops out at 25.5 W, and Hi-PoE (60 W class) doesn't have the headroom for the IR ring at full output. The camera requires PoE 802.3bt Type 4 Class 8 (90 W) or a dedicated 36 VDC supply.
Should I buy the 7A or the 6A sibling?
If the scene has any reasonable ambient lighting at night (streetlights, dock lights, security floodlights, mast lighting, moonlight) the 6A's DarkFighter 2.0 sensor alone is enough — and you'll save on the 90 W power chain. Choose the 7A specifically for genuinely dark long-range sites: rural property boundaries, dark mining haul roads, unlit power-station yards, scenic-spot and river overwatch. Compare side-by-side: DS-2DF6A436XG1-EL(Y) →
Does it support number-plate recognition (ANPR)?
This is not marketed as an ANPR camera. The 7A PTZ is built for long-range surveillance, perimeter protection and auto-tracking. For on-camera number-plate recognition, choose a dedicated DeepinView ANPR bullet — for example the iDS-2CD7A46G2/P-IZHSY with its purpose-built LPR engine and 10,000-record plate database.
How far away can the camera identify a target?
Per EN 62676-4 criteria at full telephoto: Detect 2,979 m · Observe 1,182 m · Recognise 596 m · Identify 297.9 m. "Identify" means the image is detailed enough to recognise a specific individual — that's a usable working distance for almost any large-site security application. Detection extends nearly 3 km.
How does Smart Pan-Tilt Correction work?
Over thousands of pan/tilt cycles, mechanical drift can shift preset positions by a few degrees from their original setpoints. Smart Pan-Tilt Correction measures and compensates for that drift automatically, keeping all presets accurate to the original setpoint without manual re-calibration — important for unmanned sites where a technician can't easily re-set presets in person.
Will the camera record locally if the NVR drops?
Yes. microSD up to 1 TB — when the network link to the NVR drops, the camera continues writing locally and the footage is available for retrieval once the link returns.
What's the warranty and where is it serviced?
This camera ships with a 3-year Australian Hikvision warranty, serviced back-to-base through Hikvision Australia. CCTV Guru manages the entire RA process from our Sydney office and provides Australian-based pre-sales and technical support for the life of the product.
Do you ship Australia-wide and is stock genuine?
Yes — Australian stock from authorised Hikvision Australia channels (not parallel imports). We ship Australia-wide every business day with same-day dispatch on orders placed before 2 pm AEST to Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra, Darwin and regional addresses.
Downloads & Resources
DS-2DF7A436IXG-ELY Datasheet
Hikvision PTZ Quick Start Guide
Hikvision Speed Dome User Manual
Order the Hikvision DS-2DF7A436IXG-EL(Y) from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision Ultra Series PTZ cameras. Order the DS-2DF7A436IXG-ELY 4MP 36× DarkFighter 2.0 IR PTZ with 300 m smart IR and NEMA 4X anti-corrosion housing for fast Australia-wide dispatch, expert pre-sales advice, project pricing for multi-camera and multi-PTZ rollouts, and full local warranty support. Designing a long-range zero-light surveillance project for a rural property, mining site, power station, port apron, scenic-spot overwatch or large industrial campus? Request a free quote or contact our Australian team for tailored camera-and-NVR sizing — we'll spec the right 90 W PoE++ injector or 36 VDC supply at the same time.
Face Recognition Terminal
Hikvision DS-K1T344MBWX-E1 — 4.5" Face Recognition Access Terminal
The Hikvision DS-K1T344MBWX-E1 is a high-performance face recognition access terminal with a 4.5-inch touch LCD and dual 2MP wide-angle cameras. It recognises users in 0.2 seconds or less with 99%+ accuracy and supports face, M1 card and PIN authentication.
With capacity for 3,000 faces and 3,000 cards, two-way audio, PoE or 12VDC power, plus WiFi and Bluetooth, it is a flexible IP65-rated terminal for indoor or outdoor doors.
4.5" Touch & Dual Camera
4.5-inch touch LCD with dual 2MP wide-angle cameras for reliable face capture.
Fast Recognition
Recognition at 0.3–1.5 m in under 0.2 s per user with 99%+ accuracy.
Face, Card & PIN
Stores 3,000 faces and 3,000 M1 cards with multi-factor authentication.
PoE, WiFi & Bluetooth
PoE 802.3at or 12VDC power, plus WiFi and Bluetooth connectivity; IP65 housing.
Specifications
Model
DS-K1T344MBWX-E1
Display
4.5" LCD touchscreen, 480 × 854
Cameras
Dual 2MP wide-angle
Recognition
0.3–1.5 m, ≤ 0.2 s per user
Capacity
3,000 faces & 3,000 cards
Authentication
Face, M1 card, PIN
Audio
Two-way audio
Network
Ethernet 10/100, WiFi, Bluetooth
Power
PoE 802.3at or 12VDC
Interfaces
RS-485, Wiegand, alarm I/O, USB
Protection
IP65
Download DS-K1T344MBWX-E1 Datasheet (PDF)
Download Quick Start Guide (PDF)
What authentication does it support?It supports face recognition, M1 card and PIN code, storing up to 3,000 faces and 3,000 cards.
How is it powered?It runs on PoE (IEEE 802.3at) or 12VDC, and can power a door lock.
Can it be installed outdoors?Yes. The IP65-rated housing suits indoor and outdoor doors.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Deploy fast, accurate face entry control with the Hikvision DS-K1T344MBWX-E1 terminal, backed by a 3-year Australian warranty and local tech support.
WizSense 3 · 8 MP 4K · Smart Dual Light · Motorised 2.7–13.5 mmDahua WizSense 3 · 8 MP 4K Smart Dual Light TurretDahua DH-IPC-HDW3867T-ZS-IL-ANZ — 8 MP 4K Smart Dual Light Motorised Vari-Focal Eyeball Turret WizSense 3 Network Camera (3867 Series)
The Dahua DH-IPC-HDW3867T-ZS-IL-ANZ is the 3867 series 8 MP 4K WizSense 3 Smart Dual Light motorised eyeball turret — the motorised vari-focal sibling to the fixed HDW3867EM-S-IL-ANZ. Built around a 1/1.8" CMOS sensor capturing 3840 × 2160 (true 4K) at 15 fps and 4 MP at full 25/30 fps. The motorised 2.7–13.5 mm vari-focal lens with auto-focus delivers a wide 102° field at 2.7 mm down to a tight 27° pull at 13.5 mm — re-frameable from DMSS. Smart Dual Light combines 30 m IR (stealth) and up to 50 m warm-LED full-colour illumination — auto-switches based on AI-classified event. WDR is 120 dB; the compact metal turret housing is IP67 sealed. WizSense 3 deep-learning Pro AI runs perimeter protection (tripwire, intrusion), SMD 4.0 and AcuPick attribute search. Built-in microphone, 1/1 RCA audio I/O. Built for Australian residential, retail, shopfront and architectural commercial installs where 24/7 colour identification matters and motorised optics are needed. Backed by a 3-year Australian warranty through CCTV Guru. SKU 3867 series.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why Choose the Dahua HDW3867T-ZS-IL-ANZ Smart Dual Light Turret
Smart Dual Light — IR + Warm LED
30 m IR for stealth surveillance + up to 50 m warm-LED for 24/7 full-colour identification. Auto-switches based on AI-classified events — stealth at idle, full colour on alarm.
True 4K Detail (8 MP)
Native 3840 × 2160 at 15 fps, or 4 MP at full 25/30 fps. 4× the pixel density of 1080p.
Motorised 5× Vari-Focal
2.7–13.5 mm motorised vari-focal — install wide, then pull tight via DMSS.
WizSense 3 + AcuPick
Perimeter protection, SMD 4.0 and AcuPick attribute search on the WizSense 3 chip.
1/1.8" Pro Sensor
1/1.8" CMOS — larger sensor than typical WizSense 3 cameras, better low-light performance and colour reproduction.
Built-in Mic + Audio I/O
Built-in microphone and RCA audio I/O for two-way talk.
Important Install Note
Motorised vari-focal lens is remote-controllable via DMSS. The eyeball gimbal allows ±75° pan, ±75° tilt and 0–360° rotation. The warm LED activates automatically in low light or on AI-classified events — configure mode via DMSS. For the fixed-focal sibling, see HDW3867EM-S-IL-ANZ.
AI & Smart Detection
AcuPick Attribute Search
Search recorded video by colour, clothing, vehicle type — with a Dahua AcuPick NVR.
SMD 4.0
Motion alerts triggered only by humans and vehicles.
Perimeter Protection
Tripwire and intrusion zones with human/vehicle classification.
Smart Dual Light Auto-Switch
Automatic switching between IR and warm-LED based on AI-classified event type.
AI SSA
Scene self-adaptation for rain, fog, backlight.
Two-Way Audio
Built-in mic + RCA audio I/O.
Technical Specifications
Camera, Lens & Illumination
Model
DH-IPC-HDW3867T-ZS-IL-ANZ
Form Factor
Eyeball turret (HDW chassis)
Image Sensor
1/1.8" CMOS
Maximum Resolution
3840 × 2160 (8 MP / 4K)
Frame Rate
4K @ 15 fps · 4 MP @ 25/30 fps
WDR
120 dB
Lens Type
Motorised vari-focal with auto-focus
Focal Length
2.7–13.5 mm
Field of View
H: 102°–27°
IR Illumination
Up to 30 m
Warm-LED Illumination
Up to 50 m (full-colour)
Smart Dual Light
Yes — auto-switching
Intelligence, Audio & Network
AI Engine
WizSense 3 Series
IVS
Tripwire · intrusion (human/vehicle)
SMD
SMD 4.0
AcuPick
Yes (with Dahua AcuPick NVR)
Built-in Mic
Yes
Audio I/O
1 in / 1 out (RCA)
Alarm I/O
1 in / 1 out
Network Port
RJ-45 (10/100)
Interoperability
ONVIF (Profile S, G, T) · CGI
Storage
Micro SD up to 512 GB
Mobile Client
DMSS
Power, Environment & Build
Power Supply
12 VDC / PoE (802.3af)
Operating Temperature
−40 °C to +60 °C
Protection
IP67
Casing
Metal
Australian Warranty
3 Years (via CCTV Guru)
Recommended NVR Pairings
Dahua DHI-NVR5208-8P-AI/ANZ
View NVR5208-8P-AI →
Dahua DHI-NVR5216-16P-AI/ANZ
View NVR5216-16P-AI →
Dahua DHI-NVR4216-16P-AI/ANZ
View NVR4216-16P-AI →
Dahua DHI-NVR5432-AI/ANZ
View NVR5432-AI →
Frequently Asked Questions
What is "Smart Dual Light"?
Built-in IR + warm-LED with AI-based auto-switching — stealth IR at idle, full-colour warm-LED on alarm. Best of both worlds.
Re-frame after install?
Yes — motorised vari-focal via DMSS.
AcuPick?
Yes — pair with a Dahua AcuPick NVR.
Standard PoE?
Yes — 802.3af.
True 4K?
Yes — native 3840 × 2160 at 15 fps.
Night vision range?
30 m IR + 50 m warm-LED.
Difference vs HDW3867EM fixed?
Same Smart Dual Light platform. The HDW3867EM is fixed 2.8 mm; this one is motorised 2.7–13.5 mm.
Temperature?
−40 °C to +60 °C alpine-rated.
Mobile viewing?
Yes — DMSS app.
Downloads
DH-IPC-HDW3867T-ZS-IL-ANZ DatasheetDahua IP Turret Camera Quick Start GuideDahua IP Turret Camera Installation Guide
Order Your Dahua HDW3867T-ZS-IL-ANZ from CCTV Guru
"Add to cart" to order, or contact our Australian team for project pricing. 3-year Australian warranty. cctvguru.com.au/pages/contact.
Genuine Dahua · In-Ceiling Mount · Anti-Drop RopeDahua PFB5310CA Discreet, Recessed Mount for a Clean Ceiling Finish
The Dahua PFB5310C is a reliable in-ceiling mount bracket that delivers a clean, secure recessed install for compatible network and PTZ cameras, with minimal intrusion into the camera's field of view. Built from durable SECC and polycarbonate with an anti-drop safety rope, it keeps installations safe even in busy commercial spaces. Quick to fit and easy to maintain, it suits offices, retail, warehouses and schools.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why You'll Love It
Recessed in-ceiling design — sits flush for a clean finish with full visual range for the camera.
Anti-drop safety rope — included for secure, worry-free installation in commercial environments.
SECC & polycarbonate build — rugged construction for long-lasting, reliable performance.
3.0 kg load capacity — supports compatible Dahua network and PTZ cameras.
Specifications
Model
DH-PFB5310C
Category
Ceiling Mount
Material
SECC & PC (Polycarbonate)
Colour
White
Load Capacity
3.0 kg (6.61 lb)
Dimensions
Ø 238.0 mm × 78.0 mm
Net Weight
0.35 kg
Operating Temperature
-40 °C to +60 °C
Mounting
In-ceiling (recessed)
Warranty
3 Years (AU)
Frequently Asked Questions
Which cameras is the PFB5310C compatible with?It is designed for compatible Dahua network and PTZ cameras suited to recessed ceiling mounting — check your camera's mounting spec to confirm it lists the PFB5310C.
What ceiling types does it suit?It works with standard recessed ceiling types, sitting flush for a discreet, professional finish.
Is this a genuine Dahua accessory?Yes — the PFB5310C is an official Dahua in-ceiling mount bracket built to fit Dahua camera housings.
Is it easy to maintain after installation?Yes. The bracket allows easy disassembly for maintenance, and the included anti-drop rope keeps the camera secure during servicing.
Dahua · DH-CS4226-24ET-375 · 26-Port Cloud Managed · 375W
24-PoE Cloud Switch
Dahua DH-CS4226-24ET-375 26-Port Cloud Managed PoE Switch
The Dahua DH-CS4226-24ET-375 drives up to 24 PoE cameras from a single 375W budget, with 2 combo uplinks for the network backbone. Manage it locally by web UI or remotely through the DoLynk Care app with live monitoring, alarms and topology. It powers Dahua and standard IP PoE cameras and suits supermarkets, offices, cafés and hotels.
Ports
26 total
PoE Ports
24 × PoE
PoE Budget
375W total
Uplinks
2 × combo (RJ45/SFP)
Management
Cloud (DoLynk Care)
Mounting
Desktop / rack
24 Cameras, One Switch
A 375W budget runs a full 24-camera load — ports 1–2 deliver up to 90W Hi-PoE for PTZ, the rest up to 30W PoE+.
Manage From Anywhere
DoLynk Care brings cloud monitoring, alarms, LLDP topology and remote port reboot, so you fix faults without a site visit.
250m Long-Distance PoE
Extended-reach mode pushes PoE to 250m at 10Mbps for cameras well beyond the standard 100m run.
PoE Watchdog
Automatically power-cycles a frozen camera port to restore the IPC connection and keep coverage live.
Specifications — DH-CS4226-24ET-375
Model / SKU
DH-CS4226-24ET-375
Total Ports
26: 24 × RJ45 PoE (10/100) + 2 × combo uplink (RJ45 10/100/1000 or SFP 1G)
PoE Budget
Total ≤ 375W; Port 1–2 ≤ 90W; Port 3–24 ≤ 30W
PoE Standards
IEEE 802.3af / 802.3at / 802.3bt, Hi-PoE
Long-Distance PoE
Up to 250m (bandwidth reduced to 10Mbps)
Switching Capacity
8.8 Gbps
Forwarding Rate
6.55 Mpps
MAC Table
8K
VLAN
32 VLANs, port-based VLAN
Management
Web UI + App (DoLynk Care)
Power Consumption
Idle ≤ 8.5W; Full load 400W
Operating Temperature
−10°C to +55°C
Mounting
Desktop / rack mount
Dimensions
440 × 220 × 44 mm
Warranty (Australia)
3 years · CCTV Guru Australia
Downloads & Resources
DH-CS4226-24ET-375 Datasheet
How many cameras can it power?The 375W budget supports a full 24-port PoE load. Ports 1–2 deliver up to 90W Hi-PoE for PTZ cameras, while ports 3–24 deliver up to 30W PoE+ each.
What is DoLynk Care?Dahua's free cloud platform and app for remote monitoring, alarms, network topology and remote port reboot — letting you manage the switch from anywhere.
Are the uplinks fibre-capable?Yes. The two combo uplinks accept either Gigabit RJ45 or 1G SFP fibre modules for a faster backbone link.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua WizSense · 10 × 6MP Smart Dual Light · 16CH AI NVR · AcuPick-Ready
10 × 6MP Kit
Dahua 10 × 6MP (3K) Full-Colour CCTV Kit with 16-Channel AI NVR
The Dahua 10 × 6MP (3K) Full-Colour CCTV Kit pairs ten DH-IPC-HDW3667EM-S-IL-ANZ Smart Dual-Light turret cameras with a 16-channel WizSense AI NVR for true 24/7 colour surveillance across larger Australian sites — supermarkets, childcare centres, warehouses, offices and factories. Smart Dual Light runs silent 30 m IR by night, then snaps a warm white LED on the instant WizSense AI detects a person or vehicle, capturing full-colour, evidence-grade footage of every incident. Choose the standard NVR4216-16P-AI/ANZ, or step up to the NVR5216-16P-AI/ANZ to unlock AcuPick attribute search.
Cameras
10 × 6MP Smart Dual Light
Recorder
16CH AI NVR · 16 PoE
Night Vision
30 m IR + Full Colour
AI Search
AcuPick-Ready
Audio
Built-in Mic (one-way)
Weatherproof
IP67 Rated
True 24/7 Full Colour
Smart Dual Light blends a 30 m IR illuminator with a 30 m warm-white LED. IR holds the scene at night with minimal light pollution; the warm light triggers on AI detection to record full-colour evidence of faces, clothing and number plates. Prefer no visible light? Switch to IR mode for discreet black-and-white night recording.
WizSense AI On Every Camera
A dedicated deep-learning chip runs SMD 4.0 and Perimeter Protection (tripwire + intrusion) with true human-and-vehicle classification — cutting false alarms from trees, rain, insects and shadows.
AcuPick-Ready Search
Pair the cameras with the 5-Series NVR5216-16P-AI/ANZ to unlock AcuPick — attribute-based search that finds every red car or every person in a hoodie across hours of footage in seconds.
16-Channel PoE Recorder
The 16CH AI NVR ships with 16 built-in PoE ports for true plug-and-play install, dual SATA bays for high-capacity surveillance storage, 4K HDMI output and remote viewing via the DMSS app.
What's Included
10 × Cameras
DH-IPC-HDW3667EM-S-IL-ANZ — 6MP Smart Dual-Light WizSense turret, 2.8 mm, IR 30 m, built-in mic, IP67. Each ships with eave/soffit bracket, drill template, screw pack, waterproof RJ-45 connector & quick start guide.
1 × Recorder
DHI-NVR4216-16P-AI/ANZ (16CH AI NVR, 16 PoE) with power adaptor, USB mouse, SATA cables & quick start guide — or upgrade to DHI-NVR5216-16P-AI/ANZ for AcuPick.
Power
16 × PoE+ ports built into the NVR — each camera runs on a single Cat6 network cable that carries both power and data, so there are no separate power supplies. Network cabling is run on site and is not included; pre-made Cat6 patch leads are available separately.
Mounting
Included brackets suit eave/soffit installs. For brick or flush-wall mounting, add a Dahua DH-PFB204W wall-mount bracket per camera; a DH-PFA139 junction box is also available for tidy cable management.
Storage
Dual SATA bays — HDD not included. For ~30 days of 24/7 recording from all 10 cameras (Smart H.265+) fit 2 × 8 TB Seagate SkyHawk or WD Purple; up to 16 TB per bay (32 TB total). Motion-only recording stretches this to 2–3 months.
Warranty
3-Year Australian warranty · local CCTV Guru tech support.
Best For
Supermarkets & grocery
Full-colour faces and number plates across tills, aisles and the loading dock.
Childcare centres
Clear colour coverage of entries, sign-in desks and play areas, day and night.
Offices & reception
Identify visitors and deliveries in colour, with AI alerts triggered after hours.
Warehouses & factories
Wide 110° views of racking, roller doors and yards with vehicle detection.
Retail shopfronts
Deter theft and capture evidence-grade colour footage in any lighting.
Car parks & yards
Person and vehicle AI detection with plate-readable detail over open areas.
Camera Specifications — DH-IPC-HDW3667EM-S-IL-ANZ
Camera Type
6MP Smart Dual Light Fixed-focal Eyeball WizSense Network Camera
Image Sensor
1/2.7" CMOS, progressive scan
Max. Resolution
6MP · 3288 × 1850 @ 25/30 fps
Lens
Fixed-focal 2.8 mm · M12 mount · F1.4
Field of View
H 110° · V 58° · D 132°
DORI
Detect 84.8 m · Observe 33.9 m · Recognise 17.0 m · Identify 8.5 m
Min. Illumination
0.007 lux Colour · 0.0007 lux B/W · 0 lux (illuminator on)
Smart Dual Light
30 m IR + 30 m Warm Light · Multi-core LED · Auto / Manual
WDR / S/N
120 dB WDR · >56 dB S/N
AI Engine
WizSense 3-Series · Dedicated AI chip · Deep-learning
AI Functions
SMD 4.0 · Perimeter Protection (Tripwire, Intrusion — human & vehicle) · AI SSA · Smart Illumination · AcuPick (with compatible NVR)
Compression
H.265 · H.264 · Smart H.265+/H.264+ · AI H.265/H.264 · MJPEG
Audio
Built-in microphone · G.711 / G.726 / G.723 / PCM
Network
RJ-45 10/100 · IPv4/IPv6 · ONVIF Profile S/G/T/M · 802.1x · HTTPS
Storage (edge)
MicroSD up to 512 GB · FTP / SFTP / NAS
Power
12 VDC / PoE (IEEE 802.3af) · Basic 5.3 W · Max 9.5 W
Operating Temp.
–40 °C to +60 °C · ≤95% RH
Ingress Protection
IP67
Software
DMSS · DoLynk Care · Smart PSS Lite · DSS
Warranty (Australia)
3 years · CCTV Guru Australia
Choose Your 16-Channel AI NVR
NVR4216-16P-AI/ANZ
16CH 4K WizSense AI NVR · 16 PoE+ (130 W) · 2 SATA bays (to 32 TB) · Face, IVS/Perimeter, SMD Plus, ANPR · Quick Pick target search · ONVIF 21.12
NVR5216-16P-AI/ANZ
16CH AI NVR · 16 PoE · 2 SATA bays · 1U · higher bandwidth · AI by recorder & by camera · AcuPick search supported
Pick the 5216 if…
You want AcuPick attribute search and higher recording bandwidth. AcuPick only works with Dahua 5-Series NVRs.
Installation Notes
›Cabling: run solid-copper Cat6 from each camera back to the NVR's PoE ports for stable power and video over long distances.
›Weatherproofing: even at IP67, seal outdoor RJ-45 joins with weatherproof tape or a junction box to keep out moisture and salt air.
›NVR placement: mount the recorder in a cool, dust-free, ventilated spot away from direct sunlight for reliable 24/7 recording.
Setup & Installation Guides — Official Dahua
First-time NVR setup, step by step — Dahua Technology UK & Ireland
How to add an IP camera — Dahua Technology (official)
Downloads & Resources
DH-IPC-HDW3667EM-S-IL-ANZ Datasheet
DHI-NVR4216-16P-AI/ANZ Datasheet
DHI-NVR5216-16P-AI/ANZ Datasheet
Is this kit really full colour at night?Yes. Smart Dual Light runs IR by default, then switches to a 30 m warm-white LED the moment AI detects a person or vehicle — recording full-colour footage of the event before returning to IR.
Can I turn off the white light at night?Yes. Smart Dual Light has three modes — Smart Dual (IR by default, warm light only on AI detection), full-colour (warm light always on) and IR-only. If you'd rather avoid any visible spotlight, set IR mode and the cameras keep recording clear black-and-white footage at night with no white light at all.
What's the difference between the two NVR options?The NVR4216 is the standard 16CH AI recorder. The NVR5216 adds AcuPick attribute search and higher bandwidth. AcuPick only runs on the 5-Series, so choose the 5216 if fast footage search matters to you.
Does a hard drive come included?No — the NVR has two SATA bays but ships without storage. We recommend a surveillance-grade Seagate SkyHawk or WD Purple HDD, available as an add-on above.
How are the cameras powered?Each camera runs on a single Cat6 cable to one of the NVR's 16 built-in PoE ports — no separate power supplies or powerpoints at the camera.
Can I view it on my phone?Yes. Remote live view, playback and AI alerts are free through the Dahua DMSS app on iOS and Android, plus Smart PSS Lite on desktop.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua WizSense · 10 × 8MP 4K Smart Dual Light · 16CH AI NVR · AcuPick-Ready
10 × 8MP Kit
Dahua 10 × 8MP (4K) Full-Colour CCTV Kit with 16-Channel AI NVR
The Dahua 10 × 8MP (4K) Full-Colour CCTV Kit pairs ten DH-IPC-HDW3867EM-S-IL-ANZ Smart Dual-Light turret cameras with a 16-channel WizSense AI NVR for true 24/7 colour surveillance across larger Australian sites — supermarkets, childcare centres, warehouses, offices and factories. Smart Dual Light runs silent 30 m IR by night, then snaps a warm white LED on the instant WizSense AI detects a person or vehicle, capturing full-colour, evidence-grade 4K footage of every incident. Choose the standard NVR4216-16P-AI/ANZ, or step up to the NVR5216-16P-AI/ANZ to unlock AcuPick attribute search.
Cameras
10 × 8MP Smart Dual Light
Recorder
16CH AI NVR · 16 PoE
Resolution
8MP · 4K 3840×2160
AI Search
AcuPick-Ready
Audio
Built-in Mic (one-way)
Weatherproof
IP67 Rated
True 24/7 Full Colour
Smart Dual Light blends a 30 m IR illuminator with a 30 m warm-white LED. IR holds the scene at night with minimal light pollution; the warm light triggers on AI detection to record full-colour evidence of faces, clothing and number plates. Prefer no visible light? Switch to IR mode for discreet black-and-white night recording.
8MP 4K Detail
A 1/2.8" 8MP sensor outputs 3840×2160 — forensic-quality detail on faces and licence plates, well beyond standard HD, meeting evidential needs for insurance and law enforcement.
AcuPick-Ready Search
Pair the cameras with the 5-Series NVR5216-16P-AI/ANZ to unlock AcuPick — attribute-based search that finds every red car or every person in a hoodie across hours of footage in seconds.
16-Channel PoE Recorder
The 16CH AI NVR ships with 16 built-in PoE ports for true plug-and-play install, dual SATA bays for high-capacity surveillance storage, 4K HDMI output and remote viewing via the DMSS app.
What's Included
10 × Cameras
DH-IPC-HDW3867EM-S-IL-ANZ — 8MP 4K Smart Dual-Light WizSense turret, 2.8 mm, IR 30 m, built-in mic, IP67. Each ships with eave/soffit bracket, drill template, screw pack, waterproof RJ-45 connector & quick start guide.
1 × Recorder
DHI-NVR4216-16P-AI/ANZ (16CH AI NVR, 16 PoE) with power adaptor, USB mouse, SATA cables & quick start guide — or upgrade to DHI-NVR5216-16P-AI/ANZ for AcuPick.
Power
16 × PoE+ ports built into the NVR — each camera runs on a single Cat6 network cable that carries both power and data, so there are no separate power supplies. Network cabling is run on site and is not included; pre-made Cat6 patch leads are available separately.
Mounting
Included brackets suit eave/soffit installs. For brick or flush-wall mounting, add a Dahua DH-PFB204W wall-mount bracket per camera; a DH-PFA139 junction box is also available for tidy cable management.
Storage
Dual SATA bays — HDD not included. For ~30 days of 24/7 recording from all ten 8MP cameras (Smart H.265+) fit 2 × 12 TB Seagate SkyHawk or WD Purple; up to 16 TB per bay (32 TB total). Motion-only recording stretches this much further.
Warranty
3-Year Australian warranty · local CCTV Guru tech support.
Best For
Supermarkets & grocery
Full-colour 4K faces and number plates across tills, aisles and the loading dock.
Childcare centres
Clear colour coverage of entries, sign-in desks and play areas, day and night.
Offices & reception
Identify visitors and deliveries in colour, with AI alerts triggered after hours.
Warehouses & factories
Wide 105° 4K views of racking, roller doors and yards with vehicle detection.
Retail shopfronts
Deter theft and capture evidence-grade 4K colour footage in any lighting.
Car parks & yards
Person and vehicle AI detection with plate-readable 4K detail over open areas.
Camera Specifications — DH-IPC-HDW3867EM-S-IL-ANZ
Camera Type
8MP 4K Smart Dual-Light Turret (Eyeball) WizSense Network Camera
Image Sensor
1/2.8" 8MP Progressive CMOS
Max. Resolution
3840 × 2160 (8MP / 4K) @ 20 fps
Lens
Fixed 2.8 mm · 105° horizontal FOV
Night Vision
Smart Dual-Light · IR up to 30 m · Warm White LED up to 30 m
AI Features
AcuPick (with 5-Series NVR) · SMD · IVS (Tripwire, Intrusion, Abandoned Object)
Audio
Built-in microphone (one-way)
Compression
H.265+ / H.265 / H.264+ / H.264
Ingress Protection
IP67
Operating Temp.
–30 °C to +60 °C
Power
12 VDC · PoE (IEEE 802.3af)
Dimensions
Φ109.9 × 100.9 mm
Colours
White · Black
Compatibility
Dahua 5-Series AcuPick NVRs · ONVIF-compliant systems
Warranty (Australia)
3 years · CCTV Guru Australia
Choose Your 16-Channel AI NVR
NVR4216-16P-AI/ANZ
16CH 4K WizSense AI NVR · 16 PoE+ (130 W) · 2 SATA bays (to 32 TB) · Face, IVS/Perimeter, SMD Plus, ANPR · Quick Pick target search · ONVIF 21.12
NVR5216-16P-AI/ANZ
16CH AI NVR · 16 PoE · 2 SATA bays · 1U · higher bandwidth · AI by recorder & by camera · AcuPick search supported
Pick the 5216 if…
You want AcuPick attribute search and higher recording bandwidth. AcuPick only works with Dahua 5-Series NVRs.
Installation Notes
›Cabling: run solid-copper Cat6 from each camera back to the NVR's PoE ports for stable power and video over long distances.
›Weatherproofing: even at IP67, seal outdoor RJ-45 joins with weatherproof tape or a junction box to keep out moisture and salt air.
›NVR placement: mount the recorder in a cool, dust-free, ventilated spot away from direct sunlight for reliable 24/7 recording.
Setup & Installation Guides — Official Dahua
First-time NVR setup, step by step — Dahua Technology UK & Ireland
How to add an IP camera — Dahua Technology (official)
Downloads & Resources
DH-IPC-HDW3867EM-S-IL-ANZ Datasheet
DHI-NVR4216-16P-AI/ANZ Datasheet
DHI-NVR5216-16P-AI/ANZ Datasheet
Is this kit really full colour at night?Yes. Smart Dual Light runs IR by default, then switches to a 30 m warm-white LED the moment AI detects a person or vehicle — recording full-colour 4K footage of the event before returning to IR.
Can I turn off the white light at night?Yes. Smart Dual Light has three modes — Smart Dual (IR by default, warm light only on AI detection), full-colour (warm light always on) and IR-only. If you'd rather avoid any visible spotlight, set IR mode and the cameras keep recording clear black-and-white footage at night with no white light at all.
What's the difference between the two NVR options?The NVR4216 is the standard 16CH AI recorder. The NVR5216 adds AcuPick attribute search and higher bandwidth. AcuPick only runs on the 5-Series, so choose the 5216 if fast footage search matters to you.
Does a hard drive come included?No — the NVR has two SATA bays but ships without storage. We recommend a surveillance-grade Seagate SkyHawk or WD Purple HDD, available as an add-on above.
How are the cameras powered?Each camera runs on a single Cat6 cable to one of the NVR's 16 built-in PoE ports — no separate power supplies or powerpoints at the camera.
Can I view it on my phone?Yes. Remote live view, playback and AI alerts are free through the Dahua DMSS app on iOS and Android, plus Smart PSS Lite on desktop.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
WizSense PTZ · 4 MP · 4× Optical Zoom · Mini PTZ
WizSense PTZ
Dahua DH-SD1A404DB-GNY — 4 MP Mini PTZ Network Camera with 4× Optical Zoom WizSense (1-Series)
The Dahua DH-SD1A404DB-GNY is a compact 4 MP WizSense Mini PTZ network camera that brings true pan-tilt-zoom coverage to sites that previously made do with fixed-lens domes. A 1/2.8" Starlight progressive-scan CMOS sensor delivers crisp 2560 × 1440 footage at 25/30 fps, paired with a motorised 2.8–12 mm vari-focal lens offering 4× optical zoom and a flexible 105° wide to 31° tele field of view. Smart IR reaches up to 20 m for total-darkness scenes, while 120 dB true WDR balances headlight glare and shaded corners. The IP66 / IK08 housing is built for Australian conditions — coastal salt spray, inland heat and tropical humidity included — and the camera draws under 12 W over a single 802.3af PoE cable. PTZ smarts include 300 presets, 8 tours, auto-tracking, SMD 4.0 human/vehicle filtering and IVS tripwire/intrusion. ONVIF Profile S/G/T, H.265+, two-way audio, alarm I/O and a 256 GB microSD slot round out the spec. Built for Australian retail forecourts, council carparks, regional petrol stations, warehouse yards and body-corporate buildings, every unit ships with a 3-Year AU Warranty backed by CCTV Guru.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why Choose the Dahua SD1A404DB-GNY Mini PTZ
Compact PTZ Form Factor
Mini speed-dome footprint slips under eaves, awnings and low-soffit installs where a full-size PTZ won't fit — ideal for shopfronts, ATM bays and tight carpark corners.
4× Optical Zoom 2.8–12 mm
Motorised vari-focal lens pulls in number plates, faces and signage detail without the pixel-mush of digital zoom — 105° wide at 2.8 mm, 31° tele at 12 mm.
Starlight Low-Light Performance
1/2.8" Starlight CMOS keeps colour usable deep into dusk; smart IR fills the rest out to 20 m without bleaching nearby subjects.
IP66 / IK08 Rugged Build
Sealed metal-and-polycarbonate housing shrugs off rain, dust and impacts — rated for −30°C to +60°C ambient, suiting both alpine NSW and tropical FNQ sites.
802.3af PoE Single-Cable Install
Standard 802.3af PoE budget (~12 W) means it runs off any mainstream PoE switch or NVR PoE port — no PoE+ injectors or 24 V DC supplies required.
SMD 4.0 False-Alarm Filter
SMD 4.0 only triggers on humans and vehicles, slashing the wind-and-shadow alarms that plague basic motion detection on outdoor PTZs.
Important Install Note
The SD1A404DB-GNY draws around 12 W and runs on standard 802.3af PoE — any modern Dahua NVR PoE port, UniFi/TP-Link switch or stand-alone injector will power it. Keep Cat6 runs within the 100 m Ethernet limit; for longer hauls use a PoE extender or fibre media converter. Pendant and wall-bracket adapters are available for soffit, parapet or pole installs — specify the bracket at order time. For coastal AU installs (within ~5 km of saltwater), pair the camera with a rated surge protector on the Ethernet line and earth the bracket to the building's ground bus to maintain the 3-Year AU Warranty under storm conditions.
AI & Smart Detection
Auto-Tracking
When a tripwire or intrusion event triggers, the PTZ automatically pans, tilts and zooms to follow the target — then returns to its home preset once the subject leaves frame.
SMD 4.0 (Smart Motion Detection)
On-camera AI classifies humans vs vehicles before raising an event, eliminating the rubbish-bin, foliage and rain triggers that swamp basic VMD.
IVS Tripwire & Intrusion
Draw virtual lines or zones over the scene — the camera reports crossings or loitering with bounding boxes overlaid in DMSS and on the NVR timeline.
300 Presets & 8 Tours
Program up to 300 named preset positions and chain them into 8 patrol tours — ideal for cycling between a forecourt entry, pump bay, ATM and exit.
Privacy Masking
Up to 24 configurable privacy zones blank out neighbouring windows, public footpaths or staff-only areas to meet Australian Privacy Principle obligations.
ONVIF Integration
ONVIF Profile S/G/T compliance lets the camera record into Hikvision, UniFi Protect, Milestone, Blue Iris and other third-party VMS with PTZ control intact.
Technical Specifications
Camera, Lens & Illumination
Model
DH-SD1A404DB-GNY
Form Factor
Mini PTZ Dome
Image Sensor
1/2.8" Progressive Scan CMOS (Starlight)
Max Resolution
4 MP (2560 × 1440)
Frame Rate
25/30 fps @ 4 MP
WDR
120 dB True WDR
Day/Night
ICR Auto Switch
Lens Type
Motorised Vari-focal, 4× Optical Zoom
Focal Length
2.8 mm – 12 mm
Field of View
H: 105° (Wide) – 31° (Tele)
IR Distance
Up to 20 m
Intelligence, Audio & Network
AI Engine
WizSense
IVS
Tripwire, Intrusion
SMD
SMD 4.0 (Human & Vehicle)
Auto Tracking
Yes
Presets / Tours
300 Presets / 8 Tours
Audio I/O
1/1 (Line In/Out)
Alarm I/O
1/1
Network
RJ-45 10/100 Mbps
ONVIF
Profile S/G/T
Storage
microSD up to 256 GB
App
DMSS (iOS & Android)
Power, Environment & Build
Power
PoE (802.3af) / 12 V DC, ~12 W
Operating Temp
−30°C to +60°C
Protection
IP66 / IK08
Casing
Metal + Polycarbonate Dome
Warranty
3-Year AU Warranty (CCTV Guru)
Recommended NVR Pairings
Dahua DHI-NVR5208-8P-AI/ANZ
8-channel WizSense AI NVR with 8 PoE ports — ideal for a single SD1A404DB-GNY plus fixed cameras across one site.
View DHI-NVR5208-8P-AI/ANZ →
Dahua DHI-NVR5216-16P-AI/ANZ
16-channel 16-PoE WizSense AI NVR for mid-size yards or multi-PTZ deployments.
View DHI-NVR5216-16P-AI/ANZ →
Dahua DHI-NVR4216-16P-AI/ANZ
4K 16-channel 16-PoE smart AI NVR — cost-effective recorder for SMB sites.
View DHI-NVR4216-16P-AI/ANZ →
Dahua DHI-NVR5432-AI/ANZ
32-channel WizSense AI NVR (no built-in PoE) for large campuses with separate PoE switches.
View DHI-NVR5432-AI/ANZ →
Frequently Asked Questions
What's the difference between the 4× optical zoom and digital zoom?
Optical zoom physically moves lens elements (2.8–12 mm) so every pixel of the 4 MP sensor is used at any focal length — detail stays sharp. Digital zoom just crops and upscales the existing image, so the picture softens. Always use the 4× optical first and reserve digital zoom for emergencies.
What PoE budget does it need?
Around 12 W — well within the 15.4 W of standard 802.3af. Any Dahua NVR PoE port, UniFi/TP-Link/Cisco switch or 802.3af injector will run it. PoE+ (802.3at) is not required.
How does auto-tracking behave?
When an IVS tripwire or intrusion event fires, the camera pans/tilts/zooms to keep the subject in frame. Once the subject leaves the scene or the tracking timeout expires, the PTZ automatically returns to its home preset and resumes any active tour.
Can it record to a microSD card?
Yes — the camera takes a single microSD up to 256 GB for edge recording. Use a high-endurance surveillance-rated card (e.g. Dahua S100, WD Purple, Samsung PRO Endurance) for 24/7 reliability.
Can it run stand-alone without an NVR?
Yes. With a microSD card fitted and DMSS configured for P2P, you can view live, get push alerts and review event clips entirely from the app. For 24/7 continuous recording across multiple cameras, an NVR is strongly recommended.
Will it work with non-Dahua NVRs?
Yes — ONVIF Profile S/G/T compliance covers video streaming, PTZ control and edge storage playback in Hikvision, UniFi Protect, Milestone, Blue Iris and most other VMS platforms. WizSense AI events are only forwarded natively to Dahua recorders, however.
Indoor or outdoor?
Both. IP66 / IK08 ratings cover outdoor exposure (rain, dust, vandalism) and the −30°C to +60°C operating range comfortably handles AU climates from Hobart to Darwin.
What's in the box?
Camera, mounting screws/anchors, waterproof RJ-45 boot, hex key, quick start guide. Pendant, wall and pole bracket adapters are sold separately — let our team know your install type at order time.
What are the warranty terms?
3-Year AU Warranty through CCTV Guru, covering manufacturing defects on locally-stocked product. Storm, surge, lightning and physical-damage events are excluded — pair coastal installs with surge protection to keep coverage intact.
Downloads
Datasheet (PDF)
Quick Start Guide
Installation Guide
Install Manual
Order Your Dahua SD1A404DB-GNY from CCTV Guru
Ready to deploy a compact WizSense PTZ on your forecourt, carpark or yard? The Dahua DH-SD1A404DB-GNY ships from Australian stock with a 3-Year AU Warranty, free local tech support and same-business-day dispatch on orders placed before 2 pm AEST. Need bracket advice, an NVR-and-camera quote or trade pricing? Talk to the CCTV Guru team and we'll spec the right combination for your site.
Hikvision Pro Series · 4MP · 25× Zoom · DarkFighter · AcuSense PTZ
4MP 25× DarkFighter PTZ
Hikvision DS-2DE7A425IWG1-E — 4MP Pro Series AcuSense PTZ with 25× Optical Zoom, DarkFighter & 200 m IR
The Hikvision DS-2DE7A425IWG1-E is a 4 MP Pro Series PTZ speed dome built for long-range, wide-area surveillance. A 25× optical zoom (4.8–120 mm) plus 16× digital reaches right across car parks, yards, perimeters and public spaces, while DarkFighter + AI-ISP deliver clean colour down to 0.005 lux and IR up to 200 m in full darkness. AcuSense deep-learning AI classifies people and vehicles, drives smart auto-tracking, and triggers an integrated white-light strobe and audible warning to actively deter intruders. Built tough with IP67 and IK10 ratings for Australian outdoor sites.
Resolution
4MP · 2560 × 1440
Zoom
25× Optical (4.8–120mm)
Night Vision
DarkFighter · 200 m IR
Smart AI
AcuSense · Auto-Tracking
Deterrence
Strobe + Audible Alarm
Build
IP67 · IK10
25× Long-Range Zoom
A 4.8–120 mm motorised lens with 25× optical (plus 16× digital) zoom reads faces and number plates right across large open areas, with rapid full-range refocus.
DarkFighter + AI-ISP
Ultra-low-light imaging holds colour to 0.005 lux and switches to 200 m IR in full darkness — clear footage day and night across big sites.
AcuSense + Auto-Tracking
Deep-learning human/vehicle classification cuts false alarms and lets the PTZ automatically lock on and follow a moving target across its field of view.
Active Deterrence
On a verified AcuSense event the camera flashes a white-light strobe and plays an audible warning, with dual array mics and a built-in speaker for live talk-down.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Full Specifications — DS-2DE7A425IWG1-E
Model
DS-2DE7A425IWG1-E
Camera Type
Pro Series 4 MP AcuSense DarkFighter Network PTZ Speed Dome
Max. Resolution
2560 × 1440 (4 MP) · up to 50/60 fps
Optical Zoom
25× · 4.8–120 mm motorised lens
Digital Zoom
16×
Min. Illumination
Colour 0.005 lux · B/W 0.001 lux · 0 lux with IR
IR Night Vision
Up to 200 m
Low-Light Tech
DarkFighter + AI-ISP
Pan / Tilt
Pan 360° endless · Tilt −15° to +90° · auto-flip
Smart Functions
AcuSense human/vehicle classification · smart auto-tracking · face capture · people counting · perimeter protection
Deterrence
White-light strobe + audible warning (visual & audio alarm linkage)
Audio
Dual array microphones · built-in speaker · audio in/out
Compression
H.265+ / H.265 / H.264+ / H.264
Network
RJ45 10/100/1000 Mbps · ONVIF · Hik-Connect (P2P)
Protection
IP67 · IK10 · lightning/surge protection
Operating Temp.
−30 °C to +60 °C
Warranty (Australia)
3 Years · CCTV Guru Australia
Best For
Car parks & yards
Track vehicles and people across large open areas with 25× zoom and auto-tracking.
Perimeters & acreage
200 m IR and DarkFighter cover long fence lines and rural boundaries after dark.
Industrial & logistics
Loading docks, hardstands and equipment yards with live talk-down and strobe deterrence.
Public & civic spaces
Plazas, transport hubs and council sites needing wide coverage from a single camera.
Downloads & Resources
DS-2DE7A425IWG1-E Datasheet (Hikvision)
Hikvision Speed Dome Quick Start Guide
Hikvision Speed Dome User Manual
How far can it see and identify detail?The 25× optical zoom (4.8–120 mm) plus DarkFighter and 200 m IR let it pick up faces and number plates well across large car parks, yards and perimeters — far beyond a fixed camera.
Does it track moving people/vehicles automatically?Yes — AcuSense classifies humans and vehicles and the PTZ can auto-track a target across its field of view, with manual override any time.
What deterrence does it have?An integrated white-light strobe and audible warning trigger on verified AcuSense events, and the dual mics + built-in speaker allow live two-way talk-down via Hik-Connect.
How is it powered?A PTZ of this class needs Hi-PoE or a 24 VAC supply — confirm the exact power input on the datasheet and budget for it (a standard 802.3af port is not sufficient).
Will it work with my NVR?Yes — it's ONVIF compatible and integrates fully with Hikvision NVRs and Hik-Connect for live view, PTZ control, recording and playback.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision DeepinView · 4MP · ANPR · Hybrid Light · HEOP 2.0
Hikvision iDS-2CD7347G0/P-XS — 4MP DeepinView Hybrid-Light ANPR Camera (4 mm Fixed, HEOP 2.0, IP67)
The Hikvision iDS-2CD7347G0/P-XS is a 4 MP DeepinView ANPR camera built on a 1/1.8" Progressive Scan CMOS with a fixed 4 mm lens (~94.7° horizontal). Hybrid illumination (IR + white light) reaches up to ~40 m with smart supplement-light control, and excellent low-light sensitivity to 0.0003 lux keeps plates and faces readable after dark. Running on Hikvision's HEOP 2.0 open platform with 1.5 TOPS of on-board AI, it delivers licence-plate recognition (ANPR), human/vehicle detection and smart-event metadata. IP67 weatherproof, rated −30 °C to +60 °C. Australian stock, 3-year Australian warranty.
Resolution
4 MP · 2688 × 1520
Lens
4 mm Fixed · 94.7° HFOV
Hybrid Light
IR + White · up to 40 m
ANPR
Plate Recognition
AI Platform
HEOP 2.0 · 1.5 TOPS
Protection
IP67 · 3-Year AU
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why Choose the iDS-2CD7347G0/P-XS
ANPR · Plate Recognition
On-board deep-learning licence-plate recognition for gates, car parks and access control — capture and log plates with smart-event triggering.
Hybrid Light · 40 m
IR + white-light supplement with smart control gives covert IR or white-light colour at night, readable to ~40 m.
HEOP 2.0 Open AI Platform
1.5 TOPS of on-board compute runs Hikvision analytics plus third-party HEOP apps for tailored detection workflows.
Exceptional Low Light
1/1.8" sensor holds colour to 0.0003 lux — plates and faces stay readable in very dark conditions.
Technical Specifications
iDS-2CD7347G0/P-XS · Full Specifications
SKU
iDS-2CD7347G0/P-XS
Camera Type
Hikvision DeepinView 4 MP Hybrid-Light ANPR Network Camera
Image Sensor
1/1.8" Progressive Scan CMOS
Resolution
2688 × 1520 (4 MP)
Lens
4 mm fixed · H 94.7° · V 49.4° · D 112.6°
Min. Illumination
Colour 0.0003 lux · B/W 0.0001 lux · 0 lux with light
Supplement Light
Hybrid (IR + White) up to ~40 m · smart supplement light
Day & Night
IR cut filter (blue glass to reduce ghosting)
AI Platform
HEOP 2.0 · 1.5 TOPS
Smart Analytics
ANPR / licence-plate recognition · human/vehicle detection & metadata
Video Streams
Main · sub · third
Video Compression
H.265+ · H.265 · H.264+ · H.264
Weatherproof Rating
IP67
Operating Temperature
−30 °C to +60 °C
Warranty
3-Year Australian Warranty
Frequently Asked Questions
Does it read number plates?Yes — the DeepinView ANPR engine captures and recognises licence plates on-camera, ideal for gates, car parks and access control. See the included ANPR Installation & Configuration Guide for setup.
What is Hybrid Light?Hybrid illumination combines IR and white-light LEDs (up to ~40 m) with smart supplement-light control — run covert IR, white-light colour, or a smart blend.
What does HEOP 2.0 add?HEOP 2.0 is Hikvision's open AI platform — with 1.5 TOPS of compute, the camera runs advanced Hikvision analytics and supports third-party detection apps directly on the device.
Downloads & Resources
iDS-2CD7347G0/P-XS Datasheet
Hikvision ANPR Camera Installation & Configuration Guide
Order the Hikvision iDS-2CD7347G0/P-XS from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision DeepinView AI cameras. The iDS-2CD7347G0/P-XS brings 4 MP DeepinView imaging, hybrid IR + white light, HEOP 2.0 AI and on-camera ANPR to gates, car parks and access-control points. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch. Request a free quote or contact our Australian team.
WizSense + AcuPick · 5-Series · 64-Channel · 4-HDD · 1.5U64CH AcuPick NVR
The Dahua DHI-NVR5464-AI/ANZ is a 64-channel 5-Series WizSense AI NVR with AcuPick, four SATA bays, dual Gigabit NICs, dual HDMI + dual VGA outputs, and a 1.5U rack chassis built for enterprise-scale installs. Record up to 32 MP per channel, run AcuPick across up to 32 channels, drive a 64-channel split on the main monitor, and scale storage to roughly 64 TB across the four 16 TB drives.
This is the official Australia / NZ-market SKU (the AI/ANZ suffix). It's a headend NVR with no built-in PoE — cameras connect through an external PoE switch or your existing managed network. Internal 100–240 VAC universal PSU, AS/NZS-compliant kettle cord, and a local 3-year warranty backed by CCTV Guru in Sydney. Designed for multi-site retail chains, transport hubs, large carparks, hospitals and any campus running 30–60+ cameras through a structured network. AcuPick, N+M cluster and iSCSI are enabled by Dahua's V5 firmware (current factory ship as of 2025).
AcuPick on up to 32 channels — enterprise-scale search
AcuPick Channels
Up to 32 ch · 1 event / channel / sec
Search Method
Image + attribute · front + back AI
Search by reference image
Click any person or vehicle in recorded video, hit AcuPick, and the NVR scans the active 32 channels for matches across hours or days — clothing colour, body shape, vehicle make / model / colour / direction included.
Front- + back-end intelligence
Camera-side AI extracts target attributes during recording; NVR-side AI runs the comparison. Higher accuracy than recorder-only search and orders of magnitude faster than human review.
Investigations finish in minutes
Find a suspect across the AcuPick-active channels and weeks of footage in a single search. Particularly valuable for police investigations, insurance disputes, and post-incident review.
ANPR + SMD Plus on all 64
While AcuPick covers up to 32 channels, ANPR by camera, SMD Plus by camera and perimeter protection by camera all scale across every connected camera up to 64 — site-wide intelligence with no channel left behind.
5-Series WizSense AI — depth at scale
Industrial AI Chip
Same chip as the flagship 32-ch siblings
Face Database
20 databases · 20,000 images
Face Recognition (16-ch image stream)
16 channels of camera-side face detection feeding NVR-side recognition at 16 face snapshots/sec — ideal for entry / exit and high-footfall installs. Twenty face databases, 20,000 images, full attribute filtering.
Perimeter Protection (4 ch by NVR)
4 NVR-side channels of tripwire and intrusion analytics (10 IVS rules each), plus all-channel perimeter via camera-side processing — every camera benefits from human/vehicle classification.
SMD Plus (8 ch by NVR)
8 NVR-side SMD Plus channels plus all-channel camera-side SMD — deep-learning second-pass classification on every camera, cutting false alarms across the entire site.
ANPR by camera (all channels)
Pair with Dahua ANPR cameras for full 64-channel licence-plate recognition feeding a 20,000-plate database with blocklist / allowlist control. Carpark, fleet yard, gate management, even multi-site ANPR.
Video Metadata search
8 channels of camera-side metadata extraction — top colour, bottom colour, hat, bag, umbrella, gender, age, vehicle make / model / colour / plate, helmet wear and more.
N+M cluster failover
Pair multiple 5-Series NVRs in an N+M cluster — backup recorders automatically take over if a primary fails, ensuring zero footage loss for sites where downtime isn't an option.
See AcuPick in action
Dahua AcuPick — Video search technology demonstration
AcuPick — how to configure and search on a Dahua NVR
64-channel recording · dual HDMI · 64 TB on-board storage
Up to 32 MP per channel
True 8K-class input — supports Dahua's highest-resolution cameras, plus 24 MP, 16 MP, 12 MP, 8 MP (4K), 5 MP and 4 MP IP cameras from any ONVIF brand. All 64 channels share the 384 Mbps recording bandwidth.
2× HDMI + 2× VGA outputs
Two independent HDMI heads (each up to 4K) with two mirrored VGAs — drive a multi-monitor control room with independent layouts on each screen. Heterogeneous video routing on HDMI1/HDMI2.
64-channel split on main screen
Main monitor supports 1 / 4 / 8 / 9 / 16 / 25 / 36 / 64-split layouts (sub monitor up to 16). Watch the entire site at a glance — every camera on one screen.
4 SATA bays · up to 64 TB
Four surveillance-grade HDDs (WD Purple, Seagate SkyHawk) up to 16 TB each — weeks of 64-channel recording without touching network storage.
eSATA + iSCSI expansion
External SATA archive port plus iSCSI network-storage support — scale beyond 64 TB without rebuilding the recorder. Disk-group protection across the four on-board drives.
Smart H.265+ for half the storage
AI-tuned H.265+ encoding cuts bitrate on static background pixels while preserving detail on moving targets — roughly half the storage and bandwidth of standard H.264. Critical at 64-channel scale.
Enterprise I/O — dual NIC, 16 alarm-in, 12V output
Dual Gigabit NICs
Two independent RJ-45 Gigabit ports with multi-address, load-balance and fault-tolerance bonding modes — segregate camera VLAN from management VLAN, or run an active-passive failover link.
16 alarm-in / 6 alarm-out
Physical terminal block for 16 alarm inputs and 6 alarm outputs — one of the outputs is a 12 V 1 A direct power feed for sirens, strobes or gate solenoids.
RS-232 + RS-485
Both serial standards present — integrate with POS systems, gate controllers, access control panels, PTZ joysticks or third-party VMS that need legacy serial. RS-485 is half-duplex.
3 × USB (1 × 2.0 + 2 × 3.0)
One front USB 2.0 plus two rear USB 3.0 ports — plug in backup drives, USB mice, keyboards or service tools without juggling cables behind the rack.
ONVIF 23.12 (T / S / G)
Latest ONVIF profile support on V5 firmware — drops into any current VMS, plus native integration for Panasonic, Sony, Axis, Pelco, Arecont, Canon and Hanwha as well as Dahua.
DMSS + DSS Pro VMS
Free DMSS mobile app for live view, playback and push notifications. For multi-site enterprise deployments, integrate with Dahua DSS Pro for centralised control of multiple 5464 NVRs across sites.
NVR5464 vs the family — how it compares
The 5464 (this model) sits at the top of the 5-Series AI/ANZ NVR range — twice the IP channel count of the 5432, with the same chassis, AI horsepower and storage capacity. Choose this when you have between 32 and 64 cameras connected via a structured PoE switch network. For 16–32 cameras on the same chassis, step down to the 5432; if you want built-in PoE for the first 16 cameras, choose the 5432-16P.
5-Series Top-Tier Comparison
Specification
NVR5464-AI/ANZ (this model)
NVR5432-AI/ANZ
NVR5432-16P-AI/ANZ
IP channels (licence)
64
32
32
AcuPick channels
Up to 32
Up to 32
Up to 32
Main-screen split
Up to 64
Up to 36
Up to 36
Max camera resolution
32 MP
32 MP
32 MP
Bandwidth (AI off / on)
384 / 200 Mbps
384 / 200 Mbps
384 / 200 Mbps
Built-in PoE
None (external switch)
None (external switch)
16 × ports · 150 W · 1-8 ePoE
HDD bays
4 SATA · up to 64 TB
4 SATA · up to 64 TB
4 SATA · up to 64 TB
eSATA · iSCSI
Yes / Yes
Yes / Yes
Yes / Yes
Network ports
2 × Gigabit (bondable)
2 × Gigabit (bondable)
2 × Gigabit (bondable)
Video outputs
2 × HDMI + 2 × VGA
2 × HDMI + 2 × VGA
2 × HDMI + 2 × VGA
Alarm I/O
16 in / 6 out (incl. 12 V)
16 in / 6 out (incl. 12 V)
16 in / 6 out (incl. 12 V)
USB ports
1 × 2.0 + 2 × 3.0
1 × 2.0 + 2 × 3.0
1 × 2.0 + 2 × 3.0
Form factor
1.5U
1.5U
1.5U
ONVIF (V5 firmware)
23.12 (T / S / G)
23.12 (T / S / G)
23.12 (T / S / G)
N+M cluster · Warranty
Yes / 3 years
Yes / 3 years
Yes / 3 years
Full Specifications
Model
DHI-NVR5464-AI/ANZ
Series
WizSense · NVR5000-AI/ANZ (Australia / NZ market)
Form factor
1.5U · 4-HDD · rack or desktop · NO built-in PoE
IP channels
64 · up to 32 MP per channel
Supported resolutions
32 MP · 24 MP · 16 MP · 12 MP · 8 MP · 5 MP · 4 MP · 1080p · 720p · D1 · CIF · QCIF
Bandwidth (AI off)
384 Mbps incoming / 384 Mbps record / 384 Mbps outgoing
Bandwidth (AI on)
200 Mbps incoming / 200 Mbps record / 200 Mbps outgoing
Decoding (AI off)
2 × 32 MP @ 20 fps · 2 × 24 MP @ 20 fps · 4 × 16 MP @ 30 fps · 5 × 12 MP @ 30 fps · 8 × 8 MP @ 30 fps · 12 × 5 MP @ 30 fps · 16 × 4 MP @ 30 fps · 32 × 1080p @ 30 fps
Decoding (AI on)
1 × 32 MP @ 20 fps · 1 × 24 MP @ 20 fps · 2 × 16 MP @ 30 fps · 4 × 12 MP @ 30 fps · 4 × 8 MP @ 30 fps · 8 × 5 MP @ 30 fps · 12 × 4 MP @ 30 fps · 24 × 1080p @ 30 fps
Video compression
Smart H.265+ · H.265 · Smart H.264+ · H.264 · MJPEG
Audio compression
G.711a · G.711u · PCM · G.726
AI engine
WizSense (industrial AI chip, deep-learning) · AcuPick supported
AcuPick
Up to 32 channels · 1 combined event per channel/sec (V5 firmware)
Face Detection (NVR)
2 channels · up to 12 face snapshots/sec each
Face Recognition (NVR)
16 ch (FD by camera + FR by recorder, 16 fps) · or 2 ch (FD+FR by recorder, 12 fps)
Face Database
20 databases · 20,000 images · 2.5 GB · gender / age / glasses / expression / mask / beard attributes
Perimeter Protection
4 channels by NVR · all channels by camera · 10 IVS rules per channel
SMD Plus
8 channels by NVR · all channels by camera
Video Metadata
8 channels (camera-side) · human / motor / non-motor vehicle attributes
ANPR (by camera)
All channels · 20,000-plate database · blocklist / allowlist
AI by Camera (passthrough)
Face detection · Face recognition · Video metadata · Perimeter protection · SMD Plus · Stereo analysis · Crowd distribution · People counting · ANPR · Vehicle density · Heat map
N+M cluster · iSCSI · eSATA
Yes / Yes / Yes
HDD bays
4 × SATA · up to 16 TB per drive (~64 TB max)
Video output
2 × HDMI (4K · 3840×2160) + 2 × VGA (1080p) · heterogeneous HDMI1/HDMI2 · simultaneous VGA1+HDMI1 / VGA2+HDMI2
Multi-screen display
Main screen: 1 / 4 / 8 / 9 / 16 / 25 / 36 / 64 · Sub screen: 1 / 4 / 8 / 9 / 16
Audio I/O
1 × RCA in · 2 × RCA out
Alarm I/O
16 × alarm in · 6 × alarm out (1 × 12 V 1 A power output)
USB
3 ports: 1 × front USB 2.0 + 2 × rear USB 3.0
Network ports
2 × RJ-45 Gigabit Ethernet (10 / 100 / 1000 Mbps) · multi-address / load-balance / fault-tolerance bonding
PoE
None (use external PoE switch)
RS-232 / RS-485
1 / 1 (RS-485 half-duplex)
eSATA
1 port (external archive)
Network protocols
HTTP / HTTPS · TCP/IP · IPv4/IPv6 · UDP · NTP · DHCP · DNS · SMTP · UPnP · DDNS · Alarm Server · Multicast · P2P · Auto Registration · iSCSI
ONVIF
23.12 on V5 firmware (Profile T / S / G) · CGI · SDK
Third-party camera support
ONVIF · Panasonic · Sony · Axis · Arecont · Pelco · Canon · Samsung · Hanwha
Mobile app
DMSS (iOS / Android)
Record modes
General · motion detection · intelligent · alarm · POS
Backup
USB device · network
Power supply
100 – 240 VAC · 50 – 60 Hz (internal universal-voltage PSU)
Power consumption
≤ 13 W NVR-side (without HDD)
Operating temperature
−10 °C to +55 °C
Operating humidity
10% – 93% RH
Dimensions
440 × 415.1 × 70 mm (1.5U)
Net weight
4.74 kg
Installation
Rack or desktop
Recommended firmware
DH_NVR5XXX-EI_MultiLang V5.001.0000000.0.R.251220 (or later) — required for AcuPick, N+M cluster, iSCSI and ONVIF 23.12
Certifications
FCC Part 15 Subpart B Class A · CE-EMC · CE-LVD · Security Baseline 2.3
Warranty
3 years (CCTV Guru Australia)
Downloads & documentation
Download official Dahua documents for setup, specifications, and recorder details.
DHI-NVR5464-AI/ANZ Datasheet
Dahua NVR Quick Start Guide
Dahua NVR User Manual
Dahua NVR HDD Installation Guide
Frequently asked questions
Does this NVR really support AcuPick?
Yes. Dahua's V5 firmware (binary DH_NVR5XXX-EI_MultiLang_V5.001.0000000.0.R.251220 or later) enables AcuPick on the AI/ANZ unit alongside N+M cluster, iSCSI and ONVIF 23.12. The firmware is published on Dahua AU's official product page for this model and ships from CCTV Guru with V5 installed. Older 2023-vintage datasheets predate this firmware, which is why some online documentation doesn't mention AcuPick.
Why is AcuPick capped at 32 channels when the NVR supports 64?
AcuPick is heavy on AI-chip resources — running attribute extraction and image-search against 64 channels simultaneously isn't possible on the current 5-Series silicon. You choose which 32 of the 64 channels run AcuPick (the rest still record, and still get ANPR / SMD Plus / perimeter via camera-side AI). For 64-channel AcuPick, look at Dahua's NVR6 series.
Why doesn't it have built-in PoE?
The 5464 is a headend NVR for sites with managed PoE switches. Sixty-four cameras through fixed PoE ports would mean a 3–4U chassis and a power supply that doesn't fit the 1.5U form factor. Most 64-camera installs already have a switching layer, and dedicated PoE switches give you better cable layout, VLANs and redundancy than fixed-port PoE.
What is AcuPick and what do I need for it?
AcuPick is Dahua's next-generation attribute-and-image search — it extracts rich target attributes (clothing, body shape, vehicle make/model/colour/plate, direction) at the camera AND the NVR, then lets you search by reference image or combined attributes. You need Dahua's AcuPick-ready cameras (typically TiOC PV and 5-Series WizSense Plus IPC families). Standard WizSense cameras still record and recognise faces but the full AcuPick depth requires paired AcuPick IPCs.
How big a PoE switch do I need for 64 cameras?
Allow about 7–15 W per camera for Dahua WizSense bullets/turrets, more for active-deterrence units and PTZs. Two 48-port PoE+ switches with ~370–500 W each will run 64 typical cameras comfortably, with spare ports for VoIP and APs. CCTV Guru can quote a complete switch + NVR bundle.
How much storage do I need for 64 cameras?
For 64 × 4 MP cameras at H.265+ on motion-record, allow ~50–70 TB for 30 days of retention. Four 16 TB surveillance-grade drives (WD Purple Pro, Seagate SkyHawk AI) gives you ~64 TB on-board with disk-group protection. If on-board capacity isn't enough, iSCSI lets you expand onto network-attached storage or eSATA onto external archive arrays.
Can it be rack-mounted?
Yes — 1.5U / 440 mm wide fits a standard 19-inch rack with ears (rack ears sold separately). It can also sit on a desk or shelf if you've allocated cabinet space. Plan for about 7–8 kg fully loaded with four drives.
3-Year Warranty
Australia-Wide Shipping
Australian Tech Support
Hikvision CAT6 UTP · 305m · Solid Bare Copper
DS-1LN6UZC0 — Hikvision CAT6 UTP 305m Solid Copper Network Cable (Yellow)
The Hikvision DS-1LN6UZC0 in yellow is a 305 m CAT6 U/UTP installation cable for reliable, high-performance data and IP CCTV networks — the bright jacket makes it easy to identify in busy comms cabinets and conduit. Its 0.5 mm solid bare copper conductors give low resistance and superior electrical properties, built to ANSI/TIA-568.2-D, IEC61156 and ISO/IEC11801 standards.
It holds performance in the Fluke 90 m permanent-link test at a continuous 50 °C, and in the 100 m channel test under 57 V / 1 A DC PoE load. A high-tensile sheath reduces damage on conduit pulls. Fully RoHS 2.0 compliant.
Solid Bare Copper0.5 mm true copper cores — low resistance, stable PoE delivery.
High-Visibility YellowEasy circuit identification across structured-cabling runs.
PoE & Heat TestedFluke-verified at 50 °C and under 57 V / 1 A PoE load.
Standards CompliantANSI/TIA-568.2-D, IEC61156, ISO/IEC11801, RoHS 2.0.
Technical Specifications
Model
DS-1LN6UZC0 (Yellow)
Category
CAT6 U/UTP, 4 pair
Conductor
Solid bare copper, 0.5 mm
Length
305 m
Standards
ANSI/TIA-568.2-D, IEC61156, ISO/IEC11801
Compliance
RoHS 2.0
Datasheet (PDF)
Is this safe for PoE?Yes. The solid bare copper cores are channel-tested under 57 V / 1 A DC load, suitable for PoE and PoE+ cameras.
Is it copper or CCA?100% solid bare copper — not copper-clad aluminium — for stable resistance and full PoE compliance.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
A genuine Hikvision 305 m CAT6 solid-copper cable in high-visibility yellow — standards-certified, PoE-ready and easy to trace.
Wi-Fi IP Intercom Kit · 7" Monitor · DMSS App Control
Dahua DHI-KTW02 Wi-Fi IP Video Intercom Kit with 7-Inch Touchscreen Monitor
The Dahua DHI-KTW02 is a premium Wi-Fi IP video intercom kit designed for Australian homes, villas, townhouses, offices, clinics, small businesses and modern residential entry points. It includes a 7-inch touchscreen indoor monitor and a smart 2MP outdoor door station, giving you visitor video, two-way audio, mobile app calling, IC card access and remote door release in one complete Dahua intercom package.
Unlike a basic consumer video doorbell, the KTW02 is a true IP intercom and access control solution. It supports Wi-Fi, PoE, DMSS mobile app control, door unlocking, IC card unlock, SIP server support and professional door station integration. It is ideal when you want a reliable front-door communication system that looks clean, works with proper door hardware and suits long-term home or business security.
Use it for front gates, entry doors, offices, villas, reception areas, small commercial buildings and residential upgrades where a professional intercom system is preferred over a simple battery doorbell.
Model
DHI-KTW02
Monitor
7" Touchscreen
Connectivity
Wi-Fi · PoE · IP
App
DMSS Mobile
Access
IC Card Unlock
Door Control
Remote Unlock
Genuine Dahua
Professional IP Intercom
Australian Support
What’s Included in the Kit
1 × DHI-VTH2621G-WP Indoor Monitor
7-inch touchscreen indoor monitor with Wi-Fi, PoE, two-way audio, alarm input support, microSD card support and DMSS app integration.
1 × DHI-VTO2311R-WP Door Station
2MP IP villa door station with wide-angle video, two-way audio, IC card unlock, door release support and weather-resistant outdoor design.
Mounting Accessories
Includes Dahua-supplied mounting accessories for a clean residential or small commercial intercom installation.
DMSS App Support
Answer visitor calls, view the door station and unlock compatible door hardware from your smartphone when configured correctly.
Why Choose the Dahua DHI-KTW02?
True IP Intercom System
The KTW02 is not just a smart doorbell. It is a proper IP video intercom system with indoor monitor, outdoor station, app access and door release support.
Wi-Fi and PoE Flexibility
The system supports modern IP installation options, giving installers flexibility across homes, offices, villas and small commercial entry points.
7-Inch Touchscreen Monitor
The included indoor monitor gives users a clean interface for answering calls, viewing visitors and unlocking the door from inside the property.
DMSS Mobile App Control
Receive visitor calls, speak to visitors and remotely unlock the door through the Dahua DMSS app when the system is connected and configured correctly.
IC Card Unlock
The outdoor station supports IC card access, making it practical for family members, staff, tenants and regular users.
Professional Door Release
Pair the system with a compatible electric strike or magnetic lock for proper remote door release, rather than relying on consumer-style doorbell features only.
Why KTW02 Instead of a Video Doorbell?
Built for Real Door Entry
Consumer doorbells are mainly for notifications and video. The KTW02 is designed for visitor communication, indoor monitor use and door unlocking.
Indoor Monitor Included
You are not forced to rely only on a mobile phone. The 7-inch monitor gives your home, office or reception area a dedicated intercom screen.
Access Control Ready
Use IC cards and compatible door hardware for more professional access control at the front door or gate.
Better for Long-Term Installations
Ideal for customers who want a fixed, professional entry system rather than a temporary consumer smart-home device.
Recommended For
Homes & Villas
A clean front-door intercom solution with indoor monitor, mobile app calling, IC card unlock and door release support.
Townhouses & Units
Ideal for compact properties that need a modern Wi-Fi/IP intercom without moving to a larger apartment intercom platform.
Small Offices
Let staff answer the front door from the monitor or smartphone, then release the door using compatible lock hardware.
Clinics & Reception Areas
View visitors and control access without leaving the reception desk, treatment area or office.
Retail & Back Entrances
Secure rear doors, staff entries, side doors and delivery points with video calling and controlled release.
Gate & Front Entry Projects
Suitable for residential and small commercial entry points where visitor communication and remote unlock are required.
Recommended Accessories
Electric Strikes
Pair the KTW02 with a compatible electric strike for remote door release on suitable timber, aluminium or framed doors.
Magnetic Locks
Suitable for selected glass doors, office entries and fail-safe access control applications.
Exit Buttons & Door Contacts
Add request-to-exit buttons and reed switches for better access control logic and door status monitoring.
Dahua Intercom Accessories
Browse Dahua intercom monitors, brackets, door stations and accessories for future expansion.
Watch the Dahua KTW02 in Action
Technical Specifications
Indoor Monitor — DHI-VTH2621G-WP
Display
7-inch capacitive touchscreen
Resolution
1024 × 600
Wi-Fi
Supported
Network
IP network connection supported
PoE
Supported
Mobile App
DMSS
Audio
Two-way communication
Storage
MicroSD card support
Alarm Input
Supported
Installation
Surface mount indoor installation
Door Station — DHI-VTO2311R-WP
Product Type
IP villa door station
Camera
2MP camera
Video Intercom
Supported
Audio
Two-way communication
Unlock Method
Remote unlock and IC card unlock
Network
IP network connection supported
PoE
Supported
Mobile App
DMSS supported through system configuration
Application
Homes, villas, offices, gates and small commercial entry points
Installation Notes
Plan Network and Power First
Decide whether the system will use PoE, local power or a network switch before installation. Correct network design is important for app access.
Door Lock Hardware Sold Separately
Electric strikes, magnetic locks, exit buttons and reed switches are selected separately based on the door type and access control requirement.
App Setup Requires Internet
DMSS mobile app access requires proper network configuration and internet access.
Professional Installation Recommended
Use a qualified intercom or security installer, especially where door release hardware or gate integration is required.
Downloads & Resources
Download the Dahua resources or contact CCTV Guru for help selecting compatible locks, exit buttons, power supplies and installation accessories.
Dahua Product Page
DHI-KTW02 Intercom Datasheet
Shop Electric Strikes
Access Control Accessories
Frequently Asked Questions
Is the Dahua DHI-KTW02 a video doorbell?
It is better described as a professional Wi-Fi IP video intercom kit. It includes an indoor monitor, outdoor station, app control and door release support.
Does it work with the DMSS app?
Yes. The Dahua DMSS app can be used for mobile visitor calls and remote operation when the system is configured correctly.
Can I unlock the door remotely?
Yes. Remote unlock is supported when connected to compatible electric strike, magnetic lock or suitable door release hardware.
Does it include a door lock?
No. Door locks, exit buttons, door contacts and power supplies are selected separately based on the door and installation design.
Does the kit support Wi-Fi?
Yes. The KTW02 kit includes Wi-Fi-capable intercom components for flexible installation.
Does it support PoE?
Yes. PoE is supported, making installation cleaner when used with a suitable PoE switch or injector.
Can users unlock with IC cards?
Yes. The outdoor station supports IC card unlock, making it useful for family members, staff or regular users.
Is this suitable for apartments?
It can suit selected apartment, townhouse and unit applications, but larger multi-tenant buildings may require a different Dahua apartment intercom design.
Can I add more Dahua intercom products later?
Yes. Dahua IP intercom systems can be expanded depending on the final system design, compatibility and installation requirements.
Do you ship Australia-wide?
Yes. CCTV Guru ships genuine Dahua intercom kits Australia-wide with local support.
Order the Dahua DHI-KTW02 from CCTV Guru
Order the Dahua DHI-KTW02 Wi-Fi IP Video Intercom Kit from CCTV Guru for fast Australia-wide shipping, genuine Dahua hardware and local advice on compatible door locks, exit buttons, power supplies, PoE switches and installation accessories.
Hikvision 6MP · Dual-Illumination · Strobe + Audio Deterrence · Motorised
Hikvision DS-2CD3H66G2H-LIZSUY/SL — 6MP Dual-Illumination Motorised Turret with Strobe & Audio Deterrence (2.7-13.5 mm, IP67/IK10)
The Hikvision DS-2CD3H66G2H-LIZSUY/SL is a 6 MP (3200 × 1800) dual-illumination turret camera on a 1/1.8" Progressive Scan CMOS, combining 24/7 full-colour imaging, active deterrence and a motorised 2.7-13.5 mm varifocal lens. Dual-illumination (IR + white light) reaches up to ~40 m for clear low-light footage, while the /SL active-deterrence package adds a white-light strobe and built-in audio alarm triggered on AI events. On-camera deep learning provides human and vehicle classification, face capture and perimeter protection, with 130 dB WDR, colour down to 0.001 lux, and an IP67 + IK10 metal housing. Powered by PoE 802.3at or 12 VDC. Australian stock, 3-year Australian warranty.
Resolution
6 MP · 3200 × 1800
Lens
Motorised 2.7-13.5 mm
Dual-Illumination
IR + White · up to 40 m
Deterrence
Strobe + Audio Alarm
AI Engine
Human + Vehicle · Face Capture
Protection
IP67 · IK10 · 130 dB WDR
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why Choose the DS-2CD3H66G2H-LIZSUY/SL
Active Deterrence
On a verified AI event the camera flashes a white-light strobe and plays an audible warning — turning a passive recorder into an active deterrent that stops intruders before they reach the door.
Dual-Illumination Night Vision
IR + white-light supplement up to ~40 m gives you covert IR, 24/7 full-colour, or a smart blend that switches to colour when the AI detects a threat.
Motorised Varifocal Lens
The 2.7-13.5 mm motorised lens lets you set the exact field of view remotely — wide for overview or zoomed in for identification.
AcuSense AI — Fewer False Alarms
Human and vehicle classification plus face capture and perimeter protection mean you're alerted only on real threats, not on rain, possums or moving foliage.
Technical Specifications
DS-2CD3H66G2H-LIZSUY/SL · Full Specifications
SKU
DS-2CD3H66G2H-LIZSUY/SL
Camera Type
Hikvision 6 MP Dual-Illumination Motorised Varifocal Turret with Active Deterrence
Image Sensor
1/1.8" Progressive Scan CMOS
Max Resolution
3200 × 1800 (6 MP)
Lens
Motorised varifocal 2.7-13.5 mm · H 112.3°-41.2°
Min. Illumination
Colour 0.001 lux · 0 lux with light
Supplement Light
Dual-Illumination (IR + White) up to ~40 m
Active Deterrence
White-light strobe + built-in audio alarm
Wide Dynamic Range
130 dB
Smart Analytics
Human + vehicle classification · face capture · perimeter protection
Video Compression
H.265+ · H.265 · H.264+ · H.264
Power Supply
12 VDC ± 25% or PoE (IEEE 802.3at)
Network & Protocols
RJ-45 · ONVIF · ISAPI · Hik-Connect
Protection Rating
IP67 · IK10 (metal housing)
Operating Temperature
−30 °C to +60 °C
Warranty
3-Year Australian Warranty
Frequently Asked Questions
What does the /SL suffix do?/SL is Hikvision's active-deterrence package — when the camera's AI detects a person or vehicle in your defined zone, it flashes a white-light strobe and plays an audible warning to deter the intruder.
How far does the night illumination reach?Both the IR and white-light illuminators reach up to ~40 m, with selectable IR, white-light or smart-blend modes for 24/7 colour or covert night vision.
How is it powered?The camera runs on standard PoE (IEEE 802.3at) from any Hikvision PoE NVR port, or on a 12 VDC supply.
Downloads & Resources
Hikvision Network Camera Quick Start Guide
Hikvision Network Camera User Manual
Order the Hikvision DS-2CD3H66G2H-LIZSUY/SL from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision IP cameras. The DS-2CD3H66G2H-LIZSUY/SL combines 6 MP imaging, dual-illumination night vision, AcuSense AI and active strobe + audio deterrence in a tough IP67/IK10 motorised turret — ideal for front doors, driveways and shop entries that need to stop intruders, not just record them. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch. Request a free quote or contact our Australian team.
Hikvision Pro Series · 6MP DarkFighter · AcuSense · F1.0 · Built-in Mic · IP67
Hikvision 6MP DarkFighter Turret
Hikvision DS-2CD2366G2H-IU — 6MP DarkFighter AcuSense Turret with F1.0 Lens, Built-in Mic & 120dB WDR
The Hikvision DS-2CD2366G2H-IU is a 6 MP DarkFighter turret camera from Hikvision's Pro Series — the workhorse choice for Australian residential entries, small commercial premises and body-corporate common areas. A 1/1.8" progressive CMOS paired with an ultra-fast F1.0 aperture lens delivers 0.0005 lux colour sensitivity — bright, low-noise colour imaging in near-total darkness before the IR even switches in. AcuSense H/V classification filters false alarms on animals, foliage and precipitation so your NVR only pushes notifications on actual humans and vehicles, and a built-in microphone records synchronised audio for a full evidentiary picture on every recording. Available in 2.8 mm wide-angle or 4 mm narrower-view lens, in White or Black finish. Backed by 3-year Australian warranty from CCTV Guru.
Resolution
6 MP · 3200 × 1800
Lens Options
2.8 mm (114.8°) or 4 mm (94°) · F1.0
Low-Light
DarkFighter · 0.0005 lux · 30 m IR
Audio
Built-in Mic · Sync Audio Recording
AcuSense AI
Human + Vehicle Classification
Protection
IP67 · 120 dB WDR · White or Black
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
Choose Your Lens — 2.8 mm Wide Angle or 4 mm Narrower View
Same camera body, same 6 MP DarkFighter sensor, same built-in mic — pick the lens focal length that suits your scene. The 2.8 mm wide-angle covers a broader area with a shorter effective distance; the 4 mm narrower-view gives you more detail at longer range with a tighter frame. Both are F1.0 fixed-focus with a 30 m Smart IR illuminator built in.
Lens Comparison — 2.8 mm vs 4 mm
2.8 mm Wide Angle (White SKU: DS-2CD2366G2H-IU · Black SKU: DS-2CD2366G2H-IU-BLK)
Horizontal FOV 114.8° · Vertical 58° · Diagonal 137°. Best for front doors, small yards, garage bays, side paths, shopfront awnings, apartment entry vestibules — anywhere you need a broad scene in a single frame from a close mounting position.
4 mm Narrower View (White SKU: DS-2CD2366G2H-IU-4MM)
Horizontal FOV 94° · Vertical 51° · Diagonal 114°. Best for medium-length driveways, side fences, loading dock views, alleyways — the extra reach gives you identification-level detail at 10-15 m where the 2.8 mm would only give a body-in-frame.
Rule of thumb: for indoor rooms, front-door porches, garages and shopfronts, go 2.8 mm. For a residential driveway from 5-15 m away, go 4 mm. Not sure? The 2.8 mm covers more scene and you can always digitally crop in on 6 MP footage.
What Makes This Camera Worth Choosing
F1.0 Aperture — Almost 3× the Light of an F1.6 Lens
The DarkFighter H-suffix models get a genuine F1.0 aperture — that's 2.5× more light gathered per frame than a typical F1.6 camera. Result: 0.0005 lux colour sensitivity — you keep bright, natural colour in scenes where a standard camera has already switched to monochrome IR.
AcuSense — Human / Vehicle Classification
Onboard deep-learning classifier ignores animals, wind-blown foliage, rain and headlight flare. Your NVR only pushes notifications when the camera actually detects a person or vehicle — typical false-alarm reduction is 80-90% vs a plain motion camera.
120 dB True WDR
Real hardware Wide Dynamic Range — handles the classic Australian problem scenes: sunlit garage door with dark interior behind, driveway staring into afternoon sun, front verandah in harsh backlight. Both bright and dark regions of the frame stay legible.
Built-in Microphone
Records synchronised audio with the video — useful for capturing spoken threats, arguments at the front door, delivery confirmations, and general context on incidents. No separate mic cable to run — it's inside the camera.
30 m Smart IR
Built-in Smart IR illuminator adjusts intensity + angle automatically to avoid IR washout on close targets (no white blob when someone stands 2 m from the camera) while still lighting the far end of a driveway.
H.265+ Smart Compression
Reduces bandwidth and storage by ~50 % vs H.265 alone. A single 6 MP stream at 25 fps uses ~4-6 Mbps with H.265+ — a 4 TB HDD comfortably holds ~30-45 days of recording across 4 cameras.
Where This Camera Belongs — Real Australian Use Cases
Front Doors & Porches
2.8 mm wide-angle covers the doorway, porch and approach path in a single frame from a close under-eave mount. Built-in mic captures conversation with visitors — pair with the recording NVR and you have full evidentiary audio + video.
Residential Driveways & Front Yards
4 mm variant covers a typical AU suburban driveway from house corner to street. Reads number plates at 10-15 m under IR. AcuSense filters out cars driving down the street so you only get notifications when someone actually enters the driveway.
Garages & Side Paths
2.8 mm indoors — one camera covers the whole garage from a corner-of-ceiling mount. Also excellent for narrow side paths where a wider FOV catches the full corridor and both walls.
Shopfronts & Small Commercial
2.8 mm wide-angle covers the counter, aisle and entry in one frame. Built-in mic captures customer interactions for training and dispute resolution (subject to signage and privacy law compliance).
Body Corp Common Areas
Lobbies, letterbox banks, bin rooms, gym entries — 2.8 mm covers the full space. Black finish blends into modern architectural facades; white for older render and weatherboard buildings. IP67 rated for accessible ground-floor and outdoor common area installs.
Backyards & Rear Access
4 mm for longer rear yards where you want to catch someone hopping the back fence at 10-15 m. AcuSense stops the camera from waking up every time a possum or cat walks through the frame.
Detection Range (DORI) Guide
DORI Distances — 2.8 mm vs 4 mm Lens
DORI Level
2.8 mm | 4 mm — What it means
Detect
64 m · 77 m — enough pixels to see a person exists in the frame
Observe
25 m · 30 m — enough to describe clothing, general behaviour
Recognise
12 m · 15 m — enough to recognise a known individual
Identify
6 m · 7 m — enough to identify a stranger from footage
Practical takeaway: if you want footage that police can use to identify an unknown intruder, you need them within ~6-7 m of the camera. Beyond that, footage is useful for recognising known faces but not for identifying strangers.
Technical Specifications
DS-2CD2366G2H-IU · Full Specifications
SKU — White · 2.8 mm
DS-2CD2366G2H-IU
SKU — White · 4 mm
DS-2CD2366G2H-IU-4MM
SKU — Black · 2.8 mm
DS-2CD2366G2H-IU-BLK
Camera Type
Hikvision Pro Series · 6MP AcuSense Fixed Turret · DarkFighter · Built-in Mic
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
3200 × 1800 (6 MP)
Main Stream
25/30 fps @ 3200 × 1800 · 2560 × 1440 · 1920 × 1080
Lens Options
2.8 mm F1.0 (H 114.8°) or 4 mm F1.0 (H 94°) — fixed focal length
Field of View (2.8 mm)
Horizontal 114.8° · Vertical 58° · Diagonal 137°
Field of View (4 mm)
Horizontal 94° · Vertical 51° · Diagonal 114°
Min. Illumination
Colour: 0.0005 lux @ F1.0 (AGC ON) · 0 lux with IR
Wide Dynamic Range
120 dB True WDR
Shutter Speed
1 s to 1/100,000 s
IR Distance
Up to 30 m · Smart IR intensity + angle auto-adjust
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG
Smart Functions
AcuSense: Human + Vehicle classification · Line crossing · Intrusion · Region entrance · Region exiting
Additional Analytics
Motion detection · Video tampering · Face detection · Scene change · Audio exception
Audio
Built-in microphone · Audio compression: G.711 / G.722.1 / G.726 / MP2L2
Alarm I/O
None on this variant (see -SU/SL siblings for alarm I/O)
Ethernet
1× RJ-45 10/100 Mbps
Protocols
IPv4/IPv6 · HTTPS · 802.1X · QoS · FTP · SMTP · UPnP · SNMP · DNS · DDNS · NTP · RTSP · TCP · UDP · IGMP · DHCP · Bonjour · SRTP · TLS
Storage
microSD / SDHC / SDXC up to 512 GB · NAS · ANR (Auto Network Replenishment)
API
ISAPI · Hikvision SDK · ONVIF (Profile S / G / T)
Client Software
iVMS-4200 · Hik-Central Professional · Hik-Connect
Power
12 VDC · PoE 802.3af Class 3 (max ≈ 6 W)
Weatherproof
IP67 (IEC 60529)
Operating Temperature
−30 °C to +60 °C · humidity ≤95 %
Dimensions / Weight
Ø 111 × 84.9 mm · ~500 g
Finish Options
White (2.8 mm + 4 mm) or Black (2.8 mm only)
Warranty
3-Year Australian Warranty (back-to-base)
Pair with a Hikvision M-Series or AcuSeek NVR
DS-7604NI-M1/4P — 4CH · 4 PoE
Four-channel M-Series NVR — ideal for a single-family home with 4 of these turrets around the perimeter. Handles the AcuSense metadata for smart notification filtering. View DS-7604NI-M1/4P →
DS-7608NI-M2/8P — 8CH · 8 PoE · 2 HDD
Eight channels with 2 HDD bays — commercial small-site and larger residential. Dual-drive redundancy protects critical footage. View DS-7608NI-M2/8P →
DS-7616NI-M2/16P — 16CH · 16 PoE · 2 HDD
Mid-tier commercial site with up to 16 of these turrets on the perimeter, entries and interiors. View DS-7616NI-M2/16P →
DS-7608NXI-I2/8P/VPro — AcuSeek AI NVR
For sites that want natural-language search across recordings — "show me all people at the front door between 6 pm and 10 pm." AcuSeek indexes the AcuSense metadata for post-incident search. View AcuSeek NVR →
Frequently Asked Questions
What does the "H" in G2H mean?The H suffix denotes Hikvision's DarkFighter-enhanced variant of the standard G2 model — larger 1/1.8" sensor, F1.0 aperture and improved image processor. It gets ~2.5× more light than a standard AcuSense camera at the same price tier. Worth the small premium for any night-time use case.
Why is Black only offered in 2.8 mm?Hikvision's supply of the black-finish version is limited to the 2.8 mm SKU (DS-2CD2366G2H-IU-BLK). If you need a 4 mm in black, contact us — we sometimes have alternative black-finish Hikvision turrets in the same 6 MP range that might suit.
Does it need a special PoE switch?No — PoE 802.3af Class 3 (max ~6 W). Runs on any standard Hikvision NVR PoE port or generic 802.3af PoE switch. Also accepts 12 VDC for legacy or off-grid installs.
Is the built-in microphone always recording?Yes, when audio recording is enabled on the NVR. You can also configure the microphone to trigger an alarm on audio exception (sudden loud noise, breaking glass) even when video motion doesn't fire. Note: recording audio at some AU workplaces requires signage and staff notification — check your obligations.
Does AcuSense really cut false alarms?Yes — typical reduction is 80-90% vs a motion-only camera. The camera classifies the target as human, vehicle or "other" before firing an alarm. Rain, foliage, insects, animals and passing headlights get filtered out.
Can I integrate with a non-Hikvision VMS?Yes — the camera speaks ONVIF Profile S, G and T and RTSP. Compatible with Milestone XProtect, Genetec, Exacq, Immix and most other AU VMS platforms. AcuSense metadata is only fully indexed on Hikvision NVRs.
What's the difference between this and the DS-2CD2367G3-LIS2UY/SL?The G3 sibling is Gen 3 — adds Smart Hybrid Light (integrated white LED + strobe), Live-Guard active deterrent and NEMA 4X anti-corrosion housing. The G2H turret you're looking at is the cost-effective workhorse — same AcuSense AI, same 6 MP resolution, no active deterrent. If you want proactive strobe + audio warnings, look at the G3. If you want reliable evidence recording at a lower price, the G2H is the right choice.
What warranty applies?3-Year Australian warranty, serviced back-to-base through Hikvision Australia by CCTV Guru. Cameras registered on Hik-Connect within 30 days of purchase are automatically tracked.
Downloads & Resources
DS-2CD2366G2H-IU Datasheet
Quick Start Guide
Network Camera User Manual
Order the Hikvision DS-2CD2366G2H-IU from CCTV Guru
Select your lens (2.8 mm wide-angle or 4 mm narrower-view) and finish (White or Black — Black is 2.8 mm only) from the dropdowns above. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch, project pricing for multi-camera installs and specialist pre-sales advice from our Sydney team. Request a free quote or contact our Australian team.
Hikvision Smart Managed Switch · 16 Gigabit PoE · 230W
DS-3E1518P-EI — Hikvision 16-Port Gigabit Smart Managed PoE Switch (230W)
The Hikvision DS-3E1518P-EI is a high-performance, all-Gigabit smart managed PoE switch for commercial and industrial CCTV networks. It provides 16 × 10/100/1000 Mbps PoE ports and 2 × Gigabit combo uplink ports, with a 230W total PoE budget and up to 30W per port to power demanding IP cameras.
A 36 Gbps switching capacity, fanless rack-mount design and 6 kV surge protection on all ports make it well suited to powering full camera banks over long, stable Gigabit connections.
All-Gigabit Ports16 × 10/100/1000 Mbps PoE + 2 × Gigabit combo uplinks.
230W PoE BudgetUp to 30W per port — power for a full bank of IP cameras.
36 Gbps SwitchingHigh-capacity store-and-forward for full-speed surveillance traffic.
Fanless Rack-MountSilent 19-inch rack design with 6 kV surge protection on all ports.
Technical Specifications
Model
DS-3E1518P-EI
Ethernet Ports
16 × 10/100/1000 Mbps PoE, 2 × Gigabit combo uplink
PoE Standard
IEEE 802.3af / IEEE 802.3at
PoE Budget
230W total, 30W max per port
Switching Capacity
36 Gbps
MAC Address Table
8K
Surge Protection
6 kV on all ports
Mounting
Rack mountable (19 inch), fanless
Power Supply
100–240 VAC, 50/60 Hz
Dimensions
440 × 221 × 44 mm
Weight
Approx. 2.5 kg
How many cameras can it power?With a 230W budget and up to 30W per port, it comfortably powers 16 standard IP cameras, depending on each camera's draw.
Is it rack-mountable?Yes. It ships in a fanless 19-inch rack-mount chassis for silent operation in comms cabinets.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
A powerful all-Gigabit Hikvision PoE switch with 230W of power and a fanless rack design — built for commercial and industrial surveillance networks.
