Hikvision DeepinMind Pro · AcuSeek AI · 32 CH · 16 PoE · 8K
The Hikvision iDS-9632NXI-P16 is Hikvision's flagship DeepinMind Pro AI NVR — the most powerful single-chassis recorder Hikvision builds for 32-camera deployments. It combines AcuSeek natural-language video search, AcuSearch image-based search, 16-channel live facial recognition, 32-channel face picture comparison, perimeter protection, video structuralisation and ANPR — all running on GPU-accelerated AI engines that can model up to 600,000 targets per day.
Designed for serious Australian sites — large hotels, hospitals, casinos, schools, gated estates, retail flagship stores, car dealerships and government facilities — this enterprise NVR connects up to 32 IP cameras (16 via built-in PoE) and outputs true 8K via HDMI. Eight SATA bays accept up to 16 TB drives each (128 TB total), with full RAID 0/1/5/6/10 redundancy for footage protection. Ships as a chassis only — choose your HDD configuration at checkout.
AcuSeek
Search by Text
Face Recognition
16 Live · 32 Compare
PoE Ports
16 × PoE (af/at)
Storage
8 × SATA · Up to 128 TB
The most intelligent NVR Hikvision makes
This isn't a standard NVR with AI bolted on. The DeepinMind Pro tier is Hikvision's top-of-range AI recorder, with GPU-accelerated processing that's an order of magnitude more powerful than the M Series DeepinMind chassis. It runs AcuSeek natural-language search (a feature usually exclusive to the VPro line), Hikvision's full DeepinMind facial recognition stack, and can model 600,000 detected targets every day — meaning every person, vehicle and licence plate that crosses your site is automatically indexed and searchable.
AcuSeek Natural-Language Search
Type *"a person in a red jacket at the loading dock yesterday"* and the NVR finds matching clips across all 32 channels in seconds — no manual scrubbing, no event tagging in advance.
16-Ch Live Face Recognition
Real-time facial recognition runs on 16 live camera streams. Add another 16 channels of face-picture comparison from recorded footage for forensic review.
100,000 Face Library
32 organised face libraries holding up to 100,000 enrolled faces between them — enough for staff, VIPs, watch-lists, contractors and visitor history at any commercial site.
600,000 Targets/Day Modelling
GPU-accelerated AI engine indexes up to 600,000 detected people, vehicles and licence plates every 24 hours — building a structured, searchable database of everything that happens on site.
AcuSearch by Image
Upload a reference photo of a person or vehicle and AcuSearch finds every other appearance in your footage across all 32 channels. Hours of investigation collapsed into seconds.
Perimeter, ANPR & Structuralisation
Built-in deep-learning perimeter protection, automatic number-plate recognition and video structuralisation — all running on-device, no separate analytics server required.
Face recognition that works like your phone — but for your CCTV
You know how your iPhone Photos app automatically groups pictures of "Mum," "James," or "the kids"? The iDS-9632NXI-P16 does exactly the same thing — but for your live security cameras. Enrol photos of staff, family, regulars, couriers or contractors and add their names. From then on, when the NVR sees them on any of your 32 cameras, you get a push notification on your phone that says "James arrived at the front door" instead of just *"motion detected."*
It also works the other way around. Add a banned customer, a former employee or anyone you don't want on the premises to a watchlist — and the NVR alerts you the instant they appear on any camera. Up to 100,000 faces across 32 organised libraries are stored locally on the recorder itself — no cloud subscription, no facial data leaving your premises, no monthly fees, ever.
Unlike battery-powered "smart" doorbells that only recognise faces at one entrance (and lose accuracy over time), the DeepinMind Pro NVR runs Hikvision's enterprise-grade AI engine across every camera, every angle, around the clock.
Recommended AcuSeek-compatible cameras
To unlock the full AcuSeek, AcuSearch and face-recognition stack, pair this NVR with cameras from our verified Hikvision AcuSeek Cameras collection. Every model is independently confirmed on Hikvision's official compatibility checklist (April 2026), ships from our Australian warehouse, and runs the firmware AcuSeek needs out of the box. Four of the most popular picks:
ColorVu 3.0 Turret — DS-2CD2387G3-LIS2UY/SL
The current-gen flagship: 8MP, true 24/7 full-colour night vision, Smart Hybrid Light, built-in mic, speaker and strobe. The ideal partner for AcuSeek face capture in any light. View this camera →
ColorVu 3.0 Bullet — DS-2CD2T87G3-LIS2UY/SL
Long-range 8MP bullet with active strobe and audio deterrence — perfect for driveways, side gates and perimeters where AcuSeek vehicle and person classification matters most. View this camera →
AcuSense G2H Turret — DS-2CD2366G2H-IU
6MP AcuSense Gen 2H with DarkFighter low-light sensor and built-in mic — the smart value choice for front doors, entries and counters where face capture has to stay sharp in dim light. View this camera →
Smart Hybrid Light Bullet — DS-2CD2087G3-LI2UY/SL
8MP ColorVu 3.0 with Smart Hybrid Light — switches automatically between IR (stealth) and white-light (deterrent) based on what it sees. The smartest choice for driveways and front gates. View this camera →
Browse the full Hikvision AcuSeek Cameras collection for every verified-compatible turret, bullet and dome — all in Australian stock with 3-year warranty.
Enterprise hardware backing the AI brain
The DeepinMind Pro isn't just smart — it's seriously built. Sixteen onboard PoE ports (IEEE 802.3 af/at) power your critical perimeter and entrance cameras directly; the other 16 channels accept IP cameras from anywhere on your network. Eight hot-swappable SATA bays with full RAID 0/1/5/6/10 protect footage from drive failure. True 8K HDMI output drives a flagship control-room monitor, with a second 4K HDMI for spot monitors and dual VGA for additional workstation displays.
8K + 4K Dual HDMI
HDMI 1 drives a true 8K monitor; HDMI 2 a 4K display — perfect for control rooms running a wall-mounted overview plus a workstation.
RAID 0/1/5/6/10
Octa-SATA design with full RAID support for redundancy and performance — critical for enterprise sites where footage loss isn't acceptable.
Hik-Connect & Hik-Central
Remote live view and playback via Hik-Connect, or integrate into Hik-Central Pro VMS for centralised management across multiple sites.
ONVIF Compatible
Works with the full Hikvision IP range and most third-party ONVIF cameras — flexibility for hybrid, multi-vendor enterprise sites.
Full technical specifications
Hikvision DeepinMind Pro NVR — iDS-9632NXI-P16
Model
iDS-9632NXI-P16
Series
Hikvision DeepinMind Pro AI NVR
Form Factor
2U Rack-Mount (19" rack-mount ears included)
AI Engine
GPU-accelerated DeepinMind Pro · Guanlan Large-Scale AI Model
Target Modelling
Up to 600,000 targets per day
Video Inputs
32-channel IP, up to 32 MP per channel
Video Compression
H.265+ / H.265 / H.264+ / H.264
Recording Resolution
32 MP / 24 MP / 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA
AcuSeek
Natural-language video search across all 32 channels
AcuSearch
Target-image search across all 32 channels
Facial Recognition (Live)
Up to 16 channels — real-time live stream
Face Picture Comparison
Up to 32 channels — recorded footage
Face Library
32 libraries · up to 100,000 face pictures total
Perimeter Protection
Line-crossing, intrusion, region entry/exit (multi-channel)
Video Structuralisation
Multi-channel deep-learning metadata extraction
Other AI Features
ANPR · People Counting · Heat Map · Motion Detection 2.0 · VCA
HDMI 1 Output
8K (7680 × 4320) @ 30 Hz · 4K @ 60 Hz · 2K · 1920 × 1080 @ 60 Hz
HDMI 2 Output
4K (3840 × 2160) @ 60 Hz · 2K · 1920 × 1080 @ 60 Hz · independent source
VGA Outputs
2 × 1920 × 1080 @ 60 Hz (independent sources)
Audio In / Out
1-ch RCA in · 2-ch RCA out · Two-way audio
IP Speaker Support
Connectable IP speakers for audio warnings & talk-down
Network Interface
2 × RJ45 10/100/1000 Mbps Self-Adaptive Ethernet
PoE Interfaces
16 × Independent 10/100 Mbps PoE (IEEE 802.3 af/at)
Network Protocols
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS, ONVIF, OTAP
HDD Bays
8 × SATA, up to 16 TB per drive (128 TB total capacity)
eSATA
1 × eSATA for additional storage expansion
RAID
RAID 0, 1, 5, 6, 10 supported
USB Interfaces
2 × USB 3.0 (front and rear)
Alarm In / Out
16 in / 8 out
Power Supply
100–240 V AC, 50/60 Hz
Working Temperature
−10 °C to 55 °C
Working Humidity
10% – 90%
Mobile Apps
Hik-Connect, Hik-Central, iVMS-4200
Australian Warranty
5 Years — CCTV Guru / Hikvision Australia
iDS-9632NXI-P16 vs iDS-9632NXI-P8 — which should you choose?
The P16 and P8 share exactly the same DeepinMind Pro AI engine, channel count, storage capacity and warranty. The only meaningful difference is built-in PoE port count.
DeepinMind Pro — P16 vs P8
Specification
iDS-9632NXI-P16 (this product)
iDS-9632NXI-P8
Camera Channels
32
32
Built-in PoE Ports
16 × PoE (af/at)
8 × PoE (af/at)
AI Tier
DeepinMind Pro
DeepinMind Pro
Target Modelling
600,000/day
600,000/day
Live Facial Recognition
16 channels
16 channels
Face Picture Comparison
32 channels
32 channels
AcuSeek / AcuSearch
✔ All 32 channels
✔ All 32 channels
Storage
8 × SATA · Up to 128 TB
8 × SATA · Up to 128 TB
RAID Support
RAID 0/1/5/6/10
RAID 0/1/5/6/10
Display Outputs
Dual HDMI (8K + 4K) · Dual VGA
Dual HDMI (8K + 4K) · Dual VGA
Form Factor
2U Rack-Mount
2U Rack-Mount
Australian Warranty
5 Years
5 Years
Choose the P16 if you'd rather plug 16 cameras straight into the NVR and skip a separate PoE switch entirely. Choose the P8 if your site already runs a managed PoE switch backbone and you only need a handful of cameras powered directly from the recorder.
View the iDS-9632NXI-P8 (8-PoE Version)
Browse AcuSeek-Compatible Cameras
Downloads & resources
Download official Hikvision documents for setup, specifications, and recorder details.
iDS-9632NXI-P16 Datasheet
Quick Start Guide PDF
User Manual PDF
LiveGuard Setup (Web GUI)
LiveGuard Setup (NVR GUI)
Frequently asked questions
What's the difference between DeepinMind Pro and the regular DeepinMind M Series?
The Pro tier uses a GPU-accelerated AI engine that's an order of magnitude more powerful — modelling 600,000 targets per day vs the M Series' typical 100,000–200,000. It also adds AcuSeek (text-based search), which is normally exclusive to the VPro line. The Pro is the flagship for sites that take AI seriously.
Do I need special cameras to use AcuSeek and face recognition?
No. The NVR processes video from any compatible Hikvision or ONVIF IP camera. Pair with cameras from our Hikvision AcuSeek Cameras collection for the sharpest face crops and best recognition accuracy.
Are there subscription fees?
No. All AI processing — AcuSeek, AcuSearch, facial recognition, ANPR, perimeter — runs on-board the NVR. No recurring cloud fees, no per-user licensing, ever.
Does it come with hard drives?
The recorder ships as a chassis only. CCTV Guru offers pre-fitted Seagate SkyHawk, WD Purple or enterprise Exos drives from 8 TB up to 16 TB per bay — choose your RAID configuration at checkout.
How does facial recognition handle 32 cameras?
16 channels run live real-time facial recognition (the heaviest workload). The remaining 16 channels run face picture comparison against recorded footage — slightly slower but covers forensic review across every camera.
Do you ship to my city?
We ship Australia-wide from our local warehouse — Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra and Darwin — with most metro orders arriving in 1–3 business days. Enterprise orders shipped by carrier with tracking and signature.
5-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Genuine Hikvision · Wall Mount · For PTZHikvision DS-1294ZJ-PTRock-Solid Wall Mounting for Full-Size PTZ Speed Domes
The Hikvision DS-1294ZJ-PT is a heavy-duty wall mount bracket engineered to carry the larger Hikvision PTZ speed dome range. Built for car parks, warehouses and building perimeters, it keeps your camera precisely positioned day in, day out with the structural integrity a full-size PTZ demands.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why You'll Love It
Built for full-size PTZ — engineered to support Hikvision's larger PTZ speed dome cameras.
Heavy-duty construction — reliable long-term support that keeps your camera locked in position.
Hikvision White finish — clean, professional appearance that blends with the camera range.
Commercial & industrial ready — ideal for wall-mount installs across demanding environments.
Specifications
Model
DS-1294ZJ-PT
Category
Wall Mount
Material
Steel / Heavy-duty construction
Finish/Colour
Hikvision White
Application/Mounting
Wall mount for full-size PTZ speed domes
Warranty
3 Years (AU)
Frequently Asked Questions
Which cameras is this bracket for?Designed for Hikvision full-size PTZ speed dome cameras — please verify the bracket against your specific camera's mounting spec before purchase.
Can it be used outdoors?Yes — it suits wall-mount installations in commercial and industrial environments. For exposed sites, position to shield connections from direct weather.
Is this a genuine Hikvision part?Yes — this is a genuine Hikvision DS-1294ZJ-PT bracket supplied with a 3-year Australian warranty.
Is it easy to install?Yes — installation is straightforward using standard mounting hardware for a secure, rock-solid fit.
Hikvision Wi-Fi PTZ · 4MP 4× Zoom · AcuSense · 20 m IR
Hikvision DS-2DE2A404IWG1-E/W — 4MP 4× Zoom Wi-Fi AcuSense Mini PTZ (2.4 GHz, 2.8-12 mm, 20 m IR, IP66/IK10)
The Hikvision DS-2DE2A404IWG1-E/W is the Wi-Fi variant of Hikvision's most affordable PTZ — same compact 2-inch Value Series chassis, same motorised 2.8-12 mm F1.8 lens, same 4× optical zoom, same 4 MP imaging, same 20 m smart IR, same AcuSense human + vehicle filtering, same built-in mic + speaker — plus integrated 2.4 GHz Wi-Fi (IEEE 802.11b/g/n) with WPA / WPA2 / WPA-PSK / WPA2-PSK encryption. Designed for installs where running Cat 6 is impractical or unwanted — apartment balconies, heritage buildings, rental properties, fence-corner posts, garden sheds and undercover carports where you'd rather not pull data cable across the ceiling. PoE 802.3af and 12 VDC power are still supported as fall-backs. IP66 weather-rated, IK10 vandal-rated, ~560 g. Australian stock, 3-year Australian warranty.
Wireless
Wi-Fi 2.4 GHz · 802.11b/g/n
Optical Zoom
4× · 2.8-12 mm · F1.8
Resolution
4 MP · 2560 × 1440 · 25/30 fps
AI Engine
AcuSense · Human + Vehicle
Audio
Built-in Mic + Speaker · 2-Way
Power
PoE 802.3af · 12 VDC · 11.2 W
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
See Hikvision AcuSense in Action
AcuSense is the on-camera deep-learning engine that makes this PTZ useful instead of noisy — it classifies every motion event as human, vehicle, or "other" (foliage, possums, headlight glare) and filters out the false alarms. Hikvision's official AcuSense demo shows how it works on the same AI engine that powers this Wi-Fi Value Series PTZ.
Why Choose the Wi-Fi DS-2DE2A404IWG1-E/W
The "/W" suffix adds integrated 2.4 GHz Wi-Fi to Hikvision's most affordable PTZ. The use-case is install flexibility: residential sites where pulling Cat 6 across the ceiling isn't practical, rental properties where you can't run cable through walls, heritage buildings with restrictions, fence-corner posts and garden sheds where data cable would need a long underground trench. Wi-Fi gets the PTZ on-line without a network cable.
Integrated 2.4 GHz Wi-Fi
IEEE 802.11b/g/n, 20/40 MHz channel bandwidth, WPA / WPA2 / WPA-PSK / WPA2-PSK encryption. Pairs to your existing 2.4 GHz home or office Wi-Fi — no separate access point needed.
4× Optical Zoom · 2.8-12 mm F1.8
Motorised wide-to-tele: 99.4° wide (whole driveway / shopfront) to 32.8° tele (face at the gate). 16× digital on top. ~2 s zoom transit.
AcuSense — Real Notifications
On-camera deep learning filters every motion event as human, vehicle or other. Only human/vehicle classifications trigger alerts — ~90 % fewer false alarms vs motion-only cameras.
PoE 802.3af Fallback Still Supported
Wi-Fi is the install convenience — but the camera also supports PoE 802.3af and 12 VDC wired. If your network changes or Wi-Fi range becomes a problem, you can revert to wired without buying a new camera.
Honest Wi-Fi Positioning — Read This Before You Buy
Wi-Fi is genuinely useful — but it's not magic, and we'd rather set expectations correctly up front than have you surprised on install day. Three things to know:
You Still Need a Power Cable
Wi-Fi handles data only — it can't deliver power. The camera draws up to 11.2 W and needs a 12 VDC supply or a PoE injector at the install location. "Wi-Fi" doesn't mean wireless — it means no data cable. You'll still run a single power cable to the camera location, or place a power-over-Ethernet injector nearby. Plan for it.
2.4 GHz Only — Plan for Bandwidth
The camera supports 2.4 GHz Wi-Fi only (no 5 GHz). 2.4 GHz reaches further through walls but is more congested (microwaves, baby monitors, IoT devices all share the band) and has lower peak throughput than 5 GHz. A 4 MP @ 25 fps stream uses ~4-8 Mbps — typically fine on 802.11n 2.4 GHz, but place the camera within reasonable range of your router (under ~15 m through one wall).
Initial Pairing Needs Ethernet
Per the datasheet: "Wi-Fi connection with Hik-Connect directly is not possible." Translation: you can't pair the camera to Wi-Fi using only the Hik-Connect mobile app. Initial setup requires a one-time Ethernet connection (or Hikvision's SADP / iVMS-4200 desktop tools) to enter the Wi-Fi credentials. After that, you can disconnect the Ethernet cable and the camera operates over Wi-Fi normally.
Wired Is Still Better If You Can Run Cable
If running a Cat 6 cable to the install point is practical, choose the wired-only DS-2DE2A404IWG1-E variant instead — slightly cheaper, no Wi-Fi setup, single PoE cable handles both power and data, no Wi-Fi range or congestion concerns. The Wi-Fi /W variant exists for installs where cable just isn't feasible.
For sites with longer night-time scenes, step up to the 3-inch sibling with 50 m IR: DS-2DE3A404IWG-E/W (3-inch · Wi-Fi · 50 m IR) →
Pan / Tilt / Zoom — Operator Control
355° Pan · 0°-90° Tilt
Pan 0° to 355° (5° slip-ring dead-zone — irrelevant on most ceiling / eave / wall mounts). Tilt 0° to 90° straight down for ground-level coverage from a mounted vantage.
300 Presets · Patrol Scan
300 presets + patrol scan automation. Set angles for driveway, gate, shopfront, carpark; recall with one tap. Schedule automated overnight patrol routes.
3D Positioning — Click to Zoom
Click any point on the live view to centre-frame and zoom in one motion — fastest operator workflow for investigating wide-scene events in Hik-Connect, iVMS-4200 or HikCentral Pro.
Proportional Pan + Power-Off Memory
Pan speed auto-scales with zoom (fine control at tele, fast at wide). Returns to last orientation after brown-out, power cycle or NVR restart.
Technical Specifications
DS-2DE2A404IWG1-E/W · Full Specifications
SKU
DS-2DE2A404IWG1-E/W (PoE / 12 VDC + integrated 2.4 GHz Wi-Fi)
Camera Type
Hikvision Value Series · 4 MP 4× IR AcuSense Mini PTZ Network Speed Dome (Wi-Fi)
Image Sensor
1/2.8" Progressive Scan CMOS · Powered-by-DarkFighter
Max Resolution
2560 × 1440 (4 MP 16:9)
Min. Illumination
Colour 0.005 lux @ F1.8 · B/W 0.001 lux @ F1.8 · 0 lux with IR
Shutter Speed
1/1 s to 1/30,000 s · Slow Shutter
Lens
Motorised · 2.8-12 mm · 4× optical zoom · 16× digital · max F1.8 aperture · auto / semi-auto / manual focus
Field of View
Horizontal 99.4° → 32.8° · Vertical 51.7° → 18.4° · Diagonal 119.9° → 37.5°
Zoom Speed
Approximately 2 s (wide ↔ tele)
Regional Focus / Exposure
Yes / Yes
IR Illumination
Smart IR up to 20 m · 850 nm wavelength
Day & Night
ICR (IR cut filter, mechanical)
Wide Dynamic Range
120 dB · BLC · HLC · 3D DNR · digital defog
SNR
> 52 dB
Pan Range / Speed
0° to 355° · 0.1°-50°/s configurable · preset 50°/s · proportional pan
Tilt Range / Speed
0° to 90° · 0.1°-50°/s · preset 50°/s
Presets / Patrols
300 presets · patrol scan
Park Action
Preset · patrol scan
3D Positioning
Yes — click-to-frame on live view
Power-Off Memory
Yes
Scheduled Task
Patrol scan · preset · dome reboot · dome adjust
Frame Rate (Main)
50 Hz: 25 fps @ 4 MP · 60 Hz: 30 fps @ 4 MP
Streams
3 simultaneous (main / sub / third)
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG (sub / third)
Video Bit Rate
32 Kbps – 16 Mbps · CBR / VBR · SVC (H.264 + H.265) · 1 ROI region
Deep-Learning AI
AcuSense — human + vehicle classification
Smart Events
Line crossing · intrusion · region entrance · region exiting
Basic Events
Motion · video tampering · network disconnect · IP conflict · illegal login · HDD full · HDD error
Linkage
FTP / NAS / microSD upload · centre notify · email · trigger recording · audible warning
Audio
Built-in microphone (5 m pickup) · built-in speaker (10 m effective) · 1 line-in (2–2.4 Vpp, 1 KΩ ±10%) · 1 line-out (600 Ω) · G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC
Ethernet
1 × RJ-45 10/100 Mbps self-adaptive
Wi-Fi Protocols
IEEE 802.11b · 802.11g · 802.11n
Wi-Fi Frequency
2.4 GHz – 2.4835 GHz (no 5 GHz support)
Wi-Fi Channel Bandwidth
20 / 40 MHz
Wi-Fi Encryption
64 / 128-bit WEP · WPA / WPA2 · WPA-PSK / WPA2-PSK
Wi-Fi Transfer Rate
802.11b: up to 11 Mbps · 802.11g: up to 54 Mbps · 802.11n: MCS 0-7
Wi-Fi Pairing Note
Initial Wi-Fi configuration requires one-time Ethernet connection (SADP / iVMS-4200) — direct Hik-Connect Wi-Fi pairing not supported.
On-Board Storage
microSD / SDHC / SDXC up to 512 GB · NAS (NFS / SMB-CIFS) · ANR auto network replenishment
API & Protocols
ONVIF (Profile S / G / T) · ISAPI · SDK · ISUP · 6 concurrent live-view sessions · 32 users (3 levels)
Cyber Security
HTTPS · IP filter · watermark · TLS 1.2 · MAC host authentication · audit log · password protection
Client Software
iVMS-4200 · Hik-Connect · HikCentral Pro
Web Browser
Chrome 80+ · Firefox 80+ · Safari 13+ · Edge 89+
Power Source
12 VDC max 11.2 W OR PoE IEEE 802.3af — wired Ethernet still supported alongside Wi-Fi
Dimensions / Weight
Ø 130.7 mm × 103.6 mm · ≈ 560 g
Operating Condition
−20 °C to +60 °C · humidity ≤ 90 % non-condensing
Weatherproof Rating
IP66 (IEC 60529-2013)
Vandal Resistance
IK10
Lightning Protection
TVS 4,000 V · surge + voltage transient protection
Anti-Corrosion
Not rated — no -Y / NEMA 4X variant in this family. Avoid coastal sites within ~2 km of shoreline.
DORI (Tele · 12 mm)
Detect 180 m · Observe 71.4 m · Recognise 36 m · Identify 18 m
Approvals
RCM (Australia / NZ) · IP66 / IK10 protection
Warranty
3-Year Australian Warranty (back-to-base)
DS-2DE2A404IWG1-E/W (Wi-Fi) vs DS-2DE2A404IWG1-E (Wired) — Should You Pay for Wi-Fi?
Both variants are physically identical — same sensor, same lens, same chassis, same AcuSense AI, same audio, same IR. The only difference is the integrated 2.4 GHz Wi-Fi radio on the /W variant. Pick based on whether running a Cat 6 cable to the install point is practical: yes → save money with the wired-only version; no → pay for the Wi-Fi flexibility.
DS-2DE2A404IWG1-E/W (Wi-Fi · this) vs DS-2DE2A404IWG1-E (Wired only)
Feature
DS-2DE2A404IWG1-E/W (this — Wi-Fi)
DS-2DE2A404IWG1-E (wired-only sibling)
Integrated Wi-Fi
Yes — IEEE 802.11b/g/n · 2.4 GHz
No
Wi-Fi Encryption
WPA / WPA2 · WPA-PSK / WPA2-PSK · WEP 64/128-bit
—
Wired Ethernet
Yes — 10/100 Mbps (fallback / initial pairing)
Yes — 10/100 Mbps
Image Sensor
1/2.8" CMOS · Powered-by-DarkFighter
1/2.8" CMOS · Powered-by-DarkFighter
Resolution
4 MP · 2560 × 1440
4 MP · 2560 × 1440
Optical Zoom
4× · 2.8-12 mm · F1.8
4× · 2.8-12 mm · F1.8
IR Range
Up to 20 m
Up to 20 m
WDR
120 dB
120 dB
AI Engine
AcuSense · human + vehicle
AcuSense · human + vehicle
Built-in Audio
Mic (5 m) + Speaker (10 m) · 2-way
Mic (5 m) + Speaker (10 m) · 2-way
Pan / Tilt Speed
50°/s preset
50°/s preset
Power
PoE 802.3af · 12 VDC · 11.2 W
PoE 802.3af · 12 VDC · 11.2 W
Power Cable Required
Yes — Wi-Fi handles data only, not power
No (single PoE cable covers both)
Initial Setup
One-time Ethernet pairing via SADP / iVMS-4200
Plug into NVR PoE — done
Dimensions / Weight
Ø 130.7 × 103.6 mm · ~560 g
Ø 130.7 × 103.6 mm · ~560 g
Protection
IP66 · IK10
IP66 · IK10
Anti-Corrosion
Not rated
Not rated
Warranty
3-Year Australian Warranty
3-Year Australian Warranty
Best For
Apartments, rentals, heritage buildings, fence-corner posts, garden sheds, undercover carports — anywhere a long data cable run is impractical. Single power cable + Wi-Fi for data.
Standard installs where Cat 6 to the NVR is straightforward — main residence, retail shopfront, small office, hospitality venue. Cheaper, simpler, no Wi-Fi setup.
If your site has reasonable IR night-time coverage requirements and you want Wi-Fi plus longer IR reach, the 3-inch sibling offers both: DS-2DE3A404IWG-E/W (3-inch · Wi-Fi · 50 m IR) →
Recording NVRs — Wi-Fi Camera Pairs with Any Hikvision NVR
The DS-2DE2A404IWG1-E/W appears on your Hikvision NVR as a standard IP camera over the network, regardless of whether it's connected by Wi-Fi or Ethernet. The NVR doesn't need to know it's a Wi-Fi camera — it just sees an ONVIF Profile S / G / T device on the LAN. The Hikvision M-Series NVRs are the right partner for most installs: 4K HDMI output, H.265+ compression, plug-and-play, and pricing that keeps a complete system within reach. Step up to AcuSeek / DeepinMind only when you need natural-language AI search.
DS-7604NI-M1/4P — 4CH · 4 PoE · Budget Pick
Four-channel M-Series NVR with 4 built-in PoE ports, 4K HDMI output, single HDD bay (up to 10 TB). The Wi-Fi camera joins via your home / office network rather than the NVR's PoE port — leaves all 4 PoE ports free for additional wired fixed cameras. View DS-7604NI-M1/4P →
DS-7608NI-M2/8P — 8CH · 8 PoE · 2 HDD Bay
Eight-channel M-Series NVR with 8 built-in PoE ports, 4K HDMI output, two HDD bays (up to 20 TB). Sweet spot for small business, retail, hospitality and larger homes — Wi-Fi PTZ at the awkward install spot, wired fixed cameras everywhere else. View DS-7608NI-M2/8P →
DS-7616NI-M2/16P — 16CH · 16 PoE · 2 HDD Bay
Sixteen channels at full PoE, 160 Mbps M-Series engine for stutter-free 4K playback. Standard pairing for larger homes, body-corporate sites, schools and multi-shop installs running multiple Value PTZs across a campus. View DS-7616NI-M2/16P →
Need AI Search? AcuSeek / DeepinMind NVRs
For sites where you need natural-language search across the recording fleet ("show me people in red jackets near the front gate yesterday"), step up to a Hikvision AcuSeek (VPro) or DeepinMind AI NVR. Useful for commercial, school-campus and gated-estate deployments — overkill for most homes. Browse AcuSeek & DeepinMind NVRs →
Browse the full Hikvision NVR range: Hikvision Network Video Recorders →. Not sure which tier is right? Request a free system quote.
Compatible Mounts & Accessories
The camera ships with a standard ceiling / wall bracket. Below are the official Hikvision accessory options for specific install geometries.
DS-1294ZJ-PT — Wall Mount
Wall-mount bracket sized for the 2-inch PTZ — house wall, shopfront column, garage facade or fence column install.
DS-1297ZJ — Pendant Mount
Pendant-style mount for hanging from an eave, ceiling, carport gantry or awning soffit — most common residential front-of-house geometry.
DS-1297ZJ-M / -ES / DS-1299ZJ — Pendant Variants
Alternative pendant-mount geometries — pick the reach and bracket profile that matches your install substrate. Talk to our AU team if unsure.
microSD Card for Local Storage
Supports microSD / SDHC / SDXC up to 512 GB with ANR auto-back-fill — camera keeps recording locally during Wi-Fi or NVR outages, back-fills automatically when network returns.
Frequently Asked Questions
Do I still need a cable if I'm using Wi-Fi?
Yes — but only a power cable, not a data cable. The camera draws up to 11.2 W and Wi-Fi can't deliver power. You'll either run a 12 VDC cable from a power adapter, or place a PoE injector at the install location. Wi-Fi gets you out of running Cat 6 across ceilings, but doesn't eliminate the cable entirely.
How do I pair the camera to my Wi-Fi?
Initial Wi-Fi setup requires a one-time Ethernet connection. Plug the camera into your router or switch with a Cat 5e/6 cable, use Hikvision's SADP tool or iVMS-4200 on a Windows / Mac computer to enter your Wi-Fi SSID and password, then unplug the Ethernet cable — the camera will reconnect over Wi-Fi. You can't currently pair Wi-Fi directly from the Hik-Connect mobile app.
Will the camera work on 5 GHz Wi-Fi?
No — this camera supports 2.4 GHz Wi-Fi only (IEEE 802.11b/g/n). If your router is dual-band, make sure 2.4 GHz is enabled and that your network's SSID is reachable on the 2.4 GHz band where the camera will sit. Most home and office routers run both 2.4 and 5 GHz automatically.
How far from the router can the camera be?
2.4 GHz Wi-Fi typically reaches ~15 m through one wall or up to ~30 m with line-of-sight. The camera streams at ~4-8 Mbps which is comfortable for 802.11n 2.4 GHz at reasonable signal strength. For longer-distance installs or installs with multiple walls between camera and router, add a Wi-Fi mesh node or access point closer to the camera.
Why choose Wi-Fi vs the wired-only version?
Choose Wi-Fi (/W) for install flexibility: apartments, rentals, heritage buildings, fence corners, garden sheds, undercover carports — any site where running a Cat 6 data cable would mean punching through walls or trenching. Choose the wired-only (/E) for install simplicity: typical home, shopfront or small office where a single PoE cable from the NVR is straightforward. The wired version is slightly cheaper and has no Wi-Fi setup at all.
Will the Wi-Fi stream record to my Hikvision NVR?
Yes. The Wi-Fi PTZ appears on your NVR as a standard ONVIF / ISAPI IP camera on the LAN — the NVR doesn't distinguish Wi-Fi from Ethernet. Add it using its IP address as you would any other camera, then schedule recording, motion detection and AcuSense alarms normally.
Can I install this within 2 km of the coast?
Honestly — not directly exposed. This camera does not have anti-corrosion housing (no -Y variant exists in this family). For coastal Australian installs within 2 km of saltwater, either choose a NEMA 4X-rated camera (look for the "-Y" suffix on Hikvision turrets) or mount this PTZ under deep cover (eave, undercover carport, sheltered porch) so it doesn't see direct salt-spray exposure.
Does AcuSense work the same over Wi-Fi as Ethernet?
Yes — AcuSense classification happens on the camera itself, not on the network. The deep-learning model runs locally, decides whether the motion is human / vehicle / other, then sends only the qualified alerts and metadata over Wi-Fi (or Ethernet) to the NVR or Hik-Connect. Bandwidth use is the same; false-alarm filtering is identical.
Downloads & Resources
DS-2DE2A404IWG1-E/W Datasheet
Hikvision PTZ Quick Start Guide
Hikvision PTZ User Manual
Order the Hikvision DS-2DE2A404IWG1-E/W from CCTV Guru
CCTV Guru is an authorised Australian reseller of the Hikvision Value Series PTZ range. The DS-2DE2A404IWG1-E/W is the Wi-Fi-enabled variant of Hikvision's most affordable PTZ — built for installs where running Cat 6 data cable isn't practical. 4 MP imaging, 4× optical zoom, AcuSense AI, full two-way audio, integrated 2.4 GHz Wi-Fi, all in a compact 560 g body. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch. Designing a Wi-Fi camera install for a rental, apartment, fence corner or heritage site? Request a free quote or contact our Australian team for system sizing and Wi-Fi placement advice.
Hikvision Value PTZ · 4MP 4× Zoom · AcuSense · 20 m IR
Hikvision DS-2DE2A404IWG1-E — 4MP 4× Zoom AcuSense Mini PTZ (2.8-12 mm, 20 m IR, IP66/IK10)
The Hikvision DS-2DE2A404IWG1-E is the most affordable Hikvision PTZ on the Australian market — a compact 2-inch Value Series speed dome with a motorised 2.8-12 mm F1.8 lens, 4× optical + 16× digital zoom, 4 MP 2560 × 1440 imaging, 20 m smart IR, 120 dB WDR, on-camera AcuSense human + vehicle filtering, and a built-in mic + speaker for full two-way audio via Hik-Connect. Standard PoE 802.3af means it plugs straight into any Hikvision PoE NVR port — no injector, no Hi-PoE, no special supply. IP66 weather-rated, IK10 vandal-rated, ~560 g compact chassis. Australian stock, 3-year Australian warranty.
Optical Zoom
4× · 2.8-12 mm · F1.8
Resolution
4 MP · 2560 × 1440 · 25/30 fps
Smart IR
Up to 20 m · 850 nm
AI Engine
AcuSense · Human + Vehicle
Audio
Built-in Mic + Speaker · 2-Way
Power
PoE 802.3af · 12 VDC · 11.2 W
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
See Hikvision AcuSense in Action
AcuSense is the on-camera deep-learning engine that makes this PTZ useful instead of noisy — it classifies every motion event as human, vehicle, or "other" (foliage, possums, headlight glare) and filters out the false alarms. Hikvision's official AcuSense demonstration video shows how it works on the same AI engine that powers this Value Series PTZ.
Why Choose the DS-2DE2A404IWG1-E Value PTZ
For most Australian homes, retail shops, hospitality venues and small offices, a single Value Series PTZ replaces three or four fixed cameras and gives the operator something fixed cameras can't: the ability to actively investigate a scene at zoom while keeping the wide view available on-demand.
4× Optical Zoom · 2.8-12 mm F1.8
Motorised wide-to-tele lens covers 99.4° wide (whole driveway / shopfront) to 32.8° tele (face at the gate / plate at the carpark). 16× digital on top. ~2 s zoom transit.
AcuSense — Real Notifications
On-camera deep learning filters every motion event as human, vehicle or other. Only human/vehicle classifications trigger alerts. Typical sites see ~90 % fewer false alarms than motion-only cameras.
Built-in Mic + Speaker · 2-Way Audio
Mic picks up audio within 5 m. Speaker projects voice to 10 m. Live talk-down via Hik-Connect from your phone — no external mic, speaker or audio adapter required.
Standard PoE 802.3af — Plug and Play
Runs on the same standard PoE every Hikvision NVR delivers. No PoE+ injector, no Hi-PoE switch, no 36 VDC supply. Single Cat 6 cable into the NVR port, done.
Honest Positioning — What This Camera Is, and What It Isn't
We sell a lot of PTZ cameras in Australia, and we'd rather steer you to the right one than oversell this one. The DS-2DE2A404IWG1-E is the genuine entry-level Hikvision PTZ — incredible value for the right scenario, but with real limits you should know about up front.
This Camera IS Right For…
• Residential front door, driveway and reception• Retail shopfront, hospitality venues, restaurants and cafés• Small office, school classroom, warehouse roller door• Anywhere you want one camera doing the work of three• Sites that already have a Hikvision PoE NVR• Indoor or weather-protected outdoor placement• Inland and most metro Australian sites
This Camera Is NOT The Right Pick If…
• You're within ~2 km of the coast (no anti-corrosion variant — choose a -Y turret instead)• You need IR coverage beyond 20 m (step up to 3-inch sibling with 50 m IR)• You need facial recognition / face library matching (Pro / DeepinView series)• You need automatic target tracking (Ultra Series PTZ — DS-2DF6A or 7A)• You need long-range zoom > 4× (Ultra Series with 36-42× optical)• The site is in alpine / sub-zero conditions year-round (this is rated to −20 °C)
For sites that need more than the Value Series provides, we'd recommend stepping up to the DS-2DE3A404IWG-E/W (3-inch sibling, 50 m IR), or to the Hikvision Ultra Series PTZ range for long-range identification work. Not sure which fits your site? Contact our Australian team — we'll size it correctly.
Pan / Tilt / Zoom — Operator Control
355° Pan · 0°-90° Tilt
Pan 0° to 355° (5° slip-ring dead-zone — irrelevant on most ceiling / eave / wall mounts). Tilt 0° to 90° straight down for ground-level coverage from a mounted vantage.
300 Presets · Patrol Scan
300 presets + patrol scan automation. Set angles for driveway, gate, shopfront, carpark; recall with one tap. Schedule automated overnight patrol routes.
3D Positioning — Click to Zoom
Click any point on the live view to centre-frame and zoom in one motion — fastest operator workflow for investigating wide-scene events in Hik-Connect, iVMS-4200 or HikCentral Pro.
Proportional Pan + Power-Off Memory
Pan speed auto-scales with zoom (fine control at tele, fast at wide). Returns to last orientation automatically after brown-out, power cycle or NVR restart.
Technical Specifications
DS-2DE2A404IWG1-E · Full Specifications
SKU
DS-2DE2A404IWG1-E (PoE / 12 VDC, no Wi-Fi)
Camera Type
Hikvision Value Series · 4 MP 4× IR AcuSense Mini PTZ Network Speed Dome
Image Sensor
1/2.8" Progressive Scan CMOS · Powered-by-DarkFighter
Max Resolution
2560 × 1440 (4 MP 16:9)
Min. Illumination
Colour 0.005 lux @ F1.8 (AGC ON) · B/W 0.001 lux @ F1.8 · 0 lux with IR
Shutter Speed
1/1 s to 1/30,000 s · Slow Shutter
Lens
Motorised · 2.8-12 mm · 4× optical zoom · 16× digital · max F1.8 aperture · auto / semi-auto / manual focus
Field of View
Horizontal 99.4° → 32.8° · Vertical 51.7° → 18.4° · Diagonal 119.9° → 37.5°
Zoom Speed
Approximately 2 s (wide ↔ tele)
Regional Focus / Exposure
Yes / Yes
IR Illumination
Smart IR up to 20 m · 850 nm wavelength
Day & Night
ICR (IR cut filter, mechanical)
Wide Dynamic Range
120 dB · BLC · HLC · 3D DNR · digital defog
SNR
> 52 dB
Pan Range / Speed
0° to 355° · 0.1°-50°/s configurable · preset 50°/s · proportional pan
Tilt Range / Speed
0° to 90° · 0.1°-50°/s · preset 50°/s
Presets / Patrols
300 presets · patrol scan
Park Action
Preset · patrol scan
3D Positioning
Yes — click-to-frame on live view
Power-Off Memory
Yes
Scheduled Task
Patrol scan · preset · dome reboot · dome adjust
Frame Rate (Main)
50 Hz: 25 fps @ 4 MP · 60 Hz: 30 fps @ 4 MP
Streams
3 simultaneous (main / sub / third)
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG (sub / third)
Video Bit Rate
32 Kbps – 16 Mbps · CBR / VBR · SVC (H.264 + H.265) · 1 ROI region
Deep-Learning AI
AcuSense — human + vehicle classification
Smart Events
Line crossing · intrusion · region entrance · region exiting
Basic Events
Motion · video tampering · network disconnect · IP conflict · illegal login · HDD full · HDD error
Linkage
FTP / NAS / microSD upload · centre notify · email · trigger recording · audible warning
Audio
Built-in microphone (5 m pickup) · built-in speaker (10 m effective) · 1 line-in (2–2.4 Vpp, 1 KΩ ±10%) · 1 line-out (600 Ω) · G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC
Ethernet
1 × RJ-45 10/100 Mbps self-adaptive
On-Board Storage
microSD / SDHC / SDXC up to 512 GB · NAS (NFS / SMB-CIFS) · ANR auto network replenishment
API & Protocols
ONVIF (Profile S / G / T) · ISAPI · SDK · ISUP · 6 concurrent live-view sessions · 32 users (3 levels)
Cyber Security
HTTPS · IP filter · watermark · TLS 1.2 · MAC host authentication · audit log · password protection
Client Software
iVMS-4200 · Hik-Connect · HikCentral Pro
Web Browser
Chrome 80+ · Firefox 80+ · Safari 13+ · Edge 89+
Power Source
12 VDC max 11.2 W OR PoE IEEE 802.3af — runs on standard PoE port of any Hikvision NVR · power output 12 VDC max 60 mA
Dimensions / Weight
Ø 130.7 mm × 103.6 mm · ≈ 560 g
Operating Condition
−20 °C to +60 °C · humidity ≤ 90 % non-condensing
Weatherproof Rating
IP66 (IEC 60529-2013)
Vandal Resistance
IK10
Lightning Protection
TVS 4,000 V · surge + voltage transient protection
Anti-Corrosion
Not rated — no -Y / NEMA 4X variant in this family. Avoid coastal sites within ~2 km of shoreline.
DORI (Tele · 12 mm)
Detect 180 m · Observe 71.4 m · Recognise 36 m · Identify 18 m
Approvals
RCM (Australia / NZ) · IP66 / IK10 protection
Warranty
3-Year Australian Warranty (back-to-base)
DS-2DE2A404IWG1-E (2-Inch · 20 m IR) vs DS-2DE3A404IWG-E/W (3-Inch · 50 m IR)
The 3-inch sibling DS-2DE3A404IWG-E/W is the natural step up — same Value Series family, same 4 MP 4× lens, same AcuSense AI, same built-in audio. The differences are chassis size, IR range, and integrated Wi-Fi. Pick the 2-inch for tight installs and short night-time reach; pick the 3-inch when the scene runs out past 20 m at night or where Wi-Fi placement is needed.
DS-2DE2A404IWG1-E (2-inch · this) vs DS-2DE3A404IWG-E/W (3-inch sibling)
Feature
DS-2DE2A404IWG1-E (this — 2-inch)
DS-2DE3A404IWG-E/W (3-inch sibling)
Chassis Size
2-inch · Ø 130.7 mm · ~560 g
3-inch · larger body
Image Sensor
1/2.8" CMOS · Powered-by-DarkFighter
1/2.8" CMOS · Powered-by-DarkFighter
Resolution
4 MP · 2560 × 1440
4 MP · 2560 × 1440
Optical Zoom
4× · 2.8-12 mm · F1.8
4× · 2.8-12 mm · F1.6
IR Range
Up to 20 m
Up to 50 m
WDR
120 dB
120 dB
AI Engine
AcuSense · human + vehicle
AcuSense · human + vehicle · auto-tracking
Built-in Audio
Mic + Speaker · 2-way
Mic + Speaker · 2-way
Pan / Tilt Speed
50°/s preset
80°/s preset
Wi-Fi
No (PoE / 12 VDC only)
Yes — IEEE 802.11b/g/n 2.4 GHz
Power
PoE 802.3af · 12 VDC
PoE 802.3af · 12 VDC
Protection
IP66 · IK10
IP66 · IK10
Anti-Corrosion
Not rated
Not rated
Warranty
3-Year Australian Warranty
3-Year Australian Warranty
Best For
Indoor / short-range outdoor: front door, reception, retail shopfront, restaurant, small driveway, side gate, undercover carport. The most affordable Hikvision PTZ.
Larger driveways, longer carparks, school perimeters, body-corporate courtyards. The 50 m IR ring is the difference. Also adds Wi-Fi for installs where running Cat 6 is awkward.
View the 3-inch sibling: DS-2DE3A404IWG-E/W →
Recording NVRs — Pair with an Affordable M-Series PoE NVR
The DS-2DE2A404IWG1-E runs on standard PoE 802.3af and plugs directly into any Hikvision NVR's built-in PoE port — no separate injector needed. For most residential, retail and small-business installs, the Hikvision M-Series NVRs are the right partner: 4K HDMI output, H.265+ compression, PoE built-in, plug-and-play, and pricing that keeps a complete system within reach. Step up to AcuSeek / DeepinMind only when you specifically need natural-language AI search across the recording fleet.
DS-7604NI-M1/4P — 4CH · 4 PoE · Budget Pick
Four-channel M-Series NVR with 4 built-in PoE ports, 4K HDMI output and a single HDD bay (up to 10 TB). The most cost-effective Hikvision NVR for a typical 4-camera install with this PTZ as the centrepiece plus 3 fixed turrets around the property. View DS-7604NI-M1/4P →
DS-7608NI-M2/8P — 8CH · 8 PoE · 2 HDD Bay
Eight-channel M-Series NVR with 8 built-in PoE ports, 4K HDMI output and two HDD bays (up to 20 TB total). The sweet spot for small business, retail, hospitality and larger homes running this PTZ alongside 4-7 fixed cameras. View DS-7608NI-M2/8P →
DS-7616NI-M2/16P — 16CH · 16 PoE · 2 HDD Bay
Sixteen channels at full PoE, 160 Mbps M-Series engine for stutter-free 4K playback, 2 HDD bays. Standard pairing for larger homes, body-corporate sites, schools and multi-shop installs running multiple Value PTZs plus a fleet of fixed cameras. View DS-7616NI-M2/16P →
Need AI Search? AcuSeek / DeepinMind NVRs
For sites where you need natural-language search across the recording fleet ("show me people in red jackets near the front gate yesterday afternoon"), step up to a Hikvision AcuSeek (VPro) or DeepinMind AI NVR. Useful for larger commercial, school-campus and gated-estate deployments — overkill for most homes and small businesses. Browse AcuSeek & DeepinMind NVRs →
Browse the full Hikvision NVR range: Hikvision Network Video Recorders →. Not sure which tier is right? Request a free system quote — we'll size the NVR, storage and switch correctly the first time.
Compatible Mounts & Accessories
The camera ships with a standard ceiling / wall bracket. Below are the official Hikvision accessory options for specific install geometries.
DS-1294ZJ-PT — Wall Mount
Wall-mount bracket sized for the 2-inch PTZ — house wall, shopfront column, garage facade or fence column install.
DS-1297ZJ — Pendant Mount
Pendant-style mount for hanging from an eave, ceiling, carport gantry or awning soffit — most common residential front-of-house geometry.
DS-1297ZJ-M / -ES / DS-1299ZJ — Pendant Variants
Alternative pendant-mount geometries — pick the reach and bracket profile that matches your install substrate. Talk to our AU team if unsure.
microSD Card for Local Storage
Supports microSD / SDHC / SDXC up to 512 GB with ANR auto-back-fill — camera keeps recording locally during NVR outages, back-fills automatically when network returns.
Frequently Asked Questions
Why choose a PTZ over multiple fixed cameras?
A PTZ replaces three or four fixed cameras for the same site coverage and adds the ability to investigate a scene live — zoom in on a face, follow a vehicle as it leaves, talk down to a courier. For a single front-of-house or shopfront install, a Value PTZ often costs less than the equivalent multi-camera fixed setup. For wide static perimeter coverage where you need every angle recorded simultaneously, fixed cameras are still the right answer.
Will it run on my existing Hikvision NVR's PoE port?
Yes. The camera uses standard PoE (IEEE 802.3af), the same PoE class delivered by every Hikvision PoE NVR's built-in port. No injector, no Hi-PoE, no special supply — single Cat 6 cable from the NVR port to the camera.
Is 20 m IR enough for my driveway / shopfront?
For typical Australian suburban driveways (10-15 m), retail shopfronts, reception areas, undercover carports and side-gate zones, 20 m IR is sufficient. For longer driveways or larger carparks where you need night identification beyond 20 m, step up to the 3-inch DS-2DE3A404IWG-E/W with 50 m IR, or move up to the Ultra Series with 300 m IR.
Can I use the two-way audio with my phone?
Yes. Open the live view in Hik-Connect on your phone, tap the audio button, and you can hear and speak directly through the camera's built-in mic + speaker — talk to a courier, warn off an intruder, or check what's happening at the gate.
Can I install this within 2 km of the coast?
Honestly — no, not directly exposed. This camera does not have anti-corrosion housing (there's no -Y variant in this family). For coastal Australian installs (Sydney CBD, Wollongong, Newcastle, Gold Coast, Perth, etc.) within 2 km of saltwater, either choose a NEMA 4X-rated camera (look for the "-Y" suffix on Hikvision turrets) or mount this PTZ under genuine cover (a deep eave, undercover carport, sheltered porch) so it doesn't see direct salt-spray exposure.
Why is the pan range 355°, not full 360°?
The 2-inch Value Series uses a slip-ring design with a 5° dead-zone for the cabling. For ceiling, eave and wall mounts overlooking a single scene, this is irrelevant — you don't need the 5° anyway. For corner mounts where you want a full continuous sweep, plan the orientation so the dead-zone faces away from the scene of interest (e.g. toward the wall behind the camera).
Does it support face recognition or auto-tracking?
No — those are Pro / DeepinView / Ultra Series features. This camera covers human and vehicle classification and perimeter detection only. For facial recognition against a watchlist, choose a Hikvision DeepinView model. For automatic PTZ target tracking, step up to the Ultra Series PTZ range.
Downloads & Resources
DS-2DE2A404IWG1-E Datasheet Hikvision PTZ Quick Start Guide Hikvision PTZ User Manual
Order the Hikvision DS-2DE2A404IWG1-E from CCTV Guru
CCTV Guru is an authorised Australian reseller of the Hikvision Value Series PTZ range. The DS-2DE2A404IWG1-E is the most affordable Hikvision pan / tilt / zoom camera available in Australia — and for the right install (residential front-of-house, retail shopfront, hospitality venue, small office, reception area, undercover carport), it's the right call. 4 MP imaging, 4× optical zoom, AcuSense AI, full two-way audio and standard PoE plug-and-play, all in a compact 560 g body. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch. Designing a complete PTZ-plus-fixed-camera system? Request a free quote or contact our Australian team for system sizing — we'll get the right number of cameras, the right NVR and the right brackets specified the first time.
WizSense 3 · 6 MP · Smart Dual Light · AcuPick Ready
Dahua DH-IPC-HFW3667E-AS-IL-ANZ — 6 MP Smart Dual Light Fixed-Focal Bullet WizSense Network Camera
The Dahua DH-IPC-HFW3667E-AS-IL-ANZ is a 6 MP WizSense 3 outdoor bullet IP camera with a fixed-focal 2.8 mm F1.4 lens (3.6 mm option also available). The 1/2.7" CMOS sensor outputs 3288 × 1850 at 25/30 fps with Smart H.265+ encoding, and Dahua's Smart Dual Light engine pairs a 30 m IR illuminator with a 30 m warm-light array — the camera defaults to invisible IR after dark, then flips to full-colour white light the instant WizSense classifies a person or vehicle in the scene. WDR is rated at 120 dB, the housing is IP67 sealed across –40 °C to +60 °C (Alpine-rated), and the on-board electronics include a built-in microphone, 1/1 RCA audio I/O and a 1/1 alarm wet-contact pair. Edge AcuPick, SMD 4.0 and perimeter protection run on the WizSense 3 deep-learning chip; peak draw is 10 W on standard 802.3af PoE. Built for Australian residential and small-business installs with predictable framing — single-driveway homes, shopfronts, NDIS dwellings, small carparks and rural sheds. Backed by a 3-year Australian warranty through CCTV Guru.
Lens
2.8 mm F1.4 Fixed
Resolution
6 MP @ 25/30 fps
Smart Dual Light
IR 30 m + Warm 30 m
AI Engine
WizSense 3 + AcuPick
Protection
IP67 · –40 to +60 °C
Power
12 VDC / PoE 802.3af · 10 W max
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why Choose the Dahua HFW3667E-AS-IL-ANZ
This is the WizSense 3 6 MP bullet for installs that have predictable framing and don't need a motorised lens. Below are the six reasons it outperforms generic fixed-lens 6 MP bullets in Australian deployments.
True 6 MP Image, Not Upscaled
The 1/2.7" CMOS captures a native 3288 × 1850 raster — more than double the pixel density of 1080p — so digital zoom into faces, plates and signage stays usable instead of dissolving into a noise field.
Smart Dual Light, No Light Pollution
30 m IR runs invisibly until WizSense classifies a person or vehicle, then the 30 m warm-light array switches on the target to capture full-colour evidence. No constant white-light wash for neighbours to complain about.
120 dB WDR for AU Sun
Strong WDR holds detail in both the bright sky and the dark interior in a single frame — important for north-facing entries, colourbond-shaded driveways and glass shopfronts where lesser cameras blow out one side.
110° Wide Coverage from a Single Mount
The 2.8 mm lens delivers a 110° horizontal field of view — wide enough to cover a typical Australian double driveway, a shopfront awning or an entire small carpark from one camera. DORI Identify range extends to 8.5 m.
AcuPick-Ready Edge AI
Paired with a Dahua AcuPick NVR, this camera lets you search hours of recorded video by attributes — "red top, blue trousers, walking east" — and pulls matching clips in seconds rather than scrubbing the timeline by hand.
Best-in-Class Cold-Weather Rating
Rated –40 °C to +60 °C — a 10 °C colder floor than the motorised-zoom HFW3667T variant. The right WizSense 3 bullet for Alpine NSW, Tasmanian highland, and any site that sees overnight frost.
Important Install Note
This camera draws a maximum of 10 W on PoE — comfortable on any 802.3af switch, including the integrated PoE ports on Dahua's compact NVRs. The lens is fixed-focal, so frame the camera carefully at install time — there's no remote re-framing later. For outdoor installs in exposed positions (coastal, humid, or where the RJ-45 termination sits behind the camera in still air), we strongly recommend pairing with the DH-PFA130-E water-proof junction box to keep condensation off the connector.
AI & Smart Detection Capabilities
AcuPick Target Search
Deep-learning attribute matching across people and vehicles. Find a target across hours of recorded video by colour, top/bottom clothing, vehicle type and direction — when paired with a compatible Dahua AcuPick NVR.
SMD 4.0 — Smart Motion Detection
Motion alerts triggered only by humans and vehicles. Wind-blown branches, small animals, possums on a fence and shadows are filtered out at the edge — slashing false-alarm volume on residential and small-business sites.
Perimeter Protection (IVS)
Configurable tripwire and intrusion zones with human-and-vehicle classification. Draw a line across a driveway or a polygon around a yard and only get pushed an alert when the right type of target crosses it.
Smart Dual Light Deterrence
When WizSense classifies a person in the warm-light zone, the white-light array triggers automatically — leaving subjects in no doubt they have been captured in full colour. A passive deterrent that costs nothing extra in licensing or hardware.
AI SSA — Scene Self-Adaptation
The camera detects environmental conditions like rain, fog, backlight, low light and flicker, and automatically adjusts image parameters to keep the scene clear — without an operator touching the settings.
Smart Search & Event Extraction
Pairs with a Smart NVR to refine intelligent search, extract and merge event video. Skip past hours of empty footage and jump straight to the moments where something the AI flagged as relevant happened.
Technical Specifications
Camera & Image Sensor
Model
DH-IPC-HFW3667E-AS-IL-ANZ
Form Factor
Bullet (metal casing)
Image Sensor
1/2.7" CMOS
Maximum Resolution
3288 × 1850 (6 MP)
Scanning System
Progressive
Minimum Illumination
0.005 lux @ F1.4 (Colour) · 0.0005 lux @ F1.4 (B/W) · 0 lux (illuminator on)
WDR
120 dB
Day / Night
Auto (ICR) / Colour / B&W
BLC / HLC
Yes / Yes
Noise Reduction
3D NR
Smart Illumination
Yes
Smart Dual Light
Yes
Privacy Masking
Multiple areas
Lens & Illumination
Lens Type
Fixed-focal
Lens Mount
M12
Focal Length
2.8 mm (this listing) · 3.6 mm variant also available
Maximum Aperture
F1.4
Field of View (2.8 mm)
H: 110° · V: 58° · D: 132°
Close Focus Distance
1.4 m
IR Illumination
Up to 30 m
Warm Light Illumination
Up to 30 m
Illuminator Configuration
2 × multi-core LEDs (IR + warm light)
Smart Dual Light
Yes (target-triggered IR / warm light hand-off)
DORI (2.8 mm)
Detect 84.8 m · Observe 33.9 m · Recognise 17.0 m · Identify 8.5 m
Intelligence & Video
AI Engine
WizSense 3 Series
IVS — Perimeter Protection
Tripwire, intrusion (with human + vehicle classification)
Smart Motion Detection
SMD 4.0
AcuPick
Yes (with compatible Dahua AcuPick NVR)
AI SSA
Yes (scene self-adaptation)
Smart Search
Yes (paired with Smart NVR)
Video Compression
H.265 · H.264 · H.264H · H.264B · MJPEG (sub stream)
Smart Codec
Smart H.265+ · Smart H.264+
AI Coding
AI H.265 · AI H.264
Resolutions
6 MP · 5 MP · 4 MP · 3 MP · 1080p · 720p · D1 · VGA · CIF
Main Stream
3288 × 1850 @ 1–25/30 fps
Bit Rate Control
VBR · CBR · ABR
Audio, Alarm & Network
Built-in Microphone
Yes
Audio Input
1 channel (RCA)
Audio Output
1 channel (RCA)
Audio Compression
PCM · G.711a · G.711Mu · G.726 · G.723
Alarm Input
1 channel — wet contact, 5 mA, 3–5 VDC
Alarm Output
1 channel — wet contact, 300 mA, 12 VDC
Network Port
RJ-45 (10/100 Base-T)
Network Protocols
IPv4 · IPv6 · HTTP · HTTPS · TCP · UDP · ARP · RTP · RTSP · RTCP · RTMP · SMTP · FTP · SFTP · DHCP · DNS · DDNS · QoS · UPnP · NTP · Multicast · ICMP · IGMP · NFS · SAMBA · PPPoE · SNMP · P2P · 802.1x
Interoperability
ONVIF (Profile S, G, T) · CGI
Storage
FTP · SFTP · NAS · Micro SD card up to 512 GB
Mobile Client
DMSS (iOS / Android)
Management Software
SmartPSS Lite · DSS · DMSS
Cyber Security
Trusted boot · trusted execution · trusted upgrade · video encryption · firmware encryption · 802.1x · HTTPS · IP/MAC filtering · WSSE · X.509
Recommended Firmware
Dahua V5.x (enables AcuPick, ONVIF 23.12, iSCSI, N+M with compatible NVRs)
Power, Environment & Build
Power Supply
12 VDC / PoE (802.3af)
Power Consumption (Basic)
3.7 W (12 VDC) · 5.4 W (PoE)
Power Consumption (Max.)
8 W (12 VDC) · 10 W (PoE) with H.265 + WDR + warm light + AI
Dual-Power Backup
Yes (12 VDC and PoE simultaneously supported)
Operating Temperature
–40 °C to +60 °C
Operating Humidity
≤ 95% RH (non-condensing)
Storage Temperature
–40 °C to +60 °C
Protection Rating
IP67
Casing Material
Metal
Certifications
CE-LVD (EN62368-1) · CE-EMC (2014/30/EU) · RCM (AU)
Australian Warranty
3 Years (via CCTV Guru)
How It Compares — HFW3667E-AS-IL-ANZ vs HFW3667T-ZAS-IL-ANZ
The closest sibling is the Dahua DH-IPC-HFW3667T-ZAS-IL-ANZ — the motorised-zoom 2.7–13.5 mm sibling. Same sensor, same WizSense 3 AI, same audio I/O, same IP67 build. The decision is whether you need a fixed lens (cheaper, lower power, simpler install) or motorised optics (re-frameable from the app, longer-range IR/warm light, better cold-tolerance for premium sites).
Feature
DH-IPC-HFW3667E-AS-IL-ANZ (this camera)
DH-IPC-HFW3667T-ZAS-IL-ANZ (sibling)
Resolution
6 MP (3288 × 1850)
6 MP (3288 × 1850)
Sensor
1/2.7" CMOS
1/2.7" CMOS
Lens
Fixed-focal 2.8 mm (3.6 mm option) · F1.4
Motorised vari-focal 2.7–13.5 mm · F1.4
AI Engine
WizSense 3
WizSense 3
AcuPick
Yes
Yes
Smart Dual Light
IR 30 m + warm 30 m
IR 60 m + warm 60 m
Illuminators
2 × multi-core LEDs
4 × multi-core LEDs
DORI — Identify
8.5 m (at 2.8 mm)
8.5 m wide · 28 m tele
WDR
120 dB
120 dB
Audio
Built-in mic + 1/1 RCA audio I/O
Built-in mic + 1/1 RCA audio I/O
Power Draw (PoE max)
10 W (lighter — runs on any 802.3af)
12.5 W
Operating Temperature
–40 °C to +60 °C (better cold rating)
–30 °C to +60 °C
IP Rating
IP67
IP67
Best For
Predictable framing — single-driveway homes, shopfronts, NDIS dwellings, Alpine sites
Variable framing — long driveways, carparks, sites where you may want to re-frame later
Recommended NVR Pairings
For AcuPick attribute search on recorded footage, this camera should be paired with a Dahua 5-Series AI NVR running V5 firmware. Below are four CCTV Guru-stocked recorders sized for the most common Australian deployments — from single-home through to enterprise.
Dahua DHI-NVR5208-8P-AI/ANZ
5-Series AcuPick NVR · 8 channels · 8 built-in PoE ports · 2 HDD bays · 1U · perimeter protection and SMD Plus. The most popular pairing for residential and small-business sites running 4–8 cameras.
View Dahua NVR5208-8P-AI →
Dahua DHI-NVR5216-16P-AI/ANZ
5-Series AcuPick NVR · 16 channels · 16 PoE+ ports (1–8 ePoE) · 2 HDD bays · 1U · 384 Mbps incoming. Sized for medium commercial sites and multi-building yards.
View Dahua NVR5216-16P-AI →
Dahua DHI-NVR4216-16P-AI/ANZ
4-Series WizSense AI NVR · 16 channels · 16 PoE ports · 2 HDD bays · 4K HDMI · Smart 2.0 AI with SMD+ and IVS. The value-pick 16-channel build for sites that don't need full AcuPick attribute search.
View Dahua NVR4216-16P-AI →
Dahua DHI-NVR5432-AI/ANZ
5-Series AcuPick NVR · 32 channels · 4 HDD bays · dual GbE NICs · dual HDMI + dual VGA · 1.5U. Enterprise-scale AcuPick across the entire estate — warehouses, schools, multi-tenant strata and large-format retail.
View Dahua NVR5432-AI →
Compatible Mounts & Accessories
DH-PFA130-E
Water-proof junction box — the most popular accessory for this camera. Protects the RJ-45 termination from condensation behind outdoor mounts. Strongly recommended for AU coastal and humid installs.
DH-PFA135
Standard junction box for tidy in-wall cable management on rendered or brick walls. Use when no waterproofing of the termination is required.
DH-PFA151
Corner mount bracket — for mounting the camera onto external building corners. Matches the camera's white powder-coat finish.
DH-PFA152-E
Pole mount bracket — fits 60–110 mm diameter poles. Ideal for carpark light poles, perimeter fence posts and rural driveway pylons.
G3416GW
G3/4" water joint — protects the cable gland on outdoor installs with conduit termination. Use with surface-mounted PVC or metal conduit runs.
DH-PFM321D-EN / DH-PFM320D-EN
Genuine Dahua 12 VDC power adapters — 1 A and 2 A options. Use when running the camera on local DC instead of PoE, or as a backup supply alongside PoE.
Frequently Asked Questions
What's the difference between the 2.8 mm and 3.6 mm lens options?
2.8 mm gives a wider 110° horizontal field of view — best for shopfronts, single driveways and small carparks where coverage matters more than range. 3.6 mm narrows the field but pushes more pixels onto distant targets — better for longer driveways and front-fence approaches.
Does this camera include AcuPick?
Yes — AcuPick attribute search is built into the camera's WizSense 3 firmware. To actually search recorded footage by attributes you must record to a compatible Dahua AcuPick NVR running V5 firmware.
Is this a TiOC camera?
No. TiOC SKUs carry the "PV" infix in the model number. This camera is a Smart Dual Light WizSense 3 model — it can illuminate a target on detection but does not have a red/blue strobe or built-in siren. For TiOC active deterrence, see our HFW3849T1-ZAS-PV-ANZ range instead.
How far can it see at night?
Smart Dual Light gives 30 m on IR and 30 m on warm light. DORI Identify range (where a face is recognisable) is 8.5 m at the 2.8 mm lens. For longer range, the motorised-zoom HFW3667T-ZAS-IL-ANZ variant pushes Identify out to 28 m at its tele setting.
Can I run this camera on standard PoE?
Yes — it is 802.3af-compliant and pulls a maximum of only 10 W. Any quality 802.3af switch with budget headroom will run it comfortably.
Does it have a microphone?
Yes, the camera has a built-in microphone, plus 1 × RCA audio in and 1 × RCA audio out for connecting an external mic or speaker. NDIS, retail and public-space sites should check local audio-recording legislation before enabling sound recording.
Does it work with third-party NVRs?
Yes — it supports ONVIF Profile S, G and T, so it will record to any ONVIF-compatible third-party NVR. Note that AcuPick attribute search and SMD 4.0 alarm push only work end-to-end on a genuine Dahua AI NVR.
What temperature range is it rated for?
–40 °C to +60 °C — a 10 °C wider cold-tolerance window than the motorised-zoom variant. Suitable for Alpine NSW, Tasmanian highland, and any AU site that sees overnight frost.
Can I view the camera live on my phone?
Yes — the camera works with Dahua's free DMSS app on iOS and Android. Add the device with the QR code on the housing, sign in, and you get live view, two-way audio, motion alerts and recorded-footage playback from anywhere with internet. No subscription required.
Downloads
DH-IPC-HFW3667E-AS-IL-ANZ Datasheet
Dahua IP Bullet Camera Quick Start Guide
Dahua IP Bullet Camera Installation Guide
Dahua IP Bullet Camera Operational Manual
Order Your Dahua HFW3667E-AS-IL-ANZ from CCTV Guru
"Add to cart" to order online, or contact our Australian team for a bulk quote, project pricing, multi-camera configuration advice or NVR compatibility check. We are authorised Australian Dahua resellers, hold stock locally, and back every camera with a 3-year Australian warranty and Australian-based tech support. Phone, email or live chat us through cctvguru.com.au/pages/contact — most enquiries are answered the same business day.
X-Spans Panoramic PTZ · 8+4 MP · 25× Zoom · TiOC · Xinghan AI
Dahua DH-SDT4E425-8P-GB-APV1 — 8+4 MP 25× X-Spans Panoramic TiOC PTZ Camera with Xinghan AI & Active Deterrence
The Dahua DH-SDT4E425-8P-GB-APV1 is an X-Spans series multi-sensor panoramic PTZ — two cameras inside one IP66, surge-protected housing. The overview channel is an 8 MP 1/2.7" CMOS with a 2.8 mm F1.4 lens spliced across a true 180° horizontal field of view, capturing the entire scene at all times. The detail channel is a 4 MP 1/2.8" CMOS PTZ with 5 – 125 mm F1.6 – F3.6 motorised optics, 25× optical zoom and 16× digital zoom — capable of detecting a target at 2500 m and identifying it at 250 m. Starlight low-light sensors push usable colour down to 0.005 lux. Dual-light arrays give the panoramic head 30 m IR + 30 m white, and the PTZ head 100 m IR + 50 m warm-light reach.
This camera is built for Australian sites where you would otherwise install two cameras — large carparks, school grounds, freight yards, transport hubs, depots, mining laydowns and council reserves — and want one head that maintains constant 180° awareness while a second head slews onto whatever the AI flags. Smart Tracking links the two channels so the PTZ automatically zooms onto any target the overview detects, then keeps tracking after the target leaves the panoramic FOV using Dahua's X-Spans relay tracking. Edge AI runs the new Xinghan Large-Scale AI Models with WizSense perimeter protection, SMD 4.0 and AcuPick. Active deterrence stacks red/blue light warning with 11 built-in alarms (plus 10 custom uploads) and a built-in speaker. Power is PoE+ (802.3at) or 12 VDC 3 A. Backed by a 3-year Australian warranty through CCTV Guru.
Optical Zoom
25× + 16× Digital
Dual Sensor
8 MP + 4 MP Starlight
Smart Dual Light+
IR 100 m · Warm 50 m
AI Engine
Xinghan + AcuPick
Active Deterrence
TiOC Strobe + Siren
Power
PoE+ 802.3at / 12 VDC
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
See the Dahua TiOC PRO Platform in Action
This is Dahua's official TiOC PRO highlight — the same active-deterrence platform that runs on the SDT4E425-8P-GB-APV1's PTZ head. Red/blue light warning, audible alarms, smart dual light and full AI classification working together to challenge intruders the moment they're detected.
Why Choose the Dahua SDT4E425-8P-GB-APV1
Buying a panoramic PTZ replaces two traditional cameras with one head. Below are the six reasons this specific X-Spans build is the one Australian integrators ask for when they want the dual-camera concept to actually work in the field — not the corner-case PoC demos.
180° Awareness, Always-On
The 8 MP overview channel is permanently recording a true 180° splice — so when the PTZ is steered onto a target, you don't lose situational awareness of the rest of the scene like you would with a single PTZ alone.
25× Optical Zoom · 250 m Identify Range
The detail PTZ runs 5 – 125 mm motorised optics with auto and semi-auto focus. DORI identify distance is 250 m at the tele end — long enough to read clothing and recognise faces across an entire carpark or paddock approach.
Smart Tracking Without Operator Intervention
WizTracking, relay tracking and linkage tracking work together so the PTZ automatically slews, zooms and follows whatever the overview channel's AI classifies as a person or vehicle — then keeps tracking after the target leaves the panoramic FOV.
TiOC Active Deterrence on a PTZ
Most active-deterrence cameras are fixed bullets or turrets. This camera mounts the full TiOC stack — red/blue strobe, 11-sound audible alarm library and built-in speaker — on a 25× PTZ that can challenge an intruder anywhere in its hemisphere.
Xinghan AI on the Edge
Xinghan Large-Scale AI Models bring transformer-architecture AI to the edge — joint inference between small and large models lets a single camera classify, track and respond on-device rather than depending on server-side compute.
Built for Harsh Australian Outdoor
IP66 sealed against driving rain, TVS 6000 V lightning + surge + voltage-transient protection, and rated operating range from –40 °C to +65 °C. Suitable for everything from Alpine highway sites through to the Pilbara.
Important Install Note — PoE+ Required
This camera draws a maximum of 25 W when illuminator, heater, active deterrence, ICR and PTZ are all active. It requires 802.3at PoE+, not standard 802.3af. On any deployment longer than 90 m, factor in cable resistance — for runs approaching the 100 m Ethernet limit we recommend either a local 12 VDC 3 A supply at the camera or a quality 802.3at midspan injector rather than relying on an underspecified PoE+ switch budget. The pre-included PFA150 pole-mount bracket is the standard option; wall, ceiling, parapet and corner brackets are listed in the Compatible Mounts section below.
AI & Smart Detection Capabilities
Xinghan Large-Scale AI Models
Dahua's newest edge AI generation — lightweight transformer architecture with model distillation and quantisation. The camera runs joint inference between small and large models to handle multiple simultaneous AI tasks with lower compute draw.
AcuPick Attribute Search
The overview channel supports AcuPick — when paired with a Dahua AcuPick NVR, you can search recorded video by colour, clothing, vehicle type and direction. Massively reduces investigation time.
Smart Tracking — Three Modes
WizTracking handles AI-driven human/vehicle following. Relay tracking (X-Spans exclusive) continues tracking after the target leaves the overview's 180° field. Linkage tracking restricts following to targets visible in the overview.
Full WizSense IVS Library
Tripwire, intrusion, crossing-fence detection, loitering, abandoned/missing object, fast-moving, parking detection, people gathering, human alarm classification and linkage tracking. Each event can trigger a preset, tour, capture, record, email or auto-patrol routine.
TiOC Active Deterrence Stack
Red/blue light warning with three flash frequencies (high/medium/low) and 5 – 30 s duration. 11 built-in sound alarms plus 10 importable custom sounds. Built-in speaker with 0–100% volume and 1–10 play-count control.
SMD 4.0 + Auto Patrol
Smart Motion Detection 4.0 filters animal and foliage motion, leaving alerts on people and vehicles only. After an IVS alarm, the PTZ can auto-patrol up to 5 presets or a scan path to verify the scene without an operator touching the joystick.
PTZ Kinematics
360° Endless Pan
Continuous 360° pan rotation with no mechanical stop — the PTZ can follow a target through any heading without re-homing.
–15° to +90° Tilt with Auto Flip
Tilt range covers straight down to slightly above horizon. Auto-flip 180° lets the camera track a target passing directly underneath the housing without losing the view.
Variable Manual Speed
Manual control speed runs from 0.1°/s for fine framing through 180°/s pan and 90°/s tilt for rapid scene change. Preset speeds are user-configurable across the same range.
300 Presets · 8 Tours · 5 Patterns · 5 Scans
Up to 300 stored presets, 8 multi-stop tours (32 presets each), 5 recorded patterns (joystick-driven motion playback) and 5 line scans. Power-off memory keeps the position on reboot.
Technical Specifications
Overview Channel (Panoramic)
Image Sensor
1/2.7" CMOS
Maximum Resolution
4096 (H) × 1860 (V) — 8 MP
Lens
2.8 mm fixed
Maximum Aperture
F1.4
Field of View
H: 180° · V: 86°
Min. Illumination
0.005 lux @ F1.4 (colour) · 0.0005 lux @ F1.4 (B/W) · 0 lux (illuminator on)
IR / White Light
30 m / 30 m
WDR
DWDR
DORI Distance
Detect 56 m · Observe 22.4 m · Recognise 11.2 m · Identify 5.6 m
ROM / RAM
4 GB / 2 GB
Detail Channel (25× PTZ)
Image Sensor
1/2.8" CMOS
Maximum Resolution
2560 (H) × 1440 (V) — 4 MP
Lens
5 mm – 125 mm motorised vari-focal
Optical Zoom
25×
Digital Zoom
16×
Maximum Aperture
F1.6 – F3.6
Field of View
H: 51.9° – 3.0° · V: 39.7° – 2.2° · D: 63.1° – 3.7°
Focus Control
Auto · Manual · Semi-Auto
Iris Control
Auto · Manual · Iris Priority
Min. Illumination
0.005 lux @ F1.6 (colour) · 0.0005 lux @ F1.6 (B/W) · 0 lux (illuminator on)
IR / Warm Light
100 m / 50 m
WDR
120 dB true WDR
DORI — Wide (5 mm)
Detect 100 m · Observe 40 m · Recognise 20 m · Identify 10 m
DORI — Tele (125 mm)
Detect 2500 m · Observe 1000 m · Recognise 500 m · Identify 250 m
Image Stabilisation
Electronic Image Stabilisation (EIS)
ROM / RAM
4 GB / 1 GB
PTZ & Smart Tracking
Pan Range
0° – 360° endless
Tilt Range
–15° to +90° (auto flip 180°)
Manual Speed
Pan 0.1°/s – 180°/s · Tilt 0.1°/s – 90°/s
Preset Speed
Pan 0.1°/s – 180°/s · Tilt 0.1°/s – 90°/s
Presets
300
Tours
8 (up to 32 presets per tour)
Patterns
5
Scans
5
Idle Motion
Preset · Pattern · Tour · Scan
Power-off Memory
Yes
Smart Tracking
WizTracking · Relay tracking (X-Spans) · Linkage tracking
Intelligence, Video & Active Deterrence
AI Platform
Xinghan Large-Scale AI Models · WizSense
IVS
Tripwire · intrusion · crossing-fence · loitering · abandoned/missing object · fast-moving · parking detection · people gathering · human alarm classification · linkage tracking
SMD
SMD 4.0
AcuPick
Yes (overview channel)
Auto Patrol
Up to 5 presets or scans triggered by IVS / SMD
Active Deterrence — Light
Red/blue light warning · 5 – 30 s flash duration · high/medium/low frequency
Active Deterrence — Sound
11 built-in alarms + 10 custom uploads · volume 0–100% · play 1–10 times
Video Compression
Smart H.265+ · H.265 · Smart H.264+ · H.264B · H.264M · H.264H · MJPEG (sub stream 1)
Streaming
3 streams (per channel)
Overview Main Stream
4096 × 1860 @ 1 – 25/30 fps
Detail Main Stream
2560 × 1440 / 1080p / 720p @ 1 – 25/30 fps
Bit Rate Control
CBR · VBR
Video Bit Rate (Overview)
H.264 128 kbps – 16,384 kbps · H.265 51 kbps – 13,312 kbps
Video Bit Rate (Detail)
H.264 96 kbps – 16,384 kbps · H.265 38 kbps – 10,240 kbps
Privacy Masking
Up to 24 areas (up to 8 in the same view) · multi-colour and mosaic options
Audio, Alarm & Network
Audio Compression
PCM · G.711A · G.711Mu · G.726 · MPEG2-Layer2 · G.722.1 · G.729
Audio Input
1 channel — LINE IN, bare wire
Audio Output
1 channel — LINE OUT bare wire · built-in speaker (mutually exclusive)
Alarm Input
2 channels — on/off 0 – 5 VDC
Alarm Output
1 channel
Alarm Linkage
Capture · recording · email · preset · tour · pattern · alarm digital output · audio · warning light
Network Port
RJ-45 (100 / 1,000 Base-T)
Network Protocols
HTTP · HTTPS · TCP/IP · IPv4 · IPv6 · RTSP · UDP · SMTP · NTP · DHCP · DNS · DDNS · 802.1x · SSL · QoS · FTP · UPnP · ICMP · SNMP · IGMP · ARP · RTCP · RTP · PPPoE · RTMP · Bonjour · NFS
Interoperability
ONVIF (Profile S, G, T) · CGI · SDK · P2P
Streaming Method
Unicast / Multicast
Max Users
20 (total bandwidth 64 Mbps)
Storage
Micro SD up to 512 GB · FTP / SFTP · NAS
Management Software
DMSS · DSS Pro
Mobile Client
iOS · Android (DMSS)
Power, Environment & Build
Power Supply
12 VDC, 3 A ± 10% · PoE+ (IEEE 802.3at)
Power Consumption
Basic 14 W · Max 25 W (illuminator + heating glass + active deterrence + ICR + PTZ)
Operating Temperature
–40 °C to +65 °C
Operating Humidity
≤ 95%
Protection
IP66 · TVS 6000 V lightning protection · surge protection · voltage transient protection
Product Dimensions
194.2 mm × 160 mm × 311 mm (L × W × H)
Net Weight
3.1 kg
Gross Weight
4.6 kg
Certifications
CE — EN 50130-4 · EN 55032 · EN 55035 · EN 61000-3-3 · EN IEC 61000-3-2 · EN 62368-1 · RCM (AU)
Australian Warranty
3 Years (via CCTV Guru)
How It Compares — X-Spans Dual-Head vs Traditional Two-Camera Install
Most sites that consider a panoramic PTZ are deciding between this one head and the traditional alternative — a fixed multi-sensor / fisheye for situational awareness, plus a separate single-PTZ for zoom and tracking, on two PoE drops. The table below contrasts both approaches on the deployment factors that actually move the budget.
Factor
SDT4E425-8P-GB-APV1 (this camera)
Traditional Two-Camera Install
Heads / Mounts
One housing, one mount, one cable
Two housings, two mounts, two cable runs
PoE Drops Required
1 × PoE+ (802.3at)
2 × PoE / PoE+ ports
NVR Channels Used
2 (one per sensor on the same IP)
2
Tracking Co-ordination
Native — relay + linkage tracking factory-tuned
VMS-side rules or a separate auto-tracking integration
Active Deterrence
On the PTZ head — strobe + siren + 2-way audio
Usually only on the fixed sensor; PTZ remains silent
Power Budget
25 W peak — one budgeted port
2 × budgeted PoE / PoE+ ports
Install Time
Half a day for one tradesperson
Effectively two camera installs and alignments
Outdoor Rating
IP66 · TVS 6000 V · –40 °C to +65 °C
Depends on each camera choice — often weaker
Best For
Carparks, school grounds, freight yards, depots, transport, mines, council reserves
Constrained-budget retrofits where two existing cameras are already cabled
Recommended NVR Pairings
A panoramic PTZ uses two NVR channels and benefits from full AcuPick attribute search on recorded footage. Below are four CCTV Guru-stocked Dahua AI NVRs that suit the deployments where this camera makes sense.
Dahua DHI-NVR5216-16P-AI/ANZ
5-Series AcuPick NVR · 16 channels · 16 PoE+ ports (1–8 ePoE) · 2 HDD bays · 1U · 384 Mbps incoming. The most common pairing — runs the PTZ on PoE+ plus 13 other fixed cameras around the site.
View Dahua NVR5216-16P-AI →
Dahua DHI-NVR5432-AI/ANZ
5-Series AcuPick NVR · 32 channels · 4 HDD bays · dual GbE NICs · dual HDMI + dual VGA · 1.5U. Enterprise-scale AcuPick across the entire estate — for sites running multiple X-Spans heads alongside fixed cameras.
View Dahua NVR5432-AI →
Dahua DHI-NVR5208-8P-AI/ANZ
5-Series AcuPick NVR · 8 channels · 8 built-in PoE ports · 2 HDD bays · 1U. Sized for a single-PTZ deployment alongside 4–6 fixed cameras — small business and high-end residential.
View Dahua NVR5208-8P-AI →
Dahua DHI-NVR4216-16P-AI/ANZ
4-Series WizSense AI NVR · 16 channels · 16 PoE ports · 2 HDD bays · 4K HDMI · Smart 2.0 AI. The value-pick 16-channel build for sites that don't need full 5-Series AcuPick attribute search.
View Dahua NVR4216-16P-AI →
Compatible Mounts & Accessories
PFA150 — Pole Mount
Included in the box. Mounts the camera to 60 – 110 mm diameter poles — light poles, fence posts, perimeter pylons. The default outdoor option for carpark and yard deployments.
PFB305W — Wall Mount
Heavy-duty wall mount bracket sized for the X-Spans housing. Use for façade, brick, render and tilt-slab walls. Pairs with the PFA126 or PFA114 adapters for awkward mounting geometries.
PFB303S — Parapet Mount
Mounts the camera over the edge of a parapet wall — common on flat-roof commercial buildings and warehouse roof-edges where there's no vertical wall to mount against.
PFB301S-E — Plane Mount
Flat-surface plane mount bracket. Use for soffit, overhang or eave installs where the camera needs to hang from a horizontal surface.
PFB300C / PFB301C — Ceiling Mount
Two ceiling-mount options for indoor or covered-area installs — entry lobbies, depot canopies, undercover loading bays.
PFA151 — Corner Mount · DC12V/3A — Power Adapter
PFA151 mounts the camera to an external building corner. The DC12V/3A adapter is the genuine Dahua local-power option when running on 12 VDC instead of PoE+.
Frequently Asked Questions
How many NVR channels does this camera use?
Two. The overview channel and the detail channel each present as a separate IP video stream, so they consume two channels on the NVR. Use a 16-channel NVR if you want this camera plus 12–14 other fixed cameras on the same recorder.
Is this a TiOC camera?
Yes — the APV1 suffix is the TiOC active-deterrence indicator on X-Spans cameras (equivalent to "PV" on bullet and turret SKUs). The PTZ head includes red/blue strobe, 11 sound alarms with custom-sound upload, and a built-in speaker.
Does it support AcuPick?
Yes — AcuPick is supported on the overview channel. For full attribute search across recorded footage, pair with a Dahua 5-Series AcuPick NVR (NVR5208-8P-AI/ANZ, NVR5216-16P-AI/ANZ or NVR5432-AI/ANZ).
What power does it need?
PoE+ (IEEE 802.3at), not standard 802.3af, or 12 VDC at 3 A. Maximum draw is 25 W with illuminator, heater, active deterrence, ICR and PTZ all active. A standard 802.3af PoE switch will not run this camera.
How far can the PTZ see at night?
The PTZ channel has 100 m IR and 50 m warm-light reach, plus Starlight low-light at 0.0005 lux B/W. DORI identify distance at the 125 mm tele setting is 250 m — enough to recognise people and read clothing across a large carpark or yard.
What's the warranty in Australia?
3 years, supplied through CCTV Guru as an authorised Australian Dahua reseller. We handle warranty claims locally — no overseas shipping required.
Can the camera follow a target automatically?
Yes — Smart Tracking runs in three modes. WizTracking does AI-driven human/vehicle following. Relay tracking (X-Spans exclusive) keeps tracking after a target leaves the overview's 180° field. Linkage tracking restricts following to targets currently visible in the overview.
Does it have a built-in speaker?
Yes — built-in speaker for active-deterrence audio playback. Note: the speaker and the line-out audio output are mutually exclusive — use one or the other, not both simultaneously. NDIS, retail and public-space sites should check local audio-recording legislation before enabling sound recording on the audio input.
What temperature range is it rated for?
–40 °C to +65 °C. Built-in heating glass keeps the optics clear at low temperatures. Suitable for Alpine, desert, coastal and mining-site Australian deployments.
Does it work with third-party NVRs?
Yes — ONVIF Profile S, G and T are supported, so the camera will record to any ONVIF-compatible third-party NVR. AcuPick attribute search and Xinghan AI events only push end-to-end on a genuine Dahua AI NVR.
Do you ship Australia-wide?
Yes. Stock orders placed before 3 pm AEST ship the same business day from our Australian warehouse, with tracked delivery to all metro and regional addresses Australia-wide.
Downloads
DH-SDT4E425-8P-GB-APV1 Datasheet
Dahua PTZ Camera Quick Start Guide
Dahua PTZ Camera Installation Guide
Dahua PTZ Camera Operational Manual
Order Your Dahua SDT4E425-8P-GB-APV1 from CCTV Guru
"Add to cart" to order online, or contact our Australian team for project pricing, multi-PTZ configuration advice, NVR sizing and PoE+ switch compatibility checks. We are authorised Australian Dahua resellers, hold stock locally, and back every X-Spans camera with a 3-year Australian warranty and Australian-based tech support. Phone, email or live chat us through cctvguru.com.au/pages/contact — most enquiries are answered the same business day.
WizSense 3 · 6 MP · Smart Dual Light · AcuPick Ready
Dahua DH-IPC-HFW3667T-ZAS-IL-ANZ — 6 MP Smart Dual Light Motorised Vari-focal Bullet WizSense Network Camera
The Dahua DH-IPC-HFW3667T-ZAS-IL-ANZ is a 6 MP WizSense 3 outdoor bullet IP camera built around a 1/2.7" CMOS sensor delivering 3288 × 1850 at 25/30 fps with Smart H.265+ encoding. A motorised vari-focal 2.7–13.5 mm F1.4 lens covers everything from a 114° wide overview to a tight 32° long-range pull, and Dahua's Smart Dual Light engine combines a 60 m IR illuminator with a 60 m warm-light array so the camera runs in covert IR until a person or vehicle is classified, then flips to full-colour with white light on the target. WDR is rated at a full 120 dB, IP67 sealed, with built-in microphone, 1/1 alarm I/O and 1/1 RCA audio I/O. The WizSense 3 deep-learning chip runs SMD 4.0, perimeter protection (tripwire + intrusion with human/vehicle classification) and edge AcuPick — working with compatible Dahua AcuPick NVRs to search recorded footage by colour, clothing and direction. Dual-power backup accepts 12 VDC or PoE (802.3af, 12.5 W max). Built for Australian properties that need one camera to handle general site surveillance and event-driven evidence capture — driveways, carparks, loading docks, rural sheds, depot perimeters and small business shopfronts. Backed by a 3-year Australian warranty through CCTV Guru.
Optical Zoom
2.7–13.5 mm Motorised
Resolution
6 MP @ 25/30 fps
Smart Dual Light
IR 60 m + Warm 60 m
AI Engine
WizSense 3 + AcuPick
Protection
IP67 · –30 to +60 °C
Power
12 VDC / PoE 802.3af
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why Choose the Dahua HFW3667T-ZAS-IL-ANZ
This is the Dahua bullet most installers reach for when a site needs one camera that does the job of two — a wide-angle scene camera by day and an evidence-grade target camera at night. Below are the six reasons it consistently outperforms generic 6 MP bullets in Australian deployments.
True 6 MP Image, Not Upscaled
The 1/2.7" CMOS captures a native 3288 × 1850 raster — more than double the pixel density of 1080p — so digital zoom into faces, plates and signage stays usable instead of dissolving into a noise field.
One Camera, Two Lighting Modes
Smart Dual Light runs invisibly on 60 m IR until WizSense classifies a person or vehicle, then automatically switches the 60 m warm light on the target — full-colour evidence on demand without permanent light pollution to neighbours.
120 dB WDR for AU Sun
Driveways shaded by colourbond, north-facing entries, glass-fronted shops — the camera's 120 dB true wide dynamic range holds detail in both the bright sky and the dark interior in a single frame, where lesser cameras blow out one side.
Motorised Vari-focal — Adjust from the App
2.7–13.5 mm with motorised zoom and auto-focus means an installer (or you, via DMSS) can re-frame the scene without climbing a ladder again. Detect range: up to 280 m at the tele end.
AcuPick-Ready Edge AI
Paired with a Dahua AcuPick NVR, this camera lets you search hours of recorded video by attributes — "red top, blue trousers, walking east" — and pulls matching clips in seconds, not hours.
Built for Australian Power
Dual-power backup accepts 12 VDC or PoE simultaneously, and the wide-voltage tolerance shrugs off the unstable rural-grid sag that fries cheap cameras. RCM-marked, AS/NZS-compliant, supplied stock from our AU warehouse.
Important Install Note
This camera draws up to 12.5 W on PoE when WDR, warm light and AI are all active. On longer cable runs (over 90 m) and on PoE switches that share power across many ports, plan for an 802.3at-capable switch or a local 12 VDC supply at the camera. The body is metal and IP67-rated — for outdoor mounting in exposed positions we recommend pairing with the DH-PFA130-E water-proof junction box to protect the RJ-45 termination from condensation.
AI & Smart Detection Capabilities
AcuPick Target Search
Deep-learning attribute matching across people and vehicles. Find a target across hours of recorded video by colour, top/bottom clothing, vehicle type and direction — when paired with a compatible Dahua AcuPick NVR.
SMD 4.0 — Smart Motion Detection
Motion alerts triggered only by humans and vehicles. Wind-blown branches, small animals, possums on a fence and shadows are filtered out at the edge — slashing false-alarm volume.
Perimeter Protection (IVS)
Configurable tripwire and intrusion zones with human-and-vehicle classification. Draw a line across a driveway or a polygon around a yard and only get pushed an alert when the right type of target crosses it.
Smart Dual Light Deterrence
When WizSense classifies a person in the warm-light zone, the 60 m white light triggers automatically, leaving subjects in no doubt they have been captured in full colour — a passive deterrent that costs nothing extra in licensing or hardware.
AI SSA — Scene Self-Adaptation
The camera detects environmental conditions like rain, fog, backlight, low light and flicker, and automatically adjusts image parameters to keep the scene clear without an operator touching the settings.
Smart Search & Event Extraction
Pairs with a Smart NVR to refine intelligent search, extract and merge event video. Skip past hours of empty footage and jump straight to the moments where something the AI flagged as relevant happened.
Technical Specifications
Camera & Image Sensor
Model
DH-IPC-HFW3667T-ZAS-IL-ANZ
Form Factor
Bullet (metal casing)
Image Sensor
1/2.7" CMOS
Maximum Resolution
3288 × 1850 (6 MP)
ROM / RAM
256 MB / 1 GB
Scanning System
Progressive
Electronic Shutter
Auto / Manual, 1/3 s – 1/100,000 s
Minimum Illumination
0.007 lux @ F1.4 (Colour) · 0.0007 lux @ F1.4 (B/W) · 0 lux (illuminator on)
S/N Ratio
> 56 dB
WDR
120 dB
Day / Night
Auto (ICR) / Colour / B&W
BLC / HLC
Yes / Yes
Noise Reduction
3D NR
Image Stabilisation
EIS
Region of Interest
Yes (4 areas)
Privacy Masking
8 areas
Lens & Illumination
Lens Type
Motorised vari-focal, motorised zoom & focus
Focal Length
2.7 mm – 13.5 mm
Maximum Aperture
F1.4
Field of View
H: 114° – 32° · V: 58° – 17° · D: 138° – 36°
Close Focus Distance
0.1 m
IR Illumination
Up to 60 m
Warm Light Illumination
Up to 60 m
Illuminator Configuration
4 × multi-core LEDs (IR + warm light)
Smart Dual Light
Yes (target-triggered IR / warm light hand-off)
DORI — Wide (2.7 mm)
Detect 85.3 m · Observe 34.0 m · Recognise 17.1 m · Identify 8.5 m
DORI — Tele (13.5 mm)
Detect 280 m · Observe 112 m · Recognise 56 m · Identify 28 m
Angle Adjustment
Pan 0°–360° · Tilt 0°–90° · Rotation 0°–360°
Intelligence & Video
AI Engine
WizSense 3 Series
IVS — Perimeter Protection
Tripwire, intrusion (with human + vehicle classification)
Smart Motion Detection
SMD 4.0
AcuPick
Yes (with compatible Dahua AcuPick NVR)
AI SSA
Yes (scene self-adaptation)
Smart Search
Yes (paired with Smart NVR)
Video Compression
H.265 · H.264 · H.264H · H.264B · MJPEG (sub stream)
Smart Codec
Smart H.265+ · Smart H.264+
AI Coding
AI H.265 · AI H.264
Stream Capability
3 streams
Main Stream
3288 × 1850 @ 1–25/30 fps
Sub Stream
1920 × 1080 @ 1–25/30 fps
Third Stream
1920 × 1080 @ 1–25/30 fps
Bit Rate Control
VBR · CBR · ABR
Video Bit Rate
H.264 / H.265: 3 kbps – 16,384 kbps
Motion Detection
4 rectangular areas
Audio, Alarm & Network
Built-in Microphone
Yes
Audio Input
1 channel (RCA)
Audio Output
1 channel (RCA)
Audio Compression
G.711a · G.711Mu · PCM · G.726 · G.723
Alarm Input
1 channel — wet contact, 5 mA, 3–5 VDC
Alarm Output
1 channel — wet contact, 300 mA, 12 VDC
Network Port
RJ-45 (10/100 Base-T)
Network Protocols
IPv4 · IPv6 · HTTP · HTTPS · TCP · UDP · ARP · RTP · RTSP · RTCP · RTMP · SMTP · FTP · SFTP · DHCP · DNS · DDNS · QoS · UPnP · NTP · Multicast · ICMP · IGMP · NFS · SAMBA · PPPoE · SNMP · P2P · 802.1x
Interoperability
ONVIF (Profile S, G, T, M) · CGI
Maximum Users
20 (64 Mbps total bandwidth)
Storage
FTP · SFTP · NAS · Micro SD card up to 512 GB
Mobile Client
DMSS (iOS / Android)
Management Software
SmartPSS Lite · DSS · DMSS
Cyber Security
Trusted boot · trusted execution · trusted upgrade · video encryption · firmware encryption · 802.1x · HTTPS · IP/MAC filtering · WSSE · X.509
Recommended Firmware
Dahua V5.x (enables AcuPick, ONVIF 23.12, iSCSI, N+M with compatible NVRs)
Power, Environment & Build
Power Supply
12 VDC / PoE (802.3af)
Power Consumption (Basic)
3.8 W (12 VDC) · 5.3 W (PoE)
Power Consumption (Max.)
9.9 W (12 VDC) · 12.5 W (PoE) with H.265 + WDR + warm light + AI
Dual-Power Backup
Yes (12 VDC and PoE simultaneously supported)
Operating Temperature
–30 °C to +60 °C
Operating Humidity
≤ 95% RH (non-condensing)
Storage Temperature
–40 °C to +60 °C
Protection Rating
IP67
Casing Material
Metal
Product Dimensions
238.5 mm × 90.7 mm × 90.7 mm (L × W × H)
Net Weight
835 g
Gross Weight
1090 g
Certifications
CE-LVD (EN62368-1) · CE-EMC (2014/30/EU) · RCM (AU)
Australian Warranty
3 Years (via CCTV Guru)
How It Compares — HFW3667T-ZAS-IL-ANZ vs HFW3867T-ZAS-IL-ANZ
The closest sibling is the Dahua DH-IPC-HFW3867T-ZAS-IL-ANZ — the 8 MP version of this exact camera. Same WizSense 3 chassis, same motorised-zoom Smart Dual Light approach, same install profile. The decision comes down to whether you want native 8 MP pixel density for plate-grade evidence and pixel-on-target at long range, or whether the 6 MP build's lighter storage footprint and brighter F1.4 aperture suit the site better.
Feature
DH-IPC-HFW3667T-ZAS-IL-ANZ (this camera)
DH-IPC-HFW3867T-ZAS-IL-ANZ (sibling)
Resolution
6 MP (3288 × 1850)
8 MP (3840 × 2160)
Sensor
1/2.7" CMOS
1/1.8" CMOS (larger photo-site)
Lens
2.7–13.5 mm motorised vari-focal · F1.4
2.7–13.5 mm motorised vari-focal · F1.5
AI Engine
WizSense 3
WizSense 3
AcuPick
Yes
Yes
Lighting
Smart Dual Light — IR 60 m + warm 60 m
Smart Dual Light — IR 60 m + warm 50 m
Active Deterrence
Passive — white-light pop-on + alarm relay
Passive — white-light pop-on + alarm relay
WDR
120 dB
120 dB
Audio
Built-in mic + 1/1 RCA audio I/O
Built-in mic + 1/1 RCA audio I/O
Storage Footprint (24/7 H.265)
Lighter — ~25% less than 8 MP at matched bitrate
Heavier — full 4 K main stream
Low-Light Aperture
F1.4 (slightly brighter)
F1.5
IP Rating
IP67
IP67
Best For
Sites that want full-colour evidence on event with a lighter storage budget and the brightest aperture in class
Sites that need maximum pixel-on-target — long driveways, carpark plate capture, large-frame retail and warehouse coverage
Recommended NVR Pairings
For full AcuPick attribute search to work, this camera should be paired with a Dahua 5-Series AI NVR running V5 firmware. Below are four CCTV Guru-stocked recorders that match the most common Australian deployment sizes — from small business through to enterprise.
Dahua DHI-NVR5208-8P-AI/ANZ
5-Series AcuPick NVR · 8 channels · 8 built-in PoE ports · 2 HDD bays · 1U · perimeter protection and SMD Plus. Ideal for residential and small-business sites running 4–8 cameras with full plug-and-play deployment.
View Dahua NVR5208-8P-AI →
Dahua DHI-NVR5216-16P-AI/ANZ
5-Series AcuPick NVR · 16 channels · 16 PoE+ ports (ports 1–8 ePoE) · 2 HDD bays · 1U · 384 Mbps incoming. The most common pairing for medium commercial sites, multi-building yards and busy shopfronts.
View Dahua NVR5216-16P-AI →
Dahua DHI-NVR4216-16P-AI/ANZ
4-Series WizSense AI NVR · 16 channels · 16 PoE ports · 2 HDD bays · 4K HDMI · Smart 2.0 AI with SMD+ and IVS. The value-pick 16-channel build for sites that don't need full AcuPick attribute search.
View Dahua NVR4216-16P-AI →
Dahua DHI-NVR5432-AI/ANZ
5-Series AcuPick NVR · 32 channels · 4 HDD bays · dual GbE NICs · dual HDMI + dual VGA · 1.5U. Enterprise-scale AcuPick across the entire estate — warehouses, schools, multi-tenant strata and large-format retail.
View Dahua NVR5432-AI →
Compatible Mounts & Accessories
DH-PFA130-E
Water-proof junction box. The most popular accessory for this camera — protects the RJ-45 termination from condensation behind outdoor mounts. Strongly recommended for AU coastal and humid installs.
DH-PFA135
Standard junction box for tidy in-wall cable management on rendered or brick walls. Use when no waterproofing of the termination is required.
DH-PFA151
Corner mount bracket — for mounting the camera onto external building corners. Matches the camera's white powder-coat finish.
DH-PFA152-E
Pole mount bracket — fits 60–110 mm diameter poles. Ideal for carpark light poles, perimeter fence posts and rural driveway pylons.
G3416GW
G3/4" water joint — protects the cable gland on outdoor installs with conduit termination. Use with surface-mounted PVC or metal conduit runs.
DH-PFM321D-EN / DH-PFM320D-EN
Genuine Dahua 12 VDC power adapters — 1 A and 2 A options. Use when running the camera on local DC instead of PoE, or as a backup supply alongside PoE.
Frequently Asked Questions
Does this camera include AcuPick?
Yes — AcuPick attribute search is built into the camera's WizSense 3 firmware. To actually search recorded footage by attributes you must record to a compatible Dahua AcuPick NVR running V5 firmware.
Is this a TiOC camera?
No. TiOC SKUs carry the "PV" infix in the model number. This camera is a Smart Dual Light WizSense 3 model — it can illuminate a target on detection but does not have a red/blue strobe or built-in siren. For full TiOC active deterrence, see the HFW3849T1-ZAS-PV-ANZ sibling above.
How far can it see at night?
Smart Dual Light gives 60 m on IR and 60 m on warm light. Identification range (where a face is recognisable) reaches 28 m at the tele end of the zoom under standard conditions.
Can I run this camera on standard PoE?
Yes — it is 802.3af-compliant and pulls a maximum of 12.5 W when warm light, WDR and AI are all active. Any quality 802.3af switch with budget headroom will run it. For long cable runs over 90 m, plan for an 802.3at switch or a local 12 VDC supply.
Does it have a microphone?
Yes, the camera has a built-in microphone, plus 1 × RCA audio in and 1 × RCA audio out for connecting an external mic or speaker. NDIS, retail and bus-stop sites should check local audio-recording legislation before enabling sound recording.
Does it work with third-party NVRs?
Yes — it supports ONVIF Profile S, G, T and M, so it will record to any ONVIF-compatible third-party NVR. Note that AcuPick attribute search and SMD 4.0 alarm push only work end-to-end on a genuine Dahua AI NVR.
Is it certified for the Australian market?
Yes — the ANZ variant is supplied through Dahua's Australian channel with RCM marking, CE-LVD (EN62368-1) and CE-EMC (2014/30/EU) compliance. It is the correct SKU for AU/NZ projects.
Can the camera trigger an external strobe or siren?
Yes. It has a 1-channel alarm output (wet contact, 300 mA, 12 VDC) that can be wired to a 12 V external strobe or siren module. Use IVS perimeter protection or SMD 4.0 events as the trigger source.
Can I view the camera live on my phone?
Yes — the camera works with Dahua's free DMSS app on iOS and Android. Add the device with the QR code on the housing, sign in, and you get live view, two-way audio, motion alerts and recorded-footage playback from anywhere with internet. No subscription required.
Downloads
DH-IPC-HFW3667T-ZAS-IL-ANZ Datasheet
Dahua IP Bullet Camera Quick Start Guide
Dahua IP Bullet Camera Installation Guide
Dahua IP Bullet Camera Operational Manual
Order Your Dahua HFW3667T-ZAS-IL-ANZ from CCTV Guru
"Add to cart" to order online, or contact our Australian team for a bulk quote, project pricing, multi-camera configuration advice or NVR compatibility check. We are authorised Australian Dahua resellers, hold stock locally, and back every camera with a 3-year Australian warranty and Australian-based tech support. Phone, email or live chat us through cctvguru.com.au/pages/contact — most enquiries are answered the same business day.
WizSense + AcuPick · 5-Series · 16-Channel · 16-PoE · 4-HDD · 1.5U
16CH AcuPick NVR
The Dahua DHI-NVR5416-16P-AI/ANZ is a 16-channel 5-Series WizSense AI NVR with AcuPick, 16 built-in PoE+ ports (ports 1–8 ePoE up to 800 m), and a 1.5U chassis with four SATA bays — the perfect middle-ground between the compact 2-HDD 5216-16P and the storage-heavy 8-HDD 5832-16P. Record up to 32 MP per channel, plug 16 cameras straight into the back of the recorder, and scale storage to roughly 64 TB on-board across four 16 TB drives.
This is the official Australia / NZ-market SKU (the AI/ANZ suffix). It's the all-in-one 16-channel option with double the storage of the 5216-16P — same PoE budget, same chassis depth, but room for two extra HDDs and longer retention. Internal 100–240 VAC universal PSU, AS/NZS-compliant kettle cord, and a local 3-year warranty backed by CCTV Guru in Sydney. AcuPick, N+M cluster, iSCSI and ONVIF 23.12 are enabled by Dahua's V5 firmware (current factory ship as of 2025).
16 PoE+ ports + 4-HDD storage — built for upgrades
PoE Ports
16 × · 130 W · 1–8 ePoE 800 m
Storage
4 SATA · up to 64 TB on-board
16 cameras plug straight in
Each Cat6 run carries power and video back to the NVR — no power adaptors at every camera, no separate PoE switch. Full 16-channel PoE coverage with a 130 W total budget — comfortable for typical Dahua WizSense bullets and turrets at 7–9 W each.
ePoE on ports 1–8 (800 m)
Extended PoE on the first 8 ports — 100 Mbps up to 300 m, or 10 Mbps up to 800 m on Cat6. Eliminates intermediate switches and fibre runs on long perimeter or carpark cable runs.
4 SATA bays · 64 TB max
Twice the storage of the smaller 5216-16P. Four surveillance-grade HDDs (WD Purple, Seagate SkyHawk) up to 16 TB each — roughly 90–120 days of 16-channel motion-record at 4 MP H.265+.
Powers PoE+ cameras
25.5 W per port (PoE+ / 802.3at) — handles IR-heavy bullets, mini PTZs, multi-sensor cameras and active-deterrence units that exceed the basic 15 W PoE ceiling. Plan for ~8 W average per camera across the 16 ports.
AcuPick on up to 16 channels — full-licence search
AcuPick Channels
Up to 16 ch · 1 event / channel / sec
Search Method
Image + attribute · front + back AI
Search by reference image
Click any person or vehicle in recorded video, hit AcuPick, and the NVR scans all 16 channels for matches across hours, days or weeks — clothing colour, body shape, vehicle make / model / colour / direction included.
Front- + back-end intelligence
Camera-side AI extracts target attributes during recording; NVR-side AI runs the comparison. Higher accuracy than recorder-only search and orders of magnitude faster than human review.
Investigations finish in minutes
Find a suspect across 16 channels and weeks of footage in a single search. Particularly valuable for retail loss prevention, school investigations and insurance disputes.
Beyond Quick Pick
AcuPick is the next generation of Dahua's Quick Pick — more attributes, more accuracy, and supports both people and vehicles natively. Exclusive to the 5-Series WizSense NVR family.
5-Series WizSense AI — full feature set
Industrial AI Chip
Independent deep-learning processor
Face Database
20 databases · 20,000 images
Face Recognition (16-ch image stream)
16 channels of camera-side face detection feeding NVR-side recognition at 16 face snapshots/sec — full licence coverage. Twenty face databases, 20,000 images, full attribute filtering (gender, age, mask, glasses).
Perimeter Protection (4 ch by NVR)
4 NVR-side channels of tripwire and intrusion analytics (10 IVS rules each), plus 16 channels of camera-side perimeter via WizSense IPCs — human/vehicle classification cuts false alarms from animals, weather and lighting changes.
SMD Plus on 8 channels by NVR
Smart Motion Detection Plus runs a deep-learning second pass on 8 NVR-side channels, plus 16 camera-side channels — classifies targets as person or vehicle so only real events make it to your phone.
ANPR by camera (8 channels)
Pair with Dahua ANPR cameras for 8 channels of licence-plate recognition feeding a 20,000-plate database with blocklist / allowlist control. Ideal for site gates, fleet yards and small carparks.
Video Metadata search
8 channels of camera-side metadata extraction — top colour, bottom colour, hat, bag, umbrella, gender, age, vehicle make / model / colour / plate, helmet wear and more.
N+M cluster failover
Pair multiple 5-Series NVRs in an N+M cluster — backup recorders automatically take over if a primary fails, ensuring zero footage loss for sites where downtime isn't an option.
See AcuPick in action
Dahua AcuPick — Video search technology demonstration
AcuPick — how to configure and search on a Dahua NVR
32 MP recording · dual HDMI · 64 TB on-board storage
Up to 32 MP per channel
True 8K-class input — supports Dahua's highest-resolution cameras, plus 24 MP, 16 MP, 12 MP, 8 MP (4K), 5 MP and 4 MP IP cameras from any ONVIF brand. 384 Mbps total recording bandwidth.
2× HDMI 4K + 2× VGA outputs
Two independent HDMI heads (each up to 4K) with two mirrored VGAs — drive a multi-monitor control room with independent layouts on each screen. Heterogeneous video routing on HDMI1/HDMI2.
16-channel split on main screen
Main monitor supports 1 / 4 / 8 / 9 / 16-split layouts (sub monitor up to 16). Plenty of headroom for the 16-channel licence — every camera on one screen.
4 SATA bays · up to 64 TB
Four surveillance-grade HDDs up to 16 TB each (WD Purple, Seagate SkyHawk) — months of 16-channel recording without touching network storage.
eSATA + iSCSI expansion
External SATA archive port plus iSCSI network-storage support — scale beyond 64 TB without rebuilding the recorder. Hot tier on the 4 on-board bays, archive tier on iSCSI / eSATA.
Smart H.265+ for half the storage
AI-tuned H.265+ encoding cuts bitrate on static background pixels while preserving detail on moving targets — roughly half the storage and bandwidth of standard H.264.
Built for installers, ready for compliance — 16 alarm-in, 12V output
16 alarm-in / 6 alarm-out
Physical terminal block for 16 alarm inputs and 6 alarm outputs — one of the outputs is a 12 V 1 A direct power feed for sirens, strobes or gate solenoids. Wire in PIRs, door sensors, glass-break detectors, panic buttons.
Gigabit network uplink
Single 10/100/1000 Mbps RJ-45 to your managed switch or router for remote viewing, multi-site VMS pulls and NAS backup. Cameras 1–16 power off the built-in PoE; the gigabit uplink handles client traffic.
RS-232 + RS-485
One RS-232 plus one RS-485 (half-duplex) — integrate with POS systems, gate controllers, access control panels, PTZ joysticks or third-party VMS that need legacy serial.
3 × USB (1 × 2.0 + 2 × 3.0)
One front USB 2.0 plus two rear USB 3.0 ports — plug in backup drives, USB mice, keyboards or service tools without juggling cables behind the rack.
ONVIF 23.12 (T / S / G)
Latest ONVIF profile support on V5 firmware — drops into any current VMS, plus native integration for Panasonic, Sony, Axis, Pelco, Arecont, Canon and Samsung as well as Dahua.
DMSS + DSS Pro VMS
Free DMSS mobile app for live view, playback and push notifications. For multi-site enterprise deployments, integrate with Dahua DSS Pro for centralised control of multiple 5-Series NVRs.
NVR5416-16P vs the family — how it compares
The 5416-16P (this model) is the upgraded 16-channel option — same PoE budget and AI features as the 5216-16P but with double the HDD bays and a 1.5U chassis. Choose this when your install needs longer retention or higher-resolution recording but you don't need to jump up to 32 channels. For the most compact build, step down to the 5216-16P; for 32 channels with RAID-protected 8-HDD storage, step up to the 5832-16P.
5-Series 16-PoE Comparison
Specification
NVR5416-16P-AI/ANZ (this model)
NVR5216-16P-AI/ANZ
NVR5832-16P-AI/ANZ
IP channels (licence)
16
16
32
AcuPick channels
Up to 16
Up to 16
Up to 16
Built-in PoE
16 × ports · 130 W · 1-8 ePoE
16 × ports · 130 W · 1-8 ePoE
16 × ports · 150 W · 1-8 ePoE
HDD bays · max storage
4 SATA · ~64 TB
2 SATA · ~32 TB
8 SATA · ~128 TB
Hardware RAID
Disk groups
Disk groups
RAID 0 / 1 / 5 / 6 / 10
Form factor
1.5U · 4.82 kg
1U · 2.66 kg
2U · 6.9 kg
Bandwidth (AI off / on)
384 / 200 Mbps
384 / 200 Mbps
384 / 200 Mbps
Max camera resolution
32 MP
32 MP
32 MP
Face Recognition (NVR)
2 ch · or 16 ch FD-by-cam + FR-by-NVR
2 ch · or 16 ch FD-by-cam + FR-by-NVR
2 ch · or 16 ch FD-by-cam + FR-by-NVR
Face Database
20 DBs · 20,000 images
20 DBs · 20,000 images
20 DBs · 20,000 images
Perimeter (NVR) · SMD Plus (NVR)
4 ch · 8 ch
4 ch · 8 ch
4 ch · 8 ch
ANPR (by camera)
8 channels
8 channels
8 channels
Alarm I/O
16 in / 6 out (incl. 12 V)
4 in / 2 out
16 in / 8 out (incl. 12 V)
RS-485 ports
1 (half-duplex)
1 (half-duplex)
2 (half + full duplex)
USB ports
1 × 2.0 + 2 × 3.0
1 × 2.0 + 1 × 3.0
2 × 2.0 + 2 × 3.0
Network ports
1 × Gigabit
1 × Gigabit
1 × Gigabit
Video outputs
2 × HDMI 4K + 2 × VGA
1 × HDMI 4K + 1 × VGA
2 × HDMI 4K + 2 × VGA
eSATA · iSCSI · N+M (V5 firmware)
Yes / Yes / Yes
No / Yes / Yes
Yes / Yes / Yes
ONVIF (V5 firmware)
23.12 (T / S / G)
22.06 (T / S / G)
23.12 (T / S / G)
Warranty (Australia)
3 years
3 years
3 years
Full Specifications
Model
DHI-NVR5416-16P-AI/ANZ
Series
WizSense · NVR5000-AI/ANZ (Australia / NZ market)
Form factor
1.5U · 4-HDD · rack or desktop · 16 built-in PoE+ ports
IP channels
16 · up to 32 MP per channel
Supported resolutions
32 MP · 24 MP · 16 MP · 12 MP · 8 MP · 5 MP · 4 MP · 1080p · 720p · D1 · CIF · QCIF
Bandwidth (AI off)
384 Mbps incoming / 384 Mbps record / 384 Mbps outgoing
Bandwidth (AI on)
200 Mbps incoming / 200 Mbps record / 200 Mbps outgoing
Decoding (AI off)
2 × 32 MP @ 20 fps · 2 × 24 MP @ 20 fps · 4 × 16 MP @ 30 fps · 5 × 12 MP @ 30 fps · 8 × 8 MP @ 30 fps · 12 × 5 MP @ 30 fps · 16 × 4 MP @ 30 fps
Decoding (AI on)
1 × 32 MP @ 20 fps · 1 × 24 MP @ 20 fps · 2 × 16 MP @ 30 fps · 4 × 12 MP @ 30 fps · 4 × 8 MP @ 30 fps · 8 × 5 MP @ 30 fps · 12 × 4 MP @ 30 fps
Video compression
Smart H.265+ · H.265 · Smart H.264+ · H.264 · MJPEG
Audio compression
G.711a · G.711u · PCM · G.726
AI engine
WizSense (industrial AI chip, deep-learning) · AcuPick supported
AcuPick
Up to 16 channels · 1 combined event per channel/sec (V5 firmware)
Face Detection (NVR)
2 channels · up to 12 face snapshots/sec each
Face Recognition (NVR)
16 ch (FD by camera + FR by recorder, 16 fps) · or 2 ch (FD+FR by recorder, 12 fps)
Face Database
20 databases · 20,000 images · 2.5 GB · gender / age / glasses / expression / mask / beard attributes
Perimeter Protection
4 channels by NVR · 16 channels by camera · 10 IVS rules per channel
SMD Plus
8 channels by NVR · 16 channels by camera
Video Metadata
8 channels (camera-side) · human / motor / non-motor vehicle attributes
ANPR (by camera)
8 channels · 20,000-plate database · blocklist / allowlist
AI by Camera (passthrough)
Face detection · Face recognition · Video metadata · Perimeter protection · SMD Plus · Stereo analysis · Crowd distribution · People counting · ANPR · Vehicle density · Heat map
N+M cluster · iSCSI · eSATA
Yes / Yes / Yes
HDD bays
4 × SATA · up to 16 TB per drive (~64 TB max)
Video output
2 × HDMI (4K · 3840×2160) + 2 × VGA (1080p) · heterogeneous HDMI1/HDMI2 · simultaneous VGA1+HDMI1 / VGA2+HDMI2
Multi-screen display
Main screen: 1 / 4 / 8 / 9 / 16 · Sub screen: 1 / 4 / 8 / 9 / 16
Audio I/O
1 × RCA in · 2 × RCA out
Alarm I/O
16 × alarm in · 6 × alarm out (1 × 12 V 1 A power output)
USB
3 ports: 1 × front USB 2.0 + 2 × rear USB 3.0
Network port
1 × RJ-45 Gigabit Ethernet (10 / 100 / 1000 Mbps)
PoE
16 × ports · 10/100 Mbps · IEEE 802.3af/at · 130 W total · 25.5 W per port (max) · ports 1-8 support ePoE (800 m / 100 Mbps to 300 m, 10 Mbps to 800 m)
RS-232 / RS-485
1 RS-232 · 1 RS-485 (half-duplex)
eSATA
1 port (external archive)
Network protocols
HTTP / HTTPS · TCP/IP · IPv4/IPv6 · RTSP · UDP · SNMP · NTP · DHCP · DNS · SMTP · UPnP · IP Filter · PPPoE · FTP · DDNS · Alarm Server · Multicast · P2P · Auto Registration · iSCSI
ONVIF
23.12 on V5 firmware (Profile T / S / G) · CGI · SDK
Third-party camera support
ONVIF · Panasonic · Sony · Axis · Arecont · Pelco · Canon · Samsung
Mobile app
DMSS (iOS / Android)
Record modes
General · motion detection · intelligent · alarm · POS
Backup
USB device · network
Power supply
100 – 240 VAC · 50 – 60 Hz (internal universal-voltage PSU)
Power consumption
≤ 13 W NVR-side (without HDD) · PoE total 130 W
Operating temperature
−10 °C to +55 °C
Operating humidity
10% – 93% RH
Dimensions
440 × 415.6 × 76 mm (1.5U)
Net weight
4.82 kg
Installation
Rack or desktop
Recommended firmware
DH_NVR5XXX-EI_MultiLang V5.001.0000000.0.R.251220 (or later) — required for AcuPick, N+M cluster, iSCSI and ONVIF 23.12
Certifications
FCC Part 15 Subpart B Class A · CE-EMC · CE-LVD · Security Baseline 2.3
Warranty
3 years (CCTV Guru Australia)
Downloads & documentation
Download official Dahua documents for setup, specifications, and recorder details.
DHI-NVR5416-16P-AI/ANZ Datasheet
Dahua NVR Quick Start Guide
Dahua NVR User Manual
Frequently asked questions
What's the real benefit over the smaller NVR5216-16P?
Same 16 channels and same 16 PoE+ ports — but the 5416-16P (this model) doubles the HDD bays from 2 to 4, doubles your on-board storage ceiling (~64 TB vs ~32 TB), upgrades video output from single HDMI/VGA to dual HDMI/VGA, and adds 16 alarm inputs / 6 alarm outputs (vs 4 / 2) plus eSATA. Choose this when you want longer retention or hardware alarm integration on your 16-channel build.
What does ePoE on ports 1–8 give me?
Extended PoE — long-distance Cat6 runs at reduced speed. Ports 1–8 support 100 Mbps up to 300 m or 10 Mbps up to 800 m (most IP cameras work fine at 10 Mbps for sub-stream + main-stream H.265+). Eliminates intermediate switches on long perimeter or carpark runs. Ports 9–16 run standard PoE+ at up to 100 m.
Does this NVR really support AcuPick?
Yes. Dahua's V5 firmware (binary DH_NVR5XXX-EI_MultiLang_V5.001.0000000.0.R.251220 or later) enables AcuPick on the AI/ANZ unit alongside N+M cluster, iSCSI and ONVIF 23.12. The firmware is published on Dahua AU's official product page and ships from CCTV Guru with V5 installed.
How much storage do I need for 16 cameras?
For 16 × 4 MP cameras at H.265+ on motion-record, expect ~12–18 TB for 30 days of retention. Four 6–8 TB surveillance-grade drives (WD Purple, Seagate SkyHawk) gives you ~24–32 TB on-board — roughly 60–90 days. For longer retention or higher resolution, fit 16 TB drives (the maximum supported) for up to 64 TB total.
How does the 16 PoE budget cover 16 cameras?
130 W total ÷ 16 cameras = ~8 W average per camera. That's comfortable for most Dahua WizSense bullets and turrets (5–9 W each). If you're running PTZ, IR-heavy bullets or active-deterrence units (15–25 W each), plan to mix in some lower-draw cameras or use an external PoE injector for the high-power ones.
Can it be rack-mounted?
Yes — 1.5U / 440 mm wide fits a standard 19-inch rack with ears (rack ears sold separately). At 4.82 kg empty (without HDDs), plan for ~8–10 kg fully loaded with four drives.
What's the 12 V alarm output for?
One of the 6 alarm outputs is a direct 12 V 1 A power feed — drive a siren, strobe light or electric strike directly without needing an external relay or power supply. The other 5 outputs are dry-contact relays you can wire to anything that takes a NO/NC trigger.
3-Year Warranty
Australia-Wide Shipping
Australian Tech Support
WizSense AI · Penta-brid · 4-Channel
The Dahua DH-XVR5104HS-I3-S3 is a 4-channel Penta-brid HDCVI recorder that handles five video signals on one box — HDCVI, AHD, TVI, CVBS analog, plus IP. Drop it in to replace an old DVR using the existing coax runs, or expand it later by converting analog channels to IP for up to 6 IP cameras at 6 MP. It records at up to 5 MP HDCVI per channel, supports Smart H.265+ for roughly half the storage of H.264, and ships with Dahua's WizSense AI chip for deep-learning human and vehicle filtering.
Designed for small retail, workshops, residences and offices, the XVR5104HS-I3-S3 fits a compact 1U desktop chassis with one SATA bay (up to 16 TB), HDMI + VGA simultaneous outputs, and free remote viewing through the DMSS mobile app. Backed by a 3-year warranty and Australian tech support from CCTV Guru.
Penta-brid — five signal types, one recorder
Signal Types
HDCVI · AHD · TVI · CVBS · IP
Channel Capacity
4 Analog BNC + up to 6 IP
4 analog BNC inputs
Auto-detect HDCVI, AHD, TVI and CVBS signals on every channel. Plug in any mix — the XVR figures out the format for you.
+ up to 6 IP cameras
Two IP channels by default, plus four more when analog channels are converted to IP. Mix and match analog and IP up to six cameras total.
5 MP HDCVI recording
Full 5 MP @ 25 fps on HDCVI, 4 MP @ 30 fps, or 1080p @ 30 fps — far sharper than legacy 720p / 960H DVRs using the same coax cable.
Coaxial audio on all 4 channels
Carries audio over the same BNC coax — no extra audio cable, no extra RCA runs. Rare at this price point.
WizSense AI — deep-learning detection, fewer false alarms
Dedicated AI Chip
Independent deep-learning processor
Targeted Alerts
Filters out leaves, rain, shadows & lighting
SMD Plus on all 4 channels
Smart Motion Detection Plus runs a second AI pass on every motion event, classifying targets as person or vehicle and discarding false alarms from weather and lighting.
Perimeter Protection
Up to 4 channels of tripwire and intrusion analytics (10 IVS rules per channel) with human/vehicle secondary recognition to suppress nuisance triggers.
Face Detection & Recognition
One channel of face detection (up to 8 face snapshots/sec) and one channel of face recognition with up to 10 face databases and 10,000 stored images.
QuickPick 2.0 search
Find similar targets across recorded footage in seconds — paste a person or vehicle still and QuickPick scans the timeline for matches.
AI Video Quality analytics
Continuously checks all 4 channels for brightness, colour cast, defocus, overexposure and contrast issues — alerts you the moment a camera drifts out of spec.
AI Coding (Smart H.265+)
Smart H.265+ encoding cuts storage and bandwidth by up to 50% versus H.264 by lowering the bitrate on static background pixels and keeping detail on moving targets.
See WizSense in action
Dahua AI XVR — Full Channel SMD Plus demo
WizSense 101 — Dahua's deep-learning AI explained
Built for installers, simple for end-users
1 SATA bay · up to 16 TB
Drop in one surveillance-grade HDD (WD Purple or Seagate SkyHawk recommended) for weeks of continuous 5 MP recording.
HDMI + VGA simultaneous
Drive a wall-mounted spot monitor on HDMI while the on-site PC stays on VGA — both run independently at up to 1080p.
Two-way audio
1× RCA audio in (shared with Ch. 1) and 1× RCA audio out, plus 4-channel coaxial audio over the BNC inputs for talk-back at the gate or counter.
DMSS mobile app
Free iOS and Android viewing app — live view, playback, push notifications and P2P remote access without a static IP or port forwarding.
ONVIF 24.06 (T/S/G)
Integrates with third-party IP cameras and VMS platforms — Panasonic, Sony, Hanwha, Axis, Arecont and any ONVIF-compliant device.
Compact 1U desktop
260 × 237.8 × 47.6 mm, just 0.84 kg — sits neatly on a shelf, in a cabinet or under a desk. 12 VDC PSU included.
Full Specifications
Model
DH-XVR5104HS-I3-S3
Series
WizSense · 5MP Value / 1080p · Penta-brid
Analog channels
4 × BNC — HDCVI / AHD / TVI / CVBS auto-detect
IP channels
Up to 6 (2 by default + 4 from converted analog) · up to 6 MP each
Max HDCVI resolution
5 MP @ 25 fps · 4 MP @ 30 fps · 1080p @ 30 fps
Max TVI / AHD
5 MP @ 20 fps · 4 MP @ 30 fps · 1080p @ 30 fps
Bandwidth
32 Mbps incoming / 32 Mbps record / 32 Mbps outgoing
Video compression
AI Coding · Smart H.265+ / H.265 · Smart H.264+ / H.264
Audio compression
G.711a · G.711u · PCM
AI engine
WizSense (independent AI chip, deep-learning)
SMD Plus
4 channels (human / vehicle classification)
Perimeter Protection
General Mode: 4 ch · Advanced Mode: 2 ch · 10 IVS rules per channel
Face Detection
1 channel · up to 8 face images/sec
Face Recognition
1 channel · 10 face databases · 10,000 images total · 6 attributes
QuickPick 2.0
1 channel (similar-target search)
AI Video Quality Analytics
4 channels (brightness, focus, exposure, contrast, colour cast)
HDD bays
1 × SATA · up to 16 TB
Video output
1 × HDMI + 1 × VGA · simultaneous · max 1920 × 1080
Multi-screen display
1 / 4 (1 / 4 / 6 with IP extension)
Audio I/O
1 × RCA in (shared with Ch. 1) · 1 × RCA out · 4-ch coaxial audio over BNC
Two-way talk
Yes · shares Ch. 1 audio input
USB
2 × USB 2.0 (1 front · 1 rear)
Network
1 × RJ-45 10 / 100 Mbps Ethernet
Protocols
TCP/IP · IPv4 · IPv6 · HTTP / HTTPS · RTSP · UDP · NTP · DHCP · DNS · SMTP · UPnP · IP Filter · FTP · DDNS · SNMP · Alarm Server · P2P · ONVIF 24.06 (Profile T / S / G)
Third-party support
Panasonic · Sony · Hanwha · Axis · Arecont · ONVIF
Record modes
General · alarm · motion detection · intelligent · POS
Backup
USB device · network
Mobile app
DMSS (iOS / Android)
RS-485
1 port
Power supply
12 VDC · 1.5 A (adaptor included)
Power consumption
< 5 W (without HDD)
Operating temperature
−10 °C to +55 °C
Operating humidity
10% – 90% RH (non-condensing)
Dimensions
260.0 × 237.8 × 47.6 mm (Compact 1U)
Net weight
0.84 kg
Certifications
CE-LVD · CE-EMC
Warranty
3 years (CCTV Guru Australia)
Downloads & documentation
Download official Dahua documents for setup, specifications, and recorder details.
DH-XVR5104HS-I3-S3 Datasheet
Dahua XVR Quick Start Guide
Dahua XVR User Manual
Compact & Mini HDD Installation Guide
DMSS Mobile App (iOS / Android)
Frequently asked questions
Will this XVR work with my old analog CCTV cameras?
Yes. Penta-brid means every BNC input auto-detects HDCVI, AHD, TVI and CVBS — so any analog camera using one of those four standards plugs straight in. You don't need to know which format your cameras use; the XVR figures it out.
Can I add IP cameras to it?
Yes — 2 IP channels are available by default, and up to 4 more analog channels can be converted to IP, for a maximum of 6 IP cameras at up to 6 MP each. Note: when IP extension is enabled, the WizSense AI functions are not available on those converted channels.
Does it power my cameras (PoE)?
No. The XVR5104HS-I3-S3 is a HDCVI recorder, not a PoE NVR — your analog and IP cameras each need their own 12 VDC power supply or PoE injector. For a PoE-powered solution, look at the Dahua WizSense NVR4108-P-AI/H series.
What hard drive should I use?
Use a surveillance-rated SATA HDD — Western Digital Purple or Seagate SkyHawk up to 16 TB. Standard desktop drives are not rated for 24/7 recording and will fail prematurely. CCTV Guru stocks compatible drives if you need one bundled.
How do I view it remotely on my phone?
Install the free DMSS app on iOS or Android, scan the QR code on the XVR's local menu, and you'll have live view, playback, push notifications and two-way audio without configuring port forwarding or a static IP.
Does it run hot enough to need a fan or rack?
No — under 5 W idle (without HDD) and a compact 1U desktop chassis. It runs cool on a shelf or in a cabinet. Operating range is −10 °C to +55 °C.
Is the 3-year warranty backed locally?
Yes — CCTV Guru honours a 3-year warranty in Australia, with local tech support and replacement stock held in Sydney. No overseas RMAs, no shipping back to the manufacturer.
3-Year Warranty
Australia-Wide Shipping
Australian Tech Support
Dahua · DHI-ART-ARC3800H-06-FW2 · Wireless Alarm Kit · WiFi + 4G LTEWireless Alarm KitDahua DHI-ART-ARC3800H-06-FW2 Wireless Alarm Kit
The Dahua DHI-ART-ARC3800H-06-FW2 is a complete wireless alarm kit for Australian homes, offices, retail stores and commercial sites. Built around the ARC3800H-FW2 alarm hub, it bundles three wireless PIR motion detectors, a keyfob, an indoor siren and an IP65 outdoor siren — all managed from the DMSS app with WiFi, Ethernet and 4G LTE communication paths for resilient connectivity.
Connectivity
WiFi · LAN · 4G
Encryption
AES128
Wireless Band
433MHz
Sirens
Indoor + Outdoor
Control
DMSS App
Expandable
150 Devices
Triple-Path Communication
Ethernet, WiFi and 4G LTE work together so the alarm stays connected even if one network path drops out.
Indoor + Outdoor Sirens
An indoor siren alerts occupants while the IP65-rated outdoor siren adds strong external deterrence and visibility.
App Control via DMSS
Arm, disarm, monitor events and manage every device remotely through the Dahua DMSS mobile app.
Expandable Platform
The ARC3800H-FW2 hub supports up to 150 wireless peripherals — add PIRs, keypads, repeaters, sirens and keyfobs as you grow.
Specifications — DHI-ART-ARC3800H-06-FW2
Kit Model
DHI-ART-ARC3800H-06-FW2
Alarm Hub
ARC3800H-FW2
Included Devices
1× hub, 1× keyfob (ARA24-W2), 3× PIR (ARD1233-W2), 1× indoor siren (ARA12-W2), 1× outdoor siren (ARA13-W2)
Network
Ethernet (RJ45) · WiFi · 4G LTE
SIM Support
Dual SIM, single standby
Wireless Frequency
433.1MHz – 434.6MHz, two-way RF
Encryption
AES128, with frequency hopping
Wireless Peripherals
Up to 150 devices
Video Verification
8-channel IPC alarm video upload
Notifications
App push, SMS & phone call (up to 5 numbers)
Hub Backup Battery
4,750mAh lithium · up to 12h standby
Outdoor Siren Rating
IP65
Operating Temperature
-10°C to +55°C (indoor devices)
Certifications
CE, RCM
Warranty (Australia)
3 years · CCTV Guru Australia
Downloads & Resources
DHI-ART-ARC3800H-06-FW2 DatasheetDahua Alarm Hub User Manual
Does this kit support 4G backup?Yes. The ARC3800H-FW2 hub supports Ethernet, WiFi and 4G LTE, so the alarm can stay online if one path fails.
Does it include both indoor and outdoor sirens?Yes — one indoor siren and one IP65-rated outdoor siren are included.
How many devices can the system support?The hub supports up to 150 wireless peripherals including PIRs, keyfobs, sirens, keypads and repeaters.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · DHI-ARD333-W2(915S) · Wireless Door Detector · 915MHz
Door Detector
Dahua DHI-ARD333-W2(915S) Wireless Door Detector
The Dahua DHI-ARD333-W2(915S) is a wireless reed-switch door detector that triggers an alarm when an armed non-metal door or window is opened. It uses encrypted two-way RF on the 915MHz band with frequency hopping for stable communication up to 1,400m in open space. The detector pairs with Dahua wireless alarm hubs (ARC series) and is armed, monitored and managed in the DMSS app.
Specifications — DHI-ARD333-W2(915S)
Type
Wireless reed-switch door/window detector
Frequency
915.0MHz–928.0MHz
Communication
Two-way RF, frequency hopping, AES128 encryption
Range
Up to 1,400m in open space
Scenario
Non-metal doors and windows (gap < 40mm)
Temperature Monitoring
-15°C to +65°C indoor
Battery
1 × CR123A, up to 4.1 years (Dahua test conditions)
Mounting
Wall mount (101 × 21 × 22.2mm)
Compatibility
Dahua ARC wireless alarm hubs · DMSS app
Warranty (Australia)
3 years · CCTV Guru Australia
DHI-ARD333-W2(915S) Datasheet
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · DHI-ARM7012-W2 · Wireless WallSwitch · 13A 240VWireless WallSwitchDahua DHI-ARM7012-W2 Wireless WallSwitch Smart Relay
The Dahua DHI-ARM7012-W2 Wireless WallSwitch is a compact smart power switch for compatible Dahua wireless alarm systems. It remotely controls 100–240VAC power through a built-in 13A relay while monitoring voltage, current and energy consumption — with AES128-encrypted, two-way RF communication up to 800m. Built-in overvoltage, overload and overheating protection make it a safe, installer-friendly automation accessory.
Specifications — DHI-ARM7012-W2
Model
DHI-ARM7012-W2
Type
Dahua Wireless WallSwitch (smart relay)
Relay Output
1 × NO/NC, 100–240VAC, max 13A
Power Supply
100–240VAC, 50/60Hz
Carrier Frequency
433.1MHz – 434.6MHz
Communication
Two-way wireless RF
Wireless Distance
Up to 800m in open areas
Encryption
AES128, with frequency hopping
Jamming Detection
Supported
Protection
Overvoltage, overload & overheating
Monitoring
Voltage, current & energy consumption
Operating Temperature
-10°C to +55°C (indoor)
Dimensions
39 × 33 × 19 mm
Installation
Wall mount
Certification
CE
Warranty (Australia)
3 years · CCTV Guru Australia
Downloads & Resources
DHI-ARM7012-W2 Datasheet
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · DHI-ARA43-W2 · Wireless Alarm Repeater · Up to 1000mAlarm RepeaterDahua DHI-ARA43-W2 Wireless Alarm Repeater
The Dahua DHI-ARA43-W2 extends the communication range between your Dahua wireless alarm hub and its accessories — ideal for larger homes, multi-level properties, detached garages, shops and offices where distance and walls weaken the wireless link. It supports up to 32 peripherals, reaches up to 1000m in open space, uses AES128-encrypted two-way RF, and includes a built-in lithium battery good for over 35 hours of standby.
Specifications — DHI-ARA43-W2
Model
DHI-ARA43-W2
Type
Wireless Alarm Repeater
Wireless Zone
32 × wireless peripherals
Pairing Mode
Auto / Manual
Communication
Two-way RF communication
Carrier Frequency
433.1MHz – 434.6MHz
Communication Distance
Up to 1000m in open space
Encryption
AES128, with frequency hopping
Tamper / Low-Battery Alarm
Yes
External Power Loss Detection
Yes
Power Supply
12VDC, 1.5A
Backup Battery
Built-in lithium · 35h standby
Operating Environment
-10°C to +55°C (indoor), 10–90% RH
Dimensions
163 × 163 × 32 mm
Installation
Wall mount / Desktop
Certification
CE
Warranty (Australia)
3 years · CCTV Guru Australia
Downloads & Resources
DHI-ARA43-W2 Datasheet
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision Ultra Series · 6A PTZ · 4MP · 36× Optical Zoom · DarkFighter 2.0 · 150 dB AWDR · NEMA 4X
Hikvision DS-2DF6A436XG1-EL(Y) — 4MP 36× DarkFighter 2.0 Network Speed Dome PTZ (NEMA 4X Anti-Corrosion)
The Hikvision DS-2DF6A436XG1-EL(Y) is Hikvision's flagship 6A Ultra-Series PTZ speed dome — a 4MP outdoor pan/tilt/zoom camera built around a 1/1.8" progressive-scan CMOS sensor, a 36× optical zoom motorised lens (6–216 mm, F1.2), DarkFighter 2.0 ultra-low-light technology and 150 dB AWDR. The -Y suffix on this Australian-stocked SKU denotes Hikvision's moderate anti-corrosion housing — NEMA 4X-rated for coastal Australian sites within roughly 2 km of the shoreline and for areas affected by acid rain. The base DS-2DF6A436XG1-EL (no -Y) ships with no specific corrosion protection; we stock the -Y variant by default.
This is a true long-range surveillance PTZ: the 36× zoom paired with the 1/1.8" DarkFighter 2.0 sensor identifies a target at 297.9 m at full telephoto under EN 62676-4 criteria, and detects a vehicle-sized object out to 2,979 m. On-camera deep-learning AI drives perimeter protection (line crossing, region entry / exit, intrusion), multi-target-type detection (simultaneous human / face / vehicle with feature extraction), face capture for up to 30 simultaneous faces, face comparison across 10 face libraries with 150,000 total faces, and Smart Tracking 3.0 auto-tracking with armed-person and armed-vehicle modes. Built-in gyroscope EIS, heater + demist, lightning surge protection, TPM 2.0 (FIPS 140-2 Level 2) hardware-rooted cyber security, and IP67 + IK10 outdoor rating. Australian stock, 3-year Australian warranty.
Optical Zoom
36× · 6–216 mm · F1.2
Resolution
4MP · 2688 × 1520 · up to 120 fps
Low Light
DarkFighter 2.0 · 0.0003 lux
AI Engine
Auto-Tracking 3.0 · Face Capture
Protection
IP67 · IK10 · NEMA 4X (-Y)
Power
Hi-PoE · 36 VDC · 45 W
3-Year Australian Warranty
Fast Australia-Wide Shipping
Australian Tech Support
Why Choose the DS-2DF6A436XG1-EL(Y)
A long-zoom PTZ has one job no fixed camera can do: follow the action. The 36× motorised optical zoom on a 1/1.8" DarkFighter 2.0 sensor combines reach (identify at ~300 m, detect to ~3 km), low-light competence (clear colour image at 0.0003 lux) and on-camera deep-learning AI that drives the camera to lock onto and follow a target the moment perimeter or face-detection triggers. For Australian sites where one camera has to cover a large area — port aprons, mining haul roads, council carparks, freight yards, marina entrances, school perimeters, large industrial campuses, lot-line residential acreage — the 6A PTZ is the single-asset that replaces a fleet of fixed cameras.
36× Optical Zoom — Identify at 297.9 m
The 6–216 mm motorised lens with maximum F1.2 aperture identifies a target at telephoto out to 297.9 m (EN 62676-4 Identify), recognises at 595.9 m, and detects out to 2,979 m. One pole, one camera, one cable run — covering the area a small fleet of fixed bullets used to cover.
DarkFighter 2.0 — Ultra-Low-Light Colour
Hikvision's second-generation DarkFighter pulls a clean colour image at 0.0003 lux @ F1.2 and monochrome at 0.0001 lux. That's enough sensitivity to keep colour information in scenes lit only by streetlight, after-hours dock lighting or moonlight — no external IR illuminator is needed for most ambient-lit Australian sites.
150 dB AWDR — Handles Australian Glare
Class-leading 150 dB true wide dynamic range manages the worst Australian lighting transitions — low sun at the gate at 5 pm, headlights at a boomgate entry, shadow lines across a covered apron, water glare at a marina — without losing detail in either highlights or shadows.
Smart Tracking 3.0 + Auto-Tracking
When perimeter AI detects a human or vehicle, Smart Tracking 3.0 automatically pans, tilts and zooms the camera to keep the target framed, recording the full pursuit. Armed-person and armed-vehicle modes let security teams flag specific targets that, when seen, trigger alarms + tracking + capture upload.
Face Capture — 30 Simultaneous, 150,000 Library
The on-camera face engine detects, tracks and grades up to 30 simultaneous faces, uploads the best frame plus context, and supports 10 face libraries × 30,000 faces each (150,000 total) with encrypted library storage — enterprise-scale watchlist and known-visitor recognition without an external face server.
NEMA 4X Anti-Corrosion (-Y Variant)
The -Y suffix indicates Hikvision's moderate anti-corrosion housing — NEMA 4X for coastal Australian sites within ~2 km of the shoreline and areas exposed to acid rain. Combined with IP67 + IK10 + lightning surge protection (±6 kV line-to-ground), the camera is engineered for the Australian outdoor environment.
Pan / Tilt / Zoom — Industrial-Grade Movement
360° Continuous Pan · 300°/s
Continuous 360° pan with a preset speed of 300°/s — the camera can swing from one preset target to a diagonally-opposite preset in a fraction of a second. Configurable pan speed from 0.1°/s for cinematic patrol to 300°/s for incident response.
Tilt −20° to +90° · Auto-Flip
Tilt range from −20° (below the horizon, useful for tower-mounted overviews of carparks below) to +90° with auto-flip support for tracking a target straight under the dome. Tilt speed 0.1° to 150°/s with 250°/s presets.
300 Presets · 8 Patrols · 4 Pattern Scans
300 presets per camera, 8 patrol routes (up to 32 presets each) and 4 pattern scans (over 10 minutes record each). Schedule the camera to walk a perimeter route automatically every shift change — a guard's eyes that never get tired.
3D Positioning + Power-Off Memory
Click a target on the live image and the camera pans / tilts / zooms to centre and frame it in one motion. Power-off memory means the camera returns to its previous orientation after a brown-out without operator intervention.
Built-in Gyroscope EIS
Built-in gyroscope drives electronic image stabilisation — important for tall pole installs in coastal wind, mining-site tower mounts and any environment where the mount can vibrate. Keeps the image steady for both human review and AI processing.
Heater + Demist · Lightning Surge
Built-in heater + demist function handle Australian morning condensation and overnight dew cycling. Lightning surge protection at ±6 kV line-to-ground / ±3 kV line-to-line (IEC 61000-4-5) protects the camera and the upstream network against typical strike-induced transients.
On-Camera Deep-Learning AI
The 6A PTZ doesn't simply record what crosses its field of view — it understands it. On-camera deep-learning algorithms run continuously, classifying objects and triggering only on the targets that matter.
Perimeter Protection — Filtered Alarms
Line crossing, region entrance, intrusion and region exiting detection — each restricted to human and / or vehicle targets, ignoring the rain, foliage, animals and lights that plague conventional motion detection.
Multi-Target-Type Detection
Simultaneous detection and feature extraction across three target classes: human (14 features), face (7 features) and vehicle (8 features). Feeds rich metadata into your NVR for fast post-incident search.
Face Capture & Comparison
Detects up to 30 faces in frame simultaneously, grades face quality, and uploads the best frame plus a wider context shot. Compare against on-camera face libraries — 10 libraries × 30,000 faces = 150,000 total — with encrypted library storage.
Smart Tracking 3.0 — Auto Follow
The camera locks onto a detected target and pans / tilts / zooms automatically to keep it framed for the full duration of the event. Manual override available at any moment from the iVMS-4200 client or HikCentral.
Object Arming — Person & Vehicle
Arm specific faces or specific vehicles. When the camera detects an armed target in scene, it triggers alarms, tracks the target, and uploads location and identification metadata to the NVR / HikCentral for the security team to action.
Audio & Behaviour Events
Audio exception detection, video tampering, scene change, unattended baggage detection and object removal detection — useful for unmanned dock aprons, school perimeters and after-hours retail loading bays.
Important Install Note — Hi-PoE or 36 VDC
The 6A PTZ does not run on standard PoE+ (802.3at, 25.5 W). The camera body, motor drive, heater and zoom assembly draw up to 45 W on 36 VDC or 40 W on Hi-PoE — outside the 802.3at envelope. Standardise on one of the following:
Hi-PoE (60 W class) injector or switch on the camera's network run — the cleanest install, single cable carries data and power.
36 VDC dedicated supply at the camera — used where you're carrying power separately from the network drop (for example, on a long fibre run where the network side is on SFP).
Both options reserve up to 6 W of the budget for the built-in heater. Hikvision-branded Hi-PoE injectors (DS-1602ZJ-AKS wall mount with PoE midspan compatibility) and third-party Hi-PoE injectors both work — please contact our Australian team for the right injector for your site.
Technical Specifications
DS-2DF6A436XG1-EL(Y) · Full Specifications
SKU
DS-2DF6A436XG1-ELY (AU-stocked default — NEMA 4X anti-corrosion)
Camera Type
Hikvision Ultra Series 6A · 4MP 36× DarkFighter 2.0 Network Speed Dome PTZ
Image Sensor
1/1.8" Progressive Scan CMOS · DarkFighter 2.0
Max Resolution
2688 × 1520 (4MP)
Min. Illumination
Colour 0.0003 lux @ F1.2 (AGC ON) · B/W 0.0001 lux @ F1.2
Shutter Speed
1/1 s to 1/30,000 s · Slow Shutter
Lens
Motorised · 6.0–216 mm · 36× optical · F1.2 max aperture · auto / semi-auto / manual / rapid focus
Digital Zoom
16×
Field of View
Horizontal 56.6° → 1.7° · Vertical 33.7° → 0.9° · Diagonal 63.4° → 1.9°
Zoom Speed
Approx. 4.5 s (wide ↔ tele)
Day & Night
IR cut filter (sensor-side)
Wide Dynamic Range
150 dB AWDR · BLC · HLC · 3D DNR · optical defog
Image Stabilisation
Built-in gyroscope · electronic image stabilisation
Pan Range / Speed
360° continuous · 0.1°–300°/s · preset 300°/s · proportional pan
Tilt Range / Speed
−20° to +90° (auto-flip) · 0.1°–150°/s · preset 250°/s
Presets / Patrols / Patterns
300 presets · 8 patrols (32 presets each) · 4 pattern scans (10+ min each)
Park Action
Preset · pattern scan · patrol scan · auto / tilt / random / frame / panorama scan
3D Positioning
Yes — click-to-frame on live view
Power-Off Memory
Yes — returns to last orientation after power restore
Scheduled Task
Presets · scans · dome reboot · dome adjust · aux output
Frame Rate (Main)
50 Hz: 50 fps @ 4MP / 100 fps @ 1080p · 60 Hz: 60 fps @ 4MP / 120 fps @ 1080p
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG (sub-stream)
Streams
3 simultaneous (main / sub / third)
Video Bit Rate
32 Kbps – 16,384 Kbps · CBR / VBR · SVC · ROI (8 fixed regions per stream)
Deep-Learning AI
Perimeter Protection (line crossing / intrusion / region entry & exit · human + vehicle classification)
Multi-Target Detection
Simultaneous human (14 features) / face (7 features) / vehicle (8 features)
Face Capture
Up to 30 simultaneous faces · grade / select / upload best frame + context
Face Comparison
10 libraries × 30,000 faces = 150,000 total · encrypted face library storage
Smart Tracking
Auto-Tracking 3.0 · manual + automatic · armed-person / armed-vehicle modes
Basic Events
Motion · video tampering · vandal-proof alarm · audio exception · unattended baggage · object removal · exceptions (network down / IP conflict / illegal login / HDD)
Linkage
FTP / NAS / microSD upload · centre notify · email · trigger recording · PTZ actions (preset / patrol / pattern)
Audio
1 line-in (max 2–2.4 Vpp, 1 KΩ ±10%) · 1 line-out (600 Ω) · G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 · noise filtering
Alarm I/O
7 inputs · 2 outputs
RS-485
1 × RS-485 — HIKVISION / Pelco-P / Pelco-D self-adaptive
Ethernet
1 × RJ-45 10/100 Mbps self-adaptive (not gigabit)
On-Board Storage
microSD / SDHC / SDXC up to 1 TB · ANR · NAS (NFS / SMB)
Video Output
1.0 V[p-p] / 75 Ω · PAL / NTSC · BNC (debug)
API & Protocols
ISAPI · SDK · ISUP · OTAP · ONVIF (Profile S / G / T / M) · 20 concurrent live-view sessions
Cyber Security
TPM 2.0 (FIPS 140-2 Level 2) · TLS 1.3 · 802.1X (EAP-TLS / EAP-LEAP / EAP-MD5) · HTTPS · IP filter · watermark · audit log · host authentication (MAC)
Client Software
iVMS-4200 · Hik-Connect · HikCentral
Power Source
36 VDC (max 45 W incl. 6 W heater) · Hi-PoE (max 40 W incl. 6 W heater) · NOT 802.3at PoE+
Heater + Demist
YES + YES (no wiper, no de-icing on this model)
Operating Temperature
−40 °C to +70 °C · ≤95% humidity
Material / Dimensions
Outdoor speed dome · ⌀ 231.1 mm × 355.6 mm · ~6 kg
Weatherproof Rating
IP67 (IEC 60529-2013)
Vandal Resistance
IK10 (IEC 62262:2002)
Anti-Corrosion
NEMA 4X (NEMA 250-2018) — Y variant · moderate Hikvision protection tier
Lightning Protection
±6 kV line-to-ground · ±3 kV line-to-line (IEC 61000-4-5) · surge + voltage transient
DORI (Tele)
Detect 2,979.3 m · Observe 1,182.3 m · Recognise 595.9 m · Identify 297.9 m
Approvals
CE-EMC · CE-LVD · RCM (AS/NZS CISPR 32:2015) · IC ICES-003 · KC · CB · BIS · LOA · RoHS · WEEE · REACH
Warranty
3-Year Australian Warranty (back-to-base)
DS-2DF6A436XG1-EL(Y) vs DS-2DF7A436IXG-EL(Y) — Ultra 6A or Ultra 7A IR?
Hikvision sells two closely-related 4MP 36× speed-dome PTZs in Australia: the DS-2DF6A436XG1-EL(Y) reviewed above (Ultra 6A · DarkFighter 2.0 · no built-in IR illuminator) and its higher-tier sibling the DS-2DF7A436IXG-EL(Y) (Ultra 7A · DarkFighter · with built-in IR illuminator). They share the same 36× zoom range, the same outdoor footprint and the same PTZ kinematics. The decision comes down to how dark the scene actually gets at the longest mounting distance: choose the 6A when ambient light (street, dock, perimeter) is sufficient for DarkFighter 2.0, and choose the 7A when the camera must work in complete darkness at the far end of its zoom range.
DS-2DF6A436XG1-EL(Y) (Ultra 6A · DarkFighter 2.0) vs DS-2DF7A436IXG-EL(Y) (Ultra 7A · IR)
Feature
DS-2DF6A436XG1-EL(Y) (this 6A PTZ)
DS-2DF7A436IXG-EL(Y) (7A IR PTZ)
Series Position
Hikvision Ultra Series 6A
Hikvision Ultra Series 7A (higher tier · with IR)
Image Sensor
1/1.8" CMOS · DarkFighter 2.0
1/1.8" CMOS · DarkFighter 2.0
Max Resolution
4MP · 2688 × 1520
4MP · 2688 × 1520
Optical Zoom
36× · 6–216 mm · F1.2
36× · 6–216 mm · F1.2
IR Illuminator
No built-in IR · DarkFighter 2.0 sensor
Yes — built-in Smart IR up to 300 m · 850 nm
Min. Illumination
0.0003 lux @ F1.2 colour
0.0003 lux @ F1.2 colour · 0 lux with IR
Wide Dynamic Range
150 dB AWDR
150 dB AWDR
Shutter Speed
1/1 s to 1/30,000 s (slow shutter)
1/30 s to 1/30,000 s
Frame Rate
4MP @ 50/60 fps · 1080p @ 100/120 fps
4MP @ 50/60 fps · 1080p @ 100/120 fps
Pan / Tilt Range
360° · −20° to +90°
360° · −20° to +90°
Pan Preset Speed
300°/s
550°/s (max 700°/s)
Pattern Scans
4 pattern scans
— (not listed in datasheet)
Smart Pan-Tilt Correction
—
Yes
Presets / Patrols
300 presets · 8 patrols
300 presets · 8 patrols
Deep Learning
Perimeter · multi-target · face capture (30) · face comparison (150k) · auto-tracking 3.0 · person + vehicle arming
Same AI stack · person arming only (no vehicle arming on 7A)
Cyber Security
TPM 2.0 · FIPS 140-2 L2 · TLS 1.3
TPM 2.0 · FIPS 140-2 L2 · TLS 1.3
Protection
IP67 · IK10 · NEMA 4X (-Y)
IP67 · IK10 · NEMA 4X (-Y)
Power
36 VDC · Hi-PoE 60 W class · max 45 W
36 VDC · PoE 802.3bt Class 8 · max 90 W
Heater / Demist / Wiper
Heater + Demist · No Wiper
Heater + Demist · No Wiper
Weight / Dimensions
~6 kg · ⌀ 231 × 356 mm
~5 kg · ⌀ 215 × 297 mm (smaller and lighter despite IR ring)
Best For
Ambient-lit Australian sites: lit carparks, port aprons under dock lighting, council CBDs, school perimeters with security lighting, marinas with mast lighting. The DarkFighter 2.0 sensor delivers colour at very low light without needing an IR ring.
Completely dark sites at long range: rural property boundaries, dark mining haul roads, unlit power-station yards, perimeter walls with no street lighting. The built-in long-range IR array is what unlocks identification at the far end of zoom in total darkness.
For the 7A IR sibling referenced in the comparison, contact our Australian team for current pricing and stock — contact CCTV Guru →.
Recording NVRs — Any Modern Hikvision NVR Works
The 6A PTZ streams to any modern Hikvision NVR over ONVIF Profile S/G/T/M and Hikvision ISAPI. For multi-site rollouts and the natural-language search of recorded video that goes well with this camera's rich AI metadata, the VPro AcuSeek and DeepinMind NVRs are the right partners.
DS-7608NXI-I2/8P/VPro — 8CH · AcuSeek AI
Eight-channel VPro AcuSeek AI NVR with 8 built-in PoE ports — a clean partner for a single-site PTZ deployment with mixed perimeter cameras. View DS-7608NXI-I2/8P/VPro →
DS-7616NXI-I2/16P/VPro — 16CH · AcuSeek AI
Sixteen channels at full PoE on the VPro AcuSeek AI chassis — room for the PTZ plus a fleet of perimeter and overview cameras across the whole site. View DS-7616NXI-I2/16P/VPro →
DS-7732NXI-I4/16P/VPro — 32CH · AcuSeek AI
Thirty-two channels with 16 PoE and 4 HDD bays — the typical VPro AcuSeek platform for council, port, mining and multi-building campus rollouts. View DS-7732NXI-I4/16P/VPro →
iDS-7716NXI-M4/16P/X — 16CH · DeepinMind
DeepinMind X-Series — Hikvision's most capable 16-channel AI NVR for sites running face-recognition workloads and AcuSearch natural-language search across the fleet. View iDS-7716NXI-M4/16P/X →
Important: the PTZ does not draw standard PoE from these NVRs' built-in PoE ports — its data goes over the Ethernet but power must come from a separate Hi-PoE injector or 36 VDC supply. Browse the full Hikvision NVR range: Hikvision Network Video Recorders →.
Compatible Mounts & Accessories
Hikvision DS-1602ZJ-AKS — Wall Mount
Heavy-duty wall mount for the 6A speed dome, sized for the ⌀ 231 mm / 6 kg body. Compatible with rendered, masonry and treated-timber substrates — the most common install partner for building-eave and façade mounts.
Hikvision DS-1604ZJ-BOX-Y — Junction Box (Anti-Corrosion)
Anti-corrosion-matched junction box for the -Y variant — keeps cable terminations sealed behind the camera body for clean wall and pole installs. Pairs with the DS-1602ZJ-AKS wall mount.
Hikvision DS-1604ZJ-BOX-Corner-Y — Corner Mount Box
Anti-corrosion-matched corner-mount box for installing the PTZ at the corner of a building, overlooking a carpark, dock apron or perimeter line.
Hi-PoE 60 W Injector / Switch
Hi-PoE (60 W class) midspan injector or PoE switch with at least one Hi-PoE port. Required if you're not powering the camera from a separate 36 VDC supply. Contact our Australian team for the right Hi-PoE option for your install.
Heavy-Duty 36 VDC Industrial Supply
Alternative to Hi-PoE — a weatherproof 36 VDC supply rated at minimum 1.5 A continuous with headroom. Useful where you're running fibre to the camera and powering locally.
WD Purple 256 GB Surveillance microSD
WD Purple — built for 24/7 surveillance write cycles, far longer endurance than consumer microSD cards. The 6A PTZ supports microSD up to 1 TB. View WD Purple 256 GB →
Frequently Asked Questions
What does the "-Y" suffix mean and which variant do you stock?
The -Y suffix indicates Hikvision's moderate anti-corrosion housing — NEMA 4X-rated, designed for coastal Australian sites within ~2 km of the shoreline and areas affected by acid rain. We stock the DS-2DF6A436XG1-ELY (with -Y) as our Australian default. The base DS-2DF6A436XG1-EL (no -Y) has "no specific anti-corrosion protection" per the datasheet — we don't stock it.
Does it have a built-in IR illuminator?
No. The 6A model relies on the DarkFighter 2.0 sensor for low-light performance — it produces a clean colour image at 0.0003 lux and monochrome at 0.0001 lux. For most ambient-lit Australian sites (carparks, dock aprons, residential acreage with security lighting, marinas) DarkFighter 2.0 alone is sufficient. For completely dark sites at long range, choose the DS-2DF7A436IXG-EL(Y) 7A sibling which adds a built-in IR illuminator, or add an external IR illuminator to this 6A camera.
Why doesn't it support standard PoE+?
Total camera power draw (sensor, SoC, pan/tilt motors, zoom motor, heater) is up to 45 W on 36 VDC or 40 W on Hi-PoE, exceeding the 25.5 W limit of standard PoE+ (IEEE 802.3at). The camera ships ready for Hi-PoE (60 W class) or 36 VDC direct. Most modern Hikvision Hi-PoE injectors and Hi-PoE network switches support this camera over a single Cat 6 run.
How far away can the camera identify a target?
Per EN 62676-4 criteria at full telephoto: Detect 2,979 m · Observe 1,182 m · Recognise 596 m · Identify 297.9 m. "Identify" means the image is detailed enough to recognise a specific individual — that's a usable working distance for almost any commercial site. Detection extends nearly 3 km.
How does auto-tracking work in practice?
Smart Tracking 3.0 — when on-camera deep-learning detects a human or vehicle entering a defined region or crossing a defined line, the camera automatically pans, tilts and zooms to keep the target framed for the duration of the event. Manual override is always available from iVMS-4200 / HikCentral / Hik-Connect, and armed-person and armed-vehicle modes let you flag specific faces or specific vehicles that trigger tracking on detection.
How many faces can it store on-camera for comparison?
Up to 10 face libraries × 30,000 faces each = 150,000 total faces. Library storage is encrypted on the camera. Sufficient for enterprise watchlist (known visitors, known vehicles, known persons of interest) without requiring an external face-recognition server.
Will the camera record locally if the NVR drops?
Yes. microSD up to 1 TB with ANR (Auto Network Replenishment) — when the network link to the NVR drops, the camera continues writing locally and automatically backfills missed footage to the NVR drive once the link returns.
Why is the Ethernet only 10/100 Mbps?
Hikvision's design choice on the 6A series. The maximum video bit rate of 16,384 Kbps (16 Mbps) for the main stream is well under the 100 Mbps Ethernet ceiling, so gigabit isn't required for the camera's own bandwidth. If you have an existing gigabit drop, the camera auto-negotiates at 100 Mbps and operates normally.
What's the warranty and where is it serviced?
This camera ships with a 3-year Australian Hikvision warranty, serviced back-to-base through Hikvision Australia. CCTV Guru manages the entire RA process from our Sydney office and provides Australian-based pre-sales and technical support for the life of the product.
Do you ship Australia-wide and is stock genuine?
Yes — Australian stock from authorised Hikvision Australia channels (not parallel imports). We ship Australia-wide every business day with same-day dispatch on orders placed before 2 pm AEST to Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra, Darwin and regional addresses.
Downloads & Resources
DS-2DF6A436XG1-ELY Datasheet
Hikvision PTZ Quick Start Guide
Order the Hikvision DS-2DF6A436XG1-EL(Y) from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision Ultra Series PTZ cameras. Order the DS-2DF6A436XG1-ELY 4MP 36× DarkFighter 2.0 PTZ with NEMA 4X anti-corrosion housing for fast Australia-wide dispatch, expert pre-sales advice, project pricing for multi-camera and multi-PTZ rollouts, and full local warranty support. Designing a long-range surveillance project for a port, mining site, council carpark, freight yard, marina or large industrial campus? Request a free quote or contact our Australian team for tailored camera-and-NVR sizing — we'll spec the right Hi-PoE injector or 36 VDC supply at the same time.
Hikvision DeepinView · Ultra-Low Temperature · −60 °C Cold-Rated · 4MP Bullet · 140 dB LightFighter · 12 VDC Only
Hikvision iDS-2CD8A46G0-IZ/UH — 4MP Ultra-Low-Temperature DeepinView Moto Varifocal Bullet (Boots and Runs from −60 °C)
The Hikvision iDS-2CD8A46G0-IZ/UH is a specialty 4MP DeepinView bullet camera engineered for one purpose: to start up, run continuously and deliver usable imagery at temperatures down to −60 °C (−76 °F). That places it well beyond the −30 °C / −40 °C floor of conventional Hikvision DeepinView and AcuSense cameras. This is a perimeter-protection specialty camera — not an ANPR camera, not an active-deterrence camera, and not an AcuSeek camera — purpose-built for the cold environments where standard cameras simply refuse to boot.
Typical Australian deployments include commercial cold-storage and freezer warehouses, abattoir chillers, flash-freeze tunnels in food processing, refrigerated logistics, ice rinks, alpine telecom huts and mast cabinets, ski-resort chairlift towers, mining sites in the Snowy Mountains and Tasmanian high country, LNG and industrial-gas plants, and any sub-polar marine or research deployment. The camera pairs a 1/1.8" 4MP DarkFighter CMOS sensor with LightFighter 140 dB WDR, a 2.8–12 mm motorised varifocal lens, smart IR illumination to 50 m, and a built-in front-glass heater plus demist to keep the lens clear of ice, fog and cold-warm condensation cycling. On-camera DeepinView deep-learning drives line crossing, intrusion, region entrance and region exiting alarms with human-and-vehicle classification, and the AI Open Platform accepts one custom detection / classification / mixed model for site-specific analytics. Full metal-bodied construction, IP67 sealed and IK10 vandal-resistant (excluding the glass window). Australian stock, 3-year Australian warranty.
Operating Range
−60 °C to +60 °C · Heater · Demist
Resolution
4MP · 2688 × 1520 · 25/30 fps
Motorised Zoom
2.8–12 mm · F1.9 Motorised
Night Vision
DarkFighter · 50 m Smart IR
AI Engine
DeepinView · AI Open Platform (1)
Power
12 VDC only · 51.4 W peak · No PoE
3-Year Australian Warranty
Fast Australia-Wide Shipping
Australian Tech Support
What This Camera Is — and What It Isn't
It's worth getting the positioning right upfront. The iDS-2CD8A46G0-IZ/UH is a specialty cold-environment perimeter-protection camera. It does one job extraordinarily well, and it deliberately doesn't try to do anything else. Knowing what's not on the spec sheet stops you from spec'ing the wrong camera for the wrong job.
✓ Perimeter Protection at −60 °C
On-camera deep-learning runs line-crossing, intrusion, region-entrance and region-exiting alarms with human-and-vehicle classification — accurate enough for chill-room access compliance, freezer-aisle dwell-time alerts, ski-resort gate counting and alpine-base perimeter watch.
✓ Cold-Soak Cold Start
Rated to start up from −60 °C — not merely operate after being warmed by sun. When power cycles overnight at an alpine site or an unstaffed cold-store, this camera boots immediately. Conventional cameras can refuse to boot until ambient warms past −30 °C.
✓ One-Slot AI Open Platform
One custom deep-learning model can be uploaded directly to the camera (detection, classification or mixed). Useful for PPE-on-personnel detection in cold-rooms, vehicle-type classification on alpine access roads, hi-vis detection at chairlift loading points.
✗ Not an ANPR / Plate-Recognition Camera
This model is not a number-plate camera. There is no LPR engine, no vehicle-attribute capture, no plate blocklist/allowlist, no Road-Traffic-and-Vehicle-Detection feature set. For on-camera ANPR, choose the iDS-2CD7A46G2/P-IZHSY (G2 ANPR bullet) instead.
✗ Not an Active-Deterrence Camera
No strobe, no built-in speaker, no built-in microphone, no two-way audio. For sites where the camera also needs to challenge an intruder with light and voice, pair this perimeter sensor with a separate AcuSense Smart Hybrid Light camera at the entry point.
✗ Not an AcuSeek-Native Camera
The camera predates Hikvision's AcuSeek roll-out and does not feed native AcuSeek metadata (persons / plates / vehicles / animals) into the NVR. It records and streams cleanly over ONVIF and Hikvision ISAPI to any modern Hikvision NVR — you just don't get plain-English natural-language search across this camera's archive.
Important Install Note — 12 VDC Only, No PoE
Unlike most modern Hikvision IP cameras, the iDS-2CD8A46G0-IZ/UH does not support PoE. The peak power draw with the heater on a cold-soaked −60 °C boot is up to 51.4 W, well above what standard 802.3af (15 W) or 802.3at (25.5 W) PoE can deliver at the camera end of a 100 m run. Hikvision standardises the camera on 12 VDC ± 10% direct, on a three-core terminal block, with reverse-polarity protection built in.
Plan for: a dedicated weatherproof 12 V power supply rated at minimum 5 A continuous with 15–20% headroom for the cold-start surge, or a 24 V → 12 V step-down regulator if you're carrying 24 V through a long cable run. For runs over 50 m, step up to 24 V at the supply and buck-convert at the camera to manage voltage drop. For freezer-aisle and alpine installs, choose an industrial DIN-rail supply mounted inside a heated control cabinet.
Technical Specifications
iDS-2CD8A46G0-IZ/UH · Full Specifications
SKU
iDS-2CD8A46G0-IZ/UH(2.8-12mm)
Camera Type
4MP Ultra-Low-Temperature DeepinView Moto Varifocal IR Bullet Network Camera
Image Sensor
1/1.8" Progressive Scan CMOS · DarkFighter
Max Resolution
2688 × 1520 (4MP)
Lens
Motorised varifocal · 2.8–12 mm · F1.9 · auto / semi-auto / manual focus · integrated mount
Field of View
H 110° → 46.2° · V 59.6° → 26.2° · D 130° → 53°
Min. Illumination
Colour 0.0036 lux @ F1.6 (AGC ON) · 0 lux B/W with IR
IR Range
Up to 50 m · Smart Supplement Light · 850 nm
Day & Night
IR cut filter
Wide Dynamic Range
140 dB · LightFighter pipeline · BLC · HLC · 3D DNR · Defog · Distortion Correction
Frame Rate (Main)
50 Hz: 25 fps @ 4K / 1080p / 720p · 60 Hz: 30 fps @ same
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG (substreams)
Streams
5 simultaneous streams (main / sub / third / fourth / fifth)
Video Bit Rate
32 Kbps – 8 Mbps · CBR / VBR · SVC · ROI (8 fixed regions per stream)
Deep-Learning AI
DeepinView · line-crossing, intrusion, region-entrance, region-exiting detection (human + vehicle classification)
AI Open Platform
Up to 1 model · model types: detection, classification, mixed (detection + classification)
Smart Events
Scene change detection · defocus detection
Basic Events
Motion detection · video tampering · exception (network down, IP conflict, illegal login, HDD full / error)
ANPR / LPR
Not supported (no /P suffix, no LPR algorithm)
Face Capture
Not supported
Active Deterrence
None — no strobe, no built-in speaker, no built-in microphone, no two-way audio
Linkage
Upload to FTP / NAS / memory card · notify surveillance centre · email · trigger recording · trigger capture
Ethernet
1 × RJ-45 10/100 Mbps self-adaptive (not gigabit)
On-Board Storage
microSD / SDHC / SDXC up to 256 GB · ANR · memory-card encryption supported
API & Protocols
ONVIF (Profile S / G / T) · ISAPI · SDK · 20 concurrent live-view sessions
Cyber Security
TLS 1.2 · HTTPS · 802.1X (EAP-TLS / EAP-LEAP / EAP-MD5) · IP filter · watermark · security audit log
Client Software
iVMS-4200 · Hik-Connect · HikCentral
Power Source
12 VDC ±10% only — no PoE, no 24 VAC · 4.28 A · max 51.4 W · 3-core terminal block · reverse-polarity protected
Built-in Heater
Yes
Demist
Yes
Material
Metal body
Dimensions
Ø 140 mm × 367.8 mm (Ø 5.51" × 14.48")
Weight
Approx. 1.82 kg
Weatherproof Rating
IP67 (IEC 60529-2013)
Vandal Resistance
IK10 (IEC 62262:2002) — excluding glass window
Operating Temperature
−60 °C to +60 °C · ≤95% humidity (non-condensing) — startup & continuous run
Storage Temperature
−30 °C to +65 °C · ≤95% humidity (non-condensing)
Approvals
CE-EMC · CE-LVD · RCM (AS/NZS CISPR 32:2015) · IC ICES-003 · CB · RoHS · WEEE · REACH
Warranty
3-Year Australian Warranty (back-to-base)
iDS-2CD8A46G0-IZ/UH vs iDS-2CD7A46G2/P-IZHSY — Which DeepinView Bullet?
Both are 4MP DeepinView bullets, but they're built for entirely different jobs. The iDS-2CD8A46G0-IZ/UH is the cold-environment specialty — it boots and runs at −60 °C, but it doesn't do plate recognition, face capture or active deterrence, and it needs a local 12 VDC supply because it can't be PoE-powered. The iDS-2CD7A46G2/P-IZHSY is the newer-generation G2 ANPR bullet — runs in standard climate ranges, supports on-camera number-plate recognition with ≥98% accuracy across 124+ countries, has the newer TPM 2.0 cyber-security baseline, and runs on standard PoE+ alongside 12 VDC / 24 VAC options.
iDS-2CD8A46G0-IZ/UH (Ultra-Low Temp Perimeter) vs iDS-2CD7A46G2/P-IZHSY (Standard G2 ANPR)
Feature
iDS-2CD8A46G0-IZ/UH (this ultra-low-temp bullet)
iDS-2CD7A46G2/P-IZHSY (standard-temp G2 ANPR bullet)
Series Position
DeepinView G0 · Ultra-Low-Temp specialty
DeepinView G2 · ANPR bullet
Operating Temperature
−60 °C to +60 °C
−40 °C to +65 °C
Image Sensor
1/1.8" CMOS · DarkFighter
1/1.8" CMOS · DarkFighter 2.0
Max Resolution
4MP · 2688 × 1520
4MP · 2688 × 1520
Max Frame Rate
4MP @ 25/30 fps
4MP @ 60 fps · 2MP @ 120 fps
Min. Illumination
0.0036 lux @ F1.6
0.0005 lux @ F1.2
Wide Dynamic Range
140 dB LightFighter
150 dB AWDR
Lens
Motorised 2.8–12 mm · F1.9
Motorised 2.8–12 mm or 8–32 mm · F1.38 → F2.53 / F1.7 → F1.73
IR Range
50 m
60 m (2.8–12) / 100 m (8–32)
Deep Learning
Line crossing · intrusion · region entry & exit · AI Open Platform (1 model)
Same perimeter set + combined-event triggering
ANPR / LPR
—
On-camera LPR ≥98% · 124+ countries · 10,000-record plate database
Vehicle Attributes
—
Type · colour · brand · direction · counting
Face Capture
—
—
Active Deterrence
None
None
Streams
5 simultaneous
5 simultaneous
Edge Storage
microSD up to 256 GB
microSD up to 1 TB
Ethernet
10/100 Mbps
10/100/1000 Mbps (gigabit)
Power Source
12 VDC only · max 51.4 W · NO PoE
PoE+ 802.3at · 12 VDC · 24 VAC · max 22.6 W
Built-in Heater + Demist
Yes (heavy-duty for −60 °C cold-soak)
Yes
Cyber Security
TLS 1.2 · 802.1X · audit log
TPM 2.0 · FIPS 140-2 L2 · TLS 1.3
Protection
IP67 · IK10 (excl. glass)
IP67 · IK10 · NEMA 4X (-Y)
Best For
Cold-storage facilities, freezer warehouses, abattoir chillers, alpine telecom huts, ski-resort towers, ice rinks, polar / research bases, LNG and cryogenic plants — sites where ambient routinely falls below −30 °C.
Standard outdoor Australian ANPR — boomgates, council carparks, freeway off-ramps, marina entries, freight yards — anywhere ambient stays in the −40 °C to +65 °C range and on-camera number-plate recognition matters.
For the standard-temperature G2 ANPR bullet referenced in the comparison, see: iDS-2CD7A46G2/P-IZHSY (2.8–12 mm / 8–32 mm) →
Recording NVRs — Any Modern Hikvision NVR Works
The iDS-2CD8A46G0-IZ/UH streams to any modern Hikvision NVR over ONVIF Profile S/G/T and Hikvision ISAPI — there are no AcuSeek-specific or DeepinMind-specific requirements on the recorder side because this camera does not produce AcuSeek metadata. For multi-site cold-supply-chain, abattoir or alpine rollouts that also include AcuSeek-capable cameras elsewhere on the site, the VPro AcuSeek and DeepinMind NVRs are excellent platforms — they record the cold-temp camera normally and unlock natural-language search for the rest of the fleet.
DS-7608NXI-I2/8P/VPro — 8CH · AcuSeek AI
Eight-channel VPro AcuSeek AI NVR with 8 built-in PoE ports — typical platform for a single cold-storage facility, ski-resort top station or alpine telecom site. View DS-7608NXI-I2/8P/VPro →
DS-7616NXI-I2/16P/VPro — 16CH · AcuSeek AI
Sixteen channels at full PoE — typical scale for a mid-size cold-storage warehouse, abattoir chill-room cluster or a multi-tower alpine site. View DS-7616NXI-I2/16P/VPro →
DS-7732NXI-I4/16P/VPro — 32CH · AcuSeek AI
Thirty-two channels with 16 PoE and 4 HDD bays — the typical VPro AcuSeek platform for industrial cold-supply-chain campuses, LNG plants and large ski-resort multi-station rollouts. View DS-7732NXI-I4/16P/VPro →
iDS-7716NXI-M4/16P/X — 16CH · DeepinMind
DeepinMind X-Series — the most powerful 16-channel AI NVR for sites running mixed cold-temp and standard-temp camera fleets, with AcuSearch natural-language search applied across the AcuSearch-capable cameras in the fleet. View iDS-7716NXI-M4/16P/X →
Note: the camera does not draw PoE from any of the above NVRs — its data goes over the PoE port's Ethernet but power must come from a separate local 12 VDC supply. Browse the full Hikvision NVR range: Hikvision Network Video Recorders →.
Compatible Mounts & Accessories
Hikvision DS-1475ZJ-SUS — Stainless Vertical Pole Mount
316-grade stainless vertical pole bracket — the typical install partner for cold-room ceiling penetrations, alpine pole-top installs and ski-resort tower mounts where the bracket itself must survive freeze-thaw cycling.
Hikvision DS-1476ZJ-SUS — Stainless Corner Mount
316-grade stainless corner-mount bracket for situating the bullet at the corner of a chiller-room, abattoir cold-aisle or alpine mast cabinet, looking down a perimeter line or processing aisle.
Hikvision DS-1275ZJ-S-SUS — Stainless Pendant Wall Mount
316-grade stainless pendant wall mount — for hanging the bullet from a chill-room ceiling, freezer-aisle joist, alpine eaves or telecom-hut soffit. Pairs cleanly with cable-gland penetrations from above.
Dedicated 12 VDC Power Supply (Sized for Cold-Start)
Plan for a weatherproof 12 VDC supply rated at minimum 5 A continuous with 15–20% headroom for the cold-boot heater surge. We recommend industrial-grade DIN-rail supplies for refrigerated and alpine sites — contact our Australian team for the right model.
WD Purple 256 GB Surveillance microSD
WD Purple — built for 24/7 surveillance write cycles, far longer endurance than consumer microSD cards. The recommended edge-recording card for the iDS-2CD8A46G0-IZ/UH (256 GB is this camera's maximum). View WD Purple 256 GB →
Cold-Rated Outdoor Ethernet (UV / Gel-Filled)
For freezer-room and alpine sites, pair the camera with UV-stable, gel-filled Cat 6 outdoor cable — standard indoor cable jackets crack and PVC insulation goes brittle at low temperatures.
Frequently Asked Questions
Is this an ANPR camera?
No. The iDS-2CD8A46G0-IZ/UH is a perimeter-protection DeepinView camera — line crossing, intrusion, region entrance and region exiting with human/vehicle classification. There is no LPR engine, no vehicle-attribute capture and no plate database. For on-camera number-plate recognition, choose the iDS-2CD7A46G2/P-IZHSY instead — the "/P" suffix is Hikvision's ANPR indicator.
Where would I actually use a −60 °C camera in Australia?
Far more sites than you'd expect. The most common Australian deployments are commercial cold-storage warehouses (typically held at −22 °C to −30 °C), flash-freeze tunnels in food processing (−35 °C to −40 °C), abattoir chillers and quarters-rooms, ice rinks, ski-resort chairlift top stations (often −15 °C ambient with sub-−30 °C wind chill at altitude), alpine telecom huts and mast cabinets in the Snowy Mountains and Tasmanian high country, LNG and cryogenic-gas plants, and Antarctic and sub-Antarctic research bases.
Why doesn't it support PoE?
The camera's cold-boot heater + sensor warm-up can draw up to 51.4 W, which is above what 802.3af (15 W) or even 802.3at (25.5 W) PoE can reliably deliver to the camera end of a 100 m run, especially at low temperature where cable resistance rises. Hikvision elected to drop PoE entirely on this model and standardise on 12 VDC direct so installers can spec a properly-sized cold-start supply.
What 12 VDC supply should I use?
Minimum 12 VDC ±10% at 5 A continuous, with 15–20% headroom for the cold-start surge — realistically a 12 V / 6 A or 8 A industrial DIN-rail supply. For cold-storage and alpine sites, choose an industrial-grade supply rated for the ambient where the supply itself is installed (typically inside a heated control cabinet). Reverse-polarity protection is built into the camera, but always check polarity at the terminal block before final commissioning.
Does the heater run continuously?
No. The camera's heater management is internal: the camera senses front-window and sensor temperatures and runs the heater only when needed to keep the imaging path clear. Steady-state power in a benign 0 °C ambient is much lower than the 51.4 W peak — the peak is reserved for cold-soak boot and active demist cycles. Plan supply capacity for the worst case.
Can I use it as an active-deterrence camera (strobe / speaker)?
No. There is no strobe, no built-in speaker, no built-in microphone and no two-way audio on this model. For active deterrence at a cold-environment site, install this camera as the perimeter sensor and pair it with a separate AcuSense Smart Hybrid Light camera (with strobe + speaker) at the entry door or gate.
Does it support AcuSeek natural-language search?
Not natively. AcuSeek requires camera-side metadata generation that this G0-architecture model predates. The camera records cleanly to any modern Hikvision NVR over ONVIF/ISAPI, but you don't get plain-English natural-language search across this camera's archive. AcuSeek-capable cameras elsewhere on the same NVR work normally.
Is the AI Open Platform the same as HEOP 2.0?
It's the earlier generation of Hikvision's open AI platform — supports one model slot (detection, classification, or mixed). The newer G2-generation cameras run HEOP 2.0 with more on-camera compute and multiple concurrent models. For most cold-storage and alpine deployments, one model — typically a PPE-on-personnel detector or stock-presence detector — is sufficient.
Does it record locally if the network drops?
Yes. microSD up to 256 GB with ANR (Auto Network Replenishment) — when the network link to the NVR drops, the camera continues writing locally and automatically backfills missed footage to the NVR drive once the link returns.
What's the maximum cable run from the 12 V supply?
That depends on cable gauge. As a rough rule, for the 51.4 W peak (~4.3 A at 12 V) you'll see ~3% voltage drop over 30 m of 18 AWG, ~3% over 50 m of 16 AWG, and ~3% over 80 m of 14 AWG. For runs over 50 m we recommend stepping up to 24 V at the supply and using a 24 V → 12 V buck converter at the camera, or installing the supply closer to the camera.
What's the warranty and where is it serviced?
This camera ships with a 3-year Australian Hikvision warranty, serviced back-to-base through Hikvision Australia. CCTV Guru manages the entire RA process from our Sydney office and provides Australian-based pre-sales and technical support for the life of the product.
Do you ship Australia-wide and is stock genuine?
Yes — Australian stock from authorised Hikvision Australia channels (not parallel imports). We ship Australia-wide every business day with same-day dispatch on orders placed before 2 pm AEST to Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra, Darwin and regional addresses.
Downloads & Resources
iDS-2CD8A46G0-IZ/UH Datasheet
Hikvision DeepinView Quick Start Guide
Hikvision DeepinView User Manual
Order the Hikvision iDS-2CD8A46G0-IZ/UH from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision DeepinView network cameras. Order the iDS-2CD8A46G0-IZ/UH 4MP ultra-low-temperature DeepinView bullet for fast Australia-wide dispatch, expert pre-sales advice, project pricing for cold-storage, abattoir, alpine, ski-resort and industrial cold-chain rollouts, and full local warranty support. Designing a freezer-aisle, chill-room or alpine surveillance project? Request a free quote or contact our Australian team for tailored camera-and-NVR sizing — we'll spec the right 12 VDC supply at the same time.
Hikvision · 8MP Polymer Anti-Corrosion Turret · IP68 · NEMA 4X · C5 · Smart Hybrid Light · AcuSense
Hikvision DS-2XC3386G0H-LISU/SL (PA) — 8MP Polymer Anti-Corrosion AcuSense Smart Hybrid Light Fixed Turret with Built-in 64 GB Storage
The Hikvision DS-2XC3386G0H-LISU/SL (PA) is Hikvision's flagship top-level corrosion-protected 8MP fixed turret — purpose-built for sites where standard metal-bodied cameras simply don't survive. The PA suffix denotes a fully polymer (composite) body, the highest tier in Hikvision's anti-corrosion classification: IP68 dust & water resistance, IK10 vandal resistance, NEMA 4X enclosure rating, and ISO 12944 C5 corrosion classification. That combination puts the camera on the same shelf as enclosures specified for coastlines, ocean docks, marine vessels, chemical plants, food-processing wash-down zones, fertiliser plants, water-treatment facilities, refineries and offshore platforms — anywhere salt spray, chlorine, ammonia, acid rain or industrial wash-down would corrode a stainless-steel or aluminium housing within months.
The camera pairs a 1/1.8" 8MP CMOS sensor with Smart Hybrid Light (adaptive IR + white-light supplement up to 30 m), AcuSense human-and-vehicle deep-learning classification, 120 dB WDR, a built-in microphone and speaker for two-way audio + active strobe + audible warning, and a fixed-focal lens in your choice of 2.8 mm (108.8° wide-angle, the default Australian SKU) or 4 mm (93.3°). 64 GB on-board storage ships pre-installed inside the sealed body — no SD-card door to weaken the corrosion seal — and the camera is hardened with TPM 2.0 (FIPS 140-2 Level 2) cyber security. Australian stock, 3-year Australian warranty.
Resolution
8MP · 4K · 3840 × 2160
Corrosion
Polymer · IP68 · NEMA 4X · C5
Smart Hybrid Light
IR + White Light · 30 m
AI Engine
AcuSense · Human + Vehicle
Active Deterrence
Strobe · Speaker · 2-Way Audio
Edge Storage
64 GB On-Board Included
3-Year Australian Warranty
Fast Australia-Wide Shipping
Australian Tech Support
Why a Polymer Anti-Corrosion Camera — and Why This One
On a typical Australian coastal install — within a kilometre of the shoreline, exposed to salt-laden wind and sea fog — a standard metal-bodied IP67 camera will start to pit, discolour and eventually corrode through within 12–24 months. Even stainless-steel housings can suffer chloride pitting in chlorine wash-down environments. The DS-2XC3386G0H-LISU/SL (PA) sidesteps that failure mode entirely: the camera body is a single-piece polymer composite that cannot rust, oxidise or pit, and the entire enclosure is rated to IP68 ingress, NEMA 4X enclosure, and ISO 12944 C5 corrosion class — the highest tier in Hikvision's three-level anti-corrosion classification. This is the camera Hikvision specifically lists for coastlines, docks, chemical plants.
Polymer Body — Cannot Rust, Cannot Pit
Unlike aluminium (which oxidises in salt) or stainless steel (which can suffer chloride pitting in chlorine wash-down), the polymer composite body is chemically inert to salt, chlorine, ammonia, acid rain and most industrial atmospheres. Sea-salt spray and chemical aerosols literally don't bond to it.
IP68 Ingress + IK10 Vandal Resistance
IP68 is the highest rating in the IEC 60529 ingress standard — protection against continuous immersion, not just heavy rain — paired with IK10 vandal resistance for high-traffic or wash-down zones where the camera might cop a knock from a pressure-washer wand or a forklift mast.
NEMA 4X + C5 Corrosion Class
NEMA 4X is the US/North-American equivalent of "corrosion-resistant, weatherproof, watertight" — used in chemical plants and marine. ISO 12944 C5 is the European corrosion class for "very high atmospheric corrosivity" — coastal industrial, offshore, chemical processing.
Sealed Body · 64 GB On-Board Storage
The camera ships with 64 GB of on-board flash storage already installed inside the sealed body. No SD-card door, no rubber-grommet weak point — the housing stays sealed against salt and chemical ingress for the camera's full life.
AcuSense — Real Alarms, Not Nuisance Alarms
Hikvision's deep-learning AcuSense engine classifies humans and vehicles on-camera, filtering out the seagulls, palm fronds, rain, swarming insects under the wash-down lights and the moving shadows that plague conventional motion detection on the waterfront.
Smart Hybrid Light + Live Active Deterrence
Smart Hybrid Light adapts between IR (silent) and white light (deterrent) automatically — and when AcuSense detects a human in a restricted zone, the camera triggers a white-light strobe + audible warning through its built-in speaker. Two-way audio via the built-in microphone lets a remote operator talk down a trespasser in real time.
See the Camera in Action — Official Hikvision Demos
Two short official Hikvision videos showing the two stories that define this camera: the Smart Hybrid Light + ColorVu imaging chain, and the polymer anti-corrosion housing putting in 720 hours under a continuous salt-spray test.
Hikvision Polymer Anti-Corrosion Cameras — Official Introduction
Polymer Anti-Corrosion — Official Salt Spray Test
Smart Hybrid Light + ColorVu — Imaging Overview
Meet Hikvision's Smart Hybrid Light Camera with ColorVu — Official Overview
People-Counting, Heat Map & Queue Management
Beyond perimeter alarms, the camera ships with on-board people counting, regional people counting, queue management (up to 8 regions), heat maps and on/off-duty detection — useful for unmanned dock-gate counts, food-plant zone-occupancy compliance and ferry-terminal queue monitoring.
Face Capture — Up to 10 Simultaneous
Face-capture deep-learning detects up to 10 faces simultaneously, uploads each face with both a wide-context shot and a close-up, and supports head swing ±60° and tilt ±30° — the right tool for clocking-on-and-off compliance at industrial-site entry points.
Two 30 m Fixed-Lens Options
Choose 2.8 mm for a 108.8° wide-angle (the default Australian SKU — covers a full carpark, dock apron or wash-down bay) or 4 mm for a tighter 93.3° framing on gates, stair landings or single-equipment bays. Either lens reaches 30 m with the Smart Hybrid Light supplement.
Built-in Microphone, Built-in Speaker
Real two-way audio without external mics or speakers — the entire audio chain lives inside the sealed polymer body, so there are no external mic ports or speaker grilles to corrode. Talk down trespassers, broadcast safety announcements or take audio evidence on incidents.
120 dB WDR + 1/1.8" Sensor
Class-leading 1/1.8" image sensor with 120 dB true wide dynamic range — handles harsh contrast at dock-shed entries (bright outside / dark inside), reflective wash-down concrete, and morning-sun glare off the water at jetty heads.
TPM 2.0 + FIPS 140-2 L2 Cyber Security
Hardware-rooted Trusted Platform Module 2.0 at FIPS 140-2 Level 2, plus TLS 1.2, 802.1X authentication and watermarking — meeting enterprise, port-authority, council and Australian defence-industry cyber baselines for OT camera assets.
Technical Specifications
DS-2XC3386G0H-LISU/SL (PA) · Full Specifications
SKU (Default AU)
DS-2XC3386G0H-LISU/SL(PA)(2.8mm)O-STD64G — built-in 64 GB · 2.8 mm lens
Optional Variants
DS-2XC3386G0H-LISU/SL(PA)(4mm) · DS-2XC3386G0H-LISU(PA)(2.8mm)/64G · DS-2XC3386G0H-LISU/SL(PA)(2.8mm)
Camera Type
8MP Polymer Anti-Corrosion AcuSense Smart Hybrid Light Fixed Turret IP Camera with Strobe & Speaker
Image Sensor
1/1.8" Progressive Scan CMOS
Max Resolution
3840 × 2160 (8MP / 4K)
Lens
Fixed focal · 2.8 mm or 4 mm (M16 mount) · F1.0
Field of View
2.8 mm: H 108.8° / V 56.4° / D 134.3° · 4 mm: H 93.3° / V 47.2° / D 114.2°
Depth of Field
2.8 mm: 3.3 m to ∞ · 4 mm: 3.8 m to ∞
Min. Illumination
Colour 0.002 lux @ F1.0 (AGC ON) · 0 lux with light · B/W 0.0001 lux @ F1.0 · 0 lux with IR
Supplement Light
Smart Hybrid Light — IR + White Light · up to 30 m · 850 nm IR
DORI (2.8 mm)
Detect 89.2 m · Observe 35.4 m · Recognise 17.8 m · Identify 8.9 m
DORI (4 mm)
Detect 100 m · Observe 39.7 m · Recognise 20 m · Identify 10 m
Day & Night
IR cut filter
Wide Dynamic Range
120 dB · BLC · HLC · 3D DNR · Distortion Correction
Frame Rate (Main)
50 Hz: 20 fps @ 4K · 60 Hz: 24 fps @ 4K (also 3072 × 1728 / 2560 × 1440 / 1080p / 720p)
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG (substream)
Streams
4 simultaneous streams (main / sub / third / fourth)
Video Bit Rate
32 Kbps – 16 Mbps · CBR / VBR · SVC · ROI (5 fixed regions for main stream)
AI / Deep-Learning
AcuSense — human + vehicle classification · perimeter protection (line crossing / intrusion / region entry & exit)
Smart Analytics
Face capture (up to 10 simultaneous) · people counting · queue management (8 regions) · heat map · regional people counting · on/off-duty detection
Smart Events
Unattended baggage · object removal · scene change · audio exception · defocus detection
Active Deterrence
White-light strobe + audible warning via built-in speaker + audio linkage
Audio
Built-in microphone · built-in speaker · 1 line-in / 1 line-out (3.3 Vpp) · G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC · environment noise filtering
Alarm I/O
1 input · 1 output (max 24 VDC, 1 A)
Ethernet
1 × RJ-45 10/100 Mbps self-adaptive
On-Board Storage
64 GB built-in (sealed inside body) — no SD-card door
API & Protocols
ISAPI · SDK · ISUP · ONVIF (Profile S / G / T) · 20 concurrent live-view sessions
Cyber Security
TPM 2.0 (FIPS 140-2 Level 2) · TLS 1.2 · 802.1X (EAP-MD5) · HTTPS · IP filter · watermark · security audit
Client Software
iVMS-4200 · Hik-Connect · HikCentral
Power Source
12 VDC ±25% (max 9 W, reverse-polarity protected) · PoE IEEE 802.3af Class 3 (max 9.5 W)
Material
Polymer composite (PA) — chemically inert, non-corroding
Dimensions
138.63 mm × 138.63 mm × 132.74 mm (Ø 5.46" × 5.23")
Weight
Approx. 670 g
Cable Length
0.3 m factory pigtail
Weatherproof Rating
IP68 (IEC 60529-2013) — continuous immersion
Vandal Resistance
IK10 (IEC 62262:2002)
Anti-Corrosion
NEMA 4X · ISO 12944 C5 · Top-level Hikvision protection
Approvals
CE-EMC · CE-LVD · RCM (AS/NZS CISPR 32:2015) · CB · RoHS
Operating Temp.
−30 °C to +60 °C · ≤95% humidity (non-condensing)
Included Mount
DS-1280ZJ-DM55(B)-428CPY (in box)
Warranty
3-Year Australian Warranty (back-to-base)
DS-2XC3386G0H-LISU/SL (PA) vs DS-2CD3386G2H-LISU/SL — Polymer Anti-Corrosion or Standard 8MP Turret?
Hikvision sells two closely-related 8MP AcuSense Smart Hybrid Light fixed turrets in Australia: the DS-2XC3386G0H-LISU/SL (PA) reviewed above (polymer body, top-level corrosion protection, IP68) and its standard-housing sibling the DS-2CD3386G2H-LISU/SL (metal body, IP67, no corrosion class). They share the same sensor, same lens options, same active-deterrence chain (strobe + speaker + two-way audio) and the same AcuSense human/vehicle AI. The decision is a trade-off: choose the PA polymer when corrosion is the dominant failure mode (waterfront, chemical, food-processing wash-down); choose the standard metal when you need marginally better optical performance (higher fps, longer light, better low-light) and the site is benign.
DS-2XC3386G0H-LISU/SL (PA) (polymer C5) vs DS-2CD3386G2H-LISU/SL (standard metal)
Feature
DS-2XC3386G0H-LISU/SL (PA) (this polymer anti-corrosion model)
DS-2CD3386G2H-LISU/SL (standard metal-bodied sibling)
Series Position
Anti-Corrosion Series — Top-Level (C5)
Performance Series — No specific corrosion protection
Body Material
Polymer composite (chemically inert)
Metal (cover + main body)
Ingress Rating
IP68 (continuous immersion)
IP67 (temporary immersion)
Vandal Rating
IK10
—
NEMA Rating
NEMA 4X (corrosion-resistant)
—
ISO 12944 Corrosion Class
C5 (very high)
—
Hikvision Corrosion Tier
Top-level protection
No specific protection
Image Sensor
1/1.8" Progressive Scan CMOS
1/1.8" Progressive Scan CMOS
Max Resolution
8MP · 3840 × 2160
8MP · 3840 × 2160
Max Frame Rate (4K)
20 fps (50 Hz) / 24 fps (60 Hz)
25 fps (50 Hz) / 24 fps (60 Hz)
Lens Options
Fixed 2.8 mm or 4 mm
Fixed 2.8 mm or 4 mm
Min. Illumination (colour)
0.002 lux @ F1.0
0.0005 lux @ F1.0
Wide Dynamic Range
120 dB
130 dB
Smart Hybrid Light Range
30 m
40 m
AcuSense (Human/Vehicle AI)
Yes
Yes
Active Deterrence
White-light strobe + speaker + 2-way audio
White-light strobe + speaker + 2-way audio
Built-in Mic / Speaker
Yes / Yes
Yes / Yes (95 dB SPL @ 10 cm)
HEOP Open Platform
—
Yes — HEOP 2.0 · 1.5 TOPS · Caffe / PyTorch / TensorFlow / ONNX
On-Board Storage
64 GB built-in (sealed)
microSD slot up to 512 GB (external door)
Ethernet
10/100 Mbps
10/100 Mbps
Power
PoE 802.3af Class 3 · max 9.5 W
PoE 802.3af Class 3 · max 12 W
Cyber Security
TPM 2.0 · FIPS 140-2 L2 · TLS 1.2
TPM 2.0 · FIPS 140-2 L2 · TLS 1.3
Operating Temperature
−30 °C to +60 °C
−30 °C to +60 °C
Dimensions / Weight
Ø 138.6 × 132.7 mm · ~670 g
Ø 138.3 × 115.4 mm · ~820 g
Best For
Coastlines, ocean docks, marinas, ferry terminals, chemical plants, fertiliser plants, food-processing wash-down zones, water-treatment, offshore platforms — sites where corrosion kills cameras within 2 years.
Standard residential, commercial, retail, school, warehouse and inland-industrial installs where corrosion is not the dominant failure mode, but you want the extra HEOP open-platform capability and slightly better optics.
Pair with a Hikvision AcuSense / AcuSeek AI NVR
The DS-2XC3386G0H-LISU/SL feeds AcuSense human/vehicle metadata, face captures, people-counting events and active-deterrence triggers straight into any modern Hikvision NVR. For multi-site coastal or industrial rollouts, the VPro AcuSeek line lets your security team type plain-English queries across every camera — for example "person in PPE entering wash-down bay between 2 am and 4 am yesterday".
DS-7608NXI-I2/8P/VPro — 8CH · AcuSeek AI
Eight-channel VPro AcuSeek AI NVR with 8 built-in PoE ports — perfect for a single-jetty, ferry-terminal or processing-plant install. View DS-7608NXI-I2/8P/VPro →
DS-7616NXI-I2/16P/VPro — 16CH · AcuSeek AI
Sixteen channels at full PoE on the VPro AcuSeek AI chassis — room to cover an entire small dock, marina or water-treatment campus. View DS-7616NXI-I2/16P/VPro →
DS-7732NXI-I4/16P/VPro — 32CH · AcuSeek AI
Thirty-two channels with 16 PoE and 4 HDD bays — the typical VPro AcuSeek platform for council-port, multi-wharf and food-processing rollouts where you mix corrosion-grade and standard cameras. View DS-7732NXI-I4/16P/VPro →
iDS-7716NXI-M4/16P/X — 16CH · DeepinMind
Hikvision DeepinMind X-Series — the most powerful 16-channel AI NVR for sites running face-recognition, perimeter and AcuSearch natural-language search across mixed corrosion-grade fleets. View iDS-7716NXI-M4/16P/X →
Browse the full Hikvision NVR range: Hikvision Network Video Recorders →.
Compatible Mounts & Accessories
DS-1280ZJ-DM55(B)-428CPY — Included In Box
The default mounting bracket ships with the camera — a corrosion-coated junction-box bracket sized for the 138 mm turret base. Designed for direct wall or eave install on rendered, masonry or treated-timber substrates.
DS-1258ZJ-L-428CPY — Wall & Inclined Bracket (Optional)
Optional inclined wall bracket for situations where you need to angle the turret down a stairwell, wharf edge or sloping concrete apron without compromising the corrosion seal at the mount face.
DS-1275ZJ-SUS — Stainless Vertical Pole Mount
316-grade stainless vertical pole bracket — matched to coastal and dock-side pole installs where the bracket itself must also resist salt corrosion. Pair with the polymer turret for a fully corrosion-rated install.
DS-1276ZJ-SUS — Stainless Corner Mount
316-grade stainless corner bracket for fitting the turret at a building corner overlooking a wharf, dock apron or chemical-tank farm. Same corrosion-rated stainless as the SUS pole mount.
WD Purple 256 GB Surveillance microSD (compatible variants)
If you select the LISU (no-SL, no-SD-included) variant for retrofit projects, WD Purple is the recommended 24/7 surveillance microSD card. View WD Purple 256 GB →
Sealed PoE Outdoor Couplers
For coastal and dock-side installs, pair the camera with weatherproof PoE inline couplers and tested outdoor-rated Cat 6 (gel-filled / UV-stable) — the polymer body is rated to IP68 but the cable joint still needs to be sealed to match.
Frequently Asked Questions
What does "PA" mean in the SKU?
PA = Polymer Anti-corrosion. The entire camera body is moulded from a polymer composite that is chemically inert to salt, chlorine, ammonia, acid rain and most industrial atmospheres — it cannot rust, oxidise or pit. This is what gives the camera its top-level NEMA 4X / ISO 12944 C5 corrosion rating.
What's the difference between this and the standard DS-2CD3386G2H-LISU/SL?
Same sensor, same lens options, same Smart Hybrid Light, same AcuSense, same active-deterrence chain. The PA polymer model adds polymer body, IP68 (vs IP67), NEMA 4X, C5 corrosion class, sealed 64 GB on-board storage. The trade-offs are lower 4K frame rate (20 vs 25 fps at 50 Hz), shorter Smart Hybrid Light range (30 m vs 40 m), lower WDR (120 vs 130 dB), and no HEOP open platform. Pick the PA when corrosion is the dominant failure mode; pick the standard 3386G2H for benign sites.
Where would I actually install this camera?
Hikvision specifically lists coastlines, docks and chemical plants as the typical-application targets. In Australia, that means waterfront marinas, ferry terminals, container wharves, fish-processing plants, abalone farms, salt-spray-exposed beachfront carparks, water-treatment plants, fertiliser handling, chlorine and ammonia-using facilities, food-processing wash-down zones, brewery hot/wet rooms, and any offshore-platform or oil-rig surveillance role.
Is the camera safe to pressure-wash?
Yes — it is rated IP68 (continuous immersion) and IK10 (vandal-resistant). The polymer body and sealed enclosure are designed for routine industrial wash-down at typical pressures used in food-processing and dock-cleaning. Always keep the jet a sensible distance from the lens and gasket interfaces.
How does the on-board 64 GB storage work?
The default Australian SKU (-O-STD64G) ships with 64 GB of flash storage already installed inside the sealed body — there's no SD-card door to compromise the corrosion seal. The camera writes locally for ANR (auto-network-replenishment) when the link to the NVR drops; once reconnected, missed footage backfills to the NVR drive. For longer retention requirements, run the camera as part of an NVR.
Why is the maximum 4K frame rate only 20 fps?
Hikvision tuned the PA polymer model for continuous, low-thermal operation inside a fully sealed enclosure. The slightly lower frame rate keeps the sensor and SoC running cooler over the camera's lifetime — important because the polymer body, unlike metal, isn't a heat sink. 20 fps at 8MP is sufficient for almost all evidentiary surveillance roles; if you need full 25/30 fps at 4K, the standard 3386G2H is the answer.
Does it have ColorVu (24/7 full-colour) night vision?
The camera uses Smart Hybrid Light — it automatically switches between IR (silent monochrome) and white light (full colour) based on the scene and AcuSense triggers. With white light on, it delivers full-colour imagery to ~30 m. It is not marketed as a "24/7 always-on white-light ColorVu" model — the white light is intelligent rather than always-on, which is the right call for sites where residents or neighbouring properties shouldn't see constant white spill.
Will the polymer body fade in Australian sun?
The polymer is UV-stabilised for outdoor industrial use and operates through Hikvision's full −30 °C to +60 °C range. Over very long deployments (5+ years) some cosmetic surface chalking is normal on any polymer or painted housing, but the polymer's mechanical and corrosion properties are unaffected.
Does it run on standard PoE?
Yes — standard PoE 802.3af Class 3 (max 9.5 W). It also accepts 12 VDC (max 9 W) with reverse-polarity protection if you prefer to power it from a local DC supply. No PoE+ needed.
What's the warranty and where is it serviced?
This camera ships with a 3-year Australian Hikvision warranty, serviced back-to-base through Hikvision Australia. CCTV Guru manages the entire RA process from our Sydney office and provides Australian-based pre-sales and technical support for the life of the product.
Do you ship Australia-wide and is stock genuine?
Yes — Australian stock from authorised Hikvision Australia channels (not parallel imports). We ship Australia-wide every business day with same-day dispatch on orders placed before 2 pm AEST to Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra, Darwin and regional addresses.
Downloads & Resources
DS-2XC3386G0H-LISU/SL (PA) Datasheet
Hikvision Turret Quick Start Guide
Hikvision Network Camera User Manual
Order the Hikvision DS-2XC3386G0H-LISU/SL (PA) from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision anti-corrosion network cameras. Order the DS-2XC3386G0H-LISU/SL (PA) 8MP polymer turret with built-in 64 GB and active deterrence for fast Australia-wide dispatch, expert pre-sales advice, project pricing for marina, dock-side, ferry-terminal and chemical-plant rollouts, and full local warranty support. Designing a corrosive-environment surveillance project? Request a free quote or contact our Australian team for tailored camera-and-NVR sizing.
Hikvision DeepinView · 4MP ANPR Bullet · DarkFighter 2.0 · 150 dB WDR
Hikvision iDS-2CD7A46G2/P-IZHSY — 4MP DeepinView ANPR Moto Varifocal Bullet (2.8–12 mm / 8–32 mm)
The Hikvision iDS-2CD7A46G2/P-IZHSY is Hikvision's flagship 4MP DeepinView ANPR bullet — purpose-built for on-camera licence plate recognition, vehicle attribute capture and high-accuracy perimeter protection. It pairs a 1/1.8" progressive-scan CMOS sensor with DarkFighter 2.0 ultra-low-light technology, 150 dB AWDR, a built-in heater for rain and condensation, NEMA 4X anti-corrosion housing (the -Y suffix) and 5 simultaneous video streams. Choose between two motorised varifocal lens variants — 2.8–12 mm for wide-area carpark, driveway and access-gate scenes, or 8–32 mm for long-range boomgate, freeway off-ramp and side-of-road number-plate capture out to 40 m identification distance.
Powered by Hikvision's DeepinView deep-learning engine, the camera runs licence plate recognition with ≥98% accuracy across 124+ countries and regions, captures vehicle type / colour / brand / direction, classifies humans and vehicles for line-crossing, intrusion, region entry and region exit events, and supports up to 10,000-record blocklist/allowlist ANPR rules — all entirely on the camera, with no separate analytics server required. The metal-alloy bullet body is rated IP67, IK10 and NEMA 4X, and ships with TPM 2.0 (FIPS 140-2 Level 2) hardware-rooted cyber security. Australian stock, 3-year Australian warranty.
Resolution
4MP · 2688 × 1520 · up to 120 fps
ANPR Engine
On-camera LPR · ≥98% accuracy
Low Light
DarkFighter 2.0 · 0.0005 lux
Dynamic Range
150 dB AWDR
Protection
IP67 · IK10 · NEMA 4X (-Y)
Power
PoE+ 802.3at · 12 VDC · 24 VAC
3-Year Australian Warranty
Fast Australia-Wide Shipping
Australian Tech Support
Why Choose the iDS-2CD7A46G2/P-IZHSY for Australian ANPR
On-camera number-plate recognition is the highest-value piece of analytics any commercial site can deploy — replacing manual gate watching, paid carpark attendants, dispute footage searches and after-the-fact incident review with a real-time event stream that names every vehicle entering or leaving. The G2 generation of Hikvision's DeepinView ANPR bullet is the camera built specifically for this job in Australia: full on-camera LPR, vehicle attribute capture, 4MP DarkFighter 2.0 for clear plates even at midnight, and a choice of two motorised varifocal lenses to suit anything from a single-gate carpark to a four-lane freeway off-ramp.
On-Camera ANPR — No Separate Server
The licence plate recognition algorithm runs entirely on the camera's deep-learning processor. No external ANPR analytics box, no per-channel software licence, no recurring cloud fee — just a Hikvision NVR, this camera, and a copy of the iVMS-4200 / HikCentral plate database.
≥98% LPR Accuracy · 124+ Countries
Hikvision's G2 LPR engine recognises plates from four global regions and more than 124 countries, including the standard, custom, motorcycle and stacked-character plate formats used across every Australian state and territory.
4MP DarkFighter 2.0 — Plates at Midnight
The 1/1.8" sensor captures plates at 0.0005 lux in colour and 0 lux with IR — meaning legible plates on un-lit driveways, late-night service roads and rural farm gates without needing supplementary white light.
150 dB AWDR — Sun Glare Won't Blind It
The class-leading 150 dB true wide dynamic range handles the worst Australian lighting scenarios — sun in the lens at 5 pm, headlights at a boomgate, shadow lines across a covered carpark entrance — without losing the plate detail.
Vehicle Capture up to 120 km/h
Front-installation checkpoint mode captures vehicles travelling at up to 120 km/h; side installation captures up to 80 km/h. Detection rate ≥99%, driving-direction accuracy ≥98%.
Blocklist · Allowlist · 10,000 Records
Maintain on-camera plate databases of up to 10,000 records — automatically open the boomgate for tenants, alert security on a stolen vehicle, log every visitor by plate, all entirely at the edge with no NVR-side dependency.
Hikvision Deep-Learning ANPR — Official Overview
Perimeter Protection — Human/Vehicle Filtering
Line crossing, intrusion, region entrance and region exiting — each rule can be restricted to humans only, vehicles only or both. Filters out leaves, possums, birds, flags and headlights so security only gets the alarms that matter.
Vehicle Attribute Capture
Beyond just the plate, the camera captures vehicle type, colour, brand and driving direction — feeding searchable metadata into HikCentral for post-incident vehicle search ("show me every red ute that entered after 6 pm").
Built-in Heater + Demist
Onboard heater + demist function keeps the dome glass clear in rain, heavy dew and cold-morning condensation — important for Tasmanian, alpine and coastal sites where overnight humidity rolls in.
NEMA 4X Anti-Corrosion (-Y Variant)
The -Y suffix indicates Hikvision's moderate anti-corrosion housing — rated NEMA 4X for coastal areas within ~2 km of the shoreline and sites exposed to acid rain. Ideal for Australian coastal carparks, marinas and dockyards.
TPM 2.0 + FIPS 140-2 Cyber Security
Hardware-rooted Trusted Platform Module 2.0 at FIPS 140-2 Level 2, plus TLS 1.3, 802.1X authentication, watermarking, video/firmware/config encryption and complete audit logging — meeting enterprise and government cyber baselines.
Five Simultaneous Streams
Stream main 4MP for the NVR, sub-stream for mobile, third-stream for an integrated VMS, fourth for an LPR sub-system and fifth for archival — all from a single network port, with H.265+ compression keeping bandwidth in check.
Technical Specifications
iDS-2CD7A46G2/P-IZHSY · Full Specifications
SKU
iDS-2CD7A46G2/P-IZHSY(2.8-12mm) / iDS-2CD7A46G2/P-IZHSY(8-32mm)
Camera Type
4MP DeepinView ANPR Moto Varifocal Bullet Network Camera (-Y NEMA 4X anti-corrosion)
Image Sensor
1/1.8" Progressive Scan CMOS
Max Resolution
2688 × 1520 (4MP)
Lens Options
2.8–12 mm motorised varifocal · 8–32 mm motorised varifocal (auto / semi-auto / manual focus, P-iris)
Aperture
2.8–12 mm: F1.38 to F2.53 · 8–32 mm: F1.7 to F1.73
Field of View
2.8–12 mm: H 106° → 41.8° · 8–32 mm: H 42.5° → 15.2°
Min. Illumination
Colour 0.0005 lux @ F1.2 (AGC ON) · B/W 0.0001 lux · 0 lux with IR
IR Range
2.8–12 mm: up to 60 m · 8–32 mm: up to 100 m · smart supplement light · 850 nm
Day & Night
IR cut filter · Blue-glass module (reduces ghosting)
Wide Dynamic Range
150 dB AWDR · BLC · HLC · 3D DNR · Defog · Distortion Correction · EIS
Frame Rate (Main)
4MP @ 60 fps · 2MP @ 120 fps (monitoring mode) · 4MP @ 25/30 fps (smart mode)
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG (substream)
Streams
5 simultaneous streams (main / sub / third / fourth / fifth)
Video Bit Rate
32 Kbps – 8 Mbps · CBR / VBR · SVC · ROI (4 per stream)
Deep-Learning AI
DeepinView · Perimeter Protection (line crossing / intrusion / region entry / region exit · human + vehicle classification) · combined-event triggering
ANPR / LPR
≥98% recognition accuracy · ≥99% capture rate · ≥98% driving-direction accuracy · 4 areas / 124+ countries · vehicle & motorcycle plates · blocklist/allowlist up to 10,000 records
Vehicle Capture Speed
Front (checkpoint): up to 120 km/h · Side: up to 80 km/h
Vehicle Attributes
Type · colour · brand · driving direction · vehicle / non-vehicle counting
Smart Events
Scene change · audio exception · defocus · vibration (G-sensor) · video quality diagnosis
Audio
1 in / 1 out (line) · G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC · environment noise filtering
Alarm I/O
2 inputs / 2 outputs (max 24 VDC/24 VAC, 1 A)
Wiegand (-Y)
1 Wiegand interface — CardID 26-bit, SHA-1 26-bit, Hik 34-bit, NEWG 72-bit
RS-485 (-Y)
1 × RS-485 (Half duplex; Hikvision / Pelco-P / Pelco-D)
Power Output (-Y)
12 VDC, max 100 mA
Ethernet
1 × RJ-45 10/100/1000 Mbps self-adaptive
Edge Storage
microSD / SDHC / SDXC up to 1 TB · ANR · encryption-capable card supported
API & Protocols
ISAPI · SDK · ISUP · OTAP · ONVIF (Profile S / G / T / M) · 20 concurrent live-view sessions
Cyber Security
TPM 2.0 (FIPS 140-2 Level 2) · TLS 1.2 / 1.3 · 802.1X (EAP-TLS / EAP-LEAP / EAP-MD5) · AES128/256 · IP filter · security audit log · watermark
Client Software
iVMS-4200 · Hik-Connect · HikCentral
Power Source
12 VDC ±20% · 24 VAC ±20% · PoE IEEE 802.3at Type 2 Class 4 · max 22.6 W
Weatherproof Rating
IP67 (IEC 60529-2013)
Vandal Resistance
IK10 (IEC 62262:2002)
Anti-Corrosion
NEMA 4X (NEMA 250-2018) — Y variant · moderate protection
Approvals
CE-EMC · CE-LVD · RCM (AS/NZS CISPR 32:2015) · CB · BIS · LOA · EN50121-4 (railway) · RoHS · WEEE · REACH · PVC-FREE
Operating Temp.
−40 °C to +65 °C · ≤95% humidity (non-condensing)
Dimensions
Ø 140 mm × 377.4 mm (Y variant)
Weight
Approx. 2,170 g
Housing
Aluminium alloy · PVC-free
Warranty
3-Year Australian Warranty (back-to-base)
2.8–12 mm vs 8–32 mm — Which Lens Should I Choose?
Both variants share the same body, sensor, DeepinView engine, LPR algorithm, 150 dB WDR and 4MP @ 60 fps capability. The only differences are the motorised lens range, the maximum IR distance and — most importantly — how far away from the plate the camera can be mounted. Use the 2.8–12 mm lens for wide-coverage scenes where the camera also needs to see context (the whole driveway, the entire carpark entrance), and the 8–32 mm lens for narrow, long-range plate-capture lanes (boomgates, freeway off-ramps, multi-lane checkpoints) where the camera mounts well back from the vehicle.
iDS-2CD7A46G2/P-IZHSY(2.8-12mm) vs iDS-2CD7A46G2/P-IZHSY(8-32mm)
Feature
iDS-2CD7A46G2/P-IZHSY (2.8–12 mm — wide)
iDS-2CD7A46G2/P-IZHSY (8–32 mm — long range)
Lens Range
Motorised varifocal · 2.8–12 mm
Motorised varifocal · 8–32 mm
Optical Zoom Ratio
4.3× motorised
4× motorised
Aperture
F1.38 → F2.53
F1.7 → F1.73
Horizontal FOV
106° → 41.8°
42.5° → 15.2°
Vertical FOV
55.4° → 23.6°
23.4° → 8.7°
Diagonal FOV
130° → 48.1°
49.7° → 17.3°
IR Range
Up to 60 m
Up to 100 m
DORI · Detect (Tele)
151.7 m
400 m
DORI · Recognise (Tele)
30.3 m
80 m
DORI · Identify (Tele)
15.2 m
40 m
DORI · Identify (Wide)
6 m
15 m
Image Sensor
1/1.8" Progressive Scan CMOS
1/1.8" Progressive Scan CMOS
Resolution / Max FPS
4MP @ 60 fps · 2MP @ 120 fps
4MP @ 60 fps · 2MP @ 120 fps
WDR · Min. Illumination
150 dB AWDR · 0.0005 lux
150 dB AWDR · 0.0005 lux
ANPR / LPR Engine
DeepinView G2 · ≥98% accuracy · 124+ countries
DeepinView G2 · ≥98% accuracy · 124+ countries
Vehicle Capture Speed
Front 120 km/h · Side 80 km/h
Front 120 km/h · Side 80 km/h
Protection
IP67 · IK10 · NEMA 4X (-Y)
IP67 · IK10 · NEMA 4X (-Y)
Cyber Security
TPM 2.0 · FIPS 140-2 L2 · TLS 1.3
TPM 2.0 · FIPS 140-2 L2 · TLS 1.3
Power
PoE+ 802.3at · 12 VDC · 24 VAC · 22.6 W
PoE+ 802.3at · 12 VDC · 24 VAC · 22.6 W
Best For
Single-gate carparks, residential driveways, boutique-retail loading docks, small-business entrances, mixed plate-and-overview duty where the camera mounts 3–10 m from the plate line.
Boomgate entries, multi-lane checkpoints, freeway off-ramps, large industrial sites, council car-pound entries — anywhere the camera mounts 10–40 m back from the plate line.
Not sure which lens to pick? Contact our Australian team with your camera-to-plate distance and lane width — we'll size the right variant for your site.
Pair with a Hikvision AcuSense / DeepinMind AI NVR
To get the full value out of on-camera ANPR — plate-search across recorded footage, blocklist alerts pushed to security, vehicle attribute filtering — pair the iDS-2CD7A46G2/P-IZHSY with a Hikvision AcuSense or DeepinMind NVR. The camera's LPR metadata, vehicle attributes and DeepinView events are all carried over the existing Hikvision NVR protocol — no additional licence required.
DS-7608NXI-I2/8P/Vpro — 8CH · AcuSense Pro
Eight-channel AcuSense Pro NVR with 8 built-in PoE ports — perfect for a single-site ANPR deployment with mixed perimeter cameras. View DS-7608NXI-I2/8P/Vpro →
DS-7616NXI-I2/16P/Vpro — 16CH · AcuSense Pro
Sixteen channels at full PoE — room for the ANPR camera plus a fleet of perimeter and overview cameras across the whole site. View DS-7616NXI-I2/16P/Vpro →
DS-7732NXI-I4/16P/Vpro — 32CH · AcuSense Pro
Thirty-two channels with 16 PoE and 4 HDD bays — the typical platform for council carparks, multi-building campuses and shopping-centre ANPR rollouts. View DS-7732NXI-I4/16P/Vpro →
iDS-7716NXI-M4/16P/X — 16CH · DeepinMind
Hikvision DeepinMind X-Series — the most powerful 16-channel AI NVR for sites running multiple ANPR cameras and AcuSeek natural-language vehicle search. View iDS-7716NXI-M4/16P/X →
Browse the full Hikvision NVR range here: Hikvision Network Video Recorders → or the complete Hikvision AcuSeek & DeepinView camera collection →.
Compatible Mounts & Accessories
Hikvision DS-1275ZJ-S-SUS Pendant Wall Mount
Stainless-steel pendant wall mount for the iDS-2CD7A46G2/P-IZHSY bullet — designed for coastal Australian sites where corrosion is a serious concern.
Hikvision DS-1475ZJ-SUS Vertical Pole Mount
Stainless-steel vertical pole bracket — the typical install partner when the camera goes on a fence post, light pole or gate column.
Hikvision DS-1476ZJ-SUS Corner Mount
Stainless-steel corner-mount bracket for situating the bullet at the corner of a building, looking down a perimeter line or carpark approach.
Hikvision DS-1475ZJ-Y / DS-1476ZJ-Y
Anti-corrosion-coated alternatives to the SUS series — matched to the -Y NEMA 4X bullet body for full anti-corrosion-rated installations.
Hikvision DS-FM2466 Alarm Expansion Box
LAN-attached alarm box that extends the iDS-2CD7A46G2/P-IZHSY's I/O by an additional 6 alarm inputs and 6 alarm outputs — useful when interlocking ANPR triggers with boomgates, intercoms or shed-door contactors.
WD Purple 256 GB Surveillance microSD
WD Purple — built for 24/7 surveillance write cycles, with far longer endurance than consumer microSD cards. The recommended edge-recording card for Hikvision G2 ANPR bullets. View WD Purple 256 GB →
Frequently Asked Questions
Does the iDS-2CD7A46G2/P-IZHSY need a separate ANPR licence or server?
No. The licence-plate recognition algorithm runs entirely on the camera. You don't need a dedicated ANPR analytics box, a per-channel software licence or a recurring cloud subscription — just a Hikvision NVR (or HikCentral) to receive the LPR metadata and store the captured plates.
Does it recognise Australian plates?
Yes. Hikvision's G2 LPR engine covers 124+ countries and regions across four areas, including all standard Australian state and territory plate formats — NSW, VIC, QLD, WA, SA, TAS, ACT, NT — plus custom plates, motorcycle plates and stacked-character plates.
What's the difference between the 2.8–12 mm and 8–32 mm variants?
Same camera body, same DeepinView AI, same ANPR engine — only the motorised lens range, IR range and plate-capture distance change. Use 2.8–12 mm for sites where the camera mounts 3–10 m from the plate line (residential gates, small carpark entries) and 8–32 mm for sites where the camera mounts 10–40 m back (boomgates, multi-lane checkpoints, freeway off-ramps).
What's the maximum vehicle speed it can capture?
Front-installation checkpoint mode captures up to 120 km/h. Side-mounted installations capture up to 80 km/h. Both numbers assume Hikvision's recommended install geometry and illumination — see the datasheet for full guidance.
What does the "P" in the model name mean? What about the "Y"?
The P indicates the camera is a dedicated plate-recognition (ANPR) DeepinView model. The Y indicates the moderate anti-corrosion housing — NEMA 4X-rated stainless body suitable for coastal Australian sites within 2 km of the shoreline and areas affected by acid rain.
Does it support Wiegand output for boomgate / access control?
Yes — the -Y variant includes a Wiegand interface (CardID 26-bit, SHA-1 26-bit, Hik 34-bit, NEWG 72-bit) and an RS-485 port, letting you wire the camera directly into a boomgate controller, access-control panel or third-party gate-management system.
How many plates can I store in the blocklist / allowlist?
Up to 10,000 records combined, stored on-camera. The camera matches every captured plate against the list in real time and triggers the appropriate alarm output or NVR event — automatically open the boomgate for tenants, push an alert on stolen plates, log every visitor by plate.
What's DarkFighter 2.0 and why does it matter for ANPR?
DarkFighter 2.0 is Hikvision's second-generation ultra-low-light sensor + image-processing pipeline. For ANPR it matters because the camera needs to read a tiny, fast-moving plate at night — with DarkFighter 2.0, the camera can pull a clean colour plate at 0.0005 lux ambient and a clean monochrome plate at 0 lux using only the built-in IR.
Will it record to the camera if the NVR goes offline?
Yes. The onboard microSD slot accepts up to 1 TB and supports ANR (Auto Network Replenishment) — when the camera reconnects to the NVR, any footage missed during the outage automatically backfills from the SD card to the NVR drive.
Does it run on standard PoE?
It needs PoE+ (IEEE 802.3at Type 2) — not standard 802.3af — because of the built-in heater and the motorised lens. Most modern Hikvision and Dahua PoE NVRs and switches support PoE+ on every port. It can also run on 12 VDC or 24 VAC if a separate supply is preferred.
What's the warranty and where is it serviced?
This camera ships with a 3-year Australian Hikvision warranty, serviced back-to-base through Hikvision Australia. CCTV Guru manages the entire RA process from our Sydney office and provides Australian-based pre-sales and technical support for the life of the product.
Do you ship Australia-wide and is stock genuine?
Yes — Australian stock from authorised Hikvision Australia channels (not parallel imports). We ship Australia-wide every business day with same-day dispatch on orders placed before 2 pm AEST to Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra, Darwin and regional addresses.
Downloads & Resources
iDS-2CD7A46G2/P-IZHSY Datasheet Hikvision DeepinView Quick Start Guide Hikvision DeepinView User Manual
Order the Hikvision iDS-2CD7A46G2/P-IZHSY from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision DeepinView ANPR cameras. Order the iDS-2CD7A46G2/P-IZHSY in your choice of 2.8–12 mm or 8–32 mm motorised varifocal lens for fast Australia-wide dispatch, expert pre-sales advice, project pricing for multi-camera rollouts and full local warranty support. Designing a multi-gate carpark, boomgate or council ANPR project? Request a free quote or contact our Australian team for tailored camera-and-NVR sizing.
Dahua TiOC 3.0 · Motorised Vari-Focal · F1.0 · AcuPickTiOC Vari-Focal
Dahua DH-IPC-HDW3649H-ZAS-PV-ANZ-S2 — 6MP TiOC 3.0 Motorised Vari-Focal AcuPick Active Deterrence Turret
The Dahua DH-IPC-HDW3649H-ZAS-PV-ANZ-S2 is the motorised vari-focal sibling of Dahua's 6MP TiOC 3.0 line — same red/blue strobe, siren and voice deterrence chain, same AcuPick AI and same Smart Dual-Light system as the fixed-lens 3649, but with a remotely-adjustable 2.7–13.5 mm zoom lens, a remarkable F1.0 aperture, and substantially longer reach. At wide-angle it covers a 104° field of view; at telephoto it can identify a face at 18.7 m and detect motion out to 186 m — turning a single camera into both a perimeter wide-shot and a high-zoom evidence camera.
Combined with extended 50 m IR + 40 m warm-light illumination (versus 30 m on the fixed-lens 3649), AcuPick attribute target search, SMD 4.0 false-alarm filtering, AI Coding (≥25% extra compression efficiency), EIS image stabilisation and full TiOC 3.0 active deterrence, this is the camera Australian installers reach for when they need both wide coverage and long-range identification from one mounting point — without paying the 4K-storage premium of the 8MP ZAS. Available in White (DH-IPC-HDW3649H-ZAS-PV-ANZ-S2) and Black (DH-IPC-HDW3649H-ZAS-PV-ANZ-S2-BLK). Australian stock with 3-year warranty.
Resolution
6MP · 3072 × 2048
Motorised Zoom
2.7–13.5 mm · F1.0
Night Vision
50 m IR · 40 m Warm
Active Deterrence
Strobe · Siren · Voice
Protection
IP67 · −30 °C to +60 °C
Power
PoE 802.3af · Max 12.1 W
3-Year Australian Warranty
Fast Australia-Wide Shipping
Australian Tech Support
Why Choose the Motorised Vari-Focal 3649H-ZAS-PV-ANZ-S2
The vari-focal upgrade matters when one camera needs to do two jobs — cover a wide approach and pull tight on a number plate or face at the end of the driveway. Where the fixed-lens 3649 commits to a single 2.8 mm field of view forever, the ZAS lets you dial the zoom remotely after install, after a fence is built, after vegetation grows in, or after you change your mind. It's the camera Australian installers reach for on long rural driveways, carparks, loading docks, school perimeters and anywhere field-of-view requirements change over time — at a friendlier price point than the 8MP ZAS sibling.
2.7–13.5 mm Motorised Vari-Focal
Five-times optical zoom with remote focus and zoom control via DMSS or a Dahua NVR. Set the field of view once at install, then re-tune from your phone whenever the scene changes — no ladder, no scaffolding, no re-aiming.
F1.0 Aperture — Class-Leading Light Gathering
An F1.0 aperture across the entire zoom range — extremely rare for a vari-focal lens. F1.0 lets in 2.5× more light than a typical F1.6 fixed lens, the single biggest factor behind clean colour image in dark conditions.
Massive DORI Reach at Tele
At maximum zoom the 3649 ZAS will detect motion at 186 m, recognise a person at 37.3 m, and identify a face at 18.7 m — nearly three times the identification range of the fixed-lens 3649. One camera can secure a typical Australian residential block end-to-end.
50 m IR + 40 m Warm Light
Extended Smart Dual-Light reach matches the longer optical range — IR illumination out to 50 m, warm-light LED to 40 m. Enough to fully illuminate a long driveway or a typical carpark in pitch darkness.
TiOC 3.0 — Three-in-One Active Deterrence
Same active deterrence chain as the fixed-lens 3649: red/blue strobe, on-board siren and custom voice broadcast fire automatically the moment SMD 4.0 confirms a human or vehicle. No operator, no extra hardware.
AI Coding + EIS Stabilisation
AI Coding delivers ≥25% extra compression efficiency over Smart H.265+, while Electronic Image Stabilisation (EIS) — unique to the ZAS in this line — corrects subtle vibration on long-zoom shots from a pole or gable.
Smart Features for Real-World Australian Sites
Dahua TiOC 3 & PRO Webinar 2024 — Official English Walkthrough
Remote Zoom & Auto-Focus
Adjust the 2.7–13.5 mm zoom from the DMSS app or a Dahua NVR. The motor handles focus automatically as the lens zooms — no manual focus turret to fiddle with at the camera.
IVS Tripwire & Intrusion Zones
Define a virtual line across the driveway or a no-go zone around the shed — get a notification (and trigger the deterrence chain) only when a human or vehicle actually crosses it.
Two-Way Audio & Custom Voice
Dual built-in MICs and an on-board speaker support live two-way talk via DMSS or a Dahua NVR. Pre-loaded plus uploadable voice files let you record a site-specific warning in your own voice.
Edge Recording — MicroSD up to 512 GB
On-camera MicroSD records weeks of 6MP footage independently of the NVR — a critical redundancy layer if the network drops, the recorder is stolen or power is cut.
3:2 Sensor Aspect — More Vertical Pixels
The 6MP ZAS uses a 3072 × 2048 sensor crop (3:2 aspect) — taller than the standard 3649's 16:9 frame. Useful for doorways, narrow passages and tall fences where you want vertical reach without sacrificing horizontal coverage.
Plug & Play + Third-Party VMS
Drops into any Dahua NVR via plug-and-play, and works over ONVIF Profile S/G/T with Milestone, Genetec, Hanwha WAVE, ExacqVision, Blue Iris and Synology Surveillance Station.
Pair with a Dahua 5-Series NVR for the Full AcuPick Experience
SMD 4.0, IVS rules, two-way audio and the full TiOC 3.0 deterrence chain all run on-camera — they work with any Dahua AI NVR, or even an ONVIF third-party recorder. But to unlock AcuPick — attribute-based human and vehicle target search, similar-image cross-camera tracking and AI-accelerated playback — you need a compatible Dahua 5-Series AcuPick NVR. With a long-zoom 6MP camera the AcuPick payoff is even bigger: the long-tele footage carries enough pixel density for clean facial-attribute search at distance.
DHI-NVR5208-8P-AI/ANZ — 8 Channel · 8 PoE
Compact 1U 5-Series AcuPick NVR with 8 built-in PoE ports — ideal for a single-home or small-business install with 4–8 TiOC cameras. Full AcuPick target search and AI playback. View NVR5208-8P →
DHI-NVR5216-16P-AI/ANZ — 16 Channel · 16 PoE
16-channel 5-Series AcuPick NVR with 16 PoE ports and dual-HDD bays — the sweet-spot recorder for most residential and SMB Dahua TiOC fleets. Plug-and-play with the 3649H ZAS. View NVR5216-16P →
DHI-NVR5432-16P-AI/ANZ — 32 Channel · 16 PoE
32-channel 1.5U AcuPick NVR with 16 PoE and 4 HDD bays — the standard choice for medium commercial sites, retail chains and multi-building campuses. View NVR5432-16P →
DHI-NVR5432-AI/ANZ — 32 Channel · No PoE
32-channel AcuPick NVR without built-in PoE — for sites running a separate managed PoE switch (preferred in larger commercial deployments). Same AcuPick capability, more flexible network design. View NVR5432-AI →
Need help sizing? Browse the complete Dahua AcuPick NVR range → or contact our Australian team for a tailored recommendation based on your camera count, recording retention and AcuPick search workload.
Technical Specifications
DH-IPC-HDW3649H-ZAS-PV-ANZ-S2 · Full Specifications
SKU
DH-IPC-HDW3649H-ZAS-PV-ANZ-S2 (White) · DH-IPC-HDW3649H-ZAS-PV-ANZ-S2-BLK (Black)
Camera Type
6MP TiOC 3.0 WizSense IP Network Turret · Motorised Vari-Focal · Active Deterrence
Image Sensor
1/2.7" Progressive Scan CMOS
Max Resolution
3072 × 2048 (6MP · 3:2 aspect) @ 25/30 fps
Lens Type
Motorised vari-focal · 2.7–13.5 mm (5× optical zoom) · Auto-focus
Maximum Aperture
F1.0 (2.5× the light gathering of F1.6)
Angular Field of View
Wide (2.7 mm): H 104° / V 75° / D 128° · Tele (13.5 mm): H 33° / V 26° / D 42°
DORI — Wide Angle (2.7 mm)
Detect 65.2 m · Observe 26.1 m · Recognise 13.0 m · Identify 6.5 m
DORI — Telephoto (13.5 mm)
Detect 186.6 m · Observe 74.6 m · Recognise 37.3 m · Identify 18.7 m
Min. Illumination
Colour: 0.003 lux @ F1.0 · B/W: 0.0003 lux · 0 lux (Illuminator on)
S/N Ratio
> 56 dB
Dynamic Range
120 dB True WDR
Day & Night
Auto (ICR) / Colour / B&W
Illuminators
2 × IR LED up to 50 m · 2 × Warm-light LED up to 40 m · Smart Dual-Light auto switching
Image Enhancement
3D NR · HLC · BLC · Defog · AI SSA · Smart Illumination · EIS (Electronic Image Stabilisation) · Image Rotation
Active Deterrence
Red/blue flashing warning lights · Built-in siren · Voice broadcast (custom audio supported)
Intelligent Video
AcuPick · SMD 4.0 · IVS (Tripwire, Intrusion · human/vehicle classification) · AI SSA · Smart Search
Video Compression
AI H.265 · AI H.264 · Smart H.265+ · Smart H.264+ · H.265 · H.264 · MJPEG (sub-stream)
AI Coding
≥25% additional compression efficiency
Streaming
3 streams — Main 3072×2048 · Sub 704×576 · Third 1920×1080
Video Bitrate
H.264 / H.265: 3 kbps – 16,384 kbps
Audio Compression
G.711a · G.711Mu · G.726 · G.723 · PCM (Two-Way Audio)
IP Camera Protocol
ONVIF Profile S/G/T · CGI · P2P · RTMP
Network Protocols
IPv4/v6 · HTTP/HTTPS · TCP/UDP · RTP/RTSP/RTCP/RTMP · SMTP · FTP/SFTP · DHCP · DDNS · UPnP · NTP · ICMP · IGMP · NFS · PPPoE · SNMP · 802.1x
Cyber Security
Trusted boot · Trusted execution · Trusted upgrade · HTTPS · 802.1x · IP/MAC filtering · X.509 import · syslog · video/firmware/config encryption · account lockout
Ethernet
RJ-45 (10/100BASE-T)
Alarm I/O
1 alarm in (wet contact) · 1 alarm out (wet contact)
Audio I/O
Dual built-in MIC · 1-channel built-in speaker · 1 × RCA in / 1 × RCA out
Edge Storage
MicroSD up to 512 GB · NAS · FTP / SFTP
Weatherproof Rating
IP67
Operating Temperature
−30 °C to +60 °C · ≤ 95% RH
Power Source
12 V DC · PoE (IEEE 802.3af) · ±30% wide voltage
Power Consumption
Basic 4.5 W (12 V DC) / 5.8 W (PoE) · Max 10.3 W (12 V DC) / 12.1 W (PoE)
Memory
ROM 256 MB · RAM 2 GB
Mobile App
DMSS · Smart PSS Lite · DSS (iOS & Android)
Approvals
CE-LVD (EN 62368-1) · CE-EMC 2014/30/EU
Housing
Metal · White or Black
Dimensions
127.6 mm × Φ 122.0 mm
Weight
0.885 kg (net) · 1.060 kg (gross)
Warranty
3-Year Australian Warranty (back-to-base)
3649H-ZAS (Motorised) vs 3649H-AS (Fixed) — Which 6MP TiOC Should You Choose?
Both cameras share the same chassis, the same TiOC 3.0 deterrence chain, the same AcuPick AI and the same Smart Dual-Light system. The deciding question is the lens: do you need a single fixed field of view, or the flexibility to zoom in remotely? If the site has long sightlines, changing conditions, or you want one camera to cover both wide approach and high-zoom evidence, choose the ZAS. If you only need a fixed 97° wide view and the budget is tight, the fixed-lens 3649 is the cheaper pick.
Dahua 3649H-ZAS-PV-ANZ-S2 vs 3649H-AS-PV-ANZ-S2
Feature
DH-IPC-HDW3649H-ZAS-PV-ANZ-S2 (this motorised model)
DH-IPC-HDW3649H-AS-PV-ANZ-S2 (fixed lens)
Lens
Motorised vari-focal · 2.7–13.5 mm (5× zoom)
Fixed-focal · 2.8 mm
Maximum Aperture
F1.0 across full zoom
F1.6
Remote Zoom & Focus
Yes — via DMSS or NVR
No — fixed at install
FOV — Wide
104° H
97° H (fixed)
FOV — Tele
33° H
n/a
DORI Detect (max reach)
186.6 m (at tele)
66 m (fixed)
DORI Identify (max reach)
18.7 m (at tele)
6.6 m (fixed)
IR Distance
50 m
30 m
Warm Light Distance
40 m
30 m
Sensor Aspect
3072 × 2048 (3:2 — more vertical)
3200 × 1800 (16:9)
Image Sensor
1/2.7" CMOS
1/2.7" CMOS
Image Stabilisation (EIS)
Yes
No
AI Coding
Yes — ≥25% extra efficiency
Smart H.265+ only
Memory (RAM)
2 GB
512 MB
Max Video Bitrate
16,384 kbps
8,192 kbps
Red/Blue Strobe · Siren · Voice
Yes
Yes
AcuPick AI Search
Yes — with 5-Series NVR
Yes — with 5-Series NVR
SMD Version
SMD 4.0
SMD 4.0
Two-Way Audio
Yes — dual MIC + speaker
Yes — dual MIC + speaker
WDR
120 dB True WDR
120 dB True WDR
MicroSD
Up to 512 GB
Up to 512 GB
Power (Max PoE)
12.1 W
8.8 W
Ingress Protection
IP67
IP67
Operating Temperature
−30 °C to +60 °C
−40 °C to +60 °C
Colour Options
White & Black
White & Black
Australian Warranty
3 years back-to-base
3 years back-to-base
Best For
Long driveways, rural properties, carparks, loading docks, school perimeters, sites where field-of-view requirements change over time.
Tight residential entrances, narrow side passages and budget-conscious installs where a fixed 2.8 mm wide-angle is enough.
Compatible Mounts & Accessories
Dahua PFA137 Waterproof Junction Box
Recessed IP66 junction box for clean cable concealment on exposed brick, render or weatherboard. Available in white and black to match the camera. View product →
Dahua PFB205W-E Wall Mount Bracket
Purpose-built wall arm for soffit, eave and external wall mounting. Available in white and black. View product →
Dahua PFA109 Mount Adapter
Required adapter to fit the 3649H ZAS turret onto Dahua wall and pole brackets. View product →
Dahua PFB220C Ceiling Mount
Drop-down ceiling bracket for retail awnings, undercover car parks and warehouse interiors. View product →
Dahua PFA152-E Pole Mount
Heavy-duty pole bracket for fence posts, light poles and gate columns. Pairs with PFB205W-E and PFA137. View product →
WD Purple 256 GB Surveillance MicroSD Card
Western Digital Purple — purpose-built for 24/7 surveillance read/write cycles, far longer endurance than consumer microSD cards. The recommended edge-recording card for Dahua TiOC motorised vari-focal turrets. View WD Purple 256 GB →
Frequently Asked Questions
What does the "Z" in 3649H-ZAS mean?
"Z" stands for motorised zoom — this is the motorised vari-focal lens version of the 6MP TiOC 3.0 line. The fixed-lens equivalent is the 3649H-AS-PV-ANZ-S2. Both share the same chassis, AcuPick AI, TiOC 3.0 deterrence and Smart Dual-Light; the ZAS adds a 2.7–13.5 mm zoom lens with auto-focus you can drive remotely.
Is the motorised vari-focal version worth the extra cost?
If the site has long sightlines (driveways, perimeters, carparks) or if field-of-view requirements are likely to change (new fences, vegetation, signage), yes — the ability to remotely re-zoom from the app saves a service call every time. For a fixed shop entrance or a narrow doorway, the fixed-lens 3649 is the cheaper choice.
Why pick the 6MP ZAS over the 8MP ZAS?
Two reasons. First, cheaper storage — 6MP files are about 30% smaller than 4K, so the same NVR drive holds more days of footage. Second, the 6MP ZAS uses a 3:2 aspect ratio (3072 × 2048) rather than 16:9 — giving more vertical pixels, useful for tall scenes like doorways and narrow passages. If you don't need 4K-level zoom-in capability, the 6MP ZAS often makes more sense.
Can the camera pan and tilt remotely too, or just zoom?
The 3649H-ZAS is a motorised vari-focal turret, not a PTZ. The lens supports remote zoom and auto-focus, but the camera body itself does not pan or tilt remotely — the housing is aimed manually at install time. For a fully remote pan/tilt/zoom camera, look at a Dahua PTZ.
Do I need a special NVR for AcuPick?
Yes — AcuPick target search requires a compatible Dahua 5-Series AcuPick NVR. The TiOC 3.0 deterrence chain, SMD 4.0, IVS and two-way audio all work on any Dahua AI NVR. Shop AcuPick NVRs here →
How much PoE budget does this camera need?
The ZAS draws a maximum of 12.1 W on PoE when the motor, strobe, siren and warm light are simultaneously active — well within the 802.3af PoE budget of 15.4 W. Most installs sit at 5–6 W in normal operation. Make sure your PoE switch budgets for the peak, especially on multi-camera switches.
Will the camera deter intruders automatically?
Yes. The TiOC 3.0 deterrence chain fires the instant SMD 4.0 confirms a human or vehicle inside the rule zone — strobe lights, siren and voice broadcast all run on-camera, 24/7, without any operator, NVR command or mobile-app interaction.
What is the difference between the White and Black versions?
Specifications are identical. DH-IPC-HDW3649H-ZAS-PV-ANZ-S2 is white; DH-IPC-HDW3649H-ZAS-PV-ANZ-S2-BLK is black. Choose black for dark eaves and charcoal fascia; white for traditional cream/render walls.
Will it keep recording if the NVR or internet goes down?
Yes. The on-board MicroSD slot accepts cards up to 512 GB and records 6MP footage independently of the NVR. Combined with DMSS cloud push notifications, you have three redundant recording paths: NVR, MicroSD and event clips to your phone.
Is the camera suitable for Australian outdoor conditions?
Yes. It is rated IP67 and −30 °C to +60 °C — comfortably covering every Australian climate from a Hobart winter to a Karratha summer. The metal housing and ±30% wide-voltage tolerance also handle dirty mains power common on rural sites.
Does it work with Hikvision NVRs or third-party VMS?
Basic recording, streaming and motion work over ONVIF Profile S/G/T on most third-party NVRs and VMS platforms (Milestone, Genetec, Hanwha WAVE, ExacqVision, Blue Iris, Synology). However, TiOC deterrence, AcuPick, SMD 4.0 and two-way audio require a Dahua NVR or DMSS to be triggered correctly.
What is the warranty and where is it serviced?
This camera ships with a 3-year Australian Dahua warranty, serviced back-to-base by Dahua Australia. CCTV Guru handles the entire RA process and provides Australian-based technical support for the life of the product.
Downloads & Resources
DH-IPC-HDW3649H-ZAS-PV-ANZ-S2 Datasheet
Dahua Turret Quick Start Guide
Order the Dahua DH-IPC-HDW3649H-ZAS-PV-ANZ-S2 from CCTV Guru
CCTV Guru is an authorised Australian reseller of Dahua TiOC 3.0 cameras. Order the 6MP TiOC 3.0 motorised vari-focal AcuPick turret today in White or Black for fast Australia-wide dispatch, expert pre-sales advice, project pricing for larger rollouts and full local warranty support. For multi-camera projects, contact our Australian team for a tailored quote, NVR sizing and installation guidance — request a free quote or contact the team.
Dahua WizMind AI · 8 Channel · 8 PoE/ePoE · AcuPick
Dahua DHI-NVR5208-8P-AI/ANZ-PRO 8 Channel AI NVR with Built-In PoE
The Dahua DHI-NVR5208-8P-AI/ANZ-PRO is a premium 8 channel AI network video recorder built for Australian homes, shops, warehouses, offices and commercial CCTV systems that need smarter recording, cleaner PoE installation and faster footage search.
With 8 built-in PoE/ePoE ports, AcuPick intelligent video search, support for cameras up to 32MP, advanced AI by recorder or camera, and 2 internal SATA HDD bays, this recorder is a serious upgrade over basic motion-only NVRs.
Camera Support
Up to 8 Cameras
Built-In Switch
8 PoE/ePoE Ports
AI Search
AcuPick
Storage
2 HDD Bays
Australian Support
AI CCTV Ready
PoE Installation
Why this Dahua AI NVR is a smarter 8-channel choice
Most 8 channel recorders simply store footage. The DHI-NVR5208-8P-AI/ANZ-PRO helps you find the right footage faster with intelligent event search, AcuPick support and AI filtering for people, vehicles and key security events.
Built-In 8-Port PoE/ePoE
Connect compatible IP cameras directly to the recorder using network cable. This keeps the installation cleaner and reduces the need for separate PoE switching hardware.
AcuPick Intelligent Video Search
Search faster for people and vehicles when used with compatible Dahua AI cameras, helping reduce the time spent scrolling through long recordings.
High-Resolution Camera Support
Supports IP cameras up to 32MP, giving you flexibility for 4MP, 6MP, 8MP, panoramic and specialist high-resolution camera systems.
2 HDD Bays for Longer Retention
Two internal SATA bays allow larger surveillance-grade storage options for higher-resolution systems and longer recording history.
Powerful AI Features for Modern CCTV
Powered by Dahua Xinghan AI Architecture
The DHI-NVR5208-8P-AI/ANZ-PRO is built on Dahua’s advanced Xinghan AI architecture, designed to improve intelligent video search, target filtering, metadata processing and overall AI CCTV performance for modern surveillance systems.
This Dahua AI recorder supports advanced analytics by recorder and by compatible camera, giving Australian homes and businesses a smarter CCTV platform without needing a separate VMS server.
AI by Recorder
Supports features such as face detection, face recognition, AcuPick, perimeter protection, SMD Plus and video metadata depending on system configuration.
Combined with Dahua AcuPick and Xinghan AI processing, this recorder helps operators locate relevant people and vehicle events faster across compatible AI camera systems.
AI by Camera
Unlock advanced functions from compatible Dahua AI cameras, including ANPR, people counting, heat map, metadata, face recognition and perimeter protection.
Smarter Event Filtering
Focus on humans, vehicles and important security activity instead of basic motion events caused by rain, insects, shadows or moving trees.
Ideal for Evidence Review
A strong option for driveways, shopfronts, loading bays, office corridors, car parks and shared entry points where fast video review matters.
Official Dahua Videos
Watch official Dahua videos showing how AcuPick helps locate useful footage faster.
Dahua AcuPick 2.0 Official Video
Dahua Webinar | AcuPick Australia & New Zealand
Best Suited For
Premium Home CCTV
Ideal for driveways, garages, gates, front entries, side access areas and larger homes needing smarter people and vehicle search.
Retail & Shopfronts
Great for customer areas, POS zones, stock rooms, entries and after-hours monitoring where quick footage review matters.
Warehouses & Workshops
Suitable for roller doors, loading bays, vehicle movement, stock areas, staff entrances and back-of-house security.
Offices & Commercial Sites
A clean 8-camera PoE recorder for reception areas, corridors, shared entries, car parks and small business CCTV systems.
Technical Specifications
Model
DHI-NVR5208-8P-AI/ANZ-PRO
Product Type
8 Channel AI Network Video Recorder
Video Inputs
8 IP channels
PoE Ports
8 built-in PoE/ePoE ports
Camera Resolution
Supports IP cameras up to 32MP
Decoding
Up to 32 × 1080p at 30fps or 8 × 8MP at 30fps
Bandwidth
Up to 384Mbps incoming, recording and outgoing bandwidth
AI Search
AcuPick up to 8 channels
Compression
Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG
Storage
2 × SATA HDD bays
Display Output
HDMI and VGA
Advanced Features
N+M cluster and iSCSI support
Recommended Add-Ons
Surveillance Hard Drive
Add a WD Purple or Seagate SkyHawk surveillance HDD for reliable 24/7 CCTV recording.
Dahua AI Cameras
Pair with compatible Dahua WizSense, WizMind or TiOC cameras to unlock stronger AI search and event filtering.
UPS Battery Backup
Protect your recorder from short outages and power interruptions with a suitable UPS battery backup.
Professional Cabling
Use quality Cat6 network cable for clean PoE camera runs and dependable network performance.
Helpful Internal Links
Shop Dahua NVR Recorders
Shop Dahua CCTV Cameras
Shop Dahua TiOC Cameras
Shop Surveillance Hard Drives
Shop CCTV Kits
Frequently Asked Questions
How many cameras can the DHI-NVR5208-8P-AI/ANZ-PRO support?
It supports up to 8 IP cameras.
Does it have built-in PoE?
Yes. It includes 8 built-in PoE/ePoE ports, allowing compatible IP cameras to connect directly to the recorder with network cable.
Does this NVR support AcuPick?
Yes. It supports Dahua AcuPick intelligent search with up to 8 channels when paired with compatible Dahua cameras.
Can it support 8MP or 4K cameras?
Yes. It supports 8MP cameras and can support IP cameras up to 32MP depending on the camera model and system design.
Does it include a hard drive?
Please check the selected product option. Many professional NVRs are supplied without HDD so you can choose the right surveillance-grade storage size.
Is this suitable for Australian homes and businesses?
Yes. It is a strong choice for homes, shops, offices, warehouses, cafés, workshops and small commercial sites.
Downloads & Official Resources
Official
Dahua Product Page
Dahua
Download Centre
NVR5208-8P-AI/ANZ-PRO
Datasheet
Order the Dahua DHI-NVR5208-8P-AI/ANZ-PRO from CCTV Guru
Order from CCTV Guru for a premium 8 channel Dahua AI CCTV recorder with built-in PoE/ePoE, AcuPick intelligent search and Australian support. Need help building a full system? Our team can recommend compatible Dahua cameras, storage, cabling and accessories for your site.
8-Channel DVR · Hikvision AcuSense · 4K Turbo HD · AI Perimeter Detection · HDTVI + IP
Hikvision iDS-7208HUHI-M2/S — 8 Channel AcuSense 4K Turbo HD DVR
The Hikvision iDS-7208HUHI-M2/S is Hikvision's flagship 8-channel AcuSense DVR for Australian installers and integrators who demand AI-powered false alarm reduction, 4K recording, and maximum camera flexibility in a compact 1U chassis. As a true Turbo HD DVR, it accepts HDTVI, AHD, HDCVI, CVBS, and IP cameras on the same unit — protecting your existing coaxial cable investment while giving you a clear upgrade path to full IP.
Powered by Hikvision's AcuSense deep learning engine, the iDS-7208HUHI-M2/S delivers human and vehicle classification across all analogue channels — dramatically reducing false alarms from animals, foliage, and environmental noise. Combined with 4K recording, H.265+ compression, and dual HDD bays, this is the recorder that outperforms everything else at its price point. HDD not included — add a surveillance-grade drive at checkout.
Channels
8 Analogue + 2 IP
Max Resolution
4K (8MP)
AI
AcuSense · Human & Vehicle
Inputs
HDTVI / AHD / HDCVI / IP
Compression
H.265+ / H.265
Storage
2 × HDD Bays (No HDD)
Australian Stock · Fast Dispatch
Hikvision Manufacturer Warranty
Expert Australian Tech Support
Key Features
AcuSense AI — Human & Vehicle Classification
Hikvision's AcuSense deep learning engine classifies motion events as human or vehicle — filtering out animals, foliage, rain, and other false triggers. Only real threats generate alerts. Dramatically reduces alarm fatigue for operators and end users alike.
4K Recording (8MP)
Records analogue channels at up to 4K resolution via HDTVI, and IP channels at up to 8MP. Capture faces, licence plates, and fine detail with confidence — even on wide-angle shots covering large areas.
Perimeter Protection — Line Crossing & Intrusion Detection
Define virtual tripwires and intrusion zones on analogue channels. The DVR triggers alerts only when a classified human or vehicle crosses the boundary — not every time a leaf blows past or a cat walks through frame.
Turbo HD — 5-in-1 Camera Compatibility
Accepts HDTVI, AHD, HDCVI, CVBS analogue cameras and IP cameras simultaneously. Reuse existing coaxial cable infrastructure while adding IP cameras on the same DVR. No rip-and-replace required.
Dual HDD Bays — Up to 16TB Total
Two 3.5" SATA HDD bays support up to 8TB per drive (16TB total) — double the storage capacity of single-bay recorders. Longer retention periods without compromising resolution or frame rate.
H.265+ Compression
H.265+ dual-stream compression reduces storage consumption by up to 75% versus H.264 — meaning your HDDs last longer and your bandwidth stays manageable across remote monitoring connections.
Smart Search & Quick Playback
Search recorded footage by human or vehicle events rather than scrubbing through hours of continuous recording. Find the clip you need in seconds — critical for incident investigation and insurance claims.
Remote Access via Hik-Connect & iVMS-4200
Monitor live and recorded footage from anywhere via the Hik-Connect mobile app (iOS & Android) or iVMS-4200 desktop client. P2P connection — no static IP or port forwarding required.
Recommended For
Analogue Camera Upgrades
Already have coaxial cable runs? Keep them. The iDS-7208HUHI-M2/S connects your existing HDTVI, AHD, or HDCVI cameras while letting you add IP cameras on the same DVR — a cost-effective upgrade path to AcuSense AI.
Small Retail & Convenience Stores
8 channels covers entry, POS counter, stockroom, and car park. AcuSense filters out false alarms from foot traffic — only genuine human intrusion events trigger notifications after hours.
Warehouses & Industrial Sites
Perimeter Protection secures loading docks and yard boundaries. Dual HDD bays provide extended retention for large sites with high camera activity.
Small Offices & Commercial Premises
Compact 1U chassis fits in a server rack or comms cabinet. Remote access via Hik-Connect keeps management informed without on-site visits.
Residential Homes
8 channels covers every entry point, garage, and outdoor area. AcuSense eliminates nuisance alerts from pets and passing cars. Hik-Connect app provides instant mobile push notifications.
Schools & Childcare Centres
AI-powered human detection reduces nuisance alerts in busy environments. Smart Search speeds up incident review for duty-of-care compliance.
Add a Surveillance HDD
HDD Not Included — Choose Your Capacity
The iDS-7208HUHI-M2/S has 2 × 3.5" SATA HDD bays supporting up to 8TB per drive (16TB total). We recommend a WD Purple Pro or Seagate SkyHawk AI surveillance-grade drive — purpose-built for 24/7 AI DVR workloads. Contact our team for a retention calculation based on your camera count, resolution, and recording schedule.
Estimated Retention (8 × 5MP @ 15 fps, H.265+)
2TB ≈ 10–14 days · 4TB ≈ 20–28 days · 8TB ≈ 40–56 days per drive. With 2 × 8TB drives, achieve up to 112 days of continuous recording. H.265+ compression significantly extends these estimates versus standard H.264 recorders.
Technical Specifications
Video Input
8 × BNC (HDTVI / AHD / HDCVI / CVBS) · Up to 2 additional IP camera channels · Max 8MP per IP channel
Max Recording Resolution
4K (3840 × 2160) via HDTVI · 8MP via IP
Compression
H.265+ / H.265 / H.264+ / H.264 dual-stream · AcuSense AI coding
AI Features
AcuSense human & vehicle classification · Perimeter Protection (line crossing + intrusion) · Smart Search by event type
Bandwidth & Storage
Incoming bandwidth: up to 200 Mbps · 2 × SATA HDD bays (up to 8TB each) · HDD not included
Network & Remote Access
TCP/IP · P2P · Hik-Connect app (iOS & Android) · iVMS-4200 desktop · ONVIF · 1 × RJ45 10/100/1000M
Video Output
1 × HDMI (4K) · 1 × VGA · Simultaneous output supported
Form Factor & Power
Compact 1U chassis · 100–240V AC · Operating temp: -10°C to +55°C
More Information
Datasheet
Quick Start Guide
Frequently Asked Questions
Does the DVR include an HDD?No — an HDD is not included. Add a WD Purple Pro or Seagate SkyHawk AI surveillance-grade drive at checkout. Contact us for a sizing recommendation based on your camera count and recording schedule.
Can I connect IP cameras to this DVR?Yes — the iDS-7208HUHI-M2/S supports up to 2 additional IP camera channels at up to 8MP each, in addition to the 8 BNC analogue inputs.
What analogue camera types are supported?HDTVI, AHD, HDCVI, and CVBS (standard definition) cameras are all supported on the BNC inputs — mix and match as needed.
What is AcuSense?AcuSense is Hikvision's deep learning AI that classifies motion events as human or vehicle, filtering out animals, foliage, and environmental noise. It dramatically reduces false alarms and makes footage search faster.
Can I view footage remotely?Yes — the Hik-Connect app (iOS & Android) and iVMS-4200 desktop client provide remote access via P2P. No static IP or port forwarding required.
How many HDD bays does it have?Two 3.5" SATA HDD bays, each supporting drives up to 8TB (16TB total capacity).
Does it support 4K recording?Yes — up to 4K (3840 × 2160) via HDTVI cameras, and up to 8MP via IP cameras.
What is the difference between iDS and DS series DVRs?The iDS prefix indicates AcuSense AI capability — human and vehicle classification on analogue channels. DS series DVRs use standard motion detection without AI classification.
Is it compatible with Hikvision AcuSense cameras?Yes — pairing with Hikvision AcuSense HDTVI cameras maximises AI performance. The DVR also works with non-AcuSense cameras using its own onboard AI processing.
What's the warranty?Hikvision manufacturer warranty, supported locally by CCTV Guru's Australian technical team.
Do you ship Australia-wide?Yes — fast dispatch to every state and territory from Australian stock.
Order the Hikvision iDS-7208HUHI-M2/S from CCTV Guru
CCTV Guru is an authorised Australian distributor of Hikvision surveillance products. Order the Hikvision iDS-7208HUHI-M2/S 8-Channel AcuSense 4K Turbo HD DVR today for fast Australia-wide dispatch, expert pre-sales advice on HDD sizing and camera compatibility, and full local warranty support. Contact our Australian team to add surveillance HDDs, compatible Hikvision AcuSense cameras, or build a complete Turbo HD system package.
Looking for a PoE NVR instead? View our Hikvision NVR range →
Hikvision ColorVu 3.0 · 4 × Live-Guard Turrets · 6MP or 8MP · 8CH PoE NVR
4 × ColorVu Live-Guard Kit
Hikvision 4-Camera ColorVu 3.0 Live-Guard Active Deterrence CCTV Kit with 8-Channel PoE NVR — 6MP or 8MP
The Hikvision 4-Camera ColorVu 3.0 Live-Guard Kit is a ready-to-install active-deterrence bundle for Australian homes, shops, offices and small commercial sites. It pairs four ColorVu 3.0 Smart Hybrid Light Live-Guard turrets — your choice of 6MP (DS-2CD2367G3-LIS2UY/SL) or 8MP 4K (DS-2CD2387G3-LIS2UY/SL) — with a DS-7608NI-M2/8P-M 8-channel PoE NVR. On AcuSense human/vehicle detection every camera can fire a white-light strobe, 110 dB siren and live two-way audio — stopping intruders instead of just recording them — while delivering true 24/7 colour to 0.0005 lux. All 8 PoE ports power each camera over a single Cat6 run, with room to grow to eight cameras.
Cameras
4 × ColorVu · 6MP or 8MP
Recorder
8CH 8K NVR · 8 PoE
Active Deterrence
Strobe + 110dB Siren
Colour Night
24/7 ColorVu · 0.0005 lux
Audio
2-Way · Mic + Speaker
Storage
2 × SATA · Add HDD
ColorVu 3.0 — True 24/7 Colour
A 1/1.8" sensor and F1.0 super-aperture deliver full-colour images down to 0.0005 lux. Smart Hybrid Light adds white light or IR (up to 30 m) so you capture clothing and number-plate colour all night, not grey IR.
Live-Guard Active Deterrence
On AcuSense human/vehicle detection each camera flashes a white strobe, sounds a 110 dB warning and lets you talk down live via Hik-Connect — turning intruders away before they reach the door.
8-Port PoE — Plug & Play
One Cat6 cable per camera carries power and video to the NVR's 8 built-in PoE ports — no separate power supplies, no extra switch, commissioning in minutes.
6MP or 8MP — Your Choice
Pick 6MP (3200 × 1800) for excellent detail and lower storage use, or 8MP 4K (3840 × 2160) for maximum clarity on faces, plates and large coverage areas. Same Live-Guard deterrence either way.
What's Included
4 × Cameras
4 × ColorVu Live-Guard turret (6MP or 8MP — choose your variant): DS-2CD2367G3-LIS2UY/SL (6MP) or DS-2CD2387G3-LIS2UY/SL (8MP). ColorVu 3.0 Smart Hybrid Light turret, 2.8 mm lens, white strobe + 110 dB speaker + two-way audio, F1.0 24/7 colour, AcuSense, IP67. Each ships with mounting bracket, drill template, screws & quick start guide.
1 × Recorder
DS-7608NI-M2/8P-M — 8-channel M-Series NVR with 8 built-in PoE ports, dual SATA bays, up to 32 MP per channel, 8K HDMI output and Hik-Connect remote access.
Storage
No hard drive is included. Add a surveillance-grade HDD (WD Purple / Seagate SkyHawk) to suit your retention — 4TB suits most 4-camera installs, 6TB+ for the 8MP kit or continuous recording. The NVR has two SATA bays for up to 32 TB total.
Power
8 × PoE ports built into the NVR — one Cat6 network cable per camera carries power and data, so there are no separate power supplies. Network cabling is run on site and is not included; pre-made Cat6 patch leads are available separately.
Mounting
Brackets and templates included for eave/soffit installs. For brick or flush-wall mounting, add a Hikvision wall-mount bracket per camera; a junction box is also available for tidy cable management.
Warranty
3-Year Australian warranty · local CCTV Guru tech support. Genuine Hikvision Australian stock.
Best For
Family homes
Front doors, driveways, side gates and back yards with active deterrence on every approach.
Shops & cafés
Entries, counters, storerooms and rear lanes — strobe & siren after hours, talk-down by day.
Offices & clinics
Reception, car parks and rear doors with full-colour detail and HTTPS remote access.
Warehouses & yards
Docks, gates and perimeters with full-colour plate capture and audible warnings.
Rental & holiday homes
Perimeter cover with live talk-down and event alerts straight to your phone.
Tradies & depots
Deter after-hours theft of tools and stock with visible strobe and audible warnings.
Camera Specifications — DS-2CD2387G3-LIS2UY/SL (8MP) & DS-2CD2367G3-LIS2UY/SL (6MP)
Camera Type
ColorVu 3.0 Smart Hybrid Light AcuSense Live-Guard Fixed Turret
Image Sensor
1/1.8" Progressive Scan CMOS · ColorVu 3.0
Max. Resolution
8MP = 3840 × 2160 (4K) · 6MP = 3200 × 1800 — depending on chosen variant
Min. Illumination
Colour 0.0005 lux @ F1.0 · 0 lux with white light
Lens
Fixed 2.8 mm · F1.0 · wide horizontal FOV
Supplement Light
Smart Hybrid Light (white + IR) · up to 30 m · 3 modes
WDR
130 dB scene-adaptive
AI Functions
AcuSense · human & vehicle classification · perimeter protection
Active Deterrence
White-light strobe · built-in 110 dB speaker · two-way audio
Audio
Built-in arrayed dual microphone + speaker
Compression
H.265+ / H.265 / H.264+ / H.264
Power
12 VDC / PoE (IEEE 802.3at)
Ingress Protection
IP67 weatherproof
Warranty (Australia)
3 years · CCTV Guru Australia
Recorder Specifications — DS-7608NI-M2/8P
Channels
8 IP channels · up to 32 MP input
Incoming Bandwidth
80 Mbps
PoE
8 × PoE ports (IEEE 802.3 af/at)
Storage
2 × SATA (up to 16 TB per bay, 32 TB total) · HDD not included
Video Output
1 × HDMI (up to 8K) + 1 × VGA · simultaneous
AI Functions
AcuSense human/vehicle · perimeter · facial (with compatible cameras)
Compression
H.265+ / H.265 / H.264+ / H.264
Remote / App
Hik-Connect (iOS & Android) · P2P · ONVIF
Installation Notes
›Cabling: run solid-copper Cat6 from each camera back to the NVR's PoE ports for stable power and video over long distances.
›Weatherproofing: even at IP67, seal outdoor RJ-45 joins with weatherproof tape or a junction box to keep out moisture and salt air.
›Deterrence zones: set AcuSense detection zones on the highest-risk approaches so the strobe and siren trigger on real human/vehicle events only.
Setup & Demo Videos — Hikvision
Smart Hybrid Light + ColorVu — 24/7 colour imaging
AcuSense — human & vehicle detection
Downloads & Resources
8MP Camera Datasheet (DS-2CD2387G3)
6MP Camera Datasheet (DS-2CD2367G3)
DS-7608NI-M2/8P Datasheet
Hikvision Camera Quick Start Guide
Should I choose the 6MP or 8MP kit?Both use the same ColorVu 3.0 Live-Guard turret with strobe, siren and two-way audio. Choose 6MP (3200 × 1800) for excellent detail and lower storage use; choose 8MP 4K (3840 × 2160) for maximum clarity on faces, plates and larger coverage areas.
What is Live-Guard active deterrence?On AcuSense human/vehicle detection each camera flashes a white-light strobe, sounds a 110 dB warning and lets you open live two-way audio via Hik-Connect — actively turning intruders away.
Do these really see colour at night?Yes — ColorVu 3.0 with an F1.0 super-aperture delivers full-colour images down to 0.0005 lux, with Smart Hybrid Light adding white light or IR as needed.
Is a hard drive included?No — this kit ships without an HDD so you can size storage to your needs. Add a surveillance-grade drive (4TB suits most 4-camera installs, 6TB+ for 8MP or continuous recording); the NVR has two SATA bays for up to 32 TB total.
How are the cameras powered, and can I add more?Each camera runs on a single Cat6 cable to one of the NVR's 8 built-in PoE ports — no separate power supplies. The 8-channel NVR lets you add up to four more compatible Hikvision IP cameras later.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision 9MP · DeepinView · 360° Fisheye · People Counting
Hikvision DS-2CD6395G1E-IVS 9MP DeepinView 360° Fisheye Camera — People Counting, Heat Mapping, Built-in Mic & Speaker
The Hikvision DS-2CD6395G1E-IVS is a 9 MP DeepinView panoramic fisheye camera delivering full 360° overhead coverage from a single ceiling-mounted unit. A 1/1.8" progressive-scan CMOS sensor paired with a fixed 2 mm fisheye lens produces a circular 3024 × 3024 image, with up to 20 on-board display / dewarp modes (fisheye, 180° panorama, 360° panorama, 360°+PTZ and more). Built for retail and people-analytics, it adds on-board people counting, heat mapping and queue management, with built-in IR, a built-in microphone and speaker for two-way audio, and a tough IP67 / IK10 housing. Australian stock, 3-Year Australian warranty.
Resolution
9 MP · 3024 × 3024
Coverage
360° Panoramic Fisheye
Lens
2 mm Fixed Fisheye
Analytics
People Counting · Heat Map · Queue
Audio
Built-in Mic + Speaker · 2-Way
Protection
IP67 · IK10 · 3-Year AU
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Key Features
9 MP 360° Panoramic Imaging
A single overhead fisheye covers an entire room or sales floor with no blind spots — replacing several fixed cameras. The 3024 × 3024 circular image dewarps into panoramic and quad-PTZ views in-browser or on the NVR.
People Counting & Queue Management
On-board people counting tracks entries and exits across virtual lines, while queue-management analytics monitor wait times — ideal for retail conversion, occupancy and staffing decisions.
Heat Mapping
Built-in heat-map analytics visualise dwell time and footfall density across the scene, showing which areas of a store or space attract the most attention over time.
Two-Way Audio
A built-in microphone and speaker enable live two-way audio — announcements, staff communication or visitor interaction directly through the camera.
Why Choose the DS-2CD6395G1E-IVS
One Camera, Whole Room
360° overhead coverage means one cable run, one licence and one mounting point instead of multiple cameras around a perimeter — lower install cost and cleaner ceilings.
DeepinView Analytics Engine
Hikvision's DeepinView platform brings deep-learning analytics on-board, so footfall, heat-map and queue data are generated at the edge without a separate analytics server.
Built for Exposed Installs
IP67 weatherproofing and IK10 vandal resistance rated from −30 °C to +60 °C let this fisheye go indoors or under cover outdoors with confidence.
Built-in IR
Integrated infrared illumination keeps the full 360° scene usable after dark for monitoring as well as analytics.
Recommended For
Retail & Shopping Centres
Footfall counting, heat mapping and queue analytics for conversion and merchandising insight.
Reception & Open Offices
Single-camera overhead coverage of lobbies, foyers and open-plan floors.
Warehouses & Showrooms
Wide panoramic monitoring of large open spaces from one ceiling mount.
Hospitality & Venues
Occupancy monitoring and people flow for cafes, bars, waiting areas and event spaces.
Technical Specifications
DS-2CD6395G1E-IVS · Full Specifications
SKU
DS-2CD6395G1E-IVS
Camera Type
Hikvision DeepinView 9 MP 360° Panoramic Fisheye Network Camera
Image Sensor
1/1.8" Progressive Scan CMOS
Max Resolution
3024 × 3024 (9 MP)
Lens
2 mm fixed fisheye
Display Modes
Up to 20 modes — fisheye / 180° panorama / 360° panorama / 360°+PTZ and more
Frame Rate
50 Hz: 25 fps · 60 Hz: 30 fps (fisheye view)
Supplement Light
Built-in IR
Smart Analytics
People counting · heat mapping · queue management · perimeter protection
Audio
Built-in microphone & speaker · two-way audio
Video Compression
H.265+ / H.265 / H.264+ / H.264
Protocols
ONVIF · ISAPI · SDK
Operating Temperature
−30 °C to +60 °C
Weatherproof Rating
IP67
Impact Rating
IK10 vandal-resistant
Warranty
3-Year Australian Warranty
Frequently Asked Questions
What area does a single fisheye cover?Mounted overhead, the 2 mm fisheye lens captures a full 360° circular view of the room or floor below — one camera replaces several fixed cameras for open-plan spaces.
Does it really do people counting and heat mapping?Yes — people counting, heat mapping and queue-management analytics run on-board via Hikvision's DeepinView engine, generating footfall and dwell data at the edge.
Is it 9 MP or 12 MP?The DS-2CD6395G1E-IVS is a 9 MP fisheye (3024 × 3024). Hikvision's 12 MP panoramic models use different DS-2CD63C5 part numbers.
Can it be used outdoors?Yes — it carries an IP67 weatherproof and IK10 vandal-resistant rating and operates from −30 °C to +60 °C, suitable for covered outdoor and exposed indoor installs.
Does it have audio?Yes — a built-in microphone and speaker provide two-way audio for announcements and live communication.
Downloads & Resources
DS-2CD6395G1E-IVS Datasheet
Hikvision Network Camera Quick Start Guide
CCTV Guru is an authorised Australian reseller of Hikvision DeepinView analytics cameras. Order the DS-2CD6395G1E-IVS 9 MP 360° fisheye for fast Australia-wide dispatch, expert pre-sales advice and full local warranty support. Request a free quote or contact our Australian team.
Hikvision Video Intercom Accessory
Hikvision DS-KABV6114-RS Rain Shield for Villa Door Stations
The Hikvision DS-KABV6114-RS is a genuine protective rain shield designed for compatible
Hikvision villa door stations. It helps protect the outdoor intercom from direct rain exposure while giving
the installation a cleaner, more professional surface-mounted finish.
This accessory is ideal when installing a Hikvision door station on an exposed wall, front gate pillar,
entryway or outdoor-facing surface where extra protection and a neater finish are required.
Protection
Rain Shield Cover
Compatibility
KV6114 / KV6124 Series
Mounting
Surface Mount
Material
PC Protective Body
Why Use the DS-KABV6114-RS?
Helps Protect Outdoor Door Stations
Adds a protective cover around the compatible Hikvision villa door station to help reduce direct exposure
to rain and outdoor conditions.
Cleaner Surface-Mounted Finish
Gives the installation a more finished look, especially on rendered walls, brickwork, gate pillars and
exposed entrance areas.
Made for Compatible Hikvision Models
Designed for Hikvision KV6114 and KV6124 series villa door stations, including popular 4MP Hikvision
villa intercom door stations.
Ideal for Homes and Small Businesses
A simple but useful add-on for front doors, gates, offices, townhouses, duplexes and small commercial
entry points.
Key Specifications
Model
DS-KABV6114-RS
Product Type
Rain shield / protective shield for Hikvision villa door stations
Installation
Surface mounting
Compatible Series
Hikvision DS-KV6114 / DS-KV6124 series villa door stations
Material
PC
Dimensions
194.49 mm × 84.62 mm × 47 mm
Working Temperature
-40°C to 60°C
Working Humidity
10% to 95%, non-condensing
Compatible Hikvision Door Stations
The DS-KABV6114-RS is commonly used with Hikvision villa door stations from the KV6114 and KV6124 series.
It is especially useful when the door station is installed outdoors or in an area with partial weather exposure.
DS-KV6114 Series
Suitable for compatible Hikvision DS-KV6114 villa door stations where a surface-mounted rain shield is required.
DS-KV6124 Series
Suitable for compatible Hikvision DS-KV6124 keypad villa door stations where extra outdoor protection is preferred.
Recommended Add-ons
Hikvision Villa Door Station
Pair this rain shield with a compatible Hikvision DS-KV6114 or DS-KV6124 villa door station.
Hikvision Indoor Monitor
Complete the intercom setup with a compatible Hikvision indoor station for video calling and door release control.
Electric Strike or Gate Relay
Add door or gate release hardware so visitors can be granted access from the indoor monitor or app.
PoE Switch or Power Supply
Depending on your intercom design, a PoE switch, power supply or compatible network hardware may be required.
FAQs
What is the DS-KABV6114-RS used for?
It is a rain shield / protective shield for compatible Hikvision villa door stations.
Is this a Hikvision genuine accessory?
Yes. The DS-KABV6114-RS is a Hikvision video intercom accessory.
Does it suit the DS-KV6114 series?
Yes. It is designed for compatible Hikvision KV6114 series villa door stations.
Does it suit the DS-KV6124 series?
Yes. It is also commonly listed for compatible KV6124 series villa door stations.
Is this for surface mounting?
Yes. The DS-KABV6114-RS is designed for surface-mounted installations.
Is it suitable for outdoor intercom installs?
Yes. It is designed to help protect compatible outdoor villa door stations from direct weather exposure.
Genuine Hikvision
Australia-Wide Shipping
Fast Dispatch
Hikvision AX Hybrid Pro Alarm Bundle
Hikvision AX Hybrid Pro Wired Alarm Kit with 3 PIRs, Keypad, Siren, Battery, PSU & Keytags
Secure your home, shop, office or small business with this complete Hikvision AX Hybrid Pro wired alarm kit.
This bundle includes the AX Hybrid Pro control panel, LCD keypad, 3 wired PIR motion detectors, PIR brackets, wired siren,
12V backup battery, PSU and 3 keytags.
Built around the DS-PHA64-LP/NP alarm panel, this kit gives you a professional wired alarm foundation with
room to expand. The panel supports up to 64 alarm inputs, including 8 on-board zones, making it suitable for
both residential and commercial security installations.
Alarm Panel
64-Zone Hybrid Pro
Control
LCD Keypad + Keytags
Detection
3 × 18m PIR Sensors
Alert
105dB Wired Siren
What’s Included
1 × DS-PHA64-LP/NP
Hikvision AX Hybrid Pro intrusion alarm control panel
1 × DS-PK1-LRT-HWB
Hikvision wired LCD keypad for everyday arm/disarm control
3 × DS-PDP18-EG2(B)
Hikvision wired PIR motion detectors with up to 18m detection range
3 × PIR Brackets
Mounting brackets for flexible PIR installation
1 × DS-PS1-B
Hikvision wired siren / sounder with 105dB alarm output
1 × SA12V7
12V 7Ah sealed lead-acid backup battery
3 × Keytags
Convenient keytag access for quick arm/disarm operation
1 × PSU
Power supply unit included
Why Choose This Hikvision Alarm Bundle?
Professional Wired Security
A wired alarm system is ideal for permanent installations where stable detection, reliable power and long-term performance matter.
Expandable AX Hybrid Pro Platform
The DS-PHA64-LP/NP supports up to 64 alarm inputs, giving your installer room to expand the system with additional zones and accessories.
3 × Indoor PIR Motion Detectors
The included DS-PDP18-EG2(B) detectors support up to 18m detection range, 85.9° detection angle and 15kg pet immunity.
Loud Local Siren Alert
The included DS-PS1-B wired sounder provides a 105dB alarm output at 30cm with IP54 protection and separate sound/LED flash indication.
Ideal For
Homes
Protect hallways, living areas, garages and key internal movement paths.
Retail Shops
Secure shop floors, rear doors, stock rooms, counters and after-hours entry points.
Offices
Give staff simple keypad/keytag control while protecting work areas and entry paths.
Small Warehouses
Create a strong wired alarm foundation with expansion options for larger layouts.
Key Specifications
System Type
Hikvision AX Hybrid Pro wired / hybrid intrusion alarm kit
Control Panel
DS-PHA64-LP/NP
Alarm Inputs
64 total, including 8 on-board zones
Alarm Outputs
64 total, including on-board relay and I/O outputs
PIR Detection Range
Up to 18m
PIR Detection Angle
85.9°
PIR Pet Immunity
Up to 15kg
Siren Output
105dB at 30cm
Siren Protection
IP54
Backup Battery
12V 7Ah SLA battery included
More Information
Everything you need to review the main Hikvision alarm components before installation.
DS-PHA64-LP/NP Panel Details
DS-PDP18-EG2(B) PIR Details
DS-PS1-B Siren Details
Installation Notes
This is a professional wired alarm kit and should be installed, wired and programmed by a qualified security installer.
Final detector placement, zone programming, siren location, battery connection and power setup should be confirmed during installation.
Is this a wired alarm kit?
Yes. This bundle includes a wired/hybrid AX Hybrid Pro panel, wired keypad, wired PIR detectors and wired siren.
Can this alarm system be expanded?
Yes. The DS-PHA64-LP/NP supports up to 64 alarm inputs, making it suitable for future expansion.
Does it include motion detectors?
Yes. This kit includes 3 × DS-PDP18-EG2(B) wired PIR motion detectors and 3 PIR brackets.
Does it include a siren?
Yes. This kit includes 1 × DS-PS1-B wired siren with 105dB alarm output.
Does it include a backup battery?
Yes. This bundle includes 1 × SA12V7 12V 7Ah backup battery.
Who should install this kit?
A qualified security installer is recommended for correct wiring, programming and compliance.
Genuine Hikvision
Australia-Wide Shipping
Fast Dispatch
Thermal • Fire Detection • HeatPro
Hikvision HeatPro Thermal Camera for Early Fire Detection & Temperature Monitoring
The Hikvision HM-TD1218-2-G0/T1A HeatPro thermal camera is designed for proactive fire prevention and temperature monitoring in high-risk environments. Using advanced thermal imaging, it detects abnormal heat before fire occurs, providing real-time alerts for enhanced safety.
Thermal Imaging
256×192
Detection
Fire & Heat
Protection
24/7 Monitoring
Early Fire Detection
Identify abnormal temperature changes before smoke or flames appear, reducing risk and response time.
Accurate Temperature Measurement
Real-time temperature monitoring with alarm triggers for overheating equipment or areas.
Works in Total Darkness
Thermal imaging does not rely on light, ensuring full protection day and night.
Reduced False Alarms
Advanced algorithms minimise false alerts caused by shadows or lighting changes.
Industrial-Grade Reliability
Built for demanding environments including warehouses, factories and energy sites.
Integrated Smart Alerts
Instant notifications for abnormal heat events, enabling rapid response.
Ideal Applications
Warehouses Prevent fire from overheating stock or equipment.
Factories Monitor machinery temperature in real-time.
Electrical Rooms Detect overheating circuits early.
Waste Facilities Identify heat build-up before ignition.
Key Specifications
Thermal Resolution
256 × 192
Lens
2.1 mm
Temperature Range
Up to 550°C (approx)
Accuracy
±2°C
Alarm Functions
Fire detection & temperature alarm
Video Output
Thermal + optical
Protection
IP67
More Information
DatasheetPDF
Quick Start GuideSetup
User ManualFull Guide
Authorised Hikvision Reseller
Fast Australia-Wide Shipping
Expert CCTV Support
Hikvision TandemVu ANPR · Dual 4MP · 8–32 mm + 4 mm
Hikvision iDS-2CD8A46G2-XZHSY(0832/4) — Dual-Sensor DeepinView ANPR Bullet Camera
The iDS-2CD8A46G2-XZHSY(0832/4) combines two 4MP views in one camera: an 8–32 mm motorised ANPR channel for number-plate detail and a 4 mm fixed overview channel for wider scene context. It is intended for professional car parks, gates, driveways and road-monitoring projects where an operator needs both the plate image and the surrounding vehicle event.
Hikvision’s ANPR functions can recognise number plates and vehicle attributes, while compatible Hikvision recorders or HikCentral systems can support alerts and forensic search. Capture performance depends on correct lane geometry, mounting height, shutter settings, lighting, vehicle speed and commissioning.
Why an end user would choose it
Two views from one camera: a detailed ANPR stream and a wide overview stream help explain the full event.
Dual 4MP imaging: up to 2688 × 1520 on each channel.
Flexible plate framing: the 8–32 mm motorised lens can be set for the required lane and capture distance.
Wider context: the fixed 4 mm channel records the vehicle and surrounding scene.
Strong night performance: Smart Hybrid Light reaches up to 100 m on the ANPR channel and up to 40 m on the overview channel under suitable conditions.
Backlight control: 140 dB WDR helps at headlights, entrances and changing daylight.
Professional protection: IP67 and IK10; the Y model also carries NEMA 4X moderate anti-corrosion protection.
Efficient storage: H.265+ compression and five streams support different recording and viewing needs.
Channel comparison
Channel
Lens
Main purpose
Supplementary light
ANPR detail
8–32 mm motorised
Plate and vehicle detail
Up to 100 m
Overview
4 mm fixed
Wide scene context
Up to 40 m
Important before you buy
This is a specialist project camera. Professional design and commissioning are strongly recommended.
ANPR accuracy is not guaranteed for every plate or vehicle. Results depend on plate condition, local formats, speed, angle, glare, weather and configuration.
Confirm that the selected NVR or HikCentral version supports the ANPR search, list and alert functions you require.
Privacy, signage and data-retention requirements apply to number-plate collection. The system owner is responsible for lawful use.
The exact official model supplied is iDS-2CD8A46G2-XZHSY(0832/4).
Key specifications
Resolution: 4MP + 4MP, up to 2688 × 1520 per channel
Lenses: 8–32 mm motorised ANPR lens + 4 mm fixed overview lens
Low light: DarkFighter 2.0
WDR: 140 dB
Compression: H.265+/H.265/H.264+/H.264
Protection: IP67, IK10 and NEMA 4X on the Y variant
Use cases: car-park entrances, industrial sites, road monitoring, service stations and residential vehicle access
Frequently asked questions
Why does this camera have two lenses?
The 8–32 mm channel is framed for plate detail, while the 4 mm channel keeps a wider view of the vehicle and scene. This makes events easier to verify than a plate-only image.
Can it recognise number plates at night?
It is designed for night ANPR and uses DarkFighter 2.0 plus Smart Hybrid Light. Reliable results still depend on mounting, exposure settings, vehicle speed and the site lighting.
Does it work with any NVR?
A compatible recorder may record the video, but advanced ANPR search, lists and alerts require a supported Hikvision NVR or HikCentral configuration. Confirm compatibility before ordering.
Is the lens motorised?
The 8–32 mm ANPR lens is motorised for remote framing and focus. The 4 mm overview lens is fixed.
What is the exact SKU?
The official available-model code is iDS-2CD8A46G2-XZHSY(0832/4).
Official Hikvision Australia resources
Hikvision Australia ANPR brochure (PDF)
Official product datasheet (PDF)
Dahua · ARC3800H-FW2 · Wireless Alarm Hub · WiFi + 4G LTEAlarm HubDahua ARC3800H-FW2 Wireless Alarm Hub
The Dahua ARC3800H-FW2 is the central controller for Dahua wireless alarm systems, built for homes, retail stores, offices and commercial sites that need flexible communication and reliable backup connectivity. With Ethernet, WiFi and 4G LTE, it keeps your alarm connected even when one path drops, and pairs with up to 150 Dahua wireless accessories managed through the DMSS app.
Connectivity
WiFi · LAN · 4G
Encryption
AES128
Wireless Band
433MHz
Expandable
150 Devices
Control
DMSS App
Backup
4,750mAh
Multi-Path Communication
Ethernet, WiFi and 4G LTE keep the alarm reporting even if one connection becomes unavailable.
Encrypted Two-Way RF
AES128 encryption with frequency hopping helps protect signals between the hub and connected devices.
App Control via DMSS
Arm, disarm, manage devices and review events remotely through the Dahua DMSS app.
Expandable Platform
Supports up to 150 wireless peripherals — PIRs, PIR cameras, keyfobs, repeaters, sirens and keypads.
Specifications — ARC3800H-FW2
Model
ARC3800H-FW2 (DHI-ARC3800H-FW2)
Type
Wireless Alarm Hub
Network
Ethernet, WiFi and 4G LTE
Ethernet Port
1 × RJ45 10/100 Mbps
SIM Support
Dual SIM, single standby
Wireless Frequency
433.1MHz – 434.6MHz, two-way RF
Encryption
AES128, with frequency hopping
Wireless Peripherals
Up to 150 (64 keyfobs, 64 PIR cameras, 6 sirens, 8 keypads, 4 repeaters)
Video Verification
8-channel IPC alarm video upload
Notifications
App push, SMS & phone call (up to 5 numbers)
Backup Battery
4,750mAh lithium · up to 12h standby
App
Dahua DMSS / COS Pro
Warranty (Australia)
3 years · CCTV Guru Australia
Downloads & Resources
ARC3800H-FW2 DatasheetDahua Alarm Hub User Manual
Does the ARC3800H-FW2 support 4G LTE backup?Yes. It supports Ethernet, WiFi and 4G LTE cellular communication.
What accessories can I pair?Dahua wireless PIRs, PIR cameras, door contacts, sirens, keypads, repeaters and keyfobs — up to 150 devices.
Can I control it remotely?Yes. The DMSS app handles remote arm/disarm, device management and event review.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua Dual Monitor 2-Wire Intercom Kit
Dahua 2-Wire Video Intercom Kit with Dual 7-Inch Monitors & Smartphone Access
If you want a smarter front door system with access from multiple locations inside your home, this Dahua 2-wire intercom kit is a serious upgrade. With two 7-inch indoor monitors, a modern villa door station and smartphone app control, you can answer your door, talk to visitors and unlock access from wherever you are.
This setup is ideal for double-storey homes, front + rear living areas or shared households where a single monitor just isn’t enough. Combined with Dahua’s 2-wire hybrid system, it also makes a strong option for upgrading older intercom systems without complex rewiring.
Indoor Monitors
2 × 7" Touchscreens
Door Station
IP PoE Villa Unit
Remote Access
Smartphone App
Door Control
Remote Unlock
Why This Dual Monitor Kit Stands Out
Two monitors = better coverage inside your home
Instead of running back to one screen, this kit gives you two indoor monitors so you can answer the door from multiple areas — ideal for upstairs/downstairs or front/back living zones.
Modern IP door station with PoE
The included DHI-VTO2202F-P-S2 is a more advanced IP-based door station with PoE support, giving you stable performance, cleaner installation and better long-term reliability.
Answer from your phone anywhere
With app connectivity, you can see visitors, talk in real time and unlock your door remotely. Perfect for deliveries, guests or when you're not home.
Ideal for upgrades and new builds
This system bridges the gap between simple intercom upgrades and full IP solutions, making it flexible for both renovation projects and new installations.
What’s Included in the Kit
2 × Dahua DHI-VTH5422HW Indoor Monitors
Premium 7-inch touchscreen monitors with WiFi, allowing internal communication, door answering, live view and app connectivity.
1 × Dahua DHI-VTO2202F-P-S2 Door Station
Modern IP villa door station with built-in camera, two-way audio, access control and PoE support for stable operation.
1 × Dahua VTNS1001B-2-A Switch
Core system controller that links your monitors and door station, ensuring reliable communication across the intercom network.
Mounting Options Included
Comes with surface mount bracket (VTM05R) as standard.
Perfect For
Double-storey homes
Answer the door from upstairs or downstairs without missing visitors.
Homes with multiple living zones
Place monitors in different areas so you always have convenient access.
Customers upgrading older intercom systems
Move to video + app control without jumping into overly complex setups.
Front gates and door access control
Combine video verification with remote unlocking for better security and convenience.
Technical Specifications
System Type
2-wire hybrid / IP intercom kit
Indoor Monitors
2 × DHI-VTH5422HW (7" touchscreen, WiFi)
Door Station
DHI-VTO2202F-P-S2 (IP PoE)
Controller
VTNS1001B-2-A
Mounting
Surface (VTM05R) included, flush optional
Audio
Two-way communication
Mobile Access
Smartphone app support
Door Control
Electric lock / gate release supported
Network
PoE door station + WiFi monitor
Frequently Asked Questions
Why choose a dual monitor intercom?
It gives you more flexibility around the home. With two indoor monitors, you can answer the door from multiple locations instead of relying on a single screen.
Can I use my phone to answer the door?
Yes. With app connectivity, you can receive calls, speak with visitors and unlock the door remotely from your smartphone.
Is this better than a single monitor kit?
For larger homes, double-storey layouts or properties with multiple living zones, yes. Two monitors make everyday use more convenient and practical.
Does it support electric locks?
Yes. The system can work with compatible electric door strikes or gate release setups, making it a strong option for front doors and entry gates.
Authorised Australian reseller
Fast AU shipping
Sydney-based expert support
Genuine Dahua · Wall Mount · AluminiumDahua PFB2204WA Clean, Professional Wall Mount for Your Dahua Camera
The Dahua DH-PFB2204W is a neat, durable wall mount bracket that gives your CCTV installation a cleaner, more professional finish. Built from aluminium alloy and SGCC, it positions a wide range of compatible Dahua cameras securely while keeping cabling tidy. Its white finish suits modern residential and commercial sites alike.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why You'll Love It
Aluminium alloy & SGCC build — strong, durable construction for a long-lasting, reliable mount.
Clean white finish — blends discreetly into modern residential and commercial walls.
1.0 kg load capacity — securely supports a wide range of compatible Dahua cameras.
Wide operating range — rated from -40 °C to +60 °C for dependable year-round use.
Specifications
Model
DH-PFB2204W
Category
Wall Mount
Material
Aluminium Alloy & SGCC
Colour
White
Load Capacity
1.0 kg
Dimensions
162.0 mm × 129.4 mm × 80.0 mm
Net Weight
0.49 kg
Operating Temperature
-40 °C to +60 °C
Mounting
Wall mount
Warranty
3 Years (AU)
Frequently Asked Questions
Which cameras is the PFB2204W compatible with?Designed for Dahua dome and turret cameras — check your camera's mounting spec or the Dahua Camera Accessories Selection guide to confirm it lists the PFB2204W.
Can it be used outdoors?Yes. It is rated for operating temperatures from -40 °C to +60 °C, making it suitable for sheltered outdoor and indoor installations.
Is this a genuine Dahua accessory?Yes — the PFB2204W is an official Dahua camera mounting bracket, not a generic substitute.
How much weight can it support?The bracket has a load bearing capacity of 1.0 kg, suited to a wide range of compatible Dahua cameras.
Dahua WizSense 3 · 8MP 4K · Smart Dual Light · AcuPick · IK10Smart Dual Light Dome
Dahua DH-IPC-HDBW3867E-AS-IL-ANZ — 8MP 4K Smart Dual Light AcuPick Vandal Dome Camera
The Dahua DH-IPC-HDBW3867E-AS-IL-ANZ is an 8MP 4K Smart Dual Light fixed-lens vandal dome from Dahua's WizSense 3 Series — engineered for Australian commercial, retail, school, healthcare, government and industrial sites that need 4K detail, full-colour night image, AI search and a tamper-resistant IK10 housing, all in a compact ceiling-flush package. Built around a 1/2.7" CMOS sensor with an F1.4 large aperture, the camera captures crisp 3840 × 2160 footage in a 110° wide field of view, then switches between 30 m invisible IR and 30 m warm-light LED automatically based on what's in the scene — invisible monitoring by default, full-colour evidence the instant a person or vehicle is detected.
Powered by Dahua's WizSense AI, the 3867E adds AcuPick attribute search, SMD 4.0 human/vehicle classification, IVS tripwire + intrusion, AI Coding (≥25% extra compression efficiency), AI SSA scene adaptation and Quick Pick rapid-event search to the surveillance workflow. The all-metal IP67 + IK10 housing takes a 20 J hammer strike without breaking. Available in White (DH-IPC-HDBW3867E-AS-IL-ANZ) and Black (DH-IPC-HDBW3867E-AS-IL-ANZ-BLK). Australian stock, 3-year Australian warranty.
Resolution
8MP · 4K · 3840 × 2160
Aperture & FOV
F1.4 · 110° H · 2.8 mm
Smart Dual Light
30 m IR · 30 m Warm
AI Engine
AcuPick · SMD 4.0 · IVS
Protection
IP67 · IK10 Vandal-Rated
Power
PoE 802.3af · Max 8.2 W
3-Year Australian Warranty
Fast Australia-Wide Shipping
Australian Tech Support
Why Choose the Dahua 8MP Smart Dual Light Vandal Dome in Australia
Australian integrators specify the HDBW3867E-AS-IL-ANZ when the install needs to combine three things at once — 4K resolution for evidence-grade detail, full-colour night image on detection, and a vandal-resistant flush-mount housing. School corridors, hospital wards, undercover carparks, retail back-of-house, government foyers and high-traffic commercial spaces all share the same install constraint: the camera has to disappear into the ceiling and survive being grabbed, hit or kicked, while still capturing forensic-quality colour video at night. The 3867E is built for exactly that brief.
Smart Dual Light — Colour Evidence on Detection
By default the camera runs invisible IR illumination out to 30 m for silent monitoring. The instant SMD 4.0 detects a human or vehicle, it switches to the warm-light LED (also 30 m) and records full-colour 4K — capturing clothing colour, hair colour, vehicle paint and signage detail that IR alone cannot deliver. Once the target leaves, the warm light turns off and the IR returns — minimising light pollution and LED wear.
AcuPick AI Target Search
Paired with a Dahua 5-Series AcuPick NVR, AcuPick indexes every human and vehicle event by attribute — clothing colour, vehicle type, direction of travel — so you can search a week of recorded footage in seconds rather than scrubbing timelines. Critical for retail loss-prevention, school incident review and any site with high event volume.
IK10 Vandal Resistance — Built In as Standard
The all-metal dome housing is rated IK10: it withstands more than 5 strikes from a 5 kg hammer falling 40 cm — 20 J of impact energy — without cracking or losing function. Translation: a teenager swinging a brick, a trolley hit in a carpark, or a fist swung in a corridor won't take the camera offline.
F1.4 Large Aperture + 1/2.7" Sensor
An F1.4 maximum aperture pulls in significantly more light than a typical F1.6 lens, delivering clean colour image at low ambient light and reducing how often the warm-light LED needs to fire.
110° Wide Angle — Whole-Room Coverage
The 2.8 mm fixed lens covers a 110° horizontal field of view — enough to cover a full corridor, an open-plan office, a school classroom or a retail aisle from a single mounting point. (3.6 mm variant also available with an 86° narrower field for targeted views.)
Built Tough for Australia
All-metal IP67 chassis with EIS stabilisation, ±30% wide-voltage tolerance, and an operating range engineered for every Australian climate — coastal salt, outback heat, Tasmanian frost and unstable rural mains.
Smart Features for Real-World Australian Sites
Dahua Smart Dual Illuminators — Official English Overview
SMD 4.0 — Near-Zero False Alarms
On-camera Smart Motion Detection 4.0 classifies humans and vehicles while filtering out animals, foliage, weather and shadows. Sleep through the night, not through the alarm.
IVS Tripwire & Intrusion Zones
Define a virtual line across a corridor or a no-go zone around a service door — get a notification only when a human or vehicle actually crosses it. No false alarms from cleaners or moving shadows.
AI Coding — 25%+ Less Storage
Dahua's AI Coding (AI H.265 / AI H.264) analyses the scene and dedicates bitrate only to objects of interest, delivering ≥25% additional compression efficiency over standard Smart H.265+. Longer retention on the same NVR drive.
AI SSA Scene Self-Adaptation
AI SSA detects environmental conditions — rain, fog, backlight, low light, flicker — and adjusts image parameters in real time. The camera always produces a usable image, even when the weather doesn't cooperate.
Two Lens Options (2.8 mm and 3.6 mm)
Choose 2.8 mm for wide-area coverage (110° H — whole rooms and corridors) or 3.6 mm for narrower targeted views (86° H — entries, counters, specific zones). Same camera, two install patterns.
External Audio & Alarm I/O
The AS variant supports 1 audio in / 1 audio out (RCA) plus 1 alarm in / 1 alarm out — connect an external speaker, PIR or door contact to extend the camera's capability. Built-in microphone included on-camera.
Pair with a Dahua 5-Series NVR for the Full AcuPick Experience
SMD 4.0, IVS rules, Smart Dual Light auto-switching and human/vehicle classification all run on-camera and work with any Dahua AI NVR. But to unlock AcuPick — attribute-based human and vehicle target search, similar-image cross-camera tracking and AI-accelerated playback — you need a compatible Dahua 5-Series AcuPick NVR. For any new installation we strongly recommend pairing the 3867E with one of the recorders below.
DHI-NVR5208-8P-AI/ANZ — 8 Channel · 8 PoE
Compact 1U 5-Series AcuPick NVR with 8 built-in PoE ports — ideal for a single-building or small-business install with 4–8 WizSense cameras. Full AcuPick target search and AI playback. View NVR5208-8P →
DHI-NVR5216-16P-AI/ANZ — 16 Channel · 16 PoE
16-channel 5-Series AcuPick NVR with 16 PoE ports and dual-HDD bays — the sweet-spot recorder for most residential and SMB Dahua fleets. Plug-and-play with the 3867E. View NVR5216-16P →
DHI-NVR5432-16P-AI/ANZ — 32 Channel · 16 PoE
32-channel 1.5U AcuPick NVR with 16 PoE and 4 HDD bays — the standard choice for medium commercial sites, retail chains and multi-building campuses. View NVR5432-16P →
DHI-NVR5432-AI/ANZ — 32 Channel · No PoE
32-channel AcuPick NVR without built-in PoE — for sites running a separate managed PoE switch (preferred in larger commercial deployments). Same AcuPick capability, more flexible network design. View NVR5432-AI →
Need help sizing? Browse the complete Dahua AcuPick NVR range → or contact our Australian team for a tailored recommendation based on your camera count, retention and AcuPick search workload.
Best Applications for the 8MP Smart Dual Light Vandal Dome
The DH-IPC-HDBW3867E-AS-IL-ANZ is the right tool when a project brief calls out vandal resistance, discreet ceiling-flush form factor, full-colour night image and AI-powered search. Typical Australian deployments include:
Schools and tertiary campuses — corridors, halls, common rooms and entries where IK10 takes student-grade abuse
Hospitals, GP clinics and aged-care — wards, reception areas, dispensaries where silent IR + colour-on-detection is critical
Retail interiors — store floor, back-of-house, counter zones — AcuPick speeds incident review for loss-prevention
Government foyers and councils — public-facing entrances and corridors needing tamper-resistant 4K coverage
Carparks and loading docks — undercover, exposed-ceiling installs where IK10 protects against trolleys, vehicles and weather
Hotels, motels and student accommodation — common areas, corridors and lobbies where the camera must blend into the architecture
Warehouses, factories, gyms — high-ceiling install with wide-area coverage and AI motion filtering
Apartment building common areas — lift lobbies, bin rooms, foyers — IK10 + 4K + colour-on-detection
Technical Specifications
DH-IPC-HDBW3867E-AS-IL-ANZ · Full Specifications
SKU
DH-IPC-HDBW3867E-AS-IL-ANZ (White) · DH-IPC-HDBW3867E-AS-IL-ANZ-BLK (Black)
Camera Type
8MP 4K Smart Dual Light Fixed-Focal Vandal Dome · WizSense 3 Series · AcuPick
Image Sensor
1/2.7" Progressive Scan CMOS
Max Resolution
3840 × 2160 (8MP / 4K) @ 25/30 fps
Lens Type
Fixed-focal · 2.8 mm (110° H) or 3.6 mm (86° H) · M12 mount
Maximum Aperture
F1.4
Field of View (2.8 mm)
H: 110° · V: 58° · D: 132°
Field of View (3.6 mm)
H: 86° · V: 49° · D: 100°
Dynamic Range
120 dB True WDR
Day & Night
Auto (ICR) / Colour / B&W
Illuminators
Multi-core IR + Warm-light LED · IR up to 30 m · Warm light up to 30 m · Smart Dual Light auto switching
Image Enhancement
WDR · 3D NR · HLC · BLC · Defog · AFSA · AI SSA · Smart Illumination · Smart Dual Light · EIS · Image Rotation · Digital watermarking
Active Deterrence
Not included — silent Smart Dual Light surveillance camera
Intelligent Video
WizSense AI · AcuPick · SMD 4.0 · IVS (Tripwire, Intrusion · human/vehicle classification) · Quick Pick (with AI NVR) · Smart Search · AI SSA
Video Compression
H.265 · H.264 · H.264H · H.264B · MJPEG (sub-stream) · Smart H.265+ / H.264+ · AI H.265 / AI H.264
AI Coding
≥25% additional compression efficiency
Audio
Built-in microphone · G.711a / G.711Mu / G.726 / G.723 / PCM compression
Audio I/O (AS variant)
1 audio in (RCA) · 1 audio out (RCA)
Alarm I/O (AS variant)
1 alarm in · 1 alarm out
IP Camera Protocol
ONVIF Profile S / G / T / M · CGI · P2P
Network Protocols
IPv4/v6 · HTTP/HTTPS · TCP/UDP · RTP/RTSP/RTCP/RTMP · SMTP · FTP/SFTP · DHCP · DDNS · UPnP · NTP · ICMP · IGMP · NFS · SAMBA · PPPoE · SNMP
Cyber Security
Trusted boot · Trusted execution · Trusted upgrade · HTTPS · 802.1x · IP/MAC filtering · X.509 import · syslog · video/firmware/config encryption · account lockout
Ethernet
RJ-45 (10/100BASE-T)
Edge Storage
MicroSD up to 512 GB · NAS · FTP / SFTP
Weatherproof Rating
IP67
Vandal Resistance
IK10 (20 J impact energy)
Power Source
12 V DC / PoE (IEEE 802.3af) · ±30% wide voltage
Power Consumption
Basic 3.7 W (12 V DC) / 5.1 W (PoE) · Max 6.2 W (12 V DC) / 8.2 W (PoE)
Memory
ROM 256 MB · RAM 1 GB
Mobile App
DMSS · Smart PSS · DSS (iOS & Android)
Approvals
CE-LVD (EN 62368-1) · CE-EMC 2014/30/EU
Housing
Metal · White or Black
Dimensions
89.1 × Φ 111.7 mm (compact dome)
Weight
528 g (net) · 690 g (gross)
Warranty
3-Year Australian Warranty (back-to-base)
HDBW3867E (Smart Dual Light + AcuPick) vs HDBW3866RP (IR-Only) — Which Vandal Dome?
Both cameras are 8MP 4K IK10 vandal-rated domes in the WizSense 3 Series, sharing the same SMD 4.0, IVS perimeter protection and AI Coding. The deciding question is illumination and AI tier: do you want Smart Dual Light with full-colour evidence on detection and AcuPick AI search, or IR-only silent monitoring with a longer DORI reach via motorised zoom? The 3867E adds Smart Dual Light, AcuPick attribute search and a fixed lens at a more affordable price point. The 3866RP is the motorised long-range alternative without warm light or AcuPick.
HDBW3867E-AS-IL-ANZ (Smart Dual Light + AcuPick) vs HDBW3866RP-ZAS-AUS (IR Motorised)
Feature
DH-IPC-HDBW3867E-AS-IL-ANZ (this Smart Dual Light dome)
DH-IPC-HDBW3866RP-ZAS-AUS (IR-only motorised dome)
Series Line
Smart Dual Light + AcuPick · WizSense 3
IR Vari-focal · WizSense 3
Max Resolution
8MP · 3840 × 2160 (4K)
8MP · 3840 × 2160 (4K)
Image Sensor
1/2.7" CMOS
1/2.8" CMOS
Lens
Fixed · 2.8 mm or 3.6 mm
Motorised vari-focal · 2.7–13.5 mm
Max Aperture
F1.4
F1.5
FOV (wide)
110° H @ 2.8 mm
109° H @ 2.7 mm
IR Distance
30 m
40 m
Warm-Light LED
Yes · 30 m
No
Full-Colour Night Image
Yes — Smart Dual Light auto-switch
No — IR monochrome
AcuPick AI Search
Yes — with 5-Series NVR
No
SMD Version
SMD 4.0
SMD 4.0
Quick Pick (with AI NVR)
Yes
Yes
WDR
120 dB True WDR
120 dB True WDR
AI Coding
Yes (AI H.265 / H.264)
Yes (AI H.265 / H.264)
EIS Stabilisation
Yes
Yes
MicroSD
Up to 512 GB
Up to 256 GB
ONVIF Profiles
S / G / T / M
S / G / T
Vandal Resistance
IK10 (built-in)
IK10 (built-in)
Ingress Protection
IP67
IP67
Operating Temperature
Per datasheet
−30 °C to +60 °C
Power (Max PoE)
8.2 W
10.5 W
Dimensions
89.1 × Φ 111.7 mm
94 × Φ 122 mm
Net Weight
528 g
713 g
Colour Options
White & Black
White
Best For
Sites where colour evidence on detection matters, AcuPick attribute search, fixed wide-angle coverage of a defined area, and the cleanest flush-mount profile.
Long sightlines where motorised zoom flexibility matters more than colour image at night.
Compatible Mounts & Accessories
Dahua PFA137 Junction Box Bracket
Recessed IP66 junction box for clean cable concealment on exposed brick, render or weatherboard. View product →
Dahua PFA109 Mount Adapter
Required adapter to fit the 3867E dome onto Dahua wall and pole brackets. View product →
Dahua PFB220C Ceiling Mount Bracket
Drop-down ceiling bracket for retail awnings, undercover car parks and warehouse interiors. View product →
Dahua PFB203W Wall Mount
Wall-mount bracket specifically for vandal dome cameras — projects the dome out from the wall to widen field of view past the building line. View Dahua accessories →
Dahua PFA152-E Pole Mount
Heavy-duty pole bracket for fence posts, light poles and gate columns. Pairs with the PFA109 adapter for dome mounting. View product →
WD Purple 256 GB Surveillance MicroSD Card
Western Digital Purple — purpose-built for 24/7 surveillance read/write cycles, far longer endurance than consumer microSD cards. The 3867E accepts cards up to 512 GB. View WD Purple 256 GB →
Frequently Asked Questions
What is Smart Dual Light and how does it work?
Smart Dual Light is Dahua's technology for combining invisible IR illumination with a warm-light LED in one camera. By default the camera uses IR (invisible, no light pollution) for normal night monitoring. The instant on-camera AI detects a human or vehicle, the warm-light LED fires and the camera captures full-colour 4K — clothing colour, vehicle paint, facial detail. Once the target leaves the scene, the warm light turns off and IR returns. Less light pollution than a full-time full-colour camera, full-colour evidence when it matters.
Does this camera support AcuPick AI search?
Yes — AcuPick is supported when paired with a compatible Dahua 5-Series AcuPick NVR. AcuPick indexes attribute metadata (clothing colour, vehicle type, direction) so you can search hours of footage in seconds rather than scrubbing timelines. Shop AcuPick NVRs here →
What does IK10 vandal resistance mean in practice?
IK10 is the highest rating in the IEC 62262 impact-resistance standard. The dome housing withstands more than 5 strikes from a 5 kg hammer falling 40 cm — 20 J of impact energy — without cracking or losing function. In real terms: brick throws, fist strikes, trolley impacts and accidental hits won't take the camera offline.
Should I pick the 2.8 mm or 3.6 mm lens variant?
Choose 2.8 mm (110° H FOV) for whole-room coverage — open-plan offices, retail floors, classrooms, hospital wards, undercover carparks. Choose 3.6 mm (86° H FOV) for narrower targeted views — counter zones, entry doors, specific aisles or zones where you want a tighter shot at the same camera distance. The 3.6 mm trades width for slightly better digital detail on the target.
Does this camera have active deterrence (strobe / siren)?
No. The HDBW3867E-AS-IL is a silent Smart Dual Light surveillance camera — no red/blue strobe, no built-in siren, no voice broadcast. The warm-light LED only fires when AI confirms a human/vehicle — it's an illumination tool, not a deterrence visual. For active deterrence (strobe + siren + voice), look at the Dahua TiOC line (HDW3849H-AS-PV-ANZ-S2 turret is the closest equivalent).
Why pick the dome over a bullet or turret?
Three reasons. First, vandal resistance — IK10 built-in housing is designed to take impact; bullets and turrets are easier to grab and tear off. Second, discreet flush-mount profile — the compact 89 mm × Φ112 mm dome sits neatly into ceilings and soffits. Third, architectural fit — domes blend into commercial interior design where a bullet would look industrial.
How does the camera record at night?
By default, invisible IR illumination (30 m) — captures clear monochrome 4K with no light pollution. When SMD 4.0 detects a real human or vehicle, the warm-light LED (also 30 m) switches on automatically and the camera records full-colour 4K. Once the target leaves the scene, the camera reverts to IR. You get the best of both: silent IR for normal monitoring, colour for actual events.
Does it have a built-in microphone?
Yes — the camera has a built-in microphone for capturing scene audio. The AS variant also adds external audio in / out (RCA) for connecting an external mic or speaker, plus alarm in / out for PIRs or door contacts.
Will it keep recording if the NVR or internet goes down?
Yes. The on-board MicroSD slot accepts cards up to 512 GB and records 4K footage independently of the NVR. Combined with DMSS cloud push notifications, you have redundant recording paths.
What's the difference between the White and Black versions?
Specifications are identical. DH-IPC-HDBW3867E-AS-IL-ANZ is white; DH-IPC-HDBW3867E-AS-IL-ANZ-BLK is black. Choose Black for dark ceilings, charcoal soffits and modern industrial aesthetics; White for traditional cream/render ceilings.
Is the camera suitable for Australian outdoor conditions?
Yes. It is rated IP67 (fully dust-tight, withstands 30 minutes submerged in 1 m of water) and IK10 vandal-resistant. The all-metal housing and ±30% wide-voltage tolerance handle coastal salt, outback heat and unstable rural mains. Suitable for under-eave, undercover and exposed outdoor installs alike.
Does it work with Hikvision NVRs or third-party VMS?
Yes — recording, streaming, motion and the WizSense AI metadata work over ONVIF Profile S/G/T/M on most third-party NVRs and VMS platforms (Milestone, Genetec, Hanwha WAVE, ExacqVision, Blue Iris, Synology). However, AcuPick attribute search requires a Dahua 5-Series AcuPick NVR.
What is the warranty and where is it serviced?
This camera ships with a 3-year Australian Dahua warranty, serviced back-to-base by Dahua Australia. CCTV Guru handles the entire RA process and provides Australian-based technical support for the life of the product.
Do you ship Australia-wide and is stock genuine?
Yes — Australian stock from authorised Dahua Australia channels (not parallel imports). We ship Australia-wide every business day with same-day dispatch on orders placed before 2 pm AEST to Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra, Darwin and regional addresses.
Downloads & Resources
DH-IPC-HDBW3867E-AS-IL-ANZ Datasheet
Dahua Dome Quick Start Guide
Order the Dahua DH-IPC-HDBW3867E-AS-IL-ANZ from CCTV Guru
CCTV Guru is an authorised Australian reseller of Dahua WizSense network cameras. Order the 8MP 4K Smart Dual Light AcuPick vandal dome today in White or Black for fast Australia-wide dispatch, expert pre-sales advice, project pricing for larger rollouts and full local warranty support. For multi-camera projects, contact our Australian team for a tailored quote, NVR sizing and installation guidance — request a free quote or contact the team.
Dahua WizMind 5 Series
Dahua DH-IPC-HDW5842EMP-ASE-S3 8MP WizMind AI Eyeball Camera
If you want a premium 8MP Dahua eyeball camera with stronger low-light performance and smarter search tools, the DH-IPC-HDW5842EMP-ASE-S3 is a strong step up from standard fixed cameras. It combines sharp 4K video with a larger 1/1.8" sensor, built-in WizMind analytics, face detection, perimeter protection, people counting and video metadata for faster event review on compatible systems.
For CCTV Guru customers, this model is a great fit for higher-end homes, commercial sites, offices, warehouses, retail stores and projects where image quality and smarter incident filtering matter. With PoE and ePoE support, built-in microphone, alarm input/output, audio input/output and edge recording, it is designed for more capable professional CCTV systems.
Resolution
8MP 4K
Analytics
WizMind AI
Low Light
1/1.8" Sensor
Audio
Built-in Mic
Why this Dahua WizMind camera stands out
Sharper 4K detail with stronger low-light performance
The 8MP resolution and larger 1/1.8" sensor help deliver clearer facial detail, vehicle detail and wider scene coverage than many entry-level cameras, making this a better fit for premium residential and commercial jobs.
Built for smarter event review
This model suits customers who want more than standard motion alerts. Dahua WizMind functions such as video metadata, face detection, people counting and perimeter protection help narrow down footage faster on supported recorders.
Better for premium NVR systems
When paired with a compatible Dahua Smart NVR, this camera supports smarter search workflows that make it much easier to find relevant event footage without scrubbing through long recordings manually.
Flexible installation for professional systems
With PoE and ePoE support, built-in microphone, alarm input/output, audio input/output and edge recording support, this camera suits more advanced CCTV installations where reliability and integration matter.
Recommended Dahua NVR pairing
8 Channel
Best for most homes and small businesses
If you are installing a standard CCTV system and want reliable recording with smart AI features,
the Dahua 8 Channel WizMind NVR (DHI-NVR5208-8P-AI/ANZ)
is a great match.
It gives you smooth playback, smart motion detection and enough capacity for most residential or small commercial setups.
16 Channel
Best for larger systems and advanced AI search
For bigger installations or when you want to unlock the full power of WizMind analytics,
go with the Dahua 16 Channel WizMind NVR (DHI-NVR5216-16P-AI/ANZ).
This option is ideal for commercial upgrades, new builds and customers who want faster event search,
better filtering and a more powerful CCTV system overall.
Official Dahua videos
Dahua IPC WizMind S Series Highlight Video
Technical specifications
Model
DH-IPC-HDW5842EMP-ASE-S3
Series
Dahua WizMind 5 Series S Series
Camera type
8MP fixed-focal eyeball WizMind network camera
Image sensor
1/1.8" CMOS
Maximum resolution
3840 × 2160
Lens
Fixed lens, commonly sold in 2.8mm or 3.6mm depending on supplier variant
Low-light performance
Large sensor design for stronger night performance and improved detail retention
Video compression
H.265, H.264, H.264H, H.264B, MJPEG
Built-in intelligence
Perimeter protection, face detection, smart motion detection, people counting, video metadata and other WizMind analytics
Audio
Built-in microphone, audio input and audio output
Alarm
Alarm input and alarm output
Storage
MicroSD edge recording support
Network
RJ45 Ethernet, PoE, ePoE
Power
12V DC and PoE
Weather rating
IP67
Impact rating
IK10
Housing
Metal housing for professional indoor or outdoor installation
Use case
Premium homes, retail, offices, warehouses, commercial sites and projects needing better AI search capability
Frequently asked questions
Is this camera suitable for home use?
Yes. It is a premium option for customers who want stronger image quality and smarter event filtering than standard home CCTV cameras, especially for larger homes or higher-value properties.
Does this camera record audio?
Yes. It includes a built-in microphone and also supports audio input and output for broader integration in more advanced systems.
Can it be used without an NVR?
Yes, edge recording to microSD is supported. However, most customers will get the best overall experience by pairing it with a suitable Dahua NVR for centralised recording and smarter playback workflows.
Does this camera support facial recognition?
No, not in the same way as Dahua’s dedicated face recognition camera range. It supports face detection, which helps identify when a face appears in the scene, but it is not positioned as a full facial recognition camera.
What makes WizMind different from standard Dahua cameras?
WizMind cameras are aimed at smarter AI use cases. They help reduce false alerts and make footage easier to review with tools like metadata search, face detection, perimeter protection and people counting on supported systems.
What recorder should I buy with it?
For customers buying this as part of a new premium CCTV system, pair it with a compatible Dahua Smart NVR so the camera’s analytics and search functions deliver more practical day-to-day value.
More information
Datasheet
DH-IPC-HDW5842EMP-ASE-S3 Datasheet
Quick Start Guide
Dahua Eyeball Network Camera Quick Start Guide
Installation Guide
Eyeball Network Camera Installation Guide
Free AU Shipping Over $199
3-Year Manufacturer Warranty
Sydney-Based Expert Support
Dahua WizSense XVR
Dahua DH-XVR5232AN-I3-S3 32 Channel WizSense XVR
The Dahua DH-XVR5232AN-I3-S3 is a powerful 32 channel WizSense XVR built for larger CCTV systems that need flexibility, smart detection and efficient recording. It supports multiple camera technologies including HDCVI, AHD, TVI, CVBS and IP, making it ideal for both new installations and upgrades from older coax-based systems.
For installers and end users who want a recorder that can bridge legacy cameras and newer AI-enabled surveillance, this XVR delivers strong performance, intelligent search features and reliable remote access in one scalable platform.
Channels
32CH Hybrid
AI Protection
WizSense
Recording
Up to 5MP
Why Choose the DH-XVR5232AN-I3-S3?
This recorder is a smart choice for customers who need a large-channel CCTV recorder without locking themselves into one camera type. It is especially useful when upgrading older analogue systems because you can keep compatible coax cameras in place while adding newer IP cameras over time.
Hybrid flexibility
Supports HDCVI, AHD, TVI, CVBS and IP cameras, making upgrades easier and more cost-effective.
Smarter detection
WizSense features such as SMD Plus and perimeter protection help reduce false alarms from trees, shadows and general movement.
Built for bigger systems
With 32 analogue channels and added IP capability, it suits large homes, retail sites, warehouses and commercial buildings.
Flexible Hybrid CCTV Recorder
The Dahua DH-XVR5232AN-I3-S3 is designed for customers who want maximum compatibility. Whether you are replacing an older DVR or building a more advanced surveillance system, this XVR gives you room to scale.
Supports HDCVI cameras for long-distance coax installations
Supports AHD, TVI and CVBS for broad analogue compatibility
Supports IP camera expansion for modern network-based surveillance
Helps reduce upgrade costs by reusing existing cabling where possible
Dahua WizSense AI Features
Dahua WizSense technology improves recording efficiency and event accuracy. Instead of relying only on basic motion detection, the recorder can focus on more relevant security events.
SMD Plus
Filters motion events to focus on people and vehicles for more accurate notifications and playback review.
Perimeter Protection
Supports intelligent tripwire and intrusion detection to improve site security.
Fast Search and Playback
Makes it easier to locate important recorded events across large systems.
Efficient Recording and Playback
For larger CCTV systems, storage efficiency matters. This XVR supports advanced compression technologies that help reduce hard drive usage and network load while maintaining clear video quality.
Smart H.265+ compression support
Lower bandwidth requirements for remote viewing
More efficient long-term recording
Suitable for sites running many cameras at once
Remote Viewing and Everyday Use
Once connected to your network, the recorder can be accessed remotely for live view, playback and alerts. This makes it practical for business owners, property managers and homeowners who want to check footage from anywhere.
Remote access
View cameras and playback recordings remotely using Dahua’s supported app and desktop access options.
Multi-screen viewing
Monitor multiple cameras at the same time for better situational awareness.
Commercial-ready
A practical solution for larger homes, shops, offices, workshops and warehouses.
Technical Specifications
Model
DH-XVR5232AN-I3-S3
Recorder Type
32 Channel WizSense XVR
Video Input
HDCVI / AHD / TVI / CVBS / IP
Analogue Channels
32 Channels
IP Camera Support
Supported
AI Features
SMD Plus, perimeter protection and intelligent search functions
Compression
AI Coding / Smart H.265+ / H.265 / H.264+
Max Recording Resolution
Up to 5MP analogue recording capability
Video Outputs
HDMI and VGA
Storage
2 x SATA hard drive bays
Network Access
LAN / remote app / browser access
Best For
Large hybrid CCTV systems, analogue upgrades and commercial surveillance
Ideal Applications
Warehouses and factories
Retail stores and shopping centres
Office buildings and commercial sites
Large homes and multi-building properties
Upgrades from older coax CCTV systems
Authorised Dahua Reseller
Fast Shipping Australia Wide
5% Price Beat Guarantee
Frequently Asked Questions
Can I use old analogue cameras with this recorder?
Yes. This XVR supports HDCVI, AHD, TVI and CVBS cameras, so it is ideal for upgrading existing coax systems.
Can I also add IP cameras?
Yes. This recorder supports hybrid operation, allowing you to mix supported analogue and IP cameras.
Is this a good option for large CCTV systems?
Yes. With 32 channels and strong hybrid flexibility, it is well suited to larger residential and commercial sites.
What does WizSense do?
WizSense improves event accuracy with smarter detection features such as human and vehicle filtering and perimeter-based alerts.
More Information
Everything you need to evaluate the DH-XVR5232AN-I3-S3 before purchase. Add your official Dahua links below.
Datasheet
Official product document
User Manual
Setup and operation guide
Dahua · DHI-ARM320-W2 · Wireless Input Expander · Dual InputInput ExpanderDahua DHI-ARM320-W2 Wireless Input Expander
The Dahua DHI-ARM320-W2 is a wireless input expander (transmitter) that brings external powered wired detectors into a compatible Dahua wireless alarm system — perfect for retrofits and mixed wired/wireless installs where you want to keep an existing detector without running cable back to the hub. It offers two inputs (alarm + anti-tamper), supports six alarm types, and uses AES128-encrypted two-way RF with frequency hopping.
Specifications — DHI-ARM320-W2
Model
DHI-ARM320-W2
Type
Wireless Input Expander / Transmitter
Alarm Inputs
2 (1 alarm + 1 anti-tamper)
Supported Alarm Types
Intrusion, medical, fire, emergency, gas, tamper
External Power Support
Yes
Tamper Alarm
Yes (triggers when moved)
Overheating Alarm
Yes
Communication
Two-way wireless RF
Encryption
AES128, with frequency hopping
Updates
Cloud update
Warranty (Australia)
3 years · CCTV Guru Australia
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · DHI-ARM310-W2 · Wireless Input Expander · Dry ContactInput ExpanderDahua DHI-ARM310-W2 Wireless Input Expander
The Dahua DHI-ARM310-W2 is a wireless input expander that brings a third-party wired sensor or dry-contact device into a compatible Dahua wireless alarm system — ideal for reusing an existing contact, adding a wired trigger point, or expanding the system without cabling back to the hub. It offers a 1-channel dry contact (NO/NC), supports six alarm types, reaches up to 1000m, and uses AES128-encrypted two-way RF.
Specifications — DHI-ARM310-W2
Model
DHI-ARM310-W2
Type
Wireless Input Expander
Protection Zone
1-channel dry contact input
Supported Input Types
NO and NC
Alarm Types
Intrusion, medical, fire, emergency, gas, tamper
Indicators
1 × green alarm LED, 1 × power button
Tamper / Low-Battery Alarm
Yes
Signal Strength Detection
Yes
Carrier Frequency
433.1MHz – 434.6MHz
Communication Distance
Up to 1000m in open space
Communication
Two-way RF, frequency hopping
Encryption
AES128
Power Supply
CR123A battery
Battery Life
Up to 4 years (NO), up to 2 years (NC / Pulse)
Operating Temperature
-10°C to +55°C
Dimensions
100.2 × 20.8 × 20.3 mm
Installation
Bracket mount
Warranty (Australia)
3 years · CCTV Guru Australia
Downloads & Resources
DHI-ARM310-W2 Datasheet
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · DHI-ARA14-W2 · Wireless Intercom Siren · 868MHz 100dBIntercom SirenDahua DHI-ARA14-W2 (868MHz) Wireless Intercom Siren
The Dahua DHI-ARA14-W2 (868MHz) is a wireless intercom siren that combines a high-decibel siren, flashing light and built-in microphone for Dahua wireless alarm systems. It delivers up to 100dB sound-and-light alarm output, two-way voice communication via the Dahua app, multiple alarm tones and panic-button support — all over AES128-encrypted RF with up to 1600m range.
Specifications — DHI-ARA14-W2 (868)
Model
DHI-ARA14-W2 (868)
Type
Wireless Intercom Siren
Alarm Output
Sound + Light
Sound Pressure
Up to 100dB at 1m
Audio
Two-way talk (mic up to 5m pickup)
Frequency
865.34 – 868.60 MHz
Range
Up to 1600m (alarm), 1000m (intercom) open space
Communication
Two-way wireless RF
Encryption
AES128, with frequency hopping
Panic Button
Supported
Power Supply
4 × CR123A battery or 9–15V DC
Battery Life
Up to 3 years
Operating Temperature
-10°C to +55°C
Installation
Wall mount
Warranty (Australia)
3 years · CCTV Guru Australia
Downloads & Resources
DHI-ARA14-W2 DatasheetDahua Wireless Intercom Siren User Manual
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · DHI-ARM7011-W2 · Wireless Relay Module · 0–36V DCWireless RelayDahua DHI-ARM7011-W2 Wireless Relay Module
The Dahua DHI-ARM7011-W2 is a wireless relay module that lets a Dahua wireless alarm system control external low-voltage devices — door strikes, gates, garage doors, warning lights, sirens and automation outputs. With a 0–36V DC NO/NC relay, a tamper input, two-way RF, AES128 encryption and frequency hopping, it bridges your wireless alarm to physical electrical devices for smarter automation.
Specifications — DHI-ARM7011-W2
Model
DHI-ARM7011-W2
Type
Wireless Relay Module
Relay Output
1 × NO/NC, 0–36V DC, max 5A
Alarm Input
1 × tamper input (NO/NC)
Communication
Two-way wireless RF
Frequency
433MHz / 868MHz (variant dependent)
Range
Up to 800–1200m (open space)
Encryption
AES128, with frequency hopping
Power Supply
7–24V DC
Protection
Overheating protection & voltage detection
Updates
Cloud update with auto-recovery
Operating Temperature
-10°C to +55°C
Dimensions
39 × 33 × 19 mm
Warranty (Australia)
3 years · CCTV Guru Australia
Downloads & Resources
DHI-ARM7011-W2 DatasheetDahua Wireless Relay User Manual
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dahua · ARD821-W2(868) · Wireless Panic Button · 868MHz
Panic Button
Dahua DHI-ARD821-W2(868) Wireless Panic Button
The Dahua ARD821-W2(868) is a compact single-button wireless panic button for fast, discreet emergency activation. A single press sends an encrypted AES128 two-way RF signal on the 868MHz band to your alarm panel, with no wiring required. It pairs with Dahua wireless alarm hubs (ARC series) and is managed in the DMSS app, making it ideal for homes, retail counters, reception desks, clinics and aged-care facilities.
Specifications — ARD821-W2(868)
Type
Single-button wireless panic button
Buttons
1 (with LED indicator)
Frequency
868.0MHz–868.6MHz
Communication
Two-way RF, frequency hopping, AES128 encryption
Range
Up to 1,200m in open space
Protection Rating
IP54 (dust and light splash)
Battery
Low-battery detection, level shown in app
Compatibility
Dahua ARC wireless alarm hubs · DMSS app
Warranty (Australia)
3 years · CCTV Guru Australia
ARD821-W2(868) Datasheet
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Dual-Frequency Card
Hikvision S50+TK4100 — Dual-Frequency Access Card (13.56MHz + 125KHz)
The Hikvision S50+TK4100 is a dual-frequency access control card supporting both 13.56MHz and 125KHz credentials in one thin card. By combining Mifare 1 and EM capability, it is a practical choice for mixed environments where older and newer readers are used together.
Ideal for offices, commercial sites, apartment buildings and upgrade projects where compatibility matters, and for users who prefer a card format over key fobs.
Dual Frequency
Works at both 13.56MHz and 125KHz (Mifare 1 + EM) for broad compatibility.
Read/Write
Supports read and write functions for flexible credential management.
Thin Card Format
Slim white PVC card that is easy to carry in a wallet or lanyard.
Upgrade-Friendly
Bridges legacy 125KHz systems with newer 13.56MHz access control.
Specifications
Model
S50+TK4100
Type
Dual-frequency contactless card
Frequency
13.56MHz & 125KHz
Function
Read/Write
Read Distance
≤ 10 cm
Material
PVC, white
Dimensions
85.5 × 54 × 0.8 mm
Working Temp
-20°C to +75°C
Why choose a dual-frequency card?It works at both 13.56MHz and 125KHz, so it suits mixed or upgrading access control systems.
Is it a card or a fob?It is a thin PVC card, ideal for users who prefer a wallet-friendly credential.
What is the read range?The card has a read distance of up to 10 cm.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Bridge legacy and modern readers with the Hikvision S50+TK4100 dual-frequency card, backed by a 3-year Australian warranty and local tech support.
Hikvision Intercom Kit · Keypad Access · PoE Powered
Hikvision Keypad Video Intercom Kit with 4MP Door Station, 10.1" Monitor & PoE Switch
The Hikvision Keypad Video Intercom Kit is a complete PoE-powered access control solution for Australian homes, offices, rental properties, gated entries and small commercial sites. It combines the DS-KV6124-WBE1 4MP villa door station, DS-KH9570-WTE1/S 10.1" indoor station and DS-3E1105P-EI PoE switch into one ready-to-install bundle.
Unlike a basic video doorbell, this kit gives you multiple unlock options including PIN code, RFID card, Bluetooth, indoor monitor unlock and Hik-Connect app control. The wired PoE design provides a cleaner, more reliable installation than Wi-Fi-only intercoms, while the large 10.1" indoor touchscreen gives users a premium control point inside the property.
Door Station
4MP Keypad
Access
PIN · Card · App
Monitor
10.1" Touchscreen
Power
PoE Switch Included
Locks
2 Lock Control
Remote Access
Hik-Connect App
Complete PoE Kit
PIN & Card Access
Australian Support
What’s Included
1 × Hikvision DS-KV6124-WBE14MP villa door station with keypad, 150° viewing angle, card access, PIN code unlock, Bluetooth unlock, Hik-Connect unlock, indoor station unlock and 2-lock control.
1 × Hikvision DS-KH9570-WTE1/SPremium 10.1" IPS indoor station with 1920 × 1200 resolution, Android 14 platform, dual microphones and speakers, noise suppression and echo cancellation.
1 × Hikvision DS-3E1105P-EI4-port Fast Ethernet smart PoE switch with 4 × 10/100 Mbps PoE ports, 1 × 10/100 Mbps uplink port, 60W PoE budget and 6kV surge protection on PoE ports.
Installer-Ready PoE SetupDesigned for a clean wired installation. The PoE switch powers the door station and indoor monitor over network cabling, reducing messy power adapters and Wi-Fi reliability issues.
Why Choose This Keypad Intercom Kit?
PIN Access Without KeysGive family, staff, tenants or trusted visitors a PIN code instead of handing out physical keys.
Multiple Unlock MethodsUnlock using PIN code, RFID card, Bluetooth, the indoor monitor or Hik-Connect mobile app.
Premium Indoor ControlThe 10.1" indoor screen provides a modern control point for answering calls, viewing the door station and unlocking the entry.
Wired PoE ReliabilityPoE is more stable than Wi-Fi-only doorbells and is better suited to permanent homes, offices, gates and rental properties.
Great for Multi-User SitesIdeal where different users need different access methods — homeowners, staff, cleaners, trades or short-stay guests.
Remote App ControlUse Hik-Connect to view the door station, talk to visitors and unlock remotely where configured correctly.
Recommended For
Family HomesFront door, side gate or pedestrian gate access with indoor screen and mobile app control.
Offices & StudiosAllow staff entry by PIN or card while keeping visitor calls visible from the monitor.
Airbnb & RentalsUseful for properties where codes are easier than physical keys or remote handovers.
Gated EntriesUse the 2-lock control capability for pedestrian gates, electric strikes or compatible access hardware.
Technical Specifications
Door Station — Hikvision DS-KV6124-WBE1
Camera
4MP door station camera
Viewing Angle
150° viewing angle
Unlock Methods
Card, PIN code, Bluetooth, Hik-Connect and indoor station unlock
Lock Control
2 locks control
Remote Features
Video recording and playback via Hik-Connect or PC web
Power
IEEE 802.3at PoE
Application
Villa / residential / small commercial door station
Indoor Station — Hikvision DS-KH9570-WTE1/S
Display
10.1" IPS touch display
Resolution
1920 × 1200
Operating Platform
Android 14
Performance
4-core processor · Up to 4GB RAM + 8GB ROM
Audio
Dual microphones and speakers
Audio Processing
Noise suppression and echo cancellation
Use Case
Indoor call answering, monitoring and access control
PoE Switch — Hikvision DS-3E1105P-EI
PoE Ports
4 × 10/100 Mbps PoE RJ45 ports
Uplink Port
1 × 10/100 Mbps RJ45 port
PoE Standard
IEEE 802.3af / IEEE 802.3at
PoE Budget
60W total
Max Port Power
30W per PoE port
Surge Protection
6kV surge protection for PoE ports
Housing
Metal shell, fan-free design
Downloads & Resources
DS-KV6114-WBE1 Datasheet
DS-KH9570-WTE1 Datasheet
DS-KV6114-WBE1 Quick Start Guide
DS-KH9570-WTE1 Quick Start Guide
User Manual
P2P Setup Guide
Frequently Asked Questions
Does this kit support PIN code access?Yes. The DS-KV6124-WBE1 door station includes keypad access for PIN code unlocking.
Can I unlock from my phone?Yes, remote unlock is supported through Hik-Connect when the system is configured correctly.
Does it include the PoE switch?Yes. This bundle includes the DS-3E1105P-EI PoE switch for wired power and data connection.
Is this better than a Wi-Fi doorbell?For permanent installs, yes. A wired PoE intercom is generally more stable and installer-friendly than Wi-Fi-only doorbells.
Can it control an electric strike?Yes, the door station supports 2-lock control. Final lock compatibility depends on your strike, gate controller and wiring design.
Is installation included?No. This is a hardware kit. CCTV Guru can help with product selection and recommend suitable setup guidance for your installer.
Order Your Hikvision Keypad Video Intercom Kit from CCTV Guru
Order the Hikvision Keypad Video Intercom Kit with PoE from CCTV Guru for a complete access control intercom solution with keypad entry, mobile app unlock, 10.1" indoor monitor and PoE switch. Ideal for homes, offices, rental properties and gated entries needing a more secure, flexible upgrade from a standard doorbell.
Hikvision Intercom Kit · 4MP Door Station · PoE Powered
Hikvision Premium Video Intercom Kit with 4MP Door Station, 10.1" Monitor & PoE Switch
The Hikvision Premium Video Intercom Kit is a complete wired PoE intercom solution for Australian homes, offices, shops, clinics, studios, rental properties and gated entries. It combines the DS-KV6114-WBE1 4MP video door station, DS-KH9570-WTE1/S 10.1" indoor monitor and DS-3E1105P-EI PoE switch into one clean, ready-to-install package.
Designed for reliable everyday entry control, this kit lets users see visitors clearly, speak through the indoor monitor or Hik-Connect app, and unlock compatible electric strikes or gates when configured by your installer. The PoE design keeps power and data on one network cable per device, giving you a more stable and professional setup than basic Wi-Fi-only video doorbells.
Door Station
4MP Wide Angle
Monitor
10.1" Touchscreen
Power
PoE Switch Included
Remote Access
Hik-Connect App
Unlock
App · Card · Monitor
Install
Wired PoE Setup
Complete Intercom Kit
PoE Switch Included
Australian Support
What’s Included
1 × Hikvision DS-KV6114-WBE14MP video door station with wide-angle viewing, Wi-Fi and PoE support, dual lock control and access options including card, Bluetooth, app and indoor monitor unlock.
1 × Hikvision DS-KH9570-WTE1/SPremium 10.1" indoor station with a modern touchscreen interface for answering calls, viewing the door station and controlling access from inside the property.
1 × Hikvision DS-3E1105P-EICompact PoE switch to power and connect the door station and indoor monitor using network cabling for a cleaner, more stable installation.
Ready-to-Install BundlePre-matched Hikvision components reduce compatibility guesswork and give your installer the core hardware needed for a professional wired intercom setup.
Why Choose This Hikvision Intercom Kit?
Cleaner Than a Basic DoorbellUpgrade from a simple doorbell to a proper video intercom with indoor screen, mobile app access and lock control capability.
Reliable Wired CommunicationPoE provides power and data over network cable, reducing reliance on weak Wi-Fi signals at the front door or gate.
Remote Visitor HandlingUse Hik-Connect to view, talk and unlock remotely when the system is configured correctly by your installer.
Modern Indoor MonitorThe 10.1" indoor station gives homes and businesses a premium control point for answering calls and monitoring the entrance.
Access Control ReadySuitable for compatible electric strikes, magnetic locks and gate controllers where lock wiring and power are correctly designed.
Expandable SetupAdd extra indoor monitors, access cards or lock hardware to suit larger homes, offices or multi-room layouts.
Recommended For
Residential HomesFront door, side gate or pedestrian gate control with indoor monitor and mobile app convenience.
Small OfficesLet reception, staff or managers see and speak with visitors before opening the door.
Clinics & StudiosControl entry for appointments, staff access and after-hours visitor management.
Rental & Airbnb PropertiesUseful where remote visitor handling and app-based access control are preferred over standard doorbells.
Gates & Entry PointsSuitable for controlled entry points when paired with the correct strike, relay or gate controller.
Small Commercial SitesA practical upgrade for warehouses, showrooms, workshops and business entrances.
Optional Add-Ons
Electric Strike LockAdd a compatible electric strike such as FSH FES10 or LOX ES10 for remote door release from the monitor or app.
Extra Indoor MonitorAdd another indoor station for larger homes, upstairs areas, reception counters or back offices.
RFID CardsAdd access cards or fobs for staff, family members or regular users where card access is required.
Cat6 CablingUse quality Cat6 cabling for reliable PoE power and data between the door station, indoor monitor and switch.
Technical Specifications
Door Station — Hikvision DS-KV6114-WBE1
Camera
4MP video door station
Viewing Angle
150° wide-angle view
Unlock Methods
App, card, Bluetooth and indoor monitor unlock
Lock Control
Dual lock control
Network
Wi-Fi and PoE support
Use Case
Villa, residential and small commercial video intercom
Indoor Station — Hikvision DS-KH9570-WTE1/S
Display
10.1" touchscreen indoor monitor
Function
Answer calls, view door station and unlock compatible doors or gates
App Support
Hik-Connect remote viewing and call handling when configured
Use Case
Main indoor control point for homes and small businesses
PoE Switch — Hikvision DS-3E1105P-EI
PoE Ports
4 × PoE ports
Uplink
1 × uplink port
PoE Budget
60W total PoE budget
Purpose
Powers and connects the intercom devices for wired communication
Downloads & Resources
DS-KV6114-WBE1 Datasheet
DS-KH9570-WTE1 Datasheet
DS-KV6114-WBE1 Quick Start Guide
DS-KH9570-WTE1 Quick Start Guide
User Manual
P2P Setup Guide
Frequently Asked Questions
What is included in this kit?This kit includes the Hikvision DS-KV6114-WBE1 4MP door station, DS-KH9570-WTE1/S 10.1" indoor monitor and DS-3E1105P-EI PoE switch.
Can I answer from my phone?Yes. Hik-Connect can be used to view visitors, talk and unlock remotely when the system is configured correctly.
Does it need Wi-Fi?No. The kit is designed around wired PoE communication. Wi-Fi can still be useful depending on how your installer configures remote access.
Can it unlock a door or gate?Yes. The door station supports lock control, but the final setup depends on your electric strike, magnetic lock, gate motor and power design.
Can I add another indoor monitor?Yes, additional compatible indoor stations can be added for multi-room or multi-floor setups.
Is this suitable for business use?Yes. It is suitable for homes, small offices, studios, clinics, warehouses and controlled entry points.
Is installation included?No. This is a hardware kit. We recommend installation by a licensed security or data cabling technician.
Why buy the kit instead of separate parts?The kit gives you matched Hikvision components in one package, reducing compatibility issues and making setup easier for your installer.
Order Your Hikvision Video Intercom Kit from CCTV Guru
Order the Hikvision Premium Video Intercom Kit with 4MP Door Station, 10.1" Indoor Monitor and PoE Switch from CCTV Guru for a complete wired intercom solution with video calling, app access and lock-control capability. Ideal for Australian homes, offices, shops and gated entries needing a more secure upgrade from a basic doorbell.
Hikvision 9 Series · 10.1" · WiFi 6 + PoE
The Hikvision DS-KH9570-WTE1 is a premium 10.1-inch indoor video intercom monitor designed for modern homes, apartments, and smart commercial projects that need more than a basic room station. With a 1920 × 1200 IPS touch display, Android 14, and WiFi 6 + PoE, it delivers a faster, smarter, and more connected user experience.
As part of Hikvision’s 9 Series indoor station range, this model combines video intercom, device management, and smart security control on one screen. It supports linkage with door stations, indoor extensions, and network cameras, while also providing dual microphones, dual speakers, noise suppression, and echo cancellation.
If you want a premium indoor station for a Hikvision intercom system with strong visual clarity, responsive performance, and broader smart security integration, the DS-KH9570-WTE1/S is one of Hikvision’s strongest current indoor monitor options.
Display
10.1" IPS
Resolution
1920 × 1200
Platform
Android 14
Connectivity
WiFi 6 + PoE
Audio
Dual Mic + Speaker
Memory
4GB + 8GB
✔ 10.1-inch touch display ✔ Smart security management ✔ Ideal for premium intercom systems
Best For
🏠 Premium HomesIdeal for high-end homes needing a larger, clearer, and more responsive indoor intercom experience.
🏢 Offices & Small CommercialSuitable for offices and reception environments needing visual entry management and internal communication.
📹 Unified Security ControlStrong choice for sites that want intercom, linked cameras, and smart security control on one screen.
📱 Modern Smart SystemsBuilt for projects wanting Android-based performance, WiFi 6 connectivity, and current-generation Hikvision integration.
Technical Specifications
Model
DS-KH9570-WTE1/S
Series
9 Series Indoor Station
Display Size
10.1-inch
Display Type
Colorful IPS capacitive touch screen
Resolution
1920 × 1200
Operating System
Android 14
RAM
4 GB
ROM
8 GB
Wi-Fi
Wi-Fi 6, 2.4 GHz & 5 GHz
Bluetooth
BLE 5.0
Network Port
1 × RJ-45 10/100 Mbps
Audio
2 built-in omnidirectional microphones, 2 built-in loudspeakers
Audio Features
Noise suppression and echo cancellation
TF Card
Up to 256 GB
Linked Doorphone Capacity
17
Linked Indoor Extensions
15
Linked Network Cameras
16
Power
12 VDC, 2.5 A or IEEE 802.3at PoE
Installation
Surface mounting
⚡ Explore More Hikvision Security Solutions
Build a complete security solution with video intercom systems, Hikvision security cameras, and our CCTV System Builder.
Build Your Security System →
🎥 See Hikvision Intercom in Action
Hikvision Technology Overview
Frequently Asked Questions
What is the DS-KH9570-WTE1/S used for?It is a premium indoor intercom monitor used to answer calls, manage entry, and control linked Hikvision security devices from one screen.
Does this indoor station support WiFi?Yes. It supports Wi-Fi 6 on both 2.4 GHz and 5 GHz bands.
Does it support PoE?Yes. It supports IEEE 802.3at standard PoE as well as 12 VDC power input.
Can it link to cameras and door stations?Yes. Hikvision lists support for linked doorphones, indoor extensions, and linked network cameras.
Can I add local storage?Yes. It supports a TF card up to 256 GB.
Is this suitable for homes and businesses?Yes. It suits premium residential and small commercial intercom projects that need a larger screen and broader device integration.
More information
Download official Hikvision documents for setup, specifications, and product details.
Datasheet PDF
Quick Start Guide Official Resource
User Manual Official Resource
3 Year Australian Warranty
Fast Australia-wide Delivery
Genuine Australian Stock
Hikvision Intercom · 4MP · WiFi + PoE
The Hikvision DS-KV6114-WBE1 is a smart 4MP IP video intercom designed for modern homes and small businesses that want secure, flexible access control with mobile connectivity. With a wide 150° viewing angle and multiple unlocking methods, it delivers both convenience and security at your front door.
This compact villa door station supports WiFi 6 and PoE, allowing flexible installation without complex wiring. Users can unlock doors via Hik-Connect app, Bluetooth, card, or indoor monitor, making it ideal for homes, offices, and rental properties.
If you want a reliable smart intercom with remote access, video recording, and dual lock control, the DS-KV6114-WBE1 is one of Hikvision’s best entry-level IP intercom solutions.
Camera
4MP HD
Viewing Angle
150° Wide
Unlock Methods
App / Card / Bluetooth
Connectivity
WiFi 6 + PoE
Locks
Dual Lock Control
✔ Remote unlock via app ✔ Smart access control ✔ Ideal for homes & small business
Best For
🏠 Homes & ApartmentsControl access remotely and see visitors in real time from your phone.
🏢 Small BusinessesManage entry points with app control and card access.
🚪 Gate & Door ControlSupports dual lock control for doors and gates.
📱 Remote MonitoringReceive calls and unlock doors from anywhere using Hik-Connect.
Technical Specifications
Model
DS-KV6114-WBE1
Camera
4MP (2688 × 1520)
Viewing Angle
150° horizontal
WDR
120dB
Night Vision
IR up to 3m
Audio
Built-in mic & speaker
Unlock Methods
Card / Bluetooth / App / Indoor station
Card Capacity
Up to 10,000 cards
Network
WiFi 6 + Ethernet
Power
PoE (802.3at) or 12V DC
Protection
IP65 weatherproof
Frequently Asked Questions
What is the Hikvision DS-KV6114-WBE1 used for?
It is a smart video intercom door station that allows you to see, talk to, and unlock doors or gates for visitors using your phone, card, Bluetooth, or indoor monitor.
Does this intercom support mobile app access?
Yes. It works with Hik-Connect, allowing you to receive calls, view video, and unlock doors remotely from your smartphone.
What unlock methods does it support?
The DS-KV6114-WBE1 supports multiple access methods including card, Bluetooth, mobile app (Hik-Connect), and indoor station control.
Can this intercom control more than one door or gate?
Yes. It supports dual lock control, allowing you to operate two doors or gates from a single device.
Does it require an indoor monitor to work?
No. It can operate as a standalone unit using the Hik-Connect app, but it can also be paired with indoor monitors for a full intercom system.
Is this a WiFi or wired intercom?
It supports both. You can connect via WiFi 6 or use Ethernet with PoE for a more stable wired installation.
What camera quality does it have?
It features a 4MP camera with a wide 150° viewing angle, providing clear video and wide coverage at your entrance.
Can it record video or playback footage?
Yes. It supports video recording and playback via the Hik-Connect app or web interface when properly configured.
Is it suitable for outdoor installation?
Yes. It has an IP65 weatherproof rating, making it suitable for outdoor use in various conditions.
How is the device powered?
It can be powered via PoE (Power over Ethernet) or 12V DC, giving flexibility for different installations.
⚡ Explore More Hikvision Security Solutions
Upgrade your system with video intercom systems, CCTV cameras, or build a complete solution using our CCTV System Builder.
Build Your Security System →
More information
Download official Hikvision documents for setup, specifications, intercom details.
Datasheet
PDF
Quick Start Guide
PDF
User Manual
PDF
2 Year Australian Warranty
Fast Australia-wide Delivery
Genuine Australian Stock
Hikvision Pro Series EasyIP · 2.8mm Lens
Hikvision 6MP Panoramic ColorVu Smart Bullet Camera 2.8mm – DS-2CD2T67G2P-LSU/SL
Cover wide areas with one premium panoramic bullet camera. The Hikvision DS-2CD2T67G2P-LSU/SL combines
6MP panoramic imaging, 180° coverage,
24/7 full-colour ColorVu night vision,
human and vehicle detection, and
active strobe light and audio warning in one smart bullet design.
This listing is for the 2.8mm dual-lens version.
Coverage
180° View
Resolution
6MP
Night Vision
ColorVu
Smart AI
Human + Vehicle
Deterrence
Strobe + Audio
Protection
IP67
Why this camera stands out
The DS-2CD2T67G2P-LSU/SL is designed for customers who want broader coverage in a traditional bullet-style housing.
It creates one stitched panoramic image across the scene, helping cover driveways, perimeter fences, side access paths,
wide front boundaries, loading areas, shopfronts, and commercial exteriors with fewer cameras. :contentReference[oaicite:3]{index=3}
Hikvision lists this model with 6MP panoramic imaging, 24/7 colourful imaging,
130 dB WDR, human and vehicle classification based on deep learning,
active strobe light and audio alarm, and IP67 weather resistance.
For the 2.8mm version, Hikvision lists a 180° horizontal field of view and
81° vertical field of view. :contentReference[oaicite:4]{index=4}
✨ Key Features
6MP panoramic image
Wide-area monitoring with one stitched 180° scene.
2.8mm dual lens
This page is written for the 2.8mm in-stock version.
ColorVu full-colour night vision
Capture vivid colour footage 24/7 instead of standard black-and-white night video.
Human & vehicle detection
Smarter event filtering helps reduce false alarms and improve alert relevance.
Active deterrence
Built-in strobe and audio warning help discourage unwanted activity.
IP67 weatherproof build
Suitable for demanding outdoor installations in Australian conditions.
Best For
Ideal for open driveways, long side paths, front boundaries, perimeter fences, warehouse exteriors,
building walls, loading zones, and commercial sites where a bullet form factor is preferred over a turret.
Official Hikvision Videos
The ColorVu-enabled Panoramic Camera in Action
ColorVu + Panoramic Performance Demo
Hikvision | 1 Minute Introduction to ColorVu
Hikvision 8MP 180° Panoramic Camera with ColorVu
Technical Specifications
Model
DS-2CD2T67G2P-LSU/SL
Camera Type
6 MP Panoramic ColorVu Fixed Bullet Network Camera
Image Sensor
2 × 1/2.5" Progressive Scan CMOS
Maximum Resolution
3632 × 1632
Lens Type
Fixed focal dual lens, 2.8 mm
Field of View
Horizontal 180°, Vertical 81°
Minimum Illumination
Colour: 0.0005 Lux @ F1.0, 0 Lux with light
Night Imaging
24/7 full-colour ColorVu
WDR
130 dB
Compression
H.265+, H.265, H.264+, H.264
Smart Detection
Human and vehicle classification based on deep learning
Deterrence
Active strobe light and audio alarm
Weather Rating
IP67
Power
12V DC / PoE
Frequently Asked Questions
Is this a 180° panoramic bullet camera?
Yes. The 2.8mm version is listed with a 180° horizontal field of view.
Does this page match the 2.8mm lens version?
Yes. This version is written specifically for the 2.8mm model.
Does it record in colour at night?
Yes. Hikvision ColorVu is designed for 24/7 colourful imaging.
Can it filter people and vehicles?
Yes. It uses deep-learning-based human and vehicle classification to improve alert relevance.
Does it have active deterrence?
Yes. It includes a built-in strobe light and audio alarm.
Is it suitable for outdoor use?
Yes. It is rated IP67 for water and dust resistance.
More information
Download official Hikvision documents for setup, specifications, and installation.
Datasheet
PDF
Quick Start Guide
PDF
User Manual
PDF
3 Year Australian Warranty
Fast Australia-wide Delivery
Genuine Hikvision Firmware
Hikvision 8MP 4K · ColorVu · Motorised Varifocal · AcuSense
Hikvision DS-2CD3H87G3-LIZSUY/SL 8MP 4K ColorVu Motorised Varifocal Dome — 2.7-13.5mm, AcuSense, IK10
The Hikvision DS-2CD3H87G3-LIZSUY/SL is a high-end 8 MP / 4K ColorVu dome with a 2.7-13.5 mm motorised varifocal lens for remote zoom adjustment. A 1/1.8" CMOS sensor and ColorVu imaging deliver full-colour night vision down to 0.0005 lux, while Smart Hybrid Light blends IR and white light up to 40 m. AcuSense human and vehicle classification with perimeter protection sharpens alerts, 130 dB WDR handles harsh backlight, and built-in dual microphones with two-way audio plus a strobe light and audio alarm add active deterrence. The metal housing is IP67 weatherproof and IK10 vandal-resistant, with microSD up to 512 GB. Available in white or black. Australian stock, 3-Year Australian warranty.
Resolution
8 MP · 3840 × 2160 (4K)
Lens
2.7-13.5 mm Motorised
Imaging
ColorVu · Smart Hybrid Light 40 m
AI Engine
AcuSense · Human + Vehicle
Deterrence
Strobe + Audio Alarm · 2-Way Audio
Protection
IP67 · IK10 · 3-Year AU
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Key Features
Motorised Varifocal Lens
The 2.7-13.5 mm motorised lens lets you remotely dial in the exact field of view — wide for area coverage or zoomed for distant detail — without touching the camera.
4K ColorVu Full-Colour Night
An F1.0 lens and ColorVu imaging deliver vivid colour in very low light — down to 0.0005 lux — at full 8 MP / 4K resolution.
Smart Hybrid Light — 40 m
Blends IR and white light up to 40 m, switching automatically to suit the scene.
AcuSense Human / Vehicle AI
Deep-learning classification with perimeter protection focuses on people and vehicles, reducing false alarms.
Why Choose the DS-2CD3H87G3-LIZSUY/SL
Active Deterrence
A built-in strobe light and audio alarm trigger on AcuSense detection to warn intruders off.
Two-Way Audio
Built-in dual microphones and a speaker support two-way audio for live talk-down via Hik-Connect.
Vandal-Resistant Dome
The IK10-rated metal dome resists tampering and impact — ideal for public-facing and lower-mounted positions.
White or Black Finish
Choose the housing colour that best blends with your building, with 512 GB microSD on board.
Recommended For
Retail & Commercial
Adjustable 4K coverage with deterrence for shopfronts and entries.
Warehouses
Reach distant detail across large interiors with motorised zoom.
Public-Facing Areas
IK10 vandal resistance for lobbies, corridors and entries.
Homes & Driveways
Full-colour night detail with active deterrence for residential approaches.
Technical Specifications
DS-2CD3H87G3-LIZSUY/SL · Full Specifications
SKU
DS-2CD3H87G3-LIZSUY/SL
Camera Type
Hikvision G3 8 MP / 4K ColorVu Smart Hybrid Light AcuSense Motorised Varifocal Dome
Image Sensor
1/1.8" Progressive Scan CMOS
Max Resolution
3840 × 2160 (8 MP / 4K)
Lens
2.7-13.5 mm motorised varifocal (approx. 108° to 30° HFOV)
Min. Illumination
0.0005 lux @ F1.0 (colour)
Supplement Light
Smart Hybrid Light — IR + white light · up to 40 m
Wide Dynamic Range
130 dB
AI Engine
AcuSense — human + vehicle classification · perimeter protection (line crossing, intrusion)
Deterrence
Active strobe light + audio alarm
Audio
Built-in dual microphone · two-way audio
Video Compression
H.265+ / H.265 / H.264+ / H.264
On-Board Storage
microSD up to 512 GB
Power
12 VDC ±25% / PoE 802.3af
Weatherproof Rating
IP67
Impact Rating
IK10 vandal-resistant
Material
Metal housing (white or black)
Warranty
3-Year Australian Warranty
Frequently Asked Questions
What is the benefit of a varifocal lens?The 2.7-13.5 mm motorised lens lets you zoom in and out remotely, adjusting the field of view without physically moving the camera.
Does it record in colour at night?Yes — ColorVu and Smart Hybrid Light provide full-colour night images using white light when needed, while still supporting IR for discreet monitoring.
Does it have two-way audio?Yes — built-in dual microphones and a speaker support two-way audio for live talk-down.
How rugged is it?The metal dome is IP67 weatherproof and IK10 vandal-resistant, suiting exposed and public-facing positions.
Downloads & Resources
DS-2CD3H87G3-LIZSUY/SL Datasheet
Hikvision Network Camera Quick Start Guide
CCTV Guru is an authorised Australian reseller of Hikvision ColorVu cameras. Order the DS-2CD3H87G3-LIZSUY/SL 8 MP / 4K motorised varifocal dome in white or black for fast Australia-wide dispatch, expert pre-sales advice and full local warranty support. Request a free quote or contact our Australian team.
Hikvision 6MP · DarkFighter 2.0 · Motorised Varifocal · AcuSense
Hikvision DS-2CD3667G3-LIZSUY/SL 6MP Smart Hybrid Light Varifocal Bullet — 2.7-13.5mm, AcuSense, 60m, NEMA 4X
The Hikvision DS-2CD3667G3-LIZSUY/SL is a premium 6 MP motorised varifocal bullet built for tougher outdoor environments and intelligent surveillance. A 2.7-13.5 mm motorised varifocal lens lets you reframe remotely, while DarkFighter 2.0 and HIK AI-ISP deliver 24/7 colourful imaging with strong noise reduction. Smart Hybrid Light blends IR and white light up to 60 m, AcuSense classifies people and vehicles to cut false alarms, and a built-in arrayed dual microphone with two-way audio plus strobe light and audible warning add active deterrence. The housing is IP67 and NEMA 4X anti-corrosion, with the HEOP 2.0 (1.5 TOPS) open platform on board. Australian stock, 3-Year Australian warranty.
Resolution
6 MP · 3200 × 1800
Lens
2.7-13.5 mm Motorised
Low Light
DarkFighter 2.0 · HIK AI-ISP
Smart Hybrid Light
IR + White · up to 60 m
AI Engine
AcuSense · Person + Vehicle
Protection
IP67 · NEMA 4X · 3-Year AU
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Key Features
Motorised Varifocal Lens
The 2.7-13.5 mm motorised lens lets you remotely dial in the exact field of view — wide for area coverage or zoomed for distant detail — without touching the camera.
DarkFighter 2.0 + AI-ISP
Hikvision's latest low-light imaging plus HIK AI-ISP noise reduction deliver clear, colourful 24/7 footage even in challenging light.
Smart Hybrid Light — 60 m
Blends IR and white light up to 60 m, switching automatically to suit the scene for long-range night coverage.
AcuSense Person / Vehicle AI
Deep-learning classification focuses on people and vehicles, reducing false alarms from trees, rain and animals.
Why Choose the DS-2CD3667G3-LIZSUY/SL
Two-Way Audio
A built-in arrayed dual microphone and speaker support two-way audio for live talk-down and communication via Hik-Connect.
Active Deterrence
A strobe light and audible warning trigger on detection to warn intruders off before an incident.
NEMA 4X Anti-Corrosion
IP67 plus NEMA 4X protection suits coastal and harsh Australian outdoor sites prone to corrosion.
HEOP 2.0 Open Platform
The on-board HEOP 2.0 (1.5 TOPS) platform supports third-party apps for advanced analytics and integration.
Recommended For
Gates & Driveways
Adjustable zoom to frame the exact approach you need to cover.
Perimeters & Yards
60 m night reach and long-range detail across large boundaries.
Warehouses & Car Parks
Wide-to-tight flexibility for variable commercial scenes with deterrence.
Coastal Sites
NEMA 4X anti-corrosion housing for salt-air and harsh outdoor locations.
Technical Specifications
DS-2CD3667G3-LIZSUY/SL · Full Specifications
SKU
DS-2CD3667G3-LIZSUY/SL
Camera Type
Hikvision G3 6 MP DarkFighter 2.0 Smart Hybrid Light AcuSense Motorised Varifocal Bullet
Image Sensor
1/1.8" Progressive Scan CMOS
Max Resolution
3200 × 1800 (6 MP)
Lens
2.7-13.5 mm motorised varifocal (approx. 112.3° to 41.2° HFOV)
Min. Illumination
0.001 lux (colour) · 0 lux with white light
Supplement Light
Smart Hybrid Light — IR + white light · up to 60 m
Wide Dynamic Range
Scene-adaptive WDR
AI Engine
AcuSense — deep-learning person + vehicle classification
Open Platform
HEOP 2.0 · 1.5 TOPS
Deterrence
Active strobe light + audible warning
Audio
Built-in arrayed dual microphone · two-way audio
Video Compression
H.265+ / H.265 / H.264+ / H.264
Power
PoE · 12 VDC
Weatherproof Rating
IP67
Anti-Corrosion
NEMA 4X
Warranty
3-Year Australian Warranty
Frequently Asked Questions
What is the benefit of a varifocal lens?The motorised varifocal lens lets you zoom in and out remotely, adjusting the field of view without physically moving the camera.
Does it record in colour at night?Yes — with DarkFighter 2.0 and Smart Hybrid Light it provides full-colour night images using white light when needed, while still supporting IR for discreet monitoring.
How far does it see at night?Smart Hybrid Light reaches up to 60 m, suiting large yards, perimeters and long approaches.
Is it built for harsh sites?Yes — it carries both IP67 weatherproofing and NEMA 4X anti-corrosion protection for coastal and demanding outdoor locations.
Downloads & Resources
DS-2CD3667G3-LIZSUY/SL Datasheet
Hikvision Network Camera Quick Start Guide
CCTV Guru is an authorised Australian reseller of Hikvision ColorVu cameras. Order the DS-2CD3667G3-LIZSUY/SL 6 MP motorised varifocal bullet for fast Australia-wide dispatch, expert pre-sales advice and full local warranty support. Request a free quote or contact our Australian team.
COLORVU 3.0 PRO SERIES
Vandals Don't Stand a Chance: Elite 4K Night Imaging in a Ruggedized Canopy
The Hikvision DS-2CD2187G3-LIS2UY Pro Series EasyIP represents the absolute flagship tier of standalone 4K structural surveillance, meticulously engineered for high-exposure Australian commercial fronts, luxury residences, and public spaces requiring architectural subtlety. Combining an ultra-clear, true 8MP resolution matrix with an IK10 vandal-resistant mechanical canopy, this low-profile dome architecture utilizes an oversized 1/1.8" progressive scan sensor and advanced HikAI-ISP processing. This unique ecosystem extracts vivid, courtroom-ready colour data across complex lighting frames, uses deep-learning AcuSense AI analytics to filter false motions, and encapsulates a heavy-duty physical barrier where security threats are most immediate.
Resolution Matrix
8MP 4K Ultra-HD (3840×2160)
Night Vision Engine
24/7 Vivid ColorVu 3.0
Audio Array
Dual-Mic Two-Way Audio
Impact Structural Armor
IK10 Vandal-Proof Base
3-Year Local Warranty
Genuine Australian Stock
Plugin-Free Web Access
See It In Action
Flagship 4K Engineering: High Resolution Meets Vandal Armour
True 130dB WDR Forensic Overhaul
Standard security cameras quickly become blindingly useless when tasked with processing strong backlighting, such as floor-to-ceiling glass entrance doors, reflective concrete pathways, or intense afternoon Australian sun glare. The Hikvision DS-2CD2187G3-LIS2UY answers this with an onboard hardware-driven 130dB Wide Dynamic Range system. By firing multiple specialized digital short and long-exposure frames at identical times, its core chip stitches light arrays cleanly together. This provides crisp, recognizable human faces and readable number plates even when aiming straight into harsh ambient glare environments.
Advanced Core Capabilities
IK10 Vandal-Proof Armor Canopy
Built for sites prone to tampering or physical interference. Encased in a ruggedized all-metal configuration paired with a specialized impact-absorbing polycarbonate dome, this setup carries a strict IK10 rating—capable of absorbing a direct 20-joule kinetic impact weapon blow without losing structural feed integrity.
AcuSense 3.0 Deep Learning Analytics
Stop wasting precious emergency response windows chasing false movement triggers. The integrated AcuSense deep-learning layer extracts distinct structural data nodes directly from moving vectors, categorizing human silhouettes and vehicle profiles while automatically throwing out false alerts from heavy wind, rain, shadows, or animals.
Smart Hybrid Adaptive Light Path
Tailor your lighting profile with three intelligent choices: covert zero-glow Infrared (IR) Mode, fixed continuous Warm Colour Light Mode, or automated Smart Hybrid Light Mode. In Hybrid Mode, the camera captures scenes via invisible IR until a verified human target breaks a boundary box, dropping a targeted light beam to secure colour face captures.
High-Fidelity Bidirectional Voice Intercept
Features built-in dual acoustics and advanced environmental noise cancelation. Capture clear spatial sound patterns up to 8 metres away or utilize the bidirectional audio stream to talk back to couriers, property visitors, or actively warn off trespassers right from the intuitive Hik-Connect smart app interface.
Strategic Network Integration
H.265+ Compression Optimization
Streaming true 8MP 4K resolution can choke standard networks and exhaust hard disk storage instantly. Hikvision’s optimized H.265+ algorithm resolves this by evaluating static scene elements against moving target profiles, stripping back background metadata bloat to lower network drive footprints by up to 75%.
Plugin-Free Multi-Browser Architecture
No old-world desktop browser add-on patches required. The modernized hardware firmware profile includes full HTML5 structure coding natively out of the box. This provides clean, instantaneous, lag-free control streams over local networks inside Google Chrome, Safari, Edge, Firefox, and major operating systems.
What's Included in the Box
1 x Hikvision DS-2CD2187G3-LIS2UY – 8MP ColorVu 3.0 Smart Hybrid Light Vandal Dome Camera
1 x Weatherproof RJ45 Network Cable Interface Gland Set
1 x Structural Surface Screws, Wall Anchors & Drill Target Sheet
1 x Local Factory Quick Start Operational Configuration Guide
Technical Specifications
Max Resolution Architecture
8MP (3840 × 2160) Ultra-HD 4K | 1/1.8" Progressive Scan CMOS Core
Optics & Horizontal View
2.8mm Fixed Focal Array | Sweeping 108° Ultra-Wide Horizon Field
Ultra Low-Light Performance
ColorVu 3.0 Platform | 0.0005 Lux @ (F1.0, AGC ON) Forensic Colour Sensitivity
Dynamic Illumination Range
Smart Hybrid Illumination Modes (IR + Warm Light) | Extended Reach Up to 40m
Structural Impact Rating
IK10 Vandal-Proof Protection | IP67 Dust & Submersion Weather Shield
Audio Interface Controls
Dual Built-in Microphones | Bi-directional Full Duplex Audio Channels
Local Memory Interface
Integrated Slot Array Supporting microSD / SDHC / SDXC cards up to 512GB
Frequently Asked Questions
What is the benefit of an IK10 vandal-proof dome design compared to a standard turret?
A turret design features an exposed camera lens ball that can be manually knocked away, covered with clothing, or forcefully pushed down using simple tools. An IK10 vandal-proof dome encapsulates the entire lens tracking mechanism under a high-tensile metal ring and a shatter-resistant polycarbonate dome shield. This configuration easily handles direct physical weapon attacks, throwing bricks, or blunt object hits, making it ideal for low-height installations or accessible perimeters.
Does the dome glass bubble cause halo effects or infrared night fogging over time?
Older generation dome cameras suffered from IR bounce-back, where internal night illumination leaked into the glass cover, resulting in foggy circles. The DS-2CD2187G3-LIS2UY eliminates this issue completely through its ColorVu 3.0 component engineering. The optical sensors and internal hybrid lighting diodes are isolated by an anti-reflective structural gasket seal that contains all internal scatter, guaranteeing consistent video clarity.
Can this standalone 4K camera connect directly to my smart home assistant platform?
Yes. Because this model supports global native ONVIF protocols alongside modern RTSP streaming profiles, you can smoothly link your security feeds directly into secondary automation ecosystems, customised network interfaces, third-party home management applications, and professional multi-room displays over local networks.
Is a dedicated network power point necessary to run this camera?
No. This model is engineered with full PoE (Power over Ethernet - 802.3af) compatibility. This design lets you transmit both high-resolution 4K video feeds and stable operating power over a single, standard Cat6 network cable run back to a PoE network switch or NVR recorder, cutting deployment steps and wiring overhead in half.
Will the smart vehicle AI alerts differentiate between a vehicle parked out front and an actual intruder vehicle driving in?
Yes. The AcuSense 3.0 firmware analytics layer handles movement parameters intelligently. Instead of throwing out generic alerts on everything within frame, you can map specific intrusion boxes or crossing boundaries. If a vehicle stays parked outside on the street, it remains ignored; the automated alert nodes will only activate the absolute second a target vector path passes over your property threshold lines.
COLORVU 3.0 PRO SERIES
The Hikvision DS-2CD2167G3-LIS2UY Pro Series EasyIP standalone security camera represents the absolute pinnacle of high-efficiency 6MP Ultra-HD performance, optimized for high-end residential installations and commercial property lines. Powered by the groundbreaking HikAI-ISP processing architecture and true 1/1.8" Darkfighter hardware sensors, this low-profile dome camera breaks the boundaries of traditional surveillance. It delivers rich, full-colour evidence arrays 24/7, filters false alarms with surgical precision using AcuSense 3.0 Deep Learning, and integrates bidirectional audio tracking pipelines into a single, sleek, weatherproof chassis.
Resolution Matrix
6MP Ultra-HD (3200×1800)
Night Vision Engine
24/7 Vivid ColorVu 3.0
Audio Array
Dual-Mic Two-Way Audio
Analytics Tier
AcuSense 3.0 AI
3-Year Local Warranty
Genuine Australian Stock
Plugin-Free Web Access
See It In Action
Next-Gen Illumination Logic: ColorVu 3.0 Meets Smart Hybrid Light
Dynamic Night Vision Precision
Traditional monochrome night vision renders washed-out, grainy profiles that allow critical details like clothing descriptions, hair colour, or vehicle modifications to slide past undetected. The Hikvision DS-2CD2167G3-LIS2UY eradicates this vulnerability. Utilizing advanced hardware-level AI ISP architecture, it runs real-time frame multi-exposure mapping and automated noise-floor elimination. This ensures true-to-life colour saturation down to near-absolute darkness, safeguarding prosecutable evidence when standard configurations fail completely.
Advanced Core Capabilities
Smart Hybrid Light Transition
Configure three flexible deployment options: covert Infrared (IR) Mode, constant Warm White Light Mode, or the predictive Smart Hybrid Mode. In Hybrid Mode, the camera remains covert using invisible IR paths until AcuSense triggers on a perimeter breach, instantly bathing the boundary in soft white light to grab colour-accurate face snapshots.
AcuSense 3.0 Deep Learning Filters
Stop chasing false alerts. Driven by structural data nodes engineered directly into the camera sensor module, AcuSense 3.0 prioritizes human and vehicle tracking metrics with 99% accuracy. Harmless triggers like heavy wind-blown Australian foliage, intense downpours, shadow casting, or stray neighborhood animals are automatically ignored.
Dual-Microphone Audio Intercept
Equipped with dual structural microphones utilizing intelligent environmental noise cancellation. Capture high-fidelity spatial acoustics up to 8 metres away, or deploy full bidirectional Two-Way Audio pathways via the Hik-Connect application to speak directly to couriers, visitors, or trespassers.
Optimized 2.8mm Ultra-Wide Panoramic Focal Field
The premium 2.8mm fixed architectural lens provides an expansive horizontal field of view. Perfect for sweeping coverage across broad residential driveways, commercial front offices, structural carparks, and deep side passages without suffering edge warping or pixel drop.
Strategic Network Integration
H.265+ High-Efficiency Stream Engine
Maximise your hard drive lifecycle. Hikvision's customised H.265+ smart compression algorithm dynamically analyzes static scene blocks versus moving targets. This lowers your network bandwidth footprint and reduces hard drive storage consumption by up to 75% compared to standard H.264 formats.
Plugin-Free Local Network Compatibility
Forget old Internet Explorer active-X security bugs. This updated modern firmware stack provides 100% native, plugin-free HTML5 video streaming across Google Chrome, Apple Safari, Microsoft Edge, and Mozilla Firefox over local networks.
What's Included in the Box
1 x Hikvision DS-2CD2167G3-LIS2UY – 6MP ColorVu 3.0 Smart Hybrid Light Dome Camera
1 x Heavy-Duty Weatherproof RJ45 Cable Gland Assembly
1 x Structural Drill Alignment Template & Hardened Screw Pack
1 x Factory Quick Start Operational Guide
Technical Specifications
Camera Sensor Core
6MP (3200 × 1800) Progressive Scan CMOS | Powered by HikAI-ISP Matrix
Lens Parameters
2.8mm Fixed Focal Length | Wide Horizontal Field of View (105°)
Low-Light Capabilities
ColorVu 3.0 Technology | Minimum Illumination 0.0005 Lux @ (F1.0, AGC ON)
Illumination Extension
Smart Hybrid Lighting Modes | Extended Smart Reach Up to 30 Metres
Acoustic Configuration
Dual Integrated Microphones | Bidirectional Two-Way Audio Stream Channels
Structural Engineering
IP67 Weatherproof Dust/Moisture Protection | Vandal-Resistant Housing
Frequently Asked Questions
Can I use this camera standalone without a physical NVR recorder box?
Yes. The DS-2CD2167G3-LIS2UY features a built-in onboard microSD storage bay that supports high-end memory cards up to 512GB. You can power the camera via a standalone PoE injector or 12V DC power plug, and manage all recordings, smart alerts, and real-time playback loops directly through the free Hik-Connect smartphone application.
How does the Smart Hybrid Light save me from bugs and spider webs?
Traditional night vision cameras leave a hot infrared beam blasting constantly, which actively attracts bugs, moths, and spiders—subsequently triggering hundreds of annoying false alarms. By running the camera in Smart Hybrid Mode, the visible white light stays completely offline, keeping bugs away. The intense colour light only activates the exact second an actual human or vehicle target steps across your virtual tripwire line.
Is this camera compatible with my older existing Hikvision NVR recorder?
This camera relies on modern firmware compression protocols and high throughput matrices. It will drop into any Hikvision NVR that supports H.265 decoding capabilities and modern megapixel input maps. To ensure full compatibility with the deep-learning AcuSense 3.0 event tracking configurations, we highly recommend pairing this camera with Hikvision’s flagship K-Series, I-Series, or M-Series NVR recording frameworks.
Does the white light beam turn off automatically after an alert triggers?
Yes. You have total creative control over the alert behaviors. Once the human or vehicle target moves outside the custom perimeter boundary boxes or leaves your property line zone completely, the soft white light beam automatically transitions back down to covert IR mode within a set number of seconds (which you can customize in the settings).
Is there an ongoing subscription cost to use the two-way audio or get alert notifications?
No. CCTV Guru only supplies professional self-contained ecosystems. Live video stream views, instant pushes, historical timeline scrubbing, custom smart analytics toggles, and two-way audio communications are 100% free forever through the native Hik-Connect application, completely free of hidden cloud storage paywalls or ongoing subscription contracts.
Hikvision 6MP · ColorVu 3.0 · Smart Hybrid Light · AcuSense
Hikvision DS-2CD2067G3-LI2UY/SL 6MP ColorVu 3.0 Smart Hybrid Light Bullet — Strobe + Audio Alarm, 2-Way Audio
The Hikvision DS-2CD2067G3-LI2UY/SL is a compact 6 MP ColorVu 3.0 fixed bullet built for full-colour night surveillance with smart deterrence. A 1/1.8" CMOS sensor and ColorVu 3.0 imaging deliver vivid colour in very low light, while Smart Hybrid Light intelligently switches between infrared and white light — up to 40 m — to balance clear night monitoring with reduced light pollution. AcuSense focuses on human and vehicle detection for more relevant alerts, 130 dB WDR handles harsh backlight, and the built-in dual microphone with two-way audio plus strobe light and audio alarm provide active deterrence. IP67 weatherproof, PoE-powered. Available in 2.8 mm and 4 mm lens. Australian stock, 3-Year Australian warranty.
Resolution
6 MP · 3200 × 1800
Imaging
ColorVu 3.0 · 1/1.8" CMOS
Smart Hybrid Light
IR + White · up to 40 m
AI Engine
AcuSense · Human + Vehicle
Deterrence
Strobe + Audio Alarm · 2-Way Audio
Protection
IP67 · 130 dB WDR · 3-Year AU
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Key Features
ColorVu 3.0 Full-Colour Night
Hikvision's latest ColorVu imaging delivers vivid colour images in very low light — you see clothing and vehicle colour at night, not just grey shapes.
Smart Hybrid Light
Intelligently switches between infrared and white light up to 40 m, balancing clear night monitoring with reduced light pollution.
AcuSense Human / Vehicle AI
Deep-learning classification focuses on people and vehicles for more relevant alerts and fewer false alarms.
Active Deterrence
A built-in strobe light and audio alarm trigger on detection to warn intruders off before an incident.
Why Choose the DS-2CD2067G3-LI2UY/SL
Two-Way Audio
A built-in dual microphone and speaker support two-way audio for live talk-down and visitor communication via Hik-Connect.
130 dB WDR
Wide dynamic range balances bright and dark areas in the same frame for clear images against strong backlight.
Compact Bullet Form
A small, weatherproof body suits eaves, walls and tight outdoor mounting points.
Simple PoE Install
Single-cable PoE power and data, plus microSD storage up to 512 GB for local recording and ANR.
Recommended For
Homes & Driveways
Full-colour night coverage with active deterrence for residential perimeters.
Shopfronts
Two-way audio and strobe for retail entries and counters.
Side Access & Gates
4 mm lens framing for walkways and tighter approaches.
Business Perimeters
AcuSense filtering keeps alerts relevant around commercial boundaries.
Technical Specifications
DS-2CD2067G3-LI2UY/SL · Full Specifications
SKU
DS-2CD2067G3-LI2UY/SL
Camera Type
Hikvision G3 6 MP ColorVu 3.0 Smart Hybrid Light AcuSense Bullet
Image Sensor
1/1.8" Progressive Scan CMOS
Max Resolution
3200 × 1800 (6 MP)
Lens Options
2.8 mm (108.8° HFOV) or 4 mm (93.3° HFOV) fixed
Supplement Light
Smart Hybrid Light — IR + white light · up to 40 m
Wide Dynamic Range
130 dB
AI Engine
AcuSense — human + vehicle classification
Deterrence
Active strobe light + audio alarm
Audio
Built-in dual microphone · two-way audio
Video Compression
H.265+ / H.265 / H.264+ / H.264
On-Board Storage
microSD up to 512 GB
Power
12 VDC ±25% / PoE 802.3af
Weatherproof Rating
IP67
Warranty
3-Year Australian Warranty
Frequently Asked Questions
What is ColorVu 3.0?ColorVu 3.0 is Hikvision's latest full-colour night-vision imaging — a sensitive sensor and supplemental light let the camera capture colour images in very low light instead of black-and-white IR.
Does it have two-way audio?Yes — a built-in dual microphone and speaker support two-way audio for live talk-down via Hik-Connect.
Which lens should I choose?2.8 mm (108.8°) suits driveways and wide open areas; 4 mm (93.3°) suits gates, side access and tighter framing.
How does it deter intruders?When AcuSense detects a human or vehicle, the camera flashes its strobe light and plays an audio alarm to warn the intruder off.
Downloads & Resources
DS-2CD2067G3-LI2UY/SL Datasheet
Hikvision Network Camera Quick Start Guide
CCTV Guru is an authorised Australian reseller of Hikvision ColorVu cameras. Order the DS-2CD2067G3-LI2UY/SL 6 MP ColorVu 3.0 bullet in 2.8 mm or 4 mm for fast Australia-wide dispatch, expert pre-sales advice and full local warranty support. Request a free quote or contact our Australian team.
