Dahua · Intercom Indoor Monitors10-Inch Wi-Fi 2-Wire IP Indoor Intercom Monitor
VTH8642KMS-W — Answer visitors on a larger 10-inch indoor touchscreen with two-way audio and support for a planned Dahua intercom installation. This Linux-based monitor combines Ethernet, 2.4 GHz Wi-Fi and a compatible 2-wire connection option for flexible system design.
Key features
Larger indoor display
A 10-inch touchscreen provides a larger interface for visitor communication.
Two-way conversation
Speak to visitors through the integrated microphone and speaker.
Flexible network planning
Use the documented Ethernet, Wi-Fi or compatible 2-wire arrangement.
Local storage support
Use a compatible microSD card no larger than 64 GB.
Applications & installation
Suitable where a larger indoor display is preferred. Choose the wired network mode correctly—Ethernet and the 2-wire connection are not used as simultaneous network paths. Supply the specified 48 V DC power or compatible 2-wire system power; do not assume it is a standard PoE monitor.
Technical Specifications
| Model |
VTH8642KMS-W |
| Display |
10-inch TFT capacitive touchscreen |
| Resolution |
1024 × 600 |
| Operating system |
Embedded Linux |
| Wi-Fi |
2.4 GHz |
| Wired network |
Ethernet or 2-wire, select the supported connection mode |
| Audio |
Built-in microphone and speaker |
| Storage |
microSD up to 64 GB |
| Alarm connections |
6 inputs and 1 output |
| Other interface |
RS-485 |
| Power |
48 V DC, 1.25 A or compatible 2-wire system |
| Maximum consumption |
7 W |
| Installation |
Indoor |
| Dimensions |
250 × 190 × 23.5 mm |
| Net weight |
0.67 kg |
| Warranty |
36 months — subject to warranty terms |
Frequently asked questions
Is this an Android smart panel?
No. This model uses embedded Linux. It is not the Android SCP-series smart control panel.
Can I add the 128 GB or 256 GB WD Purple card?
No. The specified maximum is 64 GB, so those larger options are not listed as compatible add-ons.
Can I use a normal PoE switch to power it?
Standard PoE powering is not specified. Use the documented 48 V DC supply or compatible 2-wire system.
Downloads
Manufacturer documentation: the datasheet identifies the product or stated product family; general guides cover the applicable equipment type. Confirm model-specific instructions before installation.
