Dahua · CCTV Camera AccessoriesAluminium Camera Mount Adapter
DH-PFA10C — Use this purpose-built aluminium mount adapter to connect a compatible Dahua camera to its specified mounting system. The white finish suits clean commercial installations, while its 3 kg load rating helps installers plan the complete assembly.
Key features
Dimensions
166 × 166 × 83.5 mm. Check the complete mounting arrangement against the official dimensions and installation requirements.
Applications & installation
Check the camera's accessory list and the adapter's dimensional drawing before ordering. An adapter plate is only one part of a mounting arrangement; it is not a complete ceiling bracket or a universal fit.
Technical Specifications
| Model |
DH-PFA10C |
| Material |
Aluminium alloy |
| Colour |
White |
| Dimensions |
166 × 166 × 83.5 mm |
| Rated load |
3 kg |
| Net weight |
0.43 kg |
| Operating temperature |
−40°C to +60°C |
| Warranty |
36 months — subject to warranty terms |
Frequently asked questions
Will this fit every Dahua camera?
No. Match the exact camera, required adapters and mounting-hole pattern to the official datasheet. A similar product name or appearance is not a compatibility guarantee.
Is the camera included?
No. This listing is for the named mounting accessory. Cameras, additional brackets, power equipment and site-specific fixings are separate unless explicitly stated.
Downloads
Manufacturer documentation: the datasheet identifies the product or stated product family; general guides cover the applicable equipment type. Confirm model-specific instructions before installation.
