UniFi Gateway — NDAA Compliant
UniFi Gateway Max (UXG-Max) — Multi-WAN 2.5G Security Gateway with USB-C Power
The UniFi Gateway Max (UXG-Max) is the high-performance step up in the UniFi gateway range — a compact, USB-C powered multi-WAN security gateway with full 2.5 Gigabit support across all five ports, 2.3 Gbps IDS/IPS routing, and the ability to remap LAN ports to WAN for true multi-WAN failover and load balancing. Designed for small-to-medium sites in Australia that need more than Gigabit throughput, the UXG-Max delivers enterprise-grade security and networking in a palm-sized, fanless enclosure — no rack space required. Genuine Ubiquiti stock with fast Australia-wide shipping.
IDS/IPS
2.3 Gbps
Ports
5 × 2.5GbE
Multi-WAN
Up to 4 WAN
Power
USB-C 5V/3A
Why Choose the UniFi Gateway Max?
2.3 Gbps IDS/IPS Routing
Full signature-based IDS/IPS threat detection at 2.3 Gbps — making it ideal for sites with high-speed NBN, fibre, or multi-WAN connections that need next-gen security without a throughput bottleneck.
Full 2.5 Gigabit on All Ports
All five ports run at 2.5 GbE (2.5G/1G/100M/10M) — future-proofing your network for multi-gig ISP connections and 2.5G switches or APs without any bottleneck at the gateway.
Multi-WAN — Up to 4 WAN Ports
Remap LAN ports to WAN to support multi-WAN failover and load balancing (max 4 WAN) — keeping your network online even if one ISP connection drops. UniFi LTE Backup adds an extra failover path.
WireGuard, OpenVPN, L2TP & IPsec
Built-in WireGuard and OpenVPN VPN servers, L2TP, OpenVPN/WireGuard VPN client, IPsec and Site Magic site-to-site VPN, plus one-click Teleport zero-config VPN — all licence-free.
Licence-Free SD-WAN & Dynamic Routing
Policy-based WAN/VPN routing, OSPF dynamic routing, advanced QoS, advanced NAT, integrated RADIUS server, and RadSec — all included at no extra cost.
Next-Gen Zone-Based Firewall
Stateful firewall, application-aware Layer 7 firewall, DPI and traffic identification, content filtering, region/domain/app filtering, ad blocking, and 55,000+ IPS signatures with CyberSecure.
USB-C Powered — 9.6W Max
Powered by the included USB-C adapter (5V/3A) drawing just 9.6W maximum — silent, fanless, and suitable for any location including a small comms cabinet or behind a desk.
NDAA Compliant
Fully NDAA Section 889 compliant for government, defence, and security-sensitive installations where supply-chain integrity is a requirement.
UXG-Max vs UXG-Lite — Which Should You Choose?
Choose UXG-Max if you need…
Multi-gig (2.5G) throughput, 2.3 Gbps IDS/IPS performance, multi-WAN failover, or a future-proof gateway for high-speed NBN/fibre connections. Best for growing SMBs and multi-WAN sites.
Choose UXG-Lite if you need…
A budget-friendly, ultra-compact gateway for standard Gigabit connections. Best for home networks and small offices where 1G throughput is sufficient and cost is a priority.
Ideal Use Cases
Small to Medium Business
High-speed NBN or fibre connections with multi-WAN failover, IDS/IPS, and VPN for offices, retail stores, and professional services firms across Australia.
Advanced Home Networks
Power users who want 2.5G throughput, IDS/IPS, and WireGuard VPN in a compact, silent, USB-C powered device.
Multi-WAN & Failover
Sites requiring multi-WAN failover or load balancing across ISP connections — remap LAN ports to WAN for true redundancy, with UniFi LTE Backup as an additional path.
UXG-Lite Upgrade
The natural upgrade from the UXG-Lite for sites that have outgrown Gigabit throughput or need multi-WAN and higher IDS/IPS performance.
Technical Specifications
Model
UXG-Max
Processor
Quad-core ARM® Cortex®-A53 @ 1.5 GHz
System Memory
2 GB
Port Layout
5 × 2.5 GbE RJ45 (2.5G/1G/100M/10M)
Default WAN
1 × 2.5 GbE RJ45 • max 4 WAN ports
IDS/IPS Throughput
2.3 Gbps
IDS/IPS Signatures
55,000+ with CyberSecure
Power Method
USB Type-C (5V DC/3A, adapter included)
Supported Voltage
100–240V AC
Max Power Consumption
9.6W
Security
Stateful & Layer 7 firewall, DPI, IPS/IDS, content/region/domain/app filtering, ad blocking
VPN
WireGuard • OpenVPN • L2TP • IPsec • Site Magic • Teleport
SD-WAN & Routing
Licence-free SD-WAN, OSPF, multi-WAN load balancing, advanced QoS, advanced NAT, RADIUS/RadSec
Management
Ethernet • Bluetooth • UniFi Network app
Enclosure
Polycarbonate • compact desktop
Dimensions / Weight
141.8 × 127.6 × 30 mm • 520 g
Operating Temperature
−10°C to 40°C, 5–95% non-condensing
Certifications
CE, FCC, IC, Anatel
Compliance
NDAA compliant
UniFi Network Requirement
Version 8.1.113 or later
What's in the Box
UXG-Max Unit
Compact multi-WAN 2.5G UniFi security gateway with 5 × 2.5GbE RJ45 ports.
USB-C Power Adapter
USB Type-C power adapter (5V/3A, 100–240V) included.
Quick-Start Guide
Installation guide and documentation included.
Controller Required
Requires UniFi Network 8.1.113+ on a Cloud Key, UniFi OS Console, or Official UniFi Hosting. Not a standalone device.
Frequently Asked Questions
Does the UXG-Max work as a standalone router?
No. The UXG-Max requires a UniFi Network controller (Cloud Key, UniFi OS Console, or Official UniFi Hosting running version 8.1.113 or later) to function.
What is the difference between the UXG-Max and UXG-Lite?
The UXG-Max has 2.5G ports on all interfaces, 2.3 Gbps IDS/IPS throughput, multi-WAN capability via remappable LAN ports, and 2GB RAM. The UXG-Lite has 1G ports and lower IDS/IPS throughput, but is more affordable for standard Gigabit deployments.
Can the UXG-Max do multi-WAN failover?
Yes. LAN ports can be remapped to WAN (up to 4 WAN), enabling multi-WAN failover and load balancing across ISP connections, with optional UniFi LTE Backup.
Does it support VPN?
Yes. WireGuard, OpenVPN server/client, L2TP, IPsec, Site Magic site-to-site, and Teleport zero-config VPN are all supported with no additional licensing fees.
Is it suitable for high-speed NBN or fibre connections?
Yes. With 2.5G ports and 2.3 Gbps IDS/IPS throughput, the UXG-Max handles multi-gig ISP connections without bottlenecking your network — ideal for 1 Gbps+ NBN or fibre plans.
Does it have Wi-Fi?
No. The UXG-Max is a wired gateway only. For Wi-Fi, pair it with UniFi Access Points managed through the same UniFi Network controller.
Downloads & Resources
UXG-Max Datasheet
Installation Guide
