Hikvision Door Controller, Single Door, TCP/IP (2601), Pro Series Access Controller, HIK-AXS-K2601-G
100,000 cards and 300,000 events storage
Communication via TCP/TP, ISUP5.0 and RS-485
ISAPI, OSDP supported
1 door access control
Alarm input/output and alarm event upload
RS-485 interface and Wiegand interface for accessing card reader
UL294 Standard Qualified
Supports battery access
DownloadDatasheet
Hikvision Door Controller, 4 Door, TCP/IP (2604), Pro Series Access Controller, HIK-AXS-K2604-G
100,000 cards and 300,000 events storage
Communication via TCP/TP, ISUP5.0 and RS-485
ISAPI, OSDP supported
4 doors access control
Alarm input/output and alarm event upload
RS-485 interface and Wiegand interface for accessing card reader
UL294 Standard Qualified
Supports battery access
DownloadDatasheet
Hikvision Door Controller, 2 Door, TCP/IP (2602), Pro Series Access Controller, HIK-AXS-K2602-G
100,000 cards and 300,000 events storage
Communication via TCP/TP, ISUP5.0 and RS-485
ISAPI, OSDP supported
2 doors access control
Alarm input/output and alarm event upload
RS-485 interface and Wiegand interface for accessing card reader
UL294 Standard Qualified
Supports battery access
DownloadDatasheet
Hikvision Face Recognition Terminal, 2MP, 7" Touch Screen, Mifare, IP65 (K1T671), Pro Face Access Terminal, HIK-AXS-K1T671M
Forced mask wearing alert: If the recognizing face does not wear a mask, the device will prompt a voice reminder. At the same time, the authentication or attendance will be failed
Face mask wearing alert: If the recognizing face does not wear a mask, the device will prompt a voice reminder. At the same time, the authentication or attendance is valid
7-inch LCD touch screen, 2 Mega pixel wide-angle lens, built-in Mifare card reading module
Face recognition distance (without face mask): 0.3 m to 3 m, Duration ＜ 0.2 s/User, Accuracy rate ≥ 99%
Max.6000 faces, Max.6000 cards
Two-way audio with client software, indoor station, and mainstation
Supports TCP/IP
Configuration via the web client
Supports ISAPI and ISUP5.0 protocol
IP65
DownloadDatasheet
Hikvision Intercom, Gen 2, Table Bracket for KH6320/KH8520 Series Indoor Station (6320), Indoor Station Table Bracket, HIK-DS-KABH6320-T
Table bracket for KH6320/8520 series indoor station
Material: SUS430
DownloadDatasheet
Hikvision Intercom, Gen 2, Villa Door Station, 1 Button, Wifi, Mifare Reader, Plastic (6113), Plastic Villa Door Station, HIK-DS-KV6113-WPE1
2 MP camera with IR supplement
One-touch button calling design for easier calls
Built-in card reader module
Standard PoE power supply
IP65 protection level
Convenient Hik-Connect APP mobile control
DownloadDatasheet
Hikvision Intercom, Gen 2, Villa Door Station, 1 Button, Plastic, Poe, No Reader (6103), Plastic Villa Door Station, HIK-DS-KV6103-PE1
2 MP camera with IR supplement
One-touch button calling design for easier calls
Built-in card reader module
Standard PoE power supply
IP65 protection level
Convenient Hik-Connect APP mobile control
DownloadDatasheet
Hikvision Intercom, Gen 2, Entry Panel Surface Mounting Box, 3 Module, Stainless Steel (ACW3), 2nd Video Intercom Brackets, HIK-DS-KD-ACW3-STAINLESS
3 Surface mounting module brackets of modular door station: includes 3 module frame , 3 module front panel, 1 button cover and some other necessary accessories
Stainless steel high quality material
DownloadDatasheet
Hikvision Intercom, Gen 2, Entry Panel Surface Mounting Box, 1 Module, Stainless Steel (ACW1), 2nd Video Intercom Brackets, HIK-DS-KD-ACW1-STAINLESS
1 Surface mounting module brackets of modular door station: includes 1 module frame, 1 module front panel and some other necessary accessories
Stainless steel high quality material
DownloadDatasheet
Hikvision Intercom, Gen 2, Keypad Module, Stainless Steel (KD-KP), KD8 Series Pro Modular Door Station, HIK-DS-KD-KP-STAINLESS
Keypad module of modular door station
Supporting input pin code to open door, call indoor station
IP65 and IK07 higher protection level
Backlight compensation behind the keypad buttons
Easy to use and extend
Stainless Steel high quality material
DownloadDatasheet
Hikvision Intercom, Gen 2, Blank Module (KD-BK), KD8 Series Pro Modular Door Station, Hik-DS-KD-BK
Blank module of modular door station
Designed for the fill blank grid during installation
IP65 protection level
Easy to use and extend
DownloadDatasheet
Hikvision 2 Wire Intercom Kit, Gen 2, 1 to 1 Surface Mount, Black (KIS), Villa Two Wire Kit, Hik-DS-KIS702
This kit comes with
2-wire digital IP video intercom kit for villa or house, only one call button
DS-KD8003-IME2/Surface x 1
DS-KH6320-WTE2 x 1
DS-KAD704 x 1
DS-KAW30-2N x 1
16GB TF card x 1
DownloadDatasheet
Hikvision Intercom, Gen 2, Power Supply for DS-KAD706 & DS-KAD706-S (KAW60-2N), Power Supply Unit, HIK-DS-KAW60-2N
24 VDC/60 W Power Supply for 2-wire IP distributor
Din rail mounting
DownloadDatasheet
Hikvision Intercom, Gen 2, Rain Hood to Suit ACW3 (RS3), Rain Shield of Module Door Station, HIK-DS-KABD8003-RS3
Convenient design available for the 3 module surface mounting of the modular door station (DS-KD8003-IME1 or DS-KD8003-IME2)
Material: SECC
DownloadDatasheet
Hikvision Intercom, Gen 2, Two-wire 7" Colour Monitor, Wifi, White (6320), Two Wire Indoor Stations, HIK-DS-KH6320-WTE2-white
2-wire IP indoor station
7“ capacitive touch-screen, Wi-Fi
TF card support, max t o 32G
8-ch alarm input, 2 × alarm output, 1 × RS485
Remote unlocking via the client or APP
Views live videos of door stations and linked cameras
DownloadDatasheet
Hikvision Mifare-1 Keytag (PTS-MF), HIK-AXS-PTS-MF
Rf Frequency -14.1 To 14.4 Mhz
Operation Temperature-10 C 50 C
Shell Material -Pvc, Ab Resin
Dimension (Wxhxd) -26x50x4.5mm
Storage Temperature --25 C 65 C
Model - DS-Pts-Mf
Hikvision Intercom, Gen 2, Entry Panel Flush Mount Box, 3 Module (ACF3), 2nd Video Intercom Brackets, HIK-DS-KD-ACF3
3 Flush mounting module brackets of modular door station: includes gang box, cover screws, lines, etc.
Plastic material
DownloadDatasheet
Hikvision Intercom, Gen 2, Entry Panel Flush Mount Box, 2 Module (ACF2), 2nd Video Intercom Brackets, HIK-DS-KD-ACF2
2 Flush mounting module brackets of modular door station: includes gang box, cover screws, lines, etc.
Plastic material
DownloadDatasheet
Hikvision Intercom, Gen 2, Entry Panel Flush Mount Box, 1 Module (ACF1), 2nd Video Intercom Brackets, HIK-DS-KD-ACF1
1 Flush mounting module brackets of modular door station: includes gang box, cover screws, lines, etc.
Plastic material
DownloadDatasheet
Hikvision Intercom, Gen 2, Display Module, 3.5in Monitor, 4 Scroll Buttons (KD-DIS), KD8 Series Pro Modular Door Station, HIK-DS-KD-DIS
Display module of modular door station
3.5-inch LCD screen with rich information display: Dial number, pin code unlock, contact list
Store up to 2000 contacts
IP65 protection level
Backlight compensation behind the module
Support multiple languages
DownloadDatasheet
Hikvision IP Intercom, Gen 2, 7" Colour Monitor, Wifi, POE, Reddot (8350), KH8 Series Indoor Station, HIK-DS-KH8350-WTE1
7-inch IPS touch screen with 1024 × 600 resolution
Reddot award winner
Convenient Hik-Connect APP Mobile Control
Receive calls, open the door and live view remotely
Easy to use without PC
Easy wizard for quick set up
Configure the whole system on one touch screen
Rich functions and extensions
Live-view of the door station and cameras in public areas
Support voice messages when no response from the indoor station
Receive alarms by internal alarm terminals
Elevator access control
DownloadDS-KH8350-WTE1 Datasheet
Hikvision Intercom, Gen 2, Entry Panel Surface Mounting Box, 3 Module (KD-ACW3), 2nd Video Intercom Brackets, DS-KD-ACW3
3 Surface mounting module brackets of modular door station: includes 3 module frame, 3 module front panel, 1 button cover and some other necessary accessories
Stainless steel high quality material
DownloadDatasheet
Hikvision Intercom, Gen 2, Entry Panel Surface Mounting Box, 2 Module (KD-ACW2), 2nd Video Intercom Brackets, HIK-DS-KD-ACW2
2 Surface mounting module brackets of modular door station: includes 2 module frame , 2 module front panel, 1 button cover and some other necessary accessories
Stainless steel high quality material
DownloadDatasheet
Hikvision Intercom, Gen 2, Mifare 1 Card Reader Module, 13.56MHz (KD-M), KD8 Series Pro Modular Door Station, HIK-DS-KD-M
M1 card reader module of modular door station
Support unlock door via swiping card, issuing cards
IP65 protection level
Backlight compensation behind the module
Easy to use and extend
Datasheet
Hikvision Intercom, Gen 2, Keypad Module (KD-KP), KD8 Series Pro Modular Door Station, HIK-DS-KD-KP
Keypad module of modular door station
Supporting input pin code to open door, call indoor station
IP65 and IK07 higher protection level
Backlight compensation behind the keypad buttons
Easy to use and extend
Datasheet
Hikvision Intercom, Gen 2, Indicator Module (KD-IN), KD8 Series Pro Modular Door Station, HIK-DS-KD-IN
Indicator module of modular door station
Rich device status indication: call, door open and two-way audio
IP65 protection level
Backlight compensation behind the module
Easy to use and extend
DownloadDatasheet
Hikvision Intercom, Gen 2, Nametag Module, 6 Button (KD-KK), KD8 Series Pro Modular Door Station, HIK-DS-KD-KK
Nametag module of modular door station
Six nametag buttons calling Design For easier calls
IP65 protection level
Backlight compensation behind the nametag buttons
Easy to use and extend
DownloadDatasheet
Hikvision Intercom Elevator/lift Controller, Master (2210), Elevator Master Controller, HIK-DS-K2210
Master elevator controller
Control 128 floors' permissions
20,000 cards and 50,000 events storage
Uplink Communication: TCP/IP and RS-485
Multiple authentication modes
Configure and manage device via web client and client software
Watchdog and tamper-proof function
Accessible Card Reader: 2 Wiegand readers or 2 RS485 readers
DownloadDatasheet
Hikvision Intercom Elevator/lift Controller, 16 Relay (0016A), Elevator Sub-Controller, HIK-DS-K2M0016A
Distributed elevator controller
Connectable with up to 16 relays to control floor buttons in the elevator
RS-485 communication with the master elevator controller
DIP switch settings for device address and relay types
Up to 8 distributed elevator controllers can be linked to the master elevator controller
Control the elevator via the relay
DownloadDatasheet
Dahua Master Station DHI-VTS5A40B
Features
Highly convenient, it has a 10-inch glass touch screen with a 1024 (H) x 600 (V) resolution and supports speaker phone and handsets
Supports desk mount installation, and the bracket can be adjusted from 0-45
Offers HDMI output with a resolution up to 1024 (H) x 600 (V)
The intercom can be set for residential areas a
Specifications
MASTER STATION
SIZE
10inch
COLOUR
Titanium Grey
RESOLUTION
1024 x 600
STORAGE
Micro SD, Max 512 GB
POWER SUPPLY
12V DC, 4A
TECHNOLOGY
Android 11
Downloads
VTS5A40B_datasheetDigital VTS_User's Manual_V1.0.0Digital VTS_Quick Start Guide_V1.0.0VTS5A40B_DIMENSIONS
Dahua 2-Wire Hybrid VIlla Door Station DHI-VTO2003F
Features
Aluminum alloy front panel
Offers video intercom which communicates through half-duplex
Auto IR illumination
Video messages can be left for unanswered calls(SD card is required for VTH)
Features nameplate and DWDR
Supports local lock and second lock
Offers anti-tampering alarm
IP65 and IK07 rated
Specifications
OUTDOOR STATION
RESOLUTION
2MP
TECHNOLOGY
2- wire
POWER SUPPLY
2- wire controller
PROTECTION
IP65
MOUNT
Surface & Flush
MATERIAL
Aluminum Alloy
Downloads
VTO2003F_datasheet_202212202-Wire Hybrid Door Station_User's Manual_V1.0.3Dahua 2-wire Hybrid Door Station_OPEN SOURCE SOFTWARE NOTICEVTO2003F_DIMENSIONSVTO2003F_Rendergraph_Application_EN
The Dahua 2-Wire Wi-Fi Video Intercom Kit DHI-KTX01(S) brings a sleek design, mobile notifications, and comprehensive security features. Night vision and IP65 waterproof are part of the package, as is the ability to integrate with popular alarm systems such as Bosch. No NVR is required, and HDCVI cameras can be connected too.
In the Box:
1 x 2-wire Wi-Fi Hybrid Indoor Monitor DHI-VTH5123H-W:
7'' TFT capacitive touch screen
Offers video intercom that communicates with VTOs through half-duplex, and the app through full-duplex
Supports recording videos and capturing snapshots. (SD card is required)
6-channel alarm input and 1-channel alarm output
The app can be used to receive calls and alarm notifications
Connects to HDCVI camera.
1 x 2-wire Hybrid Villa Door Station DHI-VTO2003F:
Aluminum alloy front panel
Auto IR illumination
Video messages can be left for unanswered calls. (SD card is required for VTH)
Features nameplate and DWDR
Supports local lock and second lock
Offers anti-tampering alarm
IP65 and IK07 rated.
1 x 2-wire Controller DHI-VTNC1003C1 x Surface Mount Bracket VTM115
Download
KTX01 Datasheet_202303032-Wire Hybrid Door Station User's Manual_V1.0.32-Wire Controller User's Manual_V1.0.42-Wire Hybrid Indoor Monitor (7-inch) User's Manual_V1.0.4Dahua 2-wire Hybrid Indoor Monitor Privacy Policy
Duhua 2-Wire Wi-Fi Hybrid Indoor Monitor DHI-VTH5123H-W
Features
7'' TFT capacitive touch screen
Offers video intercom that communicates with VTOs through half-duplex, and the app through full-duplex
Supports recording videos and capturing snapshots (SD card is required)
6-channel alarm input and 1-channel alarm output
The app can be used to receive calls and alarm notifications
Supports surface mount
Connects to HDCVI camera
Specifications
INDOOR MONITORS
SIZE
7 Inch
COLOUR
WHITE
RESOLUTION
1024x600
STORAGE
Micro SD, Max 64GB
POWER SUPPLY
2-wire Controller
TECHNOLOGY
2-wire
Downloads
VTH5123H-W_datasheet_20221118Dahua 2-wire Hybrid Indoor Monitor_Privacy PolicyDahua 2-wire Hybrid Indoor Monitor_OPEN SOURCE SOFTWARE NOTICEDahua 2-wire Hybrid Indoor Monitor_SOFTWARE LICENSE AGREEMENT2-Wire Hybrid Indoor Monitor (7-inch)_User's Manual_V1.0.4
Customised encasing for UniFi Protect G4 Doorbell.
With the UniFi Protect G4 Doorbell Skin Cover, the G4 Doorbell smoothly blends into the background of your choosing.
Dahua Aluminium Surface Box for VTO2000A & VTO2000A-2
Material: Metal
Size: 145mm x 134mm x 88mm
Weight: 1 Kg
Surface mounted box
Specifications
CAMERA BRACKETS
TYPE
Surface Mount
MATERIAL
Metal
COLOUR
Silver
DIMENSION
145mm x 134mm x 88mm
Downloads
VTOB108 Datasheet
Dahua Flush Mount Box for VTO9341D
Material: SPCC
Size: 144mm x 452mm x 69mm
Weight: 1.2 Kg
Flush mounted box
Specifications
CAMERA BRACKETS
TYPE
Flush Mount
MATERIAL
SPCC
COLOUR
Black
DIMENSION
144mm x 452mm x 69mm
Downloads
Datasheet of DH-AC-VTOB119
Dahua 2MP IP Villa 1 button Outdoor Station, Viewing Wide Angle 140 degree, Night vision, Mifare Card Reader
2MP HD CMOS camera
Aluminum panel, IP65, IK08
ICR Night vision & Voice indication
Video & Audio messaging
Remote intercom with mobile APP
Surface mounted
Specifications
OUTDOOR STATION
RESOLUTION
2MP
TECHNOLOGY
IP
POWER SUPPLY
DC 12V, PoE
PROTECTION
IP65, IK08
MOUNT
Surface
MATERIAL
Alumimum
Downloads
Datasheet of VTO3211D
Quick Start Guide of VTO3211D
Villa VTO_User's Manual_V1.0.0-Eng
Villa Door Station (Version 4.3)_Quick Start Guide_V1.0.0-Eng
Villa Door Station_Installation Guide_V1.0.0-Eng
Dahua Metal flush box for VTO2000A & VTO2000A-2
Material: Metal
Size: 125mm x 135mm x 56mm
Weight: 0.8 Kg
Flush mounted box
Specifications
CAMERA BRACKETS
TYPE
Flush Mount
MATERIAL
Metal
COLOUR
Black
DIMENSION
125mm x 135mm x 56mm
Downloads
VTOB107_Datasheet
Dahua 2-Wire Network Controller
4 groups of 2-wire port, provide power and signal to other 2-wire devices
RJ45 port, connected LAN
Surface mounted & DIN-Rail Mounted
Downloads
DH-VTNC3000A Datasheet_20161103User Manual
Dahua Plastic Flush Box for VTO1210C-X
Material: Plastic
Size: 126mm x 389mm x 71mm
Weight: 0.5 Kg
Flush mounted box
Specifications
CAMERA BRACKETS
TYPE
Flush Mount
MATERIAL
Plastic
COLOUR
Silver
DIMENSION
126mm x 389mm x 71mm
Downloads
DH-VTOB103_Datasheet
Dahua 7-inch Touch Screen IP Video Intercom Kit is the modern doorbell for your home or office. Receive notifications on your Dahua's official DMSS app when visitors press the door station. You can also view on your 7-inch IPC indoor monitor which can be beautifully hanged in your living room. The surface mounted outdoor station offer adjustable viewing angle with can turn 100 degree and features ICR 5m Night Vision. This is the IP video intercoms and cabling can be done by using RJ45 ethernet cables.
Inside the bundle:
1 x 7-inch Black Monitor VTH2621GW-P
1 x Outdoor Station VTO2101E-P
1 x Uniarch 8 Port PoE Switch with Power Supply, SW-2110-P
1 x 7-inch Monitor VTH2621GW-PThis Dahua IP Indoor Monitor features white colour frame, 7 inch touch screen, 1024×600 pixels resolution with standard PoE. 6 alarms can be connected and security cameras footage can be viewed as well.
7'' TFT capacitive touch screen, 1024 x 600
6-channel alarm input and 1-channel alarm output
Standard PoE
Door station and IPC monitor
H.265 and H.264 video coding
High performance & cost-effective
1 x Outdoor Station VTO2101E-PDahua 2MP IP Villa Outdoor Station, Viewing Wide Angle 100 degree, Adjustable Viewing Angle, ICR 5m Night Vision
HD CMOS camera.
Zinc alloy panel, IP65 and IK10 rated.
ICR night vision and voice prompt.
Video and audio messaging.
TCP/IP, and SIP.
Surface mounted.
1 x Uniarch 8 Port PoE Switch with Power Supply, SW-2110-PUniarch Switch, 10 x 100Mbps network ports, including 8 PoE/PoE+ ports, 2 x 100Mbps uplink ports, Max capacity for single port 30W, total capacity 120W, up to 250m transmission distance, all-metal housing
Multiple working modes to address your business needs: Normal, Secure and Surveillance
Support port traffic control
Support for secure mode, all downlink ports can communicate only with uplink ports
Up to 250m transmission distance on surveillance mode
Support buffer optimization
All-metal housing, safe and reliable
Dahua 7-inch Touch Screen IP Video Intercom Kit is the modern doorbell for your home or office. Receive notifications on your Dahua's official DMSS app when visitors press the door station. You can also view on your 7-inch IPC indoor monitor which can be beautifully hanged in your living room. The surface mounted outdoor station offer adjustable viewing angle with can turn 100 degree and features ICR 5m Night Vision. This is the IP video intercoms and cabling can be done by using RJ45 ethernet cables.
Inside the bundle:
1 x 7-inch Black Monitor DHI-VTH2621G-P
1 x Outdoor Station VTO2101E-P
1 x Uniarch 8 Port PoE Switch with Power Supply, SW-2110-P
1 x 7-inch Black Monitor DHI-VTH2621G-PThis Dahua IP Indoor Monitor features white colour frame, 7 inch touch screen, 1024×600 pixels resolution with standard PoE. 6 alarms can be connected and security cameras footage can be viewed as well.
7'' TFT capacitive touch screen, 1024 x 600
6-channel alarm input and 1-channel alarm output
Standard PoE
Door station and IPC monitor
H.265 and H.264 video coding
High performance & cost-effective
1 x Outdoor Station VTO2101E-PDahua 2MP IP Villa Outdoor Station, Viewing Wide Angle 100 degree, Adjustable Viewing Angle, ICR 5m Night Vision
HD CMOS camera.
Zinc alloy panel, IP65 and IK10 rated.
ICR night vision and voice prompt.
Video and audio messaging.
TCP/IP, and SIP.
Surface mounted.
1 x Uniarch 8 Port PoE Switch with Power Supply, SW-2110-PUniarch Switch, 10 x 100Mbps network ports, including 8 PoE/PoE+ ports, 2 x 100Mbps uplink ports, Max capacity for single port 30W, total capacity 120W, up to 250m transmission distance, all-metal housing
Multiple working modes to address your business needs: Normal, Secure and Surveillance
Support port traffic control
Support for secure mode, all downlink ports can communicate only with uplink ports
Up to 250m transmission distance on surveillance mode
Support buffer optimization
All-metal housing, safe and reliable
Dahua Lift Controller connects up to 1 Wiegand reader and 2 RS485 readers, Support 8 cascading, up to 128 floors permission control
Connection up to 1 Wiegand reader and 2 RS485 readers
Support 8 cascading, up to 128 floors permission control
Alarm In/Out: 6/2
Alarm records and log records: 30,000
Maximum support 60 call lift modules
All floors' permission will be released if fire alarm triggered
Remote control via web client
Downloads
DAHUA_DHI-VTM416_Lift_Controller_Data_SheetVTM416 User Manual
