NDAA Compliant • Network I/O Relay ModuleAXIS A9188 (0820-001) — Australian Stock & 5-Year Warranty
The AXIS A9188 Network I/O Relay Module is an intelligent, network-connected I/O expander that adds 8 configurable I/Os with supervised inputs and 8 Form C relays to any Axis system. Built on an open platform with the VAPIX open API, it integrates tightly with the AXIS A1001 Network Door Controller and third-party facility systems such as elevator floor management and HVAC. It also supplies 12 V DC and 24 V DC power out to connected field devices, so it can extend the functionality of virtually any Axis product that needs extra inputs, outputs or relays.
DIGITAL I/O
8x Configurable
RELAYS
8x Form C
POWER INPUT
PoE+ or 8–28 V DC
OPEN API
VAPIX & ACAP
Supervised inputs for genuine line security
Unlike a basic relay board, every one of the eight I/Os on the A9188 can be set as a standard input, a supervised input with analog read-out, or an output. Supervised inputs monitor the 0–12 V range across four states, so the module can tell the difference between a normal loop, an alarm, a cut cable and a shorted cable. Combined with a dedicated tamper input and a 30,000-event FIFO log, that makes the A9188 suitable for access control and alarm interfaces where line integrity actually matters.
Elevator & floor management
Eight Form C relays rated to 1 A at 48 V DC map neatly onto elevator floor buttons, letting an AXIS A1001 door controller restrict which levels a credential can reach.
Powers your field devices
Dual 12 V DC and 24 V DC outputs feed locks, sensors and sounders directly — up to 12 W shared when running on PoE Class 4 or DC input, or 3.6 W on PoE Class 3.
Open integration
VAPIX open API, AXIS Video Hosting System with One-Click Connection, and AXIS Camera Application Platform support for installing third-party edge applications.
Hardened networking
HTTPS encryption, IEEE 802.1X network access control, IP address filtering and digest authentication, plus SNMPv1/v2c/v3 and IPv6 for enterprise deployment.
Technical Specifications
I/O INTERFACE
Digital I/O
8x I/O, configurable as input, supervised input with analog read-out, or output
Digital input range
0 to max 40 V DC; supervision between 0–12 V (4 states)
Digital output
0 to max 40 V DC, open drain, max 100 mA
Relays
8x Form C relays, NO/NC contacts, max 1 A, 48 V DC (max 30 V DC outdoors)
Tamper
Dedicated tamper input for external tamper contact(s)
NETWORK & SECURITY
Network port
1x RJ45 10BASE-T/100BASE-TX
Security
Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X, digest authentication
Protocols
IPv4, IPv6, HTTP, HTTPS, TLS, QoS Layer 3 DiffServ, FTP, SFTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SOCKS
SYSTEM INTEGRATION
API
Open API for software integration, including VAPIX
Hosting
AXIS Video Hosting System (AVHS) with One-Click Connection
Edge applications
Support for AXIS Camera Application Platform (ACAP)
Event history
30,000 events, First In First Out (FIFO)
Event actions
Notification via email, HTTP, HTTPS and TCP; external output port; status LED
Event triggers
Tamper detection, network lost, configuration, event logger, hardware, input signal, schedule, system, time, supervised inputs (4 states), relays and outputs, heartbeat lost
POWER
Power in
8–28 V DC, max 26 W, or PoE IEEE 802.3af Type 1 Class 3 / IEEE 802.3at Type 2 Class 4
Power out
12 V DC and 24 V DC
Max power out
Shared between 12 V and 24 V outputs — PoE Class 3: 3.6 W; PoE Class 4 or DC input: 12 W
Connectors
Terminal blocks: 1x DC IN, 2x DC out, 8x inputs/outputs, 8x relays, 1x tamper, 1x RS485 (for future use)
Cable size
CSA: AWG 28–16; CUL/UL: AWG 30–14
GENERAL & ENVIRONMENTAL
Memory
256 MB RAM, 256 MB Flash
Operating conditions
-30 °C to 55 °C (-22 °F to 131 °F)
Humidity
20–85% RH (non-condensing)
Dimensions
43 x 186 x 120 mm (1.7 x 7.3 x 4.7 in)
Weight
500 g (1.1 lb)
Sustainability
PVC free
Approvals
EN 55022 Class B, EN 50130-4, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-003 Class B, C-tick AS/NZS CISPR22 Class B, VCCI Class B, IEC/EN/UL 62368-1, EN 50581
Included accessories
Connector kit, jumper kit, TORX Key TR20, installation guide
Optional accessories
AXIS T8133 Midspan 30 W, AXIS T8129 PoE Extender, AXIS T8007 PS24 power supply, AXIS T98A15-VE Surveillance Cabinet
Part number
0820-001
Warranty
5-year Axis warranty
Downloads
Axis A9188 DatasheetAxis A9188 Installation GuideAxis A9188 User Manual
Frequently Asked Questions
How many inputs, outputs and relays does the A9188 have?Eight I/O terminals, each individually configurable as a digital input, a supervised input with analog read-out, or a digital output — plus eight separate Form C relays with NO/NC contacts.
What is a supervised input and why does it matter?A supervised input monitors the resistance of the alarm loop between 0 and 12 V across four states. That lets the module report a cut or shorted cable as a fault rather than silently failing, which is essential for security-grade alarm and door contact wiring.
How is the A9188 powered?Either by Power over Ethernet — IEEE 802.3af Type 1 Class 3 or IEEE 802.3at Type 2 Class 4 (PoE+) — or from an 8–28 V DC supply drawing up to 26 W.
Can it power connected devices?Yes. It provides both 12 V DC and 24 V DC outputs. The maximum power out is shared between the two rails: 3.6 W on PoE Class 3, or 12 W on PoE Class 4 or DC input.
What can the relays switch?Each of the eight Form C relays is rated to a maximum of 1 A at 48 V DC. In outdoor installations using the AXIS T98A15-VE cabinet the maximum allowed voltage is 30 V DC.
Does it work with the AXIS A1001 Door Controller?Yes — the A9188 is designed for a high level of integration with the AXIS A1001 Network Door Controller, and is commonly used for elevator floor management. It also works with AXIS Camera Station, AXIS Video Hosting System and third-party partner software.
Can I integrate it with my own software?Yes. Axis publishes an open API including VAPIX, and the module supports the AXIS Camera Application Platform so third-party edge applications can be installed directly on the device.
Can the A9188 be installed outdoors?Not on its own. The module is rated for -30 °C to 55 °C, but outdoor installation requires the AXIS T98A15-VE Surveillance Cabinet, which also caps the maximum relay voltage at 30 V DC.
What is in the box?The A9188 ships with a connector kit, a jumper kit, a TORX TR20 key and an installation guide. Optional extras include the AXIS T8133 Midspan 30 W, AXIS T8129 PoE Extender and AXIS T8007 PS24 power supply.
