Dahua Technology is a global leader in providing video-centric smart IoT solutions and services. CCTV Guru is a certified reseller of Dahua products, offering the best prices along with a 3-year manufacturer warranty. We ship directly from our warehouses located in Sydney, Melbourne, Brisbane, Adelaide, and Perth. If you find a better deal elsewhere, we promise to beat it by 5% on all Dahua security and surveillance products. Explore our wide selection of security cameras, video recorders, intercoms, access control systems, and Dahua CCTV's accessories in Australia. We offer various options such as IP cameras, NVRs, CCTV kits. Enjoy your shopping!
Dahua 7-inch Touch Screen IP Video Intercom Kit is the modern doorbell for your home or office. Receive notifications on your Dahua's official DMSS app when visitors press the door station. You can also view on your 7-inch IPC indoor monitor which can be beautifully hanged in your living room. The surface mounted outdoor station offer adjustable viewing angle with can turn 100 degree and features ICR 5m Night Vision. This is the IP video intercoms and cabling can be done by using RJ45 ethernet cables.
Inside the bundle:
1 x 7-inch Black Monitor DHI-VTH2621G-P
1 x Outdoor Station VTO2101E-P
1 x Uniarch 8 Port PoE Switch with Power Supply, SW-2110-P
1 x 7-inch Black Monitor DHI-VTH2621G-PThis Dahua IP Indoor Monitor features white colour frame, 7 inch touch screen, 1024×600 pixels resolution with standard PoE. 6 alarms can be connected and security cameras footage can be viewed as well.
7'' TFT capacitive touch screen, 1024 x 600
6-channel alarm input and 1-channel alarm output
Standard PoE
Door station and IPC monitor
H.265 and H.264 video coding
High performance & cost-effective
1 x Outdoor Station VTO2101E-PDahua 2MP IP Villa Outdoor Station, Viewing Wide Angle 100 degree, Adjustable Viewing Angle, ICR 5m Night Vision
HD CMOS camera.
Zinc alloy panel, IP65 and IK10 rated.
ICR night vision and voice prompt.
Video and audio messaging.
TCP/IP, and SIP.
Surface mounted.
1 x Uniarch 8 Port PoE Switch with Power Supply, SW-2110-PUniarch Switch, 10 x 100Mbps network ports, including 8 PoE/PoE+ ports, 2 x 100Mbps uplink ports, Max capacity for single port 30W, total capacity 120W, up to 250m transmission distance, all-metal housing
Multiple working modes to address your business needs: Normal, Secure and Surveillance
Support port traffic control
Support for secure mode, all downlink ports can communicate only with uplink ports
Up to 250m transmission distance on surveillance mode
Support buffer optimization
All-metal housing, safe and reliable
The Dahua PFA137 is an essential accessory for any professional security installation. This waterproof junction box provides a secure, weatherproof enclosure for camera pigtails and connectors, ensuring long-term reliability by preventing water ingress and cable corrosion. Now available in both Classic White and Midnight Black to perfectly match your camera housing and building aesthetics.
Key Performance Features
Rugged Construction: Built from high-quality aluminum alloy, providing excellent structural strength and durability.
IP66 Waterproof Rating: Engineered for harsh outdoor environments, keeping your electrical connections bone-dry in heavy rain and dust.
Seamless Integration: Designed specifically for Dahua dome and turret cameras, ensuring a perfect physical fit and easy alignment.
Color Options: Choose White for standard residential installs or Black (PFA137-B) for modern architectural finishes or dark soffits.
Technical Specifications
Model
DH-PFA137 (White) / DH-PFA137-B (Black)
Material
Aluminum Alloy
Dimensions
Φ122.0mm x 34.0mm (4.80” x 1.34”)
Pipe Thread
G1/2"
Load Bearing
1.0kg (2.2lb)
Ingress Protection
IP66 Rated
Operating Temp.
-40ºC to +60ºC
Why Use a PFA137 Junction Box?
Cable Protection: Protects your RJ45 and power connectors from tampering and environmental damage.
Clean Aesthetics: Hides messy cables behind the camera for a tidy, professional look.
Serviceability: Provides a convenient access point for future maintenance without needing to re-run cables.
Downloads
DH-PFA137_datasheet
Installation Tip: For high-exposure outdoor areas, we recommend using the included waterproof gasket and applying a small amount of silicone sealant to the screw holes for maximum protection.
Dahua PoE Extender Passive work with PFT1200, connect up to 3x IPC
Support passive PoE cascade power supply and Ethernet data exchange
Support IEEE 802.3af/at standard power supply IP Camera
Cooperate with High PoE Midspan PFT1200), able to cascade level 2 PoE Extender, connect to 3 IPC (total power consumption <=25W), max transmission distance 300m
1*RJ45 10/100M PoE power supply input; 1*RJ45 10/100M supply power for IP Cam; 1*RJ45 10/100M supply power for the next extender
Installation mode: junction box internal mounting, DIN rail mounting
Downloads
PFT1300_datasheetPoE Extender_User's Manual_V1.0.3
Dahua 7-inch Touch Screen IP Intercom Kit is the modern doorbell for your home or office. Receive notifications on your Dahua's official DMSS app when visitors press the door station. You can also view on your 7-inch IPC indoor monitor which can be beautifully hanged in your living room. This kits come with rain shade for your outdoor station to protect from different weather for durability. This is the IP video intercoms and cabling can be done by using RJ45 ethernet cables.
This Dahua Video Intercom Kit comes with:
1 x 7-inch Monitor DHI-VTH2621GW-P
1 x Outdoor Station DHI-VTO2202F-P-S3
1 x IP-Com 8 Port PoE Switch with Power Supply, G1110PF-8-120W
1 x Surface Mount Bracket DH-AC-VTM05R
1 x 7-inch Monitor DHI-VTH2621GW-P
Dahua IP Indoor Monitor White, 7" TFT capacitive touch screen, 1024 × 600, 6-channel alarm input and 1-channel alarm output, Standard PoE, Outdoor station and IPC monitor, H.265 and H.264 video coding, High performance & cost-effective
7'' TFT capacitive touch screen, 1024 x 600
6-channel alarm input and 1-channel alarm output
Standard PoE
Outdoor station and IPC monitor
H.265 and H.264 video coding
High performance & cost-effective
1 x Outdoor Station DHI-VTO2202F-P-S2
Dahua 2-wire IP Villa Door Station comes with both 2-wire and ethernet port
Anodised aluminium front panel
CMOS low illumination 2MP HD colourful 160° fisheye camera
Video intercom function
Access control function that supports two locks
Mobile phone app, talk to the visitor or unlock the door remotely on
Compatible with 2-wire interface & RJ45 interface
IK07 & IP65
Support H.265
Support surface and flush mount
PoE
1 x IP-COM G1110PF-8-120W 9GE+1SFP Ethernet Switch With 8-Port PoE, G1110PF-8-120W
Compliant with IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3x,IEEE 802.3af/at standards
8 * 10/100/1000Mbps Base-T Ethernet ports(Data/Power)
1 * 10/100/1000Mbps Base-T Ethernet port(Data)
1 * 100/1000Mbps Base-X SFP port
16 K MAC address table and MAC address auto-learning
IEEE 802.3x full duplex flow control and backpressure half duplex flow control
20Gbps switching fabric for non-blocking line-speed forwarding
Total power consumption of the switch:120W
Maximum PoE output of a single port:30W
Three-mode toggle: Standard,VLAN,Extend
Desktop installation & Wall mounting
1 x Surface Mount Bracket DH-AC-VTM05R
Dahua DH-PFB204W Waterproof Wall Mount Bracket for CCTV Cameras
The Dahua DH-PFB204W is a durable waterproof wall mount bracket designed specifically for CCTV cameras. Crafted from high-quality aluminum and SECC materials, it ensures robust support and long-lasting performance. Its sleek white finish and compact dimensions (160mm x 122mm x 76mm) provide an unobtrusive, professional installation. Ideal for secure outdoor mounting, this bracket combines aesthetic design with reliable protection against the elements, making it a trusted choice for expert surveillance setups.
Features
Aesthetic design
Wall mount bracket
Material: aluminum & SECC
Specifications
Dahua Security Camera Bracket
TYPE
Wall Mount Bracket
MATERIAL
Aluminum & SECC
COLOUR
White
DIMENSION
160mmx122mmx76mm (6.30''x4.80''x2.99'')
Downloads
DH-PFB204W Datasheet
Dahua Pole Mount Bracket
Material: SECC & SUS304
Pole mount bracket
Aesthetic design
Specifications
CAMERA BRACKETS
TYPE
Pole Mount Bracket
MATERIAL
SECC & SUS304
COLOUR
White
DIMENSION
130.4mmx170mmx45mm (5.13''x6.69''x1.77'')
Downloads
DH-PFA150_datasheet
Dahua 5MP Starlight Pro HDCVI IR Eyeball, WDR, ICR, Motorised 2.7~13.5mm, IR 60m, DC12V, IP67* The parameters and data sheet below can only be applied to 2501-S2 series.* In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version.
Starlight, 120dB true WDR, 3DNR · Max. 20fps@5MP
HD/SD output switchable
Audio in interface, built-in mic
2.7-13.5mm motorized lens
Max. IR length 60m, Smart IR · IP67, DC12V±30%
Specifications
HD-CAMERA
MEGAPIXELS
5MP
CAMERA STYLE
Turret
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
HDCVI
POWER
DC 12V
Downloads
HDW2501TP-Z-A DatasheetHDW2501TP-Z-A User Manual
Dahua 5MP Starlight Pro HDCVI IR Vandal Dome, WDR, ICR, Motorised 2.7~13.5mm, IR 30m, DC12V, IP67* The parameters and data sheet below can only be applied to 2501-S2 series.* In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version.
Max 25 fps@5MP (16:9 video output)
Starlight, 120 dB true WDR, 3D NR
CVI/CVBS/AHD/TVI switchable
2.7 mm-13.5 mm motorised lens
Max. IR length 30 m, Smart IR
IP67, IK10, 12V DCx30%
Specifications
HD-CAMERA
MEGAPIXELS
5MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
HDCVI
POWER
DC 12V
Downloads
HDBW2501R DatasheetHDBW2501R User Manual
Dahua Ceiling Mount Bracket
Aesthetic design
Material: aluminium & PC
Ceiling mount bracket
Specifications
CAMERA BRACKETS
TYPE
Ceiling Mount Bracket
MATERIAL
Aluminum & PC
COLOUR
White
DIMENSION
133.6mm x 235.5mm (5.26''x16.54'')
Downloads
DH-PFB300C_datasheet
Dahua 600VA/360W Line-interactive UPS DH-PFM350-360
The Dahua 600VA/360W Line-interactive UPS DH-PFM350-360 is a reliable choice for your security camera system. With a wide input voltage range, boost and buck AVR for stabilisation, and off-mode charging, this compact UPS ensures continuous power supply and prevents data loss. Trust in its full protection and cold start function for uninterrupted operation.
Features
Wide input voltage range: AC81~145V or AC140~290V, meet the requirements in different parts for electric network fluctuation.
Boost and buck AVR for voltage stabilisation.
Off-mode charging, cold start function and full protection.
Continuous power supply for preventing data loss.
Compact size.
Specifications
Model
DH-PFM350-360
Plug type
Australian
Capacity
600VA/360W
Input
Rated voltage
220Vac~240Vac
110Vac~120Vac
Voltage range
140Vac~290Vac
81Vac~145Vac
Rated frequency range
50Hz or 60Hz
Power factor
0.6
Output
Voltage
220/230/240 VAC
110/120 VAC
AC Voltage Regulation (Batt. Mode)
±10%
Frequency Range (Batt. Mode)
50Hz or 60Hz ±1Hz
Transfer Time
2-6ms
Waveform (Batt. Mode)
Simulated sinewave
Battery
Battery type & number
12 V/7 Ah x 1
Typical recharge time
4 hours recover to 90% capacity
Charging voltage
13.7V±1%
Indicators
Battery mode
Green lighting
AC mode
Green lighting
Alarm
Battery mode
Sounding every 10 seconds
Low battery
Sounding every second
Overload
Sounding every 0.5 second
Fault
Continuously sounding
Protection
Full protection
Overload, discharge and overcharge protection
Environmental
Operating temperature
0°C ~ +40°C (+32°F ~ +104°F)
Operating humidity
0~90% RH(non-condensing)
Altitude range
<1000m(3280.84ft)
Construction
Color
Black
Noise level
<40dB
Dimensions
279mmx101mmx142mm(10.98"x3.98"x5.59")
Weight
4.25kg(9.37lb)
Downloads
Datasheet of DH-PFM350-360
Dahua AI 4MP Starlight+ IP Bullet Fixed 2.8mm, ICR+White Light, WDR (140dB), IR 20m, Micro SD, IP67, PoE
The Dahua AI 4MP Starlight+ IP Bullet delivers exceptional low-light performance with its 1/1.8" progressive scan CMOS sensor and advanced Starlight+ technology. Featuring a fixed 2.8mm lens, 140dB WDR, and 20m IR range, this camera excels in challenging lighting conditions. Smart H.264+/H.265+ compression optimises bandwidth and storage efficiency, while 25/30fps at 2688x1520 ensures crisp detail. IP67-rated and IK10 impact-resistant, it withstands harsh environments. Includes Micro SD recording, dual alarm I/O, audio connectivity, and PoE power for straightforward installation. Compatible with DSS/PSS and DMSS platforms for flexible network monitoring.
Features
1/1.8'' 4Megapixel progressive scan CMOS
ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
25/30 fps@2688x1520, 50/60 fps@1080P (1920x1080)
WDR (140 dB), Day/Night (Electronic), 3D DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS
2.8 mm fixed lens
1/1 Alarm in/out, 1/1 audio in/out
Max. LEDs Length 20 m
Micro SD memory, IP67, IK10
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WIZMIND SERIES
Downloads
Datasheet of DH-IPC-HFW5442TP-AS-LEDQuick Start Guide of DH-IPC-HFW5442TP-AS-LEDOperation Manual of DH-IPC-HFW5442TP-AS-LED
Dahua 6MP IP Turret Fixed 2.8mm, Built-in Mic, ICR, WDR, IVS, IP67, PoE
The Dahua 6MP IP Turret Fixed Camera boasts a superior 6MP resolution, low light capabilities, and a maximum IR distance of 50m. With advanced features such as built-in mic, WDR, and intelligent detection, it ensures high image definition and efficient storage. Ideal for various monitoring scenarios, this camera is a top choice for professionals.
Features
6MP, 1/2.7'' progressive scan CMOS, low illuminance, high image definition
Outputs max. 6MP (3072x1728) @20 fps, and supports 4MP(2688x1520)@30fps
H.265 codec, high compression rate, low bit rate
Built-in IR LED, max. IR distance: 50 m
ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent detection: Tripwire, intrusion
Abnormality detection: Motion detection, video tampering, defocus detection; scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection
Supports max. 256 G Micro SD card, built-in Mic
12V DC/PoE power supply
IP67 protection
SMD Plus
Specifications
Dahua PoE Camera
MEGAPIXELS
6MP
CAMERA STYLE
Turret
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WIZSENSE SERIES
POE
POE
Downloads
Datasheet of DH-IPC-HDW3641TMP-AS-0280B-AUS
Eyeball Network Camera Installation Guide_V1.0.0
Dahua Eyeball Network Camera_QSG_V1.0.1
Dahua Network Camera Web 3.0 Operation Manual_V2.1.1
This Dahua 7-inch Touch Screen IP Intercom Kit (black colour monitor) is the modern doorbell for your home or office. Receive notifications on your Dahua's official DMSS app when visitors press the door station. You can also view on your 7-inch IPC black indoor monitor which can be beautifully hanged in your living room. This kits come with rain shade for your outdoor station to protect from different weather for durability. This is the IP video intercoms and cabling can be done by using RJ45 ethernet cables.
Inside the bundle:
1 x 7-inch Monitor VTH2621G-P
1 x Outdoor Station DHI-VTO2202F-P-S2
1 x Door Station Surface Mount Bracket VTM05R
1 x Uniarch 8 Port PoE Switch with Power Supply, SW-2110-P
1 x 7-inch Monitor VTH2621G-PThis Dahua 7-inch IP Indoor Monitor features stylish black colour comes with capacitive touch screen, 1024×600 pixels resolution and Standard PoE. 6 alarms can be connected and security cameras footage can be viewed as well.
7'' TFT capacitive touch screen, 1024 x 600
6-channel alarm input and 1-channel alarm output
Standard PoE
Outdoor station and IPC monitor
H.265 and H.264 video coding
High performance & cost-effective
1 x Outdoor Station DHI-VTO2202F-P-S2Dahua 2-wire IP Villa Door Station comes with both 2-wire and ethernet port
Anodised aluminium front panel
CMOS low illumination 2MP HD colourful 160° fisheye camera
Video intercom function
Access control function that supports two locks
Mobile phone app, talk to the visitor or unlock the door remotely on
Compatible with 2-wire interface & RJ45 interface
IK07 & IP65
Support H.265
Support surface and flush mount
PoE
1 x Uniarch 8 Port PoE Switch with Power Supply, SW-2110-PUniarch switch, 10 x 100Mbps network ports, including 8 PoE/PoE+ ports, 2 x 100Mbps uplink ports, Max capacity for single port 30W, total capacity 120W, up to 250m transmission distance, all-metal housing
Multiple working modes to address your business needs: Normal, Secure and Surveillance
Support port traffic control
Support for secure mode, all downlink ports can communicate only with uplink ports
Up to 250m transmission distance on surveillance mode
Support buffer optimization
All-metal housing, safe and reliable
1 x Door Station Surface Mount Bracket VTM05R
Dahua Lift Controller connects up to 1 Wiegand reader and 2 RS485 readers, Support 8 cascading, up to 128 floors permission control
Connection up to 1 Wiegand reader and 2 RS485 readers
Support 8 cascading, up to 128 floors permission control
Alarm In/Out: 6/2
Alarm records and log records: 30,000
Maximum support 60 call lift modules
All floors' permission will be released if fire alarm triggered
Remote control via web client
Downloads
DAHUA_DHI-VTM416_Lift_Controller_Data_SheetVTM416 User Manual
Dahua Mini Dome and Turret Mount Adapter
Neat & Integrated design
Material: Aluminum
Specifications
CAMERA BRACKETS
TYPE
Adapter Plate of Mini Dome & Eyeball Camera
MATERIAL
Aluminum
COLOUR
White
DIMENSION
134.1mm x 83.5mm (5.28''x3.29'')
Downloads
DH-PFA106 Datasheet
Dahua Keyboard Villa Door Station
Keyboard villa door station
Supplemental lighting with white light
2MP CMOS camera
Mechanical button with Braille
Aluminium alloy plate, IK08, IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
Door release via password and Mifare card
Specifications
OUTDOOR STATION
RESOLUTION
2MP
TECHNOLOGY
IP
POWER SUPPLY
DC 12V, PoE
PROTECTION
IP65, IK08
MOUNT
Surface & Flush
MATERIAL
Alumimum
Downloads
Datasheet of DHI-VTO3221E-PQuick Start Guide of DHI-VTO3221E-PDahua Villa Intercom Setup GuideDahua Villa N VTHx NVTO via template
Dahua 10-Port Unmanaged Desktop Switch with 8 Port PoE DH-PFS3110-8ET-96-V2
The Dahua 10-Port Unmanaged Desktop Switch with 8 Port PoE allows for long distance transmission of power and data, while the intelligent PoE ensures efficient power supply to connected devices. With a wide operating temperature range and PoE watchdog, this switch is a reliable and adaptable solution for powering your devices.
Features
Eight-PIN Assignment PoE Power Supply
Intelligent PoE
Red port supports 90W IEEE802.3bt
PoE watchdog
250 m long distance PoE transmission
Wide operating temperature: -30C to +65C (-22F to +149F)
Specifications
ETHERNET PORT
8
OPTICAL PORT
1
UPLINK PORT
1
POE BUDGET
Port1<=60W, Port2-8<=30W, Total<=96W
LAYER
Layer 2
TYPE
Unmanaged
Downloads
Datasheet of DH-PFS3110-8ET-96User Manual
Dahua Four Door Master Access Controller
Support 200,000 valid cards & 150,000 records
CAN bus can cascade 16 sub controller modules
Support multiple cards
Support card, password, fingerprint and combination
TCP/IP interface
Wiegand or RS-485 interface to readers
Door close time out alarm, intrusion alarm, duress alarm and tamper alarm
Global anti-passback, multi-door interlock, multi-personal open, remote verification unlock
Web service can used to configure sub controller
Support 128 efficient time and holiday schedules
Built-in RTC, support DST
Watch dog function ensure device free from halting
Surface mounted installation
Accumulator battery extension
Onvif Profile C, CGI, SDK to the third party platform
Downloads
ASC2204C-H_datasheet
ASC2204C-H_Master_Controller_Users-Manaul
Connection_guide
Access Main Controller_Quick Start Guide
DHI-ASC2204C-H_A&E
Dahua Waterproof Wall Mount Bracket White
Aesthetic design
Wall mount bracket
Material: aluminum & SECC
Specifications
CAMERA BRACKETS
TYPE
Wall Mount Bracket
MATERIAL
Aluminum & SECC
COLOUR
White
DIMENSION
160mmx122mmx76mm (6.30''x4.80''x2.99'')
Downloads
DH-PFB203W_datasheet
Dahua 7-inch Touch Screen IP Video Intercom Kit is the modern doorbell for your home or office. Receive notifications on your Dahua's official DMSS app when visitors press the door station. You can also view on your 7-inch IPC indoor monitor which can be beautifully hanged in your living room. The surface mounted outdoor station offer adjustable viewing angle with can turn 140 degree and features Night Vision. You can also use it with Mifare card. This is the IP video intercoms and cabling can be done by using RJ45 ethernet cables.
Inside the bundle:
1 x 7-inch Monitor DHI-VTH2621GW-P
1 x Outdoor Station DHI-VTO3211D-P
1 x 8 Port PoE Switch with Power Supply
1 x 7-inch Monitor DHI-VTH2621GW-PThis Dahua IP Indoor Monitor features white colour frame, 7 inch touch screen, 1024×600 pixels resolution with standard PoE. 6 alarms can be connected and security cameras footage can be viewed as well.
7'' TFT capacitive touch screen, 1024 x 600
6-channel alarm input and 1-channel alarm output
Standard PoE
Door station and IPC monitor
H.265 and H.264 video coding
High performance & cost-effective
1 x Outdoor Station DHI-VTO3211D-PDahua 2MP IP Villa 1 button Outdoor Station, Viewing Wide Angle 140 degree, Night vision, Mifare Card Reader
2MP HD CMOS camera
Aluminum panel, IP65, IK08
ICR Night vision & Voice indication
Video & Audio messaging
Remote intercom with mobile APP
Surface mounted
Dahua UTP CAT6 Cable 305M Blue Colour for CCTV Security Surveillance Cameras
The Dahua UTP CAT6 Cable offers high-quality surveillance for CCTV security cameras. Its 305m length and power over Ethernet compatibility make it an efficient and convenient choice. With a custom PVC outer sheath and CE CPR Eca certification, this cable also comes with a 10-year warranty for added peace of mind. Dahua DH-PFM920I-5EUN(BLUE) cable utilises high-purity oxygen-free copper (OFC) conductors with a purity level of 99.97%.
Features
305 m (1000 ft)/carton UTP CAT6, power over Ethernet, compatible with one cable
High-purity oxygen-free copper conductor
Customised PVC outer sheath; CE CPR Eca flame retardant class certified
10-year warranty
Specifications
Cable Colour
Blue
Length
305M
Type
CAT6
Brand
Dahua
Downloads
DH-PFM920I-6UN-C Datasheet 20200426
Dahua Face Recognition Access Control & Temperature Terminal Desk Mount Bracket
One-piece Design for Quick Deployment and Portability
Aluminum Alloy Construction
Compatible with DHI-ASI7213X-T1 Thermal Temperature Station
Specifications
Material: Aluminum Alloy
Dimensions (W x H x D): 142.43 mm x 378.67 mm x 194.08 mm (5.61 in. x 14.91 in. x 7.64 in.)
Net Weight: 1.56 kg (3.44 lb)
Gross Weight: 1.13 kg (2.49 lb)
Dahua Hi-PoE Midspan, Support PoE for Hi-PoE 60W high power consumption speed dome
Support PoE for Hi-PoE 60W high power consumption speed dome
Indicator status: power (normal power on), PoE (normal power supply)
Cooperate with PoE Extender (PFT1300), able to cascade level 2 PoE Extender, connect to 3 IPC (power consumption Installation mode: wall mount
Downloads
PFT1200_Datasheet_20170728PFT1200_User Manual
Dahua Wall Mount Bracket
Aesthetic design
Wall mount bracket
Material: aluminum
Specifications
CAMERA BRACKETS
TYPE
Wall Mount Bracket
MATERIAL
Aluminum
COLOUR
White
DIMENSION
58mmx88mmx190.5mm (2.28''x3.46''x7.50'')
Downloads
DH-PFB121W Datasheet
Dahua HDMI Extender
The Dahua HDMI Extender DH-PFM700-E enables real-time transmission of HDMI video signals up to 50 meters using a single CAT6 cable, ensuring minimal delay and strong anti-interference performance. Designed for HDMI 1.3 compatibility, it supports local loop output and EDID management. The device also includes one-way infrared remote control signal transmission and offers robust protection against thunder, static, and interference without needing driver installation or network configuration. Powered by DC5V, it is optimized for reliable and straightforward HDMI extension in professional setups.
Features
Power supply: Input voltage DC5V, only supply for transmitter.
Transmission effect: Real-time transmission HDMI video signal, no delay, strong anti-interference.
Transmission distance: HDMI transmission distance 50m (max.164ft), with CAT6 of pure copper cable(DC impedance is less than 9.5 ohm for every 100 meters(328ft)).
Infrared function: support to transmit one-way infrared remote control signal.
Main functions: Use single UTP (CAT-5E and CAT-6) to transmit 1-ch HDMI video signal, support HDMI 1.3; Support HDMI local loop output; Support EDID.
Protection and anti-interference: Excellent anti-thunder, anti-static and anti-interference capabilities.
Appearance structure: No need to install driver program and set network parameters, easy to use and convenient to install.
Downloads
PFM700-E Datasheet_20190906
DAHUA 4K 40x Starlight+ IR WizMind Network PTZ Camera DH-SD8A840WA-HNF
Professional-grade 8MP PTZ camera engineered for demanding surveillance applications. Features a 1/1.8" STARVIS CMOS sensor paired with 40x optical zoom for exceptional detail across expansive areas. Starlight+ technology delivers superior low-light performance, while infrared illumination extends visibility to 500 metres. WizMind intelligence enables face recognition, autonomous tracking, and perimeter protection through deep learning algorithms. Hi-PoE power delivery simplifies installation, and IP67 rating ensures durability in harsh outdoor conditions. Integrated smart wiper maintains optical clarity. Ideal for large-scale security deployments requiring precision monitoring and intelligent video analytics.
Features
1/1.8'' 8Megapixel STARVIS CMOS
Powerful 40x optical zoom
Starlight+ technology
IR distance up to 500m
Support face recognition
Deep-learning-based auto tracking and perimeter protection
Support metadata
Support Hi-PoE
Smart wiper
IP67
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
PTZ
COLOUR
White
LENS TYPE
Motorized
TECHNOLOGY
PTZ SERIES
POE
Hi-POE
Downloads
Datasheet of DH-SD8A840WA-HNF
Installation Manual of DH-SD8A840WA-HNF
Operation Manual of DH-SD8A840WA-HNF
Dahua Mount Adapter
Aesthetic design
Material: aluminum
Mount adapter
Specifications
CAMERA BRACKETS
TYPE
Mount Adapter
MATERIAL
Aluminum
COLOUR
White
DIMENSION
60mmx49mm (2.36''x1.93'')
Downloads
DH-PFA111_datasheet
Dahua Ceiling Mount Bracket
Neat & Integrated design
Ceiling mount bracket
Material: Aluminum
Specifications
CAMERA BRACKETS
TYPE
Ceiling Mount Bracket of Mini Dome & Eyeball Camera
MATERIAL
Aluminum
COLOUR
White
DIMENSION
128.8mmx767.0mm(5.07''x30.2'')
Downloads
DH-PFB220C_datasheet
Dahua 4MP IP WDR IR Corner Network Camera, 2.5mm,ICR,IVS,IP67,POE,IR 10m
This compact corner-mount network camera delivers professional-grade surveillance with 4MP resolution and advanced imaging capabilities. The 1/1.8" progressive scan CMOS sensor captures crisp detail at 25/30 fps, while dual H.265 and H.264 encoding optimises bandwidth and storage efficiency. Wide Dynamic Range (140 dB) and ICR day/night switching ensure clear footage in challenging lighting conditions, complemented by 3D DNR and intelligent exposure controls. The fixed 2.5mm lens provides wide-angle coverage with distortion correction for accurate monitoring. Infrared illumination extends visibility up to 10 metres in complete darkness. Built for durability, this camera features IP67 weatherproofing and IK10+50J impact resistance, making it suitable for demanding indoor and outdoor installations. ePOE power delivery simplifies deployment, while comprehensive I/O connectivity supports alarms and audio integration.
Features
1/1.8'' 4 Megapixel progressive scan CMOS
H.265 & H.264 triple-stream encoding
25/30 fps@2688x1520
WDR (140 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC
2.5 mm fixed lens, distortion correction
1/1 Alarm in/out, 1/1 audio in/out
Max. IR LEDs Length 10 m
IP67 and IK10+50J protection
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Corner
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
SPECIAL SERIES
POE
ePOE
Downloads
Datasheet of DH-IPC-HCBW8442P-0250B
Quick Start Guide of DH-IPC-HCBW8442P-0250B
Installation Guide of DH-IPC-HCBW8442P-0250B
Dimension of DH-IPC-HCBW8442P-0250B
Dahua Waterproof Wall Mount Bracket White
The Dahua Waterproof Wall Mount Bracket White DH-PFB205W-E is crafted from durable aluminum alloy, offering a cost-effective and sturdy solution for mounting specific Dahua cameras. Its sleek, white design complements any installation environment while providing reliable protection against the elements. Measuring 161.6 mm x 125.6 mm x 76.0 mm, this bracket ensures a secure and precise fit, enhancing both the functionality and aesthetics of your surveillance setup. Ideal for professional installations requiring both durability and style.
Features
Aluminium alloy material, cost-effective
Dedicated for particular cameras, beautiful and elegant designed
Specifications
CAMERA BRACKETS
TYPE
Wall Mount Bracket
MATERIAL
Aluminum
COLOUR
White
DIMENSION
161.6 mmx125.6 mmx76.0 mm (6.36''x4.94''x2.99'')
Downloads
DH-PFB205W_datasheet
Dahua Mount Adapter
Aesthetic design
Material: aluminum
Mount adapter
Specifications
CAMERA BRACKETS
TYPE
Mount Adapter
MATERIAL
Aluminum
COLOUR
White
DIMENSION
59mmx53mm (2.32''x2.09'')
Downloads
DH-PFA110_datasheet
Dahua 2MP IP Villa Outdoor Station, Viewing Wide Angle 100 degree, Adjustable Viewing Angle, ICR 5m Night Vision DHI-VTO2101E-P-S2
HD CMOS camera.
Zinc alloy panel, IP65 and IK10 rated.
ICR night vision and voice prompt.
Video and audio messaging.
TCP/IP, and SIP.
Surface mounted.
Specifications
OUTDOOR STATION
RESOLUTION
2MP
TECHNOLOGY
IP
POWER SUPPLY
DC 12V, PoE
PROTECTION
IP65, IK10
MOUNT
Surface
MATERIAL
Front Panel: Zinc alloy Rear Panel: Aluminum alloy Holder: Aluminum alloy
Downloads
Datasheet of DHI-VTO2101E-P
Quick Start Guide of DHI-VTO2101E-P
Dahua Villa Intercom Setup Guide
Dahua Villa N VTHx NVTO via template
Mifare Key Fob, 13.56MHz Working Frequency
IC card ( Mifare card) with frequency 13.56MHz
Public transportation
Access management
Electronic toll collection
Car parking
Loyalty programs
Dahua Wall Mount Bracket
Neat & Integrated design
Wall mount bracket
Material: Aluminum
Safety rope hook attached, secure and reliable
Specifications
CAMERA BRACKETS
TYPE
Wall Mount Bracket
MATERIAL
Aluminum
COLOUR
White
DIMENSION
200mmx160mmx115mm
(7.87''x6.3''x4.53'')
Downloads
DH-PFB305W Datasheet
The Dahua LR1002-1ET & LR1002-1EC Kit is a high-performance Ethernet-over-Coax (ePoC) extender set designed to transmit IP data and PoE power over existing coaxial cables. This kit is the perfect solution for upgrading legacy analog surveillance systems to high-definition IP systems without the massive cost and labor of replacing old RG59/RG6 cabling.
Key Performance Features
Extreme Long Reach: Supports network transmission up to 1000 meters at 10Mbps or 400 meters at 100Mbps over high-quality coaxial cable.
PoE Over Coax: Transmits Power over Ethernet (PoE) alongside data, allowing you to power your IP cameras directly through the old coax line.
Plug-and-Play: No software configuration required. Simply connect the Transmitter (ET) at the camera end and the Receiver (EC) at the switch/NVR end.
Industrial Design: Compact, high-durability metal construction with excellent heat dissipation for 24/7 reliability.
Technical Specifications
Function
Ethernet over Coax (Transmitter & Receiver)
Port
1x 10/100 Mbps Base-TX, 1x BNC
Transmission Distance
100Mbps: 400m | 10Mbps: 1000m
Power Consumption
< 2W per unit
Lightning Protection
Common Mode 4KV, Differential Mode 2KV
Operating Temp.
-30°C to +65°C
Why Use This Extender Kit?
Replacing underground or in-wall coaxial cable with Cat6 can be expensive and disruptive. The Dahua LR1002 series allows you to leverage your existing infrastructure to deploy the latest IP camera technology instantly. It is especially useful for large sites like warehouses, parking lots, and multi-story buildings.
More Information
Download Data Sheet
Download Single-Port-Long-Reach-Ethernet-over-Coaxial-Extender_Users-Manual_V1.0.5
Dahua Single-Port Long Reach Ethernet over Coaxial Extender_User's Manual_V1.0.4
Guru Tip: Transmission distance and bandwidth are dependent on the quality of your existing coax cable. For distances over 400m, the bandwidth will automatically throttle to 10Mbps to ensure a stable connection.
Dahua 5MP Starlight Pro HDCVI IR Bullet, WDR, ICR, Motorised 2.7~13.5mm, IR 80m, DC12V, IP67, Built-in Mic* The parameters and datasheets below can only be applied to 2501-S2 series.* In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version.
Max. 25 fps@5MP (16:9 video output)
Starlight, 120 dB true WDR, 3D NR
CVI/CVBS/AHD/TVI switchable
Built-in mic
2.7 mm~13.5 mm motorized lens
Max. IR length 80 m, Smart IR
IP67, 24V AC/12V DC
Specifications
HD-CAMERA
MEGAPIXELS
5MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
HDCVI
POWER
AC 24V/ DC 12V
Downloads
HAC-HFW2501TU-Z-A-DP Datasheet 20201127HDCVI Bullet Camera Installation Guide_V1.0.2-EngHDCVI Camera User's Manual V1.0.0-Eng
Dahua Mount Junction Box DH-PFA134
Dahua Mount Box Features
Aesthetic design
Material: aluminum & SECC
Junction box
Specifications
CAMERA BRACKETS
TYPE
Junction Box
MATERIAL
Aluminum & SECC
COLOUR
White
DIMENSION
90.0mmx35.0mm (3.54''x1.38'')
Downloads
DH-PFA134_datasheet
