Description
Dahua 8 MP + 4 Channels Kit: 1 x 8 MP TiOC and 3 x 8MP Turret Cameras with 4CH NVR, GR-DH-8MP4CH
The Dahua 8 MP + 4 Channels Kit is a reliable and efficient surveillance solution for your business or home. With 1 x 8 MP TiOC and 3 x 8MP Turret Cameras, you can capture high-quality images with excellent low light performance. The 4CH NVR allows for easy storage and management of footage. Plus, with intelligent detection features such as intrusion and tripwire, you can ensure comprehensive security coverage.
This Dahua 8MP 4 Channel kit includes:
3 x 8MP Fixed Turret DH-IPC-HDW3866EMP-S-AUS
- 8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
- Outputs max. 8MP (3840 x 2160) @25/30 fps.
- H.265 codec, high compression rate, ultra-low bit rate.
- Built-in IR LED, max. IR distance: 30 m.
- ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
- Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
- Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
- Max. 256 G Micro SD card. built-in Mic.
- 12 VDC/PoE power supply facilitates installation.
- IP67 protection.
- SMD 4.0, AI SSA.
1 x 8MP TiOC Fixed Turret DH-IPC-HDW3849H-AS-PV-ANZ
- 8MP 1/2.8'' CMOS image sensor, low luminance, and high definition image.
- Outputs max. 8 MP (3840 x 2160)@25/30 fps.
- H.265 codec, high compression rate, ultra-low bit rate.
- Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.
- ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
- Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).
- Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
- Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; buit-in dual MICs; 1-ch speaker; support two-way talk.
- 12 VDC/PoE power supply.
- IP67 protection.
- Sound and light alarm (red and blue lights).
- SMD 4.0.
- One press arming/disarming through alarm input.
1 x 4CH NVR DHI-NVR4104HS-P-4KS2/L
- New 4.0 user interface, Security baseline 2.1
- H.264, H.265, Smart H.264+, and Smart H.265+. H.265 auto switch
- Max. decoding capability: 4 x 1080p@30 fps. Supports adaptive decoding
- Supports mainstream cameras of ONVIF and RTSP protocols
- P2P remote surveillance, video play on mobile device
- VGA/HDMI simultaneous video output, maximum resolution of HDMI is 4K
- AI by Camera: Face detection, perimeter protection, IVS, people counting, heat map, and SMD
- Supports remote configuration and management of IPC, such as set ting parameters, getting information, and upgrading IPC of the same model in batches
* NOTE: HDD NOT INCLUDED
Downloads
DH-IPC-HDW3866EMP-S-AUS_datasheet_20220718
IPC-HDW3849H-AS-PV_datasheet_20220827
Dahua Eyeball Network Camera_Quick Start Guide_V1.0.4
NVR4104HS-P-4KS2/L_datasheet_20210719
Dahua Network Video Recorder_User's_Manual_V2.3.0-Eng
About Dahua TiOC 2.0, the ultimate 3-in-1 Camera &
Active Deterrent Setup on Dahua's DMSS mobile app
Dahua TiOC cameras offer features like red and blue lights, a siren, and voice messages to simulate a police presence and startle potential intruders. These features can be tailored to specific needs, allowing for customization such as enabling or disabling lights and sirens, and changing voice messages. This technology enhances security by deterring criminals and adding an extra layer of protection. It can complement other security measures like fencing, lighting, and alarms to create a comprehensive security system for both residential and business spaces.
