A network camera, also known as an IP camera, is a video security camera that comes with a chipset that can process video data. It can then transmit both data and power over ethernet cables. Use this for a clean installation.
Dahua Security Camera 4MP WizSense Fixed Starlight Dome, 2.8mm, Perimeter, SMD, SD Card, WDR, IR30m, Built-in Mic, IP67, IK10, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent detection: Intrusion, tripwire (support the classification and vaccurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HDBW3466FP-AS-AUS Datasheet_20220426Dahua Dome Network_ Camera Quick Start Guide_V1.0.1Dahua Dome Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
HiLook IPC-T261H-MU(2.8mm) 6 MP AI Fixed Turret Network Camera
High quality imaging with 6 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 120 dB WDR technology
Focusing on human and vehicle classification based on deep learning
-U: Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Camera
Image Sensor: 1/2.8" Progressive Scan CMOS
Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Speed: 1/3 s to 1/100,000 s
Slow Shutter: Yes
P/N: P/N
Wide Dynamic Range: 120 dB
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Max. Resolution: 3200 × 1800
Lens
Lens Type: Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV: 2.8 mm, horizontal FOV 107°, vertical FOV 57°, diagonal FOV 128°, 4 mm, horizontal FOV 87°, vertical FOV 46°, diagonal FOV 105°
Iris Type: Fixed
Aperture: F1.6
Lens Mount: M12
DORI
DORI: 2.8 mm: D: 73 m, O: 29 m, R: 15 m, I: 7 m, 4 mm: D: 90 m, O: 35 m, R: 18 m, I: 9 m
Illuminator
Supplement Light Type: IR
Smart Supplement Light: Yes
IR Wavelength: 850 nm
IR Range: Up to 30 m
Supplement Light Range: Up to 30 m
Audio
Audio Compression: -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
Audio Bit Rate: -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)
Audio Sampling Rate: -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering: -U: Yes
Image Parameters Switch: Yes
Image Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch: Day, Night, Auto, Schedule
Image Enhancement: BLC, HLC, 3D DNR
SNR: ≥ 52 dB
Wide Dynamic Range (WDR): 120 dB
Interface
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage: Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
Built-In Microphone: -U: yes
Hardware Reset: Yes
Download
Data Sheet
Dahua Security Camera 6MP WizSense Fixed Starlight Bullet, 2.8mm, Perimeter, SMD4.0, SD Card, WDR, IR50m, Built-in Mic, IP67, POE
6MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 6 MP (3072 x 2048) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply, easy for installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
6MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WIZSENSE SERIES
POE
POE
Downloads
DH-IPC-HFW3666EP-AS-AUS Datasheet 20220718Dahua HD IR Bullet Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Axis M4216-V Dome Camera, M4216-V 4 MP Compact Dome With a 3-6mm Varifocal Lens and Remote Zoom and Focus. The Axis M4216-V Also Features Deep Learning With Dust- and IP42 Water and Dust-resistant, IK08 Impact-resistant, 02112-001
Varifocal 4 MP dome with deep learning
Great image quality in 4 MP
Varifocal lens with remote zoom and focus
WDR and Lightfinder
Support for analytics with deep learning
HDMI output for public viewing monitors
AXIS M4216-V is a compact and discreet dome that delivers great images even in challenging light conditions. With a deep learning processing unit (DLPU), you can benefit from intelligent applications based on deep learning on the edge.
Great images, every timeIdeal for any indoor surveillance application, AXIS M4216-V delivers 4 MP for wide 4:3 view and 3 MP for 16:9 aspect ratio. Thanks to its varifocal lens it offers a flexible field of view with a viewing angle of up to 100°. Wide Dynamic Range (WDR) ensures clarity even when there’s both dark and light areas in the scene. And, thanks to Lightfinder, you also get sharp, color images in low light. Additionally, with remote zoom and auto focus capabilities, there’s no need for hands-on fine tuning saving you time and effort.
Extended possibilitiesAXIS M4216-V offers great possibilities to add value to your camera and extend the functionality of your surveillance system. With a DLPU, it enables unique opportunities to take advantage of intelligent analytics based on deep learning on the edge. And it comes with AXIS Object Analytics enabling object classification for reliable detection with fewer false alarms. This compact dome offers the flexibility to add audio or I/O connectivity using accessories. And the HDMI port lets you display live video on a public viewing monitor. Furthermore, Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network.
Small and discreetCompact and flexible in design, this varifocal dome offers a wide range of accessories so it can be installed almost anywhere. For instance, it’s easy to conceal in recessed ceilings. This makes the camera perfect for any location where discreet monitoring is needed to protect your assets. AXIS M4216-V can be easily repainted to blend in seamlessly with any environment. Additionally, clear and smoked dome covers are available as accessories. Furthermore, thanks to its vandal-, impact-, and dust-resistant casing you can be confident it’s always safe and secure.
DownloadDatasheet
TP-Link VIGI 4MP C340I(4mm) Outdoor IR Bullet Network Camera, 4mm Lens, Smart Detection, 2YW (LD)
VIGI 4MP Outdoor IR Bullet Network Camera
4MP Super-High Definition: The VIGI C340I camera comes with 4MP — more than enough pixels to pick up some of the more discrete details.
Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
Smart Detection: Receive notifications and check feeds when someone crosses a boundary, enters an area you've set, obstructs the camera, or removes/abandons objects.
Smart Video Enhancement: VIGI's s professional technologies process videos to greatly improve their quality which is vital to your monitoring, including Smart IR, WDR, 3D DNR, and Night Vision.
H.265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
Waterproof: Reliable IP67 for stable outdoor performance.
PoE/12V DC: Two types of power supply not only give you more convenience but also make your wiring remarkably easy.
2.8/4/6 mm Lens: Whether you need a wide-angle lens to cover enclosed spaces or a higher millimetre lens for longer distances in open spaces, C340I comes with three different lens types to better suit your security needs.
Flexible Management: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager.
Dahua 8MP (4K) WizSense Fixed Starlight Bullet, 3.6mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR30m, Built-in Mic, IP67, PoE DH-IPC-HFW3866EP-AS-AUS-36
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8 MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 30 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
MEGAPIXELS
8MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
WizSense Series
POE
PoE
Downloads
DH-IPC-HFW3866EP-AS-AUS Datasheet 0220415Dahua HD IR Bullet Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua Security Camera 8MP (4K) WizSense Motorised Starlight Dome, 2.7-13.5mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR40m, Built-in Mic, IP67, IK10, POE, black
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports); max. 256 G Micro SD card; built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Dome
COLOUR
Black
LENS TYPE
Motorised
TECHNOLOGY
WizSense Series
PoE
PoE
Downloads
DH-IPC-HDBW3866RP-ZAS-AUS-BLK DatasheetDahua Dome Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua Security Camera 4MP WizSense Motorised Starlight Turret, 2.7–13.5 mm, Perimeter, SMD, SD Card, WDR, IR40m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion , tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Turret
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HDW3466TP-ZS-AUS DatasheetDahua Eyeball Network Camera_Quick Start Guide_V1.0.4Eyeball Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua Security Camera 8MP (4K) WizSense Motorised Starlight Bullet, 2.7-13.5mm, 4K@25/30fps, Perimeter, SMD 4.0, SD Card, WDR, IR60m, Built-in Mic, IP67, POE, black
8MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 6 MP (3072 x 2048) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 60 m.
ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply, easy for installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Bullet
COLOUR
Black
LENS TYPE
Motorised
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HFW3866TP-ZAS-AUS-BLK DatasheetBullet Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Dahua 2MP Starlight IP PTZ 3X 2.7mm~8.1mm VF lens, ICR, WDR, IR 15m, IP66, POE
1/2.8'' 2Megapixel STARVIS CMOS
Powerful 3x optical zoom
Starlight, WDR
Max. 25/30fps@1080P
IVS
Support PoE
IR distance up to 15m
IP66
Specifications
Network Security Camera
Megapixels
2MP
Camera Style
PTZ
Colour
White
Lens Type
Motorised
Technology
PTZ Series
Connection
PoE
Downloads
DH-SD1A203T-GN DatasjeetInstallation Manual of DH-SD1A203T-GNOperation Manual of DH-SD1A203T-GN
Uniarch Tri-guard 8MP Turret 2.8 lens Black, Min. illumination 0.003lux, Smart Intrusion Prevention (SIP) , ColorHunter and Active Deterrence into one IP camera, 2.8mm fixed lens, 30M IR, 120dB WDR, support 256 GB Micro SD card, Built-in- Mic & Speaker, IP67
Optional: Junction box TR-JB03-G-IN- BLACK, Wall mount TR-WM03-D-IN- BLACK
High quality image with 8MP, 1/2.8''CMOS sensor
8MP(3840*2160)@20fps; 5MP(3072*1728)@30/25fps; 4MP(2560*1440)@30/25fps; 2MP(1920*1080)@30/25fps
Ultra 265, H.265, H.264, MJPEG
Smart intrusion prevention, include cross line, intrusion, enter area, leave area detection
Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and, motor vehicle and non-motor vehicle
Supports sound and light alarm linkage. When Smart intrusion prevention is triggered, the camera links sound alarm and light linkage.
120dB true WDR technology enables clear image in strong light scene
Support 9:16 Corridor Mode
Built-in Mic and Speaker
Smart IR, up to 30m (98ft) IR distance
Supports 256 G Micro SD card
IP67 protectionIP67 protection67
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Turret
COLOUR
Black
LENS TYPE
Fixed
TECHNOLOGY
Uniarch TRI-Guard
POE
POE
Downloads
Uniarch IPC-T1P8-AF28KC-B 8MP HD Intelligent Light and Audible Warning Fixed_ Eyeball Network Camera V1.0Uniarch-IPC-Network Eyeball Cameras Quick Guide-V2.01Uniarch Network Camera User Manual-V1.00
Dahua 4 MP 25x Starlight IR WizSense Network PTZ Camera, 1/2.8" 4 Megapixel CMOS, Powerful 25x optical zoom, Starlight technology, IR distance up to 150 m, Perimeter protection, Face detection, Metadata, Full-colour illuminator; red and blue warning light, IP66, Smart dual illuminators (Recommended to use within 50 m)
1/2.8" 4Megapixel STARVIS™ CMOS
Powerful 25x optical zoom
Starlight technology
IR distance up to 150 m
Perimeter protection
Face detection
Metadata
Full-colour illuminator; red and blue warning light
IP66
Smart dual illuminators (recommended to use within 50 m)
Specifications
Network Security Camera
Megapixels
4MP
Camera Style
PTZ
Colour
White
Lens Type
Motorised
Technology
PTZ Series
Connection
PoE+
Downloads
DH-SD6C3425XB1-HNR-A-PV1 Datasheet 20211216DH-SD6C3425XB1-HNR-A-PV1 Installation Guide_V1.0.0Dahua Network Speed Dome PTZ Camera Web_3.0 User Manual_V3.0.1Network Speed Dome & PTZ Camera Installation Manual_V1.0.0
Axis 01727-001 - Varifocal IR-Corrected 12-50 mm I-CS Lens for Cameras up to 8 Megapixel Resolution and 1/1.8" Sensor
Lens i-CS 9-50 mm F1.5 8MPRemote zoom and focusThis i-CS lense features the most recent industry standard in intelligent CS-mount optics. It includes three motors, which enable automatic and remote zoom, focus, and iris opening.Lens i-CS 9-50 mm F1.5 8 MP offers great flexibility to your installation thanks to its open protocol and the ability for the camera to interface with multiple features.The long reach of this telephoto lens allows you to capture objects that are far away.The lens is IR-corrected. This means that you don't need to adjust the camera's focus when you shift between day and night mode using the IR-cut filter. Compatible with e.g. AXIS Q1645/-LE, AXIS Q1647/-LE, AXIS P1367/-E and P1368-E.
Hikvision DS-2CD63C5G1-IVS, 12 MP DeepinView Fisheye Network Camera, Panoramic 1.29mm, Mic, IR 15m
Heatmap: based on deep learning algorithms, the camera counts people and presents an intuitive map
Multi dewarping modes: the image can be dewarped to normal image for viewing intuitively
Built-in mic and speaker: the camera supports two-way audio for real-time audio security monitoring and communication
Built-in IR light: an IR range of 15 meters provides good visibility in low or even zero-light environments
High resolution 12 MP: capturing clear images even when dewarped into 4-image PTZ mode
Each image is clear and detailed
Panomorph lens RPL: 89VVT
Water and dust resistant (IP67) and vandal resistant (IK10)
Downloads
DS-2CD63C5G1-IVS DatasheetDS-2CD63C5G1-IVS Quick Start GuideDS-2CD63C5G1-IVS User Manual
TP-Link VIGI 5MP Full-Color Dome Network Camera - VIGI C250(2.8mm)
5MP Super-High Definition: The camera comes with 5MP–more than enough pixels to pick up some of the more discrete details.
24h Full-Color: Obtain 24-hour color details, even in pitch-black conditions, with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights.
Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
Smart Detection: Actively detects abnormal events like area intrusion and line-crossing, sending notifications to you instantly.
People & Vehicle Analytics: Quickly find people and vehicles of interest using a series of attributes, allowing you to improve search efficiency§.
Built-In Microphone: Features a built-in microphone to record anything going on within a 15-ft radius of the camera.
IK10 Vandal-Proof & IP67 Waterproof: With vandal-resistant, rugged housing and waterproof design, this VIGI dome camera is built tough to withstand vandalism and harsh environments with rain and dust for constant security anywhere and anytime.
H.265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
Smart Video Enhancement: VIGI's professional technologies process videos to greatly improve their quality that is vital to your monitoring, including Smart IR, True WDR, 3D DNR, and Night Vision.
PoE/12V DC: Two types of power supply not only give you more convenience but also make your wiring remarkably easy.
Flexible Management and Storage: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager. Local storage is available for each method, as well as onboard storage with SD card slot (up to 256 GB).
24/7 Stunning Visual Experience 5MP Super-High DefinitionMonitor 24-hour clear and colorful details even in pitch dark night. VIGI Full-Color camera provides maximum 5MP resolutions and ensures colorful monitoring with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights.SmartVid-Smart Video EnhancementVIGI’s professional technologies process videos to greatly improve their quality that is vital to your monitoring, including WDR, 3D DNR, Smart IR, and Night Vision.Human & Vehicle ClassificationIntegrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.Comprehensive AI Detection with Pre-Set Rules SupportedBy setting the detection rules in advance, VIGI AI-powered cameras can accurately capture various abnormal events. This will greatly reduce false alarms and cover your specified monitoring needs in different scenarios.People & Vehicle AnalyticsQuickly find people and vehicles of interest using a series of attributes.People AnalyticsFilter people of interest by various attributes, such as gender, hair length, and clothing, allowing you to improve search efficiency.Vehicle AnalyticsIdentify and search for vehicles of interest based on vehicle color and type for targeting meaningful events in a short time.No More Silent Surveillance Built-In MicrophoneThe VIGI camera features a built-in microphone to record anything going on within a 15-ft radius of the camera. This gives you more detailed monitoring for greater peace of mind.IK10 Vandal-Proof & IP67 WaterproofWith vandal-resistant, rugged housing and waterproof design, this VIGI dome camera is built tough to withstand vandalism and harsh environments with rain and dust for constant security anywhere and anytime.Smart Video Coding by H.265+Compresses the video size without sacrificing video quality, easing the network load and saving disk space.Flexible StorageLocal storage is available for each method, as well as onboard storage with an SD card slot (up to 256 GB).PoE/12V DCTwo power supply ways not only give you more convenience but also make your wiring remarkably easy.Flexible InstallationEasily route your camera’s cable into a dropped ceiling or avoid drilling by slotting it through the camera’s side outlet.Remote ManagementTake full control over your security anytime and anywhere on the VIGI app or client.One system. Full security. Run your business with peace of mind.The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
DownloadDatasheet
TP-Link VIGI 5MP Full-Color Dome Network Camera - VIGI C250(4mm)
5MP Super-High Definition: The camera comes with 5MP–more than enough pixels to pick up some of the more discrete details.
24h Full-Color: Obtain 24-hour color details, even in pitch-black conditions, with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights.
Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
Smart Detection: Actively detects abnormal events like area intrusion and line-crossing, sending notifications to you instantly.
People & Vehicle Analytics: Quickly find people and vehicles of interest using a series of attributes, allowing you to improve search efficiency§.
Built-In Microphone: Features a built-in microphone to record anything going on within a 15-ft radius of the camera.
IK10 Vandal-Proof & IP67 Waterproof: With vandal-resistant, rugged housing and waterproof design, this VIGI dome camera is built tough to withstand vandalism and harsh environments with rain and dust for constant security anywhere and anytime.
H.265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
Smart Video Enhancement: VIGI's professional technologies process videos to greatly improve their quality that is vital to your monitoring, including Smart IR, True WDR, 3D DNR, and Night Vision.
PoE/12V DC: Two types of power supply not only give you more convenience but also make your wiring remarkably easy.
Flexible Management and Storage: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager. Local storage is available for each method, as well as onboard storage with SD card slot (up to 256 GB).
24/7 Stunning Visual Experience 5MP Super-High DefinitionMonitor 24-hour clear and colorful details even in pitch dark night. VIGI Full-Color camera provides maximum 5MP resolutions and ensures colorful monitoring with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights.SmartVid-Smart Video EnhancementVIGI’s professional technologies process videos to greatly improve their quality that is vital to your monitoring, including WDR, 3D DNR, Smart IR, and Night Vision.Human & Vehicle ClassificationIntegrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.Comprehensive AI Detection with Pre-Set Rules SupportedBy setting the detection rules in advance, VIGI AI-powered cameras can accurately capture various abnormal events. This will greatly reduce false alarms and cover your specified monitoring needs in different scenarios.People & Vehicle AnalyticsQuickly find people and vehicles of interest using a series of attributes.People AnalyticsFilter people of interest by various attributes, such as gender, hair length, and clothing, allowing you to improve search efficiency.Vehicle AnalyticsIdentify and search for vehicles of interest based on vehicle color and type for targeting meaningful events in a short time.No More Silent Surveillance Built-In MicrophoneThe VIGI camera features a built-in microphone to record anything going on within a 15-ft radius of the camera. This gives you more detailed monitoring for greater peace of mind.IK10 Vandal-Proof & IP67 WaterproofWith vandal-resistant, rugged housing and waterproof design, this VIGI dome camera is built tough to withstand vandalism and harsh environments with rain and dust for constant security anywhere and anytime.Smart Video Coding by H.265+Compresses the video size without sacrificing video quality, easing the network load and saving disk space.Flexible StorageLocal storage is available for each method, as well as onboard storage with an SD card slot (up to 256 GB).PoE/12V DCTwo power supply ways not only give you more convenience but also make your wiring remarkably easy.Flexible InstallationEasily route your camera’s cable into a dropped ceiling or avoid drilling by slotting it through the camera’s side outlet.Remote ManagementTake full control over your security anytime and anywhere on the VIGI app or client.One system. Full security. Run your business with peace of mind.The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
DownloadDatasheet
Dahua 4 MP 25x Starlight IR WizSense Network PTZ Camera, 1/2.8" 4Megapixel STARVIS™ CMOS, Powerful 25x optical zoom, Starlight technology, IR distance up to 150 m, Perimeter protection · Face detection, Metadata · Full-colour illuminator; red and blue warning light, IP66, Smart dual illuminators (Recommended to use within 50 m)
Capture clear, high-definition footage with the Dahua 4MP 25x Starlight TiOC Network PTZ Camera. With starlight technology and a powerful 25x optical zoom, this camera produces detailed images even in low-light conditions. Plus, with features like perimeter protection and face detection, you can ensure your property is always secure.
Features
1/2.8" 4Megapixel STARVIS™ CMOS.
25× optical zoom.
Starlight technology.
Max. 25/30 fps@4MP.
IR distance up to 150 m.
Perimeter protection.
Face detection.
Full-color illuminator; red and blue warning light.
Auto tracking 3.0
Quick Pick.
Specifications
Megapixels
4MP
Camera Style
PTZ
Colour
White
Lens Type
Motorised
Technology
PTZ Series
PoE
PoE+
Downloads
SD6C3425GB-HNR-A-PV1_S0 Datasheet 20230614Dahua Network Speed Dome and PTZ Camera Web 5.0_User's Manual_V1.0.1Installation Guide_V1.0.0Network Speed Dome & PTZ Camera Installation Manual_V1.0.1SD6C3425GB-HNR-A-PV1 A&E 20230927134454
Hikvision PTZ DS-2DE4A425IW-DE, 4MP, 5 -120mm, 25x Optical, 16x Digital, 50m Powered by DarkFighter IR Network Speed Dome (4A425)
High quality imaging with 4 MP resolution
Excellent low-light performance via powered-by-DarkFighter technology
Clear imaging against strong back lighting due to 120 dB WDR technology
Pan and tilt ability enables camera to monitor zones of interest
25× optical zoom allows for closer viewing of subjects in expansive areas
Up to 50 m IR range ensures safety at night
Water and dust resistant (IP66)
Downloads
Datasheet
Quick Start Guide
User Manual
FAQ
Pre-order wait time: 7-9 weeks
Hikvision Covert Camera DS-2CD6425G1-30-8M-6, 2MP, 6mm single tube Lens, 8M Cable, Audio (6425)
High quality imaging with 2 MP resolution
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
Audio and alarm interface available
3D DNR technology delivers clean and sharp images
Downloads
DatasheetQuick Start GuideUser ManualFAQ
Pre-order wait time: 7-9 weeks
Hikvision Covert Camera DS-2CD6425G1-30-2M-3, 2MP, 3.7mm Tube Pin Hole Lens, 2m Lens Cable, Audio (6425)
High quality imaging with 2 MP resolution
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
Audio and alarm interface available
3D DNR technology delivers clean and sharp images
Downloads
DatasheetQuick Start GuideUser ManualFAQ
Pre-order wait time: 7-9 weeks
Hikvision Covert Camera DS-2CD6425G1-20-2M-3, 2MP, 3.7mm Block-shaped Pin Hole Lens, 2m Lens Cable, Audio (6425)
High quality imaging with 2 MP resolution
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
Audio and alarm interface available
3D DNR technology delivers clean and sharp images
Downloads
DatasheetQuick Start GuideUser ManualFAQ
Hikvision Covert Camera DS-2CD6425G1-10-2M-3, 2MP, 3.7mm Cylindrical Pin Hole Lens, 2m Lens Cable, Audio, with One Cylindrical Lens (6425)
High quality imaging with 2 MP resolution
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
Audio and alarm interface available
3D DNR technology delivers clean and sharp images
Downloads
DS-2CD6425G1-10-2M-3 User Manual
Hikvision 8MP AcuSense Bullet DS-2CD2T86G2-ISU-SL-2, IP67, IR 60m, 2.8mm, Built-in Mic, Speaker, Strobe Light (2T86)
Experience high-quality imaging with the Hikvision 8MP AcuSense Bullet camera. Its 8 MP resolution and powered-by-DarkFighter technology ensure excellent low-light performance, while 120 dB true WDR technology delivers clear imaging against strong backlight. With efficient H.265+ compression and deep learning-based human and vehicle target classification, this camera provides effective security. Plus, its active strobe light and audio alarm warn intruders, while the built-in two-way audio allows real-time communication. Water and dust-resistant (IP67), this camera is perfect for outdoor use.
Features
High quality imaging with 8 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Clear imaging against strong back light due to 120 dB true WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle targets classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Provides real-time security via built-in two-way audio
Water and dust resistant (IP67)
Downloads
DS-2CD2T86G2-ISU/SL Datasheet
DS-2CD2T86G2-ISU/SL Quick Start GuideDS-2CD2T86G2-ISU/SL User ManualDS-2CD2T86G2-ISU/SL FAQ
Hikvision PTZ DS-2DE4425IW-DE(T5), 4MP, 25x (4.8-120mm) Powered by DarkFighter IR Network Speed Dome, 100m, AcuSense (4425)
The Hikvision PTZ DS-2DE4425IW-DE(T5) is a powerful and advanced network speed dome camera, featuring a 4MP resolution and up to 25x optical zoom. With powered-by-DarkFighter technology, it offers excellent low-light performance and up to 100m of IR distance for expansive night views. The camera also supports the latest video compression technology for efficient storage and features a deep learning algorithm for accurate classification of human and vehicle targets, including the ability to capture up to 5 faces at once.
Features
Focuses on human and vehicle targets classification based on deep learning
Support face capture. Up to 5 faces captured at the same time
1/2.8" progressive scan CMOS
High quality imaging with 4 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
25× optical zoom and 16× digital zoom provide close up views over expansive areas
Expansive night view with up to 100m IR distance
Support H.265+/H.265 video compression
Downloads
DS-2DE4425IW-DE(T5) DatasheetDS-2DE4425IW-DE(T5) Quick Start GuideDS-2DE4425IW-DE(T5) User ManualDS-2DE4425IW-DE(T5) FAQ
Hikvision ColorVu Turret DS-2CD2347G2-LSU/SL, 4MP, White Light, AcuSense, Built-in Mic, Speaker, Strobe Light, 2.8mm (2347)
The Hikvision ColorVu Turret DS-2CD2347G2-LSU/SL offers high-quality 4 megapixel resolution imaging with efficient H.265+ compression technology. With 130 dB WDR technology, it can take clear images even in strong backlight. It features deep learning based classification for human and vehicle targets and provides 24/7 colorful imaging. The built-in two-way audio, strobe light, and audio alarm help enhance security measures. This IP67 water and dust resistant camera is perfect for both indoor and outdoor use.
Features
High quality imaging with 4 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Focus on human and vehicle targets classification based on deep learning
24/7 colorful imaging
Active strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
Audio and alarm interface available
Water and dust resistant (IP67)
Downloads
DS-2CD2347G2-LSU/SL DatasheetDS-2CD2347G2-LSU/SL Quick Start GuideDS-2CD2347G2-LSU/SL User ManualDS-2CD2347G2-LSU/SL FAQ
Hikvision 6MP AcuSense Dome DS-2CD2166G2-I, IP67, IR, 2.8mm (2166)
The Hikvision 6MP AcuSense Dome DS-2CD2166G2-I provides high quality imaging with 6 MP resolution and excellent low-light performance thanks to DarkFighter technology. Its efficient H.265+ compression and 120 dB true WDR technology ensure clear images even in challenging lighting conditions. With deep learning-based classification of human and vehicle targets, and built-in microphone and alarm interface options, this dome camera offers real-time audio security and is water, dust, and vandal resistant for reliable outdoor use.
Features
High quality imaging with 6 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Built-in microphone for real-time audio security (-SU)
Audio and alarm interface available(-SU)
Water and dust resistant (IP67) and vandal resistant (IK10)
Downloads
DS-2CD2166G2-I Datasheet
DS-2CD2166G2-I Quick Start Guide
DS-2CD2166G2-I User Manual
DS-2CD2166G2-I FAQ
Hikvision 180 Degree Wide Angle Indoor Turret Camera DS-2CD2345G0P-I, 4MP, IR, 1.68MM, (2345)
High quality imaging with 4 MP resolution
180°super wide field of view
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Distortion correction
Robust structure design with full metal materials
Camera
Image Sensor
1/2.7" Progressive Scan CMOS
Min. Illumination
Color: 0.028 Lux @ (F2.0, AGC ON)
B&W: 0.0028 Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Wide Dynamic Range
120 dB
Day & Night
IR Cut Filter
Angle Adjustment
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
Lens Type
Fixed lens, 1.68 mm
FOV
1.68 mm, horizontal FOV: 180° , vertical FOV: 101° , diagonal FOV: 180°
Aperture
F2.0
Lens Mount
M12
Illuminator
IR Range
Up to 10 m
Wavelength
850 nm
Video
Max. Resolution
2688 × 1520
Main Stream
50Hz: 25fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 24fps (2688 × 1520), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Video Compression
Main stream: H.265+/H.264+/H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Video Bit Rate
32 Kbps to 16 Mbps
H.264 Type
Baseline Profile/Main Profile/High Profile
H.265 Type
Main Profile
Scalable Video Coding (SVC)
H.264 and H.265 encoding support
Region Of Interest (ROI)
1 fixed region for main stream, sub-stream and third stream
Network
Simultaneous Live View
Up to 6 channels
API
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Protocols
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
User/Host
Up to 32 users, 3 levels: administrator, operator and user
Security
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Network Storage
microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR
Client
iVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local Service: Chrome 41.0+, Firefox 30.0+
Day/Night Switch
Day/Night/Auto/Schedule
Image Enhancement
BLC, HLC, 3D DNR
Image Settings
Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser
Interface
On-Board Storage
Built-in micro SD slot, up to 256 GB
Hardware Reset
Reset via reset button on camera body, web browser and client software
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
Event
Basic Event
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event
Line crossing detection, intrusion detection, unattended baggage, object removal, face detection, scene change detection
General
Linkage Method
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output , Email
Web Client Language
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
General Function
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
Storage Conditions
-10 °C to 40 °C (14 °F to 104 °F), humidity 95% or less (non-condensing)
Startup And Operating Conditions
-10 °C to 40 °C (14 °F to 104 °F), humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, Φ 5.5 mm coaxial power plug; reverse polarity protection; PoE (802.3af, type 1, class 3)
Power Consumption And Current
12 VDC, 0.48 A, max. 5.8 W; PoE (802.3af, 36 V to 57 V), 0.19 A to 0.12 A, max. 6.8W
Camera Dimension
Camera: Φ 127.3 × 104.1 mm (Φ 5" × 4.1\")
With package: 150 × 150 × 141 mm (5.9 × 5.9\" × 5.6\")
Camera Weight
Camera: Approx. 520 g (1.1 lb.)
With package: Approx. 700 g (1.5 lb.)
Approval
EMC
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
Environment
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Download
Data SheetQuick Start GuideUser Manual
Axis P1377-LE Network Camera, Outdoor, NEMA 4x, IP66/67 and IK10-rated, 5MP Resolution, Day/night, Fixed Box Camera Providing Providing Forensic Wdr and Lightfinder Technology, 01809-001
30 fps in 5 MP or up to 180 fps in HDTV 720p
OptimizedIR and Forensic WDR
Signed firmware and secure boot
Electronic image stabilization
Zipstream supporting H.264 and H.265
AXIS P1377-LE Network Camera offers fast performance and sharp images in any day or night scene. This robust, fixed box camera acts as a deterrent and is ideal for surveillance in wide outdoor areas where a high level of detail is needed, such as at airports, cargo areas and public transportation systems.
Ready for the rough stuff - every time
AXIS P1377-LE captures detailed images of fast-moving objects and people, and it's designed to be reliable in extreme temperatures ranging from -40 °C to 60 °C (-40 °F to 140 °F). It offers electronic image stabilization for stable images in situations where the camera is subject to vibrations. The IP66-, IP67-, IK10- and NEMA 4X-rated casing protects against water, corrosion and dust. And, AXIS P13 Weathershield Extension A is available for extra protection against snow or rain and to prevent reflections. AXIS P1377-LE includes scene profiles, barrel distortion correction and defogging functionality to ensure clear, sharp images even in fog or smog as well as Axis Zipstreamwith support for H.264/H.265.
Light up the night
AXIS P1377-LE delivers excellent image quality regardless of the light conditions. It offers Axis Forensic WDR for high-quality images even when there's both dark and light areas in the scene and Axis Lightfinder for sharp, color images in poor lighting conditions. It features Axis OptimizedIR for surveillance in pitch darkness up to 80m or more. The camera is ideal for varous surveillance situations thanks to a CS mount and support for motorized i-CS lenses, enabling remote zoom. Use our lens calculator to select a lens that meets your specific requirements.
Keeping you secure
AXIS P1377-LE is crammed with advanced security functionality to prevent unauthorized access and safeguard your system. Signed firmware and secure boot guarantees that the firmware hasn't been compromised and ensures only authorized firmware is installed. And if needed, secure boot guarantees the camera is completely free of malware after a factory default. For added piece of mind, it offers shock detection as well as a tampering alarm so you can be informed if there's any attempts to interfere with the camera, such as blocking or spray painting. Plus, there's a video streaming indicator making it easy to check that the video is up and running.
Downloads
P1377-LE Datasheet
Hikvision DS-2CD2387G2-LU 8MP ColorVu Turret Security Camera, White Light, AcuSense, Built-in Mic (2387) comes with 2.8mm and 4mm lens.
Capture clear images day and night with the Hikvision DS-2CD2387G2-LU 8 megapixel ColorVu Turret Security Camera. With 8 MP resolution and efficient H.265+ compression technology, it provides high quality imaging while saving storage space. The built-in mic and 130 dB WDR technology make for effective audio and backlighting security. IP67 water and dust resistance ensure durability.
High quality imaging with 8 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Built-in microphone for real-time audio security(-U)
Focus on human and vehicle targets classification based on deep learning
24/7 colorful imaging
Water and dust resistant (IP67)
Downloads
DS-2CD2387G2-LUD Datasheet
DS-2CD2387G2-LU Quick Start Guide
DS-2CD2387G2-LU Manual
HiLook IPC-T261H-MU(2.8mm)/BLACK 6 MP AI Fixed Turret Network Camera
High quality imaging with 6 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 120 dB WDR technology
Focusing on human and vehicle classification based on deep learning
-U: Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Camera
Image Sensor: 1/2.8" Progressive Scan CMOS
Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Speed: 1/3 s to 1/100,000 s
Slow Shutter: Yes
P/N: P/N
Wide Dynamic Range: 120 dB
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Max. Resolution: 3200 × 1800
Lens
Lens Type: Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV: 2.8 mm, horizontal FOV 107°, vertical FOV 57°, diagonal FOV 128°, 4 mm, horizontal FOV 87°, vertical FOV 46°, diagonal FOV 105°
Iris Type: Fixed
Aperture: F1.6
Lens Mount: M12
DORI
DORI: 2.8 mm: D: 73 m, O: 29 m, R: 15 m, I: 7 m, 4 mm: D: 90 m, O: 35 m, R: 18 m, I: 9 m
Illuminator
Supplement Light Type: IR
Smart Supplement Light: Yes
IR Wavelength: 850 nm
IR Range: Up to 30 m
Supplement Light Range: Up to 30 m
Audio
Audio Compression: -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
Audio Bit Rate: -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)
Audio Sampling Rate: -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering: -U: Yes
Image Parameters Switch: Yes
Image Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch: Day, Night, Auto, Schedule
Image Enhancement: BLC, HLC, 3D DNR
SNR: ≥ 52 dB
Wide Dynamic Range (WDR): 120 dB
Interface
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage: Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
Built-In Microphone: -U: yes
Hardware Reset: Yes
Download
Data Sheet
HiLook IPC-T261H-MU(4mm) 6 MP AI Fixed Turret Network Camera
High quality imaging with 6 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 120 dB WDR technology
Focusing on human and vehicle classification based on deep learning
-U: Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Camera
Image Sensor: 1/2.8" Progressive Scan CMOS
Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Speed: 1/3 s to 1/100,000 s
Slow Shutter: Yes
P/N: P/N
Wide Dynamic Range: 120 dB
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Max. Resolution: 3200 × 1800
Lens
Lens Type: Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV: 2.8 mm, horizontal FOV 107°, vertical FOV 57°, diagonal FOV 128°, 4 mm, horizontal FOV 87°, vertical FOV 46°, diagonal FOV 105°
Iris Type: Fixed
Aperture: F1.6
Lens Mount: M12
DORI
DORI: 2.8 mm: D: 73 m, O: 29 m, R: 15 m, I: 7 m, 4 mm: D: 90 m, O: 35 m, R: 18 m, I: 9 m
Illuminator
Supplement Light Type: IR
Smart Supplement Light: Yes
IR Wavelength: 850 nm
IR Range: Up to 30 m
Supplement Light Range: Up to 30 m
Audio
Audio Compression: -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
Audio Bit Rate: -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)
Audio Sampling Rate: -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering: -U: Yes
Image Parameters Switch: Yes
Image Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch: Day, Night, Auto, Schedule
Image Enhancement: BLC, HLC, 3D DNR
SNR: ≥ 52 dB
Wide Dynamic Range (WDR): 120 dB
Interface
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage: Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
Built-In Microphone: -U: yes
Hardware Reset: Yes
Download
Data Sheet
HiLook IPC-T269H-MU/SL(2.8mm) 6MP All-in-One Fixed Turret Network Camera
High quality imaging with 6 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Human and vehicle targets classification based on deep learning
Active red and blue strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
24/7 colorful imaging
Smart Dual -light Supplement,auto switch IR to White light supplement when event triggered
Water and dust resistant (IP67)
Camera
Image Sensor: 1/2.4" Progressive Scan CMOS
Max. Resolution: 3200 × 1800
Min. Illumination: Color: 0.003 Lux @ (F1.6, AGC ON),0 Lux with white light B/W: 0 Lux with IR
Shutter Time: 1/3 s to 1/100,000 s
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
Lens
Lens Type: Fixed lens, 2.8, 4, and 6 mm optional
Iris Type: Fixed
Focal Length & FOV: 2.8 mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127°; 4 mm, horizontal FOV 78°, vertical FOV:38°, diagonal FOV 96°; 6 mm, horizontal FOV 51°, vertical FOV 26°, diagonal FOV 59°
Aperture: F1.6
Lens Mount: M12
Illuminator
Supplement Light Type: White light & IR
Supplement Light Range: IR Range: Up to 30m ; White light Range: Up to 30m
Smart Supplement Light: Yes
Day/Night Switch: Day,Night,Auto,Schedule
Image Enhancement: BLC,HLC,3D DNR
Image Settings: Mirror, saturation, brightness, contrast, sharpness, AGC, and white balance ajustable by client sfotware or web browser
Privacy Mask: 4 regions of privacy masks
Wide Dynamic Range (WDR): 120 dB
Download
Data Sheet
HiLook IPC-T281H-MU(2.8mm)/BLACK 8 MP AI Fixed Turret Network Camera
High quality imaging with 8 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 120 dB WDR technology
Focusing on human and vehicle classification based on deep learning
-U: Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Camera
Image Sensor: 1/2.8" Progressive Scan CMOS
Max. Resolution: 3840 × 2160
Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Shutter Time: 1/3 s to 1/100,000 s
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
Lens
Lens Type: Fixed focal lens, 2.8 mm
Focal Length & FOV: 2.8 mm, horizontal FOV 107°, vertical FOV 57°, diagonal FOV 128°
Lens Mount: M12
Iris Type: Fixed
Aperture: F1.6
DORI
DORI: 2.8 mm: D: 88 m, O: 35 m, R: 17 m, I: 9 m
Illuminator
Supplement Light Type: IR
Supplement Light Range: Up to 30 m
Smart Supplement Light: Yes
IR Wavelength: 850 nm
Image Parameters Switch: Yes
Image Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch: Day,Night,Auto,Schedule
Wide Dynamic Range (WDR): 120 dB
SNR: ≥ 52 dB
Image Enhancement: BLC,HLC,3D DNR
Privacy Mask: 4 programmable polygon privacy masks
Interface
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Built-In Microphone: -U: Yes
Reset Key: Yes
Downloads
Data Sheet
AXIS P1467-LE Bullet Camera
Fully featured, all-around 5 MP surveillance
Lightfinder 2.0, Forensic WDR, OptimizedIR
Analytics with deep learning
Audio and I/O connectivity
Built-in cybersecurity features
Impact and weather resistant
AXIS P1467-LE offers excellent image quality and advanced analytics based on deep learning on the edge. Including built-in cybersecurity features, this robust, outdoor-ready camera is ideal for a variety of surveillance scenarios.
Feature-packedBased on ARTPEC-8, the latest Axis system-on-chip (SoC), this high-performance camera includes a deep learning processing unit (DLPU). This enables improved processing and storage capabilities allowing you to collect and analyze even more data than before—on the edge. Thanks to AXIS Object Analytics, it offers detection and classification of humans, vehicles, and types of vehicles—all tailored to your specific needs. With edge-to-edge technology, it can be connected to an Axis network speaker enabling two-way audio. Furthermore, it can be powered with DC power and PoE. And, even if there’s a power outage, redundant DC power ensures a reliable power supply to safeguard your data.
Excellent image quality day or nightThis fully featured camera delivers excellent image quality regardless of the light conditions. It offers 5 MP resolution at a frame rate of up to 30 fps. Thanks to Lightfinder 2.0 and Forensic WDR, it delivers true colors and great forensic detail in challenging light or near darkness. OptimizedIR enables surveillance in total darkness up to 40 m (131 ft) without the need for extra lighting. And, motion-adaptive exposure reduces the motion blur from approaching or nearby objects. Furthermore, Zipstream with support for H.264 and H.265 significantly reduces bandwidth and storage requirements without compromising image quality.
We’ve got you securedAXIS P1467-LE offers built-in cybersecurity features to help prevent unauthorized access and safeguard your system. Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis products on your network. Additionally, signed firmware and secure boot guarantee that the firmware hasn’t been compromised and ensure only authorized firmware is installed. And if needed, secure boot guarantees the camera is completely free of malware even after a factory default. Furthermore, this robust, outdoor-ready camera with IP66/67, NEMA 4X, and IK10-ratings is protected from dust, rain, snow and impacts, and can withstand winds up to 50 m/s.
Downloads
P1467-LE Datasheet
AXIS M2035-LE - Network surveillance camera - bullet - outdoor - dust resistant / weather resistant - colour (Day&Night) - 2 MP - 1920 x 1080 - 1080p - fixed iris - fixed focal - LAN 10/100 - MPEG-4, MJPEG, H.264, AVC, HEVC, H.265, MPEG-H Part 2 - PoE Class 3
2 MP affordable camera with deep learning
HDTV 1080p
Compact, lightweight design
Analytics with deep learning
Zipstream supporting H.264/H.265
Outdoor-ready with IR illumination
Ideal for tough environments, this outdoor-ready bullet-style camera offers affordable Axis excellence. Lightweight and compact in design, it’s easy to install and supports analytics with deep learning. Available in two lens alternatives.
With a deep learning processing unit (DLPU), you can benefit from applications based on deep learning on the edge. Thanks to AXIS Object Analytics, it offers detection and classification of humans, vehicles, and types of vehicles—all tailored to your specific needs. And Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network. This outdoor-ready bullet-style camera features built-in IR illumination, enabling unobtrusive surveillance in total darkness. Wide Dynamic Range (WDR) ensures clarity even when there’s both dark and light areas in the scene.
Top performance in tough conditionsIdeal for both hot and cold environments, this IK08-rated bullet camera can withstand temperatures from -30 °C to 50 °C (-22 °F to 122 °F). It includes an integrated sunshield and with IP66, IP67, and NEMA 4X ratings, it’s resistant to rough weather, dust, sand, salt spray, ice formation, and high-water pressure. AXIS M2035-LE is available in two variants with a choice of lenses; a wide 3 mm lens with a 101° horizontal field of view for wide-area surveillance and a tele 8 mm lens with a 39° horizontal field of view for surveillance from a distance. And, thanks to edge-to-edge technology it can be connected to Axis speakers, such as an Axis outdoor horn speaker.
Installation that’s as easy as 1,2,3…This small, lightweight bullet-style camera offers cost-efficient installation both indoors and outdoors. A spacious, sealed back box ensures secure cable management and offers installers greater accessibility, freedom of movement, and future serviceability. Delivered with a factory-focused lens, there’s no need for hands-on fine-tuning saving you time and effort. This easy-to-handle camera supports Power over Ethernet (PoE) so you can connect directly to your IP network with just one network cable for connectivity and power. Furthermore, AXIS M2035-LE offers flexible installation; outdoors or indoors, on walls, ceilings, poles, or in corners.
Specifications
Product Description
AXIS M2035-LE - network surveillance camera - bullet
Device Type
Network surveillance camera - fixed - bullet - outdoor - dust resistant / weather resistant
Dimensions (WxDxH)
10.1 cm x 17 cm x 10.1 cm
Weight
491 g
Colour
White, NCS S 1002-B
Connectivity Technology
Wired
Camera
Colour - Day&Night
Max Resolution
1920 x 1080
Frame Rate (max)
30 frames per second
Motion Detection
Yes
Video Modes
1080p
Optical Sensor Type
PS RGB CMOS - 1/2.9" - 2 MP
Minimum Illumination
0.16 lux - colour - F1.4 - 50 IRE ? 0.03 lux - B&W - F1.4 - 50 IRE ? 0 lux - IR
Focal Length Control
Fixed focal
Focal Length
3.2 mm
Focus Adjustment
(min distance 1.2 m)
Lens Iris
F/1.4 - fixed iris
Interfaces
Ethernet 10Base-T/100Base-TX
Voltage
PoE Class 3
Features
Sharpness control, white balance, colour control, progressive scanning, brightness control, Power over Ethernet, contrast control, image mirror, Wide Dynamic Range (WDR), infrared cut filter, Privacy Mask Function, Video Motion Detection Technology, Lightfinder technology, active tampering alarm, digital PTZ function, password protection, Edge Storage, Variable Bitrate (VBR), Zipstream technology, ONVIF (Profile S) support, ONVIF (Profile G) support, image overlay, exposure control, plastic housing, digest authentication, IP address filtering, HTTPs encryption, aluminium housing, signed firmware, secure boot, Corridor mode, ONVIF (Profile T) support, Adaptive Bitrate (ABR), VAPIX support, motion-adaptive exposure, compression, text overlay, 180? image rotation, 90? image rotation, 270? image rotation, user access log, centralised certificate management, brute force delay protection, ONVIF (Profile M) support, remote zoom, Axis Edge Vault
Manufacturer Warranty
5-year warranty
Environmental Parameters (operating)
-30 ?C - 50 ?C; 10 - 100% RH relative humidity
Download
Axis Q3536-LVE 9mm Dome Camera, Q3536-LVE-9mm Advanced Fixed Dome Camera With Deep Learning Processing Unit (DLPU), 02054-001
Advanced 4 MP dome with deep learning
Outstanding image quality in 4 MP
Analytics with deep learning
Available with wide or tele lens
IR-shielded dome to prevent reflections
Metal casing and built-in cybersecurity features
Built on ARTPEC-8, AXIS Q3536-LVE offers advanced features and powerful applications based on deep learning. This robust camera can withstand the harshest weather conditions and the most powerful impacts.
Outstanding image qualityAXIS Q3536-LVE offers outstanding image quality and forensic details in 4 MP resolution—even in the harshest weather and environments. Featuring OptimizedIR and an innovative IR-shielded dome, it prevents IR reflections from rain, and snow ensuring consistently clear, sharp images. With Lightfinder 2.0 and Forensic WDR, it delivers true colors and great detail in challenging light or near darkness. And electronic image stabilization keeps the picture steady when the camera is subject to vibrations.
Powerful analytics capabilitiesBuilt on ARTPEC-8, this high-performance camera offers advanced analytics based on deep learning on the edge. Featuring a deep learning processing unit (DLPU), it eliminates the need for expensive servers and allows for a faster and more scalable system. Plus, it improves processing capabilities so you can collect and analyze even more data than before — on the edge. AXIS Object Analytics offers detection and classification of humans, vehicles, and types of vehicles—all tailored to your specific needs. Furthermore, with support for ACAP version 4, you can add value to your system with tailor-made applications based on deep learning on the edge available from Axis and our partners.
Robust and secure—inside and outEnclosed in a metal casing, this robust, IK10+-rated outdoor-ready camera is protected against redirection, defocusing, and impacts. It can withstand temperatures as low as -50 °C and as high as 60 °C (-58 ºF to 140 ºF). Including sensors for intrusion and shock detection it’s also packed with built-in cybersecurity features such as Axis Edge Vault to prevent unauthorized access and safeguard your system. This top-of-the-line camera offers easy installation, maintenance, and operation as well as flexible cable management. It includes a built-in gyro sensor enabling leveling assistant and auto rotation. Furthermore, if there's a power outage, redundant power helps ensure a reliable power supply to safeguard the system.
Download
Q3536-LVE Datasheet
Axis M3116LVE Network Camera, M3116-LVE is a Compact 4MP Mini Dome in a Flat-faced, Outdoor-ready, IK08 Impact-resistant Design With Built-in IR Illumination, 01605-001
Affordable flat-faced 4 MP dome with IR
4 MP video quality
Forensic WDR, Lightfinder and IR illumination
Zipstream supporting H.264 and H.265
Signed firmware and secure boot
Flat-faced design suppressing light reflections
AXIS M3116-LVE is an affordable, flat-faced dome that offers 4 MP video and an excellent wide-angle view. This compact and discreet camera includes IR illumination for sharp video even in challenging light or complete darkness. It’s ideal for surveillance in a wide range of locations, including hotels, restaurants, retail stores, and offices.
Smooth, sharp videoAXIS M3116-LVE offers excellent 4 MP resolution at up to 30 fps to deliver clear, sharp video of moving objects. It features Axis Forensic WDR which preserves forensic detail when there are both light and dark areas in a scene. And Axis Lightfinder technology for increased light sensitivity and clear colors in low light. It’s perfect for monitoring inside and outside of various premises where there’s often poor light conditions.
Light up the nightThis flat-faced dome is designed to suppress light reflections and deliver excellent image quality and usability. It offers a wide-angle view of 130°, and with built-in IR illumination you’ll enjoy clear, reflection-free footage in low light or complete darkness and vibrant colors during the day. So, there’s no need for extra lighting- you get unobtrusive surveillance both day and night.
Fits in anywhereAXIS M3116-LVE offers flexible and reliable installation. It’s suitable for both indoor and outdoor surveillance and can be mounted on walls or ceilings. Kits are also available for mounting on pendants or on junction boxes. And, with a 3-axis camera angle adjustment, this compact and discreet flat-faced dome can be easily leveled and directed. Furthermore, the impact-resistant, IK08-rated casing can be re-painted in any color to blend in with specific surroundings.It offers enhanced security features to prevent unauthorized access and safeguard your system. And, Axis Zipstream technology with support for both H.264 and H.265 video compression significantly reduces bandwidth and storage requirements. Furthermore, thanks to edge storage you can record directly to an onboard memory card, helping reduce installation and maintenance costs.
DownloadDatasheet
Dahua 5MP Starlight Pro HDCVI Vandal Dome, WDR, ICR, 2.8mm lens, IR 30m, DC12V, IP67
* The parameters and data sheet below can only be applied to 2501-S2 series.* In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version.
Max 25 fps@5MP (16:9 video output)
Starlight, 120 dB true WDR, 3D NR
CVI/CVBS/AHD/TVI switchable
2.8 mm fixed lens
Max. IR length 30 m, Smart IR
IP67, IK10, DC12Vx30%
Specifications
HD-CAMERA
MEGAPIXELS
5MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
HDCVI
POWER
DC 12V
Downloads
DH-HAC-HDBW2501EP DatasheetDH-HAC-HDBW2501EP User Manual
Dahua 8MP Lite IR Fixed-focal 4K Starlight IP Bullet Network Camera, ICR, WDR, IR 30m, IP67, PoE
8MP, 1/2.7'' CMOS image sensor, low illuminance, high image definition
Outputs max. 8MP (3840x2160) @15 fps, and supports 2688x1520 (2688x1520) @25/30 fps
H.265 codec, high compression rate, ultra-low bit rate
Built-in IR LED, max IR distance: 30 m
ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent detection: Intrusion, tripwirexAbnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access,voltage detection
Supports max. 256 GB Micro SD card
12V DC/PoE power supply
IP67 protection
Specifications
Megapixels
8MP
Camera Style
Bullet
Colour
White
Lens Type
Fixed
Technology
LITE SERIES
Connection
PoE
Downloads
DH-IPC-HFW2831SP-S-0280B-S2 DatasjeetDH-IPC-HFW2831SP-S-0280B-S2 Dahua IR Bullet Network Camera_QSG_V1.0.1DH-IPC-HFW2831SP-S-0280B-S2 Bullet Network Camera Installation Guide_V1.0.0 DH-IPC-HFW2831SP-S-0280B-S2 Dahua Network Camera Web 3.0 Operation Manual_V2.1.1
Dahua 5MP Starlight Pro HDCVI IR Vandal Dome, WDR, ICR, Motorised 2.7~13.5mm, IR 30m, DC12V, IP67* The parameters and data sheet below can only be applied to 2501-S2 series.* In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version.
Max 25 fps@5MP (16:9 video output)
Starlight, 120 dB true WDR, 3D NR
CVI/CVBS/AHD/TVI switchable
2.7 mm-13.5 mm motorised lens
Max. IR length 30 m, Smart IR
IP67, IK10, 12V DCx30%
Specifications
HD-CAMERA
MEGAPIXELS
5MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
HDCVI
POWER
DC 12V
Downloads
HDBW2501R DatasheetHDBW2501R User Manual
Dahua 5MP Starlight Pro HDCVI IR Bullet, WDR, ICR, Motorised 2.7~13.5mm, IR 80m, DC12V, IP67, Built-in Mic* The parameters and datasheets below can only be applied to 2501-S2 series.* In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version.
Max. 25 fps@5MP (16:9 video output)
Starlight, 120 dB true WDR, 3D NR
CVI/CVBS/AHD/TVI switchable
Built-in mic
2.7 mm~13.5 mm motorized lens
Max. IR length 80 m, Smart IR
IP67, 24V AC/12V DC
Specifications
HD-CAMERA
MEGAPIXELS
5MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
HDCVI
POWER
AC 24V/ DC 12V
Downloads
HAC-HFW2501TU-Z-A-DP Datasheet 20201127HDCVI Bullet Camera Installation Guide_V1.0.2-EngHDCVI Camera User's Manual V1.0.0-Eng
Hikvision
DS-2CD2T87G2P-LSU/SL-4 8MP ColorVu Panoramic 180 Degree Bullet, White Light, AcuSense, Built in Mic, Speaker, Strobe Light, IP66 (2T87G2P)
Discover unparalleled, vivid visuals day and night with the Hikvision DS-2CD2T87G2P-LSU/SL. This 8MP ColorVu panoramic camera boasts a 4mm lens and 180 degree bullet design for maximum coverage. Utilizing cutting-edge features such as AcuSense technology, WDR, and deep learning, this IP66 rated camera can precisely detect and classify humans and vehicles. Additionally, the built-in mic, speaker, and strobe light act as powerful deterrents against unwanted trespassers.
Features
High quality imaging with 8 MP resolution
One image that presents all the scenes covered by the camera
24/7 colorful imaging
Efficient H.265+ compression technology
Clear imaging against strong back light due to 130 dB WDR technology
Focus on human and vehicle classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Water and dust resistant (IP67)
Downloads
DS-2CD2T87G2P-LSU/SL DatasheetDS-2CD2T87G2P-LSU/SL Quick Start GuideDS-2CD2T87G2P-LSU/SL User Manual
Hikvision DS-2CD2367G2P-LSU/SL 6 MP Panoramic ColorVu Fixed Turret Network Camera comes with 2.8mm lens
Capture every detail with the Hikvision DS-2CD2367G2P-LSU/SL 6 megapixel Panoramic ColorVu Fixed Turret Network Camera. Its 2.8mm lens provides high quality 6 MP resolution imaging. Experience 24/7 colorful imaging and clear images even in strong backlight with 130 dB WDR technology. With advanced features like human and vehicle classification and active strobe light and audio alarm, this camera is the perfect security solution. Water and dust resistant (IP67).
Features
High quality imaging with 6 MP resolution
One image that presents all the scenes covered by the camera
24/7 colorful imaging
Efficient H.265+ compression technology
Clear imaging against strong back light due to 130 dB WDR technology
Focus on human and vehicle classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Water and dust resistant (IP67)
Downloads
DS-2CD2367G2P-LSU/SLDatasheetDS-2CD2367G2P-LSU/SL Quick Start GuideDS-2CD2367G2P-LSU/SL ManualDS-2CD2367G2P-LSU/SL Installation Guide
TP-Link VIGI 4MP Full-Colour Turret Network Camera - VIGI C440(2.8MM)
4MP Ultra-High Definition: The VIGI C440 comes with 4MP–more than enough pixels to pick up some of the more discrete details.
24h Full-Colour: Obtain 24-hour colour details, even in pitch-black conditions, via high-sensitivity sensor and included spotlight LEDs.
Smart Detection (motion detection, area intrusion, line-crossing, video tampering): Receive notifications and check feeds when someone crosses a boundary, enters an area you've set, or obstructs the camera.
H.265+ Smart Coding: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
PoE/12V DC: Two power supply ways not only give you more convenience but also make your wiring remarkably easy.
Remote Monitoring: Manage your security from the palm of your hand with the VIGI app.
Clarity and Colours, All in OneMonitor 24-hour clear and colourful details even in pitch dark night. VIGI Full-Colour camera provides maximum 4MP resolutions and ensures bright monitoring with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights.Plug & Play with One CableEnjoy simple wiring with PoE connections. Connect your camera with an RJ45 cable, and then your power supply and data transmission are all settled.We keep an eye on your business.Smart DetectionReceive notifications and check feeds when someone crosses a boundary, enters an area you've set, or obstructs the camera.Active DefenseWarn and expel potential intruders instantly with sound and light alarms when abnormal events are detected.Every Event is Under Your Control.VIGI cameras intelligently detect activities, inform you instantly and respond automatically by smart detection and two-way audio.Smart IRKeeps objects from being under-rendered when far away or overexposed when close to the camera at night.Wide Dynamic RangeAdjusts for lighting contrast to minimize shadowing effects and renders images true to life.3D DNRRemoves abnormal pixelation to provide more explicit video and eliminate distortion.More compression. More savings. Same quality.Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
Flexible Management and StorageTake full control over your security via three management methods, VIGI NVR, App, and Security Manager. Local storage is available for each method, as well as onboard storage with an SD card slot.Flexible Installation Gives You More Convenience.Easily route your camera’s cable into a dropped ceiling or avoid drilling by slotting it through the camera’s side outlet.One system. Full security.Run your business with peace of mind.The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
Dahua Security Camera 8MP (4K) WizSense Motorised Starlight Dome, 2.7-13.5mm, 4K@25/30fps, Perimeter, SMD4.0, SD Card, WDR, IR40m, Built-in Mic, IP67, IK10, POE
8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 8MP (3840 x 2160) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports); max. 256 G Micro SD card; built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67, IK10 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
8MP
CAMERA STYLE
Dome
COLOUR
White
LENS TYPE
Motorised
TECHNOLOGY
WizSense Series
CONNECTION
PoE
Downloads
DH-IPC-HDBW3866RP-ZAS-AUS Datasheet 20220718Dahua Dome Network Camera_QSG_V1.0.1Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4
Dahua Security Camera 4MP WizSense Fixed Starlight Bullet, 2.8mm, Perimeter, SMD4.0, SD Card, WDR, IR50m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
Specifications
NETWORK CAMERA
MEGAPIXELS
4MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
3X66
POE
POE
Downloads
DH-IPC-HFW3466EP-AS-AUS DatasheetBullet Network Camera Installation Guide_V1.0.0Dahua Network Camera Web 5.0_Operation Manual_V1.0.4Dahua Network Camera Web 3.0_OperationManual_V2.1.4Dahua Bullet Network Camera_Quick Start Guide_V1.0.3
Uniarch Tri-guard 5MP Turret, Min. illumination 0.003lux, Smart intrusion prevention, powered by ColorHunter technology, 2.8mm fixed lens, 30M IR, 120dB WDR, support 256 GB Micro SD card, Built-in-Mic & Speaker, IP67
High quality image with 5MP, 1/2.7''CMOS sensor
5MP(2880*1620)@30/25fps; 4MP(2560*1440)@30/25fps; 3MP(2304*1296)@30/25fps; 2MP(1920*1080)@30/25fps
Ultra 265, H.265, H.264, MJPEG
Smart intrusion prevention, include cross line, intrusion, enter area, leave area detection
Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and, motor vehicle and non-motor vehicle
Supports sound and light alarm linkage. When Smart intrusion prevention is triggered, the camera links sound alarm and light linkage.
120dB true WDR technology enables clear image in strong light scene
Support 9:16 Corridor Mode
Built-in Mic and Speaker
Smart IR, up to 30m (98ft) IR distance
Supports 256 G Micro SD card
IP67 protection
Support PoE power supply
Specifications
NETWORK CAMERA
MEGAPIXELS
5MP
CAMERA STYLE
Turret
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
Uniarch TRI-Guard
POE
POE
Downloads
Uniarch IPC-T1P5-AF28KC 5MP HD Intelligent Light and Audible Warning Fixed_ Eyeball Network CameraV1.0Uniarch-IPC-Network Eyeball Cameras Quick Guide-V2.01Uniarch Network Camera User Manual-V1.00
