Uniview UNV IPC3K28SE-ADF28KMC-DL-I0 — 8MP 4K Tri-Guard 180° Panoramic Turret | Dual-Lens | ColorHunter 24/7 | Red & Blue Strobe + Siren | NDAA

Description

NDAA Compliant · 8MP 4K 180° Tri-Guard Panoramic

IPC3K28SE-ADF28KMC-DL-I0 — Australian Stock & 3-Year Warranty

The Uniview UNV IPC3K28SE-ADF28KMC-DL-I0 is an 8 MP (4K) OmniView panoramic turret that uses binocular dual-lens splicing to stitch two 4.0 mm lenses into one seamless 180° field of view (4096×1860) — replacing two standard cameras with a single PoE install. Its Tri-Guard active protection combines ColorHunter 24/7 full-colour imaging with red & blue police-style strobe, an audible siren and two-way audio to actively warn off intruders. Built tough with IP67 + IK10 for Australian conditions and backed by a 3-year Australian warranty.

Why the IPC3K28SE-ADF28KMC-DL-I0 stands out

Resolution
8MP 4K / 4096×1860
Low-Light
ColorHunter 24/7 colour
Deterrence
Red & Blue Strobe + Siren
Lens / View
Dual 4.0mm · 180°

Built for Australian conditions

One camera, 180° coverage

Binocular dual-lens splicing fuses two 4.0 mm lenses into a single seamless 180° 4K image — no blind spot between cameras, ideal for wide driveways, shopfronts and open carparks.

ColorHunter 24/7 colour

Warm-light ColorHunter imaging keeps the scene in full colour around the clock, capturing clothing and vehicle colours that IR-only cameras lose to black-and-white at night.

Active deterrence

When AI detects a person or vehicle, the red & blue strobe, siren and two-way audio trigger to actively warn off intruders — not just record them after the fact.

Weatherproof & tough

IP67 sealing and an IK10 vandal-resistant housing handle Australian sun, dust and downpours, with dual microphones and a high-power speaker for two-way talk.

Technical specifications

Uniview UNV IPC3K28SE-ADF28KMC-DL-I0 — Full Specifications
Brand / Series Uniview UNV · OmniView Tri-Guard
Model IPC3K28SE-ADF28KMC-DL-I0
Resolution 8 MP 4K — 4096×1860 @ 20fps
Lens Dual 4.0 mm fixed · binocular splicing
Field of View 180° panoramic (seamless stitched)
Low-Light Tech ColorHunter · 24/7 full-colour (warm light)
Deterrence Red & blue strobe + audible siren (Tri-Guard active warning)
Illumination 30 m IR · 30 m warm white light
Smart Analytics Smart Intrusion Prevention — human / vehicle classification
Audio Dual mics + high-power speaker · two-way audio
Compression Ultra 265 / H.265 / H.264 / MJPEG
Storage MicroSD up to 256 GB · ANR
Network RJ45 · ONVIF · RTSP / HTTPS
Power PoE (IEEE 802.3af) / DC 12V
Weather / Vandal IP67 · IK10 housing
Form Factor Panoramic turret · dual-lens
Compliance NDAA / Section 889 compliant
Warranty 3-Year Australian warranty

Frequently asked questions

Does it record in colour at night?

Yes. ColorHunter warm-light technology keeps footage in full colour 24/7, even in darkness — capturing clothing and vehicle colours that IR-only cameras render in black-and-white.

How does the 180° view work?

Two 4.0 mm lenses capture overlapping scenes that the camera stitches into a single seamless 180° 4K panorama (4096×1860) — one camera replaces two standard units with no blind spot.

What is Tri-Guard active deterrence?

On AI detection of a person or vehicle, the camera triggers a red & blue strobe, an audible siren and two-way audio to actively warn intruders off the property in real time.

Is the IPC3K28SE-ADF28KMC-DL-I0 NDAA compliant?

Yes. Uniview UNV OmniView cameras are NDAA Section 889 compliant, suitable for government, commercial and security-sensitive sites in Australia.

Does it have two-way audio?

Yes — dual microphones and a high-power speaker support full two-way talk, so you can listen and speak through the camera via a compatible app or NVR.

How is it powered?

A single PoE (IEEE 802.3af) cable carries power and data to your PoE NVR or switch. A 12V DC option is also supported.

Where should I mount it?

For a true 180° horizon view, mount it around 2.8 m high on a wall or eave overlooking the area — ideal for wide driveways, shopfronts and carpark frontages.

Which NVRs work with it?

It is plug-and-play with Uniview UNV NVRs and works with most ONVIF-compatible recorders for video and AI events.

What warranty applies?

This camera ships with a 3-year Australian warranty and local CCTV Guru tech support.

Documentation & downloads

IPC3K28SE-ADF28KMC-DL-I0 Datasheet Uniview UNV Turret Camera Quick Start Guide Uniview UNV Turret Camera User Manual
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support

Uniview UNV IPC3K28SE-ADF28KMC-DL-I0 — 8MP 4K Tri-Guard 180° Panoramic Turret | Dual-Lens | ColorHunter 24/7 | Red & Blue Strobe + Siren | NDAA

Product form

SKU: IPC3K28SE-ADF28KMC-DL-I0

$455.00  $357.00 Incl. GST

    • PayPal
    • Apple Pay
    • Visa
    • Mastercard
    • American Express
    • Zip
    • Afterpay

    Add Ons & Accessories

    • Shipped today? Order within: Jul 16, 2026 14:00:00 +1000
    • Warranty: 36 months
    • 30 day Money Back Guarantee
    • Australian Stocks & Express Delivery
    • Back-to-base Warranty & Tech Support
    • FREE Shipping over $180

    Description

    NDAA Compliant · 8MP 4K 180° Tri-Guard Panoramic

    IPC3K28SE-ADF28KMC-DL-I0 — Australian Stock & 3-Year Warranty

    The Uniview UNV IPC3K28SE-ADF28KMC-DL-I0 is an 8 MP (4K) OmniView panoramic turret that uses binocular dual-lens splicing to stitch two 4.0 mm lenses into one seamless 180° field of view (4096×1860) — replacing two standard cameras with a single PoE install. Its Tri-Guard active protection combines ColorHunter 24/7 full-colour imaging with red & blue police-style strobe, an audible siren and two-way audio to actively warn off intruders. Built tough with IP67 + IK10 for Australian conditions and backed by a 3-year Australian warranty.

    Why the IPC3K28SE-ADF28KMC-DL-I0 stands out

    Resolution
    8MP 4K / 4096×1860
    Low-Light
    ColorHunter 24/7 colour
    Deterrence
    Red & Blue Strobe + Siren
    Lens / View
    Dual 4.0mm · 180°

    Built for Australian conditions

    One camera, 180° coverage

    Binocular dual-lens splicing fuses two 4.0 mm lenses into a single seamless 180° 4K image — no blind spot between cameras, ideal for wide driveways, shopfronts and open carparks.

    ColorHunter 24/7 colour

    Warm-light ColorHunter imaging keeps the scene in full colour around the clock, capturing clothing and vehicle colours that IR-only cameras lose to black-and-white at night.

    Active deterrence

    When AI detects a person or vehicle, the red & blue strobe, siren and two-way audio trigger to actively warn off intruders — not just record them after the fact.

    Weatherproof & tough

    IP67 sealing and an IK10 vandal-resistant housing handle Australian sun, dust and downpours, with dual microphones and a high-power speaker for two-way talk.

    Technical specifications

    Uniview UNV IPC3K28SE-ADF28KMC-DL-I0 — Full Specifications
    Brand / Series Uniview UNV · OmniView Tri-Guard
    Model IPC3K28SE-ADF28KMC-DL-I0
    Resolution 8 MP 4K — 4096×1860 @ 20fps
    Lens Dual 4.0 mm fixed · binocular splicing
    Field of View 180° panoramic (seamless stitched)
    Low-Light Tech ColorHunter · 24/7 full-colour (warm light)
    Deterrence Red & blue strobe + audible siren (Tri-Guard active warning)
    Illumination 30 m IR · 30 m warm white light
    Smart Analytics Smart Intrusion Prevention — human / vehicle classification
    Audio Dual mics + high-power speaker · two-way audio
    Compression Ultra 265 / H.265 / H.264 / MJPEG
    Storage MicroSD up to 256 GB · ANR
    Network RJ45 · ONVIF · RTSP / HTTPS
    Power PoE (IEEE 802.3af) / DC 12V
    Weather / Vandal IP67 · IK10 housing
    Form Factor Panoramic turret · dual-lens
    Compliance NDAA / Section 889 compliant
    Warranty 3-Year Australian warranty

    Frequently asked questions

    Does it record in colour at night?

    Yes. ColorHunter warm-light technology keeps footage in full colour 24/7, even in darkness — capturing clothing and vehicle colours that IR-only cameras render in black-and-white.

    How does the 180° view work?

    Two 4.0 mm lenses capture overlapping scenes that the camera stitches into a single seamless 180° 4K panorama (4096×1860) — one camera replaces two standard units with no blind spot.

    What is Tri-Guard active deterrence?

    On AI detection of a person or vehicle, the camera triggers a red & blue strobe, an audible siren and two-way audio to actively warn intruders off the property in real time.

    Is the IPC3K28SE-ADF28KMC-DL-I0 NDAA compliant?

    Yes. Uniview UNV OmniView cameras are NDAA Section 889 compliant, suitable for government, commercial and security-sensitive sites in Australia.

    Does it have two-way audio?

    Yes — dual microphones and a high-power speaker support full two-way talk, so you can listen and speak through the camera via a compatible app or NVR.

    How is it powered?

    A single PoE (IEEE 802.3af) cable carries power and data to your PoE NVR or switch. A 12V DC option is also supported.

    Where should I mount it?

    For a true 180° horizon view, mount it around 2.8 m high on a wall or eave overlooking the area — ideal for wide driveways, shopfronts and carpark frontages.

    Which NVRs work with it?

    It is plug-and-play with Uniview UNV NVRs and works with most ONVIF-compatible recorders for video and AI events.

    What warranty applies?

    This camera ships with a 3-year Australian warranty and local CCTV Guru tech support.

    Documentation & downloads

    IPC3K28SE-ADF28KMC-DL-I0 Datasheet Uniview UNV Turret Camera Quick Start Guide Uniview UNV Turret Camera User Manual
