Dahua Waterproof Wall Mount Bracket
Aesthetic design
Wall mount bracket
Material: aluminum & SECC
Specifications
CAMERA BRACKETS
TYPE
Wall Mount Bracket
MATERIAL
Aluminum & SECC
COLOUR
White
DIMENSION
160mmx122mmx76mm (6.30''x4.80''x2.99'')
Downloads
DH-PFB204W_datasheet
Dahua Waterproof Wall Mount Bracket White
Aluminium alloy material, cost-effective
Dedicated for particular cameras, beautiful and elegant designed
Specifications
CAMERA BRACKETS
TYPE
Wall Mount Bracket
MATERIAL
Aluminum
COLOUR
White
DIMENSION
161.6 mmx125.6 mmx76.0 mm (6.36''x4.94''x2.99'')
Downloads
DH-PFB205W_datasheet
Dahua Waterproof Wall Mount Bracket White
Aesthetic design
Wall mount bracket
Material: aluminum & SECC
Specifications
CAMERA BRACKETS
TYPE
Wall Mount Bracket
MATERIAL
Aluminum & SECC
COLOUR
White
DIMENSION
160mmx122mmx76mm (6.30''x4.80''x2.99'')
Downloads
DH-PFB203W_datasheet
Dahua Waterproof Wall Mount Bracket Black
Aesthetic design
Wall mount bracket
Material: aluminum & SECC
Specifications
CAMERA BRACKETS
TYPE
Wall Mount Bracket
MATERIAL
Aluminum & SECC
COLOUR
Black
DIMENSION
160mmx122mmx76mm (6.30''x4.80''x2.99'')
Downloads
DH-PFB204W_datasheet
Dahua Pole Mount Bracket
Material: aluminum & SUS304
Pole mount bracket
Aesthetic design
Specifications
CAMERA BRACKETS
TYPE
Pole Mount Bracket
MATERIAL
Aluminum & SUS304
COLOUR
White
DIMENSION
125.6mmx114mmx20mm (4.94''x4.49''x0.79'')
Downloads
DH-PFA152-E_datasheet
Dahua Waterproof Wall Mount Bracket Black
Aesthetic design
Wall mount bracket
Material: aluminum & SECC
Specifications
CAMERA BRACKETS
TYPE
Wall Mount Bracket
MATERIAL
Aluminum & SECC
COLOUR
Black
DIMENSION
160mmx122mmx76mm (6.30''x4.80''x2.99'')
Downloads
DH-PFB203W_datasheet
Dahua PoE Extender Passive work with PFT1200, connect up to 3x IPC
Support passive PoE cascade power supply and Ethernet data exchange
Support IEEE 802.3af/at standard power supply IP Camera
Cooperate with High PoE Midspan PFT1200), able to cascade level 2 PoE Extender, connect to 3 IPC (total power consumption <=25W), max transmission distance 300m
1*RJ45 10/100M PoE power supply input; 1*RJ45 10/100M supply power for IP Cam; 1*RJ45 10/100M supply power for the next extender
Installation mode: junction box internal mounting, DIN rail mounting
Downloads
PFT1300_datasheetPoE Extender_User's Manual_V1.0.3
Dahua Corner Mount Bracket
Material: SECC
Corner mount bracket
Aesthetic design
Specifications
CAMERA BRACKETS
TYPE
Corner Mount Bracket
MATERIAL
SECC
COLOUR
White
DIMENSION
243mmx170mmx138mm (9.57''x6.69''x5.43'')
Downloads
DH-PFA151_datasheet
The UVC G3 Flex Professional Wall Mount is a flexible outdoor mounting option for the UVC G3 Flex Camera. It's IPX4-rated for splash resistance and supports upside-down mounting. The camera image orientation is automatically adjusted in the UniFi Protect software.
Dahua Wall Mount Bracket
Neat & Integrated design
Wall mount bracket
Material: Aluminum
Safety rope hook attached, secure and reliable
Specifications
CAMERA BRACKETS
TYPE
Wall Mount Bracket
MATERIAL
Aluminum
COLOUR
White
DIMENSION
200mmx160mmx115mm
(7.87''x6.3''x4.53'')
Downloads
DH-PFB305W Datasheet
Uniarch Fixed Turret Junction Box
Specifications
CAMERA BRACKETS
TYPE
Junction box for IPC-T1EX Series and IPC-T1PX Series fixed dome camera
MATERIAL
Aluminum alloy
COLOUR
White
DIMENSION
106.6mm*36mm (4.20'' x1.42'')
Downloads
TR-JB03-G-IN Fixed Dome Junction Box V1.0
Hikvision Wall Mount Bracket (2365/2366/2385g1/2h65/2h85/2346/2347/2386) - DS-1273ZJ-140
Aluminum alloy material with surface spray treatment
The outlet hole makes the feature looks better
Convenient installation coordinating with lower bowl
Parameters
Weight
703g
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
Φ140×182×120mm
Range Of Application
Suitable for DS-2CC51xxP(N) dome camera wall mounting
Description
DS-2CC51xxP(N) Wall Mounting Bracket for Dome Camera
Download
Data SheetQuick Start Guide
Dahua Integrated Mount Tester DH-PFM907-E
Dahua Integrated Mount Tester
Features
Supports HDCVI, AHD, HDTVI and CVBS digital surveillance system
PoE or 12 VDC power supply
Support Onvif protocol to configure IP address
Audio/RS-485 control
Digital multimeter function
TDR network cable test
Wi-Fi signals test
Download
PFM907-E_datasheetPFM907-E_User 's manualDH-PFM907-E_DIMENSIONS
Dahua Mount Adapter
Neat & Integrated design
Material: Aluminum
Specifications
CAMERA BRACKETS
TYPE
Adapter Plate of PT Network Camera
MATERIAL
Aluminum
COLOUR
White
DIMENSION
134.1mmx83.5mm(5.28''x3.29'')
Downloads
DH-PFA107_datasheet
Hikvision Junction Box (2366/2386/2h66/2h86/2346/2347/2387) - DS-1280ZJ-DM21
Junction Box
Aluminum Alloy
Hikvision White
Parameters
Weight
280 g (0.62 lb.)
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
Φ137 mm × 42 mm (5.4" × 1.7")
Description
Junction Box for Dome Camera
Download
Quick Start Guide
Dahua PoE Switch for IP System with Dahua Network Protocol, Connect up to 6 Indoor Monitor
Decent appearance
Protocol network power supply switch
Connect max 6 indoor monitors with the Cat 5e cable, transfer the signal and power together
Specifications
PoE SWITCH
ETHERNET PORT
6
OPTICAL PORT
Not support
UPLINK PORT
2
POE BUDGET
Max 45W
LAYER
Layer 2
TYPE
Unmanaged
Downloads
Datasheet of DHI-VTNS1060A-A
User Manual
Dahua Pole Mount Bracket
Material: SECC & SUS304
Pole mount bracket
Aesthetic design
Specifications
CAMERA BRACKETS
TYPE
Pole Mount Bracket
MATERIAL
SECC & SUS304
COLOUR
White
DIMENSION
130.4mmx170mmx45mm (5.13''x6.69''x1.77'')
Downloads
DH-PFA150_datasheet
Dahua Ceiling Mount Bracket
Aesthetic design
Material: aluminium & PC
Ceiling mount bracket
Specifications
CAMERA BRACKETS
TYPE
Ceiling Mount Bracket
MATERIAL
Aluminum & PC
COLOUR
White
DIMENSION
133.6mm x 235.5mm (5.26''x16.54'')
Downloads
DH-PFB300C_datasheet
Dahua Wall Mount Bracket
Aesthetic design
Wall mount bracket
Material: aluminum
Specifications
CAMERA BRACKETS
TYPE
Wall Mount Bracket
MATERIAL
Aluminum
COLOUR
White
DIMENSION
58mmx88mmx190.5mm (2.28''x3.46''x7.50'')
Downloads
DH-PFB121W Datasheet
Hikvision Corner Mount Bracket (2165/2T65/2665) - DS-1276ZJ-SUS
Corner Mount
Stainless Steel
Hikvision White
Parameters
Weight
1990 g (4.39 lb.)
Appearance
Hikvision White
Material
Stainless Steel
Dimension
126 mm × 105 mm × 250 mm (4.96" × 4.13" × 9.84")
Description
Corner Mount
Download
Quick Start Guide
Hikvision Water-proof Rain Shade (AVPIT3ZF) - DS-1250ZJ
Rain Shade for Outdoor Dome Camera
Plastic
Hikvision White
Parameters
Weight
199g
Appearance
Hikvision White
Material
Composite Fibre
Dimension
264.7*152*189.6 mm
Description
Rain Shade for Outdoor Dome Camera
Download
Quick Start Guide
Dahua Wall Mount Bracket
Aesthetic design
Wall mount bracket
Material: aluminum
Specifications
CAMERA BRACKETS
TYPE
Water-proof Wall Mount Bracket
MATERIAL
Aluminum
COLOUR
White
DIMENSION
115mmx160mmx255mm (4.53''x6.3''x10.04'')
Downloads
DH-PFB303W Datasheet
Dahua HDMI Extender
Power supply: Input voltage DC5V, only supply for transmitter.
Transmission effect: Real-time transmission HDMI video signal, no delay, strong anti-interference.
Transmission distance: HDMI transmission distance 50m (max.164ft), with CAT6 of pure copper cable(DC impedance is less than 9.5 ohm for every 100 meters(328ft)).
Infrared function: support to transmit one-way infrared remote control signal.
Main functions: Use single UTP (CAT-5E and CAT-6) to transmit 1-ch HDMI video signal, support HDMI 1.3; Support HDMI local loop output; Support EDID.
Protection and anti-interference: Excellent anti-thunder, anti-static and anti-interference capabilities.
Appearance structure: No need to install driver program and set network parameters, easy to use and convenient to install.
Downloads
PFM700-E Datasheet_20190906
Dahua Mount Adapter
Aesthetic design
Material: aluminum
Mount adapter
Specifications
CAMERA BRACKETS
TYPE
Mount Adapter
MATERIAL
Aluminum
COLOUR
White
DIMENSION
60mmx49mm (2.36''x1.93'')
Downloads
DH-PFA111_datasheet
AXIS TQ1501-E Crane and Traffic Mount
AXIS TQ1501-E Crane and Traffic Mount is a great mount for reducing vibrations and offering more stability to your camera installations in demanding situations, such as mounting on cranes or traffic lights. It’s robust and corrosion resistant with its IK10- and NEMA 4X-ratings. The mount can be tilted up to 45 degrees.
Fewer vibrations and more stability
Alleviates vibrations
Pivot mount for more stability
Robust, IK10
Coating in corrosion resilient material
Designed for demanding situations
Downloads
AXIS TQ1501-E Datasheet
Hikvision Wall mount - DS-1273ZJ-130-TRL
Wall Mount Bracket for Dome Camera
With adaptor plate
Aluminum alloy
Hikvision White
Parameters
Weight
900g
Appearance
Hik White
Material
Aluminum Alloy
Dimension
130×182×120mm
Range Of Application
Suitable for dome camera wall mounting
Description
Wall Mounting Bracket for Dome Camera (with adaptor plate)
Download
Quick Start Guide
Hikvision Wall Mount Bracket (2765/2785) - DS-1473ZJ-155
Specifications
Appearance - Hikvision White
Material - Aluminum Alloy
Dimension - 155 mm x 183.5 mm x 240 mm
Description - Wall Mount for Dome Camera
Model - DS-1473ZJ-155
Hikvision In-Ceiling Bracket PTZ (4A220/4A225/4A425) - DS-1671ZJ-SD11
In-Ceiling Mount for 4-inch PTZ Camera
Steel & Plastic
Hikvision White
Parameters
Weight
Approx. 610 g (1.34 lb.)
Appearance
Hikvision White
Material
Steel
Dimension
233.3 mm × 233.3 mm × 85 mm (9.19" × 9.19" × 3.35")
Cable Hole
Ø212 mm (8.3")
Description
In-Ceiling Mounting Bracket for 4-inch PTZ Camera
Download
Quick Start Guide
Hikvision PTZ Wall mount DS-1602ZJ
Wall Mount
Aluminum alloy
Hikvision White
Parameters
Description
Wall Mount Bracket In/Outdoor
Appearance
Hik white
Material
Aluminum alloy
Dimension
97.3 mm × 182.6 mm × 306.4 mm
(3.83” × 7.19” × 12.06”)
Weight
925 g (2.04 lb.)
DownloadQuick Start Guide
Hikvision Wall Mount Bracket With Integrated Junction Box (2365/2366/2385G1/2h65/2H85/2346/2347/2386) - DS-1273ZJ-140B
Wall Mount
With Junction Box
Aluminum alloy
Hikvision White
Parameters
Weight
1488g
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
Φ140×182×120mm
Range Of Application
Suitable for DS-2CC51xxP(N) dome camera wall mounting
Description
DS-2CC51xxP(N) Wall Mounting Bracket for Dome Camera
Download
Quick Start Guide
Parapet Mount Bracket of PTZ Camera
Parapet/plane mount and hidden line design
Material: Aluminum
10kg high load-bearing capacity
Reserved the anti-drop structure, secure and reliable
Specifications
CAMERA BRACKETS
TYPE
Parapet Mount Bracket of PTZ Camera
MATERIAL
Aluminum
COLOUR
White
DIMENSION
343.6mmx121.9mmx700.0mm (15.53''x4.8''x27.56'')
Downloads
DH-PFB301S-E Datasheet
Dahua Mount Adapter DH-PFA108
Aesthetic design
Material: aluminum
Special adapter plate for 4*2MP IR dome camera
Specifications
CAMERA BRACKETS
TYPE
Mount Adapter
MATERIAL
Aluminum
COLOUR
White
DIMENSION
140mmx39.5mm (5.51''x1.56'')
Downloads
DH-PFA108 Datasheet 20181109
Dahua Mini Dome and Turret Mount Adapter
Neat & Integrated design
Material: Aluminum
Specifications
CAMERA BRACKETS
TYPE
Adapter Plate of Mini Dome & Eyeball Camera
MATERIAL
Aluminum
COLOUR
White
DIMENSION
134.1mm x 83.5mm (5.28''x3.29'')
Downloads
DH-PFA106 Datasheet
Dahua Hi-PoE Midspan, Support PoE for Hi-PoE 60W high power consumption speed dome
Support PoE for Hi-PoE 60W high power consumption speed dome
Indicator status: power (normal power on), PoE (normal power supply)
Cooperate with PoE Extender (PFT1300), able to cascade level 2 PoE Extender, connect to 3 IPC (power consumption Installation mode: wall mount
Downloads
PFT1200_Datasheet_20170728PFT1200_User Manual
Hikvision Junction Box - DS-1280ZJ-DM8
Junction Box
Aluminum Alloy
Hikvision White
Parameters
Weight
Approx.: 210 g (0.46 lb.)
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
Φ126.7 mm × 35 mm (4.99" × 1.38")
Description
Junction Box for Dome Camera
Download
Quick Start Guide
