Genuine Dahua Accessory
Dahua PFB204W Waterproof Wall Mount Bracket — White & Black
The Dahua PFB204W is a genuine waterproof wall mount bracket built for Dahua eyeball and turret CCTV cameras. Machined from aluminium with an SECC base plate, it carries the camera clear of the wall, conceals and protects the cabling through a sealed gland, and shrugs off Australian weather from −40°C to 60°C. Now available as a single listing in your choice of White or Black to match the camera and the building.
Construction
Aluminium & SECC
Colour Options
White & Black
Why installers choose the PFB204W
Weatherproof build
Aluminium body with an SECC mounting plate stands up to rain, sun and dust for reliable outdoor mounting year-round.
Concealed, protected cabling
A sealed cable entry routes the camera lead straight into the wall, keeping connectors dry and tamper-resistant.
Two finishes, one part
Choose White or Black from the dropdown so the bracket blends into eaves, soffits and feature walls.
Clean, professional fit
Compact 160 × 122 × 76 mm footprint and a tidy profile give a factory-finished look on any facade.
Compatible Dahua cameras
The PFB204W is the standard wall-mount adapter for Dahua fixed eyeball and turret cameras, including popular WizSense IP ranges such as the IPC-HDW2xxx and IPC-HDW3xxx series, HDCVI HAC-HDW turret cameras, and HDBW-series turret/eyeball models (load rating up to 1 kg). Always confirm your camera lists PFB204W as a supported mount in its datasheet before ordering.
Specifications
Dahua PFB204W — Wall Mount Bracket
| Type |
Waterproof Wall Mount Bracket |
| Material |
Aluminium & SECC |
| Colour |
White (DH-AC-PFB204W) / Black (DH-AC-PFB204W-B) |
| Dimensions |
160 mm × 122 mm × 76 mm (6.30'' × 4.80'' × 2.99'') |
| Net Weight |
0.49 kg |
| Load Capacity |
Up to 1 kg |
| Operating Temperature |
−40°C to +60°C |
| Mounting |
Wall, with concealed cable entry |
| Compatibility |
Dahua eyeball & turret cameras |
Downloads
Frequently asked questions
What's the difference between the White and Black versions?
Only the finish. The White (DH-AC-PFB204W) and Black (DH-AC-PFB204W-B) brackets are identical in size, material and fit — pick the colour from the dropdown.
Which cameras does it fit?
Dahua fixed eyeball and turret cameras, such as the IPC-HDW2/HDW3 WizSense and HAC-HDW HDCVI ranges. Check your camera's datasheet lists PFB204W as a supported mount.
Is it suitable for outdoor use?
Yes. It's aluminium and SECC with a sealed cable entry and is rated from −40°C to +60°C for weather-exposed installs.
Does the cable run inside the bracket?
Yes. The camera lead routes through the bracket and into the wall, keeping the connection concealed and protected.
How much weight can it hold?
Up to 1 kg, which covers Dahua's eyeball and turret camera range.
Is this a genuine Dahua part?
Yes — it's the original Dahua PFB204W accessory, stocked and supported in Australia.
