The HiLook Pro NVR-216MH-K/16P is a 16-channel, 1U 4K NVR with 16 built-in PoE ports for fast plug-and-play camera installs. It supports H.265+/H.265/H.264+/H.264, delivers up to 160 Mbps incoming bandwidth, dual display outputs (HDMI up to 4K + VGA), and 2× SATA bays (up to 16TB per HDD) for reliable local recording. Key benefits True plug-and-play (16× PoE ports): power + data over one cable per camera (IEEE 802.3af/at), PoE budget up to 200W.  Crisp local viewing: HDMI up to 4K (3840×2160@30Hz) plus VGA, with independent output mode.  Storage-ready: 2× SATA bays, up to 16TB each (up to 32TB total, drive dependent).  Efficient compression: H.265+ support helps reduce storage and bandwidth vs older codecs.  AI features (smarter alarms): supports facial recognition / perimeter / Motion Detection 2.0 and more (feature availability depends on how analytics are deployed and which cameras are used).  Remote access capacity: up to 128 remote connections plus ONVIF Profile S/G compatibility for broader camera interoperability.  Low base power draw: ≤ 15W (without HDD and PoE off). Technical Specifications Key Specifications Model NVR-216MH-K/16P (HiLook Pro) IP Camera Inputs 16 channels Built-in PoE Ports 16 × RJ-45 (10/100 Mbps), IEEE 802.3af/at, PoE budget up to 200 W Video Compression H.265 / H.265+ / H.264+ / H.264 Incoming / Outgoing Bandwidth 160 Mbps / 160 Mbps HDMI Output 1-ch, up to 4K (3840 × 2160) @ 30 Hz VGA Output 1-ch, up to 1920 × 1080 @ 60 Hz Playback Up to 16-ch synchronous playback Decoding Capability Up to 2-ch @ 12MP / 4-ch @ 8MP / 8-ch @ 4MP / 16-ch @ 1080p (varies by AI settings) Storage 2 × SATA HDD bays, up to 16 TB per HDD USB Ports 2 × USB 2.0 (Front: 1, Rear: 1) Alarm I/O 4 in / 1 out Network Interface 1 × RJ-45 10/100/1000 Mbps Protocols / Integration ONVIF (Profile S/G), SDK, ISAPI; RTSP, HTTPS, DDNS, NTP, SMTP, SNMP, NFS, iSCSI, UPnP and more Remote Connections Up to 128 Power Supply 100–240 VAC, 50/60 Hz Consumption ≤ 15 W (without HDD and PoE off) Operating Temperature -10°C to 55°C Dimensions (W × D × H) 385 × 315 × 52 mm Weight ≤ 3 kg (without HDD) Why this NVR is a great choice Cleaner installs: 16 PoE ports power cameras directly—less gear, fewer points of failure. Sharper live view: 4K HDMI output for crisp monitoring on a main display. Longer retention: dual HDD bays for bigger storage and flexible RAID-free retention planning. Smarter alerts: AI functions can help reduce false alarms when paired/configured correctly. More compatibility: ONVIF support helps when mixing camera brands (where supported). Guru's recommendation  Choose the NVR-216MH-K/16P if you want a clean up-to-16 camera install where the NVR powers the cameras directly (no separate PoE switch), and you want 4K local display plus dual HDD bays for longer retention. It’s a strong fit for: retail shops, warehouses, offices, workshops multi-camera home builds (driveway + perimeter + entry points) customers wanting “set-and-forget” recording with room to expand to 16 IP cameras FAQs Does this NVR power cameras directly?Yes — it has 16 built-in PoE ports (IEEE 802.3af/at) with up to 200W PoE budget.  How many cameras can it record?Up to 16 IP cameras.  Does it support 4K output to a monitor?Yes — HDMI supports up to 4K (3840×2160@30Hz), plus a VGA output.  How much storage can I add?It has 2× SATA bays, up to 16TB per HDD (check HDD compatibility/availability).

Read more less

Hikvision HiLook Wall/ Ceiling Mount, ALARM-BKT The HiLook Wall/Ceiling Mount ALARM-BKT offers versatile installation with 0-90 degree vertical and -40 to 40 degree horizontal adjustment, ensuring optimal camera positioning. Designed for secure mounting on walls or ceilings, it provides reliable support for your surveillance equipment, enhancing coverage flexibility and installation precision. Ideal for professional security setups requiring adaptable camera angles. Features 0-90 degree vertical -40 degree to 40 degree horizontal Wall/Ceiling mount

Read more less

Hikvision HiLook Alarm PIR Detector, ALARM-PIR2 Dual-tech, Detection range: 12m 85.9, 30Kg Pet-immunity, 24GHz MW, NC detector The HiLook ALARM-PIR2 is a dual-technology PIR detector combining 24GHz K-Band microwave and advanced 3D Fresnel lens optics for reliable motion detection up to 12 meters with an 85.9° coverage angle. Designed for professional security applications, it features pet immunity up to 30kg, automatic sensitivity adjustment, and digital temperature compensation to minimize false alarms. Its 52-zone detection array includes creep-zone protection and full coverage without blind spots. The detector supports selectable EOL resistors for secure alarm and tamper-proof wiring, enabling efficient installation and enhanced system reliability. Features Detection Range: 12m / 85.9 degree Up to 30kg pey immunity Automatic sensitivity Digital temperature compensation 52 zones of 3D optics including creep-zone protection, full coverage without dead angle Selectable EOL resistors for alarm and tamper-proof wiring Sealed optics preventing insect interference 24Ghz microwave 9 to 16 V wide voltage adaptation with polarity reverse connection protection Wall/Ceiling-mounting brackets available (sold separately) IFT technology prevents false alarms More Information HA-ALARM-PIR2 Datasheet

Read more less

HiLook HA-ALARM-KP-WB LCD Wired KeyPad RS485, 433Mhz Supports 2 On-board Alarm Inputs and 1 On-board Alarm Output The HiLook HA-ALARM-KP-WB is an AX series wired keypad tailored for the Hilook alarm control panel, featuring an LCD display and integrated wireless transceiver with tag reader compatibility. It supports up to 64 keyfobs for arming and disarming, including one-touch arming without a password. The keypad includes dedicated Fire, Panic, and Medical alarm keys, displays company information and time, and offers two on-board alarm inputs alongside one on-board alarm output for enhanced security management. Features LCD screen display Supports one-touch arm(Arming without password) Supports Fire/Panic/Medical alarm key Supports company name, phone number, time display Supports 2 on-board alarm inputs and 1 on-board alarm output Supports maximum 64 keyfobsv More Information HA-ALARM-KP Datasheet

Read more less

HiLook PTZ-N4215I-DE 4-inch 2 MP 15X Powered by DarkFighter IR Network Speed Dome Four-inch 2 MP camera with pan, tilt and zoom (15x) ability Efficient H.265+ compression technology to save bandwidth and storage Clear imaging against strong back light due to 120 dB true WDR technology Excellent night-time performance with up to 100 m enhanced IR Water and dust resistant (IP66) Camera Image Sensor: 1/2.8" progressive scan CMOS Max. Resolution: 1920 × 1080 Min. Illumination: Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON), 0 Lux with IR Shutter Speed: 1/1 s to 1/30,000 s Day & Night: IR Cut Filter Zoom: 15x optical, 16x digital Lens Focal Length: 5 mm to 75 mm, 15× optical FOV: Horizontal field of view: 53.8° to 4.0° (wide-tele), Vertical field of view: 31.9° to 2.3° (wide-tele), Diagonal field of view: 60.4° to 4.6°(wide-tele) Focus: Auto, semi-auto, manual Aperture: F1.6 to F3.0 Zoom Speed: Approx. 2.4 s (optical lens, wide-tele) Illuminator Supplement Light Type: IR Supplement Light Range: Up to 100 m Smart Supplement Light: Yes Network Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets Simultaneous Live View: Up to 20 channels API: Open Network Video Interface, ISAPI, SDK, ISUP User/Host: Up to 32 users. 3 levels: Administrator, Operator and User Security: User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering Network Storage: NAS (NPS, SMB/ CIPS), ANR Client: iVMS-4200, HiLookVision Web Browser: IE10-11, Chrome 57+, Firefox 52+, Safari 12+ Image Image Settings: Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser Wide Dynamic Range (WDR): 120 dB Defog: Digital defog Image Stabilization: No Image Enhancement: BLC, HLC, 3D DNR Privacy Mask: 24 programmable privacy masks Regional Focus: Yes Regional Exposure: Yes Interface Ethernet Interface: 1 RJ45 10 M/100 M Ethernet Interface; PoE (802.3 at, class4) On-Board Storage: Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB General Power: 12 VDC, 2.0 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A, class4 Max.:18 W (IR Max.6 W) Dimension: Ø 165.9 mm × 290 mm (Ø 6.53" × 11.42") Weight: Approx. 2.5 kg (5.51 lb) Material: ADC 12, PC+10% GF Operating Condition: -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing) Downloads Data SheetQuick Start GuideUser Manual

Read more less

HiLook PTZ-N4225I-DE 4-inch 2 MP 25X Powered by DarkFighter IR Network Speed Dome The HiLook PTZ-N4225I-DE is a professional-grade 4-inch 2 MP network speed dome camera featuring 25x optical zoom and powered by advanced DarkFighter IR technology. It delivers clear, high-resolution 1080p images with excellent performance in low-light conditions, supported by up to 100 meters of enhanced infrared illumination. The camera incorporates 120 dB true WDR for superior clarity in challenging lighting, while H.265+ compression optimizes bandwidth and storage efficiency. Built to withstand harsh environments, it offers IP66-rated water and dust resistance, making it ideal for reliable outdoor surveillance with precise pan, tilt, and zoom control. Features Four-inch 2 MP camera with pan, tilt and zoom (25x) ability Efficient H.265+ compression technology to save bandwidth and storage Clear imaging against strong back light due to 120 dB true WDR technology Excellent night-time performance with up to 100 m enhanced IR Water and dust resistant (IP66) Camera Image Sensor: 1/2.8" progressive scan CMOS Max. Resolution: 1920 × 1080 Min. Illumination: Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON), 0 Lux with IR Shutter Speed: 1/1 s to 1/30,000 s Day & Night: IR Cut Filter Zoom: 25x optical, 16x digital Lens Focal Length: 4.8 mm to 120 mm, 25× optical FOV: Horizontal field of view: 57.6° to 2.5° (Wide-Tele), Vertical field of view: 34.4° to 1.4° (Wide-Tele), Diagonal field of view: 64.5° to 2.9° (Wide-Tele) Focus: Auto, semi-auto, manual Aperture: F1.6 to F3.5 Zoom Speed: Approx. 3.2 s (optical lens, wide-tele) Illuminator Supplement Light Type: IR Supplement Light Range: Up to 100 m Smart Supplement Light: Yes PTZ Movement Range (Pan): 360° endless Movement Range (Tilt): From -15° to 90° (Auto-flip) Pan Speed: Configurable, from 0.1°/s to 80°/s, Preset Speed: 80°/s Tilt Speed: Configurable, from 0.1°/s to 80°/s, Preset Speed: 80°/s Proportional Pan: Yes Presets: 300 Preset Freezing: Yes Patrol Scan: 8 patrols, up to 32 presets for each patrol Pattern Scan: 4 pattern scans, record time over 10 minutes for each scan Park Action: Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan PTZ Status Display: Yes Scheduled Task: Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust Power-Off Memory: Yes Audio Audio Compression: G.711alaw/G.711ulaw/G.722/G.726/MP2L2/PCM Audio Bit Rate: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps (MP2L2) Network Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets Simultaneous Live View: Up to 20 channels API: Open Network Video Interface, ISAPI, SDK, ISUP User/Host: Up to 32 users. 3 levels: Administrator, Operator and User Security: User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering Network Storage: NAS (NPS, SMB/ CIPS), ANR Client: iVMS-4200, HiLookVision Web Browser: IE10-11, Chrome 57+, Firefox 52+, Safari 12+ Image Image Settings: Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser Wide Dynamic Range (WDR): 120 dB Defog: Digital defog Image Stabilization: No Image Enhancement: BLC, HLC, 3D DNR Privacy Mask: 24 programmable privacy masks Regional Focus: Yes Regional Exposure: Yes Interface Ethernet Interface: 1 RJ45 10 M/100 M Ethernet Interface; PoE (802.3 at, class4) On-Board Storage: Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB Audio: 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω General Power: 12 VDC, 2.0 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A, class4 Max.:18 W (IR Max.6 W) Dimension: Ø 165.9 mm × 290 mm (Ø 6.53" × 11.42") Weight: Approx. 2.5 kg (5.51 lb) Material: ADC 12, PC+10% GF Operating Condition: -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing) Download Data SheetQuick Start GuideUser Manual

Read more less

HiLook IPC-D261H-MU(2.8mm) 6 MP AI Vandal Fixed Dome Network Camera The HiLook IPC-D261H-MU(2.8mm) is a 6 MP AI-powered vandal-resistant fixed dome network camera designed for professional surveillance. It delivers high-quality 3200 × 1800 resolution images with 120 dB true WDR for clear visibility in challenging lighting. Equipped with H.265+ compression, it optimizes storage and bandwidth. Advanced AI classifies human and vehicle targets for precise monitoring. The built-in microphone enables real-time audio security. Rated IP67 and IK10, it withstands harsh environments and vandalism. Its 2.8 mm fixed lens and flexible angle adjustments ensure comprehensive coverage for reliable security applications. Fetaures High quality imaging with 6 MP resolution Clear imaging against strong backlight due to 120 dB true WDR technology Efficient H.265+ compression technology Focus on human and vehicle targets classification based on deep learning Built-in microphone for real-time audio security Water and dust resistant (IP67) and vandal-resistant (IK10) Camera Image Sensor: 1/2.8" Progressive Scan CMOS Max. Resolution: 3200 × 1800 Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR Shutter Time: 1/3 s to 1/100,000 s Day & Night: IR cut filter Angle Adjustment: Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° Lens Lens Type: Fixed focal length, 2.8 mm Focal Length & FOV: 2.8 mm, horizontal FOV 107°, vertical FOV 57°, diagonal FOV 128° Lens Mount: M12 Iris Type: Fixed Aperture: F1.6 DORI DORI: 2.8 mm: D: 73 m, O: 29 m, R: 15 m, I: 7 m Illuminator Supplement Light Type: IR Supplement Light Range: Up to 30 m Smart Supplement Light: Yes IR Wavelength: 850 nm Video Main Stream: 50 Hz: 20 fps (3200 × 1800), 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) Sub-Stream: 50 Hz: 25 fps (1280 × 720, 960×540, 640 × 480, 640 × 360) Third Stream: 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings. Video Compression: Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 *Third stream is supported under certain settings. Video Bit Rate: 32 Kbps to 16 Mbps H.264 Type: Baseline Profile/Main Profile/High Profile H.265 Type: Main Profile Bit Rate Control: CBR/VBR Scalable Video Coding (SVC): H.264 and H.265 encoding Region Of Interest (ROI): 1 fixed region for main stream and sub-stream Image Image Parameters Switch: Yes Image Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser Day/Night Switch: Day, Night, Auto, Schedule Wide Dynamic Range (WDR): 120 dB SNR: ≥ 52 dB Image Enhancement: BLC, HLC, 3D DNR Interface Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port On-Board Storage: Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB Built-In Microphone: Yes Reset Key: Yes Download Datasheet
