Hilook Value Series
High-Performance Connectivity with Hilook NS-0326P-230
Engineered for demanding commercial environments and high-density IP surveillance systems, the Hilook NS-0326P-230 delivers robust network switching capabilities and reliable Power over Ethernet (PoE) delivery. This managed switch optimizes data transmission for security infrastructures, ensuring seamless video streaming, centralized device control, and long-term operational stability across corporate, retail, and industrial sites.
Port Capacity
24 Gigabit PoE
Power Budget
230W Total Output
Management Type
Managed L2 Layer
Uplink Interfaces
Gigabit SFP Ports
Advanced Network Control and Protocol Support
The NS-0326P-230 features advanced network management protocols, including VLAN configuration, link aggregation, and comprehensive QoS (Quality of Service) to prioritize critical video traffic over standard data. Its enterprise-grade architecture ensures secure data routing, rapid fault recovery, and optimal bandwidth allocation for multi-camera deployments.
High PoE Power Budget
Delivers up to 230W of total power distribution, easily supporting multiple high-draw PTZ cameras, infrared illuminators, and standard IP security endpoints without external power supplies.
Robust Industrial Design
Built into a durable rack-mountable metal chassis optimized for superior heat dissipation, guaranteeing reliable 24/7 continuous operation in professional server room environments.
Technical Specification Matrix
| Camera Model |
NS-0326P-230 |
| Total Port Count |
24 Gigabit PoE ports, 2 Gigabit SFP uplink ports |
| PoE Standard |
IEEE 802.3af, IEEE 802.3at |
| Max. Power Budget |
230W |
| Switching Capacity |
52 Gbps |
| Packet Forwarding Rate |
38.68 Mpps |
| MAC Address Table |
8K entries |
| Enclosure |
Metal material, fanless / fan-cooled design |
What is the total PoE power budget of the NS-0326P-230?
The switch provides a total power budget of 230W, supporting standard IEEE 802.3af/at power delivery across its active ports.
Does this switch support fiber uplinks?
Yes, it features dedicated Gigabit SFP optical fiber uplink ports for long-distance network connections.
Is this model a managed or unmanaged switch?
The NS-0326P-230 is a managed Layer 2 switch offering advanced security, VLAN, and traffic prioritization features.
Can this switch be installed in a standard server rack?
Yes, it comes with rack-mounting accessories designed for standard 19-inch server racks and cabinets.
