Official Hikvision Accessory · 130 mm Camera Wall Mount
Hikvision DS-220AZJ-130 Wall Mount Bracket — White or Black
The DS-220AZJ-130 is a Hikvision wall-mount bracket for compatible dome and turret cameras in the 130 mm mounting group. It moves the camera away from the wall, provides a cleaner cable route and gives installers access to the connections at the mounting point.
Select DS-220AZJ-130-WA for the white finish or DS-220AZJ-130-BA for black. The two variants serve the same mounting purpose but are matched to different camera finishes.
Why an end user would choose it
Neater wall installation: routes camera cabling through the bracket instead of leaving pigtails exposed.
Correct camera orientation: positions a compatible dome or turret for wall-mounted coverage.
Finish options: choose white (WA) or black (BA) to match the camera and site.
Official accessory: appears in Hikvision installation diagrams for supported camera families.
Choose the correct variant
Variant
Finish
Use
DS-220AZJ-130-WA
Hikvision white
Compatible white 130 mm dome/turret camera models
DS-220AZJ-130-BA
Black
Compatible black 130 mm dome/turret camera models
Important before you buy
This is not a universal camera bracket. Match the exact camera model to Hikvision’s accessory/installation list.
A similar camera diameter does not guarantee the fixing holes and cable path will align.
The bracket itself does not make cable connections waterproof. Outdoor installations still require correctly sealed cable and conduit entries.
Use fixings suitable for the wall material and total installed load.
Frequently asked questions
What is the difference between WA and BA?
WA is the white version and BA is the black version. Choose the finish that matches your compatible camera.
Will it fit any Hikvision dome or turret camera?
No. It is intended for supported models in the 130 mm mounting group. Confirm compatibility by exact camera model before ordering.
Does it contain space for cable connections?
It is designed to route and conceal the camera cable at the wall-mounting point. The available space and connector fit depend on the camera and installation method.
Can it be used outdoors?
It is used in compatible outdoor camera installations, but the complete cable entry and mounting system must be sealed correctly. Do not treat the bracket alone as a waterproof enclosure.
Compatibility reference
Hikvision lists the DS-220AZJ-130-WA and DS-220AZJ-130-BA in camera installation diagrams. Please match your exact camera model or contact CCTV Guru before ordering.
Official Hikvision Accessory · 4-inch PTZ Junction Box
Hikvision DS-1280ZJ-SD11 — Junction Box for Compatible 4-inch PTZ Cameras
The DS-1280ZJ-SD11 is an official Hikvision aluminium-alloy junction box for compatible 4-inch PTZ cameras. It provides space to route and protect camera connections at the mounting point and gives the installation a cleaner, serviceable finish.
This is a model-specific accessory—not a universal dome-camera bracket. Confirm your exact PTZ model in Hikvision’s accessory list before ordering.
Key details
Application: junction box for compatible 4-inch Hikvision PTZ cameras
Material: aluminium alloy
Finish: Hikvision white
Dimensions: 185.2 × 157.7 × 39.7 mm
Weight: approximately 400 g
Why use it?
Keeps cable joins and camera pigtails organised at the mounting point.
Provides a purpose-designed interface for supported Hikvision 4-inch PTZ cameras.
Allows easier future access to connections than placing joins loose behind the camera.
Matches the standard Hikvision white camera finish.
Important before you buy
Check compatibility by exact camera model. Similar-looking 4-inch PTZ cameras can use different brackets.
The official specification describes the material, dimensions, weight and application; it does not publish a standalone IP weatherproof rating for this junction box.
Outdoor weather resistance depends on the complete installation, including cable glands, conduit entries, sealing and mounting surface.
Use fixings appropriate for the wall or ceiling material and the total installed load.
Frequently asked questions
Is the DS-1280ZJ-SD11 for fixed dome cameras?
No. Hikvision specifies it as a junction box for compatible 4-inch PTZ cameras.
What are the dimensions?
It measures 185.2 × 157.7 × 39.7 mm and weighs approximately 400 g.
Is it waterproof by itself?
Hikvision does not publish a standalone IP rating for this junction box. Any outdoor installation must be correctly sealed at cable and conduit entries.
How do I confirm compatibility?
Match the exact camera model against Hikvision’s accessory list or ask CCTV Guru before ordering.
Official Hikvision reference
View the official DS-1280ZJ-SD11 product specification
Hikvision Polymer Anti-Corrosion Series · 4MP ColorVu · 4 mm
Hikvision DS-2XC6047G0-LS(4mm)(PA) — 4MP ColorVu Polymer Anti-Corrosion Bullet Camera
The DS-2XC6047G0-LS(4mm)(PA) is built for corrosive environments where a conventional metal camera housing may deteriorate quickly. Its reinforced polymer enclosure is suited to coastal, marine and industrial sites, while ColorVu imaging and a 4 mm F1.0 lens provide clear 4MP colour video with warm white supplementary light at night.
This listing is for the LS model with a 4 mm fixed lens. The LS version adds audio I/O, alarm I/O and RS-485. It is a specialist camera for harsh sites; correct cable sealing, compatible mounting hardware and professional installation remain important.
Why an end user would choose it
Designed for corrosive sites: PA polymer reinforced with glass fibre, with C5 anti-corrosion, NEMA 4X and IP68 protection ratings.
4MP identification detail: up to 2688 × 1520 resolution.
24/7 colour imaging: F1.0 aperture with warm white supplementary light up to 40 m.
Better backlit images: 120 dB WDR helps around gates, reflective water and bright entrances.
Efficient recording: H.265+ compression reduces bandwidth and storage requirements.
Local backup: microSD support up to 256 GB; card sold separately.
Integration options: PoE or wide-range 9–36 VDC power, plus audio, alarm and RS-485 connections on this LS model.
Edge applications: supports Hikvision Embedded Open Platform for compatible on-camera applications.
Important before you buy
This listing is the official DS-2XC6047G0-LS(4mm)(PA) variant. Do not use the generic L(S) family name when checking accessories or project schedules.
White supplementary light is visible at night. Choose an infrared model if visible lighting is unsuitable for the site.
Protection ratings apply to the correctly installed product. Cable entries, junctions and mounts must be sealed and installed to the site requirements.
For direct coastal spray, chemical exposure or wash-down areas, confirm the complete mounting and cabling system—not only the camera housing—is suitable.
Key specifications
Official model
DS-2XC6047G0-LS(4mm)(PA)
Resolution
4MP, up to 2688 × 1520
Sensor
1/3-inch progressive scan CMOS
Lens
4 mm fixed, F1.0
Supplementary light
Warm white, up to 40 m
WDR
120 dB
Interfaces
1 audio in/out, 1 alarm in/out, RS-485
Storage
microSD up to 256 GB
Housing
PA + 50% glass fibre; IP68, NEMA 4X, C5 anti-corrosion
Power
PoE or 9–36 VDC
Frequently asked questions
Why use a polymer anti-corrosion camera?
It is intended for sites where salt, moisture or industrial contaminants can shorten the life of conventional metal housings. The whole installation still needs suitable mounts, fixings, cable and sealing.
How does ColorVu differ from infrared?
ColorVu uses a wide F1.0 aperture and visible warm white supplementary light to retain colour at night. Infrared cameras normally switch to monochrome in darkness.
Which lens is included?
This listing is for the 4 mm fixed-lens LS(PA) model. The lens is not motorised and cannot be changed from the camera interface.
Can it record without an NVR?
It supports a microSD card up to 256 GB for local recording. An NVR is still recommended when longer retention, central playback or multiple cameras are required.
Official Hikvision resource
Download the official DS-2XC6047G0-LS datasheet (PDF)
Hikvision Pro Series · IP Video Intercom
2MP IP Villa Door Station — Surface or Flush Mount
The Hikvision DS-KV6133-WME1 is a high-performance IP villa door station for residential entryways, office suites and gated commercial properties. Choose Surface Mount or Flush Mount from the mounting style dropdown to suit your installation. Both versions share the same camera, intercom, access-control, networking and IP65 weather-resistance features.
Which Mounting Style Should I Choose?
Feature
Surface Mount
Flush Mount
Installation
Mounted directly onto the wall
Recessed into a prepared wall opening
Finished Appearance
Projects from the wall
Lower-profile, integrated finish
Wall Preparation
Minimal
Wall cut-out and suitable recess required
Best Suited For
Retrofits and straightforward installations
New builds and premium installations
SKU
DS-KV6133-WME1/SURFACE
DS-KV6133-WME1/FLUSH
Core Camera & Intercom Features
Same
Same
Installation note: Before selecting Flush Mount, confirm that the installation surface has sufficient wall depth and a suitable opening. Refer to the Flush Mount datasheet below for installation requirements.
Resolution / FOV
2MP HD / 129° Horizontal
Access Control
Mifare RFID Reader (13.56 MHz)
Connectivity
Standard PoE & 2.4GHz Wi-Fi
Protection Rating
IP65 Weather Resistant
Advanced Audio-Visual Processing & Standalone Smart Integration
Built-in noise suppression and echo cancellation deliver clear two-way audio. True 120 dB WDR and IR illumination up to 2.5 metres preserve facial detail under heavy backlight or in darkness. Power the unit using standard IEEE 802.3af PoE or 12 VDC. The integrated 2.4 GHz Wi-Fi connection supports Hik-Connect app notifications, video calls and remote door unlocking without requiring an indoor monitor.
Choose the Right InstallationSelect Surface Mount for simpler wall installation and retrofit projects, or Flush Mount for a recessed, low-profile finish where suitable wall preparation is available.
Integrated Access ControlThe onboard 13.56 MHz Mifare reader supports up to 10,000 cards and 2,000 users for secure keyless entry.
Shared Technical Specifications
Model
DS-KV6133-WME1
Mounting Options
Surface Mount or Flush Mount
Resolution
1920 × 1080p / 1280 × 720p
Field of View
Horizontal 129°, Vertical 75°
Night Vision
IR supplement up to 2.5 m
Audio
Built-in microphone and speaker; noise and echo cancellation
Access Capacity
Up to 2,000 users and 10,000 Mifare cards
Network
RJ-45 10/100 Mbps; 2.4 GHz Wi-Fi
Protection
IP65 weather resistant
Power
12 VDC or IEEE 802.3af Standard PoE
Downloads & Resources
Surface Mount Datasheet Flush Mount Datasheet
Installation Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision PanoVu Series · Multi-Sensor IP
Dual-Directional Multi-Angle Coverage with AcuSense AI & DarkFighter Tech
The Hikvision DS-2CD6D42G2-I/S is a high-performance dual-sensor multi-lens PanoVu network camera designed to cover two distinct angles simultaneously using a single IP address and network drop. Equipped with two independently adjustable 4 MP lens modules (offering a total resolution of 8 MP), it is ideal for monitoring hallway intersections, retail aisles, building corners, long perimeters, and parking structures. Powered by Hikvision's AcuSense deep learning analytics and DarkFighter low-light technology, it delivers precise human/vehicle classification and clear imaging in low-light environments while cutting infrastructure installation costs in half.
Resolution / Sensors
8MP Total (2x 4MP @ 30fps)
Optics & Flexibility
Dual 2.8mm or 4mm Lenses
Illumination / AI
30m IR / AcuSense Deep Learning
Protection Rating
IP67 Weather / IK10 Vandal
Flexible Positioning, Audio/Alarm Interfaces & 120 dB True WDR
The Hikvision DS-2CD6D42G2-I/S allows security installers to rotate and adjust each camera track independently along a 3-axis gimbal, making it easy to fine-tune coverage across challenging architectural layouts. Built-in 120 dB True WDR balances high-contrast scene lighting, while integrated Audio and Alarm I/O interfaces ("/S" model) enable seamless integration with external microphones, speakers, and security sensors. With support for micro-SD edge storage up to 256 GB and efficient H.265+ compression, it lowers both bandwidth overhead and storage consumption.
AcuSense Deep Learning Target Analytics
Uses AI algorithms on both channels to distinguish humans and vehicles from non-threatening motion like leaves, animals, or shadows, significantly reducing nuisance false alarms.
Dual-Directional Single Channel Economy
Replaces two separate physical cameras with a single housing, saving money on VMS license costs, network drops, PoE switch ports, and installation labor.
Technical Specification Matrix
Camera Model
DS-2CD6D42G2-I/S
Image Sensor
2 × 1/2.7" Progressive Scan CMOS
Max. Resolution
2560 × 1440 per channel (8 MP Total / 2x 4 MP) @ 30 fps
Lens Options
Dual 2.8 mm or 4 mm fixed focal length options
Low Light Sensitivity
Colour: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR (DarkFighter)
Infrared Illumination
Independent IR LEDs up to 30 m for each channel
Wide Dynamic Range
120 dB True WDR
Audio & Alarm Interfaces (/S)
1-ch Audio In / 1-ch Audio Out, 1-ch Alarm In / 1-ch Alarm Out
Local Edge Storage
Built-in MicroSD/SDHC/SDXC slot, up to 256 GB
Protection Ratings
IP67 Weatherproof / IK10 Vandal-Resistant / PoE+ (802.3at)
What is the benefit of a dual-directional multi-sensor camera?
It allows two completely independent directions (such as down two hallways or both sides of a building corner) to be monitored at the same time using only one network cable, one PoE port, and one mounting bracket.
What does the "/S" suffix indicate on this model?
The "/S" suffix indicates the inclusion of dedicated Audio and Alarm Interface ports (Audio I/O and Alarm I/O) for connecting external mics, speakers, or external sensor triggers.
How do AcuSense AI analytics function on dual sensors?
Both sensor channels run independent AcuSense deep learning algorithms to filter out non-human and non-vehicle movements, ensuring precise intruder detection across both camera views.
Can the two lenses be aimed independently?
Yes, each 4 MP camera head can be manually panned, tilted, and rotated along its internal track to achieve custom viewing angles.
Technical Datasheet
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision PT Series · Industrial Thermography PTZ
Thermographic Temperature Monitoring, Fire Detection & 32x Optical Identification
The Hikvision DS-2TD4228T-10/S2 is an advanced thermographic thermal and optical bi-spectrum network speed dome camera engineered for industrial heat monitoring, early fire detection, and high-security perimeter surveillance. Combining a 256 × 192 VOx uncooled thermal sensor with a high-resolution 4 MP optical camera featuring 32x optical zoom (4.8–153 mm), this speed dome delivers dual-spectrum vision across continuous 360° pan and tilt movements. Unlike standard security thermal cameras, the thermographic "T" series measures precise target temperatures up to 550°C, making it an essential asset for electrical substations, manufacturing facilities, power stations, and fire-prone infrastructure.
Dual Sensor Setup
256x192 Thermal / 4MP Optical
Thermography Range
-20°C to 550°C (±2°C / ±2%)
Optical Zoom & IR
32x Zoom (4.8-153mm) / 100m IR
Enclosure Protection
IP66 Weatherproof / TVS 6000V
Dynamic Fire Detection & Smart Bi-Spectrum Target Tracking
The Hikvision DS-2TD4228T-10/S2 incorporates intelligent fire and smoke detection algorithms that monitor thermal emissions in real time, detecting up to 10 fire points before visual flames appear. Built-in Smart Tracking linkages seamlessly tie the thermal and optical channels together, allowing panoramic, event, or multi-scene patrol tracking to auto-follow moving targets or abnormal heat signatures. With Picture-in-Picture overlay, 120 dB WDR, and 100-metre Smart IR illumination, security operators gain total visual clarity in pitch-black conditions, heavy fog, or dense smoke.
High-Accuracy Thermography (-20°C to 550°C)
Precision temperature exception monitoring with up to 21 rules per scene (points, areas, lines) alerts control rooms immediately to overheating transformers, switchgear, or machinery.
360° Endless Pan & Smart Tracking
Supports continuous 360° pan rotation, -5° to +90° tilt with auto-flip, and automated tracking routines across 300 configurable presets and 8 patrol scans.
Technical Specification Matrix
Camera Model
DS-2TD4228T-10/S2
Thermal Sensor & Resolution
VOx Uncooled Focal Plane Arrays, 256 × 192 (12 μm)
Optical Sensor & Resolution
1/2.8" Progressive Scan CMOS, 2688 × 1520 (4 MP)
Thermal Lens / FOV
10 mm focal length (Horizontal: 18.1°, Vertical: 13.6°)
Optical Lens & Zoom
4.8 mm to 153 mm (32x Optical Zoom, 16x Digital Zoom)
Temperature Measurement Range
-20 °C to 550 °C (-4 °F to 1022 °F), Accuracy: Max ±2 °C or ±2%
Smart Functions
Fire Detection (10 points), Smoke Detection, Line Crossing, Intrusion, Region Entrance/Exit
PTZ Range & Speed
Pan: 360° continuous; Tilt: -5° to +90°; Pan Speed up to 240°/s, Tilt Speed up to 200°/s
IR Distance & WDR
Up to 100 m Smart IR; 120 dB Optical WDR
Interfaces & Storage
7-ch Alarm In / 2-ch Alarm Out, Audio I/O, MicroSD slot (up to 256 GB)
Power Supply & Consumption
24 VAC, 36 VDC, 48 VDC, Hi-PoE; Max 30 W
Ingress & Operating Temp
IP66 Weatherproof, TVS 6000V Surge Protection; -40 °C to 70 °C (-40 °F to 158 °F)
What distinguishes the "T" series from standard security thermal cameras?
The "T" designation stands for Thermography. While standard security thermal models measure up to 150°C for general perimeter security, the DS-2TD4228T-10/S2 measures up to 550°C with high accuracy (±2°C) for specialized industrial monitoring.
How does Smart Tracking linkage work on this bi-spectrum PTZ?
When the thermal sensor detects an abnormal heat source or perimeter breach, the optical channel automatically zooms in and tracks the target using its 32x optical zoom to give operators crisp visual identification.
Can this camera detect fires through smoke or total darkness?
Yes. Thermal imaging penetrates total darkness, fog, and light smoke by detecting infrared radiation emitted by heat sources, allowing dynamic fire algorithms to flag fires before visual smoke accumulates.
What power options are supported for this speed dome?
It supports Hi-PoE (High Power over Ethernet) for simplified single-cable power and data deployment, as well as 24 VAC, 36 VDC, and 48 VDC terminal block connections.
Technical Datasheet User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision HeatPro Series · Thermal Security
Bi-Spectrum Thermal Imaging, Early Fire Detection & Active Deterrence
The Hikvision DS-2TD1228-3/QA is a high-performance HeatPro series thermal and optical bi-spectrum turret network camera designed for early fire detection, temperature exception monitoring, and round-the-clock perimeter protection. Equipped with a 256 × 192 thermal sensor and a 4 MP optical image sensor, this compact camera bridges thermal target detection with visible light verification. Built-in deep learning algorithms enable precise human and vehicle classification, drastically reducing false alarms caused by wildlife or environmental factors, while onboard white light strobes and audio alerts deliver proactive on-site deterrence.
Sensor Resolution
256x192 Thermal / 4MP Optical
Thermal Lens / FOV
3.6mm (50.0° × 37.3°)
Analytics & Alarms
Fire Detect & Active Strobe/Siren
Protection Rating
IP66 Weatherproof / TVS 6000V
Precision Temperature Measurement & Perimeter Target Analytics
The Hikvision DS-2TD1228-3/QA excels in temperature monitoring across critical infrastructures, server rooms, recycling centers, and commercial facilities. Capable of measuring temperatures ranging from -20°C to 150°C with high accuracy, it instantly flags thermal anomalies before real fire hazards break out. Featuring bi-spectrum image fusion, operators can overlay thermal channels with 4 MP optical video to quickly identify exact hot spots and intruders in total darkness, fog, or smoke.
Active Strobe Light & Audio Deterrence
Triggers a white flashing light and audible alarm warnings automatically upon detecting line crossings, perimeter intrusion, or fire hazards to warn off intruders immediately.
Advanced Fire & Temperature Alarm
Monitors pre-set temperature thresholds and detects early combustion or smoldering materials to notify operators long before traditional optical smoke alarms trigger.
Technical Specification Matrix
Camera Model
DS-2TD1228-3/QA
Thermal Sensor Resolution
256 × 192 (Uncooled Focal Plane Arrays)
Optical Sensor Resolution
1/2.7" Progressive Scan CMOS, 2688 × 1520 (4 MP)
Thermal Lens & FOV
3.6 mm focal length (Horizontal: 50.0°, Vertical: 37.3°)
Temperature Measurement Range
-20 °C to 150 °C (-4 °F to 302 °F), ±8 °C accuracy
Smart Functions
Line Crossing, Intrusion Detection, Fire Detection, Temperature Alarm
Optical IR Range
Up to 15 m IR distance
Audio & Alarm I/O
Built-in speaker, integrated strobe light, alarm in/out, audio in/out
Storage & Power
MicroSD slot (up to 256 GB), 12 VDC & PoE (802.3af)
Protection Ratings
IP66 Weatherproof, TVS 6000V Lightning Surge Protection
What is the benefit of a bi-spectrum camera?
Bi-spectrum cameras combine a thermal sensor for long-range heat/motion detection with an optical camera for clear visual verification in a single compact housing.
How does early fire detection work on the DS-2TD1228-3/QA?
The thermal sensor detects sudden rises in heat and spots flames or smoldering hot spots, triggering immediate alarms before smoke builds up enough to activate conventional optical smoke sensors.
Can this camera distinguish humans and vehicles from animals?
Yes, built-in HeatPro deep learning video analytics filter out false alarms caused by small animals, foliage, shadows, or weather elements to focus exclusively on human and vehicle targets.
Does the camera support active deterrence?
Yes, upon rule violations, the camera activates a white flashing light and customised audio messages or siren sounds to deter intruders on site.
Technical Datasheet Quick Start Guide
User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Ultra Series · SmartIP
Ultra HD 16MP Active Defense with AI Noise Reduction & Marine-Grade Shielding
The Hikvision DS-2CD36167G3-LIZSUY/SL is an enterprise-class 16 MP motorised varifocal bullet network camera engineered for high-security perimeters, port terminals, logistics centers, critical infrastructure, and chemical processing sites. Featuring advanced HIK AI-ISP processing, this camera achieves unprecedented low-light noise reduction and captures pristine 4608 × 3456 video detail across demanding lighting conditions. Equipped with active deterrence capabilities—including an integrated white light strobe and high-decibel audio alarm—alongside NEMA 4X marine-grade anti-corrosion protection (-Y), it delivers aggressive 24/7 proactive security across severe outdoor settings.
Resolution / Processing
16MP Ultra HD / HIK AI-ISP
Optics & Focal Length
2.7-13.5mm Motorised Zoom
Illumination / Audio
60m Hybrid / Active Deterrence
Protection Ratings
IP67 / IK10 / NEMA 4X
Deep Learning Classification & Spatial Dual-Microphone Communications
The Hikvision DS-2CD36167G3-LIZSUY/SL utilizes deep learning analytics to focus strictly on human and vehicle target classification, effectively filtering out non-threatening motion like windblown foliage or weather elements. Built with an arrayed dual-microphone system, an integrated 2W speaker, and scene-adaptive Wide Dynamic Range (WDR), it enables spatial noise reduction for crystal-clear two-way audio communication and sound event response. Featuring Smart Hybrid Light technology, remote motorised 2.7 to 13.5 mm zoom, and NEMA 4X anti-corrosion shielding (-Y), it guarantees robust 16 MP operational awareness across severe marine and industrial sites.
Active Strobe Light & Audio Alarm (/SL)
Proactively deters potential intruders upon AI event detection by automatically firing an intense white strobe light and loud customizable sound alerts directly at the target.
NEMA 4X Anti-Corrosion Rating (-Y)
Specially treated with marine-grade anti-corrosion materials to resist salt fog, high humidity, acidic atmosphere, and harsh chemical exposure in coastal and industrial facilities.
Technical Specification Matrix
Camera Model
DS-2CD36167G3-LIZSUY/SL
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
4608 × 3456 (16 Megapixel Ultra HD)
Lens Type & FOV
Motorised 2.7–13.5 mm (Horizontal: 99° to 43°)
Min. Illumination
Colour: 0.0008 Lux @ (F1.2, AGC ON), 0 Lux with Light
Supplement Light Range
Up to 60 m IR & White Light (Smart Hybrid Light)
Wide Dynamic Range
Scene-Adaptive WDR / 130 dB WDR
Audio & Deterrence
Dual Array Microphones, 2W Speaker, Active Strobe Light
Local Edge Storage
Built-in microSD/SDHC/SDXC slot, up to 512 GB
Protection Ratings
IP67 / IK10 / NEMA 4X / 12 VDC & PoE+ (802.3at, Class 4)
What coverage advantage does 16MP resolution provide?
The ultra-high 16MP resolution (4608 × 3456) delivers incredible pixel density, allowing security personnel to digitally zoom into wide scenes to review small details like faces and number plates clearly.
What level of corrosion protection does the "-Y" suffix indicate?
The "-Y" designation confirms NEMA 4X anti-corrosion protection, guaranteeing that the camera housing resists salt spray, chemical exposure, and acidic weather in coastal and industrial areas.
How does HIK AI-ISP enhance image quality?
HIK AI-ISP leverages deep-learning noise reduction algorithms to maintain clear colour, high contrast, and sharpness in dark conditions where traditional cameras suffer from noise and blurring.
Does the camera support remote focal adjustments?
Yes, the motorised 2.7 to 13.5 mm lens allows installers to adjust optical zoom and autofocus remotely via the web browser interface or client software.
Technical Datasheet Quick Start Guide
User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Ultra Series · SmartIP
Ultra HD 16MP Active Defense with AI Noise Reduction & Marine-Grade Shielding
The Hikvision DS-2CD3H167G3-LIZSUY/SL is an elite 16 MP motorised varifocal turret network camera engineered for high-security perimeters, port terminals, logistics centers, critical infrastructure, and chemical processing facilities. Powered by advanced HIK AI-ISP processing technology, this camera achieves unprecedented image noise reduction and captures pristine 4608 × 3456 video detail across demanding low-light environments. Equipped with active deterrence capabilities—including an integrated white light strobe and high-decibel audio alarm—alongside NEMA 4X marine-grade anti-corrosion protection (-Y), it delivers aggressive 24/7 proactive security across severe outdoor settings.
Resolution / Processing
16MP Ultra HD / HIK AI-ISP
Optics & Focal Length
2.7-13.5mm Motorised Zoom
Illumination / Audio
40m Hybrid / Active Deterrence
Protection Ratings
IP67 / IK10 / NEMA 4X
Deep Learning Classification & Spatial Dual-Microphone Communications
The Hikvision DS-2CD3H167G3-LIZSUY/SL utilizes deep learning analytics to focus strictly on human and vehicle target classification, effectively filtering out non-threatening motion like windblown foliage or weather elements. Built with an arrayed dual-microphone system, an integrated 2W speaker, and scene-adaptive Wide Dynamic Range (WDR), it enables spatial noise reduction for crystal-clear two-way audio communication and sound event response. Featuring Smart Hybrid Light technology, remote motorised 2.7 to 13.5 mm zoom, and NEMA 4X anti-corrosion shielding (-Y), it guarantees robust 16 MP operational awareness across severe marine and industrial sites.
Active Strobe Light & Audio Alarm (/SL)
Proactively deters potential intruders upon AI event detection by automatically firing an intense white strobe light and loud customizable sound alerts directly at the target.
NEMA 4X Anti-Corrosion Rating (-Y)
Specially treated with marine-grade anti-corrosion materials to resist salt fog, high humidity, acidic atmosphere, and harsh chemical exposure in coastal and industrial facilities.
Technical Specification Matrix
Camera Model
DS-2CD3H167G3-LIZSUY/SL
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
4608 × 3456 (16 Megapixel Ultra HD)
Lens Type & FOV
Motorised 2.7–13.5 mm (Horizontal: 99° to 43°)
Min. Illumination
Colour: 0.0008 Lux @ (F1.2, AGC ON), 0 Lux with Light
Supplement Light Range
Up to 40 m IR & White Light (Smart Hybrid Light)
Wide Dynamic Range
Scene-Adaptive WDR
Audio & Deterrence
Dual Array Microphones, 2W Speaker, Active Strobe Light
Local Edge Storage
Built-in microSD/SDHC/SDXC slot, up to 512 GB
Protection Ratings
IP67 / IK10 / NEMA 4X / 12 VDC & PoE+ (802.3at, Class 4)
What coverage advantage does 16MP resolution provide?
The ultra-high 16MP resolution (4608 × 3456) delivers incredible pixel density, allowing security personnel to digitally zoom into wide scenes to review small details like faces and number plates clearly.
What level of corrosion protection does the "-Y" suffix indicate?
The "-Y" designation confirms NEMA 4X anti-corrosion protection, guaranteeing that the camera housing resists salt spray, chemical exposure, and acidic weather in coastal and industrial areas.
How does HIK AI-ISP enhance image quality?
HIK AI-ISP leverages deep-learning noise reduction algorithms to maintain clear colour, high contrast, and sharpness in dark conditions where traditional cameras suffer from noise and blurring.
Does the camera support remote focal adjustments?
Yes, the motorised 2.7 to 13.5 mm lens allows installers to adjust optical zoom and autofocus remotely via the web browser interface or client software.
Technical Datasheet Quick Start Guide
User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Ultra Series · SmartIP
Ultra HD 16MP Resolution with AI Noise Reduction & NEMA 4X Marine Shielding
The Hikvision DS-2CD37167G3T-LIZSUY is a flagship 16 MP motorised varifocal dome network camera engineered for high-security perimeters, port terminals, logistics centers, critical infrastructure, and chemical plants. Powered by advanced HIK AI-ISP processing, this camera delivers unprecedented image noise reduction and captures pristine 4608 × 3456 video detail in challenging low-light conditions. Featuring Smart Hybrid Light technology, remote motorised 2.7 to 13.5 mm optical zoom, and NEMA 4X marine-grade anti-corrosion protection (-Y), it delivers continuous 24/7 intelligence across demanding environments.
Resolution / Processing
16MP Ultra HD / HIK AI-ISP
Optics & Iris
2.7-13.5mm Motorised / DC Iris
Illumination / Audio
40m Hybrid / Dual Mic Array
Protection Ratings
IP67 / IK10 / NEMA 4X
Deep Learning Classification & Anti-Corrosion Marine Shielding
The Hikvision DS-2CD37167G3T-LIZSUY utilizes deep learning algorithms to accurately focus on human and vehicle classification, filtering out non-threatening motion like windblown trees or rain. Equipped with dual onboard microphones for directional noise reduction, 130 dB True Wide Dynamic Range (WDR), and NEMA 4X anti-corrosion shielding (-Y), it maintains crystal-clear visual and acoustic performance in salt-spray, chemical, and severe outdoor environments. Its motorised 2.7 to 13.5 mm lens allows remote focal adjustments from a wide 99° view down to a tight 43° focus.
Anti-Corrosion NEMA 4X Rating (-Y)
Specially treated with marine-grade anti-corrosion materials to resist severe salt fog, high humidity, acidic atmosphere, and harsh chemical exposure in ports and industrial parks.
Adaptive Smart Hybrid Illumination
Seamlessly transitions between discrete IR light and warm white supplement light up to 40 metres when a target is detected, capturing vivid colour evidence when security breaches occur.
Technical Specification Matrix
Camera Model
DS-2CD37167G3T-LIZSUY
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
4608 × 3456 (16 Megapixel Ultra HD)
Lens Type & FOV
Motorised 2.7–13.5 mm (Horizontal: 99° to 43°)
Min. Illumination
Colour: 0.001 Lux @ (F1.2, AGC ON), 0 Lux with Light
Supplement Light Range
Up to 40 m IR & White Light (Smart Hybrid Light)
Wide Dynamic Range
130 dB True WDR
Audio & Alarm I/O
Dual Built-in Microphones, 1 in/1 out Line Audio, Alarm Interfaces
Local Edge Storage
Built-in microSD/SDHC/SDXC slot, up to 512 GB
Protection Ratings
IP67 Weather / IK10 Vandal / NEMA 4X Anti-Corrosion / PoE+ (802.3at)
What coverage advantage does 16MP resolution provide?
The ultra-high 16MP resolution (4608 × 3456) delivers incredible pixel density, allowing security personnel to digitally zoom into wide scenes to review small details like faces and number plates clearly.
What level of corrosion protection does the "-Y" suffix indicate?
The "-Y" designation confirms NEMA 4X anti-corrosion protection, guaranteeing that the camera housing resists salt spray, chemical exposure, and acidic weather in coastal and industrial areas.
How does HIK AI-ISP enhance image quality?
HIK AI-ISP leverages deep-learning noise reduction algorithms to maintain clear colour, high contrast, and sharpness in dark conditions where traditional cameras suffer from noise and blurring.
Does the camera support remote focal adjustments?
Yes, the motorised 2.7 to 13.5 mm lens allows installers to adjust optical zoom and autofocus remotely via the web browser interface or client software.
Technical Datasheet Quick Start Guide
User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Ultra Series · SmartIP
Ultra HD 12MP Active Defense with AI Noise Reduction & Marine-Grade Shielding
The Hikvision DS-2CD36C7G3-LIZSUY/SL(2.7-13.5mm) is an enterprise-class 12 MP motorised varifocal bullet network camera engineered for high-security perimeters, port terminals, logistics centers, critical infrastructure, and chemical sites. Featuring advanced HIK AI-ISP processing, this camera achieves exceptional low-light noise reduction and captures pristine 4608 × 2592 video detail across challenging lighting conditions. Equipped with active deterrence capabilities—including an integrated white light strobe and high-decibel audio alarm—alongside NEMA 4X marine-grade anti-corrosion protection, it provides aggressive 24/7 proactive security across harsh environmental settings.
Resolution / Processing
12MP UHD / HIK AI-ISP
Optics & Focal Length
2.7-13.5mm Motorised Zoom
Illumination / Audio
60m Hybrid / Active Deterrence
Protection Ratings
IP67 / IK10 / NEMA 4X
Deep Learning Classification & Spatial Dual-Microphone Communications
The Hikvision DS-2CD36C7G3-LIZSUY/SL(2.7-13.5mm) utilizes deep learning analytics to focus strictly on human and vehicle classification, filtering out routine environmental movement like windblown trees or rain. Built with an arrayed dual-microphone system, an integrated 2W speaker, and scene-adaptive Wide Dynamic Range (WDR), it enables spatial noise reduction for crystal-clear two-way audio communication and sound event response. Featuring Smart Hybrid Light technology, remote motorised 2.7 to 13.5 mm zoom, and NEMA 4X anti-corrosion shielding (-Y), it guarantees robust 12 MP operational awareness across severe marine and industrial sites.
Active Strobe Light & Audio Alarm (/SL)
Proactively deters potential intruders upon AI event detection by automatically firing an intense white strobe light and loud customizable sound alerts directly at the target.
NEMA 4X Anti-Corrosion Rating (-Y)
Specially treated with marine-grade anti-corrosion materials to resist salt fog, high humidity, acidic atmosphere, and harsh chemical exposure in coastal and industrial facilities.
Technical Specification Matrix
Camera Model
DS-2CD36C7G3-LIZSUY/SL(2.7-13.5mm)
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
4608 × 2592 (12 Megapixel UHD) @ 20 fps
Lens Type & FOV
Motorised 2.7–13.5 mm (Horizontal: 102° to 44°)
Min. Illumination
Colour: 0.0008 Lux @ (F1.2, AGC ON), 0 Lux with Light
Supplement Light Range
Up to 60 m IR & White Light (Smart Hybrid Light)
Wide Dynamic Range
Scene-Adaptive WDR
Audio & Deterrence
Dual Array Microphones, 2W Speaker, Active Strobe Light
Local Edge Storage
Built-in microSD/SDHC/SDXC slot, up to 512 GB
Protection Ratings
IP67 / IK10 / NEMA 4X / 12 VDC & PoE+ (802.3at, Class 4)
What image quality benefits does HIK AI-ISP bring?
HIK AI-ISP leverages deep-learning noise reduction algorithms to maintain clear colour, high contrast, and sharpness in dark conditions where traditional cameras suffer from noise and blurring.
How does active deterrence respond when a perimeter is breached?
When a human or vehicle target triggers a virtual line-crossing or intrusion rule, the camera instantly activates an intense white flashing strobe light and an audible siren or pre-recorded warning.
What level of weather and corrosion protection does this camera offer?
The unit features IP67 weather resistance against water and dust, IK10 vandal resistance, and NEMA 4X anti-corrosion coating to withstand salt spray, chemical environments, and harsh weather.
Can I communicate with visitors or intruders directly through the camera?
Yes, featuring built-in dual arrayed microphones for spatial noise suppression and a 2W loudspeaker, operators can execute real-time two-way voice communication via the web interface or client software.
Technical Datasheet Quick Start Guide
User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision 3 Series · 12MP Smart Hybrid Light
12MP Motorised Varifocal Turret Camera with Active Deterrence
The Hikvision DS-2CD3HC7G3-LIZSU/SL(Y) is a 12MP turret network camera built for detailed outdoor surveillance in demanding commercial, industrial and coastal environments. Its motorised 2.7–13.5 mm varifocal lens lets installers adjust the field of view remotely, while Smart Hybrid Light combines infrared and white illumination for clear imaging at night. Human and vehicle classification helps reduce unwanted alerts, and the integrated strobe light and speaker provide an immediate visual and audible warning when a configured event is triggered.
Resolution
12MP / 4608 × 2592
Motorised Lens
2.7–13.5 mm Varifocal
Night Illumination
Smart Hybrid Light to 40 m
Environmental Protection
IP67 / IK10 / NEMA 4X
Sharper Evidence, Smarter Alerts and Proactive Response
HIK AI-ISP image processing is designed to preserve useful colour, clarity and motion detail in difficult low-light scenes. Deep-learning human and vehicle classification focuses event detection on relevant targets, helping operators spend less time reviewing alerts caused by weather, foliage or other background movement. The dual microphones and built-in 2 W speaker support two-way audio, while the white strobe and configurable audible warning can be used for active deterrence.
Motorised Varifocal CoverageAdjust the 2.7–13.5 mm lens remotely to move between a wide overview and a tighter view of gates, loading areas, entrances or other priority zones.
Smart Hybrid LightUse infrared illumination for discreet night monitoring or white light when colour detail and visible deterrence are required, with a rated range of up to 40 metres.
Active DeterrenceA built-in flashing light and speaker can respond to configured human or vehicle events with visual and audible warnings.
Corrosion-Resistant ConstructionThe NEMA 4X-rated housing is intended for challenging environments exposed to salt spray, humidity and corrosive conditions.
Technical Specifications
Model / SKU
DS-2CD3HC7G3-LIZSU/SL(Y)
Image Sensor
1/1.8" Progressive Scan CMOS
Maximum Resolution
4608 × 2592 (12MP) at up to 20 fps
Lens
2.7–13.5 mm motorised varifocal
Horizontal Field of View
102° to 44°
Minimum Illumination
Colour: 0.0008 lux at F1.2, AGC on; 0 lux with supplementary light
Supplementary Light
IR and white light, up to 40 m
Image Processing
HIK AI-ISP and scene-adaptive WDR
Analytics
Human and vehicle classification
Audio & Deterrence
Dual microphones, built-in 2 W speaker and white strobe light
Local Storage
microSD/SDHC/SDXC card slot, up to 512 GB
Protection
IP67 weather resistance, IK10 impact resistance and NEMA 4X anti-corrosion protection
Power
PoE+ (IEEE 802.3at)
Frequently Asked Questions
What does Smart Hybrid Light do?It combines infrared and white supplementary lighting. The camera can provide discreet IR monitoring or use white light when colour detail and a visible warning are preferred.
Can the viewing angle be adjusted after installation?Yes. The motorised 2.7–13.5 mm varifocal lens can be adjusted remotely to refine the scene without manually changing the lens.
How does active deterrence work?When a configured event is detected, the camera can activate its white strobe and built-in speaker to provide an immediate warning.
Is this camera suitable for coastal locations?The housing carries NEMA 4X anti-corrosion protection in addition to IP67 and IK10 ratings, making it suitable for appropriately designed installations in harsh and corrosive environments.
Downloads & Resources
Technical Datasheet Quick Start Guide
User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Ultra Series · 12MP Smart Hybrid Light
12MP Motorised Varifocal Dome Camera for Detailed Day and Night Surveillance
The Hikvision DS-2CD37C7G3T-LIZSU(Y) is a 12MP dome network camera designed for high-detail surveillance across commercial, industrial and exposed outdoor sites. Its 1/1.8-inch sensor records up to 4608 × 2592 resolution, while the motorised 2.7–13.5 mm varifocal lens allows the viewing angle to be adjusted remotely during commissioning. HIK AI-ISP processing, scene-adaptive WDR and Smart Hybrid Light help maintain useful image detail across daylight, low-light and night-time conditions.
Resolution / Sensor
12MP / 1/1.8-inch CMOS
Motorised Lens
2.7–13.5 mm Varifocal
Night Illumination
IR + White Light to 40 m
Protection
IP67 / IK10 / NEMA 4X
High-Resolution Imaging with Smarter Event Detection
At full 12MP resolution, the camera records up to 20 frames per second, or up to 25 fps at 4K and lower resolutions in Australian 50 Hz operation. Deep-learning person and vehicle classification helps focus perimeter events on relevant targets. Face capture, line crossing, intrusion, region entrance and region exiting functions are also supported, subject to system configuration and compatible recording equipment.
HIK AI-ISP Low-Light ProcessingAdvanced image processing reduces noise and helps preserve colour, sharpness and motion detail in difficult lighting.
Smart Hybrid LightInfrared and white supplementary lighting provide three operating modes, with a rated illumination range of up to 40 metres.
Motorised Varifocal CoverageAdjust the horizontal field of view from approximately 102° to 44° to balance broad coverage with tighter detail around entrances, loading areas and perimeter zones.
Dual-Microphone AudioAn arrayed dual-microphone and environmental noise filtering support clear mono audio capture. Line-level audio input and output are also provided.
Moderate Anti-Corrosion ProtectionThe Y version carries NEMA 4X anti-corrosion protection for locations with moderate corrosion demands, including areas affected by salt-laden air or acid rain. Hikvision classifies this model as moderate protection rather than its highest marine-grade category.
Local and Network RecordingSupports microSD cards up to 512 GB, NAS storage and Auto Network Replenishment for resilient recording designs.
Technical Specifications
Product Family
DS-2CD37C7G3T-LIZSU(Y)
Inventory SKU
DS-2CD37C7G3T-LIZSUY
Image Sensor
1/1.8-inch Progressive Scan CMOS
Maximum Resolution
4608 × 2592 at up to 20 fps
Australian 50 Hz Frame Rates
20 fps at 4608 × 2592; up to 25 fps at 3840 × 2160 and lower supported resolutions
Lens
2.7–13.5 mm motorised varifocal, DC iris, maximum F1.2 aperture
Field of View
Horizontal 102°–44°; vertical 54°–25°; diagonal 123°–51°
Minimum Illumination
Colour: 0.0008 lux at F1.2, AGC on; 0 lux with supplementary light
Supplementary Lighting
850 nm infrared and white light, up to 40 m
Wide Dynamic Range
130 dB WDR
Analytics
Person and vehicle classification, perimeter protection and face capture
Audio
Arrayed dual-microphone, environmental noise filtering, 1 line input and 1 line output
Alarm Interfaces
2 inputs and 2 outputs
Local Storage
microSD/microSDHC/microSDXC card, up to 512 GB
Network Compatibility
ONVIF Profiles S, T and G; ISAPI, SDK and ISUP
Power
12 VDC, maximum 16.2 W; PoE+ IEEE 802.3at Class 4, maximum 18 W
Protection
IP67 weather resistance, IK10 impact resistance and NEMA 4X anti-corrosion protection
Operating Conditions
−30°C to 60°C; humidity 95% or less, non-condensing
Dimensions / Weight
Ø 141 × 112 mm; approximately 850 g
Frequently Asked Questions
What does the Y version mean?The Y version adds NEMA 4X anti-corrosion protection. Hikvision rates this model for moderate anti-corrosion requirements, not its highest coastal or chemical-plant protection category.
Can the viewing angle be adjusted remotely?Yes. The motorised 2.7–13.5 mm varifocal lens can be adjusted remotely during installation to refine the field of view.
How does Smart Hybrid Light work?It combines infrared and white supplementary lighting. Installers can select from three lighting modes to suit discreet monitoring, colour detail and event-triggered illumination requirements.
Does the camera support audio?Yes. It includes an arrayed dual-microphone for audio capture, environmental noise filtering, plus line-level audio input and output interfaces.
See Smart Hybrid Light in Action
Watch this official Hikvision Australia & New Zealand overview to see how infrared, white-light and Smart modes adapt to changing night-time conditions.
Downloads & Resources
Technical Datasheet Quick Start Guide
User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Ultra Series · 8MP · Smart Hybrid Light · DarkFighter S
Detailed 4K Coverage with Flexible Motorised Zoom
The Hikvision DS-2CD3686G2HT-LIZSY is an 8MP motorised varifocal bullet camera for entrances, driveways, car parks, warehouses and perimeter areas where both a wide overview and closer subject detail may be required. Its 2.7–13.5 mm lens can be adjusted remotely during setup, while DarkFighter S imaging and Smart Hybrid Light help retain useful detail as lighting changes.
Resolution
8MP (3840 × 2160)
Lens
2.7–13.5 mm motorised varifocal
Night Lighting
IR + white light, up to 60 m
Protection
IP67 · IK10 · NEMA 4X (-Y)
What This Camera Does for You
Choose the View During InstallationStart wide to cover a larger area, then zoom in remotely to concentrate detail on a gate, doorway, lane or other priority zone. Autofocus makes final setup easier.
More Useful AlertsDeep-learning analytics can classify humans and vehicles for supported motion and perimeter rules, helping reduce nuisance alerts from unrelated movement.
Adaptive Night CoverageSmart Hybrid Light combines infrared and white supplementary lighting. You can favour discreet IR monitoring, colour detail with white light, or event-driven lighting to suit the site.
Built for Exposed LocationsThe metal housing is weather resistant and vandal resistant. The -Y version also carries NEMA 4X anti-corrosion protection for sites with moderate corrosion demands.
Key Specifications
Official model
DS-2CD3686G2HT-LIZSY (2.7–13.5 mm)
Image sensor
1/1.8-inch progressive scan CMOS
Maximum resolution
3840 × 2160 (8MP)
Lens and field of view
Motorised 2.7–13.5 mm; 112.3° to 41.2° horizontal
Minimum illumination
Colour: 0.0028 lux at F1.2; 0 lux with supplementary light
Supplementary light
Infrared and white light, up to 60 m
Wide dynamic range
130 dB WDR
Analytics
Human and vehicle classification; perimeter protection; face capture; people counting
Audio
1 line input and 1 line output; external microphone/speaker required
Alarm interfaces
2 inputs and 2 outputs
Local storage
microSD/microSDHC/microSDXC, up to 512 GB
Power
12 VDC or PoE+ (IEEE 802.3at)
Protection
IP67 weather resistance, IK10 impact resistance, NEMA 4X anti-corrosion (-Y)
Frequently Asked Questions
What is the benefit of the 2.7–13.5 mm lens?It lets the installer choose between a wide scene and a tighter, more detailed view without physically changing the lens. This is useful when the exact viewing angle cannot be confirmed until the camera is mounted.
How does Smart Hybrid Light work?The camera combines infrared and white light. Depending on the selected mode, it can monitor discreetly in IR, provide colour detail with white light, or switch lighting behaviour when a configured event occurs.
Does it have a built-in microphone or speaker?No. This model provides line-level audio input and output for compatible external audio equipment. Choose a model with a built-in microphone or speaker if you need audio without extra hardware.
What does the Y suffix mean?The Y version adds NEMA 4X anti-corrosion protection. Hikvision classifies it for environments with moderate anti-corrosion requirements; site conditions and mounting hardware should still be assessed for demanding coastal or industrial installations.
See Smart Hybrid Light in Action
Watch this official Hikvision Australia & New Zealand overview to understand how infrared, white-light and Smart modes behave at night.
Downloads & Resources
Technical Datasheet User Manual
Official Hikvision Stock
Australian Warranty Support
Australia-Wide Delivery
Hikvision Ultra Series · SmartIP
Sleek Black Aesthetic with Enterprise AI & Anti-Corrosion Protection
The Hikvision DS-2CD3666G2HT-LIZSY (2.7-13.5mm) Black is an elite 6 MP motorised varifocal bullet network camera engineered for high-profile architecture, corporate facilities, coastal infrastructure, and industrial properties demanding a stealthy black finish. Powered by Hikvision's Embedded Open Platform (HEOP 2.0) with 1.5 TOPS AI computing capacity and DarkFighter sensor technology, this camera delivers ultra-sharp 3200 × 1800 resolution images. Featuring NEMA 4X anti-corrosion protection, IK10 vandal resistance, and adaptive Smart Hybrid Light technology, it delivers uncompromised 24/7 intelligence in demanding environments.
Resolution / Sensor
6MP / 1/1.8" DarkFighter
Optics & Focal Length
2.7-13.5mm Motorised Zoom
Night Vision Range
60m IR & White Light
Protection Ratings
IP67 / IK10 / NEMA 4X
HEOP 2.0 Open Computing & Advanced Perimeter Analytics
The Hikvision DS-2CD3666G2HT-LIZSY Black incorporates HEOP 2.0, facilitating the direct deployment of custom deep learning apps for specialized video analytics like licence plate detection, facial recognition, and multi-target tracking. Equipped with true 120 dB Wide Dynamic Range (WDR), built-in audio I/O, alarm interfaces, and 5 stream support, it ensures continuous clarity across severe backlight and challenging perimeter layouts. Its motorised 2.7 to 13.5 mm lens allows effortless remote zoom and focus adjustments directly from your system interface.
Anti-Corrosion NEMA 4X Rating
Specially coated with a marine-grade anti-corrosion finish to withstand harsh, salty, acidic, and chemical environments like seaports, chemical plants, and coastal perimeters.
Smart Hybrid Light Illumination
Combines discrete IR and warm white supplement light up to 60 metres, automatically illuminating colour mode when security events are triggered for vital evidence identification.
Technical Specification Matrix
Camera Model
DS-2CD3666G2HT-LIZSY (Black)
Image Sensor
1/1.8" Progressive Scan DarkFighter CMOS
Max. Resolution
3200 × 1800 (6 Megapixel) @ 25/30 fps
Lens Type & FOV
Motorised 2.7–13.5 mm (Horizontal: 112.3° to 41.2°)
Min. Illumination
Colour: 0.0028 Lux @ (F1.2, AGC ON), 0 Lux with Light
Supplement Light Range
Up to 60 m IR & White Light (Smart Hybrid Light)
Wide Dynamic Range
120 dB True WDR
Audio & Alarm I/O
1 input / 1 output Line Audio, 2 inputs / 2 outputs Alarm
Local Edge Storage
Built-in microSD/SDHC/SDXC slot, up to 512 GB
Housing & Protection
All-Metal Black Finish / IP67 / IK10 / NEMA 4X (NEMA 250-2014)
Frequently Asked Questions
What are the main advantages of the black finish model?
The sleek black housing blends seamlessly into dark architectural exteriors, iron structures, modern facades, and dark soffits where standard white cameras would be overly conspicuous.
What does the NEMA 4X rating signify?
The NEMA 4X certification ensures the camera housing is protected against corrosion, windblown dust, rain, splashing water, hose-directed water, and ice formation in extreme coastal or industrial settings.
How far does the night vision illumination reach?
The camera's Smart Hybrid Light system provides up to 60 metres of infrared and white light illumination, automatically adapting based on rule triggers and ambient lighting conditions.
Does this camera support third-party AI algorithm integration?
Yes, built on the HEOP 2.0 platform with dedicated AI chip hardware, developers can deploy specialized custom analytics directly onto the camera edge.
Technical Datasheet User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Pro Series
Choose the Right Reader for Your Door
The Hikvision DS-K1107AM Series provides dependable 13.56 MHz MIFARE card authentication in a slim, IP65-rated reader. Choose the standard DS-K1107AM for card access, or the DS-K1107AMK when a built-in 12-key keypad is required for PIN or card-and-PIN entry.
Card Technology
13.56 MHz MIFARE
Connectivity
RS-485, Wiegand & OSDP
Outdoor Protection
IP65 Rated
Keypad Option
12 Keys on DS-K1107AMK
DS-K1107AM vs DS-K1107AMK
Both models share the same core reader platform. The keypad is the main difference, so select the model that matches your authentication requirements.
Feature
DS-K1107AM
DS-K1107AMK
Reader type
MIFARE card reader
MIFARE card reader with keypad
Authentication
Card
Card, PIN or card + PIN*
Keypad
No
12 keys (0–9, * and #)
Card frequency
13.56 MHz
13.56 MHz
Reading distance
Up to 50 mm
Up to 50 mm
Communication
RS-485, Wiegand and OSDP
RS-485, Wiegand and OSDP
Protection
IP65
IP65
Dimensions
115 × 44 × 22 mm
115 × 44 × 22 mm
*Available authentication modes depend on the connected access controller and system configuration.
Built for Reliable Access Control
Fast MIFARE ReadingA 32-bit processor provides responsive 13.56 MHz card authentication with a reading distance of up to 50 mm.
Flexible IntegrationSupports RS-485, Wiegand 26/34 and OSDP for integration with compatible Hikvision access controllers.
Clear User FeedbackPower and status indicators plus a built-in buzzer provide immediate feedback during authentication.
Indoor or Outdoor UseThe IP65-rated housing, tamper support and watchdog design suit protected indoor and outdoor entry points.
Shared Technical Specifications
Models / SKUs
DS-K1107AM; DS-K1107AMK
Processor
32-bit high-speed processor
Card technology
MIFARE 1, 13.56 MHz, ISO 14443-A
Communication
1 × RS-485 with OSDP support; Wiegand selectable by DIP switch
Indicators and buzzer
Power indicator, status indicator and built-in buzzer
Security
Tamper support and self-recovering watchdog
Power
12 VDC, ≤ 2 W
Operating conditions
−20°C to 65°C; 10% to 90% humidity, non-condensing
Protection
IP65
Installation
Wall mounting with screws; gang box mounting is not supported
Which model should I choose?Choose DS-K1107AM for straightforward MIFARE card access. Choose DS-K1107AMK when you also need a keypad for PIN entry.
Can these readers be installed outdoors?Yes. Both models are IP65 rated and operate from −20°C to 65°C when installed correctly.
Which cards are compatible?Both readers support 13.56 MHz MIFARE 1 credentials compliant with ISO 14443-A.
Do both models support OSDP?Yes. Both support OSDP over RS-485, as well as selectable Wiegand communication.
DS-K1107AM Datasheet
DS-K1107AMK Datasheet
DS-K1107 Series User Manual
Official Hikvision Stock
3-Year Australian Warranty
Australia-Wide Delivery
Hikvision Ultra Series
Enterprise-Grade Access Security with Web-Based Management
The Hikvision DS-K2702X-P is an advanced 2-door access controller designed for demanding commercial, industrial, and high-density enterprise environments. Built on a resilient Linux architecture, this controller operates seamlessly via native web browser management, eliminating the need for standalone client software installations. Engineered for scalable deployments, it natively manages 2 doors and can expand to control up to 126 doors across complex facilities such as commercial towers, transit hubs, and banking centers.
Door Capacity
2-Door Native / Max 126 Doors
User & Event Storage
100k Users / 600k Events
Interface Integration
7x RS-485 & 4x Wiegand
Power & Climate
12 VDC / Battery Backup
Advanced Infrastructure Redundancy & Professional Access Logic
Featuring downstream RS-485 redundancy wiring across 5 dedicated communication channels, the Hikvision DS-K2702X-P 2-Door Controller ensures dual-bus loop isolation to prevent communication loss in critical security installations. It natively supports high-level access functions including 32 anti-passback routes, 32 multi-door interlocking groups, multi-factor authentication (card, fingerprint, PIN), and direct fire alarm relay integration for automatic emergency lock release.
Redundant Downstream Communication
Features 5-channel downlink RS-485 interface options that allow dual-bus loop connections with physical isolation, ensuring uninterrupted credential verification and signal stability across all sub-modules.
Embedded Web Configuration
Simplifies deployment by offering comprehensive system setup, access group management, time schedules, and diagnostic health monitoring directly through standard web browsers without requiring local management software.
Technical Specification Matrix
Camera Model
DS-K2702X-P
Operating System
Linux Embedded
Linked Door Capacity
Native: 2 Doors | Extended: Up to 126 Doors (via 62 RS-485 modules)
User & Credential Capacity
100,000 Users | 200,000 Cards | 10,000 Fingerprints
Event Log Storage
600,000 Offline Event Records
Reader Compatibility
4x RS-485 (OSDP Protocol) & 4x Wiegand (26/34-bit)
I/O Interfaces
2 Lock Relays, 2 Exit Buttons, 2 Door Contacts, 4 Alarm Inputs, 4 Alarm Outputs, 1 Fire Input, 1 Tamper
Network Interface
1x RJ45 10/100/1000 Mbps Self-Adaptive Ethernet
Power & Consumption
12 VDC ± 15%, Max. 72 W | Integrated Battery Charging/Discharging Support
How do I configure the Hikvision DS-K2702X-P controller?
The unit features a built-in web server. You can access all network settings, user privileges, access schedules, and diagnostic logs using any standard web browser by entering the unit's IP address.
How many doors can be expanded from this single unit?
While managing 2 doors out of the box, it can expand up to 126 total doors by connecting up to 62 Hikvision DS-K2M002X sub-access modules over RS-485 bus loops.
Does this controller support power backup in case of mains outage?
Yes, the controller includes integrated battery management terminals that support automatic charging and seamless switchover to standard 12V backup batteries during power failures.
What reader protocols are supported by this unit?
It supports up to 4 Wiegand readers (standard 26/34 format or custom) and up to 4 RS-485 readers utilizing secure OSDP protocol.
Technical Datasheet Quick Start Guide
User Manual
Official Hikvision Stock
3-Year Commercial Warranty
Aust-Wide Delivery
Hikvision Pro Series · 6MP DarkFighter · AcuSense · 80m IR · 120dB WDR · IK10
Hikvision 6MP DarkFighter Bullet
Hikvision DS-2CD2T66G2H-4I — 6MP DarkFighter AcuSense Fixed Bullet Camera with 80 m IR & IK10 Vandal Housing
The Hikvision DS-2CD2T66G2H-4I is a 6 MP AcuSense fixed bullet camera from Hikvision's Pro Series — the workhorse for commercial and residential perimeters where you need true monochrome night vision at long range and reliable human-and-vehicle classification without paying DeepinView pricing. A 1/1.8" progressive CMOS with DarkFighter ultra-low-light technology delivers clean imaging at just 0.003 lux, and when the light goes below that the 80 m Smart IR illuminator kicks in — one of the longest IR distances in the 6 MP Hikvision range. AcuSense H/V classification filters false alarms on animals, foliage and precipitation so your NVR only pushes notifications on actual humans and vehicles. Available in 2.8 mm wide-angle or 4 mm narrower-view lens, in White or Black finish. Backed by 3-year Australian warranty from CCTV Guru.
Resolution
6 MP · 3200 × 1800
Lens Options
2.8 mm (101°) or 4 mm (87°) · F1.6
Low-Light
DarkFighter · 0.003 lux · 80 m IR
WDR
120 dB True WDR
AcuSense AI
Human + Vehicle Classification
Protection
IK10 · IP67 · White or Black
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
Choose Your Lens — 2.8 mm Wide Angle or 4 mm Narrower View
Same camera body, same 6 MP DarkFighter sensor — pick the lens focal length that suits your scene. The 2.8 mm wide-angle covers a broader area with a shorter effective distance; the 4 mm narrower-view gives you more detail at longer range with a tighter frame. Both are F1.6 fixed-focus with an 80 m IR illuminator built in.
Lens Comparison — 2.8 mm vs 4 mm
2.8 mm Wide Angle (White SKU: DS-2CD2T66G2H-4I · Black SKU: DS-2CD2T66G2H-4I-BLK)
Horizontal FOV ~101° · Vertical ~55° · Diagonal ~122°. Best for entry doors, garages, small yards, driveways up to ~10 m, wall-mounted corners covering a broad approach. Wider, less-detailed at distance.
4 mm Narrower View (White SKU: DS-2CD2T66G2H-4I-4MM)
Horizontal FOV ~87° · Vertical ~46° · Diagonal ~105°. Best for longer driveways, side fences, boundary lines, car parks, commercial forecourts — the extra reach gives you readable faces and plates at 10-25 m where the 2.8 mm would only give a body-in-frame shot.
Rule of thumb: if the target is closer than ~8 m and you need broad coverage, go 2.8 mm. If the target is 8-25 m away and you want identification-level detail, go 4 mm. Not sure? Pick the 2.8 mm — you can always crop in on 6 MP footage.
What Makes This Camera Worth Its Price
1/1.8" Sensor + DarkFighter Ultra-Low-Light
The larger 1/1.8" progressive CMOS (vs 1/2.8" on entry cameras) collects more light per pixel — brighter night image, cleaner shadows, less noise. DarkFighter processing pushes minimum illumination to 0.003 lux before IR kicks in.
80 m Smart IR — One of the Longest in Hikvision 6 MP
80 metres of IR with Smart IR intensity + angle auto-adjust. Useful for long rural driveways, large commercial forecourts, and open-yard perimeters where cheaper cameras (30-40 m IR) leave dark zones at the far end.
120 dB True WDR
Real hardware WDR, not digital — handles the classic Australian problem scenes: sunlit garage door with dark interior, driveway staring into afternoon sun, front verandah under harsh backlight. Both bright and dark regions stay legible.
AcuSense — Human / Vehicle Classification
Onboard deep-learning filters false alarms on animals, wind-blown leaves, rain and headlight flare. Your NVR only fires an alert when the camera actually sees a person or vehicle — dramatically reduces phantom notifications.
IK10 Vandal-Proof + IP67 Weatherproof
Metal housing rated for 20-joule impact (IK10) and full dust-tight + immersion protection (IP67). Suitable for wall-mounted commercial installs where the camera is within reach of vandals, and outdoor mounting in rain, dust and full sun.
H.265+ Smart Compression
Reduces bandwidth and storage by ~50 % vs H.265 alone, and up to 75 % vs H.264. A single 6 MP stream at ~25 fps uses ~4-6 Mbps with H.265+ — a 4 TB HDD holds ~30-45 days on 4 cameras.
Where This Camera Belongs
Residential Driveways & Front Yards
4 mm covers a typical AU suburban driveway from front door to street. Number-plate readable at 10-15 m. 80 m IR blows out the phantom shadow zone at the street kerb that 30 m IR cameras can't reach.
Commercial Forecourts, Loading Docks
Long-range 4 mm variant with 80 m IR — reads plates and identifies drivers at the back of the loading bay, while illuminating enough of the yard to see vehicle movements through the frame.
Rural Properties & Farm Yards
The 80 m IR reach is what makes this camera work at rural scale — a house-corner mount can cover the driveway all the way out to the gate. 6 MP resolution means readable faces on approach.
Warehouse & Industrial Perimeter
IK10 rating survives contact with forklifts, pallet racking and industrial machinery. AcuSense classification stops the NVR from waking up every time a fork truck moves inside the yard.
Body Corp / Strata Common Areas
Black finish blends into modern architectural facades; white finish for older render / weatherboard. Vandal-rated for accessible ground-floor mounting near common entries.
Retail & Hospitality Exteriors
2.8 mm wide-angle covers a shopfront + full footpath in one frame. AcuSense filters foot traffic from actual approaches, letting the NVR flag genuine after-hours activity.
Technical Specifications
DS-2CD2T66G2H-4I · Full Specifications
SKU — White · 2.8 mm
DS-2CD2T66G2H-4I
SKU — White · 4 mm
DS-2CD2T66G2H-4I-4MM
SKU — Black · 2.8 mm
DS-2CD2T66G2H-4I-BLK
Camera Type
Hikvision Pro Series · 6MP AcuSense Fixed Bullet · DarkFighter · IK10
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
3200 × 1800 (6 MP)
Main Stream
25/30 fps @ 3200 × 1800 · 2560 × 1440 · 1920 × 1080
Lens Options
2.8 mm F1.6 (H 101°) or 4 mm F1.6 (H 87°) — fixed focal length
Field of View (2.8 mm)
Horizontal 101° · Vertical 55° · Diagonal 122°
Field of View (4 mm)
Horizontal 87° · Vertical 46° · Diagonal 105°
Min. Illumination
Colour: 0.003 lux @ F1.6 (AGC ON) · 0 lux with IR
Wide Dynamic Range
120 dB True WDR
Shutter Speed
1 s to 1/100,000 s
IR Distance
Up to 80 m · Smart IR intensity + angle auto-adjust
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG
Smart Functions
AcuSense: Human + Vehicle classification · Line crossing · Intrusion · Region entrance · Region exiting
Additional Analytics
Motion detection · Video tampering · Face detection · Scene change · Audio exception
Alarm I/O
1 input · 1 output
Ethernet
1× RJ-45 10/100 Mbps
Protocols
IPv4/IPv6 · HTTPS · 802.1X · QoS · FTP · SMTP · UPnP · SNMP · DNS · DDNS · NTP · RTSP · TCP · UDP · IGMP · DHCP · Bonjour · SRTP · TLS
Storage
microSD / SDHC / SDXC up to 256 GB · NAS · ANR (Auto Network Replenishment)
API
ISAPI · Hikvision SDK · ONVIF (Profile S / G / T)
Client Software
iVMS-4200 · Hik-Central Professional · Hik-Connect
Power
12 VDC · PoE 802.3af Class 3 (max ≈ 8 W)
Weatherproof
IP67 (IEC 60529)
Vandal Resistance
IK10 (20-joule impact resistance)
Operating Temperature
−40 °C to +60 °C · humidity ≤95 %
Dimensions / Weight
Ø 88 × 231.1 mm · ~600 g
Finish Options
White (2.8 mm + 4 mm) or Black (2.8 mm only)
Warranty
3-Year Australian Warranty (back-to-base)
Pair with a Hikvision M-Series or AcuSeek NVR
DS-7604NI-M1/4P — 4CH · 4 PoE
Four-channel M-Series NVR — ideal for a single-family home with 4 of these bullets on the perimeter. View DS-7604NI-M1/4P →
DS-7608NI-M2/8P — 8CH · 8 PoE · 2 HDD
Eight channels with 2 HDD bays — commercial small-site and larger residential. View DS-7608NI-M2/8P →
DS-7616NI-M2/16P — 16CH · 16 PoE · 2 HDD
Mid-tier commercial site with up to 16 bullets on the perimeter. View DS-7616NI-M2/16P →
DS-7608NXI-I2/8P/VPro — AcuSeek AI NVR
For sites that want natural-language search across recordings. Full AcuSense metadata indexing. View AcuSeek NVR →
Frequently Asked Questions
What's the difference between the 2.8 mm and 4 mm lens?The 2.8 mm is a wider view — 101° horizontal FOV. The 4 mm gives you narrower reach — 87° horizontal FOV — but each pixel covers less scene, so detail at 10-25 m is better. Same sensor, same IR range, same AcuSense AI on both.
Why is Black only offered in 2.8 mm?Hikvision's supply of the black-finish version is limited to the 2.8 mm SKU (DS-2CD2T66G2H-4I-BLK). If you need a 4 mm in black, contact us — we sometimes have alternative black-finish Hikvision bullets in the same 6 MP range that might suit.
Does it need a special PoE switch?No — PoE 802.3af Class 3 (max ~8 W). Runs on any standard Hikvision NVR PoE port or generic 802.3af PoE switch. Also accepts 12 VDC for legacy or off-grid installs.
Does AcuSense really cut false alarms?Yes — typical reduction is 80-90 % vs a motion-only camera. The camera classifies the target as human, vehicle or "other" before firing an alarm. Rain, foliage, insects, animals and passing headlights get filtered out.
What's the actual IR range in practice?Hikvision rates it at 80 m under ideal conditions (dark sky, no ambient reflection). In practice — Australian suburban driveway with some ambient street glow — expect 50-70 m of usable IR. Still one of the longer IR distances in the 6 MP range at this price point.
Can I integrate with a non-Hikvision VMS?Yes — the camera speaks ONVIF Profile S, G and T and RTSP. Compatible with Milestone XProtect, Genetec, Exacq, Immix and most other AU VMS platforms. Note that AcuSense metadata is only fully indexed on Hikvision NVRs.
Downloads & Resources
DS-2CD2T66G2H Datasheet
Quick Start Guide
User Manual
Order the Hikvision DS-2CD2T66G2H-4I from CCTV Guru
Select your lens (2.8 mm wide-angle or 4 mm narrower-view) and finish (White or Black — Black is 2.8 mm only) from the dropdowns above. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch, project pricing for multi-camera installs and specialist pre-sales advice from our Sydney team. Request a free quote or contact our Australian team.
Hikvision ACCESS CONTROL ACCESSORIES
Professional Surface Mounting Base for Access Terminals
The Hikvision DS-KAB502-S2 surface mounting box provides a clean, robust, and reliable wall-mounting interface engineered specifically for the Hikvision DS-K1T502 series access control terminals. Built to streamline commercial entry deployments, this surface back box eliminates complex wall recessing while ensuring structural stability and protected cable routing across office lobbies, multi-residential entry points, and high-density secure facilities.
Mounting Type
Surface Mount Base
Material Build
Durable SECC Steel
Compatibility
DS-K1T502 Series
Dimensions
176 × 80 × 22.8 mm
Engineered for Fast Retrofits & Cable Protection
Designed as a purpose-matched mounting solution, the Hikvision DS-KAB502-S2 simplifies installation where recessed wall cutting is impractical or prohibited. Constructed from high-quality electrolytic zinc-coated cold-rolled steel (SECC), it maintains structural integrity and corrosion resistance over long-term operation. The low-profile back box securely encloses wire connections, mitigating cable strain and preventing tampering while preserving a sleek commercial finish.
Precision Alignment & Quick Installation
Custom-engineered mounting hole patterns directly match DS-K1T502 terminals, eliminating custom bracket fabrication and significantly cutting installation time for security technicians.
Rugged SECC Steel Construction
Manufactured with commercial-grade SECC steel to shield terminal wiring connections against accidental impact, wear, and physical tampering in busy access environments.
Technical Specification Matrix
Camera / Device Model
DS-KAB502-S2
Product Type
Surface Mounting Box / Wall Mounting Bracket
Compatible Devices
Hikvision DS-K1T502 Series Access Control Terminals
Material
SECC (Electrolytic Zinc-Coated Cold-Rolled Steel)
Dimensions (W × H × D)
176 mm × 80 mm × 22.8 mm (6.9" × 3.1" × 0.9")
Weight
Approx. 145.1 g (0.32 lb)
Mounting Method
Wall Surface Mount
Compatibility Note
Not compatible with rain shield DS-KAB502-S1
Which devices are compatible with the DS-KAB502-S2?
This surface mounting box is specifically designed for Hikvision DS-K1T502 series access control terminals and intercom units.
What material is used in the construction of this mounting back box?
The DS-KAB502-S2 is crafted from high-strength SECC steel (electrolytic zinc-coated cold-rolled steel), offering long-term durability and corrosion resistance.
Can this mounting box be used alongside the DS-KAB502-S1 rain shield?
No, this surface back box is not compatible with the DS-KAB502-S1 rain shield. Please verify your installation environment requirements before selection.
Why choose surface mounting over recessed installation?
Surface mounting avoids cutting or chasing walls, making it ideal for retrofits, solid concrete surfaces, or decorative walls where recessed mounting is impractical.
Technical Datasheet
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision DS-K1T502 Series
Commercial Grade Weather Protection for Access Control Terminals
The DS-KAB502-S1 is a high-durability protective rain shield engineered specifically for Hikvision DS-K1T502 series access control terminals. Constructed from heavy-duty Electro-Galvanized Cold-Rolled Steel (SECC), this protective accessory safeguards delicate authentication devices against driving rain, direct UV glare, dust, and physical impact. Designed for high-density commercial entries, perimeter gates, apartment building foyers, and outdoor staff access points, it provides an intentional, sleek installation finish while significantly extending hardware service life in harsh environments.
Material Build
SECC Steel Shell
Compatibility
DS-K1T502 Series
Environment
Weather Resistant
Form Factor
188.6 x 85 x 42mm
Seamless Surface Integration & Model-Matched Fit
Rather than using generic universal brackets, opting for the hikvision-ds-kab502-s1-protective-rain-shield ensures precise dimensional alignment with Hikvision terminal geometry. The shield's engineered canopy overhang diverts water away from the optical scanner and card reader interface, preventing water streak interference during biometrics processing. At a light weight of just 242.5g and a tight profile depth of 42mm, it installs neatly onto standard doorframes, concrete masonry, and hollow wall partitions without adding unnecessary bulk or obscuring terminal sightlines.
Industrial SECC Construction
Manufactured using high-grade SECC steel, providing superior structural integrity, wear resistance, and long-term protection against harsh exterior conditions and everyday physical impacts.
Optimized Canopy Angle
Custom-contoured overhang minimizes direct glare on card readers and reduces water drop accumulation across optical lenses, guaranteeing unhindered operation in stormy conditions.
Technical Specification Matrix
Camera Model
DS-KAB502-S1
Product Type
Protective Rain Shield / Surface Mount Bracket
Compatible Device Series
Hikvision DS-K1T502 Series Access Control Terminals
Construction Material
SECC Steel
Dimensions (H x W x D)
188.6 mm x 85.0 mm x 42.0 mm (7.4" x 3.3" x 1.7")
Item Weight
242.5 g (0.53 lbs)
Mounting Type
Surface Wall Mounting
Application Environment
Indoor / Outdoor Weather Protected Installation
Which access control models are compatible with this protective shield?
The DS-KAB502-S1 is custom-engineered specifically for the Hikvision DS-K1T502 access control terminal series (including card, biometric, and video models).
Does installing this rain hood affect terminal screen visibility or reader range?
No. The canopy overhang is precision-contoured to protect the terminal face from weather elements while leaving all optical sensors, keypads, screen areas, and card readers fully visible and accessible.
Is additional hardware required for mounting?
The shield aligns directly with standard wall mounting points for the DS-K1T502 terminal series, allowing straightforward installation using basic mounting hardware onto flat surfaces.
What material is used to prevent rust and corrosion?
It is fabricated from SECC (Electro-Galvanized Cold-Rolled Steel), offering high durability and corrosion resistance suitable for outdoor and commercial entryways.
Technical Datasheet
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
DAHUA LIGHT SERIES · 27" 100Hz · 24/7 SURVEILLANCE MONITOR
DHI-LM27-L200N 27" Full HD 100Hz LED Monitor — Australian Stock & 3-Year Warranty
The Dahua DHI-LM27-L200N is a purpose-built 27-inch Full HD CCTV monitor from Dahua's Light Series, engineered for continuous 24/7 surveillance operation. A 1920×1080 VA panel at 100 Hz over HDMI with 178°/178° viewing angles, 3000:1 static contrast and 250 cd/m² ELED backlight delivers stable, judder-free playback from any recorder or IP camera live view — ideal for guardhouses, retail counters, IT rooms and small business control rooms.
Slim 51.9 mm depth, standard VESA 100×100 mount pattern, external 12 VDC power adapter and HDMI + VGA inputs make it a drop-in replacement for legacy PC monitors that aren't rated for round-the-clock use.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Why this monitor for CCTV
Built for 24/7 duty
Rated for 7×24 h continuous operation — unlike consumer PC monitors that overheat or fail early when left on live-view for months. The right chassis for a guardhouse or unattended NVR display.
100 Hz over HDMI
100 Hz refresh smooths fast pans and cursor motion when you scrub timelines. Response time OD 5 ms keeps moving subjects clean without ghost trails.
VA panel, wide angle
178° horizontal + 178° vertical viewing so the picture stays true from any position around the counter. 3000:1 static contrast keeps night footage crisp instead of hazy.
Universal signal inputs
HDMI 1.4 (1080p @ 100 Hz) + VGA (1080p @ 60 Hz) covers current Dahua/Hikvision/UNV NVRs, older analogue DVRs and any PC-based VMS — no dongles.
Slim + VESA-mount ready
Just 51.9 mm deep and 3.8 kg net weight with a VESA 100×100 pattern — wall mount above a desk, arm-mount over a counter, or leave it on the included base.
Low power, low heat
18.5 W typical and <0.5 W standby off the external 12 VDC / 3 A supply. Runs cool 24/7 with no fan noise.
Display & picture
Screen size
27" (16:9)
Panel technology
VA LCD, ELED backlight
Native resolution
1920 × 1080 (Full HD)
Refresh rate
100 Hz over HDMI · 60 Hz over VGA
Response time
OD 5 ms
Brightness
250 cd/m² (typ.)
Contrast ratio
3000:1 (static)
Colour depth
8-bit
Colour gamut
72% NTSC (typ.)
Viewing angle
178° horizontal · 178° vertical
Duty cycle
7 × 24 h continuous operation
Bezel colour
Black
Connectivity & mount
Video inputs
1 × HDMI 1.4 · 1 × VGA
Built-in speakers
No
Audio jack
No
USB / DisplayPort
None
VESA mount pattern
100 × 100 mm
Included stand
Yes — desktop base
Power, physical & environment
Power supply
12 VDC / 3 A (external adapter, included)
Power consumption
14 W (basic) · 18.5 W (typical) · 19 W (max)
Standby power
< 0.5 W
Dimensions (W×H×D)
615.0 × 365.7 × 51.9 mm (without base)
Net weight
3.8 kg
Operating temperature
0 °C to +40 °C
Operating humidity
10% – 85% RH
Storage temperature
−20 °C to +60 °C
Certifications
CE EMC · CE LVD · CE ERP
Best used for
Guardhouse & reception
Continuous NVR live-view display beside a front-desk operator — runs 24/7 with a wall-mount arm.
Retail counter & back office
Compact 27" screen for split-view monitoring at POS, IT room or manager's desk.
Small business control room
Pair two side-by-side on a VESA arm for a 2-up 1080p wall — sub $ per pixel vs a dedicated video wall.
Legacy DVR replacement
VGA input keeps older HDCVI/analogue DVRs going while HDMI supports current 4K NVRs downscaled to 1080p.
Works with
Dahua NVRs & XVRs
HDMI output from every current Dahua WizSense / WizMind NVR and XVR series — native 1080p on this panel.
Hikvision & HiLook recorders
HDMI 1.4 input matches all M-Series and DeepinMind NVR HDMI outs at 1080p.
UNV & other IP NVRs
Standard HDMI signalling — works with any recorder that outputs 1080p or lower on HDMI.
Older analogue DVRs
VGA fallback for legacy HDCVI / analogue installs still on VGA-only outputs.
Installation notes
Included in box: monitor, desktop base, HDMI cable, external 12 VDC power adapter, QSG.
No built-in speakers — drive audio from your NVR's dedicated audio output to external speakers if you need sound at the display.
For wall/arm mount, source a VESA 100×100 bracket (not included). Screw specification per QSG.
HDMI cable run length: keep under 10 m using a standard HDMI 1.4 cable for reliable 1080p @ 100 Hz. For longer runs, use an HDBaseT or fibre HDMI extender.
Operating temperature is 0 – 40 °C — not suitable for un-cooled outdoor kiosks in AU summer without shade + ventilation.
Frequently asked questions
Is this monitor rated for 24/7 CCTV use?Yes — Dahua rate the LM27-L200N for 7×24 h continuous operation. That's the key difference vs a consumer desktop monitor, which is only warrantied for ~10 hrs/day of use.
What's the highest resolution it supports?Native 1920×1080 (Full HD) at 100 Hz over HDMI. If your NVR outputs 4K, it will downscale to 1080p on this panel.
Does it have built-in speakers?No — there are no speakers and no headphone jack on this model. Use your NVR's dedicated audio output to external powered speakers.
Can I wall-mount it?Yes — standard VESA 100×100 mm pattern. Any VESA 100 wall mount or monitor arm will fit. Bracket not included.
What's the difference between HDMI and VGA on this monitor?HDMI 1.4 supports 1080p at 100 Hz. VGA runs at 60 Hz max. Use HDMI wherever possible for smoother playback.
Will it work with my old analogue DVR?Yes — the VGA input keeps older HDCVI/analogue DVRs working. If your DVR has HDMI out, use HDMI instead for cleaner picture.
What warranty does it come with?3 years Australian warranty, supported locally by CCTV Guru. Return direct to us for RMA — no overseas shipping required.
Is the power supply included?Yes — a 12 VDC / 3 A external adapter is included in the box. Plugs into standard AU wall power via IEC cable.
Downloads
Datasheet (PDF)
Full user manual and installation guide are supplied in-box with the monitor (paper QSG + QR code to the online manual). Contact CCTV Guru if you need a digital copy for pre-sales review.
Hikvision EasyIP 2.0+ Series
4MP AcuSense In-Ceiling Recessed Dome IP Camera with Built-in Microphone
Designed for architecturally sensitive commercial interiors, luxury retail boutiques, corporate offices, and hospitality venues, the Hikvision DS-2CD2E43G2-U (2.8mm) delivers high-definition 4MP (2560 × 1440) resolution in a ultra-discreet, flush-mount form factor. Engineered to blend seamlessly into drop ceilings and plasterboard surfaces, this recessed dome camera combines minimal visual intrusion with Hikvision's powerful AcuSense deep-learning target classification—providing accurate, real-time perimeter protection and audio monitoring without disrupting interior aesthetics.
Resolution / Optics
4MP (2560 × 1440) @ 2.8mm
Form Factor & Mounting
Recessed In-Ceiling / Flush
AI Intelligence
AcuSense Human/Vehicle
Audio & Dynamic Range
Built-in Mic / 120dB WDR
Deep Learning Target Filtering & Integrated Real-Time Audio
Significantly reducing false trigger notifications caused by moving shadows, air currents, or lighting shifts, the DS-2CD2E43G2-U incorporates AcuSense deep-learning analytics to differentiate between human subjects and vehicles with pinpoint precision. Equipped with a built-in microphone for synchronized real-time audio capture, 120 dB True WDR for balancing bright windows and shadowed interior areas, ultra-efficient H.265+ video encoding, and local microSD card backup up to 512 GB, this PoE-powered recessed dome provides comprehensive internal security without bulky hardware.
Architectural Flush-Mount Design
Installs directly into ceiling tiles or drywall with built-in retention spring clips, keeping the profile extremely low and maintaining clean interior lines in modern commercial spaces.
120 dB True WDR & Built-in Audio Capture
Master challenging indoor lighting near glass facades or bright entranceways while capturing localized environment audio with the integrated noise-filtering internal microphone.
Technical Specification Matrix
Camera Model
DS-2CD2E43G2-U
Image Sensor & Resolution
1/3" Progressive Scan CMOS; 4MP (2560 × 1440) @ 25/30fps
Lens Options & Field of View
2.8 mm Fixed Lens (Horizontal FOV: 103°, Vertical FOV: 55°, Diagonal FOV: 123°)
Low Light Sensitivity
0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR/Ambient light
Form Factor & Installation
In-Ceiling Recessed Dome; Integrated Spring Clip Mount
Wide Dynamic Range (WDR)
120 dB True WDR
Smart Analytics
AcuSense AI: Line Crossing & Intrusion Detection with Human/Vehicle Classification
Audio Capabilities
Built-in Microphone; Monaural Audio Compression (G.711/G.722.1/MP2L2/PCM)
On-Board Storage
MicroSD/SDHC/SDXC Slot, up to 512 GB
Environment & Housing
Indoor Recessed Plastic Housing
Power Supply & PoE
12 VDC ± 25% (Max 4.2 W) or PoE (802.3af, Class 3, Max 5.3 W)
Frequently Asked Questions
How is the DS-2CD2E43G2-U installed into a ceiling?
The camera features integrated spring-loaded ceiling clamps. After cutting a standard hole in a ceiling tile or drywall panel, the camera inserts directly and locks securely into place flush against the surface.
Does this camera have built-in Infrared (IR) night vision LEDs?
No, the DS-2CD2E43G2-U is designed specifically for low-profile indoor ambient lighting environments. It utilizes an ultra-sensitive sensor (0.005 Lux) and 120 dB WDR to capture clear images without bulky external IR LED rings.
Can this camera record ambient room sound?
Yes, it features an integrated internal microphone that captures clear mono audio, providing synchronized audio evidence along with the 4MP video feed.
What is the main benefit of AcuSense technology in an indoor camera?
AcuSense filters out false alarms caused by indoor environmental factors like ceiling fan motion, shifting sunlight through windows, or moving curtains, sending alerts only when a human or vehicle is detected.
Technical Datasheet Quick Start Guide
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Pro Series
8MP 4K DarkFighter Extended-Range Bullet IP Camera with Active Deterrence Strobe & Audio Alarm
Engineered for critical perimeter protection across large-scale commercial facilities, industrial logistics hubs, and high-value yards, the Hikvision DS-2CD2T86G2H-IS2U/SL (2.8mm) captures crystal-clear 8MP 4K Ultra HD resolution (3840 × 2160) powered by Hikvision's flagship DarkFighter low-light architecture. Functioning as a proactive perimeter defense shield with powerful 60-metre Smart IR range, this heavy-duty bullet camera combines deep-learning target classification with real-time active deterrence—triggering red and blue flashing LED strobe lights alongside a 120 dB audible warning or custom voice prompt the moment an unauthorized intrusion is detected.
Resolution / Optics
8MP 4K (3840 × 2160) @ 2.8mm
Low Light & Deterrence
DarkFighter & Strobe/Audio
AI Intelligence
AcuSense Human/Vehicle
Protection / Night Vision
IP67 Weather / 60m IR
AcuSense Deep Learning & Dual-Microphone Environmental Noise Filtering
Built to eliminate costly false alarms, the DS-2CD2T86G2H-IS2U/SL uses AcuSense deep-learning algorithms to isolate human and vehicle activity from non-threatening environmental motion like sway, rain, or small animals. For comprehensive audio-visual evidence, an integrated dual-microphone array filters out harsh ambient noise (such as wind and traffic) to capture crisp directional audio. Supported by 120 dB True WDR for high-contrast lighting compensation, ultra-efficient H.265+ compression, onboard microSD storage up to 512 GB, and dedicated physical Alarm/Audio I/O interfaces, it offers an enterprise-grade security package.
Active Visual Strobe & 120 dB Audible Warning
Stop threats before damage occurs. Upon a confirmed perimeter breach, the camera activates high-visibility flashing red and blue LED lights while sounding an integrated 120 dB speaker alarm or voice prompt.
DarkFighter 8MP Low-Light Imaging & 60m Smart IR
Combining an ultra-sensitive 1/1.8" sensor with DarkFighter technology and an F1.0 super-aperture, it captures rich colour detail in low ambient light, backed by 60-metre IR illumination in complete darkness.
Technical Specification Matrix
Camera Model
DS-2CD2T86G2H-IS2U/SL
Image Sensor & Resolution
1/1.8" Progressive Scan CMOS; 8MP 4K (3840 × 2160) @ 24/25/30fps
Lens & Field of View
2.8 mm Fixed Lens (Horizontal FOV: 105°, Vertical FOV: 56°, Diagonal FOV: 130°)
Low Light Sensitivity & IR Distance
DarkFighter (0.0008 Lux @ F1.0, AGC ON); Smart IR up to 60 metres
Active Deterrence Features
Flashing Red & Blue Strobe Light; Built-in 2 W Speaker (120 dB Sound Pressure)
Wide Dynamic Range (WDR)
120 dB True WDR
Smart Analytics
AcuSense AI: Line Crossing, Intrusion, Region Entrance/Exiting with Human/Vehicle Target Filtering
Audio & Alarm Interfaces
Dual Microphones; Speaker; 1 Audio In/Out; 1 Alarm In/Out (24 VDC/VAC, 1 A)
On-Board Storage
MicroSD/SDHC/SDXC Card Slot, up to 512 GB
Housing & Protection Rating
IP67 Weatherproof Standard; Rugged All-Metal Body & Bracket
Power Supply & Consumption
12 VDC ± 25% (Max 10.5 W) or PoE (802.3at, Class 4, Max 17 W)
Frequently Asked Questions
What makes 8MP 4K resolution essential for active deterrence surveillance?
8MP (3840 × 2160) provides 4 times the resolution of 1080p, allowing security personnel to digitally zoom into distant targets along perimeter lines without pixelation, making subject identification clearer for legal evidence.
How do the active strobe light and audible alarms trigger?
When the camera's AcuSense engine detects a human or vehicle crossing a designated virtual boundary, it automatically activates the flashing red and blue LED strobe lights and sounds a high-decibel warning message or siren.
Does this camera support physical alarm inputs and outputs?
Yes, the DS-2CD2T86G2H-IS2U/SL includes physical Alarm I/O terminal blocks (1 input / 1 output), enabling direct connection to external security relays, gate triggers, or third-party strobe units.
What is the benefit of having dual built-in microphones?
Dual microphones allow the camera to use noise-cancellation algorithms, suppressing background environmental sound (like wind or highway noise) to record clear, foreground voice audio.
Technical Datasheet Quick Start Guide
User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Video Intercom Accessories
Ergonomic Desk Mounting Solution for Video Intercom Indoor Stations
The DS-KABH8350-T is a premium tabletop mounting bracket purpose-built for Hikvision DS-KH8350 series indoor video intercom stations. Engineered specifically for reception desks, office workstations, security consoles, and residential side tables, this mounting accessory provides a stable, tilted display platform that transforms traditional wall-mounted indoor monitors into flexible, desk-ready communication terminals.
Compatibility
DS-KH8350 Series Monitors
Material & Build
SUS304 Stainless Steel
Form Factor
Angled Desktop Mount
Protection
Corrosion-Resistant Finish
Durable SUS304 Construction with Precision Angle Alignment
Crafted from high-grade SUS304 stainless steel, the Hikvision DS-KABH8350-T offers exceptional structural rigidity and resistance to daily wear and corrosion. Its precision-engineered inclination angle positions the intercom touchscreen for optimal viewing and touch responsiveness, reducing glare from overhead commercial lighting while ensuring effortless hands-free call handling and video previewing.
Seamless Cable & Structural Integration
Designed with dedicated pass-through routing channels, the DS-KABH8350-T keeps network and power wiring neatly concealed behind the mounting face. This prevents unsightly clutter on corporate reception desks and protects connection ports from strain or accidental disconnection.
Industrial Stainless Steel Durability
Unlike light plastic alternatives, the heavy-gauge SUS304 stainless steel construction provides a weighted, non-slip base that stays anchored in place during heavy touchscreen interaction in high-traffic administrative or security environments.
Technical Specification Matrix
Bracket Model
DS-KABH8350-T
Compatible Devices
Hikvision DS-KH8350 Series Indoor Stations (e.g., DS-KH8350-TE1)
Primary Material
SUS304 Stainless Steel
Mounting Type
Tabletop / Desktop Stand
Working Temperature
-10 °C to +55 °C (14 °F to 131 °F)
Working Humidity
10% to 90% (Non-condensing)
Dimensions (W x H x D)
194.5 mm × 106.3 mm × 115.8 mm (7.66" × 4.19" × 4.56")
Application Environment
Indoor (Reception, Security Desk, Office, Home)
Frequently Asked Questions
Which Hikvision indoor stations are compatible with the DS-KABH8350-T?
This table stand is specifically engineered to fit the Hikvision DS-KH8350 series indoor video intercom terminals, such as the DS-KH8350-TE1 model.
Is hardware required to secure the monitor to the bracket?
Yes. The bracket aligns directly with the standard mounting points on the back of the compatible indoor station for a secure, wiggle-free attachment using the included fixing screws.
Can the bracket be used outdoors?
No. The DS-KABH8350-T is designed strictly for indoor deployment on desks, counters, or tabletop surfaces within controlled ambient environments.
Does this stand require drilling into the desk surface?
No. It functions as a stable, free-standing desktop mount that allows easy repositioning without damaging commercial office furniture or counter surfaces.
Technical Datasheet
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Video Intercom Accessories
Professional Desktop Mounting Solution for Video Intercom Indoor Stations
The DS-KABH6350-T is an engineered desktop stand designed specifically for Hikvision indoor video intercom monitors. Built for environments where wall mounting is impractical or undesirable—such as reception desks, security control stations, office counters, and luxury apartment interiors—this bracket provides an optimal viewing angle and ultra-stable support. Constructed from heavy-gauge SECC zinc-coated steel with integrated silica gel contact pads, it ensures long-term structural durability while shielding both your intercom unit and desk surfaces from scratches.
Mounting Type
Desktop / Tabletop Stand
Compatibility
DS-KH6350 & KH6351 Series
Build Material
SECC Steel & Silica Gel
Operating Temp
-10 °C to +55 °C
Seamless Cable Integration & Surface Protection
Engineered to preserve clean aesthetics in high-visibility commercial and residential areas, the DS-KABH6350-T table bracket includes integrated rear cable passthroughs to route power and Ethernet cabling seamlessly. Its precision-cut SECC metal body provides a rigid base preventing tipping during touch interactions, while non-slip silica gel cushioning dampens vibration and holds the indoor station securely without scratching delicate furniture surfaces.
Electrogalvanized SECC Steel Construction
Manufactured from cold-rolled electrogalvanized steel (SECC), offering superior structural integrity, impact resistance, and rust protection for long-term commercial installations.
Silica Gel Cushioning & Cable Management
Integrated high-grade silica gel padding prevents scratches on the monitor body and tabletop, while discreet rear cutouts keep network and power cabling hidden and strain-relieved.
Technical Specification Matrix
Product Model
DS-KABH6350-T
Compatible Intercom Models
DS-KH6350-TE1, DS-KH6350-WTE1, DS-KH6351-TE1, DS-KH6351-WTE1, DS-KH7300EY-WTE2
Primary Material
SECC Steel (Electrogalvanized Cold-Rolled Steel)
Protective Elements
Silica Gel Non-Slip Contact Pads
Dimensions (W × H × D)
97.2 mm × 89.22 mm × 76.6 mm
Working Temperature
-10 °C to +55 °C (14 °F to 131 °F)
Mounting Type
Desktop / Tabletop Surface Mount
Colour / Finish
Commercial Matte Finish
Which Hikvision indoor stations are compatible with this bracket?
The DS-KABH6350-T is tailored specifically for the Hikvision DS-KH6350 and DS-KH6351 7-inch indoor video intercom series (including DS-KH6350-TE1, DS-KH6350-WTE1, DS-KH6351-TE1, DS-KH6351-WTE1) and DS-KH7300EY models.
Does this bracket require surface screws for installation?
No surface screwing is required. The bracket is designed as a free-standing desktop unit with non-slip silica gel pads that maintain stability on countertops, desks, and glass tables.
How are network cables managed with this desktop stand?
The bracket features pre-cut routing access points that allow Ethernet (PoE) or power cables to feed directly out the back of the bracket for a tidy cable-managed appearance.
Will the metal frame mark or scratch sensitive desktop surfaces?
No. Soft silica gel protective contact points prevent direct metal-to-surface contact, protecting delicate timber, veneer, or polished stone surfaces.
Technical Datasheet
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Pro Series
6MP DarkFighter Bullet IP Camera with Active Deterrence Strobe & Audible Warning
Engineered for high-risk commercial and residential perimeters, the Hikvision DS-2CD2066G2H-I2U/SL delivers high-definition 6MP (3200 × 1800) video powered by DarkFighter low-light architecture. Available in versatile 2.8mm (105° FOV) and 4mm (78° FOV) focal lengths, this compact mini bullet camera transforms passive surveillance into active prevention. When an intrusion is detected, the camera immediately activates red and blue strobe lights and triggers a customizable voice alarm or siren, deterring unauthorized access before security breaches occur in loading docks, outdoor storage lots, vehicle yards, and remote property lines.
Resolution / Lens
6MP @ 2.8mm or 4mm
Low Light & Active Defense
DarkFighter & Strobe/Audio
AI Intelligence
AcuSense Human/Vehicle
Protection / Audio
IP67 Weatherproof / Dual Mic
AcuSense Deep Learning & Dual-Microphone Environmental Noise Filtering
Eliminate false alarms caused by rain, falling leaves, or moving shadows with the integrated AcuSense deep-learning AI inside the DS-2CD2066G2H-I2U/SL. By classifying human and vehicle targets with precision, the camera streams relevant alerts directly to your monitoring software or mobile device. For complete situational awareness, it features an advanced dual-microphone array that filters out ambient background noise like wind and vehicle engine hums to record crystal-clear audio. Supported by 120 dB True WDR, 40-metre Smart IR range, efficient H.265+ compression, and on-board microSD storage up to 512 GB, it provides non-stop, high-grade security for demanding site conditions.
Active Strobe Light & Custom Voice Warnings
Instantly respond to perimeter intrusions with flashing red and blue LED strobe alerts accompanied by automated or custom audio messages, deterring potential intruders prior to property entry.
DarkFighter Ultra-Low Light & Dual Microphones
Capture detailed, colour-rich imagery in light conditions down to 0.003 Lux, paired with dual directional microphones for ambient noise suppression and clear audio evidence collection.
Technical Specification Matrix
Camera Model
DS-2CD2066G2H-I2U/SL
Image Sensor & Resolution
1/1.8" Progressive Scan CMOS; 6MP (3200 × 1800) @ 25/30fps
Lens Options & Field of View
2.8 mm (Horizontal: 105°, Vertical: 57°) | 4 mm (Horizontal: 78°, Vertical: 44°)
Min. Illumination & Night Vision
DarkFighter (0.003 Lux @ F1.6); Smart IR Range up to 40 metres
Active Deterrence
Visual Red & Blue Flashing Strobe Light; Built-in Speaker for Audio Warnings / Sirens
Wide Dynamic Range (WDR)
120 dB True WDR
Smart Analytics
AcuSense Deep Learning: Line Crossing, Intrusion, Region Entrance/Exiting with Human/Vehicle Target Classification
Audio Capabilities
Dual Built-in Microphones with Environmental Noise Suppression & Built-in Speaker
On-Board Storage
Built-in MicroSD/SDHC/SDXC Slot, up to 512 GB
Protection Rating & Enclosure
IP67 Weatherproof Standard; Full Metal Construction
Power Supply
12 VDC ± 25% or PoE (802.3af, Class 3)
Which lens option should I choose: 2.8mm or 4mm?
Select the 2.8mm lens if you need a wide 105° field of view for broad area coverage like open driveways or yard spaces. Choose the 4mm lens for a narrower 78° view that offers increased facial detail at longer detection distances along narrow fence lines or corridors.
How does Active Deterrence help prevent security incidents?
When the camera detects a classified human or vehicle intrusion, it triggers flashing strobe lights and plays sound warnings. This alerts intruders that they have been detected, deterring criminal behaviour before damage or entry occurs.
What is the benefit of the dual-microphone array?
The dual-microphone design uses directional sound sampling to filter out ambient background noise such as wind or environmental hums, ensuring crisp audio recording focused on nearby activity.
Can I customize the audio alarm messages?
Yes, you can select from preset warning sounds or upload custom voice audio clips through the camera web interface or Hik-Connect application to suit your site requirements.
Technical Datasheet Quick Start Guide
User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision TandemVu Series
4MP Dual-Channel TandemVu PTZ Camera with ColorVu Panoramic Lens & 4x Optical Zoom
Engineered for multi-scenario commercial surveillance and expansive area monitoring, the Hikvision DS-2SE3C404MWG-E/14 incorporates revolutionary TandemVu technology to capture both overall situational awareness and granular details simultaneously. Integrating a fixed 4MP ColorVu 2.0 panoramic channel alongside a 4MP pan-tilt-zoom channel with 4x optical zoom into a single compact housing, this dual-channel unit eliminates blind spots. Whether protecting commercial entryways, parking facilities, retail concourses, or perimeter boundary fencing, operators maintain continuous wide-angle coverage even while taking advantage of motorised optical tracking.
Resolution & Zoom
Dual 4MP (2560 × 1440) / 4x Zoom
Dual Night Illumination
30m ColorVu / 30m IR PTZ
AI Detection
AcuSense Human & Vehicle
Housing Rating
IP66 Weatherproof Standard
AcuSense Perimeter Analytics & Dual-Channel Synchronization
Beyond dual-camera optics, the DS-2SE3C404MWG-E/14 features Hikvision's AcuSense deep-learning engine across both channels to drastically minimise false triggers caused by environmental motion such as wind-blown foliage or rain. The fixed panoramic lens acts as an automated scout, detecting human or vehicle presence and commanding the PTZ channel to zoom in, lock on, and capture detail. Outfitted with a high-fidelity built-in microphone for synchronized audio verification, 120 dB True WDR for high-contrast backlit scene clarity, and H.265+ compression, this unit optimizes network bandwidth without compromising evidentiary quality.
ColorVu 2.0 24/7 Colour Panoramic Field
The upper panoramic lens incorporates an F1.0 super-aperture lens and warm white supplemental light to capture full-colour 4MP video 24/7, keeping overall contextual activity visible even in complete darkness.
AcuSense Target Classification & Active Linking
Deep-learning algorithms classify human and vehicle targets with precision. Panoramic analytics trigger target linkage to the PTZ module for automated close-up tracking, recording, and rapid forensic retrieval.
Technical Specification Matrix
Camera Model
DS-2SE3C404MWG-E/14
Panoramic Channel Spec
1/3" Progressive Scan CMOS; 4MP (2560 × 1440); 2.8 mm Fixed Lens (FOV 97°); ColorVu 24/7 Full-Colour
PTZ Channel Spec
1/2.8" Progressive Scan CMOS; 4MP (2560 × 1440); 2.8 to 12 mm Motorised Lens; 4x Optical / 16x Digital Zoom
Illumination Range
Panoramic: Warm White Light up to 30 m; PTZ: Smart IR up to 30 m
Wide Dynamic Range (WDR)
120 dB True WDR
Pan & Tilt Range
Pan: 0° to 350°; Tilt: 0° to 90°
Smart Analytics
AcuSense Deep Learning Target Classification (Human & Vehicle), Line Crossing, Intrusion Detection
Audio & On-Board Storage
Built-in Microphone; MicroSD/SDHC/SDXC Card Slot up to 512 GB
Environmental Rating
IP66 Weatherproof Standard; TVS 6000V Lightning & Surge Protection
Power Input
12 VDC ± 20% / PoE (802.3at, Class 4)
Frequently Asked Questions
What is the primary advantage of a TandemVu PTZ camera?
Traditional PTZ cameras lose wide-angle coverage when zoomed in. TandemVu solves this by using a fixed 24/7 wide-angle panoramic lens alongside the motorised PTZ lens, providing simultaneous wide-area oversight and zoomed target detail.
Does the DS-2SE3C404MWG-E/14 support full-colour night vision?
Yes, the panoramic channel features ColorVu technology with a warm white supplementary light that delivers full-colour 4MP video 24/7, while the PTZ channel uses adaptive smart IR illumination up to 30 metres.
Can I power this dual-channel camera using standard PoE?
Yes, the camera can be powered using Power over Ethernet+ (PoE+ 802.3at, Class 4) over a single network cable or via a conventional 12 VDC external power adapter.
How does AcuSense AI target classification assist security personnel?
AcuSense uses deep-learning algorithms to categorize movement into human, vehicle, or non-target events. This minimizes nuisance alarms caused by small animals or blowing foliage and allows faster recorded video searches.
Technical Datasheet Quick Start Guide
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision KH6 Series
Streamlined Residential Entry & Intercom Management
The DS-KH6110-WE1 is an entry-level 4.3-inch IP video intercom indoor station engineered to deliver intuitive, reliable access management for modern residential apartments, villas, and small commercial offices. Featuring a sleek white housing with a responsive capacitive touch display, the DS-KH6110-WE1 integrates seamless two-way audio communication with remote opening capabilities and mobile connectivity. Designed for fast deployment, this unit combines cost-effective hardware architecture with flexible network options to suit budget-conscious projects without compromising on core performance or user experience.
Display & Control
4.3" Touch (480×272)
Audio Processing
2-Way Noise Cancelled
Connectivity
Wi-Fi & 100M Ethernet
Power Architecture
Standard PoE / 12 VDC
Advanced Networking & Remote Control Integration
Engineered with versatile communication architecture, the hikvision-ds-kh6110-we1-4-3-ip-video-intercom-indoor-station supports standard SIP, TCP/IP, and RTSP protocols for unified integration across door stations and linked IP security cameras. Users can effortlessly view live camera feeds, answer incoming visitor calls, and unlock entryways directly from the station or remotely via the Hik-Connect mobile application. Equipped with 4 customizable touch buttons and standard IEEE 802.3af Power over Ethernet (PoE), installation is simplified to a single network cable run, reducing system overhead while maximizing operational reliability.
Customizable Quick Touch Controls
Features 9 total touch buttons, including 4 configurable shortcuts that allow occupants to instantly trigger unlock functions, call security, or access preferred camera views with a single tap.
Crystal-Clear Two-Way Audio
Integrated omnidirectional microphone and built-in loudspeaker utilize acoustic echo cancellation and hardware noise suppression for clear voice communication in dynamic indoor environments.
Technical Specification Matrix
Camera Model
DS-KH6110-WE1
Display Screen
4.3-inch Colorful TFT Capacitive Touch Screen (480 × 272 resolution)
Operating System
Embedded Linux Operating System
Audio Parameters
Built-in Omnidirectional Mic & Speaker, G.711 U/A, Noise Suppression & Echo Cancellation
Network Interfaces
1× RJ45 10/100 Mbps Adaptive Ethernet + Wi-Fi 802.11 b/g/n (2.4 GHz)
Communication Protocols
TCP/IP, SIP, RTSP, Hik-Connect P2P
Power Supply
IEEE 802.3af Standard PoE or 12 VDC (Power consumption ≤ 4 W)
Dimensions & Mounting
120 mm × 120 mm × 21 mm; Surface Wall or Table Mounting
How is the DS-KH6110-WE1 powered?
The unit can be powered using standard Power over Ethernet (IEEE 802.3af PoE) via a direct network connection or through a standard 12 VDC external power adapter.
Can I connect this indoor station to the Hik-Connect mobile app?
Yes, the station features built-in Wi-Fi and Ethernet connectivity, allowing complete remote access via the Hik-Connect app for answering calls and remotely opening doors.
How many extensions can be linked to this unit?
The DS-KH6110-WE1 supports linking up to 16 indoor extensions for multi-room communication within a single residence or office network.
Can I view external IP cameras on this screen?
Yes, through RTSP protocol integration, you can stream live video feeds from linked Hikvision door stations and compatible network security cameras directly on the 4.3" screen.
Technical Datasheet Quick Start Guide
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Ultra Series · Commerical Grade
Enterprise Multi-Authentication IP Video Intercom Station
The DS-KD9203-ME6 is a flagship IP facial recognition door station engineered by Hikvision for high-density residential towers, commercial office complexes, and gated facilities. Housed in a durable metallic enclosure with an IP65 ingress protection rating, it combines biometrics, RFID card verification, and direct numerical dialing into a streamlined access management terminal. Featuring dual 2 MP wide-angle optical sensors and a high-brightness 4.3-inch colour LCD display, this unit ensures crisp visual communication and anti-spoofing security at high-traffic entry points.
Resolution / Screen
Dual 2MP / 4.3" LCD
Auth Modes
Face, Card, PIN
Face Capacity
Up to 5,000 Users
Protection Rating
IP65 Weatherproof
Advanced Biometric Access & Network Integration
The Hikvision DS-KD9203-ME6 is powered by an embedded Linux OS to provide zero-latency local facial recognition with built-in anti-spoofing technology. Capable of storing up to 5,000 face templates and 50,000 M1 (13.56 MHz) RFID cards, it effortlessly manages entry permissions for thousands of occupants. Equipped with 120 dB Wide Dynamic Range (WDR) and built-in IR supplement lighting effective up to 3 metres, the terminal maintains accurate face detection even under severe backlight or nighttime outdoor conditions. Integrated web-based remote management, dual RS-485 interfaces, and 2 relay lock controls make it an adaptable hub for enterprise access topologies.
Deep Learning Facial Recognition
Equipped with dual 2MP optics and live body detection to eliminate photo and video spoofing, delivering rapid verification speed under varying light conditions.
Dual Relay Door Control
Includes 2 relay outputs (30 VDC, 2 A) allowing independent management of pedestrian gates, automatic doors, or turnstiles from a single terminal.
Technical Specification Matrix
Camera Model
DS-KD9203-ME6
Display Screen
4.3-inch Colorful LCD (800 × 480 Resolution)
Camera Sensor
2 × 2 MP HD Camera with 120 dB WDR
Supplement Light
IR Light, up to 3 m range
Authentication Modes
Face Recognition, Mifare Card (13.56 MHz), PIN Code
System Capacity
5,000 Faces, 50,000 Cards, 10,000 Users
Network & Control Interfaces
1x RJ-45 (10/100/1000 Mbps), 2x RS-485, 4x Alarm Input, 2x Lock Relays
Environmental Rating
IP65 Weatherproof, -30 °C to 60 °C Operating Temperature
How many doors can the DS-KD9203-ME6 control directly?
The unit features 2 integrated relay outputs (Max 30 VDC, 2A), enabling direct trigger and pulse control for up to two separate door strikes or gate actuators.
Does the camera perform effectively in low-light and high-glare environments?
Yes. It integrates 120 dB WDR along with IR supplement illumination, allowing clear image capture and biometrics up to 3 metres in total darkness or direct backlight.
Which RFID card formats are compatible with the built-in reader?
The door station has an integrated M1 card module operating on the 13.56 MHz Mifare standard, supporting up to 50,000 credentials.
How is the device configured and managed?
Configuration can be performed remotely via a standard Web browser, Hikvision iVMS-4200 software, or integrated into HikCentral management platforms.
Technical Datasheet Quick Start Guide
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision EasyIP Pro Series
Next-Generation 8MP 4K ColorVu Turret Camera with Smart Hybrid Light & AcuSense AI
Engineered for high-security commercial and perimeter protection applications, the Hikvision DS-2CD2387G3-LIS2UY/SRB (2.8mm) delivers ultra-high-definition 4K 8MP resolution with ColorVu 3.0 technology. Equipped with a large F1.0 aperture and an advanced sensor, this camera captures vibrant full-colour imagery day and night. Hikvision’s innovative Smart Hybrid Light system dynamically toggles between covert infrared illumination and supplementary warm white light upon human or vehicle detection, offering crystal-clear colour verification when events occur while maintaining a discreet profile during quiet hours.
Resolution / Optics
8MP (3840 × 2160) @ 2.8mm
Night Vision / Light
Smart Hybrid Light (IR/White)
AI Analytics
AcuSense Human/Vehicle
Protection / Housing
IP67 Weatherproof / Metal
Precision Perimeter Security Powered by Deep Learning AI
Beyond exceptional visual performance, the DS-2CD2387G3-LIS2UY/SRB features advanced AcuSense deep-learning algorithms designed to filter out up to 90% of false alarms triggered by foliage, rain, shadows, or animals. System operators receive actionable real-time alerts only when humans or vehicles cross defined boundaries. Integrated with a high-fidelity built-in microphone for synchronized audio-visual monitoring, 130 dB True WDR for high-contrast lighting balance, and efficient H.265+ compression to optimize bandwidth and storage, this turret camera sets a high standard for modern IP video surveillance.
ColorVu 3.0 & F1.0 Super-Aperture
Combining an F1.0 super-aperture lens with a high-performance image sensor, ColorVu technology maximizes available light to capture full-colour surveillance footage in near-total darkness without relying solely on bright spotlight illumination.
AcuSense False-Alarm Reduction & Built-in Audio
Deep-learning algorithms classify targets precisely to eliminate false triggers from environmental noise. An integrated microphone enables real-time situational audio capture alongside high-resolution video streams.
Technical Specification Matrix
Camera Model
DS-2CD2387G3-LIS2UY/SRB
Image Sensor & Max. Resolution
1/1.8" Progressive Scan CMOS; 8MP (3840 × 2160)
Focal Length & FOV
2.8 mm: Horizontal FOV 108.8°, Vertical FOV 56.4°, Diagonal FOV 134.3°
Lighting & Night Vision
Smart Hybrid Light (IR & Warm White Light); Up to 30 m Range
Wide Dynamic Range (WDR)
130 dB True WDR
Video Compression
H.265+ / H.265 / H.264+ / H.264 / MJPEG
Smart Features & Analytics
AcuSense Deep Learning: Human & Vehicle Target Classification, Line Crossing, Intrusion Detection
Audio Interface
Built-in Microphone for Real-Time Audio Security
On-Board Storage
Built-in MicroSD/SDHC/SDXC Slot, up to 512 GB
Operating Conditions & Protection
-30 °C to 60 °C (-22 °F to 140 °F); IP67 Weatherproof Rated; Metal Housing
Power Supply
12 VDC ± 25% or PoE (802.3af, Class 3)
Frequently Asked Questions
How does the Smart Hybrid Light feature work?
The camera uses IR light for invisible monitoring in dark conditions. When AcuSense detects a human or vehicle, the camera automatically switches to warm white light to capture full-colour event footage, returning to IR mode once the target leaves.
Does this camera record audio out of the box?
Yes, the DS-2CD2387G3-LIS2UY/SRB features a built-in microphone that captures clear environmental audio along with 8MP video without requiring an external microphone kit.
Can I power this camera over a single Ethernet cable?
Yes, the camera supports Power over Ethernet (PoE 802.3af), allowing power and data transmission through a single network cable, as well as a standard 12 VDC power connection.
Is this camera suitable for harsh outdoor conditions?
With an IP67 weather resistance rating and a durable metal housing, this camera is built to withstand heavy rain, dust, extreme heat, and freezing temperatures down to -30 °C.
Technical Datasheet Quick Start Guide
User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Ultra Series
Commercial-Grade Access Control & Multi-Modal Video Intercom
The DS-KV9503-WBE1 is Hikvision’s flagship Ultra Series IP facial recognition villa door station, engineered to deliver ultra-secure access control and high-definition video communication for luxury residences, commercial office buildings, and high-density multi-tenant environments. Featuring a sleek industrial metal housing and a bright 4.3-inch IPS capacitive touchscreen display, this station combines enterprise-grade biometric authentication with intuitive, multi-subscriber user interaction.
Resolution / Screen
Dual 2MP / 4.3" IPS Touch
Optics & Dynamic Range
120 dB WDR / IR Night
Network & Power
Wi-Fi & Standard PoE
Protection Rating
IP65 Weather / IK08 Vandal
Advanced Multi-Factor Authentication & Seamless Network Integration
Equipped with deep learning facial recognition algorithms capable of identifying authorized users in under 0.2 seconds with greater than 99% accuracy, the Hikvision DS-KV9503-WBE1 delivers versatile access control options including facial biometrics, Mifare 13.56 MHz RFID cards, temporary QR codes, PIN codes, and Bluetooth access. With built-in Wi-Fi and Ethernet connectivity, native Hik-Connect integration allows tenants to receive live video calls, communicate via full-duplex two-way audio, and remotely unlock entry points directly from smartphones.
Multi-Modal Biometric & Access Control
Supports up to 10,000 face templates, 20,000 registered users, and 100,000 RFID cards. Provides high throughput for multi-tenant and office environments while maintaining strict security via multi-factor authentication modes.
Vandal-Resistant Weatherproof Construction
Encased in an IK08 vandal-resistant alloy structure with IP65 weather sealing, operating seamlessly across temperatures from -40°C to +60°C. Designed for single-cable standard Power over Ethernet (PoE) deployment.
Technical Specification Matrix
Camera Model
DS-KV9503-WBE1
Display Screen
4.3-inch IPS Capacitive Touchscreen (800 × 480 Resolution, 425 cd/m²)
Camera & Lens
2 × 2 MP Dual Lens (H: 88°, V: 44°)
Wide Dynamic Range & IR
120 dB True WDR, Built-in IR Light (Up to 3 m)
Authentication Modes
Facial Recognition, Mifare Card (13.56 MHz), PIN, QR Code, Bluetooth
System Capacity
20,000 Users / 10,000 Faces / 100,000 Cards
Facial Recognition Speed
< 0.2 s per person (Accuracy Rate ≥ 99%)
Network & Interfaces
10/100 Mbps Ethernet, 2.4GHz Wi-Fi, 2 Relays, 4 Alarm Inputs, 1 RS-485
Protection & Power
IP65, IK08, Standard PoE (IEEE 802.3af) or 12 VDC
Can the DS-KV9503-WBE1 operate without an indoor station monitor?
Yes. The station natively supports direct call routing to the Hik-Connect mobile application via Wi-Fi or Ethernet, allowing users to receive calls and unlock doors from anywhere on smart devices.
How fast and reliable is the facial recognition feature?
The unit features deep learning biometrics capable of authenticating faces in under 0.2 seconds with an accuracy rate of over 99%, performing reliably even in low-light conditions using IR supplementation.
How is the unit powered during installation?
It supports Standard Power over Ethernet (PoE 802.3af), receiving power and data through a single network cable, or can be powered via a traditional 12 VDC power supply.
Is this door station suitable for harsh outdoor conditions?
Absolutely. It features an IP65 ingress protection rating against rain and dust, along with IK08 vandal resistance and an operating temperature range of -40°C to +60°C.
Technical Datasheet Quick Start Guide
Installation Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Smart Industrial Series
Rugged 8-Port Gigabit Industrial Smart Managed Hi-PoE Switch with 4 SFP Optical Uplinks
Engineered for mission-critical video surveillance networks, factory automation, and extreme outdoor cabinet deployments, the Hikvision DS-3T1512HP-SI-8P4F delivers uncompromising industrial-grade performance. Housed in an IP40-rated heavy-duty metal enclosure, this Layer 2 smart managed switch combines 8 Full Gigabit PoE RJ45 ports with 4 dedicated Gigabit SFP fibre optic slots for long-distance trunk backhauls. Ports 1 through 4 adopt the ultra-high-power IEEE 802.3bt Hi-PoE standard—supplying up to 90 W on a single port—allowing heavy-duty PTZ cameras, thermal imagers, and multi-sensor units to be powered directly over network cabling without external field power supplies.
Port Configuration
8 × 1G PoE + 4 × 1G SFP Fibre
Power & Standard
90 W Hi-PoE (802.3bt) / 300 W Budget
Transmission Range
300m Extended Range Mode
Industrial Protection
-40°C to 75°C & 6 kV Surge
ERPS Ring Redundancy & Smart Remote Topology Management
Built for extreme thermal conditions ranging from -40 °C to +75 °C, the DS-3T1512HP-SI/8P4F supports G.8032 ERPS (Ethernet Ring Protection Switching) to ensure sub-50ms network failover recovery in critical ring topologies. System administrators can remotely monitor network topology, inspect PoE power loads, execute port diagnostics, and receive real-time fault alerts via Hik-Partner Pro or Hik-Central Pro cloud platforms. Automated hardware PoE Watchdog continuously polls connected devices and automatically reboots frozen cameras without site visits. Dual redundant DC power inputs with hot backup guarantee unbroken operations during primary supply disruptions.
Quad 90 W IEEE 802.3bt Hi-PoE Ports & 300 W Budget
Ports 1 through 4 output up to 90 W per port using 802.3bt Hi-PoE technology, backed by a total 300 W PoE budget. Long Range mode extends power and data delivery up to 300 metres across Cat5e/Cat6 wiring.
IP40 Fanless Metal Shell & Dual Power Inputs
Hardened, fanless IP40 metal chassis withstands severe shock, vibration, and extreme temperature swings. Dual 48–57 VDC terminal block inputs provide hot-backup power redundancy for mission-critical installations.
Technical Specification Matrix
Switch Model
DS-3T1512HP-SI-8P4F
Network Interfaces
8 × Gigabit PoE RJ45 Ports, 4 × Gigabit SFP Fibre Slots
PoE Standard
Ports 1–4: IEEE 802.3af/at/bt (Hi-PoE); Ports 5–8: IEEE 802.3af/at
Max Output Power per Port
Ports 1–4: Up to 90 W; Ports 5–8: Up to 30 W
Total PoE Power Budget
300 W
Switching Capacity
56 Gbps (Whole-Device) / 24 Gbps (Port Performance)
Packet Forwarding Rate
41.66 Mpps (Whole-Device)
Redundancy & Loop Prevention
G.8032 ERPS, IEEE 802.1D STP, IEEE 802.1w RSTP
Operating Temperature & Protection
-40 °C to +75 °C (-40 °F to +167 °F); 6 kV Surge; IP40 Metal Shell
Power Input & Mounting
48 to 57 VDC Dual Inputs with Hot Backup; DIN-Rail or Desk Mounting
Frequently Asked Questions
What equipment can be powered by the 90 W Hi-PoE ports?
Ports 1 to 4 support IEEE 802.3bt Hi-PoE up to 90 W per port, making them ideal for high-draw hardware like outdoor PTZ speed domes with internal heaters, multi-sensor panos, and illuminators.
Does this switch come with an included power supply?
Industrial switches utilize external 48–57 VDC DIN-rail power supplies (such as Mean Well NDR-240-48 or NDR-480-48) connected to its terminal blocks, allowing power capacity selection based on total system PoE load.
How does G.8032 ERPS ring protection benefit industrial security networks?
G.8032 ERPS creates redundant ring network topologies that automatically recover from fibre optic or copper link failures in less than 50 milliseconds, ensuring uninterrupted camera feeds.
Can I monitor this switch remotely via Hik-Partner Pro?
Yes, the switch integrates natively with Hik-Partner Pro and Hik-Central Pro, enabling technicians to inspect visual topology, check PoE consumption, perform cable health tests, and power-cycle ports remotely.
Technical Datasheet Quick Start Guide
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Industrial Series
Heavy-Duty 240W 48V Industrial DIN Rail Power Supply
Ensure uninterrupted operation across critical security infrastructure and industrial networks with the Hikvision NDR-240-48. Designed for demanding commercial and industrial enclosures, this high-performance 240W single-output power supply converts universal AC input voltages into a stable 48 VDC output. Engineered with an ultra-slim metal housing to conserve valuable enclosure rail space, it delivers continuous power to PoE network switches, security controllers, PTZ cameras, and edge computing equipment deployed in extreme environments.
Power & Output
240W / 48V DC / 5A
AC Input Range
90 to 264 VAC Universal
Operating Efficiency
Up to 88.5% High Efficiency
Protection Suite
Short Circuit / Overload / OVP / Temp
Built-in Active PFC & TS-35 Rail Mountability
Engineered for maximum electrical stability, the NDR-240-48 features built-in active Power Factor Correction (PFC) to maintain power efficiency and comply with strict industrial power standards. Its robust metal chassis easily snaps onto standard TS-35/7.5 or TS-35/15 DIN rails, drastically reducing installation time in control panels and outdoor NEMA-rated field cabinets. With convection cooling operating from -20°C to +70°C, this power supply provides dependable operation without requiring active fan ventilation.
Slimline Metal Enclosure Design
Featuring a narrow 63mm width, this power unit maximizes space on crowded DIN rails, allowing security integrators to fit more transmission components, circuit breakers, and terminal blocks within a single enclosure.
Comprehensive Electrical Protections
Includes automated protection against short circuits, overloads, overvoltage, and over-temperature conditions, safeguarding connected surveillance hardware against grid fluctuations and field electrical anomalies.
Technical Specification Matrix
Power Supply Model
NDR-240-48
Rated Power Output
240 W
DC Output Voltage
48 VDC
Rated Current
5 A
Input Voltage Range
90 to 264 VAC / 127 to 370 VDC
Efficiency (Typ.)
88.5%
Voltage Adjustment Range
48 to 55 VDC
Mounting Format
DIN Rail TS-35/7.5 or TS-35/15
Operating Temperature
-20°C to +70°C (-4°F to +158°F)
Dimensions (W × H × D)
63 mm × 125.2 mm × 113.5 mm
Frequently Asked Questions
Can the output voltage be adjusted on the NDR-240-48?
Yes, the front panel includes an adjustable DC voltage potentiometer allowing fine-tuning of the output voltage between 48 VDC and 55 VDC to account for long cable runs.
Is active cooling required for this power supply?
No, the unit relies on free air convection cooling within its rugged metal chassis, allowing fanless operation across a wide temperature range from -20°C to +70°C.
What equipment can be powered by this 48V power supply?
It is designed to power industrial PoE switches, hardened media converters, access controllers, and 48V security equipment mounted inside DIN rail field cabinets.
Does this unit feature Power Factor Correction (PFC)?
Yes, it includes built-in active PFC (Power Factor Correction), providing an optimized power factor under full load to reduce harmonic distortion and energy losses.
Technical Datasheet
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision IP Intercom Series
Comprehensive Villa Security with HD Video Access Control
The DS-KIS606-P IP Video Intercom Kit delivers an all-in-one perimeter security and access control solution tailored for residential homes, villas, and small commercial offices. Anchored by a high-definition 2MP outdoor door station and a sleek 4.3-inch indoor station monitor, this kit ensures seamless visitor communication, remote lock release, and real-time visual verification. Engineered for simple setup and dependable daily operation, the system enables property owners to manage entryway calls directly from the indoor monitor or remotely through smart devices.
Resolution
2MP 1080p HD
Field of View
131° Horizontal
Connectivity
Wi-Fi & Standard PoE
Protection
IP65 Weatherproof
Advanced Integration & Mobile Control with Hik-Connect
Designed for flexible networking, the DS-KIS606-P kit incorporates 2.4 GHz Wi-Fi connectivity and standard IEEE 802.3af PoE power support across system components. With built-in noise suppression and echo cancellation algorithms, two-way audio conversations remain crisp and intelligible regardless of surrounding ambient noise. The outdoor station features an integrated Mifare card reader supporting up to 10,000 cards for convenient keyless entry, while instant mobile notifications and live preview streaming via the Hik-Connect application keep you connected to your entryways anywhere in the world.
Ultra-Wide 131° Lens with 120 dB WDR
Capture expansive doorway angles without missing critical peripheral activity. Equipped with 120 dB True WDR and 3-metre IR light supplementation, the door station provides clear video quality under extreme backlight conditions and pitch-black nocturnal environments.
Versatile Keyless Entry & Lock Control
Featuring a built-in 13.56 MHz Mifare proximity card reader and relay control output, the outdoor panel functions as both an intercom and an access controller. Unlock connected electronic door locks directly via access cards, the indoor monitor, or the Hik-Connect mobile application.
Technical Specification Matrix
Intercom Kit Model
DS-KIS606-P
Included Components
DS-KV6113-PE1(C) Door Station, DS-KH6110-WE1 Indoor Station, Rain Shield, Power Supply
Door Station Camera
2MP HD Camera (1920 × 1080p resolution)
Field of View (FOV)
Horizontal: 131°, Vertical: 78°
Dynamic Range & Night Vision
120 dB True WDR, IR Supplement Light up to 3 metres
Indoor Station Display
4.3-inch colorful TFT screen (480 × 272 resolution) with 9 touch buttons
Audio Capabilities
Two-way audio with built-in mic/speaker, noise suppression & echo cancellation
Access Control Capacity
Built-in Mifare reader (13.56 MHz), supports up to 2,000 users & 10,000 cards
Network & Wireless
10/100 Mbps Ethernet, Wi-Fi 802.11 b/g/n (Indoor Station), TCP/IP, RTSP, SIP
Power Supply & Protection
Standard IEEE 802.3af PoE / 12 VDC; Outdoor unit IP65 weatherproof rated
Can I receive video calls on my smartphone when I'm away from home?
Yes. The DS-KIS606-P kit integrates with the Hik-Connect mobile app. When a visitor presses the door station call button, call alerts and live video streams are pushed directly to your smartphone for remote viewing and two-way talk.
How are the door station and indoor monitor powered?
Both system devices support standard Power over Ethernet (IEEE 802.3af PoE) for single-cable power and network transmission, as well as local 12 VDC power adapters.
Is the outdoor door station weather resistant for direct outdoor installation?
Yes. The DS-KV6113-PE1(C) outdoor door station features an IP65 ingress protection rating and comes equipped with a protective rain shield, ensuring reliable operation in rain and dusty conditions.
Can additional indoor monitors be added to the system?
Yes. The kit supports expansion up to 16 linked indoor extensions, allowing you to install multiple monitors across different floors or rooms within the property.
Technical Datasheet Quick Start Guide
Installation Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision AX Hybrid Pro Series
Commercial Security Expansion with High-Density Zone Integration
The DS-PM1-I8O2-H is a high-performance wired zone expander specifically engineered for the HikvisionAX Hybrid Pro intrusion alarm control panel. Designed for demanding commercial, retail, and residential installations requiring reliable hardwired detector integration, the DS-PM1-I8O2-H expands overall system capacity while delivering robust, tamper-resistant perimeter protection and centralized output control across long-distance cable runs.
Zone Capacity
8 Hardwired Inputs
Bus Protocol
Dual Speed-X (900m)
ECL Protection
3EOL Multi-State
Auxiliary Output
12VDC / 500mA Power
Advanced Speed-X Bus Communication & Cascade Topology
Utilizing proprietary high-speed RS-485 architecture, the Hikvision DS-PM1-I8O2-H establishes a stable, interference-resistant connection to the control panel at distances up to 900 metres. Equipped with dual Speed-X bus ports (1 input and 1 output), the module supports direct expansion cascading, allowing installers to link subsequent expanders along a single bus line up to another 900m without complex intermediate hubs. Comprehensive 3EOL wiring configurations deliver enhanced signal detection for alarm triggering, anti-masking, short circuits, and tamper monitoring across every zone.
3EOL Signal & Tamper Monitoring
Supports sophisticated 3EOL resistor wiring (Alarm 1kΩ, Tamper 1kΩ, Fault 2.2kΩ) to distinguish between legitimate intrusion signals, physical enclosure tampering, wire masking, and line shorts. Front and rear anti-tamper protection ensures immediate panel alerts if the module is opened or unmounted.
On-Board Collector Outputs & Aux Power
Features 2 collector outputs for triggering external relay modules, strobes, or sirens alongside a dedicated 12 VDC / 500mA auxiliary power output. This eliminates the need for external power supplies when running short-range wired motion sensors or beam detectors.
Technical Specification Matrix
Camera / Expander Model
DS-PM1-I8O2-H
Hardwired Zone Inputs
8 On-board Wired Zones
Collector Outputs
2 On-board Open Collector Outputs (Connects to relay modules)
Communication Interface
2x Speed-X Bus (1 Control Panel Input, 1 Expander Cascade Output)
Maximum Transmission Distance
Up to 900 m per Speed-X segment
EOL Wiring Support
3EOL Connection (Alarm: 1kΩ, Tamper: 1kΩ, Fault: 2.2kΩ)
Auxiliary Power Output
9 to 12 VDC, Maximum 500 mA
Power Input & Current
11 to 24 VDC; Max 119 mA @ 12 VDC (Quiescent: 45 mA @ 12 VDC)
Enclosure & Dimensions
Plastic Housing, 110 mm × 155 mm × 32 mm, Weight: 252.5 g
Which Hikvision main control panels are compatible with this expander?
The DS-PM1-I8O2-H is designed specifically for compatibility with the Hikvision AX Hybrid Pro intrusion alarm control panel series using Speed-X bus technology.
How far can I place the expander from the main control panel?
The Speed-X bus protocol supports wiring distances of up to 900 metres from the control panel to the expander. An additional 900 metres can be extended when cascading to the next expander via the output Speed-X port.
Does this expansion module power external detectors?
Yes, it features 1 auxiliary power output providing 9 to 12 VDC at up to 500 mA, which can directly power connected hardwired motion detectors or sensors.
What types of zone states can the DS-PM1-I8O2-H detect?
Thanks to 3EOL connection support, the module can simultaneously detect zone alarm, tamper state, sensor masking, wiring fault, and short-circuit conditions.
Technical Datasheet Installation Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Transmission Series
High-Power 8-Port Unmanaged Hi-PoE Switch with Dual Gigabit Uplinks
Streamline high-power IP camera installations, PTZ speed domes, and edge surveillance networks with the Hikvision DS-3E0310HP-E(C). Engineered to deliver reliable power and data transmission in plug-and-play environments, this Layer 2 unmanaged switch features 8 Fast Ethernet PoE ports alongside 2 dedicated Full Gigabit RJ45 uplink ports. Ports 1 and 2 conform to the ultra-high-power IEEE 802.3bt Hi-PoE standard, supplying up to 90 W on a single port to drive heavy-duty outdoor heating PTZs and access control panels with ease.
Port Configuration
8 × 10/100M PoE + 2 × 1G Uplink
Power Delivery
90 W Hi-PoE (Ports 1-2) / 110 W Budget
Transmission Range
300m Extended Mode Support
Protection & Self-Healing
6 kV Surge & PoE Watchdog
Hardware DIP Switch Control & Automated Camera Recovery
Built for maximum reliability in harsh installation sites, the DS-3E0310HP-E(C) incorporates hardware DIP switches for instant feature toggling without software setup. Engage Long Range mode to extend power and data transmission up to 300 metres on ports 1 through 8 over Cat5e/Cat6 cabling. Turn on Port Isolation to prevent broadcast storms and insulate camera feeds from internal network sniffing. With built-in hardware PoE Watchdog, the switch continuously checks connected IP cameras and automatically performs a port power reset if a camera stops responding, preventing unnecessary maintenance callouts.
Dual 90 W IEEE 802.3bt Hi-PoE Ports
Ports 1 and 2 deliver up to 90 W output per port using 802.3bt Hi-PoE technology, providing high power to PTZ domes, long-range infrared illuminators, and multi-sensor cameras without requiring external power injectors.
Fanless Metal Housing & 6 kV Surge Rating
Encased in a durable, fanless metal shell designed for silent, reliable heat dissipation. Integrated 6 kV surge protection shields all network interfaces against outdoor lighting strikes and high electrical surges.
Technical Specification Matrix
Switch Model
DS-3E0310HP-E(C)
Network Ports
8 × 10/100 Mbps PoE RJ45, 2 × 10/100/1000 Mbps RJ45 Uplinks
PoE Standard
Ports 1-2: IEEE 802.3af/at/bt; Ports 3-8: IEEE 802.3af/at
Max Output Power per Port
Ports 1-2: Up to 90 W per port; Ports 3-8: Up to 30 W per port
Total PoE Power Budget
110 W
Switching Capacity
5.6 Gbps
Packet Forwarding Rate
4.17 Mpps
Long Range PoE Mode
Up to 300 metres (Ports 1 to 8)
Surge Protection
6 kV (PoE Ports)
Housing & Power Supply
Metal Shell (Fanless); 54 VDC, 2.22 A Power Adapter Included
Frequently Asked Questions
What type of devices should I connect to the Hi-PoE ports?
Ports 1 and 2 support IEEE 802.3bt Hi-PoE up to 90 W per port, making them ideal for power-hungry devices like motorised PTZ speed domes, thermal cameras, or multi-sensor cameras.
How does the 300-metre Long Range mode function?
When Long Range mode is enabled via the front-panel switch, ports 1 through 8 extend network and power delivery up to 300 metres at a stabilized 10 Mbps connection speed.
How does PoE Watchdog prevent camera downtime?
PoE Watchdog continuously monitors communication with connected IP devices. If an IP camera becomes unresponsive, the switch automatically cycles power on that port to force a hard reboot.
Why are Gigabit uplink ports important on this switch?
The 2 dedicated Gigabit RJ45 uplink ports provide high-bandwidth connections directly to your NVR or core network router, preventing video bottlenecking from the 8 Fast Ethernet camera ports.
Technical Datasheet Quick Start Guide
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Smart Managed Series
Enterprise High-Density 24-Port Gigabit Smart Managed PoE Switch with 4 SFP Fibre Uplinks
Optimize multi-site enterprise video networks, commercial IP infrastructure, and high-density surveillance setups with the Hikvision DS-3E1528P-EI. Engineered for high-throughput backbone connections, this smart managed 1U rackmount switch features 24 Full Gigabit PoE RJ45 ports paired with 4 dedicated Gigabit SFP optical fibre uplink ports, supported by a heavy-duty 370 W total PoE power budget for long-distance, high-bandwidth deployments.
Port Configuration
24 × 1G PoE + 4 × 1G SFP Fibre
PoE Power Budget
370 W Total (30 W Max/Port)
Transmission Range
300m Extended PoE Support
Protection & Management
6 kV Surge & PoE Watchdog
Quad SFP Uplinks & Intelligent Remote Cloud Topology
Designed for seamless integration into enterprise networks, the DS-3E1528P-EI connects directly to Hikvision’s Hik-Partner Pro cloud management platform. Network administrators gain real-time access to visual topology maps, remote port control, cable diagnostics, and instant system alerts. Equipped with quad Gigabit SFP slots, it enables long-distance fibre optic trunk links between server rooms and remote campus buildings. Intelligent PoE Watchdog continuously monitors active camera links, automatically power-cycling frozen endpoints to minimise system downtime. Comprehensive Layer 2 features—such as 802.1Q VLANs, STP/RSTP, port isolation, link aggregation, and 6 kV surge protection—ensure maximum reliability and bandwidth efficiency.
Quad SFP Slots & 370 W PoE Power
Features 4 dedicated Gigabit SFP slots for fibre optic backbones alongside 24 Gigabit PoE ports backed by a robust 370 W total power budget. Extended PoE mode supports power and data transmission up to 300 metres.
PoE Watchdog & Cloud Maintenance
Automated PoE Watchdog detects non-responsive IP devices and automatically restarts port power. Full Hik-Partner Pro cloud integration allows remote topology viewing, cable health testing, and batch updates.
Technical Specification Matrix
Switch Model
DS-3E1528P-EI
Network Ports
24 × Gigabit PoE RJ45, 4 × Gigabit SFP Fibre Uplink Slots
PoE Standard
IEEE 802.3af, IEEE 802.3at (PoE+)
PoE Power Budget
370 W Total (30 W Max per port)
Switching Capacity
56 Gbps
Packet Forwarding Rate
41.66 Mpps
MAC Address Table
8 K
Long Range PoE Mode
Up to 300 metres (Ports 1 to 24)
Surge Protection
6 kV (PoE Ports)
Chassis Form Factor
Solid Metal 1U 19-inch Rack-Mountable (Mounting ears included)
Frequently Asked Questions
What is the advantage of having 4 SFP fibre ports on the DS-3E1528P-EI?
The 4 dedicated SFP slots allow high-speed fibre optic trunk connections to core switches or NVRs across large campuses and multi-floor buildings without consuming any of the 24 copper Gigabit PoE ports.
Can I run cameras at long distances with this switch?
Yes, by toggling Extend mode via the cloud or web management interface, power and data transmission on ports 1 through 24 can reach distances of up to 300 metres over standard Cat5e/Cat6 cabling.
How does PoE Watchdog improve network reliability?
PoE Watchdog continuously monitors communication with connected devices. If a camera becomes unresponsive, the switch automatically resets power to that specific port to bring the device back online.
How do I remotely monitor the switch health and network topology?
The switch integrates natively with Hikvision’s Hik-Partner Pro platform, letting you inspect visual network topology, check power loads, perform remote cable diagnostics, and receive instant alert notifications.
Technical Datasheet Quick Start Guide
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Smart Managed Series
Enterprise High-Density 24-Port Gigabit Smart Managed Power over Ethernet Switch
Streamline large-scale IP surveillance networks, commercial access controls, and high-density camera deployments with the Hikvision DS-3E1526P-EI. Purpose-built for robust multi-channel video distribution, this smart managed 1U rack-mountable switch delivers 24 Full Gigabit PoE RJ45 ports alongside dedicated Gigabit uplink options (1× Gigabit RJ45 + 1× Gigabit SFP Optical Fibre), supported by a high-capacity 370 W total PoE power budget.
Port Configuration
24 × 1G PoE + 1G RJ45 / SFP Uplink
PoE Power Budget
370 W Total (30 W Max/Port)
Transmission Range
300m Extended PoE Support
Protection & Management
6 kV Surge & PoE Watchdog
Unified Cloud Topology Management & Self-Healing Network Security
The DS-3E1526P-EI seamlessly connects to Hikvision’s Hik-Partner Pro cloud platform, providing network visualizer mapping, real-time bandwidth and PoE consumption monitoring, and instant device alarm pushes. Featuring automated PoE Watchdog functionality across all 24 ports, the switch continuously checks camera connectivity and automatically reboots unresponsive IP cameras to prevent system downtime without requiring manual technician intervention. Layer 2 management tools including 802.1Q VLANs, STP/RSTP loop prevention, static link aggregation, port isolation, and 6 kV surge protection ensure secure and stable operation across critical enterprise networks.
High-Capacity 370 W Power & 300m Extended Range
Generous 370 W PoE budget easily powers a full system of up to 24 HD IP cameras. Extend mode allows data and power transmission over distances up to 300 metres across Cat5e/Cat6 cables on all 24 PoE ports.
PoE Watchdog & Cloud Maintenance
Self-healing PoE Watchdog automatically power-cycles frozen camera ports. Integration with Hik-Partner Pro allows remote device status checks, cable diagnostics, port rebooting, and firmware upgrades anywhere.
Technical Specification Matrix
Switch Model
DS-3E1526P-EI
Network Ports
24 × Gigabit PoE RJ45, 1 × Gigabit RJ45 Uplink, 1 × Gigabit SFP Fibre Optical Port
PoE Standard
IEEE 802.3af, IEEE 802.3at (PoE+)
PoE Power Budget
370 W Total (30 W Max per port)
Switching Capacity
56 Gbps
Packet Forwarding Rate
41.66 Mpps
MAC Address Table
8 K
Long Range PoE Mode
Up to 300 metres (Ports 1 to 24)
Surge Protection
6 kV (PoE Ports)
Chassis Form Factor
Solid Metal 1U 19-inch Rack-Mountable (Mounting ears included)
Frequently Asked Questions
How many cameras can the DS-3E1526P-EI power simultaneously?
With a total PoE power budget of 370 W, the DS-3E1526P-EI can easily power 24 standard IP cameras (drawing around 6 W to 12 W each) across all PoE ports at full Gigabit speeds.
How far can power and data travel using Long Range mode?
When Long Range mode is enabled, power and network data transmission distances can reach up to 300 metres across Cat5e or Cat6 cables on ports 1 through 24.
What happens if a connected camera freezes or loses connection?
The integrated PoE Watchdog continuously tests responsiveness on ports 1 through 24 and automatically performs an individual port power cycle to restart frozen cameras.
What uplink connections are included on the DS-3E1526P-EI?
The switch includes two dedicated Gigabit uplinks: one 10/100/1000 Mbps RJ45 copper port and one Gigabit SFP fibre optical port for long-distance backbone connectivity to NVRs or core switches.
Technical Datasheet Quick Start Guide
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Smart Managed Series
Intelligent 4-Port Gigabit Smart Managed Power over Ethernet Switch
Simplify deployment, monitoring, and remote network maintenance across commercial and residential IP surveillance systems with the Hikvision DS-3E1506P-EI. Designed to deliver enterprise-class stability in a compact footprint, this smart managed Layer 2 Gigabit switch provides 4 Gigabit PoE ports alongside 2 dedicated Gigabit RJ45 uplink ports, delivering up to 60 W of total PoE power budget for high-demand IP security cameras and access points.
Port Configuration
4 × 1G PoE + 2 × 1G Uplink
PoE Power Budget
60 W Total (30 W Max/Port)
Transmission & Range
300m Extended PoE Support
Protection & Health
6 kV Surge & PoE Watchdog
Remote Cloud Management & Automated Self-Healing Architecture
The DS-3E1506P-EI integrates seamlessly with Hikvision’s Hik-Partner Pro platform, allowing system integrators to remotely monitor network health, inspect topology visualizer maps, and receive instant alarm notifications on mobile or desktop interfaces. Featuring automated PoE Watchdog technology, the switch continuously detects offline cameras and performs intelligent port power reboots without requiring onsite technician intervention. Integrated 802.1Q VLAN support, port isolation, STP/RSTP loop prevention, and 6 kV surge protection ensure maximum system uptime even during severe electrical surges or adverse outdoor wiring conditions.
Automated PoE Watchdog & Long-Range PoE
Continuous monitoring auto-detects unresponsive IP cameras and soft-resets individual ports to restore connection. Extended long-range transmission mode extends power and data connectivity up to 300 metres on ports 1 through 4.
Hik-Partner Pro Cloud Topology Visualizer
Visualizes network topology in real time, displays bandwidth utilisation and PoE consumption, and enables remote device upgrades and cable health diagnostics directly from the cloud platform.
Technical Specification Matrix
Switch Model
DS-3E1506P-EI
Network Ports
4 × Gigabit PoE RJ45, 2 × Gigabit RJ45 Uplink
PoE Standard
IEEE 802.3af, IEEE 802.3at (PoE+)
PoE Power Budget
60 W Total (30 W Max per port)
Switching Capacity
14 Gbps
Packet Forwarding Rate
10.42 Mpps
MAC Address Table
2 K
Long Range PoE
Up to 300 metres (Ports 1 to 4)
Surge Protection
6 kV (PoE and Power Ports)
Construction & Mounting
Solid Metal Shell; Desk or Wall-Mounted
Frequently Asked Questions
How does the PoE Watchdog feature work on the DS-3E1506P-EI?
The PoE Watchdog continuously sends ping requests to connected IP cameras. If a camera stops responding due to a system crash, the switch automatically power-cycles that specific port to reboot and re-establish camera connectivity.
Can this switch transmit power and data over long distances?
Yes, by enabling Long Range mode via the Hik-Partner Pro platform or web UI, power and data transmission distance on ports 1 to 4 can be extended up to 300 metres.
Can I manage this switch remotely without being on-site?
Yes, the switch supports cloud management via Hik-Partner Pro, allowing technicians to inspect network topology, check PoE consumption, perform cable diagnostics, and restart ports remotely.
Is the DS-3E1506P-EI protected against lighting and electrical surges?
Yes, it features 6 kV surge protection across all network ports to safeguard connected IP security equipment against voltage spikes.
Technical Datasheet Quick Start Guide
User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Ultra Series · DeepinMind
Enterprise-Grade 128-Channel High-Density AI Network Video Recorder
Built for large-scale enterprise infrastructure, transportation hubs, and critical security command centers, the Hikvision DS-96128NXI-S24R provides massive video decoding capabilities and deep learning analytics integration. Supporting up to 128 IP camera channels with video recording resolutions up to 8K, this Ultra Series DeepinMind recorder guarantees maximum operational uptime through 24 hot-swappable SATA drive bays, dual redundant power supplies, and multi-tier RAID storage configurations.
Decoding / Resolution
Up to 8K / 32 MP Recording
Storage Capacity
24 SATA Interfaces (Hot-Swap)
Incoming Bandwidth
512 Mbps High-Throughput
System Redundancy
Dual Power & RAID 0/1/5/6/10
DeepinMind Structural AI Analytics & High-Density Storage Management
The DS-96128NXI-S24R utilizes GPU-accelerated deep learning processing to deliver high-precision perimeter defense, face recognition, and multi-target classification across continuous camera streams. Designed into a high-density 4U rack enclosure, it supports 24 hot-swappable SATA hard drives with comprehensive RAID 0, 1, 5, 6, 10, and N+1 hot spare redundancy options. Hot-swappable dual redundant power supply units ensure uninterrupted operation, rendering it ideal for mission-critical video surveillance centers.
High-Density 24-Bay RAID Array Redundancy
Features 24 hot-swappable SATA drive bays supporting enterprise RAID 0, 1, 5, 6, and 10 configurations. Drive replacement and storage expansion can be executed on-the-fly without service interruption or video recording downtime.
DeepinMind Structural Deep Learning Analytics
Hardware-accelerated AI algorithms significantly filter out false alarms triggered by environmental factors, enabling target detection, human/vehicle classification, and ultra-fast forensic search across high-channel deployments.
Technical Specification Matrix
NVR Model
DS-96128NXI-S24R
IP Video Input
128 Channels
Incoming / Outgoing Bandwidth
512 Mbps / 512 Mbps
Recording Resolution
Up to 32 MP / 8K Resolution Support
HDMI Output
2-ch HDMI (HDMI 1 supports up to 8K resolution)
SATA Storage Interfaces
24 SATA Interfaces (Up to 16 TB capacity per HDD)
RAID Configurations
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, N+1 Hot Spare
Network Interfaces
4 × RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Ports
Power Supply Redundancy
100–240 VAC, Dual Redundant Power Supply Units
Chassis Form Factor
4U Rack-Mounted Installation Chassis
Frequently Asked Questions
How many camera streams can the DS-96128NXI-S24R decode and record?
It supports up to 128 IP video channels with an incoming bandwidth capacity of 512 Mbps, capable of handling high-density 4K and 8K resolution video streams simultaneously.
What drive capacity and RAID levels does this recorder support?
The system features 24 hot-swappable SATA bays supporting up to 16 TB per drive, with RAID 0, 1, 5, 6, 10, and N+1 hot spare support for high data redundancy.
Does this model include redundant power supplies?
Yes, the DS-96128NXI-S24R includes dual hot-swappable redundant power supply units, ensuring operational continuity if a power module needs replacement.
What is the difference between the S16R and S24R models?
The DS-96128NXI-S24R provides 24 SATA drive bays in a 4U rack chassis for expanded storage retention, whereas the S16R offers 16 SATA drive bays in a 3U chassis.
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision Ultra Series · DeepinMind
Enterprise-Grade 128-Channel High-Density AI Network Video Recorder
Engineered for ultra-large-scale commercial deployments, critical infrastructure, and high-density surveillance hubs, the Hikvision DS-96128NXI-S16R delivers unprecedented decoding power and AI analytics integration. Capable of supporting up to 128 IP camera channels with resolution support up to 8K, this DeepinMind series recorder ensures high-availability recording with redundant power supplies, hot-swappable hard drive bays, and robust RAID storage array configurations.
Decoding / Resolution
Up to 8K / 32 MP Recording
Storage Capacity
16 SATA Interfaces (Hot-Swap)
Incoming Bandwidth
512 Mbps High-Throughput
System Redundancy
Dual Power & RAID 0/1/5/6/10
DeepinMind Deep Learning Video Analytics & High-Availability Architecture
The DS-96128NXI-S16R leverages advanced deep-learning algorithms to perform real-time perimeter protection, facial recognition, and human/vehicle target classification across multi-channel streams. Built on a server-class 3U rack chassis, it accommodates 16 SATA hard drives with hot-swappable HDD arrays supporting RAID 0, 1, 5, 6, 10, and N+1 hot spare configurations. Dual redundant power units guarantee non-stop system operation even during primary power supply maintenance.
Hot-Swappable RAID Array Protection
Supports enterprise storage configurations including RAID 0, 1, 5, 6, and 10 across 16 SATA interfaces. Drives can be replaced on-the-fly without taking the recording server offline or interrupting critical footage capture.
DeepinMind Structural Video Analytics
Reduces false alarms caused by environmental noise using hardware-accelerated deep learning algorithms, enabling high-accuracy perimeter protection, face identification, and target search capabilities across connected streams.
Technical Specification Matrix
NVR Model
DS-96128NXI-S16R
IP Video Input
128 Channels
Incoming / Outgoing Bandwidth
512 Mbps / 512 Mbps
Recording Resolution
Up to 32 MP / 8K Resolution Support
HDMI Output
2-ch HDMI (HDMI 1 supports up to 8K output)
SATA Storage Interfaces
16 SATA Interfaces (Up to 16 TB capacity per HDD)
RAID Configurations
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, N+1 Hot Spare
Network Interfaces
4 × RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Ports
Power Supply Redundancy
100–240 VAC, Dual Redundant Power Supply Units
Chassis Form Factor
3U Rack-Mounted Installation Chassis
Frequently Asked Questions
How many camera channels can the DS-96128NXI-S16R manage simultaneously?
It supports up to 128 IP video channels with an total incoming bandwidth capacity of up to 512 Mbps, accommodating high-resolution 4K and 8K streams across enterprise camera deployments.
What storage redundancy options are supported on this NVR?
The unit features 16 hot-swappable SATA bays supporting RAID 0, 1, 5, 6, 10, and N+1 hot spare, protecting continuous footage against individual hard drive failures.
Does the unit feature redundant power supplies?
Yes, the DS-96128NXI-S16R incorporates dual redundant power supply modules to maintain operational continuity in the event of a power supply module failure.
What video outputs are available for multi-monitor display setup?
It provides dual independent HDMI outputs (with HDMI 1 supporting up to 8K resolution display output) alongside VGA ports for multi-screen monitoring centers.
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision General Wired Detectors
Proactive Penetration Detection for Critical Infrastructure
The DS-PDSKM-VG3 is a high-precision wired seismic shock detector engineered to safeguard high-security assets including safes, ATMs, vaults, and reinforced concrete or brick walls. Powered by a high-sensitivity G-sensor and intelligent digital signal processing, the DS-PDSKM-VG3 identifies early structural vibrations caused by drilling, hammering, cutting, or mechanical attack long before physical penetration occurs, ensuring rapid incident mitigation.
Detection Method
High-Sensitivity G-Sensor
Coverage Radius
Up to 5m Detection Radius
Sensitivity Control
8 DIP Switch Levels
Housing Rating
IK10 Die-Cast Metal
Advanced Digital Signal Processing and Environmental Filtering
Engineered for mission-critical commercial applications, the Hikvision DS-PDSKM-VG3 wired seismic detector incorporates advanced background-noise digital filtering to distinguish legitimate forced-entry threats from ambient facility vibrations. Equipped with dual LED indicators (blue for alarm status, red for noise threshold monitoring), front and rear anti-tamper protection, and rapid temperature rise detection, this robust sensor provides uncompromising reliability in high-risk financial, commercial, and industrial environments.
Gross Attack Override & Multi-Level Sensitivity
Featuring 8 discrete DIP switch sensitivity settings, the detector can be fine-tuned to the exact resonant characteristics of steel, concrete, or composite barriers. Built-in gross attack override ensures immediate alarm trigger during sudden high-impact attempts.
IK10 Heavy-Duty Die-Cast Metal Enclosure
Housed in a rugged die-cast metal shell with an IK10 impact resistance rating, the device offers complete physical protection against sabotage. Front and rear tamper switches ensure immediate alert generation if the casing is opened or detached from the surface.
Technical Specification Matrix
Detector Model
DS-PDSKM-VG3
Detection Technology
High-Precision G-Sensor (Shock & Vibration)
Detection Radius
Up to 5 Metres Radius (Ø10m Coverage Area)
Sensitivity Adjustment
8 Levels via On-Board DIP Switches
Digital Processing
Advanced Background Noise Filter & Gross Attack Override
Tamper Protection
Front Cover & Rear Wall Pull-Off Switches
Special Detection Features
Displacement Detection & Rapid Temperature Rise Detection
Alarm Output & Status LEDs
Normally Closed (NC); Blue (Alarm) & Red (Noise Indication)
Power Supply & Consumption
9 to 16 VDC (Typical 12 VDC); 17 mA Max Current
Operating Temperature & Housing
-40 °C to +70 °C; IK10 Die-Cast Metal Casing (Indoor)
Where should the DS-PDSKM-VG3 seismic detector be installed?
The DS-PDSKM-VG3 is optimized for mounting directly onto physical structures requiring high-security intrusion monitoring, such as bank vaults, ATMs, commercial safes, security doors, concrete walls, and brick enclosures.
How does the background noise filter prevent false alarms?
Integrated digital signal processing (DSP) continually filters out background environmental vibration frequencies (such as traffic or HVAC rumble). The red LED offers real-time noise indication during installation to help technicians select optimal sensitivity levels.
Does the DS-PDSKM-VG3 support End-of-Line (EOL) resistors?
Yes, the unit features selectable jumper-configurable EOL resistors for Alarm (1K, 2K2, 4K7, 5K6, 6K8), Tamper (1K, 2K2, 4K7, 5K6), and Fault outputs for simple integration with security control panels.
What happens if someone attempts to pry the detector off the wall?
The unit features both front cover anti-tamper and rear wall-removal tamper protection, triggering an immediate tamper alarm to the security control panel upon physical interference.
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Genuine Axis Accessory • High-Endurance microSDXC Edge StorageAXIS Surveillance Card microSDXC 128GB–1TB — Australian Stock & 5-Year Warranty
AXIS Surveillance Cards are industrial-grade microSDXC cards developed specifically for the write pattern of a surveillance camera — not repurposed consumer media. They can be written and overwritten far more times than an ordinary SD card, which means the same card can stay in the camera for years instead of months. Choose 128 GB, 256 GB, 512 GB or 1 TB depending on how many days of edge recording you need. Every card ships with an SD adapter in a jewel case, supports Axis health monitoring so you are warned months before a card wears out, and carries a 5-year Axis warranty with free replacement of defective units.
CAPACITIES
128GB – 1TB
SPEED CLASS
V30 & UHS U3
ENDURANCE
Up to 768 TBW
WARRANTY
Axis 5-Year
Why a surveillance-grade card, not a consumer one
An SD card wears out by program/erase (P/E) cycles, and a camera recording continuously burns through them fast. Axis surveillance cards use TLC and QLC NAND with a deliberately low write amplification factor, so far fewer P/E cycles are consumed for the same amount of recorded video. Axis field data across billions of operating hours shows the vast majority of cards still working after five years — 97.9% of 128 GB cards and 99.8% of 256 GB cards — and roughly 85–95% still functional at ten years. A consumer card in the same camera typically fails long before that, usually without warning.
Health monitoring built in
Axis health monitoring tracks the wear on each card from actual usage data and notifies you months in advance when a replacement is needed — so you swap the card on a scheduled visit, not after you have lost evidence.
Encryption for stolen cards
Axis cameras can encrypt the card in the device: AES-CBC 128-bit from AXIS OS 5.80.1, AES-CBC 256-bit from AXIS OS 8.40.1, and AES-XTS-Plain64 (256-bit) on newer devices from AXIS OS 8.30.1. Pull the card out and the footage is unreadable.
Primary or failover storage
Record high-resolution video straight to the card as primary storage with no NVR on site, or run it as failover so the VMS can automatically backfill any footage missed during a network outage.
Long retention, real numbers
A 128 GB card typically delivers anywhere from 20 to 215+ days of retention depending on resolution, frame rate and event-based recording settings. Larger cards extend that considerably.
Technical Specifications
CAPACITIES & PART NUMBERS
128 GB
P/N 01491-001
256 GB
P/N 02021-001
512 GB
P/N 02365-001
1 TB
P/N 02366-001
Form factor
microSDXC with SD card adapter
Packaging
Card and SD adapter supplied in a jewel case
Colour
White
PERFORMANCE & ENDURANCE
Class (128 GB / 256 GB)
Video Speed Class V30, UHS Speed Class U3
Transfer speed (128 GB / 256 GB)
Sequential read up to 100 MB/s, sequential write up to 50 MB/s
Class (512 GB)
Speed Class 10, UHS Speed Class U3
Transfer speed (512 GB)
Sequential read up to 100 MB/s, sequential write up to 39 MB/s
Endurance — 128 GB
384 TBW (terabytes written, sequential workload)
Endurance — 256 GB
768 TBW (terabytes written, sequential workload)
NAND technology
TLC and QLC with low write amplification factor
EXPECTED CARD LIFETIME (AXIS SIMULATION)
128 GB
~10 yrs @ 2 MP 2.5 Mb/s · ~7 yrs @ 5 MP 3.5 Mb/s · ~5 yrs @ 8 MP 4.5 Mb/s
256 GB
~20 yrs @ 2 MP 2.5 Mb/s · ~14 yrs @ 5 MP 3.5 Mb/s · ~11 yrs @ 8 MP 4.5 Mb/s
512 GB
~26 yrs @ 2 MP 2.5 Mb/s · ~19 yrs @ 5 MP 3.5 Mb/s · ~15 yrs @ 8 MP 4.5 Mb/s
1 TB
~53 yrs @ 2 MP 2.5 Mb/s · ~38 yrs @ 5 MP 3.5 Mb/s · ~29 yrs @ 8 MP 4.5 Mb/s
DATA PROTECTION
Encryption
AES-CBC 128-bit (AXIS OS 5.80.1+), AES-CBC 256-bit (AXIS OS 8.40.1+), AES-XTS-Plain64 256-bit (newer devices, AXIS OS 8.30.1)
Health monitoring
Supported — data-driven wear tracking with advance replacement notification
Recommended file system
ext4 (journaling, lower risk of corruption after power loss)
PHYSICAL, ENVIRONMENT & APPROVALS
Card dimensions
microSDXC: 15 x 11 x 1.0 mm · SD adapter: 24 x 32 x 2.1 mm
Operating conditions
-25 °C to 85 °C (-13 °F to 185 °F)
Storage conditions
-40 °C to 85 °C (-40 °F to 185 °F)
Sustainability
PVC free
Approvals
EN 55032 Class B, EN 55035, FCC Part 15 Subpart B Class B, ICES-3(B)/NMB-3(B), VCCI Class B, RCM AS/NZS CISPR 32 Class B
Compatibility
All Axis products with SD card support
Warranty
Axis 5-year warranty, including free support, repair and replacement of defective units
Downloads
Axis Surveillance Card 512 GB DatasheetAxis Edge Storage White Paper
Frequently Asked Questions
Which capacity should I choose?It depends on resolution, bitrate and how many days you need to keep. As a guide, a 128 GB card typically gives 20 to 215+ days depending on configuration; 4K cameras or long retention requirements point to 512 GB or 1 TB.
Can I just use a normal microSD card?You can, but consumer cards are not built for continuous writing and often fail within months. Axis surveillance cards use low write amplification and industrial NAND so the same card generally lasts the life of the camera.
How long will the card actually last?Axis simulations put a 128 GB card at around 10 years on a 2 MP 2.5 Mb/s stream and a 1 TB card at around 53 years. Real field data shows 97.9% of 128 GB cards and 99.8% of 256 GB cards still working after five years.
Which Axis devices are compatible?All Axis products with SD card support. The card is a microSDXC with an SD adapter supplied, so it also reads in a standard SD slot for offloading footage.
Can the footage be encrypted?Yes. Axis cameras can encrypt the card in the device — AES-CBC 128-bit from AXIS OS 5.80.1, AES-CBC 256-bit from AXIS OS 8.40.1 and AES-XTS-Plain64 256-bit on newer devices — so a removed card cannot be read.
What is card health monitoring?A data-driven service in AXIS OS that tracks wear from actual card usage and notifies you months in advance when the card should be replaced, so you can schedule the swap rather than discover a failure after an incident.
Do I still need an NVR?Not necessarily. Edge storage can act as the primary recording location, or as failover storage alongside a VMS so missed footage is automatically backfilled once the network returns.
What file system should I use?Axis recommends ext4. It is a journaling file system, so it recovers faster and is less prone to corruption after a power outage — important on vehicles or sites with unreliable power.
What warranty applies in Australia?Axis provides a 5-year warranty on surveillance cards with free support, repair and replacement of defective units. CCTV Guru supplies genuine Australian stock and handles the warranty locally.
5-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
Hikvision AX Pro Series
Slim Weatherproof Curtain Motion Detector for Windows & Perimeters
The DS-PDC10AM-EG2-WB is an advanced 433 MHz wireless narrow-beam PIR curtain detector from Hikvision's AX PRO security ecosystem. Specifically engineered for window frames, balconies, corridors, and perimeter walls, its narrow 5° detection angle creates an invisible narrow barrier across vulnerable entry points. Featuring an IP65 weatherproof rating and active IR anti-masking technology, it delivers reliable outdoor intrusion detection without triggering false alarms from weather or surrounding activity.
Detection Area
10m Wall / 5m Ceiling
Anti-Masking & IP Rating
Active IR | IP65 Rated
Battery Lifespan
Up to 5 Years (2× CR123A)
Wireless Range
1,000m Open Area
Active IR Anti-Masking & Directional Detection Support
Equipped with Active Infrared (IR) anti-masking technology, the Hikvision DS-PDC10AM-EG2-WB continuously scans its optical lens for obstruction attempts (such as spray paint, paper, or foil), instantly raising an alarm if tampered with. Its intelligent directional detection algorithm allows users to configure motion triggers based on directional travel, letting occupants walk out to a patio without triggering alarms while instantly detecting unwanted entry from the outside.
IP65 Weatherproof Housing & Pet Immunity
Built to withstand harsh weather conditions from -25°C to +60°C. Includes digital temperature compensation and up to 12 kg pet immunity when wall-mounted to prevent false triggers from small animals.
Tri-X Two-Way Wireless Communication
Operates on 433 MHz two-way wireless technology with AES-128 encryption and frequency hopping against radio jamming, ensuring reliable long-range connection to AX PRO hubs.
Technical Specification Matrix
Detector Model
DS-PDC10AM-EG2-WB
Detection Method & Range
Passive Infrared (PIR) | Wall Mount: 10 m, Ceiling Mount: 5 m
Detection Angle & Zones
5° Narrow Curtain Angle | 32 Zones
Detectable Speed & Sensitivity
0.3 m/s to 2.0 m/s | Auto, Pet Immunity (up to 12 kg wall mounted)
Anti-Masking & Anti-Jamming
Active IR Anti-Masking | Frequency Hopping & AES-128 Encryption
Wireless Frequency & Range
433 MHz Tri-X Two-Way Wireless | 1,000 m Open Field
Power Source & Lifespan
2 × CR123A 3V Batteries | Up to 5 Years Standby Life
Ingress Protection & Operating Temp
IP65 Weather Resistance | -25 °C to +60 °C (-13 °F to 140 °F)
Dimensions & Mounting
29.2 mm × 134.4 mm × 39.5 mm | Wall or Ceiling Mount (L-Bracket Included)
Frequently Asked Questions
Can the DS-PDC10AM-EG2-WB be installed outdoors?
Yes. With its IP65 ingress protection rating and wide operating temperature range (-25°C to +60°C), it is designed for outdoor window frames, doorways, and covered perimeters.
How does directional detection benefit my security system?
Directional detection allows the detector to distinguish whether motion is moving inside-to-outside or outside-to-inside, letting occupants walk out without triggering an alarm while blocking incoming intrusions.
What does Active IR anti-masking do?
Active IR anti-masking detects any attempt to blind or cover the sensor lens with spray paint, plastic, tape, or objects, sending an immediate tamper signal to the AX PRO control panel.
Is a mounting bracket included in the box?
Yes, the detector comes supplied with a versatile L-shaped bracket adapter suitable for both wall and ceiling mounting configurations.
Technical Datasheet User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision AX Hybrid Pro Series
Flexible Output Expansion for AX Hybrid Pro Intrusion Alarm Systems
The DS-PM1-O4L-H is a professional wired 4-way low current relay expander engineered by Hikvision to extend the control capabilities of the AX Hybrid Pro intrusion alarm panel. Operating via Hikvision's high-speed Speed-X bus technology, this output module provides four onboard low current relays supporting 6 VDC to 30 VDC and up to 5A per channel. Designed for commercial, retail, and residential security automation, it enables seamless control of external devices such as strobe lights, sirens, access control gates, door strikes, and automation triggers.
Relay Outputs
4 Low Current Relays (5A)
Bus Communication
Speed-X Technology
Aux Power Output
12 VDC / Max 500mA
Anti-Tamper Shield
Front & Rear Tamper
High-Speed Speed-X Bus Cascading & Distributed Power Control
Engineered for complex alarm architectures, the Hikvision DS-PM1-O4L-H features dedicated uplink and downlink Speed-X bus ports. This allows installers to easily cascade multiple expander modules across long wiring runs back to the main AX Hybrid Pro panel. Additionally, the unit incorporates an auxiliary power output delivering up to 500mA (9 to 12 VDC) for directly powering low-voltage peripheral sensors, sirens, or status LEDs without requiring separate external power supplies.
4 Onboard Programmable Low Current Relays
Supports switching loads between 6 VDC and 30 VDC at up to 5A per output, allowing tailored response programming such as auto-locking doors, activating floodlights, or triggering external emergency dialers upon alarm events.
Dual Front & Rear Tamper Protection
Integrated micro-switches detect both front cover removal and wall-tear detachment, transmitting an immediate tamper alert signal via Speed-X bus to the control panel to prevent physical sabotage.
Technical Specification Matrix
Expander Model
DS-PM1-O4L-H
Relay Outputs
4 × Low Current Relays (6-30 VDC, up to 5A per relay)
Bus Interface
2 × Speed-X Bus (1 Uplink for panel, 1 Downlink for cascade)
Auxiliary Power Output
1 × 9 to 12 VDC output (Maximum 500 mA)
Power Supply Input
11 to 24 VDC, 1A
Power Consumption
Max current 153 mA @ 12 VDC; Quiescent current 70 mA @ 12 VDC
Tamper-Proof Protection
Supported (Front cover and rear wall tear-off protection)
LED Status Indicators
2 × LEDs (1 for Power status, 1 for Fault/Communication)
Dimensions & Weight
110 mm × 155 mm × 32.5 mm | Weight: 285 g
Frequently asked questions
What control panels are compatible with the DS-PM1-O4L-H?
The DS-PM1-O4L-H is designed specifically for Hikvision AX Hybrid Pro intrusion panels (such as DS-PHA48-EP / DS-PHA64-Kit) utilizing Speed-X bus communication.
How many relay expanders can be cascaded together?
Multiple expander modules can be chained sequentially using the dedicated Speed-X uplink and downlink ports up to the maximum bus address limit (addresses 0 to 63) supported by the control panel.
What type of loads can the relays handle?
Each onboard relay supports low voltage DC circuits between 6V and 30V with a maximum current of 5A, making it ideal for electronic locks, buzzers, status LEDs, and relay coils.
Does the expander require separate power configuration?
It operates on 11 to 24 VDC supplied via the bus or local power supply, drawing maximum 153 mA at 12 VDC during full relay activation.
Technical Datasheet
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision DS-UPS-R/AU · Line-Interactive · AVR · Cold Start · 600 / 1000 / 2000 VA
Hikvision DS-UPS-R/AU Range
Hikvision DS-UPS-R/AU Series — Line-Interactive Back-Up UPS with AVR for CCTV & NVR Systems
The Hikvision DS-UPS-R/AU range is a line of line-interactive tower UPS units designed to keep your CCTV recording running through mains dropouts, brownouts and dirty power. Available in 600 VA / 360 W (small residential NVRs), 1000 VA / 600 W (mainstream commercial NVR + camera load) and 2000 VA / 1200 W (large PoE switches, multi-HDD NVRs, larger sites). Built-in Automatic Voltage Regulation (AVR) corrects mains sag and surge without dropping to battery, so the batteries only discharge during actual outages — extending battery life. Cold start lets you power the NVR from battery even when there's no mains at all (useful for planned outages). Every unit is rated at 230 VAC 50 Hz, ships with Australian mains plug + AU-standard IEC outlets, and is backed by 3-year Australian warranty from CCTV Guru.
Topology
Line-Interactive · AVR
Capacity Range
600 VA · 1000 VA · 2000 VA
Input / Output
230 VAC 50 Hz · AU Plug + IEC
Cold Start
Power on from Battery · No Mains Needed
Protection
Surge · Overload · Short-Circuit · RJ11
Warranty
3-Year AU · Battery Replaceable
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
Why a UPS Matters for a CCTV or NVR System
Every CCTV recorder has a hard drive that's writing continuously. When the mains flicks off mid-write — a lightning strike, a substation dip, someone tripping the RCD — the HDD doesn't get to flush its cache before the power dies. The result is corrupted footage, index errors, or in the worst case a bricked RAID array. A UPS gives the NVR 5-15 minutes of clean battery power on an outage; the NVR shuts down cleanly (via USB signalling on models that support it), the HDD flushes properly, and there's no corruption when the power comes back. Line-interactive UPS units go one better — they use AVR (Automatic Voltage Regulation) to smooth out mains sag and surge without discharging the battery, so battery life is preserved for the times you actually need it.
Line-Interactive Topology with AVR
Automatic Voltage Regulation corrects ±25% mains sag and surge without switching to battery. Extends battery lifespan (typical AU regional grid has 30-50 minor sag events per week that would otherwise cycle a cheap standby UPS to battery).
Cold Start Capability
Start the load from battery even when there's no mains at all. Useful for planned outages (running a camera off-grid for a temporary site check) or bringing up the NVR after an extended power failure while the mains is still being restored.
USB Auto-Shutdown Signalling
Micro-USB connection to the NVR — when battery drops below the safe threshold, the UPS signals the NVR to shut down cleanly. Works with most Hikvision NVRs out of the box (may require enabling in NVR settings).
Full Range of Protections
Overload, short-circuit, over-discharge, over-charge, and mains surge protection — plus RJ11 telephone / network surge protection pass-through on all models to protect ADSL/NBN modems.
Replaceable Battery
Sealed lead-acid battery module accessible via bottom cover — replaceable at end of life (typical 3-5 years, faster in high ambient temp). Uses standard 12 V SLA batteries (600 VA: 12 V 4.5 Ah, 1000 VA: 12 V 9 Ah, 2000 VA: 2 × 12 V 9 Ah).
Silent Fan-Free Operation (600 & 1000 VA)
The 600 VA and 1000 VA models are fan-free — silent when running from mains. Suitable for reception desks, home offices, sleeping areas. The 2000 VA has a low-noise thermally-controlled fan that only runs at high load or on battery.
Capacity Guide — Which VA Rating for Which NVR?
UPS runtime is capped by the smaller of two things: the load in watts (must be under the UPS's watt rating) and the battery capacity. Below is a practical sizing guide based on Hikvision's own NVR power consumption.
Sizing Guide · Which UPS for Which NVR
600 VA / 360 W · $101
4-8 channel M-Series NVRs with 1 HDD. Small residential / single-camera commercial. NVR draw ~40-60 W → ~15-20 min runtime.
1000 VA / 600 W · $149 (most popular)
8-16 channel NVRs with 1-2 HDD + a small PoE switch. Mainstream commercial. NVR + 8 cameras ~120-180 W → ~15-25 min runtime.
2000 VA / 1200 W · $269
16-32 channel NVRs with 2-4 HDD, larger PoE-heavy sites, DeepinMind AI NVRs. Also fits sites with modem + NVR + monitor + PoE switch. ~15-30 min runtime at typical load.
Rule of thumb: add up the wattage of everything you want protected (NVR + PoE switch + modem + a small monitor if used), then pick the UPS that's at least 1.5× that number in watts. Sizing headroom = longer runtime + longer battery life.
Full Specifications Comparison
DS-UPS-R/AU Range · Specification Comparison
Spec
600 VA · 360 W · $101 | 1000 VA · 600 W · $149 | 2000 VA · 1200 W · $269
SKU
DS-UPS600-R/AU · DS-UPS1000-R/AU · DS-UPS2000-R/AU
Topology
Line-Interactive with AVR (all three)
Capacity
600 VA / 360 W · 1000 VA / 600 W · 2000 VA / 1200 W
Input Voltage
230 VAC (140-300 VAC operating range) 50 Hz (all three)
Output Voltage
230 VAC ±10% (battery mode) · simulated sine wave
Transfer Time
Typically ≤ 6 ms (all three)
Battery
12 V 4.5 Ah SLA · 12 V 9 Ah SLA · 2× 12 V 9 Ah SLA
Recharge Time
≤ 8 hours to 90% (all three)
Output Sockets
2× IEC (AU) · 3× IEC (AU) · 4× IEC (AU) + optional 15 A AU socket on 2000 VA
Communication
USB (auto-shutdown) · RJ11 surge pass-through (all three)
Cold Start
Yes (all three)
Cooling
Passive (fan-free) · Passive (fan-free) · Low-noise thermal fan
Efficiency (AC mode)
≥ 92% (all three)
Operating Temperature
0 °C to +40 °C · humidity ≤90 % (non-condensing)
Dimensions (approx.)
90×140×195 mm · 100×145×280 mm · 145×195×340 mm
Weight
~4.5 kg · ~7.5 kg · ~14 kg
Certifications
RCM (AU) · CE · RoHS
Warranty
3-Year Australian Warranty (all three)
Frequently Asked Questions
What's the difference between VA and Watts?VA (volt-amps) is the apparent power rating; Watts is the real power the UPS can deliver. For CCTV/NVR loads, the wattage number is what actually matters — that's what you compare against the actual draw of your equipment. VA is what UPS marketing leads with because it's a bigger number.
How long will the UPS run my NVR for?Depends on load. A typical 8-camera Hikvision NVR draws ~120-180 W. At half load, the 1000 VA runs 15-25 min, the 2000 VA runs 25-40 min, and the 600 VA runs 5-10 min. Enough for a clean shutdown; not enough to keep recording through a multi-hour outage. For that, you want a larger UPS or a solar / genset solution.
Can it auto-shutdown my NVR?Yes — connect the USB cable from the UPS to the NVR's USB port and enable UPS shutdown in the NVR settings. When the battery drops to the safe threshold, the UPS signals the NVR to save-and-shutdown. Works with most Hikvision NVRs; check the NVR's user manual for the exact menu path.
Does it protect my ADSL/NBN modem too?Yes — plug the modem into one of the UPS's IEC outlets to power-protect it, AND run your ADSL/phone line through the RJ11 surge pass-through ports on the back to protect against surges coming down the phone line (lightning strikes on the copper network often destroy modems).
How often do I need to replace the battery?Typical SLA battery life is 3-5 years in Australian ambient conditions. Batteries in hot spaces (comms cabinets in summer) may only last 2-3 years. The UPS beeps when the battery fails its self-test — that's your signal. Replacement batteries are standard 12 V SLA sizes available from any battery supplier.
What's a "sine wave" vs "simulated sine wave" output?Pure sine wave outputs are true smooth AC — required by some sensitive equipment (medical, some audio gear). Simulated sine wave (also called modified sine wave) is what the DS-UPS-R/AU uses — perfectly fine for NVRs, PoE switches, modems, monitors, computers and 99% of home / commercial IT gear.
Order the Hikvision DS-UPS-R/AU from CCTV Guru
Australian stock across the entire DS-UPS-R/AU range — 600 VA, 1000 VA and 2000 VA. Select your capacity from the dropdown above. Free tech advice on sizing for your specific NVR + camera load — contact us with your parts list and we'll spec the right UPS for your project. Multi-unit and installer pricing available for site rollouts and body-corp maintenance contracts. Request a free quote or contact our Australian team.
Hikvision DeepinView · 8MP 4K · DarkFighter · 120 dB WDR · Face Capture
Hikvision DeepinView 4K Dome
Hikvision iDS-2CD7186G0-IZS — 8MP 4K DeepinView Motorised Varifocal Dome with DarkFighter, Deep Learning Face Capture & Perimeter Protection
The Hikvision iDS-2CD7186G0-IZS is a premium DeepinView intelligent dome camera engineered for critical infrastructure, commercial campuses, transport hubs and high-security enterprise sites where a standard AcuSense camera isn't enough. A 1/1.8" progressive CMOS streams true 4K UHD (3840 × 2160), and a 2.8-12 mm motorised varifocal lens gives you remote scene setup without a ladder. Backed by DarkFighter ultra-low-light (0.003 lux colour), 120 dB True WDR and 30 m Smart IR for round-the-clock imaging. Onboard deep-learning analytics deliver face capture, human/vehicle perimeter protection, multi-target detection and queue management — trained models running natively on the camera, no server needed. 3-year Australian warranty, back-to-base through Hikvision Australia by CCTV Guru.
Resolution
8 MP · 3840 × 2160 · 4K UHD
Lens
2.8-12 mm Motorised Varifocal · F1.2
Low-Light
DarkFighter · 0.003 lux · 30 m Smart IR
Wide Dynamic Range
120 dB True WDR
DeepinView AI
Face Capture · Perimeter · Multi-Target
Protection
IK10 · IP67 · Vandal-Resistant
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
DeepinView — What Actually Makes This Camera Different
DeepinView is Hikvision's dedicated AI camera family — one step above AcuSense in the range hierarchy. Where AcuSense filters false alarms on humans and vehicles, DeepinView runs trained deep-learning models on the camera itself: face capture with attribute detection, multi-target tracking across the frame, queue-length analytics, and perimeter classification tuned per-scene. The camera reduces false alarms by up to 90% versus a conventional analytics camera because it's actually recognising the object type — not just detecting motion. For sites where an operator can't afford to chase phantom alerts (retail loss prevention, transport terminals, campus perimeters), DeepinView pays for itself in labour hours saved.
DarkFighter Ultra-Low-Light Imaging
0.003 lux colour sensitivity at F1.2 with AGC on, 0 lux with IR. Full colour imaging in near-total darkness — useful for retail, hospitality and public spaces where night IR washout looks unwelcoming. Auto switch to monochrome IR when ambient drops further.
Face Capture with Attribute Detection
Onboard face capture with age / gender / glasses / mask attribute detection. Faces are extracted, cropped and timestamped in real time — reduces bandwidth compared to full-frame recording and simplifies post-incident search on the NVR side.
Perimeter Protection with H/V Classification
Line crossing, intrusion, region entrance and exit rules — all with human and vehicle classification so the alarm only fires on what actually matters. Ignores animals, foliage, headlights and precipitation.
Multi-Target Detection & Queue Management
Tracks multiple people or vehicles simultaneously across the frame — useful for entry counts, dwell-time analytics, and monitoring queue lengths at checkouts, boarding gates and reception areas.
120 dB True WDR
Handles high-contrast scenes — sunlit doorways backed by dark interiors, sunrise glare, indoor-to-outdoor transitions. Preserves detail in both the bright and dark regions of the frame simultaneously.
2.8-12 mm Motorised Varifocal Lens
Remote-adjustable focal length and auto-focus. Installers set the frame once from a laptop or NVR — no lens twiddling on a ladder. Wide 2.8 mm for entry monitoring; 12 mm long-throw for corridor or lot-boundary detail.
Ideal Deployments — Where DeepinView Earns Its Price
Retail Loss Prevention
Face capture at entries and checkout aisles, plus queue-length monitoring for staffing decisions. Deep-learning classification catches the shoplifter walk-out pattern that simple motion analytics misses.
Transport Terminals & Boarding Gates
High-throughput environments where operators can't watch every screen. Face capture streams the metadata to the NVR for later search; multi-target detection tracks flow rates and dwell times.
Campus Perimeters & Building Approaches
Human/vehicle classified line-crossing along fences, boundaries and access driveways — filters out wildlife, wind-blown vegetation and headlight reflections. Alerts operations only on real events.
Financial & Enterprise Reception
Face capture at building entries with attribute detection — feeds into visitor management workflows and after-hours access review. IK10 vandal resistance for public-space installs.
Technical Specifications
iDS-2CD7186G0-IZS · Full Specifications
SKU
iDS-2CD7186G0-IZS (AU stock)
Camera Type
Hikvision DeepinView Series · 4K Motorised Varifocal Dome · Deep Learning AI
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
3840 × 2160 (8 MP / 4K UHD)
Main Stream
25/30 fps @ 3840 × 2160 · 2560 × 1440 · 1920 × 1080
Lens
2.8-12 mm Motorised Varifocal · Auto-Focus · F1.2
Field of View
111°–43.7° (horizontal, wide to tele)
Min. Illumination
Colour: 0.003 lux @ F1.2 (AGC ON) · 0 lux with IR
Wide Dynamic Range
120 dB True WDR
Shutter Speed
1 s to 1/100,000 s
IR Distance
Up to 30 m · Smart IR intensity + angle auto-adjust
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG
Deep Learning Functions
Face Capture · Perimeter Protection (H/V classified) · Multi-Target Detection · Queue Management
Face Capture
Attribute detection (age / gender / glasses / mask) · Face library matching (via NVR)
Perimeter Rules
Line crossing · Intrusion · Region entrance · Region exiting · Human + Vehicle classification
Audio
1× audio in, 1× audio out (3.5 mm) · G.711 / G.722.1 / G.726 / MP2L2 · Audio detection
Alarm I/O
1 input · 1 output
Ethernet
1× RJ-45 10/100 Mbps
Protocols
IPv4/IPv6 · HTTPS · 802.1X · QoS · FTP · SMTP · UPnP · SNMP · DNS · DDNS · NTP · RTSP · TCP · UDP · IGMP · DHCP · Bonjour · SRTP · TLS
Storage
microSD / SDHC / SDXC up to 256 GB · NAS · ANR (Auto Network Replenishment)
API
ISAPI · Hikvision SDK · ONVIF (Profile S / G / T)
Client Software
iVMS-4200 · Hik-Central Professional · Hik-Connect
Power
12 VDC · 24 VAC · PoE 802.3af Class 3 (max ≈ 12 W with IR)
Weatherproof
IP67 (IEC 60529)
Vandal Resistance
IK10
Operating Temperature
−30 °C to +60 °C · humidity ≤95 %
Warranty
3-Year Australian Warranty (back-to-base)
Pair with a Hikvision AcuSeek or DeepinMind NVR
DeepinView cameras generate rich metadata — face captures, attribute tags, human/vehicle detections. That metadata is only fully useful if your NVR indexes it. Standard M-Series NVRs record the camera reliably, but for natural-language search across the recording, step up to an AcuSeek (VPro) or DeepinMind NVR that indexes the DeepinView metadata for post-incident search.
AcuSeek VPro Series
Natural-language search across recordings — "show me all people wearing red between 2 pm and 4 pm at Camera 3." Indexes face-capture metadata from DeepinView cameras. Browse AcuSeek NVRs →
DeepinMind AI NVRs
Enterprise AI NVR family — face-library matching, cross-camera tracking, alarm correlation. For 4-16+ DeepinView cameras. Browse DeepinMind range →
Frequently Asked Questions
What's the difference between DeepinView and AcuSense?AcuSense filters false alarms with human/vehicle classification. DeepinView runs deep-learning trained models on the camera — face capture with attribute detection, multi-target tracking, queue analytics, plus everything AcuSense does. DeepinView is the tier above AcuSense in Hikvision's range.
How does the motorised varifocal lens work?The 2.8-12 mm zoom and focus are controlled remotely via the NVR, web interface, iVMS-4200 or Hik-Connect app. Installers set the frame once from a laptop, then leave the camera alone. No ladder needed for scene adjustments.
Does face capture require a separate face-recognition server?Face capture (detection + attribute tagging + cropping) runs on the camera itself. Face recognition / matching against a library requires a DeepinMind NVR or Hik-Central server. The camera streams the captured face images for the server to match.
What power supply options does the camera support?PoE 802.3af Class 3, 12 VDC, or 24 VAC. Runs on any standard Hikvision NVR PoE port — no Hi-PoE injector needed. Full max power draw approximately 12 W with IR at full range.
Is the camera vandal- and weather-rated?Yes — IP67 weather-rated (dust-tight + immersion) and IK10 vandal-rated (20-joule impact resistance). Suitable for outdoor mounting under eaves, on approach paths, in car parks, on wall mounts and at accessible ceiling heights in indoor public spaces.
Can I integrate with a non-Hikvision VMS?Yes — the camera speaks ONVIF Profile S, G and T and RTSP. Compatible with Milestone XProtect, Genetec, Exacq, Immix and most other Australian VMS platforms. Note: DeepinView-specific metadata (face captures, attribute tags) is only fully indexed on Hikvision NVRs / Hik-Central.
Downloads & Resources
iDS-2CD7186G0-IZS Datasheet
Quick Start Guide
Network Camera User Manual
Order the Hikvision iDS-2CD7186G0-IZS from CCTV Guru
CCTV Guru is an authorised Australian reseller of the Hikvision DeepinView range. The iDS-2CD7186G0-IZS is a specialist AI camera — for buyers who understand the DeepinView tier and know why they want it. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch, and specialist pre-sales advice on face-capture / perimeter deployments from our Sydney team. Request a free quote or contact our Australian team.
Hikvision Pro IP Intercom · 7" Android Touchscreen · PoE + Wi-Fi · Flush Mount
Hikvision 7" IP Intercom Station
Hikvision DS-KH8381-WTE1/Flush — 7" Android IP Intercom Indoor Station with PoE, Wi-Fi, Echo Cancellation & Flush Mount Design
The Hikvision DS-KH8381-WTE1/Flush is a premium 7-inch Android-powered IP video-intercom indoor monitor — the in-room answering device paired with Hikvision's IP door stations for villas, apartments, luxury estates and commercial reception. A 1024 × 600 IPS touchscreen, embedded Android OS, and built-in echo cancellation deliver a phone-like conversation quality on the intercom call, while PoE 802.3af and dual-band Wi-Fi 802.11 b/g/n give you a single-cable install or fully wireless retrofit. Integrates with any Hikvision IP door station, unlocks the door on a tap, and shows live video from any Hikvision IP camera on your NVR so you can verify a visitor before granting access. 3-year Australian warranty from CCTV Guru.
Display
7" IPS Touch · 1024 × 600
Operating System
Embedded Android
Connectivity
PoE 802.3af + Wi-Fi b/g/n
Audio
Full-Duplex · AEC + Noise Suppression
Alarm I/O
8 Inputs · 2 Relay Outputs · RS-485
Mounting
Flush · Low-Profile Architectural
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
Why This Is the Indoor Station to Choose
The DS-KH8381-WTE1/Flush is the top-tier indoor answering unit in Hikvision's IP intercom range — chosen for premium builds where a plain 4-inch monitor won't cut it. The 7-inch IPS touchscreen sits flush with the wall behind an included architectural bracket; there's no protruding chassis to catch the eye. Android under the hood means the UI feels like a phone — swipe, tap, quick response. Full-duplex audio with echo cancellation gives you natural conversation with the person at the door, and you can pull up a live feed from any Hikvision IP camera on your NVR to verify a visitor before you unlock. Alarm inputs (8) and relay outputs (2) turn the monitor into a small building-management panel — connect door sensors, glass-break sensors, or trigger a driveway light on visitor arrival.
Full-Duplex Audio with Echo Cancellation
Acoustic Echo Cancellation (AEC) plus digital noise reduction. Two-way conversation without the walkie-talkie "you have to stop talking" awkwardness — critical for a commercial reception setting where the impression matters.
Camera Preview from the Intercom
Tap through to any Hikvision IP camera on your network. Verify a visitor from the driveway camera before you unlock the door, or check the delivery bay from the reception monitor. Cameras don't need to be on the same door station.
PoE + Wi-Fi Flexibility
PoE 802.3af for a single-cable retrofit; Wi-Fi 802.11 b/g/n for locations where running Ethernet is impractical. Also accepts 12 VDC for legacy or off-grid installs.
8 Alarm Inputs + 2 Relay Outputs
Wired inputs for door sensors, glass break, PIR or panic buttons. Two relay outputs to trigger driveway lights, sirens, gates or auxiliary door strikes. RS-485 bus for larger integrations.
Flush Architectural Mount
Included bracket sits the monitor cleanly in the wall cavity — no protruding chassis. Suits luxury villa entries, boutique-hotel reception, high-end apartment lobbies where visible-tech looks unwelcome.
Multi-Tenant Scalability
Fits Hikvision's IP intercom system for buildings up to 4,000 monitors across a single site — apartment complexes, mixed-use developments, campuses. Works with entrance stations, villa door stations, master stations and Hik-Connect for remote answer on smartphone.
Where This Indoor Station Belongs
Luxury Villas & Estates
The 7-inch touchscreen sitting flush in an entry-hall wall — natural answering point without a chunky corded handset. Pair with an outdoor DS-KV8x13 or DS-KV6x13 IP villa door station.
Apartment Buildings & Body Corp
One indoor station per unit answering to a shared IP entrance station. Individual call routing per apartment, master station for building manager, Hik-Connect for smartphone answer when tenants are out.
Boutique Reception & Hospitality
Hotel front desk, day spa reception, medical practice — anywhere you want a discreet, premium-looking answering device with integrated camera preview.
Small Commercial & Serviced Offices
Suite entry monitoring — check the corridor camera from the desk before buzzing someone in. RS-485 and relay outputs let you integrate with electric strike locks and driveway barriers.
Technical Specifications
DS-KH8381-WTE1/Flush · Full Specifications
SKU
DS-KH8381-WTE1/Flush (AU stock)
Device Type
Hikvision Pro IP Video Intercom · Indoor Answering Monitor · Flush Mount
Operating System
Embedded Android
Display
7-inch Colour IPS Touchscreen
Display Resolution
1024 × 600
Audio Input / Output
Built-in omnidirectional microphone + built-in loudspeaker
Audio Enhancement
Acoustic Echo Cancellation (AEC) + Digital Noise Reduction · Full-Duplex
Ethernet
1× RJ-45 10/100 Mbps self-adaptive
Wi-Fi
802.11 b/g/n (2.4 GHz)
Alarm Inputs
8 channels · dry/wet contact configurable
Alarm Outputs
2× relay outputs (configurable per event)
Serial Interface
1× RS-485
Power
PoE 802.3af · or 12 VDC (2 A) local input
Power Consumption
≤ 12 W typical
Mounting
Flush mount · architectural bracket included
System Capacity
Fits Hikvision IP intercom systems up to 4,000 indoor stations per site
Camera Preview
Live view from any Hikvision IP camera on the same network
Remote Access
Hik-Connect (smartphone answer, remote unlock, snapshot review)
Client Software
iVMS-4200 · Hik-Central Professional
Compatible Door Stations
DS-KV8x13, DS-KV6x13, DS-KD8003-IME, DS-KD-ACF3 series and other Hikvision IP door stations
Operating Temperature
−10 °C to +55 °C
Operating Humidity
≤90 %
Warranty
3-Year Australian Warranty (back-to-base)
What You'll Need to Complete the System
Outdoor IP Door Station
Pair with a Hikvision IP door station — DS-KV8x13 or DS-KV6x13 for villas, DS-KD8003-IME for apartments. Handles the visitor-side call, camera and unlock command. Browse Hikvision IP door stations →
PoE Switch (Optional)
Single Ethernet cable powers and connects the indoor station via any PoE 802.3af port. If you don't have a PoE switch yet, a small unmanaged PoE switch is the cheapest way to power the whole intercom system. View network switches →
Frequently Asked Questions
Does it need a separate power supply if I use PoE?No. A single Cat 5e/6 Ethernet run from a PoE 802.3af switch carries both data and power. The 12 VDC input is only needed if you're powering the monitor over Wi-Fi (no Ethernet) or in a legacy install.
Can I view Hikvision IP cameras from the indoor station?Yes. Tap into any Hikvision IP camera on your network — during a call, or standby. Useful for checking the driveway camera before unlocking the front door, or the loading dock from the reception monitor.
What are the benefits of the flush-mount design?The flush bracket recesses the monitor into the wall cavity so the screen sits nearly flush with the plaster — no protruding chassis. Better aesthetics for luxury villas, boutique reception, apartment lobbies. Also more resistant to knocks and tampering than a surface mount.
Can I answer the intercom from my phone if I'm not home?Yes — the indoor station links to Hik-Connect on Android and iOS. Incoming door calls forward to your phone, you can talk to the visitor from anywhere and unlock the door remotely. Works over Wi-Fi or mobile data.
How many door stations can I connect?The Hikvision IP intercom system supports up to 8 door stations per indoor station and up to 4,000 indoor stations per project — from a single-villa install to a large apartment complex. Master stations can be added for a concierge / building manager.
What door strikes and locks does it work with?The 2 relay outputs are dry-contact and configurable — compatible with any standard electric strike, magnetic lock or gate motor that accepts a dry-contact input. Some door stations also have their own relay outputs — you can wire the strike from the door station side instead if it's closer to the door.
Downloads & Resources
DS-KH8381-WTE1/Flush Datasheet
Quick Start Guide
User Manual
Order the Hikvision DS-KH8381-WTE1/Flush from CCTV Guru
CCTV Guru is an authorised Australian reseller of the Hikvision IP video intercom range. The DS-KH8381-WTE1/Flush is the premium indoor answering monitor for luxury residential, apartment developments and boutique commercial installs. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch, project pricing for multi-unit installs, and specialist intercom advice from our Sydney team. Request a free quote or contact our Australian team.
