Hikvision AX Pro Series
Slim Weatherproof Curtain Motion Detector for Windows & Perimeters
The DS-PDC10AM-EG2-WB is an advanced 433 MHz wireless narrow-beam PIR curtain detector from Hikvision's AX PRO security ecosystem. Specifically engineered for window frames, balconies, corridors, and perimeter walls, its narrow 5° detection angle creates an invisible narrow barrier across vulnerable entry points. Featuring an IP65 weatherproof rating and active IR anti-masking technology, it delivers reliable outdoor intrusion detection without triggering false alarms from weather or surrounding activity.
Detection Area
10m Wall / 5m Ceiling
Anti-Masking & IP Rating
Active IR | IP65 Rated
Battery Lifespan
Up to 5 Years (2× CR123A)
Wireless Range
1,000m Open Area
Active IR Anti-Masking & Directional Detection Support
Equipped with Active Infrared (IR) anti-masking technology, the Hikvision DS-PDC10AM-EG2-WB continuously scans its optical lens for obstruction attempts (such as spray paint, paper, or foil), instantly raising an alarm if tampered with. Its intelligent directional detection algorithm allows users to configure motion triggers based on directional travel, letting occupants walk out to a patio without triggering alarms while instantly detecting unwanted entry from the outside.
IP65 Weatherproof Housing & Pet Immunity
Built to withstand harsh weather conditions from -25°C to +60°C. Includes digital temperature compensation and up to 12 kg pet immunity when wall-mounted to prevent false triggers from small animals.
Tri-X Two-Way Wireless Communication
Operates on 433 MHz two-way wireless technology with AES-128 encryption and frequency hopping against radio jamming, ensuring reliable long-range connection to AX PRO hubs.
Technical Specification Matrix
Detector Model
DS-PDC10AM-EG2-WB
Detection Method & Range
Passive Infrared (PIR) | Wall Mount: 10 m, Ceiling Mount: 5 m
Detection Angle & Zones
5° Narrow Curtain Angle | 32 Zones
Detectable Speed & Sensitivity
0.3 m/s to 2.0 m/s | Auto, Pet Immunity (up to 12 kg wall mounted)
Anti-Masking & Anti-Jamming
Active IR Anti-Masking | Frequency Hopping & AES-128 Encryption
Wireless Frequency & Range
433 MHz Tri-X Two-Way Wireless | 1,000 m Open Field
Power Source & Lifespan
2 × CR123A 3V Batteries | Up to 5 Years Standby Life
Ingress Protection & Operating Temp
IP65 Weather Resistance | -25 °C to +60 °C (-13 °F to 140 °F)
Dimensions & Mounting
29.2 mm × 134.4 mm × 39.5 mm | Wall or Ceiling Mount (L-Bracket Included)
Frequently Asked Questions
Can the DS-PDC10AM-EG2-WB be installed outdoors?
Yes. With its IP65 ingress protection rating and wide operating temperature range (-25°C to +60°C), it is designed for outdoor window frames, doorways, and covered perimeters.
How does directional detection benefit my security system?
Directional detection allows the detector to distinguish whether motion is moving inside-to-outside or outside-to-inside, letting occupants walk out without triggering an alarm while blocking incoming intrusions.
What does Active IR anti-masking do?
Active IR anti-masking detects any attempt to blind or cover the sensor lens with spray paint, plastic, tape, or objects, sending an immediate tamper signal to the AX PRO control panel.
Is a mounting bracket included in the box?
Yes, the detector comes supplied with a versatile L-shaped bracket adapter suitable for both wall and ceiling mounting configurations.
Technical Datasheet User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision AX Hybrid Pro Series
Flexible Output Expansion for AX Hybrid Pro Intrusion Alarm Systems
The DS-PM1-O4L-H is a professional wired 4-way low current relay expander engineered by Hikvision to extend the control capabilities of the AX Hybrid Pro intrusion alarm panel. Operating via Hikvision's high-speed Speed-X bus technology, this output module provides four onboard low current relays supporting 6 VDC to 30 VDC and up to 5A per channel. Designed for commercial, retail, and residential security automation, it enables seamless control of external devices such as strobe lights, sirens, access control gates, door strikes, and automation triggers.
Relay Outputs
4 Low Current Relays (5A)
Bus Communication
Speed-X Technology
Aux Power Output
12 VDC / Max 500mA
Anti-Tamper Shield
Front & Rear Tamper
High-Speed Speed-X Bus Cascading & Distributed Power Control
Engineered for complex alarm architectures, the Hikvision DS-PM1-O4L-H features dedicated uplink and downlink Speed-X bus ports. This allows installers to easily cascade multiple expander modules across long wiring runs back to the main AX Hybrid Pro panel. Additionally, the unit incorporates an auxiliary power output delivering up to 500mA (9 to 12 VDC) for directly powering low-voltage peripheral sensors, sirens, or status LEDs without requiring separate external power supplies.
4 Onboard Programmable Low Current Relays
Supports switching loads between 6 VDC and 30 VDC at up to 5A per output, allowing tailored response programming such as auto-locking doors, activating floodlights, or triggering external emergency dialers upon alarm events.
Dual Front & Rear Tamper Protection
Integrated micro-switches detect both front cover removal and wall-tear detachment, transmitting an immediate tamper alert signal via Speed-X bus to the control panel to prevent physical sabotage.
Technical Specification Matrix
Expander Model
DS-PM1-O4L-H
Relay Outputs
4 × Low Current Relays (6-30 VDC, up to 5A per relay)
Bus Interface
2 × Speed-X Bus (1 Uplink for panel, 1 Downlink for cascade)
Auxiliary Power Output
1 × 9 to 12 VDC output (Maximum 500 mA)
Power Supply Input
11 to 24 VDC, 1A
Power Consumption
Max current 153 mA @ 12 VDC; Quiescent current 70 mA @ 12 VDC
Tamper-Proof Protection
Supported (Front cover and rear wall tear-off protection)
LED Status Indicators
2 × LEDs (1 for Power status, 1 for Fault/Communication)
Dimensions & Weight
110 mm × 155 mm × 32.5 mm | Weight: 285 g
Frequently asked questions
What control panels are compatible with the DS-PM1-O4L-H?
The DS-PM1-O4L-H is designed specifically for Hikvision AX Hybrid Pro intrusion panels (such as DS-PHA48-EP / DS-PHA64-Kit) utilizing Speed-X bus communication.
How many relay expanders can be cascaded together?
Multiple expander modules can be chained sequentially using the dedicated Speed-X uplink and downlink ports up to the maximum bus address limit (addresses 0 to 63) supported by the control panel.
What type of loads can the relays handle?
Each onboard relay supports low voltage DC circuits between 6V and 30V with a maximum current of 5A, making it ideal for electronic locks, buzzers, status LEDs, and relay coils.
Does the expander require separate power configuration?
It operates on 11 to 24 VDC supplied via the bus or local power supply, drawing maximum 153 mA at 12 VDC during full relay activation.
Technical Datasheet
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
Hikvision DS-UPS-R/AU · Line-Interactive · AVR · Cold Start · 600 / 1000 / 2000 VA
Hikvision DS-UPS-R/AU Range
Hikvision DS-UPS-R/AU Series — Line-Interactive Back-Up UPS with AVR for CCTV & NVR Systems
The Hikvision DS-UPS-R/AU range is a line of line-interactive tower UPS units designed to keep your CCTV recording running through mains dropouts, brownouts and dirty power. Available in 600 VA / 360 W (small residential NVRs), 1000 VA / 600 W (mainstream commercial NVR + camera load) and 2000 VA / 1200 W (large PoE switches, multi-HDD NVRs, larger sites). Built-in Automatic Voltage Regulation (AVR) corrects mains sag and surge without dropping to battery, so the batteries only discharge during actual outages — extending battery life. Cold start lets you power the NVR from battery even when there's no mains at all (useful for planned outages). Every unit is rated at 230 VAC 50 Hz, ships with Australian mains plug + AU-standard IEC outlets, and is backed by 3-year Australian warranty from CCTV Guru.
Topology
Line-Interactive · AVR
Capacity Range
600 VA · 1000 VA · 2000 VA
Input / Output
230 VAC 50 Hz · AU Plug + IEC
Cold Start
Power on from Battery · No Mains Needed
Protection
Surge · Overload · Short-Circuit · RJ11
Warranty
3-Year AU · Battery Replaceable
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
Why a UPS Matters for a CCTV or NVR System
Every CCTV recorder has a hard drive that's writing continuously. When the mains flicks off mid-write — a lightning strike, a substation dip, someone tripping the RCD — the HDD doesn't get to flush its cache before the power dies. The result is corrupted footage, index errors, or in the worst case a bricked RAID array. A UPS gives the NVR 5-15 minutes of clean battery power on an outage; the NVR shuts down cleanly (via USB signalling on models that support it), the HDD flushes properly, and there's no corruption when the power comes back. Line-interactive UPS units go one better — they use AVR (Automatic Voltage Regulation) to smooth out mains sag and surge without discharging the battery, so battery life is preserved for the times you actually need it.
Line-Interactive Topology with AVR
Automatic Voltage Regulation corrects ±25% mains sag and surge without switching to battery. Extends battery lifespan (typical AU regional grid has 30-50 minor sag events per week that would otherwise cycle a cheap standby UPS to battery).
Cold Start Capability
Start the load from battery even when there's no mains at all. Useful for planned outages (running a camera off-grid for a temporary site check) or bringing up the NVR after an extended power failure while the mains is still being restored.
USB Auto-Shutdown Signalling
Micro-USB connection to the NVR — when battery drops below the safe threshold, the UPS signals the NVR to shut down cleanly. Works with most Hikvision NVRs out of the box (may require enabling in NVR settings).
Full Range of Protections
Overload, short-circuit, over-discharge, over-charge, and mains surge protection — plus RJ11 telephone / network surge protection pass-through on all models to protect ADSL/NBN modems.
Replaceable Battery
Sealed lead-acid battery module accessible via bottom cover — replaceable at end of life (typical 3-5 years, faster in high ambient temp). Uses standard 12 V SLA batteries (600 VA: 12 V 4.5 Ah, 1000 VA: 12 V 9 Ah, 2000 VA: 2 × 12 V 9 Ah).
Silent Fan-Free Operation (600 & 1000 VA)
The 600 VA and 1000 VA models are fan-free — silent when running from mains. Suitable for reception desks, home offices, sleeping areas. The 2000 VA has a low-noise thermally-controlled fan that only runs at high load or on battery.
Capacity Guide — Which VA Rating for Which NVR?
UPS runtime is capped by the smaller of two things: the load in watts (must be under the UPS's watt rating) and the battery capacity. Below is a practical sizing guide based on Hikvision's own NVR power consumption.
Sizing Guide · Which UPS for Which NVR
600 VA / 360 W · $101
4-8 channel M-Series NVRs with 1 HDD. Small residential / single-camera commercial. NVR draw ~40-60 W → ~15-20 min runtime.
1000 VA / 600 W · $149 (most popular)
8-16 channel NVRs with 1-2 HDD + a small PoE switch. Mainstream commercial. NVR + 8 cameras ~120-180 W → ~15-25 min runtime.
2000 VA / 1200 W · $269
16-32 channel NVRs with 2-4 HDD, larger PoE-heavy sites, DeepinMind AI NVRs. Also fits sites with modem + NVR + monitor + PoE switch. ~15-30 min runtime at typical load.
Rule of thumb: add up the wattage of everything you want protected (NVR + PoE switch + modem + a small monitor if used), then pick the UPS that's at least 1.5× that number in watts. Sizing headroom = longer runtime + longer battery life.
Full Specifications Comparison
DS-UPS-R/AU Range · Specification Comparison
Spec
600 VA · 360 W · $101 | 1000 VA · 600 W · $149 | 2000 VA · 1200 W · $269
SKU
DS-UPS600-R/AU · DS-UPS1000-R/AU · DS-UPS2000-R/AU
Topology
Line-Interactive with AVR (all three)
Capacity
600 VA / 360 W · 1000 VA / 600 W · 2000 VA / 1200 W
Input Voltage
230 VAC (140-300 VAC operating range) 50 Hz (all three)
Output Voltage
230 VAC ±10% (battery mode) · simulated sine wave
Transfer Time
Typically ≤ 6 ms (all three)
Battery
12 V 4.5 Ah SLA · 12 V 9 Ah SLA · 2× 12 V 9 Ah SLA
Recharge Time
≤ 8 hours to 90% (all three)
Output Sockets
2× IEC (AU) · 3× IEC (AU) · 4× IEC (AU) + optional 15 A AU socket on 2000 VA
Communication
USB (auto-shutdown) · RJ11 surge pass-through (all three)
Cold Start
Yes (all three)
Cooling
Passive (fan-free) · Passive (fan-free) · Low-noise thermal fan
Efficiency (AC mode)
≥ 92% (all three)
Operating Temperature
0 °C to +40 °C · humidity ≤90 % (non-condensing)
Dimensions (approx.)
90×140×195 mm · 100×145×280 mm · 145×195×340 mm
Weight
~4.5 kg · ~7.5 kg · ~14 kg
Certifications
RCM (AU) · CE · RoHS
Warranty
3-Year Australian Warranty (all three)
Frequently Asked Questions
What's the difference between VA and Watts?VA (volt-amps) is the apparent power rating; Watts is the real power the UPS can deliver. For CCTV/NVR loads, the wattage number is what actually matters — that's what you compare against the actual draw of your equipment. VA is what UPS marketing leads with because it's a bigger number.
How long will the UPS run my NVR for?Depends on load. A typical 8-camera Hikvision NVR draws ~120-180 W. At half load, the 1000 VA runs 15-25 min, the 2000 VA runs 25-40 min, and the 600 VA runs 5-10 min. Enough for a clean shutdown; not enough to keep recording through a multi-hour outage. For that, you want a larger UPS or a solar / genset solution.
Can it auto-shutdown my NVR?Yes — connect the USB cable from the UPS to the NVR's USB port and enable UPS shutdown in the NVR settings. When the battery drops to the safe threshold, the UPS signals the NVR to save-and-shutdown. Works with most Hikvision NVRs; check the NVR's user manual for the exact menu path.
Does it protect my ADSL/NBN modem too?Yes — plug the modem into one of the UPS's IEC outlets to power-protect it, AND run your ADSL/phone line through the RJ11 surge pass-through ports on the back to protect against surges coming down the phone line (lightning strikes on the copper network often destroy modems).
How often do I need to replace the battery?Typical SLA battery life is 3-5 years in Australian ambient conditions. Batteries in hot spaces (comms cabinets in summer) may only last 2-3 years. The UPS beeps when the battery fails its self-test — that's your signal. Replacement batteries are standard 12 V SLA sizes available from any battery supplier.
What's a "sine wave" vs "simulated sine wave" output?Pure sine wave outputs are true smooth AC — required by some sensitive equipment (medical, some audio gear). Simulated sine wave (also called modified sine wave) is what the DS-UPS-R/AU uses — perfectly fine for NVRs, PoE switches, modems, monitors, computers and 99% of home / commercial IT gear.
Order the Hikvision DS-UPS-R/AU from CCTV Guru
Australian stock across the entire DS-UPS-R/AU range — 600 VA, 1000 VA and 2000 VA. Select your capacity from the dropdown above. Free tech advice on sizing for your specific NVR + camera load — contact us with your parts list and we'll spec the right UPS for your project. Multi-unit and installer pricing available for site rollouts and body-corp maintenance contracts. Request a free quote or contact our Australian team.
Hikvision DeepinView · 8MP 4K · DarkFighter · 120 dB WDR · Face Capture
Hikvision DeepinView 4K Dome
Hikvision iDS-2CD7186G0-IZS — 8MP 4K DeepinView Motorised Varifocal Dome with DarkFighter, Deep Learning Face Capture & Perimeter Protection
The Hikvision iDS-2CD7186G0-IZS is a premium DeepinView intelligent dome camera engineered for critical infrastructure, commercial campuses, transport hubs and high-security enterprise sites where a standard AcuSense camera isn't enough. A 1/1.8" progressive CMOS streams true 4K UHD (3840 × 2160), and a 2.8-12 mm motorised varifocal lens gives you remote scene setup without a ladder. Backed by DarkFighter ultra-low-light (0.003 lux colour), 120 dB True WDR and 30 m Smart IR for round-the-clock imaging. Onboard deep-learning analytics deliver face capture, human/vehicle perimeter protection, multi-target detection and queue management — trained models running natively on the camera, no server needed. 3-year Australian warranty, back-to-base through Hikvision Australia by CCTV Guru.
Resolution
8 MP · 3840 × 2160 · 4K UHD
Lens
2.8-12 mm Motorised Varifocal · F1.2
Low-Light
DarkFighter · 0.003 lux · 30 m Smart IR
Wide Dynamic Range
120 dB True WDR
DeepinView AI
Face Capture · Perimeter · Multi-Target
Protection
IK10 · IP67 · Vandal-Resistant
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
DeepinView — What Actually Makes This Camera Different
DeepinView is Hikvision's dedicated AI camera family — one step above AcuSense in the range hierarchy. Where AcuSense filters false alarms on humans and vehicles, DeepinView runs trained deep-learning models on the camera itself: face capture with attribute detection, multi-target tracking across the frame, queue-length analytics, and perimeter classification tuned per-scene. The camera reduces false alarms by up to 90% versus a conventional analytics camera because it's actually recognising the object type — not just detecting motion. For sites where an operator can't afford to chase phantom alerts (retail loss prevention, transport terminals, campus perimeters), DeepinView pays for itself in labour hours saved.
DarkFighter Ultra-Low-Light Imaging
0.003 lux colour sensitivity at F1.2 with AGC on, 0 lux with IR. Full colour imaging in near-total darkness — useful for retail, hospitality and public spaces where night IR washout looks unwelcoming. Auto switch to monochrome IR when ambient drops further.
Face Capture with Attribute Detection
Onboard face capture with age / gender / glasses / mask attribute detection. Faces are extracted, cropped and timestamped in real time — reduces bandwidth compared to full-frame recording and simplifies post-incident search on the NVR side.
Perimeter Protection with H/V Classification
Line crossing, intrusion, region entrance and exit rules — all with human and vehicle classification so the alarm only fires on what actually matters. Ignores animals, foliage, headlights and precipitation.
Multi-Target Detection & Queue Management
Tracks multiple people or vehicles simultaneously across the frame — useful for entry counts, dwell-time analytics, and monitoring queue lengths at checkouts, boarding gates and reception areas.
120 dB True WDR
Handles high-contrast scenes — sunlit doorways backed by dark interiors, sunrise glare, indoor-to-outdoor transitions. Preserves detail in both the bright and dark regions of the frame simultaneously.
2.8-12 mm Motorised Varifocal Lens
Remote-adjustable focal length and auto-focus. Installers set the frame once from a laptop or NVR — no lens twiddling on a ladder. Wide 2.8 mm for entry monitoring; 12 mm long-throw for corridor or lot-boundary detail.
Ideal Deployments — Where DeepinView Earns Its Price
Retail Loss Prevention
Face capture at entries and checkout aisles, plus queue-length monitoring for staffing decisions. Deep-learning classification catches the shoplifter walk-out pattern that simple motion analytics misses.
Transport Terminals & Boarding Gates
High-throughput environments where operators can't watch every screen. Face capture streams the metadata to the NVR for later search; multi-target detection tracks flow rates and dwell times.
Campus Perimeters & Building Approaches
Human/vehicle classified line-crossing along fences, boundaries and access driveways — filters out wildlife, wind-blown vegetation and headlight reflections. Alerts operations only on real events.
Financial & Enterprise Reception
Face capture at building entries with attribute detection — feeds into visitor management workflows and after-hours access review. IK10 vandal resistance for public-space installs.
Technical Specifications
iDS-2CD7186G0-IZS · Full Specifications
SKU
iDS-2CD7186G0-IZS (AU stock)
Camera Type
Hikvision DeepinView Series · 4K Motorised Varifocal Dome · Deep Learning AI
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
3840 × 2160 (8 MP / 4K UHD)
Main Stream
25/30 fps @ 3840 × 2160 · 2560 × 1440 · 1920 × 1080
Lens
2.8-12 mm Motorised Varifocal · Auto-Focus · F1.2
Field of View
111°–43.7° (horizontal, wide to tele)
Min. Illumination
Colour: 0.003 lux @ F1.2 (AGC ON) · 0 lux with IR
Wide Dynamic Range
120 dB True WDR
Shutter Speed
1 s to 1/100,000 s
IR Distance
Up to 30 m · Smart IR intensity + angle auto-adjust
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG
Deep Learning Functions
Face Capture · Perimeter Protection (H/V classified) · Multi-Target Detection · Queue Management
Face Capture
Attribute detection (age / gender / glasses / mask) · Face library matching (via NVR)
Perimeter Rules
Line crossing · Intrusion · Region entrance · Region exiting · Human + Vehicle classification
Audio
1× audio in, 1× audio out (3.5 mm) · G.711 / G.722.1 / G.726 / MP2L2 · Audio detection
Alarm I/O
1 input · 1 output
Ethernet
1× RJ-45 10/100 Mbps
Protocols
IPv4/IPv6 · HTTPS · 802.1X · QoS · FTP · SMTP · UPnP · SNMP · DNS · DDNS · NTP · RTSP · TCP · UDP · IGMP · DHCP · Bonjour · SRTP · TLS
Storage
microSD / SDHC / SDXC up to 256 GB · NAS · ANR (Auto Network Replenishment)
API
ISAPI · Hikvision SDK · ONVIF (Profile S / G / T)
Client Software
iVMS-4200 · Hik-Central Professional · Hik-Connect
Power
12 VDC · 24 VAC · PoE 802.3af Class 3 (max ≈ 12 W with IR)
Weatherproof
IP67 (IEC 60529)
Vandal Resistance
IK10
Operating Temperature
−30 °C to +60 °C · humidity ≤95 %
Warranty
3-Year Australian Warranty (back-to-base)
Pair with a Hikvision AcuSeek or DeepinMind NVR
DeepinView cameras generate rich metadata — face captures, attribute tags, human/vehicle detections. That metadata is only fully useful if your NVR indexes it. Standard M-Series NVRs record the camera reliably, but for natural-language search across the recording, step up to an AcuSeek (VPro) or DeepinMind NVR that indexes the DeepinView metadata for post-incident search.
AcuSeek VPro Series
Natural-language search across recordings — "show me all people wearing red between 2 pm and 4 pm at Camera 3." Indexes face-capture metadata from DeepinView cameras. Browse AcuSeek NVRs →
DeepinMind AI NVRs
Enterprise AI NVR family — face-library matching, cross-camera tracking, alarm correlation. For 4-16+ DeepinView cameras. Browse DeepinMind range →
Frequently Asked Questions
What's the difference between DeepinView and AcuSense?AcuSense filters false alarms with human/vehicle classification. DeepinView runs deep-learning trained models on the camera — face capture with attribute detection, multi-target tracking, queue analytics, plus everything AcuSense does. DeepinView is the tier above AcuSense in Hikvision's range.
How does the motorised varifocal lens work?The 2.8-12 mm zoom and focus are controlled remotely via the NVR, web interface, iVMS-4200 or Hik-Connect app. Installers set the frame once from a laptop, then leave the camera alone. No ladder needed for scene adjustments.
Does face capture require a separate face-recognition server?Face capture (detection + attribute tagging + cropping) runs on the camera itself. Face recognition / matching against a library requires a DeepinMind NVR or Hik-Central server. The camera streams the captured face images for the server to match.
What power supply options does the camera support?PoE 802.3af Class 3, 12 VDC, or 24 VAC. Runs on any standard Hikvision NVR PoE port — no Hi-PoE injector needed. Full max power draw approximately 12 W with IR at full range.
Is the camera vandal- and weather-rated?Yes — IP67 weather-rated (dust-tight + immersion) and IK10 vandal-rated (20-joule impact resistance). Suitable for outdoor mounting under eaves, on approach paths, in car parks, on wall mounts and at accessible ceiling heights in indoor public spaces.
Can I integrate with a non-Hikvision VMS?Yes — the camera speaks ONVIF Profile S, G and T and RTSP. Compatible with Milestone XProtect, Genetec, Exacq, Immix and most other Australian VMS platforms. Note: DeepinView-specific metadata (face captures, attribute tags) is only fully indexed on Hikvision NVRs / Hik-Central.
Downloads & Resources
iDS-2CD7186G0-IZS Datasheet
Quick Start Guide
Network Camera User Manual
Order the Hikvision iDS-2CD7186G0-IZS from CCTV Guru
CCTV Guru is an authorised Australian reseller of the Hikvision DeepinView range. The iDS-2CD7186G0-IZS is a specialist AI camera — for buyers who understand the DeepinView tier and know why they want it. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch, and specialist pre-sales advice on face-capture / perimeter deployments from our Sydney team. Request a free quote or contact our Australian team.
Hikvision Pro IP Intercom · 7" Android Touchscreen · PoE + Wi-Fi · Flush Mount
Hikvision 7" IP Intercom Station
Hikvision DS-KH8381-WTE1/Flush — 7" Android IP Intercom Indoor Station with PoE, Wi-Fi, Echo Cancellation & Flush Mount Design
The Hikvision DS-KH8381-WTE1/Flush is a premium 7-inch Android-powered IP video-intercom indoor monitor — the in-room answering device paired with Hikvision's IP door stations for villas, apartments, luxury estates and commercial reception. A 1024 × 600 IPS touchscreen, embedded Android OS, and built-in echo cancellation deliver a phone-like conversation quality on the intercom call, while PoE 802.3af and dual-band Wi-Fi 802.11 b/g/n give you a single-cable install or fully wireless retrofit. Integrates with any Hikvision IP door station, unlocks the door on a tap, and shows live video from any Hikvision IP camera on your NVR so you can verify a visitor before granting access. 3-year Australian warranty from CCTV Guru.
Display
7" IPS Touch · 1024 × 600
Operating System
Embedded Android
Connectivity
PoE 802.3af + Wi-Fi b/g/n
Audio
Full-Duplex · AEC + Noise Suppression
Alarm I/O
8 Inputs · 2 Relay Outputs · RS-485
Mounting
Flush · Low-Profile Architectural
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
Why This Is the Indoor Station to Choose
The DS-KH8381-WTE1/Flush is the top-tier indoor answering unit in Hikvision's IP intercom range — chosen for premium builds where a plain 4-inch monitor won't cut it. The 7-inch IPS touchscreen sits flush with the wall behind an included architectural bracket; there's no protruding chassis to catch the eye. Android under the hood means the UI feels like a phone — swipe, tap, quick response. Full-duplex audio with echo cancellation gives you natural conversation with the person at the door, and you can pull up a live feed from any Hikvision IP camera on your NVR to verify a visitor before you unlock. Alarm inputs (8) and relay outputs (2) turn the monitor into a small building-management panel — connect door sensors, glass-break sensors, or trigger a driveway light on visitor arrival.
Full-Duplex Audio with Echo Cancellation
Acoustic Echo Cancellation (AEC) plus digital noise reduction. Two-way conversation without the walkie-talkie "you have to stop talking" awkwardness — critical for a commercial reception setting where the impression matters.
Camera Preview from the Intercom
Tap through to any Hikvision IP camera on your network. Verify a visitor from the driveway camera before you unlock the door, or check the delivery bay from the reception monitor. Cameras don't need to be on the same door station.
PoE + Wi-Fi Flexibility
PoE 802.3af for a single-cable retrofit; Wi-Fi 802.11 b/g/n for locations where running Ethernet is impractical. Also accepts 12 VDC for legacy or off-grid installs.
8 Alarm Inputs + 2 Relay Outputs
Wired inputs for door sensors, glass break, PIR or panic buttons. Two relay outputs to trigger driveway lights, sirens, gates or auxiliary door strikes. RS-485 bus for larger integrations.
Flush Architectural Mount
Included bracket sits the monitor cleanly in the wall cavity — no protruding chassis. Suits luxury villa entries, boutique-hotel reception, high-end apartment lobbies where visible-tech looks unwelcome.
Multi-Tenant Scalability
Fits Hikvision's IP intercom system for buildings up to 4,000 monitors across a single site — apartment complexes, mixed-use developments, campuses. Works with entrance stations, villa door stations, master stations and Hik-Connect for remote answer on smartphone.
Where This Indoor Station Belongs
Luxury Villas & Estates
The 7-inch touchscreen sitting flush in an entry-hall wall — natural answering point without a chunky corded handset. Pair with an outdoor DS-KV8x13 or DS-KV6x13 IP villa door station.
Apartment Buildings & Body Corp
One indoor station per unit answering to a shared IP entrance station. Individual call routing per apartment, master station for building manager, Hik-Connect for smartphone answer when tenants are out.
Boutique Reception & Hospitality
Hotel front desk, day spa reception, medical practice — anywhere you want a discreet, premium-looking answering device with integrated camera preview.
Small Commercial & Serviced Offices
Suite entry monitoring — check the corridor camera from the desk before buzzing someone in. RS-485 and relay outputs let you integrate with electric strike locks and driveway barriers.
Technical Specifications
DS-KH8381-WTE1/Flush · Full Specifications
SKU
DS-KH8381-WTE1/Flush (AU stock)
Device Type
Hikvision Pro IP Video Intercom · Indoor Answering Monitor · Flush Mount
Operating System
Embedded Android
Display
7-inch Colour IPS Touchscreen
Display Resolution
1024 × 600
Audio Input / Output
Built-in omnidirectional microphone + built-in loudspeaker
Audio Enhancement
Acoustic Echo Cancellation (AEC) + Digital Noise Reduction · Full-Duplex
Ethernet
1× RJ-45 10/100 Mbps self-adaptive
Wi-Fi
802.11 b/g/n (2.4 GHz)
Alarm Inputs
8 channels · dry/wet contact configurable
Alarm Outputs
2× relay outputs (configurable per event)
Serial Interface
1× RS-485
Power
PoE 802.3af · or 12 VDC (2 A) local input
Power Consumption
≤ 12 W typical
Mounting
Flush mount · architectural bracket included
System Capacity
Fits Hikvision IP intercom systems up to 4,000 indoor stations per site
Camera Preview
Live view from any Hikvision IP camera on the same network
Remote Access
Hik-Connect (smartphone answer, remote unlock, snapshot review)
Client Software
iVMS-4200 · Hik-Central Professional
Compatible Door Stations
DS-KV8x13, DS-KV6x13, DS-KD8003-IME, DS-KD-ACF3 series and other Hikvision IP door stations
Operating Temperature
−10 °C to +55 °C
Operating Humidity
≤90 %
Warranty
3-Year Australian Warranty (back-to-base)
What You'll Need to Complete the System
Outdoor IP Door Station
Pair with a Hikvision IP door station — DS-KV8x13 or DS-KV6x13 for villas, DS-KD8003-IME for apartments. Handles the visitor-side call, camera and unlock command. Browse Hikvision IP door stations →
PoE Switch (Optional)
Single Ethernet cable powers and connects the indoor station via any PoE 802.3af port. If you don't have a PoE switch yet, a small unmanaged PoE switch is the cheapest way to power the whole intercom system. View network switches →
Frequently Asked Questions
Does it need a separate power supply if I use PoE?No. A single Cat 5e/6 Ethernet run from a PoE 802.3af switch carries both data and power. The 12 VDC input is only needed if you're powering the monitor over Wi-Fi (no Ethernet) or in a legacy install.
Can I view Hikvision IP cameras from the indoor station?Yes. Tap into any Hikvision IP camera on your network — during a call, or standby. Useful for checking the driveway camera before unlocking the front door, or the loading dock from the reception monitor.
What are the benefits of the flush-mount design?The flush bracket recesses the monitor into the wall cavity so the screen sits nearly flush with the plaster — no protruding chassis. Better aesthetics for luxury villas, boutique reception, apartment lobbies. Also more resistant to knocks and tampering than a surface mount.
Can I answer the intercom from my phone if I'm not home?Yes — the indoor station links to Hik-Connect on Android and iOS. Incoming door calls forward to your phone, you can talk to the visitor from anywhere and unlock the door remotely. Works over Wi-Fi or mobile data.
How many door stations can I connect?The Hikvision IP intercom system supports up to 8 door stations per indoor station and up to 4,000 indoor stations per project — from a single-villa install to a large apartment complex. Master stations can be added for a concierge / building manager.
What door strikes and locks does it work with?The 2 relay outputs are dry-contact and configurable — compatible with any standard electric strike, magnetic lock or gate motor that accepts a dry-contact input. Some door stations also have their own relay outputs — you can wire the strike from the door station side instead if it's closer to the door.
Downloads & Resources
DS-KH8381-WTE1/Flush Datasheet
Quick Start Guide
User Manual
Order the Hikvision DS-KH8381-WTE1/Flush from CCTV Guru
CCTV Guru is an authorised Australian reseller of the Hikvision IP video intercom range. The DS-KH8381-WTE1/Flush is the premium indoor answering monitor for luxury residential, apartment developments and boutique commercial installs. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch, project pricing for multi-unit installs, and specialist intercom advice from our Sydney team. Request a free quote or contact our Australian team.
Hikvision 8MP 4K · ColorVu · Smart Hybrid Light · Live-Guard · F1.0
Hikvision 8MP 4K Live-Guard Bullet
Hikvision DS-2CD2086G2H-I2U/SL — 8MP 4K ColorVu Smart Hybrid Light Live-Guard Bullet Camera with F1.0 Lens, White Strobe & Two-Way Audio (2.8mm or 4mm, IP67)
The Hikvision DS-2CD2086G2H-I2U/SL is Hikvision's Pro Series Gen-2H bullet camera — the bullet-form counterpart to the popular G2H turret line. A 1/1.8" progressive-scan CMOS sensor combined with a fixed F1.0 super-aperture lens delivers true ColorVu 24/7 colour at 0.0008 lux; Smart Hybrid Light integrates white and 850 nm IR LEDs into a single 40 m array with three modes; AcuSense deep-learning classifies every motion event as human, vehicle or "other" and filters out ~90 % of foliage / rain / possum false alarms; and the /SL Live-Guard package adds a white strobe light, a built-in speaker for audible warnings and two-way audio via a built-in microphone. 120 dB WDR, IP67 weather protection, three variants available (2.8 mm White, 4 mm White, 2.8 mm Black) — same $379 for all three. Runs on standard PoE 802.3at Class 4 (18 W) from any Hikvision NVR PoE+ port. Australian stock, 3-year Australian warranty.
Resolution
8 MP · 3840 × 2160 · 4K UHD
Super-Aperture Lens
F1.0 · 2.8 mm or 4 mm
Smart Hybrid Light
White + IR · 3 modes · 40 m
AI Engine
AcuSense · Human + Vehicle
Live-Guard Deterrence
White Strobe · Speaker · 2-Way Audio
Protection
IP67 · 120 dB WDR · 3-Year AU
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
See Smart Hybrid Light + ColorVu in Action
The Hikvision Smart Hybrid Light demonstration shows the three illumination modes — IR-only at night for covert recording, white-light-only for 24/7 colour, or smart auto-blend where the white light burst is triggered only when AcuSense detects a human or vehicle. Same illuminator architecture powers this DS-2CD2086G2H-I2U/SL bullet.
Why the G2H Bullet Is the Right Camera for Commercial Sites
ColorVu — True 24/7 Colour at 0.0008 lux
1/1.8" CMOS + F1.0 super-aperture = 0.0008 lux colour imaging. Retains full natural colour under moonlight, dock lighting, forecourt lights or driveway lighting — no IR cut-over, no black-and-white night mode.
Smart Hybrid Light — 40 m Range
Combined white + 850 nm IR LEDs deliver up to 40 m of night-time illumination. Three modes: IR-only (covert), white-only (24/7 colour), or smart blend (white-light burst on AcuSense events).
AcuSense — Real Notifications, Not False Alarms
Deep-learning classification on the camera itself filters ~90 % of alerts caused by foliage, rain, possums and headlight glare — only human / vehicle detections trigger recording and Live-Guard deterrents.
Live-Guard /SL — Active Deterrence
White strobe + built-in speaker + built-in microphone for two-way audio. When AcuSense detects an intruder, the strobe flashes, the speaker plays the warning, and you can open a live talk-down via Hik-Connect.
Bullet Form for Long-Range Framing
The bullet housing (Ø 74 mm × 176 mm, 515 g) is ideal for wall-mount installs where you want the lens pointed along a specific axis — driveways, carparks, warehouse aisles, loading docks. Sun-shroud handles Australian glare.
Three Variants — One Price
Choose White 2.8 mm (widest), White 4 mm (longer reach) or Black 2.8 mm (blends with dark eaves and modern black cladding). All three variants are $379 — pick by what suits the install best, not by budget.
2.8 mm vs 4 mm — Which Lens for Your Install?
This camera ships with the buyer's choice of 2.8 mm or 4 mm fixed lens. Both have the same F1.0 super-aperture; they differ in field of view and how far they reach.
Lens-by-Use-Case Decision Guide
2.8 mm — Field of view
Horizontal 105.1° · Vertical 54.8° · Diagonal 128.2° — the widest option
2.8 mm — DORI (approx.)
Detect 89 m · Observe 35 m · Recognise 17 m · Identify 8 m
2.8 mm — Best for
Shopfront overview, retail entrance, driveway, small carpark, warehouse aisle, loading dock, front door of small commercial building. Captures the whole scene in one shot.
4 mm — Field of view
Horizontal ~90° · Vertical ~48° · Diagonal ~109° — narrower but reaches further
4 mm — DORI (approx.)
Detect 109 m · Observe 43 m · Recognise 21 m · Identify 10 m
4 mm — Best for
Long driveway, carpark aisle, gateway / approach view, warehouse loading zone with vehicles at the far end. More pixels on the target when you need face / plate identification at the far end.
Not sure which lens? For most Australian commercial installs, 2.8 mm is the safe starting point. Choose 4 mm when the scene is longer than ~15 m and you need to identify a face or read a plate at the far end.
White vs Black Housing — Which Colour?
Classic White
The default Hikvision commercial finish. Blends with pale eaves, off-white cladding, brick and light-coloured facades. Best for typical Australian residential and light commercial installs.
Midnight Black
Blends with dark eaves, black cladding, powder-coated aluminium, tinted-glass facades and modern architectural black exteriors. Popular for high-end retail, hospitality and premium commercial installs where the camera should disappear visually.
Technical Specifications
DS-2CD2086G2H-I2U/SL · Full Specifications
SKUs
DS-2CD2086G2H-I2U/SL (White · 2.8 mm) · DS-2CD2086G2H-I2U/SL-4MM (White · 4 mm) · DS-2CD2086G2H-I2U/SL-BLK (Black · 2.8 mm)
Camera Type
Hikvision Pro Series G2H · 8 MP / 4K UHD ColorVu Smart Hybrid Light AcuSense Live-Guard Fixed Bullet
Image Sensor
1/1.8" Progressive Scan CMOS · ColorVu
Max Resolution
3840 × 2160 (8 MP · 4K UHD)
Min. Illumination
Colour 0.0008 lux @ F1.0 (AGC ON) · 0 lux with supplement light
Shutter Speed
1/3 s to 1/100,000 s · Slow Shutter
Lens Options
2.8 mm fixed · F1.0 (105.1° H FOV) OR 4 mm fixed · F1.0 (~90° H FOV)
Day & Night
ICR (IR cut filter, mechanical)
Wide Dynamic Range
120 dB True WDR
Image Enhancement
BLC · HLC · 3D DNR · digital defog · EIS
SNR
≥ 52 dB
Supplement Light
Smart Hybrid Light — white + 850 nm IR · up to 40 m · 3 modes (IR / White / Smart Blend)
Angle Adjustment
Pan 0°-360° · Tilt 0°-90° · Rotation 0°-360°
Frame Rate (Main)
50 Hz: 25 fps @ 8 MP · 60 Hz: 30 fps @ 8 MP (4K UHD)
Streams
3 simultaneous (main / sub / third)
Video Compression
H.265+ · H.265 · H.264+ · H.264 · MJPEG (sub-stream)
Video Bit Rate
32 Kbps – 16 Mbps · CBR / VBR · SVC (H.264 + H.265) · ROI
AI — AcuSense
Human + vehicle classification · perimeter protection (line crossing / intrusion / region entry / region exit) · scene change · face capture
Live-Guard /SL Package
White strobe · audible warning · built-in speaker · built-in microphone · two-way audio
Basic Events
Motion (human + vehicle filter) · video tampering · exception
Linkage
FTP / NAS / microSD upload · centre notify · email · trigger recording · strobe flash · audible warning
Audio
Built-in microphone · built-in speaker · 2-way audio · G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC
Alarm I/O
1 input · 1 output
Ethernet
1 × RJ-45 10/100 Mbps self-adaptive
On-Board Storage
microSD / SDHC / SDXC up to 512 GB · NAS (NFS / SMB-CIFS) · ANR auto network replenishment
API & Protocols
ONVIF (Profile S / G / T) · ISAPI · SDK · ISUP
Cyber Security
HTTPS · 802.1X · IP filter · watermark · MAC host authentication · audit log · password protection
Client Software
iVMS-4200 · Hik-Connect · HikCentral Pro
Power Source
12 VDC ±25% (1.25 A, max 15 W) OR PoE 802.3at Class 4 (max 18 W) — runs on any Hikvision NVR PoE+ port
Material
Metal housing (aluminium alloy) · White or Black finish variant
Dimensions / Weight
Ø 74.4 mm × 176.3 mm · ≈ 515 g
Operating Temperature
−30 °C to +60 °C · ≤95 % humidity (non-condensing)
Weatherproof Rating
IP67 (IEC 60529-2013)
Approvals
CE-EMC · CE-LVD · UL · RCM (AS/NZS CISPR 32:2015) · IC · KC · CB · RoHS
Warranty
3-Year Australian Warranty (back-to-base)
DS-2CD2086G2H-I2U/SL (G2H Bullet) vs DS-2CD2387G3-LIS2UY/SL (G3 Turret)
Both are 8 MP / 4K ColorVu Live-Guard cameras with Smart Hybrid Light. The G2H bullet reaches further with 40 m Smart Hybrid Light and a longer-range form factor; the G3 turret has a slightly better low-light floor (0.0005 vs 0.0008 lux) and NEMA 4X anti-corrosion housing. Pick by form factor and site conditions.
DS-2CD2086G2H-I2U/SL (Bullet) vs DS-2CD2387G3-LIS2UY/SL (Turret)
Feature
DS-2CD2086G2H-I2U/SL (this — G2H Bullet)
DS-2CD2387G3-LIS2UY/SL (G3 Turret)
Form Factor
Bullet (Ø 74 × 176 mm, 515 g)
Turret (Ø 138 × 115 mm, 820 g)
Series
Pro Series G2H
Pro Series G3
Resolution
8 MP · 3840 × 2160 (4K UHD)
8 MP · 3840 × 2160 (4K UHD)
Image Sensor
1/1.8" CMOS · ColorVu
1/1.8" CMOS · ColorVu 3.0
Min. Illumination
0.0008 lux @ F1.0
0.0005 lux @ F1.0
Lens Options
2.8 mm or 4 mm · F1.0
2.8 mm or 4 mm · F1.0
Smart Hybrid Light
Up to 40 m · 3 modes
Up to 30 m · 3 modes
WDR
120 dB True WDR
130 dB Scene-Adaptive WDR
AI Engine
AcuSense human + vehicle
AcuSense human + vehicle
Live-Guard /SL
Strobe + speaker + 2-way audio
Strobe + speaker + 2-way audio
Anti-Corrosion
Not rated
NEMA 4X (Y suffix)
Colour Options
White or Black
White or Black
Power
PoE 802.3at Class 4 · 18 W
PoE 802.3at Class 4 · 17 W
Best For
Long, narrow scenes: driveways, warehouse aisles, loading docks, carpark rows, road frontages. Bullet form points the lens along a specific axis.
Coastal sites, wide-scene installs, ceiling / eave mounts. Turret is more compact and NEMA 4X-rated for saltwater environments.
View the G3 turret sibling: DS-2CD2387G3-LIS2UY/SL (8 MP 4K ColorVu Live-Guard Turret) →
Recording NVRs — Pair with an Affordable M-Series PoE NVR
This bullet runs on standard PoE 802.3at Class 4 and plugs directly into any Hikvision NVR's PoE+ port. For most Australian commercial installs, the M-Series NVRs are the right pairing.
DS-7604NI-M1/4P — 4CH · 4 PoE
Four-channel M-Series NVR with 4 PoE ports and single HDD bay. Right size for a small install with this bullet as the centrepiece. View DS-7604NI-M1/4P →
DS-7608NI-M2/8P — 8CH · 8 PoE · 2 HDD
Eight-channel NVR with 8 PoE ports and 2 HDD bays. Sweet spot for retail, hospitality and small commercial installs running 4-8 bullets. View DS-7608NI-M2/8P →
DS-7616NI-M2/16P — 16CH · 16 PoE · 2 HDD
Sixteen channels at full PoE for larger sites, body-corporate and multi-shop strata running 10-16 bullets. View DS-7616NI-M2/16P →
Need AI Search? AcuSeek / DeepinMind NVRs
For natural-language search across the fleet, step up to AcuSeek (VPro) or DeepinMind AI NVRs. Overkill for most SMB installs. Browse the AI NVR range →
Frequently Asked Questions
Bullet or turret — which should I choose?A bullet like this DS-2CD2086G2H-I2U/SL is best for long, narrow scenes — driveways, warehouse aisles, loading docks, carpark rows. The lens points along a specific axis. A turret is more compact and better for wider scenes mounted on an eave or ceiling. Both are IP67, both do ColorVu + Live-Guard — the choice is form factor + install geometry.
What's the difference between the three variants?Only lens focal length and housing colour. All three variants use the same sensor, same AcuSense AI, same Live-Guard package, same F1.0 aperture, same IP67 rating. 2.8 mm White (default) and 4 mm White differ in field of view (105° vs 90°); 2.8 mm Black has the identical lens as the White 2.8 mm but in a black metal housing.
What does "-SL" mean in the SKU?The /SL suffix is Hikvision's Live-Guard active-deterrence package. When AcuSense detects a human or vehicle, the camera flashes the white strobe, plays a warning through the built-in speaker, and lets you open two-way audio via Hik-Connect. Turns a passive recorder into an active deterrent.
What does "G2H" mean vs G2 or G3?G2 = original Pro Series Gen-2 (IR only, no ColorVu). G2H = Pro Series Gen-2 Hybrid (ColorVu + Smart Hybrid Light + Live-Guard added). G3 = latest Pro Series Gen-3 (ColorVu 3.0 + HikAI-ISP + slightly better low-light floor). The G2H sits between G2 and G3 in features and price.
Does it run on a standard Hikvision NVR PoE port?Yes — PoE 802.3at Class 4 (max 18 W), the standard PoE+ rating delivered by every Hikvision PoE NVR port. Single Cat 6 cable from NVR to camera. No special supply needed.
Is there anti-corrosion protection for coastal sites?Not on this specific model — this camera does not have the NEMA 4X anti-corrosion housing (there's no -Y variant). For genuinely coastal installs within ~2 km of the shoreline, choose the G3 turret with -Y suffix instead, or mount this bullet under deep cover so it doesn't see direct salt-spray exposure.
How does AcuSense filter false alarms?On-camera deep-learning classifies each motion event as human, vehicle or "other" (animals, foliage, rain, headlight glare). Only human / vehicle detections trigger alerts and Live-Guard deterrents. Typical sites see ~90% fewer false alerts than motion-only cameras.
Downloads & Resources
DS-2CD2086G2H-I2U/SL Datasheet
Hikvision Bullet Quick Start Guide
Hikvision Bullet User Manual
Order the Hikvision DS-2CD2086G2H-I2U/SL from CCTV Guru
CCTV Guru is an authorised Australian reseller of Hikvision ColorVu Live-Guard cameras. The DS-2CD2086G2H-I2U/SL bullet is our top pick for Australian commercial sites needing ColorVu 24/7 colour, 40 m Smart Hybrid Light, AcuSense AI filtering, and the /SL Live-Guard active-deterrence package in a bullet form factor. Choose from three variants at the same $379 price: 2.8 mm White, 4 mm White or 2.8 mm Black. Australian stock, 3-year Australian warranty. Building a complete system? Request a free quote or contact our Australian team.
Hikvision HeatPro · 256×192 Thermal + 4MP Optical · Fire Detection · 287m Range
Hikvision HeatPro Bi-Spectrum Thermal
Hikvision DS-2TD1228-7/QA — HeatPro Bi-Spectrum Thermal + Optical Turret Camera with 256×192 Thermal Sensor, 4MP Optical, Fire Detection & Temperature Measurement
The Hikvision DS-2TD1228-7/QA is a bi-spectrum thermal and optical turret camera from Hikvision's HeatPro Series — designed for Australian commercial and industrial sites that need both long-range perimeter detection and early fire / temperature-exception alarms from a single, cost-effective device. A 256 × 192 uncooled VOx thermal sensor paired with a 4 MP (2688 × 1520) optical CMOS gives you two synchronised video streams: the thermal image detects intruders, vehicles, fires and abnormal heat signatures regardless of ambient light; the optical image gives operators the visual confirmation they need to verify the alarm and dispatch a response. Vehicle detection out to 881 m, human detection out to 287 m, and fire detection out to 82.8 m — all on a single PoE 802.3af drop, no special power or cabling required. Backed by 3-year Australian warranty from CCTV Guru.
Thermal Sensor
256 × 192 · VOx · <40 mK NETD
Optical Sensor
4 MP · 2688 × 1520 · 120 dB WDR
Detection Range
881 m Vehicle · 287 m Human
Temperature Alarm
−20 °C to +150 °C · ±8 °C
Deterrence
30 m White Light + Voice Alarm
Protection
IP67 · −40 °C to +65 °C · PoE 802.3af
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
Why Bi-Spectrum Thermal Is the Right Camera for Certain Sites
A conventional visible-light camera has two problems that a thermal camera solves outright: it can't see through smoke, fog or total darkness, and it can't measure temperature. For sites where early fire detection, perimeter protection out to 287 m in complete darkness, or temperature-based loss prevention matter, a bi-spectrum thermal camera is a targeted tool — not a general-purpose surveillance camera. The DS-2TD1228-7/QA gives you both channels: the thermal camera detects, and the optical camera verifies. When the thermal sensor triggers an alarm on a human at 200 m or a fire at 80 m, the optical channel gives the operator or NVR the colour picture needed to make the response call.
256 × 192 Uncooled VOx Thermal Sensor
Vanadium Oxide Uncooled Focal Plane Arrays with 12 μm pixel pitch, NETD < 40 mK, spectral range 8–14 μm. Uncooled means no maintenance and long life — Hikvision offers a 10-year guarantee on the detector itself.
4 MP (2688 × 1520) Optical Verification Channel
Second sensor is a 1/2.7" progressive-scan CMOS at 4 MP with 120 dB True WDR and 0.0089 lux minimum illumination. Both channels stream simultaneously to the same NVR — operators see the thermal alarm AND the visual context at the same time.
Fire & Smoke Detection Algorithms
Built-in fire detection to 82.8 m and smoking detection to 10.35 m. Useful at warehouses, waste incineration plants, waste-processing sites, manufacturing workshops, timber yards, chemical stores and any site where an ignition source could go unnoticed until it's a serious fire.
Temperature Exception Alarms
Configurable temperature range from −20 °C to +150 °C with ±8 °C accuracy. Set up to 21 measurement rules (10 point rules, 10 area rules, 1 line rule) — alarm when a machine bearing runs hot, when refrigeration fails, when a battery bank overheats, when insulation catches or an exhaust exceeds safe limits.
VCA — Human + Vehicle Classification
Deep-learning video content analysis with line crossing, intrusion, region entrance and region exiting rules (up to 8 in total). Human/vehicle classification to filter out foliage, animals and lighting changes. VCA range up to 144.9 m for vehicles, 55.2 m for humans.
Active Deterrent — White Light + Voice
Built-in 30 m white-light strobe with adjustable flashing frequency and audio alarm with 2 preset voice alerts + 6 importable custom voice alerts. Triggered independently on VCA events or temperature exceptions.
Where This Camera Actually Belongs — Real Australian Use Cases
Waste, Recycling & Landfill Sites
The classic HeatPro use case — early fire detection in waste piles, tyre stockpiles, timber yards, greenwaste and lithium-battery recycling. A hot spot detected at 80 m gives you the time to intervene before it becomes a fire; a conventional camera would only see smoke once combustion is already established.
Construction Sites & Building Yards
Perimeter protection out to 287 m in total darkness. Thermal doesn't need any ambient light, so no floodlights on the site — cheaper on power, less community light-pollution complaints, and no dark corners for someone to hide in.
Warehouses, Manufacturing & Cold Storage
Temperature exception alarms on refrigeration compressors, freezer entrances, battery banks, transformer enclosures and any machinery where an overheat means expensive downtime. Combined with the optical verification channel, you get both the alarm and the visual record.
Substations, Utility & Solar Farms
Unmanned utility sites benefit from long-range perimeter detection and thermal monitoring of critical equipment. Detect an intruder at 287 m or a transformer developing a hot fault — both from one camera on one PoE run.
Villas, Rural Properties & Boundary Fences
Long rural fence lines that a standard optical camera can't monitor. Thermal detects a human at up to 287 m regardless of moon phase, cloud cover or vegetation shadowing.
Parking Lots, Loading Docks & Perimeter Roads
Where the perimeter is longer than a standard IP camera can cover, and where you want vehicle detection to 881 m (with narrow-angle 24.9° thermal lens) — useful at industrial estates, port fringes, mining site entrances and haul-road boundaries.
Detection Range Table (per EN 62676 & Johnson's Criteria)
Detection · Recognition · Identification Distances
Vehicle Detection (1.4 × 4.0 m target)
881 m — enough pixels to detect the vehicle exists
Vehicle Recognition (1.4 × 4.0 m target)
220 m — enough to classify as car / truck / larger vehicle
Vehicle Identification (1.4 × 4.0 m target)
110 m — enough to identify make / model detail
Human Detection (1.8 × 0.5 m target)
287 m — enough to detect a human is present
Human Recognition (1.8 × 0.5 m target)
72 m — enough to describe body type / posture
Human Identification (1.8 × 0.5 m target)
36 m — enough to identify individual features
VCA Analytics Range — Vehicles
144.9 m — reliable line-crossing / intrusion alarms
VCA Analytics Range — Humans
55.2 m — reliable human-classified alarms
Temperature Measurement (0.2 × 0.2 m object)
23.3 m — small hot spot on machinery
Temperature Measurement (1 × 1 m object)
116.7 m — large hot area (e.g. waste pile)
Fire Detection Range (0.2 × 0.2 m ignition)
82.8 m
Smoking Detection Range
10.35 m — cigarette-level heat signature
Technical Specifications
DS-2TD1228-7/QA · Full Specifications
SKU
DS-2TD1228-7/QA (AU stock)
Camera Type
Hikvision HeatPro Series · Bi-Spectrum (thermal + optical) Network Turret
THERMAL MODULE
Thermal Sensor
Vanadium Oxide Uncooled Focal Plane Arrays (VOx UFPA)
Thermal Resolution
256 × 192
Pixel Pitch
12 μm
Spectral Range
8 μm to 14 μm
NETD
< 40 mK (25 °C, F1.1)
Thermal Focal Length
6.9 mm
Thermal IFOV
1.74 mrad
Thermal Field of View
24.9° × 18.7° (H × V)
Thermal Aperture
F1.0
Min. Focusing Distance
1.3 m
Thermal Digital Zoom
×2, ×4
Detector Warranty
10-year manufacturer guarantee on the thermal detector
OPTICAL MODULE
Optical Sensor
1/2.7" Progressive Scan CMOS
Optical Resolution
2688 × 1520 (4 MP)
Min. Illumination
0.0089 lux @ F1.6 (AGC ON) · 0 lux with IR
Shutter Speed
1 s to 1/100,000 s
Optical Focal Length
6.4 mm
Optical Field of View
53.0° × 28.0° (H × V)
Optical Aperture
F1.6
Wide Dynamic Range
120 dB True WDR
ILLUMINATOR & DETERRENCE
IR Distance
Up to 15 m · 850 nm · smart IR intensity + angle auto-adjust
White Light Range
Up to 30 m · adjustable flashing frequency
Audio Alarm
2 preset voice alerts (VCA + Temperature Exception) + 6 importable custom voice alerts
SMART FUNCTIONS
VCA Rules
Up to 8 rules across 4 types: line crossing · intrusion · region entrance · region exiting · human + vehicle classification
Temperature Measurement
Up to 21 rules across 3 types (10 points, 10 areas, 1 line) · configurable per rule
Temperature Range
−20 °C to +150 °C (−4 °F to +302 °F)
Temperature Accuracy
±8 °C (±14.4 °F)
Additional Analytics
Fire detection · Smoking detection · Sun-reflection filter
Image Processing
Linear · histogram · self-adaptive thermal AGC · DDE · 3D DNR
VIDEO & AUDIO
Thermal Main Stream
25 fps @ 1280 × 720 / 704 × 576 / 640 × 512 / 320 × 240
Optical Main Stream
25/30 fps @ 2688 × 1520 / 1920 × 1080 / 1280 × 720
Video Compression
H.265 · H.264 (main) · MJPEG (sub-stream)
Audio Compression
G.722.1 · G.711u/a · MP2L2 · G.726 · PCM
Audio Input
1 × 3.5 mm Mic in / Line in
Audio Output
Linear level, 600 Ω
Alarm I/O
1 input (0–5 VDC) · 1 output (configurable actions)
NETWORK
Ethernet
1 × RJ-45 10/100 Mbps self-adaptive
Protocols
IPv4/IPv6 · HTTPS · 802.1X · QoS · FTP · SFTP · SMTP · UPnP · SNMP · DNS · DDNS · NTP · RTSP · RTCP · RTP · TCP · UDP · IGMP · ICMP · DHCP · PPPoE · Bonjour · SRTP · TLS
Storage
microSD / SDHC / SDXC up to 256 GB · NAS (NFS · SMB/CIFS) · ANR (Auto Network Replenishment)
API
ISAPI · Hikvision SDK · ISUP · ONVIF (Profile S / G)
Simultaneous Live View
Up to 20 channels
Users
Up to 32 users · 3 levels (Administrator / Operator / User)
Security
User authentication · MAC binding · HTTPS · 802.1X (EAP-MD5, EAP-TLS) · IP address filter
Client Software
iVMS-4200 · Hik-Connect
GENERAL
Power Source
12 VDC (max 6 W) OR PoE 802.3af Class 3 (max 6.5 W) — standard PoE, runs on any Hikvision NVR
Communication Interface
RS-485 (half-duplex)
Weatherproof
IP67 (IEC 60529)
Lightning Protection
TVS 6,000 V · surge + voltage transient protection
Operating Temperature
−40 °C to +65 °C · humidity ≤95 %
Dimensions / Weight
138.3 mm × 138.3 mm × 123.1 mm · ≈ 940 g
Web Browser
Chrome 57+ · Firefox 52+ · IE 11 (plug-in)
Warranty
3-Year Australian Warranty (back-to-base)
Recording NVRs — Pair with an M-Series or AcuSeek NVR
The bi-spectrum thermal camera streams two channels (thermal + optical) but only consumes one channel on your NVR via the primary IP stream. Runs on standard PoE 802.3af — plugs directly into any Hikvision NVR PoE port. For thermal metadata (temperature exception events, fire alarms, VCA rules), the M-Series NVRs record everything reliably; the AcuSeek / DeepinMind AI NVRs additionally index the AI metadata for post-incident search.
DS-7604NI-M1/4P — 4CH · 4 PoE
Four-channel M-Series NVR with 4 built-in PoE ports and 4K HDMI output. Sized for a single thermal camera plus 3 verification cameras — typical single-perimeter thermal install. View DS-7604NI-M1/4P →
DS-7608NI-M2/8P — 8CH · 8 PoE · 2 HDD
Eight-channel M-Series NVR with 8 PoE ports and two HDD bays. Suits a multi-thermal industrial site — 2-3 thermal cameras plus 4-5 conventional coverage cameras. View DS-7608NI-M2/8P →
DS-7616NI-M2/16P — 16CH · 16 PoE · 2 HDD
Sixteen channels for larger sites — multiple thermal cameras around a fence line, plus verification cameras at every gate. View DS-7616NI-M2/16P →
AcuSeek / DeepinMind — for AI Metadata Search
For sites running multiple HeatPro cameras and wanting natural-language search across the recording ("show me all human perimeter alarms between 10 pm and 4 am on Fence 3"), step up to an AcuSeek (VPro) or DeepinMind NVR. Browse the AI NVR range →
Compatible Mounts & Accessories
DS-1273ZJ-140 — Wall Mount
Standard wall-mount bracket sized for the HeatPro turret. Common install pattern for fence-line perimeter cameras where the housing sits on a mid-height wall or column bracket. Also available in black (DS-1273ZJ140-BLACK).
DS-1271ZJ-140 — Pendant Mount
Pendant mount for hanging the camera from an overhead structure — gantry, canopy, roof edge or dedicated pole cross-arm. Suits sites where you want the camera looking down along a perimeter.
DS-1275ZJ-SUS / DS-1276ZJ-SUS — Pole & Corner
Stainless-steel-banded pole mount and corner-of-building bracket for perimeter-fence poles, gate columns, tower mounts and building corners overlooking two perimeter zones.
DS-1280ZJ-DM21 — Junction Box
Anti-corrosion junction box for clean cable termination behind the wall or pendant mount. Recommended for any exposed outdoor install to keep conduit joins out of weather.
Frequently Asked Questions
What is "bi-spectrum" and why do I need two sensors?Bi-spectrum = one thermal sensor + one optical (visible-light) sensor in the same housing. The thermal sensor detects at distances and in conditions where a visible camera can't see (total darkness, smoke, fog, glare). The optical sensor verifies — gives you the colour picture needed to identify who or what triggered the alarm. Both stream simultaneously to your NVR.
How accurate is the temperature measurement?±8 °C accuracy across a range of −20 °C to +150 °C. Precise enough for exception alarms (a bearing running 40 °C hot, a battery bank overheating, a waste pile igniting) — but not a substitute for a calibrated industrial pyrometer if you need medical-grade or metrology-grade accuracy. For loss-prevention and fire-prevention use cases, ±8 °C is more than enough.
Will fire detection actually trigger on a small fire at 82.8 m?Yes for a hot spot of at least 0.2 × 0.2 m (per Hikvision's spec). That covers a typical ignition source — a burning cardboard box, a smouldering tyre, a hot piece of lithium-battery debris. A single flickering flame or a lit cigarette is below this threshold — for that, the smoking detection algorithm works up to about 10 m.
What's the low-light performance of the optical channel?0.0089 lux at F1.6 — good for suburban night ambient lighting. Below that, the optical channel uses its 15 m built-in IR illuminator to see; the thermal channel doesn't need any light at all and runs at full detection range 24/7.
Does it run on standard PoE?Yes — PoE 802.3af Class 3 (max 6.5 W). Runs on any Hikvision NVR built-in PoE port, no special injector or Hi-PoE switch needed. Also accepts 12 VDC for solar / battery-powered remote installs.
How high should I mount the camera for the full 287 m human detection range?For maximum detection range along a flat perimeter, mount the camera at 3-4 m height with a slight downward tilt of 5-10°. Higher mounts extend the horizon but reduce the vertical FOV at close range. For fence-line coverage, aim the thermal FOV (24.9°) parallel to the fence — that gives you the longest detection stripe along the line.
Can I integrate this with an existing non-Hikvision VMS?Yes. The camera speaks ONVIF Profile S and Profile G and RTSP for both thermal and optical streams. Compatible with most Australian VMS platforms — Milestone XProtect, Genetec, Exacq, Immix Central Station, etc. Note that some advanced Hikvision-specific analytics (temperature exception metadata) only surface fully on Hikvision NVRs and iVMS-4200.
What warranty covers the thermal detector specifically?Hikvision offers a 10-year guarantee on the thermal detector itself (per the datasheet) — the most expensive part of the camera. The full camera assembly ships with a 3-year Australian Hikvision warranty, serviced back-to-base through Hikvision Australia by CCTV Guru.
Downloads & Resources
DS-2TD1228-7/QA Datasheet
Hikvision Thermal Camera Quick Start Guide
Hikvision Thermal Camera User Manual
Order the Hikvision DS-2TD1228-7/QA from CCTV Guru
CCTV Guru is an authorised Australian reseller of the Hikvision HeatPro thermal camera range. The DS-2TD1228-7/QA is the right camera for Australian sites needing genuine thermal perimeter detection, fire prevention or temperature exception monitoring — waste sites, construction, warehouses, manufacturing, substations, solar farms, rural properties. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch, multi-camera project pricing, and specialist thermal-imaging pre-sales advice from our Sydney team. Request a free quote or contact our Australian team — thermal camera specification requires more thought than a standard IP camera, and we're happy to walk you through the range calculations for your specific site.
Hikvision AcuSense DVR · 16CH · 5MP · 5-in-1 Hybrid · 4K HDMI Hikvision 16CH AcuSense Turbo DVR
Hikvision iDS-7216HUHI-M2/XT — 16-Channel AcuSense Turbo HD DVR with 5MP Recording, 2 SATA HDD Bays, 4K HDMI Output & 5-in-1 Hybrid Input
The Hikvision iDS-7216HUHI-M2/XT is a Gen-2 AcuSense Turbo HD DVR for Australian sites that want to bring modern AI to existing analogue camera cabling — or run a hybrid analogue-plus-IP install without replacing the whole system. 16 BNC video inputs accept any mix of HDTVI, AHD, HDCVI or CVBS analogue cameras up to 8 MP (5-signal auto-detect), plus up to 32 channels of IP camera input (each up to 8 MP) for a hybrid mix of new IP + legacy coax. The on-board AcuSense deep-learning engine runs Motion Detection 2.0 across all 16 analogue channels for human + vehicle classification, plus Perimeter Protection on up to 8 channels, Face Recognition on up to 4 channels, and AcuSearch technology on 8 channels — dramatically cutting false alarms from foliage, rain, possums and headlight glare compared with legacy motion-only DVRs. H.265 Pro+ compression, 4K HDMI output, 2 SATA HDD bays (up to 12 TB each = 24 TB total), Gigabit Ethernet, ONVIF and Hik-Connect. Australian stock, 3-year Australian warranty.
Channel Count
16CH Analog + 32CH IP Hybrid
Storage
2 SATA · 12 TB per bay · 24 TB max
AI Engine
AcuSense · Face + Perimeter
Hybrid Input
5-in-1: TVI · AHD · CVI · CVBS · IP
Video Output
4K HDMI · VGA · CVBS
Compression
H.265 Pro+ · 3-Year AU
3-Year AU Warranty
Fast AU Shipping
Australian Tech Support
Why Choose the Turbo HD DVR Path over a Pure IP NVR
An AcuSense Turbo HD DVR is the right recorder for one specific scenario: you have (or plan to install) analogue cameras over coax, and you want modern AI on top. Analogue is still the cheapest way to run video signal over long distances — no PoE budget to manage, no network segmentation to plan, no VLAN debugging. Bring an existing analogue install into 2026 by putting an AcuSense DVR at the head-end. Or spec a hybrid install with the coax cameras where the wiring is easy, and IP cameras where the extra features (ColorVu, Live-Guard) actually matter.
5-Signal Hybrid Input
Every BNC input auto-detects and adapts to HDTVI, AHD, HDCVI, CVBS or IP — no jumpers, no per-channel configuration. Mix camera brands and standards freely across the 16 analogue channels; add up to 32 IP cameras on top over Gigabit Ethernet.
Motion Detection 2.0 with Human + Vehicle Filter
Hikvision's deep-learning motion detection runs by default on all 16 analogue channels, classifying every event as human, vehicle or "other" (leaves, lights, rain). Cuts false alarms by ~90% vs a legacy DVR while giving you searchable metadata by object type.
Perimeter Protection + Face Recognition
Enable Perimeter Protection on up to 8 channels (line crossing, intrusion, region entry / exit — human + vehicle filtered) and Face Recognition on up to 4 channels against a face picture library of up to 16 libraries with picture comparison alarms.
AcuSearch — Fast Post-Incident Review
8-channel AcuSearch lets you jump through recorded footage by object type or event class — find every vehicle that entered a driveway, every face captured at a gate, every perimeter breach event on a specific channel, in a fraction of the time a linear timeline scrub takes.
See Hikvision AcuSense in Action
AcuSense is the on-device deep-learning engine that classifies every motion event as human, vehicle or "other" and filters out the false alarms. The same AI runs on this DVR (recording side) as on Hikvision's current-generation cameras.
Recording, Encoding & Playback
H.265 Pro+ Compression
H.265 Pro+ significantly reduces the storage footprint vs H.264 or standard H.265 while preserving image quality. Enable it per-channel to double the retention on the same HDD without touching bitrate or resolution.
Recording Up to 8 MP
Records each analogue channel at its native resolution up to 8 MP / 4K (at 8 fps) or 5 MP / 3K (at 12 fps) or 4 MP (at 15 fps) or 1080p / 720p at full frame rate. Match the recording profile to what each camera actually needs.
2 SATA HDD Bays · Up to 24 TB
Two SATA HDD bays, each accepting up to 12 TB drives — 24 TB maximum onboard storage. Use dual drives for RAID / mirroring at the site, or single-drive for cost-optimised retention.
4K HDMI + VGA Simultaneous Output
Local monitor output supports 4K (3840 × 2160) @ 30 Hz HDMI and 1080p VGA simultaneously — useful for a wall-mounted 4K spot monitor plus an operator VGA workstation running the same live view.
Technical Specifications
iDS-7216HUHI-M2/XT · Full Specifications
SKU
iDS-7216HUHI-M2/XT (AU stock)
Recorder Type
Hikvision AcuSense Series Gen-2 · 16-Channel 1U Turbo HD DVR (Hybrid analogue + IP)
Analog Video Input
16-ch BNC (1.0 Vp-p, 75 Ω) · supports coaxitron connection
IP Camera Input
Up to 32-ch IP, each up to 8 MP
5-Signal Auto-Detect
HDTVI · AHD · HDCVI · CVBS · IP (per channel)
HDTVI Input Support
8 MP @ 12/15 fps · 3K @ 20/25 fps · 5 MP @ 20 fps · 4 MP @ 25/30 fps · 1080p @ 25/30 fps · 720p @ 25/30 fps
AHD Input Support
5 MP @ 20 fps · 4 MP @ 25/30 fps · 1080p @ 25/30 fps · 720p @ 25/30 fps
HDCVI Input Support
8 MP @ 12/15 fps · 3K @ 25 fps · 5 MP @ 20 fps · 4 MP @ 25/30 fps · 1080p @ 25/30 fps · 720p @ 25/30 fps
CVBS Input
PAL / NTSC
Video Compression
H.265 Pro+ · H.265 Pro · H.265 · H.264+ · H.264
Encoding Resolution
8 MP / 5 MP / 3K / 4 MP / 3 MP / 1080p / 720p / WD1 / 4CIF / VGA / CIF
Encoding Frame Rate (Main)
8 MP @ 8 fps · 3K @ 12 fps · 5 MP @ 12 fps · 4 MP @ 15 fps · 8 MP Lite @ 15 fps · 3 MP @ 18 fps · 1080p/720p/lower @ 25/30 fps
Encoding Frame Rate (Sub)
WD1 / 4CIF / CIF @ 25 fps (PAL) or 30 fps (NTSC)
Video Bit Rate
32 Kbps – 10 Mbps
Audio Compression
G.711u · 64 Kbps
Decoding Capability
Up to 24-ch 1080p @ 30 fps
Synchronous Playback
16 channels simultaneously
AI — Motion Detection 2.0
All 16 analogue channels · human + vehicle classification · filters foliage / rain / lights false alarms
AI — Perimeter Protection
Up to 8 channels (line crossing / intrusion / region entry & exit · human + vehicle filter)
AI — Face Recognition
Up to 4 channels face capture + comparison · up to 16 face picture libraries · face DB backed up on flash
AI — AcuSearch
8 channels · quick search by object / event type on the timeline
AI — Facial Detection
4-ch face picture capture
HDMI Output
1 × HDMI · 4K (3840 × 2160) @ 30 Hz · 2K @ 60 Hz · 1080p @ 60 Hz · lower
VGA Output
1 × VGA · 1080p / 1280 × 1024 / 720p @ 60 Hz
Simultaneous Output
HDMI + VGA can output independent or mirrored views
CVBS Output
1 × BNC · PAL 704 × 576 / NTSC 704 × 480
Audio Output
1 × RCA (linear, 1 KΩ)
Audio Input
1 × RCA (2.0 Vpp, 1 KΩ) · up to 16-ch via coaxial cable
Two-Way Audio
1-ch RCA (via audio input) · all-channel HDTVI two-way audio via coax
Network
1 × RJ-45 10/100/1000 Mbps Gigabit self-adaptive
Network Protocols
TCP/IP · PPPoE · DHCP · Hik-Connect · DNS · DDNS · NTP · SADP · NFS · iSCSI · UPnP · HTTPS · ONVIF · ISUP
Total Network Bandwidth
256 Mbps
Remote Connections
128
HDD Bays
2 × SATA · up to 12 TB per drive = 24 TB max onboard
Serial Interface
RS-485 (half-duplex)
USB Interfaces
Front: 1 × USB 2.0 · Rear: 2 × USB 3.0
Alarm I/O
Not standard — optional to support
Client Software
iVMS-4200 · Hik-Connect · HikCentral Pro
Power Supply
12 VDC, 5 A · consumption ≤ 60 W
Working Temperature
−10 °C to +55 °C · 10 % to 90 % humidity (indoor equipment room)
Dimensions (W × D × H)
385 × 315 × 52 mm (1U form factor)
Weight
≤ 2.1 kg (bare unit)
Approvals
RCM (AS/NZS) · CE-EMC · CE-LVD · FCC
Warranty
3-Year Australian Warranty (back-to-base)
iDS-7216HUHI-M2/XT (DVR) vs DS-7616NI-M2/16P (IP NVR) — Which Recorder Path?
If you're starting from scratch with all new IP cameras, an IP NVR like the DS-7616NI-M2/16P is the simpler pick — PoE built-in, no analogue cabling to plan, current-generation feature set. If you have existing analogue coax you want to keep, or you're adding cameras to a site with long cable runs where new Cat 6 isn't practical, the Turbo HD DVR is the right recorder. This DVR also hybrid-supports up to 32 IP cameras on top of the 16 analogue channels — so you're not locked out of IP.
iDS-7216HUHI-M2/XT (Turbo HD DVR) vs DS-7616NI-M2/16P (IP NVR)
Feature
iDS-7216HUHI-M2/XT (this — Turbo HD DVR)
DS-7616NI-M2/16P (IP NVR sibling)
Recorder Type
Hybrid DVR (analogue + IP)
Pure IP NVR
Analogue Camera Support
16 BNC channels · 5-in-1 hybrid (TVI/AHD/CVI/CVBS/IP)
None
IP Camera Support
Up to 32 IP channels @ 8 MP each
16 IP channels with 16 built-in PoE ports
PoE Ports
None (needs external PoE switch for IP cameras)
16 built-in PoE ports (plug-and-play)
AI Engine
AcuSense · face recognition (4-ch) · perimeter (8-ch) · AcuSearch (8-ch)
AcuSense per-camera (AI runs on the camera itself)
Max Recording Resolution
8 MP @ 8 fps / 5 MP @ 12 fps / 4 MP @ 15 fps / 1080p full-rate
8 MP @ 30 fps per channel (native IP)
Compression
H.265 Pro+ · H.264+
H.265+ · H.264+
HDD Bays
2 SATA · up to 24 TB total
2 SATA · up to 20 TB total
HDMI Output
4K @ 30 Hz
4K @ 30 Hz
Best For
Legacy analogue upgrades, hybrid installs, sites with long coax runs, retail chains still on TVI/AHD/CVI cameras, budget commercial where new Cat 6 isn't practical.
Greenfield IP installs, homes / small business with plug-and-play PoE setup, sites installing all-new Hikvision IP cameras.
For the IP NVR sibling: DS-7616NI-M2/16P (16-channel IP NVR with 16 built-in PoE) →
Compatible HDDs, Cameras & Accessories
HDD — WD Purple / Seagate SkyHawk
Fits any 3.5" SATA HDD up to 12 TB per bay. Use surveillance-grade drives (WD Purple, Seagate SkyHawk) for 24/7 recording duty. Two bays for RAID 1 mirroring or dual-drive parallel recording.
Hikvision Turbo HD Analogue Cameras
Compatible with any Hikvision Turbo HD (HDTVI) analogue camera — 5 MP, 4 MP, 3K, 8 MP, 1080p. Also accepts other-brand AHD, HDCVI and legacy CVBS analogue cameras via the 5-signal auto-detect BNC inputs.
Hikvision IP Cameras (up to 32)
Add up to 32 IP camera channels over the Gigabit Ethernet — modern G3 turrets, DeepinView cameras, Value PTZs, TandemVu — any Hikvision IP camera Hik-Connect supports.
External PoE Switch (for IP cameras)
This DVR does not have built-in PoE. Add a separate PoE switch if you're running IP cameras — sized to your channel count and PoE budget. Talk to us if you're not sure what capacity you need.
Frequently Asked Questions
What's the difference between a DVR and an NVR?
A DVR (Digital Video Recorder) records from analogue cameras connected by coaxial (BNC) cable. An NVR (Network Video Recorder) records from IP cameras over Ethernet. This unit is a hybrid DVR — it does both: 16 analogue BNC inputs + up to 32 IP channels over Gigabit.
Will it work with my existing analogue cameras?
Almost certainly yes. The DVR's BNC inputs are 5-signal auto-detect — they'll adapt to HDTVI, AHD, HDCVI or CVBS automatically. If your existing cameras use any of those four standards (nearly all analogue cameras from the last decade do), plug them in and they'll work.
Does AcuSense work on all cameras?
The AcuSense AI runs on the DVR itself (Motion Detection 2.0 with human/vehicle classification) on all 16 analogue channels. Perimeter Protection is limited to 8 channels, Face Recognition to 4 channels. The AI works with any analogue camera plugged in — it doesn't require an AcuSense-branded camera.
How much recording storage do I need?
At 4 MP @ 15 fps H.265+ per channel, 16 channels recording 24/7 for 1 month uses roughly 10-14 TB. With 24 TB total capacity (two 12 TB drives), you can retain 6-8 weeks of continuous recording or 3-4 months on motion-only recording. Ask us for a sizing estimate for your specific setup.
Can I mix analogue and IP cameras?
Yes — that's the point of a hybrid DVR. You can run any combination of the 16 analogue inputs and up to 32 IP inputs simultaneously. Common install pattern: existing coax cameras kept on the analogue side, new outdoor cameras added as IP where you want ColorVu or Live-Guard features.
Does the DVR have built-in PoE for IP cameras?
No — unlike an NVR with built-in PoE ports, this DVR only has a single Gigabit uplink. If you're running IP cameras, plug them into a separate PoE switch on the same network. The DVR will discover and add them via ONVIF or Hik-Connect.
What's the audio capability?
1 line-in audio (RCA), 1 line-out audio (RCA), 1 two-way audio channel. Plus audio-over-coax on all 16 HDTVI channels if your cameras support it — no separate audio cable needed for HDTVI cameras with a built-in mic.
Downloads & Resources
iDS-7216HUHI-M2/XT Datasheet Hikvision DVR Quick Start Guide Hikvision DVR User Manual
Order the Hikvision iDS-7216HUHI-M2/XT from CCTV Guru
CCTV Guru is an authorised Australian reseller of the Hikvision Turbo HD AcuSense DVR range. The iDS-7216HUHI-M2/XT is the right recorder for Australian sites with existing analogue camera cabling that want modern AI, or for hybrid analogue + IP installs. 16 analogue channels, 32 IP channels, 4K HDMI output, AcuSense face recognition and perimeter protection, 2 SATA HDD bays for up to 24 TB storage. Australian stock, 3-year Australian warranty, fast Australia-wide dispatch, multi-camera project pricing. Designing a hybrid or analogue upgrade system? Request a free quote or contact our Australian team for tailored recorder + camera + HDD sizing.
AXIS P37 SERIES · NDAA & TAA COMPLIANT
Four adjustable camera heads delivering continuous 360-degree high-definition coverage
The AXIS P3737-PLE is an elite, outdoor-ready multidirectional camera that packs four independent 5 MP sensor channels into a single physical housing, delivering an impressive 20 MP total resolution. Powered by the next-generation ARTPEC-8 system-on-chip, each of the four varifocal camera heads can be positioned, tilted, and zoomed individually. This allows you to capture customized, wide-angle views or tight zoom details in four different directions simultaneously. Perfect for city intersections, large parking facilities, outdoor building corners, and hallways, it replaces up to four standard cameras with a single IP address and cable install.
Resolution
20 MP (4x 5MP)
Optics
4x Varifocal
Night Vision
360° OptimizedIR
Climate Ready
IP66/67 & IK10
Edge-based intelligence and hardware-level cybersecurity for enterprise networks
The AXIS P3737-PLE features an advanced deep learning processing unit (DLPU) dedicated to each of its four channels. This enables highly specific object classification, allowing you to track and log humans and vehicles in four directions simultaneously with ultra-low false alarm rates. To keep your commercial installations secured, the onboard AXIS Edge Vault security system guarantees signed firmware, a secure boot process, and cryptographic key isolation, protecting the device's unique identifier from unauthorized modifications.
Independently controlled 360° OptimizedIR
The integrated infrared system features four separate LED arrays that adjust automatically to the zoom level of each sensor. This delivers optimal night vision illumination up to 15 meters on each channel without overlapping glare.
Lightfinder 2.0 and Forensic WDR
Equipped with Lightfinder 2.0 and Forensic WDR, the camera provides incredible color details in near-dark conditions and balances out harsh backlight, making sure every sensor channel remains forensically accurate.
Technical Specification Matrix
Camera Model
AXIS P3737-PLE
Image Sensor
4x 1/2.7” progressive scan RGB CMOS
Optical Lenses
4x Varifocal 3.0–6.0 mm, F1.8–2.6 with remote zoom and autofocus
Maximum Resolution
4x 5 MP (2592 x 1944 pixels) up to 25/30 fps per channel
Lightfinder & WDR
Lightfinder 2.0, Forensic WDR, and 4x independent OptimizedIR arrays
Edge Intelligence
Dedicated Deep Learning Processing Unit (DLPU) for advanced analytics
Environmental Rating
IP66, IP67, NEMA 4X weather-proof, IK10 physical impact rating
Power over Ethernet
PoE+ IEEE 802.3at Type 2 Class 4 (typical 11.2W, max 21.0W with IR active)
Technical Datasheet Repainting Instructions
Operation Manual Installation Manual
Frequently Asked Questions
How do I adjust the viewing angles on the AXIS P3737-PLE?
The camera features a flexible 360-degree internal ring design. Each of the four varifocal lens modules can be moved, tilted, and rotated manually along the track during physical installation, after which focus and zoom can be adjusted remotely via software.
Does this multidirectional camera require four separate network cables?
No. The AXIS P3737-PLE routes all four independent video streams through a single network cable and IP address. This significantly simplifies network configuration and lowers installation, cabling, and switch port costs.
What are the operational temperature limits for this camera?
The rugged weatherproofing features allow the camera to work reliably in temperatures ranging from -30 °C to 50 °C (-22 °F to 122 °F). It is fully protected against heavy rain, dust, and coastal winds.
Is this model compliant with NDAA and TAA regulations?
Yes. The AXIS P3737-PLE is fully compliant with the National Defense Authorization Act (NDAA) and the Trade Agreements Act (TAA), allowing it to be securely deployed on government, military, and infrastructure systems.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS P-SERIES · NDAA & TAA COMPLIANT
Complete 360° Multi-Directional Surveillance with Single-Camera Efficiency
The AXIS P3735-PLE sets a new benchmark for high-density, multi-angle surveillance by packing four independent 2-megapixel channels into a single, sleek network deployment. Engineered for critical commercial applications, transit hubs, logistics centers, and expansive intersections, this high-performance powerhouse lets you monitor four different areas concurrently over a single network cable and IP address. By bridging the gap between comprehensive situational awareness and cost-efficient installation metrics, it drastically lowers your operational overhead while leaving no blind spots exposed.
Resolution
4x 2MP Full HD
Optics
Varifocal Zoom
Night Vision
360° 360° IR Illumination
Protection
IP66 / IK10 Rated
Advanced Analytics and Enterprise-Grade Intelligence at the Edge
Beyond its physical versatility, the AXIS P3735-PLE leverages a state-of-the-art deep learning processing unit (DLPU) to bring enterprise intelligence directly to the edge. Equipped with Axis Object Analytics, the camera can accurately detect, classify, and track humans and vehicles across all four independent streams simultaneously. This intelligent system eliminates costly false alarms triggered by environmental clutter or shifting shadows. Cybersecurity is integrated from the ground up via Axis Edge Vault, a hardware-based platform that safeguards the device’s identity, blocks unauthorized access, and guarantees system integrity.
Adaptive 360° Infrared Illumination
Equipped with individually controllable zoomable LEDs, the built-in 360-degree IR illumination delivers crisp, reflection-free black-and-white footage in absolute darkness. It automatically adapts to the field of view of each sensor head for premium low-light image capture up to 15 meters or more.
Uncompromising Imagery via Lightfinder & WDR
Featuring proprietary Axis Lightfinder technology, this camera maintains vibrant color detail even when lighting conditions near zero. Combined with Forensic WDR, it easily handles high-contrast, backlit environments to preserve critical forensic clarity across both bright and dark zones.
Technical Specification Matrix
Camera Model
AXIS P3735-PLE
Image Sensor Resolution
4x 2 Megapixel (1920x1080) at up to 30 fps per channel
Lens / Optics
Four independent varifocal lenses, 3–6 mm, F1.8–F2.6 with remote zoom/focus
Minimum Illumination
Color: 0.13 lux (F1.8); B/W: 0 lux with IR illumination active
Video Compression
H.264 (MPEG-4 Part 10/AVC), H.265 (MPEG-H Part 2/HEVC), Motion JPEG, Zipstream
Audio & Input Interfaces
Audio input (line/mic) via optional accessories, digital microphone support
Security Hardware
Axis Edge Vault, Secure Boot, Signed Firmware, Cybersecurity Trust Platform
Environmental Ratings
IP66/IP67 weatherproofing, NEMA 4X, and IK10 impact resistance
Power over Ethernet
Power over Ethernet (PoE) IEEE 802.3at Type 2 Class 4 (Typical 12.3 W, Max 23.0 W)
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Can the four independent sensor heads inside the AXIS P3735-PLE be adjusted individually?
Yes, each of the four varifocal camera heads can be moved, tilted, and rotated along a circular track during installation. This allows you to position them to monitor distinct, customized directions or group them tightly for a seamless 360-degree panoramic view.
Does this camera require four licenses on my Video Management Software (VMS)?
No, because the AXIS P3735-PLE streams all four independent video feeds over a single network connection and a single IP address, most leading Video Management Systems (like AXIS Camera Station or Milestone XProtect) require only one VMS license, drastically minimizing software costs.
What benefits does the built-in deep learning processing unit (DLPU) provide?
The on-board DLPU enables highly granular, localized edge analytics. Axis Object Analytics runs on all four channels simultaneously to distinguish between humans and different classes of vehicles, dramatically improving filtering accuracy while lowering server-side processing demands.
Is the AXIS P3735-PLE suitable for deployment in high-security federal or government spaces?
Absolutely. The AXIS P3735-PLE is fully NDAA and TAA compliant. Armed with secure boot, signed firmware, and the hardware-guaranteed Axis Edge Vault cryptographic computing module, it perfectly satisfies stringent government and institutional network infrastructure mandates.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS M43 SERIES · NDAA & TAA COMPLIANT
Stunning 12 MP ultra-high-definition panoramic clarity for maximum protection
The AXIS M4308-PLE is a premier, outdoor-ready panoramic camera that captures a complete, uncompromised 360-degree overview from a single physical point. Leveraging an incredible 12 MP sensor and advanced edge-based intelligence, this discreet dome provides exceptional detail across expansive outdoor or indoor locations. It is designed to withstand harsh weather and physical interference, while its integrated 360-degree infrared illuminators deliver absolute situational awareness in complete darkness, keeping perimeters, entryways, and loading zones under continuous high-security watch.
Resolution
12 MP Sensor
Optics
360° Fisheye
Night Vision
OptimizedIR 360°
Climate Ready
IP66 & IK10 Rated
Intelligent edge analytics backed by robust cyber defense
The AXIS M4308-PLE integrates advanced camera-side dewarping to process raw fisheye streams into comfortable, distortion-free viewing perspectives like panorama, quad-split, or double panorama. Armed with a built-in deep learning processing unit (DLPU), it identifies and classifies humans and vehicles with unmatched accuracy. The internal hardware structure is fortified with Axis Edge Vault, preserving unique device IDs, authorizing signed firmware, and ensuring a secure boot environment to shield your secure network from potential intrusion.
True 360-degree OptimizedIR
The integrated, energy-conscious infrared LED arrays dynamically adjust to the environment, casting uniform illumination across a 360-degree radius in complete darkness up to 15 meters without burning out close-range subjects.
Forensic light optimization
Equipped with Lightfinder and Forensic WDR, the system ensures high-quality imaging by minimizing motion blur, capturing true colors in dim environments, and balancing highly bright and shaded spots in the same field of view.
Technical Specification Matrix
Camera Model
AXIS M4308-PLE
Image Sensor
1/1.7” progressive scan RGB CMOS
Optical Lens
1.2 mm fixed-focal lens, F2.2, Fixed iris with digital roll correction
Resolution Max
12 MP (2992 x 2992 pixels) up to 25/30 fps
Audio Capabilities
Built-in dual microphones; audio detection and recording support
Video Compression
H.264 (AVC), H.265 (HEVC), Motion JPEG with Zipstream technology
Environmental Rating
IP66, NEMA 4X weather-proof, IK10 vandal-resistant casing
Power over Ethernet
PoE IEEE 802.3af Class 3 (typical 7.5W, max 12.9W with IR active)
Technical Datasheet Quick Start Guide
Operation Manual Installation Manual
Frequently Asked Questions
How does dewarping help me view the surveillance footage?
Standard fisheye lenses capture circular, distorted images. The AXIS M4308-PLE features edge-based dewarping, which digitally reformats the circular view into flat panorama, double panorama, or quad-split layouts. This happens on the camera, so it doesn't drain your viewing PC's processing power.
Does the AXIS M4308-PLE capture audio?
Yes. The camera is built with integrated dual microphones that support high-quality stereo audio capture. It can also trigger automatic recording and system alarms upon detecting suspicious, sharp noises.
Can this camera operate in freezing or high-temperature environments?
Absolutely. The outdoor-ready construction features active temperature control, allowing the camera to operate reliably in a broad temperature range of -40 °C to 50 °C (-40 °F to 122 °F).
Is this model fully NDAA and TAA compliant?
Yes. The AXIS M4308-PLE is fully NDAA (National Defense Authorization Act) and TAA (Trade Agreements Act) certified, making it suitable for federal government, defense, and high-security enterprise installations.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS P38 SERIES · NDAA & TAA COMPLIANT
Seamless 180° Multi-Sensor Surveillance for Wide-Area Coverage
The AXIS P3818-PVE delivers a stunning 13 MP panoramic overview with perfect image stitching across its multi-sensor array. Designed for high-density, mission-critical environments such as transport hubs, airports, logistics complexes, and city surveillance, this robust network camera replaces multiple single-sensor units to provide complete situational awareness without blind spots. Featuring smart horizon correction and advanced cybersecurity infrastructure, it ensures high-performance tracking and continuous asset protection across vast commercial landscapes.
Resolution
13MP (3x 4K Ultra HD)
Optics
180° Panoramic Fixed
Night Vision
Lightfinder & Forensic WDR
Protection
IP66 / IK10 Vandal-Ready
Advanced Edge Processing and Hardware-Based Security
Engineered for complex enterprise networks, the AXIS P3818-PVE incorporates built-in horizon alignment for an optimized visual baseline, ensuring seamless continuity across all sensor fields. It supports sophisticated edge analytics alongside Axis Zipstream technology to sharply minimize bandwidth and storage overhead without compromising critical forensic detail. Security is fundamentally reinforced by AXIS Edge Vault, a hardware-based cyber platform protecting the unique Axis device ID and streamlining secure credential management across your IT infrastructure.
Flawless 180-Degree Image Stitching
Utilizes three high-definition sensors working in perfect alignment to output a single, cohesive, ultra-high-resolution panoramic video stream, eliminating the overlapping distortions and alignment gaps found in traditional multi-camera arrays.
Hardware Cyber Protection (Edge Vault)
Integrates a dedicated cryptographic compute element to anchor device authentication, secure boot cycles, and signed firmware validation, effectively mitigating unauthorized network access vectors at the hardware level.
Technical Specification Matrix
Camera Model
AXIS P3818-PVE
Image Sensor Resolution
13 Megapixel Total Array (3x 4K Sensors)
Field of View
180° Horizontal, 38° Vertical
Minimum Illumination
Color: 0.16 lux, F2.0; B/W: 0.05 lux, F2.0
Wide Dynamic Range
Forensic WDR (Wide Dynamic Range)
Video Compression
H.264 (MPEG-4 Part 10/AVC), H.265 (MPEG-H Part 2/HEVC), Axis Zipstream
Casing / Environmental
IP66-rated weather protection, NEMA 4X, IK10 vandal resistance
Power Delivery
Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Is the AXIS P3818-PVE compliant with federal security mandates?
Yes. This network camera is strictly NDAA and TAA compliant, conforming with all defense procurement guidelines and enterprise system architecture regulations.
How does multi-sensor stitching affect the network video stream?
The device aggregates all three sensors internally to transmit one uniform 180-degree panoramic stream. This provides complete spatial clarity while reducing standard VMS multi-channel licensing demands.
Can this camera withstand extreme outdoor installations?
Absolutely. Backed by IP66, NEMA 4X, and IK10 impact ratings, the camera housing safeguards inner electronics against heavy precipitation, direct corrosion vectors, and industrial physical vandalism.
What cyber security protocols are enabled on this hardware?
It supports the comprehensive AXIS Edge Vault security system, offering secure boot functionality, signed firmware validation, and an internal cryptographic platform for hardware ID verification.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS M43 SERIES · NDAA & TAA COMPLIANT
Vandal-resistant 360-degree outdoor monitoring with built-in infrared power
The AXIS M4317-PLVE is a highly robust, outdoor-ready panoramic camera designed to deliver comprehensive situational overviews in the most challenging conditions. Engineered with a powerful 6 MP sensor and a dedicated deep learning processing unit (DLPU), this sleek dome captures complete 360-degree fisheye coverage without any blind spots. Its heavy-duty, weather-shielded design combines seamlessly with built-in, adaptive infrared illumination, ensuring your facility remains fully monitored in total darkness, heavy storms, and vulnerable public areas.
Resolution
6 MP Sensor
Optics
360° Fisheye
Night Vision
OptimizedIR 360°
Climate Ready
IP66 & IK10
Uncompromising edge processing combined with robust exterior shielding
Built to handle harsh environments, the AXIS M4317-PLVE utilizes its advanced ARTPEC-8 processor to run complex edge analytics locally. It delivers precise, real-time object classification that allows operators to easily filter out non-essential triggers. With the support of client-side and camera-side dewarping, you can stream a clean, flattened view of your entryways, schoolyards, or warehouses. All systems are fully secured with AXIS Edge Vault, keeping your device safe from unauthorized tampering and firmware modifications.
Adaptive 360° OptimizedIR arrays
The integrated, energy-efficient infrared LEDs automatically adjust their power output to match the surrounding scene, illuminating a full 360-degree area in zero-lux environments while avoiding close-range reflection glare.
Extreme weatherproof and vandal resistance
Housed in an IP66, NEMA 4X, and IK10 vandal-resistant dome, this camera is built to withstand extreme mechanical impact, high-pressure water jets, dust ingress, and sub-zero temperature changes without losing connection.
Technical Specification Matrix
Camera Model
AXIS M4317-PLVE
Image Sensor
1/1.8” progressive scan RGB CMOS
Optics and Lens
1.2 mm fixed fisheye, F2.2, Fixed iris with digital roll correction
Maximum Resolution
6 MP (2016 x 2016 pixels) up to 25/30 fps
Lightfinder & Dynamic Range
Lightfinder, Forensic WDR, and built-in OptimizedIR up to 15m (50ft)
Edge Intelligence
Integrated DLPU supporting AXIS Object Analytics
Environmental Ratings
IP66, NEMA 250 Type 4X, IK10 physical impact rating
Power over Ethernet
PoE IEEE 802.3af Class 3 (typical 6.4W, max 12.9W with IR active)
Technical Datasheet Quick Start Guide
Operation Manual Installation Manual
Frequently Asked Questions
Can the AXIS M4317-PLVE handle heavy rain or dust storm environments?
Yes, the camera is fully certified with IP66 and NEMA 4X weather-protection ratings, meaning it is completely dust-tight and resistant to extreme high-pressure water jets from any direction.
What is the typical range of the built-in infrared (IR) system?
The integrated 360-degree OptimizedIR system provides coverage up to 15 meters (50 feet) in complete darkness, depending on the mounting elevation and structural reflections in the surrounding scene.
How does digital roll correction help during installation?
Instead of manually aligning the physical camera on a ladder, digital roll correction lets you adjust the orientation of your video stream electronically using the web software interface, saving considerable setup time.
Does this camera support local recording if my network disconnects?
Yes, it features an onboard microSD/microSDHC/microSDXC card slot with support for encrypted edge recording, ensuring your data is securely captured even during network connection failures.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
NDAA Compliant • 4 x 5 MP 360° Panoramic
AXIS Q6020-E Multidirectional Panoramic Camera — Australian Stock & 5-Year Warranty
The AXIS Q6020-E is an outdoor multidirectional panoramic camera built around four 5 MP 1/2” sensors that together deliver a full 360° horizontal field of view. It is not a PTZ camera — it has no motorised pan/tilt and no optical zoom. Instead, Axis designed it to hold the complete situational overview while a paired AXIS Q60-Series PTZ camera supplies the zoomed-in detail, letting an operator jump from overview to close-up in a single click. Two ARTPEC-8 chips with a deep learning processing unit run AXIS Object Analytics and AXIS Scene Metadata across all four channels at the edge, and a USB port accepts a Wi-Fi dongle so installers can check the live view while aiming the camera. Part number 02956-001 is the 50 Hz variant supplied for Australia.
Sensors
4 x 5 MP
Coverage
360° Horizontal
Low Light
Lightfinder 2.0
Rating
IP66 / IK10
Total Situational Awareness, Then One-Click Detail
Four 1/2” progressive-scan sensors with 2.9 µm pixels and F2.0 optics give the Q6020-E a genuinely wide, bright image — each channel covers 108.4° horizontally and 84° vertically at up to 2592x1944 and 30 fps. Lightfinder 2.0 holds colour down to 0.06 lux and Forensic WDR delivers up to 120 dB of dynamic range, which often removes the need for supplementary IR lighting on lit sites. Autofocus and auto-alignment set the sensors and the paired PTZ automatically, so there is no manual fine-tuning on the pole.
Four 5 MP Sensors, One 360° View
2592x1944 per channel at up to 30 fps, stitched into a single 360° overview. Zipstream with H.264 and H.265 keeps bandwidth and storage under control across up to 20 configurable streams.
Edge AI on All Four Channels
Dual ARTPEC-8 SoCs with a deep learning processing unit run AXIS Object Analytics (humans, cars, buses, trucks, bikes) and AXIS Scene Metadata (faces, licence plates, clothing and vehicle colour) on 4 channels simultaneously.
Designed to Pair With AXIS Q60 PTZ
Autopilot lets the Q6020-E watch the whole scene and cue a paired AXIS Q6086-E, Q6088-E or Q6074/75-E PTZ onto a moving person or vehicle — overview and detail from one mounting point.
Built for Harsh Australian Sites
IP66, NEMA 4X and IK10 rated with a polycarbonate dome and aluminium casing, rated from -50 °C to 55 °C and 10–100% condensing humidity, with Axis Edge Vault hardware cybersecurity built in.
Technical Specifications
IMAGING & LENS
Image Sensor
4x 1/2” progressive scan RGB CMOS, 2.9 µm pixel size
Lens
3.7 mm, F2.0, autofocus, M14 mount, fixed iris
Field of View
Horizontal 360° total (108.4° per sensor); vertical 84°
Minimum Focus Distance
1.0 m (3.3 ft)
Day / Night
Automatic IR-cut filter
Minimum Illumination
Colour 0.06 lux, B/W 0.03 lux (50 IRE, F2.0)
Shutter Speed
1/66500 s to 2 s
Camera Adjustment
Pan ±180°, tilt -40° to +75°, rotation ±95° (installation adjustment, not motorised PTZ)
Image Processing
Axis Zipstream, Forensic WDR (up to 120 dB), Lightfinder 2.0
Built-in IR
Not fitted
VIDEO & STREAMING
Resolution
4 x 2592x1944 to 320x240 (default 2592x1944)
Frame Rate
Up to 30 fps (50/60 Hz) in all resolutions
Compression
H.264 Baseline/Main/High, H.265 Main Profile, Motion JPEG
Video Streaming
Up to 20 unique configurable streams; VBR/ABR/MBR; low latency mode
Signal-to-Noise Ratio
>55 dB
Privacy Masking
32 individual polygon privacy masks, including mosaic masks
System on Chip
ARTPEC-8 (x2), 8 GB RAM, 8 GB Flash, deep learning processing unit
ANALYTICS & INTELLIGENCE
Included Applications
AXIS Object Analytics, AXIS Scene Metadata, AXIS Video Motion Detection, active tampering alarm
Multisensor Analytics
4 channels of analytics support
Object Classes
Humans, vehicles (cars, buses, trucks, bikes, other)
Scenarios
Line crossing, object in area, time in area, crossline counting, occupancy in area, tailgating detection, motion in area, Autopilot — up to 10 scenarios
Scene Metadata
Humans, faces, vehicles, licence plates; vehicle colour, clothing colour, position
Third-Party Apps
AXIS Camera Application Platform (ACAP) supported
NETWORK, INTEGRATION & SECURITY
ONVIF
Profile G, Profile M, Profile S, Profile T
API
VAPIX and ACAP open API
VMS Compatibility
AXIS Camera Station Edge, AXIS Camera Station Pro and Axis partner VMS
Network Security
IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), 802.1AE MACsec, 802.1AR, HTTPS/HSTS, TLS v1.2/v1.3, host-based firewall
Edge Security
Axis Edge Vault, signed OS, secure boot, signed video, Axis device ID, encrypted filesystem
Secure Keystore
Secure element (CC EAL 6+, FIPS 140-3 Level 3)
POWER, STORAGE & CONNECTORS
Power (camera alone, Solo Kit)
PoE IEEE 802.3bt dual signature Class 4 (60 W)
Power Consumption
Typical 14.3 W (heater off), max 51 W
Power-Optimised Profile
PoE IEEE 802.3bt single signature Class 4 (30 W); max 25.5 W
Combined With Q6086-E / Q6088-E PTZ
PoE IEEE 802.3bt dual signature Class 5 (90 W)
Network Connector
Shielded RJ45 10BASE-T/100BASE-TX/1000BASE-T PoE
USB
For AXIS TU9005 Wireless Dongle
Local Storage
microSD / microSDHC / microSDXC with AES-XTS-Plain64 256-bit card encryption
Network Storage
Recording to network-attached storage (NAS)
ENVIRONMENTAL & PHYSICAL
Casing
IP66, NEMA 4X and IK10 rated; polycarbonate dome, aluminium and polymer casing; white NCS S 1002-B
Operating Conditions
-50 °C to 55 °C (60 W dual signature PoE); start-up temperature -40 °C
Humidity
10–100% RH (condensing)
Storage Conditions
-40 °C to 65 °C, 5–95% RH non-condensing
Weight
4.7 kg (10.4 lb)
Effective Projected Area
0.058 m²
Box Content
Camera, adapter bracket, installation guide, owner authentication key
Compliance
TAA compliant; RCM AS/NZS CISPR 32 Class A
Warranty
5-year Axis warranty
Part Number (Australia)
02956-001 (50 Hz)
DORI DISTANCES — 3.7 MM LENS
Detect (25 px/m)
46.1 m
Observe (63 px/m)
19.4 m
Recognise (125 px/m)
10.0 m
Identify (250 px/m)
5.1 m
Downloads
Official Axis Datasheet (PDF)
Manuals, Firmware & Software
Axis Product Page
Frequently Asked Questions
Is the AXIS Q6020-E a PTZ camera?No. It is a fixed multidirectional panoramic camera with four 5 MP sensors covering 360° horizontally. It has no motorised pan/tilt and no optical zoom. The pan, tilt and rotation figures in the specification are installation adjustments made once at mounting. Axis designed it to run alongside an AXIS Q60-Series PTZ camera, which provides the zoom while the Q6020-E holds the full overview.
What resolution does it record?Each of the four sensors delivers up to 2592x1944 (5 MP) at up to 30 fps, for 4 x 5 MP in total. The default resolution is 2592x1944 per channel and streams can be scaled down to 320x240. It is not a single 4K sensor camera.
Does it have built-in infrared illumination?No, the Q6020-E has no built-in IR LEDs and no OptimizedIR. Four 1/2” sensors with F2.0 optics and Lightfinder 2.0 hold colour down to 0.06 lux, which often removes the need for IR on lit sites. For genuinely dark areas, add external illuminators such as the AXIS T90D series.
What power supply does it need?On its own it requires PoE IEEE 802.3bt dual signature Class 4 (60 W), drawing typically 14.3 W with the heater off and up to 51 W. A power-optimised low power profile will run on 802.3bt single signature Class 4 (30 W). Paired with an AXIS Q6086-E or Q6088-E PTZ, the combination needs 802.3bt dual signature Class 5 (90 W).
What analytics are included?AXIS Object Analytics, AXIS Scene Metadata, AXIS Video Motion Detection and an active tampering alarm are preinstalled and run on all four channels via the dual ARTPEC-8 chips and their deep learning processing unit. Object Analytics classifies humans and vehicle types and supports up to 10 simultaneous scenarios including line crossing, object in area, occupancy and tailgating detection.
How does Autopilot work with a PTZ camera?Autopilot monitors a defined area of interest and can trigger an alarm or start recording when a person, vehicle or other object moves within it. Combined with a paired AXIS Q60 PTZ camera, this lets the panoramic view cue the PTZ onto activity automatically, and autofocus with auto-alignment means the sensors and PTZ set themselves up without manual fine-tuning.
How tough is it and what temperatures will it handle?The housing is IP66, NEMA 4X and IK10 rated with a polycarbonate dome and aluminium casing. Operating range is -50 °C to 55 °C on 60 W dual signature PoE, with a start-up temperature of -40 °C and 10–100% condensing humidity tolerance. It is comfortably rated for any Australian climate.
Can it record locally without an NVR?Yes. There is a card slot supporting microSD, microSDHC and microSDXC with AES-XTS-Plain64 256-bit card encryption, and the camera can also record to network-attached storage. For continuous multi-channel recording a proper VMS or NVR is still recommended.
Can I change the field of view for longer-range detail?Yes. The supplied 3.7 mm F2.0 M14 lenses give 108.4° per sensor and 360° in total. Optional M14 lenses narrow each channel for longer range: 7.6 mm gives 58.5°, 14.1 mm gives 31°, 21.4 mm gives 19.9° and 30.8 mm gives 13.8°, extending detect distance from 46 m up to roughly 429 m.
5-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
AXIS Q-SERIES · NDAA & TAA COMPLIANT
Ligature-Resistant Security Redefined for High-Risk Environments
The AXIS Q9227-SLV is a top-tier, anti-ligature corner-mount network camera purpose-built for environments where safety and absolute resilience are paramount. Housed in an impact-resistant stainless steel casing, this 4MP powerhouse eliminates anchor points while delivering full, blind-spot-free room coverage. Ideal for correctional facilities, healthcare wards, and high-density detention centers, it bridges the gap between uncompromising physical protection and advanced network surveillance.
Resolution
4MP @ 30fps
Optics
110° FOV
Night Vision
940nm Invisible IR
Protection
IK10+ / IP66 / IP69K
Edge Intelligence and Dynamic Protection
Equipped with a deep learning processing unit (DLPU), the AXIS Q9227-SLV brings enterprise-grade analytics right to the edge. It delivers high-accuracy object classification to minimize false alarms and optimize bandwidth via Axis Zipstream. The camera boasts a custom-engineered wide angle lens that provides sweeping coverage across a full 3-axis adjustment plane, while Axis Lightfinder and Forensic WDR ensure that details remain razor-sharp under extremely challenging light, shadowed corners, or sudden flashes.
Anti-Ligature, Anti-Grip Engineering
The flush corner mount design has zero anchor points, preventing self-harm risks and eliminating the ability to hang or grasp onto the device. Its IP66/IP69K-rated housing can withstand intensive high-pressure, high-temperature washdowns for simple, sanitary maintenance.
Invisible Night Vision (940 nm)
Unlike standard infrared cameras that emit a visible, sleep-disrupting red glow, this unit uses completely invisible 940 nm IR LEDs. It ensures covert, 24/7 security monitoring without causing discomfort or drawing attention to the camera.
Technical Specification Matrix
Camera Model
AXIS Q9227-SLV
Image Sensor
1/2.7" Progressive Scan RGB CMOS
Video Resolution
2688 x 1520 (4MP) at 30 frames per second
Field of View
Horizontal: 110°, Vertical: 81°
Minimum Illumination
Color: 0.13 lux, B/W: 0.03 lux (0 lux with invisible IR on)
Casing Material
Stainless steel, impact-resistant polycarbonate dome, anti-ligature design
Durability Ratings
IK10+ (50J) impact resistance, IP66 / IP69K ingress ratings
Onboard Intelligence
Deep Learning Processing Unit (DLPU), AXIS Object Analytics
Power Source
Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
What makes the AXIS Q9227-SLV anti-ligature?
The design features zero anchor points and sloped, flush-fitting edges that fit perfectly into room corners. This prevents anyone from securing ropes, fabrics, or other objects to the camera casing, eliminating self-harm or vandalism opportunities.
Does the IR illuminator emit a glowing red light at night?
No. The camera utilizes 940 nm infrared LEDs. Unlike standard 850 nm IR which glows red to the human eye, 940 nm IR is completely invisible, ensuring covert operation and zero sleep disturbance in patient rooms.
Can this camera withstand high-pressure water cleanup?
Yes. With IP66 and IP69K ratings, the housing is fully sealed against dust ingress and high-pressure, high-temperature water jets. This makes it ideal for medical or correctional facilities requiring regular, heavy chemical washdowns.
Is the camera NDAA and TAA compliant?
Yes, the AXIS Q9227-SLV is fully compliant with both the National Defense Authorization Act (NDAA) and the Trade Agreements Act (TAA), making it suitable for US federal government facilities and critical public infrastructure projects.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS M43 SERIES · NDAA & TAA COMPLIANT
Complete 360-degree situational awareness with a single high-resolution sensor
The AXIS M4327-P delivers flawless, high-resolution panoramic surveillance designed to cover expansive indoor spaces with absolute efficiency. Powered by the high-performance ARTPEC-8 processor, this ultra-discreet dome captures detailed 6 MP fisheye images, eliminating all structural blind spots in a single overview stream. Perfect for retail outlets, open-plan offices, educational lobbies, and logistical hubs, it provides comprehensive coverage that significantly reduces the overall physical camera count needed to secure your facility.
Resolution
6 MP Sensor
Optics
360° Fisheye
Processing
ARTPEC-8 & DLPU
Profile
Discreet & Paintable
Advanced digital dewarping and deep-learning analytics at the edge
The true power of the AXIS M4327-P lies in its flexible digital dewarping capabilities, transforming raw hemispherical footage into highly functional panorama, double panorama, quad, and corner viewing perspectives. Powered by a dedicated deep learning processing unit (DLPU), this intelligent sensor runs advanced analytics on the edge, enabling precise human and vehicle classification. The architecture is protected by the AXIS Edge Vault cybersecurity framework, guaranteeing cryptographic key isolation and secure system startup.
Customizable digital roll correction
Simplify your mounting process with built-in digital roll adjustment. This feature allows you to electronically fine-tune the orientation of the raw camera image, ensuring the panoramic overview matches your room layout perfectly without manual alignment.
Lightfinder and Forensic WDR
Deliver clear forensic details even in complex light conditions. Forensic WDR preserves critical target details in areas with bright sunlight and dark shadows, while Lightfinder technology maintains sharp color streams in near-dark environments.
Technical Specification Matrix
Camera Model
AXIS M4327-P
Image Sensor
1/1.8” progressive scan RGB CMOS
Lens Optics
1.2 mm fixed-focal lens, F2.0, Fixed iris, 360°/180° field of view
Resolution Max
6 MP (2016 x 2016 pixels) up to 25/30 fps
Video Compression
H.264 (MPEG-4 Part 10/AVC), H.265 (MPEG-H Part 2/HEVC), Motion JPEG
Deep Learning Unit
Integrated DLPU supporting edge-based object classification
Storage Support
microSD/microSDHC/microSDXC card slot with edge encryption
Power Source
Power over Ethernet (PoE) IEEE 802.3af Class 3 (max 6.4W, typical 4.3W)
Technical Datasheet Quick Start Guide
Operation Manual Installation Manual
Frequently Asked Questions
What is client-side vs. camera-side dewarping?
The AXIS M4327-P supports advanced camera-side dewarping, meaning the camera processor itself reformats the rounded fisheye stream into flat panoramic or quad-split layouts. This allows you to view corrected layouts directly on any client system without special viewing software.
Can the camera casing be repainted?
Yes, the top outer casing of the AXIS M4327-P is specifically designed to be easily repainted. This allows you to match the camera housing color to your specific interior ceiling paint for ultra-low profile, aesthetic surveillance setups.
Is this model suitable for outdoor environments?
No, the AXIS M4327-P is optimized and certified specifically for indoor installations. For outdoor panoramic applications, we recommend exploring AXIS outdoor-ready multisensor or weather-rated panoramic dome models.
How does Axis Zipstream help when streaming a high-resolution 6 MP image?
Axis Zipstream analyzes the 360-degree scene in real-time to preserve important forensic details, such as human faces or vehicle profiles, while highly compressing static background areas (like walls and ceilings). This slashes storage and network bandwidth demands by up to 50%.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
NDAA Compliant • License Plate Verifier Kit
Axis P1465-LE-3 (02811-001) LPR Bullet Camera — Australian Stock & 5-Year Warranty
The AXIS P1465-LE-3 is a complete, ready-to-run licence plate recognition kit built around an HDTV 1080p outdoor bullet camera with AXIS License Plate Verifier preinstalled and licensed. Its 10.9–29 mm telephoto lens is purpose-tuned to deliver the pixel density needed to read plates from 7 to 20 metres in free-flow traffic up to 105 km/h — ideal for gated communities, car parks, campuses, ports and city access roads. Powered by the ARTPEC-8 SoC with a dedicated deep learning processing unit, it runs plate detection entirely on the edge, with no server or extra licence to buy.
Resolution
1080p up to 60 fps
Optics
10.9–29 mm P-Iris
Plate Read Range
7–20 m • 105 km/h
Protection
IP66/67 • IK10 • NEMA 4X
Reliable Plate Capture, Day and Night
Reading a moving numberplate is a very different job to general surveillance, and this camera is tuned for it. OptimizedIR with 850 nm LEDs reaches 45 metres or more, Lightfinder 2.0 preserves detail in near-darkness, and Forensic WDR (up to 120 dB) handles headlight glare against dark plates. A dedicated licence-plate scene profile sets shutter and exposure for retro-reflective plates automatically, while Axis Zipstream cuts bandwidth and storage by around 50% without losing the frames that matter.
Licence Included, No Server Needed
AXIS License Plate Verifier is preinstalled with its licence included. Configuration is done in the camera web interface — define the area of interest, build allow/block lists, and store up to 1,000 events on-camera or 100,000 on an AXIS Surveillance Card.
Barrier & Access Control Ready
Barrier mode can open to all vehicles, only allowlisted plates, or all except blocklisted plates, with up to 10,000 plates per list. It integrates directly with AXIS A1001/A1601 door controllers, A91 relay modules and 2N IP devices.
Built for Australian Conditions
IP66/IP67, NEMA 4X and IK10 rated in a polycarbonate-and-aluminium housing, rated −40 °C to 60 °C with shock detection built in. The supplied AXIS Weather Shield L handles sun, rain and coastal exposure.
Edge Vault Cybersecurity
Secure boot, signed firmware, signed video and a CC EAL 6+ secure element protect device identity and footage integrity. TAA compliant and NDAA 889 compliant as a Swedish-designed Axis product.
Technical Specifications
CAMERA & OPTICS
Model / Part Number
AXIS P1465-LE-3 License Plate Verifier Kit (02811-001)
Image Sensor
1/2.8” progressive scan RGB CMOS, 2.9 µm pixel size
Lens
Varifocal 10.9–29 mm, F1.7, P-Iris, IR corrected, remote focus & zoom
Field of View
Horizontal 29°–11°; Vertical 16°–6°
Minimum Focus Distance
2.5 m (8.2 ft)
Minimum Illumination
Colour 0.07 lux; B/W 0.01 lux (F1.7, 50 IRE); 0 lux with IR on
Day / Night
Automatic IR-cut filter, hybrid IR filter
IR Illumination
OptimizedIR, 850 nm LEDs, 45 m (150 ft) or more depending on scene
VIDEO & PROCESSING
Resolution
1920 x 1080 (2 MP) down to 160 x 90
Frame Rate
Up to 50/60 fps without WDR; up to 25/30 fps with Forensic WDR
Compression
H.264 Baseline/Main/High, H.265 Main, Motion JPEG, Axis Zipstream
WDR
Forensic WDR up to 120 dB depending on scene
Image Processing
Zipstream, Forensic WDR, Lightfinder 2.0, OptimizedIR, EIS
System on Chip
ARTPEC-8 with deep learning processing unit (DLPU)
Memory
1024 MB RAM, 8192 MB flash
Video Streams
Up to 20 configurable streams; up to 8 cropped view areas
LICENCE PLATE VERIFIER
Licence
AXIS License Plate Verifier licence included, preinstalled
Detection Range
7.0 to 20 m (20 to 65 ft)
Vehicle Speed
Up to 105 km/h (65 mph)
Detection Time
Less than 1 second
Minimum Plate Width
130 px single-row plates; 70 px two-row plates
Event Log
Up to 1,000 entries on camera; up to 100,000 on AXIS Surveillance Card
List Capacity
Up to 10,000 plates per allowlist / blocklist
Modes
Free-flow and access control (barrier) modes
NETWORK, POWER & ENVIRONMENT
Power
PoE IEEE 802.3af/802.3at Type 1 Class 3, typical 7.9 W, max 12.95 W; or 10–28 V DC
Connectors
Shielded RJ45 10/100/1000, 3.5 mm mic/line in, 1 alarm in + 1 out, DC input
Edge Storage
microSD / microSDHC / microSDXC with AES-XTS 256-bit encryption; NAS recording
ONVIF
Profile G, Profile M, Profile S, Profile T
Protection
IP66/IP67, NEMA 4X, IK10; shock detection
Operating Temperature
−40 °C to 60 °C (−40 °F to 140 °F)
Dimensions / Weight
Ø132 x 132 x 280 mm; 1.2 kg with weather shield
Warranty
5-year Axis warranty
Downloads
Technical Datasheet
Installation Guide
User Manual
Frequently Asked Questions
Do I need to buy a separate licence plate recognition licence?No. AXIS License Plate Verifier comes preinstalled on this kit with the licence included, and runs entirely on the camera. There is no server, subscription or per-camera add-on to purchase.
How far away can it read a numberplate?From 7 to 20 metres (20 to 65 feet) using the 29 mm telephoto end of the lens. Mounting inside that window is essential — too close or too far and the plate will not have enough pixel width to be read reliably.
What vehicle speed does it handle?Up to 105 km/h (65 mph), with detection in under one second. It is purpose-tuned for slow to moderate free-flow traffic such as access roads, car park entries, gated estates and campuses.
What is the difference between the P1465-LE and the P1465-LE-3?The -3 variant ships with the 10.9–29 mm telephoto lens and the License Plate Verifier application preinstalled. The standard P1465-LE uses a wider lens and is aimed at general surveillance rather than plate capture.
Can it open a boom gate or barrier automatically?Yes. In access control mode it checks each detected plate against an allowlist or blocklist of up to 10,000 entries and can trigger its onboard relay output, or integrate directly with AXIS A1001/A1601 door controllers, A91 relay modules and 2N IP devices.
Will it still read plates at night?Yes. OptimizedIR 850 nm illumination reaches 45 metres or more, and Lightfinder 2.0 plus Forensic WDR up to 120 dB manage headlight glare and retro-reflective plates so the plate stays legible rather than blowing out.
Is this camera NDAA compliant?Yes. Axis is a Swedish manufacturer and this model is both NDAA Section 889 compliant and TAA compliant, making it suitable for government, defence, critical infrastructure and enterprise procurement.
What VMS software does it work with?It integrates tightly with AXIS Camera Station and AXIS Companion, and supports ONVIF Profile G, M, S and T for third-party video management systems. Plate events stream into the VMS for forensic search and rule triggers.
5-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
AXIS Q63 SERIES · NDAA & TAA COMPLIANT
Ultra-high-definition precision tracking with lightning-fast laser focus
The AXIS Q6358-LE sets a new standard for high-tier long-range surveillance by combining breathtaking 4K UHD resolution with an aggressive 31x optical zoom. Engineered with an advanced 1/2" sensor and a dedicated laser focus system, this powerhouse tracking asset achieves pin-sharp alignment in milliseconds, even in complete darkness or fast-moving tactical scenarios. Designed specifically for critical infrastructure, airports, border control, and wide city spaces, it transforms sprawling perimeters into perfectly clear forensic data zones.
Resolution
4K UHD @ 30 FPS
Optics
31x Zoom & Laser
Night Vision
OptimizedIR Zoom
Climate Ready
IP66 & NEMA 4X
Uncompromising analytics processing at the secure network edge
Built on the next-generation ARTPEC-8 chip architecture, the AXIS Q6358-LE runs a highly specialized Deep Learning Processing Unit (DLPU). This allows the camera to deliver granular, real-time object classification to easily distinguish between vehicles and humans. The system features a built-in cryptographic hardware engine running AXIS Edge Vault. This ensures safe cryptographic keys, secure boot validation, and a verified physical identity signature to defend enterprise networks from unauthorized zero-day configuration attempts.
Adaptive OptimizedIR illumination
The highly responsive built-in infrared illumination automatically tracks the focal depth of the 31x zoom lens system, delivering optimal lighting parameters over incredible distances without washing out close-range subjects.
Laser focus distance mapping
By throwing out an eye-safe laser pulse to measure absolute physical distances, the focus tracking elements lock onto vehicles or humans instantly. This removes the common contrast focus lag found in dark or low-visibility outdoor environments.
Technical Specification Matrix
Camera Model
AXIS Q6358-LE
Image Sensor
1/2” progressive scan RGB CMOS
Optical Lens Array
6.9–214 mm, F1.35–4.6 with 31x optical zoom and laser autofocus
PTZ Coverage
360° endless pan; -20° to +90° tilt with auto-flip tracking mechanics
Resolution Target
4K Ultra HD (3840 x 2160 pixels) at up to 30 frames per second
Low-Light Metrics
Lightfinder 2.0; Forensic WDR; OptimizedIR coverage up to 200m+ (650ft)
Cybersecurity Suite
AXIS Edge Vault, Signed Firmware, Secure Boot, FIPS 140-2 level 3 storage
Enclosure Ratings
IP66, IP67, NEMA 4X, IK10 impact armor rating
Technical Datasheet Repainting Instructions
Operation Manual Installation Manual
Frequently Asked Questions
What are the operational safety benefits of the laser focus engine?
Traditional PTZ tracking systems rely on visual pixel contrast to calculate focus, which often fails in low contrast, thick mist, or dark environments. The AXIS Q6358-LE uses a dedicated laser rangefinder to map target distance instantly, providing perfect focus under any condition.
Does the camera support tilt profiles above the horizon line?
Yes. The camera frame layout provides an extended tilt profile ranging up to +90 degrees. This allows operators to look straight up into high elevations, bridges, and multi-tier industrial infrastructures without blind spots.
Can the AXIS Q6358-LE withstand freezing and scorching environments?
Absolutely. The hard shell enclosure features active temperature control and weather sealing, enabling the internal PTZ mechanics to run smoothly in temperatures between -50 °C to 50 °C (-58 °F to 122 °F).
What power supply options are required for operation?
The unit requires High Power over Ethernet (High PoE) or 60W PoE injectors complying with standard 802.3at/bt power distribution architectures to run the built-in sensor, motorized mechanisms, and heater components.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS P56 SERIES · NDAA & TAA COMPLIANT
Long-range precision tracking with advanced situational intelligence
The AXIS P5655-E represents an elite tier of cost-effective, high-performance pan-tilt-zoom (PTZ) technology designed for wide-area deployment. Powered by the proprietary ARTPEC-7 processing core, this rugged domain asset captures fluid HDTV 1080p footage at up to 60 frames per second. Its massive 32x optical lens array enables swift shifts between broad panoramic sweeps and hyper-targeted long-distance forensics. Perfect for parking zones, city surveillance loops, and manufacturing centers, it delivers critical situational verification precisely when it matters most.
Resolution
1080p @ 60 FPS
Optics
32x Optical Zoom
Low-Light
Lightfinder 2.0
Protection
IP66 & IK10 Armor
Uncompromising video stability under extreme structural vibrations
When pushed to the absolute limits of its 32x telephoto extension, the AXIS P5655-E relies on its smart Electronic Image Stabilization (EIS) matrix to eliminate frame shake caused by wind shear or heavy industrial equipment. Integrated Focus Recall memory preserves focal distance setups instantly, ensuring that panning between priority security sectors delivers sharp target acquisition without awkward calibration lag. The network engine is secured via hardware-level protections, deploying Signed Firmware and Secure Boot paths to safeguard device streams against external breaches.
Autotracking 2 and target profiling
Equipped with smart automated detection tools, the camera intelligently identifies, locks onto, and tracks targets moving across peripheral bounds, optimizing localized resources without demanding round-the-clock manual supervision.
Zipstream data optimization
Leveraging specialized H.264 and H.265 compression, Axis Zipstream reduces global network bandwidth and storage usage by up to 50 percent while preserving facial characteristics, plates, and high-priority forensic data zones.
Technical Specification Matrix
Camera Model
AXIS P5655-E
Image Sensor
1/2.8” progressive scan RGB CMOS
Lens Mechanics
Varifocal, 4.3–137.6 mm, F1.4–4.0 with autofocus and auto-iris
PTZ Capabilities
360° endless pan, 180° tilt, up to 350°/s movement speed
Minimum Illumination
Color: 0.1 lux at 30 IRE (F1.4), B/W: 0.01 lux at 30 IRE (F1.4)
Wide Dynamic Range
Forensic WDR up to 120 dB depending on environmental scene
Environmental Ratings
IP66, NEMA 250 Type 4X, IK10 vandal-resistant casing
Power Delivery
PoE+ IEEE 802.3at Type 2 Class 4 (typical 10.5W, max 19W) or 20–28V DC
Technical Datasheet Repainting Instructions
Operation Manual Installation Manual
Frequently Asked Questions
What unique value does Focus Recall provide?
Focus Recall allows operators to pre-save sharp focus metrics for custom zoom zones. When the PTZ shifts to that angle, the optics establish instant focal alignment, bypassing slow autofocus hunt cycles typical in hazy or dark conditions.
Does the system support local audio tracking integration?
Yes, the hardware features true two-way audio support and dedicated multi-connector I/O pins, permitting external microphone or line-level inputs to prompt automated PTZ presets upon noise detection triggers.
Can this camera endure freezing winter conditions?
Absolutely. The AXIS P5655-E is robustly rated for harsh settings, operating reliably in an outdoor temperature envelope spanning from -30 °C up to 50 °C (-22 °F to 122 °F).
Is the lower clear dome bubble impact-resistant?
Yes, the lower dome assembly features a high-grade polycarbonate build backed by a certified IK10 physical impact rating, defending vital internal motorized elements from intentional vandalism or physical damage.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS Q-SERIES · NDAA & TAA COMPLIANT
Enterprise-Grade Surveillance with Deep Learning Architecture
The AXIS Q1800-LE 3 represents the pinnacle of high-density commercial surveillance, offering exceptional 4K ultra-high-definition clarity coupled with advanced edge-based analytics. Driven by the groundbreaking ARTPEC-8 processing chip, this premium network camera delivers unparalleled object classification, rapid threat detection, and superior low-light tracking. Engineered explicitly for mission-critical commercial environments, infrastructure hubs, and high-security enterprise installations, it ensures absolute situational awareness under any environmental condition.
Resolution
4K UHD @ 60fps
Optics
Varifocal i-CS Lens
Night Vision
OptimizedIR Performance
Protection
IP66 / IK10 Rated
Advanced Edge Processing & Analytics Ecosystem
Equipped with specialized deep learning processing units, the AXIS Q1800-LE 3 executes sophisticated computational analysis directly at the network edge. This architecture enables native support for AXIS Object Analytics, allowing the system to distinguish between humans, vehicles, and unique vehicle types without relying on centralized server compute infrastructure. By implementing intelligent bandwidth reduction with Axis Zipstream technology and maximizing visibility with Forensic WDR, this camera provides reliable data streams optimized for rapid incident resolution and compliance-driven modern security frameworks.
Deep Learning Processing Unit
Unlocks precise, real-time metadata tagging directly on the edge. Minimize false positives and instantly classify humans, cars, trucks, and license plates for actionable operational intelligence.
Extreme Climate Performance
Encased in a robust, weather-resistant outer shell with IP66, IP67, and NEMA 4X certifications. Built to withstand extreme thermal fluctuations, structural vibrations, and physical impacts.
Technical Specification Matrix
Camera Model
AXIS Q1800-LE 3
Image Sensor
1/1.8" Progressive Scan RGB CMOS
Resolution
3840x2160 (4K UHD) at up to 60 fps
Lens Configuration
Varifocal, i-CS lens, 4.3–13.7 mm, F1.2
Minimum Illumination
Color: 0.06 lux, B/W: 0.01 lux (0 lux with IR LED on)
Infrared Technology
OptimizedIR power-efficient LEDs with long-range coverage
System Chipset
ARTPEC-8 with Deep Learning Processing Unit (DLPU)
Casing Ratings
IP66/IP67-rated, NEMA 4X, and IK10 vandal resistance
Compliance
NDAA & TAA Compliant, Secure Boot, Axis Edge Vault
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Is the AXIS Q1800-LE 3 suitable for US government facilities?
Yes. The AXIS Q1800-LE 3 is fully NDAA and TAA compliant, conforming strictly with United States federal procurement guidelines, making it perfect for critical public infrastructure applications.
What are the main benefits of the built-in ARTPEC-8 processor?
The ARTPEC-8 chip includes a dedicated Deep Learning Processing Unit (DLPU) that accelerates edge analytics, significantly improves object classification, and powers advanced internal security protocols like Axis Edge Vault.
Can this camera operate effectively in total darkness?
Absolutely. Integrated long-range OptimizedIR technology dynamically adjusts its coverage area to perfectly match the lens's field of view, delivering crisp black-and-white images in zero-light scenarios.
What is the purpose of an i-CS lens on this model?
An i-CS (intelligent Computer Space) lens communicates directly with the camera to automate zoom, focus, and iris positioning during remote installation, drastically speeding up setup times while guaranteeing optimal optical focus.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS Q16 SERIES · NDAA & TAA COMPLIANT
Elite surveillance performance with integrated edge intelligence
The AXIS Q1656-LE is a top-tier box camera that defines the benchmark for professional outdoor security. Built on the revolutionary ARTPEC-8 system-on-chip, this premium security asset delivers incredible 4 MP resolution at up to 60 frames per second. Its massive 1/1.8" optical sensor ensures unparalleled detail in high-density areas, commercial properties, and critical infrastructure sectors. Designed to operate flawlessly in any environment, its integrated physical wiper clears away rain, dust, and snow, guaranteeing clean forensic footprints around the clock.
Resolution
4 MP @ 60 FPS
Optics
1/1.8" Sensor
Night Vision
OptimizedIR 40m
Climate Ready
IP66 & Wiper
Sophisticated processing and military-grade cybersecurity at the edge
Beyond capturing crisp visual data, the AXIS Q1656-LE functions as a powerful computational edge node. Armed with Axis Lightfinder 2.0 and Forensic WDR, it reproduces lifelike color profiles in near-pitch darkness and preserves critical highlights in high-contrast environments. The custom-designed hardware features AXIS Edge Vault, a cybersecurity safeguard that secures your camera's unique identity, protects cryptographic keys, and prevents unauthorized software execution.
Deep Learning processing unit (DLPU)
By executing calculations directly on the camera hardware rather than on a remote server, the built-in deep learning engine reduces system bandwidth, lowers storage requirements, and provides lightning-fast object classification with minimal false alarms.
Integrated motorized lens wiper
Never let rain, mud, or frost compromise your operations. The remote-controlled motorized wiper ensures your field of view remains pristine during heavy storms, significantly lowering overall maintenance costs and physical inspection routines.
Technical Specification Matrix
Camera Model
AXIS Q1656-LE
Image Sensor
1/1.8” progressive scan RGB CMOS
Video Compression
H.264 (MPEG-4 Part 10/AVC), H.265 (MPEG-H Part 2/HEVC), Motion JPEG
Frame Rate & Resolution
Up to 2688 x 1512 (4 MP) at 60 frames per second
Minimum Illumination
Color: 0.05 lux (F1.2), B/W: 0.01 lux (F1.2) or 0 lux with OptimizedIR active
Security Protocols
AXIS Edge Vault, Signed Firmware, Secure Boot, IEEE 802.1X, HTTPS encryption
Environmental Ratings
IP66, NEMA 250 Type 4X, IK10 impact resistance, MIL-STD-810H rated
Power over Ethernet
Power over Ethernet (PoE) IEEE 802.3at Type 2 Class 4, max 25.5W
Technical Datasheet Repainting Instructions
Operation Manual Installation Manual
Frequently Asked Questions
Is the AXIS Q1656-LE NDAA and TAA compliant?
Yes, this camera is fully compliant with the National Defense Authorization Act (NDAA) and the Trade Agreements Act (TAA), making it approved for deployment on US federal government installations and highly secure corporate facilities.
How does the built-in wiper work?
The integrated wiper is designed to physically clear water, snow, and light dirt off the front glass. It can be activated manually via the web interface or automated through event triggers based on environmental conditions or schedules.
What is the maximum night vision distance of this camera?
Using its built-in OptimizedIR power-efficient LEDs, the AXIS Q1656-LE can illuminate objects clearly up to 40 meters (approximately 131 feet) away in total darkness, adapting to the lens zoom angle automatically.
Does this camera support local storage recording?
Yes, it has a high-performance microSD/microSDHC/microSDXC card slot that supports edge storage encryption, ensuring your data is backed up safely even if your main network connection drops.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
Dahua Ultra Series · IP & Wi-Fi Face-Recognition Villa Door Station
The Dahua VTO6631QB(S)-WP is a premium IP & Wi-Fi villa door station with an ultra-thin tempered-glass face and a 5-inch IPS touchscreen. Its dual 2MP wide-angle cameras and face recognition unlock the door in 0.2 seconds, alongside IC/ID card, Bluetooth card and password entry. Connect over PoE or Wi-Fi, control access and elevators, and manage everything through the Dahua app. IP65-rated for the front gate, in a sleek dark-silver finish. Genuine Dahua, Australian stock and local support.
Unlock
Face · Card · Bluetooth · Password
Display
5″ IPS Touch · 720×1280
Camera
Dual 2MP · 119° Wide · WDR
Connectivity
PoE · Wi-Fi · IP65
Why Choose the Dahua VTO6631QB(S)-WP
Fast, Accurate Face Recognition
Recognises faces from 0.3–2m at 99.9% accuracy in just 0.2 seconds, for genuinely hands-free entry.
Four Ways In
Unlock by face, IC/ID card, Bluetooth card or password — flexible access for family, staff and guests.
Wide, Clear Vision
Dual 2MP low-light cameras with a 119° horizontal view, 120dB WDR and auto IR keep visitors sharp day and night.
Premium, Weatherproof Build
An ultra-thin tempered-glass front in dark silver, IP65-rated with a tamper alarm for exposed gates and entries.
Huge Capacity
Stores 20,000 users and faces, 100,000 IC/ID cards, 20,000 Bluetooth cards and 200,000 records.
Access & Elevator Control
Drives a lock, exit button and door sensor, and can call elevators or grant floor access for apartments.
Technical Specifications
Camera & Display
Screen
5-inch IPS capacitive touchscreen
Resolution
720 (H) × 1280 (V)
Camera
Dual 1/2.8″ 2MP CMOS, low illumination
Field of View
H 119° · V 66° · D 142°
WDR / NR
120 dB WDR · 3D NR · auto IR
Video Coding
H.264 / H.265
Audio
Two-way, echo suppression & noise reduction
Access & Recognition
Unlock Methods
Face, IC/ID card, Bluetooth card, password
Face Recognition
0.3–2m · 99.9% accuracy · 0.2s
Card Types
IC (13.56 MHz) & ID (125 kHz)
Bluetooth
BLE, BT 5.2
Capacity
20,000 users · 20,000 faces · 100,000 cards · 200,000 records
Elevator Control
Supported
Storage
microSD up to 128GB
Ports, Power & General
Ports
RS-485, Wiegand, 2 alarm in / 1 out, exit button, door status, lock control
Network
1 × 10/100 Ethernet · ONVIF / CGI
Wi-Fi
IEEE 802.11 b/g/n, 2.4 GHz
Power Output
12V 1.5A (adapter) · 12V 0.5A (PoE)
Power Supply
Standard PoE or 12 VDC 3A
Casing
Tempered glass + PC/ABS, dark silver
Protection
IP65 (silicone sealant required) · tamper alarm
Installation
Surface mount
Dimensions
186.8 × 81.4 × 23.3 mm
Operating Temp.
-30°C to +60°C
Certification
CE
Datasheets & Guides
VTO6631QB(S)-WP Datasheet
Dahua VTO User Manual
Dahua Video Door Phone Quick Start Guide
Frequently Asked Questions
How can visitors unlock the door?By face recognition, IC/ID card, Bluetooth card or password — you choose which methods to enable.
How fast and accurate is face unlock?It recognises faces from 0.3–2m at 99.9% accuracy in about 0.2 seconds.
Does it work over Wi-Fi?Yes. It connects via standard PoE or 2.4GHz Wi-Fi.
Is it weatherproof?Yes. It's IP65-rated (with the supplied silicone sealant) and has a tamper alarm for outdoor gates.
How many users and cards does it hold?Up to 20,000 users and faces, 100,000 IC/ID cards, 20,000 Bluetooth cards and 200,000 records.
Can it control a lock and exit button?Yes. It has lock control, an exit button input, door status detection and Wiegand/RS-485 for access control.
Does it record?It supports microSD up to 128GB for snapshots and leave-video messages.
Is a door lock included?No. Electric strikes, magnetic locks and exit buttons are chosen separately to suit your door.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
AXIS SURVEILLANCE SERIES · NDAA & TAA COMPLIANT
High-Performance Edge Storage Optimized for Professional IP Surveillance
The AXIS Surveillance Card 128 GB is a high-end, edge-storage solution engineered explicitly for professional video surveillance systems. Optimized for decentralized network video architectures, this industrial-grade microSDXC card provides autonomous recording directly on the camera, ensuring maximum system resilience and continuous protection. Ideal for commercial applications, high-density multi-camera environments, and critical infrastructure installations, it acts as a robust failover system during unexpected network outages or as an efficient primary recording device in bandwidth-constrained setups.
Resolution
Supports 4K UHD
Optics
High Endurance
Night Vision/PTZ
24/7 Continuous
Protection/Climate
Industrial Grade
Advanced Analytics Compatibility & Health Monitoring Diagnostics
Designed to integrate seamlessly into modern security networks, this surveillance card supports sophisticated onboard intelligence. When paired with compatible Axis network cameras, users can access advanced health monitoring analytics that provide live telemetry data on the card’s wear level, expected lifespan, and overall structural integrity. This allows security managers to perform predictive maintenance before any degradation occurs. Learn more about deployment options via the AXIS Surveillance Card 128 GB Product Page to secure your edge storage architecture.
Optimized for Axis IP Cameras
Engineered alongside Axis hardware and firmware to maximize recording performance, prevent frame drops, and ensure long-term stability under intensive read/write cycles.
High-Endurance 3D NAND Technology
Utilizes industrial-grade component architecture to withstand rigorous continuous writing protocols, far outlasting standard commercial-grade SD cards.
Technical Specification Matrix
Camera Model
AXIS Surveillance Card 128 GB
Storage Capacity
128 GB
Card Type
microSDXC™ with SD™ Adapter Included
Speed Class
Class 10, U3, V30, A1
Application Focus
Optimized for edge recording in IP video surveillance
Health Monitoring
Supported on compatible Axis cameras
Compliance
NDAA & TAA Compliant
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
What makes this card different from consumer-grade microSD cards?
This card uses high-endurance industrial components optimized specifically for the continuous 24/7 read/write requirements of high-definition surveillance video, preventing the data corruption common in consumer cards.
Does this card support health monitoring features?
Yes, when deployed in compatible Axis network cameras, the card interfaces with the camera's OS to report real-time wear status and operational health analytics.
Is an SD adapter included in the package?
Yes, the package includes a high-quality microSD to standard SD adapter for expanded system configuration and deployment versatility.
Is this product compliant with US federal government regulations?
Yes, the AXIS Surveillance Card 128 GB is fully NDAA and TAA compliant, making it authorized for use in federal, military, and corporate high-security environments.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS D-SERIES · NDAA & TAA COMPLIANT
Active Visual & Audio Deterrence for Enterprise Environments
The AXIS D4100-VE Mk II is an advanced, fully networked IP-based strobe siren designed to deliver high-impact warnings and notifications across your premises. Combining automated multicolored RGBA light patterns with a highly penetrating 110 dB audible alarm, this next-generation alert system bridges the gap between passive surveillance and active deterrence. Built for harsh environments, it serves as an essential deployment component for commercial perimeters, high-density parking facilities, warehouse bays, and critical infrastructure requiring immediate localized response protocols.
Audio Output
110 dB Alert Siren
Visual Optics
RGBA & White LEDs
Integration
MQTT, SIP & VAPIX
Protection
IP66 / IK10 Outdoor
Smarter Edge Logic & Seamless Unified Integration
Equipped with an upgraded processing architecture and fortified with advanced hardware-level cybersecurity through Axis Edge Vault, the AXIS D4100-VE Mk II ensures mission-critical communication resilience. With deep integration protocols—including native support for VAPIX®, MQTT, and Session Initiation Protocol (SIP) for VoIP systems—this device links intuitively with license plate recognition (LPR) cameras, perimeter thermal sensors, and Axis network speakers. Security teams can establish up to 30 custom priority profiles, allowing silent strobe alerts for healthcare settings or overriding, maximum-volume flash sequences for immediate intrusion response.
Customizable Multi-Tiered Signaling
Configure tailored operational profiles based on specific threat severities. Utilizing specialized white and RGBA LED light patterns alongside flexible sound frequencies, the unit handles everything from standard warehouse loading bay clearance updates to perimeter breaching alarms.
Cost-Efficient PoE Infrastructure
By blending high-intensity strobe notification lights and a powerful siren into a single IP-addressable unit, infrastructure and installation costs are cut in half. Power over Ethernet (PoE) ensures swift single-cable connectivity without needing separate local power drops.
Technical Specification Matrix
Camera Model
AXIS D4100-VE Mk II
Visual Illumination
Red, green, blue, amber (RGBA) LEDs & White LEDs (up to 893 lm)
Maximum Sound Level
110 dB at 1 meter (3.4 kHz frequency peak)
Network API Protocols
VAPIX®, MQTT, SIP (VoIP), ACAP
Cybersecurity Hardware
Axis Edge Vault, Secure Keystore (CC EAL6+), Secure Boot
Physical Casing
IP66-, NEMA 4X-, and IK10-rated aluminum & plastic casing
Power Input
Power over Ethernet (PoE) IEEE 802.3at Type 2 Class 4 (Max 22.6 W)
Operating Range
-40 °C to 60 °C (-40 °F to 140 °F)
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Can the strobe flash without triggering the siren?
Yes. Through the profile configuration tools, you can isolate visual patterns (RGBA or white light) completely from audio actions. This allows discreet notifications or safety signaling inside hospitals, cleanrooms, or patient areas.
How does it integrate with automated network video systems?
The device leverages native VAPIX® and MQTT protocols to link directly with IP cameras running motion tracking or analytical barriers (e.g., AXIS Perimeter Defender) to activate sirens immediately upon a breach event.
Is the sound level adjustable for localized operations?
Yes. While it features a maximum output capability of 110 dB at 1 meter for outdoor environments, audio thresholds and specific pre-configured tones can be customized based on structural boundaries.
What cybersecurity frameworks protect this unit?
It includes the embedded Axis Edge Vault platform, which secures the hardware system-on-chip, implements secure boots, and relies on a dedicated cryptographic keystore (CC EAL6+) to prevent unauthorized system injection.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS D SERIES · NDAA & TAA COMPLIANT
Enterprise-Grade Environmental Analytics and Monitoring
The AXIS D6210 is a premium, purpose-built air quality sensor designed to deliver hyper-local environmental intelligence within commercial, educational, and healthcare facilities. By tracking volatile organic compounds (VOCs), particulate matter, temperature, and humidity, this high-density device enables property managers and security teams to maintain optimal indoor environments, verify air safety compliance, and safeguard occupant health through actionable, real-time data streaming directly into existing video management software (VMS).
Sensors
VOC, PM2.5, RH, Temp
Integration
VMS & MQTT Native
Power
PoE Class 3
Protection
IK08 Vandal Rated
Advanced Sensor Analytics & Smart Building Automation
Engineered for seamless architectural integration, the AXIS D6210 Air Quality Sensor acts as a vital data node for modern smart building ecosystems. Utilizing an open platform model, it transmits critical telemetry via standard networking protocols including MQTT and VMS-native integration, allowing environmental data to trigger automated responses such as increasing HVAC ventilation or driving security alerts when toxic spikes are detected. Backed by state-of-the-art cybersecurity features including Axis Edge Vault, signed firmware, and secure boot, this device guarantees absolute data integrity across your enterprise enterprise network.
Comprehensive Multi-Gas & Particulate Analysis
Simultaneously monitor Total Volatile Organic Compounds (TVOCs), PM2.5 particulate densities, ambient room temperatures, and relative humidity percentages. This elimination of multi-sensor fragmentation allows facilities to rely on a unified device for continuous indoor air characterization.
Unified Security Ecosystem Cohesion
Instead of siloing air analytics into disparate building management platforms, the D6210 interfaces directly into major Video Management Systems. Overlay data charts over live security feeds, or index events based on physical environmental shifts for dynamic site oversight.
Technical Specification Matrix
Camera Model
AXIS D6210
Monitored Parameters
PM2.5, VOC, Temperature, Relative Humidity
Network Power Supply
Power over Ethernet (PoE) IEEE 802.3af/at Type 1 Class 3
Casing Rating
IK08 Vandal-Resistant, Plastic Polycarbonate Chassis
Cybersecurity Suite
Axis Edge Vault, Secure Boot, Signed Firmware, Trusted Platform Module (TPM)
Open Integration APIs
MQTT, VMS Native Integration, VAPIX, AXIS Camera Application Platform (ACAP)
Operating Conditions
0 °C to 45 °C (32 °f to 113 °f) | Humidity 10–85% RH (non-condensing)
Compliance Standard
NDAA Section 889 Compliant, TAA Compliant, CE, FCC Class B
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Does the AXIS D6210 require a separate power cord?
No, the unit is entirely powered via Power over Ethernet (PoE Class 3). A single standard network RJ45 connection supplies both the structural operational power and data communication back to your servers.
Can this sensor work natively with third-party Building Automation Systems (BAS)?
Yes. By utilizing open MQTT network broker protocols, the sensor can easily export data streams to corporate HVAC or smart automation controllers for reactive indoor air adjustments.
Is the sensor protected against physical interference or vandalism?
Yes, it features an IK08-rated shock impact housing, providing physical durability against tampering or accidental bumps when mounted in high-traffic commercial environments.
Is the AXIS D6210 compliant with government security procurement policies?
Absolutely. The device is fully NDAA Section 889 and TAA compliant, making it safe for deployment within federal institutions, bank branches, airports, and other highly regulated environments.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS T85 SERIES · NDAA & TAA COMPLIANT
Robust Outdoor Networking for Mission-Critical Surveillance
The AXIS T8504-E is an outdoor-ready, managed PoE+ network switch engineered to simplify the deployment and management of high-density surveillance networks. Perfect for challenging commercial environments, smart city monitoring, and critical infrastructure, this heavy-duty switch eliminates the need for external electrical enclosures. It provides reliable, high-power connectivity directly to your edge devices, ensuring continuous system uptime even in the most demanding physical locations.
PoE+ Delivery
4 Ports (150W Budget)
Optics & Uplink
1x SFP Fiber Slot
Climate Ready
IP67 & NEMA 4X
Surge Rating
Built-in 6 kV Protection
Intelligent Topology and Simplified Management
Managing an outdoor device matrix becomes effortlessly streamlined with the integrated graphic web interface. When expanding your footprint with the AXIS T8504-E, installers gain an absolute visual map of the entire network topology. This deep system insight offers advanced technical capabilities, such as automated camera discovery, port-level diagnostics, and remote power cycling. Seamless optimization within AXIS Camera Station guarantees that configuration, firmware updates, and troubleshooting are executed from a single pane of glass, dramatically reducing operational truck rolls.
All-Weather Hardened Integrity
Housed in an IP67, NEMA 4X, and IK10-rated vandal-resistant enclosure, this switch completely circumvents the cost and bulk of additional environmental housing. It operates flawlessly across extreme temperature standard variances from -40 °C to 50 °C, offering continuous operation under intense frost, heat, or heavy rainfall.
Long-Distance Fiber Connectivity
Equipped with an independent SFP fiber slot alongside its standard data and PoE+ ports, the switch accommodates high-speed fiber backhaul connections. This is highly valuable for perimeter security layouts and large industrial facilities where network runs exceed standard Ethernet distance limitations.
Technical Specification Matrix
Network Switch Model
AXIS T8504-E
Interfaces
4x RJ45 10/100/1000 Base-T PoE+, 1x RJ45 Data, 1x SFP Port
PoE Power Budget
Total 150 W (Up to 30 W per port)
Environmental Rating
IP67, NEMA 4X, IK10 Vandal-Resistant Enclosure
Surge Protection
Built-in up to 6 kV surge protection on all ports
Operating Conditions
-40 °C to 50 °C (-40 °F to 122 °F)
Dimensions
240 mm x 166 mm x 72 mm (9.5 in x 6.5 in x 2.8 in)
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Does the AXIS T8504-E require an additional weather cabinet?
No. Thanks to its robust IP67, NEMA 4X, and IK10 industrial ratings, this switch is fully sealed against rain, dust, ice, and dynamic impact, allowing for direct outdoor installation on walls or utility poles.
Can I manage non-AXIS devices through the interface?
Yes. The switch features a full web interface for standard network configuration. However, enhanced features like dynamic topology maps and deep camera discovery are uniquely optimized for native AXIS devices and software.
What happens if a connected camera stops responding?
Because the switch features managed PoE infrastructure, administrators can remotely log into the graphical user interface to cycle the power of an individual port, instantly rebooting the camera without visiting the hardware site.
Is this device compliant with federal infrastructure standards?
Absolutely. The AXIS T8504-E is completely NDAA and TAA compliant, conforming strictly with United States federal government procurement regulations and safety architectures.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS ACCESSORIES · NDAA & TAA COMPLIANT
Enterprise-Grade Power Delivery for Extreme Environments
The AXIS 30 W Outdoor Midspan provides high-performance Power over Ethernet (PoE) infrastructure designed to deliver robust power transmission to network video surveillance systems. Specially engineered for critical commercial applications, infrastructure deployments, and high-density outdoor installations, this midspan safely injects up to 30W of power over standard Cat5e/Cat6 data cables. It ensures seamless, uninterrupted performance for remote IP cameras and edge devices operating under challenging environmental conditions without requiring costly local power infrastructure modifications.
Resolution
Data Passthrough
Optics
10/100/1000 Mbps
Night Vision/PTZ
IEEE 802.3at / af
Protection
IP66 / NEMA 4X
Advanced Resilience and Network Safeguards
Equipped with intelligent internal circuitry, the AXIS 30 W Outdoor Midspan reliably detects whether the downstream device is PoE-compatible, preventing electrical overloads or damage to legacy equipment. By offering built-in surge protection against unexpected electrical transients, it protects high-value edge investments from unexpected utility fluctuations. The system features seamless integration with high-speed Gigabit Ethernet networks, guaranteeing zero data throttling or latency impacts on streaming video analytics and advanced onboard tracking protocols.
All-Weather Ruggedized Design
Features an IP66, IP67, and NEMA 4X rated enclosure that seals completely against driving rain, blowing dust, sleet, and corrosion. Ideal for installations across industrial perimeters, marine berths, and remote toll checkpoints.
Flexible High-Output Power Allocation
Complies perfectly with both IEEE 802.3af (15.4W) and IEEE 802.3at (30W) frameworks. It provides sufficient headroom to power fixed lenses, heater-driven enclosures, and advanced internal edge-computing modules seamlessly.
Technical Specification Matrix
Camera Model
AXIS 30 W Outdoor Midspan
Power Output
Up to 30 W (IEEE 802.3at / IEEE 802.3af standard compliant)
Input Power
100–240 V AC (50/60 Hz)
Data Rates
10/100/1000 Mbps Gigabit Ethernet Passthrough
Connectors
Shielded RJ45, EIA 568A and 568B compatibility
Operating Temperature
-40 °C to 65 °C (-40 °F to 149 °F) at 30 W output
Environment Ratings
IP66, IP67, NEMA 4X, IK10 Impact Rated Enclosure
Compliance & Standards
NDAA Compliant, TAA Certified, CE, FCC Part 15 Class B, UL/cUL
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Does this midspan require special outdoor cabling configurations?
While the midspan itself features integrated weatherproof cable seals, AXIS strongly recommends deploying shielded, outdoor-rated Category 5e or Category 6 cabling alongside properly terminated RJ45 connectors to maintain the integrity of the weatherproofing system.
Will this power non-AXIS network equipment safely?
Yes. The unit incorporates dynamic auto-sensing intelligence matching IEEE 802.3af/at standards. It verifies the presence of an authentic PoE signature prior to outputting power, ensuring cross-brand safety for standard compliance infrastructure.
What happens during a localized power line surge event?
The AXIS 30 W Outdoor Midspan includes dedicated internal surge protection engineered to intercept high-voltage transients, diverting damaging energy away from the interconnected network camera and local switch interfaces.
Is this model fully certified under government procurement rules?
Absolutely. This device features direct NDAA and TAA compliance status, qualifying it for high-security environments, federal installations, enterprise facilities, and international commercial networks demanding stringent hardware supply verification.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS C-SERIES · NDAA & TAA COMPLIANT
Centralized Control for Enterprise Smart Audio Networks
The AXIS C7050 Mk III Core Network Audio Appliance acts as the powerhouse foundation for intelligent, large-scale commercial audio systems. Designed for sophisticated environments like retail chains, education campuses, and corporate facilities, this high-performance audio manager bridges complex software control with distributed network speaker zones. It streamlines the deployment, scheduling, and monitoring of background music, live announcements, and scheduled public address alerts, ensuring flawless operation across enterprise architectures.
Resolution
High-Fi Audio Core
Optics
Multi-Zone Matrix
Night Vision/PTZ
24/7 Automation
Protection
Enterprise Cyber
Intelligent Integration & Simplified Audio Management
Engineered for professional performance, the AXIS C7050 Mk III works in perfect synchronization with Axis audio management software to provide an intuitive interface for complex audio configuration. It handles advanced audio processing protocols, dynamic zone routing, volume management, and health monitoring diagnostics seamlessly. Armed with powerful cyber defense capabilities, including signed firmware and secure boot, this server ensures your local network audio streams remain reliable, protected, and accessible from a unified dashboard.
Enterprise Audio Scheduling & Paging
Centrally plan, coordinate, and broadcast pre-recorded messages, real-time security alerts, or high-fidelity background music playlists across dozens of distinct physical architectural zones from one server interface.
Hardened Cybersecurity Infrastructure
Equipped with state-of-the-art security enhancements like Axis Edge Vault, cryptographic device IDs, signed firmware, and secure boot sequences to shield your audio streaming framework from modern threat environments.
Technical Specification Matrix
Camera Model
AXIS C7050 Mk III
Product Type
Core Network Audio Appliance
Supported Software
AXIS Audio Manager Pro / AXIS Audio Manager Edge
Operating System
Axis Built-in Secure Linux Platform
Network Security
Signed Firmware, Secure Boot, Axis Edge Vault, Cryptographic ID
Form Factor
Compact Standalone / Rack-Mountable Ready
Regulatory Status
NDAA Compliant & TAA Certified
Power Supply
Standard External Power Adapter (Included)
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Is the AXIS C7050 Mk III fully NDAA and TAA compliant?
Yes, this audio appliance is fully compliant with the National Defense Authorization Act (NDAA) and Trade Agreements Act (TAA) regulations, making it perfect for installation in high-security federal, corporate, and public infrastructure sites.
What software does this network audio appliance run?
The device serves as the core hardware hub designed to seamlessly host and run AXIS Audio Manager platforms for complex zoning, advanced scheduling, and unified multi-site control.
Does the appliance include cybersecurity defenses?
Absolutely. The device features premium, built-in enterprise security functionalities including Axis Edge Vault, secure boot processes, and signed firmware architectures to prevent unauthorized network breaches.
Can it manage audio distribution across multiple properties?
Yes. Combined with Axis software solutions, it allows for scalable remote management across hundreds of separate endpoints, local network zones, or completely distributed commercial retail locations.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS C-SERIES · NDAA & TAA COMPLIANT
Intelligent, Long-Range Public Address Messaging
The AXIS C1610-VE is a rugged, network-integrated sound projector engineered to deliver crystal-clear voice messages across expansive commercial and public areas. Ideal for harsh outdoor environments, industrial perimeters, and high-density urban zones, this standalone IP speaker acts as a powerful audio deterrent. With a robust minimalist aesthetic and integrated smart capabilities, it seamlessly blends proactive voice intervention with your existing network video surveillance environment.
Audio Output
121 dB Max SPL
Dispersion
Long-Range Direct
Intelligence
Auto Health Test
Protection
IP66/IP67 & IK10
Advanced Edge Integration & Acoustic Testing
Driven by edge-based software, the AXIS C1610-VE operates as an all-in-one audio management powerhouse without relying on external servers. It comes equipped with pre-loaded AXIS Audio Manager Edge, enabling operators to manage scheduling, zones, and content permissions efficiently. A built-in microphone continuously monitors speaker health by performing automated acoustic tests, guaranteeing the device is fully functional when emergency announcements or security call-outs are critically needed.
All-in-One Audio System
Eliminate complex cabling and dedicated central amplifiers. The system contains a built-in power amplifier and digital signal processor (DSP) that optimizes clarity out of the box. Connects directly to standard IP networks via a single PoE/PoE+ drop for maximum installation simplicity.
Vandal & Weatherproof Engineering
Encased in a certified IK10, IP66, IP67, and NEMA 4X rated chassis. The device handles extreme environments ranging from -40 °C to 60 °C, offering long-term reliability against heavy downpours, windborne debris, corrosion, and intentional tampering.
Technical Specification Matrix
Camera Model
AXIS C1610-VE
Audio Output
121 dB SPL (Peak at 1m)
Power Method
Power over Ethernet (PoE) IEEE 802.3af/802.3at
Integrated Software
AXIS Audio Manager Edge (Pre-installed)
Microphone
Built-in electret condenser (for auto speaker test & two-way audio)
Environmental Ratings
IP66, IP67, NEMA 4X, IK10 vandal resistance
Operating Temperature
-40 °C to 60 °C (-40 °F to 140 °F)
Compliance
NDAA Compliant, TAA Compliant
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Does the system require a central server for audio schedules?
No. The unit features built-in AXIS Audio Manager Edge firmware, allowing you to configure zones, manage schedules, handle content, and deploy updates locally directly from a web browser.
How does the automatic health test work?
The integrated microphone listens for a sub-audible tone emitted by the internal amplifier components. This self-test validates that the amplifier and speaker drivers are operating flawlessly without needing onsite visual or audible checkups.
Is this model fully compliant with federal procurement standards?
Yes. The speaker is completely NDAA and TAA compliant, making it safe and certified for placement within US government sites, defense applications, and enterprise infrastructures.
Can it connect to VoIP systems?
Absolutely. It supports Session Initiation Protocol (SIP) for seamless integration with modern Voice over IP (VoIP) telephony systems, allowing live page messages via standard office phone lines.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS C SERIES · NDAA & TAA COMPLIANT
Intelligent Voice Announcements & Proactive Surveillance Audio
The AXIS C1410 Mk II is an all-in-one network speaker designed to deter unwanted activity and deliver clear voice messages across retail, commercial, and enterprise spaces. By integrating audio proactively into your security network, this intelligent speaker transforms passive surveillance into active prevention. Perfect for tight spaces or discreet wall installations, it acts as a smart, standalone perimeter responder that stops security breaches before they escalate.
Audio Output
90 dB Max SPL
Integrated PIR
Built-in Motion Sensor
Mic & Feedback
Built-in Microphone
Power Connectivity
PoE Support
Open Standards Architecture with Intelligent Motion Detection
The AXIS C1410 Mk II is engineered on open software standards, making integration into your existing Video Management Software (VMS), VoIP telephony (via SIP), and advanced network analytics platforms completely seamless. It comes equipped with a preconfigured passive infrared (PIR) sensor that detects motion precisely, allowing the device to trigger pre-recorded, localized voice warnings when an intruder approaches. With onboard memory for local audio file storage, a built-in microphone for remote healthcare checks or acoustic testing, and a system health indicator, this device ensures zero downtime and constant operational transparency.
All-in-One Compact Audio Node
Forget external amplifiers, mixers, or complex audio wiring. The C1410 Mk II packs digital signal processing (DSP), an integrated amplifier, storage, and an active microphone into a single, compact housing that connects with a single PoE cable.
Smart PIR Motion Integration
Drive instant action at the edge. The built-in PIR sensor provides 90° coverage, triggering custom warning files or live announcements immediately upon human detection, bypassing the need for separate external sensors.
Technical Specification Matrix
Camera Model
AXIS C1410 Mk II
Audio Output
90 dB SPL (at 1 meter distance)
Frequency Response
100 Hz to 20 kHz
Built-in Storage
MicroSD/microSDHC/microSDXC slot, up to 128 GB local storage
Power Method
Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3
PIR Sensor Range
Up to 6 meters (20 ft) tracking with a 90° wide angle
Supported Protocols
IPv4/v6, HTTP, HTTPS, SIP, SSL/TLS, QoS, Bonjour
Compliance
NDAA Compliant, TAA Certified
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Can this speaker work standalone without a complex backend system?
Yes, the AXIS C1410 Mk II operates as an independent edge device. Thanks to its integrated PIR sensor and on-board storage, you can store prerecorded messages directly on the speaker and trigger them instantly upon motion detection without an external server.
Does the C1410 Mk II support integration into third-party VoIP systems?
Absolutely. It supports SIP (Session Initiation Protocol) standards, allowing it to seamlessly register as a standard endpoint within your existing VoIP telephony infrastructure for easy live paging from any office phone.
How does the speaker verify its own hardware health over time?
It features a built-in microphone that performs regular, automated speaker health tests (Auto Speaker Test). The microphone listens to low-frequency signals emitted by the speaker to ensure clear performance and flag errors remotely.
Is this model fully compliant with federal procurement regulations?
Yes, this network speaker is fully certified as NDAA and TAA compliant, making it safe and approved for deployment within federal institutions, critical infrastructure, and high-security enterprise projects.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS C SERIES · NDAA & TAA COMPLIANT
Discreet, Intelligent Audio for Commercial Infrastructure
The AXIS C1710 is a premier all-in-one network audio ceiling speaker designed to blend seamlessly into modern retail, enterprise, and public architectural spaces. Delivering crisp live announcements, scheduled voice messaging, and high-fidelity background music over a standard network, this intelligent endpoint removes the complexity of traditional analog public address systems. Engineered for seamless flush-mount integration, it is ideal for high-density applications requiring superior audio clarity without sacrificing aesthetic integrity.
Audio Output
High-SPL Clarity
Architecture
All-In-One System
Connectivity
PoE Network Audio
Security compliance
NDAA & TAA Ready
Advanced Digital Signal Processing & Network Sovereignty
Unlike standard passive components, this intelligent endpoint incorporates a built-in power amplifier and digital signal processing (DSP) unit configured directly out of the box. By migrating your facility architecture to the AXIS C1710, you deploy an open-standards solution using SIP, VoIP, and VAPIX protocols. Security teams can leverage zone-based routing, automated health testing, and bidirectional communication integrations to achieve total operating awareness across local networks.
Pre-configured DSP & Auto-Testing
Features an onboard digital signal processor optimized for pristine speech intelligibility and balanced background audio. The embedded system regularly performs remote health-checks to ensure operation continuity.
One Cable via PoE Deployment
Eliminates the logistical bottlenecks of traditional multi-tier analog audio grids. Power, configurations, and dual-channel streaming audio travel safely through a single standard Cat5e/Cat6 ethernet terminal connection.
Technical Specification Matrix
Camera Model
AXIS C1710
Product Type
Network Ceiling Speaker
Audio Management
AXIS Audio Manager Edge Built-In
Power Method
Power over Ethernet (PoE) IEEE 802.3af/802.3at
Frequency Range
Voice optimized with High-SPL response
Supported Protocols
IPv4/v6, SIP, VAPIX, HTTP/HTTPS, SRTP
Compliance Status
NDAA Compliant / TAA Compliant
Housing Enclosure
Flush-mount ceiling design, plenum-rated components
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Does the AXIS C1710 require a central matrix amplifier unit?
No. The AXIS C1710 is a standalone edge device featuring an integrated internal digital amplifier and signal processor. It connects directly to your network switch via a standard Ethernet connection.
Can I synchronize multiple C1710 audio units for zone paging?
Yes. By utilizing the embedded AXIS Audio Manager Edge control interface, you can easily group, manage, and schedule distinct content for dozens of endpoints simultaneously over local IP subnets.
Is this network speaker NDAA and TAA compliant?
Absolutely. The AXIS C1710 complies fully with the National Defense Authorization Act (NDAA) and Trade Agreements Act (TAA) frameworks, fulfilling standard government and enterprise cybersecurity deployment rules.
How is the unit powered over standard enterprise switches?
The system utilizes standard Power over Ethernet protocols. An Ethernet cord delivers network connectivity and clean low-voltage operational power instantly, minimizing auxiliary line runs.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
Dahua Ultra Series · Android 14 Smart Control Panel
The Dahua SCP3044A-BZ is a premium 10.1-inch smart control panel that runs the latest Android 14 on an edge-to-edge IPS touchscreen. As a hybrid indoor monitor it works over IP, Wi-Fi 6 or 4-wire cabling, answers your Dahua door station, controls access and even monitors room temperature and humidity from the home screen. Proximity wake, auto-brightness and multi-colour breathing indicators make it a genuinely smart hub for modern homes and apartments. Genuine Dahua, Australian stock and local support.
Operating System
Android 14
Display
10.1″ IPS Touch · 1280×800
Connectivity
IP · Wi-Fi 6 · 4-Wire
Smart Sensors
Temperature & Humidity
Why Choose the Dahua SCP3044A-BZ
Android 14 Performance
The latest Android platform delivers a fast, app-like experience with a clean, user-friendly interface for everyday control.
Edge-to-Edge 10.1″ IPS
A full-screen design with ultra-narrow black border and 80° wide viewing angles both ways for a bright, premium look.
Hybrid IP + 4-Wire
Connect over IP, Wi-Fi or Dahua 4-wire cabling — flexible for new builds and retrofits alike.
Wi-Fi 6, Bluetooth & Zigbee
Dual-band Wi-Fi 6 (802.11ax), Bluetooth and reserved Zigbee 3.0 make it a future-ready smart-home hub.
Effortless Interaction
Proximity auto-wake, a light sensor for auto-brightness and multi-colour breathing indicators keep status clear at a glance.
Built-In Climate Monitoring
Onboard temperature and humidity detectors let you check room conditions straight from the home screen.
Technical Specifications
System & Display
Operating System
Android 14
Screen
10.1-inch IPS capacitive multi-touch
Resolution
1280 (H) × 800 (V)
Viewing Angle
Up to 80° horizontal & vertical
Network Protocols
IPv4, RTSP, UDP, DNS, FTP, RTP, TCP, SIP
Communication
Full digital & analog 4-wire
Audio
Two-way, echo suppression & noise reduction
Extensions
Villa: 1 main + 9 · Apartment: 1 main + 4
Smart Sensors
Temperature & humidity, light sensor, proximity wake
Storage
microSD up to 512GB
Wireless
Wi-Fi
IEEE 802.11 a/b/g/n/ac/ax (Wi-Fi 6)
Wi-Fi Bands
2.4 GHz & 5 GHz
Bluetooth
BR / EDR / BLE
Zigbee
Zigbee 3.0 (reserved for third-party access)
Sub-1G
868–868.6 MHz
Ports, Power & General
Ports
1 × RS-485, 1 × USB, 1 × 10/100 Ethernet, 1 × 4-wire
Alarm I/O
8 inputs / 1 output · 12V 200mA power output
Power Supply
12 VDC 2A or standard PoE
Power Consumption
≤ 12W standby, ≤ 15W working
Casing
PC + ABS, grey
Installation
Flush mount (bracket included)
Dimensions
246.5 × 156.1 × 33.0 mm
Operating Temp.
-10°C to +55°C
Certification
CE
Datasheets & Guides
DHI-SCP3044A-BZ Datasheet
Dahua Smart Control Panel User Manual
Dahua Video Door Phone Quick Start Guide
Dahua Smart Control Panel Privacy Policy
Dahua Software License Agreement
Dahua Open Source Software Notice
Frequently Asked Questions
What is the SCP3044A-BZ?A Dahua Ultra Series Android 14 smart control panel — a 10.1-inch touchscreen indoor monitor for video intercom, access and smart-home control.
How does it connect?Over IP, dual-band Wi-Fi 6 or Dahua 4-wire cabling, so it suits both new installs and retrofits.
Does it monitor room conditions?Yes. Built-in temperature and humidity detectors show live readings on the home screen.
Can I expand to more monitors?Yes. It supports 1 main plus 9 extensions in villa mode, or 1 main plus 4 in apartment mode.
How is it powered?By 12 VDC 2A or standard PoE over a single network cable.
How is it mounted?Flush-mounted, with the bracket and cabling accessories included in the box.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
AXIS Q-SERIES · NDAA & TAA COMPLIANT
High-Resolution Perimeter Protection with 32x Optical Zoom & Edge AI
The AXIS Q1806-LE is an elite, high-performance outdoor bullet camera engineered for long-range surveillance and ultra-precise target identification. Combining a brilliant 4MP Quad HD resolution with a powerful 32x optical zoom, this camera allows security teams to monitor sprawling perimeters, high-traffic corridors, and critical infrastructure with stunning clarity. Powered by the ARTPEC-8 processor and a hardware-dedicated Deep Learning Processing Unit (DLPU), it brings advanced, edge-based object classification right to the front line of your security framework.
Resolution
4MP Quad HD
Optics
32x Optical Zoom
Night Vision
100m OptimizedIR
Protection
IP66/67, NEMA 4X, IK10
Exceptional Low-Light Control & Comprehensive Hardware Security
The AXIS Q1806-LE is equipped with a premium 1/1.8" sensor, driving Lightfinder 2.0 and Forensic WDR to capture vivid, low-noise color detail in near-pitch darkness and highly uneven, back-lit scenes. Its built-in electronic image stabilization (EIS) ensures smooth, shake-free feeds even when the camera is zoomed in completely or subjected to strong winds. To guard against network vulnerabilities, the integrated Axis Edge Vault technology ensures strict hardware-level cybersecurity with signed firmware, secure boot, and a FIPS 140-3 Level 3 certified secure cryptographic key store.
True 32x Optical Zoom with 4MP Quality
Capture forensic-level details at extreme distances. Unlike digital cropping which degrades image quality, the 32x optical zoom maintains native 4MP Quad HD resolution, making it easy to identify license plates, faces, and insignias across vast open fields.
Adaptive, Long-Range OptimizedIR
Equipped with highly adaptive IR illumination, the camera dynamically narrows or widens its infrared beams to perfectly mirror the zoom level. It provides balanced, crystal-clear night-vision coverage up to 100 meters (328 feet) without overexposing foreground subjects.
Technical Specification Matrix
Camera Model
AXIS Q1806-LE
Image Sensor Size
High-performance 1/1.8" progressive scan RGB CMOS
Optical Zoom & Lens
Varifocal, 4.3–137 mm, F1.4–4.0, 32x Optical Zoom, Auto-focus, P-Iris control
Field of View
Horizontal: 60° to 2.3°, Vertical: 35° to 1.3°
Processing SoC
ARTPEC-8 with hardware Deep Learning Processing Unit (DLPU)
Video Compression
H.265 (Main Profile), H.264 (Baseline/Main/High), Motion JPEG with Zipstream
Max Resolution & Frame Rate
2688x1512 (4MP) at up to 50/60 fps (WDR on) or up to 100/120 fps (WDR off)
Power Architecture
PoE (IEEE 802.3at Type 2 Class 4), Max 22.1 W; or 12–28 V DC / 24 V AC input
Enclosure Ratings
IP66, IP67 weather-proof, NEMA 4X corrosion-resistant, and IK10 impact-rated casing
Hardware Security
Axis Edge Vault, FIPS 140-3 Level 3 certified secure key storage, Signed OS, Secure Boot
Technical Datasheet Repainting Instructions
Operation Manual Installation Manual
Frequently Asked Questions
What is the difference between the AXIS Q1805-LE and the Q1806-LE?
While both cameras share the same elite 32x optical zoom lens, physical housing, and robust deep learning processors, the main difference lies in resolution. The AXIS Q1805-LE records in 2MP (1080p), whereas the AXIS Q1806-LE captures in a higher-density 4MP Quad HD resolution for even greater pixel density and forensic digital crop capabilities.
Is the AXIS Q1806-LE compliant with federal NDAA standards?
Yes. The AXIS Q1806-LE is fully NDAA (National Defense Authorization Act) and TAA (Trade Agreements Act) compliant, ensuring that it uses secure, non-blacklisted global components and meets all US government and military security procurement requirements.
How does Electronic Image Stabilization (EIS) work on this model?
At high focal lengths (zoomed fully in), even minor vibrations from nearby wind, machinery, or heavy vehicles can make a video stream unusable. The Q1806-LE uses built-in gyroscopic sensors to detect vibration and dynamically stabilizes the video stream in real time to ensure smooth, usable footage.
How durable is this camera's chassis for industrial environments?
The camera is built inside an IP66/IP67 weather-proof, NEMA 4X corrosion-resistant, and IK10 impact-rated aluminum housing. It features a built-in heater and dehumidifying membrane to manage internal condensation, ensuring seamless operation between -40 °C and 60 °C (-40 °F to 140 °F).
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS Q-SERIES · NDAA & TAA COMPLIANT
Long-Range Intelligence: High-Performance Bullet Camera with 32x Optical Zoom
The AXIS Q1805-LE is an elite, outdoor-ready bullet camera designed for long-distance surveillance and razor-sharp target identification. Delivering outstanding 2MP 1080p resolution at high frame rates up to 120 fps, this performance-driven camera is powered by the newest generation ARTPEC-8 system-on-chip. Incorporating a dedicated Deep Learning Processing Unit (DLPU), it enables edge-based object analytics, classifying humans, vehicles, and specific vehicle types with incredible accuracy over massive coverage zones.
Resolution
2MP 1080p @ 120fps
Optics
32x Optical Zoom
Night Vision
100m OptimizedIR
Protection
IP66/67, NEMA 4X, IK10
Premium Low-Light Technology & Heavy-Duty Build
Engineered with a powerful 4.3–137 mm varifocal lens, the AXIS Q1805-LE enables security teams to zoom in across broad perimeters, highways, or shipping lanes with absolute clarity. Thanks to Lightfinder 2.0 and Forensic WDR, the sensor effortlessly balances high-contrast, harsh-backlit environments and delivers full-color details in near-pitch darkness. For perimeter integrity, Axis Edge Vault shields the device with a hardware-based cyber security system, secure boot, and a FIPS 140-3 Level 3 certified cryptographic key store.
True 32x Optical Zoom Performance
Never lose pixels to digital magnification. The precision-engineered 32x optical zoom lens allows operators to focus on license plates, faces, and distant safety signs hundreds of meters away with incredible fine-grain detail.
Adaptive, Long-Range OptimizedIR
The integrated power-efficient OptimizedIR dynamically alters its illumination beam to match the exact field of view of the optical zoom, reaching a massive distance of up to 100 meters (328 feet) in complete darkness.
Technical Specification Matrix
Camera Model
AXIS Q1805-LE
Image Sensor Size
Premium 1/1.8" progressive scan RGB CMOS
Optical Zoom & Lens
Varifocal, 4.3–137 mm, F1.4–4.0, 32x Optical Zoom, Auto-focus, P-Iris control
Field of View
Horizontal: 60° to 2.3°, Vertical: 35° to 1.3°
Processing SoC
ARTPEC-8 with hardware Deep Learning Processing Unit (DLPU)
Video Compression
H.265 (Main Profile), H.264 (Baseline/Main/High), Motion JPEG with Zipstream
Max Resolution & Frame Rate
1920x1080 (2MP) at up to 100/120 fps (WDR off) or 50/60 fps (WDR on)
Power Architecture
PoE (IEEE 802.3at Type 2 Class 4), Max 22.1 W; or 12–28 V DC / 24 V AC input
Enclosure Ratings
IP66, IP67, NEMA 4X, and IK10 metal housing with integrated dehumidifying membrane
Hardware Security
Axis Edge Vault, FIPS 140-3 Level 3 certified secure key storage, Signed OS, Secure Boot
Technical Datasheet Repainting Instructions
Operation Manual Installation Manual
Frequently Asked Questions
Is the AXIS Q1805-LE compliant with federal regulations like the NDAA?
Yes. The AXIS Q1805-LE is fully NDAA (National Defense Authorization Act) and TAA (Trade Agreements Act) compliant. It does not use components or chipsets from blacklisted manufacturers, making it ideal for federal, aviation, municipal, and military installations.
How does the 32x optical zoom maintain image quality at distance?
Unlike digital zoom, which crops and loses pixel density, the 32x optical zoom on the AXIS Q1805-LE relies on moving glass elements to adjust focal length. This retains the full 2MP (1080p) sensor resolution even when zooming in on objects hundreds of meters away.
Can this camera operate in extremely cold or warm environments?
Yes. Equipped with a built-in climate control system, heater, and dehumidifying membrane, the rugged IP66/67-rated enclosure operates efficiently in extreme temperatures ranging from -40 °C to 60 °C (-40 °F to 140 °F).
What is the purpose of the built-in Deep Learning Processing Unit (DLPU)?
The hardware-dedicated DLPU runs AI analytics directly on the camera. It processes AXIS Object Analytics to differentiate between humans and different classes of vehicles (cars, trucks, buses, bikes) on-edge, significantly lowering false alarms and server processing costs.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS Q-SERIES · NDAA & TAA COMPLIANT
Top-Tier Vandal-Resistant Dome Built for Critical Surveillance
The AXIS Q3546-LVE is a premier, outdoor-ready fixed dome camera engineered to deliver high-performance video capture and intelligent scene understanding under the harshest environmental conditions. Equipped with a high-accuracy 4.3–10 mm varifocal lens, this advanced Q-series camera provides flexible coverage options from wide-angle overviews to focused zoomed views. Leveraging deep learning processing capabilities directly on the edge, the camera classifies complex objects in real time, serving as an active security asset for public spaces, critical transit hubs, and industrial environments.
Resolution
4MP Quad HD
Optics
4.3-10mm Varifocal
Night Vision
40m OptimizedIR
Protection
IP66/IP67 & IK10+
Proactive Visual Capture & Bulletproof Cybersecurity Protocols
The AXIS Q3546-LVE boasts outstanding low-light performance thanks to Lightfinder 2.0 and Forensic WDR, capturing true-to-life colors even when illuminated by faint starlight. The camera integrates Zipstream compression technology, protecting both storage space and bandwidth without losing critical, pixel-dense detail. Additionally, it is fortified with Axis Edge Vault, safeguarding your entire network connection through secure boot, signed firmware, and a hardware-protected cryptographic key store.
Advanced Edge-AI Analytics Engine
The dedicated hardware DLPU accelerates deep learning processing right on the camera. With preloaded AXIS Object Analytics, it tracks and accurately differentiates between human pedestrians and vehicle types, optimizing metadata generation and eliminating standard motion-based false triggers.
IK10+ Extreme Impact Resistance
Featuring a robust, weather-shielded casing rated to IK10+ (surpassing standard vandal ratings), this camera is built to withstand high-energy impacts and direct physical tampering, continuing to record cleanly even in highly volatile public environments.
Technical Specification Matrix
Camera Model
AXIS Q3546-LVE
Image Sensor
1/1.8" progressive scan RGB CMOS
Lens & Focal Length
Varifocal, 4.3–10 mm, F1.5–2.0, Remote Zoom & Focus, P-Iris control
Field of View
Horizontal: 104° to 44°, Vertical: 56° to 25°
Intelligence Processing
Advanced ARTPEC SoC with integrated Deep Learning Processing Unit (DLPU)
Video Compression
H.265 (Main Profile), H.264 (Baseline/Main/High), Motion JPEG with Zipstream
Max Resolution & Frame Rate
2688x1512 (4 MP) @ 50/60 fps (WDR off) or 25/30 fps (WDR on)
Power Supply
Power over Ethernet (PoE) IEEE 802.3af/at Type 1 Class 3 (Max 12.95 W)
Housing Ratings
IP66/IP67 weather-proof, NEMA 4X, and IK10+ vandal-resistant casing
Onboard Security
Axis Edge Vault, Secure Boot, Signed OS, Cryptographic Key Storage
Technical Datasheet Quick Start Guide
Operation Manual Installation Manual
Frequently Asked Questions
Is the AXIS Q3546-LVE NDAA compliant for government deployments?
Yes. The AXIS Q3546-LVE is fully NDAA (National Defense Authorization Act) and TAA (Trade Agreements Act) compliant. This ensures it meets the highest digital security and sourcing standards, qualifying it for government and military facilities.
What does the IK10+ rating signify?
While the standard high-vandal rating is IK10 (resisting 20 joules of impact), the AXIS Q35-LVE series is built to exceed this up to IK10+ (withstanding up to 50 joules). This extra-tough reinforcement is ideal for prisons, subway terminals, and areas highly prone to extreme physical attacks.
What are the benefits of a remote zoom and focus lens on a dome?
Traditional domes require physical configuration on a ladder during install. The AXIS Q3546-LVE features a motorized varifocal lens, allowing security integrators to adjust both the optical zoom and pixel-perfect focus entirely through the camera's web console.
Can this camera operate in severe sub-zero climates?
Yes. Built with robust climate control systems, an integrated window heater, and weather-proof sealing, the AXIS Q3546-LVE functions flawlessly at operational temperatures ranging from -50 °C to 60 °C (-58 °F to 140 °F).
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS P13 SERIES · NDAA & TAA COMPLIANT
Enterprise Fixed Box Surveillance Powered by Advanced Deep Learning
The AXIS P1388-LE is a top-tier, outdoor-ready 8MP 4K fixed box camera built for exceptional imaging and edge-based intelligence in commercial security environments. Running on the power of the AXIS ARTPEC-8 system-on-chip, this high-end device features a hardware-dedicated Deep Learning Processing Unit (DLPU). This native processing engine allows for incredibly precise object detection, classification, and metadata extraction, empowering system operators with fast forensic search capabilities and reducing system-wide false alarm events to a minimum.
Resolution
8MP 4K Ultra HD
Optics
3.9-10mm i-CS Lens
Night Vision
80m OptimizedIR
Protection
IP66/67, NEMA 4X, IK10
Intelligent i-CS Optics & Built-In Cybersecurity Protections
The AXIS P1388-LE is equipped with an intelligent i-CS lens that enables automatic motorized zoom, focus, and aperture configuration, significantly speeding up installation and deployment. Under challenging lighting, Lightfinder 2.0 and Forensic WDR capture sharp, low-noise color details even in extreme near-darkness. For maximum platform security, Axis Edge Vault provides a hardware-based cyber protection suite featuring a secure cryptographic compute environment, FIPS 140-3 Level 3 certified secure storage, and a signed operating system.
Advanced Object Analytics on the Edge
The dedicated hardware DLPU facilitates highly granular AI computing right on-device. The pre-installed AXIS Object Analytics tool classifies humans and vehicles in real-time, delivering immediate alerts and rich metadata tagging while optimizing bandwidth and server CPU loads.
Adaptive Long-Range OptimizedIR
OptimizedIR dynamically adjusts the width and spread of its infrared beam to match the current zoom angle of the i-CS lens. It delivers clear night-vision illumination across open environments up to 80 meters (262 feet) without causing foreground washout.
Technical Specification Matrix
Camera Model
AXIS P1388-LE
Image Sensor Size
Premium 1/1.2" progressive scan RGB CMOS
Lens & Focal Length
Varifocal, i-CS, 3.9–10 mm, F1.5, Remote Zoom & Focus, P-iris, IR corrected
Field of View
Horizontal: 111° to 47°, Vertical: 61° to 27°
System on Chip
ARTPEC-8 with Deep Learning Processing Unit (DLPU)
Video Compression
H.265 (Main Profile), H.264 (Baseline/Main/High), Motion JPEG with Zipstream
Max Resolution & Frame Rate
3840x2160 (8 MP 4K) @ 25/30 fps (WDR on) or up to 50/60 fps (WDR off)
Power Specifications
PoE (IEEE 802.3af/at Type 1 Class 4), Max 19.1 W; or 12–28 V DC input, Max 18.2 W
Casing Protection
IP66, IP67, NEMA 4X, and IK10 vandal-resistant aluminum housing
Onboard Security
Axis Edge Vault, FIPS 140-3 Level 3 certified secure key storage, Signed OS, Secure Boot
Technical Datasheet Repainting Instructions
Operation Manual Installation Manual
Frequently Asked Questions
Is the AXIS P1388-LE NDAA compliant for security deployment?
Yes. The AXIS P1388-LE is fully NDAA (National Defense Authorization Act) and TAA (Trade Agreements Act) compliant. It meets all federal, military, and critical infrastructure regulations, allowing it to be safely proposed for major government tenders.
What are the main benefits of an intelligent i-CS lens?
The i-CS (intelligent CS-mount) lens communicates directly with the AXIS P1388-LE to exchange metadata like focal length, zoom position, and optical distortion factors. This enables automated remote zoom and focus, fast automatic camera setup, and simplified electronic image stabilization.
Can the lens on the AXIS P1388-LE be replaced if required?
Yes. Because it is a modular, CS-mount fixed box camera design, the pre-installed 3.9-10 mm lens can be swapped with other compatible CS-mount or i-CS zoom and telephoto lenses depending on your specialized viewing distance requirements.
What temperature ranges can this outdoor-ready camera withstand?
Equipped with an integrated heater and internal climate control, the rugged IP66/67-rated enclosure ensures complete functionality in extreme weather conditions ranging from -40 °C to 60 °C (-40 °F to 140 °F).
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS C-SERIES · NDAA & TAA COMPLIANT
Convert Passive Speakers Into Smart Network Audio Systems
The AXIS C8210 Network Audio Amplifier is a compact, smart migration tool that bridges the gap between traditional analog audio and modern IP technology. By delivering up to 15W of high-quality digital audio, it transforms any passive speaker—regardless of brand—into a fully feature-rich network speaker. Ideal for commercial offices, retail outlets, educational institutions, and healthcare facilities, this intelligent amplifier deploys easily on existing networks to provide zoned background music, clear voice announcements, and scheduled audio paging.
Power Output
15W Class D
Connectivity
PoE / PoE+
Software
Audio Edge
Compliance
NDAA & TAA
Advanced Edge-Based Intelligence and Integration
Built on open IP standards, the AXIS C8210 provides robust integration pathways with leading Video Management Systems (VMS), VoIP protocols (using SIP), and unified network infrastructure. With built-in features such as an internal pre-configured equalizer, onboard microSD slot for edge-storage playback, and customizable I/O ports for physical trigger sensors, this amplifier acts as an all-in-one system controller. Its network compliance ensures zero reliance on proprietary servers, allowing your enterprise to manage multi-zone audio streaming directly from a local interface.
All-In-One Audio Edge Management
Comes pre-installed with AXIS Audio Manager Edge, enabling decentralized control over zones, volume parameters, scheduling presets, and user permissions without requiring an external controller license.
Proactive Device Health Monitoring
Supports automated microphone-free testing via impedance verification and network pings, alerting your administrative dashboard instantly if a passive speaker connection becomes disconnected or degraded.
Technical Specification Matrix
Camera Model
AXIS C8210
Amplifier Technology
Built-in Class D digital amplifier
Power Output
15W with PoE+ (Class 4) / 7W with PoE (Class 3)
Supported Speakers
Passive speakers (Minimum impedance 4-16 Ohms)
Network Audio Protocols
SIP (VoIP/IP-PBX integration), RTP/RTSP, Axis Audio Streaming
Edge Storage
microSD/microSDHC/microSDXC card slot (up to 128 GB supported)
Power Input
Power over Ethernet (PoE) IEEE 802.3af/at Type 1 Class 3/Type 2 Class 4
Audio Processing
Configurable High-pass filter, Equalizer, Dynamic Range Control
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Can I use any third-party passive speaker with the AXIS C8210?
Yes. The AXIS C8210 is designed to work with any 4 to 16 Ohm passive speaker, regardless of brand, transforming it directly into a network speaker.
Is the audio management software included for free?
Absolutely. The device comes pre-installed with AXIS Audio Manager Edge, giving you full control of scheduling, volume, zones, and playlists without additional license costs.
How is the unit powered?
The unit is powered via Power over Ethernet (PoE). For full 15W output power performance, PoE+ (IEEE 802.3at Type 2 Class 4) is highly recommended.
Does this amplifier support standard SIP/VoIP systems?
Yes. It supports SIP protocols for direct registration with PBX and VoIP telephony environments, letting you page speakers using IP phones.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS P14 SERIES · NDAA & TAA COMPLIANT
Intelligent, Long-Range Surveillance Powered by Next-Gen AI
The AXIS P1485-LE is a robust, high-performance outdoor bullet camera engineered specifically for demanding commercial applications that require long-range detection and forensic detail. Operating on the cutting-edge AXIS ARTPEC-9 system-on-chip, this advanced camera integrates a dedicated Deep Learning Processing Unit (DLPU) to run next-generation edge analytics with supreme accuracy. From high-speed traffic monitoring to secure perimeter enforcement, its telephoto varifocal lens captures crystal-clear video across extensive areas under any light condition.
Resolution
2MP Full HD (1080p)
Optics
10.8-28.2mm Telephoto
Night Vision
80m OptimizedIR
Protection
IP66/67 & IK10 Rated
State-of-the-Art Imaging Technologies & Efficient Compression
Engineered with exceptional low-light technology, the AXIS P1485-LE features Lightfinder 2.0 and Forensic WDR to provide color accuracy and clear, high-contrast imagery even when facing extreme differences in dark and light areas. Through the incorporation of the next-gen AV1 video codec and Axis Zipstream, this system actively optimizes bandwidth and storage footprints without compromising crucial image details. It is also packed with Axis Edge Vault, a hardware-based cybersecurity platform that ensures secure key storage, secure boot, and a signed operating system.
Deep Learning Processing Unit (DLPU)
The hardware-integrated DLPU enables highly granular object classification directly at the edge. AXIS Object Analytics accurately distinguishes humans and vehicles, allowing administrators to customize trigger criteria, reduce false alarms, and streamline forensic search operations.
Long-Range OptimizedIR Illumination
OptimizedIR adapts the angle of illumination as the remote optical zoom modifies its focal length. Delivering even illumination in complete darkness up to 80 meters (262 feet) or more, this technology prevents overexposure of close-up objects while exposing distant threats.
Technical Specification Matrix
Camera Model
AXIS P1485-LE
Image Sensor
1/2.8" progressive scan RGB CMOS
Lens & Focal Length
Varifocal, 10.8–28.2 mm, F1.7–1.76, Remote Zoom & Focus, P-iris, IR corrected
Field of View
Horizontal: 29.4° to 11°, Vertical: 16.5° to 6.3°
System on Chip
ARTPEC-9 with Deep Learning Processing Unit (DLPU)
Video Compression
AV1, H.265 (Main Profile), H.264 (Baseline/Main/High), Motion JPEG with Zipstream
Max Resolution & Frame Rate
1920x1080 (2 MP) @ 50/60 fps (WDR off) or 25/30 fps (WDR on)
Power Supply
PoE (IEEE 802.3af/at Type 1 Class 3), Max 12.95 W; or 10–28 V DC input, Max 12.95 W
Casing Rating
IP66/67, NEMA 4X, and IK10 impact-resistant aluminum and polycarbonate casing
Cybersecurity
Axis Edge Vault, FIPS 140-3 Level 3 certified secure key storage, Signed OS, Secure Boot
Technical Datasheet
Repainting Instructions
Operation Manual
Installation Manual
Is the AXIS P1485-LE compliant with government security procurement standards?
Yes. The AXIS P1485-LE is fully NDAA (National Defense Authorization Act) and TAA (Trade Agreements Act) compliant, making it highly eligible and secure for federal, government, and commercial mission-critical infrastructure deployments.
What are the key benefits of the ARTPEC-9 system-on-chip with AV1?
The ARTPEC-9 SoC accelerates deep learning algorithms directly on the device. By incorporating the license-free AV1 codec alongside Axis Zipstream, the camera dramatically lowers bitrate, bandwidth overhead, and storage costs while retaining high-fidelity visual evidence.
How does the telephoto lens affect target identification at long distances?
With a focal length range of 10.8mm to 28.2mm, this telephoto lens offers narrower fields of view (down to 11° horizontal) that pull distant subjects closer. This optical magnification allows for high-pixel-density captures at great ranges, which is ideal for license plate recognition and vehicle verification.
Can this camera withstand harsh outdoor environments?
Absolutely. It features an IP66, IP67, and NEMA 4X weather-proof rating to protect against water, dust, and corrosion. Additionally, its IK10-rated vandal-resistant casing resists physical tampering, and it starts up reliably in temperatures as low as -40 °C (-40 °F).
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS C SERIES · NDAA & TAA COMPLIANT
Next-Generation Audio Integration with 4K Video Capability
The AXIS C6110 redefines the boundary between network audio and high-definition visual surveillance. Engineered specifically for high-density commercial spaces, modern corporate campuses, and smart retail ecosystems, this premium micro-console allows organizations to combine two-way SIP audio communication with crisp, overview video. Its ultra-compact form factor blends seamlessly into any architecturally sensitive environment, ensuring your premises remain secure, communicative, and operationally intelligent without drawing unnecessary attention.
Resolution
4K UHD Resolution
Optics
Fixed Overview Lens
Audio Support
Two-Way SIP Built-In
Climate Ready
Premium Indoor Rating
Advanced Edge Analytics and Unified SIP Interoperability
Beyond standard edge recording, the AXIS C6110 leverages an advanced system architecture capable of running complex deep learning applications on the edge. This provides operators with high-fidelity sound profiling and proactive visual trigger matrices. By natively supporting open standards such as SIP, this micro-console acts as an intelligent bridge, routing audio alerts directly into unified IP telephony systems or central video management platforms, lowering infrastructure overhead and optimizing day-to-day operations.
High-Definition Visual Context
Delivers continuous, ultra-sharp 4K overview feeds that provide vital contextual information alongside audio notifications, eliminating blind spots during critical communications.
Seamless Audio Communication
Features embedded two-way audio components utilizing open SIP protocols for crystal-clear paging, interactive customer assistance, or direct live operator deterrents.
Technical Specification Matrix
Camera Model
AXIS C6110
Video Resolution
Up to 3840x2160 (4K UHD)
Audio Integration
Built-in microphone and speaker, full duplex, SIP support
Compression Standards
H.264, H.265, Motion JPEG via Axis Zipstream
Power Supply
Power over Ethernet (PoE) IEEE 802.3af/802.3at
Edge Storage
microSD/microSDHC/microSDXC card slot with encryption support
Security Protocols
Password protection, HTTPS encryption, IEEE 802.1X, Axis Edge Vault
Compliance
NDAA Compliant, TAA Certified
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Is the AXIS C6110 fully compliant with local federal procurement requirements?
Yes. The AXIS C6110 is fully NDAA and TAA compliant, making it approved for deployment in corporate, government, and high-security enterprise projects subject to strict supply chain regulations.
Does this console require dedicated power cabling?
No, the unit functions utilizing Power over Ethernet (PoE). This allows both data communication, 4K video transport, and audio capabilities to run over a single standard Category network cable.
Can the built-in SIP capabilities connect directly to a corporate VoIP network?
Absolutely. It utilizes open SIP standards, allowing integration into major IP telephony and PBX systems for direct calls, paging routing, and interactive communication.
How does Axis Zipstream technology help the C6110 manage 4K video feeds?
Axis Zipstream analyzes the video feed in real-time, compressing background noise and static areas while preserving critical photographic details. This lowers storage and bandwidth costs up to 50% without reducing clarity.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS AUDIO · NDAA & TAA COMPLIANT
Professional Close-Range Voice Pickup for Critical Paging Environments
The AXIS TC6901 Gooseneck Microphone is an engineered audio solution purpose-built for commercial, industrial, and high-density operational centers. Explicitly designed to integrate seamlessly with the AXIS C6110 Network Paging Console, this premium accessory offers directional sound isolation when deployed in noisy operational environments like transport hubs, education centers, control rooms, and retail service desks. By capturing high-intelligibility speech at close range, it circumvents ambient background noise, ensuring critical announcements remain crystal clear.
Polar Pattern
Cardioid Directional
Frequency Profile
40 Hz – 16 kHz
Dynamic Range
100 dB Sensitivity
Climate Ready
-20 °C to 60 °C
Advanced Acoustic Engineering & Seamless Hardware Deployment
Beyond standard paging hardware, the microphone employs a premium electret condenser bias core with active balanced output capabilities, achieving an impressive 100 dB dynamic range. This allows operators to convey natural, uncompressed voice audio even during high-pressure alerts. To optimize deployment, explore how this hardware links into broad IP audio ecosystems via the axis-tc6901-gooseneck-microphone-ndaa-compliant infrastructure, utilizing standard XLR connection paths coupled with 11-48 V Phantom power options. Each unit ships as a complete kit incorporating a robust surface mount plate and a snap-fit foam windscreen to diminish plosives and environmental air currents.
Ergonomic Adjustability for Shared Desks
The highly flexible gooseneck mechanical chassis gives operators total control over physical positioning. Multi-user workstations, reception counters, and multi-shift security dispatch hubs can immediately adjust the capsule placement to align precisely with varying speaking heights, ensuring consistent audio capture metrics across teams.
Industrial Noise Suppression Architecture
Utilizing a hyper-precise cardioid acoustic directional pattern, the condenser capsule emphasizes the speaker directly in front of the lens while rejecting sound originating from peripheral areas. This eliminates echo feedback loops and ambient facility background clatter for elite transmission quality.
Technical Specification Matrix
Camera Model
AXIS TC6901
Microphone Type
Condenser (electret bias)
Polar Pattern
Cardioid Directional
Frequency Response
40 Hz – 16 kHz
Dynamic Range
100 dB (at 1 kHz, 1 kΩ load)
Max SPL
120 dB (1 kHz at 1% THD)
Power Interface
11–48 V XLR Phantom Power (< 5 mA draw)
Physical Dimensions
Length: 365 mm (14.4 in) / Weight: 72 g
Compliance & Security
NDAA Compliant, TAA Certified, RoHS, CE
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Is the AXIS TC6901 compatible with standard network switches directly?
No, the AXIS TC6901 is an analog XLR accessory designed to connect directly into the specialized XLR interface slot on the AXIS C6110 Network Paging Console or compatible Axis hardware featuring 11-48 V Phantom power support.
What are the key benefits of using this over the paging console's built-in mic?
The gooseneck extension offers dedicated close-range voice pickup. It is highly recommended for busy, noisy, or echo-prone environments, as its proximity to the mouth captures clear speech before room ambiance disrupts it.
Does this device ship with required mounting plates?
Yes, each AXIS TC6901 is delivered as a comprehensive deployment kit that incorporates both the matching permanent mount plate and a snap-fit foam windscreen.
Is this hardware rated for cold or extreme ambient setups?
Yes. The microphone is designed for highly resilient long-term commercial operation, featuring a reliable working thermal window spanning from -20 °C up to 60 °C (-4 °F to 140 °F).
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS P-SERIES · NDAA & TAA COMPLIANT
Ultra HD 4K Resolution and Next-Gen ARTPEC-9 Intelligence
The AXIS P3288-LV represents a major leap in premium indoor video surveillance, combining pristine 4K resolution with the massive edge-processing power of the ARTPEC-9 system-on-chip. Built specifically for high-stakes indoor environments—such as corporate banking floors, spacious commercial lobbies, retail showrooms, and transit terminals—this fixed dome camera delivers flawless forensic detail. Its high-density sensor captures crisp facial metrics and transaction variables even at extensive digital zoom depths, providing operations with unmatched clarity.
Resolution
4K Ultra HD
Optics
Varifocal Remote Zoom
Night Vision
OptimizedIR (40m)
Protection
IK10 Vandal Rated
Multidimensional Analytics Processing and Advanced AV1 Coding
Equipped with an optimized Deep Learning Processing Unit (DLPU), the AXIS P3288-LV streamlines security protocols by classifying objects locally on the edge. It features preinstalled AXIS Object Analytics to accurately isolate people, vehicles, and custom object categories, virtually eliminating false alarms from fluctuating indoor reflections or lighting transitions. Elevating overall awareness, an integrated acoustic sensor powers AXIS Audio Analytics to instantly pinpoint screams, glass breakage, or vocal aggression outside the lens viewpoint. Crucially, massive 4K visual data sets are compressed using next-generation AV1 and H.265 protocols via Axis Zipstream, preserving local storage limits while locking in raw forensic clarity.
Lightfinder 2.0 & Forensic WDR Alignment
By synchronizing Axis Lightfinder 2.0 with Forensic WDR capabilities, the system maintains accurate color presentation across dim architectural interiors and filters out localized bright glare. Moving targets traversing highly contrasted shadow lines remain clean and readable for post-incident review panels.
Axis Edge Vault Cryptographic Defense
Embedded with the secure Axis Edge Vault platform, the camera incorporates a certified cryptographic hardware compute module to intercept unauthorized access. It handles automatic credential encryption, signed device firmware packages, and secure boot sequences to completely guard network communication lines.
Technical Specification Matrix
Camera Model
AXIS P3288-LV
System on Chip (SoC)
ARTPEC-9 with Deep Learning Processing Unit (DLPU)
Image Sensor Element
1/2.8" Progressive Scan RGB CMOS
Max Video Resolution
3840x2160 (4K Ultra HD) at up to 50/60 fps
Lens Configuration
Varifocal, Remote Focus and Zoom adjustment, P-Iris Control
Infrared Capacity
OptimizedIR power up to 40 meters (130 feet) coverage radius
Chassis Protection
IK10 Vandal-Resistant Indoor Structural Polycarbonate/Aluminum Casing
Audio Capabilities
Built-in acoustic sensor for pre-loaded AXIS Audio Analytics
Technical Datasheet Quick Start Guide
Operation Manual Installation Manual
Frequently Asked Questions
What spatial advantages does the 4K sensor bring to indoor monitoring?
4K resolution delivers four times the pixel detail of standard 1080p hardware. This allows security operators to digitally zoom into deep target areas to identify clothing patterns, transaction currency, and crisp facial traits without pixel degradation.
How does the integrated acoustic sensor assist indoor operators?
The integrated acoustic sensor unlocks sound classification features straight out of the box. The on-board ARTPEC-9 AI engine identifies acoustic anomalies—such as shouting, aggressive calling, or breaking display glass—triggering automated system alarms even if the disturbance is completely out of frame.
What differentiates the "LV" from the "LVE" configuration?
The standard "LV" designation signifies an optimized indoor model housed in a low-profile, sleek structural frame with an IK10 impact score. The "LVE" model introduces external heavy weatherproofing gaskets and NEMA 4X shell ratings specifically optimized for direct outdoor placement.
Does the AXIS P3288-LV support modern security compliance standards?
Yes. The AXIS P3288-LV conforms entirely with the National Defense Authorization Act (NDAA) and Trade Agreements Act (TAA) guidelines, rendering it completely authorized for use in federal arrays and corporate enterprise deployments.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS TQ5001-E · NDAA & TAA COMPLIANT
Ruggedized Mounting Excellence for Enterprise Surveillance
The AXIS TQ5001-E delivers an ultra-robust, commercial-grade mounting solution engineered specifically for high-performance AXIS PTZ and multi-sensor cameras. Built from impact-resistant, premium aluminum casing, this versatile mount simplifies high-density outdoor deployments. By integrating a reversible mounting bracket, field technicians can easily transition between wall-mounted facades and freestanding pole structures without purchasing separate brackets. It is the ultimate accessory for high-security environments, critical infrastructure, transport hubs, and public surveillance projects where structural integrity is non-negotiable.
System Integration
PTZ & Multi-Sensor
Optics Bracket
Reversible Wall/Pole
Weatherproofing
IP66 RJ45 Cable
Vandal Protection
IK10 Impact Rating
Advanced In-Field Termination & Seamless Installation
Engineered to mitigate common installation points of failure, the AXIS TQ5001-E Wall and Pole Mount features a dual-connection path using either an RJ45 connector or an insulation-displacement contact (IDC) terminal block. A pre-installed internal cable with an IP66-rated Ethernet coupler ensures a hermetic, moisture-free seal inside the camera assembly, preventing environmental decay and long-term signal loss. From sub-zero industrial environments to scorching coastal perimeters, this mounting system maintains structural load support up to 40 kg, preserving the stability required for advanced PTZ tracking and analytics.
Dual-Purpose Reversible Chassis
Eliminate project planning complexity and reduce warehouse SKU overhead. A simple inversion of the primary bracket lets installers pivot from architectural flat-wall mounting to round-pole installation with marine-grade steel straps.
Military-Grade Environmental Protection
Boasting IK10 mechanical impact resistance, IP66 ingress sealing, and MIL-STD-810G salt spray compliance, the marine-ready powder-coated aluminum casing is built to withstand direct impacts and extreme corrosion forces.
Technical Specification Matrix
Camera Mount Model
AXIS TQ5001-E
Casing Material
IP66-, NEMA 4X- and IK10-rated white powder-coated aluminum (NCS S 1002-B)
Compatible Series
AXIS M5000, M55, P56, Q37, Q60, Q61, and Q63 Series PTZ & Multi-sensor cameras
Connectivity Options
Output: IP66 RJ45 Ethernet (male) | Input: RJ45 Ethernet (female) & IDC (insulation-displacement contact)
Maximum Load Capacity
40 kg (88.2 lb)
Operating Temperature
-50 °C to 65 °C (-58 °F to 149 °F) | Humidity: 10–100% RH (non-condensing)
Weight & Dimensions
1960 g (4.3 lb) | Profile: 291.8 mm x 175.4 mm (11.49" x 6.90")
Sourcing Compliance
NDAA Compliant & TAA Compliant (GSA Approved)
Warranty
AXIS 5-Year Comprehensive Warranty
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Is the AXIS TQ5001-E suitable for pole installation out of the box?
Yes, the bracket itself is reversible to accommodate poles. However, please note that you will need separate stainless steel pole straps (such as AXIS Steel Straps TX30) to firmly lash the assembly to structural columns.
What is the purpose of the IDC connection option?
The IDC (insulation-displacement contact) connector offers versatile wiring flexibility. Installers can easily punch down raw field Ethernet cables directly inside the bracket without having to crimp an RJ45 jack in restricted overhead environments.
Does this mount include environmental protection against rain and storms?
Absolutely. It features a built-in cable with an IP66-rated Ethernet connection collar. This forms an airtight and watertight seal when connected to compatible Axis network PTZ dome cameras.
Is this mount GSA schedule eligible and compliant with federal procurement?
Yes. The AXIS TQ5001-E is fully TAA and NDAA compliant, making it eligible for integration into US government buildings, military installations, and critical municipal network architectures.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS TP SERIES · NDAA & TAA COMPLIANT
Seamless Aesthetic Integration for Premium Fixed Dome Security
The AXIS TP3101 Pendant Wall Mount revolutionizes interior surveillance installations by delivering a clean, pendant-style configuration for premium indoor mini domes without requiring cumbersome, multi-piece pendant kits. Architecturally optimized for commercial high-density environments, retail storefronts, corporate receptions, and healthcare institutions, this mount features a professional contemporary design that effortlessly transforms security infrastructure into a cohesive element of your interior architecture. By enabling precise positioning, the mount maximizes the efficacy of advanced edge-based retail analytics like high-accuracy people counting and automated face recognition at critical access points.
Mounting Style
Pendant Wall/Ceiling
Optics Alignment
Multi-Directional
Target Placement
Retail & Entrances
Protection Rating
Concealed Anti-Tamper
Advanced Hardware Concealment & Integrated Connectivity
Engineered for high-security environments where visual presentation is paramount, the AXIS TP3101 Pendant Wall Mount eliminates unsightly external wiring infrastructure. The impact-resistant casing is completely paintable to seamlessly match proprietary interior design themes or corporate color schemes. Beyond its sleek aesthetics, the mount contains a spacious internal, ingress-protected accessory compartment designed to safeguard secondary connectivity hardware. System integrators can deploy auxiliary modules directly at the device endpoint—including audio interfaces, standalone microphones, deterrent LEDs, or PoE-over-Coax compact extenders—keeping the hardware secure, unified, and protected from physical tampering.
Concealed Cabling & Anti-Tamper Hardware
Features an innovative architecture that completely routes and hides cabling within the inner structure while fully masking mounting screws behind a snap-on cover. This minimizes physical vulnerabilities, limits tampering risks, and provides a polished, ultra-clean commercial aesthetic required for luxury retail, enterprise lobbies, and corporate offices.
Smart Compartment for Edge Accessories
The integrated internal service bay accommodates critical performance-expanding accessories directly at the camera node. Installers can seamlessly tuck away AXIS T61 Series audio/IO interfaces, high-fidelity microphones, AXIS deterrent LEDs, or coax migration modules without adding cluttered external equipment enclosures.
Technical Specification Matrix
Camera Mount Model
AXIS TP3101
Supported Products
AXIS M32 Series, AXIS P32 Series, AXIS M4308-PLE, M4317/M4318 Panoramic Series
Casing Material
PC-ABS Blend Cover; Glass-Fibre Reinforced Polyamide Bottom Bracket
Color & Finish
White NCS S 1002-B (Repaintable in any color)
Dimensions
204 mm x 148 mm x 42 mm (8.0" x 5.8" x 1.7")
Weight
228 g (0.50 lb)
Maximum Load Capacity
3 kg (6.6 lbs)
Operating Environment
Indoor Operational Range: -10 °C to 50 °C (14 °F to 122 °F)
Sustainability Compliance
PVC-Free Construction, 22% Recycled Plastics
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Does the AXIS TP3101 require an additional pendant kit to mount dome cameras?
No. The AXIS TP3101 is explicitly designed to enable complete, clean pendant-style mounting natively for compatible AXIS dome cameras. This eliminates the need to source or configure separate pendant adapters, reducing hardware costs and installation complexity.
Can this mount be deployed on surfaces other than a standard vertical wall?
Yes. Due to its flexible design, it can be mounted directly on vertical walls, hard ceilings, desktops, or checkout countertops. It is also fully compatible with junction boxes when paired with the optional AXIS TP3701 J-Box & Pole Adapter accessory.
What accessories can safely fit inside the built-in storage compartment?
The integrated internal, ingress-protected space is designed to hold the AXIS T6101 Audio and I/O Interface, AXIS Device Microphone A or B, the AXIS I/O Indication LED deterrent device, or the AXIS T8643 PoE+ over Coax Compact unit.
Is the plastic casing safe to paint for custom commercial color matching?
Yes. The exterior cover is crafted from a high-quality, eco-friendly PC-ABS blend that can easily be repainted in any color to allow the finished installation to blend seamlessly with surrounding architecture.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS P-SERIES · NDAA & TAA COMPLIANT
Ultra HD 4K Clarity and Intelligent Edge Analytics for Challenging Environments
The AXIS P3278-LVE sets a benchmark for outdoor surveillance excellence, delivering pristine 4K resolution across complex commercial sites and industrial zones. Housed in a heavily ruggedized, weather-proof, and impact-resistant casing, this dome camera is engineered to excel in high-density perimeter zones, shipping terminals, and corporate campus exterior walls. Its high-resolution matrix captures minuscule target characteristics flawlessly, ensuring exceptional details even under unpredictable outdoor lighting conditions.
Resolution
4K Ultra HD
Optics
Varifocal Remote Zoom
Night Vision
OptimizedIR (40m)
Protection
IP66 / IK10 Rated
Deep Learning Infrastructure and High-Efficiency Data Management
Equipped with an advanced Deep Learning Processing Unit (DLPU), the AXIS P3278-LVE performs sophisticated target tracking and filtering natively on the edge. It features AXIS Object Analytics to accurately distinguish between pedestrians, vehicles, and varied asset subsets, significantly filtering out false triggers like swaying foliage or birds. To manage massive 4K streams sustainably, built-in Axis Zipstream technology supports H.264 and H.265 compression, maintaining crucial forensic details while shrinking network storage footprints.
Lightfinder 2.0 & Forensic WDR Alignment
By blending Axis Lightfinder 2.0 with high-performance Forensic WDR, the system ensures vibrant color depth in near-pitch darkness and filters intense blinding reflections. Moving targets transiting across highly contrasted exterior building shadows remain crisp for quick identification.
Hardened Cyber Defense with Edge Vault
Embedded with the Axis Edge Vault platform, the camera incorporates a secure cryptographic hardware element to prevent unauthorized intrusions. It coordinates signed device firmware packages, a secure boot process, and tamper-proof device identity keys to safeguard network communication lines.
Technical Specification Matrix
Camera Model
AXIS P3278-LVE
Image Sensor Element
1/2.8" Progressive Scan RGB CMOS
Max Resolution
3840x2160 (4K Ultra HD) at up to 30 fps
Lens Configuration
Varifocal, Remote Focus and Zoom, P-Iris Control Matrix
Low Light Processing
Lightfinder 2.0 with Forensic Wide Dynamic Range (WDR)
Infrared Capacity
OptimizedIR power up to 40 meters (130 feet) coverage radius
Chassis Protection
IP66 Weatherproof, NEMA 4X Grade, IK10 Vandal Structural Rating
Intelligence Chip
On-board Deep Learning Processing Unit (DLPU) architecture
Technical Datasheet Quick Start Guide
Operation Manual Installation Manual
Frequently Asked Questions
What distinguishes the "LVE" from the standard "LV" variant?
The "E" suffix stands for "Environmental." While the standard LV camera is optimized for indoor or sheltered spaces, the P3278-LVE features an outdoor-ready casing with IP66, IP67, and NEMA 4X certifications to protect against extreme weather, water ingress, and corrosion.
How does OptimizedIR adjust for different fields of view?
Axis OptimizedIR automatically syncs the angle of the infrared illumination with the mechanical zoom level. This prevents illumination hot-spots when zoomed into far-off assets and guarantees seamless light dispersion when set to wide viewing angles.
Can this camera withstand heavy impacts and external vandalism?
Yes. The P3278-LVE is enclosed in an IK10-rated vandal-resistant aluminum structure, designed to withstand up to 20 joules of impact. It also features electronic tampering alarms that alert the control center if the camera is spray-painted or redirected.
Is the AXIS P3278-LVE certified for government contracts?
Absolutely. This device complies fully with the National Defense Authorization Act (NDAA) and the Trade Agreements Act (TAA), making it completely approved for use in federal infrastructure, military bases, and high-security enterprise systems.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS T91B51 · NDAA & TAA COMPLIANT
Resilient Low-Ceiling Surveillance Infrastructure
The AXIS T91B51 Ceiling Mount provides a high-density, ruggedized structural installation base optimized for low-clearance environments, commercial warehouses, loading docks, and roof overhangs. Designed to preserve hardware integrity, it effortlessly secures high-performance AXIS PTZ and fixed dome cameras close to the ceiling architecture to mitigate the risks of accidental physical contact in busy operational zones.
Mount Interface
1.5" NPS Thread
Swivel Action
±45° Pivot Angle
Load Capacity
10 kg (22 lbs)
Protection Rating
IK10 & NEMA 4X
Advanced Impact Mitigation & Sloped Ceiling Adaptability
Engineered to absorb severe structural forces without structural failure, the AXIS T91B51 incorporates an integrated ball-joint mechanism that allows the mount to swing dynamically if accidentally struck by forklifts, tall vehicles, or industrial equipment. This unique feature protects both the internal camera electronics and the building ceiling structure from costly permanent damage. Furthermore, its physical design ensures the camera remains completely straight and perpendicular when installed on sloped ceilings or uneven roof overhangs, neutralizing complex architectural constraints.
Safety Swivel Innovation
Rather than providing a rigid point of failure, the internal ball joint enables a controlled ±45° pivot path. If impacted by moving facility machinery, it safely yields and swings, instantly preventing catastrophic shear strain on hardware and mounts.
Extreme-Duty Corrosion Defense
Constructed from marine-grade powder-coated aluminum, the unit achieves official NEMA 4X and IK10 ratings. It provides rugged defense against high-energy physical impacts, salt spray, moisture, and extreme environmental deterioration.
Technical Specification Matrix
Camera Model
AXIS T91B51
Part Number
5507-461
Thread Interface
1.5" NPS thread standard
Maximum Mechanical Load
10 kg (22 lbs)
Pivot Angle Bounds
±45° dynamic deflection
Casing Material
Powder-coated aluminum alloy
Impact Resistance
IK10 Vandal-resistant certified
Environmental Resistance
NEMA 4X corrosion-resistant
Dimensions & Weight
Length: 104 mm (4 in) | Weight: 1.2 kg (2.6 lb)
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
What exact cameras are natively supported by this mount?
The AXIS T91B51 natively supports all Axis PTZ dome cameras and outdoor models of Axis fixed domes that use a standard 1.5” NPS thread interface. Certain configurations require model-specific pendant kits.
Can the hanging length be extended for high-ceiling facilities?
Yes. If a longer drop profile is required for your setup, the base unit is fully compatible with optional AXIS T91B52 extension pipes available in 30 cm (12 in) and 100 cm (39 in) variations.
How does the swivel action mechanism prevent asset damage?
Instead of acting as a rigid bracket that breaks or warps when hit, the internal ball joint yields up to ±45 degrees under mechanical force. This prevents structural damage to the ceiling surface and minimizes shock to the camera.
Is this hardware rated for corrosive or maritime outdoor use?
Absolutely. With its premium powder-coated aluminum construction and NEMA 4X classification, this mount is fully protected against corrosion, extreme moisture, and industrial salt spray.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS T-SERIES · NDAA & TAA COMPLIANT
Industrial-Grade Structural Integration for Fixed Camera Housings
The AXIS T94Q01F Ceiling-and-Column Mount offers premier architectural flexibility for demanding commercial surveillance environments. Constructed from heavy-duty powder-coated aluminum, this mount supports critical infrastructure by adapting seamlessly to both ceiling/soffit overhead positions and column/parapet vertical terminations. Engineered to sustain stability across high-density logistics hubs, transit terminals, and exposed industrial facades, it provides a stable foundation that guarantees optimal camera positioning and clear video verification year after year.
Resolution
Fixed Housing Fit
Optics
Swivel & Tilt Arm
Night Vision/PTZ
360° Manual Pan
Protection
IK10 & NEMA 4X
Advanced Protection and Streamlined Vandal-Resistant Engineering
Beyond its rugged physical presence, this system prioritizes internal security protocols through a completely enclosed cable management architecture. By routing data and power links directly through the internal aluminum pipe, critical connections are never exposed to severe weather elements or potential physical tampering. System operators can easily maintain alignment adjustments using the integrated flexible swivel arm mechanism. For high-tier enterprise compliance deployments requiring verifiable infrastructure, integrating the AXIS T94Q01F ensures full adherence to strict governmental facility regulations while ensuring compatibility across a vast range of AXIS outdoor-ready box camera series.
Vandal-Proof Impact & Environmental Resilience
Certified with strict IK10 impact and NEMA 4X environmental ratings, this mount provides structural security against deliberate physical strikes, windblown dust, high-pressure water jets, and corrosive salt air sprays, making it ideal for marine or heavy industrial sites.
Omnidirectional Adjustment Flexibility
The specialized mechanical arm design supports a comprehensive 360-degree rotation, +25 to -65 degree tilt ranges, and a wide mechanical pan configuration. This lets technicians fine-tune fields of view during complex, tight-angle perimeter installations.
Technical Specification Matrix
Camera Mount Model
AXIS T94Q01F
Material Construction
Powder-coated aluminum casing (Color: White NCS S 1002-B)
Maximum Load Capacity
5.0 kg (11.0 lbs)
Mechanical Adjustments
Arm: 360° | Tilt: +25° to -65° | Pan: ±100°
Environmental Protection
NEMA 4X-rated weatherproofing, IK10-rated impact resistance
Cable Routing Design
Internal pipe routing with back cable hole and M25 3/4" side conduit entries
Supported Product Lines
AXIS T92E/T93F Series, M11-E/P13-E/Q16-E/Q1775-E Network Cameras
Compliance & Certifications
NDAA Compliant, TAA Compliant, IEC/EN/UL 60950-1, CE, REACH
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Is the AXIS T94Q01F mount fully compliant with federal procurement standards?
Yes. The AXIS T94Q01F is completely NDAA and TAA compliant, making it authorized for use in federal infrastructure, military installations, and highly secure commercial operational centers.
What housing series are directly compatible with this ceiling/column setup?
This mount is specifically engineered to hold standard fixed camera housings, including the AXIS T92E Series, AXIS T93F Series, and outdoor-ready box camera models like the M11-E, P13-E, Q16-E, and Q1775-E.
Does this mount include built-in conduit adapters for side cable routing?
The mount features integrated M25 3/4" side conduit entries. If side routing is required while maintaining full environmental seal integrity, standard AXIS ACI conduit adapters can be purchased separately.
How does internal cable management protect against localized vandalism?
Cables feed directly into the base mount and through the specialized internal structural cavity. This leaves no exposed external wiring that can be cut, pulled, or damaged by malicious actors.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS P-SERIES · NDAA & TAA COMPLIANT
Ultra HD 4K Clarity Mixed with Intelligent Deep Learning Analytics
The AXIS P3278-LV defines high-tier surveillance efficiency, offering pristine 4K resolution tailored for rigorous commercial infrastructure and high-traffic public domains. Housed within a robust, weatherproof, and vandal-resistant shell, this outdoor-ready fixed dome camera provides pristine environmental tracking over sprawling logistics areas, enterprise banking lobbies, and expansive retail floors. Its high-resolution matrix captures minuscule target characteristics flawlessly, empowering automated tools and operators with unparalleled structural evidence.
Resolution
4K Ultra HD
Optics
Varifocal Remote Zoom
Night Vision
OptimizedIR (40m)
Protection
IP66 / IK10 Shielded
Advanced Scene Adaptation & Edge-Calculated Object Filtering
Engineered with a dedicated Deep Learning Processing Unit (DLPU), the AXIS P3278-LV strips away metadata latency by classifying tracking instances directly on the camera. Running AXIS Object Analytics natively, the system accurately delineates humans, vehicles, and varied asset subsets to filter out common outdoor disturbances like moving shadows or animal presence. To preserve storage profiles against heavy 4K pixel arrays, embedded Axis Zipstream technology works intelligently with standard H.264 and H.265 infrastructure, isolating compression to static scenery pixels while retaining critical target visibility.
Lightfinder 2.0 & Forensic WDR Alignment
Blending Axis Lightfinder 2.0 and state-of-the-art Forensic WDR, the system ensures rich color depth in dark spaces and cleans high-glare blinding regions. Subjects transiting across erratic, heavily contrasted exterior areas remain perfectly readable during post-incident tracking panels.
Axis Edge Vault Hardened Defense
Incorporating Axis Edge Vault architecture, the device safeguards crucial stream assets at the edge. Utilizing a secure hardware block, it coordinates automated cryptographic verification keys, signed device firmware packages, and secure boot matrices to seal system nodes against external intruders.
Technical Specification Matrix
Camera Model
AXIS P3278-LV
Image Sensor Element
1/2.8" Progressive Scan RGB CMOS
Max Target Resolution
3840x2160 (4K Ultra HD) at up to 30 fps
Lens Configuration
Varifocal, Remote Focus and Zoom, P-Iris Control Matrix
Low Light Processing
Lightfinder 2.0 with Forensic Wide Dynamic Range (WDR)
Infrared Capacity
OptimizedIR power up to 40 meters (130 feet) coverage radius
Chassis Protection
IP66 Weatherproof, NEMA 4X Grade, IK10 Vandal Structural Rating
Intelligence Chip
On-board Deep Learning Processing Unit (DLPU) architecture
Technical Datasheet Quick Start Guide
Operation Manual Installation Manual
Frequently Asked Questions
What spatial advantages does 4K resolution bring to the AXIS P3278-LV?
4K resolution delivers four times the pixel density of standard 1080p setups. This provides exceptionally crisp digital cropping, enabling security systems to pull identifiable traits, license profiles, and facial metrics over a much larger visual region.
How does OptimizedIR technology mitigate image glare issues at night?
Axis OptimizedIR automatically syncs its beam spread pattern to match the motorized lens adjustments. As the camera zooms in or out, the infrared intensity actively shifts to avoid overexposing objects that approach the lens array.
Can this network camera operate safely inside freezing climates?
Yes. Engineered with ruggedized weatherproof shielding, the P3278-LV boasts IP66 and NEMA 4X performance scores. It is fully qualified to withstand heavy snow, frost, dust buildup, and structural wind forces seamlessly.
Is the camera compliant with US federal acquisition laws?
Absolutely. The AXIS P3278-LV fully meets the strict governance criteria outlined by the National Defense Authorization Act (NDAA) and Trade Agreements Act (TAA), making it completely approved for government infrastructure deployment.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
AXIS ACCESSORIES · NDAA & TAA COMPLIANT
Discreet High-End Integration for Enterprise Environments
The AXIS TM3201 Recessed Mount offers a premium, low-profile mounting alternative for indoor surveillance deployments. Specifically designed for high-density corporate environments, retail storefronts, and architectural projects where hardware visibility must be kept to a minimum, this mount allows compatible Axis dome cameras to be seamlessly embedded directly into drop ceilings or drywall panels. By shifting the form factor into a flush orientation, it helps maintain building aesthetics without compromising operational camera fields of view.
Mount Type
Recessed In-Ceiling
Optics Match
Axis Dome Series
Profile
Ultra Low-Profile
Protection
Indoor Secured
Architectural Adaptability and Hardware Integrity
Engineered to satisfy stringent interior design specifications, the AXIS TM3201 Recessed Mount simplifies physical cable management while maintaining stable sensor orientation. By reducing the physical footprint that extends past the ceiling plane, the kit effectively mitigates the risks of accidental physical impacts or line-of-sight tampering. It provides an ideal framework for multi-camera rollouts inside enterprise offices, banking lobbies, and high-end hospitality venues where standard surface mounts disrupt the ceiling flow.
Flush Professional Finish
Transforms standard protruding dome cameras into highly recessed, visually clean installations that align flawlessly with corporate design guidelines and modern ceiling layouts.
Simplified Assembly Path
Designed with modular installation components to accelerate multi-device site handovers, reducing labor overhead for large enterprise security deployments.
Technical Specification Matrix
Camera Model
AXIS TM3201
Mounting Type
Recessed In-Ceiling Kit
Environment
Indoor Use Only
Color Option
White / Paintable Blend
Material Structure
High-quality impact polymer / alloy components
Compliance
NDAA Compliant, TAA Compliant
Technical Datasheet
Quick Start Guide
Operation Manual
Installation Manual
Is the AXIS TM3201 compatible with outdoor installations?
No, the AXIS TM3201 is optimized and rated exclusively for indoor drop-ceiling or interior drywall mounting environments.
Can the visible trim ring of the mount be custom painted?
Yes, the structural trim components are designed so they can be carefully painted to match custom interior colors or specific architectural color schemes.
Is this accessory completely NDAA and TAA compliant?
Yes, like the majority of professional AXIS hardware lines, this product meets all federal criteria for NDAA and TAA supply chains.
Does the mount include integrated cable management routes?
Yes, the structural layout provides clean pathways to route and hide networking cables up into the ceiling plenum securely.
Official AXIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
